Introduction
ATmega164P/V/324P/V/644P/V
megaAVR® Data Sheet
The ATmega164P/V/324P/V/644P/V is a low power, CMOS 8-bit microcontrollers based on the AVR
enhanced RISC architecture. The ATmega164P/V/324P/V/644P/V is a 40/44-pins device ranging from
16 KB to 64 KB Flash, with 1 KB to 4 KB SRAM, 512 Bytes to 2 KB EEPROM. By executing instructions in
a single clock cycle, the devices achieve CPU throughput approaching one million instructions per second
(MIPS) per megahertz, allowing the system designer to optimize power consumption versus processing
speed.
Features
High-performance, Low-power AVR
Advanced RISC Architecture
131 Powerful Instructions – Most Single-clock Cycle Execution
32 × 8 General Purpose Working Registers
Fully Static Operation
Up to 20 MIPS Throughput at 20 MHz
On-chip 2-cycle Multiplier
High Endurance Non-volatile Memory segments
16K/32K/64K Bytes of In-System Self-programmable Flash program memory
512B/1K/2K Bytes EEPROM
1K/2K/4K Bytes Internal SRAM
Write/Erase Cycles: 10,000 Flash/ 100,000 EEPROM
Data retention: 20 years at 85C/100 years at 25C
Optional Boot Code Section with Independent Lock Bits
In-System Programming by On-chip Boot Program
®
8-bit Microcontroller
(1)
®
True Read-While-Write Operation
Programming Lock for Software Security
JTAG (IEEE std. 1149.1 Compliant) Interface
Boundary-scan Capabilities According to the JTAG Standard
Extensive On-chip Debug Support
Programming of Flash, EEPROM, Fuses, and Lock Bits through the JTAG Interface
Peripheral Features
Two 8-bit Timer/Counters with Separate Prescalers and Compare Modes
One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture Mode
Real Time Counter with Separate Oscillator
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 1
ATmega164P/V/324P/V/644P/V
Six PWM Channels
8-channel, 10-bit ADC
Differential mode with selectable gain at 1×, 10× or 200×
Byte-oriented Two-wire Serial Interface
Two Programmable Serial USART
Master/Slave SPI Serial Interface
Programmable Watchdog Timer with Separate On-chip Oscillator
On-chip Analog Comparator
Interrupt and Wake-up on Pin Change
Special Microcontroller Features
Power-on Reset and Programmable Brown-out Detection
Internal Calibrated RC Oscillator
External and Internal Interrupt Sources
Six Sleep Modes: Idle, ADC Noise Reduction, Power-save, Power-down, Standby and Extended Standby
I/O and Packages
32 Programmable I/O Lines
40-pin PDIP, 44-lead TQFP, 44-pad VQFN/QFN/MLF (ATmega164P/324P/644P)
44-pad DRQFN (ATmega164P)
Operating Voltages
1.8V - 5.5V for ATmega164PV/324PV/644PV
2.7V - 5.5V for ATmega164P/324P/644P
Speed Grades
ATmega164PV/324PV/644PV: 0 - 4 MHz @ 1.8V - 5.5V, 0 - 10 MHz @ 2.7V - 5.5V
ATmega164P/324P/644P: 0 - 10 MHz @ 2.7V - 5.5V, 0 - 20 MHz @ 4.5V - 5.5V
Power Consumption at 1 MHz, 1.8V, 25°C for ATmega164PV/324PV/644PV
Active: 0.4 mA
Power-down Mode: 0.1 µA
Power-save Mode: 0.6 µA (Including 32 kHz RTC)
Note: 1. See “Data Retention” on page 16.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 2
ATmega164P/V/324P/V/644P/V
Table of Contents
1 Pin Configurations .............................................................................................................. 11
1.1 Pinout - PDIP/TQFP/VQFN/QFN/MLF ............................................................ 11
2Overview .................................................................................................................................... 12
2.1 Block Diagram ................................................................................................. 12
2.2 Comparison Between ATmega164P, ATmega324P and ATmega644P ......... 13
2.3 Pin Descriptions............................................................................................... 14
3 About ........................................................................................................................................... 16
3.1 Resources ....................................................................................................... 16
3.2 About Code Examples..................................................................................... 16
3.3 Data Retention................................................................................................. 16
4 AVR CPU Core ....................................................................................................................... 17
4.1 Overview.......................................................................................................... 17
4.2 ALU – Arithmetic Logic Unit............................................................................. 18
4.3 Status Register ................................................................................................ 18
4.4 General Purpose Register File ........................................................................ 19
4.5 Stack Pointer ................................................................................................... 21
4.6 Instruction Execution Timing ........................................................................... 22
4.7 Reset and Interrupt Handling........................................................................... 23
5 AVR Memories ....................................................................................................................... 26
5.1 Overview.......................................................................................................... 26
5.2 In-System Reprogrammable Flash Program Memory ..................................... 26
5.3 SRAM Data Memory........................................................................................ 27
5.4 EEPROM Data Memory .................................................................................. 29
5.5 I/O Memory...................................................................................................... 30
5.6 Register Description ........................................................................................ 31
6 System Clock and Clock Options .............................................................................. 36
6.1 Clock Systems and their Distribution............................................................... 36
6.2 Clock Sources ................................................................................................. 37
6.3 Low Power Crystal Oscillator........................................................................... 39
6.4 Full Swing Crystal Oscillator ............................................................................ 40
6.5 Low Frequency Crystal Oscillator .................................................................... 41
6.6 Calibrated Internal RC Oscillator ..................................................................... 43
6.7 128 kHz Internal Oscillator .............................................................................. 44
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 3
ATmega164P/V/324P/V/644P/V
6.8 External Clock ................................................................................................. 44
6.9 Timer/Counter Oscillator.................................................................................. 45
6.10 Clock Output Buffer ......................................................................................... 45
6.11 System Clock Prescaler .................................................................................. 45
6.12 Register Description ........................................................................................ 47
7 Power Management and Sleep Modes ................................................................... 49
7.1 Overview.......................................................................................................... 49
7.2 Sleep Modes.................................................................................................... 49
7.3 BOD Disable.................................................................................................... 50
7.4 Idle Mode......................................................................................................... 50
7.5 ADC Noise Reduction Mode............................................................................ 50
7.6 Power-down Mode........................................................................................... 51
7.7 Power-save Mode............................................................................................ 51
7.8 Standby Mode ................................................................................................. 51
7.9 Extended Standby Mode ................................................................................. 51
7.10 Power Reduction Register ............................................................................... 52
7.11 Minimizing Power Consumption ...................................................................... 52
7.12 Register Description ........................................................................................ 54
8 System Control and Reset ............................................................................................. 57
8.1 Resetting the AVR ........................................................................................... 57
8.2 Reset Sources ................................................................................................. 57
8.3 Power-on Reset............................................................................................... 58
8.4 External Reset ................................................................................................. 59
8.5 Brown-out Detection ........................................................................................ 60
8.6 Watchdog Reset .............................................................................................. 60
8.7 Internal Voltage Reference.............................................................................. 61
8.8 Watchdog Timer .............................................................................................. 62
8.9 Register Description ........................................................................................ 65
9 Interrupts ................................................................................................................................... 68
9.1 Overview.......................................................................................................... 68
9.2 Interrupt Vectors in ATmega164P/324P/644P ................................................ 68
9.3 Register Description ........................................................................................ 72
10 External Interrupts .............................................................................................................. 74
10.1 Overview.......................................................................................................... 74
10.2 Register Description ........................................................................................ 74
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 4
ATmega164P/V/324P/V/644P/V
11 I/O-Ports ..................................................................................................................................... 79
11.1 Overview.......................................................................................................... 79
11.2 Ports as General Digital I/O ............................................................................. 80
11.3 Alternate Port Functions .................................................................................. 85
11.4 Register Description ........................................................................................ 98
12 8-bit Timer/Counter0 with PWM ................................................................................ 100
12.1 Features ........................................................................................................ 100
12.2 Overview........................................................................................................ 100
12.3 Timer/Counter Clock Sources ....................................................................... 101
12.4 Counter Unit .................................................................................................. 101
12.5 Output Compare Unit..................................................................................... 102
12.6 Compare Match Output Unit .......................................................................... 103
12.7 Modes of Operation ....................................................................................... 104
12.8 Timer/Counter Timing Diagrams ................................................................... 108
12.9 Register Description ...................................................................................... 110
13 16-bit Timer/Counter1 with PWM ............................................................................. 117
13.1 Features ........................................................................................................ 117
13.2 Overview........................................................................................................ 117
13.3 Accessing 16-bit Registers ............................................................................ 119
13.4 Timer/Counter Clock Sources ....................................................................... 122
13.5 Counter Unit .................................................................................................. 122
13.6 Input Capture Unit ......................................................................................... 123
13.7 Output Compare Units ................................................................................... 125
13.8 Compare Match Output Unit .......................................................................... 128
13.9 Modes of Operation ....................................................................................... 129
13.10 Timer/Counter Timing Diagrams ................................................................... 136
13.11 Register Description ...................................................................................... 137
14 8-bit Timer/Counter2 with PWM and Asynchronous Operation ........... 145
14.1 Features ........................................................................................................ 145
14.2 Overview........................................................................................................ 145
14.3 Timer/Counter Clock Sources ....................................................................... 146
14.4 Counter Unit .................................................................................................. 147
14.5 Output Compare Unit..................................................................................... 147
14.6 Compare Match Output Unit .......................................................................... 149
14.7 Modes of Operation ....................................................................................... 150
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 5
ATmega164P/V/324P/V/644P/V
14.8 Timer/Counter Timing Diagrams ................................................................... 154
14.9 Asynchronous Operation of Timer/Counter2 ................................................. 155
14.10 Timer/Counter Prescaler ............................................................................... 157
14.11 Register Description ...................................................................................... 157
15 SPI – Serial Peripheral Interface ............................................................................... 165
15.1 Features ........................................................................................................ 165
15.2 Overview........................................................................................................ 165
15.3 SS Pin Functionality ...................................................................................... 169
15.4 Data Modes ................................................................................................... 169
15.5 Register Description ...................................................................................... 171
16 USART ...................................................................................................................................... 174
16.1 Features ........................................................................................................ 174
16.2 USART1 and USART0 .................................................................................. 174
16.3 Overview........................................................................................................ 174
16.4 Clock Generation........................................................................................... 175
16.5 Frame Formats .............................................................................................. 178
16.6 USART Initialization....................................................................................... 179
16.7 Data Transmission – The USART Transmitter .............................................. 180
16.8 Data Reception – The USART Receiver ....................................................... 183
16.9 Asynchronous Data Reception ...................................................................... 187
16.10 Multi-processor Communication Mode .......................................................... 190
16.11 Register Description ...................................................................................... 192
16.12 Examples of Baud Rate Setting..................................................................... 197
17 USART in SPI Mode .......................................................................................................... 201
17.1 Features ........................................................................................................ 201
17.2 Overview........................................................................................................ 201
17.3 Clock Generation........................................................................................... 201
17.4 SPI Data Modes and Timing.......................................................................... 202
17.5 Frame Formats .............................................................................................. 202
17.6 Data Transfer................................................................................................. 204
17.7 AVR USART MSPIM vs. AVR SPI ................................................................ 206
17.8 Register Description ...................................................................................... 207
18 2-wire Serial Interface ..................................................................................................... 210
18.1 Features ........................................................................................................ 210
18.2 2-wire Serial Interface Bus Definition ............................................................ 210
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 6
ATmega164P/V/324P/V/644P/V
18.3 Data Transfer and Frame Format .................................................................. 211
18.4 Multi-master Bus Systems, Arbitration and Synchronization ......................... 213
18.5 Overview of the TWI Module ......................................................................... 216
18.6 Using the TWI................................................................................................ 218
18.7 Transmission Modes ..................................................................................... 221
18.8 Multi-master Systems and Arbitration............................................................ 233
18.9 Register Description ...................................................................................... 234
19 AC - Analog Comparator ............................................................................................... 238
19.1 Overview........................................................................................................ 238
19.2 Analog Comparator Multiplexed Input ........................................................... 238
19.3 Register Description ...................................................................................... 239
20 ADC - Analog-to-digital Converter .......................................................................... 241
20.1 Features ........................................................................................................ 241
20.2 Overview........................................................................................................ 241
20.3 Operation....................................................................................................... 242
20.4 Starting a Conversion .................................................................................... 243
20.5 Prescaling and Conversion Timing................................................................ 244
20.6 Changing Channel or Reference Selection ................................................... 247
20.7 ADC Noise Canceler ..................................................................................... 248
20.8 ADC Conversion Result................................................................................. 253
20.9 Register Description ...................................................................................... 255
21 JTAG Interface and On-chip Debug System ..................................................... 260
21.1 Features ........................................................................................................ 260
21.2 Overview........................................................................................................ 260
21.3 TAP – Test Access Port ................................................................................ 260
21.4 TAP Controller ............................................................................................... 262
21.5 Using the Boundary-scan Chain .................................................................... 263
21.6 Using the On-chip Debug System ................................................................. 263
21.7 On-chip Debug Specific JTAG Instructions ................................................... 264
21.8 Using the JTAG Programming Capabilities ................................................... 264
21.9 Bibliography................................................................................................... 265
21.10 Register Description ...................................................................................... 265
22 IEEE 1149.1 (JTAG) Boundary-scan ...................................................................... 266
22.1 Features ........................................................................................................ 266
22.2 Overview........................................................................................................ 266
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 7
ATmega164P/V/324P/V/644P/V
22.3 Data Registers ............................................................................................... 267
22.4 Boundary-scan Specific JTAG Instructions ................................................... 268
22.5 Boundary-scan Chain .................................................................................... 269
22.6 ATmega164P/324P/644P Boundary-scan Order .......................................... 272
22.7 Boundary-scan Description Language Files .................................................. 273
22.8 Register Description ...................................................................................... 274
23 Boot Loader Support – Read-While-Write Self-Programming ............... 275
23.1 Features ........................................................................................................ 275
23.2 Overview........................................................................................................ 275
23.3 Application and Boot Loader Flash Sections ................................................. 275
23.4 Read-While-Write and No Read-While-Write Flash Sections........................ 276
23.5 Boot Loader Lock Bits ................................................................................... 278
23.6 Entering the Boot Loader Program................................................................ 279
23.7 Addressing the Flash During Self-Programming ........................................... 280
23.8 Self-Programming the Flash.......................................................................... 280
23.9 Register Description ...................................................................................... 290
24 Memory Programming .................................................................................................... 292
24.1 Program And Data Memory Lock Bits ........................................................... 292
24.2 Fuse Bits........................................................................................................ 293
24.3 Signature Bytes ............................................................................................. 295
24.4 Calibration Byte ............................................................................................. 295
24.5 Page Size ...................................................................................................... 295
24.6 Parallel Programming Parameters, Pin Mapping, and Commands ............... 295
24.7 Parallel Programming .................................................................................... 298
24.8 Serial Downloading........................................................................................ 306
24.9 Serial Programming Instruction set ............................................................... 308
24.10 Programming via the JTAG Interface ............................................................ 310
25 Electrical Characteristics – TA = -40°C to 85°C .............................................. 322
25.1 DC Characteristics......................................................................................... 322
25.2 Speed Grades ............................................................................................... 326
25.3 Clock Characteristics ..................................................................................... 327
25.4 System and Reset Characteristics ................................................................ 328
25.5 External Interrupts Characteristics ................................................................ 328
25.6 SPI Timing Characteristics ............................................................................ 329
25.7 2-wire Serial Interface Characteristics ........................................................... 330
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 8
ATmega164P/V/324P/V/644P/V
25.8 ADC Characteristics ...................................................................................... 332
26 Electrical Characteristics – TA = -40°C to 105°C ............................................ 335
26.1 DC Characteristics......................................................................................... 335
27 Typical Characteristics – TA = -40°C to 85°C ................................................... 338
27.1 ATmega164P Typical Characterization ......................................................... 338
27.2 ATmega324P Typical Characteristics ........................................................... 363
27.3 ATmega644P Typical Characteristic ............................................................. 388
28 Typical Characteristics – TA = -40°C to 105°C ................................................ 413
28.1 ATmega164P Typical Characteristics ........................................................... 413
28.2 ATmega324P Typical Characteristics ........................................................... 434
28.3 ATmega644P Typical Characteristics ........................................................... 455
29 Register Summary ............................................................................................................. 476
30 Instruction Set Summary .............................................................................................. 480
31 Ordering Information ....................................................................................................... 483
31.1 ATmega164P................................................................................................. 483
31.2 ATmega324P................................................................................................. 484
31.3 ATmega644P................................................................................................. 485
32 Packaging Information ................................................................................................... 486
32.1 44A ................................................................................................................ 486
32.2 40P6 .............................................................................................................. 487
32.3 44M1.............................................................................................................. 488
33 Errata ......................................................................................................................................... 489
33.1 ATmega164P................................................................................................. 489
33.2 ATmega324P................................................................................................. 489
33.3 ATmega644P................................................................................................. 489
34 Datasheet Revision History ......................................................................................... 490
34.1 Rev. A - 10/2018............................................................................................ 490
34.2 Rev. 8011R - 09/2015 ................................................................................... 490
34.3 Rev. 8011Q - 02/2013 ................................................................................... 490
34.4 Rev. 8011O - 07/10 ....................................................................................... 490
34.5 Rev. 8011N - 10/09 ....................................................................................... 490
34.6 Rev. 8011M - 08/09 ....................................................................................... 491
34.7 Rev. 8011L - 02/09 ........................................................................................ 491
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 9
ATmega164P/V/324P/V/644P/V
34.8 Rev. 8011K - 09/08........................................................................................ 491
34.9 Rev. 8011J - 09/08 ........................................................................................ 491
34.10 Rev. 8011I - 05/08 ......................................................................................... 491
34.11 Rev. 8011H - 04/08 ....................................................................................... 492
34.12 Rev. 8011G - 08/07 ....................................................................................... 492
34.13 Rev. 8011F - 04/07........................................................................................ 493
34.14 Rev. 8011E - 04/07........................................................................................ 493
34.15 Rev. 8011D - 02/07 ....................................................................................... 493
34.16 Rev. 8011C - 10/06 ....................................................................................... 493
34.17 Rev. 8011B - 09/06........................................................................................ 493
34.18 Rev. 8011A - 08/06........................................................................................ 493
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 10
1. Pin Configurations
1.1 Pinout - PDIP/TQFP/VQFN/QFN/MLF
Figure 1-1. Pinout ATmega164P/324P/644P
ATmega164P/V/324P/V/644P/V
PDIP
(PCINT8/XCK0/T0) PB0
(PCINT9/CLKO/T1) PB1
(PCINT10/INT2/AIN0) PB2
(PCINT11/OC0A/AIN1) PB3
(PCINT12/OC0B/SS) PB4
(PCINT13/MOSI) PB5
(PCINT14/MISO) PB6
(PCINT15/SCK) PB7
RESET
VCC
GND
XTAL2
XTAL1
(PCINT24/RXD0) PD0
(PCINT25/TXD0) PD1
(PCINT26/RXD1/INT0) PD2
(PCINT27/TXD1/INT1) PD3
(PCINT28/XCK1/OC1B) PD4
(PCINT29/OC1A) PD5
(PCINT30/OC2B/ICP) PD6
TQFP/VQFN/QFN/MLF
PB4 (SS/OC0B/PCINT12)
PB3 (AIN1/OC0A/PCINT11)
PB2 (AIN0/INT2/PCINT10)
PB1 (T1/CLKO/PCINT9)
PB0 (XCK0/T0/PCINT8)
GND
VCC
PA0 (ADC0/PCINT0)
PA1 (ADC1/PCINT1)
PA0 (ADC0/PCINT0)
PA1 (ADC1/PCINT1)
PA2 (ADC2/PCINT2)
PA3 (ADC3/PCINT3)
PA4 (ADC4/PCINT4)
PA5 (ADC5/PCINT5)
PA6 (ADC6/PCINT6)
PA7 (ADC7/PCINT7)
AREF
GND
AVC C
PC7 (TOSC2/PCINT23)
PC6 (TOSC1/PCINT22)
PC5 (TDI/PCINT21)
PC4 (TDO/PCINT20)
PC3 (TMS/PCINT19)
PC2 (TCK/PCINT18)
PC1 (SDA/PCINT17)
PC0 (SCL/PCINT16)
PD7 (OC2A/PCINT31)
PA2 (ADC2/PCINT2)
PA3 (ADC3/PCINT3)
(PCINT13/MOSI) PB5
(PCINT14/MISO) PB6
(PCINT15/SCK) PB7
RESET
VCC
GND
XTAL2
XTAL1
(PCINT24/RXD0) PD0
(PCINT25/TXD0) PD1
(PCINT26/RXD1/INT0) PD2
VCC
GND
(PCINT16/SCL) PC0
(PCINT29/OC1A) PD5
(PCINT31/OC2A) PD7
(PCINT30/OC2B/ICP) PD6
(PCINT27/TXD1/INT1) PD3
(PCINT28/XCK1/OC1B) PD4
(PCINT17/SDA) PC1
(PCINT18/TCK) PC2
PA4 (ADC4/PCINT4)
PA5 (ADC5/PCINT5)
PA6 (ADC6/PCINT6)
PA7 (ADC7/PCINT7)
AREF
GND
AVC C
PC7 (TOSC2/PCINT23)
PC6 (TOSC1/PCINT22)
PC5 (TDI/PCINT21)
PC4 (TDO/PCINT20)
(PCINT19/TMS) PC3
Note: The large center pad underneath the VQFN/QFN/MLF package should be soldered to ground on the board to
ensure good mechanical stability.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 11
2. Overview
CPU
GND
VCC
RESET
Power
Supervision
POR / BOD &
RESET
Watchdog
Oscillator
Watchdog
Timer
Oscillator
Circuits /
Clock
Generation
XTAL1
XTAL2
PORT A (8)
PORT D (8)
PD7..0
PORT C (8)
PC5..0
TWI
SPI
EEPROM
JTAG/OCD
16 bit T/C 1
8 bit T/C 2
8 bit T/C 0
SRAMFLASH
USART 0
Internal
Bandgap reference
Analog
Comparator
A/D
Converter
PA7..0
PORT B (8)
PB7..0
USART 1
TOSC1/PC6TOSC2/PC7
The ATmega164P/324P/644P is a low-power CMOS 8-bit microcontroller based on the AVR enhanced RISC
architecture. By executing powerful instructions in a single clock cycle, the ATmega164P/324P/644P achieves
throughputs approaching 1 MIPS per MHz allowing the system designer to optimize power consumption versus
processing speed.
2.1 Block Diagram
Figure 2-1. Block Diagram
ATmega164P/V/324P/V/644P/V
The AVR core combines a rich instruction set with 32 general purpose working registers. All the 32 registers are
directly connected to the Arithmetic Logic Unit (ALU), allowing two independent registers to be accessed in one
single instruction executed in one clock cycle. The resulting architecture is more code efficient while achieving
throughputs up to ten times faster than conventional CISC microcontrollers.
The ATmega164P/324P/644P provides the following features: 16K/32K/64K bytes of In-System Programmable
Flash with Read-While-Write capabilities, 512B/1K/2K bytes EEPROM, 1K/2K/4K bytes SRAM, 32 general
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 12
ATmega164P/V/324P/V/644P/V
purpose I/O lines, 32 general purpose working registers, Real Time Counter (RTC), three flexible
Timer/Counters with compare modes and PWM, 2 USARTs, a byte oriented 2-wire Serial Interface, a 8channel, 10-bit ADC with optional differential input stage with programmable gain, programmable Watchdog
Timer with Internal Oscillator, an SPI serial port, IEEE std. 1149.1 compliant JTAG test interface, also used for
accessing the On-chip Debug system and programming and six software selectable power saving modes. The
Idle mode stops the CPU while allowing the SRAM, Timer/Counters, SPI port, and interrupt system to continue
functioning. The Power-down mode saves the register contents but freezes the Oscillator, disabling all other
chip functions until the next interrupt or Hardware Reset. In Power-save mode, the asynchronous timer
continues to run, allowing the user to maintain a timer base while the rest of the device is sleeping. The ADC
Noise Reduction mode stops the CPU and all I/O modules except Asynchronous Timer and ADC, to minimize
switching noise during ADC conversions. In Standby mode, the Crystal/Resonator Oscillator is running while the
rest of the device is sleeping. This allows very fast start-up combined with low power consumption. In Extended
Standby mode, both the main Oscillator and the Asynchronous Timer continue to run.
The device is manufactured using high-density nonvolatile memory technology. The On-chip ISP Flash allows
the program memory to be reprogrammed in-system through an SPI serial interface, by a conventional
nonvolatile memory programmer, or by an On-chip Boot program running on the AVR core. The boot program
can use any interface to download the application program in the application Flash memory. Software in the
Boot Flash section will continue to run while the Application Flash section is updated, providing true ReadWhile-Write operation. By combining an 8-bit RISC CPU with In-System Self-Programmable Flash on a
monolithic chip, the ATmega164P/324P/644P is a powerful microcontroller that provides a highly flexible and
cost effective solution to many embedded control applications.
The ATmega164P/324P/644P AVR is supported with a full suite of program and system development tools
including: C compilers, macro assemblers, program debugger/simulators, in-circuit emulators, and evaluation
kits.
2.2 Comparison Between ATmega164P, ATmega324P and ATmega644P
Table 2-1. Differences between ATmega164P and ATmega644P
Device Flash EEPROM RAM
ATmega164P 16 Kbyte 512 Bytes 1 Kbyte
ATmega324P 32 Kbyte 1 Kbyte 2 Kbyte
ATmega644P 64 Kbyte 2 Kbyte 4 Kbyte
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 13
2.3 Pin Descriptions
2.3.1 VCC
Digital supply voltage.
2.3.2 GND
Ground.
2.3.3 Port A (PA7:PA0)
Port A serves as analog inputs to the Analog-to-digital Converter.
Port A also serves as an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The
Port A output buffers have symmetrical drive characteristics with both high sink and source capability. As inputs,
Port A pins that are externally pulled low will source current if the pull-up resistors are activated. The Port A pins
are tri-stated when a reset condition becomes active, even if the clock is not running.
Port A also serves the functions of various special features of the ATmega164P/324P/644P as listed on page
87.
ATmega164P/V/324P/V/644P/V
2.3.4 Port B (PB7:PB0)
Port B is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The Port B output
buffers have symmetrical drive characteristics with both high sink and source capability. As inputs, Port B pins
that are externally pulled low will source current if the pull-up resistors are activated. The Port B pins are tristated when a reset condition becomes active, even if the clock is not running.
Port B also serves the functions of various special features of the ATmega164P/324P/644P as listed on page
88.
2.3.5 Port C (PC7:PC0)
Port C is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The Port C output
buffers have symmetrical drive characteristics with both high sink and source capability. As inputs, Port C pins
that are externally pulled low will source current if the pull-up resistors are activated. The Port C pins are tristated when a reset condition becomes active, even if the clock is not running.
Port C also serves the functions of the JTAG interface, along with special features of the
ATmega164P/324P/644P as listed on page 91.
2.3.6 Port D (PD7:PD0)
Port D is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The Port D output
buffers have symmetrical drive characteristics with both high sink and source capability. As inputs, Port D pins
that are externally pulled low will source current if the pull-up resistors are activated. The Port D pins are tristated when a reset condition becomes active, even if the clock is not running.
2.3.7
Port D also serves the functions of various special features of the ATmega164P/324P/644P as listed on page
94.
RESET
Reset input. A low level on this pin for longer than the minimum pulse length will generate a reset, even if the
clock is not running. The minimum pulse length is given in ”System and Reset Characteristics” on page 328.
Shorter pulses are not ensured to generate a reset.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 14
2.3.8 XTAL1
Input to the inverting Oscillator amplifier and input to the internal clock operating circuit.
2.3.9 XTAL2
Output from the inverting Oscillator amplifier.
2.3.10 AVCC
AVCC is the supply voltage pin for Port A and the Analog-to-digital Converter. It should be externally connected
to V
CC
2.3.11 AREF
This is the analog reference pin for the Analog-to-digital Converter.
ATmega164P/V/324P/V/644P/V
, even if the ADC is not used. If the ADC is used, it should be connected to VCC through a low-pass filter.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 15
3. About
3.1 Resources
A comprehensive set of development tools, application notes and datasheets are available for download on
www.microchip.com.
3.2 About Code Examples
This documentation contains simple code examples that briefly show how to use various parts of the device. Be
aware that not all C compiler vendors include bit definitions in the header files and interrupt handling in C is
compiler dependent. Refer to the C compiler documentation for more details.
The code examples assume that the part specific header file is included before compilation. For I/O registers
located in extended I/O map, "IN", "OUT", "SBIS", "SBIC", "CBI", and "SBI" instructions must be replaced with
instructions that allow access to extended I/O. Typically "LDS" and "STS" combined with "SBRS", "SBRC",
"SBR", and "CBR".
3.3 Data Retention
ATmega164P/V/324P/V/644P/V
Reliability Qualification results show that the projected data retention failure rate is much less than 1 PPM over
20 years at 85°C or 100 years at 25°C.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 16
4. AVR CPU Core
Flash
Program
Memory
Instruction
Register
Instruction
Decoder
Program
Counter
Control Lines
32 x 8
General
Purpose
Registrers
ALU
Status
and Control
I/O Lines
EEPROM
Data Bus 8-bit
Data
SRAM
Direct Addressing
Indirect Addressing
Interrupt
Unit
SPI
Unit
Watchdog
Timer
Analog
Comparator
I/O Module 2
I/O Module1
I/O Module n
4.1 Overview
This section discusses the AVR core architecture in general. The main function of the CPU core is to ensure
correct program execution. The CPU must therefore be able to access memories, perform calculations, control
peripherals, and handle interrupts.
Figure 4-1. Block Diagram of the AVR Architecture
ATmega164P/V/324P/V/644P/V
In order to maximize performance and parallelism, the AVR uses a Harvard architecture – with separate
memories and buses for program and data. Instructions in the program memory are executed with a single level
pipelining. While one instruction is being executed, the next instruction is pre-fetched from the program memory.
This concept enables instructions to be executed in every clock cycle. The program memory is In-System
Reprogrammable Flash memory.
The fast-access Register File contains 32 × 8-bit general purpose working registers with a single clock cycle
access time. This allows single-cycle Arithmetic Logic Unit (ALU) operation. In a typical ALU operation, two
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 17
ATmega164P/V/324P/V/644P/V
operands are output from the Register File, the operation is executed, and the result is stored back in the
Register File – in one clock cycle.
Six of the 32 registers can be used as three 16-bit indirect address register pointers for Data Space addressing
– enabling efficient address calculations. One of the these address pointers can also be used as an address
pointer for look up tables in Flash program memory. These added function registers are the 16-bit X-, Y-, and Zregister, described later in this section.
The ALU supports arithmetic and logic operations between registers or between a constant and a register.
Single register operations can also be executed in the ALU. After an arithmetic operation, the Status Register is
updated to reflect information about the result of the operation.
Program flow is provided by conditional and unconditional jump and call instructions, able to directly address the
whole address space. Most AVR instructions have a single 16-bit word format. Every program memory address
contains a 16-bit or 32-bit instruction.
Program Flash memory space is divided in two sections, the Boot Program section and the Application Program
section. Both sections have dedicated Lock bits for write and read/write protection. The SPM instruction that
writes into the Application Flash memory section must reside in the Boot Program section.
During interrupts and subroutine calls, the return address Program Counter (PC) is stored on the Stack. The
Stack is effectively allocated in the general data SRAM, and consequently the Stack size is only limited by the
total SRAM size and the usage of the SRAM. All user programs must initialize the SP in the Reset routine
(before subroutines or interrupts are executed). The Stack Pointer (SP) is read/write accessible in the I/O space.
The data SRAM can easily be accessed through the five different addressing modes supported in the AVR
architecture.
The memory spaces in the AVR architecture are all linear and regular memory maps.
A flexible interrupt module has its control registers in the I/O space with an additional Global Interrupt Enable bit
in the Status Register. All interrupts have a separate Interrupt Vector in the Interrupt Vector table. The interrupts
have priority in accordance with their Interrupt Vector position. The lower the Interrupt Vector address, the
higher the priority.
The I/O memory space contains 64 addresses for CPU peripheral functions as Control Registers, SPI, and other
I/O functions. The I/O Memory can be accessed directly, or as the Data Space locations following those of the
Register File, 0x20 - 0x5F. In addition, the ATmega164P/324P/644P has Extended I/O space from 0x60 - 0xFF
in SRAM where only the ST/STS/STD and LD/LDS/LDD instructions can be used.
4.2 ALU – Arithmetic Logic Unit
The high-performance AVR ALU operates in direct connection with all the 32 general purpose working registers.
Within a single clock cycle, arithmetic operations between general purpose registers or between a register and
an immediate are executed. The ALU operations are divided into three main categories – arithmetic, logical, and
bit-functions. Some implementations of the architecture also provide a powerful multiplier supporting both
signed/unsigned multiplication and fractional format. See the “Instruction Set” section for a detailed description.
4.3 Status Register
The Status Register contains information about the result of the most recently executed arithmetic instruction.
This information can be used for altering program flow in order to perform conditional operations. Note that the
Status Register is updated after all ALU operations, as specified in the Instruction Set Reference. This will in
many cases remove the need for using the dedicated compare instructions, resulting in faster and more
compact code.
The Status Register is not automatically stored when entering an interrupt routine and restored when returning
from an interrupt. This must be handled by software.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 18
ATmega164P/V/324P/V/644P/V
4.3.1 SREG – Status Register
The AVR Status Register – SREG – is defined as:
Bit 76543210
0x3F (0x5F) I T H S V N Z C SREG
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
• Bit 7 – I: Global Interrupt Enable
The Global Interrupt Enable bit must be set for the interrupts to be enabled. The individual interrupt enable
control is then performed in separate control registers. If the Global Interrupt Enable Register is cleared, none of
the interrupts are enabled independent of the individual interrupt enable settings. The I-bit is cleared by
hardware after an interrupt has occurred, and is set by the RETI instruction to enable subsequent interrupts.
The I-bit can also be set and cleared by the application with the SEI and CLI instructions, as described in the
Instruction Set Manual on www.microchip.com.
• Bit 6 – T: Bit Copy Storage
The Bit Copy instructions BLD (Bit LoaD) and BST (Bit STore) use the T-bit as source or destination for the
operated bit. A bit from a register in the Register File can be copied into T by the BST instruction, and a bit in T
can be copied into a bit in a register in the Register File by the BLD instruction.
• Bit 5 – H: Half Carry Flag
The Half Carry Flag H indicates a Half Carry in some arithmetic operations. Half Carry Is useful in BCD
arithmetic.
(1)
• Bit 4 – S: Sign Bit, S = N
V
The S-bit is always an exclusive or between the Negative Flag N and the Two’s Complement Overflow Flag V.
• Bit 3 – V: Two’s Complement Overflow Flag
The Two’s Complement Overflow Flag V supports two’s complement arithmetic.
• Bit 2 – N: Negative Flag
The Negative Flag N indicates a negative result in an arithmetic or logic operation.
• Bit 1 – Z: Zero Flag
The Zero Flag Z indicates a zero result in an arithmetic or logic operation.
• Bit 0 – C: Carry Flag
The Carry Flag C indicates a carry in an arithmetic or logic operation.
Note: 1. Refer to the Instruction Set Manual on www.microchip.com for more details.
4.4 General Purpose Register File
The Register File is optimized for the AVR Enhanced RISC instruction set. In order to achieve the required
performance and flexibility, the following input/output schemes are supported by the Register File:
One 8-bit output operand and one 8-bit result input
Two 8-bit output operands and one 8-bit result input
Two 8-bit output operands and one 16-bit result input
One 16-bit output operand and one 16-bit result input
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 19
ATmega164P/V/324P/V/644P/V
Figure 4-2 shows the structure of the 32 general purpose working registers in the CPU.
Figure 4-2. AVR CPU General Purpose Working Registers
7 0 Addr.
R0 0x00
R1 0x01
R2 0x02
…
R13 0x0D
General R14 0x0E
Purpose R15 0x0F
Working R16 0x10
Registers R17 0x11
…
R26 0x1A X-register Low Byte
R27 0x1B X-register High Byte
R28 0x1C Y-register Low Byte
R29 0x1D Y-register High Byte
R30 0x1E Z-register Low Byte
R31 0x1F Z-register High Byte
Most of the instructions operating on the Register File have direct access to all registers, and most of them are
single cycle instructions.
As shown in Figure 4-2, each register is also assigned a data memory address, mapping them directly into the
first 32 locations of the user Data Space. Although not being physically implemented as SRAM locations, this
memory organization provides great flexibility in access of the registers, as the X-, Y- and Z-pointer registers
can be set to index any register in the file.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 20
4.4.1 The X-register, Y-register, and Z-register
The registers R26..R31 have some added functions to their general purpose usage. These registers are 16-bit
address pointers for indirect addressing of the data space. The three indirect address registers X, Y, and Z are
defined as described in Figure 4-3.
Figure 4-3. The X-, Y-, and Z-registers
15 XH XL 0
X-register 7 0 7 0
R27 (0x1B) R26 (0x1A)
15 YH YL 0
Y-register 7 0 7 0
R29 (0x1D) R28 (0x1C)
15 ZH ZL 0
Z-register 7 0 7 0
R31 (0x1F) R30 (0x1E)
In the different addressing modes these address registers have functions as fixed displacement, automatic
increment, and automatic decrement (see the instruction set reference for details).
ATmega164P/V/324P/V/644P/V
4.5 Stack Pointer
The Stack is mainly used for storing temporary data, for storing local variables and for storing return addresses
after interrupts and subroutine calls. Note that the Stack is implemented as growing from higher to lower
memory locations. The Stack Pointer Register always points to the top of the Stack. The Stack Pointer points to
the data SRAM Stack area where the Subroutine and Interrupt Stacks are located. A Stack PUSH command will
decrease the Stack Pointer.
The Stack in the data SRAM must be defined by the program before any subroutine calls are executed or
interrupts are enabled. Initial Stack Pointer value equals the last address of the internal SRAM and the Stack
Pointer must be set to point above start of the SRAM, see Figure 5-2 on page 28.
See Table 4-1 for Stack Pointer details.
Table 4-1. Stack Pointer instructions
Instruction Stack Pointer Description
PUSH Decremented by 1 Data is pushed onto the stack
CALL
ICALL
RCALL
POP Incremented by 1 Data is popped from the stack
RET
RETI
Decremented by 2 Return address is pushed onto the stack with a subroutine call or
Incremented by 2 Return address is popped from the stack with return from
interrupt
subroutine or return from interrupt
The AVR Stack Pointer is implemented as two 8-bit registers in the I/O space. The number of bits actually used
is implementation dependent, see Table 4-2 on page 22. Note that the data space in some implementations of
the AVR architecture is so small that only SPL is needed. In this case, the SPH Register will not be present.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 21
ATmega164P/V/324P/V/644P/V
4.5.1 SPH and SPL – Stack Pointer High and Stack pointer Low
Bit 151413121110 9 8
0x3E (0x5E) – – – SP12 SP11 SP10 SP9 SP8 SPH
0x3D (0x5D) SP7 SP6 SP5 SP4 SP3 SP2 SP1 SP0 SPL
76543210
Read/Write R R R R/W R/W R/W R/W R/W
R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0/0/1
11111111
Note: 1. Initial values respectively for the ATmega164P/324P/644P.
Table 4-2. Stack Pointer size
Device Stack Pointer size
ATmega164P SP[10:0]
ATmega324P SP[11:0]
ATmega644P SP[12:0]
(1)
0/1/0
(1)
1/0/0
(1)
00
4.5.2 RAMPZ – Extended Z-pointer Register for ELPM/SPM
Bit 765432 1 0
0x3B (0x5B)
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
RAMPZ7 RAMPZ6 RAMPZ5 RAMPZ4 RAMPZ3 RAMPZ2 RAMPZ1 RAMPZ0
For ELPM/SPM instructions, the Z-pointer is a concatenation of RAMPZ, ZH, and ZL, as shown in Figure 4-4.
Note that LPM is not affected by the RAMPZ setting.
Figure 4-4. The Z-pointer used by ELPM and SPM
Bit (Individually) 7 0 7 0 7 0
RAMPZ ZH ZL
Bit (Z-pointer) 23 16 15 8 7 0
The actual number of bits is implementation dependent. Unused bits in an implementation will always read as
zero. For compatibility with future devices, be sure to write these bits to zero.
4.6 Instruction Execution Timing
This section describes the general access timing concepts for instruction execution. The AVR CPU is driven by
the CPU clock clk
used.
Figure 4-5 on page 23 shows the parallel instruction fetches and instruction executions enabled by the Harvard
architecture and the fast-access Register File concept. This is the basic pipelining concept to obtain up to
1 MIPS per MHz with the corresponding unique results for functions per cost, functions per clocks, and functions
per power-unit.
, directly generated from the selected clock source for the chip. No internal clock division is
CPU
RAMPZ
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 22
ATmega164P/V/324P/V/644P/V
clk
1st Instruction Fetch
1st Instruction Execute
2nd Instruction Fetch
2nd Instruction Execute
3rd Instruction Fetch
3rd Instruction Execute
4th Instruction Fetch
T1 T2 T3 T4
CPU
Total Execution Time
Register Operands Fetch
ALU Operation Execute
Result Write Back
T1 T2 T3 T4
clk
CPU
Figure 4-5. The Parallel Instruction Fetches and Instruction Executions
Figure 4-6 shows the internal timing concept for the Register File. In a single clock cycle an ALU operation using
two register operands is executed, and the result is stored back to the destination register.
Figure 4-6. Single Cycle ALU Operation
4.7 Reset and Interrupt Handling
The AVR provides several different interrupt sources. These interrupts and the separate Reset Vector each
have a separate program vector in the program memory space. All interrupts are assigned individual enable bits
which must be written logic one together with the Global Interrupt Enable bit in the Status Register in order to
enable the interrupt. Depending on the Program Counter value, interrupts may be automatically disabled when
Boot Lock bits BLB02 or BLB12 are programmed. This feature improves software security. See the section
”Memory Programming” on page 292 for details.
The lowest addresses in the program memory space are by default defined as the Reset and Interrupt Vectors.
The complete list of vectors is shown in ”Interrupts” on page 68. The list also determines the priority levels of the
different interrupts. The lower the address the higher is the priority level. RESET has the highest priority, and
next is INT0 – the External Interrupt Request 0. The Interrupt Vectors can be moved to the start of the Boot
Flash section by setting the IVSEL bit in the MCU Control Register (MCUCR). Refer to ”Interrupts” on page 68
for more information. The Reset Vector can also be moved to the start of the Boot Flash section by
programming the BOOTRST Fuse, see ”Memory Programming” on page 292.
When an interrupt occurs, the Global Interrupt Enable I-bit is cleared and all interrupts are disabled. The user
software can write logic one to the I-bit to enable nested interrupts. All enabled interrupts can then interrupt the
current interrupt routine. The I-bit is automatically set when a Return from Interrupt instruction – RETI – is
executed.
There are basically two types of interrupts. The first type is triggered by an event that sets the Interrupt Flag. For
these interrupts, the Program Counter is vectored to the actual Interrupt Vector in order to execute the interrupt
handling routine, and hardware clears the corresponding Interrupt Flag. Interrupt Flags can also be cleared by
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 23
ATmega164P/V/324P/V/644P/V
writing a logic one to the flag bit position(s) to be cleared. If an interrupt condition occurs while the
corresponding interrupt enable bit is cleared, the Interrupt Flag will be set and remembered until the interrupt is
enabled, or the flag is cleared by software. Similarly, if one or more interrupt conditions occur while the Global
Interrupt Enable bit is cleared, the corresponding Interrupt Flag(s) will be set and remembered until the Global
Interrupt Enable bit is set, and will then be executed by order of priority.
The second type of interrupts will trigger as long as the interrupt condition is present. These interrupts do not
necessarily have Interrupt Flags. If the interrupt condition disappears before the interrupt is enabled, the
interrupt will not be triggered.
When the AVR exits from an interrupt, it will always return to the main program and execute one more
instruction before any pending interrupt is served.
Note that the Status Register is not automatically stored when entering an interrupt routine, nor restored when
returning from an interrupt routine. This must be handled by software.
When using the CLI instruction to disable interrupts, the interrupts will be immediately disabled. No interrupt will
be executed after the CLI instruction, even if it occurs simultaneously with the CLI instruction. The following
example shows how this can be used to avoid interrupts during the timed EEPROM write sequence.
Assembly Code Example
in r16, SREG ; store SREG
value
cli ; disable interrupts during timed
sequence
sbi EECR, EEMPE ; start
EEPROM write
sbi EECR, EEPE
out SREG, r16 ; restore
SREG value (I-bit)
C Code Example
char cSREG;
cSREG = SREG; /* store
SREG value */
/* disable interrupts during timed sequence */
__disable_interrupt();
EECR |= (1<<EEMPE); /* start EEPROM write */
EECR |= (1<<EEPE);
SREG = cSREG; /* restore SREG value (I-bit) */
When using the SEI instruction to enable interrupts, the instruction following SEI will be executed before any
pending interrupts, as shown in this example.
Assembly Code Example
sei ; set Global Interrupt Enable
sleep ; enter sleep, waiting for interrupt
; note: will enter sleep before any pending
; interrupt(s)
C Code Example
__enable_interrupt(); /* set Global Interrupt Enable */
__sleep(); /* enter sleep, waiting for interrupt */
/* note: will enter sleep before any pending interrupt(s) */
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 24
4.7.1 Interrupt Response Time
The interrupt execution response for all the enabled AVR interrupts is five clock cycles minimum. After five clock
cycles the program vector address for the actual interrupt handling routine is executed. During these five clock
cycle period, the Program Counter is pushed onto the Stack. The vector is normally a jump to the interrupt
routine, and this jump takes three clock cycles. If an interrupt occurs during execution of a multi-cycle
instruction, this instruction is completed before the interrupt is served. If an interrupt occurs when the MCU is in
sleep mode, the interrupt execution response time is increased by five clock cycles. This increase comes in
addition to the start-up time from the selected sleep mode.
A return from an interrupt handling routine takes five clock cycles. During these five clock cycles, the Program
Counter (three bytes) is popped back from the Stack, the Stack Pointer is incremented by three, and the I-bit in
SREG is set.
ATmega164P/V/324P/V/644P/V
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 25
ATmega164P/V/324P/V/644P/V
5. AVR Memories
5.1 Overview
This section describes the different memories in the ATmega164P/324P/644P. The AVR architecture has two
main memory spaces, the Data Memory and the Program Memory space. In addition, the
ATmega164P/324P/644P features an EEPROM Memory for data storage. All three memory spaces are linear
and regular.
5.2 In-System Reprogrammable Flash Program Memory
The ATmega164P/324P/644P contains 16K/32K/64K bytes On-chip In-System Reprogrammable Flash memory
for program storage. Since all AVR instructions are 16 bits or 32 bits wide, the Flash is organized as 32/64 x 16.
For software security, the Flash Program memory space is divided into two sections, Boot Program section and
Application Program section.
The Flash memory has an endurance of at least 10,000 write/erase cycles. The ATmega164P/324P/644P
Program Counter (PC) is 15/16 bits wide, thus addressing the 32/64K program memory locations. The operation
of Boot Program section and associated Boot Lock bits for software protection are described in detail in
”Memory Programming” on page 292. ”Memory Programming” on page 292 contains a detailed description on
Flash data serial downloading using the SPI pins or the JTAG interface.
Constant tables can be allocated within the entire program memory address space (see the LPM – Load
Program Memory instruction description.
Timing diagrams for instruction fetch and execution are presented in ”Instruction Execution Timing” on page 22.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 26
Figure 5-1. Program Memory Map
ATmega164P/V/324P/V/644P/V
Program Memory
0x0000
Application Flash Section
5.3 SRAM Data Memory
Figure 5-2 shows how the ATmega164P/324P/644P SRAM Memory is organized.
The ATmega164P/324P/644P is a complex microcontroller with more peripheral units than can be supported
within the 64 location reserved in the Opcode for the IN and OUT instructions. For the Extended I/O space from
$060 - $FF in SRAM, only the ST/STS/STD and LD/LDS/LDD instructions can be used.
The first 4,352 Data Memory locations address both the Register File, the I/O Memory, Extended I/O Memory,
and the internal data SRAM. The first 32 locations address the Register file, the next 64 location the standard
I/O Memory, then 160 locations of Extended I/O memory and the next 4,096 locations address the internal data
SRAM.
The five different addressing modes for the data memory cover: Direct, Indirect with Displacement, Indirect,
Indirect with Pre-decrement, and Indirect with Post-increment. In the Register file, registers R26 to R31 feature
the indirect addressing pointer registers.
The direct addressing reaches the entire data space.
The Indirect with Displacement mode reaches 63 address locations from the base address given by the Y- or Zregister.
When using register indirect addressing modes with automatic pre-decrement and post-increment, the address
registers X, Y, and Z are decremented or incremented.
The 32 general purpose working registers, 64 I/O registers, 160 Extended I/O Registers and the
1024/2048/4096 bytes of internal data SRAM in the ATmega164P/324P/644P are all accessible through all
these addressing modes. The Register File is described in ”General Purpose Register File” on page 19.
Boot Flash Section
0x1FFF
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 27
ATmega164P/V/324P/V/644P/V
F
Data Memory
clk
WR
RD
Data
Data
Address
Address valid
T1 T2 T3
Compute Address
Read
Write
CPU
Memory Access Instruction
Next Instruction
Figure 5-2. Data Memory Map for ATmega164P/324P/644P
5.3.1 Data Memory Access Times
This section describes the general access timing concepts for internal memory access. The internal data SRAM
access is performed in two clk
Figure 5-3. On-chip Data SRAM Access Cycles
32 Registers
64 I/O Registers
160 Ext I/O Reg.
0x0000 - 0x001F
0x0020 - 0x005F
0x0060 - 0x00FF
0x0100
Internal SRAM
(1024/2048/4096 x 8)
0x04FF/0x08FF/0x10F
cycles as described in Figure 5-3.
CPU
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 28
5.4 EEPROM Data Memory
The ATmega164P/324P/644P contains 512B/1K/2K bytes of data EEPROM memory. It is organized as a
separate data space, in which single bytes can be read and written. The EEPROM has an endurance of at least
100,000 write/erase cycles. The access between the EEPROM and the CPU is described in the following,
specifying the EEPROM Address Registers, the EEPROM Data Register, and the EEPROM Control Register.
For a detailed description of SPI, JTAG and Parallel data downloading to the EEPROM, see page 306, page
310, and page 295 respectively.
5.4.1 EEPROM Read/Write Access
The EEPROM Access Registers are accessible in the I/O space. See ”Register Description” on page 31 for
details.
The write access time for the EEPROM is given in Table 5-2 on page 33. A self-timing function, however, lets
the user software detect when the next byte can be written. If the user code contains instructions that write the
EEPROM, some precautions must be taken. In heavily filtered power supplies, V
on power-up/down. This causes the device for some period of time to run at a voltage lower than specified as
minimum for the clock frequency used. See Section “5.4.2” on page 29. for details on how to avoid problems in
these situations.
In order to prevent unintentional EEPROM writes, a specific write procedure must be followed. Refer to the
description of the EEPROM Control Register for details on this.
When the EEPROM is read, the CPU is halted for four clock cycles before the next instruction is executed.
When the EEPROM is written, the CPU is halted for two clock cycles before the next instruction is executed.
ATmega164P/V/324P/V/644P/V
is likely to rise or fall slowly
CC
5.4.2 Preventing EEPROM Corruption
During periods of low V
the EEPROM data can be corrupted because the supply voltage is too low for the
CC,
CPU and the EEPROM to operate properly. These issues are the same as for board level systems using
EEPROM, and the same design solutions should be applied.
An EEPROM data corruption can be caused by two situations when the voltage is too low. First, a regular write
sequence to the EEPROM requires a minimum voltage to operate correctly. Secondly, the CPU itself can
execute instructions incorrectly, if the supply voltage is too low.
EEPROM data corruption can easily be avoided by following this design recommendation:
Keep the AVR RESET active (low) during periods of insufficient power supply voltage. This can be done by
enabling the internal Brown-out Detector (BOD). If the detection level of the internal BOD does not match the
needed detection level, an external low V
operation is in progress, the write operation will be completed provided that the power supply voltage is
sufficient.
reset Protection circuit can be used. If a reset occurs while a write
CC
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 29
5.5 I/O Memory
The I/O space definition of the ATmega164P/324P/644P is shown in ”Register Summary” on page 476.
All ATmega164P/324P/644P I/Os and peripherals are placed in the I/O space. All I/O locations may be
accessed by the LD/LDS/LDD and ST/STS/STD instructions, transferring data between the 32 general purpose
working registers and the I/O space. I/O Registers within the address range 0x00 - 0x1F are directly bitaccessible using the SBI and CBI instructions. In these registers, the value of single bits can be checked by
using the SBIS and SBIC instructions. Refer to the instruction set section for more details. When using the I/O
specific commands IN and OUT, the I/O addresses 0x00 - 0x3F must be used. When addressing I/O Registers
as data space using LD and ST instructions, 0x20 must be added to these addresses. The
ATmega164P/324P/644P is a complex microcontroller with more peripheral units than can be supported within
the 64 location reserved in Opcode for the IN and OUT instructions. For the Extended I/O space from 0x60 0xFF in SRAM, only the ST/STS/STD and LD/LDS/LDD instructions can be used.
For compatibility with future devices, reserved bits should be written to zero if accessed. Reserved I/O memory
addresses should never be written.
Some of the Status Flags are cleared by writing a logical one to them. Note that, unlike most other AVRs, the
CBI and SBI instructions will only operate on the specified bit, and can therefore be used on registers containing
such Status Flags. The CBI and SBI instructions work with registers 0x00 to 0x1F only.
The I/O and peripherals control registers are explained in later sections.
ATmega164P/V/324P/V/644P/V
The ATmega164P/324P/644P contains three General Purpose I/O Registers, see ”Register Description” on
page 31. These registers can be used for storing any information, and they are particularly useful for storing
global variables and Status Flags. General Purpose I/O Registers within the address range 0x00 - 0x1F are
directly bit-accessible using the SBI, CBI, SBIS, and SBIC instructions.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 30
ATmega164P/V/324P/V/644P/V
5.6 Register Description
5.6.1 EEARH and EEARL – The EEPROM Address Register
Bit 15141312 11 10 9 8
0x22 (0x42) – – – – EEAR11 EEAR10 EEAR9 EEAR8 EEARH
0x21 (0x41) EEAR7 EEAR6 EEAR5 EEAR4 EEAR3 EEAR2 EEAR1 EEAR0 EEARL
7654 3 2 10
Read/Write R R R R R/W R/W R/W R/W
R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 X X X X
XXXXXXXX
• Bits 15:12 – Res: Reserved Bits
These bits are reserved bits in the ATmega164P/324P/644P and will always read as zero.
• Bits 11:0 – EEAR8:0: EEPROM Address
The EEPROM Address Registers – EEARH and EEARL specify the EEPROM address in the 4K bytes
EEPROM space. The EEPROM data bytes are addressed linearly between 0 and 4096. The initial value of
EEAR is undefined. A proper value must be written before the EEPROM may be accessed.
5.6.2 EEDR – The EEPROM Data Register
Bit 76543210
0x20 (0x40) MSB LSB EEDR
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
• Bits 7:0 – EEDR7:0: EEPROM Data
For the EEPROM write operation, the EEDR Register contains the data to be written to the EEPROM in the
address given by the EEAR Register. For the EEPROM read operation, the EEDR contains the data read out
from the EEPROM at the address given by EEAR.
5.6.3 EECR – The EEPROM Control Register
Bit 76543 2 10
0x1F (0x3F) – – EEPM1 EEPM0 EERIE EEMPE EEPE EERE EECR
Read/Write R R R/W R/W R/W R/W R/W R/W
Initial Value 0 0 X X 0 0 X 0
• Bits 7:6 – Res: Reserved Bits
These bits are reserved bits in the ATmega164P/324P/644P and will always read as zero.
• Bits 5:4 – EEPM1 and EEPM0: EEPROM Programming Mode Bits
The EEPROM Programming mode bit setting defines which programming action that will be triggered when
writing EEPE. It is possible to program data in one atomic operation (erase the old value and program the new
value) or to split the Erase and Write operations in two different operations. The Programming times for the
different modes are shown in Table 5-1 on page 32. While EEPE is set, any write to EEPMn will be ignored.
During reset, the EEPMn bits will be reset to 0b00 unless the EEPROM is busy programming.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 31
ATmega164P/V/324P/V/644P/V
Table 5-1. EEPROM Mode Bits
Programming
EEPM1 EEPM0
0 0 3.4 ms Erase and Write in one operation (Atomic Operation)
0 1 1.8 ms Erase Only
1 0 1.8 ms Write Only
1 1 – Reserved for future use
• Bit 3 – EERIE: EEPROM Ready Interrupt Enable
Writing EERIE to one enables the EEPROM Ready Interrupt if the I-bit in SREG is set. Writing EERIE to zero
disables the interrupt. The EEPROM Ready interrupt generates a constant interrupt when EEPE is cleared.
• Bit 2 – EEMPE: EEPROM Master Programming Enable
The EEMPE bit determines whether setting EEPE to one causes the EEPROM to be written. When EEMPE is
set, setting EEPE within four clock cycles will write data to the EEPROM at the selected address If EEMPE is
zero, setting EEPE will have no effect. When EEMPE has been written to one by software, hardware clears the
bit to zero after four clock cycles. See the description of the EEPE bit for an EEPROM write procedure.
Time Operation
• Bit 1 – EEPE: EEPROM Programming Enable
The EEPROM Write Enable Signal EEPE is the write strobe to the EEPROM. When address and data are
correctly set up, the EEPE bit must be written to one to write the value into the EEPROM. The EEMPE bit must
be written to one before a logical one is written to EEPE, otherwise no EEPROM write takes place. The
following procedure should be followed when writing the EEPROM (the order of steps 3 and 4 is not essential):
1. Wait until EEPE becomes zero.
2. Wait until SPMEN in SPMCSR becomes zero.
3. Write new EEPROM address to EEAR (optional).
4. Write new EEPROM data to EEDR (optional).
5. Write a logical one to the EEMPE bit while writing a zero to EEPE in EECR.
6. Within four clock cycles after setting EEMPE, write a logical one to EEPE.
The EEPROM can not be programmed during a CPU write to the Flash memory. The software must check that
the Flash programming is completed before initiating a new EEPROM write. Step 2 is only relevant if the
software contains a Boot Loader allowing the CPU to program the Flash. If the Flash is never being updated by
the CPU, step 2 can be omitted. See ”Memory Programming” on page 292 for details about Boot programming.
Caution: An interrupt between step 5 and step 6 will make the write cycle fail, since the EEPROM Master Write
Enable will time-out. If an interrupt routine accessing the EEPROM is interrupting another EEPROM access, the
EEAR or EEDR Register will be modified, causing the interrupted EEPROM access to fail. It is recommended to
have the Global Interrupt Flag cleared during all the steps to avoid these problems.
When the write access time has elapsed, the EEPE bit is cleared by hardware. The user software can poll this
bit and wait for a zero before writing the next byte. When EEPE has been set, the CPU is halted for two cycles
before the next instruction is executed.
• Bit 0 – EERE: EEPROM Read Enable
The EEPROM Read Enable Signal EERE is the read strobe to the EEPROM. When the correct address is set
up in the EEAR Register, the EERE bit must be written to a logic one to trigger the EEPROM read. The
EEPROM read access takes one instruction, and the requested data is available immediately. When the
EEPROM is read, the CPU is halted for four cycles before the next instruction is executed.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 32
ATmega164P/V/324P/V/644P/V
The user should poll the EEPE bit before starting the read operation. If a write operation is in progress, it is
neither possible to read the EEPROM, nor to change the EEAR Register.
The calibrated Oscillator is used to time the EEPROM accesses. Table 5-2 on page 33 lists the typical
programming time for EEPROM access from the CPU.
Table 5-2. EEPROM Programming Time
Symbol Number of Calibrated RC Oscillator Cycles Typ Programming Time
EEPROM write
(from CPU)
26,368 3.3 ms
The following code examples show one assembly and one C function for writing to the EEPROM. The examples
assume that interrupts are controlled (for example by disabling interrupts globally) so that no interrupts will occur
during execution of these functions. The examples also assume that no Flash Boot Loader is present in the
software. If such code is present, the EEPROM write function must also wait for any ongoing SPM command to
finish.
Assembly Code Example
EEPROM_write:
; Wait for completion of previous write
sbic EECR,EEPE
rjmp EEPROM_write
; Set up address (r18:r17) in address register
out EEARH, r18
out EEARL, r17
; Write data (r16) to Data Register
out EEDR,r16
; Write logical one to EEMPE
sbi EECR,EEMPE
; Start eeprom write by setting EEPE
sbi EECR,EEPE
ret
C Code Example
(1)
()
void EEPROM_write(unsigned int uiAddress, unsigned char ucData)
{
/* Wait for completion of previous write */
while(EECR & (1<<EEPE))
;
/* Set up address and Data Registers */
EEAR = uiAddress;
EEDR = ucData;
/* Write logical one to EEMPE */
EECR |= (1<<EEMPE);
/* Start eeprom write by setting EEPE */
EECR |= (1<<EEPE);
}
Note: 1. See “About Code Examples” on page 16.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 33
ATmega164P/V/324P/V/644P/V
The next code examples show assembly and C functions for reading the EEPROM. The examples assume that
interrupts are controlled so that no interrupts will occur during execution of these functions.
Assembly Code Example
EEPROM_read:
; Wait for completion of previous write
sbic EECR,EEPE
rjmp EEPROM_read
; Set up address (r18:r17) in address register
out EEARH, r18
out EEARL, r17
; Start eeprom read by writing EERE
sbi EECR,EERE
; Read data from Data Register
in r16,EEDR
ret
C Code Example
unsigned char EEPROM_read(unsigned int uiAddress)
{
}
(1)
/* Wait for completion of previous write */
while(EECR & (1<<EEPE))
/* Set up address register */
EEAR = uiAddress;
/* Start eeprom read by writing EERE */
EECR |= (1<<EERE);
/* Return data from Data Register */
return EEDR;
(1)
;
Note: 1. See “About Code Examples” on page 16.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 34
5.6.4 GPIOR2 – General Purpose I/O Register 2
Bit 76543210
0x2B (0x4B) MSB LSB GPIOR2
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
5.6.5 GPIOR1 – General Purpose I/O Register 1
Bit 76543210
0x2A (0x4A) MSB LSB GPIOR1
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
5.6.6 GPIOR0 – General Purpose I/O Register 0
Bit 76543210
0x1E (0x3E) MSB LSB GPIOR0
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
ATmega164P/V/324P/V/644P/V
Note: 1. SRWn1 = SRW11 (upper sector) or SRW01 (lower sector), SRWn0 = SRW10 (upper sector) or SRW00 (lower
sector). The ALE pulse in period T4 is only present if the next instruction accesses the RAM (internal or
external).
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 35
6. System Clock and Clock Options
6.1 Clock Systems and their Distribution
Figure 6-1 presents the principal clock systems in the AVR and their distribution. All of the clocks need not be
active at a given time. In order to reduce power consumption, the clocks to modules not being used can be
halted by using different sleep modes, as described in ”Power Management and Sleep Modes” on page 49. The
clock systems are detailed below.
Figure 6-1. Clock Distribution
Asynchronous
Timer/Counter
General I/O
Modules
ATmega164P/V/324P/V/644P/V
ADC
CPU Core RAM
clk
ADC
Flash and
EEPROM
6.1.1 CPU Clock – clk
The CPU clock is routed to parts of the system concerned with operation of the AVR core. Examples of such
modules are the General Purpose Register File, the Status Register and the data memory holding the Stack
Pointer. Halting the CPU clock inhibits the core from performing general operations and calculations.
Timer/Counter
Oscillator
CPU
clk
I/O
clk
ASY
External Clock
AVR Clock
Control Unit
Source clock
System Clock
Prescaler
Clock
Multiplexer
Oscillator
Crystal
clk
CPU
clk
FLASH
Reset Logic
Watchdog Timer
Watchdog clock
Watchdog
Oscillator
Low-frequency
Crystal Oscillator
Calibrated RC
Oscillator
6.1.2 I/O Clock – clk
The I/O clock is used by the majority of the I/O modules, like Timer/Counters, SPI, and USART. The I/O clock is
also used by the External Interrupt module, but note that some external interrupts are detected by asynchronous
logic, allowing such interrupts to be detected even if the I/O clock is halted. Also note that start condition
detection in the USI module is carried out asynchronously when clk
sleep modes.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 36
I/O
is halted, TWI address recognition in all
I/O
ATmega164P/V/324P/V/644P/V
6.1.3 Flash Clock – clk
FLASH
The Flash clock controls operation of the Flash interface. The Flash clock is usually active simultaneously with
the CPU clock.
6.1.4 Asynchronous Timer Clock – clk
The Asynchronous Timer clock allows the Asynchronous Timer/Counter to be clocked directly from an external
clock or an external 32 kHz clock crystal. The dedicated clock domain allows using this Timer/Counter as a realtime counter even when the device is in sleep mode.
6.1.5 ADC Clock – clk
ADC
The ADC is provided with a dedicated clock domain. This allows halting the CPU and I/O clocks in order to
reduce noise generated by digital circuitry. This gives more accurate ADC conversion results.
6.2 Clock Sources
The device has the following clock source options, selectable by Flash Fuse bits as shown below. The clock
from the selected source is input to the AVR clock generator, and routed to the appropriate modules.
Table 6-1. Device Clocking Options Select
Device Clocking Option CKSEL3..0
Low Power Crystal Oscillator 1111 - 1000
Full Swing Crystal Oscillator 0111 - 0110
Low Frequency Crystal Oscillator 0101 - 0100
ASY
(1)
Internal 128 kHz RC Oscillator 0011
Calibrated Internal RC Oscillator 0010
External Clock 0000
Reserved 0001
Note: 1. For all fuses “1” means unprogrammed while “0” means programmed.
6.2.1 Default Clock Source
The device is shipped with internal RC oscillator at 8.0 MHz and with the fuse CKDIV8 programmed, resulting in
1.0 MHz system clock. The startup time is set to maximum and time-out period enabled. (CKSEL = "0010", SUT
= "10", CKDIV8 = "0"). The default setting ensures that all users can make their desired clock source setting
using any available programming interface.
6.2.2 Clock Startup Sequence
Any clock source needs a sufficient V
can be considered stable.
To ensure sufficient V
, the device issues an internal reset with a time-out delay (t
CC
released by all other reset sources. ”On-chip Debug System” on page 53 describes the start conditions for the
internal reset. The delay (t
set by the SUTx and CKSELx fuse bits. The selectable delays are shown in Table 6-2. The frequency of the
Watchdog Oscillator is voltage dependent as shown in ”Typical Characteristics – TA = -40°C to 85°C” on page
338.
to start oscillating and a minimum number of oscillating cycles before it
CC
) after the device reset is
TOUT
) is timed from the Watchdog Oscillator and the number of cycles in the delay is
TOUT
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 37
Table 6-2. Number of Watchdog Oscillator Cycles
XTAL2
XTAL1
GND
C2
C1
ATmega164P/V/324P/V/644P/V
Typ Time-out (V
0 ms 0 ms 0
4.1 ms 4.3 ms 512
65 ms 69 ms 8K (8,192)
= 5.0V) Typ Time-out (VCC = 3.0V) Number of Cycles
CC
Main purpose of the delay is to keep the AVR in reset until it is supplied with minimum Vcc. The delay will not
monitor the actual voltage and it will be required to select a delay longer than the Vcc rise time. If this is not
possible, an internal or external Brown-Out Detection circuit should be used. A BOD circuit will ensure sufficient
Vcc before it releases the reset, and the time-out delay can be disabled. Disabling the time-out delay without
utilizing a Brown-Out Detection circuit is not recommended.
The oscillator is required to oscillate for a minimum number of cycles before the clock is considered stable. An
internal ripple counter monitors the oscillator output clock, and keeps the internal reset active for a given
number of clock cycles. The reset is then released and the device will start to execute. The recommended
oscillator start-up time is dependent on the clock type, and varies from 6 cycles for an externally applied clock to
32K cycles for a low frequency crystal.
The start-up sequence for the clock includes both the time-out delay and the start-up time when the device
starts up from reset. When starting up from Power-save or Power-down mode, Vcc is assumed to be at a
sufficient level and only the start-up time is included.
6.2.3 Clock Source Connections
The pins XTAL1 and XTAL2 are input and output, respectively, of an inverting amplifier which can be configured
for use as an On-chip Oscillator, as shown in Figure 6-2 on page 38. Either a quartz crystal or a ceramic
resonator may be used.
C1 and C2 should always be equal for both crystals and resonators. The optimal value of the capacitors
depends on the crystal or resonator in use, the amount of stray capacitance, and the electromagnetic noise of
the environment. For ceramic resonators, the capacitor values given by the manufacturer should be used.
Figure 6-2. Crystal Oscillator Connections
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 38
6.3 Low Power Crystal Oscillator
This Crystal Oscillator is a low power oscillator, with reduced voltage swing on the XTAL2 output. It gives the
lowest power consumption, but is not capable of driving other clock inputs, and may be more susceptible to
noise in noisy environments. In these cases, refer to the ”Full Swing Crystal Oscillator” on page 40.
Some initial guidelines for choosing capacitors for use with crystals are given in Table 6-3. The crystal should be
connected as described in ”Clock Source Connections” on page 38.
The Low Power Oscillator can operate in three different modes, each optimized for a specific frequency range.
The operating mode is selected by the fuses CKSEL3..1 as shown in Table 6-3.
ATmega164P/V/324P/V/644P/V
Table 6-3. Low Power Crystal Oscillator Operating Modes
Frequency Range (MHz) CKSEL3..1
0.4 - 0.9 100
(2)
(3)
(1)
Recommended Range for Capacitors C1
and C2 (pF)
–
0.9 - 3.0 101 12 - 22
3.0 - 8.0 110 12 - 22
8.0 - 16.0 111 12 - 22
Notes: 1. If 8 MHz frequency exceeds the specification of the device (depends on VCC), the CKDIV8 Fuse can be
programmed in order to divide the internal frequency by 8. It must be ensured that the resulting divided clock
meets the frequency specification of the device.
2. This is the recommended CKSEL settings for the different frequency ranges.
3. This option should not be used with crystals, only with ceramic resonators.
The CKSEL0 Fuse together with the SUT1..0 Fuses select the start-up times as shown in Table 6-4.
Table 6-4. Start-up Times for the Low Power Crystal Oscillator Clock Selection
Oscillator Source /
Power Conditions
Ceramic resonator, fast
rising power
Start-up Time from
Power-down and
Power-save
258 CK 14CK + 4.1 ms
Additional Delay
from Reset
= 5.0V) CKSEL0 SUT1..0
(V
CC
(1)
000
Ceramic resonator, slowly
rising power
Ceramic resonator, BOD
enabled
Ceramic resonator, fast
rising power
Ceramic resonator, slowly
rising power
Crystal Oscillator, BOD
enabled
Crystal Oscillator, fast
rising power
Crystal Oscillator, slowly
rising power
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 39
258 CK 14CK + 65 ms
1K CK 14CK
1K CK 14CK + 4.1 ms
1K CK 14CK + 65 ms
16K CK 14CK 1 01
16K CK 14CK + 4.1 ms 1 10
16K CK 14CK + 65 ms 1 11
(1)
(2)
(2)
(2)
001
010
011
100
Notes: 1. These options should only be used when not operating close to the maximum frequency of the device, and
only if frequency stability at start-up is not important for the application. These options are not suitable for
crystals.
2. These options are intended for use with ceramic resonators and will ensure frequency stability at start-up. They
can also be used with crystals when not operating close to the maximum frequency of the device, and if
frequency stability at start-up is not important for the application.
6.4 Full Swing Crystal Oscillator
This Crystal Oscillator is a full swing oscillator, with rail-to-rail swing on the XTAL2 output. This is useful for
driving other clock inputs and in noisy environments. The current consumption is higher than the ”Low Power
Crystal Oscillator” on page 39. Note that the Full Swing Crystal Oscillator will only operate for Vcc = 2.7 - 5.5
volts.
Some initial guidelines for choosing capacitors for use with crystals are given in Table 6-6. The crystal should be
connected as described in ”Clock Source Connections” on page 38.
The operating mode is selected by the fuses CKSEL3..1 as shown in Table 6-5.
Table 6-5. Full Swing Crystal Oscillator Operating Modes
(1)
Frequency Range
(MHz) CKSEL3..1
ATmega164P/V/324P/V/644P/V
Recommended Range for Capacitors C1
and C2 (pF)
0.4 - 20 011 12 - 22
Notes: 1. If 8 MHz frequency exceeds the specification of the device (depends on VCC), the CKDIV8 Fuse can be
programmed in order to divide the internal frequency by 8. It must be ensured that the resulting divided clock
meets the frequency specification of the device.
Table 6-6. Start-up Times for the Full Swing Crystal Oscillator Clock Selection
Oscillator Source /
Power Conditions
Ceramic resonator, fast
rising power
Ceramic resonator, slowly
rising power
Ceramic resonator, BOD
enabled
Ceramic resonator, fast
rising power
Ceramic resonator, slowly
rising power
Crystal Oscillator, BOD
enabled
Crystal Oscillator, fast
rising power
Crystal Oscillator, slowly
rising power
Start-up Time from
Power-down and
Power-save
258 CK 14CK + 4.1 ms
258 CK 14CK + 65 ms
1K CK 14CK
1K CK 14CK + 4.1 ms
1K CK 14CK + 65 ms
16K CK 14CK 1 01
16K CK 14CK + 4.1 ms 1 10
16K CK 14CK + 65 ms 1 11
Additional Delay
from Reset
(V
= 5.0V) CKSEL0 SUT1..0
CC
(1)
(1)
(2)
(2)
(2)
000
001
010
011
100
Notes: 1. These options should only be used when not operating close to the maximum frequency of the device, and
only if frequency stability at start-up is not important for the application. These options are not suitable for
crystals.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 40
2. These options are intended for use with ceramic resonators and will ensure frequency stability at start-up. They
C 2 CL Cs–=
can also be used with crystals when not operating close to the maximum frequency of the device, and if
frequency stability at start-up is not important for the application.
6.5 Low Frequency Crystal Oscillator
The Low-frequency Crystal Oscillator is optimized for use with a 32.768 kHz watch crystal. When selecting
crystals, load capasitance and crystal’s Equivalent Series Resistance, ESR must be taken into consideration.
Both values are specified by the crystal vendor. ATmega164P/324P/644P oscillator is optimized for very low
power consumption, and thus when selecting crystals, see Table 6-7 on page 41 for maximum ESR
recommendations on 9 pF and 12.5 pF crystals
Table 6-7. Maximum ESR Recommendation for 32.768 kHz Watch Crystal
ATmega164P/V/324P/V/644P/V
Crystal CL (pF) Max ESR [k]
9.0 65
12.5 30
Note: 1. Maximum ESR is typical value based on characterization
(1)
The Low-frequency Crystal Oscillator provides an internal load capacitance, seeTable 6-8 on page 41 at each
TOSC pin.
Table 6-8. Capasitance for Low-frequency Oscillator.
Device 32 kHz Osc. Type Cap(Xtal1/Tosc1) Cap(Xtal2/Tosc2)
ATmega164P/324P/644P System Osc. 18 pF 8 pF
Timer Osc. 6 pF 6 pF
The capacitance (Ce +Ci) needed at each TOSC pin can be calculated by using:
where:
Ce - is optional external capacitors as described in Figure 8-2 on page29
Ci - is the pin capacitance in table 8-8 on page 33
CL - is the load capacitance for a 32.768 kHz crystal specified by the crystal vendor
CS - is the total stray capacitance for one TOSC pin.
Crystals specifying load capacitance (CL) higher than 8.0 pF, require external capacitors applied as described
in Figure 6-2 on page 38.
When this oscillator is selected, start-up times are determined by the SUT Fuses and CKSEL0 as shown in
Table 6-9.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 41
ATmega164P/V/324P/V/644P/V
Table 6-9. Start-up Times for the Low Frequency Crystal Oscillator Clock Selection
Start-up Time from
Power-down and
Power Conditions
Power-save
BOD enabled 1K CK 14CK
Fast rising power 1K CK 14CK + 4.1 ms
Slowly rising power 1K CK 14CK + 65 ms
Reserved 0 11
BOD enabled 32K CK 14CK 1 00
Fast rising power 32K CK 14CK + 4.1 ms 1 01
Slowly rising power 32K CK 14CK + 65 ms 1 10
Reserved 1 11
Note: 1. These options should only be used if frequency stability at start-up is not important for the application.
Additional Delay
from Reset
(V
= 5.0V) CKSEL0 SUT1..0
CC
(1)
(1)
(1)
000
001
010
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 42
6.6 Calibrated Internal RC Oscillator
By default, the Internal RC Oscillator provides an approximate 8 MHz clock. Though voltage and temperature
dependent, this clock can be very accurately calibrated by the the user. See Table 25-4 on page 327 and
”Internal Oscillator Speed” on page 356 and page 380 for more details. The device is shipped with the CKDIV8
Fuse programmed. See ”System Clock Prescaler” on page 45 for more details.
This clock may be selected as the system clock by programming the CKSEL Fuses as shown in Table 6-10. If
selected, it will operate with no external components. During reset, hardware loads the pre-programmed
calibration value into the OSCCAL Register and thereby automatically calibrates the RC Oscillator. The
accuracy of this calibration is shown as Factory calibration in Table 25-4 on page 327.
By changing the OSCCAL register from SW, see ”OSCCAL – Oscillator Calibration Register” on page 47, it is
possible to get a higher calibration accuracy than by using the factory calibration. The accuracy of this
calibration is shown as User calibration in Table 25-4 on page 327.
When this Oscillator is used as the chip clock, the Watchdog Oscillator will still be used for the Watchdog Timer
and for the Reset Time-out. For more information on the pre-programmed calibration value, see the section
”Calibration Byte” on page 295.
Table 6-10. Internal Calibrated RC Oscillator Operating Modes
Frequency Range
7.3 - 8.1 0010
(2)
(MHz) CKSEL3..0
ATmega164P/V/324P/V/644P/V
(1)
Notes: 1. The device is shipped with this option selected.
2. If 8 MHz frequency exceeds the specification of the device (depends on V
programmed in order to divide the internal frequency by 8.
), the CKDIV8 Fuse can be
CC
When this Oscillator is selected, start-up times are determined by the SUT Fuses as shown in Table 6-11 on
page 43.
Table 6-11. Start-up times for the Internal Calibrated RC Oscillator clock selection
Start-up Time from Power-
Power Conditions
BOD enabled 6 CK 14CK 00
Fast rising power 6 CK 14CK + 4.1 ms 01
Slowly rising power 6 CK 14CK + 65 ms 10
Note: 1. The device is shipped with this option selected.
down and Power-save
Reserved 11
Additional Delay from
Reset (V
= 5.0V) SUT1..0
CC
(1)
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 43
6.7 128 kHz Internal Oscillator
NC
EXTERNAL
CLOCK
SIGNAL
XTAL2
XTAL1
GND
The 128 kHz internal Oscillator is a low power Oscillator providing a clock of 128 kHz. The frequency is nominal
at 3V and 25C. This clock may be select as the system clock by programming the CKSEL Fuses to “0011” as
shown in Table 6-12.
ATmega164P/V/324P/V/644P/V
Table 6-12. 128 kHz Internal Oscillator Operating Modes
Note: 1. Note that the 128 kHz oscillator is a very low power clock source, and is not designed for high accuracy.
When this clock source is selected, start-up times are determined by the SUT Fuses as shown in Table 6-13.
Table 6-13. Start-up Times for the 128 kHz Internal Oscillator
Power Conditions
BOD enabled 6 CK 14CK 00
Fast rising power 6 CK 14CK + 4 ms 01
Slowly rising power 6 CK 14CK + 64 ms 10
6.8 External Clock
To drive the device from an external clock source, XTAL1 should be driven as shown in Figure 6-3. To run the
device on an external clock, the CKSEL Fuses must be programmed to “0000”.
(2)
Nominal Frequency CKSEL3..0
128 kHz 0011
Start-up Time from Power-
down and Power-save
Reserved 11
Additional Delay from
Reset SUT1..0
Figure 6-3. External Clock Drive Configuration
When this clock source is selected, start-up times are determined by the SUT Fuses as shown in Table 6-15.
Table 6-14. Crystal Oscillator Clock Frequency
Nominal Frequency CKSEL3..0
0 - 20 MHz 0000
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 44
Table 6-15. Start-up Times for the External Clock Selection
Start-up Time from Power-
Power Conditions
BOD enabled 6 CK 14CK 00
Fast rising power 6 CK 14CK + 4.1 ms 01
Slowly rising power 6 CK 14CK + 65 ms 10
When applying an external clock, it is required to avoid sudden changes in the applied clock frequency to
ensure stable operation of the MCU. A variation in frequency of more than 2% from one clock cycle to the next
can lead to unpredictable behavior. If changes of more than 2% is required, ensure that the MCU is kept in
Reset during the changes.
Note that the System Clock Prescaler can be used to implement run-time changes of the internal clock
frequency while still ensuring stable operation. Refer to ”System Clock Prescaler” on page 45 for details.
6.9 Timer/Counter Oscillator
ATmega164P/324P/644P uses the same type of crystal oscillator for Low-frequency Crystal Oscillator and
Timer/Counter Oscillator. See ”Low Frequency Crystal Oscillator” on page 41 for details on the oscillator and
crystal requirements.
The device can operate its Timer/Counter2 from an external 32.768 kHz watch crystal or a external clock
source. See ”Clock Source Connections” on page 38 for details.
Applying an external clock source to TOSC1 can be done if EXTCLK in the ASSR Register is written to logic
one. See ”The Output Compare Register B contains an 8-bit value that is continuously compared with the
counter value (TCNT2). A match can be used to generate an Output Compare interrupt, or to generate a
waveform output on the OC2B pin.” on page 162 for further description on selecting external clock as input
instead of a 32.768 kHz watch crystal.
ATmega164P/V/324P/V/644P/V
Additional Delay from
down and Power-save
Reserved 11
Reset (V
= 5.0V) SUT1..0
CC
6.10 Clock Output Buffer
The device can output the system clock on the CLKO pin. To enable the output, the CKOUT Fuse has to be
programmed. This mode is suitable when the chip clock is used to drive other circuits on the system. The clock
also will be output during reset, and the normal operation of I/O pin will be overridden when the fuse is
programmed. Any clock source, including the internal RC Oscillator, can be selected when the clock is output on
CLKO. If the System Clock Prescaler is used, it is the divided system clock that is output.
6.11 System Clock Prescaler
The ATmega164P/324P/644P has a system clock prescaler, and the system clock can be divided by setting the
”CLKPR – Clock Prescale Register” on page 47. This feature can be used to decrease the system clock
frequency and the power consumption when the requirement for processing power is low. This can be used with
all clock source options, and it will affect the clock frequency of the CPU and all synchronous peripherals. clk
clk
, clk
ADC
When switching between prescaler settings, the System Clock Prescaler ensures that no glitches occurs in the
clock system. It also ensures that no intermediate frequency is higher than neither the clock frequency
corresponding to the previous setting, nor the clock frequency corresponding to the new setting.
The ripple counter that implements the prescaler runs at the frequency of the undivided clock, which may be
faster than the CPU's clock frequency. Hence, it is not possible to determine the state of the prescaler - even if
it were readable, and the exact time it takes to switch from one clock division to the other cannot be exactly
CPU
, and clk
are divided by a factor as shown in Table 6-16 on page 48.
FLASH
I/O
,
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 45
ATmega164P/V/324P/V/644P/V
predicted. From the time the CLKPS values are written, it takes between T1 + T2 and T1 + 2 * T2 before the
new clock frequency is active. In this interval, 2 active clock edges are produced. Here, T1 is the previous clock
period, and T2 is the period corresponding to the new prescaler setting.
To avoid unintentional changes of clock frequency, a special write procedure must be followed to change the
CLKPS bits:
1. Write the Clock Prescaler Change Enable (CLKPCE) bit to one and all other bits in CLKPR to zero.
2. Within four cycles, write the desired value to CLKPS while writing a zero to CLKPCE.
Interrupts must be disabled when changing prescaler setting to make sure the write procedure is not interrupted.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 46
6.12 Register Description
6.12.1 OSCCAL – Oscillator Calibration Register
Bit 76543210
(0x66) CAL7 CAL6 CAL5 CAL4 CAL3 CAL2 CAL1 CAL0 OSCCAL
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value Device Specific Calibration Value
• Bits 7:0 – CAL7:0: Oscillator Calibration Value
The Oscillator Calibration Register is used to trim the Calibrated Internal RC Oscillator to remove process
variations from the oscillator frequency. A pre-programmed calibration value is automatically written to this
register during chip reset, giving the Factory calibrated frequency as specified in Table 25-4 on page 327. The
application software can write this register to change the oscillator frequency. The oscillator can be calibrated to
frequencies as specified in Table 25-4 on page 327. Calibration outside that range is not ensured.
Note that this oscillator is used to time EEPROM and Flash write accesses, and these write times will be
affected accordingly. If the EEPROM or Flash are written, do not calibrate to more than 8.8 MHz. Otherwise, the
EEPROM or Flash write may fail.
The CAL7 bit determines the range of operation for the oscillator. Setting this bit to 0 gives the lowest frequency
range, setting this bit to 1 gives the highest frequency range. The two frequency ranges are overlapping, in other
words a setting of OSCCAL = 0x7F gives a higher frequency than OSCCAL = 0x80.
ATmega164P/V/324P/V/644P/V
The CAL6..0 bits are used to tune the frequency within the selected range. A setting of 0x00 gives the lowest
frequency in that range, and a setting of 0x7F gives the highest frequency in the range.
6.12.2 CLKPR – Clock Prescale Register
Bit 7 6543210
(0x61)
Read/Write R/W R R R R/W R/W R/W R/W
Initial Value 0 0 0 0 See Bit Description
CLKPCE – – – CLKPS3 CLKPS2 CLKPS1 CLKPS0 CLKPR
• Bit 7 – CLKPCE: Clock Prescaler Change Enable
The CLKPCE bit must be written to logic one to enable change of the CLKPS bits. The CLKPCE bit is only
updated when the other bits in CLKPR are simultaneously written to zero. CLKPCE is cleared by hardware four
cycles after it is written or when CLKPS bits are written. Rewriting the CLKPCE bit within this time-out period
does neither extend the time-out period, nor clear the CLKPCE bit.
• Bits 3:0 – CLKPS3:0: Clock Prescaler Select Bits 3 - 0
These bits define the division factor between the selected clock source and the internal system clock. These bits
can be written run-time to vary the clock frequency to suit the application requirements. As the divider divides
the master clock input to the MCU, the speed of all synchronous peripherals is reduced when a division factor is
used. The division factors are given in Table 6-16 on page 48.
The CKDIV8 Fuse determines the initial value of the CLKPS bits. If CKDIV8 is unprogrammed, the CLKPS bits
will be reset to “0000”. If CKDIV8 is programmed, CLKPS bits are reset to “0011”, giving a division factor of 8 at
start up. This feature should be used if the selected clock source has a higher frequency than the maximum
frequency of the device at the present operating conditions. Note that any value can be written to the CLKPS
bits regardless of the CKDIV8 Fuse setting. The Application software must ensure that a sufficient division factor
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 47
ATmega164P/V/324P/V/644P/V
is chosen if the selected clock source has a higher frequency than the maximum frequency of the device at the
present operating conditions. The device is shipped with the CKDIV8 Fuse programmed.
Table 6-16. Clock Prescaler Select
CLKPS3 CLKPS2 CLKPS1 CLKPS0 Clock Division Factor
0000 1
0001 2
0010 4
0011 8
0100 16
0101 32
0110 64
0111 128
1000 256
1001 Reserved
1010 Reserved
1011 Reserved
1100 Reserved
1101 Reserved
1110 Reserved
1111 Reserved
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 48
ATmega164P/V/324P/V/644P/V
7. Power Management and Sleep Modes
7.1 Overview
Sleep modes enable the application to shut down unused modules in the MCU, thereby savingpower. The AVR
provides various sleep modes allowing the user to tailor the power consumption to the application’s
requirements.
When enabled, the Brown-out Detector (BOD) actively monitors the power supply voltage during the sleep
periods. To further save power, it is possible to disable the BOD in some sleep modes. See ”BOD Disable” on
page 50 for more details.
7.2 Sleep Modes
Figure 6-1 on page 36 presents the different clock systems in the ATmega164P/324P/644P, and their
distribution. The figure is helpful in selecting an appropriate sleep mode. Table 7-1 shows the different sleep
modes, their wake up sources and BOD disable ability.
Table 7-1. Active Clock Domains and Wake-up Sources in the Different Sleep Modes.
Active Clock Domains Oscillators Wake-up Sources
CPU
FLASH
Sleep Mode
clk
clk
Idle XXX X X
ADCNRM X X X X
Power-down X
Power-save X X
Standby
(1)
Extended
Standby
clkIOclk
ADC
ASY
Software
clk
Main Clock
Source
Enabled
Timer Osc
Enabled
INT2:0 and
Pin Change
TWI Address
Match
Timer2
SPM/
EEPROM Ready
ADC
WDT Interrupt
(2)
XXXXXXX
(2)
(3)
X
(3)
(2)
(3)
X
XX
(2)
X
XX
(3)
(2)
(3)
X
(2)
XX
XXX
XXX
XX X X
XXX
XX X X
Other I/O
BOD Disdable
Notes: 1. Only recommended with external crystal or resonator selected as clock source.
2. If Timer/Counter2 is running in asynchronous mode.
3. For INT0, only level interrupt.
To enter any of the sleep modes, the SE bit in SMCR must be written to logic one and a SLEEP instruction must
be executed. The SM2, SM1, and SM0 bits in the SMCR Register select which sleep mode will be activated by
the SLEEP instruction. See Table 7-2 on page 54 for a summary.
If an enabled interrupt occurs while the MCU is in a sleep mode, the MCU wakes up. The MCU is then halted for
four cycles in addition to the start-up time, executes the interrupt routine, and resumes execution from the
instruction following SLEEP. The contents of the Register File and SRAM are unaltered when the device wakes
up from sleep. If a reset occurs during sleep mode, the MCU wakes up and executes from the Reset Vector.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 49
7.3 BOD Disable
When the Brown-out Detector (BOD) is enabled by BODLEVEL fuses, Table 24-3 on page 293, the BOD is
actively monitoring the power supply voltage during a sleep period. To save power, it is possible to disable the
BOD by software for some of the sleep modes, see Table 7-1 on page 49. The sleep mode power consumption
will then be at the same level as when BOD is globally disabled by fuses. If BOD is disabled in software, the
BOD function is turned off immediately after entering the sleep mode. Upon wake-up from sleep, BOD is
automatically enabled again. This ensures safe operation in case the V
period.
When the BOD has been disabled, the wake-up time from sleep mode will be approximately 60 µs to ensure
that the BOD is working correctly before the MCU continues executing code.
BOD disable is controlled by bit 6, BODS (BOD Sleep) in the control register MCUCR, see ”MCUCR – MCU
Control Register” on page 55. Writing this bit to one turns off the BOD in relevant sleep modes, while a zero in
this bit keeps BOD active. Default setting keeps BOD active, that is, BODS set to zero.
Writing to the BODS bit is controlled by a timed sequence and an enable bit, see ”MCUCR – MCU Control
Register” on page 55.
7.4 Idle Mode
ATmega164P/V/324P/V/644P/V
level has dropped during the sleep
CC
When the SM2..0 bits are written to 000, the SLEEP instruction makes the MCU enter Idle mode, stopping the
CPU but allowing the SPI, USART, Analog Comparator, ADC, 2-wire Serial Interface, Timer/Counters,
Watchdog, and the interrupt system to continue operating. This sleep mode basically halts clk
while allowing the other clocks to run.
Idle mode enables the MCU to wake up from external triggered interrupts as well as internal ones like the Timer
Overflow and USART Transmit Complete interrupts. If wake-up from the Analog Comparator interrupt is not
required, the Analog Comparator can be powered down by setting the ACD bit in the Analog Comparator
Control and Status Register – ACSR. This will reduce power consumption in Idle mode. If the ADC is enabled, a
conversion starts automatically when this mode is entered.
7.5 ADC Noise Reduction Mode
When the SM2..0 bits are written to 001, the SLEEP instruction makes the MCU enter ADC Noise Reduction
mode, stopping the CPU but allowing the ADC, the external interrupts, 2-wire Serial Interface address match,
Timer/Counter2 and the Watchdog to continue operating (if enabled). This sleep mode basically halts clk
clk
, and clk
CPU
This improves the noise environment for the ADC, enabling higher resolution measurements. If the ADC is
enabled, a conversion starts automatically when this mode is entered. Apart form the ADC Conversion
Complete interrupt, only an External Reset, a Watchdog System Reset, a Watchdog interrupt, a Brown-out
Reset, a 2-wire serial interface interrupt, a Timer/Counter2 interrupt, an SPM/EEPROM ready interrupt, an
external level interrupt on PCINT7:4 or a pin change interrupt can wakeup the MCU from ADC Noise Reduction
mode.
, while allowing the other clocks to run.
FLASH
CPU
and clk
FLASH
,
I/O
,
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 50
7.6 Power-down Mode
When the SM2..0 bits are written to 010, the SLEEP instruction makes the MCU enter Power-down mode. In
this mode, the external Oscillator is stopped, while the external interrupts, the 2-wire Serial Interface, and the
Watchdog continue operating (if enabled). Only an External Reset, a Watchdog Reset, a Brown-out Reset, 2wire Serial Interface address match, an external level interrupt on PCINT7:4, an external interrupt on INT2:0, or
a pin change interrupt can wake up the MCU. This sleep mode basically halts all generated clocks, allowing
operation of asynchronous modules only.
Note that if a level triggered interrupt is used for wake-up from Power-down mode, the changed level must be
held for some time to wake up the MCU. Refer to ”External Interrupts” on page 74 for details.
When waking up from Power-down mode, there is a delay from the wake-up condition occurs until the wake-up
becomes effective. This allows the clock to restart and become stable after having been stopped. The wake-up
period is defined by the same CKSEL Fuses that define the Reset Time-out period, as described in ”Clock
Sources” on page 37.
7.7 Power-save Mode
When the SM2:0 bits are written to 011, the SLEEP instruction makes the MCU enter Power-save mode. This
mode is identical to Power-down, with one exception:
If Timer/Counter2 is enabled, it will keep running during sleep. The device can wake up from either Timer
Overflow or Output Compare event from Timer/Counter2 if the corresponding Timer/Counter2 interrupt enable
bits are set in TIMSK2, and the Global Interrupt Enable bit in SREG is set.
If Timer/Counter2 is not running, Power-down mode is recommended instead of Power-save mode.
The Timer/Counter2 can be clocked both synchronously and asynchronously in Power-save mode. If the
Timer/Counter2 is not using the asynchronous clock, the Timer/Counter Oscillator is stopped during sleep. If the
Timer/Counter2 is not using the synchronous clock, the clock source is stopped during sleep. Note that even if
the synchronous clock is running in Power-save, this clock is only available for the Timer/Counter2.
ATmega164P/V/324P/V/644P/V
7.8 Standby Mode
When the SM2..0 bits are 110 and an external crystal/resonator clock option is selected, the SLEEP instruction
makes the MCU enter Standby mode. This mode is identical to Power-down with the exception that the
Oscillator is kept running. From Standby mode, the device wakes up in six clock cycles.
7.9 Extended Standby Mode
When the SM2..0 bits are 111 and an external crystal/resonator clock option is selected, the SLEEP instruction
makes the MCU enter Extended Standby mode. This mode is identical to Power-save mode with the exception
that the Oscillator is kept running. From Extended Standby mode, the device wakes up in six clock cycles.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 51
7.10 Power Reduction Register
The Power Reduction Register(PRR), see ”PRR – Power Reduction Register” on page 55, provides a method to
stop the clock to individual peripherals to reduce power consumption. The current state of the peripheral is
frozen and the I/O registers can not be read or written. Resources used by the peripheral when stopping the
clock will remain occupied, hence the peripheral should in most cases be disabled before stopping the clock.
Waking up a peripheral, which is done by clearing the bit in PRR, puts the peripheral in the same state as before
shutdown.
Peripheral shutdown can be used in Idle mode and Active mode to significantly reduce the overall power
consumption. In all other sleep modes, the clock is already stopped.
7.11 Minimizing Power Consumption
There are several issues to consider when trying to minimize the power consumption in an AVR controlled
system. In general, sleep modes should be used as much as possible, and the sleep mode should be selected
so that as few as possible of the device’s functions are operating. All functions not needed should be disabled.
In particular, the following modules may need special consideration when trying to achieve the lowest possible
power consumption.
7.11.1 Analog to Digital Converter
ATmega164P/V/324P/V/644P/V
If enabled, the ADC will be enabled in all sleep modes. To save power, the ADC should be disabled before
entering any sleep mode. When the ADC is turned off and on again, the next conversion will be an extended
conversion. Refer to ”ADC - Analog-to-digital Converter” on page 241 for details on ADC operation.
7.11.2 Analog Comparator
When entering Idle mode, the Analog Comparator should be disabled if not used. When entering ADC Noise
Reduction mode, the Analog Comparator should be disabled. In other sleep modes, the Analog Comparator is
automatically disabled. However, if the Analog Comparator is set up to use the Internal Voltage Reference as
input, the Analog Comparator should be disabled in all sleep modes. Otherwise, the Internal Voltage Reference
will be enabled, independent of sleep mode. Refer to ”AC - Analog Comparator” on page 238 for details on how
to configure the Analog Comparator.
7.11.3 Brown-out Detector
If the Brown-out Detector is not needed by the application, this module should be turned off. If the Brown-out
Detector is enabled by the BODLEVEL Fuses, it will be enabled in all sleep modes, and hence, always consume
power. In the deeper sleep modes, this will contribute significantly to the total current consumption. Refer to
”Brown-out Detection” on page 60 for details on how to configure the Brown-out Detector.
7.11.4 Internal Voltage Reference
The Internal Voltage Reference will be enabled when needed by the Brown-out Detection, the Analog
Comparator or the ADC. If these modules are disabled as described in the sections above, the internal voltage
reference will be disabled and it will not be consuming power. When turned on again, the user must allow the
reference to start up before the output is used. If the reference is kept on in sleep mode, the output can be used
immediately. Refer to ”Internal Voltage Reference” on page 61 for details on the start-up time.
7.11.5 Watchdog Timer
If the Watchdog Timer is not needed in the application, the module should be turned off. If the Watchdog Timer
is enabled, it will be enabled in all sleep modes, and hence, always consume power. In the deeper sleep modes,
this will contribute significantly to the total current consumption. Refer to ”Interrupts” on page 68 for details on
how to configure the Watchdog Timer.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 52
7.11.6 Port Pins
When entering a sleep mode, all port pins should be configured to use minimum power. The most important is
then to ensure that no pins drive resistive loads. In sleep modes where both the I/O clock (clk
clock (clk
) are stopped, the input buffers of the device will be disabled. This ensures that no power is
ADC
consumed by the input logic when not needed. In some cases, the input logic is needed for detecting wake-up
conditions, and it will then be enabled. Refer to the section ”Digital Input Enable and Sleep Modes” on page 83
for details on which pins are enabled. If the input buffer is enabled and the input signal is left floating or have an
analog signal level close to V
For analog input pins, the digital input buffer should be disabled at all times. An analog signal level close to
V
/2 on an input pin can cause significant current even in active mode. Digital input buffers can be disabled by
CC
writing to the Digital Input Disable Registers (DIDR1 and DIDR0). Refer to ”DIDR1 – Digital Input Disable
Register 1” on page 240 and ”DIDR0 – Digital Input Disable Register 0” on page 259 for details.
7.11.7 On-chip Debug System
If the On-chip debug system is enabled by the OCDEN Fuse and the chip enters sleep mode, the main clock
source is enabled, and hence, always consumes power. In the deeper sleep modes, this will contribute
significantly to the total current consumption.
There are three alternative ways to disable the OCD system:
Disable the OCDEN Fuse.
Disable the JTAGEN Fuse.
Write one to the JTD bit in MCUCR.
ATmega164P/V/324P/V/644P/V
/2, the input buffer will use excessive power.
CC
) and the ADC
I/O
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 53
7.12 Register Description
7.12.1 SMCR – Sleep Mode Control Register
The Sleep Mode Control Register contains control bits for power management.
Bit 76543210
0x33 (0x53) ––––SM2SM1SM0SESMCR
Read/Write R R R R R/W R/W R/W R/W
Initial Value00000000
• Bits 3, 2, 1 – SM2:0: Sleep Mode Select Bits 2, 1, and 0
These bits select between the five available sleep modes as shown in Table 7-2.
Table 7-2. Sleep Mode Select
SM2 SM1 SM0 Sleep Mode
000Idle
0 0 1 ADC Noise Reduction
0 1 0 Power-down
0 1 1 Power-save
ATmega164P/V/324P/V/644P/V
1 0 0 Reserved
1 0 1 Reserved
1 1 0 Standby
1 1 1 Extended Standby
Note: 1. Standby modes are only recommended for use with external crystals or resonators.
(1)
(1)
• Bit 0 – SE: Sleep Enable
The SE bit must be written to logic one to make the MCU enter the sleep mode when the SLEEP instruction is
executed. To avoid the MCU entering the sleep mode unless it is the programmer’s purpose, it is recommended
to write the Sleep Enable (SE) bit to one just before the execution of the SLEEP instruction and to clear it
immediately after waking up.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 54
7.12.2 MCUCR – MCU Control Register
Bit 7 6 5 4 3 2 1 0
0x35 (0x55)
Read/Write R/W R R R/W R R R/W R/W
Initial Value 0 0 0 0 0 0 0 0
JTD BODS BODSE PUD – – IVSEL IVCE MCUCR
• Bit 6 – BODS: BOD Sleep
The BODS bit must be written to logic one in order to turn off BOD during sleep, see Table 7-1 on page 49.
Writing to the BODS bit is controlled by a timed sequence and an enable bit, BODSE in MCUCR. To disable
BOD in relevant sleep modes, both BODS and BODSE must first be set to one. Then, to set the BODS bit,
BODS must be set to one and BODSE must be set to zero within four clock cycles.
The BODS bit is active three clock cycles after it is set. A sleep instruction must be executed while BODS is
active in order to turn off the BOD for the actual sleep mode. The BODS bit is automatically cleared after three
clock cycles.
• Bit 5 – BODSE: BOD Sleep Enable
BODSE enables setting of BODS control bit, as explained in BODS bit description. BOD disable is controlled by
a timed sequence.
ATmega164P/V/324P/V/644P/V
7.12.3 PRR – Power Reduction Register
Bit 76543210
(0x64) PRTWI PRTIM2 PRTIM0 PRUSART1 PRTIM1 PRSPI PRUSART0 PRADC PRR
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
• Bit 7 - PRTWI: Power Reduction TWI
Writing a logic one to this bit shuts down the TWI by stopping the clock to the module. When waking up the TWI
again, the TWI should be re initialized to ensure proper operation.
• Bit 6 - PRTIM2: Power Reduction Timer/Counter2
Writing a logic one to this bit shuts down the Timer/Counter2 module in synchronous mode (AS2 is 0). When the
Timer/Counter2 is enabled, operation will continue like before the shutdown.
• Bit 5 - PRTIM0: Power Reduction Timer/Counter0
Writing a logic one to this bit shuts down the Timer/Counter0 module. When the Timer/Counter0 is enabled,
operation will continue like before the shutdown.
• Bit 4 - PRUSART1: Power Reduction USART1
Writing a logic one to this bit shuts down the USART1 by stopping the clock to the module. When waking up the
USART1 again, the USART1 should be reinitialized to ensure proper operation.
• Bit 3 - PRTIM1: Power Reduction Timer/Counter1
Writing a logic one to this bit shuts down the Timer/Counter1 module. When the Timer/Counter1 is enabled,
operation will continue like before the shutdown.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 55
ATmega164P/V/324P/V/644P/V
• Bit 2 - PRSPI: Power Reduction Serial Peripheral Interface
Writing a logic one to this bit shuts down the Serial Peripheral Interface by stopping the clock to the module.
When waking up the SPI again, the SPI should be re initialized to ensure proper operation.
• Bit 1 - PRUSART0: Power Reduction USART0
Writing a logic one to this bit shuts down the USART0 by stopping the clock to the module. When waking up the
USART0 again, the USART0 should be reinitialized to ensure proper operation.
• Bit 0 - PRADC: Power Reduction ADC
Writing a logic one to this bit shuts down the ADC. The ADC must be disabled before shut down. The analog
comparator cannot use the ADC input MUX when the ADC is shut down.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 56
8. System Control and Reset
8.1 Resetting the AVR
During reset, all I/O Registers are set to their initial values, and the program starts execution from the Reset
Vector. The instruction placed at the Reset Vector must be a JMP – Absolute Jump – instruction to the reset
handling routine. If the program never enables an interrupt source, the Interrupt Vectors are not used, and
regular program code can be placed at these locations. This is also the case if the Reset Vector is in the
Application section while the Interrupt Vectors are in the Boot section or vice versa. The circuit diagram in Figure
8-1 on page 58 shows the reset logic. ”System and Reset Characteristics” on page 328 defines the electrical
parameters of the reset circuitry.
The I/O ports of the AVR are immediately reset to their initial state when a reset source goes active. This does
not require any clock source to be running.
After all reset sources have gone inactive, a delay counter is invoked, stretching the internal reset. This allows
the power to reach a stable level before normal operation starts. The time-out period of the delay counter is
defined by the user through the SUT and CKSEL Fuses. The different selections for the delay period are
presented in ”Clock Sources” on page 37.
ATmega164P/V/324P/V/644P/V
8.2 Reset Sources
The ATmega164P/324P/644P has five sources of reset:
Power-on Reset. The MCU is reset when the supply voltage is below the Power-on Reset threshold
(V
).
POT
External Reset. The MCU is reset when a low level is present on the RESET pin for longer than the
minimum pulse length.
Watchdog Reset. The MCU is reset when the Watchdog Timer period expires and the Watchdog is
enabled.
Brown-out Reset. The MCU is reset when the supply voltage V
(V
) and the Brown-out Detector is enabled.
BOT
JTAG AVR Reset. The MCU is reset as long as there is a logic one in the Reset Register, one of the scan
chains of the JTAG system. Refer to the section ”IEEE 1149.1 (JTAG) Boundary-scan” on page 266 for
details.
is below the Brown-out Reset threshold
CC
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 57
Figure 8-1. Reset Logic
MCU Status
Register (MCUSR)
Brown-out
Reset Circuit
BODLEVEL [2..0]
Delay Counters
CKSEL[3:0]
CK
TIMEOUT
WDRF
BORF
EXTRF
PORF
DATA BU S
Clock
Generator
SPIKE
FILTER
Pull-up Resistor
JTRF
JTAG Reset
Register
Watchdog
Oscillator
SUT[1:0]
Power-on Reset
Circuit
V
RESET
TIME-OUT
INTERNAL
RESET
t
TOUT
V
POT
V
RST
CC
ATmega164P/V/324P/V/644P/V
8.3 Power-on Reset
A Power-on Reset (POR) pulse is generated by an On-chip detection circuit. The detection level is defined in
”System and Reset Characteristics” on page 328. The POR is activated whenever V
is below the detection
CC
level. The POR circuit can be used to trigger the start-up Reset, as well as to detect a failure in supply voltage.
A Power-on Reset (POR) circuit ensures that the device is reset from Power-on. Reaching the Power-on Reset
threshold voltage invokes the delay counter, which determines how long the device is kept in RESET after V
rise. The RESET signal is activated again, without any delay, when V
Figure 8-2. MCU Start-up, RESET Tied to V
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 58
CC
decreases below the detection level.
CC
CC
Figure 8-3. MCU Start-up, RESET Extended Externally
RESET
TIME-OUT
INTERNAL
RESET
t
TOUT
V
POT
V
RST
V
CC
CC
8.4 External Reset
An External Reset is generated by a low level on the RESET pin. Reset pulses longer than the minimum pulse
width (see ”System and Reset Characteristics” on page 328) will generate a reset, even if the clock is not
running. Shorter pulses are not ensured to generate a reset. When the applied signal reaches the Reset
Threshold Voltage – V
t
TOUT –
has expired.
ATmega164P/V/324P/V/644P/V
– on its positive edge, the delay counter starts the MCU after the Time-out period –
RST
Figure 8-4. External Reset During Operation
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 59
8.5 Brown-out Detection
V
CC
RESET
TIME-OUT
INTERNAL
RESET
V
BOT-
V
BOT+
t
TOUT
CK
CC
ATmega164P/324P/644P has an On-chip Brown-out Detection (BOD) circuit for monitoring the VCC level during
operation by comparing it to a fixed trigger level. The trigger level for the BOD can be selected by the
BODLEVEL Fuses. The trigger level has a hysteresis to ensure spike free Brown-out Detection. The hysteresis
on the detection level should be interpreted as V
When the BOD is enabled, and V
60), the Brown-out Reset is immediately activated. When V
8-5 on page 60), the delay counter starts the MCU after the Time-out period t
The BOD circuit will only detect a drop in V
given in ”System and Reset Characteristics” on page 328.
Figure 8-5. Brown-out Reset During Operation
ATmega164P/V/324P/V/644P/V
= V
BOT+
decreases to a value below the trigger level (V
CC
if the voltage stays below the trigger level for longer than t
CC
+ V
BOT
increases above the trigger level (V
CC
HYST
/2 and V
= V
BOT-
BOT-
has expired.
TOUT
BOT
- V
HYST
/2.
in Figure 8-5 on page
in Figure
BOT+
BOD
8.6 Watchdog Reset
When the Watchdog times out, it will generate a short reset pulse of one CK cycle duration. On the falling edge
of this pulse, the delay timer starts counting the Time-out period t
of the Watchdog Timer.
Figure 8-6. Watchdog Reset During Operation
. Refer to page 68 for details on operation
TOUT
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 60
ATmega164P/V/324P/V/644P/V
8.7 Internal Voltage Reference
ATmega164P/324P/644P features an internal bandgap reference. This reference is used for Brown-out
Detection, and it can be used as an input to the Analog Comparator or the ADC.
8.7.1 Voltage Reference Enable Signals and Start-up Time
The voltage reference has a start-up time that may influence the way it should be used. The start-up time is
given in ”System and Reset Characteristics” on page 328. To save power, the reference is not always turned on.
The reference is on during the following situations:
1. When the BOD is enabled (by programming the BODLEVEL [2:0] Fuse).
2. When the bandgap reference is connected to the Analog Comparator (by setting the ACBG bit in ACSR).
3. When the ADC is enabled.
Thus, when the BOD is not enabled, after setting the ACBG bit or enabling the ADC, the user must always allow
the reference to start up before the output from the Analog Comparator or ADC is used. To reduce power
consumption in Power-down mode, the user can avoid the three conditions above to ensure that the reference
is turned off before entering Power-down mode.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 61
8.8 Watchdog Timer
8.8.1 Features
Clocked from separate On-chip Oscillator
•
• 3 Operating modes
– Interrupt
– System Reset
– Interrupt and System Reset
• Selectable Time-out period from 16 ms to 8s
• Possible Hardware fuse Watchdog always on (WDTON) for fail-safe mode
8.8.2 Overview
ATmega164P/324P/644P has an Enhanced Watchdog Timer (WDT). The WDT is a timer counting cycles of a
separate on-chip 128 kHz oscillator. The WDT gives an interrupt or a system reset when the counter reaches a
given time-out value. In normal operation mode, it is required that the system uses the WDR - Watchdog Timer
Reset - instruction to restart the counter before the time-out value is reached. If the system doesn't restart the
counter, an interrupt or system reset will be issued.
ATmega164P/V/324P/V/644P/V
Figure 8-7. Watchdog Timer
128 kHz
OSCILLATOR
OSC/2K
OSC/4K
OSC/8K
OSC/16K
OSC/32K
OSC/64K
OSC/128K
OSC/256K
OSC/512K
OSC/1024K
WDP0
WATCHDOG
RESET
WDE
WDIF
WDIE
WDP1
WDP2
WDP3
MCU RESET
INTERRUPT
In Interrupt mode, the WDT gives an interrupt when the timer expires. This interrupt can be used to wake the
device from sleep-modes, and also as a general system timer. One example is to limit the maximum time
allowed for certain operations, giving an interrupt when the operation has run longer than expected. In System
Reset mode, the WDT gives a reset when the timer expires. This is typically used to prevent system hang-up in
case of runaway code. The third mode, Interrupt and System Reset mode, combines the other two modes by
first giving an interrupt and then switch to System Reset mode. This mode will for instance allow a safe
shutdown by saving critical parameters before a system reset.
The Watchdog always on (WDTON) fuse, if programmed, will force the Watchdog Timer to System Reset mode.
With the fuse programmed the System Reset mode bit (WDE) and Interrupt mode bit (WDIE) are locked to 1
and 0 respectively. To further ensure program security, alterations to the Watchdog set-up must follow timed
sequences. The sequence for clearing WDE and changing time-out configuration is as follows:
1. In the same operation, write a logic one to the Watchdog change enable bit (WDCE) and WDE. A logic
one must be written to WDE regardless of the previous value of the WDE bit.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 62
ATmega164P/V/324P/V/644P/V
2. Within the next four clock cycles, write the WDE and Watchdog prescaler bits (WDP) as desired, but with
the WDCE bit cleared. This must be done in one operation.
The following code example shows one assembly and one C function for turning off the Watchdog Timer. The
example assumes that interrupts are controlled (for example by disabling interrupts globally) so that no
interrupts will occur during the execution of these functions.
Assembly Code Example
WDT_off:
; Turn off global interrupt
cli
; Reset Watchdog Timer
wdr
; Clear WDRF in MCUSR
in r16, MCUSR
andi r16, (0xff & (0<<WDRF))
out MCUSR, r16
; Write logical one to WDCE and WDE
; Keep old prescaler setting to prevent unintentional
time-out
in r16, WDTCSR
ori r16, (1<<WDCE) | (1<<WDE)
out WDTCSR, r16
; Turn off WDT
ldi r16, (0<<WDE)
out WDTCSR, r16
; Turn on global interrupt
sei
ret
C Code Example
(1)
(1)
void WDT_off(void)
{
__disable_interrupt();
__watchdog_reset();
/* Clear WDRF in MCUSR */
MCUSR &= ~(1<<WDRF);
/* Write logical one to WDCE and WDE */
/* Keep old prescaler setting to prevent unintentional
time-out */
WDTCSR |= (1<<WDCE) | (1<<WDE);
/* Turn off WDT */
WDTCSR = 0x00;
__enable_interrupt();
}
Note: 1. The example code assumes that the part specific header file is included.
Note: If the Watchdog is accidentally enabled, for example by a runaway pointer or brown-out condition, the
device will be reset and the Watchdog Timer will stay enabled. If the code is not set up to handle the Watchdog,
this might lead to an eternal loop of time-out resets. To avoid this situation, the application software should
always clear the Watchdog System Reset Flag (WDRF) and the WDE control bit in the initialisation routine,
even if the Watchdog is not in use.
The following code example shows one assembly and one C function for changing the time-out value of the
Watchdog Timer.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 63
ATmega164P/V/324P/V/644P/V
Assembly Code Example
WDT_Prescaler_Change:
; Turn off global interrupt
cli
; Reset Watchdog Timer
wdr
; Start timed sequence
in r16, WDTCSR
ori r16, (1<<WDCE) | (1<<WDE)
out WDTCSR, r16
; -- Got four cycles to set the new values from here ; Set new prescaler(time-out) value = 64K cycles (~0.5 s)
ldi r16, (1<<WDE) | (1<<WDP2) | (1<<WDP0)
out WDTCSR, r16
; -- Finished setting new values, used 2 cycles ; Turn on global interrupt
sei
ret
C Code Example
void WDT_Prescaler_Change(void)
{
s) */
}
(1)
__disable_interrupt();
__watchdog_reset();
/* Start timed equence */
WDTCSR |= (1<<WDCE) | (1<<WDE);
/* Set new prescaler(time-out) value = 64K cycles (~0.5
WDTCSR = (1<<WDE) | (1<<WDP2) | (1<<WDP0);
__enable_interrupt();
(1)
Note: 1. The example code assumes that the part specific header file is included.
Note: The Watchdog Timer should be reset before any change of the WDP bits, since a change in the WDP bits
can result in a time-out when switching to a shorter time-out period.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 64
8.9 Register Description
8.9.1 MCUSR – MCU Status Register
The MCU Status Register provides information on which reset source caused an MCU reset.
Bit 76543210
0x34 (0x54)
Read/Write R R R R/W R/W R/W R/W R/W
Initial Value 0 0 0 See Bit Description
• Bit 4 – JTRF: JTAG Reset Flag
This bit is set if a reset is being caused by a logic one in the JTAG Reset Register selected by the JTAG
instruction AVR_RESET. This bit is reset by a Power-on Reset, or by writing a logic zero to the flag.
• Bit 3 – WDRF: Watchdog Reset Flag
This bit is set if a Watchdog Reset occurs. The bit is reset by a Power-on Reset, or by writing a logic zero to the
flag.
• Bit 2 – BORF: Brown-out Reset Flag
This bit is set if a Brown-out Reset occurs. The bit is reset by a Power-on Reset, or by writing a logic zero to the
flag.
– – – JTRF WDRF BORF EXTRF PORF MCUSR
ATmega164P/V/324P/V/644P/V
• Bit 1 – EXTRF: External Reset Flag
This bit is set if an External Reset occurs. The bit is reset by a Power-on Reset, or by writing a logic zero to the
flag.
• Bit 0 – PORF: Power-on Reset Flag
This bit is set if a Power-on Reset occurs. The bit is reset only by writing a logic zero to the flag.
To make use of the Reset Flags to identify a reset condition, the user should read and then Reset the MCUSR
as early as possible in the program. If the register is cleared before another reset occurs, the source of the reset
can be found by examining the Reset Flags.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 65
8.9.2 WDTCSR – Watchdog Timer Control Register
Bit 76543210
(0x60) WDIF WDIE WDP3 WDCE WDE WDP2 WDP1 WDP0 WDTCSR
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 X 0 0 0
• Bit 7 - WDIF: Watchdog Interrupt Flag
This bit is set when a time-out occurs in the Watchdog Timer and the Watchdog Timer is configured for interrupt.
WDIF is cleared by hardware when executing the corresponding interrupt handling vector. Alternatively, WDIF is
cleared by writing a logic one to the flag. When the I-bit in SREG and WDIE are set, the Watchdog Time-out
Interrupt is executed.
• Bit 6 - WDIE: Watchdog Interrupt Enable
When this bit is written to one and the I-bit in the Status Register is set, the Watchdog Interrupt is enabled. If
WDE is cleared in combination with this setting, the Watchdog Timer is in Interrupt Mode, and the
corresponding interrupt is executed if time-out in the Watchdog Timer occurs.
If WDE is set, the Watchdog Timer is in Interrupt and System Reset Mode. The first time-out in the Watchdog
Timer will set WDIF. Executing the corresponding interrupt vector will clear WDIE and WDIF automatically by
hardware (the Watchdog goes to System Reset Mode). This is useful for keeping the Watchdog Timer security
while using the interrupt. To stay in Interrupt and System Reset Mode, WDIE must be set after each interrupt.
This should however not be done within the interrupt service routine itself, as this might compromise the safetyfunction of the Watchdog System Reset mode. If the interrupt is not executed before the next time-out, a System
Reset will be applied.
ATmega164P/V/324P/V/644P/V
Table 8-1. Watchdog Timer Configuration
WDTON WDE WDIE Mode Action on Time-out
1 0 0 Stopped None
1 0 1 Interrupt Mode Interrupt
1 1 0 System Reset Mode Reset
111
0 x x System Reset Mode Reset
Interrupt and System Reset
Mode
Interrupt, then go to System
Reset Mode
• Bit 4 - WDCE: Watchdog Change Enable
This bit is used in timed sequences for changing WDE and prescaler bits. To clear the WDE bit, and/or change
the prescaler bits, WDCE must be set.
Once written to one, hardware will clear WDCE after four clock cycles.
• Bit 3 - WDE: Watchdog System Reset Enable
WDE is overridden by WDRF in MCUSR. This means that WDE is always set when WDRF is set. To clear
WDE, WDRF must be cleared first. This feature ensures multiple resets during conditions causing failure, and a
safe start-up after the failure.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 66
ATmega164P/V/324P/V/644P/V
• Bit 5, 2:0 - WDP3:0: Watchdog Timer Prescaler 3, 2, 1 and 0
The WDP3:0 bits determine the Watchdog Timer prescaling when the Watchdog Timer is running. The different
prescaling values and their corresponding time-out periods are shown in Table 8-2 on page 67.
.
Table 8-2. Watchdog Timer Prescale Select
Number of WDT Oscillator
WDP3 WDP2 WDP1 WDP0
0000 2K (2048) cycles 16 ms
0001 4K (4096) cycles 32 ms
0010 8K (8192) cycles 64 ms
0011 16K (16384) cycles 0.125s
0100 32K (32768) cycles 0.25s
0101 64K (65536) cycles 0.5s
0110 128K (131072) cycles 1.0s
0111 256K (262144) cycles 2.0s
1000 512K (524288) cycles 4.0s
10011024K (1048576) cycles 8.0s
Cycles
Typical Time-out at
V
= 5.0V
CC
1010
1011
1100
1101
1110
1111
Reserved
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 67
ATmega164P/V/324P/V/644P/V
9. Interrupts
9.1 Overview
This section describes the specifics of the interrupt handling as performed in ATmega164P/324P/644P. For a
general explanation of the AVR interrupt handling, refer to ”Reset and Interrupt Handling” on page 23.
9.2 Interrupt Vectors in ATmega164P/324P/644P
Table 9-1. Reset and Interrupt Vectors
Vector
No.
1 $0000
2 $0002 INT0 External Interrupt Request 0
3 $0004 INT1 External Interrupt Request 1
4 $0006 INT2 External Interrupt Request 2
5 $0008 PCINT0 Pin Change Interrupt Request 0
6 $000A PCINT1 Pin Change Interrupt Request 1
Program
Address
(1)
(2)
Source Interrupt Definition
RESET
External Pin, Power-on Reset, Brown-out Reset,
Watchdog Reset, and JTAG AVR Reset
7 $000C PCINT2 Pin Change Interrupt Request 2
8 $000E PCINT3 Pin Change Interrupt Request 3
9 $0010 WDT Watchdog Time-out Interrupt
10 $0012 TIMER2_COMPA Timer/Counter2 Compare Match A
11 $0014 TIMER2_COMPB Timer/Counter2 Compare Match B
12 $0016 TIMER2_OVF Timer/Counter2 Overflow
13 $0018 TIMER1_CAPT Timer/Counter1 Capture Event
14 $001A TIMER1_COMPA Timer/Counter1 Compare Match A
15 $001C TIMER1_COMPB Timer/Counter1 Compare Match B
16 $001E TIMER1_OVF Timer/Counter1 Overflow
17 $0020 TIMER0_COMPA Timer/Counter0 Compare Match A
18 $0022 TIMER0_COMPB Timer/Counter0 Compare match B
19 $0024 TIMER0_OVF Timer/Counter0 Overflow
20 $0026 SPI_STC SPI Serial Transfer Complete
21 $0028 USART0_RX USART0 Rx Complete
22 $002A USART0_UDRE USART0 Data Register Empty
23 $002C USART0_TX USART0 Tx Complete
24 $002E ANALOG_COMP Analog Comparator
25 $0030 ADC ADC Conversion Complete
26 $0032 EE_READY EEPROM Ready
27 $0034 TWI 2-wire Serial Interface
28 $0036 SPM_READY Store Program Memory Ready
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 68
ATmega164P/V/324P/V/644P/V
Table 9-1. Reset and Interrupt Vectors (Continued)
Vector
No.
29 $0038 USART1_RX USART1 Rx Complete
30 $003A USART1_UDRE USART1 Data Register Empty
31 $003C USART1_TX USART1 Tx Complete
Notes: 1. When the BOOTRST Fuse is programmed, the device will jump to the Boot Loader address at reset, see
Table 9-2 shows reset and Interrupt Vectors placement for the various combinations of BOOTRST and IVSEL
settings. If the program never enables an interrupt source, the Interrupt Vectors are not used, and regular
program code can be placed at these locations. This is also the case if the Reset Vector is in the Application
section while the Interrupt Vectors are in the Boot section or vice versa.
Table 9-2. Reset and Interrupt Vectors Placement
BOOTRST IVSEL Reset Address Interrupt Vectors Start Address
Program
Address
”Memory Programming” on page 292.
2. When the IVSEL bit in MCUCR is set, Interrupt Vectors will be moved to the start of the Boot Flash Section.
The address of each Interrupt Vector will then be the address in this table added to the start address of the
Boot Flash Section.
1 0 0x0000 0x0002
1 1 0x0000 Boot Reset Address + 0x0002
(2)
Source Interrupt Definition
(1)
0 0 Boot Reset Address 0x0002
0 1 Boot Reset Address Boot Reset Address + 0x0002
Note: 1. The Boot Reset Address is shown in Table 23-7 on page 287. For the BOOTRST Fuse “1” means
unprogrammed while “0” means programmed.
The most typical and general program setup for the Reset and Interrupt Vector Addresses in
ATmega164P/324P/644P is:
Address Labels Code Comments
0x0000 jmp RESET ; Reset
0x0002 jmp INT0 ; IRQ0
0x0004 jmp INT1 ; IRQ1
0x0006 jmp INT2 ; IRQ2
0x0008 jmp PCINT0 ; PCINT0
0x000A jmp PCINT1 ; PCINT1
0x000C jmp PCINT2 ; PCINT2
0x000E jmp PCINT3 ; PCINT3
0x0010 jmp WDT ; Watchdog Timeout
0x0012 jmp TIM2_COMPA ; Timer2 CompareA
0x0014 jmp TIM2_COMPB ; Timer2 CompareB
0x0016 jmp TIM2_OVF ; Timer2 Overflow
0x0018 jmp TIM1_CAPT ; Timer1 Capture
0x001A jmp TIM1_COMPA ; Timer1 CompareA
0x001C jmp TIM1_COMPB ; Timer1 CompareB
0x001E jmp TIM1_OVF ; Timer1 Overflow
0x0020 jmp TIM0_COMPA ; Timer0 CompareA
0x0022 jmp TIM0_COMPB ; Timer0 CompareB
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 69
ATmega164P/V/324P/V/644P/V
0x0024 jmp TIM0_OVF ; Timer0 Overflow
0x0026 jmp SPI_STC ; SPI Transfer Complete
0x0028 jmp USART0_RXC ; USART0 RX Complete
0x002A jmp USART0_UDRE ; USART0,UDR Empty
0x002C jmp USART0_TXC ; USART0 TX Complete
0x002E jmp ANA_COMP ; Analog Comparator
0x0030 jmp ADC ; ADC Conversion
Complete
0x0032 jmp EE_RDY ; EEPROM Ready
0x0034 jmp TWI ; 2-wire Serial
0x0036 jmp SPM_RDY ; SPM Ready
0x0038 jmp USART1_RXC ; USART1 RX Complete
0x003A jmp USART1_UDRE ; USART1,UDR Empty
0x003C jmp USART1_TXC ; USART1 TX Complete
;
0x003E RES
ET:
0x003F out SPH,r16 ; Set Stack Pointer to top of
0x0040 ldi r16,
0x0041 out SPL,r16
0x0042 sei ; Enable interrupts
0x0043 <instr
... ... ... ...
ldi r16,
high(RAMEND)
low(RAMEND)
xxx
>
; Main program start
RAM
When the BOOTRST Fuse is unprogrammed, the Boot section size set to 8 Kbytes and the IVSEL bit in the
MCUCR Register is set before any interrupts are enabled, the most typical and general program setup for the
Reset and Interrupt Vector Addresses is:
Address Labels CodeComments
0x00000 RESET: ldir16,high(RAMEND); Main
program start
0x00001 outSPH,r16; Set Stack
Pointer to top of RAM
0x00002 ldir16,low(RAMEND)
0x00003 outSPL,r16
0x00004 sei; Enable interrupts
0x00005 <instr> xxx
;
.org 0x1F002
0x1F002 jmpEXT_INT0; IRQ0 Handler
0x1F004 jmpEXT_INT1; IRQ1 Handler
... ......;
0x1FO36 jmpSPM_RDY; SPM Ready
Handler
When the BOOTRST Fuse is programmed and the Boot section size set to 8 Kbytes, the most typical and
general program setup for the Reset and Interrupt Vector Addresses is:
Address Labels CodeComments
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 70
ATmega164P/V/324P/V/644P/V
.org 0x0002
0x00002 jmpEXT_INT0; IRQ0 Handler
0x00004 jmpEXT_INT1; IRQ1 Handler
... ......;
0x00036 jmpSPM_RDY; SPM Ready
Handler
;
.org 0x1F000
0x1F000 RESET: ldir16,high(RAMEND); Main
program start
0x1F001 outSPH,r16; Set Stack
Pointer to top of RAM
0x1F002 ldir16,low(RAMEND)
0x1F003 outSPL,r16
0x1F004 sei; Enable interrupts
0x1F005 <instr> xxx
When the BOOTRST Fuse is programmed, the Boot section size set to 8 Kbytes and the IVSEL bit in the
MCUCR Register is set before any interrupts are enabled, the most typical and general program setup for the
Reset and Interrupt Vector Addresses is:
Address Labels CodeComments
;
.org 0x1F000
0x1F000 jmpRESET; Reset handler
0x1F002 jmpEXT_INT0; IRQ0 Handler
0x1F004 jmpEXT_INT1; IRQ1 Handler
... ......;
0x1F036 jmpSPM_RDY; SPM Ready
Handler
;
0x1F03E RESET: ldir16,high(RAMEND); Main
program start
0x1F03F outSPH,r16; Set Stack
Pointer to top of RAM
0x1F040 ldir16,low(RAMEND)
0x1F041 outSPL,r16
0x1F042 sei; Enable interrupts
0x1FO43 <instr> xxx
9.2.1 Moving Interrupts Between Application and Boot Space
The General Interrupt Control Register controls the placement of the Interrupt Vector table.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 71
9.3 Register Description
9.3.1 MCUCR – MCU Control Register
Bit 76543210
0x35 (0x55)
Read/Write R/W R R R/W R R R/W R/W
Initial Value 0 0 0 0 0 0 0 0
• Bit 1 – IVSEL: Interrupt Vector Select
When the IVSEL bit is cleared (zero), the Interrupt Vectors are placed at the start of the Flash memory. When
this bit is set (one), the Interrupt Vectors are moved to the beginning of the Boot Loader section of the Flash.
The actual address of the start of the Boot Flash Section is determined by the BOOTSZ Fuses. Refer to the
section ”Memory Programming” on page 292 for details. To avoid unintentional changes of Interrupt Vector
tables, a special write procedure must be followed to change the IVSEL bit:
1. Write the Interrupt Vector Change Enable (IVCE) bit to one.
2. Within four cycles, write the desired value to IVSEL while writing a zero to IVCE.
Interrupts will automatically be disabled while this sequence is executed. Interrupts are disabled in the cycle
IVCE is set, and they remain disabled until after the instruction following the write to IVSEL. If IVSEL is not
written, interrupts remain disabled for four cycles. The I-bit in the Status Register is unaffected by the automatic
disabling.
Note: If Interrupt Vectors are placed in the Boot Loader section and Boot Lock bit BLB02 is programmed, interrupts are
disabled while executing from the Application section. If Interrupt Vectors are placed in the Application section and
Boot Lock bit BLB12 is programed, interrupts are disabled while executing from the Boot Loader section. Refer to
the section ”Memory Programming” on page 292 for details on Boot Lock bits.
JTD BODS BODSE PUD – – IVSEL IVCE MCUCR
ATmega164P/V/324P/V/644P/V
• Bit 0 – IVCE: Interrupt Vector Change Enable
The IVCE bit must be written to logic one to enable change of the IVSEL bit. IVCE is cleared by hardware four
cycles after it is written or when IVSEL is written. Setting the IVCE bit will disable interrupts, as explained in the
IVSEL description above. See the following Code Example.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 72
Assembly Code Example
Move_interrupts:
; Get MCUCR
in r16, MCUCR
mov r17, r16
; Enable change of Interrupt Vectors
ori r16, (1<<IVCE)
out MCUCR, r16
; Move interrupts to Boot Flash section
ori r17, (1<<IVSEL)
out MCUCR, r17
ret
C Code Example
void Move_interrupts(void)
{
uchar temp;
/* GET MCUCR*/
temp = MCUCR;
/* Enable change of Interrupt Vectors */
MCUCR = temp|(1<<IVCE);
/* Move interrupts to Boot Flash section */
MCUCR = temp|(1<<IVSEL);
}
ATmega164P/V/324P/V/644P/V
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 73
10. External Interrupts
10.1 Overview
The External Interrupts are triggered by the INT2:0 pin or any of the PCINT31:0 pins. Observe that, if enabled,
the interrupts will trigger even if the INT2:0 or PCINT31:0 pins are configured as outputs. This feature provides
a way of generating a software interrupt.
The Pin change interrupt PCI3 will trigger if any enabled PCINT31:24 pin toggle, Pin change interrupt PCI2 will
trigger if any enabled PCINT23:16 pin toggles, Pin change interrupt PCI1 if any enabled PCINT15:8 toggles and
Pin change interrupts PCI0 will trigger if any enabled PCINT7:0 pin toggles. PCMSK3, PCMSK2, PCMSK1 and
PCMSK0 Registers control which pins contribute to the pin change interrupts. Pin change interrupts on
PCINT31:0 are detected asynchronously. This implies that these interrupts can be used for waking the part also
from sleep modes other than Idle mode.
The External Interrupts can be triggered by a falling or rising edge or a low level. This is set up as indicated in
the specification for the External Interrupt Control Registers – EICRA (INT2:0). When the external interrupt is
enabled and is configured as level triggered, the interrupt will trigger as long as the pin is held low. Low level
interrupts and the edge interrupt on INT2:0 are detected asynchronously. This implies that these interrupts can
be used for waking the part also from sleep modes other than Idle mode. The I/O clock is halted in all sleep
modes except Idle mode.
Note that if a level triggered interrupt is used for wake-up from Power-down, the required level must be held long
enough for the MCU to complete the wake-up to trigger the level interrupt. If the level disappears before the end
of the Start-up Time, the MCU will still wake up, but no interrupt will be generated. The start-up time is defined
by the SUT and CKSEL Fuses as described in ”System Clock and Clock Options” on page 36.
ATmega164P/V/324P/V/644P/V
10.2 Register Description
10.2.1 EICRA – External Interrupt Control Register A
The External Interrupt Control Register A contains control bits for interrupt sense control.
Bit 76543210
(0x69) – – ISC21 ISC20 ISC11 ISC10 ISC01 ISC00 EICRA
Read/Write R R R/W R/W R/W R/W R/W R/W
Initial Value00000000
• Bits 7:6 – Reserved
These bits are reserved in the ATmega164P/324P/644P, and will always read as zero.
• Bits 5:0 – ISC21, ISC20 – ISC00, ISC00: External Interrupt 2 - 0 Sense Control Bits
The External Interrupts 2 - 0 are activated by the external pins INT2:0 if the SREG I-flag and the corresponding
interrupt mask in the EIMSK is set. The level and edges on the external pins that activate the interrupts are
defined in Table 10-1. Edges on INT2..INT0 are registered asynchronously. Pulses on INT2:0 pins wider than
the minimum pulse width given in ”External Interrupts Characteristics” on page 328 will generate an interrupt.
Shorter pulses are not ensured to generate an interrupt. If low level interrupt is selected, the low level must be
held until the completion of the currently executing instruction to generate an interrupt. If enabled, a level
triggered interrupt will generate an interrupt request as long as the pin is held low. When changing the ISCn bit,
an interrupt can occur. Therefore, it is recommended to first disable INTn by clearing its Interrupt Enable bit in
the EIMSK Register. Then, the ISCn bit can be changed. Finally, the INTn interrupt flag should be cleared by
writing a logical one to its Interrupt Flag bit (INTFn) in the EIFR Register before the interrupt is re-enabled.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 74
ATmega164P/V/324P/V/644P/V
Table 10-1. Interrupt Sense Control
ISCn1 ISCn0 Description
0 0 The low level of INTn generates an interrupt request.
0 1 Any edge of INTn generates asynchronously an interrupt request.
1 0 The falling edge of INTn generates asynchronously an interrupt request.
1 1 The rising edge of INTn generates asynchronously an interrupt request.
Note: 1. n = 2, 1 or 0.
When changing the ISCn1/ISCn0 bits, the interrupt must be disabled by clearing its Interrupt Enable bit in the
EIMSK Register. Otherwise an interrupt can occur when the bits are changed.
(1)
10.2.2 EIMSK – External Interrupt Mask Register
Bit 76543210
0x1D (0x3D)
Read/Write RRRRRR/WR/WR/W
Initial Value00000000
– – – – – INT2 INT1 IINT0 EIMSK
• Bits 2:0 – INT2:0: External Interrupt Request 2 - 0 Enable
When an INT2:0 bit is written to one and the I-bit in the Status Register (SREG) is set (one), the corresponding
external pin interrupt is enabled. The Interrupt Sense Control bits in the External Interrupt Control Register,
EICRA, defines whether the external interrupt is activated on rising or falling edge or level sensed. Activity on
any of these pins will trigger an interrupt request even if the pin is enabled as an output. This provides a way of
generating a software interrupt.
10.2.3 EIFR –External Interrupt Flag Register
Bit 76543210
0x1C (0x3C)
Read/WriteR/WRRRRR/WR/WR/W
Initial Value00000000
– – – – – INTF2 INTF1 IINTF0 EIFR
• Bits 2:0 – INTF2:0: External Interrupt Flags 2 - 0
When an edge or logic change on the INT2:0 pin triggers an interrupt request, INTF2:0 becomes set (one). If the
I-bit in SREG and the corresponding interrupt enable bit, INT2:0 in EIMSK, are set (one), the MCU will jump to
the interrupt vector. The flag is cleared when the interrupt routine is executed. Alternatively, the flag can be
cleared by writing a logical one to it. These flags are always cleared when INT2:0 are configured as level
interrupt. Note that when entering sleep mode with the INT2:0 interrupts disabled, the input buffers on these
pins will be disabled. This may cause a logic change in internal signals which will set the INTF2:0 flags. See
”Digital Input Enable and Sleep Modes” on page 83 for more information.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 75
10.2.4 PCICR – Pin Change Interrupt Control Register
Bit 76543210
(0x68)
Read/Write R R R R R/W R/W R/W R/W
Initial Value 00000000
– – – – PCIE3 PCIE2 PCIE1 PCIE0 PCICR
• Bit 3 – PCIE3: Pin Change Interrupt Enable 3
When the PCIE3 bit is set (one) and the I-bit in the Status Register (SREG) is set (one), pin change interrupt 3 is
enabled. Any change on any enabled PCINT31..24 pin will cause an interrupt. The corresponding interrupt of
Pin Change Interrupt Request is executed from the PCI3 Interrupt Vector. PCINT31..24 pins are enabled
individually by the PCMSK3 Register.
• Bit 2 – PCIE2: Pin Change Interrupt Enable 2
When the PCIE2 bit is set (one) and the I-bit in the Status Register (SREG) is set (one), pin change interrupt 2 is
enabled. Any change on any enabled PCINT23..16 pin will cause an interrupt. The corresponding interrupt of
Pin Change Interrupt Request is executed from the PCI2 Interrupt Vector. PCINT23..16 pins are enabled
individually by the PCMSK2 Register.
ATmega164P/V/324P/V/644P/V
• Bit 1 – PCIE1: Pin Change Interrupt Enable 1
When the PCIE1 bit is set (one) and the I-bit in the Status Register (SREG) is set (one), pin change interrupt 1 is
enabled. Any change on any enabled PCINT15..8 pin will cause an interrupt. The corresponding interrupt of Pin
Change Interrupt Request is executed from the PCI1 Interrupt Vector. PCINT15..8 pins are enabled individually
by the PCMSK1 Register.
• Bit 0 – PCIE0: Pin Change Interrupt Enable 0
When the PCIE0 bit is set (one) and the I-bit in the Status Register (SREG) is set (one), pin change interrupt 0 is
enabled. Any change on any enabled PCINT7..0 pin will cause an interrupt. The corresponding interrupt of Pin
Change Interrupt Request is executed from the PCI0 Interrupt Vector. PCINT7..0 pins are enabled individually
by the PCMSK0 Register.
10.2.5 PCIFR – Pin Change Interrupt Flag Register
Bit 76543210
0x1B (0x3B)
Read/Write R R R R R/W R/W R/W R/W
Initial Value 00000000
– – PCIF3 PCIF2 PCIF1 PCIF0 PCIFR
• Bit 3– PCIF3: Pin Change Interrupt Flag 3
When a logic change on any PCINT31..24 pin triggers an interrupt request, PCIF3 becomes set (one). If the I-bit
in SREG and the PCIE3 bit in PCICR are set (one), the MCU will jump to the corresponding Interrupt Vector.
The flag is cleared when the interrupt routine is executed. Alternatively, the flag can be cleared by writing a
logical one to it.
• Bit 2 – PCIF2: Pin Change Interrupt Flag 2
When a logic change on any PCINT23..16 pin triggers an interrupt request, PCIF2 becomes set (one). If the I-bit
in SREG and the PCIE2 bit in PCICR are set (one), the MCU will jump to the corresponding Interrupt Vector.
The flag is cleared when the interrupt routine is executed. Alternatively, the flag can be cleared by writing a
logical one to it.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 76
• Bit 1 – PCIF1: Pin Change Interrupt Flag 1
When a logic change on any PCINT15..8 pin triggers an interrupt request, PCIF1 becomes set (one). If the I-bit
in SREG and the PCIE1 bit in PCICR are set (one), the MCU will jump to the corresponding Interrupt Vector.
The flag is cleared when the interrupt routine is executed. Alternatively, the flag can be cleared by writing a
logical one to it.
• Bit 0 – PCIF0: Pin Change Interrupt Flag 0
When a logic change on any PCINT7..0 pin triggers an interrupt request, PCIF0 becomes set (one). If the I-bit in
SREG and the PCIE0 bit in PCICR are set (one), the MCU will jump to the corresponding Interrupt Vector. The
flag is cleared when the interrupt routine is executed. Alternatively, the flag can be cleared by writing a logical
one to it.
10.2.6 PCMSK3 – Pin Change Mask Register 3
Bit 76543210
(0x73)
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
PCINT31 PCINT30 PCINT29 PCINT28 PCINT27 PCINT26 PCINT25 PCINT24 PCMSK3
ATmega164P/V/324P/V/644P/V
• Bit 7:0 – PCINT31:24: Pin Change Enable Mask 31:24
Each PCINT31:24-bit selects whether pin change interrupt is enabled on the corresponding I/O pin. If
PCINT31:24 is set and the PCIE2 bit in PCICR is set, pin change interrupt is enabled on the corresponding I/O
pin. If PCINT31..24 is cleared, pin change interrupt on the corresponding I/O pin is disabled.
10.2.7 PCMSK2 – Pin Change Mask Register 2
Bit 76543210
(0x6D)
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
PCINT23 PCINT22 PCINT21 PCINT20 PCINT19 PCINT18 PCINT17 PCINT16 PCMSK2
• Bit 7:0 – PCINT23:16: Pin Change Enable Mask 23..16
Each PCINT23:16-bit selects whether pin change interrupt is enabled on the corresponding I/O pin. If
PCINT23:16 is set and the PCIE2 bit in PCICR is set, pin change interrupt is enabled on the corresponding I/O
pin. If PCINT23..16 is cleared, pin change interrupt on the corresponding I/O pin is disabled.
10.2.8 PCMSK1 – Pin Change Mask Register 1
Bit 76543210
(0x6C)
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
PCINT15 PCINT14 PCINT13 PCINT12 PCINT11 PCINT10 PCINT9 PCINT8 PCMSK1
• Bit 7:0 – PCINT15:8: Pin Change Enable Mask 15..8
Each PCINT15:8-bit selects whether pin change interrupt is enabled on the corresponding I/O pin. If PCINT15:8
is set and the PCIE1 bit in PCICR is set, pin change interrupt is enabled on the corresponding I/O pin. If
PCINT15:8 is cleared, pin change interrupt on the corresponding I/O pin is disabled.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 77
10.2.9 PCMSK0 – Pin Change Mask Register 0
Bit 76543210
(0x6B) PCINT7 PCINT6 PCINT5 PCINT4 PCINT3 PCINT2 PCINT1 PCINT0 PCMSK0
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
• Bit 7:0 – PCINT7:0: Pin Change Enable Mask 7..0
Each PCINT7:0 bit selects whether pin change interrupt is enabled on the corresponding I/O pin. If PCINT7:0 is
set and the PCIE0 bit in PCICR is set, pin change interrupt is enabled on the corresponding I/O pin. If PCINT7..0
is cleared, pin change interrupt on the corresponding I/O pin is disabled.
ATmega164P/V/324P/V/644P/V
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 78
11. I/O-Ports
C
pin
Logic
R
pu
See Figure
"General Digital I/O" for
Details
Pxn
11.1 Overview
All AVR ports have true Read-Modify-Write functionality when used as general digital I/O ports. This means that
the direction of one port pin can be changed without unintentionally changing the direction of any other pin with
the SBI and CBI instructions. The same applies when changing drive value (if configured as output) or
enabling/disabling of pull-up resistors (if configured as input). Each output buffer has symmetrical drive
characteristics with both high sink and source capability. The pin driver is strong enough to drive LED displays
directly. All port pins have individually selectable pull-up resistors with a supply-voltage invariant resistance. All
I/O pins have protection diodes to both V
Characteristics – TA = -40°C to 85°C” on page 322 for a complete list of parameters.
Figure 11-1. I/O Pin Equivalent Schematic
ATmega164P/V/324P/V/644P/V
and Ground as indicated in Figure 11-1. Refer to ”Electrical
CC
All registers and bit references in this section are written in general form. A lower case “x” represents the
numbering letter for the port, and a lower case “n” represents the bit number. However, when using the register
or bit defines in a program, the precise form must be used. For example, PORTB3 for bit no. 3 in Port B, here
documented generally as PORTxn. The physical I/O Registers and bit locations are listed in ”Register
Description” on page 98.
Three I/O memory address locations are allocated for each port, one each for the Data Register – PORTx, Data
Direction Register – DDRx, and the Port Input Pins – PINx. The Port Input Pins I/O location is read only, while
the Data Register and the Data Direction Register are read/write. However, writing a logic one to a bit in the
PINx Register, will result in a toggle in the corresponding bit in the Data Register. In addition, the Pull-up Disable
– PUD bit in MCUCR disables the pull-up function for all pins in all ports when set.
Using the I/O port as General Digital I/O is described in ”Ports as General Digital I/O” on page 80. Most port pins
are multiplexed with alternate functions for the peripheral features on the device. How each alternate function
interferes with the port pin is described in ”Alternate Port Functions” on page 85. Refer to the individual module
sections for a full description of the alternate functions.
Note that enabling the alternate function of some of the port pins does not affect the use of the other pins in the
port as general digital I/O.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 79
11.2 Ports as General Digital I/O
The ports are bi-directional I/O ports with optional internal pull-ups. Figure 11-2 shows a functional description of
one I/O-port pin, here generically called Pxn.
ATmega164P/V/324P/V/644P/V
Figure 11-2. General Digital I/O
Pxn
PUD: PULLUP DISABLE
SLEEP: SLEEP CONTROL
clk
I/O
(1)
SLEEP
: I/O CLOCK
SYNCHRONIZER
DLQ
D
PINxn
Q
PUD
Q
D
DDxn
Q
CLR
RESET
D
Q
PORTxn
Q
CLR
RESET
Q
Q
WDx: WRITE DDRx
RDx: READ DDRx
WRx: WRITE PORTx
RRx: READ PORTx REGISTER
RPx: READ PORTx PIN
WPx: WRITE PINx REGISTER
RRx
WDx
RDx
RPx
clk
1
0
I/O
WRx
DATA BUS
WPx
Note: 1. WRx, WPx, WDx, RRx, RPx, and RDx are common to all pins within the same port. clk
common to all ports.
11.2.1 Configuring the Pin
Each port pin consists of three register bits: DDxn, PORTxn, and PINxn. As shown in ”Register Description” on
page 98, the DDxn bits are accessed at the DDRx I/O address, the PORTxn bits at the PORTx I/O address, and
the PINxn bits at the PINx I/O address.
The DDxn bit in the DDRx Register selects the direction of this pin. If DDxn is written logic one, Pxn is
configured as an output pin. If DDxn is written logic zero, Pxn is configured as an input pin.
If PORTxn is written logic one when the pin is configured as an input pin, the pull-up resistor is activated. To
switch the pull-up resistor off, PORTxn has to be written logic zero or the pin has to be configured as an output
pin. The port pins are tri-stated when reset condition becomes active, even if no clocks are running.
If PORTxn is written logic one when the pin is configured as an output pin, the port pin is driven high (one). If
PORTxn is written logic zero when the pin is configured as an output pin, the port pin is driven low (zero).
11.2.2 Toggling the Pin
Writing a logic one to PINxn toggles the value of PORTxn, independent on the value of DDRxn. Note that the
SBI instruction can be used to toggle one single bit in a port.
, SLEEP, and PUD are
I/O
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 80
11.2.3 Switching Between Input and Output
XXX in r17, PINx
0x00 0xFF
INSTRUCTIONS
SYNC LATCH
PINxn
r17
XXX
SYSTEM CLK
t
pd, max
t
pd, min
When switching between tri-state ({DDxn, PORTxn} = 0b00) and output high ({DDxn, PORTxn} = 0b11), an
intermediate state with either pull-up enabled {DDxn, PORTxn} = 0b01) or output low ({DDxn, PORTxn} = 0b10)
must occur. Normally, the pull-up enabled state is fully acceptable, as a high-impedant environment will not
notice the difference between a strong high driver and a pull-up. If this is not the case, the PUD bit in the
MCUCR Register can be set to disable all pull-ups in all ports.
Switching between input with pull-up and output low generates the same problem. The user must use either the
tri-state ({DDxn, PORTxn} = 0b00) or the output high state ({DDxn, PORTxn} = 0b11) as an intermediate step.
Table 11-1 summarizes the control signals for the pin value.
Table 11-1. Port Pin Configurations
PUD
DDxn PORTxn
0 0 X Input No Tri-state (Hi-Z)
0 1 0 Input Yes Pxn will source current if ext. pulled low.
0 1 1 Input No Tri-state (Hi-Z)
1 0 X Output No Output Low (Sink)
1 1 X Output No Output High (Source)
(in MCUCR) I/O Pull-up Comment
ATmega164P/V/324P/V/644P/V
11.2.4 Reading the Pin Value
Independent of the setting of Data Direction bit DDxn, the port pin can be read through the PINxn Register bit.
As shown in Figure 11-2, the PINxn Register bit and the preceding latch constitute a synchronizer. This is
needed to avoid metastability if the physical pin changes value near the edge of the internal clock, but it also
introduces a delay. Figure 11-3 shows a timing diagram of the synchronization when reading an externally
applied pin value. The maximum and minimum propagation delays are denoted t
Figure 11-3. Synchronization when Reading an Externally Applied Pin value
pd,max
and t
respectively.
pd,min
Consider the clock period starting shortly after the first falling edge of the system clock. The latch is closed when
the clock is low, and goes transparent when the clock is high, as indicated by the shaded region of the “SYNC
LATCH” signal. The signal value is latched when the system clock goes low. It is clocked into the PINxn
Register at the succeeding positive clock edge. As indicated by the two arrows tpd,max and tpd,min, a single
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 81
ATmega164P/V/324P/V/644P/V
out PORTx, r16 nop in r17, PINx
0xFF
0x00 0xFF
SYSTEM CLK
r16
INSTRUCTIONS
SYNC LATCH
PINxn
r17
t
pd
signal transition on the pin will be delayed between ½ and 1½ system clock period depending upon the time of
assertion.
When reading back a software assigned pin value, a nop instruction must be inserted as indicated in Figure 11-
4. The out instruction sets the “SYNC LATCH” signal at the positive edge of the clock. In this case, the delay tpd
through the synchronizer is 1 system clock period.
Figure 11-4. Synchronization when Reading a Software Assigned Pin Value
The following code example shows how to set port B pins 0 and 1 high, 2 and 3 low, and define the port pins
from 4 to 7 as input with pull-ups assigned to port pins 6 and 7. The resulting pin values are read back again, but
as previously discussed, a nop instruction is included to be able to read back the value recently assigned to
some of the pins.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 82
ATmega164P/V/324P/V/644P/V
Assembly Code Example
...
; Define pull-ups and set outputs high
; Define directions for port pins
ldi
r16,(1<<PB7)|(1<<PB6)|(1<<PB1)|(1<<PB0)
ldi
r17,(1<<DDB3)|(1<<DDB2)|(1<<DDB1)|(1<<DDB0)
out PORTB,r16
out DDRB,r17
; Insert nop for synchronization
nop
; Read port pins
in r16,PINB
...
C Code Example
unsigned char i;
...
/* Define pull-ups and set outputs high */
/* Define directions for port pins */
PORTB = (1<<PB7)|(1<<PB6)|(1<<PB1)|(1<<PB0);
DDRB = (1<<DDB3)|(1<<DDB2)|(1<<DDB1)|(1<<DDB0);
/* Insert nop for synchronization*/
__no_operation();
/* Read port pins */
i = PINB;
...
(1)
Note: 1. For the assembly program, two temporary registers are used to minimize the time from pull-ups are set on pins
0, 1, 6, and 7, until the direction bits are correctly set, defining bit 2 and bit 3 as low and redefining bit 0 and bit1
as strong high drivers.
11.2.5 Digital Input Enable and Sleep Modes
As shown in Figure 11-2, the digital input signal can be clamped to ground at the input of the schmitt-trigger. The
signal denoted SLEEP in the figure, is set by the MCU Sleep Controller in Power-down mode, Power-save
mode, and Standby mode to avoid high power consumption if some input signals are left floating, or have an
analog signal level close to V
CC
/2.
SLEEP is overridden for port pins enabled as external interrupt pins. If the external interrupt request is not
enabled, SLEEP is active also for these pins. SLEEP is also overridden by various other alternate functions as
described in ”Alternate Port Functions” on page 85.
If a logic high level (“one”) is present on an asynchronous external interrupt pin configured as “Interrupt on
Rising Edge, Falling Edge, or Any Logic Change on Pin” while the external interrupt is not enabled, the
corresponding External Interrupt Flag will be set when resuming from the above mentioned Sleep mode, as the
clamping in these sleep mode produces the requested logic change.
11.2.6 Unconnected Pins
If some pins are unused, it is recommended to ensure that these pins have a defined level. Even though most of
the digital inputs are disabled in the deep sleep modes as described above, floating inputs should be avoided to
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 83
ATmega164P/V/324P/V/644P/V
reduce current consumption in all other modes where the digital inputs are enabled (Reset, Active mode and
Idle mode).
The simplest method to ensure a defined level of an unused pin, is to enable the internal pull-up. In this case,
the pull-up will be disabled during reset. If low power consumption during reset is important, it is recommended
to use an external pull-up or pull-down. Connecting unused pins directly to V
since this may cause excessive currents if the pin is accidentally configured as an output.
or GND is not recommended,
CC
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 84
11.3 Alternate Port Functions
Most port pins have alternate functions in addition to being general digital I/Os. Figure 11-5 shows how the port
pin control signals from the simplified Figure 11-2 on page 80 can be overridden by alternate functions. The
overriding signals may not be present in all port pins, but the figure serves as a generic description applicable to
all port pins in the AVR microcontroller family.
ATmega164P/V/324P/V/644P/V
Figure 11-5. Alternate Port Functions
Pxn
(1)
PUOExn
1
0
1
0
1
0
1
0
PUOVxn
DDOExn
DDOVxn
PVOExn
PVOVxn
DIEOExn
DIEOVxn
SLEEP
SYNCHRONIZER
SET
DLQ
Q
CLR
D
PINxn
CLR
Q
PORTxn
Q
CLR
RESET
Q
Q
Q
Q
RESET
D
DDxn
PUD
D
CLR
WDx
RDx
1
0
RRx
WRx
PTOExn
WPx
DATA BUS
RPx
clk
I/O
DIxn
AIOxn
PUOExn: Pxn PULL-UP OVERRIDE ENABLE
PUOVxn: Pxn PULL-UP OVERRIDE VALUE
DDOExn: Pxn DATA DIRECTION OVERRIDE ENABLE
DDOVxn: Pxn DATA DIRECTION OVERRIDE VALUE
PVOExn: Pxn PORT VALUE OVERRIDE ENABLE
PVOVxn: Pxn PORT VALUE OVERRIDE VALUE
DIEOExn: Pxn DIGITAL INPUT-ENABLE OVERRIDE ENABLE
DIEOVxn: Pxn DIGITAL INPUT-ENABLE OVERRIDE VALUE
SLEEP: SLEEP CONTROL
PTOExn: Pxn, PORT TOGGLE OVERRIDE ENABLE
PUD: PULLUP DISABLE
WDx: WRITE DDRx
RDx: READ DDRx
RRx: READ PORTx REGISTER
WRx: WRITE PORTx
RPx: READ PORTx PIN
WPx: WRITE PINx
: I/O CLOCK
clk
I/O
DIxn: DIGITAL INPUT PIN n ON PORTx
AIOxn: ANALOG INPUT/OUTPUT PIN n ON PORTx
Note: 1. WRx, WPx, WDx, RRx, RPx, and RDx are common to all pins within the same port. clk
common to all ports. All other signals are unique for each pin.
, SLEEP, and PUD are
I/O
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 85
ATmega164P/V/324P/V/644P/V
Table 11-2 summarizes the function of the overriding signals. The pin and port indexes from Figure 11-5 are not
shown in the succeeding tables. The overriding signals are generated internally in the modules having the
alternate function.
Table 11-2. Generic Description of Overriding Signals for Alternate Functions
Signal Name Full Name Description
If this signal is set, the pull-up enable is controlled by the PUOV
signal. If this signal is cleared, the pull-up is enabled when
{DDxn, PORTxn, PUD} = 0b010.
If PUOE is set, the pull-up is enabled/disabled when PUOV is
set/cleared, regardless of the setting of the DDxn, PORTxn,
and PUD Register bits.
PUOE
PUOV
Pull-up Override
Enable
Pull-up Override
Valu e
DDOE
DDOV
PVOE
PVOV
PTOE
DIEOE
DIEOV
DI Digital Input
AIO
Data Direction
Override Enable
Data Direction
Override Value
Port Value
Override Enable
Port Value
Override Value
Port Toggle
Override Enable
Digital Input
Enable Override
Enable
Digital Input
Enable Override
Valu e
Analog
Input/Output
If this signal is set, the Output Driver Enable is controlled by the
DDOV signal. If this signal is cleared, the Output driver is
enabled by the DDxn Register bit.
If DDOE is set, the Output Driver is enabled/disabled when
DDOV is set/cleared, regardless of the setting of the DDxn
Register bit.
If this signal is set and the Output Driver is enabled, the port
value is controlled by the PVOV signal. If PVOE is cleared, and
the Output Driver is enabled, the port Value is controlled by the
PORTxn Register bit.
If PVOE is set, the port value is set to PVOV, regardless of the
setting of the PORTxn Register bit.
If PTOE is set, the PORTxn Register bit is inverted.
If this bit is set, the Digital Input Enable is controlled by the
DIEOV signal. If this signal is cleared, the Digital Input Enable
is determined by MCU state (Normal mode, sleep mode).
If DIEOE is set, the Digital Input is enabled/disabled when
DIEOV is set/cleared, regardless of the MCU state (Normal
mode, sleep mode).
This is the Digital Input to alternate functions. In the figure, the
signal is connected to the output of the schmitt trigger but
before the synchronizer. Unless the Digital Input is used as a
clock source, the module with the alternate function will use its
own synchronizer.
This is the Analog Input/output to/from alternate functions. The
signal is connected directly to the pad, and can be used bidirectionally.
The following subsections shortly describe the alternate functions for each port, and relate the overriding signals
to the alternate function. Refer to the alternate function description for further details.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 86
11.3.1 Alternate Functions of Port A
The Port A pins with alternate functions are shown in Table 11-3.
Table 11-3. Port A Pins Alternate Functions
Port Pin Alternate Function
PA7
ADC7 (ADC input channel 7)
PCINT7 (Pin Change Interrupt 7)
ATmega164P/V/324P/V/644P/V
PA6
PA5
PA4
PA3
PA2
PA1
PA0
ADC6 (ADC input channel 6)
PCINT6 (Pin Change Interrupt 6)
ADC5 (ADC input channel 5)
PCINT5 (Pin Change Interrupt 5)
ADC4 (ADC input channel 4)
PCINT4 (Pin Change Interrupt 4)
ADC3 (ADC input channel 3)
PCINT3 (Pin Change Interrupt 3)
ADC2 (ADC input channel 2)
PCINT2 (Pin Change Interrupt 2)
ADC1 (ADC input channel 1)
PCINT1 (Pin Change Interrupt 1)
ADC0 (ADC input channel 0)
PCINT0 (Pin Change Interrupt 0)
• ADC7:0/PCINT7:0 – Port A, Bit 7:0
ADC7:0, Analog to Digital Converter, Channels 7:0
.
PCINT7:0, Pin Change Interrupt source 7:0: The PA7:0 pins can serve as external interrupt sources.
Table 11-4 on page 87 and Table 11-5 on page 88 relates the alternate functions of Port A to the overriding
signals shown in Figure 11-5 on page 85.
Table 11-4. Overriding Signals for Alternate Functions in PA7:PA4
Signal
Name
PUOE0000
PUOV0000
DDOE 0 0 0 0
DDOV 0 0 0 0
PVOE 0 0 0 0
PVOV 0 0 0 0
DIEOE
DIEOV PCINT7 • PCIE0 PCINT6 • PCIE0 PCINT5 • PCIE0 PCINT4 • PCIE0
DI PCINT7 INPUT PCINT6 INPUT PCINT5 INPUT PCINT4 INPUT
AIO ADC7 INPUT ADC6 INPUT ADC5 INPUT ADC4 INPUT
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 87
PA7/ADC7/
PCINT7
PCINT7 • PCIE0 +
ADC7D
PA6/ADC6/
PCINT6
PCINT6 • PCIE0 +
ADC6D
PA5/ADC5/
PCINT5
PCINT5 • PCIE0 +
ADC5D
PA4/ADC4/
PCINT4
PCINT4 • PCIE0 +
ADC4D
ATmega164P/V/324P/V/644P/V
Table 11-5. Overriding Signals for Alternate Functions in PA3:PA0
Signal
Name
PUOE0000
PUOV0000
DDOE 0 0 0 0
DDOV 0 0 0 0
PVOE 0 0 0 0
PVOV 0 0 0 0
DIEOE
DIEOV PCINT3 • PCIE0 PCINT2 • PCIE0 PCINT1 • PCIE0 PCINT0 • PCIE0
DI PCINT3 INPUT PCINT2 INPUT PCINT1 INPUT PCINT0 INPUT
AIO ADC3 INPUT ADC2 INPUT ADC1 INPUT ADC0 INPUT
PA3/ADC3/
PCINT3
PCINT3 • PCIE0 +
ADC3D
11.3.2 Alternate Functions of Port B
The Port B pins with alternate functions are shown in Table 11-6.
Table 11-6. Port B Pins Alternate Functions
Port Pin Alternate Functions
PB7
PB6
SCK (SPI Bus Master clock input)
PCINT15 (Pin Change Interrupt 15)
MISO (SPI Bus Master Input/Slave Output)
PCINT14 (Pin Change Interrupt 14)
PA2/ADC2/
PCINT2
PCINT2 • PCIE0 +
ADC2D
PA1/ADC1/
PCINT1
PCINT1 • PCIE0 +
ADC1D
PA0/ADC0/
PCINT0
PCINT0 • PCIE0 +
ADC0D
PB5
PB4
PB3
PB2
PB1
PB0
MOSI (SPI Bus Master Output/Slave Input)
PCINT13 (Pin Change Interrupt 13)
(SPI Slave Select input)
SS
OC0B (Timer/Conter 0 Output Compare Match B Output)
PCINT12 (Pin Change Interrupt 12)
AIN1 (Analog Comparator Negative Input)
OC0A (Timer/Conter 0 Output Compare Match A Output)
PCINT11 (Pin Change Interrupt 11)
AIN0 (Analog Comparator Positive Input)
INT2 (External Interrupt 2 Input)
PCINT10 (Pin Change Interrupt 10)
T1 (Timer/Counter 1 External Counter Input)
CLKO (Divided System Clock Output)
PCINT9 (Pin Change Interrupt 9)
T0 (Timer/Counter 0 External Counter Input)
XCK0 (USART0 External Clock Input/Output)
PCINT8 (Pin Change Interrupt 8)
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 88
ATmega164P/V/324P/V/644P/V
The alternate pin configuration is as follows:
• SCK/PCINT15 – Port B, Bit 7
SCK: Master Clock output, Slave Clock input pin for SPI channel. When the SPI is enabled as a slave, this pin is
configured as an input regardless of the setting of DDB7. When the SPI0 is enabled as a master, the data
direction of this pin is controlled by DDB7. When the pin is forced to be an input, the pull-up can still be
controlled by the PORTB7 bit.
PCINT15, Pin Change Interrupt source 15: The PB7 pin can serve as an external interrupt source.
• MISO/PCINT14 – Port B, Bit 6
MISO: Master Data input, Slave Data output pin for SPI channel. When the SPI is enabled as a master, this pin
is configured as an input regardless of the setting of DDB6. When the SPI is enabled as a slave, the data
direction of this pin is controlled by DDB6. When the pin is forced to be an input, the pull-up can still be
controlled by the PORTB6 bit.
PCINT14, Pin Change Interrupt source 14: The PB6 pin can serve as an external interrupt source.
• MOSI/PCINT13 – Port B, Bit 5
MOSI: SPI Master Data output, Slave Data input for SPI channel. When the SPI is enabled as a slave, this pin is
configured as an input regardless of the setting of DDB5. When the SPI is enabled as a master, the data
direction of this pin is controlled by DDB5. When the pin is forced to be an input, the pull-up can still be
controlled by the PORTB5 bit.
PCINT13, Pin Change Interrupt source 13: The PB5 pin can serve as an external interrupt source.
•SS
/OC0B/PCINT12 – Port B, Bit 4
SS
: Slave Port Select input. When the SPI is enabled as a slave, this pin is configured as an input regardless of
the setting of DDB4. As a slave, the SPI is activated when this pin is driven low. When the SPI is enabled as a
master, the data direction of this pin is controlled by DDB4. When the pin is forced to be an input, the pull-up can
still be controlled by the PORTB4 bit.
OC0B, Output Compare Match B output: The PB4 pin can serve as an external output for the Timer/Counter0
Output Compare. The pin has to be configured as an output (DDB4 set “one”) to serve this function. The OC0B
pin is also the output pin for the PWM mode timer function.
PCINT12, Pin Change Interrupt source 12: The PB4 pin can serve as an external interrupt source.
• AIN1/OC0A/PCINT11, Bit 3
AIN1, Analog Comparator Negative input. This pin is directly connected to the negative input of the Analog
Comparator.
OC0A, Output Compare Match A output: The PB3 pin can serve as an external output for the Timer/Counter0
Output Compare. The pin has to be configured as an output (DDB3 set “one”) to serve this function. The OC0A
pin is also the output pin for the PWM mode timer function.
PCINT11, Pin Change Interrupt source 11: The PB3 pin can serve as an external interrupt source.
• AIN0/INT2/PCINT10, Bit 2
AIN0, Analog Comparator Positive input. This pin is directly connected to the positive input of the Analog
Comparator.
INT2, External Interrupt source 2. The PB2 pin can serve as an External Interrupt source to the MCU.
PCINT10, Pin Change Interrupt source 10: The PB2 pin can serve as an external interrupt source.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 89
ATmega164P/V/324P/V/644P/V
• T1/CLKO/PCINT9, Bit 1
T1, Timer/Counter1 counter source.
CLKO, Divided System Clock: The divided system clock can be output on the PB1 pin. The divided system clock
will be output if the CKOUT Fuse is programmed, regardless of the PORTB1 and DDB1 settings. It will also be
output during reset.
PCINT9, Pin Change Interrupt source 9: The PB1 pin can serve as an external interrupt source.
• T0/XCK0/PCINT8, Bit 0
T0, Timer/Counter0 counter source.
XCK0, USART0 External clock. The Data Direction Register (DDB0) controls whether the clock is output (DDD0
set “one”) or input (DDD0 cleared). The XCK0 pin is active only when the USART0 operates in Synchronous
mode.
PCINT8, Pin Change Interrupt source 8: The PB0 pin can serve as an external interrupt source.
Table 11-7 and Table 11-8 relate the alternate functions of Port B to the overriding signals shown in Figure 11-5
on page 85. SPI MSTR INPUT and SPI SLAVE OUTPUT constitute the MISO signal, while MOSI is divided into
SPI MSTR OUTPUT and SPI SLAVE INPUT. .
Table 11-7. Overriding Signals for Alternate Functions in PB7:PB4
Signal
Name
PUOE SPE • MSTR
PUOV PORTB7 • PUD PORTB14 • PUD PORTB13 • PUD PORTB12 • PUD
DDOE SPE • MSTR SPE • MSTR SPE • MSTR SPE • MSTR
DDOV 0 0 0 0
PVOE SPE • MSTR SPE • MSTR
PVOV SCK OUTPUT
DIEOE PCINT15 • PCIE1 PCINT14 • PCIE1 PCINT13 • PCIE1 PCINT12 • PCIE1
DIEOV 1 1 1 1
DI
AIO – – – –
PB7/SCK/
PCINT15
SCK INPUT
PCINT17 INPUT
PB6/MISO/
PCINT14
SPE • MSTR SPE • MSTR SPE • MSTR
SPI SLAVE
OUTPUT
SPI MSTR INPUT
PCINT14 INPUT
PB5/MOSI/
PCINT13
SPE • MSTR OC0A ENABLE
SPI MSTR OUTPUT OC0A
SPI SLAVE INPUT
PCINT13 INPUT
PB4/SS
PCINT12
SPI SS
PCINT12 INPUT
/OC0B/
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 90
ATmega164P/V/324P/V/644P/V
Table 11-8. Overriding Signals for Alternate Functions in PB3:PB0
Signal
Name
PUOE0000
PUOV0000
DDOE 0 0 CKOUT 0
DDOV 0 0 CKOUT 0
PVOE OC0B ENABLE 0 CKOUT 0
PVOV OC0B 0 CLK I/O 0
DIEOE PCINT11 • PCIE1
DIEOV1111
DI PCINT11 INPUT
AIO AIN1 INPUT AIN0 INPUT – –
PB3/AIN1/OC0B/
PCINT11
PB2/AIN0/INT2/
PCINT10
INT2 ENABLE
PCINT10 • PCIE1
INT2 INPUT
PCINT10 INPUT
PB1/T1/CLKO/PCI
NT9
PCINT9 • PCIE1 PCINT8 • PCIE1
T1 INPUT
PCINT9 INPUT
PB0/T0/XCK/
PCINT8
T0 INPUT
PCINT8 INPUT
11.3.3 Alternate Functions of Port C
The Port C pins with alternate functions are shown in Table 11-9.
Table 11-9. Port C Pins Alternate Functions
Port Pin Alternate Function
PC7
PC6
PC5
PC4
PC3
PC2
PC1
PC0
TOSC2 (Timer Oscillator pin 2)
PCINT23 (Pin Change Interrupt 23)
TOSC1 (Timer Oscillator pin 1)
PCINT22 (Pin Change Interrupt 22)
TDI (JTAG Test Data Input)
PCINT21 (Pin Change Interrupt 21)
TDO (JTAG Test Data Output)
PCINT20 (Pin Change Interrupt 20)
TMS (JTAG Test Mode Select)
PCINT19 (Pin Change Interrupt 19)
TCK (JTAG Test Clock)
PCINT18 (Pin Change Interrupt 18)
SDA (2-wire Serial Bus Data Input/Output Line)
PCINT17 (Pin Change Interrupt 17)
SCL (2-wire Serial Bus Clock Line)
PCINT16 (Pin Change Interrupt 16)
• TOSC2/PCINT23 – Port C, Bit 7
TOSC2, Timer Oscillator pin 2. The PC7 pin can serve as an external interrupt source to the MCU.
PCINT23, Pin Change Interrupt source 23: The PC7 pin can serve as an external interrupt source.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 91
ATmega164P/V/324P/V/644P/V
• TOSC1/PCINT22 – Port C, Bit 6
TOSC1, Timer Oscillator pin 1. The PC6 pin can serve as an external interrupt source to the MCU.
PCINT22, Pin Change Interrupt source 22: The PC6 pin can serve as an external interrupt source.
• TDI/PCINT21 – Port C, Bit 5
TDI, JTAG Test Data Input.
PCINT21, Pin Change Interrupt source 21: The PC5 pin can serve as an external interrupt source.
• TDO/PCINT20 – Port C, Bit 4
TDO, JTAG Test Data Output.
PCINT20, Pin Change Interrupt source 20: The PC4 pin can serve as an external interrupt source.
• TMS/PCINT19 – Port C, Bit 3
TMS, JTAG Test Mode Select.
PCINT19, Pin Change Interrupt source 19: The PC3 pin can serve as an external interrupt source.
• TCK/PCINT18 – Port C, Bit 2
TCK, JTAG Test Clock.
PCINT18, Pin Change Interrupt source 18: The PC2 pin can serve as an external interrupt source.
• SDA/PCINT17 – Port C, Bit 1
SDA, 2-wire Serial Bus Data Input/Output Line.
PCINT17, Pin Change Interrupt source 17: The PC1 pin can serve as an external interrupt source.
• SCL/PCINT16 – Port C, Bit 0
SCL, 2-wire Serial Bus Clock Line.
PCINT16, Pin Change Interrupt source 16: The PC0 pin can serve as an external interrupt source.
Table 11-10 and Table 11-11 relate the alternate functions of Port C to the overriding signals shown in Figure
11-5 on page 85.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 92
ATmega164P/V/324P/V/644P/V
Table 11-10. Overriding Signals for Alternate Functions in PC7:PC4
Signal
Name
PUOE AS2 • EXCLK
PUOV 0 0 1 1
DDOE AS2 • EXCLK AS2 JTAGEN JTAGEN
DDOV 0 0 0
PVOE 0 0 0 JTAGEN
PVOV 0 0 0 TDO
PC7/TOSC2/
PCINT23
PC6/TOSC1/
PCINT22
AS2 JTAGEN JTAGEN
PC5/TDI/
PCINT21
PC4/TDO/
PCINT20
SHIFT_IR +
SHIFT_DR
DIEOE
DIEOV AS2
DI PCINT23 INPUT PCINT22 INPUT PCINT21 INPUT PCINT20 INPUT
AIO T/C2 OSC OUTPUT
Table 11-11. Overriding Signals for Alternate Functions in PC3:PC0
Signal
Name
PUOE JTAGEN JTAGEN TWEN TWEN
PUOV 1 1 PORTC1 • PUD
DDOE JTAGEN JTAGEN TWEN TWEN
DDOV 0 0 0 0
PVOE 0 0 TWEN TWEN
PVOV 0 0 SDA OUT SCL OUT
DIEOE
DIEOV JTAGEN
DI PCINT19 INPUT PCINT18 INPUT PCINT17 INPUT PCINT16 INPUT
AIO TMS INPUT TCK INPUT SDA INPUT SCL INPUT
AS2 • EXCLK +
PCINT23 • PCIE2
PC3/TMS/
PCINT19
JTAGEN +
PCINT19 • PCIE2
AS2 +
PCINT22 • PCIE2
EXCLK + AS2 JTAGEN JTAGEN
T/C2 OSC
INPUT
PC2/TCK/
PCINT18
JTAGEN +
PCINT18 • PCIE2
JTAGEN 11
JTAGEN +
PCINT21 • PCIE2
TDI INPUT –
PC1/SDA/
PCINT17
PCINT17 • PCIE2 PCINT16 • PCIE2
JTAGEN +
PCINT20 • PCIE2
PC0/SCL/
PCINT16
PORTC0 • PUD
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 93
11.3.4 Alternate Functions of Port D
The Port D pins with alternate functions are shown in Table 11-12.
Table 11-12. Port D Pins Alternate Functions
Port Pin Alternate Function
PD7
PD6
OC2A (Timer/Counter2 Output Compare Match A Output)
PCINT31 (Pin Change Interrupt 31)
ICP1 (Timer/Counter1 Input Capture Trigger)
OC2B (Timer/Counter2 Output Compare Match B Output)
PCINT30 (Pin Change Interrupt 30)
ATmega164P/V/324P/V/644P/V
PD5
PD4
PD3
PD2
PD1
PD0
OC1A (Timer/Counter1 Output Compare Match A Output)
PCINT29 (Pin Change Interrupt 29)
OC1B (Timer/Counter1 Output Compare Match B Output)
XCK1 (USART1 External Clock Input/Output)
PCINT28 (Pin Change Interrupt 28)
INT1 (External Interrupt1 Input)
TXD1 (USART1 Transmit Pin)
PCINT27 (Pin Change Interrupt 27)
INT0 (External Interrupt0 Input)
RXD1 (USART1 Receive Pin)
PCINT26 (Pin Change Interrupt 26)
TXD0 (USART0 Transmit Pin)
PCINT25 (Pin Change Interrupt 25)
RXD0 (USART0 Receive Pin)
PCINT24 (Pin Change Interrupt 24)
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 94
ATmega164P/V/324P/V/644P/V
The alternate pin configuration is as follows:
• OC2A/PCINT31 – Port D, Bit 7
OC2A, Output Compare Match A output: The PD7 pin can serve as an external output for the Timer/Counter2
Output Compare A. The pin has to be configured as an output (DDD7 set (one)) to serve this function. The
OC2A pin is also the output pin for the PWM mode timer function.
PCINT31, Pin Change Interrupt Source 31:The PD7 pin can serve as an external interrupt source.
• ICP1/OC2B/PCINT30 – Port D, Bit 6
ICP1, Input Capture Pin 1: The PD6 pin can act as an input capture pin for Timer/Counter1.
OC2B, Output Compare Match B output: The PD6 pin can serve as an external output for the Timer/Counter2
Output Compare B. The pin has to be configured as an output (DDD6 set (one)) to serve this function. The
OC2B pin is also the output pin for the PWM mode timer function.
PCINT30, Pin Change Interrupt Source 30: The PD6 pin can serve as an external interrupt source.
• OC1A/PCINT29 – Port D, Bit 5
OC1A, Output Compare Match A output: The PD5 pin can serve as an external output for the Timer/Counter1
Output Compare A. The pin has to be configured as an output (DDD5 set (one)) to serve this function. The
OC1A pin is also the output pin for the PWM mode timer function.
PCINT29, Pin Change Interrupt Source 29: The PD5 pin can serve as an external interrupt source.
• OC1B/XCK1/PCINT28 – Port D, Bit 4
OC1B, Output Compare Match B output: The PB4 pin can serve as an external output for the Timer/Counter1
Output Compare B. The pin has to be configured as an output (DDD4 set (one)) to serve this function. The
OC1B pin is also the output pin for the PWM mode timer function.
XCK1, USART1 External clock. The Data Direction Register (DDB4) controls whether the clock is output (DDD4
set “one”) or input (DDD4 cleared). The XCK4 pin is active only when the USART1 operates in Synchronous
mode.
PCINT28, Pin Change Interrupt Source 28: The PD4 pin can serve as an external interrupt source.
• INT1/TXD1/PCINT27 – Port D, Bit 3
INT1, External Interrupt source 1. The PD3 pin can serve as an external interrupt source to the MCU.
TXD1, Transmit Data (Data output pin for the USART1). When the USART1 Transmitter is enabled, this pin is
configured as an output regardless of the value of DDD3.
PCINT27, Pin Change Interrupt Source 27: The PD3 pin can serve as an external interrupt source.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 95
ATmega164P/V/324P/V/644P/V
• INT0/RXD1/PCINT26 – Port D, Bit 2
INT0, External Interrupt source 0. The PD2 pin can serve as an external interrupt source to the MCU.
RXD1, RXD0, Receive Data (Data input pin for the USART1). When the USART1 receiver is enabled this pin is
configured as an input regardless of the value of DDD2. When the USART forces this pin to be an input, the
pull-up can still be controlled by the PORTD2 bit.
PCINT26, Pin Change Interrupt Source 26: The PD2 pin can serve as an external interrupt source.
• TXD0/PCINT25 – Port D, Bit 1
TXD0, Transmit Data (Data output pin for the USART0). When the USART0 Transmitter is enabled, this pin is
configured as an output regardless of the value of DDD1.
PCINT25, Pin Change Interrupt Source 25: The PD1 pin can serve as an external interrupt source.
• RXD0/PCINT24 – Port D, Bit 0
RXD0, Receive Data (Data input pin for the USART0). When the USART0 receiver is enabled this pin is
configured as an input regardless of the value of DDD0. When the USART forces this pin to be an input, the
pull-up can still be controlled by the PORTD0 bit.
PCINT24, Pin Change Interrupt Source 24: The PD0 pin can serve as an external interrupt source.
Table 11-13 on page 96 and Table 11-14 on page 97 relates the alternate functions of Port D to the overriding
signals shown in Figure 11-5 on page 85.
Table 11-13. Overriding Signals for Alternate Functions PD7:PD4
PD6/ICP1/
PD7/OC2A/
Signal Name
PUOE0000
PUOV0000
DDOE0000
DDOV0000
PVOE OC2A ENABLE OC2B ENABLE OC1A ENABLE OC1B ENABLE
PVOV OCA2A OC2B OC1A OC1B
DIEOE PCINT31 • PCIE3 PCINT30 • PCIE3 PCINT29 • PCIE3 PCINT28 • PCIE3
DIEOV1111
DI PCINT31 INPUT
AIO––––
PCINT31
OC2B/
PCINT30
ICP1 INPUT
PCINT30 INPUT
PD5/OC1A/
PCINT29
PCINT29 INPUT PCINT28 INPUT
PD4/OC1B/XCK1/
PCINT28
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 96
ATmega164P/V/324P/V/644P/V
Table 11-14. Overriding Signals for Alternate Functions in PD3:PD0
Signal Name
PD3/INT1/TXD1/
PCINT27
PD2/INT0/RXD1/
PCINT26
PD1/TXD0/
PCINT25
PUOE TXEN1 RXEN1 TXEN0 RXEN1
PUOV 0 PORTD2 • PUD
0PORTD0 • PUD
DDOE TXEN1 RXEN1 TXEN0 RXEN1
DDOV 1 0 1 0
PVOE TXEN1 0 TXEN0 0
PVOV TXD1 0 TXD0 0
DIEOE
INT1 ENABLE
PCINT27 • PCIE3
INT2 ENABLE
PCINT26 • PCIE3
PCINT25 • PCIE3 PCINT24 • PCIE3
DIEOV1111
INT0 INPUT
RXD1
PCINT26 INPUT
PCINT25 INPUT
DI
INT1 INPUT
PCINT27 INPUT
AIO––––
(1)
PD0/RXD0/
PCINT27
RXD0
PCINT24 INPUT
Note: 1. When enabled, the 2-wire Serial Interface enables Slew-Rate controls on the output pins PD0 and PD1. This is
not shown in this table. In addition, spike filters are connected between the AIO outputs shown in the port figure
and the digital logic of the TWI module.
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 97
Register Description
11.3.5 MCUCR – MCU Control Register
Bit 7 6 5 4 3 2 1 0
0x35 (0x55)
Read/Write R/W R R R/W R R R/W R/W
Initial Value 0 0 0 0 0 0 0 0
• Bit 4 – PUD: Pull-up Disable
When this bit is written to one, the pull-ups in the I/O ports are disabled even if the DDxn and PORTxn Registers
are configured to enable the pull-ups ({DDxn, PORTxn} = 0b01). See ”Configuring the Pin” on page 80 for more
details about this feature.
11.3.6 PORTA – Port A Data Register
Bit 76543210
0x02 (0x22)
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
JTD BODS BODSE PUD – – IVSEL IVCE MCUCR
PORTA7 PORTA6 PORTA5 PORTA4 PORTA3 PORTA2 PORTA1 PORTA0
ATmega164P/V/324P/V/644P/V
PORTA
11.3.7 DDRA – Port A Data Direction Register
Bit 76543210
0x01 (0x21) DDA7 DDA6 DDA5 DDA4 DDA3 DDA2 DDA1 DDA0 DDRA
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
11.3.8 PINA – Port A Input Pins Address
Bit 76543210
0x00 (0x20) PINA7 PINA6 PINA5 PINA4 PINA3 PINA2 PINA1 PINA0 PINA
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value N/A N/A N/A N/A N/A N/A N/A N/A
11.3.9 PORTB – Port B Data Register
Bit 76543210
0x05 (0x25)
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
PORTB7 PORTB6 PORTB5 PORTB4 PORTB3 PORTB2 PORTB1 PORTB0 PORTB
11.3.10 DDRB – Port B Data Direction Register
Bit 76543210
0x04 (0x24) DDB7 DDB6 DDB5 DDB4 DDB3 DDB2 DDB1 DDB0 DDRB
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
11.3.11 PINB – Port B Input Pins Address
Bit 76543210
0x03 (0x23) PINB7 PINB6 PINB5 PINB4 PINB3 PINB2 PINB1 PINB0 PINB
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value N/A N/A N/A N/A N/A N/A N/A N/A
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 98
11.3.12 PORTC – Port C Data Register
Bit 76543210
0x08 (0x28)
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
PORTC7 PORTC6 PORTC5 PORTC4 PORTC3 PORTC2 PORTC1 PORTC0 PORTC
11.3.13 DDRC – Port C Data Direction Register
Bit 76543210
0x07 (0x27) DDC7 DDC6 DDC5 DDC4 DDC3 DDC2 DDC1 DDC0 DDRC
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
11.3.14 PINC – Port C Input Pins Address
Bit 76543210
0x06 (0x26) PINC7 PINC6 PINC5 PINC4 PINC3 PINC2 PINC1 PINC0 PINC
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value N/A N/A N/A N/A N/A N/A N/A N/A
11.3.15 PORTD – Port D Data Register
ATmega164P/V/324P/V/644P/V
Bit 76543210
0x0B (0x2B)
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
PORTD7 PORTD6 PORTD5 PORTD4 PORTD3 PORTD2 PORTD1 PORTD0 PORTD
11.3.16 DDRD – Port D Data Direction Register
Bit 76543210
0x0A (0x2A) DDD7 DDD6 DDD5 DDD4 DDD3 DDD2 DDD1 DDD0 DDRD
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value00000000
11.3.17 PIND – Port D Input Pins Address
Bit 76543210
0x09 (0x29) PIND7 PIND6 PIND5 PIND4 PIND3 PIND2 PIND1 PIND0 PIND
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value N/A N/A N/A N/A N/A N/A N/A N/A
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 99
12. 8-bit Timer/Counter0 with PWM
12.1 Features
• Two Independent Output Compare Units
• Double Buffered Output Compare Registers
• Clear Timer on Compare Match (Auto Reload)
• Glitch Free, Phase Correct Pulse Width Modulator (PWM)
• Variable PWM Period
• Frequency Generator
• Three Independent Interrupt Sources (TOV0, OCF0A, and OCF0B)
12.2 Overview
Timer/Counter0 is a general purpose 8-bit Timer/Counter module, with two independent Output Compare Units,
and with PWM support. It allows accurate program execution timing (event management) and wave generation.
A simplified block diagram of the 8-bit Timer/Counter is shown in Figure 12-1. For the actual placement of I/O
pins, see ”Pin Configurations” on page 11. CPU accessible I/O Registers, including I/O bits and I/O pins, are
shown in bold. The device-specific I/O Register and bit locations are listed in the ”Register Description” on page
110.
ATmega164P/V/324P/V/644P/V
Figure 12-1. 8-bit Timer/Counter Block Diagram
12.2.1 Registers
Count
Clear
Control Logic
Direction
TOP BOTTO M
Timer/Counter
TCNTn
=
OCRnA
=
DATA BUS
OCRnB
TCCRnA TCCRnB
clk
Tn
=
Fixed
TOP
Val ue
=
0
TOVn
(Int.Req.)
Clock Select
Edge
Detector
( From Prescaler )
OCnA
(Int.Req.)
Wavefor m
Generation
OCnB
(Int.Req.)
Wavefor m
Generation
Tn
OCnA
OCnB
The Timer/Counter (TCNT0) and Output Compare Registers (OCR0A and OCR0B) are 8-bit registers. Interrupt
request (abbreviated to Int.Req. in the figure) signals are all visible in the Timer Interrupt Flag Register (TIFR0).
All interrupts are individually masked with the Timer Interrupt Mask Register (TIMSK0). TIFR0 and TIMSK0 are
not shown in the figure.
The Timer/Counter can be clocked internally, via the prescaler, or by an external clock source on the T0 pin.
The Clock Select logic block controls which clock source and edge the Timer/Counter uses to increment (or
2018 Microchip Technology Inc. Data Sheet Complete DS40002071A-page 100
Loading...
