Zoom We3G User Manual
3G HOTSPOT USER GUIDE
Safety Precautions
Read the safety precautions carefully to ensure the correct and safe use of your wireless device.
Do not switch on your device when the device use is prohibited or when the device use may cause interference or danger.
Follow the rules or regulations in hospitals and health care facilities. Switch off your device near medical apparatus.
Switch off your device in an aircraft. The device may cause interference to control signals of the aircraft.
Switch off your device near high-precision electronic devices. The device may affect the performance of these devices.
Do not attempt to disassemble your device or its accessories. Only qualified personnel are allowed to service or repair the device.
Do not place your device or its accessories in containers with strong electromagnetic field.
Do not place magnetic storage media near your device. Radiation from the device may erase the information stored on them.
Do not put your device in a high-temperature place or use it in a place with flammable gas such as a gas station.
Keep your device and its accessories away from children. Do not allow children to use your device without guidance.
Use approved batteries and chargers only to avoid explosion.
Observe the laws or regulations on device use. Respect others’ privacy and legal rights when using your device.
It is recommended that the equipment only be used in the environment where temperature is between 0 and 50 and humidity is between 10% to 90%. Keep the equipment in the environment where temperature is between -10 and 70 or humidity is between 10% to 90%.
1
Content |
|
|
Safety Precautions.................................................................................................... |
1 |
|
1. Overview ................................................................................................................ |
3 |
|
1.1 |
Introduction ...................................................................................................... |
3 |
1.2 |
System Requirements ..................................................................................... |
6 |
2. Quick Start ............................................................................................................. |
7 |
|
2.1 |
Connect the Device ......................................................................................... |
7 |
2.2 |
Basic Tasks ..................................................................................................... |
8 |
3. Quick Setup ......................................................................................................... |
12 |
|
4. Advanced Settings .............................................................................................. |
14 |
|
4.1 |
Wireless LAN Settings ................................................................................... |
14 |
4.2 |
Internet Settings............................................................................................. |
16 |
4.3 |
Router Settings .............................................................................................. |
17 |
4.4 |
NAT Settings .................................................................................................. |
18 |
4.5 |
System Settings............................................................................................. |
19 |
5 Warning and Precautions .................................................................................... |
20 |
|
6 FCC Regulations .................................................................................................. |
22 |
|
2
1. Overview
3G Hotspot provides a simple way to use 3G connect to the Internet with any Wi-Fi-enabled device and to fulfill needs of sharing your internet connection during outside home.
1.1 Introduction
Indicator Description
1
2
3
4
Fig 1.1
The device is equipped with four LED status indicators (Fig 1.1) including:
|
Indicator |
|
Status |
|
|
Description |
|
|
|
|
|
|
|
|
|
|
Keep Red |
|
|
SIM error, PIN verification failed or no |
|
|
|
|
|
signal. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Keep Yellow |
|
|
Weak signal |
|
|
|
|
|
|
|
|
1. Signal |
|
Keep Green |
|
|
Good signal |
|
|
|
|
|
|
|
|
|
Keep Blue |
|
|
Roaming and good signal |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
Blue and flashing slowly |
|
Roaming but poor signal |
|
|
|
|
|
|
|
|
|
|
|
Unlit |
|
|
power off, normal working mode or |
|
|
|
|
|
Sleeping Mode |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2. Network |
|
Keep Red |
|
|
no network |
|
|
|
|
|
|
|
|
|
|
|
3 |
|
|
|
Green and flashing fast |
dialling |
|
|
|
|
|
|
Green and flashing slowly |
registering to 2G network |
|
|
|
|
|
|
Keep Green |
connected to 2G network |
|
|
|
|
|
|
Blue and flashing slowly |
registering to 3G network |
|
|
|
|
|
|
Keep Blue |
connected to 3G network |
|
|
|
|
|
|
Yellow and flashing fast |
dial failed |
|
|
|
|
|
|
Unlit |
power off, normal working mode or |
|
|
Sleeping Mode |
||
|
|
||
|
|
|
|
|
Keep Green |
normal battery power |
|
|
|
|
|
|
Keep Yellow |
low battery power |
|
|
|
|
|
|
Keep Red |
very low battery power and will power |
|
3. Power/ |
off automatically |
||
|
|||
Connect |
Green and flashing slowly |
charging |
|
|
|
|
|
|
Blue and breathing |
Normal working mode |
|
|
|
|
|
|
Yellow and breathing |
Sleeping Mode |
|
|
|
|
|
|
Unlit |
power off |
|
|
|
|
|
|
Blue and flashing slowly |
Wi-Fi on and transmit data |
|
|
|
|
|
|
Green and flashing fast |
WPS connection is building |
|
4. WIFI/WPS |
|
|
|
Keep Green for 5 Seconds |
WPS connection built |
||
|
|
|
|
|
Keep Red for 5 Seconds |
WPS connection failed to build |
|
|
|
|
|
|
Unlit |
Wi-Fi off |
|
|
|
|
Button Description
3 |
2 |
1 |
Fig 1.2
1. Power/Connect
Press and hold the power button more than 2 seconds to power on/off. Short press the power button (less than 2 seconds) to connect/disconnect. When the power indicator is blue and breathing, short press it (less than 2 seconds) to light all indicators.
4
2. Wi-Fi/WPS
Turn on/off Wi-Fi or WPS.
When Wi-Fi is on, press and hold this button until the WIFI/WPS Indicator go out to turn off Wi-Fi.
When Wi-Fi is off, press and hold this button for about 2 seconds until the WIFI/WPS Indicator start flashing to activate WPS.
When Wi-Fi is off, short press this button to turn on Wi-Fi.
3. Reset
Short press the button until all the 4 LED indicators become blue and flashing and the device will reboot.
Press and hold more than 4 seconds until the indicators become green and flashing, and the device will reset to factory default settings.
Connector Description
1
2
3
Fig 1.3
1. SIM Slot
A SIM can be inserted for connecting to the network.
2. Micro USB Connector
A terminal device can be connected via USB cable.
3. Micro SD Slot
A MicroSD card (maximum 16G supported) can be inserted for file transfer or storage. Please do as the following to insert them (Fig 1.4).
5
Fig 1.4
1.2 System Requirements
CPU: Pentium 500MHz or above.
Hard Disk: 50MB available space.
Operating System: Windows7/VISTA/XP (SP2 and above ), Mac OS X 10.4.9 and Later, Up to X10.6.0.
Display Resolving Power: 800 × 600 pixels or above (1024 × 768 is recommended).
Interface: Standard USB 2.0 interface.
Web Browser: Internet Explorer 6/7/8, Safari3/4/5.
One or more computing devices that support Wi-Fi (802.11b/g).
6
2. Quick Start
2.1 Connect the Device
Before you want to use the device, setup your device as following:
1.Insert SIM;
2.Insert MicroSD Card;
3.Insert the battery;
4.Hold the Power/Connect button to power on;
5.Connect this device to your terminal device.
If you want to go to internet, manage LAN, connect your terminal device to 3G Hotspot via USB or Wi-Fi:
Via USB: If your terminal device (such as desktop) is Wi-Fi disabled, you can connect them via USB cable. After connected in the first time, driver will be installed automatically.
Via Wi-Fi: It is better for you to connect the device to Wi-Fi-enabled devices through Wi-Fi, for which you don’t need to install any driver.
Fig 2.1
7
