Pocket DV 5100M
Do not drop, puncture or disassemble
1.
the camera; otherwise the warranty will
be voided.
Avoid all contact with water and dry
2.
hands before using.
3.
Do not expose the camera to high
temperature or leave it in direct sunlight.
Doing so may damage the camera.
Use the camera with care. Avoid
4.
pressing hard on the camera body.
For your own safety, avoid using the
5.
camera when there is a storm or
lightning.
Avoid using batteries of different brands
6.
or types at the same time.
Remove batteries during long periods
7.
between usage, as deteriorated
batteries may affect the functionality of
the camera.
8.
Remove batteries if they show signs of
leaking or distortion.
9.
We suggest using only the accessories
supplied by the manufacturer.
1
2
3
4
5
6
7
8
9
Contents
Getting Started
1. Your camera parts
2. Loading the battery
3. Inserting and removing the CF card (optional)
Inserting the card
Removing the card
4. How to hold your camera
5. Attaching the strap
6. Using the tripod
Basic Operation
1. Switching on and off
2. Setting the language
3. The LCD display information
4. Recording movies
5. Taking still pictures
6. Recording audio clips
7. Playing your pictures, movies and audio clips
Playback mode
Viewing your pictures
Playing your movies and audio clips
Deleting your files
8. Using the self-timer
4
4
5
6
6
6
7
7
8
9
9
10
11
12
13
14
15
15
16
17
19
20
1
9. Real-time display on TV
21
Advanced Settings
1. Settings menu access
2. Settings menu events
Enjoying your Images and Audio Clips
on the Computer
1. Installing DV 5100M driver
2. Connecting your camera to your computer
3. Copying images and audio clips to your computer
4. Playing on your computer
Using the PC Camera Function
1. Installing DV 5100M driver
2. Connecting your camera to your computer
3. Capturing immediate images to your computer
4. Advanced settings
Troubleshooting
Other Information
22
22
23
25
25
28
29
31
32
32
33
35
37
40
42
1. Storage capacity
42
2
2. Battery indicator
3. Conserving battery power
4. More on flicker
5. Specifications
43
43
44
45
3
Getting Started
1. Your camera parts
Knowing your camera parts well before using it will assist you
greatly in camera operation.
1
20
21
11
CF card eject switch
12
Viewfinder
13
LCD display
14
Focus switch
15
Lens
16
Microphone
17
Self-portrait mirror
18
Battery cover
19
Tripod port
20
Speaker
21
Strap hook
10
11
12
13
1
Shutter button
2
Record button
3
Up button (Zoom in)
4
Down button (Zoom out)
MENU/OK button
5
(Power button)
USB port
6
Card slot (with cover)
7
A/V out connector
8
9
LED indicator
10
LCD on/off switch
9 8
2
3
4
5
6
7
14
15
16
17
18
19
4
2. Loading the battery
Please use two AA batteries.
Slide the battery cover in the
direction of indication to open it.
1
Follow the indication to load
batteries into the battery section
2
with + and - ends correctly
installed.
Slide the battery cover in the
direction of indication to lock it.
3
1. We recommend you to use rechargeable 1.2V Ni-MH batteries to
increase the time of usage.
2. 1.5V alkaline batteries are also recommended for high performance.
1
2
3
Get tin g Started
5
3. Inserting and removing the CF card
Label side
Back side
(optional)
1
Inserting the card
First lift and slide the cover open. Then
insert the card in the direction of
indication and push it in till the end of the
card slot.
2
Removing the card
Lift and slide the cover open. Then push
the Eject switch in the direction of
indication to remove the card.
To confirm if the card is inserted firmly:
If successfully inserting a memory card while the camera is powered
on, a beep will emit and the icon will appear at the top right section
of the LCD display.
The camera comes with flash memory built inside for storage. If you do not
insert a CF card, the data will be automatically saved in the built-in flash
memory.
6
4. How to hold your camera
Please hold the camera as the following illustration indicates.
Avoid blocking the lens or the microphone to retain better
image/sound recordings.
Get tin g Started
Avoid blocking the
lens.
5. Attaching the strap
For convenience and safety, you may wish to attach the
carrying strap.
Thread the strap loop through the
hook in the direction of indication.
1
Fasten the strap loop as indicated.
2
1
2
Avoid hindering the
microphone.
7
6. Using the tripod
Use the tripod to minimize camera movement and ensure
optimal image quality, particularly while taking self-portraits or
having a video conference.
Attach the tripod to the port on the
bottom of the camera and rotate
1
the serrated wheel to lock it.
Unfold the legs to set up. Pull
upward the handle and adjust the
2
alignment to the desired position.
Then pull downward the handle to
lock.
1
2
Handle
Serrated
wheel
8
Basic Operation
USB
MENU
OK
1. Switching on and off
1
Switching on
Open the LCD panel as indicated or
press and hold down the MENU/OK
button for 3 seconds to switch the
camera on.
2
Switching off
Close the LCD panel as indicated or
press and hold down the MENU/OK
button for 3 seconds to switch the
camera off.
If the camera stays idle for over 60 seconds, the LCD display will be
turned off to conserve battery power. Pressing any key will awake the
camera. If you do not operate the camera for over 3 minutes, it will shut
down automatically.
If the LCD panel is closed during recording or video/audio playback, the camera
!
will not stop working unless you manually terminate the recording or playback.
90
Basic Operation
o
OR
9
2. Setting the language
Press : Exit
Menu
Exit
Playback
Record Audi o
Self Tim er
English
Settings
Language
Flicker
Display
Default
Settings
Exit
Vid eo
Beep
Exit
When you switch the camera on for the first time, the LCD
display may not show messages in your local language. You can
set the LCD display language by using the method below.
1
2
3
10
Menu mode
Press the MENU/OK button to
enter the MENU.
Settings mode
Use the Up or Down button to
highlight the Settings_ item.
Then press the MENU/OK button
to confirm.
Select language
Use the Up or Down button to
highlight the Language_ item.
Then press the MENU/OK button
to confirm.
Use the Up or Down button to
highlight the desired language.
Then press the MENU/OK button
to confirm.
Press the Record button to exit.
1
3. The LCD display information
1
2
3
4
Still picture/ video mode
1
2
Zoom ratio
3
Self-timer mode
4
Video resolution
Storage media
5
1.0 X1.0 X
2626
Internal memory:
CF card:
6
Number of pictures, video clips and audio clips
7
Picture resolution
Battery life
8
5
6
Basic Operation
7
8
11
USB
MENU
OK
VIDEO
Zoom out
Zoom in
4. Recording movies
Switch on
1
Open the LCD panel to switch the
camera on.
Focus
2
Adjust the Focus switch to set the
focus as appropriate.
12"~16" (30cm~40cm)
Macro
16"~ (40cm~ )
Micro
Start recording
3
Press the Record button to start
recording. The counter on the
screen will start counting.
Zoom in or zoom out
4
Press the Up button to zoom in or
the Down button to zoom out.
Stop recording
5
Press the Record button again to
stop recording.
1
o
90
12
5. Taking still pictures
USB
MENU
OK
VIDEO
Zoom out
Zoom in
Switch on
1
Open the LCD panel to switch the
camera on.
Focus
2
Push the Focus switch to set the
mode best for your picture.
12"~16" (30cm~40cm)
Macro
16"~ (40cm~ )
Micro
Zoom in or zoom out
3
Press the Up button to zoom in or
the Down button to zoom out.
Take a still
4
Press the Shutter button to take a
still picture.
1
o
90
Basic Operation
13
USB
MENU
OK
6. Recording audio clips
USB
MENU
OK
Press : Start
Menu
Exit
Playback
Record Audi o
Self Tim er
Switch on
1
Open the LCD panel to switch the
camera on.
Record audio mode
2
Press the MENU/OK button to
enter the MENU. Use the Up or
Down button to highlight the
Record Audio_ item.
Start recording
3
Then press the MENU/OK button
to start recording. The counter on
the screen will start counting.
Stop recording
4
Press the MENU/OK button again
to stop recording.
1
o
90
14
7. Playing your pictures, movies and
Press : Start
4/154/15
Press : Enter
Menu
Exit
Playback
Record Audi o
Self Tim er
audio clips
1
Playback mode
1
2
3
Switch on
Open the LCD panel to switch the
camera on.
Playback mode
Press the MENU/OK button to
enter the MENU. Use the Up or
Down button to highlight the
Playback_ item. Then press
the MENU/OK button to enter the
playback mode.
Select images
You are now in the thumbnail
mode. Press the Up button to
select the previous image or the
Down button to select the next
one. The selected file will be
highlighted.
There are three file types that you can identify by the icon at the top left
section of the thumbnails.
: pictures
: video clips
: audio clips
1
o
90
Thumbnail view
Basic Operation
15
2
4/154/15
USB
MENU
OK
VIDEO
To thumbnail
mode
Exit
USB
MENU
OK
Play
Viewing your pictures
View a picture
1
(Continuing page 15) Once you
select the target file with a icon,
press the MENU/OK button to
view the full-screen file.
Exit
2
Press the MENU/OK button to
return to thumbnail view or press
the Record button to exit.
1
Full-screen view
2
In the full-screen mode, you can use the Up and Down buttons to
shift between files.
16
5/155/15
00: 00:0300: 00:03
5/155/15
00: 00:0400: 00:04
USB
MENU
OK
VIDEO
Volume down
Volume up
3
12/ 1512/ 15
00: 00:0600: 00:06
00: 00:4200: 00:42
IMG -0012 .WAVIMG -0012 .WAV
USB
MENU
OK
Play
USB
MENU
OK
Play
Playing your movies and audio clips
Play
1
(Continuing page 15) Once you
select the target file with a
(video) or (audio) icon, press
the MENU/OK button to play the
file.
Adjust the volume
2
While playing a recording, use the
Up or Down button to increase or
decrease the volume.
1
The video clip is played.
The audio clip is played.
2
The volume controller will
appear at the right side while
adjusting the volume.
Basic Operation
17
Stop playing
USB
MENU
OK
VIDEO
Stop playing
Pause/resume
USB
MENU
OK
VIDEO
To thumbnail
mode
Exit
3
While playing back a recording,
you can press the MENU/OK
button to stop playing.
3
18
Pause and resume
4
While playing a recording, you can
press the Video button to pause.
Press the Video button again to
resume.
Exit
4
When a recording finishes or stops
playing, press the MENU/OK
button to return to thumbnail view
or press the Record button to
exit.
Once the playback is stopped, you can use the Up and Down buttons
to shift between files.
4
USB
MENU
OK
VIDEO
Exit
Press : Delete
4/154/15
Delete
Deleting your files
Delete
1
(Continuing page 15) Once you
select the target file, press the
Shutter button to delete. Then
press the Shutter button again to
confirm the deletion.
Exit
2
Press the Record button to exit.
1
Basic Operation
2
As in the step 1. above, if you do not wish to delete the file, press any
button except the Shutter button to cancel the deletion.
19
8. Using the self-timer
CF CARD
USB
MENU
OK
VIDEO
1.0X1.0X
2626
Press : Exit
Menu
Exit
Playback
Record Audi o
Self Tim er
Press : Select
Menu
Exit
Playback
Record Audi o
Self Tim er
The self-timer allows a delay of ten seconds before the shutter
fires when taking a self-portrait picture or a movie.
1
2
3
20
Menu mode
Press the MENU/OK button to
enter the MENU.
Set self-timer on
Use the Up or Down button to
highlight the Self Timer_ item.
Then press the MENU/OK button
to set self-timer on. You will see a
icon at the bottom left section
of the LCD display.
Use the self-timer
When the Shutter button is
pressed (the Record button is
functional as well with the selftimer enabled), the camera will
have ten seconds delay before
taking a picture. After the shutter
fires, the self-timer will be
automatically disabled.
As in the step 2. above, if you want to cancel the setting of self-timer,
you can press the MENU/OK button twice to disable.
1
9. Real-time display on TV
Connect your camera and TV via an AV cable for real-time
display. By previewing the camera display on the TV screen,
your can share the video clips, still pictures and audio recordings
with your family or friends.
Set TV to AV mode
1
Turn on your TV and switch to the AV mode.
Connect your camera to TV
2
Insert the video and audio ends of the AV cable to the AV-in
port on your TV.
Insert the other end of the AV cable to the TV-out port on
your camera.
Turn on your camera
3
A/V-Mode
Video Audio
If the TV screen displays noises after the camera is connected, check if
the TV system (PAL / NTSC) is set appropriate. (Please refer to the "TV
system" section on page 23.)
Basic Operation
21
Advanced Settings
Press : Exit
Menu
Exit
Playback
Record Audi o
Self Tim er
Settings
Exit
Vid eo
Beep
Exit
Settings
Exit
Vid eo
Beep
320X240
USB
MENU
OK
VIDEO
Select
Confirm
Exit
1. Settings menu access
The Settings menu provides more advanced features for you to
fine-tune the camera. The following describes how to access the
Settings menu.
1
2
3
22
Menu mode
Press the MENU/OK button to
enter the MENU.
Settings mode
Use the Up or Down button to
highlight the Settings_ item.
Then press the MENU/OK button
to confirm.
Adjust the settings
Use the Up or Down button to
highlight the desired item. Then
press the MENU/OK button to
enter the sub-menu.
1
2. Settings menu events
The Settings menu allows you to set some elemental functions
of the camera. The following table provides detailed descriptions
of the settings items.
Settings
Video
Beep
TV
system
Items
640x480
352x288
320x240
160x128
2560x1920
2304x1728
2048x1536
1600x1200
640x480
On
Off
PAL
NTSC
Descriptions
High quality for viewing on TV.
Standard quality and suitable for viewing on TV.
High quality for network transmission or email.
Standard quality for network transmission or email.
The most memory-demanding option. Ideal for
developing 6x9 or 6x8 photos.
Suitable for developing 6x8 photos or smaller.
Suitable for developing 5x7 photos or smaller.
The default setting. Suitable for developing
4x6 photos or smaller.
The most memory-saving option. Suitable for
viewing on the computer or email.
This item determines whether the camera
speaker beeps when operating the camera.
This item is related to viewing images on your
television. Set the proper TV type to prevent
television display problems. The default option
depends on your country. PAL is for European
countries, China, Hong Kong, etc; NTSC is for
America, Japan, Taiwan, Korea, etc.
Advanced Settings
23
Language
This item allows you to set the usage of language on the LCD
display. For details on the setting, see page 10.
Flicker
Display
Default
Delete
All
Format
50 Hz
60 Hz
On
Off
Yes
Yes
Yes
If you travel to another country, the flicker
setting may not suit the place you are staying.
This item allows you to set the flicker to
prevent noises from occurring on your image.
The default flicker value depends on your
country. For details, please refer to the "More
on flicker" section on page 44.
This item determines whether the OSD icons for
illustration would appear on the LCD screen.
This item restores the factory defaults. Note
that your current non-default settings will be
overridden.
This item allows you to quick-erase all files in
the memory card or internal memory.
This item allows you to format the storage and
thus erase all files in the card or internal
memory. All files will be gone forever once you
execute the format item.
*The storage medium icon on the LCD
displays as below:
Internal memory CF card -
To format the files in the card, please insert
the card. To format the files in the internal
memory, please remove the card.
24
Enjoying your Images and Audio Clips on the Computer
1. Installing DV 5100M driver
You need to install DV 5100M driver before connecting your
camera to the computer to ensure that video clips can be played
back on your computer. Please follow the steps to complete the
installation.
Turn on your computer.
1
Do not connect the USB cable to your computer at this stage.
!
Turn off other applications running on your computer.
!
Place the supplied CD into the CD-ROM drive.
2
Upon seeing the autorun title screen, move the cursor over
the icon (DV 5100M Driver) and click it.
3
If no title appears on the screen, please
take the following measures:
1. Double click the "My computer" icon.
2. Double-click the CD-ROM drive icon (DV 5100M driver (E:)*). The
name of CD-ROM drive may change depending on your computer
settings.
3. Browse to the "\DV 5100M driver" folder and start the Setup.exe
program manually.
Enjoying your Images and Audio Clips on the Computer
25
The "Install Shield Wizard" dialogue box appears and the
automatic installation takes place. When a window as Fig 1
4
appears, click "Next". Then follow the on-screen instructions to
continue.
Fig 1
Notice for Windows 2000 users
1. The "Digital Signature Not Found" dialogue box may appear
twice. Please simply click "Yes". The camera is fully compatible
with Windows 2000.
2. Follow the on-screen instructions and click "Finish".
26
Do not restart your computer at this stage.
!
After the driver installation is complete, the program will prompt
you to install Windows Media Player Codecs. If you are not
5
sure whether the codecs have been installed in your computer,
please click "Yes" and follow the on-screen instructions to
complete the installation.
Fig 2
After the codec installation is complete, the program will prompt
you to install Direct X 8.0 or above. If you are not sure whether
6
this program has been installed in your computer, please click
"Yes" to continue.
Fig 3
After the installation is finished, you may need to restart your
computer for the driver to take effect.
7
Windows Media Player Codecs and Direct X 8.0 or above are
necessary for viewing the video clips recorded by the camera.
Enjoying your Images and Audio Clips on the Computer
27
2. Connecting your camera to your computer
Turn on your computer.
1
Insert the USB cable to the USB port on your computer.
2
Insert the other end of the USB cable to the USB port on your
camera.
3
Set your camera to the Disk Mode_ item. Then press the
MENU/OK button to confirm.
4
28
Dis k Mode
Dis k Mode
Liv e Mode
Pre ss : Sele ct
3. Copying images and audio clips to your
computer
For Windows XP users
1
After connecting your camera to the computer, a window will
automatically appear (as Fig 4). Select the "Open folder to
view files using Windows Explorer" item and then click
"OK".
11
Enjoying your Images and Audio Clips on the Computer
Fig 4
For Windows 2000/ME/98SE users
Double-click "My Computer", and then double-click the new
"Removable Disk" icon.
11
Some users may find two removable disks appear in "My Computer".
That is because the OS detects two storage media in the camera (the
internal memory and the CF card). If you cannot find your files in one of
the disks, try to find them in the other disk.
22
22
29
Double-click the "DCIM" file folder.
2
Double-click the "100MEDIA" file folder.
3
Drag the file to "My Documents" to copy your image or audio
clip to the computer.
4
30
For Windows XP users
The storage position of the files
You can find the files of your pictures, movies and audio clips in
the illustrated folder (as Fig 5).
Fig 5
For Windows
2000/ME/98SE users
4. Playing on your computer
Double-click "My Documents".
1
For Windows XP users
Select the desired file and double-click it to view.
2
Notice for Windows 2000/ME users on how to
disconnect the camera from the computer:
To disconnect your camera from the computer, please follow these
steps.
1. Double-click on the task bar.
2. Click (USB Disk), then click "Stop".
3. Select the camera (DV 5100M) on the confirmation screen and
then click "OK".
4. Follow the on-screen instructions to safely disconnect the camera
from your computer.
For Windows
2000/ME/98SE users
Enjoying your Images and Audio Clips on the Computer
31
Using the PC Camera Function
1. Installing the DV 5100M driver
You need to install the DV 5100M driver before using PC
Camera or video conferencing function.
32
If you never install DV 5100M driver, please finish the installation first.
For details, please see step 1. "Installing DV 5100M driver" on page 25.
If you have already installed DV 5100M driver, please go to step 2.
"Connecting your camera to your computer" on the next page.
2. Connecting your camera to your computer
Turn on your computer.
1
Insert the USB cable to the USB port on your computer.
2
Insert the other end of the USB cable to the USB port on your
camera.
3
Set your camera to the Live Mode_ item. Then press the
MENU/OK button to confirm.
4
Liv e Mode
Dis k Mode
Liv e Mode
Pre ss : Sele ct
Using the PC Camera Function
33
Notice for Windows 2000/ME/98SE users
During the first-time installation process, please take note of the
followings according to your operation system:
For Windows 2000 users
The "Digital Signature Not Found" dialogue box may appear
twice or more. Please click "Yes" to continue. This camera is fully
compatible with Windows 2000 system.
For Windows ME users
Please select "Automatic search for a better driver" when a
window as Fig 6 appears.
For Windows 98SE users
Click "Next" when a window as Fig 7 appears.
Select "Search for a best driver for your device" and click
"Next" when a window as Fig 8 appears.
Select the position where your Windows 98SE CD-ROM drive is.
Then follow the on-screen instructions to complete the
installation.
34
Fig 6 Fig 7 Fig 8
3. Capturing immediate images to your
computer
After installing the driver and connecting the camera to your PC,
you are now ready to use the PC Camera function or run other
video conferencing applications. (This manual provides
information related to PC Camera function only.)
Launch the software
1
Double-click the icon on the desktop to execute the
program. (If you cannot find the program shortcut on the
desktop, please click the "Start" menu and go to "Programs".
Then go to the folder named "DV 5100M" and click the program
item to launch the software.)
PC Camera interface
2
The windows below is the interface of DV 5100M.
Using the PC Camera Function
35
Capture immediate images
3
Press the buttons on the PC Camera panel to use the functions.
7
8 9
6
5
4
3
2
1
Start recording
1
2
Stop recording
Snapshot
3
4
Format *
Source *
5
* indicates that sub-menu is available.
6
Start / Stop preview window
Setting *
7
Open album
8
Select video source
9
36
Viewing your pictures and movies with PC
Camera program
Please click the (Open album) button on the PC Camera panel,
or go to the following path to find the files.
C:\Program Files\DV 5100M\Work Temp
4. Advanced settings
Click the (Format), (Properties) and (Setting)
buttons to bring up the advanced settings.
Format settings
Color Space/Compression
1
Set one of the following functions according to your needs.
RGB 24: Better image quality.
I420: The file will be compressed to take advantage of faster
transmission.
Output Size
2
Set output size to change the size of the preview window. The
default size is 320x240. Select larger pixels when you need a
larger preview window.
Using the PC Camera Function
11
22
37
Properties settings
Video Setting
1
1
11
Banding Filter
If the screen of your computer flickers when using PC Camera
function, change the "Banding Filter" item on the "Video Setting"
tab to avoid noise. Select "50Hz" or "60Hz" until the screen stops
flickering.
11
11 22
22
Bandwidth
If the controller does not have enough bandwidth available for the
camera, set the "Bandwidth" item on the "Video Setting" tab. The
smaller the bandwidth value is, the less the bandwidth is
occupied, which means more time is required for transmitting
images.
Custom Setting
2
You can use the default settings or change the settings of
brightness, contrast, saturation, sharpness, and hue on your
own.
22
38
Flicker setting
If you take your camera abroad, and find the screen of your
computer flickers when using PC Camera function, please select
the "Cancel Flicker" check box to prevent noises from appearing
on the screen. Or, you can refer to the Flicker Settings Table (p.
44) for proper flicker value that suits the country you are staying.
Using the PC Camera Function
39
Troubleshooting
Question
When using the camera
The camera has no power.
Cannot power on my
camera even though
batteries are installed.
The camera is powered on,
but the LCD panel does not
display.
Cannot take pictures and
movies when pressing the
Record / Shutter button.
I did not delete the picture
and movie, but cannot find
the data in the CF card.
Answer
The batteries may be out of power, please
change the batteries.
Make sure that the batteries are installed
correctly.
If the camera is idle for over 3 minutes, it
will shut down automatically. Please
switch the camera on. (p. 9)
Make sure that the LCD on/off switch is
set to on.
If the camera is idle for over 60 seconds,
the LCD display will be turned off. Please
press any button to reactivate the display.
The storage is full. Please free some
space from the CF card or internal
memory.
If the "MEMORY ERROR" or "CARD
ERROR" message appears on the LCD,
please set the camera to the Settings
mode and format the storage medium.
Check if your files are stored in the
camera's internal memory. If you insert a
card, the camera will use the card as the
main storage medium and files previously
stored in the internal memory will become
inaccessible until the card is removed.
40
The image is too blurred.
Adjust the focus.
Keep the camera steady while pressing
the Shutter button.
Noise occurs on my camera
when viewing the image on
the LCD display or on the
computer.
The TV screen does not
display after connecting the
camera to the TV.
Set the filter matching the place you are
staying. Please refer to the "More on flicker"
section on page 44.
Check if the camera is correctly
connected to the TV.
Make sure the TV system is correctly set
in the camera settings. Please see page
21 for more details.
When connecting the camera to your computer
The driver installation failed.
A conflict with other
installed camera or capture
device.
The movie cannot be
played on my computer.
Noise occurs on my
computer when using video
conferencing.
Please remove the driver and other
related programs. Follow the installation
steps in this manual to reinstall.
Install the driver before inserting the USB
cable.
If you have any other camera or capture
device, please disconnect the device and
remove its driver from the computer to
avoid a driver conflict.
Please install DirectX 8.1 or above and
Windows Media 9.0 Codecs to solve this
problem. (See the "Installing DV 5100M
driver" section on page 25 or go to
http://microsoft.com to download the
required files.)
Set the filter matching the place you are
staying. Please refer to the "Banding Filter"
section on page 38.
Tro ubl esh oot ing
41
Other Information
1. Storage capacity
Memory
Still picture (pic.)
Flash memory (13MB)
CF card (32MB)
CF card (64MB)
CF card (128MB)
CF card (256MB)
CF card (512MB)
12
30
60
120
240
480
Video clip (min.)
140
280
560
18
160
320
640
35
40
80
80
160
320
640
1280
15
35
70
Memory
Flash memory (13MB)
CF card (32MB)
CF card (64MB)
CF card (128MB)
CF card (256MB)
CF card (512MB)
Notes:
1. Actual value of storage capacity may vary (up to + 30%) depending on
1-1.5
2-3
4-6
8-12
16-24
32-48
2-3
4-6
8-12
16-24
32-48
64-96
the resolution and color saturation.
2-3
4-6
8-12
16-24
32-48
64-96
10-15
20-30
40-60
80-120
160-240
320-480
-
2. The table above is for reference only.
140
320
640
1280
2560
5120
Audio clip
Maximum
18 mins
40 mins
80 mins
160 mins
320 mins
640 mins
42
2. Battery indicator
Icons
*Please replace batteries immediately when the icon indicates that the battery
power is depleted.
Meanings
Full battery life.
Adequate battery life.
Low battery life.
Empty battery life.
3. Conserving battery power
If the camera stays idle over 60 seconds, the LCD display will be
turned off automatically to conserve power. In addition, you can
manually set the LCD on/off switch to off to conserve battery
power.
LCD on/off switch
On
Off
Oth er In formation
43
4. More on flicker
The default flicker setting of your camera depends on your
country. When using the camera abroad, please refer to the
table below to match the flicker setting with the place you go.
44
Country
Setting
Country
Setting
England
50Hz
Portugal
50Hz
Germany
50Hz
America
France
Taiwan
Italy
50Hz 50Hz60Hz
China
50Hz60Hz60Hz
Spain
50Hz
Japan
50/60Hz
Netherlands
Korea
60Hz
5. Specifications
Hardware resolution
Sensor effective resolution
Internal memory
External memory
Digital still camera
Digital video camcorder
Digital voice reocrder
Video conferencing VGA (640x480 pixels) / up to 10 fps
LCD display
Digital zoom
Exposure
White balance
Lens
Self Timer
Interface
Power saving
Built-in microphone / speaker
TV-out
Battery
Dimension
2560x1920 (5 Mega pixels)
2048x1536 (3 Mega pixels)
Built-in 16 MB flash memory (13 MB flash memory for
storage)
Built-in CF slot (maximum: 512 MB)
JPEG (.JPG) Format.
2560x1920 (5 Mega pixels); 2304x1728 (4 Mega pixels);
2048x1536 (3 Mega pixels); 1600x1200 (2 Mega pixels);
640x480 (VGA)
MPEG4 (.ASF) Format.
TV-HQ: VGA (640x480 pixels) / up to 11 fps;
TV-S: CIF (352x288 pixels) / up to 30 fps;
Web-HQ: QVGA (320x240 pixels) / up to 30 fps;
Web-S: 160x128 pixels / up to 30 fps.
WAVE (.WAV) Format.
QVGA (320x240 pixels) / up to 20 fps
1.5" Color TFT LCD
4x
Auto
Auto
F=3.0 / 8.7mm
10 seconds
USB 1.1 (USB 2.0 compatible)
Auto power-off if idle for over 3 minutes
Auto suspense if idle for over 1 minute
Yes
Support NTSC and PAL TV systems
AAx2 (Alkaline or rechargeable Ni-MH batteries recommended)
83x78x41 mm
Oth er In formation
45
82-400-90020v1.0
Loading...
