Users Manual
Version 1.3 August 2004
ENGLISH
PMH660M/PMH880S
EUROPOWER
EUROPOWER PMH660M/PMH880S
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: To reduce the risk of electric shock, do not remove
the top cover (or the rear section). No user
serviceable parts inside; refer servicing to qualified
personnel.
WARNING: To reduce the risk of fire or electric shock, do not
expose this appliance to rain and moisture. The
apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such
as vases, shall be placed on the apparatus.
This symbol, wherever it appears, alerts you to the
presence of uninsulated dangerous voltage inside
the enclosurevoltage that may be sufficient to
constitute a risk of shock.
This symbol, wherever it appears, alerts you to
important operating and maintenance instructions
in the accompanying literature. Please read the
manual.
DETAILED SAFETY INSTRUCTIONS:
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturers instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury from
tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
15) CAUTION - These service instructions are for use by
qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than
that contained in the operation instructions unless you
are qualified to do so.
2
EUROPOWER PMH660M/PMH880S
FOREWORD
Dear Customer,
Welcome to the team of
EUROPOWER users and
thank you very much for
expressing your confidence in BEHRINGER
products by purchasing
this power mixer.
It is one of my most
pleasant tasks to write
this letter to you, because
it is the culmination of
many months of hard
work delivered by our
engineering team to reach
a very ambitious goal:
to present you two
outstanding power
mixers that give you
performance with a unique sound character and broad range of
striking functions.
The task to design the new PMH series certainly meant a great
deal of responsibility, which we assumed by focusing on you,
the discerning user and musician. It also meant a lot of work and
night shifts to accomplish this goal. But it was fun, too. Developing
a product usually brings a lot of people together, and what a
great feeling it is when everybody who participated in such a
project can be proud of what weve achieved.
It is our philosophy to share our joy with you, because you are
the most important member of the BEHRINGER team. With your
highly competent suggestions for new products youve greatly
contributed to shaping our company and making it successful. In
return, we guarantee you uncompromising quality as well as
excellent technical and audio properties at an extremely
favorable price. All of this will enable you to fully unfold your
creativity without being hampered by budget constraints.
We are often asked how we can make it to produce such
high-grade devices at such unbelievably low prices. The answer
is quite simple: its you, our customers! Many satisfied customers
means large sales volumes enabling us to get better conditions
of purchase for components, etc. Isnt it only fair to pass this
benefit back to you? Because we know that your success is
our success, too!
I would like to thank all people whose help on Project PMH
has made it all possible. Everybody has made very personal
contributions, starting from the designers of the unit to the many
staff members in our company and finally to you, the user of
BEHRINGER products.
maximum flexibility and
My friends, its been worth the trouble!
Thank you very much,
3
EUROPOWER PMH660M/PMH880S
1. INTRODUCTION
Congratulations! With the PMH660M/PMH880S you have
acquired a state-of-the-art power mixer that sets new standards.
Right from the very start it has been our goal to design a
revolutionary unit that can be used for a wide variety of
applications. And indeed, this overwhelming power mixer gives
you plenty of functionality and a broad range of connection and
expansion options.
Your power mixer features our revolutionary COOLAUDIO
amplifier technology that reduces weight and size of your device
and provides extreme high output power.
Further advantages are the integrated Voice Canceller that
removes vocal tracks from a playback, the FBQ function for
feedback detection and the Speaker Processing function for
adjusting the frequency response of any loudspeakerand
everything with 24-bit/46 kHz resolution.
The mixing consoles of the PMH series feature a state of the
art, integrated switch-mode power supply (SMPS). One of the
great advantages is that (compared to conventional circuits) a
switch-mode power supply adapts to mains voltages between
100 and 240 volts automatically. Furthermore, due to its much
greater efficiency, it consumes much less energy than a
conventional power supply unit.
BEHRINGER is a company with its roots in professional
recording studio technology. For many years we have been
successful in developing products for studio and live use. These
include microphones and 19" units of all types (compressors,
enhancers, noise gates, tube processors, headphone amplifiers,
digital effects, DI boxes, etc.), monitor and P.A. speakers as
well as professional live and recording mixers. Our entire
technical know-how has gone into your PMH power mixer.
1.1 Before you get started
1.1.1 Shipment
Your PMH was carefully packed at the factory and the
packaging is designed to protect the unit from rough handling.
Nevertheless, we recommend that you carefully examine the
packaging and its contents for any signs of physical damage
which may have occurred during transit.
+ If the unit is damaged, please do NOT return it to
BEHRINGER, but notify your dealer and the shipping
company immediately. Otherwise, claims for damage
or replacement may not be granted.
+ We recommend that you use a flight case, so as to give
your power mixer optimum protection during use or
transport.
+ Always use the original packing carton to prevent
damage during storage or transport.
+ Make sure that children cannot play unsupervised with
the device or its packaging.
+ Please ensure proper disposal of all packing materials.
1.1.2 Initial operation
Be sure that there is enough air space around the unit for cooling
and, to avoid overheating, please do not place the EUROPOWER
near radiators, etc.
+ Blown fuses must be replaced by fuses of the same
type and rating! Please refer to the
SPECIFICATIONS for details.
The mains connection is made using the enclosed power cord
and a standard IEC receptacle. It meets all of the international
safety certification requirements.
+ Please make sure that all units have proper ground
connection. For your own safety, never remove or
disable the ground conductor from the unit or on
the AC power cord.
1.1.3 Warranty
The EUROPOWERs serial number is located on the rear panel.
Please take the time to fill in and return the warranty card within
14 days after the date of purchase, so as to benefit from our
extended warranty. Or register online at www.behringer.com.
1.2 The manual
This manual is designed to give you both an overview of all
control elements and to provide detail about how to use them. To
provide you with a clear structure, we have grouped the control
elements according to their function. They can easily be found
on the enclosed numbered illustrations. If you need more detailed
information on specific topics, please visit our web site
www.behringer.com. The product-related information pages and
the ULTRANET-based glossary explain the relevant audio
engineering terminology in full detail.
2. CONTROL ELEMENTS
A detailed description of all functions of your power mixer can
be found in the following chapters. Please also refer to the
enclosed sheet with the numbered illustrations to get an overview
of the control layout.
2.1 Mono and stereo channels
The HI control in the EQ section governs the high-frequency
range of the respective channel.
Use the MID control to boost or cut the mid-range
frequencies.
The LOW control allows you too boost/cut the low-frequency
range.
With the MON control you can adjust the volume of each
channel in the monitor mix.
The FX control determines the signal level sent from each
channel to the built-in effects processor; this signal is also
present at the FX OUT jack (see ). The PMH880S has
two FX controls (FX 1 and FX 2), so that you can use two
effects simulteneously. Accordingly, it also provides two
effect Aux paths (see ).
+ Please note that the effects processor signal will
be inaudible when the FX RETURN control ( ) is
set fully counter-clockwise.
For the mono input channels, the PMH880S has a
PAN(ORAMA) control which determines the position of the
channel signal in the stereo main mix. The PMH660M has
no PAN on the input channels, because it is a dual-mono
power mixer.
The BAL(ANCE) control for the stereo channels of the
PMH880S corresonds to the PAN control for the mono
channels. It determines the relative volume of the left and
right input signals before they are routed to the stereo main
output. The PMH660M has no stereo channels and hence
no BAL control, because it is a dual-mono power mixer.
4
2. CONTROL ELEMENTS
EUROPOWER PMH660M/PMH880S
The LEVEL control adjusts the channel signal level in the
main mix.
2.1.1 Input section
The CLIP LED is very useful to control the input gain. It
should never be constantly illuminated (only with signal
peaks).
The PAD switch reduces the input sensitivity of the channel
by approx. 30 dB, to connect for example line-level signals.
The balanced HI-Z input (1/4" TRS) can be used for linelevel signal sources, e.g. keyboards, electric guitars and
basses.
Each channel has a balanced LOW-Z microphone input
with XLR connectors, which also supply the +48 V phantom
power for condenser microphones (see ).
Unbalanced stereo line inputs with 1/4" connectors for
stereo channels 7 to 10 of the PMH880S. They can be
used for connecting keyboards with stereo outputs or
stereo drum machines.
+ Please remember to use either the microphone or
the line input of a channel at a time, but never both
at the same time!
2.2 Effects section
List of all multi-effects presets.
LED level meter of the effects processor. Since the
PMH880S allows you to select two effects simultaneously,
it also has two level meters (DUAL FX). Be sure that the
clip LED illuminates for signal peaks only. If it is illuminated
all the time, it is a sign that the effects processor is
overloading and hence producing unpleasant distortion.
The EFFECT display (PMH880S: two displays) shows the
currently selected preset.
Turn the PROGRAM control (PMH880S: one control each
for FX 1 and FX 2) to select an effects preset (preset
2. CONTROL ELEMENTS
5
EUROPOWER PMH660M/PMH880S
If STANDBY is pressed, all input channels are muted.
During breaks you can thus prevent the microphones from
picking up noise or interference, which would then be
reproduced by the P.A. system. The advantage is that all
faders can be left untouched while you play a CD via the
CD/TAPE inputs (see ). There is also no need to move
down the faders of muted channels and lose your mix.
2.3.1 Connectors
The FOOTSWITCH connector is for a standard
footswitch. You can activate an effect bypass that mutes
the effects processor. Please use a dual footswitch for
the PMH880S, so that you can enable/disable FX1 and FX2
independently of each other. In this case, the tip of the 1/4"
plug controls FX1, and the ring FX2.
The FX OUT connector is used to route the FX SEND signal
from the input channels, for example, to the input of an
external effects processor. The PMH880S has two
FX controls per input signal (see ) and also two
FX OUT connectors (FX OUT 1 and FX OUT 2).
+ Please note: When you connect a mono plug to one
of the FX OUT jacks, the signal path from the
respective FX send to the built-in effects processor
is interrupted. For each FX send you can either use
the built-in effect or the corresponding FX OUT jack
(for an external effect), but never both at the same
time. When you use a stereo plug (tip and ring
interconnected) you can use the built-in effects
processor and the FX OUT jacks in parallel.
Use the AUX IN 1/4" inputs to route an external stereo
signal to the main mix. This can be the signal generated by
an external effects processor. Use the left input for mono
signals, which are then reproduced on both stereo sides.
The PMH660S has only one mono AUX IN connector.
The AUX IN control adjusts the volume of the external
signal in the main mix.
The 2TR IN RCA input allows you to feed in external stereo
signals, e.g. from a CD player, tape deck or other line-level
source.
The VOICE CANCELLER filters vocal-specific
frequencies from the 2TR IN signal. This function
can be used for karaoke, i.e. you can remove the
vocals from a song and then sing along with the
music yourself.
The REC OUT (RCA) provides line-level signals from the
power mixer to a DAT recorder, for example. On the
PMH880S the REC OUT signal is stereo and on the
PMH660M two identical mono signals are provided.
+ If the REC OUT signal is connected to a recorder
whose output signal is returned to the 2TR IN,
feedback can occur when you activate the record
function. So, disconnect the 2TR IN from the
recorder, before you start recording!
The MAIN 1/4" connectors allow you to send the main
signal to an external amplifier, when you only wish to use
the mixer and effects section. The signal is taken prepower stage of the mixer. It is also possible to use only the
left jack of the output. The PMH660M has only one mono
output connector.
Connect your monitor power amps or active monitor
speakers to the mono MONITOR output to monitor the
signal mix created with the MON controls or to route it to
the musicians on stage.
Use the POWER switch to put the unit into operation. The
POWER switch should always be in the Off position when
you are about to connect the unit to the mains.
+ Please note: The POWER switch does not fully
disconnect the unit from the mains. Unplug the
power cord completely when the unit is not used
for prolonged periods of time.
2.4 Rear panel
The mains connection is on a standard IEC receptacle. An
appropriate power cord is supplied with the unit.
FUSE HOLDER. Before connecting the unit to the mains,
ensure that the voltage setting matches your local voltage.
Blown fuses should only be replaced by fuses of the same
type and rating. Please also read the information given in
chapter 6 SPECIFICATIONS.
These are the two cooling fans of the unit.
Loudspeaker OUTPUT A.
PMH880S: Depending on the operating mode selected (see
) either the left main signal or the monitor signal is
provided at OUTPUT A. NEVER use this output in bridged
mono mode.
PMH660M: In MON/MAIN mode, the monitor signal is provided
at OUTPUT A (see ). NEVER use this output in bridged
mono mode, except when you use a cable with the normal
pin connections (SPEAKON® cable: pins 1+/1-). In this case
you can take the mono main signal from this output in
MAIN/MAIN (BRIDGE) mode (not bridged). Please also refer
to chapter 4.4 Loudspeaker connection.
+ The impedance of the loudspeaker connected must
not fall below 4 Ω.
+ Please note that the power delivered to the speaker
in bridged mono mode is considerably higher than
in other operating modes. Please read the
information given on the rear panel of the power
mixer.
Loudspeaker OUTPUT B.
PMH880S: Depending on the operating mode selected
(see ) either the right main signal, the mono main signal
or the bridged mono signal is provided at OUTPUT B.
PMH660M: Either the main or the bridged main mono signal
is provided at OUTPUT B (see ). When you use a cable
with the normal pin connections (SPEAKON® cable: pins
1+/1-), it is possible in MAIN/MAIN (BRIDGE) mode to take
the mono main signal from this output (not bridged). Please
also refer to chapter 4.4 Loudspeaker connection.
+ In BRIDGE mode, always connect only one loudspeaker
with an impedance of at least 8 W to OUTPUT B (pins
1+/2+)! Please note that OUTPUT A must NEVER be
used in BRIDGE mode (with pin connections 1+/2+)!
+ In all other operating modes, the minimum
impedance of the speaker connected must not fall
below 4 Ω.
+ Information on how to properly connect your
speaker with regard to polarity can be found on the
rear of the mixer (PINOUTs).
SERIAL NUMBER. Please take the time to fill in and return
the warranty card within 14 days after the date of purchase,
so as to benefit from our extended warranty. Or register
online at www.behringer.com.
6
2. CONTROL ELEMENTS
EUROPOWER PMH660M/PMH880S
3. DIGITAL EFFECTS PROCESSOR
A special feature of your PMH880S and PMH660M is the built-
in multi-effects processor that features the same audio
quality as our renowned studio-grade VIRTUALIZER
PRO DSP2024P. The PMH880S even has two effects
processors, each of them with 99 different standard
effects such as reverb, chorus, flanger, delay, vocal
distortion as well as various effects combinations.
CATHEDRAL: Simulates the dense, long reverberation of a
large cathedral, which is appropriate for solo instruments or vocals
in slow pieces. Choose between two variations.
PLATE: Simulates the sound of plate reverberations and hence
is a classic for drums (snare) and vocals. The second one
features more high-end sparkle than the first.
CONCERT: Select between a small theater and a large hall.
Although this program is similar to studio (see below) it features
more presence, which adds to its lively character.
STAGE: Is well suited for dissipating the sound of a keyboard
or an acoustic guitar.
ROOM: You can clearly hear the walls of the room. A useful
program for reverb that isnt directly noticeable (rap, hip hop
vocals) or to make dry recordings of instruments sound natural
again.
STUDIO: This simulation of a middle to large-sized room is
also available in two variations. Both variations sound very
natural and can be used as all-purpose effects.
SMALL HALL: Simulates a small, lively (strongly reflecting)
hall and is perfect for processing drums.
AMBIENCE: Reproduces a middle-sized room without late
reflections.
EARLY REFLECTIONS: The initial reflections of this room are
clearly audible. This effect is a classic for dynamic signals (drums,
percussion, slap bass, etc.).
SPRING REVERB: Simulates classic spring reverberation.
GATED REVERB: This effect synthetically cuts off reverberation
after a period of time. It is famous in the song In the Air Tonight
by Phil Collins. The variations differ in the reverb length.
REVERSE REVERB: This is a reverberation in which the
envelope is reversed, i.e. it slowly gets louder.
PHASER: With the phaser, a second, phase-shifted signal is
added to the original audio signal. The resulting sound is thicker
and above all livelier. This effect is often used for guitar sounds
and keyboards. In the 70s, it was also extensively used for
other instruments like electric pianos. The PMH offers you four
different phaser variations.
ROTARY SPEAKER: The simulation of a classic effect that is
normally generated with a (slow or fast) rotating speaker.
DELAY: A delay of the input signal with various repetitions.
Different tempo settings (ten variations in total) allow interesting
delay effects.
ECHO: Similar to the stereo delay, with the difference being
that the repetitions have less presence. This simulates the
character of the original tape echo that was used before the
digital era and can be thought of as a Vintage Sound.
MULTI TAP: A delay effect with changing stereo positioning
(left, center, right). Four variations are available.
CHORUS & REVERB: This algorithm combines the popular
chorus with a reverb effect. Taking all variations into account, they
differ in the length of reverb time.
FLANGER & REVERB: The combination of flanger and reverb
effects.
PHASER & REVERB: The combination of a classic stereo
phaser and a reverb effect. Here, too, the phaser is combined
with different reverb types.
ROTARY SPEAKER & REVERB: The combination of a rotary
speaker effect and reverb program.
DELAY & REVERB: Delay and reverb is the most common
combination for vocals, solo guitars, etc.
PITCH & REVERB: The pitch shifter slightly detunes the audio
signal, while the reverb adds ambience to the signal.
DELAY & CHORUS: Chorus can contribute to a wideness of
the signal and interesting repetition effects can be adjusted with
the delay. Vocals can be given a distinctive effect without making
the voice sounding blurred.
DELAY & FLANGER: This effect is just right for creating a
modern, slightly spacy vocal sound.
DELAY & PITCH: A repetition of the audio signal, with an
oscillatory effect added by the pitch shifter.
CHORUS: This effect slightly detunes the original signal. A very
pleasant detune effect is created in connection with the pitch
variation. The chorus effect is used often and quite extensively
used for dispersing signals. The variations available range from
slow to fast chorus effects.
SYMPHONIC: This effect creates the sound of an eight-voice
(!) vocal chorus.
FLANGER: The word flange means tape spool, and this
explains the characteristics of the effect. Originally, the flanger
effect was generated with two tape recorders which ran
synchronously. The same audio signal was recorded on both
machines. If you put a finger on the left spool of one of the
machines, the spool and the playback speed are slowed down.
The generated delay results in phase shifting of the signals.
Please choose either medium flanger or one of the bright
flanger programs, which feature an increase in presence.
3. DIGITAL EFFECTS PROCESSOR
7
EUROPOWER PMH660M/PMH880S
SPACE RADIO: Here, the typical sound of scanning an FM
tuner is simulated. This can be a very interesting effect when
sound-tracking radio plays.
TEST TONE: Use this 1-kHz test tone to facilitate P.A. level
setting.
4. INSTALLATION
4.1 Mains connection
Blown fuses must be replaced by fuses of the same type and
rating.
The mains connection is made using the enclosed power cord
and a standard IEC receptacle. It meets all of the international
safety certification requirements.
+ Please make sure that all units have a proper
ground connection. For your own safety, never
remove or disable the ground conductor from the
unit or of the AC power cord.
4.2 Audio connections
The inputs and outputs of the BEHRINGER EUROPOWER are
unbalanced 1/4" TS connectorsexcept for the balanced mono
line inputs. Of course, all inputs and outputs work with both
balanced and unbalanced connectors. The Tape Ins and Outs
are on stereo RCA connectors.
+ Please ensure that only qualified personnel install
and operate the power mixer. During installation
and operation, the user must have sufficient
electrical contact to earth. Electrostatic charges
might affect the operation of the unit.
8
4. INSTALLATION
EUROPOWER PMH660M/PMH880S
Fig. 4.6: Loudspeaker connector
Please be sure to only use commercial SPEAKON® cables (type
NL4FC) for connecting your loudspeakers to the mixer. Please
check the pin connections of your loudspeakers and cables
depending on the EUROPOWER speaker output you choose.
(85232:(530+6
287387$
0$,1/
021
287387%
287387%
0$,15
0212
%5,'*(
1+ 1- 2+ 2POS NEG - POS NEG - -
- - POS NEG
1+ 1- 2+ 2POS NEG - POS NEG - POS - NEG -
287387$
0$,10212
021
%5,'*(
287387%
0$,10212
0$,1
%5,'*(
(85232:(530+0
1+ 1- 2+ 2POS NEG - POS NEG - -
----
1+ 1- 2+ 2POS NEG - POS NEG - POS - NEG -
4. INSTALLATION
9
EUROPOWER PMH660M/PMH880S
5. WIRING EXAMPLES
For stereo operation the POWER AMP switch of the
PMH880S must be set to its upper position (MAIN L/MAIN R). Outputs
A and B deliver the stereo main signal to the P.A. speakers. Two
active speakers, wired in parallel, are connected to the PREAMP
MONITOR output. They are used as on-stage monitor speakers.
The effects processors can be switched on and off with a dual
footswitch. This set-up is not possible with the PMH660M (no
stereo operation possible).
10
EUROPOWER PMH660M/PMH880S
This illustration shows just one example of how the channels
of your power mixer can be used, including the connection of
mono and stereo sources, and the tape ins and outs recording
the mix signal or playing back external signals.
11
EUROPOWER PMH660M/PMH880S
Type
Mic E.I.N. (20 Hz - 20 k Hz)
@ 0 Ω source resistance
@ 50 Ω source resist ance
@ 150
source resistance
Gain
Max. input level
Impedance
Signal-to-noise ratio
Noise (THD + N)
Type
Impedance
Max. input level
Type-1/4" TRS connectors, unbalanced
Impedance
-
approx. 100
k
unbalanced
Max. input level
-
+21 dBu
Low
Mid
High
Type
Impedance
MAIN
Type
Impedance
Max. output level
MONITOR
Type
Impedance
Max. output level
Type-1/4" TRS connectors, unbalanced
Impedance
-
approx. 150
unbalanced
Max. input level
-
+21 dBu
Type
RCA, mono output
RCA
Impedance
approx. 1
kΩapprox. 1
k
Max. input level
+21 dBu
+21 dBu
Noise
MAIN MIX @ -oo
Channel fader -oo
MAIN MIX @ 0 dB
Channel fader -oo
MAIN MIX @ 0 dB
Channel fader @ 0 dB
Type
Load impedance
MAIN L/R
-
4 - 8
MONITOR/MAIN MONO
MAIN MONO/MA IN MONO
BRIDGE
Converter
Dynamics D/A
Sampling rate
Delay Time
Signal run time (Line In > Line Out)
Type
2-digit, 7-segment LED
2 x 2-digit, 7-segment LED
Output power @ 4
2 x 300 W
2 x 400 W
Output power @ 8
2 x 150 W
2 x 200 W
Output power @ 8
(
BRIDGE)
1 x 600 W
1 x 800 W
Mains voltage
Power consumption
500 W
700 W
Fuse
250 V
250 V
Mains connect or
8.5 kg
9.4 kg
18.74 lb.
20.73 lb.
NEUTRIK
®
SPEAKON
®
-compatible
6. SPECIFICATIONS
0,&523+21(,13876
Ω
Frequency response
0212/,1(,13876
67(5(2/,1(,13876
(48$/,=(5
75$&.,1387
35($032873876
67(5(2287 3 876
30+0 30+6
XLR, electronically balanced input circ ui t
-112 dB / 114 dB A-weighted
-112 dB / 114 dB A-weighted
-112 dB / 114 dB A-weighted
< 10 Hz - 200 kHz (-1 dB)
< 10 Hz - > 200 kHz (-3 dB)
+30 dB, +10 dB with pad
approx. 2.2 kΩ balanced / 1.1 kΩ unbalanced
110 dB / 114 dB A-weighted (0 dBu In @ +10 dB gain)
+12 dBu @ +10 dB gain
0.001% / 0.0007% A-weighted
1/4" TS connectors, balanced
approx. 20 k
1/4" TS connec tors, unbalanced
approx. 150
1/4" TS connec tors, unbalanced
approx. 150 Ω, unbalanced
Ω,
balanced
+21 dBu
80 Hz / +/-15 dB
2.5 kHz / +/-15 dB
12 kHz / +/-15 dB
RCA
approx. 10 kΩ
Ω,
unbalanced
+21 dBu
+21 dBu
Ω,
Ω,
Ω
0$,10,;6<67(0'$7$
-102 dB/-106 dB A-weigh ted
-88 dB/-91 dB A-weighted
-84 dB/-86 dB A-weighted
/28'63($.(52873876
Ω
4 - 8
Ω
4 - 8
Ω
'63
',63/$<
$03/,),(5
Ω
Ω
32:(56833/<
',0(16,216:(,*+7
Dimensions (H x W x D)
Weight
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time to time to existing products without prior
notice. Specifications and appearance may differ from those listed or illustrated.
Ω
7$+
24-bit Delta-Sigma, 64/128-times oversampl ing
approx. 12 2/5" x 18 1/10" x 8 3/5"
approx. 315 mm x 460 mm x 220 m m
8 - 16
90 dB
46.875 kHz
max. 5 secs
approx. 1.5 msecs
Output power
85 - 250 V~, 50 / 60 Hz
IEC standard receptacle
Ω
7$+
12
6. SPECIFICATIONS
EUROPOWER PMH660M/PMH880S
7. WARRANTY
§ 1 WARRANTY CARD/ONLINE REGISTRATION
To be protected by the extended warranty, the buyer must
complete and return the enclosed warranty card within 14 days
of the date of purchase to BEHRINGER Spezielle Studiotechnik
GmbH, in accordance with the conditions stipulated in § 3. Failure
to return the card in due time (date as per postmark) will void any
extended warranty claims. Based on the conditions herein, the
buyer may also choose to use the online registration option via
the Internet (www.behringer.com or www.behringer.de).
§ 2 WARRANTY
1. BEHRINGER (BEHRINGER Spezielle Studiotechnik GmbH
including all BEHRINGER subsidiaries listed on the enclosed page,
except BEHRINGER Japan) warrants the mechanical and
electronic components of this product to be free of defects in
material and workmanship for a period of one (1) year* from the
original date of purchase, in accordance with the warranty
regulations described below. If the product shows any defects
within the specified warranty period that are not excluded from
this warranty as described under § 4, BEHRINGER shall, at its
discretion, either replace or repair the product using suitable
new or reconditioned parts. In the case that other parts are used
which constitute an improvement, BEHRINGER may, at its
discretion, charge the customer for the additional cost of these
parts.
2. If the warranty claim proves to be justified, the product will
be returned to the user freight prepaid.
3. Warranty claims other than those indicated above are
expressly excluded.
§ 3 RETURN AUTHORIZATION NUMBER
1. To obtain warranty service, the buyer (or his authorized
dealer) must call BEHRINGER (see enclosed list) during normal
business hours BEFORE returning the product. All inquiries must
be accompanied by a description of the problem. BEHRINGER
will then issue a return authorization number.
2. Subsequently, the product must be returned in its original
shipping carton, together with the return authorization number to
the address indicated by BEHRINGER.
3. Shipments without freight prepaid will not be accepted.
§ 4 WARRANTY REGULATIONS
1. Warranty services will be furnished only if the product is
accompanied by a copy of the original retail dealers invoice.
Any product deemed eligible for repair or replacement under the
terms of this warranty will be repaired or replaced.
2. If the product needs to be modified or adapted in order to
comply with applicable technical or safety standards on a national
or local level, in any country which is not the country for which
the product was originally developed and manufactured, this
modification/adaptation shall not be considered a defect in
materials or workmanship. The warranty does not cover any
such modification/adaptation, irrespective of whether it was
carried out properly or not. Under the terms of this warranty,
BEHRINGER shall not be held responsible for any cost resulting
from such a modification/adaptation.
3. Free inspections and maintenance/repair work are expressly
excluded from this warranty, in particular, if caused by improper
handling of the product by the user. This also applies to defects
caused by normal wear and tear, in particular, of faders,
crossfaders, potentiometers, keys/buttons, tubes, guitar strings,
illuminants and similar parts.
4. Damages/defects caused by the following conditions are
not covered by this warranty:
s improper handling, neglect or failure to operate the unit in
compliance with the instructions given in BEHRINGER user
or service manuals.
s connection or operation of the unit in any way that does not
comply with the technical or safety regulations applicable in
the country where the product is used.
s damages/defects caused by force majeure or any other
condition that is beyond the control of BEHRINGER.
5. Any repair or opening of the unit carried out by unauthorized
personnel (user included) will void the warranty.
6. If an inspection of the product by BEHRINGER shows that
the defect in question is not covered by the warranty, the
inspection costs are payable by the customer.
7. Products which do not meet the terms of this warranty will
be repaired exclusively at the buyers expense. BEHRINGER will
inform the buyer of any such circumstance. If the buyer fails to
submit a written repair order within 6 weeks after notification,
BEHRINGER will return the unit C.O.D. with a separate invoice
for freight and packing. Such costs will also be invoiced
separately when the buyer has sent in a written repair order.
§ 5 WARRANTY TRANSFERABILITY
This warranty is extended exclusively to the original buyer
(customer of retail dealer) and is not transferable to anyone
who may subsequently purchase this product. No other person
(retail dealer, etc.) shall be entitled to give any warranty promise
on behalf of BEHRINGER.
§ 6 CLAIM FOR DAMAGES
Failure of BEHRINGER to provide proper warranty service shall
not entitle the buyer to claim (consequential) damages. In no
event shall the liability of BEHRINGER exceed the invoiced value
of the product.
§ 7 OTHER WARRANTY RIGHTS AND NATIONAL LAW
1. This warranty does not exclude or limit the buyers statutory
rights provided by national law, in particular, any such rights
against the seller that arise from a legally effective purchase
contract.
2. The warranty regulations mentioned herein are applicable
unless they constitute an infringement of national warranty law.
* Customers in the European Union please contact BEHRINGER
Germany Support for further details.
Technical specifications and appearance subject to change without notice. The information contained herein is correct at the time of printing. The names
of companies, institutions or publications pictured or mentioned and their respective logos are registered trademarks of their respective owners. Their use
neither constitutes a claim of the trademarks by BEHRINGER® nor affiliation of the trademark owners with BEHRINGER®. BEHRINGER® accepts no
liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained
herein. Colours and specification may vary slightly from product. Products are sold through our authorised dealers only. Distributors and dealers are not
agents of BEHRINGER® and have absolutely no authority to bind BEHRINGER® by any express or implied undertaking or representation. No part of this
manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for
any purpose, without the express written permission of BEHRINGER Spezielle Studiotechnik GmbH. BEHRINGER® is a registered trademark.
ALL RIGHTS RESERVED. © 2004 BEHRINGER Spezielle Studiotechnik GmbH,
Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide II, Germany.
Tel. +49 2154 9206 0, Fax +49 2154 9206 4903
7. WARRANTY
13
Loading...
