Rediscover an American legend.
We took more than a century of experience building America and put it to work tackling the challenges of our industry. The result? The new Mack Anthem™—a truck that will make you rethink what’s possible on the highway. Boldly designed and engineered tough, Anthem is born ready for whatever the road demands.
BUILT FOR YOUR BUSINESS.
Efficient in every sense of the word, Anthem saves on fuel and reduces maintenance costs while maximizing uptime—and your bottom line.
DESIGNED FOR THE DRIVER.
Anthem’s cab design and driver environment are built around
the way work gets done on the road, keeping drivers comfortable, safe and focused all day long.
https://www.truck-manuals.net/mack/
Built foryour
business.
EFFICIENT DESIGN
Anthem’s advanced aerodynamics and purposebuilt design put function at the forefront and reduce day-to-day costs.
DEPENDABLE SUPPORT
From parts and service to our 24/7 Uptime Centers, Mack has the right combination of people and technology to keep you on the road.
THE STRENGTH OF A LEGEND
Anthem comes standard with our proprietary Mack® engines, transmissions and axles, delivering unrivaled performance and fuel efficiency.
4 |
https://www.truck-manuals.net/mack/ |
|
Day Cab |
48-inch Flat Top Sleeper |
70-inch Stand Up Sleeper |
https://www.truck-manuals.net/mack/
Aerodynamic never looked so Mack.
The new Mack Anthem™ challenges the expectations of aerodynamic design with a bold look that dramatically improves efficiency up to 3%.
By displacing air to the sides, as well as over the hood and roof, Anthem cuts wind resistance and improves fuel economy by up to 3%.
6 |
https://www.truck-manuals.net/mack/ |
|
Roof Fairings with Adjustable Trim Tab
Improves airflow from the cab to the trailer (70-inch Stand Up Sleeper only).
Hood Mirrors
Single support decreases wind resistance compared to tripod designs and folds on impact to prevent damage.
Hood and Fenders
Hood slope and fender design direct air over and around the trailer.
Close-Out Flange
Prevents airflow between hood and bumper and moves air around the cab.
Air Dam |
Covered Tow Loops |
Reduces turbulence under |
Cuts down on wind resistance |
the vehicle for less drag. |
and creates a clean look. |
https://www.truck-manuals.net/mack/ |
7 |
|
Built to last.
Mack Anthem™ drives down operating costs with durablility that stands up to the rigors of the road and keeps you out of the shop.
Breakaway Hood Mirrors
The mounts are spring-loaded to rotate when hit, preventing damage to the hood and lowering parts and repair costs.
Breakaway Side Mirrors
Strong hinges with zero plastic, tougher materials and springloaded mounts help keep maintenance costs down.
Durable Components
From bolts to latches, all Anthem components are made from tough, long-lasting materials.
LED Lights
LED headlights are 66% brighter, last longer, use less energy and provide better visibility.
8 |
https://www.truck-manuals.net/mack/ |
|
Smart serviceability.
Anthem’s tilt-assist hood and functional, modular design allow service professionals to access, repair and replace components more quickly.
EFFICIENT ENGINE ACCESS
Mack MP® Engine
Single-Point Latch and Tilt Assist
Requires 50% less effort to open for easy access to the engine.
|
Easy Access |
Level Check |
for Engine |
Serviceability |
Check and top off oil and fluid levels from the ground.
3-PIECE HOOD |
3-PIECE BUMPER |
The 3 pieces are bonded together but can be separated and repaired individually for lower replacement costs.
The 3 pieces can be ordered as separate replacement parts for improved serviceability and lower repair costs.
https://www.truck-manuals.net/mack/ |
9 |
|
Powered by Mack’s integrated powertrain.
Engineered for efficiency and performance, and proudly assembled in Mack’s Hagerstown, Maryland facility, our integrated powertrain is the toughest in the game. Bar none.
Mack MP® Engines
With horsepower, torque and superior fuel economy, Mack’s MP® engines conquer the highway, mile after mile.
Mack Transmissions
Mack’s transmissions are designed and built to perform at the highest level in the most demanding conditions, just like the rest of the truck.
10 |
https://www.truck-manuals.net/mack/ |
|
Mack Axles
Built to handle long hauls and the relentless punishment of the road.
Mack Suspensions
Engineered to be lighter and stronger, for enhanced reliability and outstanding performance.
Mack’s industry-leading automated manual transmission expands your driver base and reduces costs.
Wave Piston Design
By adding small waves to the piston bowl, the engine can burn fuel more efficiently for reduced fuel consumption and lower emissions.
|
Mack Wave Piston |
Standard piston |
Mack Wave Piston |
combustion |
combustion |
efficiency |
efficiency |
MP®8-TC Engine
The MP®8-TC with turbocompounding captures lost energy and converts it to power, burning up to 9% less fuel in highway operations.
Burns up to
9%
less fuel.
Hot exhaust |
Exhaust gas converted |
Turbo delivers |
captured |
to mechanical energy |
torque to the |
from engine. |
by turbo unit. |
crankshaft. |
Smarter Hauling
mDRIVE™ continuously monitors changes in grade, acceleration, vehicle weight and more to optimize fuel economy.
Easy to Operate
Drivers can manage mDRIVE™ with just the press of a button, making it more comfortable and easier to operate, even for new drivers.
Minimal Service
Proven technology and superior design mean mDRIVE™ requires minimal service, significantly reducing maintenance costs and downtime.
https://www.truck-manuals.net/mack/ |
11 |
