Behringer GDI21 Product Information

Product Information Document

Guitar Stompboxes

V-TONEGUITARDRIVERDI
GDI21

Guitar Amp Modeler/
Direct Recording Preamp/DI Box

Analog guitar modeling preamp/

#

stompbox with DI recording output

This BEHRINGER product has been

#

designed to compete head to head
with leading products on the market

Authentic V-TONE modeling

#

technology for 3 classic guitar amps,
3 gain modes and 3 mic placements
for a total of 27 con gurations.
Easilyachieve the most sought­after tube amp sounds from clean,
crunchto super-fat distortion

Provides a truckload of great amps

#

in a single stomp box—simply
choose your favourite sounds with a
 ick of a switch

Precise level and drive control

#

plus musical 2-band EQ for
ultimatesound

Dual DI mode for either direct

#

recording output with speaker
simulation or standard active direct
injection box in bypass mode

Output available on ¼'' TS

#

or balanced, gold-plated
XLRconnectors

Ground lift switch eliminates typical

#

ground loop problems

Our authentic V-TONE modeling

technology recreates 3 of the most

sought-after classic guitar amps, with

3 gain modes and 3 mic placements for

a total of 27 possible con gurations.

You get a truckload of great amps in

one convenient stomp box, allowing

you to go from clean or crunch to

super-fat distortion in a  ash. And if

you don’t want to use the emulation

feature, just step on the switch and the GDI21 functions as a superb active

DI box.

cone, for more upper mids and beefy low-end

3. (CLSIC)—Slightly in front of the cabinet, for high midrange content with tons
ofde nition

Extremely User-Friendly

Operation is simple; just choose the type
of amp, from the smooth Calif (Californian),
the bright, punchy Twed (Tweed), or the
Brit (British) with its incredible sustain
and aggressive mids. Then select the gain
mode, Cln (clean), Hot or Hi G (high gain).
Lastly, choose the mic placement from the
three available selections. This feature is a
BEHRINGER exclusive, allowing you to place
the “virtual mic” in any of three positions:

1. (OFF X)—At the edge of the speaker
cone, producing a smoother, softer sound
with less midrange content

2. (CNTR)—Positioned at the center of the

Product Information Document

20161075321.510.70.50.30.20.10.050.02

-15

-12

-9

-6

-3

0

3

6

9

12

15

Frequency (KHz)

Magnitude (dB)

Dynamic Microphone

Condenser Microphone

Guitar Stompboxes

V-TONEGUITARDRIVERDI
GDI21

Guitar Amp Modeler/
Direct Recording Preamp/DI Box

Runs on 9 V battery or the

#

BEHRINGER PSU-SB DC power supply
(not included)

High-quality components and

#

exceptionally rugged construction
ensure long life

3-Year Warranty Program*

#

Conceived and designed by

#

BEHRINGER Germany

It’s a Tone Thing

We’ve also included a dedicated Drive control,
for adjusting the amount of gain. This control
e ectively mimics the amount of push applied
to the output stage of a tube ampli er, from
a gentle nudge to full-out, tube-melting
overdrive. Further tone shaping is provided by
a highly musical 2-band EQ.

*Warrant y details can be fo und at music-group.c om.

Versatility

The GDI21 can be used for direct recording output, with speaker simulation or, when used
in bypass mode, as a superb active DI box. A ¼ " output jack is provided for connecting to
your amp and the gold-plated, balanced XLR connector will link you cleanly to the front
of house console. Ground loop problems are nonexistent, thanks to the onboard ground
liftswitch.

2 of 6
