R-320
radia
S E R I E S
A r c h i t e c t u r a l L o u d s p e a k e r
T H E R A D I A S E R I E S
The new Radia R-320 by BG is the most versatile model in the new Radia
Architectural Series. An updated version of a classic, this compact in-wall can fit
almost anywhere while easily filling your listening space with amazing sound.
Driving the R-320 are two 8” midrange planar ribbons, our patented Neo3PDR tweeter
and two 5.25” long-throw woofers featuring the latest neodymium magnet technology.
This three-way symmetric array takes advantage of both conventional loudspeaker
design, as well as our proprietary PDR planar technology, offering the best of both worlds.
The result? Stunning sound in a compact form that can be easily mounted in an opening
less than 6” wide and 4” deep.
As with all Radia loudspeakers, the R-320 is hand crafted from the finest materials such
as high-grade steel and aircraft grade aluminum. The speaker’s rugged, precision frame
p l a n a r t e c h n o l o g y
reduces wall resonance, making it an excellent choice for professional installations, where
there is zero tolerance for error and maximum demand for high fidelity. In addtion, the
R-320 is paintable allowing your customer to match the finish to their decor.
Compact yet powerful, the R-320 delivers a deep, spacious soundstage with lifelike imaging
and uncanny accuracy for a wide array of locations and applications.
Rugged Highest quality components will provide a lifetime of trouble-free enjoyment
›
Versatile Perfectly suited as a horizontal center channel, main or surround speaker
›
Stylish Attractive industrial design with paintable grille and frame to match any decor
›
Lifelike Horizontal dispersion creates expanded soundstage and wider “sweet spot”
›
Accurate Planar ribbon drivers provide superior clarity, resolution and fidelity of sound
›
T h e P o w e r o f C l a r i t y
Page 2
radia
S E R I E S
A r c h i t e c t u r a l L o u d s p e a k e r
R-320
p l a n a r t e c h n o l o g y
T H E R A D I A S E R I E S
G E N E R A L P A R A M E T E R S :
›
S y s t e m t y p e
S y s t e m d i m e n s i o n s
(H xW x In st al le d Gr il le H )
W e i g h t
W a l l c u t - o u t s i z e
D r i v e r c o m p l e m e n t
Three-way symmetric hybrid array
34 3/16 x 7 1/8” x 3/4 ( 86.7 x 17.9 x 1.9 cm)
14.2 lbs. (6.5 kg)
32 5/16” x 5 7/8” (82 x 15.2 cm)
2 x 5.25” long-throw Neodymium magnet woofers
2 x Neo8 Planar Midrange drivers
1 x Neo3PDR Planar ribbon tweeter
C r o s s o v e r 450 Hz, 2.4 kHz, passive
F r e q u e n c y r e s p o n s e 50 Hz -25 kHz (-6 dB, half space)
S e n s i t i v i t y 88 dB /2.83 V / 1m
R a t e d i m p e d a n c e 4 ohms
P o w e r h a n d l i n g 200 W RMS
W a r r a n t y
1
Lifetime to the original owner
The Radia R-320 is currently available through BG’s authorized network of specialty custom
retailers and integrators.
1
Please see BG warranty for complete details
3535 Arrowhead Drive · Carson City, NV 89706 ·
phone:
internet:
www.bgcorp.com ·
© Copyrigh t 2006 BG Corp. All rights res erved. Products, features and spe cications sub ject to change without notice.
775-884-1900 ·
email:
toll free:
888-8PLANAR (888-875-2627)
