USER GUIDE
Pace Xi3
PX031ANI
BRINGING TECHNOLOGY HOME
www.pace.com
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights.
Use of this copyright protection technology must be authorized by Rovi corporation, and is intended for home and other limited
pay-per-view uses only unless otherwise authorized by Rovi corporation. Reverse engineering or disassembly is prohibited.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
CableCARD™ is a trademark of Cable Television Laboratories, Inc.
COMCAST, the COMCAST logo, XFINITY and the XFINITY logo are all trademarks or service marks of Comcast
Corporation or its subsidiaries. All other trademarks and service marks appearing herein are the properties of their
respective owners.
Other trademarks listed herein are the property of their respective owners.
© 2013 Pace plc. All rights reserved. Pace and are trademarks and/or registered trademarks of Pace plc
Xi3 (PX031ANI) USER GUIDE DRAFT (501-340120x)
2
CAUTION
SAFETY INFORMATION
This digital set-top box has been manufactured and tested with your safety
in mind. However, improper use can result in potential electric shock,
property damage or fire hazards. To avoid defeating the safeguards that
have been built into your set-top box, please observe the precautions
discussed in this document.
Warnings on the power supply unit
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within a triangle,
is intended to alert you to the presence of uninsulated
“dangerous” voltages within your set-top box’s enclosure
that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a triangle is intended to alert
you to the presence of important instructions in the literature
accompanying your set-top box.
To ensure correct operation, use this set-top box only with the Paceapproved power supply unit provided. If you use an unapproved
alternative, you will invalidate the warranty.
Other warnings
To reduce the risk of electric shock, do not remove the cover of your settop box. There are no user-serviceable parts inside it.
Do not perform any servicing unless you are qualified to do so. Refer all
servicing to qualified service personnel. Servicing the set-top box yourself
will invalidate the warranty.
To reduce the risk of fire or electric shock, do not expose this set-top box
to rain or moisture.
On the rear panel of your set-top box there is a tamper-evident label that
states ‘Warranty void if broken or removed’.
IMPORTANT SAFETY INSTRUCTIONS
Before you install or use the apparatus, you must read and
understand these Important Safety Instructions.
At all times when using the apparatus you must follow
these Important Safety Instructions to reduce the risk of fire,
electrical shock and injury to persons.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or groundingtype plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into the outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Installation
The installation of your set-top box should be carried out by a qualified
installer and should conform to local codes.
Note to the installer
This reminder is provided to call the attention of the cable-TV-system
installer to Section 820 of the National Electrical Code (USA), which
provides guidelines for proper grounding and, in particular, specifies
that the cable ground shall be connected to the grounding system of the
building, as close to the point of cable entry as is practical.
Xi3 (PX031ANI) USER GUIDE DRAFT (501-340120x)
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
Service address:
Pace Americas Inc.
3701 FAU Boulevard, Suite 200, Boca Raton, Florida 33431 U.S.A.
3
SAFETY INFORMATION (cont.)
In addition to the Important Safety Instructions, please read the Safety
Information below.
Power sources
The model number, serial number, and electrical rating of this set-top box
are on a label on its base.
You must operate your set-top box only from the type of power source
indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your dealer or local power company. If you
move your set-top box between locations at different temperatures, allow it
to reach room temperature before you apply power to it.
Overloading
Do not overload wall AC outlets, extension cords or other power outlets as
this can result in a risk of fire or electric shock.
To avoid possible damage to your set-top box or to a connected TV or
component, all AC power cords must be plugged into properly wired
outlets. As with all electrical products, connection to faulty or defective
components, or the failure to connect your set-top box to a properly wired
outlet, may cause sparking, property damage or damage to any TV or other
component connected to your set-top box and pose a fire hazard.
Lightning
For added protection for your set-top box during a lightning storm, or when
it is left unattended and unused for long periods of time, disconnect your
set-top box from the power supply and disconnect the cable system from
your set-top box. See also item 13 in the Important Safety Instructions.
Ambient temperature
The operating temperature range of your set-top box is 32-104°F. If the
ambient temperature around your set-top box falls outside this range, you
must correct this in order for your set-top box to work correctly and safely.
For example, if the temperature is too high, make sure there is sufficient
ventilation (see below) and that your set-top box is not directly on top of or
underneath other equipment.
Ventilation
Slots and openings in the casing of your set-top box are provided for
ventilation, to ensure reliable operation of your set-top box and to protect it
from overheating.
• Never block the ventilation
openings by placing your settop box on a bed, sofa, rug, or
other similar surface. Place it
on a hard, flat surface.
• Never cover the ventilation
openings with items such as
newspapers, table-cloths, or
curtains.
3 in.
3 in.
3 in.
• You can place your set-top
box near other consumer
electronics devices, such as
stereo amplifiers or televisions,
but you must not place it directly on top or underneath them.
• Do not place your set-top box in a built-in installation such as a
bookcase or rack unless proper ventilation is provided and you have
adhered to the manufacturer’s instructions.
• Maintain a minimum distance of three inches around your
set-top box for sufficient ventilation.
See also item 7 in the Important Safety Instructions.
Water and moisture
Do not expose your set-top box to rain or moisture, dripping or splashing,
and ensure that no objects filled with liquids, such as vases, are placed on
your set-top box. See also item 5 in the Important Safety Instructions.
Entry of objects and liquids
Never push objects of any kind into your set-top box through openings
as they may touch dangerous voltage points or short-out parts that could
result in fire or electric shock. Never spill liquid of any kind on your settop box.
Transporting
Move the combination of set-top box and cart with care. Quick stops,
excessive force and uneven surfaces may cause the combination of
set-top box and cart to overturn. See also item 12 in the Important Safety
Instructions.
Placement and mounting
Do not place your set-top box on an unstable or uneven surface. Your
set-top box may fall, causing serious injury to a child or adult and serious
damage to your set-top box. If you mount your set-top box, for example
to a wall or ceiling, follow the manufacturer’s instructions and use a
mounting accessory recommended by the manufacturer. See also item 12
in the Important Safety Instructions.
Risk of fire or scorching
Never place naked flame sources, such as lighted candles, on or adjacent
to your set-top box.
Replacement parts
When replacement parts are required, be sure that the service technician
has used replacement parts specified by the manufacturer or that have
the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock or other hazards. See also item 14 in the
Important Safety Instructions.
Safety check
Upon completion of any servicing or repairs to your set-top box, ask the
service technician to perform safety checks to determine that your set-top
box is in its proper operating condition. See also item 14 in the Important
Safety Instructions.
SAVE THIS INFORMATION FOR FUTURE REFERENCE
Xi3 (PX031ANI) USER GUIDE DRAFT (501-340120x)
4
Warranty VOID
if Broken
or Removed
SAFETY INFORMATION (cont.)
Safety aspects of connections
Full details of the rear panel are on page 6.
Connecting
Do not connect your set-top box (or any other equipment such as a TV or
DVD player) to the power supply until you have properly connected all the
other cables.
Your set-top box is designed for use only with the power supply unit provided.
On the power supply unit there is a label that specifies the correct AC
power supply input for it. Do not connect the power supply unit to any
supply other than this.
Always connect the 5 volt DC cord from the power supply unit to your settop box before you insert the AC power cord from the power supply unit
into the wall AC outlet.
Disconnecting
To disconnect power from your set-top box, always detach the power
supply unit from the wall AC outlet (rather than remove the 5 volt cord
from your set-top box).
Therefore you must install your set-top box near to the wall AC outlet,
which should be easily accessible.
If you are in any doubt about the power supply cord, its plug or its
connection, or are not certain that the electrical outlets you are using
are properly wired and grounded, consult a qualified electrician before
proceeding any further.
To ensure correct operation, use this set-top box only with the Pace-approved
power supply unit provided. If you use an unapproved alternative, you will
invalidate the warranty.
Regulatory information
CAUTION:
• Do not attempt to modify your set-top box without written
authorization from the manufacturer. Unauthorized
modification could void your authority to operate your settop box.
• Failure to heed the Safety Information provided by
failing to connect to a properly wired outlet may void the
manufacturer’s warranty.
NOTE
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. End users must follow the specific
operating instructions for satisfying RF exposure compliance. This
transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
The Cable In connector is designed for
connection to a cable network only.
You must not connect any other
equipment, such as a VCR, to this input.
Power Input
5 volt power
supply unit
FCC RF Radiation Exposure Statement
MPE/SAR/RF Exposure Information.
This equipment complies with FCC RF radiation exposure limits set
forth for an uncontrolled environment.
This equipment was verified for RF exposure and found to comply with
Council Recommendation 1999/519/EC and FCC OET-65 RF exposure
requirements.
WARNING: While this equipment is in operation, a separation distance
of at least 20 centimetres (equal to 8 inches) must be maintained
between the antenna inside the equipment and the bodies of all
persons exposed to the antenna in order to meet the FCC RF exposure
guidelines. Making changes to the antenna or the equipment is not
permitted. Doing so may result in the equipment exceeding the FCC
RF exposure guidelines. This equipment must not be co-located or
operated in conjunction with any other antenna or radio transmitter.
Xi3 (PX031ANI) USER GUIDE DRAFT (501-340120x)
5
Loading...
