FX RFID READER SERIES

Embedded SDK Sample Application

User Guide

MN000539A01

FX RFID READER SERIES EMBEDDED SDK

SAMPLE APPLICATIONS USER GUIDE

MN000539A01

Revision A

December 2017

Copyright

© 2017 ZIH Corp. and/or its affiliates. All rights reserved. ZEBRA and the stylized Zebra head are trademarks of ZIH Corp., registered in many jurisdictions worldwide. All other trademarks are the property of their respective owners.

COPYRIGHTS & TRADEMARKS: For complete copyright and trademark information, go to www.zebra.com/copyright.

WARRANTY: For complete warranty information, go to www.zebra.com/warranty.

END USER LICENSE AGREEMENT: For complete EULA information, go to www.zebra.com/eula.

For Australia Only

For Australia Only. This warranty is given by Zebra Technologies Asia Pacific Pte. Ltd., 71 Robinson Road, #05-02/03, Singapore 068895, Singapore. Our goods come with guarantees that cannot be excluded under the Australia Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

Zebra Technologies Corporation Australia’s limited warranty above is in addition to any rights and remedies you may have under the Australian Consumer Law. If you have any queries, please call Zebra Technologies Corporation at +65 6858 0722. You may also visit our website: www.zebra.com for the most updated warranty terms.

Terms of Use

•

Proprietary Statement

This manual contains proprietary information of Zebra Technologies Corporation and its subsidiaries (“Zebra Technologies”). It is intended solely for the information and use of parties operating and maintaining the equipment described herein. Such proprietary information may not be used, reproduced, or disclosed to any other parties for any other purpose without the express, written permission of Zebra Technologies.

•

Product Improvements

Continuous improvement of products is a policy of Zebra Technologies. All specifications and designs are subject to change without notice.

•

Liability Disclaimer

Zebra Technologies takes steps to ensure that its published Engineering specifications and manuals are correct; however, errors do occur. Zebra Technologies reserves the right to correct any such errors and disclaims liability resulting therefrom.

•

Limitation of Liability

In no event shall Zebra Technologies or anyone else involved in the creation, production, or delivery of the accompanying product (including hardware and software) be liable for any damages whatsoever (including, without limitation, consequential damages including loss of business profits, business interruption, or loss of business information) arising out of the use of, the results of use of, or inability to use such product, even if Zebra Technologies has been advised of the possibility of such damages. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

Revision History

Changes to the original manual are listed below:

Change Date Description

-01 Rev A 12/2017 Initial release

Copyright ......................................................................................................................................... 3

For Australia Only ..................................................................................................................... 3

Terms of Use ................................................................................................................................... 3

Revision History .............................................................................................................................. 4

About This Guide

Introduction ............................................................................................................................................ 6

Chapter Descriptions .............................................................................................................................6

Notational Conventions .........................................................................................................................6

Related Documents and Software ........................................................................................................ 7

Service Information ............................................................................................................................... 7

Setting Up SDK for Debugging

Introduction ..................................................................................................................................... 8

C and C++ Sample Application

Introduction ................................................................................................................................... 16

Connecting to the FX Series RFID Reader ................................................................................. 17

Compiling the C and C++ Sample Application ........................................................................... 20

Debugging the C and C++ Sample Application .......................................................................... 23

Embedded Java Application

Introduction ................................................................................................................................... 29

Connecting to the FX Series RFID Reader ................................................................................. 30

Building the Java Sample Application ........................................................................................ 36

Debugging the Java Sample Application ................................................................................... 39

ABOUT THIS GUIDE

Introduction

This guide describes how to use the sample applications of the FX Series RFID Reader Embedded SDK.

Chapter Descriptions

Topics covered in this guide are as follows:

• Setting Up SDK for Debugging describes how to set up the SDK to enable remote application

debugging.

• C and C++ Sample Application describes how to compile and debug the C and C++ sample

applications.

• Embedded Java Application describes how to compile and debug the Java sample application.

Notational Conventions

The following conventions are used in this document:

• FX Series RFID reader refers to the FX7500 and FX9600 RFID readers.

• Bullets (•) indicate:

• Action items

• Lists of alternatives

• Lists of required steps that are not necessarily sequential.

• Sequential lists (e.g., those that describe step-by-step procedures) appear as numbered lists.

About This Guide

Service Information

If you have a problem with your equipment, contact Zebra Global Customer Support for your region. Contact information is available at:

When contacting support, please have the following information available:

• Serial number of the unit

• Model number or product name

• Software type and version number.

Zebra responds to calls by email, telephone or fax within the time limits set forth in support agreements.

If your problem cannot be solved by Zebra Customer Support, you may need to return your equipment for servicing and will be given specific directions. Zebra is not responsible for any damages incurred during shipment if the approved shipping container is not used. Shipping the units improperly can possibly void the warranty.

If you purchased your Zebra business product from a Zebra business partner, contact that business partner for support.

www.zebra.com/support.

Setting Up SDK for Debugging

Introduction

This chapter describes how to set up the SDK to enable remote application debugging. This is required only once to prepare the FX Series RFID Reader for remote debugging of the sample applications.

NOTE: The instructions in this chapter show Microsoft Windows 7 screens. This procedure was not

tested on Microsoft Windows 8. The installation was reported as working on Microsoft Windows 8, but is

currently not officially supported.

NOTE: Screen captures are for example use only. Actual screens may vary upon product and software

release.

To set up the SDK for remote debugging of the sample applications:

1. Execute the shortcut FX Series RFID Reader (the FX7500 is used as an example only) Embedded SDK

from the desktop to start the SDK.

Figure 1 Workspace Launcher

Setting Up SDK for Debugging

2. Select the workspace path of one of the sample applications. For example, to select the C sample

application, browse the Workspace Launcher window.

NOTE: The install path of the FX Series Embedded SDK in this example is C:\Zebra-FXSeries

-Embedded-SDK. The sample applications are in the following workspace folders:

- C sample application: [INSTALL PATH]\samples\C\CodeSourcery

- C++ sample application: [INSTALL PATH]\samples\C++\CodeSourcery

- Java sample application: [INSTALL PATH]\samples\Java.

3. Select OK.

4. Select the Remote System Explorer button in the top-right corner of the main window, or select

Windows > Open Perspective > Other….

Figure 2 Selecting Remote System Explorer

5. Right-click on FX Series in the left window and select Properties.

Figure 3 FX Series Properties

Setting Up SDK for Debugging

6. Select Host.

Figure 4 Host Properties

Setting Up SDK for Debugging

7. Enter the Host name of the FX Series RFID Reader (example: FX7500 + last 6 digits of the mac address

or IP address).

8. In the Default User ID field, enter rfidadm.

9. Select OK.

10. Expand the FX Series entry.

Setting Up SDK for Debugging

Figure 5 FX Series Expanded Selection

11. Expand My Home. If the Enter Password window appears, leave the Password field blank and check

Save password.

Figure 6 Enter Password Window

12. Select OK.

13. Select Yes or OK on any warning message windows regarding authentication and missing folders for

SSH handling.

14. In File Explorer, navigate to the samples folder in the SDK installation folder ([INSTALL

PATH]\samples).

15. Right-click the files gdbserver and samples.sh and select Copy.

Setting Up SDK for Debugging

Figure 7 Copying Sample Files

16. Return to the Remote System Explorer, right-click My Home, and select Paste.

NOTE: Copying gdbserver and samples.sh is only required the first time you are using a new FX Series

RFID reader for remote debugging of the sample applications.

Figure 8 Pasting Sample Files

17. Right-click on Ssh Terminals and select Launch Terminal.

Setting Up SDK for Debugging

Figure 9 Selecting Launch Terminal

18. A terminal window opens at the bottom of the main window with a prompt in the Home directory.

Setting Up SDK for Debugging

Figure 10 Remote System Details

19. Execute sh samples.sh in the terminal window. This creates debug folders for the sample applications,

the debug script for the Java sample application, and prepares the gdbserver application.

Figure 11 Debug Information

20. Return to previous perspective by selecting the C/C++ button or Java button in the top-right corner of

the main window, or by selecting the perspective through Windows > Open Perspective > Other… .

21. Select File > Exit to close the SDK.

C and C++ Sample Application

Introduction

This chapter describes how to compile and debug the C and C++ sample applications.

NOTE: The instructions in this chapter show Microsoft Windows 7 screens. This procedure was not

tested on Microsoft Windows 8. The installation was reported as working on Microsoft Windows 8, but is

currently not officially supported.

The procedures for both sample applications are identical except for the workspace selected.

NOTE: If using a new FX Series RFID Reader, follow the instructions in Setting Up SDK for Debugging

before performing the procedures in this chapter.

NOTE: Screen captures are for example use only. Actual screens may vary upon product and software

release.

C and C++ Sample Application

Connecting to the FX Series RFID Reader

Perform this only if the connection (FX7500 reference only) was not changed or if using a different FX Series RFID Reader. If the connection reference is correct, skip this section.

1. Execute the shortcut FX Series RFID Reader Embedded SDK from the desktop to start the SDK.

Figure 12 Workspace Launcher

2. Select the workspace path of the C or C++ sample application by clicking Browse... in the Workspace

Launcher window.

NOTE: The install path of the FX7500 Embedded SDK in this example is

C:\Zebra-FXSeries-Embedded-SDK. The sample applications are in the following workspace folders:

- C sample application: [INSTALL PATH]\samples\C\CodeSourcery

- C++ sample application: [INSTALL PATH]\samples\C++\CodeSourcery

3. Select OK.

4. Select the Remote System Explorer button in the top-right corner of the main window, or select

Windows > Open Perspective > Other….

Figure 13 Selecting Remote System Explorer

5. Right-click on FX Series in the left window and select Properties.

Figure 14 FX7500 Properties

C and C++ Sample Application

6. Select Host.

Figure 15 Host Properties

C and C++ Sample Application

7. Enter the Host name of the FX7500 (FX7500 + last 6 digits of the mac address or IP address).

8. In the Default User ID field, enter rfidadm.

9. Select OK.

10. Return to previous perspective by selecting the C/C++ button in the top-right corner of the main

window, or by selecting Windows > Open Perspective > Other… .

C and C++ Sample Application

Compiling the C and C++ Sample Application

1. Execute the shortcut FX Series RFID Reader (the FX7500 is used as an example only) Embedded SDK

from the desktop to start the SDK.

Figure 16 Workspace Launcher

2. Select the workspace path of the C or C++ sample application by clicking Browse... in the Workspace

Launcher window.

NOTE: The install path of the FX7500 Embedded SDK in this example is

C:\Zebra-FXSeries-Embedded-SDK. The sample applications are in the following workspace folders:

- C sample application: [INSTALL PATH]\samples\C\CodeSourcery

- C++ sample application: [INSTALL PATH]\samples\C++\CodeSourcery

3. Select OK.

4. To compile the application select Build All or Build Project from the Project menu, or right-click the

project name RFIDSample4App in the Project Explorer on the left side of the main window and select Build Project.

Figure 17 Building the Project

C and C++ Sample Application

After the successful compilation, the Console window at the bottom of the main window displays the compile and linking commands and information.

C and C++ Sample Application

Figure 18 Compile and Linking Commands and Information

C and C++ Sample Application

Debugging the C and C++ Sample Application

To debug the sample application:

1. Click the debug symbol down arrow , located at the top of the window near the menus.

2. Select 1 RFIDSample4App.

Figure 19 Selecting Sample Application

3. If the Enter Password window appears, leave the Password field blank and check Save password.

Figure 20 Enter Password Window

4. Select OK.

5. Select Yes or OK on any warning message windows regarding authentication and missing folders for

SSH handling.

The Console window at the bottom of the main window indicates that remote debugging is in progress. The Confirm Perspective Switch window may open.

C and C++ Sample Application

Figure 21 Confirm Perspective Switch Window

NOTE: Ensure port 2345 is not blocked by the firewall.

6. Select Yes to open the Debug perspective.

Figure 22 Debug Window

C and C++ Sample Application

NOTE: To switch between the compile perspective and the debug perspective, select the appropriate

button at the top right section of the main window, or select Windows > Open Perspective > Other.

NOTE: If the following error condition occurs, select the Go button at the top of the main window to

continue. This issue should not impact the debugging and is believed to be an issue with the gdbserver

on the device which needs further investigation. Report if the execution of the program is not possible as

explained in this procedure.

C and C++ Sample Application

Figure 23 Debug ErrorContinue debugging by selecting Go at the top of the main window.

NOTE: Debugging stops at the main function by default. Change the debug settings to alter this if

desired.

The Console window at the bottom of the main window shows the application output, which is a menu offering various functions.

Figure 24 Application Output

C and C++ Sample Application

7. Select 5. Exit or the stop debug button to complete the debug session.

NOTE: This debug procedure assumes that the GDB debugger executable arm-none-linux-gnueabi.exe

resides in a directory path that the IDE (environment variables) can locate. If the IDE experiences

problems finding the GDB debugger application, add full path information to the setting as shown in

Figure 25.

C and C++ Sample Application

Figure 25 GDB Debugger Path Information

Embedded Java Application

Introduction

This chapter describes how to compile and debug the Java sample application.

NOTE: The instructions in this chapter show Microsoft Windows 7 screens. This procedure was not

tested on Microsoft Windows 8. The installation was reported as working on Microsoft Windows 8, but is

currently not officially supported.

NOTE: If using a new FX Series RFID Reader, follow the instructions in Setting Up SDK for Debugging

before performing the procedures in this chapter.

NOTE: Screen captures are for example use only. Actual screens may vary upon product and software

release.

Embedded Java Application

Connecting to the FX Series RFID Reader

Perform this only if the connection (FX7500 reference only) was not changed or if using a different FX Series RFID Reader. If the connection reference is correct, skip this section.

1. Execute the shortcut FX RFID Reader Embedded SDK from the desktop to start the SDK.

Figure 26 Workspace Launcher

2. Select the workspace path of the Java sample application by clicking Browse... in the Workspace

Launcher window.

NOTE: The install path of the FX7500 Embedded SDK in this example is

C:\Zebra-FXSeries-Embedded-SDK\. The Java sample application is in the following workspace folder:

[INSTALL PATH]\samples\Java

3. Select OK.

4. Select the Remote System Explorer button in the top-right corner of the main window, or select

Windows > Open Perspective > Other….

Figure 27 Selecting Remote System Explorer

5. Right-click on FX7500 in the left window and select Properties.

Figure 28 FX7500 Properties

Embedded Java Application

6. Select Host.

Figure 29 Host Properties

Embedded Java Application

7. Enter the Host name of the FX7500 (FX7500 + last 6 digits of the mac address or IP address).

8. In the Default User ID field, enter rfidadm.

9. Select OK.

10. Return to previous perspective by selecting the Java button in the top-right corner of the main window,

or by selecting Windows > Open Perspective > Other… .

11. Right-click on RFIDSample4App in the Package Explorer window and select Debug As > Debug

Configurations.

Embedded Java Application

Figure 30 Selecting Debug Configurations

12. Select RFIDSample4App under Remote Java Application.

Embedded Java Application

Figure 31 Selecting RFIDSample4App

13. Enter the Host name of the FX7500 (FX7500 + last 6 digits of the mac address or IP address) and click

Apply.

Figure 32 Entering Host Name

Embedded Java Application

14. Select Close.

Embedded Java Application

Building the Java Sample Application

15. Execute the shortcut FX Series RFID Reader Embedded SDK from the desktop to start the SDK.

Figure 33 Workspace Launcher

16. Select the workspace path of the Java sample application by clicking Browse... in the Workspace

Launcher window.

NOTE: The install path of the FX7500 Embedded SDK in this example is

C:\Zebra-FXSeries-Embedded-SDK. The Java sample application is in the following workspace folder:

[INSTALL PATH]\samples\Java

17. Select OK.

18. To compile the application select Build All or Build Project from the Project menu, or right-click the

project name RFIDSample4App in the Project Explorer on the left side of the main window and select Build Project.

Embedded Java Application

Figure 34 Building the Application

After the successful compilation, the Problems window at the bottom of the main window does not show any errors.

Figure 35 Problems Window

Embedded Java Application

Debugging the Java Sample Application

1. In the Package Explorer, open RFIDSample4App.java under RFIDSample4App > src > org > zebra >

RFIDSample4App.

Figure 36 Opening RFID Sample Application

2. Set a breakpoint in the main window by double-clicking the location of the blue circle at the source

code line (the blue circle indicates the breakpoint is active).

3. Select the Remote System Explorer button in the top-right corner of the main window, or select

Windows > Open Perspective > Other.

Figure 37 Selecting Remote System Explorer

4. Expand the FX7500 entry.

Embedded Java Application

Figure 38 Expanding FX Series Selection

5. Right-click on Ssh Terminals and select Launch Terminal.

Figure 39 Launching Terminal

6. If the Enter Password window appears, leave the Password field blank and check Save password.

Embedded Java Application

Figure 40 Enter Password Window

7. Select OK.

8. Select Yes or OK on any warning message windows regarding authentication and missing folders for

SSH handling. A window opens at the bottom of the main window with a prompt in the Home directory.

Figure 41 FX7500 Window

9. Return to the Java perspective by selecting the Java button in the top-right corner of the main window

or by selecting Windows > Open Perspective > Other….

10. Select Windows > Show View > Other… to open the Terminal window.

11. Select Remote Systems > Terminals.

Embedded Java Application

12. Select OK.

13. In the Terminal window, enter cd samples/Java/RFIDSample4App and select Enter to open the folder

~/samples/Java/RFIDSample4App.

14. In the Terminal window, enter sh ../RFIDSample4App_debug.sh and select Enter to start the debug

session on the device. After few seconds the Terminal window indicates the remote debug session has started.

NOTE: RFIDSample4App_debug.sh is created by the samples.sh as described in earlier, and configures

the Java debug environment and starts the debug session on the device. To re-use

RFIDSample4App_debug.sh to debug a new Java application, replace the Zebra sample app name

org.Zebra.RFIDSample4App.RFIDSampleApp with the new application Java class file name.

Figure 42 Renaming Sample Application

NOTE: Ensure port 8998 is not blocked by the firewall.

15. Click the debug symbol down arrow , located at the top of the window near the menus.

16. Select 1 RFIDSample4App.

Embedded Java Application

Figure 43 Selecting Sample Application

17. If the Enter Password window appears, leave the Password field blank and check Save password.

Figure 44 Enter Password Window

18. Select OK.

19. Select Yes or OK on any warning message windows regarding authentication and missing folders for

SSH handling.

Embedded Java Application

Figure 45 Confirm Perspective Switch Message

20. Select Yes to open the Debug perspective.

Figure 46 Debug Window

NOTE: To switch between the build perspective and the debug perspective, select the appropriate

button at the top right section of the main window, or select Windows > Open Perspective > Other.

21. Select Windows > Show View > Other… to open the Terminal window.

Embedded Java Application

22. Select Remote Systems > Terminals.

23. Select OK.

Figure 47 Terminals Window

24. Continue debugging by selecting the Go button at the top of the main window.

NOTE: Debugging stops at the main function due to breakpoint.

The Terminals window at the bottom of the main window shows the application output, which is a menu offering various functions.

Figure 48 Application Output

Embedded Java Application

25. Select 5. Exit to stop the application or the suspend debug button to interrupt the debug session.

www.zebra.com

Zebra FX7500 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Copyright

For Australia Only

Terms of Use

Revision History

Table of Contents

ABOUT THIS GUIDE

Introduction

Chapter Descriptions

Notational Conventions

Related Documents and Software

Service Information

Setting Up SDK for Debugging

Introduction

C and C++ Sample Application

Introduction

Connecting to the FX Series RFID Reader

Compiling the C and C++ Sample Application

Debugging the C and C++ Sample Application

Embedded Java Application

Introduction

Connecting to the FX Series RFID Reader

Building the Java Sample Application

Debugging the Java Sample Application
