Page 1
Hob
PKF6...17., PKN6...17., PKN6..BA1.
[en] Instruction manual
Page 2
3.)
3.13.1%$
Table of contents
Safety precautions..................................................................... 2
Causes of damage .............................................................................3
Environmental protection ......................................................... 4
Environmentally-friendly disposal.....................................................4
Energy-saving tips...............................................................................4
Getting to know your appliance................................................ 4
The control panel ................................................................................4
The hotplates .......................................................................................5
Residual heat indicator ......................................................................5
Setting the hob........................................................................... 5
Switching the hob on and off ...........................................................5
Setting a hotplate................................................................................5
Table of cooking times ......................................................................6
Childproof lock........................................................................... 7
Switching the childproof lock on and off........................................7
Automatic childproof lock .................................................................7
[en]Instruction manual
Automatic time limit................................................................... 7
Basic settings............................................................................. 7
Changing the basic settings .............................................................8
Cleaning and care...................................................................... 8
Ceramic ................................................................................................8
Hob surround.......................................................................................8
Rectifying faults......................................................................... 9
After-sales service..................................................................... 9
Test dishes ................................................................................. 9
Produktinfo
Additional information on products, accessories, replacement
parts and services can be found at www.bosch-home.com and
in the online shop www.bosch-eshop.com
: Safety precautions
Please read this manual carefully. Please keep the instruction and installation manual as well as the appliance certificate in a safe place for later use or for subsequent owners.
Check the appliance for damage after unpacking it. Do not connect the appliance if it has been damaged in transport.
Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under warranty.
This appliance is intended for private
domestic use and the household
environment only. The appliance must only
be used for the preparation of food and
beverages. The cooking process must be
supervised. A short cooking process must
be supervised without interruption. Only use
the appliance in enclosed spaces.
This appliance is intended for use up to a maximum height of 2000 metres above sea level.
Do not use covers. These can cause accidents, due to overheating, catching fire or materials shattering, for example.
Do not use inappropriate child safety shields or hob guards. These can cause accidents.
This appliance may be used by children
over the age of 8 years old and by persons
with reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
2 Ø = cm
Page 3
Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
Risk of fire!
■
Hot oil and fat can ignite very quickly.
Never leave hot fat or oil unattended.
Never use water to put out burning oil or
fat. Switch off the hotplate. Extinguish
flames carefully using a lid, fire blanket or
something similar.
Risk of fire!
■
The hotplates become very hot. Never
place combustible items on the hob.
Never place objects on the hob.
Risk of fire!
■
The appliance gets hot. Do not keep
combustible objects or aerosol cans in
drawers directly underneath the hob.
Risk of fire!
■
The hob switches off automatically and
can no longer be operated. It may switch
on unintentionally at a later point. Switch
off the circuit breaker in the fuse box.
Contact the after-sales service.
become very hot. Never touch the hot
surfaces. Keep children at a safe distance.
Risk of burns!
■
The hotplate heats up but the display does
not work. Switch off the circuit breaker in
the fuse box. Contact the after-sales
service.
Risk of electric shock!
■
Incorrect repairs are dangerous. Repairs
may only be carried out by one of our
trained after-sales engineers. If the
appliance is faulty, unplug the mains plug
or switch off the fuse in the fuse box.
Contact the after-sales service.
Risk of electric shock!
■
Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■
A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in
the fuse box. Contact the after-sales
service.
Risk of electric shock!
■
Cracks or fractures in the glass ceramic
may cause electric shocks. Switch off the
circuit breaker in the fuse box. Contact the
after-sales service.
Risk of burns!
■
The hotplates and surrounding area
(particularly the hob surround, if fitted)
Risk of injury!
Saucepans may suddenly jump due to liquid between the pan base and the hotplate. Always keep the hotplate and saucepan bases dry.
Causes of damage
Caution!
■ Rough pot and pan bases scratch the ceramic.
■ Avoid boiling pots dry. This may cause damage.
■ Never place hot pots or pans on the control panel, the
display area or the surround. This may cause damage.
Overview
The following table provides an overview of the most frequent
kinds of damage:
Damage Cause Action
Stains Food spills Remove spills immediately with a glass scraper.
Unsuitable cleaning agents Only use cleaning agents which are suitable for ceramic
Scratches Salt, sugar and sand Do not use the hob as a work surface or storage space.
Rough pot and pan bases scratch the
ceramic.
Discolouration Unsuitable cleaning agents Only use cleaning agents which are suitable for ceramic
Pan abrasion (e.g. aluminium) Lift the pots and pans when moving them.
Blisters Sugar, food with a high sugar content Remove spills immediately with a glass scraper.
Check your cookware.
■ Damage can occur if hard or pointed objects fall on the hob.
■ Aluminium foil and plastic containers melt on hot hotplates.
Oven protective foil is not suitable for your hob.
3
Page 4
Environmental protection
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning used
electrical and electronic appliances (waste electrical
and electronic equipment - WEEE). The guideline
determines the framework for the return and recycling
of used appliances as applicable throughout the EU.
Energy-saving tips
■ Always place suitable lids on saucepans. When cooking
without a lid, considerably more energy is required. A glass
lid means that you can see inside without having to lift the lid.
■ Use pots and pans with even bases. Uneven bases increase
energy consumption.
Getting to know your appliance
The instruction manual is the same for various different hobs.
An overview of the models with their dimensions is given on
page 2.
■ The diameter of pot and pan bases should be the same size
as the hotplate. In particular, small saucepans on the hotplate
cause energy losses. Please note: cookware manufacturers
often indicate the upper diameter of the saucepan. This is
usually bigger than the diameter of the base of the pan.
■ Use a small saucepan for small quantities. A larger, less full
saucepan requires a lot of energy.
■ Cook with only a little water. This will save energy. Vitamins
and minerals in vegetables are preserved.
■ Always cover as large an area of the hotplate as possible
with your saucepan.
■ Switch to a lower heat setting in good time.
■ Select a suitable ongoing cooking setting. You will waste
energy by using an ongoing cooking setting which is too
high.
■ Use the residual heat of the hob. For longer cooking times,
you can switch the hotplate off 5-10 minutes before the end
of the cooking time.
The control panel
Displays
‚-Š
•/œ
Controls
#
D
$
A @
ö
Heat settings
Residual heat
Main switch
Childproof lock
Hotplate selection
Adjustment fields
Automatic zone control
Notes
■ When you touch a symbol, the respective function is
activated.
■ Always keep the controls dry. Moisture reduces their
effectiveness.
■ Do not pull pans close to the displays and sensors. The
electronics could overheat.
4
Page 5
The hotplates
Hotplate Connecting and disconnecting
$
ð
î
When the hotplate is connected: the corresponding indicator lights up. On appliances with multiple zone connection, the display
only lights up when the hotplate has been selected.
When the hotplate is switched on: the last selected size is automatically selected again
Residual heat indicator
The hob has a two-stage residual heat indicator for each
hotplate.
Single-circuit hotplate
Dual-circuit hotplate
Extended cooking zone
Select the hotplate and touch the
Select the hotplate and touch the
If
• appears in the display the hob is still hot. It may be used,
for example, to keep a small meal warm or to melt cooking
chocolate. As the hotplate cools down further, the display
changes to
cooled sufficiently.
ö symbol
ö symbol
œ. The display remains lit until the hotplate has
Setting the hob
This section informs you how to set the hotplates. The table
shows heat settings and cooking times for various meals.
Switching the hob on and off
The main switch is used to switch the hob on and off.
To switch on: Touch the
The indicator light above the main switch and the
light up. The hob is ready for use.
To switch off: Touch the
the main switch and the displays go out. All hotplates are
switched off. The residual heat indicator remains on until the
hotplates have cooled down sufficiently.
Notes
■ The hob switches off automatically if all hotplates have been
switched off for more than 20 seconds.
■ The settings remain stored for 4 seconds after the hob has
been switched off. If you switch it on again during this time,
the hob will operate using the previously stored settings.
# symbol. An audible signal sounds.
‹ displays
# symbol until the display light above
Setting a hotplate
Use the + and - symbols to set the desired heat setting.
Heat setting 1 = lowest setting
Heat setting 9 = highest setting
There is an intermediate setting between each heat setting. This
is identified by a dot.
Setting the heat setting
The hob must be switched on.
1. Touch the $ symbol to select the hotplate.
2. Touch the + or - symbol within the next 10 seconds. The
basic setting appears.
+ symbol: heat setting 9
- symbol: heat setting 4
3. To change the heat setting: touch the + or - symbol until the
desired heat setting appears.
Switching off the hotplate
Use the
symbol until
heat indicator appears.
Notes
■ The last selected hotplate remains activated. You can set the
■ Hotplate temperature is regulated by the heat switching on
$ symbol to select the hotplate. Touch the + or -
‹ appears. After about 10 seconds, the residual
hotplate without selecting it again.
and off. The heat may also switch on and off at the highest
setting.
5
Page 6
Table of cooking times
The following table provides some examples.
Cooking times and heat settings may vary depending on the
type of food, its weight and quality. Deviations are therefore
possible.
For bringing liquids to the boil, use heat setting 9.
Stir thick liquids occasionally.
Melting
Chocolate coating
Butter, honey, gelatine
Heating and keeping warm
Stew (e.g. lentil stew)
Milk**
Heating sausages in water**
Defrosting and heating
Frozen spinach
Frozen goulash
Poaching, simmering
Dumplings
Fish
White sauces, e.g. béchamel sauce
Emulsified sauces, e.g. béarnaise sauce, hollandaise sauce
Boiling, steaming, braising
Rice (with double the quantity of water)
Rice pudding
Unpeeled boiled potatoes
Boiled potatoes
Pasta, noodles
Stew, soups
Vegetables
Frozen vegetables
Cooking in a pressure cooker
Braising
Roulades
Pot roasts
Goulash
Frying**
Escalope, plain or breaded
Escalope, frozen
Cutlet, plain or breaded***
Steak (3 cm thick)
Hamburger, rissoles (3 cm thick)***
Poultry breast (2 cm thick)***
Poultry breast, frozen***
Fish and fish fillet, plain
Fish and fish fillet, breaded
Fish and fish fillet, breaded and frozen, e.g. fish fingers
Scampi and prawns
Stir fry, frozen
Pancakes
Omelette
Fried eggs
* Ongoing cooking without a lid
** Without lid
*** Turn frequently
Ongoing cooking
setting
1-1.
1-2
1-2
1.-2.
3-4
2.-3.
2.-3.
4.-5.*
4-5*
1-2
3-4
2-3
1.-2.
4-5
4-5
6-7*
3.-4.
2.-3.
3.-4.
4-5
4-5
4-5
2.-3.
6-7
6-7
6-7
7-8
4.-5.
5-6
5-6
5-6
6-7
6-7
7-8
6-7
6-7
3.-4.
5-6
Ongoing cooking
time in minutes
-
-
-
-
-
10-20 min
20-30 min
20-30 min
10-15 min
3-6 min
8-12 min
15-30 min
35-45 min
25-30 min
15-25 min
6-10 min
15-60 min
10-20 min
10-20 min
-
50-60 min
60-100 min
50-60 min
6-10 min
8-12 min
8-12 min
8-12 min
30-40 min
10-20 min
10-30 min
8-20 min
8-20 min
8-12 min
4-10 min
6-10 min
consecutively
consecutively
3-6 min
6
Page 7
Deep-fat frying (fry 150-200 g per portion continuously in 1-2 litres oil**)
Frozen products, e.g. chips, chicken nuggets
Croquettes
Meat, e.g. chicken portions
Fish, breaded or battered
Vegetables, mushrooms, breaded or battered
Small baked items, e.g. doughnuts, fruit in batter
* Ongoing cooking without a lid
** Without lid
*** Turn frequently
Childproof lock
Ongoing cooking
setting
8-9
7-8
6-7
5-6
5-6
4-5
Ongoing cooking
time in minutes
-
-
-
-
-
-
You can use the childproof lock to prevent children from
switching on the hotplates.
Switching the childproof lock on and off
The hob must be switched off.
To switch on: Touch the
display light above the
The hob is locked.
D symbol for approx. 4 seconds. The
D symbol lights up for 10 seconds.
Automatic time limit
If a hotplate has been switched on for a long time without the
setting being changed, the automatic time limit is activated.
The hotplate stops heating.
indicator flash alternately on the hotplate display.
” ‰ and the •/œ residual heat
Basic settings
Your appliance has various basic settings. You can adapt these
settings to suit your own needs.
To switch off: Touch the D symbol for approx. 4 seconds. The
hob is unlocked.
Automatic childproof lock
This function automatically activates the childproof lock every
time you switch the hob off.
Switching on and off
You can find out how to switch the automatic childproof lock on
and off in the Basic settings section.
The display goes out when you touch any control. You can
make new settings.
When the time limit is activated depends on the heat setting
selected (1 to 10 hours).
Display Function
™‚
Automatic childproof lock
‹ Switched off.*
‚ Switched on.
™ƒ
Audible signal
‹ Confirmation signal and incorrect operation signal switched off (main switch signal always remains on).
‚ Only incorrect operation signal switched on.
ƒ Only confirmation signal switched on.
„ Confirmation signal and incorrect operation signal switched on.*
™ˆ
Activation of the filament circuits
‹ Switched off.
‚ Switched on.
ƒ Last setting before the hotplate switched off.*
*Basic setting
7
Page 8
Display Function
™Š
Time for selecting the hotplate
‹ Unlimited: The last selected hotplate can always be adjusted without having to select it again.*
‚ Once you select a hotplate, you have 10 seconds to adjust it, after which you will have to select it again in order to
be able to adjust it.
™‹
Reset the basic settings
‹ Switched off.*
‚ Switched on.
*Basic setting
Changing the basic settings
The hob must be switched off.
1. Switch on the hob.
2. Within the next 10 seconds, touch the D symbol for
4 seconds.
™ and ‚ flash alternately in the lower display and ‹ lights up in
the upper display.
Cleaning and care
3. Touch the D symbol repeatedly until the desired indicator
appears in the lower display.
4. Touch the + or - symbol repeatedly until the desired setting
appears in the upper display.
5. Touch the D symbol for 4 seconds.
The setting is activated.
Switching off
To exit the basic setting, switch off the hob with the main switch
and make new settings.
The information in this section provides help on how best to
care for your hob.
Suitable maintenance and cleaning products can be purchased
from the after-sales service or in our e-Shop.
Ceramic
Clean the hob after each use. This will prevent spills from
burning onto the ceramic.
Only clean the hob when it has cooled down sufficiently.
Use only cleaning agents which are suitable for glass ceramic.
Follow the cleaning instructions on the packaging.
Never use:
■ Undiluted washing-up liquid
■ Detergent intended for dishwashers
■ Scouring agents
■ Harsh cleaning agents such as oven spray or stain remover
■ Abrasive sponges
■ High-pressure cleaners or steam jet cleaners
Ground-in dirt can be best removed with a glass scraper,
available from retailers. Please note the manufacturer's
instructions.
You can also obtain a suitable glass scraper from our aftersales service or from the e-Shop.
Using special sponges to clean glass ceramic achieves great
cleaning results.
Hob surround
To prevent damage to the hob surround, observe the following
instructions:
■ Use only hot soapy water.
■ Wash new sponge cloths thoroughly before use.
■ Do not use any sharp or abrasive agents.
■ Do not use the glass scraper.
8
Page 9
Rectifying faults
Malfunctions often have simple explanations. Please read the
following notes before calling the aftersales service.
Display Fault Measure
Blank There is no power supply. Check the household fuse for the appliance. Check whether there is a
All displays
flash
”ƒ
”…
”‰
The controls are damp or an object is
resting on them.
The electronics have overheated and
have switched off the corresponding
hotplate.
The electronics have overheated and
have switched off all hotplates.
The hotplate was in operation for too
long and has switched itself off.
power cut by trying other electronic appliances.
Dry the controls or remove the object.
Wait until the electronics have cooled down sufficiently. Then touch a control for the hotplate.
Wait until the electronics have cooled down sufficiently. Then touch any
control.
You can switch the hotplate back on again immediately.
If - flashes in the hotplate indicators: If - flashes in the hotplate indicators when the appliance is
connected to the mains or following a power cut, the
electronics are malfunctioning. To acknowledge the fault, briefly
cover the controls with your hand.
After-sales service
Our after-sales service is there for you if your appliance should
need to be repaired. We are committed fo find the best solution
also in order to avoid an unnecessary call-out.
E number and FD number:
Please quote the E number (product number) and the FD
number (production number) of your appliance when
contacting the after-sales service. The rating plate bearing
these numbers can be found on the appliance certificate.
Please note that a visit from an after-sales service engineer is
not free of charge, even during the warranty period.
Please find the contact data of all countries in the enclosed
customer service list.
To book an engineer visit and product advice
GB 0344 892 8979
Calls charged at local or mobile rate.
IE 01450 2655
0.03 € per minute at peak. Off peak 0.0088 € per
minute.
Rely on the professionalism of the manufacturer. You can
therefore be sure that the repair is carried out by trained service
technicians who carry original spare parts for your appliances.
Test dishes
This table has been produced for test institutes to facilitate the
testing of our appliances.
The data in the table refers to our accessory cookware from
Schulte Ufer (4-part induction pot set HEZ 390042) with the
following dimensions:
■ Saucepan dia.16 cm, 1.2 litres, for 14.5 cm dia. single-circuit
hotplate
Heating up/bringing to boil Ongoing cooking
Test dishes Heat setting Cooking time (min:sec) Lid Ongoing cooking
Melting chocolate
Cookware: saucepan
Cooking chocolate (e.g. Dr. Oetker dark
chocolate, 150 g) on 14.5 cm dia. hotplate
---1.No
■ Cooking pot dia. 16 cm, 1.7 litres, for 14.5 cm dia. single-
circuit hotplate
■ Cooking pot dia. 22 cm, 4.2 litres, for 18 cm dia. or 17 cm
dia. hotplate
■ Frying pan dia. 24 cm, for 18 cm dia. or 17 cm dia. hotplate
setting
Lid
9
Page 10
Heating up/bringing to boil Ongoing cooking
Test dishes Heat setting Cooking time (min:sec) Lid Ongoing cooking
Lid
setting
Heating and keeping lentil stew warm
Cookware: cooking pot
Lentil stew made to DIN 44550
Initial temperature 20 °C
Amount: 450 g for 14.5 cm dia. hotplate 9 approx. 2:00 without stirring Yes 1. Yes
Amount: 800 g for 18 cm dia. or 17 cm
9 approx. 2:00 without stirring Yes 1. Yes
dia. hotplate
Lentil stew from the tin
e.g lentils with Erasco sausages:
Initial temperature 20 °C
Amount: 500 g for 14.5 cm dia. hotplate 9 approx. 2:00
Yes 1. Yes
(Stir after approx. 1:30)
Amount: 1000 g for 18 cm dia. or 17 cm
dia. hotplate
9 approx. 2:30
(Stir after approx. 1:30)
Yes 1. Yes
Simmering Béchamel sauce
Cookware: saucepan
Milk temperature: 7° C
Recipe: 40 g butter, 40 g flour, 0.5 l milk
2
9
approx. 5:20 No
1, 3
1
No
(3.5% fat content) and a pinch of salt for
14.5 cm dia. hotplate
1
Melt the butter, stir in the
flour and salt, and keep
cooking the roux for 3 minutes
2
Add the milk to the roux and bring to the
boil, stirring continuously
3
After the Béchamel sauce
has come to the boil, keep
cooking it at setting 1 for a
further 2 minutes, stirring all
the time
Cooking rice pudding - Ongoing cooking with lid
Cookware: cooking pot
Milk temperature: 7° C
Recipe: 190 g round grain rice, 90 g
sugar, 750 ml milk (3.5% fat content)
and 1 g salt for 14.5 cm dia. hotplate
9 approx. 6:45
Heat the milk until it starts to rise
up. Switch down to the ongoing
No 2 Yes
cooking setting and add the rice,
sugar and salt to the milk
Total cooking time (incl. bringing
to boil) approx. 45 minutes
Stir the rice pudding after 10
minutes
Recipe: 250 g round grain rice, 120 g
sugar, 1 l milk (3.5% fat content) and a
pinch of salt for 18 cm dia. or 17 cm dia.
hotplate
9 approx. 7:20
Heat the milk until it starts to rise
up. Switch down to the ongoing
cooking setting and add the rice,
No 2 Yes
sugar and salt to the milk
Total cooking time (incl. bringing
to boil) approx. 45 minutes
Stir the rice pudding after 10
minutes
Cooking rice pudding - Ongoing cooking without lid
Cookware: cooking pot
Milk temperature: 7° C
10
Page 11
Heating up/bringing to boil Ongoing cooking
Test dishes Heat setting Cooking time (min:sec) Lid Ongoing cooking
Recipe: 190 g round grain rice, 90 g
sugar, 750 ml milk (3.5% fat content)
and 1 g salt for 14.5 cm dia. hotplate
Recipe: 250 g round grain rice, 120 g
sugar, 1 l milk (3.5% fat content) and 1.5
g salt for 18 cm dia. or 17 cm dia. hotplate
Cooking rice
Cookware: cooking pot
Water temperature 20° C
Recipe acc. to DIN 44550:
125 g long grain rice, 300 g water and a
pinch of salt for 14.5 cm dia. hotplate
Recipe acc. to DIN 44550:
250 g long grain rice, 600 g water and a
pinch of salt for 18 cm dia. or 17 cm dia.
hotplate
Frying pork loin chops
Cookware: frying pan
Initial temperature loin chops: 7° C
Amount: 3 loin chops (total weight
approx. 300 g, about 1 cm thick) 15 g
sunflower oil for 18 cm dia. or 17 cm
dia. hotplate
Frying pancakes
Cookware: frying pan
Recipe acc. to DIN EN 60350-2
Amount: 55 ml batter per pancake for 18
cm dia. or 17 cm dia. hotplate
Deep-fat frying frozen chips
Cookware: cooking pot
Amount: 1.8 kg sunflower oil, per portion: 200 g frozen chips (e.g. McCain
123 Original fries) for 18 cm dia. or 17
cm dia. hotplate
9 approx. 7:30
Add rice, sugar and salt to the
milk and heat the mixture up,
stirring continuously. At a milk
temperature of approx. 90°C
switch down to the ongoing
cooking setting.
Simmer for approx. 50 minutes
9 approx. 8:00
Add rice, sugar and salt to the
milk and heat the mixture up,
stirring continuously. At a milk
temperature of approx. 90°C
switch down to the ongoing
cooking setting.
Simmer for approx. 50 minutes
9 approx. 2:48 Yes 2 Yes
9 approx. 3:15 Yes 2. Yes
9 approx. 2:40 No 7 No
9 approx. 2:40 No 6 or 6. depending
9 Until oil temperature reaches
180 °C
No 2 No
No 2 No
No 9 No
setting
on browning level
Lid
No
If the tests are carried out with an 18 cm dia. hotplate with a
power rating of 1500 W, the boiling time is increased by
approx. 20% and the ongoing cooking setting by one ongoing
cooking setting.
11
Page 12
Robert Bosch Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München
Germany
www.bosch-home.com
*9000735358*
9000735358
960111
Loading...
