ZTE MF823L UserMan
MF823L
LTE USB Modem
Quick Guide
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: +86-755-26779999
URL: http://www.zte.com.cn
E-mail: mobile@zte.com.cn
LEGAL INFORMATION
Copyright © 2012 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form
or by any means, electronic or mechanical, including photocopying and microfilm, without
the prior written permission of ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make modifications
on print errors or update specifications without prior notice.
Version No.: 1.0
Edition Time: 08 21, 2012
Confidential and Proprietary Information of ZTE CORPORATION 1
Quick Guide
Introduction
The ZTE MF823L LTE USB modem is a multi-mode USB modem, working in
LTE/HSPA+/HSUPA/HSDPA/WCDMA/EDGE/GPRS/GSM networks. With USB interface
connecting to a laptop or a desktop PC, it integrates the functionality of a modem and a
mobile phone (SMS), and combines mobile communication with Internet perfectly. It
supports data and SMS services through the mobile phone network, enabling you to
communicate anytime and anywhere.
Getting to know your device
The following figure shows the appearance of the MF823L. It is only for your reference.
The actual product may be different.
1. Indicator
2. Front Cover
3. USB Connector
4. microSD card slot
5. SIM card slot
Hardware Installation
1. Open the front cover to remove it from the modem.
NOTE:
Do not open the front cover rudely so as to avoid the damage of the front cover.
2. Insert the SIM card into the SIM card slot.
Loading...
