Alinco DR-CS25T Instruction Manual

Manufacture:

ALINCO, INC.

Y

odoyabashi Dai-bldg 13F
4-4-9 Koraibashi, Chuo-ku, Osaka 541-0043 Japan
Phone: [phone] Fax: [phone]
http://www.alinco.com
E-mail:[e-mail]

A1.221124

Electrical and electronic equipment and batteries should
be recycled at a facility capable of handling these items.
Contact your local authority for details of disposal rules.

Copyright Alinco, lnc. PS1075/FNFF-EN

Printed in China

222MHz FM Mobile Transceiver

DR-CS25

Instruction Manual

Thank you for purchasing your new Alinco transceiver.
Please read this manual carefully before using the
product to ensure full performance, and keep this
manual for future reference as it contains information
on after-sales services. In case addendum or errata
sheets are included with this product, please read
those materials and keep them together with this
instruction manual for future reference.

MEMO

[

]

Introduction

Thank you very much for purchasing this excellent Alinco transceiver.
Our products are ranked among the finest in the world. This radio has
been manufactured with state of the art technology and it has been tested
carefully at our factory. It is designed to operate to your satisfaction for
many years under normal use.

Please read this manual completely from the first page to the
last, to learn all the functions the product offers. It is important to
note that some of the operations may be explained in relation to
information in previous chapters. By reading just one part of the
manual, you may risk not understanding the complete explanation
of the function.

Before transmitting

There are many radio stations operating in proximity to the frequency
ranges this product covers. Be careful not to cause interference when
transmitting around such radio stations.

■

Covering ranges

It may vary drastically depending on the type and location of antenna
system. Please consult your dealer for details as DR-CS25 requires an
external antenna.

■

Lightning

Any person is not safe outdoors during thunderstorms and lightning. Note
also that no car provides adequate protection of its passengers or drivers
against lightning as well. Therefore, Alinco will not take responsibility
for any danger associated with using radios outdoors or inside the car
during lightning.

■

Electromagnetic Interference/Compatibility

During transmissions, your radio generates RF energy that can
possibly cause interference with other devices or systems. To avoid

such interference, turn off the radio in areas where signs are posted to
do so. DO NOT operate the transmitter in areas that are sensitive to
electromagnetic radiation such as hospitals, aircraft, and blasting sites.

■

Enclosure protection

This transceiver is NOT water and dust protected. Avoid contacts with
water and dust, and if wet or dirty, immediately wipe them out with clean
dry cloth. This product is NOT anti-explosive.

Never use in close vicinity to explosive gas, combustible dust,on an oil
rig or in an open mine.

■

About Utility Software

The utility software may be available and programming cable is optional.
Please ask to your dealer for details.

Features

■ Ultra compact, Output power selectable 50W/20W/10W

■ PC-programmable 200ch

■ Alphanumeric name tags

■ Bright and color-selectable display

■ Wide variety of selective calling features built-in; The
2-Tone, 5-Tone, 51 CTCSS, 1024 DCS, 4 Tone-burst tones
and DTMF/ANI decode

■ Radio stun/kill/revive functions

■ Multi-function, backlit microphone enables direct
frequency entry & more from keypads

■ Packed with useful features like various scan modes, key-
lock, narrow bandwidth and more!

Conformity Symbols

This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

An amateur radio operator license is required to operate this device.

Comformity information

Manufacturer:

ALINCO, Inc. Electronics Division

Yodoyabashi Dai-bldg. 13F

4-4-9 Koraibashi, Chuo-ku,

Osaka 541-0043 Japan

Check with your local waste ofcials for details on recycling or

proper disposal in your area.

Copyright 2022 All rights reserved. NO part of this document may be
reproduced, copied, translated or transcribed in any form or by any
means without the prior writhout the prior written permission of Alinco.
Inc, Osaka, Japan, English Edition Printed in China.

Compliance Information Statement

FCC WARNING

This equipment generates or uses radio frequency energy.
Changes or modifications to this equipment may cause harmful

interference unless the modifications are expressly approved in the
instruction manual. The user could lose the authority to operate this

equipment if an unauthorized change or modication is made.

INFORMATION TO THE DIGITAL DEVICE USER REQUIRED BY THE FCC

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against
harmful interference in a residential installation.

This equipment generates, uses and can generate radio frequency
energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that the interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer for technical assistance.

Information in this document is subject to change without notice or
obligation. All brand names and trademarks are the property of their
respective owners. Alinco cannot be liable for pictorial or typographical
inaccuracies. Some parts, options and/or accessories are unavailable
in certain areas. Changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority to
operate the equipment.

Electromagnetic Interference/Compatibility

Electronic devices are susceptible to electromagnetic interference (EMI)
if they are not adequately shielded or designed for electromagnetic
compatibility. Because this transceiver generates RF energy, it can cause
interference to such equipment.

Turn OFF your transceiver where signs are posted to do so.

•

Hospitals and health care facilities use equipment that is sensitive to
electromagnetic radiation.

WARNING

To prevent any hazard during operation of Alinco’s radio product, in this

manual and on the product you may nd symbols shown below. Please

read and understand the meanings of these symbols before starting to
use the product.

This symbol is intended to alert the user to an

Danger

Alert

Caution

Environment and condition of use

An amateur radio operator licence is required to operate this device.Please
consult with your dealer about radio laws and regulations before purchase.

immediate danger that may cause loss of life and
property if the user disregards the warning

This symbol is intended to alert the user to a
possible hazard that may cause loss of life and
property if the user disregards the warning.

This symbol is intended to alert the user a
possible hazard that may cause loss of property
or injure the user if the warning is disregarded.

Alert symbol. An explanation is given

Warning symbol. An explanation is given.

Instruction symbol. An explanation is given.

.

.

ALERT

Environment and condition of use

Do not drive while handling the radio for your safety. It is recommended that

you check local trafc regulations regarding the use of radio equipment while

driving. Some countries prohibit the operation of radio while driving.

Do not use this product in close proximity to other electronics devices,
especially medical ones. It may cause interference to those devices.

Keep the radio out of the reach of children

In case a liquid leaks from the product, do not touch it. It may damage your
skin. Rinse with plenty of cold water if the liquid contacted your skin.

Never operate this product in facilities where radio products are prohibited for
use such as aboard aircraft, in airports, in ports, within or near the operating
area of business wireless stations or their relay stations.

Use of this product may be prohibited or illegal outside of your country. Be
informed in advance when you travel.

The manufacturer declines any responsibilities against loss of life and/or
property due to a failure of this product when used to perform important tasks
like lifeguarding, surveillance, and rescue.

Do not use multiple radios in very close proximity. It may cause interference
and/or damage to the product(s).

Never install this product in a place that may obstacle proper functions of car
safety devices such as seat belts and air bags.

The manufacturer declines any responsibilities against loss of life and
property due to a failure of this product when used with or as a part of a
device made by third parties.

Use of third party accessory may result in damage to this product. It will void
our warranty for repair.

.

WARNING

Handling this product

Be sure to reduce the audio output level before operating. Excessive audio
may damage hearing.

Do not open the unit without permission or instruction from the manufacturer.

Unauthorized modication or repair may result in electric shock, re and/or

malfunction.

Do not operate this product in a wet place such as shower room. It may

result in electric shock, re and/or malfunction.

Do not place conductive materials, such as water or metal in close proximity

to the product. A short-circuit to the product may result in electric shock, re

and/or malfunction.

Do not touch the heatsink (on/around the unit mostly found on mobile-base
units) as it may become very hot during/after the operation that may risk burn
your skin.

About power-supply:

Use only appropriate, reliable and certied power supply of correct voltage

and capacity.

Do not connect cables in reverse polarity. It may result in electric shock, re

and/or malfunction.

Do not plug multiple devices including the power-supply into a single wall

outlet. It may result in overheating and/or re.

Do not handle a power-supply with a wet hand. It may result in electric
shock.

Securely plug the power-supply to the wall outlet. Insecure installation may

result in short-circuit, electronic shock and/or re.

Do not plug the power-supply into the wall outlet if the contacts are dirty and/

or dusty. Shortcircuiting and/or overheating may result in re, electric shock

and/or damage to the product.

Do not modify or remove fuse-assembly from the DC-cable. It may result in

re,electric shock and/or damage to the product.

In case of emergency

In case of the following situation(s), please turn off the product, switch
off the source of power, then remove or unplug the power-cord. Please
contact your local dealer of this product for service and assistance. Do not
use the product until the trouble is resolved. Do not try to troubleshoot the
problem by yourself. Unauthorized repair voids warranty.

● When a strange sound, smoke and or strange odor comes out of the

product.

● When the product is dropped or the case is broken or cracked.

● When a liquid penetrated inside.

● When a power-cord ( including DC-cables, AC-cables and adapters) is

damaged.

For your safety, turn off then remove all related AC-lines to the product and
its accessories including the antenna if a thunderstorm is likely.

Maintenance

Do not open the unit and its accessories. Please consult with your local
dealer of this product for service and assistance.

CAUTION

Environment and condition of use

Do not use the product in proximity to a audio products such as TV, radio
and stereo. It may cause interference or receive interference.

Do not install in a humid, dusty or insufciently ventilated place. It may result
in electric shock, re and/or malfunction.

Do not install in an unstable or vibrating position. It may result in electric

shock, re and/or malfunction when/if the product falls to the ground.

Do not install the product in proximity to a source of heat and humidity such
as a heater or a stove. Avoid placing the unit in direct sunlight.

Do not modify, dismantle, incinerate, or immerse the batteries that may be
used in accessories you use with this product.
Please check your local regulations for details on recycling option or disposal
of the batteries in your area.

About radio

Do not connect devices other than specied ones to the jacks and ports on

the product. It may result in damage to the devices.

Turn off and remove the power-source (AC cable, DC cable, battery, cigar­cable, charger adapter etc) from the product when the product is not in use
for extended period of time or in case of maintenance.

Never pull the cord alone when you unplug AC cable from the wall outlet.

Use a clean, dry cloth to wipe off dirt and condensation from the surface
of the product. Never use thinner or benzene for cleaning. Use cleaners
recommended to audio-video devices in case very dirty.

WARNING

About power-supply

Use only reliable power supply of specic DC output range and be mindful of

the polarity of the cables and DC jack.

Always turn off the power supply when connecting or disconnecting the
cables.

When using an external antenna, make sure that the antenna ground is not
common with the ground of the power supply.

Do not put magnetic cards like credit card, magnetic key etc. on/around the
radio. It may risk deleting data from the cards.

Before Operating the Radio

Attention

● Do not remove the case or touch the interior components. Tampering can cause equipment trouble.

● Do not use or keep the radio where it is exposed to direct sunlight, dusty places, or near sources of heat.

● Even though a heat protection circiut is buil-in, this product is not a 100% duty transmitter.

● When the internal temperature excesses, it turns to the MID power setting automatically to prevent over-
heating.

CONTENTS

Supplied Accessories ..........................................................1

Supplied Accessories ....................................................................... 1

Initial Installation ..................................................................2

Mobile installation ............................................................................2

DC Power Cable Connection ........................................................... 3

Power supply voltage Display .......................................................... 5

Antenna Connection ........................................................................5

Accessories Connections .................................................................5

Getting Acquainted ..............................................................7

Front panel ....................................................................................... 7

Rear panel .......................................................................................8

Display ............................................................................................. 8

Microphone ..................................................................................... 9

Basic Operations ................................................................. 10

Switching the Power On/Off ............................................................ 10

Adjusting the Volume .......................................................................10

Adjusting Squelch Level ...................................................................10

Switch between VFO and Memory Mode ........................................10

Adjusting Frequency/Channel .......................................................... 10

Receiving ......................................................................................... 10

Transmitting .....................................................................................10

Transmitting Tone Burst Tone ..........................................................11

Transmitting Optional Signaling .......................................................11

Memory Channel Programming ....................................................... 11

Memory Channel Function List ........................................................ 11

Memory Channel DeletIng ............................................................... 11

KEY OPERATIONS ................................................................ 12

Squelch Off (Monitor Function) ........................................................ 12

Frequency Scan ............................................................................... 12

Memory Scan (Channel Scan) ......................................................... 12

CTCSS/DCS Encode and Decode setup ......................................... 12

CTCSS SCAN .................................................................................. 13

DCS SCAN ......................................................................................13

High/Mid/Low Power Setting ............................................................ 13

Offset Direction And Offset Frequency Setup .................................. 13

Keypad Lockout ............................................................................... 14

Auto-Dialer Setup .............................................................................14

Emergency Alarm .............................................................................14

FUNCTION MENU SETUP ....................................................15

How To Use Function Menu ............................................................. 15

Frequency Step Setup ..................................................................... 15

Receiving Dtmf, Dtmf Ani, 2Tone Or 5Tone Signaling ......................15

Sending 2-Tone Call .........................................................................16

Sending 5-Tone Call .........................................................................16

Sending DTMF call ..........................................................................16

Signaling Combination Setup ...........................................................17

High/Mid/Low Power Selection ........................................................ 17

Band-width Selection ....................................................................... 17

TX OFF Setup .................................................................................. 18

Busy Channel Lockout ..................................................................... 18

CONTENTS

Editing Channel Name ..................................................................... 18

Reverse TX/RX ................................................................................18

Talk Around ..................................................................................... 19

Radio's DTMF Self ID Enquiry ......................................................... 19

Radio's 5TONE Self ID Enquiry .......................................................19

Beep Sound ..................................................................................... 19

TOT (Time-out timer) .......................................................................19

APO (Auto power off) .......................................................................20

DTMF Transmitting Time ..................................................................20

Display Iiiumination Color Setting .................................................... 20

Scan Resume Time Setup ...............................................................20

Tone-burst Tones .............................................................................21

Display Mode Setup ......................................................................... 21

Starting Password(

Address list .....................................................................................21

Restore(RESET) .............................................................................. 22

Useless if password is not assigned

) .........21

Microphone Operation .........................................................23

Keypad Lock .................................................................................... 23

Transmitting DTMF By Microphone Keypad ....................................23

Function Setup By Microphone Keypad ...........................................23

Switches Between Vfo And Memory Mode .....................................23

Short Calling ....................................................................................23

Transmitting DTMF Code .................................................................23

Frequency Step ...............................................................................23

Optional Signaling ........................................................................... 23

Scan Skip ........................................................................................ 24

Frequency/Channel Scan ...............................................................24

Busy Channel Lockout ..................................................................... 24

Reverse TX/RX ................................................................................ 24

TOT (Time-out timer) .......................................................................24

CTCSS/DCS Encode and Decode ...................................................24

Talk Around ..................................................................................... 25

Beep Sound ..................................................................................... 25

HIGH/MID/LOW Power Selection .................................................... 25

LCD Backlight ................................................................................. 25

Cable Clone ........................................................................... 26

Optional Accessories ........................................................... 26

Maintenance .......................................................................... 27

Key Function .................................................................................... 27

Trouble Shooting ..............................................................................27

Specications .......................................................................28

Appendix ...............................................................................29

51 groups CTCSS Tone Frequency(Hz). .........................................29

1024 groups DCS Code. .................................................................. 29

Supplied Accessories

Supplied Accessories

Carefully unpack to make sure the following items are found in the package in addition to this manual:

1

Transceiver
DR-CS25

Microphone EMS-74
(with DTMF keyboard)

Mobile Mounting
Bracket

DC Power Cable with
Fuse Holder(ADUA38)

Spare Fuses(15A)

The standard accessories may vary slightly depending on the version you have purchased. Please contact
your local authorized Alinco dealer should you have any questions. Alinco and authorized dealers are not
responsible for any typographical errors there may be in this manual. Standard accessories may change
without notice.

Warranty Policy: Please refer to any enclosed warranty information or contact your authorized Alinco dealer /
distributor for the warranty policy before purchase.

■

In order to operate this product, a properly tuned antenna, its feedline with hardwares and

in case of xed station a 20A-class power supply are necessary.

Please consult with your dealer for details.

Hardware Kit for Bracket

Fixing screws

(

M5x10mm

(2PCS)

Tapping screws

(

M4x12mm

(2PCS)

Pads

)

(2PCS)

S-Washer

)

(2PCS)

1

2

Initial Installation

Mobile installation

The transceiver may be installed in any position in your car, where the
controls and microphone are easily accessible and it does not interfere
with the safe operation of the vehicle. If your vehicle is equipped with
air bags, be certain your radio will not interfere with their deployment. If
you are uncertain about where to mount the unit, contact your vehicle's
dealer.

Install the mounting bracket in the vehicle using the supplied self-

1.

tapping screws (2pcs) and at washers (2pcs).

Car body

Washer
Tapping screw
(M5x20mm)

2

Position the transceiver, then insert and tighten the supplied xing

2.

screws.

Double check that all screws are tightened to prevent vehicle



vibration from loosening the bracket or transceiver.

Mounting bracket

Caution:

Use only the provided screws
otherwise you risk damaging the
circuit board, components or fall-off
of the unit.

Determine the appropriate angle of the transceiver, using the screw



hole position on the side of the mounting bracket.

CAUTION:

RF Hazard Warming
The electro-magnetic (radio Frequency) exposure level of this
device may exceed the European standards of the hazard level
when transmitting at the high-power setting while connected to a
unity gain antenna at a distance of 63cm or less from the operator.
Furthermore, the hazardous RF exposure level depends on the
conditions of the combination of the antenna gain, distance from
the operator, output setting and installation environment, therefore
the operator may be exposed to stronger RF even at a distance of
more than 63cm. For safety purpose, it is recommended that the
antenna be installed outside of, and as far as possible from, the
operator’s area. Avoid using an excessively high-gained antenna
in case the distance between the operator and the antenna is
very limited. Always use the minimum necessary output power for
communications.

Put the pads to both sides
for more tightened.

DC Power Cable Connection

Mobile Operation

The vehicle battery must have a nominal rating of 12V. Never
connect the transceiver to a 24V battery. Be sure to use a 12V
vehicle battery that has sufficient current capacity. If the current
to the transceiver is insufficient, the display may darken during
transmission, or transmitting output power may drop excessively.

Route the DC power cable supplied with the transceiver directly

1.

to the vehicle's battery terminals using the shortest path from the
transceiver.

Never use the cigarette lighter socket as a DC source.



The entire length of the cable must be dressed so it is isolated from



heat, moisture, and the engine secondary(high voltage) ignition
system/cables.

After installing cable, in order to avoid the risk of damp, please

2.

use heat-resistant tap to tie together with fuse box. Don't forget to
reinforce whole cable.

In order to avoid the risk of short circuit, please cut down

3.

connection with negative (-) of battery, then connect with radio.

Confirm the correct polarity of the connections, then attach the

4.

power cable to the battery terminals; red connects to the positive (+)
terminal and black connects to the negative (-) terminal.

Never remove the fuse holders from the cable.



Reconnect any wiring removed from the negative terminal.

5.

Initial Installation

Connect the DC power cable to the transceiver's power supply

6.

connector.

Press the connectors rmly together until the locking tab clicks.



Ext. Power jack

DC power cable

2

3

Red

Black

2

Fixed Station Operation

In order to use this transceiver for xed station operation, you will need

a separate 13.8V DC power supply (not included) , Please contact local
dealer to require.

The current capacity of your power supply must be 12A or more.

4

Initial Installation

Connect the DC power cable to the regulated DC power supply

1.

and ensure that the polarities are correct. (Red: positive, Black:
negative).

Never directly connect the transceiver to an AC outlet.



Use the supplied DC power cable to connect the transceiver to a



regulated power supply.

Do not substitute a cable with smaller gauge wires.



Regulated

power supply

Black

(Negative)

DC power cable with fuse holder

Red(Positive)

Connect the transceiver's DC power connector to the connector on

2.

the DC power cable.

Press the connectors rmly together until the locking tab clicks.



Be sure to turn off both the transceiver and power supply before start
setting and connections.

REPLACING FUSES

If the fuse blows, determine the cause, then correct the problem. After the
problem is resolved, replace the fuse. If newly installed fuses continue to
blow, disconnect the power cable and contact your dealer for assistance

Fuse Location Fuse Current Rating

Transceiver 15A

Supplied DC

power cable

Only use fuses of the specied type and rating, otherwise the transceiver

could be damaged.

If you use the transceiver for a long period when the vehicle battery is
not fully charged, or when the engine is OFF, the battery may become

discharged, and will not have sufcient reserves to start the vehicle. Avoid

using the transceiver in these conditions.

15A

.

Power supply voltage Display

After being connected to an appropreate power source, press
to turn on. Press and hold P3 key for 2 seconds to display the supplied
voltage.

The display immediately changes as the voltage supply changes, It also
displays voltage during transmission.

The transceiver will return to its normal operation when the power is
turned ON/OFF or repeat above operation.

The range of displayed voltage is from 9V to16V DC. Because the
displayed value is estimated, please use a voltmeter when a more

Important

precise reading is desired.

PWR

key

Antenna Connection

Before operating, install an efcient, well-tuned antenna. The success of

your communication will depend on the type of antenna and its correct
installation.

Use a 50Ω impedance antenna and low-loss coaxial feed-line that
has a characteristic impedance of 50Ω, to match the transceiver input

impedance. Coupling the antenna to the transceiver via feed-lines having

an impedance other than 50Ω reduces the efficiency of the antenna

system and can cause interference to nearby televisions, radio receivers
and other electronic equipment.

Transmitting without rst connecting an antenna or other unmatched

load may damage the transceiver. Always connect the antenna to the
transceiver before transmitting.

All xed stations should be equipped with a lightning arrester to reduce
the risk of re, electric shock, and transceiver damage.

Initial Installation

2

Accessories Connections

External Speaker

If you plan to use an external speaker, choose a speaker with an

impedance of 8Ω. The external speaker jack accepts a Φ3.5mm (1/8")

mono (2-conductor) plug.

5

2

Initial Installation

Microphone

For voice communications, connect a provided microphone into the
socket on the front of the main unit. Turn the ring firmly on the plug
until it locks. Attach the supplied microphone hanger in an appropriate
location using the screws included in the screw set.

Microphone
connector

6

Microphone [EMS-74]

Antenna

External speaker

Front panel

P2

Basic Functions

NO. KEY FUNCTION

1

PWR(Power) Power on/Off

2

VOL

Knob

3

SQL Knob Adjust Squelch level

4

FUNC Various functions

5

P1

6

P2 Changes frequency by 1MHz order

7

P3 Sets CTCSS and DCS values

8

P4 Call channel

Data Terminal

9

/Mic.connector

10

TX/RX indicator RX is Green / TX is Red

Adjust audio level

Switches between VFO mode and Memory mode

Data reading/writing, cloning and Microphone
connection port

P3

P4

Getting Acquainted

Functions that require pressing
press the following key.

FUNC

key until icon appears then

3

NO. KEY FUNCTION

1

FUNCPWR

P1 MW(Setting memory channel data)

2

P2 Deleting memory channel

3

P3

Keypad lockout

4

P4 High/Middle/Low power

Functions that require holding for over 2 seconds the following key.

NO. KEY FUNCTION

1

FUNC Goes to FUNCTION MENU

2

P1 SCAN

3

P2

4

P3

5

P4 --

Frequency Offset

Power voltage monitor

7

Functions of P1-P4 keys are programmable as you prefer

by using the utility software

FACT reset will return the key assignments to default as listed here.
See P.22 for details.

3

Getting Acquainted

Rear panel

3

NO. Jack Connectors FUNCTION

1

Ext. Sp Terminal for optional external speaker.

2

Not in use (Not in use)

8

Antenna

3

Connector

Connection for 50Ω coaxial cable and

antenna.Connector is PL/M.

DISPLAY

19

1

2

16

15

1718

13

NO. KEY

1

1

2

3

4

2

5

6

7

8

9

10

11

12

13

14

15

14

13

12

10

11

9

16

17

18

8

19

Å

SQL

M

Dot

Decimal point

DCS

_

+

A

Nar

LO

Mi

FUNCTION

(Not in use)

Memory mode.

Indicates the channel number in memory mode.

Channel skip.

Indicates the decimal point of frequency and the
scanning function.

Indicates the frequency or memory name.

Signal is being received or monitoring.

Signal strength of receiving and transmitting.
Strength of receiving or transmitting signals.

(Not in use)

Keypad lock .

Set DCS function.

Set CTCSS function.

Offset frequency direction.

(Not in use)

Auto power off.

Narrow mode.

Low power.

Middle Power.

Function key is activated

3

4

5

6

7

microphone

NO. KEY FUNCTION

UP Increase frequency, channel number or setting value.

1

DOWN Decrease frequency, channel number or setting value.

2

PTT Push-To-Talk key to transmit.

3

Numerical Keyd Input VFO frequencies and other various oprations.

4

DTMF ON/OFF Switches between DTMF and function operations.

5

LOCK Switch Locks all keys excep PTT.

6

MIC Microphone element is located.

7

Getting Acquainted

MIC Connector Diagram(in the front view of connector)

3

9

4

Switching The Power On/Off

Press the

PWR

key for 1 second to turn off.

Basic Operations

PWR

switch to power on. Press the

PWR KEY

PWR

P2

Adjusting The Volume

Turn the VOL knob clockwise to increase the
audio level, counterclockwise to decrease.

P3

P4

ADJUSTING SQUELCH LEVEL

A squelch eliminates white-noise (the background noise when a signal is

not received). Higher level settings will keep the squelch "closed" more

10

tightly for quieter monitoring, but weak signals will not be heard. Lower

settings allow weaker signals to "open" the squelch but noise may also

cause it to open. By rotating the
the desired level.

SQL

knob, adjust the squelch level to

Switch between VFO and MEMORY mode

In standby, press key or Microphone's

key until appear , this indicates current
frequency in Memory mode. Repeat above
operation to switch between Frequency mode
(VFO) and Memory mode.

FUNC

Adjusting Frequency/Channel

In frequency (VFO) mode, you can change the current frequency to

1.

the desired one through microphone [ / ] key. Press

key to increase frequency and press key to decrease
frequency. In another way you also can directly input the desired
frequency by MIC's numeric keys. Press
digits will be masked. In this status, Microphone [ /

] key will increase or decrease frequency quickly by 1MHz
step.

In memory mode, you can change the current channel to the

2.

desired one through microphone [ / ] key. Press

key to the forward channel and press key to the
backward channel. In another way you also can directly input the
desired channel by MIC`s numeric keys. For example, choosing
CH1, press [0] [0] [1] .

Available steps are 2.5K, 5K, 6.25k, 8.33K,10K, 12.5K, 20K, 25K and 30K.
When you want to exit from adjusting frequency mode, perss P2.

P2

key, the KHz order

Receiving

Select the desired receiving frequency or browse channels to listen to
ongoing communications. The S-meter shows
relative signal strength between BUSY and
5th segment when the transceiver detects an
incoming signal.

Transmitting

Press MIC's key to monitor for a while to confirm the channel
desired is not busy. Press Mic's key to return standby status,Then
press and hold [PTT] key to speak into microphone.

Speaking too loud distorts, too undertone won't modulate enough your



voice.

While transmitting, LED lights RED and TX-meter shows relative power level.
Release PTT to receive.

Transmitting Tone BURST TONE

Press and hold [PTT] key, then press Microphone key to transmit

selected tone-burst tone. Pre-programming is necessary.

Transmitting OPTIONAL SIGNALING

Press and hold [PTT] key, then press Microphone key to

transmit pre-stored and selected DTMF/2Tone/5Tone optional signaling.

Preprogramming is necessary.

Basic Operations

4

Memory Channel Function List

●

Band Width

●

TX Power

●

CTCSS/DCS Encode / Decode

●

Optional Signal

●

TX Off

●

Scan Skip

●

Reverse / Talk Around

●

Busy Channel Lock-Out

In memory mode, the setting may be changed temporary but changing
a channel or turning off the radio will cancel the operation and returns to
programmed setting.

MEMORY CHANNEL PROGRAMMING

Be sure the undesired functions are turned off before programming.

1.

Memory channels hold setting like signaling and power settings.

If you wish to include settings such as signaling and power in the

2.

memory, Set them to the VFO in advance to the memory programming
operation. Refer to the list on the right for parameters you may include in
a memory channel.

FUNC

Press

3.

current channel appear on LCD. Flashing

means the current channel is empty.

Press or Key to select the

4.

desired channel number to store.

Press key, , icon and channel

5.

number disappears and beep sounds twice.

Press key again to confirm that the memory channel is properly

6.

stored.

key, LCD appears , and

MEMORY CHANNEL DELETING

Under Memory mode, input by MIC's numeric keys to select

1.

channel to be deleted. For example, choosing CH1, press [0] [0] [1].

FUNC

Press

2.

memory will be deleted and a beep sounds twice. icon ashing
means current memory channel is deleted. Can not delete all
memory channels, at least one channel will be saved.

key, LCD appears icon, then press P2 key, current

11

5

KEY OPERATIONS

squelch off(Monitor function)

Press key to disable squelch, press key again to resume
squelch. While monitoring, all signaling features are temporary
released.

Frequency Scan

Scans all VFO frequencies in regard to the preset tuning step.

In VFO mode, press until starts

1.

scanning.

Press Microphone [ / ] key to change scan direction.

2.

12

Press any key except

3.

PWR

and

FUNC

key to stop.

MEMORY Scan(channel scan)

Scans all memory channels unless Memory skip feature is selected for a
given memory.

In memory mode, press and hold key for over 2 seconds to

1.

enter into channel scan.

Press Microphone [ / ] key

2.

to change scan direction.

Press any key except

3.

exit.

PWR

and

FUNC

key to

CTCSS/DCS Encode and Decode setup

Many repeaters require CTCSS or DCS
tone encoding to access the system. Tone
decoding features are often used to filter
unwanted signals. In this mode, regardless
of the main squelch status, the audio can
be heard ONLY when the matching tone/
code signal is received. The combination
of CTCSS squelch and DCS function is not
available; only one or the other may be used
for a given channel. Tone settings can be
programmed in memory channels. In memory mode, the setting may
be changed temporary but changing a channel or turning off the radio
will cancel the operation and returns to programmed setting.

Press P3 key. The current setting will be displayed with

1.

icons and relative frequency/code.

Select icon to set the encoding tone.The number below

2.

represents the tone frequency in Hz. Use [ / ] keys
to select the desired encoding tone.If the repeater requires only
encoding tone, press [PTT] to set and operate.

To set tone squelch, Press P3 key again to display icon.

3.

Select decoding tone frequency that can be set different from
encoding tone. Press [PTT] to set and operate tone-squelch.

Press it again so that the 3-digit number and icon is displayed.

4.

This is the DCS code, and it enables DCS encoding and decoding.

Press [ / ] keys to change codes. Press any key ( Except

FUNC / PWR / TS / DCS, UP / DOWN

return to original status. The
show the current selective-calling status. To exit, simply use the P3 key
and press it until the relative status icon

T/SQ/DCS

keys) to enter the setting and

icon will remain on the display to

T/TQ/DCS

disappears.

T/SQ/DCS

The standard set of 50 different CTCSS tones are available. DCS
encode/decode cannot be separated. The list of selectable tones and
codes is shown on Appendix at the end of this manual.

CTCSS SCAN

While receiving CTCSS signal, press P3 key
to select or
starts scanning. Once finding a matching
CTCSS tone, a voice will be heard and
resumes scanning after 15 seconds.

Press any key except

TSQ

then hold P3 key until

PWR

and

FUNC

key to exit.

DCS SCAN

While receiving DCS signal, press P3 key to select DCS then hold

P3

key until starts scanning. Once finding a
matching DCS code, a voice will be heard and
resumes scanning after 15 seconds.

Press any key except

PWR

and

FUNC

key to exit.

HIGH/MID/LOW Power SETTING

FUNC

Press

P4

power.

None

key to display icon, then press

key to switch between high/Mid/low

: Transmits in high power 50W

: Transmits in middle power 20W

KEY OPERATIONS

5

Offset Direction and offset frequency setup

Repeater receives a signal(UP-LINK) on one frequency and re-transmits
on another frequency(DOWN-LINK). The difference between these two
frequencies is called the offset frequency. If the UP-LINK frequency is
higher than DOWN-LINK frequency, the direction is positive, If it is lower,
the shift direction is negative.

This operation is possible also in the memory mode but
temporaly. Changing frequencies or turning off the radio will reset
the setting.

Press and hold P2 key for over 2

1.

seconds, LCD displays offset direction
and offset frequency.

Repeatedly press P2 key to select

2.

positive offset or negative offset.

When LCD displays " " icon, it indicates positive offset, which

3.

means transmitting frequency higher than receiving frequency.

When LCD displays " " icon, it indicates negative offset, which

4.

means transmitting frequency lower than receiving frequency.

Mic's [ / ] key to change offset frequency in

5.

accordance with the step setting.

Press any key except

6.

In memory mode, this operation can be temporarily available.

FUNC

and P2 key to set and nish setting.

13

: Transmits in low power 10W

5

KEY OPERATIONS

KEYPAD LOCKOUT

To avoid unintentional operations, this function will lock all keys except

FUNC

PWR

and

1.

2.

.

FUNC

Press
icon, then press P3 key until LCD
displays icon.

Repeat above operation, icon disappears, indicating keypad
lockout function is invalid.

key until LCD displays

Auto-Dialer Setup

Auto-dialer is to automatically transmit preprogrammed and stored DTMF

tone codes. Easier way is to use "

software.

14

To program codes manually, press key on your microphone. 2 digit
numbers and EMPTY or codes appear on the display.

Press / key to choose group you wish to edit. Up to

1.

16 Auto-dialer memories are available. The display scrolls when
the 7th digit is entered. The numbers 0-9, --, A-D, * and # can be
stored up to a total of 24 digit in a group.

Press key to program the DTMF

2.

codes you wish by using microphone's
keypads.

After editing, press [PTT] key to send

3.

programmed codes.

Press P4 to store the codes and exit,

4.

or use / keys to continue
programming.

DTMF set

" menu in the PC utility

Emergency Alarm

This transceiver has 4 optional Alarm modes that can only be set using

programming software. Press pre-programmed key to display "

to operate. Repeat above operation or turn off the transceiver to cancel
the alarm.

ALARM

"

How to use FUNCTION MENU

Press and hold

1.

MENU SETUP.

Press P3 or P4 to select the desired menu. P3 key to forward

2.

P4

and

Press / to select the desired parameter.

3.

Press any key except

4.

Menu No. LCD Display

01 STP (Channel Step) 5K
02 T (DTMF,2 TONE, 5 TONE Of RX) OFF
03 2TONE (TX) 00
04 5TONE (TX)
05 DTMF (TX)
06 SPK (Signal Combination) SQ
07 POWER HIGH
08 BAND 20K
09 TX ON
10 LOCK(Busy Channel Lock Out) OFF
11 Editting Channel Name ­12 REV (Reverse TX/RX) OFF
13 TALK (Talk Around) OFF
14 D (DTMF Self ID Enquiry) 001
15 F (5 TONE Self ID Enquiry) 12345
16 BEEP (Beep Sound) ON
17 TOT (Time Out Timer) 3 Minutes
18 APO (Auto Power Off) OFF
19 SPD (DTMF Transmitting Time) 50
20 COL (Display Color) ORG
21 SCAN T0
22 TB (Tone-Bust Tones) 1750
23 DSP (Display Mode Setup) FR
24 CODE OFF
25 BOOK (Address List) ­26 RESTORE -

Some of features can be also operated through the microphone keys.
It is recommended to read Chapter 8 (p.23) together with this chapter.

FUNC

key for over 2 seconds to enter the FUNCTION

key to backward menus.

PWR

, P3, P4, , key to exit.

Å

Default

00
01

FUNCTION MENU SETUP

7

Frequency Step Setup

Only in VFO mode, this function is valid.

Press and hold

1.

FUNC

key for over 2

seconds to enter setting menu.

/

P4

P3

Press

2.

125

".

Press / to select the desired frequency channel step.

3.

key to choose No.01 menu, LCD displays "

STP--

Available steps in KHz are: 2.5(shown as 2K5), 5, 6.25(62), 8.33(83),
10, 12.5(125), 20, 25, 30 and 50.

Press any key except

4.

PWR

, P3, P4, , key to exit.

01 STP menu won't appear when the radio is in memory mode.

RECEIVING DTMF, DTMF ANI, 2TONE OR 5TONE SIGNALING

DTMF/5Tone/2Tone signalling are used for selective-calling. DTMF and
5Tone signalling can be applied for other advanced features such as
ANI, PTT ID, group call, remotely stun, remotely kill, revive,...etc.

Tone code settings should be performed in advance to Signaling
operations by PC programming. Manual code setting is not available.

Press and hold

1.

menu.

P3

Press

2.

Press / to select the desired setup.

3.

"DTMF”: The channel will be mute by a DTMF signal. The speaker



won’t sound until receiving a correspondent DTMF signal. Hold

PTT

[

] then press [UP] directly t o

transmit the pre-stored DTMF tones.

FUNC

key for over 2 seconds to enter into setting

/ P4

to choose No. 2 menu, LCD displays "

T-OFF

" .

15

7

"2TONE": The channel will be mute



by a 2-Tone signal. The speaker won’t
sound until receiving a correspondent
2-Tone signal. Hold [
[UP] to transmit the pre-stored 2-Tone
signal.

"5Tone": The channel will be mute by



a 5-Tone signal. The Speaker won’t
sound until receiving a correspondent 5-Tone signal. Hold [
then press [UP] directly to transmit the pre-stored 5-Tone signal.

Press any key except

4.

Sending 2-Tone Call

Press and hold

1.

16

Press P3 /

2.

XX

", "XX" indicates the preprogrammed

groups.

Press / to select the

3.

desired 2-TONE group, Press PTT to
transmit selected group.

Total:32groups, 00-31, Default: 00.

4.

Press any key except

5.

2-TONE will be operation parameters must be edited by
programming software prior to the practical operation.
This function is to only query edited group or name.

FUNCTION MENU SETUP

PTT

] then press

PWR

, P3, P4, , key to exit.

FUNC

key for over 2 seconds to enter setting menu.

P4

key to choose No.03 menu, LCD displays "

PWR

, P3, P4, , key to exit.

PTT

2TON

Sending 5-Tone Call

Press and hold

1.

Press P3 /

2.

LCD displays "

FUNC

key for over 2 seconds to enter setting menu.

P4

key to choose No.04 menu,

5TON XX

", "XX" indicates

the preprogrammed groups.

Press / to select the desired 5-TONE group, Press

3.

PTT]

[

]

to transmit selected group.

Total:100groups, 00-99, Default:00.

4.

Press any key except

5.

PWR

, P3, P4, , key to exit.

5-TONE operation parameters must be edited by programming
software prior to the practical operation.

Sending DTMF call

Press and hold

1.

P3

Press

2.

XX

", "XX" indicates the operation parameters must be.

Press / to select the desired

3.

DTMF group.

Total:16groups, 01-16, Default:01.

4.

Press any key except

5.

, key to exit.

FUNC

key for over 2 seconds to enter setting menu.

/ P4 key to choose No.05 menu, LCD displays "

PWR

, P3, P4,

DTMF

Signaling Combination setup

This function is to improve the level of protecting the radio against
receiving irrelative signal.

Press and hold

1.

P3

Press

2.

SQ

".

Press / to select the desired combination.

3.

If select "SQ", it indicates you can hear

the calling from caller when receive a
matching carrier.

If LCD displays "CTC", it indicates



you can hear the calling from caller
when receive a matching carrier and
CTCSS/DCS signaling .

If LCD displays "TON", it indicates



you can hear the calling from caller
when receive a matching carrier and
DTMF/2TONE/5TONE signaling .

If LCD displays "C/T", it indicates



you can hear the calling from caller
when receive a matching carrier and
CTCSS/DCS and DTMF/2TONE/5TONE signaling.

If LCD displays "C/T", it indicates you



can hear the calling from caller when
receive a matching carrier and either
CTCSS/DCS DTMF/2TONE/5TONE signaling.

Press any key except

4.

This function is available only for pre-programmed units with
Tone-signals and CTCSS/DCS selective calling.

FUNC

key for over 2 seconds to enter setting menu.

/ P4 key to choose No.06 menu, LCD displays "

PWR

, P3, P4, , key to exit.

SPK--

FUNCTION MENU SETUP

HIGH/MID/LOW Power Selection

Press and hold

1.

seconds to enter setting menu.

P3

Press

2.

menu, LCD displays "

Press / to select the desired setting.

3.

HI: High TX Power (50W)

MI: Middle TX Power (20W)

LOW: Low TX Power (10W)

Press any key except

4.

FUNC

key for over 2

P4

/

key to choose No.07

POW--HI

PWR

, P3, P4, , key to exit.

".

Band-width Selection

Select suitable bandwidth in accordance with your local band-plans.

Press and hold

1.

P3

Press

2.

25

".

Press / to select the

3.

desired setting.

25:Band width is 25KHz(Wide band)

20:Band width is 20KHz(Middle band)

12:Band width is 12.5KHz(Narrow band)

Press any key except

4.

, key to exit.

"25" is hardly used in amateur radio. Be sure to select 20 or 12

to avoid interferring stations nearby. Default setting is 20.

FUNC

key for over 2 seconds to enter setting menu.

P4

/

key to choose No.08 menu, LCD displays "

PWR

, P3, P4,

BAND--

7

17

7

FUNCTION MENU SETUP

TX OFF SETUP

This function is to prohibit the transmission and to use the radio as a
receiver.

Press and hold

1.

P3

Press

2.

Press / to select the

3.

desired setting.

On:In current channel, press PTT to
transmit

OFF:In current channel, PTT is invalid.

4. Press any key except

FUNC

key for over 2 seconds to enter setting menu.

P4

/

key to choose No.09 menu, LCD displays "

PWR

, P3, P4, , key to exit.

TX-ON

OFF: Busy channel lockout is disabled. It can transmit in any



receiving status.

Press P2 key to conrm and exit.

4.

".

Editing Channel NAME

In memory-mode, press and hold

1.

(Available only in Memory mode)

FUNC

key

for over 2 seconds to enter setting menu.

Press P3 /

2.

P4

key to choose No.11

menu, LCD displays cursor and ashing.

Press / to select the desired letter, press P2 key

3.

to conrm selected letter and enter into next edition, press P1 to

return forward edition.

After edition, press

4.

FUNC

key to exit.

Busy Channel Lockout

18

BCLO is to disable transmitting while receiving. Once the channel is busy
and you press PTT, the radio will beep as warning and holds transmitting
until receiving signal is gone.

Press and hold

1.

FUNC

key for over 2

seconds to enter setting menu.

Press P3 /

2.

menu, LCD displays "

Press / to select the

3.

P4

key to choose No.10

LOCK--OFF

".

desired setting.

BU: Enable BCLO, Carrier lockout, transmitting is inhibited when



current channel receives a carrier.

RL: Enable BTLO, transmitting is inhibited when current channel



receives a carrier but dis-matching CTCSS/DCS.

In Frequnecy display (VFO)mode, this menu is not available.

Reverse TX/RX

This function is used to check if you can talk without using a repeater.
TX frequency turns to RX frequency & RX frequency changes to TX
frequency. CTCSS/DCS setting is respected also.

Press and hold

1.

Press P3 /

2.

menu, LCD displays "

Press / to select the

3.

desired setting.

ON:Enable Frequency Reverse

OFF:Disable Frequency Reverse.

Press any key except

4.

FUNC

key for over 2 seconds to enter setting menu.

P4

key to choose No.12

REV—OF

PWR

".

, P3, P4, , key to exit.

Talk Around

This is to talk simplex on the RX frequency of the duplex setting, in case
of repeater failure or out-of-range.
By Talk Around function, you can directly communicate with other radios
in your group in case the repeater is not activated or when you are out of
the repeater range. The transceiver will transmit on RX frequency with its
CTCSS/DCS signaling.

Press and hold

1.

FUNC

key for over 2

seconds to enter setting menu.

Press P3 /

2.

menu, LCD displays "

Press / to select the desired

3.

P4

key to choose No.13

TALK—OF

".

setting.

ON:Enable Talk Around

OFF:Disable Talk Around

Press any key except

4.

PWR

, P3, P4, , key to exit.

Radio's DTMF SELF ID ENQUIRY

Press and hold

1.

Press P3 /

2.

menu, LCD displays "

radio's DTMF SELF ID.

Press any key except

3.

FUNC

key for over 2 seconds to enter setting menu.

P4

key to choose No.14

D--XXX

". XXX is

PWR

, P3, P4, , key to exit.

Radio's 5TONE SELF ID ENQUIRY

Press and hold

1.

Press P3 /

2.

menu, LCD displays"

XXXXX

"

Press any key except

3.

FUNC

key for over 2s to enter setting menu.

P4

key to choose No.15

F--XXXXX

" is radio's 5TONE SELF ID.

PWR

, P3, P4, , key to exit.

" ,

FUNCTION MENU SETUP

7

beep sound

The beep provides conrmation of entry, error status or malfunctions of

the radio. You can enable or disable beep sounds.

Press and hold

1.

FUNC

key for over 2

seconds to enter setting menu.

Press P3 /

2.

menu, LCD displays "

Press / to select the

3.

P4

key to choose No.16

BEEP--ON

".

desired setting.

ON:Enable beep sounds.

OFF:Disable beep sounds.

Press any key except

4.

PWR

, P3, P4, , key to exit.

TOT (Time-out timer)

TOT prohibits the users from transmitting after a certain period of time
has elapsed. When the time is over, transmitting stops and automatically
returns to receiving. Until the PTT is released once and pressed again,
the radio will not transmit.

Press and hold

1.

Press P3 /

2.

Press / to select the

3.

desired timer setting.

Timer:1-30min,each level 1min

OFF: Disable TOT

Press any key except

4.

FUNC

key for over 2 seconds to enter setting menu.

P4

key to choose No.17 menu, LCD displays "

PWR

, P3, P4, , key to exit.

TOT--3

".

19

7

FUNCTION MENU SETUP

APO (Auto power off)

Once APO is activated, the radio will be automatically switched off when
the pre-set time is elapsed.

Press and hold key for over 2

1.

seconds to enter setting menu.

Press P3/

2.

menu, LCD displays "

Press / to select the

3.

desired setting.

30MIN:Auto power off after 30m

1HOUR:Auto power off after 1h

2HOUR:Auto power off after 2h

OFF:Disable Auto power off

20

Press any key except

4.

P4

key to choose No.18

APO--OFF

PWR

, P3, P4, , key to exit.

".

DTMF Transmitting Time

Press and hold

1.

seconds to enter setting menu.

Press P3/

2.

menu, LCD displays "

Press / to select the desired setting, in miliseconds.

3.

30/50/100/200/300/500, which indicates the time for sending each
DTMF signal & the interval between each DTMF being sent.

Press any key except

4.

FUNC

key for over 2

P4

key to choose No.19

SPD--50

".

PWR

, P3, P4, , key to exit.

Display iiiumination color setting

This is to select the display illumination color.

Press and hold

1.

Press P3/P4 key to choose No.20 menu, LCD displays "

2.

ORG

".

Press / to select the desired color. Display changes

3.

color while selection.

ORG:

Orange

SAK:

(Sakura) light pink

WHI:

White

OFF:

NO backlight

Press any key except

4.

FUNC

key for over 2 seconds to enter setting menu.

PWR

, P3, P4, , key to exit.

Scan resume Time Setup

There are 3 kinds of scan resume conditions.

Press and hold

1.

seconds to enter setting menu.

Press P3/P4 key to choose No.21

2.

menu, LCD displays "

Press / to select the

3.

desired Scan Resume Time.

TO: Timed Scan, it resumes scanning
after receiving 5 seconds or when the
signal is gone, which ever faster.

CO: Busy Scan, it resumes scanning when the receiving signal is
gone.

SE: Stops scanning when a signal is received.
Manual operation is necessary to resume scanning.

FUNC

key for over 2

SCAN--TO

".

COL--

8

Press any key except

4.

tone-burst tones

Press and hold

1.

Press P3/P4 key to choose No.22

2.

menu, LCD displays "

Press / to select the

3.

desired tone frequency. Available tones
are 1000,1450,1750 and 2100Hz.

Press any key except

4.

Display Mode Setup

There are 3 different display modes: Frequency+Memory mode, Memory
mode & Frequency mode + Memory mode.

Press and hold

1.

Press P3/P4 key to choose No.23 menu, LCD displays "

2.

FR

".

Press / to select the desired mode.

3.

FR:

Frequency mode+Memory mode.

CH:

Memory mode.

NM:

Frequency mode + Memory mode (if
it is named a name tag, name tag will be
shown).

Press any key except

4.

, key to exit.

PWR

, P3, P4, , key to exit.

FUNC

key for over 2 seconds to enter setting menu.

TB--1750

PWR

FUNC

key for over 2 seconds to enter setting menu.

".

, P3, P4, , key to exit.

PWR

, P3, P4,

DSP—

FUNCTION MENU SETUP

STARTING PASSWORD(

Enable this function, you have to insert a matching PASSWORD to enter
into normal status when radio is turned on.(The PASSWORD can be
assigend by programming software only.)

Press and hold

1.

seconds to enter setting menu.
Press P3/P4 key to choose No.24

2.

menu, LCD displays "

Press / to enable/disable

3.

PASSWORD setup.

ON: Turn on PASSWORD setup

OFF:Turn off PASSWORD setup

Press any key except

4.

Useless if PASSWORD is not assigned

FUNC

key for over 2

CODE-OF

PWR

".

, P3, P4, , key to exit.

7

)

Address list

You store desired ID and corresponding ID name in address list. The
LCD displays ID corresponding name if radio received ANI calling and

nd matching ID in address list.

Press and hold

1.

setting menu.

Press P3/P4 key to choose No.25

2.

menu, LCD displays "

Press P2 to enter into ID setting, press

3.

P3

/P4 to select the desired group

(00-127, total is 128 group ID). Press

/ to select desired number,

P3

press
next edition, press P4 return to forward
edition, press to clear out all digits.

confirm and move cursor to

FUNC

key for over 2 seconds to enter general

BOOK

".

21

7

4.

5.

6.

FUNCTION MENU SETUP

After finishing edition, press to confirm and enter into edition of
current group's ID corresponding name.Press / to
select desired letter, press P3 to move cursor to next edition,
press to clear out all letters. 00-127, total 128 group ID and
corresponding ID name.

Press P2 to confirm and return into main menu. Repeat above
Step 3 and Step 4 operations to edit multi-ID and corresponding ID
name.

FUNC

Press

key to return to standby status.

RESTORE(RESET)

If your radio seems to be malfunctioning, resetting the microprocessor
may solve the problem. When performing the reset, you may lose
memory data and stored information. Use PC software to save the
memory and setting data whenever you edit setting for this reset
purposes.

22

Press and hold

1.

seconds to enter general setting menu.

Press P3/P4 key to choose No.26

2.

menu, LCD displays "

Press / to select the

3.

desired operation.

FACT:Resume factory default for
channel, signaling and general setting.

SETUP:Return initial setup for No.16-No.24 general setting menu.

Press any key except

4.

FUNC

key for over 2

RESTORE

PWR

".

, P3, P4, , key to exit.

DOWN

PTT

Lock Switch

Following operatins are available using keypads on the EMS-74
microphone.

Keypad Lock

SLIDE the switch to lock position, The lamp is turned off and all keys
are locked except PTT.

Transmitting DTMF By Microphone KeyPAD

Slide DTMF key to DTMF position, press and hold the [PTT] key,
transmitting the desired DTMF signaling by the numeric key directly.

The keypad operation is suspended in DTMF position.
The transmitting tone doesn't sound from the mic or your radio.

UP

MIC

Numeric Keys

DTMF ON/OFF

Function Setup By Microphone Keypad

Squelch off

squelch is disabled when icon ashed
in LCD, Press again to enable squelch
and the icon disappears.

:In standby, press key, the

Microphone Operation

Switches between VFO and MEMORY mode

In standby, press key to switch between memory mode and
Frequency mode (VFO).

Short Calling

Press PTT switch and key to transmit the selected DTMF/
2TONE /5TONE in current channel.

Transmitting DTMF Code

In standby, press , LCD displays DTMF data and group. Press [

/ ] key to select the desired transmitting DTMF group,

then Press PTT to transmit.
If no DTMF data in current group, LCD displays "EMPTY", press

key again and input desired DTMF code by keypad, press PTT to
transmit and store DTMF data.

8

FREQUENCY STEP

Only in VFO mode, this function is valid.

1. Press , then press , LCD displays "

2. Press / to select the desired frequency channel step.

3. Press any numeric keys to save and exit.

Optional signaling

In standby, press , then press to add
optional signaling, repeat above operation to
set DTMF, 2TONE or 5TONE signaling.

D: DTMF

T: 2-tone

F: 5-tone

Press and hold [PTT] + [UP] to transmit Optional signal.

See P15 "RECEIVING DTMF, DTMF ANI, 2TONE OR 5TONE SIGNALING".

STP--10

".

23

8

Microphone Operation

This function can be temporarily used in memory mode. Once the
radio is turned off or switched to another channel, the temporary
setting will be erased and back to initial settings.

To exclude selected channels from memory scanning

Scan Skip

In memory mode, press then press , decimal point appears.
It means current channel is scan skip. Repeat above operation to set
scan or scan skip in current channel. Decimal point dissapears when the
channel is available for scanning.

(

Frequency/Channel scan

In corresponding mode, press then press key to start scanning.

24

In scanning mode, press / to change scan direction.

Press [PTT] to stop scanning.

Busy Channel Lockout

Refer to P.18 for details.

In standby, press , then press to enter into Busy Channel

1.

Lockout.
Same parameters BU/RL/OFF as explained in P.18 are available.

Press [ / ] to select the desired value.

2.

Press number keys to conrm and exit.

3.

Reverse TX/RX

Refer to P.18 for details.

In standby, press , then press , LCD displays “

1.

Press [ / ] to select the desired value.

2.

)

ON:Enable Frequency Reverse

OFF:Disable Frequency Reverse

Press number keys to conrm and exit.

3.

REV—OF

”.

TOT (Time-out timer)

Refer to P.19 for details.

In standby, press , then press LCD displays "

1.

Press [ / ] to select the desired value.

2.

Press number key to conrm and exit.

3.

TOT-X

".

CTCSS/DCS Encode and Decode

In standby, press , then press to enter into CTCSS/DCS

1.

Encode and Decode.

Repeat above operation to set as below:

2.

LCD displays icon, it indicates CTCSS encode set in current



channel.

LCD displays and icon, it indicates CTCSS encode and



decode set in current channel.

LCD displays



in current channel.

DCS

icon, it indicates DCS encode and decode set

In corresponding icon, press [ / ] to select the desired

3.

CTCSS/DCS encode and decode.

Press , , or to conrm and exit.

4.

Talk Around

Refer to P.19 for details.

In standby, press , then press key, LCD displays "

1.

OF

".

Press [ / ] to select the desired setting .

2.

ON:Enable Talk Around

OFF:Disable Talk Around

Press number key to conrm and exit.

3.

BEEP sound

Refer to P.19 for details.

In standby, press , then press , LCD displays "

1.

Press [ / ] to turn on/off BEEP prompt.

2.

BEEP—OF: turn off the beep;

BEEP—ON: turn on the beep.

Press number key to conrm and exit.

3.

BEEP--XX

TALK--

Microphone Operation

8

HIGH/MID/LOW Power Selection

In standby, press , then press , LCD displays "

1.

Press [ / ] to select the desired power.

2.

HI:High Power

MI:Middle Power

LOW:Low Power

Press number key to conrm and exit.

3.

POW-XX

".

LCD Backlight

In standby status, press , then press LCD displays "

1.

XX

" .

Press [ / ] to select desired backlight.

2.

ORG:Orange
SAK: Sakura (Blight Pink)
WHI:Whilt

”.

OFF:No backlight

Press number key to conrm and exit.

3.

COL-

25

9

This feature clones the programmed data and parameters in the master unit to slave units.

1.

2.

Cable Clone

An optional EDS-29 cloning cable and PC programming is necessary to activate cloning function to the master unit. Make a master unit by setting
and programming it as desired. Turn off both units. Connect the cable between the DATA jacks on both units.

Master unit: Press programmed CLONE function key (Program the Key by PC) or other way that press and hold Power(On)+ FUNC+ P2 key at the

same time to enter into cloning mode. LCD displays "

CLONE

".

26

Press master unit's [

3.

unit will restart. Turn off the power, disconnect the cable and repeat step 3 operations to clone the next slave unit.

This function is useful to clone many units in enviornment where PC is not available. This feature is popular to commercial land mobiles.

10

OPTIONAL ACCESSORIES

FUNC

] key, LCD displays "

CLONEXX

". Slave unit displays "

CLONEXXX

". When the cloning is successfully nished, the slave

- EDS-29 Clone cable

- ERW-12 PC cable

- EMS-74 Microphone (spare)

Key Function

The function of key combinations can be changed by PC software.
Below is the default setting.

Key
Combination

FUNC

P1

P2

P3

P4

Short press

"F" is indicated. Goes to setting menu --

V/M SCAN

MHz Frequency Offset

TS/DCS

CALL -- High/Middle/Low power

Hold for over 2
seconds

Power voltage
monitor

FUNC+

MW(Setting memory
channel data)

Deleting memory
channel

Keypad lockout

Maintenance

11

Trouble Shooting

Problem Possible Causes and Potential Solutions

(a)

Power is on, nothing

appears on Display.

(b)

Fuse is blown.

(c)

Display is too dim. Set the LCD backlight parameter properly.

(d)

No sound comes from

speaker.

(e)

Key and Dial do not

function.

(i)

Rotating Dial will not

change memory channel.

(g)

PTT key is pressed but

doesn't transmit.

Please contact your dealer when a technical assistance may be
necessary.

+ and - polarities of power connection are
reversed. Connect red lead to positive
terminal and black lead to negative terminal of
DC power supply.

Check and solve problem resulting in blown
fuse and replace fuse with a new one.

• Squelch level too high. Decrease squelch level.

• Selective-calling like TSQ activated. Press

Micro's key to monitor.

Key-lock function is activated. Cancel Key-lock
function.

Transceiver is in CALL mode. Press .

• Microphone connection is poor. Connect

microphone properly.

• Antenna connection is poor. Connect antenna

properly.

27

12

Frequency Range

Number of Channels

Channel Spacing

Channel step

Operating Voltage 13.8V DC ±15%

Squelch

Frequency Stability ±2.5ppm

Operating Temperature

Dimensions(WxHxD)

28

Weight about 0.910Kg

Specifications

TX : 222-225.9975MHz
RX : 220-259.9975MHz

200 channels

25KHz (Wide Band)
20KHz (Middle Band)

12.5KHz (Narrow band)

2.5KHz,5KHz, 6.25KHz, 8.33KHz, 10KHz,

12.5KHz, 15KHz, 20KHz, 25KHz, 30KHz, 50KHz

Carrier/CTCSS/DCS/5Tone/2Tone/DTMF

-20℃~+60

140(W)x35(H)x180(L)mm

Specications are subject to change without notice due to advancements in

technology.

General

℃

Receiver

Wide band Narrow band

Sensitivity
(12dB Sinad)
Adjacent Channel
Selectivity

Intermodulation ≥65dB ≥60dB

Spurious Rejection ≥70dB ≥70dB

Audio Response +1~-3dB(0.3~3KHz) +1~-3dB(0.3~2.55KHz)

Hum & Noise ≥45dB ≥40dB

Audio distortion ≤5%

Audio power output >2W@10%

Current drain (Max) < 0.6A

≤0.3μV ≤0.35μV

≥70dB ≥60dB

Transmitter

Wide band Narrow band

Power Output 50W/20W/10W

Current drain (Max) < 10A

Modulation 16KΦF3E 11KΦF3E

Adjacent Channel
Power

Hum & Noise ≥40dB ≥36dB

Spurious Emission ≥60dB ≥60dB

Audio Response +1~-3dB(0.3~3KHz) +1~-3dB(0.3~2.55KHz)

Audio Distortion ≤5%

≥68dB ≥60dB

51 groups CTCSS Tone Frequency(Hz) 1024 groups DCS Code

62.5 67.0 79.7 94.8 110.9 131.8 156.7 171.3 186.2 203.5

229.1 69.3 82.5 97.4 114.8 136.5 159.8 173.8 189.9 206.5

233.6 71.9 85.4 100.0 118.8 141.3 162.2 177.3 192.8 210.7

241.8 74.4 88.5 103.5 123.0 146.2 165.5 179.9 196.6 218.1

250.3 77.0 91.5 107.2 127.3 151.4 167.9 183.5 199.5 225.7

254.1

000 001 002 003 004 005 006 007

010 011 012 013 014 015 016 017

020 021 022 023 024 025 026 027

030 031 032 033 034 035 036 037

040 041 042 043 044 045 046 047

050 051 052 053 054 055 056 057

060 061 062 063 064 065 066 067

070 071 072 073 074 075 076 077

100 101 102 103 104 105 106 107

110 111 112 113 114 115 116 117

120 121 122 123 124 125 126 127

130 131 132 133 134 135 136 137

140 141 142 143 144 145 146 147

150 151 152 153 154 155 156 157

160 161 162 163 164 165 166 167

170 171 172 173 174 175 176 177

200 201 202 203 204 205 206 207

210 211 212 213 214 215 216 217

220 221 222 223 224 225 226 227

230 231 232 233 234 235 236 237

240 241 242 243 244 245 246 247

250 251 252 253 254 255 256 257

260 261 262 263 264 265 266 267

270 271 272 273 274 275 276 277

300 301 302 303 304 305 306 307

310 311 312 313 314 315 316 317

Appendix

13

29

14

320 321 322 323 324 325 326 327

330 331 332 333 334 335 336 337

340 341 342 343 344 345 346 347

350 351 352 353 354 355 356 357

360 361 362 363 364 365 366 367

370 371 372 373 374 375 376 377

400 401 402 403 404 405 406 407

410 411 412 413 414 415 416 417

420 421 422 423 424 425 426 427

430 431 432 433 434 435 436 437

440 441 442 443 444 445 446 447

450 451 452 453 454 455 456 457

460 461 462 463 464 465 466 467

470 471 472 473 474 475 476 477

500 501 502 503 504 505 506 507

30

510 511 512 513 514 515 516 517

520 521 522 523 524 525 526 527

530 531 532 533 534 535 536 537

540 541 542 543 544 545 546 547

550 551 552 553 554 555 556 557

560 561 562 563 564 565 566 567

570 571 572 573 574 575 576 577

600 601 602 603 604 605 606 607

610 611 612 613 614 615 616 617

620 621 622 623 624 625 626 627

630 631 632 633 634 635 636 637

640 641 642 643 644 645 646 347

650 651 652 653 654 655 656 657

660 661 662 663 664 665 666 667

670 671 672 673 674 675 676 677

Appendix

700 701 702 703 704 705 706 707

710 711 712 713 714 715 716 717

720 721 722 723 724 725 726 727

730 731 732 733 734 735 736 737

740 741 742 743 744 745 746 747

750 751 752 753 754 755 756 757

760 761 762 763 764 765 766 767

770 771 772 773 774 775 776 777

N

is positive code, I is negative code, total: 1024groups.

[MEMO]
