ALESIS DEQ230D User Manual
Reference Manual
This page intentionally left blank
10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
Table Of Contents
Introduction ..................................................................3
Welcome!......................................................................................................3
DEQ230 Key Features .................................................................... 4
How to Use This Manual................................................................ 5
Important Safety Instructions..................................7
Important Safety Instructions (English)................................... 7
Safety symbols used in this product.........................................................7
Please follow these precautions when using this product: ...................7
Instructions de Sécurité Importantes (French) ...................... 9
Symboles utilisés dans ce produit.............................................................9
Veuillez suivre ces précautions lors de l’utilisation de
l’appareil: ...................................................................................................... 9
Lesen Sie bitte die folgende Sicherheitshinweise
(German) ........................................................................................... 11
Sicherheit Symbole verwendet in diesem Produkt.................................11
Folgen Sie bitte diesen Vorkehrungen, wenn dieses
Produkt verwendet wird: ........................................................................... 11
CE Declaration Of Conformity..................................................... 13
FCC Compliance Statement ......................................................... 13
Chapter One: Quick Start Guide .............................. 15
If you can't wait to get started..................................................................15
Step 1: Hook it up to a mixer ........................................................ 15
Step 2: Try some equalization ...................................................... 16
Step 3: Store the Program............................................................. 16
Chapter Two: Connections ........................................19
Unpacking and Inspection............................................................ 19
Installing in a Rack ........................................................................ 19
Thermal Considerations in Rack Mounting ............................. 19
AC Power Hookup........................................................................... 20
To use the DEQ230 in another country: ................................................20
Connecting Inputs and Outputs .................................................. 21
Connecting to the Channel or Main Inserts of a mixing
console..........................................................................................................21
Connecting to the inserts on an instrument amplifier .......................... 23
Connecting to equipment with XLR inputs and outputs ..................... 23
Connecting to equipment with S/PDIF inputs and
outputs (DEQ230D only) ........................................................................... 23
About Audio Cables ........................................................................ 25
1
Chapter Three: Basics of Equalization...................27
What is equalization? ..................................................................... 27
Description of the Controls .......................................................... 28
Description of the Basic Modes ................................................... 29
Basic operation: Program mode .................................................. 31
Basic operation: Edit mode........................................................... 32
Table Of Contents
Basic operation: Store mode......................................................... 38
Channel Copy.............................................................................................. 39
Basic operation: Audition mode .................................................. 40
Basic operation: Channel Level mode........................................ 42
The "Hidden" Modes........................................................................ 43
Demonstration mode.................................................................................43
Real-time Analysis mode (DEQ230D only): ............................................ 43
Setup mode..................................................................................................44
Button combinations.................................................................................. 49
Equalization Artifacts.................................................................... 50
Constant Q vs. Variable Q ............................................................. 51
Chapter Four: Applications.......................................55
Filtering effects ............................................................................... 56
Chapter Five: Program Charts .................................59
DEQ230 Settings Chart .................................................................. 69
Chapter Six: Troubleshooting................................... 71
Restoring the Factory Programs & Defaults ............................ 71
Line Conditioners and Protectors .............................................. 71
Care and Maintenance................................................................... 71
Troubleshooting Index .............................................................................. 72
Specifications...................................................................75
Audio Performance .................................................................................... 75
Mechanical ................................................................................................... 75
2
Warranty/Contact Alesis ............................................77
Alesis Limited Warranty.............................................................................77
Alesis Contact Information....................................................................... 78
F
s
r
o
h
/
s
E
D
D
Introduction
Welcome!
Thank you for purchasing the Alesis DEQ230. It is a versatile
product, and whether it becomes a part of your studio or finds
its place in your live setup, we know it will serve you well. Since
1984, we've been designing and building creative tools for the
audio community. We believe in our products, because we've
heard the results that creative people like you achieve with them.
One of Alesis' goals is to make high-quality music technology
available to everyone. This Reference Manual is an important part
of that, because in it we try to present the DEQ230’s features in a
way that is easy to understand and remember. But even beyond
explaining each feature and parameter, this manual can be a key
that unlocks an application for the DEQ230 that you may not have
considered. So we try to write our manuals as carefully as we build
our products.
The goal of this manual is to get you the information you need as
quickly as possible, with a minimum of hassle. We hope we've
achieved that. If not, please drop us an email and give us your
suggestions on how we could improve future editions of this
manual.
We hope your investment will bring you many years of creative
enjoyment and help you achieve your goals.
Sincerely,
The people of Alesis
xcept as noted, when this
user guide refers to the
EQ230 we will be
referring to both the
EQ230 and the DEQ230D.
or more effective
ervice and product
update notices, please
egister your DEQ230
nline at:
ttp://www.alesis.com
upport/warranty.htm
3
Introduction
DEQ230 Key Features
1. Offers the best of digital technology and analog-style control:
a graphic display with instant editing of any band or
combination of bands, plus the ability to store programs
2. 60 programs total: 30 preset and 30 user-programmable
3. 48 KHz sampling rate, 24-bit A/D/A, 28-bit internal
processing
4. Two channels of equalization, independent or linkable
5. 30 EQ bands per channel, spanning 25 Hz-20 KHz in 1/3octave increments
6. +/- 12 dB boost/cut with center detente
7. Constant Q technology for finer control of audio
8. LOCK function for "set and forget" situations, which
prevents accidental reprogramming
9. AUDITION mode for automated program comparison
10. Individual Channel Level adjustment per program
11. Master Level adjustment
12. [LINK] button for quick creation of matched EQ curves
13. [BYPASS] button
14. Configurable editing modes to suit the way you work
15. Several methods of accelerated program selection
16. Ability to copy settings from Channel A to Channel B during
Store procedure
17. Easy-to-read 7-segment Numeric LED Display
18. Over 750 Band Gain LEDs, making it easy to read EQ curves
from a distance
19. SIGNAL and CLIP LEDs
20. Balanced input/impedance-balanced output (TRS)
21. Compact 1-space rackmount profile
DEQ230D only:
22. Real-time Analysis (RTA) mode for visual feedback of
incoming audio signal, with selectable metering modes
23. S/PDIF input/output, auto-senses incoming digital audio
24. Clock selectable between 44.1k and 48k sampling rates
25. MIDI in/out for program changes and sys-ex storage
26. Balanced input/output (TRS)
27. +4/-10 operating level switch (rear panel)
For full operating specifications, see page 75.
4
Introduction
H
How to Use This Manual
This manual is divided into the following sections describing the
various functions of and applications for the DEQ230. While it's a
good idea to read through the entire manual once carefully, those
having general knowledge about audio equipment should use the
table of contents to look up specific functions.
Chapter 1: Quick Start Guide. If you're already familiar with
equalization, this will get you started using the DEQ230 right away.
It's a short guide to the essential elements of hooking it up and
using it for the first time.
Chapter 2: Connections. This section gives detailed instructions for
connecting the DEQ230 to a variety of typical audio systems.
Chapter 3: Basics of Equalization. This section explains what an
equalizer does and explains the function of each of the controls.
Chapter 4: Applications. Skip to this section for tips on using the
DEQ230 in a variety of settings.
Chapter 5: Program Charts. Here you will find the names for all 60
Factory Programs, with a brief description of each and a small
graphic representation of the front panel settings.
Chapter 6: Troubleshooting. Near the end of the manual you will find
troubleshooting tips and a complete list of the DEQ230’s
specifications.
elpful tips and advice are
highlighted in a shaded box
like this.
The names of specific buttons
on the DEQ230 are printed in
a bold font and bracketed:
i.e., the [BYPASS] button.
When something important
appears in the manual, an
exclamation mark (like the
one shown at left) will appear
with some explanatory text.
This symbol indicates that
this information is vital when
operating the DEQ230.
5
Introduction
This page intentionally left blank
6
Important Safety
Instructions
Important Safety Instructions (English)
Safety symbols used in this product
operating and maintenance instructions in the literature
accompanying this unit.
the unit that can cause dangerous electric shocks.
voltages that can cause dangerous electrical shock.
Please follow these precautions when using
this product:
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a damp cloth. Do not spray any liquid cleaner
7. Install in accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat
9. Do not defeat the safety purpose of the polarized or
10. Protect the power cord from being walked on or pinched,
11. Use only attachments or accessories specified by the
This symbol alerts the user that there are important
This symbol warns the user of uninsulated voltage within
This symbol warns the user that output connectors contain
onto the faceplate, as this may damage the front panel controls
or cause a dangerous condition.
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding-type plug has two blades
and a third grounding prong. The wide blade or the third
prong are provided for your safety. When the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
manufacturer.
Continued next page
7
Important Safety Instructions
12. Use only with a cart, stand, bracket, or table designed for use
with professional audio or music equipment. In any
installation, make sure that injury or damage will not result
from cables pulling on the apparatus and its mounting. If a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as when the power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15. This unit produces heat when operated normally. Operate in a
well-ventilated area with at least six inches of clearance from
peripheral equipment.
16. This product, in combination with an amplifier and
headphones or speakers, may be capable of producing sound
levels that could cause permanent hearing loss. Do not operate
for a long period of time at a high volume level or at a level
that is uncomfortable. If you experience any hearing loss or
ringing in the ears, you should consult an audiologist.
17. Do not expose the apparatus to dripping or splashing. Do not
place objects filled with liquids (flower vases, soft drink cans,
coffee cups) on the apparatus.
18. WARNING: To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
8
Important Safety Instructions
Instructions de Sécurité Importantes (French)
Symboles utilisés dans ce produit
Ce symbole alèrte l’utilisateur qu’il existe des instructions
de fonctionnement et de maintenance dans la documentation
jointe avec ce produit.
Ce symbole avertit l’utilisateur de la présence d’une
tension non isolée à l’intérieur de l’appareil pouvant engendrer des
chocs électriques.
Ce symbole prévient l'utilisateur de la présence de tensions
sur les raccordements de sorties, représentant un risque
d'électrocution.
Veuillez suivre ces précautions lors de
l’utilisation de l’appareil:
1. Lisez ces instructions.
2. Gardez ces instructions.
3. Tenez compte de tous les avertissements.
4. Suivez toutes les instructions.
5. N’utilisez pas cet allareil à proximité de l’eau.
6. Ne nettoyez qu’avec un chiffon humide. Il est potentiellement
dangereux d'utiliser des pulvérisateurs ou nettoyants liquides
sur cet appareil.
7. Installez selon les recommandations du constructeur.
8. Ne pas installer à proximilé de sources de chaleur comme
radiateurs, cuisinière ou autre appareils (don’t les
amplificateurs) produisant de la chaleur.
9. Ne pas enlever la prise de terre du cordon secteur. Une prise
murale avec terre deux broches et une troisièrme reliée à la
terre. Cette dernière est présente pour votre sécurité. Si le
cordon secteur ne rentre pas dans la prise de courant,
demandez à un électricien qualifié de remplacer la prise.
10. Evitez de marcher sur le cordon secteur ou de le pincer, en
particulier au niveau de la prise, et aux endroits où il sor de
l’appareil.
11. N’utilisez que des accessoires spécifiés par le constructeur.
Suite de la page suivante
9
Important Safety Instructions
12. N’utilisez qu’avec un stand, ou table conçus pour l’utilisation
d’audio professionnel ou instruments de musique. Dans toute
installation, veillez de ne rien endommager à cause de câbles
qui tirent sur des appareils et leur support.
13. Débranchez l’appareil lors d’un orage ou lorsqu’il n’est pas
utilisé pendant longtemps.
14. Faites réparer par un personnel qualifié. Une réparation est
nécessaire lorsque l’appareil a été endommagé de quelque sorte
que ce soit, par exemple losrque le cordon secteur ou la prise
sont endommagés, si du liquide a coulé ou des objets se sont
introduits dans l’appareil, si celui-ci a été exposé à la pluie ou à
l’humidité, ne fonctionne pas normalement ou est tombé.
15. Puisque son fonctionement normale génère de la chaleur,
placez cet appareil au moins 15cm. des équipments
péripheriques et assurez que l’emplacement permet la
circulation de l’air.
16. Ce produit, utilisé avec un amplificateur et un casque ou des
enceintes, est capable de produite des niveaux sonores pouvant
engendrer une perte permanente de l’ouïe. Ne l’utilisez pas
pendant longtemps à un niveau sonore élevé ou à un niveau
non confortable. Si vous remarquez une perte de l’ouïe ou un
bourdonnement dans les oreilles, consultez un spécialiste.
17. N'exposez pas l'appareil à l'égoutture ou à l'éclaboussement.
Ne placez pas les objets remplis de liquides (vases à fleur,
boîtes de boisson non alcoolique, tasses de café) sur l'appareil.
18. AVERTISSEMENT: Pour réduire le risque du feu ou de
décharge électrique, n'exposez pas cet appareil à la pluie ou à
l'humidité.
10
Important Safety Instructions
Lesen Sie bitte die folgende Sicherheitshinweise (German)
Sicherheit Symbole verwendet in diesem
Produkt
Dieses Symbol alarmiert den Benutzer, daß es wichtige
Funktionieren und Wartung Anweisungen in der Literatur gibt, die
diese Maßeinheit begleitet.
Dieses Symbol warnt den Benutzer der nicht isolierten
Spannung innerhalb der Maßeinheit, die gefährliche elektrische
Schläge verursachen kann.
Dieses Symbol warnt den Benutzer, dem Ausgabestecker
Spannungen enthalten, die gefährlichen elektrischen Schlag
verursachen können.
Folgen Sie bitte diesen Vorkehrungen, wenn
dieses Produkt verwendet wird:
1. Lesen Sie die Hinweise.
2. Halten Sie sich an die Anleitung.
3. Beachten Sie alle Warnungen.
4. Beachten Sie alle Hinweise.
5. Bringen Sie das Gerät nie mit Wasser in Berührung.
6. Verwenden Sie zur Reinigung nur ein weiches Tuch.
Verwenden Sie keine flüssigen Reinigungsmittel. Dies kann
gefährliche Folgen haben.
7. Halten Sie sich beim Aufbau des Gerätes an die Angaben des
Herstellers.
8. Stellen Sie das Gerät nich in der Nähe von Heizkörpern,
Heizungsklappen oder anderen Wärmequellen (einschließlich
Verstärkern) auf.
9. Verfehlen Sie nicht den Zweck des grounging Terminals auf
dem Netzstecker. Dieses Terminal wird für Ihre Sicherheit zur
Verfügung gestellt.
10. Verlegen Sie das Netzkabel des Gerätes niemals so, daß man
darüber stolpern kann oder daß es gequetscht wird.
11. Benutzen Sie nur das vom Hersteller empfohlene Zubehör.
Fortsetzung auf nächster seite
11
Important Safety Instructions
12. Verwenden Sie ausschließlich Wagen, Ständer, oder Tische, die
speziell für professionelle Audio- und Musikinstrumente
geeignet sind. Achten Sie immer darauf, daß die jeweiligen
Geräte sicher installiert sind, um Schäden und Verletzungen zu
vermeiden. Wenn Sie einen Rollwagen benutzen, achten Sie
darauf, das dieser nicht umkippt, um Verletzungen
auszuschließen.
13. Ziehen Sie während eines Gewitters oder wenn Sie das Gerät
über einen längeren Zeitraum nicht benutzen den Netzstecher
aus der Steckdose.
14. Die Wartung sollte nur durch qualifiziertes Fachpersonal
erfolgen. Die Wartung wird notwendig, wenn das Gerät
beschädigt wurde oder aber das Stromkabel oder der Stecker,
Gegenstände oder Flüssigkeit in das Gerät gelangt sind, das
Gerät dem Regen oder Feuchtigkeit ausgesetzt war und
deshalb nicht mehr normal arbeitet oder heruntergefallen ist.
15. Dieses Gerät produziert auch im normalen Betrieb Wärme.
Achten Sie deshalb auf ausreichende Lüftung mit mindestens
15 cm Abstand von anderen Geräten.
16. Dieses Produkt kann in Verbindung mit einem Verstärker und
Kopfhörern oder Lautsprechern Lautstärkepegel erzeugen, die
anhaltende Gehörschäden verursachen. Betreiben Sie es nicht
über längere Zeit mit hoher Lautstärke oder einem Pegel, der
Ihnen unangenehm is. Wenn Sie ein Nachlassen des Gehörs
oder ein Klingeln in den Ohren feststellen, sollten Sie einen
Ohrenarzt aufsuchen.
17. Setzen Sie den Apparat nicht Bratenfett oder dem Spritzen
aus. Plazieren Sie die Nachrichten, die mit Flüssigkeiten
(gefüllt werden Blumevases, Getränkdosen, Kaffeetassen)
nicht auf den Apparat.
18. WARNING: um die Gefahr des Feuers oder des elektrischen
Schlages zu verringern, setzen Sie diesen Apparat nicht Regen
oder Feuchtigkeit aus.
12
Important Safety Instructions
CE Declaration Of Conformity
See our website at:
http://www.alesis.com
FCC Compliance Statement
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help.
13
Important Safety Instructions
This page intentionally left blank
14
I
p
p
A
1 Quick Start Guide
If you can't wait to get started
The Alesis DEQ230 is a unique product, but its basic hookup and
operation are similar to other equalizers in most respects. If you're
experienced with signal processors, this chapter is a “shorthand”
guide for those who want to start using the DEQ230 right away. If
you have questions about any of the features, don’t worry – we’ll
cover everything in greater detail in later chapters.
Step 1: Hook it up to a mixer
1. Plug the POWER jack on the back of the DEQ230 into a
grounded AC power source with the supplied power cable.
2. Using a pair of high-quality cables, plug the left and right main
outputs of a non-powered mixer into the CHAN A and
CHAN B INPUTs on the back of the DEQ230.
3. Connect another pair of cables to the CHAN A and CHAN
B OUTPUTs of the DEQ230 and plug them into your
amplification system or a pair of powered monitors.
4. Press the [POWER] switch on the front of the DEQ230 to
power up the unit.
5. If the LINK LED is not lit, you may want to press the
[LINK/EXIT] button on the front of the DEQ230.
That way you’ll hear the changes you make with Channel A
affect both channels of audio at once.
f you're new to signal
rocessing, start with the more
detailed instructions for
hookup and operation found in
the next cha
The DEQ230’s power will turn
on automatically once its AC
cable is plugged in, so be sure
to press the [POWER] switch
to turn the unit off while you’re
connecting it to your other
equipment.
When connecting the DEQ230
to other equipment, make sure
all gear has been turned off.
lso, to protect your speakers,
be certain your amplifier(s)
are turned all the way down
before turning your equipment
back on.
ter.
15
1 Quick Start Guide
R
p
P
Step 2: Try some equalization
Play some signal into the unit
While learning the unit, you should play a CD or a multitrack
source into the equalizer. Choose a song or musical passage with a
fairly consistent level, so you can take your time experimenting
with the different features.
1. Put the mixer’s main faders all the way down so you don’t
distort the unit by sending it too much signal.
2. Select program 00 on the DEQ230. The fastest way to do this
is to press the [DOWN] and [UP] buttons at the same time.
This will call up a program with all frequencies set to 0 dB,
which will allow you to hear the changes you make to the
audio more easily.
3. Begin playing your source material. Bring the mixer’s main
faders up gradually until the green LED over the word
SIGNAL begins to light up on each side. Carefully increase the
mixer’s output level until the green LEDs are lit most of the
time. If the red LEDs light up at all, back the mixer’s output
level down until they stop lighting up. This is important,
because the red LEDs indicate that the signal is clipping on
that channel.
4. Press one of the [BAND SELECT] buttons to select a
frequency. One of the LEDs above that button will begin to
blink.
5. Use the [DOWN] and [UP] buttons on either side of the
[POWER] switch to decrease or increase the chosen
frequency. If desired, select another frequency and repeat this
process.
6. Press the [BYPASS] button to hear the signal without the
equalization effect. Press it again to return to the EQ’d signal.
Step 3: Store the Program
Once you have created an interesting program, you can save it to
one of the 30 User program locations. Here’s how to do this:
1. Press the [STORE] button to enter Store mode.
2. Use the [DOWN/UP] buttons to select the new location for
the edited program. For your convenience, programs 55-59
have been left “blank” so you can store your editing
experiments somewhere without fear of overwriting a
program you might want to use later.
3. Press the [STORE] button again to store the program to the
new location.
For a detailed explanation on how to use this mode, see page 38.
emember: if one or both of the
red LEDs light up, that means
the signal is clipping. To
revent this, reduce the level
being sent to the proper
channel.
rograms 55-59 have been left
“blank” so you have places to
store your new programs right
away.
16
Quick Start Guide 1
17
1 Quick Start Guide
18
2 Connections
Unpacking and Inspection
Your DEQ230 was packed carefully at the factory. The shipping
carton was designed to protect the unit during transit. Please keep
this carton in the highly unlikely event that you need to return the
DEQ230 for servicing.
The shipping carton should contain the following items:
• DEQ230 with the same serial number as shown on shipping
carton
• A/C power supply adapter (DEQ230 only)
• A/C power cable (DEQ230D only)
• This instruction manual
Installing in a Rack
The DEQ230 may be simply set on a table, or installed in a
standard 19" audio equipment rack.
Thermal Considerations in Rack
Mounting
The DEQ230 can be mounted in an equipment rack (occupying
one rack space) or placed on a table or shelf. When you install it,
keep in mind that heat is the greatest enemy of electronic
equipment. Please observe the following:
• The DEQ230 is designed to perform properly over a range of
ambient temperatures from 10° C to +40° C (50° F to 104° F),
in up to 80% non-condensing humidity. These are not absolute
limits, but Alesis cannot guarantee that the DEQ230 will meet
its published specs or remain reliable if operated outside of
these ranges.
• Always allow adequate ventilation behind the DEQ230. Do not
seal any enclosure that holds this unit. It is not necessary to
leave an empty rack space above or below the DEQ230.
However, if your environment is unusually warm and not air
conditioned, space between units will help the units run cooler.
19
2 Connections
p
A
A
t
AC Power Hookup
The DEQ230D has what’s known as a “switching power supply.”
This means it will detect any standard line voltage from 90 to 230
volts, 50-60 Hz, and adapt itself to that. All you need is the proper
A/C cable for the country in which you find yourself. Just plug the
"female" end of the power cable into the DEQ230D’s POWER
receptacle and the “male” end into a good quality, noise-free A/C
power source.
The DEQ230 will work with any standard line voltage from 100 to
240 volts as long as the appropriate detachable power supply
adapter is used. The DEQ230 has been shipped with the suitable
adapter for the line voltage in your area.
Plug the "barrel" end of an approved power supply adapter into
the DEQ230’s POWER 9V AC jack and the transformer end into
a good quality, noise-free AC power source of the proper rating.
To use the DEQ230 in another country:
Your DEQ230 was supplied with the correct power supply adapter
for your country or local area. If you plan to travel with it to
another country, obtain an Alesis AC power supply adapter
compatible with the outlets used in the other country and use it in
place of the supplied adapter. These can be obtained through your
Alesis dealer or through the Alesis Parts department.
The DEQ230 is specifically
designed to be powered by
the power supply adapter we
have included. Do not
substitute any other type of
ower supply adapter. If a
replacement is needed, one
may be purchased from your
lesis dealer or from the
lesis Parts departmen
.
20
I
p
Connections 2
Connecting Inputs and Outputs
Connecting to the Channel or Main Inserts
of a mixing console
Unbalanced I/O
Most mixing consoles have insert jacks near the main outputs and
for each channel as well. These are typically Tip-Ring-Sleeve (TRS)
jacks with the send and return on the same jack. To use the
DEQ230 as an effects insert device, you will need an insert cable
(not included).
When connecting audio
cables and/or turning power
on and off, please make sure
that your amplifiers are
turned off or down to prevent
damage to your speakers.
This cable splits the TRS insert jack into two unbalanced mono
connectors. Usually, the tip is wired to the "Send" connector,
which plugs into one INPUT of the equalizer, and the ring is
wired to the "Return" connector, which plugs into the
corresponding OUTPUT of the equalizer. However, the wiring
of the insert jacks is different on some recording consoles, which
means that the input/output relationship may be reversed. Check
your mixer’s Reference Manual to be sure, or just try it both ways –
this won’t damage the DEQ230.
f your mixer does not have
insert jacks available at its
main outputs, simply connect
the main outputs of your non-
owered mixer to the inputs
of the DEQ230, then connect
the outputs of the equalizer to
the inputs of your mixdown
recorder or amplified
monitoring system.
21
2 Connections
f
M
p
L
p
N
p
Mono connections
This example shows how to connect the DEQ230 to one mono
source. You can use this method to connect two mono sources or
one stereo source to the DEQ230. You would need two insert
cables to make both of these connections.
Stereo connections
Use two insert cables to connect the DEQ230 to the main L/R
bus in the same way you would connect it to a pair of channel
inserts. Simply connect one insert cable to the left main insert of
the mixer, and connect the two mono jacks to the CHAN A
INPUT and OUTPUT of the DEQ230. Use another insert cable
to connect the right main insert to the CHAN B INPUT and
OUTPUT of the DEQ230.
You can also simply connect the balanced main outputs of the
mixer to the inputs of the DEQ230, then connect the outputs of
the equalizer to the inputs of your mixdown recorder, monitor
system, etc.
Balanced I/O
Some recording consoles have separate balanced jacks for the
sends and returns instead of a single TRS jack. If your recording
console has these connections, use a balanced TRS cable to
connect the insert send to the INPUT of the equalizer, and
another balanced TRS cable to connect the equalizer OUTPUT to
the insert return.
Operating Levels
The DEQ230D can operate in either a +4dBu or –10dBV setting.
A rear panel switch allows you to configure the unit to your audio
environment.
The DEQ230 is a “line level” device, which means that it operates
at a nominal level of –10dBV, with a maximum input level of
+8dBV. Some equipment operates at a nominal level of +4dBu,
and can run the signal up to +24dBu. To prevent clipping, reduce
the level being sent from this equipment.
If you are unsure about the nominal operating level of the
equipment to which you will be connecting the DEQ230, refer to
the Reference Manual for that equipment.
Since the DEQ230 has two
channels, A and B, you can
connect two independent
sources. For example, you
could use channel A to EQ
the rhythm guitar and
channel B to EQ the bass
guitar. Or use channel A on
the kick drum and channel B
or the snare drum.
ever place the equalizer
between the power amp and
the speakers, as the high-
owered levels created by
the power amp will damage
the DEQ230.
odern production values
sometimes lead to the heavy
use of compression during
the mastering process. When
rocessing CD audio, you
may find it necessary at
times to lower the Channel
evel of the active program
so as to avoid clipping the
output stage of the DEQ230.
This will allow additional
headroom for more
extensive equalization. See
g. 42 for details on the
Channel Level function.
22
Loading...
