Purpose

1

Introduction

The purpose of this manual is to dene and describe the PrintManager application

programming interface (API). The PrintManager API supports two methodologies for
interfacing to an application: Message-based printing and SDK-based printing; both
methods require communication via TCP/IP or via drag-and-drop from a hot-drop
folder.

P1057447-002 PrintManager Programmer's Reference Manual 1

Introduction

PrintManager Overview

PrintManager Overview

PrintManager is a service that runs on Microsoft Windows operating systems.
PrintManager can process ZMotif-based and message-based jobs—this includes
template- and job-based which both support XML and CSV. PrintManager creates
print jobs from the received data, directing the jobs to the appropriate printers.
PrintManager supports the ZXP Series 3, ZXP Series 7, and ZXP Series 8 Card
Printers.

PrintManager stores templates and images to be used for template-based printing.
Templates are XML documents, and images are binary data which may be one of
many formats including bitmap and jpeg. The variable data for a template-based print

job is packaged as a data document in XML or CSV le format. The ZMotif SDK is
used to build print jobs from templates, image les, and data documents.

PrintManager can also receive ZMotif-based jobs directly. The ZMotif SDK can be
used to build and send a print job to PrintManager.

ZMotif Job

XML Doc

Data Document

CSV Doc

Print Manager

PrintManager consists of three modules: Queue, Store, and Job. Queue Modules
are virtual printers that receive data streams, parse the data, and send the data
to the Store Module. The Store Module saves the data for future processing. The
Job Module gets data via the Store Module, analyzes the data, creates print jobs,
determines the appropriate printer, and tracks job status.

Queue Module

Queue Module

Queue Module

Store

Module

Job Module

PRINT MANAGER

2 PrintManager Programmer's Reference Manual P1057447-002

PrintManager Data

PrintManager Data consists of job-specic data received by PrintManager for

purposes of performing template- and job-based printing using the message interface

described in this manual. The job-specic data must be formatted as a document
using the XML or CSV le formats. The data document is delivered to PrintManager

via TCP/IP from any host capable of streaming data documents via TCP/IP such as
Linux, UNIX, and Microsoft Windows

The XML document shown below is an example of an XML-formatted data document
used for a template-based print job.

<?xml version=’1.0’ encoding=’utf-16’?>
<data template=’CuppaJoe’>
<Name>Test Job</Name>
</data>

The CSV document shown below is an example of a CSV-formatted data document
used for a template-based print job.

template,Name
CuppaJoe,Test Job

Introduction

PrintManager Data

P1057447-002 PrintManager Programmer's Reference Manual 3

Introduction

Print Job Processing

Print Job Processing

Print Job Processing refers to the tasks required to complete a print job. The tasks
associated with the completion of a print job include receiving data documents when

template-based job messaging is in use, receiving job xml les when job-based

messaging is in use, and receiving ZMotif-based jobs when the ZMotif SDK is in use.

4 PrintManager Programmer's Reference Manual P1057447-002

Template-Based Printing

Template-Based Printing is a process that combines a template document and its
required images (if appropriate) with a data document to create a ZMotif-based print
job.

PrintManager uses the ZMotif SDK to build a print job from a template, its required
image(s), and a data document.

Template documents specify the card layout by dening the required parameters.

These parameters include combinations of the following elements: font types, the
number of sides to print (single or double), graphics, text, barcode, lines, rectangles,
ellipses, and magnetic encoding (if supported). Some of these parameters become
placeholders for data—the data document contains the data required by these
placeholders.

Before a template and its required image(s) can be used by PrintManager to
build a ZMotif-based print job, the template and image(s) must be stored where

PrintManager can locate them. The template interface specication includes

commands which enable templates and images to be programmatically stored by
PrintManager.

Introduction

Template-Based Printing

ZMotif is a print job language that contains job characteristics and binary images.
Software tools for Microsoft Windows developers that generate ZMotif are the ZXP
Series printer drivers, and ZMotif Software Developer Kits (SDKs).

PRINT MANAGER

Stored Images

XML Doc

Data Document

CSV Doc

Data Binding

Stored Template

Create Print Job

P1057447-002 PrintManager Programmer's Reference Manual 5

Introduction

Sample Template

Sample Template

The following xml document is an example of a Template that would be stored in the
PrintManager for use with data documents for print jobs.

<?xml version=”1.0” encoding=”utf-16”?>
<template name=”text_job”>
<fonts>
<font id=”1” name=”arial” size=”12” bold=”yes” />
</fonts>
<sides>
<side name=”front”>
<print_types>
<print_type type=”color”>
<graphic eld=” logo” type=”bmp” x=”100” y=”100”
height=”150” width=”150” />

<text eld=”Firstname” font_id=”1” x=”100” y=”300” />
<text eld=”Lastname” font_id=”1” x=”100” y=”500” />

</print_type>
</print_types>
</side>
</sides>
</ template >

Sample Data Document

Data documents specify data to be bound with a template at job creation—they can
be XML or CSV formatted documents.

The following XML document is an example of an xml-formatted data document used
by the sample template on the previous page; its contents would be merged with the
sample template’s contents to create a print job.

XML Data Document
<data template=”text_job”>
(template to be used with the data)
<logo>zebra_logo</ logo >
(data for print job)
<Firstname>John</ Firstname >
(data for print job)
<Lastname>Doe</ Lastname >
(data for print job)
</data>

The following CSV document is an example of a CSV-formatted data document used
by the sample template on the previous page; its contents would be merged with the
sample template’s contents to create a print job.

CSV Data Document
template,logo,Firstname,Lastname
text_job,zebra_logo,John,Doe

CSV Data Docuement Items (not part of the CSV document)
Template, placeholder in template

logo, placeholder in template
Firstname, place holder in template
Lastname placeholder in template
text_job, template to be used with the data

zebra_logo, image le required by template

John, data for print job
Doe, data for print job

6 PrintManager Programmer's Reference Manual P1057447-002

SDK-Based Printing

SDK-based printing is a process that makes use of Zebra’s ZMotif SDKs for building
print jobs and sending them to PrintManager.

An application would use various methods in the SDK to build a print job. Once built,
the job is then sent to PrintManager by making use of other methods available in the
SDK. Unlike template-based printing, SDK-based printing delivers pre-built jobs to
the PrintManager; therefore, it is not required to build the job. Instead, PrintManager
simply forwards the job to an appropriate printer.

Introduction

SDK-Based Printing

P1057447-002 PrintManager Programmer's Reference Manual 7

8 PrintManager Programmer's Reference Manual P1057447-002

PrintManager Programming

Interface

Introduction

This chapter describes the methods for interfacing an application to PrintManager:
template-based printing and SDK-based. The chapter focuses on ZXP Card Interface

which is the message-based specication for template-based jobs; it also provides

an introduction to the SKD-based approach.

2

Template-based printing makes use of template documents and data documents

to build print jobs. A template document describes a card’s layout by dening fonts,

sides, graphics, text, barcodes, QR codes, lines, rectangles, ellipses and magnetic

encoding. The template also species data and image binding. A data document
denes the information unique to a card such as a customer’s name, an employee’s
identication number, and date of expiration.

SDK-based printing makes use of the ZMotif Printer and Graphics SDKs to build print
jobs. Using the SDK approach, each job is built through the use of methods provided
by the SDK as if all aspects of the job were unique, even if common background
images, titles, etc are part of each card produced.

P1057447-002 PrintManager Programmer's Reference Manual 9

PrintManager Programming Interface

Template Printing

Template Printing

The ZXP Card interface provides a standardized process for sending and receiving
data to/from the PrintManager. Data documents can be comma-separated values
(CSV), XML documents or binary data. Data is sent within an interface command
payload; the payload can be: templates, images, job data, or functional commands.
Responses will be XML formatted documents or binary data.

There are four ZXP Card interface commands supported by PrintManager: Store,
Submit, Delete and Request. The Store command downloads templates and images
on the PrintManager. The Delete command removes templates and images from
the PrintManager. The Submit command sends data or functional commands to be

processed by the PrintManager. The request command is used to request specic

information from PrintManager including job status, list of available queues, and a

queue’s conguration.

10 PrintManager Programmer's Reference Manual P1057447-002

Template Document

This section identies all of the possible components of the template document. A

template document is used to describe those parts of a card layout that are common

to all cards to be printed. The template also species data and image binding, and

must be stored by PrintManager prior to its use.

A template document describes card layout by dening fonts, sides, graphics, text,

barcodes, lines, rectangles, ellipses, and magnetic encoding. The template also

species data and image binding and is sent in store commands.

<?xml version=”1.0” encoding=”utf-8” ?>
<template>
<fonts>
<font />
</fonts>
<sides>
<side>
<print_types>
<print_type>
<graphic />
<text />
<barcode />
<line />
<ellipse />
<rectangle />
</print_type>
</print_types>
</side>
</sides>
<magdata>
<track />
</magdata>
</template>

PrintManager Programming Interface

Template Document

P1057447-002 PrintManager Programmer's Reference Manual 11

PrintManager Programming Interface

Template Document

Tag Descriptions

Template

<template name=”” version=”” card_type=”” card_thickness=”” delete=”” destination=”” >

name name of the template

version template version number

card_type identies the card type

card_thickness thickness of card in mm; default is 30

delete “no” = job data will be kept until the next job is received; (default)

destination “eject” = normal exit path for printer without laminator (default)

“yes” = job will be deleted at the end of processing

“reject” = card goes into the reject tray

“hold” = card goes to the home position

“feeder” = card returns to the input location

“lam_top” = card goes to laminator for top side lamination

“lam_bottom” = card goes to laminator for bottom side lamination

“lam_both” = card goes to laminator for top and bottom side lamination

“lam_any” = card goes to laminator without regard for laminate
availability. It will be laminated top, bottom, both or neither (if no
laminate is installed, the card simply passes through the laminator)

“lam_none” = card passes through laminator without lamination

Font

<font id=”” name=”” size=”” bold=”” italic=”” underline=”” />

all fonts used by a template are predened

id font index; used by a text tag

name font name; default is Arial

size font point size; default is 10

bold “yes” or “no”; default is “no”

italic “yes” or “no”; default is “no”

underline “yes“ or “no” default is “no”

Side

<side name=”” orientation=”” rotation=”” sharpness=”” k_mode=””>

name “front” or “back” default is “front”

orientation “landscape” or “portrait” default is “landscape”

rotation 0 or 180; default is 0

sharpness “off”, “low”, “normal”, “high”; default is “off”

k_mode “text”, “barcode”, mixed”, “picture”; default is “mixed”

12 PrintManager Programmer's Reference Manual P1057447-002

PrintManager Programming Interface

Template Document

Print Type

<print_type type=”” ll=”” preheat=””>

type “color”, “monochrome”, “overlay”, “inhibit”, “helper”; default is color

ll background ll color (RGB) for the ll layer; default is none

preheat valid range -50 to 50 for color, mono front, or mono back only

Graphics

<graphic order_id=”” eld=”” format=”” opacity=”” height=”” width=”” x=”” y=”” rotation=”” delete=””

/>

order_id processing order, 1 thru x with 1 being the bottom layer

eld reference name for data binding

format “bmp”, “jpeg”; default is “bmp”

opacity

height height of the image in pixels

width width of the image in pixels

x bottom left x axis in pixels

y bottom left y axis in pixels

rotation 0, 90, 180, 270; default is 0

delete “yes” or “no” delete image after processing; default=”yes”

<graphic>reference</graphic> reference species the name of a stored image

P1057447-002 PrintManager Programmer's Reference Manual 13

PrintManager Programming Interface

Template Document

Text

<text order_id=”” eld=”” font_id=”” x=”” y=”” color=”” angle=”” height=”” width=”” alignment=””

v_alignment=”” shrink=””/>

order_id processing order, 1 thru x with 1 being the bottom layer

eld reference name for data binding

font_id font reference

x x axis location in pixels

y y axis location in pixels

color RGB text color

red “FF0000”

green “00FF00”

blue “0000FF”

angle angle of rotation; referenced point is the lower left x, y coordinates

width width of the text box; optional

height height of the text box; optional

alignment horizontal alignment within the text box; only valid if height and width

“left”, “right”, “center”;
default is “left”

v_alignment vertical alignment within the text box; only valid if height and width

“top”, “bottom”, “center”;
default is “left”

shrink “yes” or “no”; “yes” indicates if the text is to t within the width

have been dened

have been dened

specication

<text>data</text> data species the text data to print

14 PrintManager Programmer's Reference Manual P1057447-002

PrintManager Programming Interface

Template Document

Barcode

<barcode order_id=”” eld=”” font_id=”” x=”” y=”” rotation=”” code=”” multiplier=”” ratio=”” height=”” width=””

bar_height=”” quiet_zone_width=”” add_checksum=”” display_checksum=”” fore_color=”” bar_color=””
back_color=”” show_text=”” encode_type=”” error_correction_level=”” code_version=”” module_size=””
encoding_name=”” />

order_id processing order, 1 thru x with 1 being the bottom layer

eld reference name for data binding

font_id font used to display barcode text

x lower left x axis location

y lower right y axis location

rotation angle of rotation; referenced point is the lower left x, y coordinates

code “code39”, “code128”, “code128A”, “code128B”, “code128C”, “interleaved2of5”,

multiplier

ratio ratio between the wide bar or space and the narrow bar or space

width width of the bounding box that the barcode will be printed in

height height of the bounding box that the barcode will be printed in

bar_height height of the barcode

quiet_zone_width area around bar code that serves to isolate it from surrounding text and

add_checksum enable checksum: default is “no”

display_checksum display checksum: default is “no”

fore_color text color of printed code value: default is black

bar_color barcode color: default is black

back_color background color; default is transparent

show_text indicates if text is to be shown under the barcode; “yes” or “no”

encode_type “auto”, “numeric”, “alpha numeric”, “kanji”, “byte”: default is “auto”

error_correction_level “l” for high symbol quality and/or the need for the smallest possible symbol

code_version species the QR code version to use on symbology

module_size

encoding_name “asmo-708” “big5” “cp1025” “cp866” “cp875” “csISO2022JP” “DOS-720”

“industrial2of5”,
“qrcode”: default is “code39”

graphics

“m” standard, offers a good compromise between small size and increased
reliability

“q” high reliability level, suitable for more critical or poor print quality

“h” offers the maximum achievable reliability

default is “m”

“auto”, “v01” thru “v40”; increments are in steps of 4; default is “auto”

“v01” = 21 x 21

“v40” = 177 x 177”

“DOS862” “EUC-CN” “euc-jp” euc-kr” “GB18030” gb2312” “hz-gb-2312”
“IBM00858” “IBM00924” “IBM01047” “IBM01140” “IBM01141” “IBM01142”
“IBM01143” “IBM01144” “IBM01145” “IBM01146” “IBM01147” “IBM01148”
“IBM01149” “IBM037” IBM1026” “IBM273” “IBM277” “IBM278” “IBM280”
“IBM284” “IBM285” “IBM290” “IBM297” “IBM420” “IBM423” “IBM424” “IBM437”
“IBM500” “ibm737” “ibm775” “ibm850” “ibm852” “ibm855” “ibm857” “us-ascii”
“utf-7” “utf-8” “utf-16” “utf-32” “utf-32BE” “iso-8859-1” “iso-8859-2” “iso-8859-3”
“iso-8859-4” “iso-8859-5” “iso-8859-6” “iso-8859-7” “iso-8859-8” “iso-8859-8-i”
“iso-8859-9” “iso-8859-13” “iso-8859-15”

<barcode>data</barcode> data species the barcode to print

P1057447-002 PrintManager Programmer's Reference Manual 15

PrintManager Programming Interface

Template Document

Line

<line order_id=”” x1=”” y1=”” x2=”” y2=”” thickness=”” color=”” />

order_id processing order, 1 thru x with 1 being the bottom layer

x1 start x axis location

y1 start y axis location

x2 end x axis location

y2 end y axis location

thickness line thickness in pixels

color RGB text color

Ellipse

<ellipse order_id=”” x=”” y=”” height=”” width=”” thickness=”” color=”” ll_color=”” />

order_id processing order, 1 thru x with 1 being the bottom layer

x bottom left corner x location

y bottom left corner y location

width width in number of pixels

height height in number of pixels

thickness line thickness in number of pixels

color line color in RGB

ll_color ll color in RGB; if attribute does not exist indicates no ll or

red “FF0000”

green “00FF00”

blue “0000FF”

transparent

Rectangle

<rectangle order_id=”” x=”” y=”” height=”” width=”” thickness=”” color=”” ll_color=”” radius=”” />

order_id processing order, 1 thru x with 1 being the bottom layer

x bottom left corner x location

y bottom left corner y location

width width in number of pixels

height height in number of pixels

thickness line thickness in number of pixels

color line color in RGB

ll_color ll color in RGB; if attribute does not exist indicates no ll or

transparent

radius for rounded corners; numeric value: default is 0

16 PrintManager Programmer's Reference Manual P1057447-002

PrintManager Programming Interface

Template Document

Mag Data

<magdata format=”” coercivity=”” verify=””>

format “iso”, “aamva”, “jis”, “vingcard”, “ballys”, “custom”, “binary”; default is

“iso”

coercivity “high” or “low”; default is “high”

verify “yes” or “no”; default is “no”

Tracks

<track eld=”” number=”” format=”” />

eld reference name for data binding

number track number to encode

format “ascii” or “hex”

P1057447-002 PrintManager Programmer's Reference Manual 17

PrintManager Programming Interface

Job Document

Job Document

A job document is used to provide all required information to create a specic print

job. Unlike a data document for a template-based job, a job document does not
reference a template. Instead, it includes the information that would be contained in

both the data and template documents to dene a job; thus, it uses many of the same
xml tag descriptors to dene a print job. This section identies all of the possible

components of the job document.

<?xml version=”1.0” encoding=”utf-8” ?>
<job name=”” hold=””>
<fonts>
<font />
</fonts>
<sides>
<side>
<print_types>
<print_type>
<graphic />
<text />
<barcode />
<line />
<ellipse />
<rectangle />
</print_type>
</print_types>
</side>
</sides>
<magdata >
<track />
</magdata>
</job>

Sample Job Document

The following xml document is an example of a job document that would be sent to
the PrintManager as a print job.

<?xml version=”1.0” encoding=”utf-8”?>
<job name=”PrintSingleSide”>
<fonts>
<font id=”1” name=”arial” size=”12” bold=”yes” />
</fonts>
<sides>
<side name=”front”>
<print_types>
<print_type type=”color”>
<graphic type=”bmp” x=”100” y=”100” height=”150” width=”150”>
logo.bmp</graphic>
<text font_id=”1” x=”100” y=”300” > John </Text>
<text font_id=”1” x=”100” y=”500”/> Smith </Text>
</print_type>
</print_types>
</side>
</sides>
</ job >

18 PrintManager Programmer's Reference Manual P1057447-002

Data Document

A data document is required for all template-based printing. The data document

species the template to be used and the information unique to a specic card to be

printed such as customer name, customer address, customer photo, membership
number, etc.

A data document can be built using the XML or CSV le formats. The sample code

demonstrated in this section is written in the C# language; however, it is not a
requirement to use C# when building data documents.

XML Data Document

This section demonstrates how to build a data document using the XML le format.

Header

Each data document requires a header to identify the start of the document.

string dataDoc = string.empty;
dataDoc = “<?xml version=’1.0’ encoding=’utf-16’?>” + “\r\n”;

PrintManager Programming Interface

Data Document

Start of Data Section

The start of the data section of each data document is dened by the beginning data
tag. Within the data tag the name of the template to be used is identied.

docData += “<data template=’” + GolfMembership + “’”;
docData += “>”;
docData += “\r\n”;

Field Information

The eld information represents the data that is unique to each card. It can consist
of text, image, and barcode data. The eld name must appear within opening and
closing xml tags while the data for the eld must appear between the tags as shown

below.

docData += “<” + “FirstName” + “>”;
docData += “John”;
docData += “</” + “FirstName” + “>”;
docData += “\r\n”;

docData += “<” + “LastName” + “>”;
docData += “Doe”;
docData += “</” + “LastName” + “>”;
docData += “\r\n”;

docData += “<” + “MembershipNumber” + “>”;
docData += “123456789”;
docData += “</” + “MembershipNumber” + “>”;
docData += “\r\n”;

docData += “<” + “ExpirationDate” + “>”;
docData += “12/31/2015”;
docData += “</” + “ExpirationDate” + “>”;
docData += “\r\n”;

P1057447-002 PrintManager Programmer's Reference Manual 19

PrintManager Programming Interface

Data Document

End of Data Section

The end of the data section of the data document is dened by the ending data tag.

Once the ending data tag has been added, the data document is complete.

docData += “</data>”;

Completed Data Document

The completed data document described in the previous four sections is shown here.

<?xml version=”1.0” encoding=”utf-16”?>
<data template”GolfMembership”>
<FirstName>John</FirstName>
<LastName>Doe</LastName>
<MembershipNumber>123456789</MembershipNumber>
<ExpirationDate>12/31/2015</ExpirationDate>
</data >

CSV Data Document

This section demonstrates how to build a data document using the CSV le format.

Header

Each data document requires a header to identify the start of the document.

string dataDoc = “template”;

Start of Data Section

The start of the data section of each data document is dened by a comma ‘,’.

docData += “,”;

Field Name Information

The eld information represents the data that is unique to each card. It can consist
of text, image, and barcode data. The rst eld name must appear immediately
following the comma identifying the start of the data section. Each subsequent eld
name must be preceded by a comma. The last eld name must be terminated with a
carriage return-line eld.

docData += “FirstName”;
docData += “,” + “LastName”;
docData += “,” + “MembershipNumber”;
docData += “,” + “ExpirationDate”;
docData += “\r\n”;

Field Data Information

The data for the rst eld must appear immediately after the carriage return-line feed
of the eld name information. Each subsequent data eld must be preceded by a
comma. Unlike the name elds, the last data eld does not require a carriage return-

line feed.

docData += “GolfMembership”;
docData += “,” + “John”;
docData += “,” + “Doe”;
docData += “,” + “123456789”;
docData += “,” + “12/31/2015”;

20 PrintManager Programmer's Reference Manual P1057447-002

PrintManager Programming Interface

Data Document

End of Data Section

There is no designation to dene the end of data section. The nal data eld value
denes the end the of the data section.

Completed Data Document

The completed data document described in the previous ve sections is shown here.

template,FirstName,LastName,MembershipNumber,ExpirationDate\r\
nGolfMembership,John,Doe,123456789,12/31/2015

P1057447-002 PrintManager Programmer's Reference Manual 21

PrintManager Programming Interface

ZXP Card Interface

ZXP Card Interface

ZXP Card interface provides a standardized process for sending and receiving
data to/from the PrintManager. Data can be comma-separated values (CSV), XML
documents or binary data. Data is sent in an interface command payload consisting
of templates, images, job data or functional commands to the PrintManager.
Responses returned from PrintManager will consist of XML formatted documents or
binary data.

There are four interface commands supported by PrintManager: Store, Submit,
Delete and Request. The Store command downloads templates and images to the
PrintManager. The Delete command removes templates and images previously
stored on the . The Submit command sends data or functional commands to the
PrintManager. The Request command requests information from the PrintManager.

The interface commands are built and sent to the PrintManager through the use of a
data document using the xml format described in the data document section of this
manual.

ZXP Card Interface Command Syntax

The syntax for the interface commands is as follows:

zxpf:command:sub-command:name:size:type:payload;
zxpf = header for the command

command = operation to be performed: store, delete, submit, or request

sub-command = the category the command will act upon: template, image, job,
data, or information

name = name of the data being stored, deleted, submitted, or requested

The following elds are optional based upon the command and sub-command:

size = size of the payload in bytes being stored or submitted

type = format of the payload: xml, bmp, jpeg, gif, png

payload = ACII text, or byte array of data: template, data document, job
document, or image

Each eld of the command is delimited by a ‘:’ character.

The command is terminated by the ‘;’ character.

22 PrintManager Programmer's Reference Manual P1057447-002

Store Command

The Store command downloads templates and images to the PrintManager.

syntax: zxpf:store:category:name:size:type:payload;

zxpf = header for the command

store = operation to be performed

category = template or image

name = name of the template or image le being stored

size = size of the template or image le being stored

type = depends upon the category; templates are xml; images can be bmp, jpeg,
gif, or png

payload = template document or image data

PrintManager Programming Interface

ZXP Card Interface

Response to Store command

If store command succeeds:

<?xml version=”1.0” encoding=”utf-8” ?>
<zxpf_resp>
<error_code>0</error_code>
<detail>No error</detail>
</zxpf_resp>

If store command fails:

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<error_code>error code here</error_code>
<detail>description of error code here</detail>
</zxpf_resp>

Example Store commands

Store a template on PrintManager:

zxpf:store:template:GolfTemplateOneOne.xml:2622:xml:<?xml version=”1.0” encoding=”utf-16”
standalone=”yes”?>
<template name=”GolfTemplateOneOne” card_type=”1” card_thickness=”30” delete=”false”>
<!-- Note: card_thickness is hard-coded to 30 as it is not currently used -->
<fonts>
<font id=”1” name=”Arial” size=”13” bold=”yes” italic=”yes” underline=”no”/>
<font id=”2” name=”Arial” size=”12” bold=”yes” italic=”yes” underline=”no”/>
<font id=”3” name=”Arial” size=”12” bold=”no” italic=”no” underline=”yes”/>
</fonts>
<sides>
<side name=”front” orientation=”landscape”>
<print_types>
<print_type type=”color”>
<graphic order_id=”1” format=”bmp” opacity=”100” height=”646” width=”1030” x=”0” y=”0”
rotation=”0” delete=”false”>GolfTemplateOneOne_img_1</graphic>

<text order_id=”2” eld=”DateOfMembership” font_id=”1” x=”24” y=”19” color=”0x0” angle=”0”

P1057447-002 PrintManager Programmer's Reference Manual 23

PrintManager Programming Interface

ZXP Card Interface

height=”62” width=”641” alignment=”left” v_alignment=”top” shrink=”no”/>
<graphic order_id=”3” format=”bmp” opacity=”100” height=”164” width=”195” x=”768” y=”379”
rotation=”0” delete=”false”>GolfTemplateOneOne_img_2</graphic>
<text order_id=”4” font_id=”2” x=”598” y=”137” color=”0xC20000” angle=”0” height=”75”
width=”401” alignment=”center” v_alignment=”top” shrink=”yes”>Visitor Badge</text>

<ellipse order_id=”6” x=”51” y=”155” height=”110” width=”147” ll_color=”0x3A8FA3”/>

<ellipse order_id=”7” x=”51” y=”155” height=”110” width=”147” thickness=”6” color=”0x0”/>
<rectangle order_id=”8” x=”705” y=”256” height=”60” width=”253” angle=”0”

ll_color=”0x324BE1”/>

<rectangle order_id=”9” x=”705” y=”256” height=”60” width=”253” thickness=”6” angle=”0”
color=”0x0”/>

<rectangle order_id=”10” ll_color=”0xAFCC99” width=”54” height=”174” x=”548” y=”465”

angle=”90”/>
</print_type>
<print_type type=”mono”>

<text order_id=”5” eld=”MemberName” font_id=”3” x=”27” y=”456” color=”0x0” angle=”0”

height=”52” width=”326” alignment=”left” v_alignment=”top” shrink=”no”/>
<barcode order_id=”11” height=”54” width=”174” x=”548” y=”465” rotation=”90” show_text=”no”
truncated=”no” code=”PDF417”>1234567890</barcode>
</print_type>
<print_type type=”overlay”>
<rectangle order_id=”12” x=”0” y=”0” height=”646” width=”1030” thickness=”1” color=”0x0”

ll_color=”0x0”/>

</print_type>
</print_types>
</side>
<side name=”back” orientation=”landscape”>
<print_types>
<print_type type=”overlay”>
<rectangle order_id=”13” x=”0” y=”0” height=”646” width=”1030” thickness=”1” color=”0x0”

ll_color=”0x0”/>

</print_type>
</print_types>
</side>
</sides>
</template> ;

Response if the store command above succeeds:

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<error_code>0</error_code>
<detail>No Error</detail>
</zxpf_resp>

Example of a response if the store command above fails:

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<error_code>6005</error_code>
<detail>Invalid Template Data, print_type Overlay is not valid for ZXP 8 Queue
with ribbon YCMK</detail>
</zxpf_resp>

Store an image on PrintManager:

zxpf:store:image:GolfTemplateOneOne_img_1:1966134:bmp:

Note • The actual bitmap to be stored would need to be appended to the command

following the ‘:’ after bmp. It would be appended as a byte array, after the entire

command had been converted to its equivalent bytes and stored in a byte array.

24 PrintManager Programmer's Reference Manual P1057447-002

Response if the store command above succeeds:

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<error_code>0</error_code>
<detail>No Error</detail>
</zxpf_resp>

Example of a response if the store command above fails:

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<error_code>6005</error_code>
<detail>Parameter is not valid</detail>
</zxpf_resp>

Delete Command

The Delete command removes templates and images previously stored on the
PrintManager.

syntax: zxpf:delete:category:name;

PrintManager Programming Interface

ZXP Card Interface

zxpf = header for the command

delete = operation to be performed

category = template or image

name = name of the template or image le to be deleted

Response to Delete command

If delete command succeeds:

<?xml version=”1.0” encoding=”utf-8” ?>
<zxpf_resp>
<error_code>0</error_code>
<detail>No error</detail>
</zxpf_resp>

If delete command fails:

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<error_code>error code here</error_code>
<detail>description of error code here</detail>
</zxpf_resp>

Example Delete commands

Delete an image from PrintManager:

zxpf:delete:image:GolfTemplateOneOne_img_1;

Delete a template from PrintManager:

zxpf:delete:template:GolfTemplateOneOne;

P1057447-002 PrintManager Programmer's Reference Manual 25

PrintManager Programming Interface

ZXP Card Interface

Response if the delete commands above succeed:

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<error_code>0</error_code>
<detail>No Error</detail>
</zxpf_resp>

Example of a response if the delete commands above fail:

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<error_code>6005</error_code>
<detail>Parameter is not valid</detail>
</zxpf_resp>

Submit Command

The Submit command sends data, job or functional commands to the PrintManager.

syntax: zxpf:submit:category:size:type:payload

zxpf = header for the command

submit = operation to be performed

category = data or job

size = size of the data, job or functional command to be submitted

type = depends upon the category; data can be csv or xml; job is xml

payload = data or job to be submitted

Response to Submit command

If submit command succeeds:

<?xml version=”1.0” encoding=”utf-8” ?>
<zxpf_resp>
<error_code>0</error_code>
<detail>No error</detail
</zxpf_resp>

If submit command fails:

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<error_code>error code here</error_code>
<detail>description of error code here</detail>
</zxpf_resp>

26 PrintManager Programmer's Reference Manual P1057447-002

PrintManager Programming Interface

ZXP Card Interface

Example Submit command

Submit a data document to PrintManager for template-based printing

zxpf:submit:data:236:xml:<?xml version=’1.0’ encoding=’utf-16’?>\r\n
<data template=’PAOne19’>\r\n<Name>HANNAH LUM</Name>\r\n
<MemberNumber>8120 1130 2237 0158</MemberNumber>\r\n
<Location>ANCHORVALE CC</Location>\r\n
<ExpirationDate>EXP 12 DEC 2014</ExpirationDate>\r\n</data> ;

Submit a job document to PrintManager for printing

zxpf:submit:job:1113:xml:<?xml version=\”1.0\” encoding=\”utf-16\” standalone=\”yes\”?>\r\n
<template name=\”CuppaJoe\” card_type=\”1\” card_thickness=\”30\” delete=\”false\”>\r\n\t
<fonts>\r\n\t\t
<font id=\”1\” name=\”Arial\” size=\”11\” bold=\”false\” italic=\”true\”
underline=\”false\”/>\r\n\t\t
<font id=\”2\” name=\”Arial\” size=\”10\” bold=\”false\” italic=\”false\”
underline=\”false\”/>\r\n\t
</fonts>\r\n\t
<sides>\r\n\t\t
<side name=\”front\” orientation=\”landscape\”>\r\n\t\t\t
<print_types>\r\n\t\t\t\t
<print_type type=\”color\”>\r\n\t\t\t\t\t
<graphic format=\”bmp\” width=\”1016\” height=\”632\” x=\”5\” y=\”6\
“delete=\”false\”>CuppaJoe_img_1.bmp</graphic>\r\n\t\t\t\t
</print_type>\r\n\t\t\t\t
<print_type type=\”mono\”>\r\n\t\t\t\t\t
<text font_id=\”1\” width=\”431\” height=\”52\” x=\”299\” y=\”15\”color=\”0x0\”>Cuppa Joe
Rewards</text>\r\n\t\t\t\t\t

<text eld=\”Name\” font_id=\”2\” width=\”326\” height=\”47\” x=\”686\” y=\”580\”

color=\”0x0\”/>\r\n\t\t\t\t
</print_type>\r\n\t\t\t
</print_types>\r\n\t\t
</side>\r\n\t\t
<side name=\”back\” orientation=\”landscape\”>\r\n\t\t\t
<print_types>\r\n\t\t\t\t<print_type type=\”mono\”>\r\n\t\t\t\t\t
<graphic format=\”bmp\” width=\”1003\” height=\”630\” x=\”7\” y=\”8\”
delete=\”false\”> CuppaJoe_img_2.bmp</graphic>\r\n\t\t\t\t
</print_type>\r\n\t\t\t
</print_types>\r\n\t\t
</side>\r\n\t
</sides>\r\n
</template>\r\n\r\n ;

Response if the submit commands above succeed: (job id is returned)

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<job_ids>
<job_id>15</job_id> <=Job Number returned for data or job document submitted
</job_ids>
</zxpf_resp>

P1057447-002 PrintManager Programmer's Reference Manual 27

PrintManager Programming Interface

ZXP Card Interface

Example of a response if the submit commands above fail:

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<error_code>1002</error_code>
<detail> Unable to read data from the transport connection: A connection attempt
failed because the connected party did not properly respond after a
period of time, or established connection failed because connected host
has failed to respond.
</ detail>
</zxpf_resp>

Request Command

The Request command requests information from the PrintManager.

Request command syntax: zxpf:request:category:name;

zxpf:request:category:name:size:type:payload;

zxpf = header for the command

request = operation to be performed

category = image list, template list, queue list, or job status

name = name of the data being requested

size = size of the payload in bytes

type = depends upon the category; data can be csv or xml; job is xml

payload = data or job to be submitted

Response to Submit command

If request command succeeds:

<?xml version=”1.0” encoding=”utf-8” ?>
<zxpf_resp>
<error_code>0</error_code>
<detail>No error</detail>
</zxpf_resp>

If request command fails:

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<error_code>error code here</error_code>
<detail>description of error code here</detail>
</zxpf_resp>

Example Request command

Request the list of images currently stored on PrintManager

zxpf:request:image:list;

28 PrintManager Programmer's Reference Manual P1057447-002

PrintManager Programming Interface

ZXP Card Interface

Response if the request command above succeeds: (list of image le

names is returned)

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<images>
<image>Badge</image>
<image>CalabriaGardens</image>
<image>Golf</image>
</images>
</zxpf_resp>

Request the list of templates currently stored on PrintManager

zxpf:request:template:list;

Response if the request command above succeeds: (list of template le

names is returned)

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<templates>
<template>CuppaJoe</template>
<template>LifeGuard</template>
<template>SkiPass</template>
<template>VisitorBadge</template>
</templates>
</zxpf_resp>

Request the list of queues currently congured in PrintManager

zxpf:request:information:queues;

Response if the request command above succeeds: (list of queues and

their congurations returned)

<?xml version=”1.0” encoding=”utf-8”?>\r\n
<zxpf_resp>r\n
<queues>\r\n
<queue>\r\n
<name>=ZXP8_Queue</ name >\r\n
<url>/ZPS/ZXP8_Queue</ url >\r\n
<port>9100</port>\r\n
<sequence>RoundRobin</sequence>\r\n
<model>ZXP Series 8</model>\r\n
<ribbon>YMCK</ribbon>\r\n

<lm>Standard</lm>\r\n

<laminate_top></laminate_top>\r\n
<laminate_bottom></laminate_bottom>\r\n
<sides>2</sides>\r\n
<mag>false</mag>\r\n
<contact>false</contact>\r\n
<contactless>false</contactless>\r\n
</queue>\r\n
<queue>\r\n
<name>ZXP3 Queue</ name >\r\n
<url>/ZPS/ZXP3 Queue</url >\r\n
<port>9101</port>\r\n
<sequence>RoundRobin</sequence>\r\n
<model> ZXP Series 3</model>\r\n
<ribbon> YMCKO</ribbon>\r\n
<sides>2</sides>\r\n
<mag>false</mag>\r\n
<contact>false</contact>\r\n
<contactless>false</contactless>\r\n

P1057447-002 PrintManager Programmer's Reference Manual 29

PrintManager Programming Interface

ZXP Card Interface

</queue>\r\n
<queue>\r\n
<name>ZXP7 Queue</ name >\r\n
<url>ZPS/ ZXP7 Queue</url>\r\n
<port>9102</port>\r\n
<sequence>RoundRobin</sequence>\r\n
<model> ZXP Series 7</model>\r\n
<ribbon>YMCK</ribbon>\r\n

<lm></lm>\r\n

<laminate_top></laminate_top>\r\n
<laminate_bottom></laminate_bottom>\r\n
<sides>2</sides>\r\n
<mag>false</mag>\r\n
<contact>false</contact>\r\n
<contactless>false</contactless>\r\n
</queue>\r\n
</queues>\r\n
</zxpf_resp>

Example of a response if the request command above fail:

<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_resp>
<error_code>1002</error_code>
<detail> Unable to read data from the transport connection: A connection attempt
failed because the connected party did not properly respond after a
period of time, or established connection failed because connected host
has failed to respond.
</detail>
</zxpf_resp>

Request job status from PrintManager: request information on pending

jobs for a specic date

zxpf:request:status:193:xml:<?xml version=’1.0’ encoding=’utf-8’ ?>
<zxpf_req>
<jobs>
<job_status host_ip_addr=’yes’ start_date=’9/28/2012 12:07:08 PM’
end_date=’9/28/2012 12:07:08PM’>pending</job_status>
</jobs>
</zxpf_req>”

Response if the request command above succeeds: (list of action ids
for pending jobs is returned)

<?xml version=\”1.0\” encoding=\”utf-8\”?>\r\n
<zxpf_resp>\r\n
<jobs>\r\n
<job>\r\n
<action_id>141</action_id>\r\n
<queue>ZXP8 Queue</queue>\r\n
<received_date>9/28/2012 12:07:05 PM
</received_date>\r\n
</job>\r\n
</jobs>\r\n
</zxpf_resp>

30 PrintManager Programmer's Reference Manual P1057447-002

PrintManager Programming Interface

ZXP Card Interface

Request job status from PrintManager: request information on a specif­ic job

zxpf:request:status:142:xml:<?xml version=”1.0” encoding=”utf-8”?>
<zxpf_req >
<jobs>

<job_status action_id=’1596’host_ip_addr = ‘yes’>pending</ job_status >

</ jobs>
</zxpf_req >

Response if the request command above succeeds: (current status of
the job is returned)

Note • In the example below, the status returned is in_progress which indicates the
job is currently being printed.

<?xml version=”1.0” encoding=”utf-8”?>r\n
<zxpf_resp>\r\n
<jobs>\r\n
< job>\r\n
<action_id>1596</ action_id>\r\n
<queue>ZXP8 Queue</ queue>\r\n
<printing_status>in_progress</ printing_status>\r\n
<printer_ip_addr>10.1.22.56</ printer_ip_addr>\r\n
<error_code>0</ error_code >\r\n
<received_date>10/4/2012 1:29:48 PM</ received_date>\r\n
<start_date>10/4/2012 1:29:56 PM</ start_date>\r\n
<complete_date></ complete_date>\r\n
<delete_date></ delete_date>\r\n
</ job>\r\n
</ jobs>\r\n
</zxpf_resp>

Note • In the example below, the status returned is done_ok which indicates the job
printed successfully.

<?xml version=”1.0” encoding=”utf-8”?>r\n<zxpf_resp>\r\n
<jobs>\r\n
< job>\r\n
<action_id>1596</ action_id>\r\n
<queue>ZXP8 Queue</ queue>\r\n
<printing_status>done_ok</ printing_status>\r\n
<printer_ip_addr>10.1.22.56</ printer_ip_addr>\r\n
<error_code>0</ error_code >\r\n
<received_date>10/4/2012 1:29:48 PM</ received_date>\r\n
<start_date>10/4/2012 1:29:56 PM</ start_date>\r\n
<complete_date>10/4/2012 1:34:26 PM </ complete_date>\r\n
<delete_date></ delete_date>\r\n
</ job>\r\n
</ jobs>\r\n
</zxpf_resp>

P1057447-002 PrintManager Programmer's Reference Manual 31

PrintManager Programming Interface

Sending Document to PrintManager

Sending Document to PrintManager

All documents, template, job, and data, are delivered to PrintManager in the
same manner: using TCP/IP. The process of sending documents to PrintManager
involves: opening a TCP/IP connection between the host PC and the PC running
PrintManager, sending the documents via this TCP/IP connection, receiving a
response from PrintManager, parsing the response to determine whether or not
the document was successfully delivered to PrintManager, and closing the TCP/IP
connection.

Note • Data documents are sent to PrintManager in the same manner regardless of
their format: XML or CSV.

This section demonstrates how to send a document to PrintManager from a host PC
running Windows and how to parse PrintManager’s response to determine whether
or not the document was delivered successfully. The sample code demonstrated in
this section is written in the C# language; however, it is not a requirement to use C#.

Open a TCP/IP Connection

Declare the required variables, instantiate the required objects and open the
TCP/IP connection. Note: error handling and other programming code has been
intentionally omitted.

Socket s = null;
IPAddress address = null;
string ipAddress = “10.1.24.29”;
int port = 9100;

IPAddress.TryParse(ipAddr, out address);

IPEndPoint endpoint = new IPEndPoint(address, port);

s = new Socket(endpoint.AddressFamily, SocketType.Stream, ProtocolType.Tcp);\

//open connection:
s.Connect(endpoint);

Send a Document

Declare the required variables, and send the document to PrintManager. The sample
code depicted here builds upon the sample code shown in the previous section.
Note: Error handling and other programming code has been intentionally omitted.

byte[ ] buf = null;
int size = 0;

//set communincation timeout:
s.SendTimeout = 30000;

//convert the data document string to its equivalent bytes:
buf = ASCIIEncoding.ASCII.GetBytes(jobDoc);

//send the document:
s.Send(buf, 0, buf.Length, SocketFlags.None);

32 PrintManager Programmer's Reference Manual P1057447-002

Receive PrintManager’s Response

Declare the required variables, and receive PrintManager’s response.
The sample code depicted here builds upon the sample code shown in the previous
sections. Note: error handling and other programming code has been intentionally
omitted.

int bytesRead = 0;

// Response data buffer, sized to read rst four bytes (payloadSize)

byte[] respBuffer = new byte[4];

// Offset into respBuffer
int offset = 0;

// Number of bytes to read
int bytesToRead = respBuffer.Length;

// Initialize socket receive parameters
s.ReceiveBufferSize = respBuffer.Length;
s.ReceiveTimeout = 30000;

PrintManager Programming Interface

Sending Document to PrintManager

//get reply from PrintManager

// Read rst four bytes to determine payload length

do
{
bytesRead = s.Receive(respBuffer, offset, bytesToRead, SocketFlags.None);
if (bytesRead > 0)
{
offset += bytesRead; // Increment offset into respBuffer
bytesToRead -= bytesToRead; // Subtract number of bytes remaining
}
} while (bytesToRead > 0);

// Convert four byte response to payload length
int payloadSize = BitConverter.ToInt32(respBuffer, 0);

// Clear and resize respBuffer to payloadSize
Array.Clear(respBuffer, 0, respBuffer.Length);
Array.Resize(ref respBuffer, payloadSize);

// Read the rest of the response data (payloadSize)
do
{
bytesRead = s.Receive(respBuffer, offset, bytesToRead, SocketFlags.None);
if (bytesRead > 0)
{
offset += bytesRead; // Increment offset into respBuffer
bytesToRead -= bytesRead; // Subtract number of bytes remaining
}
} while (bytesToRead > 0);

size = respBuffer.Length;

P1057447-002 PrintManager Programmer's Reference Manual 33

PrintManager Programming Interface

Sending Document to PrintManager

Parse the Received Response

Declare the required variables, and receive PrintManager’s response.
The sample code depicted here builds upon the sample code shown in the previous
sections. Note: error handling and other programming code has been intentionally
omitted.

To determine whether or not the document was received correctly, check for an
error condition. In the case of a data document or job document, a check of the

response for a jobID can also be made. The presence of a job id conrms that the

data document or job document has been submitted to a printer as a print job to be
processed.

The sample code below demonstrates how to determine if a data document or job
document was delivered successfully.

string errorCondition = “zxpf_resp/error_code”;

string errorDescription = “zxpf_resp/detail”;
string job_id = “zxpf_resp/job_ids/job_id”;

string errorStr = string.Empty;
string errDetail = string.Empty;
string JobId = string.Empty;

XmlDocument doc = new XmlDocument();

//convert received bytes into a string
string resp = Encoding.ASCII.GetString(respBuffer);

//determine if response indicates an error condition:
doc.LoadXml(resp);
XmlNode node = doc.SelectSingleNode(errorCondition);

if (node != null && !string.IsNullOrEmpty(node.InnerText))
{
//error: document not delivered successfully

//get error code
errorStr = node.InnerText;

int errCode;
Int32.TryParse(errorStr, out errCode);

//get error description:
node = doc.SelectSingleNode(errorDescription);
if (node != null && !string.IsNullOrEmpty(node.InnerText))
{
errDetail = node.InnerText; //get error description
}
}
else //document delivered successfully
{
//get job id
node = doc.SelectSingleNode(job_id);
if (node != null && !string.IsNullOrEmpty(node.InnerText))
{
JobId = node.InnerText; //get job ID
}
}

34 PrintManager Programmer's Reference Manual P1057447-002

Close a TCP/IP Connection

Close the TCP/IP connection and release the allocated memory. The sample code
depicted here builds upon the sample code shown in the previous sections. Note:
error handling and other programming code has been intentionally omitted.

s.Close();
s = null;
buf = null;

PrintManager Programming Interface

Sending Document to PrintManager

P1057447-002 PrintManager Programmer's Reference Manual 35

PrintManager Programming Interface

Sending ZMotif-Based Jobs to PrintManager

Sending ZMotif-Based Jobs to PrintManager

Sending ZMotif-based jobs to PrintManager involves the use of the ZMotif SDK to
build the job, open a TCP/IP connection between the host PC and the PC running
PrintManager, build the job, send the job via this TCP/IP connection, receive
PrintManager’s response, and close the TCP/IP connection.

Unlike template-based printing, the response from PrintManager does not require
parsing to determine if a job was successfully delivered. Instead, the response will
include a job id if delivered. In the case of a failure, the SDK will throw an exception
identifying the cause of the failure. Another difference between template-based
printing and ZMotif-based printing is that the ZMotif SDK requires the host PC to be
running a version of the Windows operating system.

This section demonstrates how to send a ZMotif-based job to PrintManager using the
SDK and how to determine whether or not the job was delivered successfully.

Note: The sample code demonstrated in this section is written in the C# language;
however, it is not a requirement to use C#.

The programming code demonstrated here is a basic, high-level view of the ZMotif
SDK. Please consult the ZMotif Programmers Reference Manual for details.
Complete, sample applications, written in several programming languages, are
available upon request from Zebra’s SDK support team at Card_SDK_Questions@
zebra.com.

Open a TCP/IP Connection

Declare the required variables, instantiate the required objects, and open the
TCP/IP connection. Note: Error handling and other programming code has been
intentionally omitted.

string ipAddress = “10.1.24.29”;
int port = 9100;
Job job = new Job();
if (!job.IsOpen)
{
ipAddress += “:”;

ipAddress += port.ToString();
job.Open(iPAddress);
}

Build a print job

Building a job includes dening the side of the card to be printed on, whether or not

the printing is to be color or monochrome, and the type of information to be printed
on the card. The sample code below demonstrates how a job would be built to print
a bitmap image on the front-side of a card, and builds upon the sample code shown
in the previous section. Note: Error handling and other programming code has been
intentionally omitted.

job.BuildGraphicsLayers(SideEnum.Front, PrintTypeEnum.Color, 0, 0, 0, -1,
GraphicTypeEnum.BMP, bmpFront);

36 PrintManager Programmer's Reference Manual P1057447-002

Send a print job

Sending a job requires dening how many copies of the card should be printed and

retrieving a job id from PrintManager. The sample code below demonstrates how to
send a job to PrintManager, and builds upon the sample code shown in the previous
sections.

Note: If an invalid job is built using the SDK, the SDK will throw an exception upon
trying to send the job to PrintManager. Error handling and other programming code
has been intentionally omitted.

int copies = 1;
int jobID = 0;

job.PrintGraphicsLayers(copies, out jobID);

Receive PrintManager’s Response

Receiving PrintManager’s response is nothing more than checking the jobID

returned to conrm a non-zero value has been received. The sample code below
demonstrates conrming PrintManager returned a non-zero job id, and builds upon

the sample code shown in the previous sections.

if (jobID > 0) //valid job id returned: job delivered to PrintManager successfully
{
//take appropriate action for valid job
}
else //invalid job id returned: failed to deliver job to PrintManager
{
//take appropriate action for invalid job
}
catch (Exception e)
{
//job built & delivered to PrintManager was invalid
//examine exception to determine the problem with job
}

PrintManager Programming Interface

Sending ZMotif-Based Jobs to PrintManager

Close a TCP/IP Connection

Close the TCP/IP connection and release the allocated memory. The sample code
depicted here builds upon the sample code shown in the previous sections. Note:
error handling and other programming code has been intentionally omitted.

job.Close();
do
{
Thread.Sleep(10);
} while (Marshal.FinalReleaseComObject(job) > 0);

job = null;

P1057447-002 PrintManager Programmer's Reference Manual 37

38 PrintManager Programmer's Reference Manual P1057447-002

Appendix C

Worldwide Support

For Technical Support or Repair Services, contact the appropriate facility listed
below.

North America and Latin America - Technical Support

T: +1 877 ASK ZEBRA (877 275 9327)
[phone]
E: [e-mail]

North America and Latin America - Repair Services

Before returning any equipment to Zebra Technologies Corporation for in-warranty
or out-of-warranty repair, contact Repair Services for a Repair Order (RO) number.
Mark the RO number clearly on the outside of the box. Ship the equipment, freight
prepaid, to the address listed below:

Zebra Technologies Repair Services
333 Corporate Woods Parkway
Vernon Hills, IL 60061
webform: www.zebra.com/repair
T: +1 877 ASK ZEBRA (877 275 9327)
E: [e-mail]

P1057447-002 PrintManager Programmer's Reference Manual 39

Worldwide Support

Europe, Middle East, and Africa - Technical Support

Language Phone Email

Arabic [phone] [e-mail]

Dutch [phone] [e-mail]

English (UK) [phone] [e-mail]

(Sweden) [phone] [e-mail]

(South Africa) [phone] [e-mail]

French [phone] [e-mail]

German [phone] [e-mail]

Hebrew [phone] [e-mail]

Italian [phone] [e-mail]

Polish [phone] [e-mail]

Russian [phone] [e-mail]

Spanish [phone] [e-mail]

Turkish [phone] [e-mail]

For further assistance, contact:

Zebra Technologies Card Printer Solutions
Dukes Meadow
Millboard Road, Bourne End
Buckinghamshire SL8 5XF, UK

T: [phone]
F: [phone]
E: [e-mail]

40 PrintManager Programmer's Reference Manual P1057447-002

Europe, Middle East, and Africa - Repair Services

Before returning any equipment to Zebra Technologies Corporation for in-warranty
or out-of-warranty repair, contact your supplier for a Return Materials Authorization
(RMA) number, or contact one ot the following repair centers for support and
instructions:

Type of repair and location Phone Email

Depot Repair in Germany,
Austria, Switzerland

Depot Repair in France [phone] [e-mail]

Depot and On-Site Repair in
UK and Ireland

Depot Repair in South Africa [phone] -

Depot Repair in Middle East [phone] [e-mail]

For further assistance, contact:

[phone] [e-mail]

[phone] [e-mail]

Worldwide Support

For assistance anywhere in the EMEA, contact After Sales Customer Services at:

T: + 44 (0) 177 2 69 3069
E: [e-mail]

P1057447-002 PrintManager Programmer's Reference Manual 41

Worldwide Support

Asia Pacic - Technical Support

Zebra Technologies Asia Pacic Pte. Ltd.

120 Robinson Road
#06-01 Parakou Building
Singapore 068913

T: [phone]
F: [phone]

E: tsasiapaci[e-mail]

Asia Pacic - Repair Services

Before returning any equipment to Zebra Technologies Corporation for in-warranty or
out-of warranty repair, contact Repair Services for a Return Materials Authorization
(RMA) number. Repack the equipment in the original packing material, and mark the
RMA number clearly on the outside. Ship the equipment, freight prepaid, to either
address listed below:

Zebra Technologies Asia Pacic Pte. Ltd.

No.5 Changi North Way Level 3
Singapore 498771
Agility Building
T: [phone] ext 3203 and 3204
F: [phone]
E: [e-mail]

Zebra Website

http://www.zebra.com
km.zebra.com (Knowledge Base)

42 PrintManager Programmer's Reference Manual P1057447-002
