Canon EOS 800D + EF-S 18-55 4.0-5.6 IS STM User Manual

IMAGE SENSOR

Type 22.3mm x 14.9 mm CMOS

Effective Pixels Approx. 24.20 megapixels

Total Pixels Approx. 25.80 megapixels

Aspect Ratio 3:2

Low-Pass Filter Built-in/Fixed

Sensor Cleaning EOS integrated cleaning system

Colour Filter Type Primary Colour

IMAGE PROCESSOR

Type DIGIC 7

LENS

Lens Mount EF/EF-S

Focal Length Equivalent to 1.6x the focal length of the lens

Image Stabilisation

FOCUSING

Type TTL-CT-SIR with a CMOS sensor

AF System/ Points

45 cross-type AF points
(45 f/5.6 cross-type AF points, 27 f/8 points [9 cross­type], centre point is f/2.8 and f/5.6 dual cross­type) (11)

AF working range EV -3 - 18 (at 23°C & ISO100)

AF Modes AI Focus

One Shot
AI Servo

AF Point Selection

Automatic selection: 45 point AF
Manual selection: Single point AF
Manual selection: Zone AF
Manual selection: Large Zone AF
AF points can be selected separately for vertical
and horizontal shooting

Selected AF point display

Indicated by a transmissive LCD in viewfinder and
Quick Control screen

Predictive AF (7) Yes, up to 8m

AF Lock

Locked when shutter button is pressed half way in
One Shot AF mode or AF-ON button is pressed.

AF Assist Beam

Intermittent firing of built-in flash or emitted by
optional dedicated Speedlite

Manual Focus Selected on lens

Focus Bracketing

AF Microadjustment

EXPOSURE CONTROL

Metering modes

7560-pixel RGB+IR metering sensor
Metering with the area divided into 63 segments
(9×7)
(1) Evaluative metering (linked to all AF points)
(2) Partial metering (approx. 6.0% of viewfinder)
(3) Spot metering (approx. 3.5% of viewfinder)
(4) Center-weighted average metering

Metering Range EV 1-20 (at 23°C with 50mm f/1.4 lens ISO100)

AE Lock

Auto: In One-shot AF mode with evaluative
metering exposure is locked when focus is
achieved.
Manual: By AE lock button in creative zone modes.

Exposure Compensation

+/-5 EV in 1/3 or 1/2 stop increments (can be
combined with AEB).

AEB 3 shots +/-3 EV 1/3 or 1/2 stop increments

ISO Sensitivity (8)

Auto (100-25600), 100-25600 (in 1/3-stop or whole
stop increments)
ISO can be expanded to H: 51200
During Movie shooting: Auto (100-12800), 100-12800
(in 1/3-stop or whole stop increments) ISO can be
expanded to H: 25600

EOS 800D

SHUTTER

Type Electronically-controlled focal-plane shutter

Speed

30-1/4000 sec (1/2 or 1/3 stop increments), Bulb
(Total shutter speed range. Available range varies
by shooting mode)

WHITE BALANCE

Type Auto white balance with the imaging sensor

Settings

AWB (Ambience priority, White priority), Daylight,
Shade, Cloudy, Tungsten light, White
Fluorescent light, Flash, Custom, Colour
Temperature Setting.
White balance compensation:

1. Blue/Amber +/-9

2. Magenta/ Green +/-9.

Custom White Balance Yes, 1 setting can be registered

WB Bracketing

+/-3 levels in single level increments
3 bracketed images per shutter release.
Selectable Blue/Amber bias or Magenta/ Green
bias.

VIEWFINDER

Type Pentamirror

Coverage (Vertical/Horizontal) Approx. 95%

Magnification Approx. 0.82x (4)

Eyepoint Approx. 19mm (from eyepiece lens centre)

Dioptre Correction -3 to +1 m-1 (dioptre)

Focusing Screen Fixed

Mirror

Quick-return half mirror (Transmission: reflection ratio
of 40:60, no mirror cut-off with EF 600mm f/4 IS USM
or shorter)

Viewfinder Information

AF information: AF points, focus confirmation
Exposure information: Shutter speed, aperture
value, ISO speed (always displayed), AE lock,
exposure level/compensation, spot metering circle,
exposure warning, AEB.
Flash information: Flash ready, high-speed sync, FE
lock, flash exposure compensation, red-eye
reduction light.
Image information: Card information, maximum
burst (1 digit display), Highlight tone priority (D+).
Composition information: Grid, Electronic level,
Aspect Ratio
Other information: Warning icon, Flicker Detection

Depth of field preview Yes, with Depth of Field preview button.

Eyepiece shutter On strap

LCD MONITOR

Type

Touch screen Vari angle 7.7cm (3.0") 3:2 Clear View
II TFT, approx. 1040K dots

Coverage Approx. 100%

Viewing Angle (horizontally/vertically) Approx 170°

Coating Anti-reflection and Anti smudge

Brightness Adjustment

Adjustable to one of seven levels

Display Options

(1) Quick Control Screen
(2) Camera settings
(3) Electronic Level

FLASH

Built-in Flash GN (ISO 100, meters) 12

Built-in Flash Coverage up to 17mm focal length (35mm equivalent: 27mm)
Built-in Flash recycle time Approx. 3 seconds

Modes Auto, Manual flash, Integrated Speedlite Transmitter
Red-Eye Reduction Yes - with red-eye reduction lamp

X-sync 1/250sec

Flash Exposure Compensation +/- 3EV in 1/2 or 1/3 increments

Flash Exposure Bracketing Yes, with compatible External Flash

Flash Exposure Lock Yes

Second Curtain Synchronisation Yes

HotShoe/ PC terminal Yes/ No

External Flash Compatibility

E-TTL II with EX series Speedlites, wireless optical
multi-flash support

External Flash Control via camera menu screen

SHOOTING

Modes

Scene Intelligent Auto (Stills and Movie), No Flash,
Creative Auto, Portrait, Landscape, Close-up,
Sports, SCN(,Night Portrait, Handheld Night Scene,
HDR Backlight Control, Food, Kids, Candlelight),
Creative filters, Program AE, Shutter priority AE,
Aperture priority AE, Manual (Stills and Movie),

Picture Styles

Auto, Standard, Portrait, Landscape, Fine Detail,
Neutral, Faithful, Monochrome, User Defined (x3)

Colour Space sRGB and Adobe RGB

Image Processing

Highlight Tone Priority
Auto Lighting Optimizer (4 settings)
Long exposure noise reduction
High ISO speed noise reduction (4 settings)
Multi Shot Noise Reduction
Auto Correction of Lens Peripheral illumination,
Chromatic aberration correction, Distortion
correction, Diffraction correction
Creative filters (Grainy B/W, Soft focus, Fish-eye
effect, Art bold effect, Water painting effect, Toy
camera effect, Miniature effect, HDR art standard,
HDR art vivid, HDR art bold, HDR art embossed)
Multi-exposure
RAW image processing - during image Playback
only
Resize to M or S1, S2, S3

Drive modes

Single, Continuous L, Continuous H, Self timer
(2s+remote, 10s +remote), Silent single shooting,
Silent continous shooting

Continuous Shooting

Max. Approx. 6fps. (speed maintained until card is
full) (JPEG)(1)(10)(with UHS-I card), 27 images
(RAW)(with UHS-I card)) (2) (10)

Intervalometer
