Bosch GAA 10,8V-21 User Manual
Robert Bosch Power Tools GmbH
1 609 92A 5C1
70538 Stuttgart
GERMANY
www.bosch-pt.com
1 609 92A 5C1 (2019.08) T / 23
GAA 10,8V-21 Professional
en Original instructions
ko 사용 설명서 원본
2 |
English . . .. .. .. .. .. . .. .. .. .. .. .. .. .. .. .. .. . .. .. .. .. .. . .. .. Page 6
한국어 . .. .. .. .. .. . .. .. .. .. .. . .. .. .. .. .. . .. .. .. .. .. . .. 페이지 18
1 609 92A 5C1 | (06.08.2019) Bosch Power Tools
(1)
(2)
(3)
(4)
(5)
(6)
GAA 10,8V-21
| 3
Bosch Power Tools 1 609 92A 5C1 | (06.08.2019)
1 1
2
(1)
(4)
(1)
(5)(5)
(4)
A1
A2
4 |
1 609 92A 5C1 | (06.08.2019) Bosch Power Tools
(8)
(3)
(2)
(7)
(6)
B
C
| 5
Bosch Power Tools 1 609 92A 5C1 | (06.08.2019)
6 | English
English
Safety instructions
Read all the safety information and general instructions. Failure
to observe the safety information and general instructions may result
in electric shock, fire and/or serious injury.
Keep all the safety information and general instructions for future reference.
Safety instructions for dealing with batteries
u Do not open the battery. There is a risk of short-circuiting.
u In case of damage and improper use of the battery, vapours may be emitted. The
battery can set alight or explode. Ensure the area is well ventilated and seek medical attention should you experience any adverse effects. The vapours may irritate the
respiratory system.
u If used incorrectly or if the battery is damaged, flammable liquid may be ejected
from the battery. Contact with this liquid should be avoided. If contact accidentally occurs, rinse off with water. If the liquid comes into contact with your eyes,
seek additional medical attention. Liquid ejected from the battery may cause irrita-
tion or burns.
u The battery can be damaged by pointed objects such as nails or screwdrivers or
by force applied externally. An internal short circuit may occur, causing the battery
to burn, smoke, explode or overheat.
u When the battery is not in use, keep it away from paper clips, coins, keys, nails,
screws or other small metal objects that could make a connection from one terminal to another. A short circuit between the battery terminals may cause burns or a
fire.
u Only use the battery with products from the manufacturer. This is the only way in
which you can protect the battery against dangerous overload.
u Only charge the batteries using chargers recommended by the manufacturer. A
charger that is suitable for one type of battery may pose a fire risk when used with a
different battery.
1 609 92A 5C1 | (06.08.2019) Bosch Power Tools
English | 7
Protect the battery against heat, e.g. against continuous intense
sunlight, fire, dirt, water and moisture. There is a risk of explosion
and short-circuiting.
u Do not insert the battery into the battery adapter if the release buttons are
broken or faulty. The battery may fall out during operation.
u Used batteries should be recycled in an environmentally friendly manner. Ob-
serve the instructions for this in the "Transport" and "Disposal" sections.
Product Description and Specifications
Please observe the illustrations at the beginning of this operating manual.
Intended Use
The battery adapter is intended for use with a Bosch 10.8 or 12 V lithium-ion battery as
the power source. The battery adapter can be used to power a maximum of one USB
device and one heating element for heated workwear at any one time.
Product Features
The numbering of the components shown refers to the illustrations on the graphic pages.
Battery adapter
(1)
USB port
(2)
Socket for connector plug of heating element for heated workwear
(3)
(4)
(5)
(6)
(7)
(8)
A)
Accessories shown or described are not included with the product as standard. You can
find the complete selection of accessories in our accessories range.
A)
Battery
Battery release button
Belt clip
Activation button for USB connection
Connector plug
Technical Data
Battery adapter GAA 10,8V-21
Article number 1 600 A01 435
USB port Type A
Bosch Power Tools 1 609 92A 5C1 | (06.08.2019)
