Blaupunkt MC CD 42e Instruction Manual

Download

MS BT 26e

MS BT 26e / MC CD 42e

MC CD 42e

Mikroanlage mit Bluetooth Micro system with Bluetooth

MS BT 26e/MC CD 42e

CLASS 1 LASER PRO DU CT

LUOKAN 1 LASE RL AI TE

KLASS 1 LASERAP PARAT

MS BT 26e/MC CD 42e

F.FWD

F.REV

MS BT 26e

SOURCE

5 6

MC CD 42eMC CD 42e

MS BT 26e/MC CD 42e

Competence Center Audio M3 Electronic GmbH. Gutenbergstrasse 5, D-65830 Kriftel-Germany

2.0 Bluetooth CD Micro System with USB FM: 87.5-108MHz Power Consumption: 40 Watt Power Source: 220-240V~50Hz Standby Power Consumption: <0.5 Watt Batch NO.: PO 10470

AUX IN

MS BT 26e/MC CD 42e

STANDBY

USB

AUX

FREQUENCY

FAST REVERSE

SAVE

MO/ST

AUX

MO/ST

TONE

MUTE

BLUETOOTH FM

NUMBER BUT TONS

STOP

FAST FORWARD

PLAY/PAUSE

REPEAT

VOL-

REPEAT

TONE

VOLUME+/-

MS BT 26e

MS BT 26e/MC CD 42e

STANDBY

CD/USB

AUX

FREQUENCY

FAST REVERSE

SAVE

MO/ST

PROGRAM

CD/USB

AUX

MO/ST

TONE

EJECT

BLUETOOTH FM

NUMBER BUT TONS

STOP

FAST FORWARD PLAY/PAUSE

REPEAT

VOL-

MUTE

REPEAT TONE

VOLUME+/-

EQ MUTE

RANDOM

MC CD 42e

MS BT 26e/MC CD 42e

Competence Center Audio M3 Electronic GmbH. Gutenbergstrasse 5, D-65830 Kriftel-Germany

2.0 Bluetooth CD Micro System with USB FM: 87.5-108MHz Power Consumption: 40 Watt Power Source: 220-240V~50Hz Standby Power Consumption: <0.5 Watt Batch NO.: PO 10470

AUX IN

MS BT 26e/MC CD 42e

Important Safety Instructions

Impor tant Safety Instructions

Caution:

To reduce the risk of electric shock, do n ot dismantle the product and do no t expose the apparatus to rain or mois ture. No user-serviceable parts inside. Refer servicing to qualified personnel only.

Explanation of Graphical Symbols:

The l ightning flash within an equilate ral triangle is i nte nded to aler t you to the presence of uninsulated dangerous voltage within the produc t's enclosure that may b e of sufficient magn itude to constitute an electric shock to a person or persons.

The exclamation point within an equilateral triangle is intended to alert you to the presence of important operating and maintenance ( servicing) instructions in the literature accompanying the p roduct.

To achieve the utmost in enjoyment and per forma nce, and in order to become familiar with its features, please read this manual carefully before attemp ting to op era te this product. This will assure you years of trouble free per forma nce a nd li ste nin g pleasure.

Impor tant Notes

Thi s safety a nd opera tin g instruction should be retained for future reference. The a ppa ratus sh oul d not be exposed to dripping or splashing or placed in a humid

atm osphere suc h as a bathroom .

¡Do not install the product in the following areas: ¡Pla ces expo sed to direct sunlight or close to radiators. ¡On to p of ot her stereo eq uip ment tha t rad iate too much heat. ¡Blocking ventilation or in a dusty area. ¡Areas where there is constant vibration. ¡Humid or moist places. Do not place near candles or other naked flames. Operate the p roduct only as instructed in this manu al. Before turn ing o n the power for the first time, make sure the power adaptor is properly

con nec ted.

For safety reasons, do not re move any cover s or at tempt to gain a ccess to the inside of th e produc t. Refe r any servicing to qualified personnel. Do not attempt to remove any screws, or open t he ca sin g of the unit; there are no u ser serviceable parts inside. Refer all servi cing to qualified servi ce pe rso nnel.

MS BT 26e/MC CD 42e

Conformity

Model number: MS BT 26e/MC CD 42e Description: Mic ro System with Bluetooth Bra nd na me: Blaupunkt Responsible party: M 3 Ele ctronic GmbH Gutenb erg str ass e 5, D-65830 Krif tel. Ge rmany Hereby, Blau pun kt Compe tence Center Audio M3 Electronic GmbH, declares that this Class 1 equipment is in compliance with the essential requirement and other relevant provisio ns of Directive 1999/5/EC. Letter of conformity can b e obt ain ed from in fo@m3- electronic.de.

Safety Instructions

Read Instructions

- All the safety and ope rating instructions must be read before

the product is op erated.

Retain Instructions - The safety and operating instruc tions should be k ept with the

product for future reference.

Heed war nings - All warnings o n the product and in the operating instructi ons

should be adhered to.

Follow instructions Installation - Instal l in accordance with the manufacturer's instruct ions.

Power sources - This product should be operated only from the ty pe of power

- All operating and users’ ins tructions should be followed.

source indicated by the mark ing adjacent to the power cord entry. If you are not sure of the type of power sup ply to your home, consult your product dealer or local power company.

Grounding or polarization - the product is not required to be grounded. Ensure

that the plug is fully inserted into the wall outle t or extension co rd receptacle to prevent blade or pin exposure. Some versions of the produc t are equipped with a power cord fitte d with a polarized alternating line plug (a plug having one blade wider than the other). This plug will fit onto the power outlet onl y one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, tr y revers ing the plug. If the plug should still fail to fit, contact your el ectrician to replace your obsolete outlet. D o not defeat the safety purpose of the po larized plug. When using an extension power-su pply cord or a power-supply cord other than that suppli ed with the appliance, it sh ould be fitted with the appropriate molded plugs and carry safety approval appropri ate to the countr y of use.

Power cord protection - Power-supply cords should be routed so that they are not

likely to be walked on, kinked or pinched by items placed on or against the m, pay ing par ticular attentio n to co rds f rom p lugs, receptacles and the point where they exit from the produc t.

Overloading - Do not overload wall outlets, extension cords, or multiple sockets, as

this can result in a risk of fire or electric shock.

10.

Ventilation - The produ ct must be properly ventilated. Do not place the product on

a bed, sofa, or other similar surface. Do not cover the product with any items such a s tablecloths, newspapers, etc.

MS BT 26e/MC CD 42e

- The product should be situated away from heat sources such as radiators,

Heat

11.

heat registers, stoves, or ot her products, including amplifiers that produce heat. No naked flame sources, such as lighted candles, should be placed on the ap paratus.

Water and moisture - To reduce the risk of fire or electric shock, do not expose the

12.

product to train, dr ipping, splashin g or exces sive moisture such as in a sauna or bathroom. Do not use this product near water, for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement or near a swimming pool (or similar).

Object and Liquid Entry - Never push objects of any k ind into this produc t through

13.

openings, as they may touch dangerous voltage points or shor t-circui t parts that cou ld result in a fire or electric shoc k. Never spill liquid of any ki nd on the product. Do not place any objec t containing liquid on top of the product.

14.

Cleaning - Unplug the product from the wall outlet before cleaning. Dust in the

woofer may be cleaned with a dry cloth. If you wish to use an aeros ol cleaning spray, do not spray directly on the cabinet; s pray onto the cloth. Be careful not to damage the drive units.

Attachments - Do not use attachments n ot recommended by the product

15.

manufact ure r, as th ey may cause hazards.

Accessories - Do not place this product on an unstable cart, stand, t ripod, bracket

16.

or table. The product may fall, causing serious injur y to a child or adult, and serious damage to the produc t. Use only with a cart, stand, t ripod, bracket or ta ble recommended by the manufacturer or sol d with the produc t. Any mounting of the product shoul d follow the manufac turer ’s instructions and s hould use a mounting accessor y recommended by the manu facturer.

Moving the product - A product and cart combination sh ould be moved with care.

17.

Quick stops, excessive force and uneven surfaces may cause the product and cart com bination to overturn.

Unused periods - The power cord of the applian ce should be unplugged from the

18.

outlet during l ightning storms or when the apparat us is left unu sed for a long period of time.

Servicing - Do not attempt to service this product yourself, as opening or removing

19.

covers may expose you to dangerous voltage or other hazards. Refer all servici ng to qualified ser vice personnel.

20.

Please remove the power plug form the main power source or wall power source when not in use. When plugged in to a power source, the system is in stand by mode, so the power is not entirely cut o ff.

Replacement parts - When replacement parts are required, ensure that the service

21.

tec hnician has used replacement parts specified by the manufacturer or have the same characte ristics as the original par t. Unauthorized s ubstitution s may result in fire, electric shock or other hazards.

22.

Mains fuses - For continued protection against fire hazard, use fuses only of the

cor rect type and rating. The correct fuse s pecification for each voltage range is marked on the product. Do not turn up the volume while listeni ng to a sectio n with very low level inputs or

23.

no audio signals. If you do, the spea ker may be damaged when a peak level section is suddenly played.

MS BT 26e/MC CD 42e

The o nly means of completely disconnec ting the produc t from the power supply is

24.

by removing the power cord from the wall outlet or the product. The wall outlet or the powe r cord entry to the p roduct must remain freely accessible at all times while the product is in u se. Try to install the product near a wall socket or extension cord and shall be easily

25.

accessible.

26.

The h ighest environmental tem perature suitable for this product is 35°C.

ESD hints - If the product maybe reset or not reset to operation of control due to

27.

electrostatic discharge, just switch off and reconnect again, or move the product to another location.

28.

Batter y

1).

The b atteries must not be exposed to excessive heat such as sunshine, fire or the like. The b atteries should be drawn to the environmental aspects of batter y

2). disposal.

3).

Battery usage CAUT ION-to prevent batter y leakage which may result in body injuries, proper ty damage, or damag e to the apparatus: Install all batteries correc tly, + and – as mar ked on the apparatus. Do not mix batteries (old and new or carbon and alkaline, etc.) Remove batteries when t he unit is not used for a lo ng time.

ERP2 - (Energy rel ated produc ts) note

Thi s pro duct with ecodesign complies with the stage 2 requireme nts of Commission Regulation (EC) NO. 1275/2008 implementing Directive 2009/125/EC regard to st andby and off mode elec tric power consumption of elec tronic household and office equipment. After 15 minutes wit hout any audio input, the system will automatically switch into standby mode. Follow up the instruction manual to resume the operation.

Warning

Thi s appliance is not intended for use by persons (i ncluding chil dre n) with reduced physic al sensory or mental cap abilities, or lack of experience and knowledge, unless they have bee n given supervision or inst ruction concerning use of the appliance by a person responsible for their safety. Children should be super vised to ensure that they do not play with the appliance.

Never use the device unsupervised! Switch off the device whenever you are not using it, even if this only for a short while. The a ppliance is not intended to be operated by means of an external ti mer or

2. separate remote control system. If the supply cord is damaged, it must be replace d by the manufacturer, its ser vice

3. agent or similarly qualified persons in order to avoid a hazard.

Before o perating this system, c heck the voltage of this system to see if it is identical to th e voltage of your local power supply. The u nit should not be i mpeded by covering the ventilation opening with items

5. such as newspaper, table-cloths, cur tains etc. Make sure that there are at least 20 cm of space above and at least 5 cm of space on each side of the unit.

MS BT 26e/MC CD 42e

The a pparatus must not be exposed to dripp ing or splashin g and that objects filled

6. with liquids, such as vases, must not be placed o n the apparatus. To prevent fire or shock hazard, do not expose this equipment to hot places, rain,

7. moisture or dust. Do not locate this unit near any water sources e.g. taps, bathtubs, washing

8. machines or swimming pools. Ensure that you place the unit on a dr y, stable surface.

Do not place this unit close to a strong magnetic field. Do not place the unit on a amplifier or receiver.

10.

11.

Do not place this unit in a damp area as the moisture will affect t he life of electr ic com ponents.

12.

If the system is brought directly from a cold to a warm location, or is placed in a very damp room, moisture may condense on the lens inside the player. If this occurs, the sys tem will not operate properly. Please leave the system t urned on for about an hour until the moisture evaporates. Do not attempt to clean the unit with chemical solvents as this might damage the

13. finish. Wipe with a clean, dry or slightly damp c loth. When removing the power plug from the wall outlet, always pull di rec tly on the

14. plug, never pull on the cord. Depending on th e electromagn etic waves used by a television bro adcast, if a TV is

15. turned on near th is unit while it is also on, lines might appear on the TV s cre en. Neither this unit nor the TV is malfunctioni ng. I f you see such lines, keep this unit well away from the TV set.

16.

The m ains plug is used a s the disconnec t device, the disconnect device must remain readily operable. To keep the lase r pickup clean, do not touch it, and always cl ose the disc tray.

17. During playback, the disc rotates at high speed. DO NOT lift or move the unit during

18. playback, doing so may damage the disc or the unit. When changing places of installation o r packing the unit for moving, be sure to

19. remove the disc and return the disc tray to its closed posi tion in the player. Then, press switch to turn the power off and disconnect the power cord. Moving this unit with the disc loaded may re sult in damage to this unit. Put discs back in their case after playing them. Never expose di scs to direct sun light

20. or heat sources. Never leave discs inside a car parked in full sunlight.

Do not touch the playback side of disks. Hol d discs by the

21. edges to avoid leaving fingerprints on the surface. Any dust, fingerprints or scratches may cause a malfunction. Never attach a label or sticky tape to the disc. Use a c lean soft lint-free cloth to clean th e disc, working

22. from the center outwards in a st raight line, thinners, com mercially available cleaners or anti s tatic sprays for vinyl discs.

MS BT 26e/MC CD 42e

Warning: Danger of radiation

CLASS 1 LASER PRO DU CT

LUOKAN 1 LASE RL AI TE

KLASS 1 LASERAP PARAT

Thi s label means that this unit contains a l aser component. Opening the CD compartment lid and defeating the safety interlocks will expose the user to radiation from the lase r beam. Do not stare into the laser while it is operating.

Before operation

Notes: Concerning compact discs.

Since dirty, damaged or warped discs may d amage the appliance, care should be taken of the followings items:

a. Us able compact discs. Use only compac t disc with the mark shown below. b. CD compact disc only with digital audio signals.

The B luetooth word mark and lo gos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by M3 Electronic GmbH is under license. Other trademarks and trade names are those of their respective owners.

MS BT 26e/MC CD 42e

Panels

Front

1 2

1. INDICATOR LIGHT

2. STANDBY

3. SOURCE

4. NEXT

MS BT 26e

5. PREVIOUS

6. VOLUME KNOB

7. Display screen

8. IR remote control sensor

SOURCE

F.FWD

F.REV

9. PLAY/PAUSE

10. FAST FORWARD

11. FAST REVERSE

12. USB PORT

1. INDICATOR LIGHT

2. STANDBY

3. SOURCE

4. NEXT

5 6

MC CD 42e

5. PREVIOUS

6. VOLUME KNOB

7. Display screen

8. IR remote control sensor

9. EJEC T

10. PLAY/PAUSE

11. STOP

12.DISC TRAY

13.USB PORT

MS BT 26e/MC CD 42e

Back

Competence Center Audio M3 Electronic GmbH. Gutenbergstrasse 5, D-65830 Kriftel-Germany

2.0 Bluetooth CD Micro System with USB FM: 87.5-108MHz Power Consumption: 40 Watt Power Source: 220-240V~50Hz Standby Power Consumption: <0.5 Watt Batch NO.: PO 10470

AUX IN

MS BT 26e/MC CD 42e

1. FM ANTE NNA

2. AUX IN L/R

3. Power supply input

4. SPEAKERS L/R

Connecting the speakers

Note:

- For optimal sound, use the supplied speakers only.

- Connect only sp eakers with imp edance that is the same or higher than the supplied

speakers. (Refer to t he Specifications secti on of this manual.)

RIGHT SPEAKER LEFT SPEAKER

Competence Center Audio M3 Electronic GmbH. Gutenbergstrasse 5, D-65830 Kriftel-Germany

2.0 Bluetooth CD Micro System with USB FM: 87.5-108MHz Power Consumption: 40 Watt Power Source: 220-240V~50Hz Standby Power Consumption: <0.5 Watt Batch NO.: PO 10470

Inser t the speake r connect into SPEAKER panel (L and R):

cables

1. The RED connect cable of ri ght speaker to R (+); th e BLACK co nnect cable of right

speaker to R (-).

2. The RED connect cable of left speaker to L (+) ; the BLACK connect cable of left

speaker to L (-).

AUX IN

RED BLACKRED BLACK

MS BT 26e/MC CD 42e

Remote control

Usage

Before you us e the remote control, please check if yo u have installed batteries (”AAA” 2 x 1.5V, includ ed) inside. The remote control should direct to the remote sensor which is located on the fro nt panel of the device. If the remote control does not work , please try to adjust the direction angl e and distance with the device. Obstacle s between the remote control and the main unit can impact remote sensitiveness. If the remote control is in weak function, please try to replace the batteries.

Remote control graphics

STANDBY

USB

AUX

FREQUENCY

FAST REVERSE

SAVE

MO/ST

AUX

MO/ST

TONE

MUTE

BLUETOOTH FM

NUMBER BUT TONS

STOP

FAST FORWARD

PLAY/PAUSE

REPEAT

VOL-

REPEAT

TONE

VOLUME+/-

MS BT 26e

MS BT 26e/MC CD 42e

Remote control graphics

STANDBY

CD/USB

AUX

FREQUENCY

FAST REVERSE

SAVE

MO/ST

PROGRAM

CD/USB

AUX

MO/ST

TONE

EJECT

BLUETOOTH FM

NUMBER BUT TONS

STOP

FAST FORWARD PLAY/PAUSE

REPEAT

VOL-

MUTE

REPEAT TONE

VOLUME+/-

EQ MUTE

RANDOM

MC CD 42e

MS BT 26e/MC CD 42e

Basic Operation

Getting started

Connect the mai ns plug to a wall outlet. Extend the aerial as far as it ca n go.

NOTE: The quality of the FM reception will be influenced by the positioning of the aerial.

Standby mode

Press STANDBY button on the front panel or on the remote control to switch th e sys tem intos tandby mode.

Note: make sure that the unit is connected to the p ower source.

Mode Selection

Press SOURCE but ton on the front panel or USB (or CD/USB for MC CD 42e), BT, AUX, FM buttons on remote control to choose the mode you want. There are 4 modes in MS BT 26e:

BT, USB, FM(tuner), AUX(audio) and there are 5 modes in MC CD 42e: BT, USB, FM(tuner), AUX(audio) and CD.

Volume Control

The volume knob is to control the volume. To inc rease the volume, adjust the knob to clock-wise direction. To decrease th e volume, adjust the k nob in anticlockwise dire ction. You can also adjust the volume by pressing VOL+, VOL- buttons on the remote control.

Mute button

If you press the MUTE button while playing, the sound output will be switched off. Press again the VOL+/- buttons to resum e the previous volume level.

Play/Pause

During playback, press the PLAY/PAUSE button once to pause playback. Press it again to resume playback.

Stop

During playback, press the STOP button once to stop playba ck. Press PLAY/PAUSE to play fro m the beginning.

Repeat Press REPEAT button to set repeat mode: repeat one, repeat all, repeat off.

Press EQ button to s elect the diffe rent sound fields: Eq-00 (Off ), Eq-01(Jazz), Eq-02(Rock), Eq-03(Classic), Eq- 04(Pop), Eq -05(Live), Eq-06(Dance).

Tone

Press TONE button to adjust the volume, ba ss and treble. E.g. press TONE button to se lect the required item, then press VOL+/- buttons to adjust the effect of bass or trebl e.

Previous and Next

In play status, press or to play the previous or next track.

Fast forward and Fast reverse

In play status, press or to fast forward or fast reverse by speed x1, x2. Press or button to FAST FORWARD or FAST REVERSE: press once to fast at speed x1, press twice to fast at speed x2. Press a third time to resume to normal speed.

MS BT 26e/MC CD 42e

CD Operation (only available in MC CD 42e)

Press CD/USB button on the remote control to switch to CD mode. Press EJECT button and place the CD disc on DISC TRAY. The unit will automatically load the disc and star t playing when it recognizes the disc.

Playback operation:

You can control playback by using buttons such as: , , , , etc. For more operations, ple ase refer to Ba sic Operati on.

Random While playing CD disc, press R ANDOM button to play the tracks/songs in a rand om order

Program

Thi s function is available in stop mode while playing a CD di sc. This functio n plays CD tracks in a programmed order. (a) Press STOP button while playing a CD disc. Press PROGRAM button and the display shows: Pr 0100 (b) Input the number of the song which you want to play first: e.g. input 04 and the fourth song will be played as the first song. When you finish entering the first order, it will turn to the next order automatically. (c) When you finish all progress, pre ss PLAY/PAUSE to confi rm, and it will play the songs by the programmed order. (d) To cancel programmed playing, press STOP button. Then the unit exits programming automatica lly. Now you can press PLAY/PAUSE button to restar t playing the disc.

MS BT 26e/MC CD 42e

USB Operation

To listen to a USB device:

1. Connect the de vice USB to the USB port on the front pa nel of the unit.

2. Press the SOURC E button to cycle through and enter relevant mode. The unit

will detect devices automatic ally.

3. If the USB devices haven’t been connected, words “NO USB” will appear on the

display.

4. Then insert the USB device. After the device is found the player starts p laying

a uto mat ica lly.

Playback operation:

1. When the device is reading the USB, it automatically sorts all available files in

numbers. You can select tracks by pressing Number buttons.

2. Press PLAY/PAUSE button to start or pause playback.

3. Press STOP button to stop playback. Press PLAY/PAUSE to star t playback from

the beginning.

4. Press PREVIOUS /NEXT buttons to select the previous or next track.

5. Us e the MUTE button or VOLUME+/- buttons to control the volume.

6. Press button to FAST FORWARD. Press once to fast forward at sp eed x1, press

twice to fast for ward at speed x2. Press a third time to resume to normal speed.

7. Press button to FAST REVERSE. Press once to fast rever se at speed x1, press

twice to fast reverse at speed x2. Press a third time to resume to normal speed.

8. When all the tracks have played over, press the button to start the playback from

the beginning. Note:

1. USB extensio n cable shall have a max. length of 0.25m.

2. Depending on t he amount of data and media speed, it may take l onger for system to

read the contents of media dev ice. In some cases, reading time may be as long as 60 seconds.This is not malfunction.

3. Depending on t he content some files may not play or be displayed even when they

are in a supported format.

4. The m ax. suppor ted capacity of USB devices is 32GB.

5. Connect your USB de vice directly to the USB port of the unit. Using a n extension

cable is not recommended and may cause interference and fail ure o f data transfer.

MS BT 26e/MC CD 42e

External audio input operation (AUX IN)

You can connec t an externa l audio device to the un it to enjoy music via your un it.

1. Connect the ex ternal audio playe r ’s audio output with the AUX IN L/R sockets on

the rear panel of the unit.

2. Sw itch the unit to aux in mo de by pressing the AUX button on the remote control or

SOURCE button on the front panel.

3. Start playback on the external device. Adjust the volume by using the m ain unit volume button (or remote control).

Turn off both devi ces before disconnect ing them from the wall outlet.

Note: The connected external device cannot be controlled by remote control. You can only adjust the volume. I f you can not hear any sound co ming from the speakers, check the volume on the external device.

MS BT 26e/MC CD 42e

Bluetooth Operation

Pairing operation (to pair your Bluetooth devices)

1. Press the BT button on the remote control or SOURCE button on the front panel

to switch to Bluetooth mode. The b lue indicator light will flash.

2. Turn on the Bluetooth function on your device (e.g. mobile phon e). Then place your

device in Bluetoot h search mode and it will start searching this unit.

3. Select “BP MS BT 26e“ or “BP MC CD 42e“ from the list of found de vices on the

mobile phone (or music device).

4. Select OK or YES to pair the unit with your mob ile phone or musi c device.

5. Enter 0000 for passkey (if prompted).

6. Af ter the unit pairs successfully, the Bluetooth indicator light start flashing steadily.

Playback Operation

Playback is controlled by the but tons on the front panel of the unit and by the remote control such as VOL+/-, , , and .

To disconnect and pair with another device

1. Turn off the Bluetooth function on your device to disconnect it with the unit. The

unit will enter the Bluetooth pairing status automatically with the new device.

2. In the pair ing status, follow the steps 2-5 of PAIR OPERATION section to connect

another Bluetooth device.

Phone call while playing music

Music will stop auto matically if a phone call is coming while playing music from the mobile phone.When the call ends, it depends on the setting of your phone whether the current track will resume playback or not.

Note: Some devices, such as an iPhone, connect i mmediately af ter pairing, some may tak e

longer to connect. The un it can only be connected and playing co ntent from one device at a time. To connect to a different paired device, yo u have to tu rn off Bluetooth function or unpair from the current ly paired device, and connec t manually to the other device. Due to different device manufacturers, models, and software versions, a full function ality cann ot be guaranteed.

The B luetooth word mark and lo gos are regisitered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by M3 Electronic GmbH is under license. Other trademarks and trade names are those of their respective owners.

MS BT 26e/MC CD 42e

FM Operation

Tuning to a station:

1. Press SOURCE bu tton repeatedly to select FM (tuner) mode or press FM button

on the remote control.

2. Adjust the volume to a comfor table level by VOLUME+/- .

3. Press MO/ST to sw itch between STEREO ON or OFF if there is a strong radio signal.

To select a station:

1. You can scan up or down the frequency range manually by pressing or buttons

to in crease or decrease the frequency in 0.05 MHz increments.

2. Press and hold or buttons to automatically c ycle through the presets, and

it stops when it finds the available stations.

3. Press SEARCH bu tton to search all available s tations and up to 30 stations are

automatically saved as preset stations. (Pressing SEARCH button will clear all the saved st ations.)

4. You can select the previous or next stations by pressing the or buttons.

5. You can also select stations by NUMBER buttons on the remote control.

6. Press F (Frequency) button on the remote control to select frequency.

E.g. if you want to listen to the 88.9 MHz, press F button first, then press n umber buttons 8, 8, 9, 0 to enter the selected frequency.

To save stations:

1. It is possible to store your favorite stations. This will enable you to access your

favorite stations quickly & easily.

2. Tune to the radio station you want to save as a preset.

3. Press SAVE button on the remote control to enter preset saving mode.

4. Press or button to select a preset number.

5. Press SAVE again on the remote co ntrol. The currently tuned stati on is now saved to

the selected preset number.

6. Repeat Steps 2-5 of TO SAVE STATIONS to store up to 30 FM preset statio ns.

7. To select a preset station, briefly press / repeatedly to reach the station you

want.

(Please vary the antenna direction to find the strongest signal for each station.)

MS BT 26e/MC CD 42e

Trouble shooting

PROBLEM

No so und Sta tic S oun d Sound is distored

Desire d station not found

The d isp lay is blank

I can h ear a bur bling n oise on so me stat ion s

The s oun d is weak or of poo r quali ty

Specifications

Power source

Max. power consu mpt ion

Sta ndby power consumption

FM frequenc y

FM presets

USB supported file formats

Blueto oth vers ion

Blueto oth work ing distance Input jacks

CAUSE

Volume not turned on Sig nal reception too low Volume is too hi gh

Weak sign al

Thi s may occur if the broadcaste r cha nges th e lab el of a s ervice or removes a label while tuned.

Weak sign al

Other devices, e.g. a televisi on, are interfe rin g wit h reception.

220-240V~50Hz

40 Watt

< 0.5 Watt

87.5 ~ 108MHz

M 3 and WMA

CSR V2.1+EDR

33 ft. (10 m)

USB and AUX IN

SOLUTION

Adjust the main volume knob Adjust the antenna or move th e uni t to a stronger signal location

Use t he Ma nua l Tune fu nction

The radio will try to ret une per formance a scan.

Try re-p osi tio nin g the a eri al

Move the unit further away from these devices.

Care and maintenance

After using the unit---- Switch to standby and power off the unit. Unplug the unit and

avoid le aving batteries fitted if you are leaving it unattended for a long period (ho liday etc ). The batteries may leak and damage the remote control. Care and cleaning---- All care and cle aning operations should be carried out with the unit unplugged from the mains power. Occasionally wipe the cabinet with a lint free duster. Never clean the unit with liquids or solvents.

MS BT 26e/MC CD 42e

Thi s sym bol on the prod uct or in the instructions means that your electrical and el ectronic equipment should be disposed at the end of its life separately from your h ousehold waste. The re are separate collection systems for recycling in the EU. For more infor mat ion, please contact the local author ity or your ret ailer where you purchased the prod uct.

All r ights re ser ved by Blaupunkt Competence Center Audio M3 Elect ronic Gm bH. This materi al may be reproduced, copied or distributed for personal use only.

Blaupunkt MC CD 42e Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
