AIXAM 19972004 |
101 |
|
400
Pièces détachées |
|
Accessoires Moteur |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
U55005 |
|
MOTEUR KUBOTA Z400L3 |
1 |
---> 743822 |
||
|
|
|
|
|
|
|
||
1 |
|
V00220 |
|
MOTEUR KUBOTA Z402B AIX.1 |
1 |
756 349 --> |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
1H002 |
|
LIAISON DROITE MOTEUR BOITE 400 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
3 |
|
1K004 |
|
SUPPORT MOTEUR AVANT 400/500 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
1H036 |
|
SUPPORT RADIATEUR 400 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
1F40 |
|
CROCHET RADIATEUR 400/500 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
6 |
|
1F43 |
|
PLOT RADIATEUR 50 SH |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7 |
|
1K006 |
|
SILENT BLOC MOTEUR 65SH TARAUDE |
2 |
|
-> VLGC 34VB000028650 |
|
|
|
|
|
|
|
|
|
|
7 |
|
1K006A |
|
SILENT-BLOC MOTEUR 45SH TARAUDE |
2 |
|
VLGC 34VB000028651-> |
|
|
|
|
|
|
|
|
|
|
8 |
|
1C37 |
|
DIABOLO M6 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
9 |
|
1K035 |
|
RAIDISSEUR RADIATEUR ARRIERE 400 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
10 |
|
1K058 |
|
VOLUTE DE RADIATEUR |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
11 |
|
1K059 |
|
PRISE D'AIR MOTEUR 400 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2 / 52
AIXAM 19972004 |
102 |
|
400
Pièces détachées |
|
Accessoires Moteur |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
1K019 |
|
PEDALE D'ACCELERATEUR FRANCE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
1K021 |
|
CABLE D'ACCELERATEUR 400 FRANCE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
|
1K022 |
|
ENTRETOISE LAITON PEDALE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
1K020 |
|
RESSORT TORSION PEDALIER |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
1K042 |
|
RENVOI ARRET DE GAINE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 3 / 52 |
19/01/2010 |
AIXAM 19972004 |
103 |
|
400
Pièces détachées |
|
Alimentation |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
1K010 |
|
RESERVOIR CARBURANT 15L |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
1K015 |
|
GOULOTTE + TUBULURE + EVENT |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
|
1K016 |
|
BOUCHON DE RESERVOIR A CLE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
1K012 |
|
JOINT DE JAUGE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
1K011 |
|
JAUGE A CARBURANT |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
6 |
|
1K013 |
|
ECROU DE JAUGE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
7 |
|
1K017 |
|
ENJOLIVEUR DE BOUCHON DE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
9 |
|
1K052 |
|
JOINT DE GOULOTTE (couvercle) |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
10 |
|
1K050 |
|
TUYAU RETOUR 2 PLACES L.1860 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
11 |
|
1K051 |
|
TUYAU ALIMENTATION 2 PLACES |
1 |
|
|
|
|
|
|
|
|
|
|
||
12 |
|
1A14 |
|
TUYAU GAS-OIL DIAMETRE 7/13 |
|
X |
||
|
|
|
|
|
|
|
||
13 |
|
1A25 |
|
TUYAU GAS-OIL DIAMETRE 5/10 |
|
X |
||
|
|
|
|
|
|
|
|
|
14 |
|
1D33 |
|
TE RETOUR CARBURANT |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
15 |
|
1B40 |
|
RACCORD BANJO DE M6 X 100 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
16 |
|
1K053 |
|
COLLIER |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
17 |
|
1K054 |
|
COLLIER |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
18 |
|
1K056 |
|
CROCHET TIGE FIXATION RESERVOIR |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
19 |
|
1K060 |
|
PASSE-FILS |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
20 |
|
1K063 |
|
PREFILTRE MOTEUR DIESEL |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 4 / 52 |
19/01/2010 |
AIXAM 19972004 |
104 |
|
400
Pièces détachées Echappement
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
1K007 |
|
COLLECTEUR D'ECHAPPEMENT 400 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
1AA032 |
|
FLEXIBLE ECHAPEMENT |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
|
1K030 |
|
LIGNE ARRIERE ECHAP. A / M < 4077 |
1 |
|
-> VLGC 34VB 000028650 |
|
|
|
|
|
|
|
|
|
|
3 |
|
1K030C |
|
SILENCIEUX ARR Z402 |
1 |
|
VLGC 34VB 000028651 -> |
|
|
|
|
|
|
|
|
|
|
4 |
|
1C37 |
|
DIABOLO M6 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
1H009 |
|
COLLIER |
|
X |
|
|
|
|
|
|
|
|
|
|
|
6 |
|
1S062 |
|
SILENCIEUX INTER TQM 2001 |
1 |
|
VLGC 34VB 000028651 -> |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7 |
|
1K037 |
|
ANNEAU D'ECHAPPEMENT ARR. REF |
1 |
|
VLGC 34VB 000028651 -> |
|
|
|
|
|
|
|
|
|
|
8 |
|
1K061 |
|
CROCHET SILENCIEUX ARR VSP |
1 |
|
VLGC 34VB 000028651 -> |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 5 / 52 |
19/01/2010 |
AIXAM 19972004 |
201 |
|
400
Pièces détachées |
|
Chauffage |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
2K007 |
|
CONDUIT DIFFUSEUR D'AIR |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
2K004 |
|
AERATEUR |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
|
2K001 |
|
VENTILATEUR |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
2K012 |
|
ROBINET DE CHAUFFAGE + JOINT |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
2K005 |
|
RADIATEUR DE CHAUFFAGE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
7 |
|
2B16 |
|
DURITE DE CHAUFFAGE LE METRE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
8 |
|
2K027 |
|
TIRETTE REPARTITION D'AIR |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
9 |
|
2K023 |
|
LEVIER DE CHAUFFAGE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
10 |
|
2K024 |
|
LEVIER D'ARRET DE GAINE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
11 |
|
2K003 |
|
VOLET CHAUFFAGE VEH97 + |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 6 / 52 |
19/01/2010 |
AIXAM 19972004 |
202 |
|
400
Pièces détachées |
|
Chauffage |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
2K029 |
|
BOUTON DE COMMANDE CHAUFFAGE |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
2K025 |
|
FACADE DE CHAUFFAGE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
|
2K026 |
|
SUPPORT FACADE CHAUFFAGE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
2K031 |
|
AXE COURT FACADE CHAUFFAGE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
2K032 |
|
AXE LONG FACADE CHAUFFAGE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
6 |
|
2K030 |
|
COMMUTATEUR DE VENTILATION |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
7 |
|
2K023 |
|
LEVIER DE CHAUFFAGE |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8 |
|
2K024 |
|
LEVIER D'ARRET DE GAINE |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
9 |
|
2K028 |
|
TIRETTE CHAUFFAGE ROBINET |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
10 |
|
2K027 |
|
TIRETTE REPARTITION D'AIR |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 7 / 52 |
19/01/2010 |
AIXAM 19972004 |
203 |
|
400
Pièces détachées |
|
Ventilateur |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
2K033 |
|
BUSE DE DEGIVRAGE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
2K034 |
|
BOITIER DE CHAUFFAGE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 8 / 52 |
19/01/2010 |
AIXAM 19972004 |
301 |
|
400
Pièces détachées |
|
Pont inverseur |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
3K001 |
|
PONT INVERSEUR 1:11 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
3A2 |
|
CLAVETTE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
|
3A11 |
|
ECROU NYLSTOP D12 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
3K034 |
|
PROTECTION COURROIE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
1K006 |
|
SILENT BLOC MOTEUR 65SH TARAUDE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
6 |
|
3A8 |
|
VIS M12X135 8/8 ZINGUEE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
7 |
|
3G007L |
|
ENTRETOISE ALU. D26/D12.5 LG11 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8 |
|
3A11 |
|
ECROU NYLSTOP D12 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
9 |
|
3D10 |
|
RONDELLE DIAM. 8 LARGE EPAIS. 3 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 9 / 52 |
19/01/2010 |
AIXAM 19972004 |
302 |
|
400
Pièces détachées |
|
Pont inverseur |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
3A17B |
|
FLEXIBLE DE COMPTEUR M12X100 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
3K014 |
|
CABLE INVERSEUR |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
|
3K015 |
|
SOUFFLET LEVIER INVERS.. |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
3K013 |
|
POMMEAU DE LEVIER INVERSEUR |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
3K012 |
|
LEVIER INVERSEUR |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
6 |
|
8K002 |
|
CONTACTEUR (RUPTEUR) |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 10 / 52 |
19/01/2010 |
AIXAM 19972004 |
303 |
|
400
Pièces détachées |
|
Pont inverseur |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
3AC1N |
|
JOINT SPI MODIF.BOITE |
1 |
|
Z 25 561 |
|
|
|
|
|
|
|
|
|
|
2 |
|
3AC16 |
|
ECROU |
8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
|
3AC13 |
|
RONDELLE |
8 |
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
3KC2 |
|
SELECTEUR |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
3AC3 |
|
CENTREUR |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
6 |
|
3AC4N |
|
ROULEMENT |
1 |
|
FAM 54 |
|
|
|
|
|
|
|
|
|
|
7 |
|
3AC5 |
|
ARBRE DE MARCHE ARRIERE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8 |
|
3KC20 |
|
ARBRE D'ENTREE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
9 |
|
3AC7 |
|
PIGNON MOBILE MARCHE ARRIERE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
10 |
|
3AC4 |
|
ROULEMENT |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
11 |
|
3AC9 |
|
MANCHON CRABOT |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
12 |
|
3AC10 |
|
CIRCLIPS |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
13 |
|
3AC11 |
|
PIGNON FIXE MARCHE ARRIERE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
14 |
|
3AC52 |
|
ENTRETOISE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
15 |
|
3AC45 |
|
ROULEMENT |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
16 |
|
3AC12 |
|
BOUCHON |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
17 |
|
3AC14 |
|
VIS |
8 |
|
|
|
|
|
|
|
|
|
|
|
|
18 |
|
3AC53 |
|
JOINT |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
19 |
|
3AC50 |
|
JOINT |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
20 |
|
3AC49 |
|
BRIDE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
21 |
|
3AC51 |
|
VIS |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
22 |
|
3AC48/31 |
|
PRISE COMPTEUR 1:11 NOUVEAU |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
23 |
|
3DC19 |
|
PIGNON 2ème REDUCTION 1:11 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 11 / 52 |
19/01/2010 |
|
|
AIXAM 19972004 |
303 |
|
|
|
|
||
|
|
|
400 |
|
|
3AC21 |
PIGNON 1ère REDUCTION |
1 |
|
24 |
|
|||
|
|
|
|
|
25 |
3AC10N |
CIRCLIPS |
1 |
|
|
|
|
|
|
26 |
3AC24 |
BOITIER |
1 |
|
|
|
|
|
|
27 |
3AC25 |
BILLE |
1 |
|
|
|
|
|
|
28 |
3AC26 |
RESSORT |
1 |
|
|
|
|
|
|
29 |
3AC1 |
JOINT SPI |
2 |
|
|
|
|
|
|
30 |
3KC29 |
DEMI-CARTER GAUCHE |
1 |
|
|
|
|
|
|
31 |
3AC30 |
RONDELLE |
2 |
|
|
|
|
|
|
32 |
3AC31 |
VIS DE NIVEAU |
2 |
|
|
|
|
|
|
33 |
3KC32 |
GUIDE D'ARBRE |
1 |
|
|
|
|
|
|
34 |
3AC33 |
ANNEAU |
1 |
|
|
|
|
|
|
35 |
3AC34 |
CIRCLIPS |
1 |
|
|
|
|
|
|
36 |
3KC35 |
LEVIER |
1 |
|
|
|
|
|
|
37 |
3KC36 |
RONDELLE |
1 |
|
|
|
|
|
|
38 |
3AC23 |
ECROU |
1 |
|
|
|
|
|
|
39 |
3RC54 |
DIFFERENTIEL COMPLET 1:11 |
1 |
|
|
|
|
|
|
40 |
3KC43 |
JOINT |
1 |
|
|
|
|
|
|
41 |
3KC46 |
DEMI-CARTER DROIT |
1 |
|
|
|
|
|
|
42 |
3AC21R |
RONDELLE POUR PIGNON N/M |
1 |
|
|
|
|
|
|
43 |
3AC47 |
VIS T.E. |
1 |
|
|
|
|
|
|
44 |
3KC1 |
RESSORT |
1 |
|
|
|
|
|
|
45 |
3AC4 |
ROULEMENT |
1 |
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 12 / 52 |
19/01/2010 |
AIXAM 19972004 |
304 |
|
400
Pièces détachées |
|
Pont inverseur |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
3GC38 |
|
COURONNE DE DIFFERENTIEL 1:11 NM |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
3GC39 |
|
DEMI-CORPS DIFFERENTIEL |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
|
3AC40 |
|
GOUPILLE |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
3GC41 |
|
SATELLITE NOUVEAU MODELE |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
3GC42 |
|
ARBRE DE SORTIE CLIPS N/M |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
6 |
|
3AC23 |
|
ECROU |
4 |
|
|
|
|
|
|
|
|
|
|
|
|
7 |
|
3GC17 |
|
VIS DE DIFFERENTIEL NOUVEAU |
4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 13 / 52 |
19/01/2010 |
AIXAM 19972004 |
305 |
|
400
Pièces détachées |
|
Variateur |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
3HP22 |
|
POULIE MOTRICE A540 TWIN |
1 |
|
-> VLGC 34VB 000027779 |
|
|
|
|
|
|
|
|
|
|
1 |
|
3KP22 |
|
POULIE MOTRICE 400 N/M |
1 |
|
VLGC 34VB 000027780 -> |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
3KP24 |
|
POULIE RECEPTRICE 400 |
1 |
|
-> VLGC 34VB 000027779 |
|
|
|
|
|
|
|
|
|
|
2 |
|
3WP24 |
|
POULIE RECEPTRICE |
1 |
|
VLGC 34VB 000027780 -> |
|
|
|
|
|
|
|
|
|
|
3 |
|
3HP23 |
|
COURROIE DOUBLE CRANTAGE MOT. |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
3BP13 |
|
VIS DE FIXATION M8 X 160 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
3W011 |
|
ECROU POULIE RECEPTRICE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 14 / 52 |
19/01/2010 |
AIXAM 19972004 |
306 |
|
400
Pièces détachées |
|
Variateur |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
3HP1 |
|
DEMI-POULIE FIXE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
3HP2 |
|
ROULEMENT POULIE MOTRICE N/M |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
|
3HP2A |
|
ENTRETOISE D'APPUI NOUVEAU |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
3FP4 |
|
RONDELLE 05 |
|
X |
|
|
|
|
|
|
|
|
|
|
|
5 |
|
3FP4B |
|
RONDELLE 0,25 |
|
X |
|
|
|
|
|
|
|
|
|
|
|
6 |
|
3FP5 |
|
DEMI-POULIE TWIN |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
7 |
|
3FP6 |
|
RESSORT (15 MM ) |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8 |
|
3FP7 |
|
MASSELOTTE 135 GRAMMES |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
9 |
|
3FP8 |
|
BLOC DROIT CONIQUE ROUGE |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
10 |
|
3FP9B |
|
PALIER INFERIEUR VARIATEUR N/M |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
11 |
|
3FP10 |
|
RESSORT PRINCIPAL |
1 |
|
-> VLGC 34VB 000027779 |
|
|
|
|
|
|
|
|
|
|
11 |
|
3KP10 |
|
RESSORT BLEU N/M |
1 |
|
VLGC 34VB 000027780 -> |
|
|
|
|
|
|
|
|
|
|
12 |
|
3FP11 |
|
ESPACEUR D'AJUSTEMENT épais. 1.2 |
|
X |
|
|
|
|
|
|
|
|
|
|
|
13 |
|
3FP11B |
|
ESPACEUR D'AJUSTEMENT épais. 0.6 |
|
X |
|
|
|
|
|
|
|
|
|
|
|
14 |
|
3FP12 |
|
PALIER SUPERIEUR VARIATEUR |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
15 |
|
3FP13 |
|
CIRCLIPS |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
16 |
|
3GP14A |
|
CALE DE DEBRAYAGE |
|
X |
|
|
|
|
|
|
|
|
|
|
|
17 |
|
3GP14B |
|
CALE DE DEBRAYAGE |
|
X |
|
|
|
|
|
|
|
|
|
|
|
18 |
|
3HP15 |
|
CAPUCHON DROIT 20MM |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
19 |
|
3HP16 |
|
RONDELLE EPAISSEUR DIAMETRE 20 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
20 |
|
3HP17 |
|
DEMI-ECROU M20 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 15 / 52 |
19/01/2010 |
AIXAM 19972004 |
307 |
|
400
Pièces détachées |
|
Variateur |
|
|
|
|
|
|
|
|
|
Rep |
|
Référence |
|
Désignation |
|
Qté |
|
Remarques |
1 |
|
3KP36 |
|
JOUE FIXE RECEPTRICE 400 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
2 |
|
3BP20 |
|
CLAVETTE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
|
3FP11 |
|
ESPACEUR D'AJUSTEMENT épais. 1.2 |
|
X |
|
|
|
|
|
|
|
|
|
|
|
4 |
|
3FP11B |
|
ESPACEUR D'AJUSTEMENT épais. 0.6 |
|
X |
|
|
|
|
|
|
|
|
|
|
|
5 |
|
3BP21 |
|
CIRCLIPS |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
6 |
|
3DP17 |
|
DEMI-POULIE MOBILE |
1 |
|
-> VLGC 34VB 000027779 |
|
|
|
|
|
|
|
|
|
|
6 |
|
3KP17 |
|
DEMI-POULIE MOBILE |
1 |
|
VLGC 34VB 000027780 -> |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7 |
|
3FP26 |
|
SABOT NYLON NOUVEAU MODELE |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
8 |
|
3DP18 |
|
RESSORT JAUNE |
1 |
|
-> VLGC 34VB 000027779 |
|
|
|
|
|
|
|
|
|
|
8 |
|
3CP18 |
|
RESSORT GRIS |
1 |
|
VLGC 34VB 000027780 -> |
|
|
|
|
|
|
|
|
|
|
9 |
|
3BP19 |
|
CAME FIXE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
10 |
|
3FP30 |
|
VIS DE REGLAGE RECEPTRICE |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AIXAM-MEGA |
Page 16 / 52 |
19/01/2010 |
Loading...
