Overview
About this book
This book provides you the main information about various components
in your Joybook and demonstrates how to use them. The following are
the major chapters of this book.
Chapter Title Description
Chapter 1 Overview Introduction to this book.
Chapter 2 Getting started Information about beginning
Chapter 3 Touring your
Joybook
Chapter 4 Using your
Joybook
Chapter 5 Using BIOS setup Information about how to use
Chapter 6 Connecting to
external display
devices
Chapter 7 Installing
additional memory
Chapter 8 FAQ and
troubleshooting
Chapter 9 Information on
cleaning and
battery
maintenance
Chapter 10 Service and
support
Chapter 11 Appendix Important safety information.
to use your Joybook.
Introduction to the hardware
components of your Joybook.
Basic and advanced
information about operating
your Joybook.
the BIOS setup utility.
Information about how to
connect your Joybook to
external display devices.
Offers information about how
to add the memory.
Frequently asked questions
and troubleshooting
information.
Information about cleaning
and battery maintenance.
Joybook service and support
information.
Typog ra phics
The usage of notes, tips and warnings is specifically for different
purposes, which are described as follows.
Icon/
Symbol
< > or [ ] Keys on the
Item Meaning
Warning Information mainly to prevent the
Tip Useful information for completing
Note Supplementary information.
keyboard; User
Interface (UI) on
the screen
damage to components, data, or
personal injury caused by misuse
and improper operation or
behavior.
a task.
Indicates a key on the keyboard,
or the UI on the screen. Do not
actually type the symbols
together with the enclosed letters.
Overview 1
Getting started
Depending on the model of your Joybook, the appearance may be
different from those shown in this manual.
Package contents
Before using your Joybook for the first time, please check if you have all
the items with you. For details about what should be included in the
package, refer to the package contents label on the accessory box. If any of
the items are missing or appear damaged, contact your dealer
immediately. Save the packaging in case you need to ship your Joybook
for service.
Getting your Joybook ready for use
1. Installing the battery pack
2. Connecting the power
Connect the power cord to the power adapter.
Connect the power adapter to the power socket on your Joybook.
Turn your Joybook upside down and put it on a soft clean cloth. With the
label side of the battery pack facing down, slide it gently into the battery
compartment until it snaps into place (1). Move the release latch to the
left as shown to lock the battery pack into place (2).
Getting started2
Connect the power cord to a wall outlet and start charging the battery.
Power systems and plug types might vary depending on your country/
region.
• When the battery is charging, the battery indicator appears in amber.
When the charging process is completed, the light goes off.
• For details about the colors and meanings of the indicators, refer to
"Indicators" on page 11.
3. Opening your Joybook
To open your Joybook, slide the latch to the right, and then lift the lid up.
4. Performing initial setup
Press the power button to start up your Joybook, and then follow the onscreen instructions to complete the initial Windows XP setup.
• The actual operating system that comes with your Joybook might vary.
For more information, refer to the Product Specification Label on the
product carton.
• Your Joybook P51 Series only works with Microsoft Windows® XP
Home and Windows® XP Professional editions.
Getting started 3
Expanding the capabilities of your Joybook
Connect an external display device (such as a monitor or projector) to the
VGA port of your Joybook.
Connect a telephone line to the modem port of your Joybook and dial-up
to the Internet.
Getting started4
Access local area network (LAN) by connecting a network cable to the
LAN port of your Joybook.
Use various ExpressCard on the market by inserting one into the
ExpressCard slot of your Joybook.
Use the optical drive to access data on various kinds of discs or enjoy
DVD/VCD movies.
Connect an earphone to the earphone jack to output sounds.
Connects to a Hi-Fi set, radio, synthesizer, walkman, etc.
Connect a microphone to the microphone jack to record sounds.
Getting started 5
Insert a Memory Stick, Memory Stick Pro, SD or MMC memory card to
exchange files.
Connect USB peripherals to the USB port of your Joybook.
Connect digital camcorders and high-speed storage equipment to this
IEEE 1394 (FireWire) Port.
Getting started6
Output video images on your Joybook to a TV or AV device by
connecting it to the S-Video out jack on your Joybook.
Touring your Joybook
Depending on the model of your Joybook, the appearance may be different from those shown in this manual.
Front view
(1) Built-in microphone
Receives sounds and voices for recording.
Internet hotkey
Starts up the Internet Explorer Web browser.
E-mail hotkey
Starts up the Outlook Express e-mail client.
Wireless LAN launch button
Enables/disables the wireless LAN.
(3) Tou ch pa d
(4) LCD panel
(5) Keyboard
(6) Earphone/SPDIF audio output jack
Can be used to connect to an earphone/headset or external speaker
for playing Joybook audio.
(7) Audio input jack
Can be used to connects to a Hi-Fi set, radio, synthesizer, walkman,
etc.
(8) Microphone input jack
Can be used to connect to a microphone for recording sounds.
(9) IEEE 1394 (FireWire) port
For connecting high-speed peripherals such as digital video cameras
and other consumer electronics devices that use the IEEE 1394
(FireWire) interface.
(2) Power button and quick access buttons
Power
Turns your Joybook on or off.
Touring your Joybook 7
Left side view
(1) Power jack
For connecting AC power supply.
(2) Ventilation holes
For dissipating heat and keeping the computer at an optimal
temperature.
(3) LAN (Ethernet) port (RJ-45 connector)
Allows Joybook to connect to a 10/100/1000Mbps Ethernet network.
Do not plug a phone jack connector in the RJ-45 port. This may damage
this device.
(4) VGA port
For connecting external display devices, such as monitors and projectors.
(5) S-Video out jack
Allows Joybook to outputs video signals to a television set or VCR that
has an S-Video in jack via an S-Video cable.
Touring your Joybook8
(6) USB 2.0 port
For connecting peripherals such as mice, digital cameras and MP3 players
that use the USB interface.
Right side view
(1) Four-in-One memory card slot
Reads a Memory Stick, Memory Stick Pro, SD or MMC memory card.
(2) ExpressCard slot
This ExpressCard slot accepts one double-wide or single-wide type
ExpressCard. You can use it and various ExpressCard on the market to
further expand the capabilities of your Joybook.
Insert a ExpressCard into the slot following the direction indicated on the
card and complete related driver settings.
(3) USB 2.0 port
For connecting peripherals such as mice, digital cameras and MP3 players
that use the USB interface.
(4) DVD/CD-RW Combo/DVD-Dual/DVD Super-Multi drive
(Optional)
The type of optical drive varies by model, and the support of disc
types depends on the optical drive that comes with your Joybook.
Supports multi-functional optical module for reading music CDs, VCDs
and DVDs or burning CD-R/CD-RW or DVD+R/DVD-R/DVD+RW/
DVD-RW/DVD-RAM (optional) discs. Discs can be inserted/ejected by
pressing the small ejection button on the drive.
(5) Tray ejection hole
If you wish to open the disc tray when your Joybook power is off, or it
can't be opened using the ejection button, insert a pointed object into the
tray ejection hole next to the ejection button to force open the disc tray.
(6) Modem port (RJ-11 connector)
Accepts an analog telephone line for use with the internal modem.
To reduce the risk of fire, use only No. 26 AWG or larger
telecommunications line cord.
(7) USB 2.0 port
For connecting peripherals such as mice, digital cameras and MP3 players
that use the USB interface.
(8) Anti-theft lock hole
You can attach a anti-theft lock and cable to this hole to prevent theft.
Touring your Joybook 9
Bottom view
(1) Hard disk drive compartment
Accommodates the hard disk drive of Joybook.
(2) MiniCard slot, Memory expansion slot and CPU
compartment
Accommodates the CPU and memory slot of Joybook. There is also a
MiniCard slot for using an optional MiniCard.
Depending on your model, a MiniCard wireless network card may have
been pre-installed.
(3) Battery retainer A
Secures the battery in place.
Touring your Joybook10
(4) Battery pack
Supplies power to Joybook when external power is not connected.
(5) Battery retainer B
Secures the battery in place.
Loading...
