Washing machine
WAN20051IL
[en] User manual and installation instructions
en
Table of contents
1 |
Safety............................................ |
4 |
|
1.1 |
General information.................... |
4 |
|
1.2 |
Intended use............................... |
4 |
|
1.3 |
Restriction on user group........... |
4 |
|
1.4 |
Safe installation .......................... |
5 |
|
1.5 |
Safe use ..................................... |
7 |
|
1.6 |
Safe cleaning and mainten- |
|
|
|
|
ance............................................ |
9 |
2 |
Preventing material damage ..... |
10 |
|
3 |
Environmental protection and |
|
|
|
saving energy............................. |
11 |
|
3.1 |
Disposing of packaging ........... |
11 |
|
3.2 |
Save energy and conserve |
|
|
|
|
resources.................................. |
11 |
3.3 |
Energy saving mode ................ |
11 |
|
4 |
Installation and connection....... |
12 |
|
4.1 |
Unpacking the appliance ......... |
12 |
|
4.2 |
Contents of package................ |
13 |
|
4.3 |
Requirements for the install- |
|
|
|
|
ation location ............................ |
13 |
4.4 |
Removing the transit bolts ....... |
14 |
|
4.5 |
Connecting the appliance ........ |
15 |
|
4.6 |
Aligning the appliance.............. |
16 |
|
4.7 |
Connecting the appliance to |
|
|
|
|
the electricity supply................. |
17 |
5 |
Familiarising yourself with |
|
|
|
your appliance............................ |
18 |
|
5.1 |
Appliance ................................. |
18 |
|
5.2 |
Detergent drawer...................... |
19 |
|
5.3 |
Controls .................................... |
19 |
|
6 |
Display ........................................ |
20 |
|
7 |
Buttons ....................................... |
22 |
|
8 Programmes ............................... |
23 |
||
9 |
Accessories................................ |
26 |
|
10 Before using for the |
|
|
first time.................................... |
26 |
|
10.1 |
Starting an empty washing |
|
|
cycle ....................................... |
26 |
11 Laundry..................................... |
27 |
|
11.1 |
Preparing the laundry............. |
27 |
11.2 |
Sorting laundry ....................... |
28 |
11.3 |
Degrees of soiling .................. |
28 |
11.4 |
Care symbols on the care |
|
|
labels ...................................... |
28 |
12 Detergents and care |
|
|
products ................................... |
29 |
|
12.1 |
Detergent recommendation ... |
29 |
12.2 |
Detergent dosage .................. |
30 |
13 Basic operation ........................ |
30 |
|
13.1 |
Switching on the appliance .... |
30 |
13.2 |
Setting a programme ............. |
31 |
13.3 |
Adjusting the programme |
|
|
settings ................................... |
31 |
13.4 |
Loading laundry...................... |
31 |
13.5 |
Using a measuring aid for |
|
|
liquid detergent ...................... |
31 |
13.6 |
Adding detergent and care |
|
|
product ................................... |
32 |
13.7 |
Starting the programme ......... |
32 |
13.8Adjusting the "Ready in" time before the programme
starts....................................... |
32 |
|
13.9 Soaking laundry ..................... |
32 |
|
13.10 |
Adding laundry ..................... |
32 |
13.11 |
Cancelling the pro- |
|
|
gramme ................................ |
33 |
13.12Resuming the programme when the programme
|
status is Rinse Hold ............. |
33 |
13.13 |
Unloading the laundry .......... |
33 |
13.14 |
Switching off the appli- |
|
|
ance...................................... |
33 |
2
en
14 |
Childproof lock......................... |
34 |
|
14.1 |
Activating the childproof |
|
|
|
|
lock......................................... |
34 |
14.2 |
Deactivating the childproof |
|
|
|
|
lock......................................... |
34 |
15 |
Basic settings........................... |
35 |
|
15.1 |
Overview of the basic set- |
|
|
|
|
tings........................................ |
35 |
15.2 |
Changing the basic set- |
|
|
|
|
tings........................................ |
36 |
16 |
Cleaning and servicing............ |
36 |
|
16.1 |
Tips on appliance care........... |
36 |
|
16.2 |
Cleaning the drum.................. |
36 |
|
16.3 |
Cleaning the detergent |
|
|
|
|
drawer..................................... |
37 |
16.4 |
Descaling................................ |
38 |
|
16.5 |
Cleaning the drain pump........ |
38 |
|
16.6 |
Cleaning the water outlet |
|
|
|
|
hose at the siphon ................. |
40 |
16.7 |
Clean the water inlet filters..... |
40 |
|
17 |
Troubleshooting....................... |
43 |
|
18 |
Transportation, storage and |
|
|
|
disposal .................................... |
51 |
|
18.1 |
Removing the appliance ........ |
51 |
|
18.2 |
Inserting the transit bolts........ |
51 |
|
18.3 |
Using the appliance again ..... |
52 |
|
18.4 |
Disposing of old appliance .... |
52 |
|
19 |
Customer Service..................... |
53 |
|
19.1 |
Product number (E-Nr.) and |
|
|
|
|
production number (FD)......... |
53 |
20 |
Consumption values................ |
54 |
|
21 |
Technical specifications.......... |
54 |
|
3
en Safety
1 Safety
Observe the following safety instructions.
1.1 General information
¡Read this instruction manual carefully.
¡Keep the instruction manual and the product information safe for future reference or for the next owner.
¡Do not connect the appliance if it has been damaged in transit.
1.2 Intended use
Only use this appliance:
¡For washing machine-washable fabrics and hand-washable wool in accordance with the care label.
¡With tap water and commercially available detergents and care products suitable for washing machines.
¡In private households and in enclosed spaces in a domestic environment.
¡Up to an altitude of max. 4000 m above sea level.
1.3 Restriction on user group
This appliance may be used by children aged 8 or over and by people who have reduced physical, sensory or mental abilities or inadequate experience and/or knowledge, provided that they are supervised or have been instructed on how to use the appliance safely and have understood the resulting dangers.
Children must not play with the appliance.
Cleaning and user maintenance must not be performed by children unless they are being supervised.
Keep children under the age of 3 years and pets away from the appliance.
4
Safety en
1.4 Safe installation
Take note of the safety instructions when installing the appliance.
WARNING ‒ Risk of electric shock!
Improper installation is dangerous.
Connect and operate the appliance only in accordance with the specifications on the rating plate.
Connect the appliance to a power supply with alternating current only via a properly installed socket with earthing.
The protective conductor system of the domestic electrical installation must be properly installed. The installation must have a sufficiently large cross section.
When using a residual current circuit breaker, only use a type with the
mark.
Never equip the appliance with an external switching device, e.g. a timer or remote control.
When the appliance is installed, the mains plug of the power cord must be freely accessible. If free access is not possible, an all-pole isolating switch must be installed in the permanent electrical installation according to the installation regulations.
When installing the appliance, check that the power cable is not trapped or damaged.
If the insulation of the power cord is damaged, this is dangerous.
Never let the power cord come into contact with hot appliance parts or heat sources.
Never let the power cord come into contact with sharp points or edges.
Never kink, crush or modify the power cord.
WARNING ‒ Risk of fire!
It is dangerous to use an extended power cord and non-approved adapters.
Do not use extension cables or multiple socket strips.
If the power cord is too short, contact Customer Service.
Only use adapters approved by the manufacturer.
5
en Safety
WARNING ‒ Risk of injury!
The high weight of the appliance may result in injury when lifted.Do not lift the appliance on your own.
If this appliance is not correctly installed in a washer-dryer stack, the installed appliance may fall.
Only stack the dryer on a washing machine using the connection kit from the dryer manufacturer . No other installation method is permitted.
Do not install the appliance in a washer-dryer stack if the dryer manufacturer does not offer a suitable connection kit.
Do not install appliances from different manufacturers and with varying depths and widths in a washer-dryer stack.
Do not install a washer-dryer stack on a platform; the appliances may tip over.
WARNING ‒ Risk of suffocation!
Children may put packaging material over their heads or wrap themselves up in it and suffocate.
Keep packaging material away from children.
Do not let children play with packaging material.
CAUTION ‒ Risk of injury!
The appliance may vibrate or move when in use.
Place the appliance on a clean, even, solid surface.
Align the appliance using the appliance feet and a spirit level.
If hoses and power cords have been laid incorrectly, this causes a tripping hazard.
Lay hoses and power cords in such a way that there is no risk of tripping.
If the appliance is moved by holding onto protruding components, such as the appliance door, the parts may break off.
Do not move the appliance by holding onto protruding parts.
CAUTION ‒ Risk of cutting!
Touching sharp edges on the appliance may lead to cuts.Do not touch the sharp edges on the appliance.
6
Safety en
Wear protective gloves when installing and transporting the appliance.
1.5 Safe use
WARNING ‒ Risk of electric shock!
If the appliance or the power cord is damaged, this is dangerous.
Never operate a damaged appliance.
Never pull on the power cord to unplug the appliance. Always unplug the appliance at the mains.
If the appliance or the power cord is damaged, immediately unplug the power cord or switch off the fuse in the fuse box and turn off the water tap.
Call customer services. → Page 53
An ingress of moisture can cause an electric shock.
Only use the appliance in enclosed spaces.
Never expose the appliance to intense heat or humidity.
Do not use steamor high-pressure cleaners, hoses or sprays to clean the appliance.
WARNING ‒ Risk of harm to health!
Children can lock themselves in the appliance, thereby putting their lives at risk.
Do not install the appliance behind a door as this may obstruct the appliance door or prevent it from opening.
With redundant appliances, unplug the power cord. Then cut through the cord and damage the lock on the appliance door beyond repair so that the appliance door will no longer close.
WARNING ‒ Risk of suffocation!
Children may breathe in or swallow small parts, causing them to suffocate.
Keep small parts away from children.
Do not let children play with small parts.
7
en Safety
WARNING ‒ Risk of poisoning!
Detergents and care products may result in poisoning if consumed.
If accidentally swallowed, seek medical advice.
Keep detergents and care products out of the reach of children.
WARNING ‒ Risk of explosion!
Laundry that has been pretreated with cleaning agents that contain solvents may cause an explosion in the appliance.
Rinse pretreated laundry thoroughly with water before washing.
CAUTION ‒ Risk of injury!
The covering plate may break if you stand on or climb onto the appliance.
Do not stand on or climb onto the appliance.
The appliance may tip over if you sit on or lean against the open door.
Do not sit on or lean against the appliance door.
Do not place any objects on the appliance door.
Reaching into the drum while it is still turning may cause hand injuries.
Wait for the drum to come to a complete stop before reaching inside.
CAUTION ‒ Risk of burns!
When washing at high temperatures, the glass in the appliance door becomes hot.
Do not touch the appliance door when it is hot.
Keep children away from the appliance door when it is hot.
CAUTION ‒ Risk of scalding!
When you wash at high temperatures, the detergent solution gets hot.
Do not touch the hot detergent solution.
8
Safety en
CAUTION ‒ Risk of chemical burns!
If the detergent drawer is opened, detergent and care products may spray out from the appliance. Contact with eyes or skin may cause irritation.
Rinse eyes and/or skin thoroughly with clean water if they come into contact with detergents or care products.
If accidentally swallowed, seek medical advice.
Keep detergents and care products out of the reach of children.
1.6 Safe cleaning and maintenance
Take note of the safety instructions when cleaning and performing maintenance work on the appliance.
WARNING ‒ Risk of electric shock!
Incorrect repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
Only use genuine spare parts when repairing the appliance.
If the power cord of this appliance is damaged, it must be re-
placed by the manufacturer, the manufacturer's Customer Service or a similarly qualified person in order to prevent any risk.
An ingress of moisture can cause an electric shock.
Do not use steamor high-pressure cleaners, hoses or sprays to clean the appliance.
WARNING ‒ Risk of injury!
The use of non-original spare parts and non-original accessories is dangerous.
Only use the manufacturer's original spare parts and original accessories.
WARNING ‒ Risk of poisoning!
Poisonous fumes may be given off if you use cleaning agents that contain solvents.
Do not use cleaning agents that contain solvents.
9
en Preventing material damage
2 Preventing material damage
Follow these instructions to avoid material damage and damage to the appliance.
ATTENTION!
The functionality of the appliance may be impaired if you use the wrong quantity of fabric softener, detergent, care product or cleaning agent.
Follow the dosage recommendations from the manufacturer.
Exceeding the maximum load capacity impairs the function of the appliance.
Observe the maximum load capacity for each programme and do not exceed it.
→ "Programmes", Page 23
The appliance is secured for transportation using transit bolts. Transit bolts which have not been removed may result in material damage and damage to the appliance.
Before starting up the appliance, remove the transit bolts completely and keep them in a safe place.
Before transport, fit the transit bolts fully in order to prevent damage in transit.
Material damage may be caused if the water inlet hose is connected incorrectly.
Tighten the screw connections on the water inlet until they are handtight.
Ideally, connect the water inlet hose directly to the water tap, without any additional connecting elements such as adapters, extensions, valves or similar.
Ensure that the inner diameter of the water tap is at least 17 mm.
Make sure that the length of the thread on the connection to the water tap is at least 10 mm.
If the water pressure is too high or too low, the appliance may not be able to operate properly.
Ensure that the water pressure in the water supply system is at least 100 kPa (1 bar) and max.
1000 kPa (10 bar).
If the water pressure exceeds the maximum value specified, a pres- sure-reducing valve must be installed between the drinking water connection and the hose set of the appliance.
Do not connect the appliance to the mixer tap of an unpressurised hot-water boiler.
Modified or damaged water hoses may result in material damage and damage to the appliance.
Never kink, crush, modify or cut through water hoses.
Only use the water hoses supplied with the appliance or genuine spare hoses.
Never re-use water hoses that
have been used before. Operating the appliance using water
that is dirty or too hot may cause material damage.
Only operate the appliance with cold mains water.
Unsuitable cleaning products may damage the surfaces of the appliance.
Do not use harsh or abrasive detergents.
Do not use cleaning products with a high alcohol content.
Do not use hard scouring pads or cleaning sponges.
Clean the appliance with nothing but water and a soft, damp cloth.
10
Environmental protection and saving energy en
Remove all detergent residue, spray residue or other residues immediately if they come into contact with the appliance.
3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compatible and can be recycled.
Sort the individual components by type and dispose of them separately.
3.2 Save energy and conserve resources
If you follow these instructions, your appliance will use less electricity and less water.
Choose programmes with low temperatures and longer wash times and use maximum load capacity
→ Page 23.
a Energy consumption and water consumption is most efficient.
Add → Page 30 detergent based on the laundry's degree of soiling.
a For light to normal soiling, a smaller amount of detergent is sufficient. Observe the dosage recommendation from the detergent manufacturer.
Reduce the washing temperature for lightly and normally soiled laundry.
a At low temperatures, the appliance consumes less energy. For light to normal soiling, lower temperatures than indicated on the care label are also sufficient.
Set the maximum spin speed if you want to dry the laundry in a tumble dryer afterwards.
a The drier the laundry, the shorter the programme duration when drying which, in turn, reduces energy consumption. A higher spin speed reduces the residual moisture in the laundry and increases the volume of the spin noise.
Wash the laundry without prewash.
a Washing with prewash increases the programme duration and increases energy and water consumption.
The appliance has a continuous automatic load adjustment function.
a Depending on the type of fabric and load capacity, the continuous automatic load adjustment function optimally adjusts the water consumption and programme duration.
3.3 Energy saving mode
If you do not use the appliance for an extended period, it automatically switches to energy-saving mode. All displays go out and Start / Reload
flashes.
Energy-saving mode ends when you use the appliance again, e.g. if you open or close the door.
11
en Installation and connection
4 Installation and connection
4.1 Unpacking the appliance
Note: Please read the information in the Safety → Page 4 and Preventing material damage → Page 10 sections to ensure that you use the appliance safely.
ATTENTION!
Objects remaining in the drum that are not designed for operation with the appliance may cause material damage and damage to the appliance.
Remove these objects, along with all supplied accessories, from the drum before starting the appliance.
1.Remove any packaging and protective covers completely from the appliance.
For the environmentally friendly disposal of the packaging materials, observe the information on the topic of
→"Disposing of packaging", Page 11.
2.Check the appliance for visible damage.
3.Open the door.
→"Basic operation", Page 30
4.Remove the accessory from the drum.
5.Close the door.
12
Installation and connection en
4.2 Contents of package
After unpacking all parts, check for any damage in transit and completeness of the delivery.
|
1 |
1 |
Washing machine |
2 |
Accompanying documents |
3 |
Water inlet hose |
4 |
Cover caps |
4.3 Requirements for the installation location
Note: Please read the information in the Safety → Page 4 and Preventing material damage → Page 10 sections to ensure that you use the appliance safely.
4
2 |
3 |
WARNING
Risk of electric shock!
The appliance contains live parts. Touching live parts is dangerous.
Do not operate the appliance without a cover cap.
WARNING Risk of injury!
When using the appliance on a base, the appliance may tip over.
Always secure the feet of the appliance to a base using the manufacturer's fixing brackets → Page 26 before using the appliance for the first time.
13
en Installation and connection
ATTENTION!
If the appliance is installed in areas exposed to frost or outdoors, frozen residual water may damage the appliance and frozen hoses may crack or split.
Do not install or operate this appliance anywhere that is liable to experience frost and/or outdoors.
The appliance underwent a function test before leaving the factory and may, therefore, contain residual water. This residual water may leak out if the appliance is tilted at an angle greater than 40°.
Tilt the appliance carefully.
Installation locaRequirements tion
On a base |
Secure the appli- |
|
ance with fixing |
|
brackets |
|
→ Page 26. |
On a wooden |
Place the appli- |
joist floor |
ance on a water- |
|
resistant wooden |
|
board which is |
|
screwed tightly to |
|
the floor. The |
|
wooden board |
|
should be at |
|
least 30 mm |
|
thick. |
In a kitchen unit |
¡ A niche width |
|
of 60 cm is re- |
|
quired. |
|
¡ Only install the |
|
appliance un- |
|
derneath a |
|
continuous |
|
worktop that is |
|
securely con- |
|
nected to adja- |
|
cent cabinets. |
Installation locaRequirements tion
On a wall |
Do not trap the |
|
hoses between |
|
the wall and the |
|
appliance. |
4.4 Removing the transit bolts
The appliance is secured for transportation using transit bolts on the rear of the appliance.
Notes
¡Please read the information in the Safety → Page 4 and Preventing material damage → Page 10 sections to ensure that you use the appliance safely.
¡Keep the transit bolts, screws and sleeves in a safe place for future transport → Page 51.
1. Pull the hoses out of the holders.
14
|
Installation and connection en |
2. Unscrew and remove all four |
5. Put on the four cover caps. |
screws for the transit bolts with a |
|
WAF 13 wrench. |
|
6. Press down on the four cover caps.
3.Pull the power cord out of the holder.
4.5 Connecting the appliance
4. Remove the four sleeves.
Connecting the water inlet hose
Note
¡ Please read the information in the Safety → Page 4 and Preventing material damage → Page 10 sections to ensure that you use the appliance safely.
15
en Installation and connection
1. Connect the water inlet hose.
2.Connect the water inlet hose to a tap (26.4 mm = 3/4").
3.Open the water tap carefully and check that the connection points are tight.
Water outlet connection types
This information is intended to help you to connect this appliance to the water outlet.
Note: Please read the information in the Safety → Page 4 and Preventing material damage → Page 10 sections to ensure that you use the appliance safely.
ATTENTION!
When draining, the water outlet hose is subject to water pressure and may come loose from the installed connection point.
Secure the water outlet hose against unintentional loosening.
Note: Observe the draining heights. The draining heights are: minimum: 60 cm, maximum: 100 cm.
Drainage into a |
Secure the con- |
siphon |
nection point with |
|
a (24–40 mm) |
|
hose clamp. |
Drainage into a |
Fix and secure |
washbasin |
the water outlet |
|
using an elbow. |
|
→ Page 26 |
Drainage into a |
Fix and secure |
plastic pipe with |
the water outlet |
rubber sleeve. |
using an elbow. |
|
→ Page 26 |
4.6 Aligning the appliance
In order to reduce noise and vibration and to prevent the appliance from moving, align the appliance correctly.
Note: Please read the information in the Safety → Page 4 and Preventing material damage → Page 10 sections to ensure that you use the appliance safely.
16
1.Loosen the lock nuts using a WAF 17 wrench by turning it in a clockwise direction.
2.To align the appliance, turn the appliance feet. Check that the appliance is level using a spirit level.
All appliance feet must stand firmly on the ground.
Installation and connection en
3.Screw the lock nuts tightly against the housing using a WAF 17 wrench.
In doing so, hold the foot tight and do not adjust its height.
4.7 Connecting the appliance to the electricity supply
Note: Please read the information in the Safety → Page 4 and Preventing material damage → Page 10 sections to ensure that you use the appliance safely.
1.Insert the mains plug of the appliance's power cable in a socket nearby.
The connection details of the appliance can be found under Technical data → Page 54.
2.Check the mains plug is inserted properly.
17
Loading...
