Asus AX-112 User Manual

®

AX-112

Analog Telephone Adapter

User Guide

E2674/ June 2006

Copyright Information

E2674
First Edition
June 2006

Copyright © 2006 ASUSTeK COMPUTER INC. All Rights Reserved.

No part of this manual, including the products and software described in it, may
be reproduced, transmitted, transcribed, stored in a retrieval system, or translated
into any language in any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written permission of ASUSTeK
COMPUTER INC. (ASUS).

Product warranty or service will not be extended if: (1) the product is repaired,

modied or altered, unless such repair, modication of alteration is authorized in

writing by ASUS; or (2) the serial number of the product is defaced or missing.

ASUS provides this manual “as is” without warranty of any kind, either express
or implied, including but not limited to the implied warranties or conditions of
merchantability or fitness for a particular purpose. In no event shall ASUS, its

directors, ofcers, employees, or agents be liable for any indirect, special, incidental,
or consequential damages (including damages for loss of prots, loss of business,

loss of use or data, interruption of business and the like), even if ASUS has been
advised of the possibility of such damages arising from any defect or error in this
manual or product.

Sp ec if ic ations and information contained in this ma nu al a re f ur ni sh ed for
informational use only, and are subject to change at any time without notice,
and should not be construed as a commitment by ASUS. ASUS assumes no
responsibility or liability for any errors or inaccuracies that may appear in this
manual, including the products and software described in it.

Products and corporate names appearing in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

2 AX-112 Analog Telephone Adapter

Contact Information

ASUSTeK COMPUTER INC.

Company address: 15 Li-Te Road, Beitou, Taipei 11259
General (tel): [phone]
Web site address: www.asus.com.tw
General (fax): [phone]
General email: [e-mail]

Technical support

General support (tel): [phone]
Online support: http://support.asus.com

ASUS COMPUTER INTERNATIONAL (America)

Company address: 44370 Nobel Drive, Fremont, CA 94538, USA
General (fax): [phone]
Web site address: usa.asus.com

Technical support

General support (tel): [phone]
Online support: http://support.asus.com
Notebook (tel): [phone] x5110
Support (fax): [phone]

ASUS COMPUTER GmbH (Germany & Austria)

Company address: Harkort Str. 25, D-40880 Ratingen, Germany
General (tel): [phone]
Web site address: www.asus.com.de
General (fax): [phone]
Online contact: www.asus.com.de/sales

Technical support

Component support: [phone]
Online support: http://support.asus.com
Notebook support: [phone]
Support (fax): [phone]

AX-112 Analog Telephone Adapter 3

Notices

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received including
interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used

in accordance with manufacturer’s instructions, may cause harmful

interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that
to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

4 AX-112 Analog Telephone Adapter

Conventions used in this guide

Symbols

To make sure that you perform certain tasks properly, take note of the

following symbols used throughout this manual.

DANGER/WARNING: Information to prevent injury to

yourself when trying to complete a task.when trying to complete a task.

CAUTION: Information to prevent damage to the

components when trying to complete a taskwhen trying to complete a task

IMPORTANT: Instructions that you MUST follow to complete

a task.task.

NOTE: Tips and additional information to help you complete

a task.task.

AX-112 Analog Telephone Adapter 5

Table of Contents

1. Introduction ..............................................................................7

Overview ................................................................................................7

Features ................................................................................................8

Hardware specications ........................................................................9

Package ................................................................................................9

2. Quick Installation ...................................................................10

Connectors ..........................................................................................10

Cable connection .................................................................................12

WAN IP assignment .............................................................................12

3. Conguration ..........................................................................13

Status ..................................................................................................13

WAN ....................................................................................................13

SIP ....................................................................................................14

Advance setting ..................................................................................15

Management .......................................................................................20

4. Operation ................................................................................22

IVR Operation .....................................................................................22

Call service features ...........................................................................23

Life line/PSTN features ......................................................................24

Conference/Transfer call .....................................................................24

LED indication .....................................................................................24

5. Troubleshooting .....................................................................25

6 AX-112 Analog Telephone Adapter

1. Introduction

PSTN

Internet

NAT/Router

Chapter 1 - Introduction

Overview

Thank you for buying an ASUS AX-112 Analog Telephone Adapter!

The ASUS AX-112 analog telephone adapter is a Session Initiation Protocol
(SIP) compliant Voice over Internet (VoIP) terminal adapter. It features high
audio quality, multiple telephone functions, and compact design. It can work
with SIP compliant devices and server to provide voice communication via the
Internet.

AX-112's compact design is specially-designed with WAN and LAN ports, and
with FXO and FXS ports. It supports Ethernet LAN to WAN bridge capability
and users can connect their PC or notebook to the Internet through the cable
on LAN port.

The FXO is designed with a bypass relay, which means that the FXO can pass
through connection to the phone set on FXS port. You can call via the internet
through:

• the phone set on FXS port; or

• pressing the control code on the phone key pad to switch to normal PSTN
line.

English

AX-112 Analog Telephone Adapter 7

Chapter 1 - Introduction

English

Features

• Compact design for easy handling and installation

•

Supports SIP 2.0 (RFC3261), DHCP client, PPPoE, DNS, HTTP

•

Two RJ45 ports for WAN-LAN bridging

•

Two RJ11 jacks for one full function FXS port and one bypass FXO
port.

•

Supports most popular vocoders ; G.711u/A, G.723.1, G.729AB with 16ms
tail length line echo cancellation (G.168), silence suppression, VAD (Voice

Activity Detection), CNG (Comfortable Noise Generator)

•

Adaptive jitter buffer or user-congurable xed jitter buffer length

•

Supports DTMF/FSK caller ID generation, and call transfer, call forwarding,
call waiting

•

DTMF operation mode: RFC2833, Info, in-band audio

•

Supports FAX pass through or T.38

•

Support standard encryption authentication, DIEGST with MD5

•

QoS Support 802.1Q VLAN, 802.1p, ToS, DiffServ

•

Supports Auto NAT traversal and STUN

•

Allows conguration by web browser or phone touch tone keypad

•

Firmware upgrade by TFTP or HTTP

8 AX-112 Analog Telephone Adapter

Chapter 1 - Introduction

Hardwarespecications

Power DC jack x 1 Power consumption <8W

Input voltage: 100-240 VAC

Output voltage: 5VDC/2A

WAN port RJ45, 10/100BaseT Auto MDI/MDIX

LAN port RJ45, 10/100BaseT Auto MDI/MDIX

FXS port RJ-11 x1 On-hook voltage: 48VDC

Loop current: 25mA

Ringer: REN 3, 55V/rms

FXO port RJ-11 x1 No DAA function, with by pass relay only(life

line)

LED Red x 1, Green x 1 Green LED w/dimmer effect

Dimension 9.8cm x 9.8cm x 2cm

Weight 100g

Package contents

Check the following items in your ASUS AX-112 Analog Telephone Adapter
package:

English

AX-112 ATA x 1

RJ-45 Ethernet cable x 1, RJ11 phone cable x 1

5V/2A DC power adapter x 1

Quick Start Guide

AX-112 is able to operate SIP TA function by itself, and no other software

installation is needed. You may use IE to congure this device, or thru a
phone set plugged on the AX-112’s RJ11 jack. Please refer to Chapter 3
for conguration guide.

AX-112 Analog Telephone Adapter 9

Chapter 2 - Quick Installation

PWR

WAN

English

2. Quick Installation

2. 1 Connectors

There are five connectors on AX-112, and you can find them on the two
side panels. These two side panels can be distinguished by the arrow icon,
the upward arrow indicates the WAN side, while the other downward arrow
indicates the LAN side.

2.1.1 WAN side connectors

PWR

DC power jack

Use the universal power adapter included in the package. The adapter is a
high quality switching power device which accepts 100~240VAC input, and
5VDC output with 2A rating. If you have to use a substitute power adapter,
use an adapter of good quality and with the correct rating. Incorrect voltage
adapter output may damage the AX-112, and poor quality adapter may induce
unacceptable ripple noise to the phone set.

PSTN
(FXO)

WAN

RJ45 WAN

Normally, this port is connected to your broadband Ethernet port which could be

xDSL, cable modem or your ofce LAN. You have to assign an IP to the WAN port

of AX-112, or enable its DHCP client to get an IP from your DHCP server.

RJ11 line port

The line port is used for connecting to the PSTN line. It is also called as the Foreign

Exchange Ofce (FXO) port. This line port on AX-112 only has bypass function

without the DAA circuit. This means that it can relay the incoming call from PSTN
to the phone set connected to the phone port, but the VoIP call can not go through
by this line port.

10 AX-112 Analog Telephone Adapter

Chapter 2 - Quick Installation

LAN

Reset

2.1.2 LAN side connectors

English

LAN

PHONE (FXS)

LAN

Normally, you can only have one Ethernet cable at your desk. If you also have
to use your PC or notebook while the VoIP device is running, then an extra LAN
port is necessary for this purpose on AX-112. The LAN port has bridge capability
to WAN port and allows the connected device to be able to access the network
easily without other settings.

RJ11 phone port

AX-112 needs an ordinary phone set to work as an IP phone, and the RJ11
phone port is used for this purpose. Any ordinary analog phone set could be plug
into this jack. Then you may make the VoIP call, or switch the connection to the
PSTN (Public Switched Telephone Network) line and make a normal local phone
call. You can make the connection switch from the VoIP to the PSTN line through
pressing the special codes on the phone keypad. The default PSTN access code

is “*0” and it is user congurable.

Reset button

You may nd the Reset button at the bottom of the case. Press the button, with a

small rod or pen, and hold for 5 seconds to restore the factory default settings.

AX-112 Analog Telephone Adapter 11

Chapter 2 - Quick Installation

English

2. 2 Hardware connection

• Use a standard Category 5 (CAT5) Ethernet cable with RJ45 jack to
connect the WAN port of AX-112 to the LAN port of your ADSL modem or
router.

• Use another Ethernet cable to connect your PC or notebook to the LAN
port of AX-112 if necessary.

• Use an ordinary phone cable with RJ11 jack to connect the phone-set to

AX-112’s phone port.

• Use another phone cable with RJ11 jack to connect the AX-112’s line port

to your PSTN jack if necessary. The PSTN jack is normally on the wall.

• Connect the power adapter, and then refer to the next section for how to
assign an IP address to the WAN port for future operation.

2. 3 WAN IP assignment

After you have correctly set up the hardware connection, the next step is

the WAN port IP assignment. You may assign a xed IP address to AX-112

or enable its DHCP client to get an IP address from your DHCP server.

At the rst stage of assigning an IP address to the WAN port, you may get the IP

address by using the phone-set and entering the proper DTMF code command.
AX-112 will the report the WAN address for you by voice. You may access the

WAN port’s IP address via IVR. Follow the instructions below:

1. Pick up the phone and dial “****”; and

2. After hearing the voice menu, dial “100#”. You should hear the WAN

status reported by voice.

By default, the AX-112’s WAN port is set to the DHCP client mode. If there is no
DHCP server in your network, you can assign a xed IP address for AX-112 via
IVR. Refer to the Chapter 4 for more information on how to congure the IVR.

12 AX-112 Analog Telephone Adapter

Chapter3-Conguration

3. Conguration

In an Internet browser, enter the WAN IP address that you got either via the

DHCP server or the IVR). You will be taken to the AX-112’s web conguration
page, which consists of ve menu items for future settings.

3. 1 Status

In this page, you will see all the system
status including WAN port status,
IP/MAC address, system uptime and

rmware version.

3. 2 WAN

You can either choose to statically

congure or to dynamically congure

the WAN interface (via a DHCP server
on the network, or via PPP if you are
using PPPoE),

If you wish to statically assign the WAN
interface settings: enter the IP address, the subnet mask, the default gateway
IP address, and the DNS server IP address. It is also recommended that the
network domain name be provided as well, to ensure correct DNS operation.
Press “Apply” to save and apply the new settings.

English

3.2.1 NTP server

To automatically obtain the time via the NTP server:

1. Enter the NTP server address for the network (if this address is left blank, aEnter the NTP server address for the network (if this address is left blank, a
default public NTP server will be used, if accessible);

2. Select the time zone andelect the time zone and

3. Press the “Apply” button to save and apply the new settings.

AX-112 Analog Telephone Adapter 13

Chapter3-Conguration

English

3.2.2MACspoong

This eld allows the user to set the Ethernet hardware/MAC address to be used
by the WAN interface. This is typically done to mimic (‘spoof’ or ‘clone’) the MAC

address of one of the devices connected to the private LAN interface. To do this,
follow these steps:

1. Enter the 12 digits hardware address to assign to the WAN interface; andEnter the 12 digits hardware address to assign to the WAN interface; and

2. Press the “Apply” button to save and apply the new settings.

3. 3 SIP

3.3.1 SIP proxy server

Enter the SIP server’s address and port

value. The address may either be an IP

address or the server’s name. If you wish

to specify a special SIP domain name,
you may enter the domain name here.
If no domain name is entered, the SIP
domain name will be set to that of the
network (i.e. that which is obtained via

DHCP, or specied on the LAN settings

page).

Select whether or not to send a Registration Request to the SIP server by
assigning a value (in seconds) for the “Registration Expiration”. Enter the line
phone number, the Caller-ID Name, the signaling port value, the authentication
username and the password.

There are two groups of SIP server IP and account data elds for user to enter,
AX-112 will try to register with the rst one and if the rst registration failed, it will
try the second SIP server IP, if you have entered the conguration data. If both

of the SIP servers IP failed to register, you will hear a busy tone when you pick
up the phone-set. Otherwise, you will hear a normal dialing tone if the registration
is successful.

3.3.2 Outbound proxy

If you need to use outbound proxy, assign the outbound proxy server IP and its
port number.

14 AX-112 Analog Telephone Adapter

Chapter3-Conguration

3.3.3 NAT traversal setting

Select the NAT traversal type. You may check the uPnP button if your NAT/Firewall
supports uPnP SIP ALG, or assign the STUN server IP if you are using STUN
service. You may also assign the RTP port if there is port enabling on your router
settings.

3.3.4 ToS/DiffServ settings

This sub-page is used to congure the Type-of-Service/Diffserv byte values. These

values are to be used in the IP header of all transmitted SIP signaling packets and
RTP packets. The ToS/DiffServ byte values are entered as a two-digit hexadecimal

value. If no special ToS/DiffServ value is to be used for a particular trafc type,

enter “00” or leave the setting empty.

3. 4 Advanced setting

There are ve sub-pages in the advanced settings page. Basically, this page is for

the advanced users. Most of the time, the default settings should work for normal

application unless your service provider needs special conguration.

3.4.1 CODEC & Packet

English

CODECconguration

Choose which codecs are to be supported. For SIP protocol, the G711U and
G711A protocols are always supported by default. You can select which complex
codec is to be supported in AX-112. But due to memory limitations, it is not possible
to select more than one complex codec at the same time.

You can also select to enable or disable the silent suppression function for each
codec type. To do this, just click on the checkbox beside a codec type.

AX-112 Analog Telephone Adapter 15

Chapter3-Conguration

English

Packetization period

Select the packetization period to be used for each selected CODEC. Each codec
has a different basic packetize period (usually it’s 30ms for G.723, 10ms for G.729).
You can select longer time period to increase the transmission efciency. But,
longer packetization time will cause longer delay time.

3.4.2 DTMF & Gain & Dialling

DTMF

This eld allows conguration of the

DTMF signaling options for SIP. Select
whether the OOB (Out-Of-B and)
telephone event signaling is to be done
using the SIP INFO message; or to be
done via RFC2833 RTP signaling; or
select in band audio which will directly
transmit out the DTMF tone.

Jitter buffer

The Jitter Buffer settings apply to all active CODEC decoders. You may choose

an adaptive jitter buffer or a xed length jitter buffer. For an adaptive jitter buffer,
choose the maximum allowable play out delay (in milliseconds). For a xed jitter
buffer, choose the xed play out delay (in milliseconds). Finally, select whether

or not a decoder should automatically switch from an adaptive jitter buffer to

a xed jitter buffer upon fax/modem tone detection. Adaptive jitter buffers are

sometimes detrimental to fax transmission over G711 CODECs if they have to
adapt too rapidly or too extensively due to inconsistent and widespread packet

delays. In these adverse network conditions, a xed jitter buffer provides superior

performance when handling incoming fax transmissions over G711 CODECs.

Tx/Rx Gain

You can adjust the VoIP voice transmission and receive volume by adding or
decreasing the db value. The adjustable range is from –12db to +18db.

Actually , this is a very wide range for gain adjustment; the default value is 0 db
for both direction. To set the gain too high may cause echo, voice distortion or
DTMF tone will not be able to send the correct errors. Normally, it is reasonable
to make the adjustment between –6db to +6db range.

16 AX-112 Analog Telephone Adapter

Chapter3-Conguration

Phone default connect to

You can select the connection state of the phone set to VoIP FXS codec circuit

or to the PSTN port when the line is idle. It is set to ‘FXS’ by factory default for

normal usage. For one special case, when the caller ID signal from PSTN line

comes before the rst ring, then you may select the phone set to be connected

to PSTN as default and ensure all the caller ID signal pass to the phone set.

When you select the option “Phone default connect to PSTN”, you must make

sure your PSTN line is properly connected to the RJ11 jack of the line port and it is

working properly. If your PSTN line is not working with proper voltage on line, the

phone set will not operate properly.

Dialing plan

A dialing plan gives the unit a map to determine when a complete number has
been entered. Dialing plans are expressed using the same syntax as used by

MGCP NCS specication. The formal syntax of the dialing plan is described by

the following notation:

Digit ::= “0” | “1” | “2” | “3” | “4” | “5” | “6” | “7” | “8” | “9”
Timer ::= “T” | “t”
Letter ::= Digit | Timer | “#” | “*” | “A” | “a” | “B” | “b” | “C” | “c”| “D” | “d”

Range ::= “X” | “x” --matches any digit | “[“ Letters “]” --matches any of the specied

letters
Letters::= Subrange | Subrange Letters

Subrange::= Letter --matches the specied letter | Digit “-” Digit --matches any digit
between rst and last

Position::= Letter | Range
StringElement::= Position --matches any occurrence of the position | Position “.” -­matches an arbitrary number of occurrences including 0
String ::= StringElement | StringElement String
StringList::= String | String “|” StringList
DialPlan::= String | “(“ StringList “)”

English

A dialing plan, according to this syntax, is dened either by a (case insensitive)

string or by a list of strings. Regardless of the above syntax a timer is only allowed
if it appears in the last position in a string (12T3 is not valid). Each string is an
alternate numbering scheme. The unit will process the dialing plan by comparing

the current dial string against the dialing plan, if the result is not qualied (partial

matches at least one entry) then it will do nothing further. If the result matches or

is over-qualied (no further digits could possibly produce a match) then sends

out the string and clear the dial string. The Timer T is activated when it is all that
is required to produce a match. The period of timer T is 4 seconds. For example
a dialing plan of (xxxT|xxxxx) will match immediately if 5 digits are entered, it will
also match after a 4 second pause when 3 digits are entered.

AX-112 Analog Telephone Adapter 17

Chapter3-Conguration

English

Simple dial plan

Allows dialing of 7 digit numbers (e.g. 5551234) or an operator on 0. Dial plan
is (0T|xxxxxxx) .

Complex dial plan

Local operator on 0, long distance operator on 00, four digit local extension number

starting with 3,4 or 5, seven digit local numbers are prexed by an 8, two digit star
services (e.g. 69), ten digit long distance prexed by 91, and international numbers

starting with 9011+variable number of digits. Dial plan for this is:

(0T|00T|[3-5]xxx|8xxxxxxx|*xx|91xxxxxxxxxx|9011x.T)

Quick dial key

This function lets you to select if you want to use the “#” or “*” key as end of

DTMF input key, it’s useful especially when the dialing number length is not
xed. Pressing the “#” can notify AX-112 to stop waiting any more DTMF input

and sends the numbers out.

For system dialing plan, you may need to send the “#” and “*” key as part of the
dialing number. You may check the buttons to enable or disable this option.

Caller ID type

You can select the AX-112 output caller ID type to t to different phone-set. AX-

112 can show the incoming call ID to your phone set LCD. There are four types
supported that you can choose from. Refer to the list below.

Bellcore(N.Amer,China) (USA, CHINA , Belgium , Germany)
ETSI FSK with Brief Ring (France)
ETSI FSK With PR (UK)
NTT (Japan)

Service code

This sub-page is used to congure the service code. After the service code
has been dened, you can subscribe to a call service by setting it through the
keypad. You must have dened the parameter of these elds before using

relative command by phone set. Click “Apply” to make save and apply the new
settings.

ASUS recommends that you change the service code values only if there is a

conict with the setting of your service provider. Refer to Chapter 4: Operation

for more information.

18 AX-112 Analog Telephone Adapter

Chapter3-Conguration

Speed dial & phone book

AX-112 supports eight speed-dial and eight phone book entries for easy call

operation. You may enter the SIP extension number in the speed-dial elds. By
dialing the speed-dial prex code (default is ‘*68n’) dened in the “Service Code”

with the speed dial index number (1~8), AX-112 will send out the call invitation
through the registered SIP server.

The phone book has almost the same function as the speed-dial. The difference
is, it needs a user ID, an IP address, and a port number to send out call invitation.
This means you can not send out call invitation to different IP addresses through
the registered SIP server. Click the “Apply” button to save and apply the new
settings.

Tone

The various tone patterns generated by the AX-112 are all congurable via the
standard conguration variable process. This section describes how to congure

the commonly used tones. The “language” for specifying the tone components is
quite simple. Basically, the language is a combination of frequency, duration and
amplitude and it is known as ABNF. Please refer to the following examples:

Example 1: European dialtone

425Hz @ -5dbm0, tone repeats indenitely. In this case, the value of the ON time (i.e.

1000) is irrelevant, but MUST be greater than zero.

DIALTONE = 425@-5#ON(1000),R

Example 2: US ringback tone

440Hz @ -19dbm0 + 480Hz @ -19dbm0, with the following play out sequence being
repeated indenitely: ON for 2s, OFF for 4s.

RINGBACK = 440@-19+480@-19#ON(2000),OFF(4000),R

Example 3: Custom tone with repeated states.

In this case, a tone of two frequencies (440Hz@-5dbm0 + 1200Hz@-5dbm0) is played

out according to the following timing sequence: ON for 500ms, OFF for 500ms, ON for

500ms, OFF for 500ms, ON for 500ms, OFF for 500ms, ON indenitely (the value of
the last ON is irrelevant, but must be non-zero).

CUSTOM_1 = 440@-5+1200@-5#[ON(500),OFF(500)]3,ON(1000),R

English

AX-112 Analog Telephone Adapter 19

Chapter3-Conguration

English

3. 5 Management

3.5.1 Administration password

In the old password eld, input the

old password, if you have it. In the

new password eld, input the new
password. In the conrm password
eld, input the password again for
conrmation. Click the “Apply” button

to save the changes. If you have set
the password, the system will redirect
to the password-protected web
page. Input password that you have
changed , then press “Authenticate”
button into the system.

3.5.2 Firmware upgrade

This page provides three options
for downloading a new firmware
application image to the device.
If you wish to download the new

rmware image using TFTP, enter
the lename of the ROM image and

enter the IP address of the TFTP
server on which this file resides.
Press “Start” to initiate the TFTP
download process. If the ROM image is stored on the same local machine you

are using to access the device’s web pages, you can choose to download the
ROM le to the device using an HTTP post or URL. Enter the lename of the
ROM image or press “Browse” to help locate the le. Press “Start” to initiate the

HTTP download process.

20 AX-112 Analog Telephone Adapter

Chapter3-Conguration

3.5.3Conguration

To backup all the setting value in a le on your PC, just click the backup “Start”
button and then enter the le name to keep the data. To retrieve the setting value
from a le, click the restore “Start” button and enter the le name of the le you

want to retrieve.

3.5.4 Restore factory default

To restore AX-112’s factory default settings, click the “Start” button. You can also

press the reset button, located at the bottom of the case, for 5 seconds.

English

If you have made any changes to the conguration, reboot the AX-112 adapter.

AX-112 Analog Telephone Adapter 21

Chapter 4 - Operation

English

4. Operation

4. 1 IVR operation

To use the IVR, pick up the phone and dial four consecutive asterisks (****) to
enter the main IVR menu. To stop the IVR, just hang up the phone.

CODE STATUS USER INPUT

**** Menu Enter choice code.

100# Network status None.

110# WAN setting 1# to enable DHCP mode

2# to enable Static IP mode

3# to enable PPPoE mode

# back to menu

120# IP address setting Use “*” to instead of “.”, and “#” to

end. Or # back to menu.

130# Gateway setting Same as IP address setting

140# Net mask setting Same as IP address setting

22

AX-112 Analog Telephone Adapter

Chapter 4 - Operation

4.2 Call service features

AX-112 has a set of pre-dened service dial code for using the functions such

as conditional forwarding, call return, and PSTN mode switch. Refer to the

table for the functions’ description and usage.

English

FUNCTION PRESS

USAGE

KEY

(Default)

Conditional Call Forwarding *70# Enter the forwarding phone number right

after *70#, you will hear 3 short tone as

conrm.

Call Forward On *72# Same as above

Call Forward Off #72# 3 short tone will be played as conrm

Do Not Disturb On *74# Same as above. Will reject all incoming

call.

Do Not Disturb Off #74# 3 short tone will be played as conrm

Call Transfer *98# Enter the destination phone number

right after *98#, and hang up phone after
hearing 3 short tone will transfer the call
(blind transfer).

Call Return *69# Auto redial the previous one missed

incoming call.

Speed Dial *68n There are 8 speed dial number entries

on web GUI, you have to predene
the phone number in each eld for
this function. The value ‘n’ indicates
the relative number of speed dial eld

number from 1 to 8.

The relative setting elds on the web can not be left blank. You have to predene

all the call service command in the web GUI in advance, or use the default setting,

before using service functions.

ASUS recommends that you change the service code values only if you have meet

conict with the setting of your service provider.

AX-112 Analog Telephone Adapter 23

Chapter 4 - Operation

English

4.3 Life line / PSTN access

By default, when you pick up the phone set and dial a number, the number is
interpreted as a VoIP call. If you have connected the FXO to PSTN line on AX­112, you can dial to the PSTN line instead of VoIP by the PSTN access code. The

PSTN’s default access code is “*0”, and it is user congurable on the web GUI.

4.4 Conference call / Transfer call

To transfer a call

Blind Transfer: Transferring a call to a thri party without notifying the recipient.
Dial “*98#nnnn” (nnnn is the phone number of recipient) and hang up.

Attendant Transfer: Transferring a call to recipient an ensuring the call is
successfully transferred.

Talking with A --> Press ‘Flash’ key -->(Dial tone present) --> Dial the new party
number of B -->Press “*98#” --> Transfer complete

To make 3-way conference call

Talking with A --> Press ‘Flash’ key -->(Dial tone present) --> Dial the new party
number of B --> Conference

4. 5 LED indication

There are two LEDs located on the center and inside the box, they are in red and
green color. There is no LED hole or lens to guide the light out of the plastic box,
instead, the light is directly penetrating out of the white upper case. Refer to the
table for the possible status of the LED lighting pattern.

LED Pattern Possible Status

Red LED always on Firmware upgrading
Red LED blinking SIP ser ve r registr ation fai l/IP no t

dened

System error
Green LED always on SIP server registration success
Green LED blinking SIP server registration processing
Green LED on and off gradually every
two seconds

24

AX-112 Analog Telephone Adapter

Call progression

Chapter 5 - Troubleshooting

5. Troubleshooting

5.1 General Troubleshooting

There is no LED activity at power on.

• Check that the power supply unit (PSU) is properly connected.

• Check if the ‘Phone default connect to’ option at ‘Advanced’ setting page. If it
were set to “PSTN’ and your PSTN line is not wired properly (without voltage

presented), then there will be no dialing tone at all. If you have no PSTN line

connected to the AX-112 line port, please set the ‘Phone default connect to’

option to “FXS”.

5.2 Network Troubleshooting

General network activity problems. The device does not appear to be
performing any network related functions.

• For Ethernet devices, make sure that the Ethernet connection is secure, and
the Ethernet cable quality is good.

• Try pinging the device’s IP address from any Unix or Windows machine

connected to the same network.

Input: ping www.xxx.yyy.zzz [Enter]

(where www.xxx.yyy.zzz is the IP address of the unit).

English

The automatic DNS discovery process for a VoIP server does not
appear to work.

• Ensure that the DNS server is capable of servicing DNS TXT or SRV
queries, and that it is configured to respond with the correct server
information when queried.

• If the device is configured via DHCP, ensure that the DHCP server has provided
the correct DNS server and the domain name information.

AX-112 Analog Telephone Adapter 25

Chapter 5 - Troubleshooting

English

Thedevice’sWebpagesarenotaccessible.

• Try pinging the device’s IP address.

• The unit is trying to acquire a DHCP IP address. Make sure that the Ethernet
cable connection is secure.

• Verify that the DHCP server on the network is functioning.

• If you do not have a DHCP server or want to use a fixed IP address instead,
you need to reconfigure the device to use a static network assignment.

• If the device network information has been statically assigned (i.e. not via
DHCP), ensure that the DNS server IP address is correct, and that the network
domain name has been provided and is correct.

The web browser complains often about errors on the page.

• Ensure that the web browser supports frames and that javascript is enabled.

Although the device’s internal web pages should be accessible from most

modern web browsers, we recommend using Microsoft IE 5.0 (or later version)
or Netscape4.0 (or later version) for optimal results.

TheinterfaceisconguredforPPPoE,butisnotworking.

• If authentication is required, check that the username and password are
correct.

• The PPPoE server may require special Service Name or AC Name tags.
Check with the server if these tags are required and make sure the appropriate
values are configured.

I’veforgottentheIPaddressofthedevice,andhencecannotreachitviamy

web browser

• Please refer to Chapter 4.1 IVR Operation for how to use IVR to check your
WAN port status.

26 AX-112 Analog Telephone Adapter
