Analog Telephone
Analog Push-button Telephones for Ericsson MX-ONE™ and Ericsson MD110
User Guide
Cover Page Graphic
Place the graphic directly on the page, do not care about
putting it in the text flow. Select Graphics > Properties
and make the following settings:
• Width: 15,4 cm (Important!)
• Height: 11,2 cm (May be smaller)
• Top: 5,3 cm (Important!)
• Left: -0,3 cm (Important!)
This text should then be hidden.
?
Title
EN/LZT 103 77 R2A
© Copyright Ericsson AB 2007. All rights reserved.
Table of Contents
page
Welcome ..........................................................4
Description ....................................................... 6
Free Seating (optional) ...................................... 9
Incoming Calls ............................................... 10
Outgoing Calls ............................................... 12
During Calls ....................................................24
Call Forwarding .............................................. 27
Absence Information (optional) ....................... 38
Messages ......................................................40
Group Features .............................................. 45
Other Useful Features ..................................... 47
Glossary ......................................................... 52
Index .............................................................. 53
Tab le of Co nt en ts
3Analog Telephone
Welcome
Welcome
Welcome to the user guide for any type of analog push-button
phone used with Ericsson MX-ONE™ or Ericsson MD110.
Some markets use differing codes for some functions. In this guide,
all functions are described using the most common code. The
markets and their differing code is shown as a side note.
The user guide describes the facilities of the system functions as
they are programmed at delivery from the factory. There may be
some differences in the way your phone is programmed. Please
consult your system administrator if you need further information.
The latest version of this user guide can be downloaded from:
http://www.ericsson.com/enterprise/
Analog Telephone4
Welcome
Copyright
All rights reserved. No parts of this publication may be reproduced,
stored in retrieval systems, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording or
otherwise, without prior written permission of the publisher except
in accordance with the following terms.
When this publication is made available on Ericsson media,
Ericsson gives its consent to downloading and printing copies of
the content provided in this file only for private use and not for
redistribution. No parts of this publication may be subject to
alteration, modification or commercial use. Ericsson will not be
liable for any damages arising from use of an illegal modified or
altered publication.
Warranty
ERICSSON MAKES NO WARRANTY OF ANY KIND WITH
REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. Ericsson shall not be
liable for errors contained herein nor for incidental or consequential
damages in connection with the furnishing, performance or use of
this material.
5Analog Telephone
Description
Description
This guide describes how you via any type of analog phone, can
use the functions in Ericsson MD110 or Ericsson MX-ONE™.
Functions are controlled by use of the keypad (keys 0-9,
and the R key.
Note: For functions built-in to your phone, see the user
guide supplied with your phone.
* and #)
Analog Telephone6
Tones and signals
The following different tones and signals are sent from the
exchange to your phone.
Tone characteristics
The tones shown in this section are the most used tones
worldwide. Many markets use a differing tone for one or more
situations.
Dial tone
Special dial tone
Ringing tone or queue tone every 4 seconds
Busy tone
Congestion tone
Number unobtainable tone
Description
Call waiting tone
Intrusion tone
Conference tone every 15 seconds (to all parties)
Verification tone
Warning tone, expensive route
7Analog Telephone
Description
Internal ring signal
External ring signal
Recall signal
(Callback reminder)
Ring signals
Three different ring signals inform you about the type of the
incoming call. The signals shown in this section are the most used
signals worldwide. Many markets use signals that are adapted for
the local standards. If you get a signal that is not described or you
cannot identify, ask your system administrator.
Analog Telephone8
Free Seating (optional)
The Free Seating function is used for persons who have an office
extension number but no phone set of their own. For example,
flexible office workers, persons mostly working outside the office,
etc. As a Free Seating user and working from the office, you logon
to any free phone set that temporarily will be assigned with your
extension number and your system authorities.
To log on
u Lift the handset.
*11* Dial.
Free Seating (optional)
z* Enter the authorization code and press.
z# Enter your phone number and press.
d Replace the handset to finish the procedure.
The display shows your phone number.
Note: An earlier version of the Free Seating function uses
another procedure: To log on, dial
To log off
* 1 0 * extension No. #.
u Lift the handset.
#11# Dial.
d Replace the handset to finish the procedure.
Note: An earlier version of the Free Seating function uses
another procedure: To log off, dial
# 1 0 #.
9Analog Telephone
Incoming Calls
Incoming Calls
A ring signal indicates an incoming internal or external call.
Answer calls
u Lift the handset.
On another extension
You can answer a call to another extension from any phone in your
office.
uz Lift the handset and call the ringing extension.
You re c e i v e b u s y t o ne.
8 Press.
Note: France, press
4; Sweden, press 6
Analog Telephone10
Incoming Calls
Answer a second call
A call waiting tone will inform you, during a conversation, that a
second call is waiting on your phone. You have two options.
Option 1:
Finish the ongoing call:
d Replace the handset.
The new call will be signalled on your phone.
u Lift the handset to receive the new call.
Option 2:
Ask your conversation partner to wait:
Rd Press and replace the handset.
The waiting call will be signalled on your phone.
u Lift the handset to receive the new call.
After finishing the new call:
d Replace the handset.
Your first call will be signalled on your phone.
u Lift the handset to receive the first call again.
11Analog Telephone
Outgoing Calls
Outgoing Calls
Make calls
How to make internal and external calls.
u Lift the handset and dial either:
z An extension number to make an internal call.
Or:
0z The digit or digits to get an external line and the external
number.
Note: Which digit to press for external call access,
depends on the configuration of the system.
d Replace the handset to end the call.
Notes:
You can make your calls faster, using Common Speed
Dialing numbers and by programming your own Speed
Dialing numbers, see section “Speed Dialing” on page 18.
If you receive a queue tone when the digit or digits to get an
external line are dialed (optional function Least Cost Routing
is used in the system), keep waiting.
Once a line becomes free, you will receive a dial tone.
If a warning tone is heard, the selected line is marked
“Expensive”.
Analog Telephone12
Number presentation restriction
If you do not want your name and number to be displayed to the
person you are calling, you can use the following procedure.
Notes:
This function is only available in newer versions of the
exchange, and it might be blocked for use on your
extension (programmed by your system administrator).
The number presentation restriction is only valid for the
ongoing call, i.e. the procedure has to be repeated the next
time you want to use it.
u Lift the handset.
*42# Dial and wait for a new dial tone.
Outgoing Calls
z Dial the number.
Your name and number is not indicated on the called person´s
display.
Individual External Line
To make a call on a specific external line:
u Lift the handset.
*0* Dial.
z# Dial the individual external line number and press.
z Dial the digit or digits to get an external line and the external
number.
13Analog Telephone
Outgoing Calls
Last External Number Redial
When you initiate an external call the system automatically stores all
the dialed digits, irrespective of whether the call was successful or
not.
u Lift the handset.
*** Press to redial the last dialed external number.
Note: Finland and Sweden, dial
When you receive a busy tone
If you call an extension and receive a busy tone or get no answer or
all external lines are busy you can use these methods:
Callback
If a called extension is busy or there is no answer:
* * 0
6 Press.
Note: France, Finland and Sweden, press
d Replace the handset to finish procedure.
You are called back (recall ring signal) when the ongoing call is
finished or the next time a new call is finished. You have to answer
within eight seconds, otherwise the Callback service is cancelled.
u Lift the handset when you are called back.
The system calls the extension.
Note: Callbacks can be activated on several extensions at
the same time.
5
Analog Telephone14
If all external lines are busy (after dialing the digit or digits to get a
line):
6 Press.
Outgoing Calls
Note: France, Finland and Sweden, press
z# Dial the external number and press.
d Replace the handset to finish procedure.
When an external line becomes free, you will be called back (recall
ring signal). You have to answer within eight seconds, otherwise the
Callback service is cancelled.
u Lift the handset when you are called back.
The system calls the external number.
Note: Only one Callback can be activated on a busy
external line.
Cancel any single Callback
u Lift the handset.
#37* z Dial and enter the extension number.
Note: To cancel a single Callback on a specific external line,
dial the digit or digits to get a line instead of the extension
number.
#d Press and replace the handset.
Cancel all Callbacks
5
u Lift the handset.
#37# Dial.
d Replace the handset.
15Analog Telephone
Outgoing Calls
Activate Call Waiting
If you urgently wish to contact a busy extension or external line, you
can notify it by a Call Waiting signal.
5 Press.
Note: France and Finland, press
Keep handset off hook. When the called extension or the external
line becomes free, it will be called automatically.
Notes:
The Call Waiting function might be blocked for use on your
extension (programmed by your system administrator).
If Call Waiting is not allowed you will continue to receive a
busy tone.
Intrusion on a busy extension
You can intrude on an ongoing call on a busy extension.
6; Sweden, press 4
4 Press.
Note: France and Sweden, press
Before the Intrusion is executed, a warning tone is sent to the
parties in the ongoing call. A three party call is established and a
warning tone is heard.
Notes:
The warning tone might be disabled for your system.
The Intrusion function might be blocked for use on your
extension (programmed by your system administrator).
If Intrusion is not allowed, you will continue to receive a busy
tone.
8
Analog Telephone16
Intrusion on a busy external line
You can intrude on an ongoing call on a busy external line.
*44* z Dial and enter the individual external line number.
Outgoing Calls
#z Press and dial the digit or digits to get an external line.
Busy tone.
4 Press.
Note: France and Sweden, press
Before the Intrusion is executed, a warning tone is sent to the
parties in the ongoing call. A three party call is established and a
warning tone is heard.
Notes:
The warning tone might be disabled for your system.
The Intrusion function might be blocked for use on your
extension (programmed by your system administrator).
If Intrusion is not allowed you will continue to receive a busy
tone.
Bypass
If this function is allowed from your extension, you can bypass an;
activated Diversion, activated Follow-me or activated Absence
information on a specific extension.
8
u Lift the handset.
*60* z Dial and enter the extension number.
# Press and wait for answer.
17Analog Telephone
Outgoing Calls
Speed Dialing
Common Speed Dialing numbers
By using common Speed Dialing numbers, you can make calls
simply by pressing a few keys. The common Speed Dialing
numbers consist of 1–5 digits and are stored in the exchange (by your
system administrator).
uz Lift the handset and dial the common Speed Dialing number.
Individual Speed Dialing numbers
You can program up to ten frequently used phone numbers on the
digit keys 0–9 and use them as individual Speed Dialing numbers (if
this function is allowed).
Note: In Finland, up to nine numbers, keys 1–9.
To u s e :
u Lift the handset.
** ( 0— 9) Dial and press the relevant digit.
Note: Finland, dial
* * ( 1 — 9 ); Sweden, dial ( 0 — 9 ) #.
Analog Telephone18
To program and alter individual Speed Dialing numbers:
u Lift the handset.
*51* ( 0— 9) Dial and press the selected digit.
Outgoing Calls
Note: Finland, dial
* 5 1 * ( 1 — 9 ).
*z Press and dial the phone number.
The digit or digits to get an external line, must be added before
external phone numbers.
#d Press and replace the handset.
Note: The programmed number may consist of a
maximum of 20 digits plus
dial tone from the public network.
To erase one programmed number:
u Lift the handset.
#51* ( 0— 9) Dial and press the selected digit.
Note: Finland, dial
# 5 1 * ( 1 — 9 )
#d Press and replace the handset.
To erase all programmed numbers:
u Lift the handset.
#51# Dial.
*, which indicates the second
d Replace the handset.
19Analog Telephone
Outgoing Calls
Authority
Data privacy
Data privacy allows you to make a call without any disturbances,
i.e. Intrusion. This function is automatically cancelled when the call
is finished.
To o r d e r :
u Lift the handset.
*41# z Dial and enter the number.
Do not disturb, DND
When you activate DND, calls to your extension are not indicated.
Outgoing calls can be made as usual.
*27# Dial to activate.
Special dial tone.
or
#27# Dial to deactivate.
d Replace the handset to finish activation/deactivation.
Analog Telephone20
Authorization code, common (optional)
If you are assigned to use a common authorization code (1 to 7
digits) you can temporarily change any used phone within the
exchange to the authority level connected to this code. You can
use the code for one call only or you can open the phone to some
calls and lock it when leaving the phone.
To use for a single call:
u Lift the handset.
*72* Dial.
Outgoing Calls
z# Enter authorization code and press.
Verification tone.
z Dial the digit or digits to get an external line and the external
number.
To open an extension for some calls:
u Lift the handset.
#73* Dial.
z# Enter authorization code and press.
Verification tone.
To lock an extension:
u Lift the handset.
*73* Dial.
z# Enter authorization code and press.
Verification tone.
21Analog Telephone
Outgoing Calls
Authorization code, individual (optional)
If you are assigned to an individual authorization code (1 to 7 digits,
affiliated to your own extension) you can lock your own extension to
a common authority level, e.g. when out of the office. You can also
temporarily change any other used phone within the exchange to
the same authority level as you have on your own phone. The
individual code can be changed from your own extension.
To lock your phone:
u Lift the handset.
*76* Dial.
z# Enter authorization code and press.
Verification tone.
To make calls with your authority level when your phone is locked:
u Lift the handset.
*75* Dial.
z# Enter authorization code and press.
Verification tone.
z Dial the digit or digits to get an external line and the external
number.
To open your phone:
u Lift the handset.
#76* Dial.
z# Enter authorization code and press.
Verification tone.
Analog Telephone22
To assign your own authority level to another phone:
u Lift the handset.
*75* Dial.
Outgoing Calls
z* Enter authorization code and press.
Verification tone.
z# Dial your own extension number and press.
Verification tone.
z Dial the digit or digits to get an external line and the external
number.
To change your individual authorization code:
u Lift the handset.
*74* Dial.
z* Enter old authorization code and press.
z# Enter new authorization code and press.
Verification tone.
23Analog Telephone
During Calls
During Calls
Inquiry
You have an ongoing conversation and you would like to make an
Inquiry to an internal or external party.
R Press.
Dial tone. The first call is put on hold.
z Call the third party.
When the other party answers, you can switch between the calls
(Refer back), Transfer the call, create a Conference or end one of
the calls.
2 Press to return to the first call.
Note: Sweden, press
Refer Back
R
2 Press to Refer back to the other party.
The party you talk to is put on hold, the other party is connected.
Note: Sweden, press
R
Analog Telephone24
Transfer
You want to transfer an ongoing call.
R Press.
Dial tone.
During Calls
z Call the third party.
You can transfer the call before answer or wait for answer.
d Replace the handset.
The ongoing call is transferred.
Note: If you have put more than one call on hold, the last
call that was put on hold will be transferred. If the dialed
extension is busy or Transfer is not allowed, your phone will
ring again.
Call Waiting
If you hear the Call Waiting tone during an ongoing conversation,
another person is trying to contact you.
To terminate the ongoing call and answer the waiting call:
d Replace the handset to finish the ongoing call.
The waiting call is signalled on your phone.
u Lift the handset to answer the new call.
Note: The Call Waiting function might be blocked for use on
your extension (programmed by your system
administrator).
25Analog Telephone
During Calls
Conference
With this procedure you can include up to seven parties in a
conference. Only the conference leader can admit participants.
During the conference, a tone will be heard every 15 seconds.
Note: The conference tone might be disabled for your
system.
You have an ongoing conversation and want to establish a phone
conference. You will become the conference leader.
R Press.
z Call the third party.
Wait for answer.
3 Press to establish a conference.
Repeat the procedure to include other persons to the
conference.
d Replace the handset to leave the conference.
On hold
You can temporarily put the ongoing call on hold. Calls put on hold
can be resumed on your own or another phone.
Rd Press and replace the handset.
To resume the call on your own extension:
u Lift the handset.
To resume the call on another extension:
u Lift the handset.
z Call the extension where the call was put on hold.
8 Press.
Note: France, press
4; Sweden, press 6
Analog Telephone26
Call Forwarding
Call Forwarding
Diversion
If you do not want to be disturbed or will be out of the office, you
can have all calls to your extension diverted to a preprogrammed
answering position. During Diversion you will hear a special dial
tone. You can still make calls as usual.
Diversion can be direct, on no answer, on busy or to another
information service facility.
Order Direct Diversion from your own extension
The call is diverted to an individual position or up to three predetermined common answering positions (depending on the type
of the incoming call). Programmed by your system administrator.
u Lift the handset.
*21# Dial.
Note: U.K., dial
d Replace the handset.
Note: Diversion can also be ordered and cancelled from
the answering position, use the same procedure as in
section “Internal Follow-me” on page 30.
* 2 #
27Analog Telephone
Call Forwarding
Cancel Direct Diversion from your own extension
u Lift the handset.
#21# Dial.
Note: U.K., dial
d Replace the handset.
Note: Diversion can also be ordered and cancelled from
the answering position, use the same procedure as in
section “Internal Follow-me” on page 30.
Diversion when there is no answer
u Lift the handset.
*211# Dial to order.
Note: Finland and Norway, dial
d Replace the handset.
The incoming call is diverted after 3 signals.
To cancel:
u Lift the handset.
#211# Dial to cancel.
Note: Finland and Norway, dial
d Replace the handset.
# 2 #
* 6 1 #
# 6 1 #
Analog Telephone28
Diversion when caller receives a busy tone
u Lift the handset.
*212# Dial to order.
Call Forwarding
Note: Finland and Norway, dial
d Replace the handset.
To cancel:
u Lift the handset.
#212# Dial to cancel.
Note: Finland and Norway, dial
d Replace the handset.
Diversion to another information service facility
u Lift the handset.
*218# Dial to order.
d Replace the handset.
To cancel:
u Lift the handset.
#218# Dial to cancel.
d Replace the handset.
* 6 7 #
# 6 7 #
29Analog Telephone
Call Forwarding
Internal Follow-me
All calls to your extension are diverted to another extension of your
choice (within the private network). During Follow-me you will hear
a special dial tone. You can still make calls as usual.
Order from your own extension
u Lift the handset.
*21* z Dial and enter the answering position number.
Note: U.K., dial
* 2 * No.
#d Press and replace the handset.
Cancel from your own extension
u Lift the handset.
#21# Dial.
Note: U.K., dial
# 2 #
d Replace the handset.
Redirect from answering position
If you are in another room, you can still answer your calls by
forwarding them to where you are.
u Lift the handset.
*21* z Dial and enter your own extension number.
Note: U.K., dial
* 2 * No.
*z Press and enter the Diversion number.
#d Press and replace the handset.
Calls are diverted to the answering position.
Note: Internal Follow-me must be ordered from your own
extension before you can redirect from answering position.
Analog Telephone30
Cancel from answering position
u Lift the handset.
#21* z Dial and enter your own extension number.
Call Forwarding
Note: U.K., dial
# 2 * No.
#d Press and replace the handset.
External Follow-me
If external Follow-me is allowed, you can have all calls to your
extension diverted to an external number of your choice. A special
dial tone will be heard. You can still make calls as usual.
Order
u Lift the handset.
*22# z Dial and enter the digit or digits to get an external line and
enter the external number.
#d Press and replace the handset.
Cancel
u Lift the handset.
#22# Dial.
d Replace the handset.
31Analog Telephone
Call Forwarding
Personal Number (optional)
With this function you can be reached on your normal office phone
number even if you are in another room, out of the office or at
home, etc.
Depending on the functionality of your office exchange, you can
have either one individual single search profile or you can choose
between five individual search profiles (optional).
A search profile can be designed to fit the situation, i.e. in the office,
traveling, at home, etc. Both internal or external phone numbers
can be used in a profile.
At your request, the search profiles are programmed or modified by
your system administrator. See section “To design and order your
search profiles” on page 34.
When the function is activated, incoming calls are transferred to
different phones or to back-up services in the order you choose. If
an answering position in the profile is busy, the call can be
transferred to another predefined position in the profile, i.e. voice
mail or a colleague. You can activate the function from your own
office phone or when out of the office, by using the Direct Inward
System Access function (DISA).
To activate or change to another profile from your office
phone
u Lift the handset.
*10* Dial.
( 1— 5) Press the search profile digit.
#d Press and replace the handset.
Note: When another party is included in the activated
profile, a colleague or an operator, etc., always remember
to inform about your absence. If voice mail is included in the
activated profile, always update your greeting with absence
information.
Analog Telephone32
To cancel from your office phone
u Lift the handset.
#10# Dial.
d Replace the handset.
To activate or change to another profile from an external
phone
The external phone must be of push button type provided with
pound key (
tone pulses (DTMF).
#) and star key (*) or a mobile phone adapted for dial
Call Forwarding
z Call the DISA function at your office.
Dial tone.
*75* Dial.
z* Enter the authorization code and press.
z# Dial your own extension number and press.
Dial tone.
*10* Dial.
z* Dial your own extension number and press.
( 1— 5) Press the search profile digit.
#d Press and replace the handset.
Note: When another party is included in the activated
profile, a colleague or an operator, etc., always remember
to inform about your absence. If voice mail is included in the
activated profile, always update your greeting with absence
information.
33Analog Telephone
Call Forwarding
To cancel from an external phone
The external phone must be of push button type provided with
pound key (
tone pulses (DTMF).
#) and star key (*) or a mobile phone adapted for dial
z Call the DISA function at your office.
Dial tone.
*75* Dial.
z* Dial the authorization code and press.
z# Dial your own extension number and press.
Dial tone.
#10* Dial.
z# Dial your own extension number and press.
d Replace the handset.
To design and order your search profiles
The search profiles are installed or changed by your system
administrator. In order to set up your profiles, copy the setting form,
fill in your new or changed profiles and give it to your system
administrator.
Note: If a profile handling application is connected to your
system, you can edit profiles via your Intranet. See separate
instructions for the application.
Analog Telephone34
Call Forwarding
Important notes when designing your search profiles:
• Avoid ring times longer than 45 seconds for your profiles.
Usually the caller hangs up after 3-6 ring signals. If you need a
longer ring time, the maximum time is 60 sec.
• Consider the time you need to react and answer on each
answering position in your profile.
You might need up to 15 seconds to react and answer a call on
a desk or cordless phone and 20–25 seconds for a mobile
phone.
• There must be an answering position at the end of every profile
(Voice mail or operator/secretary).
If not, calls might end up unanswered.
• Consider what should happen while you are busy on a phone.
The available options are:
– Diversion to voice mail
– Diversion to the operator
• If an answering machine, a fax or other answering device is
used as an early answering position, it might interrupt the
searching.
Disconnect the answering device, or design the ring times so
they do not affect the searching.
• If your system admits just one single personal profile, design the
profile only with your 2–3 most frequently used positions.
If you add more numbers, there is a risk that the caller hangs up
before a latter position is called.
• If your system admits 1–5 personal profiles, design the different
profiles to fit your most frequently used positions.
Make sure you use as few answering positions as possible for
each profile. Profile examples:
–In office
–At home
–Traveling
– Absent/not reachable
35Analog Telephone
Call Forwarding
Example:
How to fill in your setting form for search profiles:
Profile 1 In office
Search
order
1Desk 1234 10
2Cordless 5234 15
3 Voice mail
* Examples: Desk, Cordless, Mobile, External, Voice mail, Operator, etc.
Profile 2 At home
Search
order
1External 222222 20
2 Mobile 0706666666 25
3 Voice mail
Type of telephone or
Answering position* Telephone number
Type of telephone or
Answering position* Telephone number
Ring time
(seconds)
Ring time
(seconds)
Analog Telephone36
Setting form for search profiles
Name:
Department:
Tel e p h o n e N o :
Account:
Call Forwarding
Profile 1 ..........................
Search
order
1
2
3
4
* Examples: Desk, Cordless, Mobile, External, Voice mail, Operator, etc.
Type of telephone or
Answering position* Telephone number
Profile 2 ..........................
Search
order
1
2
3
4
Type of telephone or
Answering position* Telephone number
Profile 3 ..........................
Search
order
1
2
3
4
Type of telephone or
Answering position* Telephone number
Profile 4 ..........................
Search
order
1
2
3
4
Type of telephone or
Answering position* Telephone number
Ring time
(seconds)
Ring time
(seconds)
Ring time
(seconds)
Ring time
(seconds)
Profile 5 ..........................
Search
order
1
2
3
4
Type of telephone or
Answering position* Telephone number
Ring time
(seconds)
37Analog Telephone
Absence Information (optional)
u Lift the handset.
*23* Dial.
Absence Information (optional)
The absence information is used to inform callers why you are
absent and when you return. If you are authorized, you can also
enter absence information for another extension from your own
extension.
Order
Example: Back on September 15 (=0915).
( 0— 9) Enter the absence code.
Note: The absence codes consist of one digit which
depends on the system connected to the exchange.
Contact your system administrator regarding the available
absence codes.
*0915 Press and enter the date (MMDD) or time (HHMM) of your
return.
Notes:
If no ret urn time o r da te is nee ded, t his st ep can be s ki pped.
The order in which the date is stated is system dependent.
#d Press and replace the handset.
Analog Telephone38
Cancel
u Lift the handset.
#23# Dial.
Absence Information (optional)
d Replace the handset.
The programmed information is erased.
Order for another extension
u Lift the handset.
*230* Dial.
z* Dial the extension number and press.
( 0— 9) Enter the absence code.
*0915 Press and enter the date or time of the other person's return.
#d Press and replace the handset.
Cancel for another extension
u Lift the handset.
#230* Dial.
z# Dial the extension number and press.
Note: If the special dial tone is received, the authorization
code for the other extension is required. Add the code and
press
# before replacing the handset.
d Replace the handset.
39Analog Telephone
Messages
Messages
Manual Message Waiting (MMW)
If the called extension does not answer, you can send a message
waiting signal to that extension (if this feature is allowed).
Answer
u Lift the handset.
A call is initiated to the extension that requested Message Waiting.
Cancel MMW at your own extension
u Lift the handset.
#31# Dial.
d Replace the handset.
Order MMW to another extension
u Lift the handset.
*31* Dial.
z Dial the extension number.
#d Press and replace the handset.
Analog Telephone40
Cancel MMW to another extension
u Lift the handset.
#31* Dial.
z Dial the extension number.
#d Press and replace the handset.
Voice mail (optional)
This integrated function allows you to leave a voice message to the
caller when you are unable to answer calls, e.g. when out of office,
in a meeting, etc. The caller can then leave a message in your
mailbox. When back in office, you can enter your mailbox and listen
to the messages received.
You can choose to divert all incoming calls to your mailbox, or calls
when there is no answer, or calls when your phone is busy.
When you enter your mailbox, you will hear recorded instructions
on how to handle listening, recording, storing and deleting
messages, and how to change your security code.
Messages
To activate and deactivate your mailbox
For all incoming calls:
See “Diversion” on page 27 (function code 21). Use the number to
the voice mail system as the “answering position number”.
When incoming calls get no answer:
See “Diversion” on page 27 when there is no answer (function code
211).
When incoming calls get a busy tone:
See “Diversion” on page 27 when caller receives a busy tone
(function code 212).
41Analog Telephone
Messages
To enter your mailbox
From your office phone:
u Lift the handset.
z Dial the number to the voice mail system.
If you are asked to enter your security code:
z Enter your security code.
Code at delivery = your extension number.
Follow the recorded instructions.
From another phone:
u Lift the handset.
z Dial the number to the voice mail system.
If you are asked to enter your security code (the used phone has a
mailbox of its own):
# Press.
z Dial your mailbox number.
(normally your office extension number)
z Enter your security code (if required).
Follow the recorded instructions.
Analog Telephone42
To enter someone else´s mailbox
u Lift the handset.
z Dial the number to the voice mail system.
If you are asked to enter your security code (the used phone has a
mailbox of its own):
# Press.
Messages
z Dial the mailbox number.
(normally the office extension number of the other person)
z Enter the security code of the other person (if required).
Follow the recorded instructions.
43Analog Telephone
Messages
To handle the mailbox
Recorded information on the line tells you the number of new and
stored messages. If you have too many messages stored, you will
first be asked to delete saved messages. Recorded instructions
ask you to press different digits in order to listen to callers’
messages, record your own greetings, change your password or
exit your mailbox, etc.
The following diagram gives an overview of the mailbox system and
the digits to be used.
Analog Telephone44
Group Features
Group Call-pick-up
People working in a team can have their phones programmed by
their system administrator to form Call-pick-up groups.
In a Call-pick-up group, any member can answer any individual call
to group members.
u Lift the handset.
8 Press to answer.
Notes:
One Call-pick-up group can serve as an alternative to
another group. Calls to the alternative group can only be
answered when there are no calls to your own group.
Group Features
Finland and Sweden, press
Common bell group
Calls are signalled on a common bell.
u Lift the handset.
8 Press to answer.
Note: Finland and Sweden, press
0
0
45Analog Telephone
Group Features
Group Hunting
As a member of a group of extensions that is called by a common
number, you can temporarily leave the group.
u Lift the handset.
*21* z Dial and enter your own extension number.
Note: U.K., dial
* 2 * No.
#d Press and replace the handset.
To re-en t e r t h e g r oup
u Lift the handset.
#21# Dial.
Note: U.K., dial
# 2 #
d Replace the handset.
If you are authorized, you can divert all calls to a group, to another
extension or to another group:
u Lift the handset.
*24* Dial.
z* Dial the number of the group to be diverted and press.
z
Dial the extension number of the new anwering position.
#d Press and replace the handset.
To cancel the Diversion:
u Lift the handset.
#24* Dial.
z
Dial the number of the group that has been diverted.
#d Press and replace the handset.
Analog Telephone46
Other Useful Features
Account code (optional)
This function is used to charge a call to an account number or to
prevent unauthorised calls from your phone. The account code can
have 1 to 15 digits.
u Lift the handset.
*61* Dial.
Other Useful Features
Note: Finland and Norway, dial
* 7 1 *
z# Dial the account code and press.
Dial tone.
z Dial the digit or digits to get an external line and the external
number.
Ongoing external call
When used to charge a call it is also possible to connect an
ongoing external call to an account code. During the call:
Rd Press and replace the handset to put the call on hold.
*61* Dial.
Note: Finland and Norway, dial
* 7 1 *
z# Dial the account code and press.
Dial tone.
u Lift the handset to resume the call put on hold.
47Analog Telephone
Other Useful Features
#001# Dial.
General Deactivation
The following features can be simultaneously cancelled:
• Callback (all Callbacks are cancelled).
• Diversion/Internal and External Follow-me.
• Manual Message Waiting/Message Diversion.
• Do not disturb.
Order
u Lift the handset.
d Replace the handset.
Night Service
When the exchange is in Night Service mode, all your incoming
calls to the operator are transferred to a selected extension or
group of extensions. The exchange is equipped with three different
Night Service modes:
Common Night Service
All incoming calls to the operator are transferred to one specific
extension. Answer the call in the normal way.
Individual Night Service
Selected external calls to the operator are transferred to one
specific extension. Answer the call in the normal way.
Universal Night Service
All incoming calls to the operator are transferred to a universal
signalling device, e.g. the common bell. Answer the call as
descibed in section “Common bell group” on page 45.
Analog Telephone48
Other Useful Features
Hot line
Ask your system administrator if you require this function.
Delayed Hot line
When the handset of the delayed Hot line phone is lifted, a Call
Duration is started. If no digit is pressed before time out, a call is
automatically generated to a specific extension or external line. If a
digit is pressed before Time out the phone works as an ordinary
phone.
Note: This function is only available in newer versions of the
telephone exchange.
Direct Hot line
The same function as described above, but no delay. Only Hot line
calls can be placed from this line. To be used e.g. as alarm phone,
door phone etc.
Alarm extension
An extension can be programmed by your system administrator as
an Alarm extension. A call to an Alarm extension obtains automatic
Intrusion if the extension is busy. Up to seven calling parties may be
connected at the same time.
Emergency mode
In the event of an emergency, the operator can set the exchange
into Emergency mode, during which only preprogrammed
extensions are permitted to make calls.
49Analog Telephone
Other Useful Features
Data communication
Your phone can be used together with a PC as an integrated voice
and data terminal. Contact your system administrator if you require
this function.
DISA = Direct Inward System Access (optional)
If you are assigned to use this function and you are working
externally, you can call your office and get access to an external
line in order to make business calls. The business call will be
charged your office extension number or an account number. You
will just be charged for the call to the office.
The external phone must be of push button type provided with
pound key (
tone pulses (DTMF).
After a completed DISA call you must hang up before a new DISA
call can be made.
Depending on the type of authorization code and if an account
code is used, different procedures must be used:
#) and star key (*) or a mobile phone adapted for dial
With common authorization code
z Call the DISA function at your office.
Dial tone.
*72* Dial.
z# Dial the authorization code and press.
Dial tone.
z Dial the external number.
Analog Telephone50
With individual authorization code
Other Useful Features
z Call the DISA function at your office.
Dial tone.
*75* Dial.
z* Dial the authorization code and press.
z# Dial your own extension number and press.
Dial tone.
z Dial the external number.
51Analog Telephone
Glossary
Glossary
Exchange Switch. Your telephone switching system, for example
Idle mode The state your phone is in when nothing is activated; not
Least Cost Routing A function that automatically selects the cheapest way to
Speed Dialing number Abbreviated number or short number, used for making
Third party A third connection (person), which can be included in an
Ericsson MD110 and Ericsson MX-ONE™.
calling, not ringing, not diverted etc.
connect your external call (not necessarily the shortest
distance).
frequently used numbers faster to dial.
ongoing two person conversation. The connection can be
internal or external.
Analog Telephone52
Index
Index
A
Absence Information 38
Account code 47
Alarm extension 49
Answer calls 10
Authority 20
Authorization code, common 21
Authorization code, individual 22
B
Bypass 17
C
Call Forwarding 27
Diversion 27
External Follow-me 31
Internal Follow-me 30
Personal Number 32
Call Waiting 16, 25
Callback 14
Common bell group 45
Common Speed Dialing numbers 18
Conference 26
Copyright 5
D
Data communication 50
Data privacy 20
Description 6
To ne s 7
DISA = Direct Inward System Access 50
Diversion 27
Do not disturb, DND 20
During Calls 24
Call Waiting 25
Conference 26
Inquiry 24
On hold 26
Refer Back 24
During calls
Transfer 25
E
Emergency mode 49
External Follow-me 31
F
Free Seating 9
G
General Deactivation 48
Glossary 52
Group Call-pick-up 45
Group Features 45
Group Hunting 46
H
Hold 26
Hot line 49
I
Incoming Calls 10
Answer calls 10
Individual External Line 13
Individual Speed Dialing numbers 18
Inquiry 24
Internal Follow-me 30
Intrusion 16
L
Last External Number Redial 14
M
Mailbox 44
Make calls 12
Manual Message Waiting (MMW) 40
53Analog Telephone
Index
Messages 40
Manual Message Waiting (MMW) 40
Voice mail 41
N
Night Service 48
Number presentation restriction 13
O
On hold 26
Other Useful Features 47
Outgoing Calls 12
Last External Number Redial 14
Make calls 12
Outgoing calls
Authority 20
Bypass 17
Call Waiting 16
Callback 14
Individual External Line 13
Intrusion 16
Number presentation restriction 13
Speed Dialing 18
When you receive a busy tone 14
P
Personal Number 32
R
Refer Back 24
Ring signals 8
S
Setting form for search profiles 37
Short numbers 18
Speed Dialing 18
T
To ne s 7
Transfer 25
V
Voice mail 41
W
Warranty 5
Welcome 4
When you receive a busy tone 14
Analog Telephone54
Ericsson is shaping the future of Mobile and Broadband Internet communications through its
continuous technology leadership. Providing innovative solutions in more than 140 countries,
Ericsson is helping to create the most powerful communication companies in the world.
Subject to alteration without prior notice.
For questions regarding the product, please contact your
Ericsson Enterprise Certified Sales Partner.
Also visit us on http://www.ericsson.com/enterprise
© Copyright Ericsson AB 2007. All rights reserved.
EN/LZT 103 77 R2A
Loading...
