Instruction Manual

Instruction manuals (PDF files) and software can be downloaded from the Canon website (p.4, 311).

www.canon.com/icpd

ENGLISH

Introduction

The EOS 4000D is a digital single-lens reflex camera featuring a fine-detail CMOS sensor with approx. 18.0 effective megapixels, DIGIC 4+, high-precision and high-speed 9-point AF, approx.

3.0 shots/sec. continuous shooting, Live View shooting, Full High-Definition (Full HD) movie shooting, and Wi-Fi (wireless communication) function.

Before Starting to Shoot, Be Sure to Read the Following

To avoid botched pictures and accidents, first read the “Safety Instructions” (p.20-22) and “Handling Precautions” (p.23-25). Also, read this manual carefully to ensure that you use the camera correctly.

Refer to This Manual while Using the Camera to Further Familiarize Yourself with the Camera

While reading this manual, take a few test shots and see how they come out. You can then better understand the camera. Be sure to store this manual safely, too, so that you can refer to it again when necessary.

Testing the Camera Before Use and Liability

After shooting, play images back and check whether they have been properly recorded. If the camera or memory card is faulty and the images cannot be recorded or downloaded to a computer, Canon cannot be held liable for any loss or inconvenience caused.

Copyrights

Copyright laws in your country may prohibit the use of your recorded images or copyrighted music and images with music in the memory card for anything other than private enjoyment. Also be aware that certain public performances, exhibitions, etc. may prohibit photography even for private enjoyment.

Item Check List

Battery Pack LP-E10

(with protective cover)

Battery Charger

LC-E10E*

Strap

Camera

(with eyecup and body cap)

When you need Lens Instruction Manuals, download them from the Canon website (p.4). The Lens Instruction Manuals (PDF) are for lenses sold individually. Note that when purchasing the Lens Kit, some of the accessories included with the lens may not match those listed in the Lens Instruction Manual.

Software can be downloaded from the Canon website (p.311) for your use.

Before starting, check that all the following items are included with your camera. If anything is missing, contact your dealer.

* Battery Charger LC-E10E comes with a power cord.

 The camera does not come with the Software CD-ROM, an interface cable

or HDMI cable.

 The Instruction Manuals provided are listed on the next page.  If you purchased a Lens Kit, check that the lenses are included.  Be careful not to lose any of the above items.  For items sold separately, see the System Map (p.274).

Instruction Manuals

Quick Reference Guide

The booklet describes the basic operations. More detailed Instruction Manuals (PDF files) can be downloaded from the Canon website.

Downloading and Viewing the Instruction Manuals (PDF Files)

1 Download the Instruction Manuals (PDF files).

 Connect to the Internet and access the following Canon website.

www.canon.com/icpd

 Select your country or region of residence and download the

Instruction Manuals.

Instruction Manuals Available for Download

• Camera Instruction Manual

• Wireless Function Instruction Manual

• Quick Reference Guide

• Lens Instruction Manuals

• Software Instruction Manuals

2 View the Instruction Manuals (PDF files).

 Double-click the downloaded Instruction Manual (PDF file) to

open it.

 To view the Instruction Manuals (PDF files), Adobe Acrobat

Reader DC or other Adobe PDF viewer (most recent version recommended) is required.

 Adobe Acrobat Reader DC can be downloaded for free from the

Internet.

 To learn how to use PDF viewing software, refer to the software’s

Help section.

Compatible Cards

The camera can use UHS-I cards, but since it is not compatible with the UHS-I standard, writing/reading speeds will be equivalent to SD Speed Class 10 at most.

In this manual, “card” refers to SD memory cards, SDHC memory cards, and SDXC memory cards. * The camera does not come with a card for recording images/

movies. Please purchase it separately.

The following cards can be used with the camera regardless of capacity: If the card is new or was previously formatted by another

camera or computer, it is recommended that you format the card with this camera (p.52).

• SD memory cards

• SDHC memory cards

• SDXC memory cards

Cards that Can Record Movies

When shooting movies, use a large-capacity SD card rated SD Speed Class 6 “ ” or higher.

 If you use a slow-writing card when shooting movies, the movie may

not be recorded properly. Also, if you play back a movie on a card with a slow reading speed, the movie may not play back properly.

 To check the card’s writing/reading speed, refer to the card

manufacturer’s website.

Quick Start Guide

White index Red index

Insert the battery (p.36).



To charge the battery, see page 34.

Insert the card (p.36).



With the card’s label facing toward the back of the camera, insert it into the card slot.

Attach the lens (p.44).



Align the lens’s white or red mount index with the camera’s mount index of the same color to attach the lens.

Set the lens’s focus mode switch to <AF>

(p.44).

 When the LCD monitor displays the date/time/zone setting

screen, see page 41.

Set the Mode Dial to <A> (Scene Intelligent Auto)



All the necessary camera settings will be set automatically.

(p.58).

Quick Start Guide

Focus on the subject (p.47).

 To shoot while looking at the LCD monitor, see “Live View

Shooting” (p.137).

 To view the images captured so far, see “Image Playback” (p.82).  To delete an image, see “Erasing Images” (p.228).

Look through the viewfinder and

aim the viewfinder center over the subject. Press the shutter button halfway, and



the camera will focus on the subject.

If the <I> icon blinks in the

viewfinder, raise the built-in flash with your fingers.

Take the picture (p.47).

Press the shutter button completely

to take the picture.

Review the picture.

The captured image will be

displayed for approx. 2 sec. on the LCD monitor.

To display the image again, press

the <x> button (p.82).

Conventions Used in this Manual

Icons in this Manual

<6> : Indicates the Main Dial. <W><X><Y><Z> : Indicates the <S> cross keys on the top,

<0> : Indicates the Setting button. 0, 9, 7, 8 : Indicates that each function remains active for

* In addition to the above, the icons and symbols used on the camera’s buttons

and displayed on the LCD monitor are also used in this manual when discussing relevant operations and functionality.

3 : Indicates a function that can be changed by pressing the

<M> button to change its settings.

M : This icon at the upper right of the page titles indicates that

the function is available only in the Creative Zone modes (p.30).

(p.**) : Reference page numbers for more information.

: Warning to prevent shooting problems.

: Supplemental information.

: Tips or advice for better shooting.

: Troubleshooting advice.

Basic Assumptions and Sample Photos

All operations explained in this manual assume that the Mode Dial is

set to any mode other than < operation, turn the Mode Dial to the corresponding mode.

It is assumed that all the menu settings and Custom Functions are

set to their defaults.

The illustrations in this manual show the camera attached with the

EF-S18-55mm f/3.5-5.6 IS II lens as an example.

The sample photos used in this manual are only for illustrative

purposes to show the effects more clearly.

bottom, left, and right.

approx. 4 sec., 6 sec., 10 sec., or 16 sec. after you let go of the button.

d> (p.39). Before performing an

Chapters

234

56789

101112

Introduction

Getting Started

Basic Shooting and Image Playback

Creative Shooting

Advanced Shooting

Shooting with the LCD Monitor (Live View

Shooting)

Shooting Movies

Handy Features

Image Playback

Post-Processing Images

Printing Images

Customizing the Camera

Reference

105

137

157

181

205

233

239

255

267

Software Start Guide / Downloading Images to a Computer

309

Contents at a Glance

Shooting

 Shoot automatically  p.57-81 (Basic Zone modes)

 Shoot continuously  p.100 (i Continuous shooting)



Take a picture of yourself in a group

 Freeze the action  p.106 (s Shutter-priority AE)  Blur the action

 Blur the background  p.63 (C Creative Auto) 

Keep the background in sharp focus



Adjust the image brightness (exposure)

 Shoot in low light  p.58, 103 (D Flash photography)

 Shoot fireworks at night  p.112 (Bulb exposure)



Shoot while viewing the LCD monitor

 Shoot movies  p.157 (k Movie shooting)

Image Quality

 Shoot with image effects  p.93 (Picture Style)

matching the subject



Make a large-size print of the picture

 Take many pictures  p.86 (7a, 8a, b, c)

 p.101 (j Self-timer)

 p.108 (f Aperture-priority AE)

 p.114 (Exposure compensation)

p.90 (ISO speed setting)

 p.137 (A Live View shooting)

 p.86 (73, 83, 1)

Focusing

 Change the point of focus  p.97 (S AF point selection)

 Shoot a moving subject  p.69, 96 (AI Servo AF)

Playback

 View the images on the camera  p.82 (x Playback)

 Search for pictures quickly  p.206 (H Index display)

 Rate images  p.210 (Ratings)

 Prevent important images  p.226 (K Image protect)

from accidental deletion

 Delete unnecessary images  p.228 (L Delete)



Auto play back photos and movies



View the photos or movies on a TV set



Adjust the LCD monitor brightness

 Apply special effect to images  p.234 (Creative filters)

p.207 (I Image browsing)

 p.220 (Slide show)

 p.224 (TV set)

 p.183 (LCD monitor brightness)

Printing

 Print pictures easily  p.239 (Direct printing)

Index to Features

Power

Battery

• Charging  p.34

• Installing/Removing  p.36

• Battery level  p.40

Auto power off  p.39

Cards

Installing/Removing  p.36 Formatting  p.52

Release shutter

without card  p.182

Lens

Attaching/Detaching  p.44 Zoom  p.45

Basic Settings

Language  p.43 Date/Time/Zone  p.41 Beeper  p.182 LCD off/on button  p.195

LCD brightness

adjustment  p.183

Recording Images

Creating/Selecting

a folder  p.184

File numbering  p.186

Image Quality

Image-recording quality  p.86 Picture Style  p.93 White balance  p.129 Color space  p.135

Image enhancement features

• Auto Lighting Optimizer  p.121

• Lens peripheral

illumination correction  p.122

• Noise reduction for

long exposures  p.260

• Noise reduction for

high ISO speeds  p.261

• Highlight tone priority  p.261

AF operation  p.95 AF point selection  p.97 Manual focusing  p.99

Drive

Drive mode  p.28 Continuous shooting  p.100 Self-timer  p.101 Maximum burst  p.88

Shooting

Shooting mode  p.30 ISO speed  p.90 Feature guide  p.55 Bulb  p.112 Metering mode  p.113 Quick Control  p.48

Index to Features

Exposure

Exposure compensation  p.114 AEB  p.116 AE lock  p.118

Flash

Built-in flash  p.103

• Flash exposure

compensation  p.115

• FE lock  p.119

External flash  p.268 Flash control  p.196

Live View Shooting

Live View shooting  p.137

Autofocusing (AF)

methods  p.146

Aspect ratio  p.144 Grid  p.143 Quick Control  p.142

Movie Shooting

Movie shooting  p.157 Sound recording  p.176 Grid  p.177 Manual exposure  p.160 Quick Control  p.165 Video snapshot  p.168

Playback

Image review time  p.182 Single-image display  p.82

Shooting information

display  p.230

Index display  p.206

Image browsing

(Jump display)  p.207

Magnified view  p.208 Image rotate  p.209 Rating  p.210 Movie playback  p.216

Editing out movie’s

first/last scene  p.218

Slide show  p.220

Viewing images on a

TV set  p.224

Protect  p.226 Erase  p.228 Quick Control  p.212

Image Editing

Creative filters  p.234 Resize  p.237

Printing

PictBridge  p.242 Print Order (DPOF)  p.249 Photobook Set-up  p.253

Customization

Custom Functions (C.Fn)  p.256 My Menu  p.265

Software

Software Start Guide  p.310

Software Instruction

Manuals  p.312

Wireless Functions

 Wireless Function Instruction

Manual

Introduction 2

Item Check List................................................................................. 3

Instruction Manuals .......................................................................... 4

Compatible Cards............................................................................. 5

Quick Start Guide ............................................................................. 6

Conventions Used in this Manual..................................................... 8

Chapters........................................................................................... 9

Contents at a Glance...................................................................... 10

Index to Features ........................................................................... 12

Safety Instructions.......................................................................... 20

Handling Precautions ..................................................................... 23

Nomenclature ................................................................................. 26

Getting Started 33

Charging the Battery ...................................................................... 34

Installing and Removing the Battery and Card............................... 36

Turning on the Power ..................................................................... 39

Setting the Date, Time, and Zone................................................... 41

Selecting the Interface Language................................................... 43

Attaching and Detaching a Lens..................................................... 44

Basic Operation.............................................................................. 46

Q Quick Control for Shooting Functions ....................................... 48

3 Menu Operations.................................................................. 50

Formatting the Card ....................................................................... 52

Switching the LCD Monitor Display................................................ 54

Feature Guide ................................................................................ 55

Basic Shooting and Image Playback 57

A Fully Automatic Shooting (Scene Intelligent Auto) ...................58

A Full Auto Techniques (Scene Intelligent Auto)..........................61

C Creative Auto Shooting.............................................................63

2 Shooting Portraits ......................................................................66

3 Shooting Landscapes ...............................................................67

4 Shooting Close-ups....................................................................68

5 Shooting Moving Subjects ........................................................69

P Shooting Food ............................................................................70

6 Shooting Night Portraits .............................................................71

Q Quick Control.............................................................................73

Shooting with Ambience Selection..................................................75

Shooting by Lighting or Scene Type ...............................................79

x Image Playback ........................................................................82

Creative Shooting 83

d: Program AE...............................................................................84

Setting the Image-Recording Quality..............................................86

i: Changing the ISO Speed to Suit the Light Level.....................90

A Selecting Optimal Image Characteristics for the Subject

(Picture Style)..................................................................................93

f: Changing the Autofocus Operation (AF operation)..................95

S Selecting the AF Point ..............................................................97

Subjects Difficult to Focus on..........................................................99

MF: Manual Focus .......................................................................99

i Continuous Shooting...............................................................100

j Using the Self-timer .................................................................101

D Using the Built-in Flash.............................................................103

Contents

Advanced Shooting 105

s: Conveying the Subject’s Movement ..................................... 106

f: Changing the Depth of Field ................................................ 108

Depth-of-Field Preview...............................................................110

a: Manual Exposure....................................................................111

q Changing the Metering Mode..................................................113

Setting Exposure Compensation...................................................114

Auto Exposure Bracketing.............................................................116

A Locking the Exposure ..............................................................118

A Locking the Flash Exposure.....................................................119

Auto Correction of Brightness and Contrast

(Auto Lighting Optimizer).............................................................. 121

Correcting the Image’s Dark Corners ........................................... 122

A Customizing Image Characteristics (Picture Style) .............. 124

Registering Preferred Image Characteristics (Picture Style)

B: Matching the Light Source (White balance)......................... 129

u Adjusting the Color Tone for the Light Source......................... 133

Setting the Color Reproduction Range (Color space) .................. 135

Shooting with the LCD Monitor (Live View Shooting) 137

A Shooting with the LCD Monitor .............................................. 138

Shooting Function Settings .......................................................... 142

Menu Function Settings................................................................ 143

Using AF to Focus (AF Method)................................................... 146

MF: Focusing Manually ................................................................ 154

... 127

Shooting Movies 157

k Shooting Movies .....................................................................158

Autoexposure Shooting..............................................................158

Manual Exposure Shooting........................................................160

Shooting Function Settings...........................................................165

Setting the Movie Recording Size................................................. 166

Shooting Video Snapshots............................................................168

Menu Function Settings ................................................................ 174

Handy Features 181

Handy Features ............................................................................182

Disabling the Beeper..................................................................182

Card Reminder........................................................................... 182

Setting the Image Review Time .................................................182

Setting the Auto Power-off Time ................................................183

Adjusting the LCD Monitor Brightness .......................................183

Creating and Selecting a Folder.................................................184

File Numbering Methods ............................................................186

Setting Copyright Information.....................................................188

Auto Rotation of Vertical Images ................................................190

Checking Camera Settings ........................................................191

Reverting the Camera to the Default Settings............................192

Turning the LCD Monitor Off/On ................................................195

Changing the Shooting Settings Screen Color...........................195

Setting the Flash...........................................................................196

Appending Dust Delete Data ........................................................200

Manual Sensor Cleaning...............................................................202

Contents

Image Playback 205

x Searching for Images Quickly ................................................ 206

u/y Magnified View................................................................... 208

b Rotating the Image.................................................................. 209

Setting Ratings ............................................................................. 210

Q Quick Control for Playback ..................................................... 212

k Enjoying Movies..................................................................... 214

k Playing Back Movies.............................................................. 216

X Editing a Movie’s First and Last Scenes ................................. 218

Slide Show (Auto Playback)......................................................... 220

Viewing Images on a TV Set........................................................ 224

K Protecting Images................................................................... 226

L Erasing Images........................................................................ 228

B Shooting Information Display............................................... 230

Post-Processing Images 233

U Applying Creative Filters......................................................... 234

S Resizing JPEG Images........................................................... 237

Printing Images 239

Preparing to Print.......................................................................... 240

w Printing................................................................................... 242

Cropping the Image ................................................................... 247

W Digital Print Order Format (DPOF) ......................................... 249

W Direct Printing of Print-Ordered Images ................................. 252

p Specifying Images for a Photobook ......................................... 253

Customizing the Camera 255

Setting Custom Functions.............................................................256

Custom Function Settings.............................................................258

C.Fn I: Exposure ........................................................................258

C.Fn II: Image ............................................................................260

C.Fn III: Autofocus/Drive............................................................262

C.Fn IV: Operation/Others..........................................................263

Registering My Menu....................................................................265

Reference 267

External Speedlites .......................................................................268

H Using Eye-Fi Cards .................................................................269

Function Availability Table by Shooting Mode...............................272

System Map ..................................................................................274

Menu Settings...............................................................................276

Troubleshooting Guide..................................................................282

Error Codes...................................................................................294

Specifications................................................................................295

Software Start Guide /

Downloading Images to a Computer 309

Software Start Guide.....................................................................310

Downloading and Viewing the Software Instruction Manuals

(PDF Files)....................................................................................312

Downloading Images to a Computer.............................................313

Index .............................................................................................315

Contents

Safety Instructions

Be sure to read these instructions in order to operate the product safely. Follow these instructions to prevent injury or harm to the operator of the product or others.

WARNING:

 Keep the product out of the reach of young children.

A strap wrapped around a person’s neck may result in strangulation. The parts or provided items of cameras or accessories are dangerous if swallowed. If swallowed, seek immediate medical assistance. The battery is dangerous if swallowed. If swallowed, seek immediate medical assistance.

 Use only power sources specified in this instruction manual  Do not disassemble or modify the product.  Do not expose the product to strong shocks or vibration.  Do not touch any exposed internal parts.  Stop using the product in any case of unusual circumstances such as the presence

of smoke or a strange smell.

 Do not use organic solvents such as alcohol, benzine or paint thinner to clean the

product.

 Do not get the product wet. Do not insert foreign objects or liquids into the product.  Do not subject the product to high water pressure or get it wet with large quantities of

liquids. Do not insert foreign objects or liquids into the product.

 Do not insert foreign objects or liquids into the product.  Do not use the product where flammable gases may be present.

This may cause electric shock, explosion or fire.

 Do not leave a lens or a camera with a lens attached, exposed without the lens cap

attached.

The lens may concentrate the light and cause fire.

 Do not look through the viewfinder at strong light sources such as the sun on a bright

day or lasers and other strong artificial light sources.

This may harm your vision.

 Do not touch the product connected to a power outlet during lightning storms.

This may cause electric shock.

 Observe the following instructions when using commercially available batteries or

provided battery packs.

• Use batteries/battery packs only with their specified product.

• Do not heat batteries/battery packs or expose them to fire.

• Do not charge batteries/battery packs using non-authorized battery chargers.

• Do not expose the terminals to dirt or let them come into contact with metallic pins or other metal objects.

• Do not use leaking batteries/battery packs.

• When disposing of batteries/battery packs, insulate the terminals with tape or other means.

This may cause electric shock, explosion or fire. If a battery/battery pack leaks and the material contacts your skin or clothing, flush the exposed area thoroughly with running water. In case of eye contact, flush thoroughly with copious amounts of clean running water and seek immediate medical assistance.

Denotes the risk of serious injury or death.

for use with the product.

Safety Instructions

 Observe the following instructions when using a battery charger or AC adapter.

• Periodically remove any dust buildup from the power plug and power outlet using a dry cloth.

• Do not plug in or unplug the product with wet hands.

• Do not use the product if the power plug is not fully inserted into the power outlet.

• Do not expose the power plug and terminals to dirt or let them come into contact with metallic pins or other metal objects.

 Do not touch the battery charger or AC adapter connected to a power outlet during

lightning storms.

 Do not place heavy objects on the power cord. Do not damage, break or modify the

power cord.

 Do not wrap the product in cloth or other materials when in use or shortly after use

when the product is still warm in temperature.

 Do not unplug the product by pulling the power cord.  Do not leave the product connected to a power source for long periods of time.  Do not charge batteries/battery packs at temperatures outside the range of 6 - 40 °C

(43 - 104 °F).

This may cause electric shock, explosion or fire.

 Do not allow the product to maintain contact with the same area of skin for extended

periods of time during use. This may result in low-temperature contact burns, including skin redness and blistering, even if the product does not feel hot. The use of a tripod or similar equipment is recommended when using the product in hot places and for people with circulation problems or less sensitive skin.

 Follow any indications to turn off the product in places where its use is forbidden.

Not doing so may cause other equipment to malfunction due to the effect of electromagnetic waves and even result in accidents.

 To prevent fire, excessive heat, chemical leakage, explosions, and electrical shock,

follow the safeguards below:

• Do not insert the battery’s plus and minus ends incorrectly.

 Do not leave any cords near a heat source.

It can deform the cord or melt the insulation and cause a fire or electrical shock.

 Do not fire the flash at anyone driving a car or other vehicle.

It may cause an accident.

 Do not use or store the equipment in dusty or humid places. Likewise, keep the

battery away from metallic items and store it with its protective cover attached to

prevent short-circuit. This is to prevent fire, excessive heat, electrical shock, and burns.

 To prevent a fire and electrical shock, follow the safeguards below:

• Do not connect too many power plugs to the same power outlet.

• Do not use a cord whose wire is broken or insulation is damaged.



Do not connect the battery directly to an electrical outlet or a car’s cigarette lighter outlet. The battery may leak, generate excessive heat or explode, causing fire, burns, or injuries.

 A thorough explanation of how to use the product by an adult is required when the

product is used by children. Supervise children while they are using the product. Incorrect usage may result in electrical shock or injury.

Safety Instructions

CAUTION:

 Do not fire the flash near the eyes.

It may hurt the eyes.

 Strap is intended for use on the body only. Hanging the strap with any product

attached on a hook or other object may damage the product. Also, do not shake the product or expose the product to strong impacts.

 Do not apply strong pressure on the lens or allow an object to hit it.

This may cause injury or damage to the product.

 Flash emits high temperatures when fired. Keep fingers, any other part of your body,

and objects away from the flash unit while taking pictures.

This may cause burns or malfunction of the flash.

 Do not leave the product in places exposed to extremely high or low temperatures.

The product may become extremely hot/cold and cause burns or injury when touched.

 Only mount the product on a tripod that is sufficiently sturdy.  Do not carry the product when it is mounted on a tripod.

This may cause injury or may result in an accident.

 Do not look at the screen or through the viewfinder for prolonged periods of time.

This may induce symptoms similar to motion sickness. In such a case, stop using the product immediately and rest for a while before resuming use.

 Do not touch any parts inside the product.

This may cause injury.

Denotes the risk of injury.

Handling Precautions

Camera Care

 This camera is a precision instrument. Do not drop it or subject it to physical

shock.

 The camera is not waterproof and cannot be used underwater. If you

accidentally drop the camera into water, promptly consult the nearest Canon Service Center. Wipe off any water droplets with a dry and clean cloth. If the camera has been exposed to salty air, wipe it with a well-wrung wet cloth.

 Never leave the camera near anything having a strong magnetic field such

as a magnet or electric motor. Also, avoid using or leaving the camera near anything emitting strong radio waves, such as a large antenna. Strong magnetic fields can cause camera misoperation or destroy image data.

 Do not leave the camera in excessive heat, such as in a car in direct

sunlight.

 The camera contains precision electronic circuitry. Never attempt to

disassemble the camera yourself.

 Do not block the built-in flash or mirror operation with your finger, etc. Doing

so may cause a malfunction.

 Use only a commercially-available blower to blow away dust when it adheres

to the lens, viewfinder, reflex mirror, focusing screen, etc. Do not use cleaners that contain organic solvents to clean the camera body or lens. For stubborn dirt, take the camera to the nearest Canon Service Center.

 Do not touch the camera’s electrical contacts with your fingers. This is to

prevent the contacts from corroding. Corroded contacts may cause camera misoperation.

 If the camera is suddenly brought in from the cold into a warm room,

condensation may form on the camera and internal parts. To prevent condensation, first put the camera in a sealed plastic bag and let it adjust to the warmer temperature before taking it out of the bag.

 If condensation forms on the camera, do not use the camera. This is to avoid

damaging the camera. If there is condensation, remove the lens, card and battery from the camera, and wait until condensation has evaporated before using the camera.

 If the camera will not be used for an extended period, remove the battery

and store the camera in a cool, dry, well-ventilated location. Even while the camera is in storage, press the shutter button a few times once in a while to check that the camera is still working.

Handling Precautions

Lens mount

 Avoid storing the camera where there are chemicals that result in rust and

corrosion such as in a chemical lab.

 If the camera has not been used for an extended period, test all its functions

before using it. If you have not used the camera for some time or if there is an important shoot such as a foreign trip coming up, have the camera checked by your nearest Canon Service Center or check the camera yourself and make sure it is working properly.

 If you use continuous shooting, Live View shooting, or movie shooting for a

prolonged period, the camera may become hot. This is not a malfunction.

 If there is a bright light source inside or outside the image area, ghosting

may occur.

LCD Monitor

 Although the LCD monitor is manufactured with very high precision

technology with over 99.99% effective pixels, there may be a few dead pixels displaying only black or red, etc. among the remaining 0.01% or less pixels. Dead pixels are not a malfunction. They do not affect the images recorded.

 If the LCD monitor is left on for a prolonged period, screen burn-in may occur

where you see remnants of what was displayed. However, this is only temporary and will disappear when the camera is left unused for a few days.

 The LCD monitor display may seem slow in low temperatures, or look black

in high temperatures. It will return to normal at room temperature.

 Look straight at the LCD monitor. The display may be difficult to see

depending on the angle.

Lens Mount Maintenance

If dust adheres to the lens mount, wipe it off with a dry and clean cloth. Never use cleaners that contain organic solvents, such as alcohol wet wipes. Doing so may scratch the lens mount or make it difficult to attach or detach the lens.

Handling Precautions

Contacts

Cards

To protect the card and its recorded data, note the following:

 Do not drop, bend, or wet the card. Do not subject it to excessive force,

physical shock, or vibration.

 Do not touch the card’s electronic contacts with your fingers or anything

metallic.

 Do not affix any stickers, etc. on the card.  Do not store or use the card near anything that has a strong magnetic field,

such as a TV set, speakers, or magnets. Also avoid places prone to having static electricity.

 Do not leave the card in direct sunlight or near a heat source.  Store the card in a case, etc.  Do not store the card in hot, dusty, or humid locations.

Lens

After detaching the lens from the camera, put down the lens with the rear end up and attach the rear lens cap to avoid scratching the lens surface and electrical contacts.

Smudges Adhering to the Front of the Sensor

Besides dust entering the camera from outside, in rare cases lubricant from the camera’s internal parts may adhere to the front of the sensor. If smudges are visible on the images, having the sensor cleaned by a Canon Service Center is recommended.

Nomenclature

Mode Dial (p.30, 39)

<6> Main Dial

Shutter button (p.47)

Grip

Mirror (p.202)

Contacts (p.25)

Lens mount (p.24)

Lens lock pin

Built-in flash/AF-assist beam emitter (p.103/98)

EF Lens mount index (p.44)

EF-S Lens mount index (p.44)

Hot shoe

Microphone (p.158, 176)

<V> Focal plane mark (p.68)

Strap mount (p.33)

Lens release button (p.45)

Body cap (p.44)

<A> Live View shooting/ Movie shooting button (p.138/158)

Eyecup (p.102)

Viewfinder eyepiece

LCD monitor (p.50, 183)

<O/L> Aperture/Exposure compensation button/ Erase button (p.111/114/228)

<Q> Quick Control button (p.48)

Tripod socket

<M> Menu button (p.50)

<x> Playback button (p.82)

<W><X><Y><Z>: <S> Cross keys (p.50) <Wi> ISO speed setting button (p.90) <XB> White balance selection button (p.129) <Yi/j> Drive/Self-timer selection button

(p.100-101)

<Zf> AF operation selection button (p.95)

Battery compartment (p.36)

<B> Display button (p.54, 82, 140, 162, 191)

<A/Hy> AE lock/ FE lock button/Index/ Reduce button (p.118/119/206/208, 247)

Card slot/Battery compartment cover (p.36)

Card slot/Battery compartment cover release lever (p.36)

Card slot (p.36)

Access/ Wi-Fi lamp (p.38)

Serial number

Digital terminal (p.240, 313)

HDMI mini OUT terminal (p.224)

Terminal cover

<S/u> AF point selection button/ Magnify button (p.97/208, 247)

<0> Setting button (p.50)

Nomenclature

Picture Style (p.93)

AF operation (p.95)

X: One-Shot AF

9: AI Focus AF Z: AI Servo AF

MF: Manual Focus

c Main Dial pointer (p.105)

Shooting mode

Exposure level indicator

Exposure compensation amount (p.114) AEB range (p.116)

Quick Control icon (p.48, 73)

Battery level (p.40)

zxcn

White balance (p.129)

Q Auto: Ambience priority QwAuto: White priority W Daylight E Shade R Cloudy Y Tungsten light U White fluorescent light I Flash O Custom

Drive/self-timer (p.100-101)

u Single shooting i Continuous shooting j Self-timer: 10 sec. l Self-timer: 2 sec.

q Self-timer: Continuous

Shutter speed

Aperture

Auto Lighting Optimizer (p.121)

ISO speed (p.90)

Highlight tone priority (p.261)

y Flash exposure compensation (p.115) 0 External flash exposure compensation

Image-recording quality (p.86)

73 Large/Fine 83 Large/Normal 74 Medium/Fine 84 Medium/Normal 7a Small 1/Fine 8a Small 1/Normal

b Small 2 (Fine) c Small 3 (Fine)

1+73

RAW+Large/Fine

1 RAW

Possible shots

Possible shots during white balance bracketing

Self-timer countdown

u White balance correction (p.133) B White balance bracketing (p.134)

Metering mode (p.113)

q Evaluative metering w Partial metering e

Center-weighted average metering

Eye-Fi transmission status (p.269)

Shooting Function Settings (in Creative Zone modes, p.30)

The display will show only the settings currently applied.

Viewfinder Information

<D> Use of flash

recommended (blinking) Flash-ready (illuminated) FE lock out of range warning (blinking)

Focusing screen

<A> AE lock/

AEB in-progress

<e> High-speed sync

(FP flash)

<d> FE lock/

FEB in-progress

<y> Flash exposure

compensation

Shutter speed FE lock (FEL) Busy (buSY) Built-in flash recycling (D buSY)

Card full warning (FuLL) Card error warning (Card) No card warning (Card)

AF point activation indicator <•>

AF point

<i> ISO speed

<u> White balance correction

<o> Focus indicator

Maximum burst

<0> Monochrome shooting

ISO speed

<A> Highlight tone priority

Exposure level indicator

Exposure compensation amou nt AEB range

Aperture

Nomenclature

The display will show only the settings currently applied.

Nomenclature

Creative Zone

These modes give you more control for shooting various subjects as desired.

d : Program AE (p.84) s : Shutter-priority AE (p.106) f : Aperture-priority AE (p.108) a : Manual exposure (p.111)

Basic Zone

All you do is press the shutter button. The camera sets everything to suit the subject or scene for shooting.

A : Scene Intelligent Auto (p.58)

C : Creative Auto (p.63)

Image Zone

2 : Portrait (p.66) 3 : Landscape (p.67) 4 : Close-up (p.68) 5 : Sports (p.69) P : Food (p.70) 6 : Night Portrait (p.71)

k: Movie Shooting

(p.157)

d: Power off (p.39)

Mode Dial

The Mode Dial includes the Basic Zone modes, Creative Zone modes, and the Movie shooting mode.

+ 292 hidden pages
