See Warranty on page 14 for important information about commercial use of this product.

BUILT TO LAST

Gasoline Powered

Horizontal Pressure

Washers

Product Manual

PW2220, PW3005, PW3221, PW3228, PW3520





Please record Model No. and Serial No. for use when contacting the manufacturer:

Model No. ______________ Purchase date ____________________

Serial No. ______________ Purchase place ____________________

For Information About This Product, call 1-800-330-0712

Contents

Page





Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Safety and Warning Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Assembly and Pre-Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5

Startup, Operation, Shutdown, and Storage . . . . . . . . . . . . . . . . . . . . . . . . 6 - 10

Maintenance and Technical Information . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 11

Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 - 13

Service Record and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Carefully read and understand these instructions before operating your pressure washer.

REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.

© 2003 Campbell Hausfeld/Scott Fetzer

For parts, product & service information

IN462600AV 8/03

visit www.chpower.com

Pressure Washers

Frequently Asked Questions

How do I start my pressure washer?

1.Make sure you have gas and oil in the engine.

2.Turn the water on, then trigger the gun to make sure the water will flow smoothly out of the nozzle or tip.

3.Put the engine throttle control in the “Fast/Start” position. Set the fuel shut off switch to “ON.” Set the on/off switch to “ON” (if applicable).

4.Set the choke to “ON.”

5.Pull the trigger (to relieve any back pressure in the pump) while pulling the starter cord.

6.If the engine does not start after three tries, repeat Step 5 (See Page 6) or see Troubleshooting Section (Pages 12-13).

What type of oil do I use?

The pump on the horizontal pressure washer comes filled with the correct amount of oil and should not need filling. See Page 11 for pump oil types and quantities. THE ENGINE DOES NOT COME FILLED WITH OIL. See Page 11 for engine oil types and quantities. Refer to Pages 10 and 11 of this manual and also refer to the included engine owner’s manual for oil changing instructions.

Why don’t I have any water pressure?

Is the water hose attached to the pressure washer?

Is the water turned on?

Check for any kinks, leaks, or blockage in the hoses, fittings, or the nozzle.

Is the adjustable nozzle in the low psi position? If so, move it into the high psi position (See Page 8).

Is the inlet filter screen free of debris? Check and remove debris if needed.

Is the quick connect tip in place? (See Page 4.)

How do I get high pressure?

For high pressure, move the nozzle into the high psi position (See Page 8).

For units with quick connect tips: use any color tip with the exception of black. Black tip is used for low pressure detergent application.

How do I get the soap suction to work?

1.Attach clear plastic tube to brass barb on pump (See Page 4).

2.Insert filter end of clear plastic tube into detergent liquid.

3.Move the nozzle into the low psi position (See Page 8).

4.For quick connect lance, use black detergent tip (see Page 8).

Why doesn’t the pressure washer apply detergents with high pressure?

The reason you don’t apply detergents with high pressure is that the detergents “bounce” off the cleaning surface as fast as you apply them. Detergent is only effective when you allow it time to work on the surface of whatever you are cleaning. You can only apply detergent at low pressure, wait 1-3 minutes to allow it to work, and rinse the surface with high pressure.

What maintenance do I need to perform on my pressure washer?

1.After turning off the pressure washer and the water, depressurize the hose by triggering the gun.

2.Remove the garden hose and high pressure hose from the pump.

3.Pull the start rope slowly five times to purge water from the pump. This will help protect the pump from damage.

4.Do not store your pressure washer in an area where the temperature will drop below 32˚ F unless pressure washer is properly winterized (see Page 9).

What do I do if I’m missing a part?

Call Campbell Hausfeld at 1-800-330-0712 and we will promptly replace your missing parts. DO NOT RETURN THE PRESSURE

WASHER TO THE RETAILER!

Where can I buy accessories for my pressure washer?

If you can’t find accessories at the store where you purchased your pressure washer, call Campbell Hausfeld at 1-800-330-0712 or visit our website at www.chpower.com.

Who do I call if I have questions or problems?

Call Campbell Hausfeld at 1-800-330-0712 (U.S.A.)

www.chpower.com

2

! WARNING
! DANGER

Safety and Warning Information

Safety Guidelines

This manual contains information that is very important to know and understand. This information is provided for SAFETY and to PREVENT EQUIPMENT PROBLEMS. To help recognize this information, observe the following symbols.

Danger indicates an imminently haz-

ardous situation which, if not avoided, WILL result in death or serious injury.

Warning indicates a potentially haz-

ardous situation which, if not avoided, COULD result in death or serious injury.

Caution indicates a ! CAUTION potentially haz-

ardous situation which, if not avoided, MAY result in minor or moderate injury.

Notice indicates NOTICE important informa-

tion, that if not followed, may cause damage to equipment.

NOTE: Information that requires special attention.

Important Safety Instructions

SAVE THESE INSTRUCTIONS

! WARNING

When using this product, basic precautions should always be followed, including the following:

1.Read all instructions before using the product.

2.To reduce the risk of injury, close supervision is necessary when the product is used near children.

3.Follow all safety codes as well as the Occupational Safety and Health Act (OSHA).

4.Ensure safety devices are operating properly before each use. DO NOT remove or modify any part of the gun or unit.

5.Know how to stop this product and bleed pressure quickly. Be thoroughly familiar with the controls.

6.Stay alert – watch what you are doing.

7.Do not operate the product when fatigued or under the influence of alcohol or drugs.

8.Keep operation area clear of all persons.

9.Do not overreach or stand on unsta-

ble support. Keep good footing and balance at all times.

10.Follow the maintenance instructions specified in the manual.

Risk of injection ! WARNING or severe injury.

Keep clear of nozzle. Do not discharge streams at persons. This product is to be used only by trained operators.

Always remove lance from gun before cleaning debris from tip.

Keep clear of nozzle. NEVER direct high pressure spray at a person, animal, or yourself.

Always wear safety glasses or goggles and protective equipment (hearing protection, gloves, rubber boots, protective clothing) when operating or performing maintenance.

Never put hand or fingers over the spray tip while operating the unit.

Never try to stop or deflect leaks with any body part.

Always engage the trigger safety latch in the safe position when spraying is stopped even if only for a few moments.

Always follow detergent manufacturer’s label recommendations for proper use of detergents. Always protect eyes, skin, and respiratory system from detergent use.

Do not use pres- ! WARNING sure that exceeds

the operating pressure of any of the parts (hoses, fittings, etc.) in the pressurized system. Ensure all equipment and accessories are rated to withstand the maximum working pressure of the unit.

! WARNING Explosionhazard.

NEVER spray flammable liquids or use pressure washer in areas containing combustible dust, liquids, or vapors.

NEVER operate this machine in a closed building or in or near an explosive environment.

Do not remove fuel tank cap or fill fuel tank while engine is hot or running (allow engine to cool two minutes before refueling). Always fill the tank slowly.

Never disconnect the high pressure discharge hose from the machine while the system is pressurized. To depressurize machine, turn power

and water supply off, then press the gun trigger 2-3 times.

Never permanently engage the trigger mechanism on the gun.

Never operate the machine without all components properly connected to the machine (handle, gun/wand assembly, nozzle, etc.).

Equipment

NOTICE damage.

ALWAYS turn water supply “ON” before turning pressure washer “ON.” Running pump dry causes serious damage.

Do not operate the pressure washer with the inlet water screen removed. Keep screen clear of debris and sediment.

NEVER operate pressure washer with broken or missing parts. Check equipment regularly and repair or replace worn or damaged parts immediately.

Use only the nozzle supplied with this machine.

Never leave the wand unattended while the machine is running.

Never tamper with the engine governor or attempt to alter factory settings. Altering factory settings could damage the unit and will void the warranty.

Always hold gun and wand firmly when starting and operating the machine.

NEVER allow the unit to run with the trigger released (off) for more than one minute. Resulting heat buildup will damage the pump.

NEVER store the pressure washer outdoors or where it could freeze. Freezing temperatures can seriously damage the pump.

Release the trigger when changing from high to low pressure modes. Failure to do so could result in damage to the nozzle.

Keep hose away

! CAUTION from sharp objects. Bursting hoses may cause injury. Examine hoses regularly and replace if damaged. Do not attempt to mend a damaged hose.

www.chpower.com

3

! WARNING

Pressure Washers

Pre-Operation

UNPACKING

Remove the equipment and all parts from the carton. The carton should contain the following.

One pressure washer (pump, engine, cart base).

One cart handle assembly.

One spray gun.

One lance with nozzle.

Spray tips (not included with all models).

One high pressure hose.

One pack of nuts, bolts, and manuals.

One or two bottles of engine oil.

If any parts are missing, DO NOT RETURN THE UNIT TO THE RETAILER. Know the unit’s model number (located on the serial number tag on the pressure washer frame) and call 1-800- 330-0712 for replacement parts.

After unpacking the product, inspect it carefully for any damage that may have occurred during transit. Make sure to tighten fittings and bolts before using the pressure washer.

Do not operate the unit if it’s damaged

during shipping, handling, or use. Damage could result in bursting and cause injury or property damage.

ASSEMBLY

Use 1/2” wrench to assemble pressure washer.

1.Slide the handle assembly over the lower legs of the cart base. Use the standard nut and bolt to secure the legs. See Figure 1.

Figure 2 - Connect detergent hose to brass barb

3.If applicable: insert quick connect tips into rubber holders on front of placard (See Figure 3).

Figure 3 - Insert quick connect tips

4.Secure garden hose (not included) to the inlet connection on pump (See Figure 4).

Figure 5 - Connect high pressure hose to pump

6.Attach the lance with nozzle to the gun (See Figure 6).

Figure 6 - Attach lance to gun

7.Install quick connect tip, if applicable (See Figure 7).

Figure 4 - Secure garden hose



Figure 7 - Quick Connect Tip













5.Connect the high pressure hose to the pump outlet (See Figure 5).

Figure 1 - Assemble Handle

2.Connect clear plastic detergent hose to brass barb on pump (See Figure 2).

www.chpower.com

4
