Bosch FME-SOLOGAS-A10 Specsheet

Fire Alarm Systems | FME-SOLOGAS-A10 Smoke testing aerosol

FME-SOLOGAS-A10 Smoke testing aerosol

www.boschsecurity.com

u Simple to use with the SOLO330 Test device for

optical smoke detectors and SOLO332 Smoke
tester for detectors ≤ 5.25 in. (13.335 cm) diameter

u HFC and silicone free to protect the environment

and the detector

When used with the SOLO330/SOLO332, the smoke
aerosol for testing optical smoke detectors
accomplishes a functional test. It introduces simulated
smoke from the protected area through the vents of a
detector to the sensor(s).

Certifications and approvals

No Climb Products Ltd. (SOLO) hold the following
listings:

Region Regulatory compliance/quality marks

USA UL ANSI/UL 268 - Smoke Detectors for Fire

Alarm Signaling Systems

Canada ULC CAN/ULC-S529 - Smoke Detectors for

Fire Alarm Systems

Parts included

Quantity Component

12 6.8 oz. (0.193 kg) canisters each containing 4.8 oz.

(0.14 kg) of the test gas

u Non-flammable with no lasting residue

Technical specifications

Mechanical specifications are for a box of 12 canisters.

Mechanical

Dimensions

9 in. x 7 in. x 6 in. (22.9 cm x 17.8 cm x 15.3 cm)

(LxWxH)

Gross weight 73.2 oz. (2.08 kg)

Trademarks

All hardware/software product names used in this
document are likely to be registered trademarks and
must be treated accordingly.

Ordering information

FME-SOLOGAS-A10 Smoke testing aerosol

Smoke aerosol for use with SOLO330 and SOLO332
detector testers. Sold by case containing twelve 6.8
oz. (0.193 kg) canisters. Each canister contains 4.8 oz.
(0.14 kg) of the test gas.

Order number FME-SOLOGAS-A10

1 Literature - User guide
