Asrock H670M-ITX/ax Quick Installation Guide

Version 1.0
Published December 2021
Copyright©2021 ASRock INC. All rights reserved.

Copyright Notice:

No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.

Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or tness for a particular
purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of prots, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage caused by our goods. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure. If you require assistance please call ASRock Tel

: [phone] ext.123 (Standard International call charges apply)

e terms HDMI® and HDMI High-Denition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

INTEL END USER SOFTWARE LICENSE AGREEMENT

IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING.

LICENSE. Licensee has a license under Intel’s copyrights to reproduce Intel’s Soware
only in its unmodied and binary form, (with the accompanying documentation, the
“Soware”) for Licensee’s personal use only, and not commercial use, in connection with
Intel-based products for which the Soware has been provided, subject to the following
conditions:

(a) Licensee may not disclose, distribute or transfer any part of the Soware, and You agree
to prevent unauthorized copying of the Soware.

(b) Licensee may not reverse engineer, decompile, or disassemble the Soware.

(c) Licensee may not sublicense the Soware.

(d) e Soware may contain the soware and other intellectual property of third party
suppliers, some of which may be identied in, and licensed in accordance with, an enclosed
license.txt le or other text or le.

(e) Intel has no obligation to provide any support, technical assistance or updates for the
Soware.

OWNERSHIP OF SOFTWARE AND COPYRIGHTS. Title to all copies of the Soware
remains with Intel or its licensors or suppliers. e Soware is copyrighted and protected
by the laws of the United States and other countries, and international treaty provisions.
Licensee may not remove any copyright notices from the Soware. Except as otherwise
expressly provided above, Intel grants no express or implied right under Intel patents,
copyrights, trademarks, or other intellectual property rights. Transfer of the license termi­nates Licensee’s right to use the Soware.

DISCLAIMER OF WARRANTY. e Soware is provided “AS IS” without warranty of
any kind, EITHER EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PUR­POSE.

LIMITATION OF LIABILITY. NEITHER INTEL NOR ITS LICENSORS OR SUPPLIERS
WILL BE LIABLE FOR ANY LOSS OF PROFITS, LOSS OF USE, INTERRUPTION OF
BUSINESS, OR INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAG

ES OF ANY KIND WHETHER UNDER THIS AGREEMENT OR OTHERWISE, EVEN
IF INTEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

LICENSE TO USE COMMENTS AND SUGGESTIONS. is Agreement does NOT
obligate Licensee to provide Intel with comments or suggestions regarding the Soware.
However, if Licensee provides Intel with comments or suggestions for the modication,
correction, improvement or enhancement of (a) the Soware or (b) Intel products or
processes that work with the Soware, Licensee grants to Intel a non-exclusive, worldwide,
perpetual, irrevocable, transferable, royalty-free license, with the right to sublicense, under
Licensee’s intellectual property rights, to incorporate or otherwise utilize those comments
and suggestions.

TERMINATION OF THIS LICENSE. Intel or the sublicensor may terminate this license
at any time if Licensee is in breach of any of its terms or conditions. Upon termination,
Licensee will immediately destroy or return to Intel all copies of the Soware.

THIRD PARTY BENEFICIARY. Intel is an intended beneciary of the End User License
Agreement and has the right to enforce all of its terms.

U.S. GOVERNMENT RESTRICTED RIGHTS. e Soware is a commercial item (as
dened in 48 C.F.R. 2.101) consisting of commercial computer soware and commercial
computer soware documentation (as those terms are used in 48 C.F.R. 12.212), consistent
with 48 C.F.R. 12.212 and 48 C.F.R 227.7202-1 through 227.7202-4. You will not provide
the Soware to the U.S. Government. Contractor or Manufacturer is Intel Corporation,
2200 Mission College Blvd., Santa Clara, CA 95054.

EXPORT LAWS. Licensee agrees that neither Licensee nor Licensee’s subsidiaries will
export/re-export the Soware, directly or indirectly, to any country for which the U.S.
Department of Commerce or any other agency or department of the U.S. Government
or the foreign government from where it is shipping requires an export license, or other
governmental approval, without rst obtaining any such required license or approval. In
the event the Soware is exported from the U.S.A. or re-exported from a foreign destina­tion by Licensee, Licensee will ensure that the distribution and export/re-export or import
of the Soware complies with all laws, regulations, orders, or other restrictions of the U.S.
Export Administration Regulations and the appropriate foreign government.

APPLICABLE LAWS. is Agreement and any dispute arising out of or relating to it will
be governed by the laws of the U.S.A. and Delaware, without regard to conict of laws
principles. e Parties to this Agreement exclude the application of the United Nations
Convention on Contracts for the International Sale of Goods (1980). e state and federal
courts sitting in Delaware, U.S.A. will have exclusive jurisdiction over any dispute arising
out of or relating to this Agreement. e Parties consent to personal jurisdiction and venue
in those courts. A Party that obtains a judgment against the other Party in the courts iden­tied in this section may enforce that judgment in any court that has jurisdiction over the
Parties.

Licensee’s specic rights may vary from country to country.

CE Warning

is device complies with directive 2014/53/EU issued by the Commision of the European
Community.

is equipment complies with EU radiation exposure limits set forth for an uncontrolled
environment.
is equipment should be installed and operated with minimum distance 20cm between
the radiator & your body.

Operations in the 5.15-5.35GHz band are restricted to indoor usage only.

Radio transmit power per transceiver type

Function Frequency Maximum Output Power (EIRP)

2400-2483.5 MHz 18.5 + / -1.5 dbm

5150-5250 MHz 21.5 + / -1.5 dbm

WiFi

Bluetooth 2400-2483.5 MHz 8.5 + / -1.5 dbm

5250-5350 MHz

5470-5725 MHz

18.5 + / -1.5 dbm (no TPC)

21.5 + / -1.5 dbm (TPC)

25.5 + / -1.5 dbm (no TPC)

28.5 + / -1.5 dbm (TPC)

Motherboard Layout

PCIE1

DDR4_ A1 (64 bi t, 288- pi n mod ul e)

DDR4_ B1 (64 bi t, 288- pi n mod ul e)

CPU_FAN1

CHA_FAN1/WP

7

RoHS

H670M-ITX/ax

2

8

10

15

9

19

16

6

1

HD_AUDIO1

SPEAK ER1

Intel

H670

ATXPWR1

USB3_ 12

1

4

3

PANEL1

HDLED RESET

PLED PWRBTN

1

Top:

LIN E IN

Cen ter:

FRO NT

Bot tom:

MIC I N

SATA3_3

SATA3_2

1

CLRMOS1

SATA3_1

SATA3_0

1

USB_56

M2_ 2

RJ-45:

2.5G LAN

1

11

12

13

14

M2_WIFI1

DP_ 1

CHA_FAN2

USB 3.2 Gen2x2:

USB32_TC_1

HDM I1

USB 2.0
T: USB_1
B: USB_2

RGB_LED1

1

M2_ 1

USB 3.2 Gen2:

USB31_TA_1

RJ-45:

LAN

USB 2.0:

USB_3

USB 3.2 Gen2:

USB_4

F_USB3_TC_1

ADDR_ LED1

1

5

17

18

BIOS_FB1_PH1

USB 2.0:

BIOS_FB1_USB1

1

H670M-ITX/ax

English

1

No. Description

1 Chassis/Waterpump Fan Connector (CHA_FAN1/WP)

2 ATX 12V Power Connector (ATX12V1)

3 CPU Fan Connector (CPU_FAN1)

4 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)

5 RGB LED Header (RGB_LED1)

6 ATX Power Connector (ATXPWR1)

7 USB 2.0 Header (USB_56)

8 USB 3.2 Gen1 Header (USB3_12)

9 SATA3 Connector (SATA3_1)

10 SATA3 Connector (SATA3_0)

11 SATA3 Connector (SATA3_3)

12 SATA3 Connector (SATA3_2)

13 Front Panel Type C USB 3.2 Gen1 Header (F_USB3_TC_1)

14 System Panel Header (PANEL1)

15 Addressable LED Header (ADDR_LED1)

16 Clear CMOS Jumper (CLRMOS1)

17 Chassis Fan Connector (CHA_FAN2)

18 Chassis Speaker Header (SPEAKER1)

19 Front Panel Audio Header (HD_AUDIO1)

English

2

I/O Panel

H670M-ITX/ax

5

1

2

3 4

6

15

14

13

911

8

7

12 10

No. Description No. Description

1 DisplayPort 1.4 9 USB 3.2 Gen2 Type-A Port (USB31_TA_1)

2 BIOS Flashback Button 10 USB 3.2 Gen2x2 Type-C Port (USB32_TC_1)

3 LAN RJ-45 Port (Intel® I219V)* 11 USB 2.0 Port (USB_3)

4 2.5G LAN RJ-45 Port (Dragon RTL8125BG)** 12 USB 3.2 Gen2 Port (USB_4)

5 Line In (Light Blue)*** 13 USB 2.0 Ports (USB_12)

6 Front Speaker (Lime)*** 14 USB 2.0 Port (BIOS_FB1_USB1)

7 Antenna Ports 15 HDMI Port

8 Microphone (Pink)***

* ere are two LEDs on ea ch LAN port. Please refer to the table below for the LA N port LED indications .

ACT/LINK LED

SPEED LED

LAN Por t

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection

English

3

** ere are two LEDs on each LAN port. Please refe r to the table below for the LA N port LED indications.

ACT/LINK LED

SPEED LED

LAN Por t

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection
Blinking Data Activity Orange 100Mbps/1Gbps connection

On Link Green 2.5Gbps connection

*** Function of the Audio Ports in 7.1-channel Conguration:

Port Function

Light Blue (Rear panel) Rear Speaker Out
Lime (Rear panel) Front Speaker Out
Pink (Rear panel) Central /Subwoofer Speaker Out
Lime (Front panel) Side Speaker Out

English

4

H670M-ITX/ax

802.11ax Wi-Fi 6E Module and ASRock WiFi 2.4/5/6 GHz
Antennas

802.11ax Wi-Fi 6E + BT Module

is motherboard comes with an exclusive 802.11 a/b/g/n/ax Wi-Fi 6E + BT module
(pre-installed on the rear I/O panel) that oers support for 802.11 a/b/g/n/ax Wi­Fi 6E connectivity standards and Bluetooth. Wi-Fi 6E + BT module is an easy­to-use wireless local area network (WLAN) adapter to support Wi-Fi 6E + BT.
Bluetooth standard features Smart Ready technology that adds a whole new class of
functionality into the mobile devices. BT also includes Low Energy Technology and
ensures extraordinary low power consumption for PCs.

* e transmission speed may vary according to the environment.

* Wi-Fi 6E (6GHz band) is not currently enabled by default due to the dierent
regulation status of each country. It will be activated (for supported countries)
through Windows Update and soware update once available. e update is
expected to be in the middle of 2021.

English

5

WiFi Antennas Installation Guide

Step 1

Prepare the WiFi 2.4/5/6 GHz Antennas that
come with the package.

Step 2

Connect the two WiFi 2.4/5/6 GHz Antennas
to the antenna connectors. Turn the antenna
clockwise until it is securely connected.

Step 3

Set the WiFi 2.4/5/6 GHz Antenna as shown in
the illustration.

*You may need to adjust the direction of
the antenna for a stronger signal.

English

6

Chapter 1 Introduction

ank you for purchasing ASRock H670M-ITX/ax motherboard, a reliable
motherboard produced under ASRock ’s consistently stringent quality control.
It delivers excellent performance with robust design conforming to ASRock’s
commitment to quality and endurance.

Becau se the motherboard specication s and the BIOS soware might be updated, the
content of this doc umentation will be subject to change without notice. In case any
modications of this documentation occur, the updated version w ill be available on
ASRock’s website without further notice. If you require technical support related to
this motherboard, please visit our website for specic infor mation about the model
you are using. You may nd the latest VGA cards and CPU support li st on ASRock’s
website a s well. ASRock website http://www.asrock.com.

1.1 Package Contents

ASRock H670M-ITX/ax Motherboard (Mini-ITX Form Factor)

•

ASRock H670M-ITX/ax Quick Installation Guide

•

ASRock H670M-ITX/ax Support CD

•

2 x Serial ATA (SATA) Data Cables (Optional)

•

1 x I/O Panel Shield

•

2 x ASRock WiFi 2.4/5/6 GHz Antennas (Optional)

•

2 x Screws for M.2 Sockets (Optiona l)

•

H670M-ITX/ax

English

7

1.2 Specications

Platform

CPU

Chipset

Memory

•

•

•

•

•

•

•

•

•

•

•

* Supports DDR4 3200 natively.
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)

•

•

•

Mini-ITX Form Factor
8 Layer PCB

Supports 12th Gen Intel® CoreTM Processors (LGA1700)
Digi Power design
8 Power Phase design
Supports Intel® Hybrid Technology
Supports Intel® Turbo Boost Max 3.0 Technology

Intel® H670

Dual Channel DDR4 Memory Technology
2 x DDR4 DIMM Slots
Supports DDR4 non-ECC, un-buered memory up to
5000+(OC)*

Supports ECC UDIMM memory modules (operate in non­ECC mo de)
Max. capacity of system memory: 64GB
Supports Intel® Extreme Memory Prole (XMP) 2.0

English

8

Expansion
Slot

Graphics

1 x PCIe Gen5x16 Slot*

•

* Supports PCIe riser cards to extend one x16 slot to two x8 slots
* Supports NVMe SSD as boot disks

1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT

•

PCIe WiFi module and Intel® CNVi (Integrated WiFi/BT)

* Intel® UHD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.

Intel® Xe Graphics Architecture (Gen 12)

•

Dual graphics output: support HDMI and DisplayPort 1.4

•

ports by independent display controllers
Supports HDMI 2.1 TMDS Compatible with max. resolution

•

up to 4K x 2K (4096x2160) @ 60Hz

Audio

Supports DisplayPort 1.4 with DSC (compressed) max.

•

resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @
120Hz
Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and

•

DisplayPort 1.4 Ports

7.1 CH HD Audio (Realtek ALC897 Audio Codec)

•

Supports Surge Protection

•

Nahimic Audio

•

H670M-ITX/ax

LAN

Wireless
LAN

1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s (Dragon RTL-

8125BG)

Supports Dragon 2.5G LAN Soware

•

- Smart Auto Adjust Bandwidth Control

- Visual User Friendly UI

- Visual Network Usage Statistics

- Optimized Default Setting for Game, Browser, and
Streaming Modes

- User Customized Priority Control
Supports Wake-On-LAN

•

Supports Lightning/ESD Protection

•

Supports Energy Ecient Ethernet 802.3az

•

Supports PXE

•

1 x Gigabit LAN 10/100/1000 Mb/s (Intel® I219V)

Supports Wake-On-LAN

•

Supports Lightning/ESD Protection

•

Supports Energy Ecient Ethernet 802.3az

•

Supports UEFI PXE

•

802.11ax Wi-Fi 6E Module

•

Supports IEEE 802.11a/b/g/n/ax

•

Supports Dual-Band 2x2 160MHz with extended 6GHz

•

band* support

* Wi-Fi 6E (6GHz band) will be supported by Microso®
Windows® 11. e availability will depend on the dierent
regulation status of each country and region.
It will be activated (for supported countries) through Windows
Update and soware updates once available.
* A 6GHz compatible router is required for 6E functionality.

English

9

Rear Panel
I/O

Storage

2 antennas to support 2 (Transmit) x 2 (Receive) diversity

•

technology
Supports Bluetooth + High speed class II

•

Supports MU-MIMO

•

2 x Antenna Ports

•

1 x HDMI Port

•

1 x DisplayPort 1.4

•

2 x USB 3.2 Gen2 Ports (10 Gb/s) (Supports ESD Protection)

•

1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s) (Supports ESD

•

Protection)
4 x USB 2.0 Ports (Supports ESD Protection)

•

2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED

•

LED)
1 x BIOS Flashback Button

•

HD Audio Jacks: Line in / Front Speaker / Microphone

•

4 x SATA3 6.0 Gb/s Connectors

•

1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280

•

PCIe Gen4x4 (64 Gb/s) mode*
1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280

•

SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes*
* Supports Intel® OptaneTM Tech nol ogy
* Supports Intel® Volume Management Device (VMD)
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit

English

10

RAID

Connector

Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA

•

storage devices

Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe

•

storage devices*
* Requires additional M.2 NVMe expansion cards to support
RAID 5

1 x RGB LED Header

•

* Supports in total up to 12V/3A, 36W LED Strip

1 x Addressable LED Header

•

* Supports in total up to 5V/3A, 15W LED Strip

1 x CPU Fan Connector (4-pin)

•

* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.

BIOS
Feature

H670M-ITX/ax

1 x Chassis Fan Connector (4-pin)

•

* e Chassis Fan Connector supports the chassis fan of maxi­mum 1A (12W) fan power.

1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan

•

Speed Control)
* e Chassis/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
* CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.

1 x 24 pin ATX Power Connector

•

1 x 8 pin 12V Power Connector (Hi-Density Power Connec-

•

tor)

1 x Front Panel Audio Connector

•

1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports

•

ESD Protection)

1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)

•

(Supports ESD Protection)

1 x Front Panel Type C USB 3.2 Gen1 Header (Supports ESD

•

Protection)

AMI UEFI Legal BIOS with multilingual GUI support

•

ACPI 6.0 Compliant wake up events

•

SMBIOS 2.7 Support

•

CPU Core/Cache, CPU GT, DRAM, VCCIN AUX, +1.05V

•

PROC, +1.8V PROC, +0.82V PCH, +1.05V PCH Voltage

Multi-adjustment

Fan Tachometer: CPU, Chassis, Chassis/Water Pump Fans

Hardware
Monitor

OS

Certica­tions

* For detailed product infor mation, please visit our website: http://www.asrock .com

•

Quiet Fan (Auto adjust chassis fan speed by CPU tempera-

•

ture): CPU, Chassis, Chassis/Water Pump Fans

Fan Multi-Speed Control: CPU, Chassis, Chassis/Water

•

Pump Fans

Voltage monitoring: CPU Vcore, +12V, +5V, +3.3V

•

Microso® Windows® 10 64-bit / 11 64-bit

•

FCC, CE

•

ErP/EuP ready (ErP/EuP ready power supply is required)

•

English

11

Please realize that there is a certain risk involved with overclocking, including
adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using
third-party overclocking tools. Overclocking may aect your system’s stability, or
even cause damage to the components and devices of your system . It should be done
at your own risk and expen se. We are not responsible for possible damage caused by
overclocking.

English

12

H670M-ITX/ax

Chapter 2 Installation

is is a Mini-ITX form factor motherboard. Before you install the motherboard,
study the conguration of your chassis to ensure that the motherboard ts into it.

Pre-installation Precautions

Take note of the following precautions before you install motherboard components
or change any motherboard settings.

Make sure to unplug the power cord before installing or removing the motherboard

•

components. Failure to do so may cause physical injuries and damages to motherboard
components.
In order to avoid damage from static electricity to the motherboard’s components,

•

NEVER place your motherboard directly on a carpet. Also remember to use a grounded
wrist strap or touch a safety grounded object before you handle the components.
Hold components by the edges and do not touch the ICs.

•

Whenever you uninstall any components, place them on a grounded anti-static pad or

•

in the bag that comes with the components.
When placing screws to secure the motherboard to the chassis, please do not over-

•

tighten the screws! Doing so may damage the motherboard.

13

English

2.1 Installing the CPU

1. Before you insert the 1700-Pin CPU into the socket, please check if the PnP cap
is on the socket, if the CPU surface is unclean, or if there are any bent pins in the
socket. Do not force to insert the CPU into the socket if above situation i s found.
Other wise, the CPU will be seriously damaged.

2. Unplug all power cables before installing the CPU.

1

A

B

English

14

2 3

H670M-ITX/ax

4

76

5

15

English

Please save and replace the cover if the processor is removed. e cover must be
placed if you wish to return the motherboard for aer service.

English

16

2.2 Installing the CPU Fan and Heatsink

1 2

H670M-ITX/ax

CPU_FAN

English

17

2.3 Installing Memory Modules (DIMM)

is motherboard provides two 288-pin DDR4 (Double Data Rate 4) DIMM slots,
and supports Dual Channel Memory Technology.

1. For dual channel conguration, you always need to install identical (the same
brand, speed, size and chip-ty pe) DDR4 DIMM pairs.

2. It is unable to activate Dual Channel Memory Technology with only one memory
module installed.

3. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4
slot; otherwi se, this motherboard and DIMM may be damaged .

e DIMM only ts in one correct orientation. It will cause permanent damage to
the mothe rboard and the DIMM if you force the DIMM into the slot at incorrect
orientation.

English

18

H670M-ITX/ax

1

2

3

English

19

2.4 Expansion Slot (PCI Express Slot)

ere is 1 PCI Express slot on the motherboard.

Before installing an expansion card, ple ase make sure that the power supply is
switched o or the power cord is unplug ged. Please read the documentation of the
expan sion card and make necessary hardware settings for the card before you start
the installation.

PCIe slot:
PCIE1 (PCIe 5.0 x16 slot) is used for PCIe x16 lane width graphics cards.

English

20

H670M-ITX/ax

2.5 Jumpers Setup

e illustration shows how jumpers are setup. When the jumper cap is placed on
the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is

“Open”.

Clear CMOS Jumper
(CLR MOS1)
(see p.1, No. 16)

CLRMOS1 allows you to clear the data in CMOS. To clear and reset the system
parameters to default setup, please turn o the computer and unplug the power
cord from the power supply. Aer waiting for 15 seconds, use a jumper cap to
short the pins on CLRMOS1 for 5 seconds. However, please do not clear the
CMOS right aer you update the BIOS. If you need to clear the CMOS when you
just nish updating the BIOS, you must boot up the system rst, and then shut it
down before you do the clear-CMOS action. Please be noted that the password,
date, time, and user default prole will be cleared only if the CMOS battery is
removed. Please remember toremove the jumper cap aer clearing the CMOS.

2-pin Jumper

21

English

2.6 Onboard Headers and Connectors

Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over
these headers and connectors. Placing jumper caps over the headers and connectors
will cause permanent damage to the motherboard.

System Panel Header
(9-p in PA NEL1)
(see p.1, No. 14)

PWRBTN (Power Swi tch):

Connec t to the power switch on the chassis f ront panel. You may congure the way to
turn o your system using the power switch.

RESET (Reset Sw itch):
Connec t to the reset switch on the cha ssis front panel. Press the reset switch to restar t
the computer if the computer f reezes and fails to per form a normal restart.

PLED (Syste m Power LED):
Connec t to the power status indicator on the chassi s front panel. e LED is on when
the system is operating. e LED keeps blinking when the system is in S1/S3 sleep
state. e LED is o when the system is in S4 sleep state or powe red o (S5).

HDLED (Ha rd Drive Activity LED):
Connec t to the hard drive activity LED on the chassis f ront panel. e LED is on
when the hard drive is reading or writing data.

e front panel design may dier by chassis . A front panel module mainly consists
of power switch, reset switch, power LED, hard drive activity LED, speaker and etc.
When connecting your cha ssis front panel module to this header, make sure the wire
assig nments and the pin assignments are matched correctly.

Connect the power
switch, reset switch and
system status indicator on
the chassis to this header
according to the pin
assignments below. Note
the positive and negative
pins before connecting
the cables.

English

22

H670M-ITX/ax

Serial ATA3 Connectors
(SATA3_0:
see p.1, No. 10)
(SATA3_1:
see p.1, No. 9)
(SATA3_2:
see p.1, No. 12)
(SATA3_3:
see p.1, No. 11)

USB 2.0 Header
(9-pin USB_56)
(see p.1, No. 7)

USB 3.2 Gen1 Header
(19-pin USB3_12)
(see p.1, No. 8)

SATA3_1

SATA3_3

Vbus

IntA_PA_SSRX-

IntA_PA_SSRX+

GND

IntA_PA_SSTX-

IntA_PA_SSTX+

GND

IntA_PA_D-

IntA_PA_D+

VbusVbus

IntA_PB_SSRX-

IntA_PB_SSRX+

GND

IntA_PB_SSTX-

IntA_PB_SSTX+

GND

IntA_PB_D-

IntA_PB_D+

Dummy

1

ese four SATA3
connectors support SATA
data cables for internal

SATA3_0

storage devices with up to

6.0 Gb/s data transfer rate.

SATA3_2

ere is one USB2.0
header on this
motherboard. is USB

2.0 header can support
two ports.

ere is one header on
this motherboard. is
USB 3.2 Gen1 header can
support two ports.

Front Panel Type C USB

3.2 Gen1 Header
(20-pin F_USB3_TC_1)
(see p.1, No. 13)

Front Panel Audio Header
(9-pin HD_AUDIO1)
(see p.1, No. 19)

USB Type-C Cable

GND

PRESENCE#

MIC_RET

1

OUT2_R

MIC2_R

MIC2_L

OUT_RET

OUT2_L

J_SENSE

ere is one Front
Panel Type C USB 3.2
Gen1 Header on this
motherboard. is header
is used for connecting a
USB 3.2 Gen1 module for
additional USB 3.2 Gen1
ports.

is header is for
connecting audio devices
to the front audio panel.

English

23

4 3 2 1

1. High Denition Audio supports Jack Sensing, but the panel wire on the chassis
must support HDA to function correctly. Plea se follow the instructions in our
manual and chassis manual to install your system.

2. If you use an AC’97 audio panel, please in stall it to the front panel audio header by
the steps below:
A. Connect Mic_ IN (MIC) to MIC2_L.
B. Conne ct Audio_R (RIN) to OUT2 _R and Audio_ L (LIN) to OUT2_ L.
C. Connect Ground (GND) to Ground (GND).
D. MIC_ RET and OUT_RET are for the HD audio panel only. You don’t need to
connect them for the AC’97 audio panel.
E. To activate the front mic, go to the “FrontMic” Tab in the Realtek Control panel
and adjust “Recording Volume”.

English

Chassis Speaker Header
(4-pin SPE AKER 1)
(see p.1, No. 18)

Chassis/Water Pump Fan
Connector
(4-pin CHA_FAN1/WP)
(see p.1, No. 1)

Chassis Fan Connector
(4-pin CHA_FAN2)
(see p.1, No. 17)

SPEAKER

DUMMY

DUMMY

+5V

1

FAN_SPEED_CONTROL

CHA_FAN_SPEED

FAN_VOLTAGE

FAN_SPEED_CONTROL

CHA_FAN_SPEED

4 3 2 1

GND

+12V

GND

Please connect the chassis
speaker to this header.

is motherboard
provides a 4-Pin water
cooling

chassis

fan
connector. If you plan to
connect a 3-Pin

chassis
water cooler fan, please
connect it to Pin 1-3.

Please connect fan cables
to the fan connector and
match the black wire to
the ground pin.

24

H670M-ITX/ax

FAN_SPEED

FAN_SPEED_CONTROL

+12V

GND

4

2

3

1

8 5

CPU Fan Connector
(4-pin CPU_FAN1)
(see p.1, No. 3)

ATX Power Connector
(24-pin AT XPWR 1)
(see p.1, No. 6)

ATX 12V Power
Connector
(8-pin ATX12V1)
(see p.1, No. 2)

12

24

1

13

4

is motherboard pro­vides a 4-Pin CPU fan
(Quiet Fan) connector.
If you plan to connect a
3-Pin CPU fan, please
connect it to Pin 1-3.

is motherboard pro­vides a 24-pin ATX power
connector.

is motherboard
provides a 8-pin ATX 12V

1

power connector. To use a
4-pin ATX power supply,
please plug it along Pin 1
and Pin 5.

*Warning: Please make

sure that the power cable

connected is for the CPU

and not the graphics

card. Do not plug the

PCIe power cable to this

connec tor.

RGB LED Header
(4-pin RGB _LED1)
(see p.1, No. 5)

B

R

G

12V

1

RGB header is used to connect
RGB LED extension cable which
allows users to choose from vari­ous LED lighting eects.

Caution: Never install the RGB

LED cable in the wrong orienta-

tion; otherwise, the cable may

be damaged.

* Please refer to page 33 for

English

further instructions on this
header.

25

Addressable LED Header
(3-pin ADDR _LED1)
(see p.1, No. 15)

is header is used to connect
Addressable
which allows users to choose
from various LED lighting
eects.

Caution: Never install the

Addressable LED cable in the

wrong orientation; otherwise,

the cable may be damaged.

* Please refer to page 34 for
further instructions on this
header.

LED extension cable

English

26
