EUROLIVE P1020/P1220/P1220F/P1520/P2520/P1800S

User manual

Version 1.0 December 2006

EUROLIVE P1020/P1220/P1220F/P1520/P2520/P1800S

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5)Do not use this apparatus near water.

6)Clean only with a dry cloth.

7)Be sure to mount your speakers on a solid, stable and level base or stand. Vibrating floors do not provide reliable support for speaker enclosures or stacks.

8)Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9)Only use attachments/accessories specified by the manufacturer.

10)Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over.

11)Refer all servicing to qualified service personnel. Servicing is required when the unit has been damaged in any way, liquid has been spilled or objects have fallen into the device, the unit has been exposed to rain or moisture, does not operate normally, or has been dropped.

12)Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

2

EUROLIVE P1020/P1220/P1220F/P1520/P2520/P1800S

FOREWORD

Dear Customer,

Welcome to the team of BEHRINGER users, and thank you very much for expressing your confidence in us by purchasing this PA loudspeaker.

Writing this foreword for you gives me great pleasure, because it represents the culmination of many months of hard work delivered by our engineering team to achieve a very ambitious goal: to develop an outstanding PA system that offers a maximum in flexibility and

performance through its impressive sound character and outstanding features. The task of designing our new P Series certainly meant a great deal of responsibility, which we assumed by focusing on you, the discerning user and musician. Meeting your expectations also meant a lot of work and night shifts. But it was fun, too. Developing a product usually brings a lot of people together, and what a great feeling it is when all who participated in such a project can be proud of what they’ve achieved.

It is our philosophy to share our enjoyment with you, because you are the most important member of the BEHRINGER team. With your highly competent suggestions for new products you’ve made a significant contribution to shaping our company and making it successful. In return, we guarantee you uncompromising quality as well as excellent technical and audio properties at an extremely reasonable price. All of this will enable you to give free rein to your creativity without being hampered by budget constraints.

We are often asked how we manage to produce such highquality devices at such unbelievably low prices. The answer is quite simple: it’s you, our customers! Many satisfied customers mean large sales volumes enabling us to get better purchasing terms for components, etc. Isn’t it only fair to pass this benefit on to you? Because we know that your success is our success too!

I would like to thank all of you who have made the P Series possible. You have all made your own personal contributions, from the developers and the many other employees at this company, to you, the BEHRINGER user.

My friends, it’s been worth the effort!

Thank you very much,

Uli Behringer

TABLE OF CONTENTS

1. INTRODUCTION .........................................................

4

1.1

Before you get started ...................................................

4



1.1.1

Shipment ...............................................................

4



1.1.2

Online registration ................................................

4

2. CONNECTIONS ..........................................................

4

3. POWERAMP RATING ................................................

5

4. WIRING

.......................................................................

5

4.1

Full-range stereo operation ............................................

5

4.2

Two- ..............way stereo operation with subwoofers

5

5. SPECIFICATIONS .......................................................

6

6. WARRANTY ................................................................

7

ATTENTION!

+This loudspeaker is capable of producing extreme volumes. Please bear in mind that high sound pressures do not only temporarily damage your hearing, but can also cause permanent damage. Always make sure to select an appropriate volume.

3
