Cyclone
II EP2C5 Device Pin-Out
PT-EP2C5-2.0
© 2008 Altera Corporation. All rights reserved. Altera, The Programmable Solutions Company, the stylized Altera logo, specific device designations, and all other words and logos that are identified as trademarks and/or service marks are, unless noted otherwise, the trademarks and service marks of Altera Corporation in the U.S. and other countries. All other product or service names are the property of their respective holders. Altera products are protected under numerous U.S. and foreign patents and pending applications, maskwork rights, and copyrights. Altera warrants performance of its semiconductor products to current specifications in accordance with Altera’s standard warranty, but reserves the right to make changes to any products and services at any time without notice. Altera assumes no responsibility or liability arising out of the application or use of any information, product, or service described herein except as expressly agreed to in writing by Altera. Altera customers are advised to obtain the latest version of device specifications before relying on any published information and before placing orders for products or services.
The pin connection guidelines in the device pin-out are considered preliminary. These pin connection guidelines should only be used as a recommendation, not as a specification. The use of the pin connection guidelines for any particular design should be verified for device operation, with the datasheet and Altera.
PLEASE REVIEW THE FOLLOWING TERMS AND CONDITIONS CAREFULLY BEFORE USING THE DEVICE PIN-OUT("PIN-OUT") PROVIDED TO YOU. BY USING THE PIN-OUT, YOU INDICATE YOUR ACCEPTANCE OF SUCH TERMS AND CONDITIONS, WHICH CONSTITUTE THE LICENSE AGREEMENT ("AGREEMENT") BETWEEN YOU AND ALTERA CORPORATION ("ALTERA"). IF YOU DO NOT AGREE WITH ANY OF THESE TERMS AND CONDITIONS, DO NOT DOWNLOAD, COPY, INSTALL, OR USE OF THE PIN-OUT.
1. Subject to the terms and conditions of this Agreement, Altera grants to you a license to use the Pin-out to determine the pin connections of the associated Altera programmable logic device or field programmable gate array. You may not use the Pin-out for other purpose. You are expressly prohibited from using the Pin-out with any programmable logic devices or field programmable gate arrays designed or manufactured by any company or entity other than Altera.
2. Altera does not guarantee or imply the reliability, serviceability, or function of the Pin-out. The files contained herein are provided 'AS IS'. ALTERA DISCLAIMS ALL WARRANTIES , EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, TITLE AND NON-INFRINGEMENT.
3. In no event shall the aggregate liability of Altera relating to this Agreement or the subject matter hereof under any legal theory (whether in tort, contract, or otherwise), exceed One US Dollar (US$1.00). In no event shall Altera be liable for any lost revenue, lost profits, or other consequential, indirect, or special damages caused by your use of these guidelines even if advised of the possibility of such damages.
4. This Agreement shall be governed by the laws of the State of California, without regard to conflict of law or choice of law principles. You agree to submit to the exclusive jurisdiction of the courts in the County of Santa Clara, State of California for the resolution of any dispute or claim arising out of or relating to this Agreement. The parties hereby agree that the party who is not the substantially prevailing party with respect to a dispute, claim, or controversy relating to this Agreement shall pay the costs actually incurred by the substantially prevailing party in relation to such dispute, claim, or controversy, including attorneys' fees.
BY DOWNLOADING OR USING THE PIN-OUT, YOU ACKNOWLEDGE THAT YOU HAVE READ THIS AGREEMENT, UNDERSTAND IT, AND AGREE TO BE BOUND BY ITS TERMS AND CONDITIONS. YOU AND ALTERA FURTHER AGREE THAT IT IS THE COMPLETE AND EXCLUSIVE STATEMENT OF THE AGREEMENT BETWEEN YOU AND ALTERA, WHICH SUPERSEDES ANY PROPOSAL OR PRIOR AGREEMENT, ORAL OR WRITTEN, AND ANY OTHER COMMUNICATIONS BETWEEN YOU AND ALTERA RELATING TO THE SUBJECT MATTER OF THIS AGREEMENT.
Device Pin-Out Agreement © 2008 Altera Corporation. All rights reserved.
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.

Disclaimer

Pin Information for the Cyclone® II EP2C5 Device
V
Page 2 of 15
ersion 2.0
Note (1), (2)
Bank Number
B1 VREFB1N0 IO ASDO ASDO 1 1 C3 B1 VREFB1N0 IO nCSO nCSO 2 2 F4 B1 VREFB1N0 IO LVDS9p CRC_ERROR 3 3 C1 B1 VREFB1N0 IO LVDS9n CLKUSR 4 4 C2 B1 VREFB1N0 IO LVDS8p 5 D5 B1 VREFB1N0 IO LVDS8n 6 E5 DQ0L0 DQ1L0 B1 VREFB1N0 VCCIO1 5 7 B1 VREFB1N0 IO LVDS7p 8 E3 DQ1L0 DQ0L1 DQ1L1 B1 VREFB1N0 GND 6 9 B1 VREFB1N0 IO LVDS7n 10 E4 DQ1L1 DQ0L2 DQ1L2 B1 VREFB1N0 IO LVDS6p 11 D3 DQ1L2 DQ0L3 DQ1L3 B1 VREFB1N0 IO LVDS6n 12 D4 DQ1L3 DQ0L4 DQ1L4 B1 VREFB1N0 IO VREFB1N0 7 13 F3 B1 VREFB1N0 VCCIO1 B1 VREFB1N0 IO LVDS5p 8 14 E1 DPCLK0/DQS0L DPCLK0/DQS0L DPCLK0/DQS0L DPCLK0/DQS0L DPCLK0/DQS0L B1 VREFB1N0 IO LVDS5n 9 15 E2 DQ0L5 DQ1L5 B1 VREFB1N0 TDO TDO 10 16 G2 B1 VREFB1N0 TMS TMS 11 17 G1 B1 VREFB1N0 TCK TCK 12 18 F2 B1 VREFB1N0 TDI TDI 13 19 H5 B1 VREFB1N0 DATA0 DATA0 DATA0 14 20 F1 B1 VREFB1N0 DCLK DCLK DCLK 15 21 H4 B1 VREFB1N0 nCE nCE 16 22 G5 B1 VREFB1N0 CLK0 B1 VREFB1N0 CLK1 B1 VREFB1N0 GND 19 25 B1 VREFB1N0 nCONFIG nCONFIG 20 26 J5 B1 VREFB1N1 CLK2 B1 VREFB1N1 CLK3 B1 VREFB1N1 VCCIO1 23 29 B1 VREFB1N1 IO LVDS4p 24 30 K2 DPCLK1/DQS1L DPCLK1/DQS1L DPCLK1/DQS1L DPCLK1/DQS1L DPCLK1/DQS1L B1 VREFB1N1 IO LVDS4n 25 31 K1 DQ0L6 DQ1L6 B1 VREFB1N1 IO LVDS3p 26 32 K4 DQ0L7 DQ1L7 B1 VREFB1N1 IO LVDS3n 27 33 K5 DQ1L4 DQ1L8 B1 VREFB1N1 IO 34 M1 DQ1L5 DM0L DM1L0/BWS#1L0 B1 VREFB1N1 IO LVDS2p 35 L1 DQ1L6 DQ1L0 DQ1L9
VREFB Group
Pin Name / Function
Optional Function(s) Configuration
Function
LVDSCLK0p/input(3) LVDSCLK0n/input(3)
LVDSCLK1p/input(3) LVDSCLK1n/input(3)
T144 Q208 F256 DQS for x8/x9 in
T144
17 23 H2 18 24 H1
21 27 J2 22 28 J1
DQS for x8/x9 in Q208
DQS for x16/x18 in Q208
DQS for x8/x9 in F256
DQS for x16/x18 in F256
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.

Pin List

Pin Information for the Cyclone® II EP2C5 Device
V
Page 3 of 15
ersion 2.0
Note (1), (2)
Bank Number
B1 VREFB1N1 IO LVDS2n 36 L2 DQ1L1 DQ1L10 B1 VREFB1N1 IO VREFB1N1 28 37 J4 B1 VREFB1N1 IO M2 DQ1L2 DQ1L11 B1 VREFB1N1 GND 38 B1 VREFB1N1 IO 39 M3 DQ1L7 DQ1L3 DQ1L12 B1 VREFB1N1 IO LVDS1p 40 N1 DQ1L8 DQ1L4 DQ1L13 B1 VREFB1N1 IO LVDS1n 41 N2 DM1L/BWS#1L DQ1L5 DQ1L14 B1 VREFB1N1 VCCIO1 29 42 B1 VREFB1N1 IO 43 L3 DQ1L6 DQ1L15 B1 VREFB1N1 IO LVDS0p 44 P1 DQ1L7 DQ1L16 B1 VREFB1N1 IO LVDS0n 45 P2 DQ1L8 DQ1L17 B1 VREFB1N1 IO 30 46 P3 DM1L/BWS#1L DM1L1/BWS#1L1 B1 VREFB1N1 IO PLL1_OUTp 31 47 L4 B1 VREFB1N1 IO PLL1_OUTn 32 48 M4 B1 VREFB1N1 GND 33 49 B1 VREFB1N1 GND_PLL1 34 50 L5 B1 VREFB1N1 VCCD_PLL1 35 51 L6 B1 VREFB1N1 GND_PLL1 36 52 N5 B4 VREFB4N1 VCCA_PLL1 37 53 M5 B4 VREFB4N1 GNDA_PLL1 38 54 M6 B4 VREFB4N1 GND 39 55 B4 VREFB4N1 IO LVDS58n DEV_OE 40 56 R3 B4 VREFB4N1 IO LVDS58p 41 57 T3 DM1B/BWS#1B DM1B/BWS#1B DM1B1/BWS#1B1 DM1B/BWS#1B DM1B1/BWS#1B1 B4 VREFB4N1 IO LVDS57p 42 58 P5 DQ1B8 DQ1B8 DQ1B17 DQ1B8 DQ1B17 B4 VREFB4N1 IO LVDS57n 43 59 P4 DQ1B7 DQ1B7 DQ1B16 DQ1B7 DQ1B16 B4 VREFB4N1 IO LVDS56p 44 60 T4 DQ1B6 DQ1B6 DQ1B15 DQ1B6 DQ1B15 B4 VREFB4N1 IO LVDS56n 45 61 R4 DQ1B5 DQ1B5 DQ1B14 DQ1B5 DQ1B14 B4 VREFB4N1 VCCIO4 46 62 B4 VREFB4N1 IO LVDS55p 47 63 T5 DPCLK2/DQS1B DPCLK2/DQS1B DPCLK2/DQS1B DPCLK2/DQS1B DPCLK2/DQS1B B4 VREFB4N1 GND B4 VREFB4N1 IO LVDS55n 48 64 R5 DQ1B4 DQ1B13 B4 VREFB4N1 VCCIO4 B4 VREFB4N1 GND B4 VREFB4N1 GND 49 65 B4 VREFB4N1 IO T6 DQ1B3 DQ1B12 B4 VREFB4N1 VCCINT 50 66
VREFB Group
Pin Name / Function
Optional Function(s) Configuration
Function
T144 Q208 F256 DQS for x8/x9 in
T144
DQS for x8/x9 in Q208
DQS for x16/x18 in Q208
DQS for x8/x9 in F256
DQS for x16/x18 in F256
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.
Pin List
Pin Information for the Cyclone® II EP2C5 Device
V
Page 4 of 15
ersion 2.0
Note (1), (2)
Bank Number
B4 VREFB4N1 IO VREFB4N1 51 67 N8 B4 VREFB4N1 IO LVDS54p 52 68 T7 DQ1B4 DQ1B4 DQ1B13 DQ1B2 DQ1B11 B4 VREFB4N1 IO LVDS54n 69 R7 DQ1B3 DQ1B12 DQ1B1 DQ1B10 B4 VREFB4N1 IO LVDS60p L7 B4 VREFB4N1 IO LVDS60n L8 B4 VREFB4N1 IO LVDS53p 53 70 T8 DQ1B3 DQ1B2 DQ1B11 DQ1B0 DQ1B9 B4 VREFB4N1 VCCIO4 54 71 B4 VREFB4N1 IO LVDS53n 55 72 R8 DQ1B2 DQ1B1 DQ1B10 DM1B0/BWS#1B0 B4 VREFB4N1 GND 56 73 B4 VREFB4N1 IO LVDS52p 57 74 T9 DQ1B1 DQ1B0 DQ1B9 B4 VREFB4N1 IO LVDS52n 58 75 R9 DQ1B0 B4 VREFB4N0 IO LVDS59p N9 B4 VREFB4N0 IO LVDS59n N10 B4 VREFB4N0 VCCIO4 B4 VREFB4N0 IO LVDS51p 59 76 T11 B4 VREFB4N0 GND B4 VREFB4N0 IO LVDS51n 60 77 R11 DM0B DQ1B8 B4 VREFB4N0 GND 61 78 B4 VREFB4N0 VCCINT 62 79 B4 VREFB4N0 IO 80 P11 B4 VREFB4N0 IO LVDS50p 81 L9 B4 VREFB4N0 IO LVDS50n 82 L10 B4 VREFB4N0 VCCIO4 83 B4 VREFB4N0 IO LVDS49p 84 R10 DM0B DM1B0/BWS#1B0 B4 VREFB4N0 GND 85 B4 VREFB4N0 IO LVDS49n 86 T10 DQ1B8 DQ0B7 DQ1B7 B4 VREFB4N0 IO LVDS48p 87 K11 DQ0B7 DQ1B7 B4 VREFB4N0 IO LVDS48n 88 K10 DQ0B6 DQ1B6 B4 VREFB4N0 IO VREFB4N0 63 89 N11 B4 VREFB4N0 IO LVDS47p 90 P12 DQ0B5 DQ1B5 DQ0B6 DQ1B6 B4 VREFB4N0 VCCIO4 91 B4 VREFB4N0 IO LVDS47n 92 P13 DQ0B4 DQ1B4 DQ0B5 DQ1B5 B4 VREFB4N0 GND 93 B4 VREFB4N0 IO LVDS46p 64 94 T12 DPCLK4/DQS0B DPCLK4/DQS0B DPCLK4/DQS0B DPCLK4/DQS0B DPCLK4/DQS0B B4 VREFB4N0 IO LVDS46n 65 95 R12 DQ0B4 DQ1B4 B4 VREFB4N0 IO 96 L12 DQ0B3 DQ1B3
VREFB Group
Pin Name / Function
Optional Function(s) Configuration
Function
T144 Q208 F256 DQS for x8/x9 in
T144
DQS for x8/x9 in Q208
DQS for x16/x18 in Q208
DQS for x8/x9 in F256
DQS for x16/x18 in F256
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.
Pin List
Pin Information for the Cyclone® II EP2C5 Device
V
Page 5 of 15
ersion 2.0
Note (1), (2)
Bank Number
B4 VREFB4N0 IO LVDS45p 97 T13 DQ0B2 DQ1B2 DQ0B3 DQ1B3 B4 VREFB4N0 VCCIO4 66 98 B4 VREFB4N0 IO LVDS45n 67 99 R13 DQ0B1 DQ1B1 DQ0B2 DQ1B2 B4 VREFB4N0 GND 68 100 B4 VREFB4N0 IO LVDS44p 69 101 T14 DQ0B0 DQ1B0 DQ0B1 DQ1B1 B4 VREFB4N0 IO LVDS44n 70 102 R14 DQ0B0 DQ1B0 B4 VREFB4N0 IO LVDS43p 71 103 M11 B4 VREFB4N0 IO LVDS43n 72 104 L11 B3 VREFB3N1 IO LVDS42n 73 105 N12 DM1R/BWS#1R B3 VREFB3N1 IO LVDS42p 74 106 M12 DQ1R8 DM1R/BWS#1R DM1R1/BWS#1R1 B3 VREFB3N1 IO LVDS41n INIT_DONE 75 107 N13 B3 VREFB3N1 IO LVDS41p nCEO 76 108 N14 B3 VREFB3N1 IO P14 B3 VREFB3N1 VCCIO3 77 109 B3 VREFB3N1 IO LVDS40n 110 P15 DQ1R8 DQ1R17 DM1R/BWS#1R DM1R1/BWS#1R1 B3 VREFB3N1 GND 78 111 B3 VREFB3N1 IO LVDS40p 112 P16 DQ1R7 DQ1R16 DQ1R8 DQ1R17 B3 VREFB3N1 IO LVDS39n 113 N15 DQ1R6 DQ1R15 DQ1R7 DQ1R16 B3 VREFB3N1 IO LVDS39p 114 N16 DQ1R5 DQ1R14 DQ1R6 DQ1R15 B3 VREFB3N1 IO LVDS38n 115 M15 DQ1R4 DQ1R13 DQ1R5 DQ1R14 B3 VREFB3N1 IO LVDS38p 116 M16 DQ1R3 DQ1R12 DQ1R4 DQ1R13 B3 VREFB3N1 IO VREFB3N1 79 117 M14 B3 VREFB3N1 IO 118 L14 DQ1R2 DQ1R11 B3 VREFB3N1 IO LVDS37n 80 119 L15 DQ1R3 DQ1R12 B3 VREFB3N1 IO LVDS37p 81 120 L16 DQ1R2 DQ1R11 B3 VREFB3N1 nSTATUS nSTATUS 82 121 M13 B3 VREFB3N1 VCCIO3 122 B3 VREFB3N1 CONF_DONE CONF_DONE 83 123 L13 B3 VREFB3N1 GND 124 B3 VREFB3N1 MSEL1 MSEL1 84 125 K12 B3 VREFB3N1 MSEL0 MSEL0 85 126 J13 B3 VREFB3N1 IO LVDS36n 86 127 K16 DQ1R7 DQ1R1 DQ1R10 DQ1R1 DQ1R10 B3 VREFB3N1 IO LVDS36p 87 128 K15 DPCLK6/DQS1R DPCLK6/DQS1R DPCLK6/DQS1R DPCLK6/DQS1R DPCLK6/DQS1R B3 VREFB3N1 CLK7 B3 VREFB3N1 CLK6 B3 VREFB3N0 CLK5
VREFB Group
Pin Name / Function
Optional Function(s) Configuration
Function
LVDSCLK3n/input(3) LVDSCLK3p/input(3) LVDSCLK2n/input(3)
T144 Q208 F256 DQS for x8/x9 in
T144
88 129 J16 89 130 J15 90 131 H15
DQS for x8/x9 in Q208
DQS for x16/x18 in Q208
DQS for x8/x9 in F256
DQS for x16/x18 in F256
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.
Pin List
Pin Information for the Cyclone® II EP2C5 Device
V
Page 6 of 15
ersion 2.0
Note (1), (2)
Bank Number
B3 VREFB3N0 CLK4 B3 VREFB3N0 IO LVDS35n 92 133 H12 DQ1R6 DQ1R0 DQ1R9 DQ1R0 DQ1R9 B3 VREFB3N0 IO LVDS35p 93 134 J12 DPCLK7/DQS0R DPCLK7/DQS0R DPCLK7/DQS0R DPCLK7/DQS0R DPCLK7/DQS0R B3 VREFB3N0 IO LVDS34n 94 135 G16 DQ1R5 DM0R DM1R0/BWS#1R0 DM0R DM1R0/BWS#1R0 B3 VREFB3N0 VCCIO3 95 136 B3 VREFB3N0 IO LVDS34p 96 137 G15 DQ1R4 DQ1R8 DQ1R8 B3 VREFB3N0 IO LVDS33n 97 138 F15 DQ1R3 DQ0R7 DQ1R7 DQ0R7 DQ1R7 B3 VREFB3N0 IO LVDS33p 139 F16 DQ0R6 DQ1R6 DQ0R6 DQ1R6 B3 VREFB3N0 GND 98 140 B3 VREFB3N0 IO LVDS32n 141 J11 DQ0R5 DQ1R5 DQ0R5 DQ1R5 B3 VREFB3N0 IO LVDS32p 142 H11 DQ0R4 DQ1R4 DQ0R4 DQ1R4 B3 VREFB3N0 IO LVDS31n 143 G12 DQ0R3 DQ1R3 DQ0R3 DQ1R3 B3 VREFB3N0 IO LVDS31p 144 G13 DQ0R2 DQ1R2 DQ0R2 DQ1R2 B3 VREFB3N0 IO VREFB3N0 99 145 H13 B3 VREFB3N0 IO LVDS30n 100 146 D15 DQ1R2 DQ0R1 DQ1R1 DQ0R1 DQ1R1 B3 VREFB3N0 IO LVDS30p 101 147 D16 DQ1R1 DQ0R0 DQ1R0 DQ0R0 DQ1R0 B3 VREFB3N0 VCCIO3 102 148 B3 VREFB3N0 IO E16 B3 VREFB3N0 IO LVDS29n 149 C14 B3 VREFB3N0 IO LVDS29p 150 D13 B3 VREFB3N0 IO PLL2_OUTp 103 151 E14 DQ1R0 B3 VREFB3N0 IO PLL2_OUTn 104 152 D14 B3 VREFB3N0 GND 105 153 B3 VREFB3N0 GND_PLL2 106 154 F12 B3 VREFB3N0 VCCD_PLL2 107 155 F11 B3 VREFB3N0 GND_PLL2 108 156 D12 B2 VREFB2N0 VCCA_PLL2 109 157 E12 B2 VREFB2N0 GNDA_PLL2 110 158 E11 B2 VREFB2N0 GND 111 159 B2 VREFB2N0 IO LVDS28n 112 160 B14 B2 VREFB2N0 IO LVDS28p 113 161 A14 DQ0T0 DQ1T0 DQ0T0 DQ1T0 B2 VREFB2N0 IO LVDS27n 114 162 C13 DQ0T1 DQ1T1 DQ0T1 DQ1T1 B2 VREFB2N0 IO LVDS27p 115 163 C12 DQ0T2 DQ1T2 DQ0T2 DQ1T2 B2 VREFB2N0 IO LVDS26n 164 B13 DQ0T3 DQ1T3 DQ0T3 DQ1T3 B2 VREFB2N0 IO LVDS26p 165 A13 DQ0T4 DQ1T4 DQ0T4 DQ1T4 B2 VREFB2N0 VCCIO2 116 166
VREFB Group
Pin Name / Function
Optional Function(s) Configuration
Function
LVDSCLK2p/input(3)
T144 Q208 F256 DQS for x8/x9 in
T144
91 132 H16
DQS for x8/x9 in Q208
DQS for x16/x18 in Q208
DQS for x8/x9 in F256
DQS for x16/x18 in F256
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.
Pin List
Pin Information for the Cyclone® II EP2C5 Device
V
Page 7 of 15
ersion 2.0
Note (1), (2)
Bank Number
B2 VREFB2N0 IO B11 B2 VREFB2N0 GND 117 167 B2 VREFB2N0 IO LVDS25n 118 168 B12 DQ0T5 DQ1T5 B2 VREFB2N0 IO LVDS25p 119 169 A12 DPCLK8/DQS0T DPCLK8/DQS0T DPCLK8/DQS0T DPCLK8/DQS0T DPCLK8/DQS0T B2 VREFB2N0 IO A11 B2 VREFB2N0 IO VREFB2N0 120 170 C11 B2 VREFB2N0 IO LVDS24n 121 171 G10 DQ0T5 DQ1T5 B2 VREFB2N0 VCCIO2 172 B2 VREFB2N0 IO LVDS24p 122 173 G11 DQ0T6 DQ1T6 DQ0T6 DQ1T6 B2 VREFB2N0 GND 174 B2 VREFB2N0 IO LVDS23n 175 B10 DQ0T7 DQ1T7 DQ0T7 DQ1T7 B2 VREFB2N0 IO LVDS23p 176 A10 DQ1T8 DQ1T8 B2 VREFB2N0 IO LVDS22n F10 B2 VREFB2N0 GND 123 177 B2 VREFB2N0 IO LVDS22p F9 B2 VREFB2N0 VCCINT 124 178 B2 VREFB2N0 VCCIO2 B2 VREFB2N0 GND B2 VREFB2N0 IO LVDS21n 125 179 D11 DQ1T0 DM0T DM1T0/BWS#1T0 DM0T DM1T0/BWS#1T0 B2 VREFB2N0 IO LVDS21p 126 180 D10 DQ1T1 B2 VREFB2N0 IO LVDS20n 181 A9 B2 VREFB2N0 IO LVDS20p 182 B9 B2 VREFB2N1 VCCIO2 127 183 B2 VREFB2N1 GND 128 184 B2 VREFB2N1 IO 129 185 A8 DQ1T2 DQ1T0 DQ1T9 B2 VREFB2N1 GND 130 186 B2 VREFB2N1 IO LVDS19n 187 A7 DQ1T0 DQ1T9 B2 VREFB2N1 IO LVDS19p 188 B7 DQ1T1 DQ1T10 DQ1T1 DQ1T10 B2 VREFB2N1 IO LVDS18n 189 F7 DQ1T2 DQ1T11 DQ1T2 DQ1T11 B2 VREFB2N1 VCCINT 131 190 B2 VREFB2N1 IO LVDS18p 191 F8 DQ1T3 DQ1T12 DQ1T3 DQ1T12 B2 VREFB2N1 IO VREFB2N1 132 192 D8 B2 VREFB2N1 IO LVDS17n 133 193 B6 DQ1T3 DQ1T4 DQ1T13 DQ1T4 DQ1T13 B2 VREFB2N1 VCCIO2 194 B2 VREFB2N1 IO LVDS17p 134 195 A6 DQ1T4 DQ1T5 DQ1T14 DQ1T5 DQ1T14 B2 VREFB2N1 GND 196
VREFB Group
Pin Name / Function
Optional Function(s) Configuration
Function
T144 Q208 F256 DQS for x8/x9 in
T144
DQS for x8/x9 in Q208
DQS for x16/x18 in Q208
DQS for x8/x9 in F256
DQS for x16/x18 in F256
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.
Pin List
Pin Information for the Cyclone® II EP2C5 Device
V
Page 8 of 15
ersion 2.0
Note (1), (2)
Bank Number
B2 VREFB2N1 IO LVDS16n G6 B2 VREFB2N1 IO LVDS16p G7 B2 VREFB2N1 IO LVDS15n 197 D6 B2 VREFB2N1 VCCIO2 B2 VREFB2N1 IO LVDS15p 198 C6 B2 VREFB2N1 GND B2 VREFB2N1 IO LVDS14n C5 B2 VREFB2N1 IO LVDS14p C4 B2 VREFB2N1 IO LVDS13n 135 199 B5 DQ1T5 DQ1T6 DQ1T15 B2 VREFB2N1 IO LVDS13p 136 200 A5 DPCLK10/DQS1T DPCLK10/DQS1T DPCLK10/DQS1T DPCLK10/DQS1T DPCLK10/DQS1T B2 VREFB2N1 IO LVDS12n 137 201 B4 DQ1T6 DQ1T6 DQ1T15 DQ1T7 DQ1T16 B2 VREFB2N1 VCCIO2 138 202 B2 VREFB2N1 IO LVDS12p 139 203 A4 DQ1T7 DQ1T7 DQ1T16 DQ1T8 DQ1T17 B2 VREFB2N1 GND 140 204 B2 VREFB2N1 IO LVDS11p 141 205 A3 DQ1T8 DQ1T8 DQ1T17 DM1T/BWS#1T DM1T1/BWS#1T1 B2 VREFB2N1 IO LVDS11n DEV_CLRn 142 206 B3 B2 VREFB2N1 IO LVDS10p 143 207 E6 DM1T/BWS#1T DM1T/BWS#1T DM1T1/BWS#1T1 B2 VREFB2N1 IO LVDS10n 144 208 F6
VREFB Group
Pin Name / Function
VCCINT G9 VCCINT H7 VCCINT H10 VCCINT J7 VCCIO1 B1 VCCIO1 G3 VCCIO1 K3 VCCIO1 R1 VCCIO4 M7 VCCIO4 M10 VCCIO4 P7 VCCIO4 P10 VCCIO4 T2 VCCIO4 T15 VCCIO3 B16 VCCIO3 G14 VCCIO3 K14 VCCIO3 R16
Optional Function(s) Configuration
Function
T144 Q208 F256 DQS for x8/x9 in
T144
DQS for x8/x9 in Q208
DQS for x16/x18 in Q208
DQS for x8/x9 in F256
DQS for x16/x18 in F256
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.
Pin List
Bank
V
Page 9 of 15
Number
VREFB Group
Pin Name / Function
VCCIO2 A2 VCCIO2 A15 VCCIO2 C7 VCCIO2 C10 VCCIO2 E7 VCCIO2 E10 GND G8 GND H8 GND H9 GND J8 GND A1 GND A16 GND B2 GND B15 GND C8 GND C9 GND E8 GND E9 GND H3 GND H14 GND J3 GND J14 GND M8 GND M9 GND P8 GND P9 GND R2 GND R15 GND T1 GND T16 GND J9 GND K9 NC B8 NC C15 NC C16 NC D1
Optional Function(s) Configuration
Function
T144 Q208 F256 DQS for x8/x9 in
T144
Pin Information for the Cyclone® II EP2C5 Device
DQS for x8/x9 in Q208
DQS for x16/x18 in Q208
DQS for x8/x9 in F256
ersion 2.0
Note (1), (2)
DQS for x16/x18 in F256
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.
Pin List
Bank
V
Page 10 of 15
Number
VREFB Group
Pin Name / Function
NC D2 NC D7 NC D9 NC E13 NC E15 NC F5 NC F13 NC F14 NC G4 NC H6 NC J6 NC J10 NC K6 NC K7 NC K8 NC K13 NC N3 NC N4 NC N6 NC N7 NC P6 NC R6
Optional Function(s) Configuration
Function
T144 Q208 F256 DQS for x8/x9 in
T144
Pin Information for the Cyclone® II EP2C5 Device
DQS for x8/x9 in Q208
DQS for x16/x18 in Q208
DQS for x8/x9 in F256
ersion 2.0
Note (1), (2)
DQS for x16/x18 in F256
Notes:
(1) The optional functions (e.g. LVDS, DDR) are not available for some pins in certain packages. For example, for the EP2C8 device, the LVDS70 pair is available for the Q208 and F256 packages, but not for the T144 package. (2) The DQS0T, DQS1T, DQS0B, and DQS1B pin functions are only available in the F672 and F896 packages. (3) If the dedicated CLK pins are not used to feed the global clock networks, they can be used as general-purpose input pins to feed the core logic. The dedicated CLK pins do not support the I/O register.
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.
Pin List
Pin Name
V
(1)
Page 11 of 15
VCCINT Power
VCCIO[1..8]
GND
VREFB[1..8]N[0..3]
VCCA_PLL[1..4](Note 4)
VCCD_PLL[1..4](Note 4)
GNDA_PLL[1..4](Note 4) GND_PLL[1..4](Note 4)
NC No Connect
DCLK
DATA0 Input
MSEL[0..1]
nCE
nCONFIG
CONF_DONE
Pin Type (1st, 2nd, and 3rd Function) Pin Description Connection Guidelines
Power
Ground
I/O
Power
Power
Ground
Ground
Input (PS) Output (AS)
Input
Input
Input
Bidirectional (open-drain)
Pin Information for the Cyclone® II EP2C5 Device
These are internal logic array voltage supply pins. VCCINT also supplies power to the input buffers used for the LVPECL, LVDS (regular I/O and CLK pins), differential HSTL, and differential SSTL I/O standards.
These are I/O supply voltage pins for banks 1 through 8. Each bank can support a different voltage level. VCCIO supplies power to the output buffers for all I/O standards. VCCIO also supplies power to the input buffers used for the LVTTL, LVCMOS, 1.5-V, 1.8-V, 2.5-V, 3.3-V PCI, and 3.3-V PCI-X, differential SSTL, differential HSTL, and LVDS (regular I/O) I/O standards.
Device ground pins. Connect all GND pins to the board GND plane.
Input reference voltage for each I/O bank. If a bank uses a voltage-referenced I/O standard, then these pins are used as the voltage-referenced pins for the bank.
Analog power for PLLs[1..4].
Digital power for PLLs[1..4].
Analog ground for PLLs[1..4].
Ground for PLLs[1..4]. Connect these pins to the GND plane on the board.
No Connect Do not drive signals into these pins.
Dedicated configuration clock pin. In PS configuration, DCLK is used to clock configuration data from an external source into the Cyclone II device. In AS mode, DCLK is an output from the Cyclone II device that provides timing for the configuration interface. The input buffer on this pin supports hysteresis using the Schmitt trigger circuitry.
Dedicated configuration data input pin. In serial configuration modes, bit-wide configuration data is received through this pin. In AS mode, DATA0 has an internal pull-up resistor that is always active. The input buffer on this pin supports hysteresis using the Schmitt trigger circuitry.
Configuration input pins that set the Cyclone II device configuration scheme.
Dedicated active-low chip enable. When nCE is low, the device is enabled. When nCE is high, the device is disabled. The input buffer on this pin supports hysteresis using the Schmitt trigger circuitry.
Dedicated configuration control input. Pulling this pin low during user mode causes the FPGA to lose its configuration data, enter a reset state, and tri-state all I/O pins. Returning this pin to a logic high level initiates reconfiguration. The input buffer on this pin supports hysteresis using the Schmitt trigger circuitry.
This is a dedicated configuration status pin. As a status output, the CONF_DONE pin drives low before and during configuration. Once all configuration data is received without error and the initialization cycle starts, CONF_DONE is released. As a status input, CONF_DONE goes high after all data is received. Then the device initializes and enters user mode. It is not available as a user I/O pin. The input buffer on this pin supports hysteresis using the Schmitt trigger circuitry.
Supply and Reference Pins
Dedicated Configuration/JTAG Pins
Connect all VCCINT pins to 1.2 V. Decoupling depends on the design decoupling requirements of the specific board. (Note 2)
Verify that the VCCIO voltage level connected is consistent with the .pin report from the
®
Quartus
II software. Decoupling depends on the design decoupling requirements of the specific
board. (Note 2)
If voltage-referenced I/O standards are not used in the bank, the VREF pins are available as user I/O pins. Decoupling depends on the design decoupling requirements of the specific board.
(Note 2)
Connect these pins to 1.2 V, even if the PLL is not used. Use an isolated linear supply for better jitter performance. You can connect all VCCA_PLL pins to a single linear supply to minimize cost. Power on the PLLs should be decoupled. Decoupling depends on the design decoupling requirements of the specific board (Note 2). For more information on this pin, refer to the PLLs in Cyclone II Devices chapter in the Cyclone II Device Handbook.
Connect these pins to the quietest digital supply on board (1.2 V), which is also supplied to the VCCINT, even if the PLL is not used. Power on the PLLs should be decoupled. Decoupling depends on the design decoupling requirements of the specific board (Note 2) . For more information on this pin, refer to the PLLs in Cyclone II Devices chapter in the Cyclone II Device Handbook.
Connect these pins directly to the same ground plane as the digital ground of the device, even if the PLL is not used. For more information on this pin, refer to the PLLs in Cyclone II Devices chapter in the Cyclone II Device Handbook.
DCLK should not be left floating. You should drive it high or low, whichever is more convenient on the board.
DATA0 should not be left floating. You should drive it high or low, whichever is more convenient on the board.
These pins must be hardwired to VCCIO of the bank they reside in or GND. Do not leave these pins floating. When these pins are unused, connect them to GND. For MSEL pin settings for different configuration schemes, refer to the Configuring Cyclone II Devices chapter in the Cyclone II Device Handbook.
In a multi-device configuration, nCE of the first device is tied low while its nCEO pin drives the nCE of the next device in the chain. In a single-device configuration, nCE is tied low.
nCONFIG should be pulled high by an external 10-k pull-up resistor to a 3.3-V supply. If the configuration scheme uses an enhanced configuration device or EPC2, nCONFIG can be tied directly to the nINIT_CONF pin of the configuration device. If this pin is not used, this pin can be connected through a resistor to VCCIO.
CONF_DONE should be pulled high by an external 10-k pull-up resistor to a 3.3-V supply. If internal pull-up resistors on the enhanced configuration device are used, external 10-k pull-up resistors should not be used on this pin.
ersion 2.0
Note
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.

Pin Definitions

Pin Name
V
(1)
s
Page 12 of 15
nSTATUS
TCK
TMS
TDI
TDO
CLK[0,2,4,6,8,10,12,14], LVDSCLK[0..7]p
CLK[1,3,5,7,9,11,13,15], LVDSCLK[0..7]n
PLL[1..4]_OUTp(Note 4) I/O, Output
PLL[1..4]_OUTn(Note 4) I/O, Output
nCEO
nCSO
ASDO I/O, Output
CRC_ERROR I/O, Output
DEV_CLRn
DEV_OE
INIT_DONE
CLKUSR I/O, Input
Pin Type (1st, 2nd, and 3rd Function) Pin Description Connection Guidelines
Bidirectional (open-drain)
Input
Input
Input
Output
Clock, Input
Clock, Input
I/O, Output
I/O, Output
I/O (when option off), Input (when option on)
I/O (when option off), Input (when option on)
I/O, Output (open-drain)
Pin Information for the Cyclone® II EP2C5 Device
ersion 2.0
This is a dedicated configuration status pin. The FPGA drives nSTATUS low immediately after power­up and releases it after POR time. As a status output, the nSTATUS is pulled low if an error occurs during configuration. As a status input, the device enters an error state when nSTATUS is driven low by an external source during configuration or initialization. It is not available as a user I/O pin. The input buffer on this pin supports hysteresis using the Schmitt trigger circuitry. nSTATUS should be pulled high by an external 10-k pull-up resistor to a 3.3-V supply. Dedicated JTAG clock input pin. This pin has weak internal pull-down resistors. The input buffer on this pin supports hysteresis using the Schmitt trigger circuitry.
Dedicated JTAG input pin that provides the control signal to determine the transitions of the TAP controller state machine. This pin has weak internal pull-up resistors. The input buffer on this pin supports hysteresis using the Schmitt trigger circuitry. weak internal pull-up resistors. The input buffer on this pin supports hysteresis using the Schmitt trigger circuitry.
Dedicated JTAG data output pin for instructions, and test and programming data.
Dedicated global clock input pins that can also be used for the positive terminal inputs for differential global clock input or user input pins. Connect unused pins to GND. Dedicated global clock input pins that can also be used for the negative terminal inputs for differential global clock input or user input pins. Connect unused pins to GND. Optional positive terminal for external clock outputs from PLLs[1..4]. These pins can only use the differential I/O standard if it is being fed by a PLL output. Optional negative terminal for external clock outputs from PLLs[1..4]. These pins can only use the differential I/O standard if it is being fed by a PLL output.
Output that drives low when device configuration is complete.
Output control signal from the Cyclone II FPGA to the nCS pin of the serial configuration device in AS mode that enables the configuration device by driving it low. In AS mode, the nCSO has internal weak pull-up resistor, which is always active.
Output control signal from the Cyclone II FPGA to the serial configuration device in AS mode used to read out configuration data. In AS mode, the ASDO has internal weak pull-up resistor, which is alway active.
Active-high signal that indicates the error-detection circuit has detected errors in the configuration SRAM bits. This pin is optional and is used when the CRC error-detection circuit is enabled.
Optional chip-wide reset pin that allows you to override all clears on all device registers. When this pin is driven low, all registers are cleared; when this pin is driven high, all registers behave as programmed. The DEV_CLRn pin does not affect JTAG boundary-scan or programming operations. This pin is enabled by turning on the Enable device-wide reset (DEV_CLRn) option in the Quartus II software.
Optional pin that allows you to override all tri-states on the device. When this pin is driven low, all I/O pins are tri-stated; when this pin is driven high, all I/O pins behave as defined in the design. This pin is enabled by turning on the Enable device-wide output enable (DEV_OE) option in the Quartus II software.
This is a dual-purpose status pin and can be used as an I/O pin when not enabled as INIT_DONE. When enabled, a transition from low to high at the pin indicates when the device has entered user mode. If the INIT_DONE output is enabled, the INIT_DONE pin cannot be used as a user I/O pin after configuration. This pin is enabled by turning on the Enable INIT_DONE output option in the Quartus II software.
Optional user-supplied clock input. Synchronizes the initialization of one or more devices. If this pin is not enabled for use as a user-supplied configuration clock, it can be used as a user I/O pin. This pin is enabled by turning on the Enable user-supplied start-up clock (CLKUSR) option in the Quartus II software.
Dual-Purpose Differential & External Memory Interface Pins
Clock and PLL Pins
Optional/Dual-Purpose Configuration Pins
Connect this pin to GND via a 1-k resistor. If the JTAG circuitry is not used, connect TCK to GND.
Connect this pin to a 1-k resistor via the VCCIO of the bank it resides in. If the JTAG circuitry is not used, connect TMS to VCCIO. Connect this pin to a 1-k resistor via the VCCIO of the bank it resides in. If the JTAG circuitry is not used, connect TDI to VCCIO.
When not in JTAG mode, this pin should be left unconnected.
When not used as PLL output pins, these pins can be used as user I/O pins. When these pins are not used, they may be left floating. When not used as PLL output pins, these pins can be used as user I/O pins. When these pins are not used, they may be left floating.
During a multi-device configuration, this pin feeds the nCE pin of a subsequent device and must be pulled high to VCCIO by an external 10-k pull-up resistor. During a single-device configuration and for the last device in a multi-device configuration, this pin can be left unconnected or used as an user I/O after configuration.
When not programming the device in AS mode, the nCSO pin can be used as user I/O. When this pin is not used as an I/O, Altera recommends that you leave the pin unconnected.
When not programming the device in AS mode, the ASDO pin can be used as user I/O. When this pin is not used as an I/O, Altera recommends that you leave the pin unconnected.
When the dedicated output for CRC_ERROR is not used and this pin is not used as an I/O, Altera recommends that you leave the pin unconnected.
When the dedicated output for DEV_CLRn is not used and this pin is not used as an I/O, Altera recommends that you tie this pin to the VCCIO of the bank that it resides in or ground. (Note 6)
When the dedicated output for DEV_OE is not used and this pin is not used as an I/O, Altera recommends that you tie this pin to the VCCIO of the bank that it resides in or ground. (Note 6)
When INIT_DONE is enabled, connect this pin to a 10-k resistor via the VCCIO of the bank that it resides in.
If the CLKUSR pin is not used as a configuration clock input and the pin is not used as an I/O, Altera recommends that you connect this pin to ground.
Note
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.
Pin Definitions
Pin Name
V
(1)
e
e
Page 13 of 15
LVDS[0-256][p,n](Note 3)
DPCLK[0..11]/ DQS[[0,1]L,[3,5,4,2]B,[1,0]R,[2,4,5,3]T]
(Note 5)
CDPCLK[0..7]/ DQS[[2,3]L,[1,0]B,[3,2]R,[0,1]T](Note 5)
DQ[[[1,3][L,R]],[[3,5][B,T]]][0..17](Note 5)
DQ[[[0..3][L,R]],[[0..5][B,T]]][0..8](Note 5)
DM[[[0..3][L,R]],[[0..5][B,T]]](Note 5 )
DM[[[1,3][L,R]],[[3,5][B,T]]][0,1](Note 5)
DM[[[0..3][L,R]],[[0..5][B,T]]](Note 5)
DM[[[1,3][L,R]],[[3,5][B,T]]][0,1](Note 5)
Altera provides these guidelines only as recommendations. It is the responsibility of the designer to apply simulation results to the design to verify proper device functionality.
Pin Type (1st, 2nd, and 3rd Function) Pin Description Connection Guidelines
Dual-purpose differential transmitter/receiver channels 0 to 256. These channels can be used for transmitting or receiving LVDS-compatible signals. Pins with a "p" suffix carry the positive signal for
I/O, TX/RX channel
I/O, DPCLK/DQS
I/O, CDPCLK/DQS
I/O, DQ
I/O, DQ
I/O, DM
I/O, DM
I/O, BWS
I/O, BWS
the differential channel. Pins with an "n" suffix carry the negative signal for the differential channel. If not used for differential signaling, these pins are available as user I/O pins.
Dual-purpose DPCLK/DQS pins can connect to the global clock network for high-fanout control signals such as clocks, asynchronous clears, presets, and clock enables. It can also be used as optional data strobe signal for use in external memory interfacing. These pins drive to dedicated DQS phase-shift circuitry, which allows for the fine-tuning of the phase shift for input clocks or strobes to properly align clock edges needed to capture data.
Dual-purpose CDPCLK/DQS pins can connect to the global clock network for high-fanout control signals such as clocks, asynchronous clears, presets, and clock enables. Only one of the two CDPCLK in each corner can feed the clock control block at a time. The other pin can be used as a general-purpose I/O pin. The CDPCLK signals incur more delay to the clock block control because they are multiplexed before being driven into the clock block control. It can also be used as optional data strobe signal for use in external memory interfacing. These pins drive to dedicated DQS phase­shift circuitry, which allows for the fine-tuning of the phase shift for input clocks or strobes to properly align clock edges needed to capture data.
Optional data signal for use in external memory interfacing in the x16 or x18 modes.
Optional data signal for use in external memory interfacing in the x8 or x9 modes.
Optional data mask pins for x8/x9 modes are required when writing to DDR SDRAM and DDR2 SDRAM devices. A low signal indicates that the write is valid. If the DM signal is high, the memory masks the DQ signals. Each group of DQ and DQS signals requires a DM pin.
Optional data mask pins for x16/x18 modes are required when writing to DDR SDRAM and DDR2 SDRAM devices. A low signal indicates that the write is valid. If the DM signal is high, the memory masks the DQ signals. Each group of DQ and DQS signals requires a DM pin.
Byte Write Select is an active-low pin. When asserted active, BWS selects which byte is written into the device during write operation. Bytes not written remain unchanged. Deselecting BWS causes writ data to be ignored and not written into device.
Byte Write Select is an active-low pin. When asserted active, BWS selects which byte is written into the device during write operation. Bytes not written remain unchanged. Deselecting BWS causes writ data to be ignored and not written into device.
When these pins are not used, they can be tied to the VCCIO of the bank that they reside in or GND. (Note 6)
When these pins are not used, they can be tied to the VCCIO of the bank that they reside in or GND. (Note 6)
When these pins are not used, they can be tied to the VCCIO of the bank that they reside in or GND. (Note 6) When these pins are not used, they can be tied to the VCCIO of the bank that they reside in or GND. (Note 6) When these pins are not used, they can be tied to the VCCIO of the bank that they reside in or GND. (Note 6)
When these pins are not used, they can be tied to the VCCIO of the bank that they reside in or GND. (Note 6)
When these pins are not used, they can be tied to the VCCIO of the bank that they reside in or GND. (Note 6)
When these pins are not used, they can be tied to the VCCIO of the bank that they reside in or GND. (Note 6)
When these pins are not used, they can be tied to the VCCIO of the bank that they reside in or GND. (Note 6)
Pin Information for the Cyclone® II EP2C5 Device
ersion 2.0
Note
Notes:
1) These pin connection guidelines are created based on the largest Cyclone II device, EP2C70F896. Refer to the pin list for the availability of pins in each density.
2) Capacitance values for the power supply should be selected after considering the amount of power they need to supply over the frequency of operation of the particular circuit being decoupled. A target impedance for the power plane should be calculated based on current draw and voltage droop requirements of the device or supply. The power plane should then be decoupled using the appropriate number of capacitors. On-board capacitors do not decouple higher than 100 MHz due to “Equivalent Series Inductance” of the mounting of the packages. Proper board design techniques such as interplaning capacitance with low inductance should be considered for higher frequency decoupling.
3) The differential transmitter/receiver channel count for each device and package is different; smaller packages may contain less than the maximum number of differential transmitter/receiver channels. For details on the differential transmitter/receiver channel count for each device, refer to the corresponding pin-out from www.altera.com.
4) The EP2C5, EP2C8, and EP2C8A devices have only PLL1 and PLL2.
5) The DQ, DQS, DM, and BWS# bus mode count for each device and package is different. Smaller packages may contain less than the maximum number of DQ, DQS, DM, and BWS# bus modes. For details on the DQ, DQS, DM, and BWS# bus mode count for each device, refer to the corresponding pin-out from www.altera.com.
6) Make sure that unused pins are set to input tristated in the Quartus II software. For instructions on how to set this, refer to the Quartus II Handbook.
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.
Pin Definitions
Pin Information for the Cyclone® II EP2C5 Device, ver 2.0
Page 14 of 15
VREFB2N1 VREFB2N0
PLL2B2
VREFB1N0VREFB1N1
PLL1
B1
VREFB3N0VREFB3N1
B3
B4
VREFB4N1 VREFB4N0
Notes:
1. This is a top view of the silicon die.
2. This is only a pictorial representation to get an idea of placement on the device. Refer to the pin list and the Quartus
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.
®
II software for exact locations.

Bank & PLL Diagram

Pin Information for the Cyclone® II EP2C5 Device
V
Page 15 of 15
Version Number Date Changes Made
1.0 10/6/2004 Initial revision
1.1 1/18/2005 Added F256 package
1.2 2/24/2005 Modified Pin Definitions for DATA0 pin
1.3 5/3/2005 Added CRC_ERROR pin in Pin List and Pin Definition Changed pin name from GNDD_PLL and GNDG_PLL to GND_PLL Finalize
1.4 6/2/2005 Modified Pin Type column in Pin Definitions for VREFB[1..8]N[0..1] pins
1.5 7/28/2005 Modified LVDS naming in Pin List: LVDS12p/n to LVDS22p/n LVDS22p/n to LVDS21p/n LVDS21p/n to LVDS20p/n LVDS20p/n to LVDS19p/n LVDS19p/n to LVDS18p/n LVDS18p/n to LVDS17p/n LVDS11p/n to LVDS16p/n LVDS17p/n to LVDS15p/n LVDS10p/n to LVDS14p/n LVDS16p/n to LVDS13p/n LVDS15p/n to LVDS12p/n LVDS14p/n to LVDS11p/n LVDS13p/n to LVDS10p/n
1.6 2/10/2006 Added footnote for pins that do not support Optional Functions (LVDS, DDR, etc) Added footnote for DQS0T, DQS1T, DQS0B and DQS1B pins Modified Pin Description of NC pins Modified Pin Description of VREFB[1..4]N[0..1] pins Modified Pin Description of VCCA_PLL[1..4] and VCCD_PLL[1..4] pins Added Pin Description for BWS pins
1.7 3/1/2006 Added comment for PLL_OUT pins in Pin Definitions
1.8
1.9 10/11/2006 Modified Pin Description for number of PLLs available from 4 to 2.
2.0 4/25/2008 Incorporated pin connection guidelines into pin definitions worksheet.
6/16/2006
Added "I/O" to pin type of pin nCEO, nCSO and ASDO Modified Pin Description for NCONFIG, NCE, DATA0, TMS, TCK, TDI, NSTATUS, CONDONE and DCLK pins
Modified Pin Description of VCCIO and VCCINT. Moved nCEO Discription from section "Dedicated Configuration/JTAG Pins" to section "Optional/Dual-Purpose Configuration Pins"
ersion 2.0
PT-EP2C5-2.0.xls Copyright © 2008 Altera Corp.

Revision History

Loading...
