Quick Start Guide
A
Hardware Installation
B
Check LED Lights More Secure (Optional)
Troubleshooting
PLA5405 v2
1300Mbps Powerline Gigabit
Ethernet Adapter
ENGLISH | DEUTSCH | FRANÇAIS |
ITALIANO | ESPAÑOL | NEDERLANDS |
DANSK
PLA5405 v2 - 1
Device for
Internet access
LAN
PLA5405 v2 - 2
LAN
EN
A
Connect one PLA to a device for Internet access,
such as a router. Connect the other PLA to a
device requiring Internet over Powerline.
A
DE
Verbinden Sie unseren PowerLine Adapter (PLA)
mit einem Gerät für den Internetzugang und
einen anderen mit einem Gerät, das Internet
über Powerline bezieht.
A
FR
Connecter une PLA à un appareil pour l'accès
internet et une autre pour un appareil passant
par une ligne électrique pour internet.
A
Connettere uno dei PLA al router con accesso ad
IT
Internet, e l'altro al dispositivo che necessita di
accesso a Internet tramite Powerline.
Conecte un PLA a un dispositivo para acceso a
A
ES
Internet y otro a un dispositivo que necesite
Internet por línea eléctrica.
A
NL
Sluit een PLA aan op een apparaat voor
internettoegang en een andere op een apparaat
met internet via Powerline.
A
Tilslut en PLA til en enhed for internetadgang og
DK
en anden til en enhed der kræver internet over
lysnettet.
Room1
Room2
Power
Green: Power is on.
HomePlug
Green: More than 80 Mbps - Best
Amber: 20 to 80 Mbps - Good
Red: 0 to 20 Mbps - see Troubleshooting
Ethernet
Green: The Ethernet connection is up.
EN
The HomePlug light indicates how good your
B
Powerline connection is.
DE
B
Das HomePlug-Licht zeigt an, wie gut die Powerline-Verbindung ist.
FR
B
La lumière HomePlug indique la qualité de votre
connexion électrique.
IT
B
Il led HomePlug indica la qualità della connessione tramite Powerline.
ES
La luz HomePlug indica la calidad de la conexión
B
de su línea eléctrica.
NL
B
Het HomePlug lampje geeft aan hoe goed uw
Powerline aansluiting is.
DK
B
HomePlug-lyset viser hvor god din forbindelse, via
lysnettet, er.
PLA5405 v2 - 1
ETHERNET
PT
Y
RESET
ENCR
PLA5405 v2 - 2
ETHERNET
PT
Y
RESET
ENCR
within
minutes
ENCRYPT
Hold for
2 seconds
2
ENCRYPT
Hold for
2 seconds
Not Recommended
ON
EN
More Secure (Optional)
The PLAs must have an active Ethernet connection
to use the ENCRYPT button.
DE
Mehr Sicherheit (optional)
Der PowerLine Adapter (PLA) benötigt eine
Ethernet-Verbindung, um den VERSCHLÜSSELUNGS-Knopf nutzen zu können.
FR
Plus de Sécurité (option)
Les PLAs doivent avoir une connexion Ethernet
pour pouvoir utiliser le bouton ENCRYPT
Più sicuro (Opzionale)
IT
I PLA devono avere una connessione Ethernet per
poter usare il pulsante ENCRYPT
Más seguro (opcional)
ES
Los PLAs debe tener una conexión Ethernet para
usar el botón ENCRYPT.
Veiliger (Optioneel)
NL
De PLA's dienen een Ethernetaansluiting te hebben
om de ENCRYPT-toets te gebruiken.
Mere sikker (Valgfri)
DK
PLA'er skal have en Ethernet-forbindelse for at
bruge ENCRYPT-knappen (KRTPTERING).
If a power light does not come on, make sure the PLA
is turned on.
If an Ethernet light does not come on, please check
the Ethernet cable.
If the HomePlug light does not turn on, this means
there is no communications between PLA devices.
This can be due to other PLA devices not being
plugged in to electrical outlets yet, PLA device is
possibly in low power mode or there is an issue on the
power circuit. Make sure that the PLAs are on the
same power circuit. Test by connecting PLAs into
nearby outlets. Make sure that you do not have a
power meter between them.
To minimize interference, move PLAs away from high
powered electrical devices such as refrigerators,
air-conditioners, microwave ovens, etc.
When securing the Powerline network, make sure not
to press the ENCRYPT buttons on both PLAs for more
than 3 seconds. If the process fails, press the
said buttons on both PLAs over 10 seconds to
disconnect, then try to reconnect again.
See the User's Guide for more troubleshooting tips.
Support Information
North America
USA
+ 1 800 255 4101
support@zyxel.com
UK
+ 44 (0) 118 912 1700
support@zyxel.co.uk
Germany
+ 49 (0) 2405 69 09 69
support@zyxel.de
France
+ 33 (0) 4 72 52 97 97
support@zyxel.fr
See the User's Guide at www.zyxel.com
for more information, including customer support
and safety warnings .
EU Importer
Zyxel Communications A/S
Gladsaxevej 378, 2. th. 2860 Søborg, Denmark
http://www.zyxel.dk
US Importer
Zyxel Communications, Inc
1130 North Miller Street Anaheim, CA 92806-2001
http://www.us.zyxel.com
Copyright © 2018 Zyxel Communications Corp. All Rights Reserved.
Italy
+ 39 011 2308000
support@zyxel.it
Spain
+ 911 792 100
soporte@zyxel.es
Netherlands
+ 31 (0) 88-00029112
support@zyxel.nl
Denmark
+ 45 39 55 07 85
support@zyxel.dk
