Brocade TurboIron 24X Configuration Guide

Download

53-1003053-01

30 September 2013

Brocade TurboIron 24X Series

Configuration Guide

Supporting FastIron Software Release 08.0.01

ADX, AnyIO, Brocade, Brocade Assurance, the B-wing symbol, DCX, Fabric OS, ICX, MLX, MyBrocade, OpenScript, VCS, VDX, and Vyatta are registered trademarks, and HyperEdge, The Effortless Network, and The On-Demand Data Center are trademarks of Brocade Communications Systems, Inc., in the United States and/or in other countries. Other brands, products, or service names mentioned may be trademarks of their respective owners.

Notice: This document is for informational purposes only and does not set forth any warranty, expressed or implied, concerning any equipment, equipment feature, or service offered or to be offered by Brocade. Brocade reserves the right to make changes to this document at any time, without notice, and assumes no responsibility for its use. This informational document describes features that may not be currently available. Contact a Brocade sales office for information on feature and product availability. Export of technical data contained in this document may require an export license from the United States government.

The authors and Brocade Communications Systems, Inc. shall have no liability or responsibility to any person or entity with respect to any loss, cost, liability, or damages arising from the information contained in this book or the computer programs that accompany it.

The product described by this document may contain “open source” software covered by the GNU General Public License or other open source license agreements. To find out which open source software is included in Brocade products, view the licensing terms applicable to the open source software, and obtain a copy of the programming source code, please visit http://www.brocade.com/support/oscd.

Brocade Communications Systems, Incorporated

Corporate and Latin American Headquarters Brocade Communications Systems, Inc. 130 Holger Way San Jose, CA 95134 Tel: 1-408-333-8000 Fax: 1-408-333-8101 E-mail: info@brocade.com

European Headquarters Brocade Communications Switzerland Sàrl Centre Swissair Tour B - 4ème étage 29, Route de l'Aéroport Case Postale 105 CH-1215 Genève 15 Switzerland Tel: +41 22 799 5640 Fax: +41 22 799 5641 E-mail: emea-info@brocade.com

Asia-Pacific Headquarters Brocade Communications Systems China HK, Ltd. No. 1 Guanghua Road Chao Yang District Units 2718 and 2818 Beijing 100020, China Tel: +8610 6588 8888 Fax: +8610 6588 9999 E-mail: china-info@brocade.com

Asia-Pacific Headquarters Brocade Communications Systems Co., Ltd. (Shenzhen WFOE) Citic Plaza No. 233 Tian He Road North Unit 1308 – 13th Floor Guangzhou, China Tel: +8620 3891 2000 Fax: +8620 3891 2111 E-mail: china-info@brocade.com

Document History

Title Publication number Summary of changes Date

Brocade TurboIron 24X Series Configuration Guide

53-1003053-01 Release 08.0.00 has been

updated for Release

08.0.01

September 2013

Contents

About This Document

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxi

Device nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxi

What’s new in this document. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxii

Document conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxii

Text formatting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xxxii

Notes, cautions, and danger notices . . . . . . . . . . . . . . . . . . . .xxxii

Notice to the reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxiii

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxiii

Getting technical help or reporting errors . . . . . . . . . . . . . . . . . . . xxxiii

Document feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxiv

Chapter 1 Feature Highlights

Introduction to features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Supported features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Supported management features . . . . . . . . . . . . . . . . . . . . . . . . 1

Supported security features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Supported system-level features . . . . . . . . . . . . . . . . . . . . . . . . . 3

Supported Layer 2 features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Supported Layer 3 features on TurboIron X Series devices . . . . 7

Supported IPv6 management features . . . . . . . . . . . . . . . . . . . . . . . . 8

Unsupported features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Chapter 2 Getting Familiar with Management Applications

Using the management port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

How the management port works. . . . . . . . . . . . . . . . . . . . . . . . 11

CLI Commands for use with the management port. . . . . . . . . .11

Logging on through the CLI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

On-line help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Command completion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Scroll control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Line editing commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Using and port number with CLI commands. . . . . . . . . . . . . . . . . . .15

CLI nomenclature on TurboIron X Series devices . . . . . . . . . . .15

Searching and filtering output from CLI commands . . . . . . . . .15

Using special characters in regular expressions . . . . . . . . . . . .18

Creating an alias for a CLI command . . . . . . . . . . . . . . . . . . . . . 19

Brocade TurboIron 24X Series Configuration Guide iii 53-1003053-01

Logging on through Brocade Network Advisor . . . . . . . . . . . . . . . . .20

Chapter 3 Configuring Basic Software Features

Configuring basic system parameters . . . . . . . . . . . . . . . . . . . . . . . .21

Entering system administration information . . . . . . . . . . . . . . .22

Configuring Simple Network Management Protocol (SNMP)

parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Disabling Syslog messages and traps for CLI access . . . . . . . .26

Configuring an interface as the source for all Telnet packets . 27

Cancelling an outbound Telnet session . . . . . . . . . . . . . . . . . . .28

Specifying a Simple Network Time Protocol (NTPv4) server . . .28

Setting the system clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Limiting broadcast, multicast, and unknown unicast traffic. . . 31

Configuring basic port parameters . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Assigning a port name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Modifying port speed and duplex mode. . . . . . . . . . . . . . . . . . .35

Auto speed detect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Modifying port duplex mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Disabling or re-enabling a port . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Disabling or re-enabling flow control . . . . . . . . . . . . . . . . . . . . .37

Auto-negotiation and advertisement of flow control . . . . . . . . . 37

TurboIron X SeriesConfiguring the Interpacket Gap (IPG) . . . . .38

Changing the Gbps fiber negotiation mode . . . . . . . . . . . . . . . .39

Modifying port priority (QoS) . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Configuring port flap dampening . . . . . . . . . . . . . . . . . . . . . . . .39

Port loop detection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Chapter 4 Operations, Administration, and Maintenance

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Determining the software versions installed and

running on a device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Determining the flash image version running on the device . .48 Determining the image versions installed in flash memory . . . 48

Flash image verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Image file types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Upgrading software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Upgrading the boot code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Upgrading the flash code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Boot code synchronization feature. . . . . . . . . . . . . . . . . . . . . . . 51

Using SNMP to upgrade software . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Changing the block size for TFTP file transfers . . . . . . . . . . . . . . . . . 52

Rebooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Displaying the boot preference . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

iv Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Loading and saving configuration files . . . . . . . . . . . . . . . . . . . . . . .54

Replacing the startup configuration with the

running configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Replacing the running configuration with the

startup configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Logging changes to the startup-config file. . . . . . . . . . . . . . . . .55

Copying a configuration file to or from a TFTP server . . . . . . . . 55

Dynamic configuration loading . . . . . . . . . . . . . . . . . . . . . . . . . .56

Maximum file sizes for startup-config file and running-config . 58

Scheduling a system reload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

Reloading at a specific time . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

Reloading after a specific amount of time. . . . . . . . . . . . . . . . .59

Displaying the amount of time remaining

before a scheduled reload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Canceling a scheduled reload. . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Diagnostic error codes and remedies for TFTP transfers. . . . . . . . .60

Chapter 5 Securing Access to Management Functions

Securing access methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Restricting remote access to management functions . . . . . . . . . . .65

Using ACLs to restrict remote access . . . . . . . . . . . . . . . . . . . . .65

Defining the console idle time . . . . . . . . . . . . . . . . . . . . . . . . . .67

Restricting remote access to the device to specific IP addresses68 Restricting access to the device based on IP or

MAC address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

Specifying the maximum number of login attempts

for Telnet access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70

Restricting remote access to the device to specific

VLAN IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Designated VLAN for Telnet management sessions to a Layer 2

Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Device management security . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Disabling specific access methods. . . . . . . . . . . . . . . . . . . . . . . 72

Setting passwords. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Setting a Telnet password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Setting passwords for management privilege levels . . . . . . . . . 74

Recovering from a lost password . . . . . . . . . . . . . . . . . . . . . . . . 77

Displaying the SNMP community string . . . . . . . . . . . . . . . . . . . 77

Specifying a minimum password length. . . . . . . . . . . . . . . . . . . 77

Setting up local user accounts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

Enhancements to username and password . . . . . . . . . . . . . . .78

Configuring a local user account . . . . . . . . . . . . . . . . . . . . . . . .82

Create password option. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83

Changing a local user password . . . . . . . . . . . . . . . . . . . . . . . . .84

Brocade TurboIron 24X Series Configuration Guide v 53-1003053-01

Configuring TACACS/TACACS+ security . . . . . . . . . . . . . . . . . . . . . . .84

How TACACS+ differs from TACACS. . . . . . . . . . . . . . . . . . . . . . .85

TACACS/TACACS+ authentication, authorization,

and accounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

TACACS authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

TACACS/TACACS+ configuration considerations . . . . . . . . . . . .89

Enabling TACACS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89

Identifying the TACACS/TACACS+ servers. . . . . . . . . . . . . . . . . . 90

Specifying different servers for individual AAA functions . . . . . 90

Setting optional TACACS/TACACS+ parameters. . . . . . . . . . . . .91

Configuring authentication-method lists for TACACS/TACACS+ 92

Configuring TACACS+ authorization . . . . . . . . . . . . . . . . . . . . . .94

Configuring TACACS+ accounting . . . . . . . . . . . . . . . . . . . . . . . . 97

Configuring an interface as the source for all

TACACS/TACACS+ packets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98

Displaying TACACS/TACACS+ statistics and

configuration information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99

Configuring RADIUS security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100

RADIUS authentication, authorization, and accounting . . . . .100

RADIUS configuration considerations. . . . . . . . . . . . . . . . . . . .103

RADIUS configuration procedure . . . . . . . . . . . . . . . . . . . . . . .104

Configuring Brocade-specific attributes on the RADIUS server104

Enabling SNMP to configure RADIUS . . . . . . . . . . . . . . . . . . . .105

Identifying the RADIUS server to the device. . . . . . . . . . . . . . .106

Specifying different servers for individual AAA functions . . . .106

Configuring a RADIUS server per port . . . . . . . . . . . . . . . . . . .106

Mapping a RADIUS server to individual ports . . . . . . . . . . . . . 107

Setting RADIUS parameters . . . . . . . . . . . . . . . . . . . . . . . . . . .108

Configuring authentication-method lists for RADIUS. . . . . . . .109

Configuring RADIUS authorization . . . . . . . . . . . . . . . . . . . . . .111

Configuring RADIUS accounting . . . . . . . . . . . . . . . . . . . . . . . .113

Configuring an interface as the source for all

RADIUS packets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114

Displaying RADIUS configuration information . . . . . . . . . . . . .114

Configuring authentication-method lists . . . . . . . . . . . . . . . . . . . . .115

Configuration considerations for authentication- method lists116

Examples of authentication-method lists. . . . . . . . . . . . . . . . .117

Chapter 6 Configuring SSH2 and SCP

SSH version 2 support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119

Tested SSH2 clients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120

Supported features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120

Unsupported features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120

AES encryption for SSH2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121

Configuring SSH2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121

Recreating SSH keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122

Generating a host key pair . . . . . . . . . . . . . . . . . . . . . . . . . . . .122

Configuring DSA challenge-response authentication . . . . . . .123

vi Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Setting optional parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125

Setting the number of SSH authentication retries . . . . . . . . .126

Deactivating user authentication . . . . . . . . . . . . . . . . . . . . . . .126

Enabling empty password logins. . . . . . . . . . . . . . . . . . . . . . . .126

Setting the SSH port number . . . . . . . . . . . . . . . . . . . . . . . . . .127

Setting the SSH login timeout value. . . . . . . . . . . . . . . . . . . . .127

Designating an interface as the source for all SSH

packets (Layer 3 code only). . . . . . . . . . . . . . . . . . . . . . . . . . . .127

Configuring the maximum idle time for SSH sessions . . . . . .128

Filtering SSH access using ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . .128

Terminating an active SSH connection . . . . . . . . . . . . . . . . . . . . . .128

Displaying SSH connection information . . . . . . . . . . . . . . . . . . . . .128

Using Secure copy with SSH2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130

Enabling and disabling SCP . . . . . . . . . . . . . . . . . . . . . . . . . . .130

Example file transfers using SCP . . . . . . . . . . . . . . . . . . . . . . .130

Chapter 7 Configuring IPv6 Connectivity

IPv6 addressing overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .133

IPv6 address types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134

IPv6 stateless autoconfiguration . . . . . . . . . . . . . . . . . . . . . . .136

IPv6 CLI command support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .136

Configuring an IPv6 host address on a Layer 2 switch. . . . . . . . . .137

Enabling IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138

Configuring a global or site-local IPv6 address with a

manually configured interface ID . . . . . . . . . . . . . . . . . . . . . . .138

Configuring the management port for an IPv6 automatic address

configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138

Configuring basic IPv6 connectivity on a Layer 3 switch . . . . . . . .138

Configuring IPv6 on each router interface . . . . . . . . . . . . . . . .138

IPv6 management (IPv6 host support) . . . . . . . . . . . . . . . . . . . . . .141

Restricting SNMP access to an IPv6 node. . . . . . . . . . . . . . . .141

Specifying an IPv6 SNMP trap receiver . . . . . . . . . . . . . . . . . .141

SNMP V3 over IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141

SNTP over IPv6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142

Secure Shell, SCP, and IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . .142

IPv6 Telnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142

Configuring name-to-IPv6 address resolution using IPv6 DNS

resolver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .143

Defining an IPv6 DNS entry. . . . . . . . . . . . . . . . . . . . . . . . . . . .143

Using the IPv6 copy command . . . . . . . . . . . . . . . . . . . . . . . . .143

Using the IPv6 ncopy command . . . . . . . . . . . . . . . . . . . . . . . .145

IPv6 ping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147

Configuring an IPv6 Syslog server . . . . . . . . . . . . . . . . . . . . . .148

Viewing IPv6 SNMP server addresses . . . . . . . . . . . . . . . . . . .149

Disabling IPv6 on a Layer 2 switch. . . . . . . . . . . . . . . . . . . . . .149

Brocade TurboIron 24X Series Configuration Guide vii 53-1003053-01

Clearing global IPv6 information . . . . . . . . . . . . . . . . . . . . . . . . . . .150

Clearing the IPv6 cache. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150

Clearing IPv6 neighbor information . . . . . . . . . . . . . . . . . . . . .150

Clearing IPv6 traffic statistics . . . . . . . . . . . . . . . . . . . . . . . . . .151

Displaying global IPv6 information. . . . . . . . . . . . . . . . . . . . . . . . . .151

Displaying IPv6 cache information . . . . . . . . . . . . . . . . . . . . . .151

Displaying IPv6 interface information. . . . . . . . . . . . . . . . . . . .152

Displaying IPv6 neighbor information. . . . . . . . . . . . . . . . . . . .154

Displaying IPv6 TCP information . . . . . . . . . . . . . . . . . . . . . . . .155

Displaying IPv6 traffic statistics . . . . . . . . . . . . . . . . . . . . . . . .158

Chapter 8 Securing SNMP Access

SNMP overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163

Establishing SNMP community strings . . . . . . . . . . . . . . . . . . . . . .164

Encryption of SNMP community strings . . . . . . . . . . . . . . . . . .164

Adding an SNMP community string . . . . . . . . . . . . . . . . . . . . .164

Displaying the SNMP community strings . . . . . . . . . . . . . . . . .166

Configuring your NMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .166

Configuring SNMP version 3 . . . . . . . . . . . . . . . . . . . . . . . . . . .167

Defining the engine id . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167

Defining an SNMP group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168

Defining an SNMP user account. . . . . . . . . . . . . . . . . . . . . . . .169

Defining SNMP views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170

SNMP version 3 traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Defining an SNMP group and specifying which

view is notified of traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Defining the UDP port for SNMP v3 traps . . . . . . . . . . . . . . . .172

Trap MIB changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173

Specifying an IPv6 host as an SNMP trap receiver . . . . . . . . .173

Displaying SNMP Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Displaying the Engine ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Displaying SNMP groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Displaying user information. . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Interpreting varbinds in report packets . . . . . . . . . . . . . . . . . .175

SNMP v3 Configuration examples . . . . . . . . . . . . . . . . . . . . . . . . . .175

Simple SNMP v3 configuration . . . . . . . . . . . . . . . . . . . . . . . . .175

More detailed SNMP v3 configuration . . . . . . . . . . . . . . . . . . . 176

Chapter 9 Enabling the Foundry Discovery Protocol and Reading Cisco

Discovery Protocol Packets

Using FDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

Configuring FDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

Displaying FDP information. . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Clearing FDP and CDP information. . . . . . . . . . . . . . . . . . . . . .181

viii Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Reading CDP packets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .182

Enabling interception of CDP packets globally . . . . . . . . . . . .182

Enabling interception of CDP packets on an interface . . . . . .182

Displaying CDP information. . . . . . . . . . . . . . . . . . . . . . . . . . . .182

Clearing CDP information . . . . . . . . . . . . . . . . . . . . . . . . . . . . .184

Chapter 10 Configuring LLDP

Terms used in this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .187

LLDP overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .188

Benefits of LLDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .189

General operating principles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .189

Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .189

LLDP packets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190

TLV support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190

MIB support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .193

Syslog messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .194

Configuring LLDP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .194

Configuration notes and considerations . . . . . . . . . . . . . . . . .194

Enabling and disabling LLDP. . . . . . . . . . . . . . . . . . . . . . . . . . .195

Changing a port LLDP operating mode . . . . . . . . . . . . . . . . . .195

Specifying the maximum number of LLDP neighbors. . . . . . .196

Enabling LLDP SNMP notifications and syslog messages . . . 197 Changing the minimum time between LLDP transmissions . .198 Changing the interval between regular LLDP transmissions .199

Changing the holdtime multiplier for transmit TTL . . . . . . . . .199

Changing the minimum time between port reinitializations. .199

LLDP TLVs advertised by the device . . . . . . . . . . . . . . . . . . . . .200

Displaying LLDP statistics and configuration settings. . . . . . .205

LLDP configuration summary . . . . . . . . . . . . . . . . . . . . . . . . . .205

LLDP statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .206

LLDP neighbors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .207

LLDP neighbors detail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .208

LLDP configuration details . . . . . . . . . . . . . . . . . . . . . . . . . . . .210

Resetting LLDP statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .211

Clearing cached LLDP neighbor information. . . . . . . . . . . . . . . . . .211

Chapter 11 Monitoring Hardware Components

Hardware support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .213

Brocade TurboIron 24X Series Configuration Guide ix 53-1003053-01

Digital optical monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .213

Supported media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .213

Media not supported . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .214

Supported media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .214

Media not supported . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .214

Configuration limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .214

Enabling digital optical monitoring . . . . . . . . . . . . . . . . . . . . . .214

Setting the alarm interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . .215

Displaying information about installed media . . . . . . . . . . . . .215

Viewing optical monitoring information . . . . . . . . . . . . . . . . . .216

Syslog messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .218

Chapter 12 Using Syslog

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .221

Displaying Syslog messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .222

Enabling real-time display of Syslog messages. . . . . . . . . . . .222

Enabling real-time display for a Telnet or SSH session . . . . . .222

Show log on all terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . .223

Configuring the Syslog service . . . . . . . . . . . . . . . . . . . . . . . . . . . . .223

Displaying the Syslog configuration . . . . . . . . . . . . . . . . . . . . .223

Disabling or re-enabling Syslog. . . . . . . . . . . . . . . . . . . . . . . . .227

Specifying a Syslog server. . . . . . . . . . . . . . . . . . . . . . . . . . . . .227

Specifying an additional Syslog server. . . . . . . . . . . . . . . . . . .227

Disabling logging of a message level . . . . . . . . . . . . . . . . . . . .228

Changing the number of entries the local buffer can hold. . .228

Changing the log facility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .228

Displaying Interface names in Syslog messages. . . . . . . . . . .229

Displaying TCP or UDP port numbers in Syslog messages . . .230

Clearing the Syslog messages from the local buffer . . . . . . . .230

Appendix 13 Network Monitoring

Basic management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .231

Viewing system information . . . . . . . . . . . . . . . . . . . . . . . . . . .231

Viewing configuration information . . . . . . . . . . . . . . . . . . . . . .232

Viewing port statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .232

Viewing STP statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .234

Clearing statistics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .234

Traffic counters for outbound traffic. . . . . . . . . . . . . . . . . . . . .235

RMON support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .238

Maximum number of entries allowed in the

RMON control table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .238

Statistics (RMON group 1). . . . . . . . . . . . . . . . . . . . . . . . . . . . .238

History (RMON group 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .240

Alarm (RMON group 3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .241

Event (RMON group 9). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .241

x Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

sFlow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241

sFlow support for IPv6 packets. . . . . . . . . . . . . . . . . . . . . . . . .242

Configuration considerations . . . . . . . . . . . . . . . . . . . . . . . . . .243

Configuring and enabling sFlow . . . . . . . . . . . . . . . . . . . . . . . .244

Displaying sFlow information . . . . . . . . . . . . . . . . . . . . . . . . . .249

Configuring a utilization list for an uplink port . . . . . . . . . . . . . . . .251

Command syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .252

Displaying utilization percentages for an uplink . . . . . . . . . . .252

Chapter 14 Configuring Basic Layer 2 Features

Enabling or disabling the Spanning Tree Protocol (STP). . . . . . . . .255

Modifying STP bridge and port parameters . . . . . . . . . . . . . . .256

Changing the MAC age time and disabling MAC address learning256

Disabling the automatic learning of MAC addresses . . . . . . .256

Displaying the MAC address table . . . . . . . . . . . . . . . . . . . . . .257

Configuring static MAC entries. . . . . . . . . . . . . . . . . . . . . . . . . . . . .257

Multi-port static MAC address. . . . . . . . . . . . . . . . . . . . . . . . . .258

Configuring VLAN-based static MAC entries . . . . . . . . . . . . . . . . . .259

Enabling port-based VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .259

Assigning IEEE 802.1Q tagging to a port . . . . . . . . . . . . . . . . .260

Defining MAC address filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .260

Configuration notes and limitations . . . . . . . . . . . . . . . . . . . . .261

Command syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .261

Enabling logging of management traffic

permitted by MAC filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .263

MAC address filter override for 802.1X-enabled ports. . . . . . . . . .264

MAC address filter override configuration notes . . . . . . . . . . .264

MAC address filter override configuration syntax . . . . . . . . . .264

Displaying and modifying system parameter default settings . . . .265

Configuration considerations . . . . . . . . . . . . . . . . . . . . . . . . . .265

Displaying system parameter default values . . . . . . . . . . . . . .265

Modifying system parameter default values . . . . . . . . . . . . . .267

Egress buffer thresholds for QoS priorities . . . . . . . . . . . . . . . . . . .267

Cut-Through Switching Support. . . . . . . . . . . . . . . . . . . . . . . . .269

Default settings for egress buffer thresholds . . . . . . . . . . . . .269

Disabling and re-enabling the default settings

for egress buffer thresholds . . . . . . . . . . . . . . . . . . . . . . . . . . .269

Setting the egress buffer threshold for all QoS

priorities on a port or group of ports . . . . . . . . . . . . . . . . . . . .270

Setting the egress buffer threshold for a specific

QoS priority on a port or group of ports . . . . . . . . . . . . . . . . . .270

Link Fault Signaling (LFS) for 10G . . . . . . . . . . . . . . . . . . . . . . . . . . 271

Jumbo frame support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .272

Brocade TurboIron 24X Series Configuration Guide xi 53-1003053-01

Chapter 15 Configuring Metro Features

Topology groups. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .273

Master VLAN and member VLANs . . . . . . . . . . . . . . . . . . . . . .273

Control ports and free ports . . . . . . . . . . . . . . . . . . . . . . . . . . . 274

Configuration considerations . . . . . . . . . . . . . . . . . . . . . . . . . . 274

Configuring a topology group . . . . . . . . . . . . . . . . . . . . . . . . . .275

Displaying topology group information . . . . . . . . . . . . . . . . . . . 276

Metro Ring Protocol (MRP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .277

Configuration notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .279

MRP rings without shared interfaces (MRP Phase 1) . . . . . . .279

MRP rings with shared interfaces (MRP Phase 2). . . . . . . . . .280

Ring initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .282

How ring breaks are detected and healed . . . . . . . . . . . . . . . .285

Alarm RHP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .288

Master VLANs and customer VLANs. . . . . . . . . . . . . . . . . . . . .289

Configuring MRP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .291

Using MRP diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .293

Displaying MRP information . . . . . . . . . . . . . . . . . . . . . . . . . . .294

MRP CLI example. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .296

Virtual Switch Redundancy Protocol (VSRP) . . . . . . . . . . . . . . . . . .298

Configuration notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .300

Layer 2 and Layer 3 redundancy . . . . . . . . . . . . . . . . . . . . . . .300

Master election and failover . . . . . . . . . . . . . . . . . . . . . . . . . . .300

VSRP-Aware security features. . . . . . . . . . . . . . . . . . . . . . . . . .305

VSRP parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .305

Configuring basic VSRP parameters. . . . . . . . . . . . . . . . . . . . .308

Configuring optional VSRP parameters . . . . . . . . . . . . . . . . . .309

Displaying VSRP information. . . . . . . . . . . . . . . . . . . . . . . . . . .318

VSRP fast start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .321

VSRP and MRP signaling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .322

Chapter 16 Configuring Uni-Directional Link Detection (UDLD)

UDLD overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .325

Configuration considerations . . . . . . . . . . . . . . . . . . . . . . . . . .325

Enabling UDLD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .326

Changing the Keepalive interval . . . . . . . . . . . . . . . . . . . . . . . .326

Changing the Keepalive retries . . . . . . . . . . . . . . . . . . . . . . . . .326

UDLD for tagged ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .327

Displaying UDLD information . . . . . . . . . . . . . . . . . . . . . . . . . .327

Clearing UDLD statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .329

Chapter 17 Configuring Trunk Groups and Dynamic Link Aggregation

Trunk group overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .331

Trunk group connectivity to a server. . . . . . . . . . . . . . . . . . . . .332

Trunk group rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .333

Trunk group configuration examples . . . . . . . . . . . . . . . . . . . .334

Flexible trunk group membership. . . . . . . . . . . . . . . . . . . . . . .334

Trunk group load sharing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .335

xii Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring a trunk group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .336

CLI syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .336

Example 1: Configuring the trunk groups shown in Figure 75337 Example 2: Configuring a trunk group that spans

two Gbps Ethernet modules in a chassis device. . . . . . . . . . .338

Example 3: Configuring a multi-slot trunk group

with one port per module . . . . . . . . . . . . . . . . . . . . . . . . . . . . .338

Example 4: Configuring a trunk group of 10 Gbps

Ethernet ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .338

Additional trunking options . . . . . . . . . . . . . . . . . . . . . . . . . . . .339

Displaying trunk group configuration information . . . . . . . . . . . . .343

Dynamic link aggregation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .344

Examples of valid LACP trunk groups . . . . . . . . . . . . . . . . . . . .345

Configuration notes and limitations . . . . . . . . . . . . . . . . . . . . .345

Adaptation to trunk disappearance . . . . . . . . . . . . . . . . . . . . .347

Flexible trunk eligibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .347

Enabling dynamic link aggregation. . . . . . . . . . . . . . . . . . . . . .348

How changing the VLAN membership of a port affects

trunk groups and dynamic keys . . . . . . . . . . . . . . . . . . . . . . . .350

Link aggregation parameters . . . . . . . . . . . . . . . . . . . . . . . . . .350

Displaying and determining the status of aggregate links . . . . . . .355

Events that affect the status of ports in an aggregate link. . .355

Displaying link aggregation and port status information . . . .356

Displaying LACP status information . . . . . . . . . . . . . . . . . . . . .358

Clearing the negotiated aggregate links table . . . . . . . . . . . . . . . .358

Configuring single link LACP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .358

Configuration notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .359

CLI syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .359

Chapter 18 Configuring Virtual LANs (VLANs)

VLAN overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .361

Types of VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .361

Default VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .366

802.1Q tagging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .367

Spanning Tree Protocol (STP) . . . . . . . . . . . . . . . . . . . . . . . . . .369

Virtual routing interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .370

VLAN and virtual routing interface groups . . . . . . . . . . . . . . . .371

Dynamic, static, and excluded port membership . . . . . . . . . .372

Super aggregated VLANs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 374

Trunk group ports and VLAN membership . . . . . . . . . . . . . . . . 374

Brocade TurboIron 24X Series Configuration Guide xiii 53-1003053-01

Routing between VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 374

Virtual routing interfaces (Layer 3 Switches only) . . . . . . . . . . 374

Routing between VLANs using virtual routing

interfaces (Layer 3 Switches only) . . . . . . . . . . . . . . . . . . . . . .375

Dynamic port assignment (Layer 2 Switches

and Layer 3 Switches) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 376

Assigning a different VLAN ID to the default VLAN . . . . . . . . . 376

Assigning different VLAN IDs to reserved VLANs 4091 and 4092376

Assigning trunk group ports . . . . . . . . . . . . . . . . . . . . . . . . . . .377

Configuring port-based VLANs . . . . . . . . . . . . . . . . . . . . . . . . .378

Modifying a port-based VLAN . . . . . . . . . . . . . . . . . . . . . . . . . .381

Enable spanning tree on a VLAN . . . . . . . . . . . . . . . . . . . . . . .382

Configuring IP subnet, IPX network andprotocol-based VLANs . . .383

Configuration example. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .383

Routing between VLANs using virtual routing

interfaces (Layer 3 Switches only) . . . . . . . . . . . . . . . . . . . . . . . . . .385

Configuring uplink ports within a port-based VLAN . . . . . . . . . . . .391

Configuration considerations . . . . . . . . . . . . . . . . . . . . . . . . . .391

Configuration syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .391

Configuring the same IP subnet address on multiple

port-based VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .392

Configuring VLAN groups and virtual routing interface groups . . .395

Configuring a VLAN group . . . . . . . . . . . . . . . . . . . . . . . . . . . . .395

Configuring a virtual routing interface group . . . . . . . . . . . . . .397

Displaying the VLAN group and virtual routing

interface group information . . . . . . . . . . . . . . . . . . . . . . . . . . .398

Allocating memory for more VLANs or virtual routing interfaces398

Configuring super aggregated VLANs . . . . . . . . . . . . . . . . . . . . . . .399

Configuration note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .403

Configuring aggregated VLANs . . . . . . . . . . . . . . . . . . . . . . . . .403

Verifying the configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . .404

Complete CLI examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .404

Configuring 802.1Q-in-Q tagging . . . . . . . . . . . . . . . . . . . . . . . . . . .407

Configuration rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .408

Enabling 802.1Q-in-Q tagging. . . . . . . . . . . . . . . . . . . . . . . . . .408

Example configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .409

Configuring private VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .411

Configuration notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .412

Configuration notes and limitations . . . . . . . . . . . . . . . . . . . . .413

Command syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 413

CLI example for Figure 52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .415

Dual-mode VLAN ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 415

Displaying VLAN information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .418

Displaying VLANs in alphanumeric order . . . . . . . . . . . . . . . . .418

Displaying system-wide VLAN information . . . . . . . . . . . . . . . .419

Displaying VLAN information for specific ports . . . . . . . . . . . .420

xiv Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Chapter 19 Configuring Port Mirroring and Monitoring

Mirroring support by platform . . . . . . . . . . . . . . . . . . . . . . . . . . . . .423

Configuring port mirroring and monitoring . . . . . . . . . . . . . . . . . . .423

Configuration notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .424

Monitoring a port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .425

Monitoring an individual trunk port . . . . . . . . . . . . . . . . . . . . .425

ACL-based inbound mirroring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .426

Creating an ACL-based inbound mirror clause . . . . . . . . . . . . .426

MAC filter-based mirroring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .430

Configuring MAC filter-based mirroring. . . . . . . . . . . . . . . . . . .430

Chapter 20 Configuring IP

Basic configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .433

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .433

IP interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .434

IP packet flow through a Layer 3 Switch. . . . . . . . . . . . . . . . . .435

IP route exchange protocols . . . . . . . . . . . . . . . . . . . . . . . . . . .439

IP multicast protocols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .440

IP interface redundancy protocols . . . . . . . . . . . . . . . . . . . . . .440

Access Control Lists and IP access policies. . . . . . . . . . . . . . .440

Basic IP parameters and defaults – Layer 3 Switches. . . . . . . . . .441

When parameter changes take effect . . . . . . . . . . . . . . . . . . .441

IP global parameters – Layer 3 Switches . . . . . . . . . . . . . . . . .442

IP interface parameters – Layer 3 Switches . . . . . . . . . . . . . .445

Basic IP parameters and defaults – Layer 2 Switches. . . . . . . . . .446

IP global parameters – Layer 2 Switches . . . . . . . . . . . . . . . . .446

Interface IP parameters – Layer 2 Switches . . . . . . . . . . . . . .447

Configuring IP parameters – Layer 3 Switches . . . . . . . . . . . . . . . . 447

Configuring IP addresses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .448

Configuring 31-bit subnet masks on point-to-point networks.450

Configuring packet parameters . . . . . . . . . . . . . . . . . . . . . . . .452

Changing the router ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .455

Specifying a single source interface for Telnet,

TACACS/TACACS+, or RADIUS Packets . . . . . . . . . . . . . . . . . . .456

Configuring ARP parameters. . . . . . . . . . . . . . . . . . . . . . . . . . .458

Configuring forwarding parameters . . . . . . . . . . . . . . . . . . . . .462

Disabling ICMP messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . .463

Configuring static routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .465

Configuring a default network route . . . . . . . . . . . . . . . . . . . . . 473

Configuring IP load sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 474

Configuring IRDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .477

Configuring RARP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .479

Configuring UDP broadcast and IP helper parameters . . . . . .481

Configuring BootP/DHCP relay parameters . . . . . . . . . . . . . . .483

Brocade TurboIron 24X Series Configuration Guide xv 53-1003053-01

Configuring IP parameters – Layer 2 Switches . . . . . . . . . . . . . . . .484

Configuring the management IP address and specifying

the default gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .485

Configuring Domain Name Server (DNS) resolver. . . . . . . . . .486

Changing the TTL threshold . . . . . . . . . . . . . . . . . . . . . . . . . . .487

Configuring DHCP Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .488

Displaying IP configuration information and statistics . . . . . . . . . .492

Changing the network mask display to prefix format . . . . . . .492

Displaying IP information – Layer 3 Switches . . . . . . . . . . . . .492

Displaying IP information – Layer 2 Switches . . . . . . . . . . . . .506

Chapter 21 Configuring Spanning Tree Protocol (STP) Related Features

STP overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 511

Configuring standard STP parameters. . . . . . . . . . . . . . . . . . . . . . .511

STP parameters and defaults . . . . . . . . . . . . . . . . . . . . . . . . . .512

Enabling or disabling the Spanning Tree Protocol (STP) . . . . .513

Changing STP bridge and port parameters . . . . . . . . . . . . . . .514

STP protection enhancement . . . . . . . . . . . . . . . . . . . . . . . . . . 516

Displaying STP information . . . . . . . . . . . . . . . . . . . . . . . . . . . .517

Configuring STP related features . . . . . . . . . . . . . . . . . . . . . . . . . . .524

802.1W Rapid Spanning Tree (RSTP). . . . . . . . . . . . . . . . . . . .525

802.1W Draft 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .562

Single Spanning Tree (SSTP) . . . . . . . . . . . . . . . . . . . . . . . . . . .566

PVST/PVST+ compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .568

Overview of PVST and PVST+ . . . . . . . . . . . . . . . . . . . . . . . . . .569

VLAN tags and dual mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . .570

Configuring PVST+ support . . . . . . . . . . . . . . . . . . . . . . . . . . . .571

Displaying PVST+ support information. . . . . . . . . . . . . . . . . . .571

Configuration examples. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .572

PVRST compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .575

BPDU guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .575

Enabling BPDU protection by port. . . . . . . . . . . . . . . . . . . . . . .575

Re-enabling ports disabled by BPDU guard . . . . . . . . . . . . . . .576

Displaying the BPDU guard status . . . . . . . . . . . . . . . . . . . . . . 576

Example console messages . . . . . . . . . . . . . . . . . . . . . . . . . . .577

Root guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .577

Enabling STP root guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .578

Displaying the STP root guard . . . . . . . . . . . . . . . . . . . . . . . . . .578

802.1s Multiple Spanning Tree Protocol . . . . . . . . . . . . . . . . . . . . .578

Multiple spanning-tree regions . . . . . . . . . . . . . . . . . . . . . . . . .578

Configuration notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .580

Configuring MSTP mode and scope . . . . . . . . . . . . . . . . . . . . .580

Configuring additional MSTP parameters . . . . . . . . . . . . . . . .581

Chapter 22 Configuring RIP

RIP overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .591

ICMP host unreachable message for undeliverable ARPs . . .591

xvi Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

RIP parameters and defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .592

RIP global parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .592

RIP interface parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . .593

Configuring RIP parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .593

Enabling RIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .593

Configuring metric parameters . . . . . . . . . . . . . . . . . . . . . . . . .594

Changing the administrative distance. . . . . . . . . . . . . . . . . . .595

Configuring redistribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . .595

Configuring route learning and advertising parameters . . . . .598

Changing the route loop prevention method . . . . . . . . . . . . . .599

Suppressing RIP route advertisement on a VRRP

or VRRPE backup interface . . . . . . . . . . . . . . . . . . . . . . . . . . . .600

Configuring RIP route filters . . . . . . . . . . . . . . . . . . . . . . . . . . .600

Displaying RIP filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .601

Displaying CPU utilization statistics . . . . . . . . . . . . . . . . . . . . . . . . .602

Chapter 23 Configuring OSPF Version 2 (IPv4)

Overview of OSPF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .605

OSPF point-to-point Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 607

Designated routers in multi-access networks . . . . . . . . . . . . .608

Designated router election in multi-access networks . . . . . . .608

OSPF RFC 1583 and 2178 compliance . . . . . . . . . . . . . . . . . .609

Reduction of equivalent AS External LSAs . . . . . . . . . . . . . . . .610

Support for OSPF RFC 2328 Appendix E . . . . . . . . . . . . . . . . .612

Dynamic OSPF activation and configuration . . . . . . . . . . . . . .613

Brocade TurboIron 24X Series Configuration Guide xvii 53-1003053-01

Configuring OSPF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .613

Configuration rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .614

OSPF parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .614

Enable OSPF on the router . . . . . . . . . . . . . . . . . . . . . . . . . . . .615

Assign OSPF areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 616

Assigning an area range (optional). . . . . . . . . . . . . . . . . . . . . .620

Assigning interfaces to an area . . . . . . . . . . . . . . . . . . . . . . . .620

Modify interface defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . .620

Change the timer for OSPF authentication changes. . . . . . . .623

Block flooding of outbound LSAs on specific OSPF interfaces624

Assign virtual links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .624

Modify virtual link parameters . . . . . . . . . . . . . . . . . . . . . . . . .626

Changing the reference bandwidth for the cost on

OSPF interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .627

Define redistribution filters . . . . . . . . . . . . . . . . . . . . . . . . . . . .629

Prevent specific OSPF routes from being installed in the

IP route table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .631

Modify default metric for redistribution . . . . . . . . . . . . . . . . . .634

Enable route redistribution . . . . . . . . . . . . . . . . . . . . . . . . . . . .635

Disable or re-enable load sharing. . . . . . . . . . . . . . . . . . . . . . .636

Configure external route summarization . . . . . . . . . . . . . . . . .637

Configure default route origination. . . . . . . . . . . . . . . . . . . . . .639

Modify SPF timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .640

Modify redistribution metric type . . . . . . . . . . . . . . . . . . . . . . .640

Modify administrative distance. . . . . . . . . . . . . . . . . . . . . . . . .641

Configure OSPF group Link State Advertisement

(LSA) pacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .642

Modify OSPF traps generated . . . . . . . . . . . . . . . . . . . . . . . . . .642

Modify OSPF standard compliance setting . . . . . . . . . . . . . . .643

Modify exit overflow interval . . . . . . . . . . . . . . . . . . . . . . . . . . .643

Specifying the types of OSPF Syslog messages to log . . . . . .644

Clearing OSPF information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .644

Clearing OSPF neighbor information . . . . . . . . . . . . . . . . . . . .644

Clearing OSPF topology information . . . . . . . . . . . . . . . . . . . . .645

Clearing redistributed routes from the OSPF routing table . . .645

Clearing information for OSPF areas . . . . . . . . . . . . . . . . . . . .645

Displaying OSPF information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .646

Displaying general OSPF configuration information . . . . . . . .646

Displaying CPU utilization statistics . . . . . . . . . . . . . . . . . . . . . 647

Displaying OSPF area information . . . . . . . . . . . . . . . . . . . . . .649

Displaying OSPF neighbor information. . . . . . . . . . . . . . . . . . .649

Displaying OSPF interface information. . . . . . . . . . . . . . . . . . .651

Displaying OSPF route information . . . . . . . . . . . . . . . . . . . . . .653

Displaying OSPF external link state information . . . . . . . . . . .655

Displaying OSPF link state information . . . . . . . . . . . . . . . . . .656

Displaying the data in an LSA . . . . . . . . . . . . . . . . . . . . . . . . . .656

Displaying OSPF virtual neighbor information . . . . . . . . . . . . .657

Displaying OSPF virtual link information . . . . . . . . . . . . . . . . .657

Displaying OSPF ABR and ASBR information. . . . . . . . . . . . . .657

Displaying OSPF trap status . . . . . . . . . . . . . . . . . . . . . . . . . . .658

xviii Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Chapter 24 Configuring BGP4

Overview of BGP4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .660

Relationship between the BGP4 route table and the IP route table 660

How BGP4 selects a path for a route . . . . . . . . . . . . . . . . . . . .661

BGP4 message types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .663

Basic configuration and activation for BGP4 . . . . . . . . . . . . . . . . .665

Note regarding disabling BGP4. . . . . . . . . . . . . . . . . . . . . . . . .665

BGP4 parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .666

When parameter changes take effect . . . . . . . . . . . . . . . . . . .667

Memory considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .668

Memory configuration options obsoleted by dynamic memory669

Basic configuration tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .669

Enabling BGP4 on the router . . . . . . . . . . . . . . . . . . . . . . . . . .669

Changing the router ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .669

Setting the local AS number . . . . . . . . . . . . . . . . . . . . . . . . . . .670

Adding a loopback interface . . . . . . . . . . . . . . . . . . . . . . . . . . .670

Adding BGP4 neighbors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .671

Adding a BGP4 peer group . . . . . . . . . . . . . . . . . . . . . . . . . . . .677

Optional configuration tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .681

Changing the Keep Alive Time and Hold Time . . . . . . . . . . . . .681

Changing the BGP4 next-hop update timer . . . . . . . . . . . . . . .682

Enabling fast external fallover. . . . . . . . . . . . . . . . . . . . . . . . . .682

Changing the maximum number of paths for

BGP4 load sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .683

Customizing BGP4 load sharing . . . . . . . . . . . . . . . . . . . . . . . .684

Specifying a list of networks to advertise. . . . . . . . . . . . . . . . .685

Changing the default local preference . . . . . . . . . . . . . . . . . . .686

Using the IP default route as a valid next hop for

a BGP4 route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .687

Advertising the default route. . . . . . . . . . . . . . . . . . . . . . . . . . .687

Changing the default MED (Metric) used for

route redistribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .687

Enabling next-hop recursion . . . . . . . . . . . . . . . . . . . . . . . . . . .688

Changing administrative distances . . . . . . . . . . . . . . . . . . . . .691

Requiring the first AS to be the neighbor AS . . . . . . . . . . . . . .692

Disabling or re-enabling comparison of the AS-Path length . .692

Enabling or disabling comparison of the router IDs . . . . . . . .693

Configuring the Layer 3 Switch to always compare

Multi-Exit Discriminators (MEDs) . . . . . . . . . . . . . . . . . . . . . . .693

Treating missing MEDs as the worst MEDs . . . . . . . . . . . . . . .694

Configuring route reflection parameters . . . . . . . . . . . . . . . . .694

Aggregating routes advertised to BGP4 neighbors . . . . . . . . .698

Brocade TurboIron 24X Series Configuration Guide xix 53-1003053-01

Modifying redistribution parameters . . . . . . . . . . . . . . . . . . . . . . . .699

Redistributing connected routes. . . . . . . . . . . . . . . . . . . . . . . .699

Redistributing RIP routes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .700

Redistributing OSPF external routes. . . . . . . . . . . . . . . . . . . . .700

Redistributing static routes. . . . . . . . . . . . . . . . . . . . . . . . . . . .701

Disabling or re-enabling re-advertisement of all learned

BGP4 routes to all BGP4 neighbors . . . . . . . . . . . . . . . . . . . . .701

Redistributing IBGP routes into RIP and OSPF. . . . . . . . . . . . .701

Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .702

Filtering specific IP addresses . . . . . . . . . . . . . . . . . . . . . . . . .702

Filtering AS-paths. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .703

Filtering communities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .707

Defining IP prefix lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .709

Defining neighbor distribute lists . . . . . . . . . . . . . . . . . . . . . . .710

Defining route maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .711

Using a table map to set the rag value. . . . . . . . . . . . . . . . . . . 719

Configuring cooperative BGP4 route filtering. . . . . . . . . . . . . .719

Configuring route flap dampening . . . . . . . . . . . . . . . . . . . . . . . . . .722

Globally configuring route flap dampening . . . . . . . . . . . . . . .723

Using a route map to configure route flap dampening

for specific routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .724

Using a route map to configure route flap dampening for

a specific neighbor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .725

Removing route dampening from a route. . . . . . . . . . . . . . . . .726

Removing route dampening from a neighbor routes

suppressed due to aggregation . . . . . . . . . . . . . . . . . . . . . . . .726

Displaying and clearing route flap dampening statistics . . . .727

Generating traps for BGP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .729

Displaying BGP4 information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .729

Displaying summary BGP4 information . . . . . . . . . . . . . . . . . .729

Displaying the active BGP4 configuration . . . . . . . . . . . . . . . .731

Displaying CPU utilization statistics . . . . . . . . . . . . . . . . . . . . .732

Displaying summary neighbor information . . . . . . . . . . . . . . .733

Displaying BGP4 neighbor information. . . . . . . . . . . . . . . . . . .735

Displaying peer group information . . . . . . . . . . . . . . . . . . . . . .746

Displaying summary route information . . . . . . . . . . . . . . . . . . 747

Displaying the BGP4 route table. . . . . . . . . . . . . . . . . . . . . . . .748

Displaying BGP4 route-attribute entries . . . . . . . . . . . . . . . . . .754

Displaying the routes BGP4 has placed in the

IP route table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .755

Displaying route flap dampening statistics . . . . . . . . . . . . . . .756

Displaying the active route map configuration . . . . . . . . . . . .757

Updating route information and resetting a neighbor session . . .758

Using soft reconfiguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . .758

Dynamically requesting a route refresh from

a BGP4 neighbor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .761

Closing or resetting a neighbor session . . . . . . . . . . . . . . . . . . 764

Clearing and resetting BGP4 routes in the IP route table . . . .764

Clearing traffic counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .765

xx Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Clearing route flap dampening statistics. . . . . . . . . . . . . . . . . . . . .765

Removing route flap dampening . . . . . . . . . . . . . . . . . . . . . . . . . . .765

Clearing diagnostic buffers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .766

Chapter 25 Configuring IP Multicast Traffic Reduction

IGMP snooping overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .767

IGMP V1, V2, and V3 snooping support . . . . . . . . . . . . . . . . . .768

Queriers and non-queriers . . . . . . . . . . . . . . . . . . . . . . . . . . . .768

IGMP snooping enhancements. . . . . . . . . . . . . . . . . . . . . . . . .769

Configuration notes and feature limitations . . . . . . . . . . . . . .769

PIM SM traffic snooping overview . . . . . . . . . . . . . . . . . . . . . . . . . . 771

PIM SM snooping support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 771

Application examples. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 771

Configuration notes and limitations . . . . . . . . . . . . . . . . . . . . .773

Configuring IGMP snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .773

Enabling IGMP snooping globally on the device . . . . . . . . . . .775

Configuring the IGMP mode . . . . . . . . . . . . . . . . . . . . . . . . . . .775

Configuring the IGMP version . . . . . . . . . . . . . . . . . . . . . . . . . .776

Disabling IGMP snooping on a VLAN . . . . . . . . . . . . . . . . . . . . 776

Disabling transmission and receipt of IGMP packets

on a port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .777

Modifying the age interval for group membership entries . . .777 Modifying the query interval (active IGMP snooping

mode only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .777

Modifying the maximum response time. . . . . . . . . . . . . . . . . .778

Configuring report control . . . . . . . . . . . . . . . . . . . . . . . . . . . . .778

Modifying the wait time before stopping traffic when receiving a

leave message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .778

Modifying the multicast cache age time . . . . . . . . . . . . . . . . .779

Enabling or disabling error and warning messages . . . . . . . .779

Configuring static router ports . . . . . . . . . . . . . . . . . . . . . . . . .779

Turning off static group proxy . . . . . . . . . . . . . . . . . . . . . . . . . .779

IGMP V3 membership tracking and fast leave . . . . . . . . . . . .780

Fast leave for IGMP V2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .780

Fast convergence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .781

Configuring PIM SM snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . .781

Enabling or disabling PIM SM snooping. . . . . . . . . . . . . . . . . .781

Enabling PIM SM snooping on a VLAN . . . . . . . . . . . . . . . . . . .782

Disabling PIM SM snooping on a VLAN . . . . . . . . . . . . . . . . . .782

IGMP snooping show commands. . . . . . . . . . . . . . . . . . . . . . . . . . .782

Displaying the IGMP snooping configuration . . . . . . . . . . . . . .782

Displaying IGMP snooping errors . . . . . . . . . . . . . . . . . . . . . . .783

Displaying IGMP group information . . . . . . . . . . . . . . . . . . . . .784

Displaying IGMP snooping mcache information . . . . . . . . . . .785

Displaying software resource usage for VLANs . . . . . . . . . . . .786

Displaying the status of IGMP snooping traffic . . . . . . . . . . . .787

Brocade TurboIron 24X Series Configuration Guide xxi 53-1003053-01

PIM SM snooping show commands. . . . . . . . . . . . . . . . . . . . . . . . .788

Displaying PIM SM snooping information. . . . . . . . . . . . . . . . .788

Displaying PIM SM snooping information on a Layer 2 switch788 Displaying PIM SM snooping information for a specific

group or source group pair . . . . . . . . . . . . . . . . . . . . . . . . . . . .789

Clear commands for IGMP snooping . . . . . . . . . . . . . . . . . . . . . . . .790

Clearing the IGMP mcache . . . . . . . . . . . . . . . . . . . . . . . . . . . .790

Clearing the mcache on a specific VLAN . . . . . . . . . . . . . . . . .790

Clearing traffic on a specific VLAN . . . . . . . . . . . . . . . . . . . . . .791

Clearing IGMP counters on VLANs . . . . . . . . . . . . . . . . . . . . . .791

Chapter 26 Configuring IP Multicast Protocols

Overview of IP multicasting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .793

IPv4 multicast group addresses . . . . . . . . . . . . . . . . . . . . . . . .794

Mapping of IPv4 Multicast group addresses to

Ethernet MAC addresses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .794

Supported Layer 3 multicast routing protocols . . . . . . . . . . . .794

Multicast terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .794

Changing global IP multicast parameters . . . . . . . . . . . . . . . . . . . .795

Changing dynamic memory allocation for IP multicast groups795

Changing IGMP V1 and V2 parameters . . . . . . . . . . . . . . . . . .796

PIM Dense . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .798

Initiating PIM multicasts on a network . . . . . . . . . . . . . . . . . . .798

Pruning a multicast tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .799

Grafts to a multicast Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . .801

PIM DM versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .802

Configuring PIM DM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .802

Failover time in a multi-path topology . . . . . . . . . . . . . . . . . . .806

Modifying the TTL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .806

PIM Sparse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .806

PIM Sparse switch types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .807

RP paths and SPT paths . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .808

Configuring PIM Sparse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .808

Displaying PIM Sparse configuration information

and statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 817

Passive multicast route insertion. . . . . . . . . . . . . . . . . . . . . . . . . . .830

Multicast Source Discovery Protocol (MSDP) . . . . . . . . . . . . . . . . .830

Peer Reverse Path Forwarding (RPF) flooding . . . . . . . . . . . . .832

Source active caching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .832

Configuring MSDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .833

Designating an interface IP address as

the RP IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .834

Filtering MSDP source-group pairs . . . . . . . . . . . . . . . . . . . . . .835

MSDP mesh groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .838

Displaying MSDP information . . . . . . . . . . . . . . . . . . . . . . . . . .844

Clearing MSDP information. . . . . . . . . . . . . . . . . . . . . . . . . . . .848

xxii Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Using ACLs to control multicast features. . . . . . . . . . . . . . . . . . . . .849

Using ACLs to limit static RP groups. . . . . . . . . . . . . . . . . . . . .849

Using ACLs to limit PIM RP candidate advertisement . . . . . . .851

Tracing a multicast route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .852

Displaying the multicast configuration for another multicast router853

IGMP V3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .854

Default IGMP version. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .855

Compatibility with IGMP V1 and V2 . . . . . . . . . . . . . . . . . . . . .855

Globally enabling the IGMP version . . . . . . . . . . . . . . . . . . . . .856

Enabling the IGMP version per interface setting. . . . . . . . . . .856

Enabling the IGMP version on a physical port within

a virtual routing interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . .856

Enabling membership tracking and fast leave . . . . . . . . . . . .857

Setting the query interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . .857

Setting the group membership time. . . . . . . . . . . . . . . . . . . . .858

Setting the maximum response time . . . . . . . . . . . . . . . . . . . .858

Displaying IGMP V3 information on Layer 3 Switches. . . . . . .858

Clearing IGMP statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .862

Chapter 27 Configuring VRRP and VRRPE

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .863

Overview of VRRP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .864

Overview of VRRPE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .868

Configuration note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 871

Comparison of VRRP and VRRPE. . . . . . . . . . . . . . . . . . . . . . . . . . . 871

VRRP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 871

VRRPE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .871

Architectural differences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 871

VRRP and VRRPE parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . .872

Configuring basic VRRP parameters . . . . . . . . . . . . . . . . . . . . . . . .874

Configuring the Owner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .875

Configuring a Backup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .875

Configuration rules for VRRP. . . . . . . . . . . . . . . . . . . . . . . . . . .875

Configuring basic VRRPE parameters . . . . . . . . . . . . . . . . . . . . . . .875

Configuration rules for VRRPE . . . . . . . . . . . . . . . . . . . . . . . . .876

Note regarding disabling VRRP or VRRPE . . . . . . . . . . . . . . . . . . . .876

Configuring additional VRRP and VRRPE parameters . . . . . . . . . . 876

Forcing a Master router to abdicate to a standby router . . . . . . . .883

Displaying VRRP and VRRPE information . . . . . . . . . . . . . . . . . . . .884

Displaying summary information . . . . . . . . . . . . . . . . . . . . . . .884

Displaying detailed information . . . . . . . . . . . . . . . . . . . . . . . .886

Displaying statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .891

Clearing VRRP or VRRPE statistics . . . . . . . . . . . . . . . . . . . . . .892

Displaying CPU utilization statistics . . . . . . . . . . . . . . . . . . . . .892

Brocade TurboIron 24X Series Configuration Guide xxiii 53-1003053-01

Configuration examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .894

VRRP example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .894

VRRPE example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .895

Chapter 28 Configuring Rule-Based IP Access Control Lists

ACL overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .897

Types of IP ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .898

ACL IDs and entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .898

Numbered and named ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . .899

Default ACL action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .899

How hardware-based ACLs work . . . . . . . . . . . . . . . . . . . . . . . . . . .899

How fragmented packets are processed . . . . . . . . . . . . . . . . .899

Hardware aging of Layer 4 CAM entries . . . . . . . . . . . . . . . . . .900

Configuration considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .900

Configuring standard numbered ACLs. . . . . . . . . . . . . . . . . . . . . . .901

Standard numbered ACL syntax . . . . . . . . . . . . . . . . . . . . . . . .901

Configuration example for standard numbered ACLs . . . . . . .902

Configuring standard named ACLs . . . . . . . . . . . . . . . . . . . . . . . . .903

Standard named ACL syntax. . . . . . . . . . . . . . . . . . . . . . . . . . .903

Configuration example for standard named ACLs . . . . . . . . . .904

Configuring extended numbered ACLs . . . . . . . . . . . . . . . . . . . . . .905

Extended numbered ACL syntax . . . . . . . . . . . . . . . . . . . . . . . .906

Configuration examples for extended numbered ACLs . . . . . .909

Configuring extended named ACLs . . . . . . . . . . . . . . . . . . . . . . . . .911

Extended named ACL syntax. . . . . . . . . . . . . . . . . . . . . . . . . . . 911

Configuration example for extended named ACLs. . . . . . . . . .915

Preserving user input for ACL TCP/UDP port numbers. . . . . . . . . .915

Managing ACL comment text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .916

Adding a comment to an entry in a numbered ACL. . . . . . . . .916

Applying an ACL to a virtual interface in a protocol-

or subnet-based VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 917

Enabling ACL logging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 917

Enabling strict control of ACL filtering of fragmented packets. . . .919

Enabling ACL support for switched traffic in the router image . . .920

Enabling ACL filtering based on VLAN membership or VE port

membership . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .920

Applying an IPv4 ACL to specific VLAN members on

a port (Layer 2 devices only) . . . . . . . . . . . . . . . . . . . . . . . . . . .921

Applying an IPv4 ACL to a subset of ports on a virtual

interface (Layer 3 devices only) . . . . . . . . . . . . . . . . . . . . . . . .922

Filtering on IP precedence and ToS values . . . . . . . . . . . . . . . . . . .922

QoS options for IP ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .923

DSCP matching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .924

ACL-based rate limiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .925

xxiv Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Using ACLs to control multicast features. . . . . . . . . . . . . . . . . . . . .925

Enabling and viewing hardware usage statistics for an ACL . . . . .925

Displaying ACL information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .926

Troubleshooting ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .926

Chapter 29 Configuring Traffic Policies

About traffic policies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .929

Configuration notes and feature limitations . . . . . . . . . . . . . . . . . .930

Maximum number of traffic policies supported on a device . . . . .931

Setting the maximum number of traffic policies supported

on a Layer 3 device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .931

ACL-based rate limiting using traffic policies. . . . . . . . . . . . . . . . . .931

Support for fixed rate limiting and adaptive rate limiting . . . .932

Configuring ACL-based fixed rate limiting. . . . . . . . . . . . . . . . .932

Configuring ACL-based adaptive rate limiting . . . . . . . . . . . . .933

Specifying the action to be taken for packets that are

over the limit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .935

ACL and rate limit counting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .936

Enabling ACL statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .937

Enabling ACL statistics with rate limiting traffic policies. . . . .938

Viewing ACL and rate limit counters . . . . . . . . . . . . . . . . . . . . .938

Clearing ACL and rate limit counters . . . . . . . . . . . . . . . . . . . .939

Viewing traffic policies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .939

Chapter 30 Configuring 802.1X Port Security

IETF RFC support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .941

How 802.1X port security works . . . . . . . . . . . . . . . . . . . . . . . . . . .941

Device roles in an 802.1X configuration . . . . . . . . . . . . . . . . .941

Communication between the devices . . . . . . . . . . . . . . . . . . .942

Controlled and uncontrolled ports . . . . . . . . . . . . . . . . . . . . . .944

Message exchange during authentication. . . . . . . . . . . . . . . .945

Authenticating multiple hosts connected to the same port . .947

802.1X port security and sFlow . . . . . . . . . . . . . . . . . . . . . . . .950

Brocade TurboIron 24X Series Configuration Guide xxv 53-1003053-01

Configuring 802.1X port security. . . . . . . . . . . . . . . . . . . . . . . . . . .950

Configuring an authentication method list for 802.1X . . . . . .950

Setting RADIUS parameters . . . . . . . . . . . . . . . . . . . . . . . . . . .951

Configuring dynamic VLAN assignment for 802.1X ports . . . .954

Dynamically applying IP ACLs and MAC filters to

802.1X ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .958

Enabling 802.1X port security. . . . . . . . . . . . . . . . . . . . . . . . . .961

Setting the port control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .962

Configuring periodic re-authentication . . . . . . . . . . . . . . . . . . .963

Re-authenticating a port manually . . . . . . . . . . . . . . . . . . . . . .963

Setting the quiet period. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .964

Specifying the wait interval and number of EAP-request/

identity frame retransmissions . . . . . . . . . . . . . . . . . . . . . . . . .964

Specifying the wait interval and number of EAP-request/

identity frame retransmissions from the RADIUS server . . . .965

Specifying a timeout for retransmission of messages to the

authentication server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .966

Initializing 802.1X on a port . . . . . . . . . . . . . . . . . . . . . . . . . . .966

Allowing access to multiple hosts. . . . . . . . . . . . . . . . . . . . . . .966

Configuring VLAN access for non-EAP-capable clients . . . . . .968

Displaying 802.1X information. . . . . . . . . . . . . . . . . . . . . . . . . . . . .969

Displaying 802.1X configuration information . . . . . . . . . . . . .970

Displaying 802.1X statistics . . . . . . . . . . . . . . . . . . . . . . . . . . .972

Clearing 802.1X statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . .973

Displaying dynamically assigned VLAN information . . . . . . . .973

Displaying information about dynamically applied

MAC filters and IP ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 974

Displaying 802.1X multiple-host authentication

information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .975

Sample 802.1X configurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . .979

Point-to-point configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . 979

Hub configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .981

802.1X Authentication with dynamic VLAN assignment . . . . .983

Using multi-device port authentication and 802.1X security

on the same port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .984

Configuring Brocade-specific attributes on the RADIUS server985

Example configurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .986

Chapter 31 Using the MAC Port Security Feature

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .991

Local and global resources . . . . . . . . . . . . . . . . . . . . . . . . . . . .991

Configuration notes and feature limitations . . . . . . . . . . . . . .992

xxvi Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring the MAC port security feature . . . . . . . . . . . . . . . . . . .992

Enabling the MAC port security feature . . . . . . . . . . . . . . . . . .992

Setting the maximum number of secure MAC addresses

for an interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .993

Setting the port security age timer . . . . . . . . . . . . . . . . . . . . . .993

Specifying secure MAC addresses . . . . . . . . . . . . . . . . . . . . . .993

Autosaving secure MAC addresses to the

startup-config file. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .994

Specifying the action taken when a security

violation occurs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .995

Clearing port security statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . .996

Clearing restricted MAC addresses. . . . . . . . . . . . . . . . . . . . . .996

Clearing violation statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . .996

Displaying port security information . . . . . . . . . . . . . . . . . . . . . . . .996

Displaying port security settings . . . . . . . . . . . . . . . . . . . . . . . .997

Displaying the secure MAC addresses . . . . . . . . . . . . . . . . . . . 997

Displaying port security statistics . . . . . . . . . . . . . . . . . . . . . . .998

Displaying restricted MAC addresses on a port. . . . . . . . . . . .998

Chapter 32 Configuring Multi-Device Port Authentication

How multi-device port authentication works. . . . . . . . . . . . . . . . . .999

RADIUS authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .999

Authentication-failure actions . . . . . . . . . . . . . . . . . . . . . . . . 1000

Supported RADIUS attributes . . . . . . . . . . . . . . . . . . . . . . . . 1000

Support for dynamic VLAN assignment . . . . . . . . . . . . . . . . .1001

Support for dynamic ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . .1001

Support for authenticating multiple MAC addresses

on an interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1001

Using multi-device port authentication and

802.1X security on the same port . . . . . . . . . . . . . . . . . . . . . . . . .1001

Configuring Brocade-specific attributes on the RADIUS server1002

Configuring multi-device port authentication . . . . . . . . . . . . . . . 1003

Enabling multi-device port authentication . . . . . . . . . . . . . . 1003

Specifying the format of the MAC addresses sent

to the RADIUS server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1004

Specifying the authentication-failure action . . . . . . . . . . . . 1004

Generating traps for multi-device port authentication . . . . 1005

Defining MAC address filters. . . . . . . . . . . . . . . . . . . . . . . . . 1005

Configuring dynamic VLAN assignment . . . . . . . . . . . . . . . . 1006

Dynamically applying IP ACLs to authenticated MAC

addresses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1008

Enabling denial of service attack protection . . . . . . . . . . . . .1010

Clearing authenticated MAC addresses. . . . . . . . . . . . . . . . .1011

Disabling aging for authenticated MAC addresses . . . . . . . .1011

Changing the hardware aging period for blocked

MAC addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1012

Specifying the aging time for blocked MAC addresses . . . . .1013

Specifying the RADIUS timeout action . . . . . . . . . . . . . . . . . .1013

Multi-device port authentication password override . . . . . . .1014

Limiting the number of authenticated MAC addresses. . . . .1015

Brocade TurboIron 24X Series Configuration Guide xxvii 53-1003053-01

Displaying multi-device port authentication information . . . . . . .1015

Displaying authenticated MAC address information . . . . . . .1015

Displaying multi-device port authentication configuration

information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1016

Displaying multi-device port authentication information

for a specific MAC address or por t . . . . . . . . . . . . . . . . . . . . .1016

Displaying the authenticated MAC addresses . . . . . . . . . . . .1017

Displaying the non-authenticated MAC addresses . . . . . . . .1017

Displaying multi-device port authentication

information for a port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1018

Displaying multi-device port authentication settings

and authenticated MAC addresses . . . . . . . . . . . . . . . . . . . .1018

Chapter 33 Protecting Against Denial of Service Attacks

Protecting against Smurf attacks. . . . . . . . . . . . . . . . . . . . . . . . . 1023

Avoiding being a victim in a Smurf attack . . . . . . . . . . . . . . .1024

Protection against ICMP attacks. . . . . . . . . . . . . . . . . . . . . . .1024

Protecting against TCP SYN attacks. . . . . . . . . . . . . . . . . . . . . . . 1025

Protection against TCP-SYN attacks . . . . . . . . . . . . . . . . . . . 1025

TCP security enhancement . . . . . . . . . . . . . . . . . . . . . . . . . . 1026

Displaying statistics about packets dropped

because of DoS attacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1027

Displaying statistics about packets dropped due to

DoS attacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1028

Chapter 34 Configuring Rate Limiting and Rate Shaping

Rate limiting overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1029

Rate limiting in hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1029

How Fixed Rate Limiting works . . . . . . . . . . . . . . . . . . . . . . . 1030

Configuration notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1030

Configuring a port-based rate limiting policy . . . . . . . . . . . . .1031

Configuring an ACL-based rate limiting policy . . . . . . . . . . . .1031

Displaying the fixed rate limiting configuration . . . . . . . . . . .1031

Rate shaping overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1032

Configuration notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1032

Configuring outbound rate shaping for a port . . . . . . . . . . . 1033

Configuring outbound rate shaping for a specific priority. . 1033

Configuring outbound rate shaping for a trunk port . . . . . . 1033

Displaying rate shaping configurations . . . . . . . . . . . . . . . . 1033

Chapter 35 Configuring Quality of Service

Classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1035

Processing of classified traffic . . . . . . . . . . . . . . . . . . . . . . . 1035

QoS queues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1039

Assigning QoS priorities to traffic . . . . . . . . . . . . . . . . . . . . . 1039

Buffer allocation/threshold for QoS queues . . . . . . . . . . . . .1041

Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1041

xxviii Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring DSCP-based QoS. . . . . . . . . . . . . . . . . . . . . . . . . . . . .1041

Application notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1042

Using ACLs to honor DSCP-based QoS . . . . . . . . . . . . . . . . . 1042

Configuring the QoS mappings. . . . . . . . . . . . . . . . . . . . . . . . . . . 1042

Default DSCP –> Internal forwarding priority mappings . . . 1042 Changing the DSCP –> internal forwarding priority mappings1043 Changing the internal forwarding priority –> hardware

forwarding queue mappings . . . . . . . . . . . . . . . . . . . . . . . . . 1044

Scheduling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1045

QoS Queuing methods. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1045

Selecting the QoS queuing method . . . . . . . . . . . . . . . . . . . 1046

Configuring the QoS queues . . . . . . . . . . . . . . . . . . . . . . . . . 1046

Viewing QoS settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1049

Viewing DSCP-based QoS settings. . . . . . . . . . . . . . . . . . . . . . . . 1049

Appendix A Syslog messages

Appendix B Software Specifications

IEEE compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1075

RFC support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1075

Internet drafts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1080

Appendix C NIAP-CCEVS Certification

NIAP-CCEVS certified TurboIron X Series equipment and

Ironware releases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1081

Local user password changes . . . . . . . . . . . . . . . . . . . . . . . . . . . 1082

Brocade TurboIron 24X Series Configuration Guide xxix 53-1003053-01

xxx Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

About This Document

In this chapter

•Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxi

•Device nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxi

•What’s new in this document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxii

•Document conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxii

•Notice to the reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxiii

•Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxiii

•Getting technical help or reporting errors . . . . . . . . . . . . . . . . . . . . . . . . . xxxiii

•Document feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxxiv

Introduction

This guide describes the following product families from Brocade:

• TurboIron X Series switch

This guide includes procedures for configuring the software. The software procedures show how to perform tasks using the CLI. This guide also describes how to monitor TurboIron products using statistics and summary screens.

This guide applies to the TurboIron X Series models.

Device nomenclature

Tab le 1 lists the terms (product names) contained in this guide and the specific set of devices to

which each term refers.

TABLE 1 TurboIron X Series family of switches

This name Refers to these devices

TurboIron 24X Devices

TurboIron 24X (TIX) TurboIron 24X or TurboIron

Brocade TurboIron 24X Series Configuration Guide xxxi 53-1003053-01

What’s new in this document

NOTE

CAUTION

There are no enhancements in FastIron release 08.0.01 for TurboIron 24X.

Document conventions

This section describes text formatting conventions and important notice formats used in this document.

Text formatting

The narrative-text formatting conventions that are used are as follows:

bold text Identifies command names

Identifies the names of user-manipulated GUI elements

Identifies keywords

Identifies text to enter at the CLI

italic text Provides emphasis

Identifies <variables>

Identifies document titles

code text Identifies CLI output

For readability, command names in the narrative portions of this guide are presented in bold: for example, show version.

Notes, cautions, and danger notices

The following notices and statements are used in this manual. They are listed below in order of increasing severity of potential hazards.

A note provides a tip, guidance or advice, emphasizes important information, or provides a reference to related information.

A Caution statement alerts you to situations that can be potentially hazardous to you or cause damage to hardware, firmware, software, or data.

xxxii Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Notice to the reader

NOTE

This document may contain references to the trademarks of the following corporations. These trademarks are the properties of their respective companies and corporations.

Related publications

The following documents supplement the information in this guide:

• FastIron Ethernet Switch Administration Guide

• FastIron Ethernet Switch Platform and Layer 2 Switching Configuration Guide

• FastIron Ethernet Switch Layer 3 Routing Configuration Guide

• FastIron Ethernet Switch IP Multicast Configuration Guide

• FastIron Ethernet Switch Security Configuration Guide

• FastIron Ethernet Switch Software Upgrade Guide

• FastIron Switch Stacking Configuration Guide

• FastIron Ethernet Switch Traffic Management Guide

• FastIron Ethernet Switch Software Licensing Guide

• FastIron Feature Support Matrix

• Brocade TurboIron 24X Series Configuration Guide

• Brocade ICX 6430-C Switch Installation Guide

• Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide

• Brocade FCX Series Hardware Installation Guide

• Brocade FastIron ICX 6610 Stackable Switch Hardware Installation Guide

• Brocade ICX 6650 Ethernet Switch Installation Guide

• Brocade FastIron SX Series Chassis Hardware Installation Guide

• Brocade TurboIron 24X Series Hardware Installation Guide

• Brocade ICX 6450-C12-PD Switch Installation Guide

• Brocade FastIron FCX, ICX, and TurboIron Diagnostic Reference

• Unified IP MIB Reference

For the latest edition of these documents, which contain the most up-to-date information, go to

http://www.brocade.com/products.

Getting technical help or reporting errors

To contact Technical Support, go to http://www.brocade.com/services-support/index.page for the latest e-mail and telephone contact information.

Brocade TurboIron 24X Series Configuration Guide xxxiii 53-1003053-01

Document feedback

Quality is our first concern at Brocade and we have made every effort to ensure the accuracy and completeness of this document. However, if you find an error or an omission, or you think that a topic needs further development, we want to hear from you. Forward your feedback to:

documentation@brocade.com

Provide the title and version number of the document and as much detail as possible about your comment, including the topic heading and page number and your suggestions for improvement.

xxxiv Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Chapter

Feature Highlights

In this chapter

•Supported features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

•Supported IPv6 management features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

•Unsupported features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Introduction to features

The features that are available on a device depend on the type of software image the device is running. You can run one of the following types of software images on these devices:

• Layer 2 is supported on all models

• Layer 3 features supported on TurboIron devices only.

Tab le 2 lists the software that is loaded into the primary and secondary flash areas at the factory.

TABLE 2 Default software loads

Model Software images

All TurboIron models Layer 2 Layer 2

Supported features

The tables in this section list the feature highlights in the TurboIron software.

Supported management features

Tab le 3 lists the supported management features. These features are supported in the Layer 2

software images..

TABLE 3 Supported management features

Category, description, and configuration notes

AAA support for console commands Yes

Access Control Lists (ACLs) for controlling management access

Alias Command Yes

Primary flash Secondary flash

TurboIron X Series

Yes

Brocade TurboIron 24X Series Configuration Guide 1 53-1003053-01

Supported features

TABLE 3 Supported management features (Continued)

Category, description, and configuration notes

TurboIron X Series

Combined DSCP and internal marking in one ACL rule

Disabling TFTP Access Yes

Brocade Network Advisor Yes

P-Bridge and Q-Bridge MIBs Yes

Remote monitoring (RMON) Yes

sFlow:

Yes

• For inbound traffic only

• 802.1X username export support

for encrypted and non-encrypted EAP types

Serial and Telnet access to industry-standard Command Line Interface (CLI)

Show log on all terminals Yes

SNMP v1, v2, v3 Yes

SNMP V3 traps Yes

Specifying the maximum number of entries allowed in the RMON Control Tab le

Traffic counters for outbound traffic Yes

Yes

Supported security features

Tab le 4 lists the supported security features. These features are supported in the Layer 2 software

images.

TABLE 4 Supported security features

Category, description, and configuration notes

802.1X port security Yes

802.1X authentication RADIUS timeout action

802.1X dynamic assignment for ACL, MAC filter, and VLAN

Access Control Lists (ACLs) for filtering transit traffic:

• Support for inbound ACLs only.

These devices do not support outbound ACLs.

AES Encryption for SNMP v3 Yes

AES Encryption for SSH v2 Yes

TurboIron X Series

Yes

2 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

TABLE 4 Supported security features (Continued)

Category, description, and configuration notes

TurboIron X Series

Supported features

Authentication, Authorization and Accounting (AAA):

Yes

• RADIUS, TACACS/TACACS+

Denial of Service (DoS) protection:

Yes

• TCP SYN Attacks and ICMP Attacks

Local passwords Yes

MAC filter override of 802.1X Yes

MAC filtering:

Yes

• Filtering on source and destination

MAC addresses

Ability to disable MAC Learning Yes

MAC port security Yes

Multi-device port authentication Yes

Multi-device port authentication with dynamic ACLs

Multi-device port authentication with dynamic VLAN assignment

Multi-device port authentication password override

Multi-device port authentication RADIUS timeout action

Secure Copy (SCP) Yes

Secure Shell (SSH) v2 Server Yes

Packet filtering on TCP Flags Yes

Yes

Supported system-level features

Tab le 5 lists the supported system-level features. These features are supported in the Layer 2

software images.

TABLE 5 Supported system-level features

Category, description, and configuration notes

10/100/1000 port speed Yes

1 Gbps and 10 Gbps configurable port speed on fiber ports

16,000 MAC addresses per switch Yes

32,000 MAC addresses per switch Yes

ACL-Based Mirroring Yes

Brocade TurboIron 24X Series Configuration Guide 3 53-1003053-01

TurboIron X Series

Yes

Supported features

TABLE 5 Supported system-level features (Continued)

Category, description, and configuration notes

TurboIron X Series

ACL-Based Rate Limiting:

Yes

• TurboIron X Series devices support

ACL-based fixed and adaptive rate limiting on inbound ports

ACL filtering based on VLAN membership or VE port membership

ACL logging of denied packets:

Yes

• ACL logging is supported for denied

packets, which are sent to the CPU for logging

• ACL logging is not supported for

permitted packets

• Packets that are denied by ACL

filters are logged in the Syslog based on a sample time-period.

ACL statistics Yes

Asymmetric flow control:

Yes

• Responds to flow control packets,

but does not generate them

Auto-negotiation Yes

Broadcast, multicast, and unknown-unicast rate limiting

Boot and reload after 5 minutes at or above shutdown temperature

Cut-through switching Yes

DiffServ support Yes

Digital Optical Monitoring Yes

Displaying interface names in Syslog Yes

Displaying TCP/UDP port numbers in Syslog messages

DSCP Mapping for values 1 through 8 Yes

Dynamic buffer allocation Yes

Egress buffer thresholds Yes

Fixed rate limiting:

Yes

• TurboIron X Series devices support:

• Port-based rate limiting on

inbound ports

• Not supported on 10 GbE ports

on TurboIron X Series devices.

• Fixed rate limiting is not

supported on tagged ports in the full Layer 3 router image

4 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

TABLE 5 Supported system-level features (Continued)

Category, description, and configuration notes

TurboIron X Series

Supported features

Foundry Discovery Protocol (FDP) / Cisco Discovery Protocol (CDP)

LLDP Yes

MAC filter-based mirroring Yes

Multi-port static MAC address Yes

Multiple Syslog server logging:

Yes

• Up to six Syslog servers

Negative temperature setting Yes

Outbound rate shaping Yes

Port flap dampening Yes

Port mirroring and monitoring:

Yes

• Mirroring of both inbound and

outbound traffic on individual ports is supported.

Priority mapping using ACLs Yes

Specifying a Simple Network Time Protocol (SNTP) Server

Specifying the minimum number of ports in a trunk group

Static MAC entries with option to set traffic priority

Yes

Supported Layer 2 features

Layer 2 software images include all of the management, security, and system-level features listed in the previous tables, plus the features listed in Table 6.

TABLE 6 Supported Layer 2 features

Category, description, and configuration notes

802.1D Spanning Tree Support:

• Enhanced IronSpan support

includes Fast Port Span and Single-instance Span

• TurboIron X Series devices support

up to 510 spanning tree instances for VLANs.

802.1p Quality of Service (QoS):

• Strict Priority (SP)

• Weighted Round Robin (WRR)

• Combined SP and WRR

• 8 priority queues

Brocade TurboIron 24X Series Configuration Guide 5 53-1003053-01

TurboIron X Series

Yes

Supported features

TABLE 6 Supported Layer 2 features (Continued)

Category, description, and configuration notes

802.1s Multiple Spanning Tree Yes

802.1W Rapid Spanning Tree (RSTP):

• 802.1W RSTP support allows for

802.3ad link aggregation (dynamic trunk groups):

• TurboIron X Series ports enabled for

ACL-based rate limiting QoS Yes

BPDU Guard Yes

Dynamic Host Configuration Protocol (DHCP) Assist

IGMP v1/v2 Snooping Global Yes

IGMP v3 Snooping Global Yes

IGMP v1/v2/v3 Snooping per VLAN Yes

IGMP v2/v3 Fast Leave (membership tracking)

Interpacket Gap (IPG) adjustment Yes

Jumbo frames:

• 1 Gbps and 10 Gbps Ethernet ports

• Up to 9216 bytes

Jumbo frames 10/100 support :

• Up to 10240 bytes

LACP:

• LACP trunk group ports follow the

• Support for single link LACP

Link Fault Signaling (LFS) for 10 Gbps Ethernet ports

Metro Ring Protocol 1 (MRP 1) Yes

Metro Ring Protocol 2 (MRP 2) TurboIron X Series devices support Alarm

RHP

PIM-SM V2 Snooping Yes

PVST/PVST+ compatibility Yes

TurboIron X Series

Yes

sub-second convergence (both final standard and draft 3 supported)

Yes

link aggregation follow the same rules as ports configured for trunk groups. Refer to “Trunk group rules” on page 333.

Yes

(*,G and S,G)

Yes

same configuration rules as for statically configured trunk group ports.

Yes

6 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

TABLE 6 Supported Layer 2 features (Continued)

Category, description, and configuration notes

PVRST+ compatibility Yes

Root Guard Yes

Super Aggregated VLANs Yes

Tru n k gro u ps:

TurboIron X Series

Yes

• Trunk threshold for static trunk

groups

• Flexible trunk group membership

Topology groups Yes

Uni-directional Link Detection (UDLD) (Link keepalive)

Uplink Ports Within a Port-Based VLAN Yes

VLAN Support:

Yes

• 802.1Q with tagging Yes

• Dual-mode VLANs Yes

• Protocol VLANs (AppleTalk, IPv4,

and IPX)

Yes

• VLAN groups Yes

• Private VLANs Yes

VLAN Q-in-Q Tagging (tag-type 8100 over 8100 encapsulatio n)

VLAN-based mirroring No

Virtual Switch Redundancy Protocol (VSRP)

VSRP-Aware security features Yes

VSRP and MRP signaling Yes

VSRP Fast Start Yes

VSRP timer scaling Yes

Yes

Supported features

Supported Layer 3 features on TurboIron X Series devices

• ECMP

• RIP V1 and V2 (advertising only): Static RIP support only. The TurboIron X Series does not learn

RIP routes from other Layer 3 devices. However, the device does advertise directly connected routes.

• Routing for directly connected IP subnets

• Static IP routing:

• Virtual Interfaces: Up to 255 virtual interfaces

• VRRP

Brocade TurboIron 24X Series Configuration Guide 7 53-1003053-01

Supported IPv6 management features

• OSPF V2 (IPv4)

• Route-only support (Global and interface configuration levels )

• VRRP

• Anycast RP

• IGMP V1, V2, and V3 (for multicast routing scenarios)

• IP multicast routing protocols (PIM-SM, PIM-DM): TurboIron X Series devices support PIM-SM

and PIM-DM

• ICMP Redirect messages

• Multiprotocol Source Discovery Protocol (MSDP)

• Route-only support:

• Disabling Layer 2 Switching at the CLI Interface level as well as the Global CONFIG level.

• This feature is not supported on virtual interfaces

• VRRP-E

• DHCP relay

• IP helper

Supported IPv6 management features

Tab le 7 shows the IPV6 management features that are supported for TurboIron X Series devices

that can be configured as IPv6 hosts in an IPv6 network.

TABLE 7 Supported IPv6 management features

Category, description, and configuration notes

Link-Local IPv6 Address Yes

IPv6 copy Yes

IPv6 ncopy Yes

IPv6 debug Yes

IPv6 ping Yes

IPv6 traceroute Yes

DNS server name resolution Yes

Logging (Syslog) Yes

RADIUS Yes

SCP Yes

SSH Yes

SNMP v1, v2, v3 Yes

SNTP Yes

Syslog Yes

TACACS/TACACS+ Yes

TurboIron X Series

8 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

TABLE 7 Supported IPv6 management features

Category, description, and configuration notes

Tel net Yes

TFTP Yes

Tra ps Yes

Unsupported features

Tab le 8 lists the features that are not supported on the TurboIron X Series devices. If required,

these features are available on other TurboIron X Series devices.

TABLE 8 Unsupported Features

Unsupported features

System-level features not supported:

• Broadcast and multicast MAC filters

Layer 2 features not supported:

• SuperSpan

• VLAN-based priority

Layer 3 features not supported:

• AppleTalk

• Foundry Standby Router Protocol (FSRP)

• IPv6 Multicast Routing

• IPX

• IS-IS

• Multiprotocol Border Gateway Protocol (MBGP)

• Multiprotocol Label Switching (MPLS)

• Network Address Translation (NAT)

Web Management

Unsupported features

TurboIron X Series

Brocade TurboIron 24X Series Configuration Guide 9 53-1003053-01

Unsupported features

10 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Chapter

Getting Familiar with Management Applications

In this chapter

•Using the management port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

•Logging on through the CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

•Using and port number with CLI commands . . . . . . . . . . . . . . . . . . . . . . . . . 15

•Logging on through Brocade Network Advisor. . . . . . . . . . . . . . . . . . . . . . . . 20

Using the management port

The management port is an out-of-band port that customers can use to manage their devices without interfering with the in-band ports. The management port is widely used to download images and configurations and for Telnet sessions.

The MAC address for the management port is derived from the base MAC address of the unit, plus the number of ports in the base module.

How the management port works

The following rules apply to management ports:

• Any packets that are specifically addressed to the management port MAC address or the

broadcast MAC address are forwarded accordingly. All other packets are filtered out.

• No packet received on a management port is sent to any in-band ports, and no packets

received on in-band ports are sent to a management port.

• A management port is not part of any VLAN

• Protocols are not supported on the management port.

• Creating a management VLAN disables the management port on the device.

• All features that can be configured from the global configuration mode can also be configured

from the interface level of the manamement port. Features that are configured through the management port take effect globally, not on the management port itself (on switches only).

For switches, any in-band port may be used for management purposes. A Router sends Layer 3 packets using the MAC address of the port as the source MAC address.

CLI Commands for use with the management port

The following CLI commands can be used with a management port.

To display the current configuration, use the show running-config interface management command.

Syntax: show running-config interface management <num>

Brocade TurboIron 24X Series Configuration Guide 11 53-1003053-01

Using the management port

TurboIron(config-if-mgmt)#ip addr 10.44.9.64/24 TurboIron(config)#show running-config interface management 1 interface management 1 ip address 10.44.9/64 255.255.255.0

To display the current configuration, use the show interfaces management command.

Syntax: show interfaces management <num>

TurboIron(config)#show interfaces management 1 GigEthernetmgmt1 is up, line protocol is up Hardware is GigEthernet, address is 0000.0076.544a (bia 0000.0076.544a) Configured speed auto, actual 1Gbit, configured duplex fdx, actual fdx Configured mdi mode AUTO, actual none BPRU guard is disabled, ROOT protect is disabled Link Error Dampening is Disabled STP configured to OFF, priority is level0, mac-learning is enabled Flow Control is config disabled, oper enabled Mirror disabled, Monitor disabled Not member of any active trunks Not member of any configured trunks No port name IPG MII 0 bits-time, IPG GMII 0 bits-time IP MTU 1500 bytes 300 second input rate: 83728 bits/sec, 130 packets/sec, 0.01% utilization 300 second output rate: 24 bits/sec, 0 packets/sec, 0.00% utilization 39926 packets input, 3210077 bytes, 0 no buffer Received 4353 broadcasts, 32503 multicasts, 370 unicasts 0 input errors, 0 CRC, 0 frame, 0 ignored 0 runts, 0 giants 22 packets output, 1540 bytres, 0 underruns Transmitted 0 broadcasts, 6 multicasts, 16 unicasts 0 output errors, 0 collisions

To display the management interface information in brief form, enter the show interfaces brief management command.

Syntax: show interfaces brief management <num>

TurboIron#show interfacde brief management 1

To display management port statistics, enter the show statistics management command.

Syntax: show statistics management <num>

12 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Logging on through the CLI

NOTE

TurboIron#show statistics management 1 Port Link State Dup Speed Trunk Tag Pvid Pri MAC Name mgmt1 Up None Full100M None No 1 0 00000.0000.0118

InOctets 3210941 OutOctets 1540 InPkts 39939 OutPackets 22 InBroadcastPkts 4355 OutbroadcastPkts 0 InMultiastPkts 35214 OutMulticastPkts 6 InUnicastPkts 370 OutUnicastPkts 16 InBadPkts 0 InFragments 0 InDiscards 0 OutErrors 0 CRC 0 Collisions 0 InErrors 0 LateCollisions 0 InGiantPkts 0 InShortPkts 0 InJabber 0 InFlowCtrlPkts 0 OutFlowCtrlPkts 0 InBitsPerSec 83728 OutBitsPerSec 24 InPktsPerSec 130 OutPktsPerSec 0 InUtilization 0.01% OutUtilization 0.00%

To display the management interface statistics in brief form, enter the show statistics brief management command.

Syntax: show statistics brief management <num>

Logging on through the CLI

Once an IP address is assigned to an Brocade device running Layer 2 software or to an interface on an Brocade device running Layer 3 software, you can access the CLI either through the direct serial connection to the device or through a local or remote Telnet session.

You can initiate a local Telnet or SNMP connection by attaching a cable to a port and specifying the assigned management station IP address.

The commands in the CLI are organized into the following levels:

• User EXEC – Lets you display information and perform basic tasks such as pings and

traceroutes.

• Privileged EXEC – Lets you use the same commands as those at the User EXEC level plus

Brocade TurboIron 24X Series Configuration Guide 13 53-1003053-01

configuration commands that do not require saving the changes to the system-config file.

• CONFIG – Lets you make configuration changes to the device. To save the changes across

reboots, you need to save them to the system-config file. The CONFIG level contains sub-levels for individual ports, for VLANs, for routing protocols, and other configuration areas.

By default, any user who can open a serial or Telnet connection to the Brocade device can access all these CLI levels. To secure access, you can configure Enable passwords or local user accounts, or you can configure the device to use a RADIUS or TACACS/TACACS+ server for authentication. Refer to Chapter 5, “Securing Access to Management Functions”.

Logging on through the CLI

On-line help

To display a list of available commands or command options, enter “?” or press Tab. If you have not entered part of a command at the command prompt, all the commands supported at the current CLI level are listed. If you enter part of a command, then enter “?” or press Tab, the CLI lists the options you can enter at this point in the command string.

If you enter an invalid command followed by ?, a message appears indicating the command was unrecognized. An example is given below.

TurboIron(config)#rooter ip Unrecognized command

Command completion

The CLI supports command completion, so you do not need to enter the entire name of a command or option. As long as you enter enough characters of the command or option name to avoid ambiguity with other commands or options, the CLI understands what you are typing.

Scroll control

By default, the CLI uses a page mode to paginate displays that are longer than the number of rows in your terminal emulation window. For example, if you display a list of all the commands at the global CONFIG level but your terminal emulation window does not have enough rows to display them all at once, the page mode stops the display and lists your choices for continuing the display. An example is given below.

aaa all-client appletalk arp boot some lines omitted for brevity...

ipx lock-address logging mac

--More--, next page: Space, next line: Return key, quit: Control-c

The software provides the following scrolling options:

• Press the Space bar to display the next page (one screen at a time).

• Press the Return or Enter key to display the next line (one line at a time).

• Press Ctrl+C or Ctrl+Q to cancel the display.

Line editing commands

The CLI supports the following line editing commands. To enter a line-editing command, use the CTRL+key combination for the command by pressing and holding the CTRL key, then pressing the letter associated with the command.

14 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Using and port number with CLI commands

TABLE 9 CLI line editing commands

Ctrl+Key combination Description

Ctrl+A Moves to the first character on the command line.

Ctrl+B Moves the cursor back one character.

Ctrl+C Escapes and terminates command prompts and ongoing tasks (such as

lengthy displays), and displays a fresh command prompt.

Ctrl+D Deletes the character at the cursor.

Ctrl+E Moves to the end of the current command line.

Ctrl+F Moves the cursor forward one character.

Ctrl+K Deletes all characters from the cursor to the end of the command line.

Ctrl+L; Ctrl+R Repeats the current command line on a new line.

Ctrl+N Enters the next command line in the history buffer.

Ctrl+P Enters the previous command line in the history buffer.

Ctrl+U; Ctrl+X Deletes all characters from the cursor to the beginning of the command line.

Ctrl+W Deletes the last word you typed.

Ctrl+Z Moves from any CONFIG level of the CLI to the Privileged EXEC level; at the

Privileged EXEC level, moves to the User EXEC level.

Using and port number with CLI commands

Many CLI commands require users to enter port numbers as part of the command syntax, and many show command outputs display port numbers. The port numbers are entered and displayed in one of the following formats.

CLI nomenclature on TurboIron X Series devices

The TurboIron X Series devices use port numbers only. When you enter CLI commands that require port numbers as part of the syntax, just specify the port number.

Here are some examples. The following commands change the CLI from the global CONFIG level to the configuration level for the first port on the device:

• TurboIron X Series commands

TurboIron(config)#interface e1 TurboIron(config-if-e10000-1)#

Searching and filtering output from CLI commands

You can filter CLI output from show commands and at the --More-- prompt. You can search for individual characters, strings, or construct complex regular expressions to filter the output.

Brocade TurboIron 24X Series Configuration Guide 15 53-1003053-01

Using and port number with CLI commands

NOTE

Searching and filtering output from Show commands

You can filter output from show commands to display lines containing a specified string, lines that do not contain a specified string, or output starting with a line containing a specified string. The search string is a regular expression consisting of a single character or string of characters. You can use special characters to construct complex regular expressions. Refer to “Using special

characters in regular expressions” on page 18 for information on special characters used with

regular expressions.

Using include to display lines containing a specified string The include modifier filters the output of the show interface command for port 11 so it displays only

lines containing the word “Internet”. This command can be used to display the IP address of the interface.

TurboIron#show interface e 11 | include Internet Internet address is 192.168.1.11/24, MTU 1518 bytes, encapsulation ethernet

Syntax: show-command | include <regular-expression>

The vertical bar ( | ) is part of the command.

The regular expression specified as the search string is case sensitive. In the example above, a search string of “Internet” would match the line containing the IP address, but a search string of “internet” would not.

Using exclude to display lines that do not contain a specified string The exclude modifier filters the output of the show who command so it displays only lines that do

not contain the word “closed”. This command can be used to display open connections to the device

TurboIron#show who | exclude closed Console connections: established you are connecting to this session 2 seconds in idle Telnet connections (inbound): 1 established, client ip address 192.168.9.37 27 seconds in idle Telnet connection (outbound): SSH connections:

Syntax: show-command | exclude <regular-expression>

Using begin to display lines starting with a specified string The begin modifier filters the output of the show who command so it displays output starting with

the first line that contains the word “SSH”. This command can be used to display information about SSH connections to the device.

TurboIron#show who | begin SSH SSH connections: 1 established, client ip address 192.168.9.210 7 seconds in idle 2 closed

16 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Using and port number with CLI commands

3 closed 4 closed 5 closed

Syntax: show-command | begin <regular-expression>

Searching and filtering output at the --More-- prompt

The --More-- prompt displays when output extends beyond a single page. From this prompt, you can press the Space bar to display the next page, the Return or Enter key to display the next line, or Ctrl+C or Q to cancel the display. In addition, you can search and filter output from this prompt.

At the --More-- prompt, you can press the forward slash key ( / ) and then enter a search string. The device displays output starting from the first line that contains the search string, similar to the begin modifier for show commands. An example is given below.

--More--, next page: Space, next line: Return key, quit: Control-c /telnet

The results of the search are displayed.

searching... telnet Telnet by name or IP address temperature temperature sensor commands terminal display syslog traceroute TraceRoute to IP node undebug Disable debugging functions (see also 'debug') undelete Undelete flash card files whois WHOIS lookup write Write running configuration to flash or terminal

To display lines containing only a specified search string (similar to the include modifier for show commands) press the plus sign key ( + ) at the --More-- prompt and then enter the search string.

--More--, next page: Space, next line: Return key, quit: Control-c +telnet

The filtered results are displayed.

filtering... telnet Telnet by name or IP address

To display lines that do not contain a specified search string (similar to the exclude modifier for show commands) press the minus sign key ( - ) at the --More-- prompt and then enter the search string.

--More--, next page: Space, next line: Return key, quit: Control-c

-telnet

The filtered results are displayed.

filtering... temperature temperature sensor commands terminal display syslog traceroute TraceRoute to IP node

Brocade TurboIron 24X Series Configuration Guide 17 53-1003053-01

Using and port number with CLI commands

undebug Disable debugging functions (see also 'debug') undelete Undelete flash card files whois WHOIS lookup write Write running configuration to flash or terminal

As with the modifiers for filtering output from show commands, the search string is a regular expression consisting of a single character or string of characters. You can use special characters to construct complex regular expressions. See the next section for information on special characters used with regular expressions.

Using special characters in regular expressions

You use a regular expression to specify a single character or multiple characters as a search string. In addition, you can include special characters that influence the way the software matches the output against the search string. These special characters are listed in the following table.

TABLE 10 Special characters for regular expressions

Character Operation

. The period matches on any single character, including a blank space.

For example, the following regular expression matches “aaz”, “abz”, “acz”, and so on, but not just “az”:

a.z

* The asterisk matches on zero or more sequential instances of a pattern.

For example, the following regular expression matches output that contains the string “abc”, followed by zero or more Xs:

abcX*

+ The plus sign matches on one or more sequential instances of a pattern.

For example, the following regular expression matches output that contains "de", followed by a sequence of “g”s, such as “deg”, “degg”, “deggg”, and so on: deg+

? The question mark matches on zero occurrences or one occurrence of a pattern.

For example, the following regular expression matches output that contains "dg" or "deg": de?g

NOTE: Normally when you type a question mark, the CLI lists the commands or options at that CLI

level that begin with the character or string you entered. However, if you enter Ctrl+V and then type a question mark, the question mark is inserted into the command line, allowing you to use it as part of a regular expression.

^ A caret (when not used within brackets) matches on the beginning of an input string.

For example, the following regular expression matches output that begins with “deg”: ^deg

$ A dollar sign matches on the end of an input string.

For example, the following regular expression matches output that ends with “deg”: deg$

18 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Using and port number with CLI commands

TABLE 10 Special characters for regular expressions (Continued)

Character Operation

_ An underscore matches on one or more of the following:

• , (comma)

• { (left curly brace)

• } (right curly brace)

• ( (left parenthesis)

• ) (right parenthesis)

• The beginning of the input string

• The end of the input string

• A blank space

For example, the following regular expression matches on “100” but not on “1002”, “2100”, and so on. _100_

[ ] Square brackets enclose a range of single-character patterns.

For example, the following regular expression matches output that contains “1”, “2”, “3”, “4”, or “5”:

[1-5] You can use the following expression symbols within the brackets. These symbols are allowed only inside the brackets.

• ^ – The caret matches on any characters except the ones in the brackets. For example, the

following regular expression matches output that does not contain “1”, “2”, “3”, “4”, or “5”:

[^1-5]

• - The hyphen separates the beginning and ending of a range of characters. A match occurs if

any of the characters within the range is present. See the example above.

| A vertical bar separates two alternative values or sets of values. The output can match one or the

other value. For example, the following regular expression matches output that contains either “abc” or “defg”: abc|defg

( ) Parentheses allow you to create complex expressions.

For example, the following complex expression matches on “abc”, “abcabc”, or “defg”, but not on “abcdefgdefg”: ((abc)+)|((defg)?)

If you want to filter for a special character instead of using the special character as described in the table above, enter “\” (backslash) in front of the character. For example, to filter on output containing an asterisk, enter the asterisk portion of the regular expression as “\*”.

TurboIron#show ip route bgp | include \*

Creating an alias for a CLI command

You can crea te aliases for CLI commands. An alias serves as a shorthand version of a longer CLI command. For example, you can create an alias called shoro for the CLI command show ip route. Then when you enter shoro at the command prompt, the show ip route command is executed.

To create an alias called shoro for show ip route, enter the following command.

TurboIron(config)#alias shoro = show ip route

Syntax: [no] alias <alias-name> = <cli-command>

The <alias-name> must be a single word, without spaces.

Brocade TurboIron 24X Series Configuration Guide 19 53-1003053-01

Logging on through Brocade Network Advisor

After the alias is configured, entering shoro at either the Privileged EXEC or CONFIG levels of the CLI executes the show ip route command.

To create an alias called wrsbc for copy running-config tftp 10.10.10.10 test.cfg, enter the following command.

TurboIron(config)#alias wrsbc = copy running-config tftp 10.10.10.10 test.cfg

To re m ove the wrsbc alias from the configuration, enter one of the following commands.

TurboIron(config)#no alias wrsbc

TurboIron(config)#unalias wrsbc

Syntax: unalias <alias-name>

The specified <alias-name> must be the name of an alias already configured on the device.

To display the aliases currently configured on the device, enter the following command at either the Privileged EXEC or CONFIG levels of the CLI.

TurboIron#alias wrsbc copy running-config tftp 10.10.10.10 test.cfg shoro show ip route

Syntax: alias

Configuration notes

The following configuration notes apply to this feature:

• You cannot include additional parameters with the alias at the command prompt. For example,

after you create the shoro alias, shoro bgp would not be a valid command.

• If configured on the device, authentication, authorization, and accounting is performed on the

actual command, not on the alias for the command.

• To save an alias definition to the startup-config file, use the write memory command.

Logging on through Brocade Network Advisor

Refer to the Brocade Network Advisor manuals for information about using Brocade Network Advisor.

20 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Chapter

NOTE

Configuring Basic Software Features

In this chapter

•Configuring basic system parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

•Configuring basic port parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Configuring basic system parameters

Brocade devices are configured at the factory with default parameters that allow you to begin using the basic features of the system immediately. However, many of the advanced features such as VLANs or routing protocols for the device must first be enabled at the system (global) level before they can be configured. If you use the Command Line Interface (CLI) to configure system parameters, you can find these system level parameters at the Global CONFIG level of the CLI.

Before assigning or modifying any router parameters, you must assign the IP subnet (interface) addresses for each port.

For information about configuring IP addresses, DNS resolver, DHCP assist, and other IP-related parameters, refer to Chapter 20, “Configuring IP”.

For information about the Syslog buffer and messages, refer to Chapter 12, “Using Syslog”.

The procedures in this section describe how to configure the basic system parameters listed in

Tab le 11.

TABLE 11 Basic system parameters

Basic system parameter See page

System name, contact, and location page 22

SNMP trap receiver, trap source address, and other parameters page 22

Single source address for all Telnet packets page 27

Single source address for all TFTP packets page 28

Single source address for all Syslog packets page 28

Single source address for all NTPv4 packets page 28

System time using a Simple Network Time Protocol (NTPv4) server or local system counter page 28

System clock page 29

Broadcast, multicast, or unknown-unicast limits, if required to support slower third-party devices

page 31

Brocade TurboIron 24X Series Configuration Guide 21 53-1003053-01

Configuring basic system parameters

NOTE

For information about the Syslog buffer and messages, refer to Chapter 12, “Using Syslog”.

Entering system administration information

You can configure a system name, contact, and location for a device and save the information locally in the configuration file for future reference. This information is not required for system operation but is suggested. When you configure a system name, the name replaces the default system name in the CLI command prompt.

The name, contact, and location each can be up to 32 alphanumeric characters.

Here is an example of how to configure a system name, system contact, and location.

TurboIron(config)#hostname zappa zappa(config)#snmp-server contact Support Services zappa(config)#snmp-server location Centerville zappa(config)#end zappa#write memory

Syntax: hostname <string>

Syntax: snmp-server contact string>

Syntax: snmp-server location <string>

The text strings can contain blanks. The SNMP text strings do not require quotation marks when they contain blanks but the host name does.

The chassis name command does not change the CLI prompt. Instead, the command assigns an administrative ID to the device.

Configuring Simple Network Management Protocol (SNMP) parameters

Use the procedures in this section to perform the following configuration tasks:

• Specify an SNMP trap receiver.

• Specify a source address and community string for all traps sent by the device.

• Change the holddown time for SNMP traps

• Disable individual SNMP traps. (All traps are enabled by default.)

• Disable traps for CLI access that is authenticated by a local user account, a RADIUS server, or

a TACACS/TACACS+ server.

To add and modify “get” (read-only) and “set” (read-write) community strings, refer to Chapter 5,

“Securing Access to Management Functions”.

22 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring basic system parameters

Specifying an SNMP trap receiver

You can specify a trap receiver to ensure that all SNMP traps sent by the device go to the same SNMP trap receiver or set of receivers, typically one or more host devices on the network. When you specify the host, you also specify a community string. The device sends all the SNMP traps to the specified hosts and includes the specified community string. Administrators can therefore filter for traps from a device based on IP address or community string.

When you add a trap receiver, the software automatically encrypts the community string you associate with the receiver when the string is displayed by the CLI. If you want the software to show the community string in the clear, you must explicitly specify this when you add a trap receiver. In either case, the software does not encrypt the string in the SNMP traps sent to the receiver.

To specify the host to which the device sends all SNMP traps, use one of the following methods.

To add a trap receiver and encrypt the display of the community string, enter commands such as the following.

To specify an SNMP trap receiver and change the UDP port that will be used to receive traps, enter a command such as the following.

TurboIron(config)#snmp-server host 10.2.2.2 0 mypublic port 200 TurboIron(config)#write memory

Syntax: snmp-server host <ip-addr> [0 | 1] <string> [port <value>]

The <ip-addr> parameter specifies the IP address of the trap receiver.

The 0 | 1 parameter specifies whether you want the software to encrypt the string (1) or show the string in the clear (0). The default is 0.

The <string> parameter specifies an SNMP community string configured on the device. The string can be a read-only string or a read-write string. The string is not used to authenticate access to the trap host but is instead a useful method for filtering traps on the host. For example, if you configure each of your devices that use the trap host to send a different community string, you can easily distinguish among the traps from different devices based on the community strings.

The command in the example above adds trap receiver 10.2.2.2 and configures the software to encrypt display of the community string. When you save the new community string to the startup-config file (using the write memory command), the software adds the following command to the file.

snmp-server host 10.2.2.2 1 <encrypted-string>

To add a trap receiver and configure the software to encrypt display of the community string in the CLI, enter commands such as the following.

device(config)#snmp-server host 10.2.2.2 0 device-12 device(config)#write memory

The port <value> parameter allows you to specify which UDP port will be used by the trap receiver. This parameter allows you to configure several trap receivers in a system. With this parameter, device and another network management application can coexist in the same system. Devices can be configured to send copies of traps to more than one network management application.

Brocade TurboIron 24X Series Configuration Guide 23 53-1003053-01

Configuring basic system parameters

Specifying a single trap source

You can specify a single trap source to ensure that all SNMP traps sent by the device use the same source IP address. When you configure the SNMP source address, you specify the Ethernet port, loopback interface, or virtual interface that is the source for the traps. The device then uses the lowest-numbered IP address configured on the port or interface as the source IP address in the SNMP traps sent by the device.

Identifying a single source IP address for SNMP traps provides the following benefits:

• If your trap receiver is configured to accept traps only from specific links or IP addresses, you

can use this feature to simplify configuration of the trap receiver by configuring the device to always send the traps from the same link or source address.

• If you specify a loopback interface as the single source for SNMP traps, SNMP trap receivers

can receive traps regardless of the states of individual links. Thus, if a link to the trap receiver becomes unavailable but the receiver can be reached through another link, the receiver still receives the trap, and the trap still has the source IP address of the loopback interface.

To specify a port, loopback interface, or virtual interface whose lowest-numbered IP address the device must use as the source for all SNMP traps sent by the device, use the following CLI method.

To configure the device to send all SNMP traps from the first configured IP address on port 4, enter the following commands.

TurboIron(config)#snmp trap-source ethernet 4 TurboIron(config)#write memory

Syntax: snmp-server trap-source loopback <num> | ethernet <portnum> | ve <num>

The <num> parameter is a loopback interface or virtual interface number.

To specify a loopback interface as the SNMP trap source for the device, enter commands such as the following.

TurboIron(config)#int loopback 1 TurboIron(config-lbif-1)#ip address 10.0.0.1/24 TurboIron(config-lbif-1)#exit TurboIron(config)#snmp-server trap-source loopback 1

The commands in this example configure loopback interface 1, assign IP address 10.00.1/24 to the loopback interface, then designate the interface as the SNMP trap source for this device. Regardless of the port the device uses to send traps to the receiver, the traps always arrive from the same source IP address.

Setting the SNMP trap holddown time

When a device starts up, the software waits for Layer 2 convergence (STP) and Layer 3 convergence (OSPF) before beginning to send SNMP traps to external SNMP servers. Until convergence occurs, the device might not be able to reach the servers, in which case the messages are lost.

By default, a device uses a one-minute holddown time to wait for the convergence to occur before starting to send SNMP traps. After the holddown time expires, the device sends the traps, including traps such as “cold start” or “warm start” that occur before the holddown time expires.

You can change the holddown time to a value from one second to ten minutes.

To change the holddown time for SNMP traps, enter a command such as the following at the global CONFIG level of the CLI.

24 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring basic system parameters

NOTE

TurboIron(config)#snmp-server enable traps holddown-time 30

The command in this example changes the holddown time for SNMP traps to 30 seconds. The device waits 30 seconds to allow convergence in STP and OSPF before sending traps to the SNMP trap receiver.

Syntax: [no] snmp-server enable traps holddown-time <secs>

The <secs> parameter specifies the number of seconds and can be from 1 – 600 (ten minutes). The default is 60 seconds.

Disabling SNMP traps

TurboIron X Series devices come with SNMP trap generation enabled by default for all traps. You can selectively disable one or more of the following traps.

By default, all SNMP traps are enabled at system startup.

Layer 2 traps The following traps are generated on devices running Layer 2 software:

• SNMP authentication keys

• Power supply failure

• Fan failure

• Cold start

• Link up

• Link down

• Bridge new root

• Bridge topology change

• Locked address violation

Layer 3 traps The following traps are generated on devices running Layer 3 software:

• SNMP authentication key

• Power supply failure

• Fan failure

• Cold start

• Link up

• Link down

• Bridge new root

• Bridge topology change

• Locked address violation

• BGP4

• OSPF

• VRRP

Brocade TurboIron 24X Series Configuration Guide 25 53-1003053-01

Configuring basic system parameters

NOTE

TurboIron#show logging Syslog logging: enabled (0 messages dropped, 0 flushes, 0 overruns) Buffer logging: level ACDMEINW, 12 messages logged level code: A=alert C=critical D=debugging M=emergency E=error I=informational N=notification W=warning Static Log Buffer: Dec 15 19:04:14:A:Fan 1, fan on right connector, failed

Dynamic Log Buffer (50 entries): Oct 15 18:01:11:info:dg logout from USER EXEC mode Oct 15 17:59:22:info:dg logout from PRIVILEGE EXEC mode Oct 15 17:38:07:info:dg login to PRIVILEGE EXEC mode Oct 15 17:38:03:info:dg login to USER EXEC mode

• VRRP-E

To stop link down occurrences from being reported, enter the following.

TurboIron(config)#no snmp-server enable traps link-down

Syntax: [no] snmp-server enable traps <trap-type>

Disabling Syslog messages and traps for CLI access

TurboIron X Seriesdevices send Syslog messages and SNMP traps when a user logs into or out of the User EXEC or Privileged EXEC level of the CLI. The feature applies to users whose access is authenticated by an authentication-method list based on a local user account, RADIUS server, or TACACS/TACACS+ server.

The Privileged EXEC level is sometimes called the “Enable” level, because the command for accessing this level is enable.

The feature is enabled by default.

Examples of Syslog messages for CLI access When a user whose access is authenticated by a local user account, a RADIUS server, or a

TACACS/TACACS+ server logs into or out of the CLI User EXEC or Privileged EXEC mode, the software generates a Syslog message and trap containing the following information:

• The time stamp

• The user name

• Whether the user logged in or out

• The CLI level the user logged into or out of (User EXEC or Privileged EXEC level)

Messages for accessing the User EXEC level apply only to access through Telnet. The device does not authenticate initial access through serial connections but does authenticate serial access to the Privileged EXEC level. Messages for accessing the Privileged EXEC level apply to access through the serial connection or Telnet.

The following examples show login and logout messages for the User EXEC and Privileged EXEC levels of the CLI.

Syntax: show logging

26 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring basic system parameters

The first message (the one on the bottom) indicates that user “dg” logged in to the CLI User EXEC level on October 15 at 5:38 PM and 3 seconds (Oct 15 17:38:03). The same user logged into the Privileged EXEC level four seconds later.

The user remained in the Privileged EXEC mode until 5:59 PM and 22 seconds. (The user could have used the CONFIG modes as well. Once you access the Privileged EXEC level, no further authentication is required to access the CONFIG levels.) At 6:01 PM and 11 seconds, the user ended the CLI session.

Disabling the Syslog messages and traps Logging of CLI access is enabled by default. If you want to disable the logging, enter the following

commands.

TurboIron(config)#no logging enable user-login TurboIron(config)#write memory TurboIron(config)#end TurboIron#reload

Syntax: [no] logging enable user-login

Configuring an interface as the source for all Telnet packets

You can designate the lowest-numbered IP address configured on an interface as the source IP address for all Telnet packets from the device. Identifying a single source IP address for Telnet packets provides the following benefits:

• If your Telnet server is configured to accept packets only from specific links or IP addresses,

you can use this feature to simplify configuration of the Telnet server by configuring the device to always send the Telnet packets from the same link or source address.

• If you specify a loopback interface as the single source for Telnet packets, Telnet servers can

receive the packets regardless of the states of individual links. Thus, if a link to the Telnet server becomes unavailable but the client or server can be reached through another link, the client or server still receives the packets, and the packets still have the source IP address of the loopback interface.

The software contains separate CLI commands for specifying the source interface for Telnet, TACACS/TACACS+, and RADIUS packets. You can configure a source interface for one or more of these types of packets.

To specify an interface as the source for all Telnet packets from the device, use the following CLI method. The software uses the lowest-numbered IP address configured on the interface as the source IP address for Telnet packets originated by the device.

To specify the lowest-numbered IP address configured on a virtual interface as the device source for all Telnet packets, enter commands such as the following.

TurboIron(config)#int loopback 2 TurboIron(config-lbif-2)#ip address 10.0.0.2/24 TurboIron(config-lbif-2)#exit TurboIron(config)#ip telnet source-interface loopback 2

The commands in this example configure loopback interface 2, assign IP address 10.0.0.2/24 to the interface, then designate the interface as the source for all Telnet packets from the device.

Syntax: ip telnet source-interface ethernet <portnum> | loopback <num> | ve <num>

The following commands configure an IP interface on an Ethernet port and designate the address port as the source for all Telnet packets from the device.

Brocade TurboIron 24X Series Configuration Guide 27 53-1003053-01

Configuring basic system parameters

NOTE

TurboIron#show sntp associations address ref clock st when poll delay disp ~10.95.6.102 0.0.0.0 16 202 4 0.0 5.45 ~10.95.6.101 0.0.0.0 16 202 0 0.0 0.0 * synced, ~ configured

TurboIron(config)#interface ethernet 4 TurboIron(config-if-e10000-4)#ip address 10.157.22.110/24 TurboIron(config-if-e10000-4)#exit TurboIron(config)#ip telnet source-interface ethernet 4

Cancelling an outbound Telnet session

If you want to cancel a Telnet session from the console to a remote Telnet server (for example, if the connection is frozen), you can terminate the Telnet session by doing the following.

1. At the console, press Ctrl+^ (Ctrl+Shift-6).

2. Press the X key to terminate the Telnet session.

Pressing Ctrl+^ twice in a row causes a single Ctrl+^ character to be sent to the Telnet server. After you press Ctrl+^, pressing any key other than X or Ctrl+^ returns you to the Telnet session.

Specifying a Simple Network Time Protocol (NTPv4) server

You can configure the device to consult NTPv4 servers for the current time and date.

TurboIron X Series devices do not retain time and date information across power cycles. Unless you want to reconfigure the system time counter each time the system is reset, Brocade recommends that you use the NTPv4 feature.

To identify an NTPv4 server with IP address 10.99.8.95 to act as the clock reference for a device, enter the following.

TurboIron(config)#sntp server 10.99.8.95

Syntax: sntp server <ip-addr> | <hostname> [<version>]

The <version> parameter specifies the NTPv4 version the server is running and can be from 1 – 4. The default is 1. You can configure up to three NTPv4 servers by entering three separate sntp server commands.

By default, the device polls its NTPv4 server every 30 minutes (1800 seconds). To configure the device to poll for clock updates from a NTPv4 server every 15 minutes, enter the following.

TurboIron(config)#sntp poll-interval 900

Syntax: [no] sntp poll-interval <1-65535>

To display information about NTPv4 associations, enter the following command.

Syntax: show sntp associations

The following table describes the information displayed by the show sntp associations command.

28 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring basic system parameters

TurboIron#show sntp status Clock is unsynchronized, stratum = 0, no reference clock precision is 2**0 reference time is 0 .0 clock offset is 0.0 msec, root delay is 0.0 msec root dispersion is 0.0 msec, peer dispersion is 0.0 msec

TABLE 12 Output from the show sntp associations command

This field... Displays...

(leading character) One or both of the following:

*Synchronized to this peer ~ Peer is statically configured

address IP address of the peer

ref clock IP address of the peer reference clock

st NTP stratum level of the peer

when Amount of time since the last NTP packet was received from the peer

poll Poll interval in seconds

delay Round trip delay in milliseconds

disp Dispersion in seconds

To display information about NTPv4 status, enter the following command.

Syntax: show sntp status

The following table describes the information displayed by the show sntp status command.

TABLE 13 Output from the show sntp status command

This field... Indicates...

unsynchronized System is not synchronized to an NTP peer.

synchronized System is synchronized to an NTP peer.

stratum NTP stratum level of this system

reference clock IP Address of the peer (if any) to which the unit is synchronized

precision Precision of this system's clock (in Hz)

reference time Reference time stamp

clock offset Offset of clock to synchronized peer

root delay Total delay along the path to the root clock

root dispersion Dispersion of the root path

peer dispersion Dispersion of the synchronized peer

Setting the system clock

In addition to NTPv4 support, switches and routers also allow you to set the system time counter. The time counter setting is not retained across power cycles and is not automatically synchronized with an NTPv4 server. The counter merely starts the system time and date clock with the time and date you specify.

Brocade TurboIron 24X Series Configuration Guide 29 53-1003053-01

Configuring basic system parameters

NOTE

You can synchronize the time counter with your NTPv4 server time by entering the sntp sync command from the Privileged EXEC level of the CLI.

Unless you identify an NTPv4 server for the system time and date, you will need to re-enter the time and date following each reboot.

For more details about NTPv4, refer to “Specifying a Simple Network Time Protocol (NTPv4) server” on page 28.

To set the system time and date to 10:15:05 on October 15, 2003, enter the following command.

TurboIron#clock set 10:15:05 10-15-2003

Syntax: [no] clock set <hh:mm:ss> | <mm-dd-yy> | <mm-dd-yyyy>

By default, switches and routers do not change the system time for daylight saving time. To enable daylight saving time, enter the following command.

TurboIron(config)#clock summer-time

Syntax: clock summer-time

Although NTPv4 servers typically deliver the time and date in Greenwich Mean Time (GMT), you can configure the device to adjust the time for any one-hour offset from GMT or for one of the following U.S. time zones:

• US Pacific

• Alaska

• Aleutian

• Arizona

• Central

• East-Indiana

• Eastern

• Hawaii

• Michigan

• Mountain

• Pacific

• Samoa

To change the time zone to Australian East Coast time (which is normally 10 hours ahead of GMT), enter the following command.

TurboIron(config)#clock timezone gmt gmt+10

Syntax: clock timezone gmt gmt | us <time-zone>

You can enter one of the following values for <time-zone>:

• US time zones (us): alaska, aleutian, arizona, central, east-indiana, eastern, hawaii, michigan,

mountain, pacific, samoa.

• GMT time zones (gmt): gmt+0:00 to gmt+12:00 in increments of 1, and gmt-0:00 to gmt-12:00

in decrements of 1 are supported.

30 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring basic system parameters

NOTE

New start and end dates for US daylight saving time

This feature applies to US time zones only.

Starting in 2007, the system will automatically change the system clock to Daylight Saving Time (DST), in compliance with the new federally mandated start of daylight saving time, which is extended one month beginning in 2007. The DST will start at 2:00am on the second Sunday in March and will end at 2:00am on the first Sunday in November.

The DST feature is automatic, but to trigger the device to the correct time, the device must be configured to the US time zone, not the GMT offset. To configure your device to use the US time zone, enter the following command.

TurboIron(config)#clock timezone us pacific

Syntax: [no] clock timezone us <timezone-type>

Enter pacific, eastern, central, or mountain for <timezone-type>.

This command must be configured on every device that follows the US DST.

To verify the change, run a show clock command.

TurboIron#show clock

Limiting broadcast, multicast, and unknown unicast traffic

TurboIron X Series devices can forward all flooded traffic at wire speed within a VLAN. However, some third-party networking devices cannot handle high rates of broadcast, multicast, or unknown-unicast traffic. If high rates of traffic are being received by the device on a given port of that VLAN, you can limit the number of broadcast, multicast, or unknown-unicast packets or bytes received each second on that port. This can help to control the number of such packets or bytes that are flooded on the VLAN to other devices.

Byte-based limiting for broadcast, multicast, and unknown unicast traffic provides the ability to rate limit traffic based on byte count instead of packet count. When the byte mode is enabled, packets will be received on a port as long as the number of bytes received per second is less than the corresponding limit. Once the limit is reached, further packets will be dropped.

TurboIron X Seriesdevices do not support packet-based and byte-based limiting simultaneously on the same port. For example, if you configure packet-based limiting for broadcast traffic, you must also configure packet-based limiting for multicast and unknown unicast traffic. Likewise, if you configure byte-based limiting for broadcast traffic, you must also configure byte-based limiting for multicast and unknown unicast traffic.

Command syntax for packet-based limiting

To enable broadcast limiting on a group of ports by counting the number of packets received, enter commands such as the following.

TurboIron(config)#interface ethernet 1 to 8 TurboIron(config-mif-e10000-1-8)#broadcast limit 65536

These commands configure packet-based broadcast limiting on ports 1 – 8. On each port, the maximum number of broadcast packets per second cannot exceed 65,536 packets per second.

Brocade TurboIron 24X Series Configuration Guide 31 53-1003053-01

Configuring basic system parameters

NOTE

On TurboIron X Series devices, multicast limiting is independent of broadcast limiting. To enable multicast limiting on devices, enter commands such as the following.

TurboIron(config)#interface ethernet 1 to 8 TurboIron(config-mif-e10000-1-8)#multicast limit 65536

To enable unknown unicast limiting by counting the number of packets received, enter commands such as the following.

TurboIron(config)#interface eth 1 TurboIron(config-if-e10000-1)#unknown-unicast limit 65536 The combined number of inbound Unknown Unicast packets permitted for ports 1 to 12 is now set to 65536 TurboIron((config-if-e10000-1)#

Syntax: [no] broadcast limit <num>

Syntax: [no] unknown-unicast limit <num>

Syntax: [no]

Syntax: [no] multicast limit <num>

The multicast limit <num> command applies to devices only.

The <num> variable specifies the maximum number of packets per second. Acceptable values differ depending on the device you are configuring:

• On TurboIron X Seriesdevices, <num> can be any number between 1 and 8388607 (packets

per second). The actual value will be determined by the system. Once you enter the value, the CLI will display a message indicating the actual value. The following shows an example configuration.

TurboIron(config)#interface ethernet 9 TurboIronconfig-mif-e10000-9)#multicast limit 50

Multicast limit in pkts/sec set to 31

If you specify 0, limiting is disabled. Limiting is disabled by default.

Command syntax for byte-based limiting

TurboIron X Series devices limit traffic based on kilobits per second (kbps). To enable limiting, refer to the appropriate section, below.

TurboIron X Series devices To enable broadcast limiting on a group of ports by counting the number of kilobits received, enter

commands such as the following.

TurboIron(config)#interface ethernet 9 to 10 TurboIron(config-mif-e10000-9-10)#broadcast limit 131072 kbps Broadcast limit in kbits/sec set to 130000

These commands configure broadcast limiting on ports 9 and 10. On each port, the total number of kilobits received from broadcast packets cannot exceed 130,000 per second.

To enable multicast limiting, enter commands such as the following.

32 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring basic system parameters

TurboIron#show run interface interface ethernet 4 broadcast limit 1245184 bytes multicast limit ! interface ethernet 5 broadcast limit 1245184 bytes multicast limit ! interface ethernet 12 unknown-unicast limit 524288 ! interface ethernet 13 unknown-unicast limit 65536 bytes ! interface ethernet 14 broadcast limit 65536 ! interface ethernet 23 broadcast limit 131072 multicast limit !

TurboIron(config)#interface ethernet 8 TurboIron(config-mif-e10000-1-8)#multicast limit 9000 kbps Multicast limit in kbits/sec set to 8064

To enable unknown unicast limiting, enter commands such as the following.

TurboIron(config)#int e 13 TurboIron(config-if-e10000-13)#unknown-unicast limit 65536 kbps Unknown unicast limit in kbits/sec set to 64000

Syntax: [no] broadcast limit <num> kbps

Syntax: [no] multicast limit <num> kbps

Syntax: [no] unknown-unicast limit <num> kbps

The <num> variable can be any number between 1 and 10000000. The actual value will be determined by the system. Once you enter the value, the CLI will display a message indicating the actual value, as shown in the configuration examples above. If you specify 0, limiting is disabled. Limiting is disabled by default.

Viewing broadcast, multicast, and unknown unicast limits

You can use the show run interface command to display the broadcast, multicast, and unknown-unicast limits configured on the device.

In addition to the show run interface command, to display the broadcast, multicast, and unknown-unicast limits configured on the device:

• show rate-limit unknown-unicast

• show rate-limit broadcast

Use the show run interface command to view the broadcast, multicast, and unknown-unicast limit configured on each port.

Brocade TurboIron 24X Series Configuration Guide 33 53-1003053-01

Syntax: show run interface

Configuring basic port parameters

TurboIron#show rate-limit unknown-unicast Unknown Unicast Limit Settings: Port Region Combined Limit Packets/Bytes 1 - 12 524288 Packets 13 - 24 65536 Bytes

TurboIron#show rate-limit broadcast Broadcast/Multicast Limit Settings: Port Limit Packets/Bytes Packet Type(s) 4 1245184 Bytes Broadcast + Multicast 5 1245184 Bytes Broadcast + Multicast 14 65536 Packets Broadcast only 23 131072 Packets Broadcast + Multicast

Use the show rate-limit unknown-unicast command to display the unknown unicast limit for each port region to which it applies.

Syntax: show rate-limit unknown-unicast

Use the show rate-limit broadcast command to display the broadcast limit or broadcast and multicast limit for each port to which it applies.

Syntax: show rate-limit broadcast

Configuring basic port parameters

The procedures in this section describe how to configure the port parameters shown in Tab le 14.

TABLE 14 Basic port parameters

Port parameter See page

Name page 35

Speed page 35

Duplex mode page 36

Port status (enable or disable) page 36

Flow control page 37

Auto-negotiation and advertisement of flow control page 37

Configuring PHY FIFO Rx and TX Depth page 38

Interpacket Gap (IPG) page 38

Gbps fiber negotiate mode page 39

QoS priority page 39

Port flap dampening page 39

All ports are pre-configured with default values that allow the device to be fully operational at initial startup without any additional configuration. However, in some cases, changes to the port parameters may be necessary to adjust to attached devices or other network requirements.

34 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring basic port parameters

NOTE

Assigning a port name

A port name can be assigned to help identify interfaces on the network. You can assign a port name to physical ports, virtual interfaces, and loopback interfaces.

To assign a name to a port.

TurboIron(config)#interface e 2 TurboIron(config-if-e10000-2)#port-name Marsha

Syntax: port-name <text>

The <text> parameter is an alphanumeric string. The name can be up to 64 characters long. The name can contain blanks. You do not need to use quotation marks around the string, even when it contains blanks.

Modifying port speed and duplex mode

This section describes how to modify port speed and duplex mode on TurboIron X Series devices.

Copper ports

The Gigabit Ethernet copper ports are designed to auto-sense and auto-negotiate the speed and duplex mode of the connected device. If the attached device does not support this operation, you can manually enter the port speed to operate at either 10, 100, or 1000 Mbps. The default and recommended setting is 10/100/1000 auto-sense.

On TurboIron X Series devices, you can modify the port speed of copper ports and the 24 fiber ports.

For optimal link operation, copper ports on devices that do not support 803.3u must be configured with like parameters, such as speed (10,100,1000), duplex (half, full), and Flow Control.

Fiber ports on the TurboIron X Series

The fiber ports on the TurboIron X Series devices support 1 GbE and 10 GbE connections, depending on the SFP optic installed in the port. SFP+ optics are used for 10 GbE filber connections, and SFP optics are used for 1 GbE fiber connections. The default setting is 10 GbE full-duplex mode with SFP+ optics. To use 1 GbE in a 10 GbE port, insert an SFP optic and change the speed-duplex to 1 GbE (speed-duplex 1000).

Configuration syntax

The following commands change the port speed of fiber interface 8 on a TurboIron X Series device from the default of 10 Gbps to 1 Gbps.

TurboIron(config)#interface e 8 TurboIron(config-if-e10000-8)#speed-duplex 1000

Syntax: speed-duplex <value>

where< value> can be one of the following:

• 10-full – 10 Mbps, full duplex

Brocade TurboIron 24X Series Configuration Guide 35 53-1003053-01

Configuring basic port parameters

NOTE

• 10-half – 10 Mbps, half duplex

• 100-full – 100 Mbps, full duplex

• 100-half – 100 Mbps, half duplex

• 1000 – 1 Gbps, full duplex (not supported on TurboIron X Series 10-GbE ports only)

• 1000-full-master – 1 Gbps, full duplex master (supported on the TurboIron X Series)

• 1000-full-slave – 1 Gbps, full duplex slave (not supported on the TurboIron X Series)

• 10000 – 10 Gbps, full duplex (supported on TurboIron X Series 10-GbE ports only)

• auto – auto-negotiation

The default for copper ports is auto (auto-negotiation).

The default for fiber ports on the TurboIron X Series is 10000 (10 Gbps, full duplex).

Use the no form of the command to restore the default.

On TurboIron X Series devices, when 10/100/1000 copper ports (ports 25 – 28) auto-negotiate to either 1 Gbps or 100 Mbps, the green and amber LEDs will be lit solid (ON) when the link is up, and the amber LED will blink when traffic flows through the port. On TurboIron X Series devices, if the speed is set to Auto for a 1G port, the port auto-negotiates the flow control with the neighboring port.

Auto speed detect

On TurboIron X Series devices, if you insert a 1G SFP, the device detects the media change and automatically change the speed to support 1G for that port. This happens when the configured speed is 10G. The configured speed continues to be 10G, but the port comes up with operational speed of 1G. This removes the need for explicitly configuring speed-duplex 1000 for SFPs where the device is able to detect the media type.

All the po r ts wi th 1G SF Ps which need to form a trunk (static or dynamic), need to use either the Auto speed detect feature to come up in 1G mode or use the speed-duplex 1000 command. Configuring speed-duplex 1000 on only few of the ports to be part of the trunk will prevent trunk creation.

Modifying port duplex mode

You can manually configure a 10/100 Mbps port to accept either full-duplex (bi-directional) or half-duplex (uni-directional) traffic.

You can modify the port duplex mode of copper ports only. This feature does not apply to fiber ports.

Port duplex mode and port speed are modified by the same command, which is speed-duplex.

Disabling or re-enabling a port

A port can be made inactive (disable) or active (enable) by selecting the appropriate status option. The default value for a port is enabled.

To disable port 8 of a device, enter the following.

36 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring basic port parameters

NOTE

TurboIron(config)#interface e 8 TurboIron(config-if-e10000-8)#disable

Syntax: disable

You also can disable or re-enable a virtual interface. To do so, enter commands such as the following.

TurboIron(config)#interface ve v1 TurboIron(config-vif-1)#disable

Syntax: disable

To re-enable a virtual interface, enter the enable command at the Interface configuration level. For example, to re-enable virtual interface v1, enter the following command.

TurboIron(config-vif-1)#enable

Syntax: enable

Disabling or re-enabling flow control

You can configure full-duplex ports on a system to operate with or without flow control (802.3x). Flow control is enabled by default.

To disable flow control on full-duplex ports on a system, enter the following.

TurboIron(config)#no flow-control

To turn the feature back on.

TurboIron(config)#flow-control

Syntax: [no] flow-control

For optimal link operation, link ports on devices that do not support 803.3u must be configured with like parameters, such as speed (10,100,1000), duplex (half, full), and Flow Control.

Auto-negotiation and advertisement of flow control

Auto-negotiation of flow control can be enabled and advertised for 10/100/1000M ports. To enable and advertise flow control capability, enter the following commands.

TurboIron(config)#interface ethernet 21 TurboIron(config-if-e10000-21)#flow-control

To also enable auto-negotiation of flow control, enter the following commands.

TurboIron(config)#interface ethernet 21 TurboIron(config-if-e10000-21)#flow-control neg-on

Syntax: #[no] flow-control [neg-on]

• flow-control [default] - Enable flow control, advertise flow control and disable negotiation of

flow control

• flow-control neg-on - Advertise flow control and enable negotiation of flow control

• no flow-control - Disable flow control, disable advertising flow control and also disable

negotiation of flow control

Brocade TurboIron 24X Series Configuration Guide 37 53-1003053-01

Configuring basic port parameters

Commands may be entered in IF (single port) or MIF (multiple ports at once) mode.

TurboIron(config)#interface ethernet 21 TurboIron(config-if-e10000-21)#flow-control

This command enables flow-control on port 21.

TurboIron(config)#interface e 11 to 15 TurboIron(config-mif-11-15)#flow-control

This command enables flow-control on ports 11 to 15.

TurboIron X SeriesConfiguring the Interpacket Gap (IPG)

IPG is the time delay, in bit time, between frames transmitted by the device. You configure IPG at the interface level. The command you use depends on the interface type on which IPG is being configured.

The default interpacket gap is 96 bits-time, which is 9.6 microseconds for 10 Mbps Ethernet, 960 nanoseconds for 100 Mbps Ethernet, 96 nanoseconds for 1 Gbps Ethernet, and 9.6 nanoseconds for 10 Gbps Ethernet.

Configuration notes

• When you enter a value for IPG, the device applies the closest valid IPG value for the port mode

to the interface. For example, if you specify 120 for a 1 Gbps Ethernet port in 1 Gbps mode, the device assigns 112 as the closest valid IPG value to program into hardware.

Configuring IPG on a Gbps Ethernet port

On a Gbps Ethernet port, you can configure IPG for 10/100 mode and for Gbps Ethernet mode.

10/100M mode To configure IPG on a Gbps Ethernet port for 10/100M mode, enter the following command.

TurboIron(config)#interface ethernet 1 TurboIron(config-if-e10000-1)#ipg-mii 120 IPG 120(120) has been successfully configured for ports 1 to 12

Syntax: [no] ipg-mii <bit time>

Enter 12-124 for <bit time>. The default is 96 bit time.

1G mode To configure IPG on a Gbps Ethernet port for 1-Gbps Ethernet mode, enter commands such as the

following.

TurboIron(config)#interface ethernet 1 TurboIron(config-if-e10000-1)#ipg-gmii 120 IPG 120(112) has been successfully configured for ports 1 to 12

Syntax: [no] ipg-gmii <bit time>

Enter 48 - 112 for <bit time>. The default is 96 bit time.

38 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring basic port parameters

NOTE

Configuring IPG on a 10 Gbps Ethernet interface

To configure IPG on a 10 Gbps Ethernet interface, enter commands such as the following.

TurboIron(config)#interface ethernet 1 TurboIron(config-if-e10000-1)#ipg-xgmii 120 IPG 120(128) has been successfully configured for port 1

Syntax: [no] ipg-xgmii <bit time>

Enter 96-192 for <bit time>. The default is 96 bit time.

Changing the Gbps fiber negotiation mode

The globally configured Gbps negotiation mode is the default mode for all Gbps fiber ports. You can override the globally configured default and set individual ports to the following:

• Negotiate-full-auto – The port first tries to perform a handshake with the other port to

exchange capability information. If the other port does not respond to the handshake attempt, the port uses the manually configured configuration information (or the defaults if an administrator has not set the information). This is the default.

• Auto-Gbps – The port tries to perform a handshake with the other port to exchange capability

information.

• Negotiation-off – The port does not try to perform a handshake. Instead, the port uses

configuration information manually configured by an administrator.

To change the mode for individual ports, enter commands such as the following.

TurboIron(config)#int ethernet 1 to 4 TurboIron(config-mif-1-4)#gig-default auto-gig

This command overrides the global setting and sets the negotiation mode to auto-Gbps for ports 1 – 4.

Syntax: gig-default neg-full-auto | auto-gig | neg-off

When Gbps negotiation mode is turned off (CLI command gig-default neg-off), the device may inadvertently take down both ends of a link. This is a hardware limitation for which there is currently no workaround.

Modifying port priority (QoS)

You can give preference to the inbound traffic on specific ports by changing the Quality of Service (QoS) level on those ports. For information and procedures, refer to Chapter 35, “Configuring

Quality of Service”.

Configuring port flap dampening

Port Flap Dampening increases the resilience and availability of the network by limiting the number of port state transitions on an interface.

Brocade TurboIron 24X Series Configuration Guide 39 53-1003053-01

Configuring basic port parameters

If the port link state toggles from up to down for a specified number of times within a specified period, the interface is physically disabled for the specified wait period. Once the wait period expires, the port link state is re-enabled. However, if the wait period is set to zero (0) seconds, the port link state will remain disabled until it is manually re-enabled.

Configuration notes

• When a flap dampening port becomes a member of a trunk group, that port, as well as all

other member ports of that trunk group, will inherit the primary port configuration. This means that the member ports will inherit the primary port flap dampening configuration, regardless of any previous configuration.

• The device counts the number of times a port link state toggles from "up to down", and not

from "down to up".

• The sampling time or window (the time during which the specified toggle threshold can occur

before the wait period is activated) is triggered when the first "up to down" transition occurs.

• "Up to down" transitions include UDLD-based toggles, as well as the physical link state.

Configuring port flap dampening on an interface

This feature is configured at the interface level.

TurboIron(config)#interface ethernet 1 TurboIron(config-if-e10000-1)#link-error-disable 10 3 10

Syntax: [no] link-error-disable <toggle-threshold> <sampling-time-in-sec> <wait-time-in-sec>

The <toggle-threshold> is the number of times a port link state goes from up to down and down to up before the wait period is activated. The default is 0. Enter a valid value range from 1-50.

The <sampling-time-in-sec> is the amount of time during which the specified toggle threshold can occur before the wait period is activated. The default is 0 seconds. Enter 0 – 65535 seconds.

The <wait-time-in-sec> is the amount of time the port remains disabled (down) before it becomes enabled. Entering 0 – 65535 seconds; 0 indicates that the port will stay down until an administrative override occurs.

Configuring port flap dampening on a trunk

You can configure the port flap dampening feature on the primary port of a trunk using the link-error-disable command. Once configured on the primary port, the feature is enabled on all ports that are members of the trunk. You cannot configure port flap dampening on port members of the trunk.

Enter commands such as the following on the primary port of a trunk.

TurboIron(config)#interface ethernet 1 TurboIron(config-if-e10000-1)#link-error-disable 10 3 10

Re-enabling a port disabled by port flap dampening

A port disabled by port flap dampening is automatically re-enabled once the wait period expires; however, if the wait period is set to zero (0) seconds, you must re-enable the port by entering the following command on the disabled port.

40 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring basic port parameters

TurboIron#show link-error-disable Port 1 is forced down by link-error-disable.

TurboIron#show link-error-disable all Port -----------------Config--------------- ------Oper--- # Threshold Sampling-Time Shutoff-Time State Counter

----- --------- ------------- ------------ ----- ------ 11 3 120 600 Idle N/A 12 3 120 500 Down 424

TurboIron(config)#interface ethernet 1 TurboIron(config-if-e10000-1)#no link-error-disable 10 3 10

Displaying ports configured with port flap dampening

Ports that have been disabled due to the port flap dampening feature are identified in the output of the show link-error-disable command. The following shows an example output.

Use the show link-error-disable all command to display the ports with the port flap dampening feature enabled.

For TurboIron X Series devices, the output of the command shows the following.

Tab le 15 defines the port flap dampening statistics displayed by the show link-error-disable all

command.

TABLE 15 Output of show link-error-disable

This column... Displays...

Port # The por t number.

Threshold The number of times the port link state will go from up to down and

down to up before the wait period is activated.

Sampling-Time The number of seconds during which the specified toggle threshold can

occur before the wait period is activated.

Shutoff-Time The number of seconds the port will remain disabled (down) before it

becomes enabled. A zero (0) indicates that the port will stay down until an administrative override occurs.

State The port state can be one of the following:

• Idle – The link is normal and no link state toggles have been

detected or sampled.

• Down – The port is disabled because the number of sampled errors

exceeded the configured threshold.

• Err – The port sampled one or more errors.

Counter

• If the port state is Idle, this field displays N/A.

• If the port state is Down, this field shows the remaining value of the

shutoff timer.

• If the port state is Err, this field shows the number of errors

sampled.

Syntax: show link-error-disable [all]

Also, in TurboIron X Series devices, the show interface command indicates if the port flap dampening feature is enabled on the port.

Brocade TurboIron 24X Series Configuration Guide 41 53-1003053-01

Configuring basic port parameters

TurboIron#show interface ethernet 15 GigabitEthernet15 is up, line protocol is up Link Error Dampening is Enabled Hardware is GigabitEthernet, address is 0000.0000.010e (bia 0000.0000.010e) Configured speed auto, actual 1Gbit, configured duplex fdx, actual fdx Configured mdi mode AUTO, actual MDIX

TurboIron#show interface ethernet 17 GigabitEthernet17 is ERR-DISABLED, line protocol is down Link Error Dampening is Enabled Hardware is GigabitEthernet, address is 0000.0000.010e (bia 0000.0000.010e) Configured speed auto, actual unknown, configured duplex fdx, actual unknown

TurboIron#show interface brief e17

Port Link State Dupl Speed Trunk Tag Priori MAC Name 17 ERR-DIS None None None 15 Yes level0 0000.0000.010e

The line “Link Error Dampening” displays “Enabled” if port flap dampening is enabled on the port or “Disabled” if the feature is disabled on the port. The feature is enabled on the ports in the two examples above. Also, the characters “ERR-DISABLED” is displayed for the “GbpsEthernet” line if the port is disabled because of link errors.

Syntax: show interface ethernet <port-number>

In addition to the show commands above, the output of the show interface brief command for TurboIron X Series devices, indicates if a port is down due to link errors.

The ERR-DIS entry under the “Link” column indicates the port is down due to link errors.

Port loop detection

This feature allows the device to disable a port that is on the receiving end of a loop by sending test packets. You can configure the time period during which test packets are sent.

Strict mode and loose mode

There are two types of loop detection; Strict Mode and Loose Mode. In Strict Mode, a port is disabled only if a packet is looped back to that same port. Strict Mode overcomes specific hardware issues where packets are echoed back to the input port. In Strict Mode, loop detection must be configured on the physical port.

In Loose Mode, loop detection is configured on the VLAN of the receiving port. Loose Mode disables the receiving port if packets originate from any port or VLAN on the same device. The VLAN of the receiving port must be configured for loop detection in order to disable the port.

Recovering disabled ports

Once a loop is detected on a port, it is placed in Err-Disable state. The port will remain disabled until one of the following occurs:

• You manually disable and enable the port at the Interface Level of the CLI.

• You enter the command clear loop-detection. This command clears loop detection statistics

and enables all Err-Disabled ports.

42 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring basic port parameters

NOTE

• The device automatically re-enables the port. To set your device to automatically re-enable

Err-Disabled ports, refer to “Configuring the device to automatically re-enable ports” on page 44.

Configuration notes

• Loopback detection packets are sent and received on both tagged and untagged ports.

Therefore, this feature cannot be used to detect a loop across separate devices.

• On TurboIron X Series devices, the port loop detection feature works only on untagged ports.

The following information applies to Loose Mode loop detection:

• With Loose Mode, two ports of a loop are disabled.

• Different VLANs may disable different ports. A disabled port affects every VLAN using it.

• Loose Mode floods test packets to the entire VLAN. This can impact system performance if too

many VLANs are configured for Loose Mode loop detection.

Brocade recommends that you limit the use of Loose Mode. If you have a large number of VLANS, configuring loop detection on all of them can significantly affect system performance because of the flooding of test packets to all configured VLANs. An alternative to configuring loop detection in a VLAN-group of many VLANs is to configure a separate VLAN with the same tagged port and configuration, and enable loop detection on this VLAN only.

When loop detection is used with Layer 2 loop prevention p rotocols, such as spanning tree (STP) , the Layer 2 protocol takes higher priority. Loop detection cannot send or receive probe packets if ports are blocked by Layer 2 protocols, so it does not detect Layer 2 loops when STP is running because loops within a VLAN have been prevented by STP. Loop detection running in Loose Mode can detect and break Layer 3 loops because STP cannot prevent loops across different VLANs. In these instances, the ports are not blocked and loop detection is able to send out probe packets in one VLAN and receive packets in another VLAN. In this way, loop detection running in Loose Mode disables both ingress and egress ports.

Enabling loop detection

Use the loop-detection command to enable loop detection on a physical port (Strict Mode) or a VLAN (Loose Mode). Loop detection is disabled by default. The following example shows a Strict Mode configuration.

TurboIron(config)#interface ethernet 1 TurboIron(config-if-e10000-1)#loop-detection

The following example shows a Loose Mode configuration.

TurboIron(config)#vlan20 TurboIron(config-vlan-20)#loop-detection

By default, the port will send test packets every one second, or the number of seconds specified by the loop-detection-interval command. Refer to “Configuring a global loop detection interval” on page 44.

Syntax: [no] loop-detection

Use the [no] form of the command to disable loop detection.

Brocade TurboIron 24X Series Configuration Guide 43 53-1003053-01

Configuring basic port parameters

Configuring a global loop detection interval

The loop detection interval specifies how often a test packet is sent on a port. When loop detection is enabled, the loop detection time unit is 0.1 second, with a default of 10 (one second). The range is from 1 (one tenth of a second) to 100 (10 seconds). You can use the show loop-detection status command to view the loop detection interval.

To configure the global loop detection interval, enter a command similar to the following.

TurboIron(config)#loop-detection-interval 50

This command sets the loop-detection interval to 5 seconds (50 x 0.1).

To revert to the default global loop detection interval of 10, enter one of the following.

TurboIron(config)#loop-detection-interval 10

OR TurboIron(config)#no loop-detection-interval 50

Syntax: [no] loop-detection-interval <number>

where <number> is a value from 1 to 100. The system multiplies your entry by 0.1 to calculate the interval at which test packets will be sent.

Configuring the device to automatically re-enable ports

To configure the device to automatically re-enable ports that were disabled because of a loop detection, enter the following command.

TurboIron(config)#errdisable recovery cause loop-detection

The above command will cause the device to automatically re-enable ports that were disabled because of a loop detection. By default, the device will wait 300 seconds before re-enabling the ports. You can optionally change this interval to a value from 10 to 65535 seconds. Refer to

“Specifying the recovery time interval” on page 44.

Syntax: [no] errdisable recovery cause loop-detection

Use the [no] form of the command to disable this feature.

Specifying the recovery time interval

The recovery time interval specifies the number of seconds the device will wait before automatically re-enabling ports that were disabled because of a loop detection. (Refer to

“Configuring the device to automatically re-enable ports” on page 44.) By default, the device will

wait 300 seconds. To change the recovery time interval, enter a command such as the following.

TurboIron(config)#errdisable recovery interval 120

This command configures the device to wait 120 seconds (2 minutes) before re-enabling the ports.

To revert to the default recovery time interval of 300 seconds (5 minutes), enter one of the following commands.

TurboIron(config)#errdisable recovery interval 300

TurboIron(config)#no errdisable recovery interval 120

44 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring basic port parameters

Syntax: [no] errdisable recovery interval <seconds>

where <seconds> is a number from 10 to 65535.

Clearing loop-detection

To clear loop detection statistics and re-enable all ports that are in Err-Disable state because of a loop detection, enter the following command.

TurboIron#clear loop-detection

Displaying loop-detection information

Use the show loop-detection status command to display loop detection status, as shown.

TurboIron#show loop-detection status loop detection packets interval: 10 (unit 0.1 sec) Number of err-disabled ports: 3 You can re-enable err-disable ports one by one by "disable" then "enable" under interface config, re-enable all by "clear loop-detect", or configure "errdisable recovery cause loop-detection" for automatic recovery index port/vlan status #errdis sent-pkts recv-pkts 1 13 untag, LEARNING 0 0 0 2 15 untag, BLOCKING 0 0 0 3 17 untag, DISABLED 0 0 0 4 18 ERR-DISABLE by itself 1 6 1 5 19 ERR-DISABLE by vlan 12 0 0 0 6 vlan12 2 ERR-DISABLE ports 2 24 2

If a port is errdisabled in Strict mode, it shows “ERR-DISABLE by itself”. If it is errdisabled due to its associated vlan, it shows “ERR-DISABLE by vlan ?”

The following command displays the current disabled ports, including the cause and the time.

TurboIron#show loop-detection disable Number of err-disabled ports: 3 You can re-enable err-disable ports one by one by "disable" then "enable" under interface config, re-enable all by "clear loop-detect", or configure "errdisable recovery cause loop-detection" for automatic recovery index port caused-by disabled-time 1 18 itself 00:13:30 2 19 vlan 12 00:13:30 3 20 vlan 12 00:13:30

This example shows the disabled ports, the cause, and the time the port was disabled. If loop-detection is configured on a physical port, the disable cause will show “itself”. For VLANs configured for loop-detection, the cause will be a VLAN.

The following command shows the hardware and software resources being used by the loop-detection feature.

Vlans configured loop-detection use 1 HW MAC Vlans not configured but use HW MAC: 1 10

alloc in-use avail get-fail limit get-mem size init configuration pool 16 6 10 0 3712 6 15 16 linklist pool 16 10 6 0 3712 10 16 16

Brocade TurboIron 24X Series Configuration Guide 45 53-1003053-01

Configuring basic port parameters

Syslog message

The following message is logged when a port is disabled due to loop detection. This message also appears on the console.

loop-detect: port ?\?\? vlan ?, into errdisable state

The Errdisable function logs a message whenever it re-enables a port.

46 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Chapter

NOTE

Operations, Administration, and Maintenance

In this chapter

•Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

•Determining the software versions installed and running on a device . . . . 48

•Image file types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

•Upgrading software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

•Using SNMP to upgrade software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

•Changing the block size for TFTP file transfers . . . . . . . . . . . . . . . . . . . . . . . 52

•Rebooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

•Displaying the boot preference. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

•Loading and saving configuration files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

•Scheduling a system reload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

•Diagnostic error codes and remedies for TFTP transfers . . . . . . . . . . . . . . . 60

Overview

For easy software image management, all devices support the download and upload of software images between the flash modules on the devices and a Trivial File Transfer Protocol (TFTP) server on the network.

TurboIron X Series devices have two flash memory modules:

• Primary flash – The default local storage device for image files and configuration files.

• Secondary flash – A second flash storage device. You can use the secondary flash to store

redundant images for additional reload reliability or to preserve one software image while testing another one.

Only one flash device is active at a time. By default, the primary image will become active upon reload.

You can update the software contained on a flash module using TFTP to copy the update image from a TFTP server onto the flash module. In addition, you can copy software images and configuration files from a flash module to a TFTP server.

TurboIron X Series devices are TFTP clients but not TFTP servers. You must perform the TFTP transaction from the device. You cannot “put” a file onto the device using the interface of your TFTP server.

Brocade TurboIron 24X Series Configuration Guide 47 53-1003053-01

Determining the software versions installed and running on a device

NOTE

TurboIron#show version SW: Version 07.2.02b071T203 Copyright (c) 1996-2010 Brocade Communications Systems, Inc. Compiled on Dec 02 2010 at 08:07:06 labeled as TIR07202b071 (6092645 bytes) from Secondary TIR07202b071 Compressed Boot-Monitor Image size = 373767, Version:04.1.00T205 (grz04100) HW: Stackable TurboIron-X24 ========================================================================== Serial #: XXXXXXXXXXX P-ASIC 0: type B820, rev 01 subrev 00 ========================================================================== 833 MHz Power PC processor 8541 (version 32/0020) 66 MHz bus 512 KB boot flash memory 31744 KB code flash memory 512 MB DRAM The system uptime is 5 minutes 34 seconds The system : started=warm start reloaded=by "reload"

If you are attempting to transfer a file using TFTP but have received an error message, refer to

“Diagnostic error codes and remedies for TFTP transfers” on page 60.

Determining the software versions installed and running on a device

Use the following methods to display the software versions running on the device and the versions installed in flash memory.

Determining the flash image version running on the device

To determine the flash image version running on a device, enter the show version command at any level of the CLI. Some examples are shown below.

Compact devices

To determine the flash image version running on a Compact device, enter the show version command at any level of the CLI. The following shows an example output.

The version information is shown in bold type in this example:

• “07.2.02b071T203” indicates the flash code version number. The “T203” is used by Brocade

for record keeping.

• “labeled as TIR07202b071” indicates the flash code image label. The label indicates the

48 Brocade TurboIron 24X Series Configuration Guide

image type and version and is especially useful if you change the image file name.

• “Secondary TIR07202b071” indicates the flash code image file name that was loaded.

Determining the image versions installed in flash memory

Enter the show flash command to display the boot and flash images installed on the device.

53-1003053-01

Determining the software versions installed and running on a device

• The “Compressed Pri Code size” line lists the flash code version installed in the primary flash

area.

• The “Compressed Sec Code size” line lists the flash code version installed in the secondary

flash area.

• The “Boot Monitor Image size” line lists the boot code version installed in flash memory. The

device does not have separate primary and secondary flash areas for the boot image. The flash memory module contains only one boot image.

Flash image verification

The Flash Image Verification feature allows you to verify boot images based on hash codes, and to generate hash codes where needed. This feature lets you select from three data integrity verification algorithms:

• MD5 - Message Digest algorithm (RFC 1321)

• SHA1 - US Secure Hash Algorithm (RFC 3174)

• CRC - Cyclic Redundancy Checksum algorithm

CLI commands

Use the following command syntax to verify the flash image:

Syntax: verify md5 | sha1 | crc32 <ASCII string> | primary | secondary [<hash code>]

• md5 – Generates a 16-byte hash code

• sha1 – Generates a 20-byte hash code

• crc32 – Generates a 4 byte checksum

• ascii string – A valid image filename

• primary – The primary boot image (primary.img)

• secondary – The secondary boot image (secondary.img)

• hash code – The hash code to verify

The following examples show how the verify command can be used in a variety of circumstances.

To generate an MD5 hash value for the secondary image, enter the following command.

TurboIron#verify md5 secondary

TurboIron#.........................Done

Size = 2044830, MD5 01c410d6d153189a4a5d36c955653862

To generate a SHA-1 hash value for the secondary image, enter the following command.

TurboIron#verify sha secondary

TurboIron#.........................Done

Size = 2044830, SHA1 49d12d26552072337f7f5fcaef4cf4b742a9f525

To generate a CRC32 hash value for the secondary image, enter the following command.

TurboIron#verify crc32 secondary

TurboIron#.........................Done

Size = 2044830, CRC32 b31fcbc0

To verify the hash value of a secondary image with a known value, enter the following commands.

Brocade TurboIron 24X Series Configuration Guide 49 53-1003053-01

Image file types

TurboIron#verify md5 secondary 01c410d6d153189a4a5d36c955653861

TurboIron#.........................Done

Size = 2044830, MD5 01c410d6d153189a4a5d36c955653862 Verification FAILED.

In the previous example, the codes did not match, and verification failed. If verification succeeds, the output will look like this.

TurboIron#verify md5 secondary 01c410d6d153189a4a5d36c955653861

TurboIron#.........................Done

Size = 2044830, MD5 01c410d6d153189a4a5d36c955653861 Verification SUCEEDED.

The following examples show this process for SHA-1 and CRC32 algorithms.

TurboIron#verify sha secondary 49d12d26552072337f7f5fcaef4cf4b742a9f525

TurboIron#.........................Done

Size = 2044830, sha 49d12d26552072337f7f5fcaef4cf4b742a9f525 Verification SUCCEEDED.

and

TurboIron#verify crc32 secondary b31fcbc0

TurboIron#.........................Done

Size = 2044830, CRC32 b31fcbc0 Verification SUCCEEDED.

Image file types

This section lists the boot and flash image file types supported on the TurboIron X Series of switches and how to install them. For information about a specific version of code, refer to the release notes.

TABLE 16 Software image files

Product Boot image

TurboIron X Series TRZxxxxx.bin TISxxxxx.bin (Layer 2)

Upgrading software

Use the following procedures to upgrade the software.

Upgrading the boot code

Follow the steps given below to upgrade the boot code.

1. Place the new boot code on a TFTP server to which the device has access.

2. Enter the following command at the Privileged EXEC level of the CLI to copy the boot code from the TFTP server into flash memory:

Flash image

• copy tftp flash <ip-addr> <image-file-name> bootrom

50 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Upgrading software

NOTE

Use the copy tftp flash command to copy the boot code to the device only during a maintenance window. Attempting to do so during normal networking operations can cause disruption to the network.

3. Verify that the code has been successfully copied by entering the following command at any level of the CLI:

• show flash

The output will display the compressed boot ROM code size and the boot code version.

4. Upgrade the flash code as instructed in the following section.

Upgrading the flash code

Follow the steps given below to upgrade the flash code.

1. Place the new flash code on a TFTP server to which the device has access.

2. Enter the following command at the Privileged EXEC level of the CLI to copy the flash code from the TFTP server into the flash memory.

copy tftp flash <ip-addr> <image-file-name> primary | secondary

3. Verify that the flash code has been successfully copied by entering the following command at any level of the CLI.

show flash

4. If the flash code version is correct, go to step 5. Otherwise, go to step 1.

5. Reload the software by entering one of the following commands:

• reload (this command boots from the default boot source, which is the primary flash area

by default)

• hitless-reload primary | secondary

• boot system flash primary | secondary

The boot system flash process occurs after a boot system flash primary/secondary command is entered and gives an administrator the opportunity to make last minute changes or corrections before performing a reload. The example below shows the confirmation step. TurboIron#boot system flash primary Are you sure? (enter ‘Y’ or ‘N’): y

Boot code synchronization feature

When the new boot image is copied into the active module, it is automatically synchronized with the redundant management module.

There is currently no option for manual synchronization of the boot image.

To activate the boot synchronization process, enter the following command.

TurboIron#copy tftp flash 192.168.255.102 GRZ04100.bin bootrom

Brocade TurboIron 24X Series Configuration Guide 51 53-1003053-01

Using SNMP to upgrade software

NOTE

The system responds with the following message.

TurboIron#Load to buffer (8192 bytes per dot)

..................Write to boot flash......................

TFTP to Flash Done. TurboIron#Synchronizing with standby module... Boot image synchronization done.

Using SNMP to upgrade software

You can use a third-party SNMP management application to upgrade software on a device.

Brocade recommends that you make a backup copy of the startup-config file before you upgrade the software. If you need to run an older release, you will need to use the backup copy of the startup-config file.

1. Configure a read-write community string on the device, if one is not already configured. To configure a read-write community string, enter the following command from the global CONFIG level of the CLI.

snmp-server community <string> ro | rw

where <string> is the community string and can be up to 32 characters long.

2. On the device, enter the following command from the global CONFIG level of the CLI.

no snmp-server pw-check

This command disables password checking for SNMP set requests. If a third-party SNMP management application does not add a password to the password field when it sends SNMP set requests to a device, by default the device rejects the request.

Changing the block size for TFTP file transfers

When you use TFTP to copy a file to or from a device, the device transfers the data in blocks of 8192 bytes by default. You can change the block size to one of the following if needed:

• 4096

• 2048

• 1024

• 512

• 256

• 128

• 64

• 32

• 16

To change the block size for TFTP file transfers, enter a command such as the following at the global CONFIG level of the CLI.

52 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

NOTE

Rebooting

NOTE

Rebooting

TurboIron(config)#flash 2047 set flash copy block size to 2048

Syntax: [no] flash <num>

The software rounds up the <num> value you enter to the next valid power of two, and displays the resulting value. In this example, the software rounds the value up to 2048.

If the value you enter is one of the valid powers of two for this parameter, the software still rounds the value up to the next valid power of two. Thus, if you enter 2048, the software rounds the value up to 4096.

You can use boot commands to immediately initiate software boots from a software image stored in primary or secondary flash on a device or from a BootP or TFTP server. You can test new versions of code on a device or choose the preferred boot source from the console boot prompt without requiring a system reset.

It is very important that you verify a successful TFTP transfer of the boot code before you reset the system. If the boot code is not transferred successfully but you try to reset the system, the system will not have the boot code with which to successfully boot.

By default, the device first attempts to boot from the image stored in its primary flash, then its secondary flash, and then from a TFTP server. You can modify this booting sequence at the global CONFIG level of the CLI using the boot system… command.

To initiate an immediate boot from the CLI, enter one of the boot system… commands.

If you are booting the device from a TFTP server through a fiber connection, use the following command: boot system tftp <ip-address> <filename> fiber-port.

Displaying the boot preference

Use the show boot-preference command to display the boot sequence in the startup config and running config files. The boot sequence displayed is also identified as either user-configured or the default.

The following example shows the default boot sequence preference.

TurboIron#show boot-preference Boot system preference (Configured):

Use Default

Boot system preference(Default):

Boot system flash primary Boot system flash secondary

The following example shows a user-configured boot sequence preference.

Brocade TurboIron 24X Series Configuration Guide 53 53-1003053-01

Loading and saving configuration files

TurboIron#show boot-preference Boot system preference(Configured):

Boot system flash secondary Boot system tftp 10.1.1.1 TIX04200b1.bin Boot system flash primary

Boot system preference (Default)

Boot system flash primary Boot system flash secondary

Syntax: show boot-preference

The results of the show run command for the configured example above appear as follows.

TurboIron#show run Current Configuration: !

boot sys fl sec boot sys df 10.1.1.1 TIX04200b1.bin boot sys fl pri

ip address 10.1.1.4 255.255.255.0 snmp-client 10.1.1.1 ! end

Loading and saving configuration files

For easy configuration management, all devices support both the download and upload of configuration files between the devices and a TFTP server on the network.

You can upload either the startup configuration file or the running configuration file to the TFTP server for backup and use in booting the system:

• Startup configuration file – This file contains the configuration information that is currently

saved in flash. To display this file, enter the show configuration command at any CLI prompt.

• Running configuration file – This file contains the configuration active in the system RAM but

not yet saved to flash. These changes could represent a short-term requirement or general configuration change. To display this file, enter the show running-config or write terminal command at any CLI prompt.

Each device can have one startup configuration file and one running configuration file. The startup configuration file is shared by both flash modules. The running configuration file resides in DRAM.

When you load the startup-config file, the CLI parses the file three times.

1. During the first pass, the parser searches for system-max commands. A system-max command changes the size of statically configured memory.

2. During the second pass, the parser implements the system-max commands if present and also implements trunk configuration commands (trunk command) if present.

3. During the third pass, the parser implements the remaining commands.

54 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Loading and saving configuration files

NOTE

Replacing the startup configuration with the running configuration

After you make configuration changes to the active system, you can save those changes by writing them to flash memory. When you write configuration changes to flash memory, you replace the startup configuration with the running configuration.

To replace the startup configuration with the running configuration, enter the following command at any Enable or CONFIG command prompt.

TurboIron#write memory

Replacing the running configuration with the startup configuration

If you want to back out of the changes you have made to the running configuration and return to the startup configuration, enter the following command at the Privileged EXEC level of the CLI.

TurboIron#reload

Logging changes to the startup-config file

You can configure a device to generate a Syslog message when the startup-config file is changed. The trap is enabled by default.

The following Syslog message is generated when the startup-config file is changed.

startup-config was changed

If the startup-config file was modified by a valid user, the following Syslog message is generated.

startup-config was changed by <username>

To disable or re-enable Syslog messages when the startup-config file is changed, use the following command.

Syntax: [no] logging enable config-changed

Copying a configuration file to or from a TFTP server

To copy the startup-config or running-config file to a TFTP server using the CLI, use one of the following commands.

You can name the configuration file when you copy it to a TFTP server.

• copy startup-config tftp <tftp-ip-addr> <filename> – Use this command to upload a copy of the

startup configuration file from the device to a TFTP server.

• copy running-config tftp <tftp-ip-addr> <filename> – Use this command to upload a copy of

the running configuration file from the device to a TFTP server.

Brocade TurboIron 24X Series Configuration Guide 55 53-1003053-01

Loading and saving configuration files

NOTE

To copy the startup-config or running-config file from a TFTP server using the CLI, use one of the following commands.

When you copy a configura tion file from the TFTP server to a device, the filename should not contain the "/" and "\" characters. If required, you can specify the filename along with its path, for example, “ip/turboiron/config1.txt”. However, the file is always copied as “startup-config” or “running-config”, depending on which type of file you saved to the server.

• copy tftp startup-config <tftp-ip-addr> <filename> – Use this command to download a copy of

the startup configuration file from a TFTP server to a device.

• copy tftp running-config <tftp-ip-addr> <filename> – Use this command to download a copy of

the running configuration file from a TFTP server to a device.

Dynamic configuration loading

You can load dynamic configuration commands (commands that do not require a reload to take effect) from a file on a TFTP server into the running-config on the device device. You can make configuration changes off-line, then load the changes directly into the device running-config, without reloading the software.

Usage considerations

• Use this feature only to load configuration information that does not require a software reload

to take effect. For example, you cannot use this feature to change statically configured memory (system-max command) or to enter trunk group configuration information into the running-config.

• Do not use this feature if you have deleted a trunk group but have not yet placed the changes

into effect by saving the configuration and then reloading. When you delete a trunk group, the command to configure the trunk group is removed from the device running-config, but the trunk group remains active. To finish deleting a trunk group, save the configuration (to the startup-config file), then reload the software. After you reload the software, then you can load the configuration from the file.

• Do not load port configuration information for secondary ports in a trunk group. Since all ports

in a trunk group use the port configuration settings of the primary port in the group, the software cannot implement the changes to the secondary port.

Preparing the configuration file

A configuration file that you create must follow the same syntax rules as the startup-config file the device creates.

• The configuration file is a script containing CLI configuration commands. The CLI reacts to

each command entered from the file in the same way the CLI reacts to the command if you enter it. For example, if the command results in an error message or a change to the CLI configuration level, the software responds by displaying the message or changing the CLI level.

56 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Loading and saving configuration files

NOTE

• The software retains the running-config that is currently on the device, and changes the

running-config only by adding new commands from the configuration file. If the running config already contains a command that is also in the configuration file you are loading, the CLI rejects the new command as a duplicate and displays an error message. For example, if the running-config already contains a a command that configures ACL 1, the software rejects ACL 1 in the configuration file, and displays a message that ACL 1 is already configured.

• The file can contain global CONFIG commands or configuration commands for interfaces,

routing protocols, and so on. You cannot enter User EXEC or Privileged EXEC commands.

• The default CLI configuration level in a configuration file is the global CONFIG level. Thus, the

first command in the file must be a global CONFIG command or “ ! ”. The ! (exclamation point) character means “return to the global CONFIG level”.

You can enter text following “ ! “ as a comment. However, the “ !” is not a comment marker. It returns the CLI to the global configuration level.

If you copy-and-paste a configuration into a management session, the CLI ignores the “ ! “ instead of changing the CLI to the global CONFIG level. As a result, you might get different results if you copy-and-paste a configuration instead of loading the configuration using TFTP.

• Make sure you enter each command at the correct CLI level. Since some commands have

identical forms at both the global CONFIG level and individual configuration levels, if the CLI response to the configuration file results in the CLI entering a configuration level you did not intend, then you can get unexpected results.

For example, if a trunk group is active on the device, and the configuration file contains a command to disable STP on one of the secondary ports in the trunk group, the CLI rejects the commands to enter the interface configuration level for the port and moves on to the next command in the file you are loading. If the next command is a spanning-tree command whose syntax is valid at the global CONFIG level as well as the interface configuration level, then the software applies the command globally. Here is an example.

The configuration file contains these commands.

interface ethernet 2 no spanning-tree

The CLI responds like this.

TurboIron(config)#interface ethernet 2 Error - cannot configure secondary ports of a trunk TurboIron(config)#no spanning-tree TurboIron(config)#

• If the file contains commands that must be entered in a specific order, the commands must

appear in the file in the required order. For example, if you want to use the file to replace an IP address on an interface, you must first remove the old address using “no” in front of the ip address command, then add the new address. Otherwise, the CLI displays an error message and does not implement the command. Here is an example.

The configuration file contains these commands.

interface ethernet 11 ip address 10.10.10.69/24

Brocade TurboIron 24X Series Configuration Guide 57 53-1003053-01

Loading and saving configuration files

NOTE

The running-config already has a command to add an address to port 11, so the CLI responds like this.

TurboIron(config)#interface ethernet 11 TurboIron(config-if-e10000-11)#ip add 10.10.10.69/24 Error: can only assign one primary ip address per subnet TurboIron(config-if-e10000-11)#

To successfully replace the address, enter commands into the file as follows.

interface ethernet 11 no ip address 10.20.20.69/24 ip address 10.10.10.69/24

This time, the CLI accepts the command, and no error message is displayed.

TurboIron(config)#interface ethernet 11 TurboIron(config-if-e10000-11)#no ip add 10.20.20.69/24 TurboIron(config-if-e10000-11)#ip add 10.10.10.69/24 TurboIron(config-if-e10000-11)

• Always use the end command at the end of the file. The end command must appear on the

last line of the file, by itself.

Loading the configuration information into the running-config

To load the file from a TFTP server, use either of the following commands:

• copy tftp running-config <ip-addr> <filename>

• ncopy tftp <ip-addr> <filename> running-config

If you are loading a configuration file that uses a truncated form of the CLI command access-list, the software will not go into batch mode.

For example, the following command line will initiate batch mode.

access-list 131 permit host pc1 host pc2

The following command line will not initiate batch mode.

acc 131 permit host pc1 host pc2

Maximum file sizes for startup-config file and running-config

Each device has a maximum allowable size for the running-config and the startup-config file. If you use TFTP to load additional information into a device running-config or startup-config file, it is possible to exceed the maximum allowable size. If this occurs, you will not be able to save the configuration changes.

The maximum size for the running-config and the startup-config file is 64K each.

To determine the size of a running-config or star tup-config file, copy it to a TFTP server, then use the directory services on the server to list the size of the copied file. To copy the running-config or startup-config file to a TFTP server, use one of the following commands:

• Commands to copy the running-config to a TFTP server:

• copy running-config tftp <ip-addr> <filename>

58 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

• ncopy running-config tftp <ip-addr> <from-name>

NOTE

• Commands to copy the startup-config file to a TFTP server:

• copy startup-config tftp <ip-addr> <filename>

• ncopy startup-config tftp <ip-addr> <from-name>

Scheduling a system reload

In addition to reloading the system manually, you can configure the device to reload itself at a specific time or after a specific amount of time has passed.

The scheduled reload feature requires the system clock. You can use a Simple Network Time Protocol (SNTP) server to set the clock or you can set the device clock manually. Refer to “Specifying

a Simple Network Time Protocol (NTPv4) server” on page 28 or “Setting the system clock” on

page 29.

Reloading at a specific time

Scheduling a system reload

To schedule a system reload for a specific time, use the reload at command. For example, to schedule a system reload from the primary flash module for 6:00:00 AM, April 1, 2003, enter the following command at the global CONFIG level of the CLI.

TurboIron#reload at 06:00:00 04-01-03

Syntax: reload at <hh:mm:ss> <mm-dd-yy> [primary | secondary]

• <hh:mm:ss> is hours, minutes, and seconds.

• <mm-dd-yy> is month, day, and year.

• primary | secondary specifies whether the reload is to occur from the primary code flash

module or the secondary code flash module. The default is primary.

Reloading after a specific amount of time

To schedule a system reload to occur after a specific amount of time has passed on the system clock, use reload after command. For example, to schedule a system reload from the secondary flash one day and 12 hours later, enter the following command at the global CONFIG level of the CLI.

TurboIron#reload after 01:12:00 secondary

Syntax: reload after <dd:hh:mm> [primary | secondary]

• <dd:hh:mm> is the number of days, hours, and minutes.

• primary | secondary specifies whether the reload is to occur from the primary code flash

module or the secondary code flash module.

Brocade TurboIron 24X Series Configuration Guide 59 53-1003053-01

Diagnostic error codes and remedies for TFTP transfers

Displaying the amount of time remaining before a scheduled reload

To display how much time is remaining before a scheduled system reload, enter the following command from any level of the CLI.

TurboIron#show reload

Canceling a scheduled reload

To cancel a scheduled system reload using the CLI, enter the following command at the global CONFIG level of the CLI.

TurboIron#reload cancel

Diagnostic error codes and remedies for TFTP transfers

If an error occurs with a TFTP transfer to or from a device one of the following error codes is displayed on the console.

TABLE 17 Diagnostic error codes for TFTP transfer

Error code

1 Flash read preparation failed. A flash error occurred during the download.

2Flash read failed.

3 Flash write preparation failed.

4 Flash write failed.

5 TFTP session timeout. TFTP failed because of a time out.

6 TFTP out of buffer space. The file is larger than the amount of room on the device or TFTP server.

7 TFTP busy, only one TFTP

8 File type check failed. You accidentally attempted to copy the incorrect image code into the

Message Explanation and action

Retry the download. If it fails again, contact customer support.

Check IP connectivity and make sure the TFTP server is running.

If you are copying an image file to flash, first copy the other image to your TFTP server, then delete it from flash. (Use the erase flash... CLI command at the Privileged EXEC level to erase the image in the flash.) If you are copying a configuration file to flash, edit the file to remove unneeded information, then try again.

Another TFTP transfer is active on another CLI session or Brocade

session can be active.

Network Advisor session. Wait, then retry the transfer.

system. Retry the transfer using the correct image.

60 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Diagnostic error codes and remedies for TFTP transfers

TABLE 17 Diagnostic error codes for TFTP transfer

Error code

16 TFTP remote - general error. The TFTP configuration has an error. The specific error message

17 TFTP remote - no such file.

18 TFTP remote - access violation.

19 TFTP remote - disk full.

20 TFTP remote - illegal operation.

21 TFTP remote - unknown

22 TFTP remote - file already

23 TFTP remote - no such user.

Message Explanation and action

describes the error. Correct the error, then retry the transfer.

transfer ID.

exists.

Brocade TurboIron 24X Series Configuration Guide 61 53-1003053-01

Diagnostic error codes and remedies for TFTP transfers

62 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Chapter

NOTE

Securing Access to Management Functions

In this chapter

•Securing access methods. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

•Restricting remote access to management functions . . . . . . . . . . . . . . . . . 65

•Setting passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

•Setting up local user accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

•Configuring TACACS/TACACS+ security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

•Configuring RADIUS security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

•Configuring authentication-method lists . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

This chapter explains how to secure access to management functions on a device.

For all devices, RADIUS Challenge is supported for 802.1x authentication but not for login authentication. Also, multiple challenges are supported for TACACS+ login authentication.

Securing access methods

The following table lists the management access methods available on a device, how they are secured by default, and the ways in which they can be secured.

TABLE 18 Ways to secure management access to devices

Access method How the access

Serial access to the CLI Not secured Establish passwords for management privilege

Access to the Privileged EXEC and CONFIG levels of the CLI

Ways to secure the access method See page method is secured by default

levels

Not secured Establish a password for Telnet access to the

CLI

Establish passwords for management privilege

levels

Set up local user accounts page 78

Configure TACACS/TACACS+ security page 84

Configure RADIUS security page 100

page 74

Brocade TurboIron 24X Series Configuration Guide 63 53-1003053-01

Securing access methods

TABLE 18 Ways to secure management access to devices (Continued)

Access method How the access

Telnet access Not secured Regulate Telnet access using ACLs page 65

Secure Shell (SSH) access Not configured Configure SSH page 945

SNMP (Brocade Network Advisor) access

method is secured by default

SNMP read or read-write community strings and the password to the Super User privilege level

NOTE: SNMP read

or read-write community strings are always required for SNMP access to the device.

Ways to secure the access method See page

Allow Telnet access only from specific IP

addresses

Restrict Telnet access based on a client MAC

address

Allow Telnet access only from specific MAC

addresses

Specify the maximum number of login attempts

for Telnet access

Disable Telnet access page 73

Establish a password for Telnet access page 74

Establish passwords for privilege levels of the

CLI

Set up local user accounts page 78

Configure TACACS/TACACS+ security page 84

Configure RADIUS security page 100

Regulate SSH access using ACLs page 66

Allow SSH access only from specific IP

addresses

Allow SSH access only from specific MAC

addresses

Establish passwords for privilege levels of the

CLI

Set up local user accounts page 78

Configure TACACS/TACACS+ security page 84

Configure RADIUS security page 100

Regulate SNMP access using ACLs page 66

Allow SNMP access only from specific IP

addresses

Disable SNMP access page 73

Allow SNMP access only to clients connected to

a specific VLAN

Establish passwords to management levels of

the CLI

Set up local user accounts page 78

Establish SNMP read or read-write community

strings

page 68

page 69

page 70

page 74

page 68

page 69

page 74

page 68

page 71

page 74

page 84

64 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Restricting remote access to management functions

TABLE 18 Ways to secure management access to devices (Continued)

Access method How the access

method is secured by default

Ways to secure the access method See page

TFTP access Not secured Allow TFTP access only to clients connected to a

specific VLAN

Disable TFTP access page 73

Restricting remote access to management functions

You can restrict access to management functions from remote sources, including Telnet and SNMP. The following methods for restricting remote access are supported:

• Using ACLs to restrict Telnet or SNMP access

• Allowing remote access only from specific IP addresses

• Allowing Telnet and SSH access only from specific MAC addresses

• Allowing remote access only to clients connected to a specific VLAN

• Specifically disabling Telnet or SNMP access to the device

The following sections describe how to restrict remote access to a device using these methods.

Using ACLs to restrict remote access

You can use standard ACLs to control the following access methods to management functions on a device:

page 71

• Teln et

• SSH

• SNMP

Consider the following to configure access control for these management access methods.

1. Configure an ACL with the IP addresses you want to allow to access the device.

2. Configure a Telnet access group, SSH access group, Web access group, and SNMP community strings. Each of these configuration items accepts an ACL as a parameter. The ACL contains entries that identify the IP addresses that can use the access method.

The following sections present examples of how to secure management access using ACLs. Refer to Chapter 28, “Configuring Rule-Based IP Access Control Lists” for more information on configuring ACLs.

Using an ACL to restrict Telnet access

To configure an ACL that restricts Telnet access to the device, enter commands such as the following.

Brocade TurboIron 24X Series Configuration Guide 65 53-1003053-01

Restricting remote access to management functions

NOTE

TurboIron(config)#access-list 12 deny host 10.157.22.98 log TurboIron(config)#access-list 12 deny 10.157.23.0 0.0.0.255 log TurboIron(config)#access-list 12 deny 10.157.24.0/24 log TurboIron(config)#access-list 12 permit any TurboIron(config)#ssh access-group 12 TurboIron(config)#write memory

TurboIron(config)#access-list 10 deny host 10.157.22.32 log TurboIron(config)#access-list 10 deny 10.157.23.0 0.0.0.255 log TurboIron(config)#access-list 10 deny 10.157.24.0 0.0.0.255 log TurboIron(config)#access-list 10 deny 10.157.25.0/24 log TurboIron(config)#access-list 10 permit any TurboIron(config)#telnet access-group 10 TurboIron(config)#write memory

Syntax: telnet access-group <num>

The <num> parameter specifies the number of a standard ACL and must be from 1 – 99.

The commands above configure ACL 10, then apply the ACL as the access list for Telnet access. The device allows Telnet access to all IP addresses except those listed in ACL 10.

To configure a more restrictive ACL, create permit entries and omit the permit any entry at the end of the ACL.

Example

TurboIron(config)#access-list 10 permit host 10.157.22.32 TurboIron(config)#access-list 10 permit 10.157.23.0 0.0.0.255 TurboIron(config)#access-list 10 permit 10.157.24.0 0.0.0.255 TurboIron(config)#access-list 10 permit 10.157.25.0/24 TurboIron(config)#telnet access-group 10 TurboIron(config)#write memory

The ACL in this example permits Telnet access only to the IP addresses in the permit entries and denies Telnet access from all other IP addresses.

Using an ACL to restrict SSH access

To configure an ACL that restricts SSH access to the device, enter commands such as the following.

Syntax: ssh access-group <num>

The <num> parameter specifies the number of a standard ACL and must be from 1 – 99.

These commands configure ACL 12, then apply the ACL as the access list for SSH access. The device denies SSH access from the IP addresses listed in ACL 12 and permits SSH access from all other IP addresses. Without the last ACL entry for permitting all packets, this ACL would deny SSH access from all IP addresses.

In this example, the command ssh access-group 10 could have been used to apply the ACL configured in the example for Telnet access. You can use the same ACL multiple times.

Using ACLs to restrict SNMP access

To restrict SNMP access to the device using ACLs, enter commands such as the following.

66 Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Brocade TurboIron 24X Configuration Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

About This Document

Introduction

Device nomenclature

What’s new in this document

Document conventions

Text formatting

Notes, cautions, and danger notices

Notice to the reader

Related publications

Getting technical help or reporting errors

Document feedback

Feature Highlights

Introduction to features

Supported features
