Zebra ET56 Product Reference Guide

Download

ET51/56

Enterprise Tablet

Product Reference Guide

for

Android™10

MN-003876-05EN Rev. A

ZEBRA and the stylized Zebra head are trademarks of Zebra Technologies Corporation, registered in many jurisdictions worldwide. Google, Android, Google Play and other marks are trademarks of Google LLC. All other trademarks are the property of their respective owners. ©2020 Zebra Technologies Corporation and/or its affiliates. All rights reserved.

COPYRIGHTS & TRADEMARKS: For complete copyright and trademark information, go to

zebra.com/copyright

WARRANTY: For complete warranty information, go to zebra.com/warranty

END USER LICENSE AGREEMENT: For complete EULA information, go to zebra.com/eula

Terms of Use

• Proprietary Statement

This manual contains proprietary information of Zebra Technologies Corporation and its subsidiaries (“Zebra Technologies”). It is intended solely for the information and use of parties operating and maintaining the equipment described herein. Such proprietary information may not be used, reproduced, or disclosed to any other parties for any other purpose without the express, written permission of Zebra Technologies.

• Product Improvements

Continuous improvement of products is a policy of Zebra Technologies. All specifications and designs are subject to change without notice.

• Liability Disclaimer

Zebra Technologies takes steps to ensure that its published Engineering specifications and manuals are correct; however, errors do occur. Zebra Technologies reserves the right to correct any such errors and disclaims liability resulting therefrom.

• Limitation of Liability

In no event shall Zebra Technologies or anyone else involved in the creation, production, or delivery of the accompanying product (including hardware and software) be liable for any damages whatsoever (including, without limitation, consequential damages including loss of business profits, business interruption, or loss of business information) arising out of the use of, the results of use of, or inability to use such product, even if Zebra Technologies has been advised of the possibility of such damages. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

Revision History

Changes to the original guide are listed below:

Change Date Description

-01EN Rev A 10/2020 Initial release.

-02EN Rev. A 3/2021 Change charging LED from Orange to Blinking Amber.

-03EN Rev. A 9/2021 Correct hard reset key combo. Add new tall insert for Charge Only Cradle.

-04EN Rev. A 12/2021 Remove beep alert note on page 78.

-05EN Rev. A 8/2022 Remove USB Scanner using SSI section on page 33. Update cradle support

Update GMS Restricted section.

for ET5x with Integrated Scanner on page 103.

Table of Contents

Terms of Use................................................................................................................... 2

Revision History .............................................................................................................. 2

About This Guide.............................................................................................................................. 11

Configurations............................................................................................................... 11

Related Documents and Software ................................................................................ 12

Notational Conventions................................................................................................. 12

Icon Conventions .......................................................................................................... 13

Service Information ....................................................................................................... 13

Determining Software Versions..................................................................................... 13

Determining the Serial Number..................................................................................... 14

Getting Started.................................................................................................................................. 15

Introduction ................................................................................................................... 15

Unpacking ..................................................................................................................... 15

ET51/56 Features ......................................................................................................... 16

ET51 with Integrated Scanner Features ....................................................................... 18

Getting Started.............................................................................................................. 20

Installing a microSD Card....................................................................................... 20

Install the microSD Card .................................................................................. 21

Install the nano SIM Card................................................................................. 22

Charging the Battery............................................................................................... 25

Google Account Setup............................................................................................ 25

Turning Off the Tablet ................................................................................................... 25

Replacing the SIM Card................................................................................................ 25

Replacing the microSD Card......................................................................................... 26

Interactive Sensor Technology...................................................................................... 26

Turning Off the Display ................................................................................................. 26

Table of Contents

Using the Device............................................................................................................................... 27

Home Screen ................................................................................................................ 27

Setting Home Screen Rotation ............................................................................... 28

Status Bar............................................................................................................... 28

Notification Icons.............................................................................................. 29

Status Icons ..................................................................................................... 30

Managing Notifications ........................................................................................... 31

Opening the Quick Access Panel ........................................................................... 32

Quick Access Panel Icons................................................................................ 32

Editing Icons on the Quick Settings Bar ................................................................. 33

Battery Management..................................................................................................... 33

Checking Battery Status ......................................................................................... 33

Monitoring Battery Usage ....................................................................................... 34

Low Battery Notification.......................................................................................... 34

Interactive Sensor Technology...................................................................................... 34

Waking the Device ........................................................................................................ 34

USB Communication..................................................................................................... 35

Transferring Files.................................................................................................... 35

Transferring Photos ................................................................................................ 35

Disconnect from the Host Computer ...................................................................... 36

Settings.............................................................................................................................................. 37

Accessing Settings........................................................................................................ 37

Display Settings ............................................................................................................ 37

Setting the Screen Brightness Manually................................................................. 37

Setting the Screen Brightness Automatically.......................................................... 37

Setting Night Light .................................................................................................. 37

Setting Screen Rotation.......................................................................................... 38

Setting Screen Timeout .......................................................................................... 38

Lock Screen Display............................................................................................... 38

Setting Font Size .................................................................................................... 39

Touch Panel Mode ................................................................................................. 39

Setting the Date and Time ............................................................................................ 39

General Sound Setting.................................................................................................. 40

Sound Options........................................................................................................ 40

Remapping a Button ..................................................................................................... 41

Remappable Keys......................................................................................................... 41

Keyboards..................................................................................................................... 41

Keyboard Configuration.......................................................................................... 42

Enabling Keyboards ......................................................................................... 42

Switching Between Keyboards......................................................................... 42

Table of Contents

Using the Android and Gboard Keyboards............................................................. 42

Edit Text ........................................................................................................... 42

Entering Numbers, Symbols, and Special Characters ..................................... 42

Using the Enterprise Keyboard............................................................................... 42

Numeric Tab..................................................................................................... 43

Alpha Tab......................................................................................................... 43

Additional Character Tab ................................................................................. 43

Scan Tab.......................................................................................................... 43

Language Usage........................................................................................................... 43

Changing the Language Setting ............................................................................. 43

Adding Words to the Dictionary .............................................................................. 43

Notifications................................................................................................................... 44

Setting App Notifications ........................................................................................ 44

Viewing Notification Settings for All Apps ........................................................ 44

Controlling Lock Screen Notifications .............................................................. 44

Blink Light......................................................................................................... 45

Applications ...................................................................................................................................... 46

Accessing Apps............................................................................................................. 49

Switching Between Recent Apps............................................................................ 49

Battery Manager............................................................................................................ 49

Opening Battery Manager ...................................................................................... 49

Battery Manager Information Tab........................................................................... 50

Camera ......................................................................................................................... 52

Taking Photos......................................................................................................... 52

Taking a Panoramic Photo ..................................................................................... 53

Recording Videos ................................................................................................... 53

Photo Settings ........................................................................................................ 54

Rear Camera Photo Settings ........................................................................... 54

Front Camera Photo Settings........................................................................... 55

Video Settings ........................................................................................................ 56

Rear Camera Video Settings ........................................................................... 56

Front Camera Video Settings........................................................................... 57

DataWedge Demonstration........................................................................................... 57

Scanner Selection .................................................................................................. 58

RxLogger....................................................................................................................... 59

RxLogger Configuration.......................................................................................... 59

Configuration File ................................................................................................... 59

Enabling Logging.................................................................................................... 59

Disabling Logging ................................................................................................... 59

Extracting Log Files ................................................................................................ 59

Backing Up ............................................................................................................. 59

Table of Contents

RxLogger Utility ...................................................................................................... 60

Initiating the Main Chat Head........................................................................... 60

Removing the Main Chat Head ........................................................................ 60

Viewing Logs.................................................................................................... 60

Removing a Sub Chat Head Icon..................................................................... 60

Backing Up In Overlay View............................................................................. 60

Sound Recorder............................................................................................................ 60

VC Settings ................................................................................................................... 62

Display.................................................................................................................... 62

Screen Blanking ..................................................................................................... 62

Data Capture ..................................................................................................................................... 63

Imaging ......................................................................................................................... 63

Scanning Considerations .............................................................................................. 63

Expansion Back ............................................................................................................ 64

Integrated Scanner........................................................................................................ 64

RS507/RS507X Hands-Free Imager............................................................................. 64

RS5100 Ring Scanner .................................................................................................. 64

RS6000 Bluetooth Ring Scanner .................................................................................. 65

DS36X8 Digital Scanner ............................................................................................... 65

DS2278 Digital Scanner................................................................................................ 66

DS8178 Scanner........................................................................................................... 66

Scanning with SE4750 Expansion Back ....................................................................... 67

Scanning with the Integrated Scanner .......................................................................... 68

Scanning with RS507/RS507X Hands-Free Imager ..................................................... 69

Scanning with RS5100 Ring Scanner........................................................................... 70

Scanning with RS6000 Bluetooth Ring Scanner........................................................... 72

Scanning with the DS36X8 Scanner............................................................................. 73

Scanning with DS2278 Digital Scanner ........................................................................ 74

Scanning with DS8178 Digital Scanner ........................................................................ 75

Pairing the RS507/RS5100/RS6000 Ring Scanner ...................................................... 75

Pairing Using Simple Serial Interface (SSI)............................................................ 75

Pairing Using Bluetooth Human Interface Device .................................................. 76

Pairing a Bluetooth Scanner ......................................................................................... 77

Pairing Using Simple Serial Interface ..................................................................... 77

Pairing Using Bluetooth Human Interface Device .................................................. 77

Connecting a USB Scanner Using HID......................................................................... 78

DataWedge ................................................................................................................... 78

Enabling DataWedge.............................................................................................. 78

Disabling DataWedge............................................................................................. 79

Supported Decoders............................................................................................... 79

Table of Contents

Wireless............................................................................................................................................. 82

Wireless Wide Area Networks....................................................................................... 82

Sharing the Mobile Data Connection...................................................................... 82

Enabling USB Tethering................................................................................... 82

Enabling Bluetooth Tethering........................................................................... 83

Enabling Wi-Fi Hotspot .................................................................................... 83

Configuring the Wi-Fi Hotspot .......................................................................... 83

Data Usage............................................................................................................. 84

Setting Data Usage Warning............................................................................ 84

Setting Data Limit............................................................................................. 84

Cellular Network Settings ....................................................................................... 85

Data When Roaming........................................................................................ 85

Setting Preferred Network................................................................................ 85

Using Search for MicroCell .............................................................................. 85

Configuring the Access Point Name ................................................................ 85

Locking the SIM Card....................................................................................... 86

Wireless Local Area Networks ...................................................................................... 86

Connecting to a Wi-Fi Network............................................................................... 87

Removing a Wi-Fi Network..................................................................................... 87

WLAN Configuration ..................................................................................................... 87

Configuring a Secure Wi-Fi Network ...................................................................... 87

Manually Adding a Wi-Fi Network .......................................................................... 88

Configuring for a Proxy Server ............................................................................... 90

Configuring the Device to Use a Static IP Address ................................................ 90

Wi-Fi Preferences................................................................................................... 91

Additional Wi-Fi Settings ........................................................................................ 91

Wi-Fi Direct............................................................................................................. 92

Bluetooth....................................................................................................................... 92

Adaptive Frequency Hopping ................................................................................. 92

Security................................................................................................................... 93

Bluetooth Profiles ................................................................................................... 93

Bluetooth Power States .......................................................................................... 94

Bluetooth Radio Power........................................................................................... 94

Enabling Bluetooth ........................................................................................... 95

Disabling Bluetooth .......................................................................................... 95

Discovering Bluetooth Device(s) ............................................................................ 95

Changing the Bluetooth Name ............................................................................... 95

Connecting to a Bluetooth Device .......................................................................... 95

Selecting Profiles on the Bluetooth Device............................................................. 96

Unpairing a Bluetooth Device ................................................................................. 96

Cast............................................................................................................................... 96

Near Field Communications.......................................................................................... 96

Reading NFC Cards ............................................................................................... 97

Table of Contents

Enterprise NFC Settings......................................................................................... 97

Accessories....................................................................................................................................... 99

Introduction ................................................................................................................... 99

Battery Charging ......................................................................................................... 101

Main Battery Charging.......................................................................................... 101

Charging Temperature ......................................................................................... 102

Charge Only Cradle .................................................................................................... 103

Installing the Short Insert...................................................................................... 104

Installing the Tall Insert......................................................................................... 104

Charging the Device ............................................................................................. 105

Communication and Charging Cradle......................................................................... 107

Installing the Insert ............................................................................................... 108

Charging the Device ............................................................................................. 109

Rugged Communication and Charging Cradle ........................................................... 111

Charging the Device ............................................................................................. 112

4-Slot Charge Only Cradle.......................................................................................... 114

Power Setup ......................................................................................................... 115

Insert Installation .................................................................................................. 116

Battery Charger Installation .................................................................................. 118

Insert Tablet into Slot............................................................................................ 118

Device without Rugged Frame....................................................................... 118

Device with Rugged Frame............................................................................ 119

Battery Charger Installation .................................................................................. 120

Rugged Charge Connector ......................................................................................... 121

Power Pack................................................................................................................. 123

Charging the Power Pack..................................................................................... 124

Using Cradle .................................................................................................. 124

Using the 4-Slot Battery Charger ................................................................................ 125

Charging the Power Pack..................................................................................... 125

Rugged Frame ............................................................................................................ 127

Expansion Back .......................................................................................................... 130

Installation ............................................................................................................ 130

Replacement Hand Strap ..................................................................................... 132

Attaching the Stylus to the Expansion Back ......................................................... 136

Removal ............................................................................................................... 137

ET51 with Integrated Scanner Hand Strap ................................................................. 140

Removing the Hand Strap .................................................................................... 140

Installing the Hand Strap on the Back of the Device ............................................ 140

Installing the Hand Strap on the Side of the Device ............................................. 142

Table of Contents

Application Deployment................................................................................................................. 144

Security ....................................................................................................................... 144

Secure Certificates...................................................................................................... 144

Installing a Secure Certificate ..................................................................................... 144

Configuring Credential Storage Settings .............................................................. 145

Development Tools ..................................................................................................... 145

Android Application Development ........................................................................ 145

Development Workstation .............................................................................. 145

Enabling Developer Options .......................................................................... 145

EMDK for Android................................................................................................. 146

StageNow ............................................................................................................. 146

GMS Restricted........................................................................................................... 146

ADB USB Setup.......................................................................................................... 146

Enabling USB Debugging..................................................................................... 146

Entering Android Recovery Manually ................................................................... 147

Application Installation ................................................................................................ 147

Installing Applications Using the USB Connection ............................................... 148

Installing Applications Using the Android Debug Bridge ...................................... 148

Installing Applications Using a microSD Card ...................................................... 149

Uninstalling an Application ................................................................................... 149

Performing a System Update...................................................................................... 150

Downloading the System Update Package .......................................................... 150

Performing a System Update Using microSD Card.............................................. 150

Performing a System Update Using ADB............................................................. 150

Verifying System Update Installation.................................................................... 151

Enterprise Reset ......................................................................................................... 151

Performing an Enterprise Reset From Device Settings........................................ 152

Downloading the Enterprise Reset Package ........................................................ 152

Performing an Enterprise Reset Using microSD Card ......................................... 152

Performing an Enterprise Reset Using ADB......................................................... 152

Performing a Factory Reset ........................................................................................ 153

Downloading the Factory Reset Package ............................................................ 153

Performing a Factory Reset Using microSD Card................................................ 153

Performing a Factory Reset Using ADB ............................................................... 154

Storage........................................................................................................................ 155

Random Access Memory ..................................................................................... 155

Viewing Memory............................................................................................. 155

Internal Storage .................................................................................................... 155

Viewing Internal Storage ................................................................................ 155

External Storage................................................................................................... 156

Viewing External Storage............................................................................... 156

Formatting a microSD Card ........................................................................... 156

Table of Contents

Formatting a microSD Card as Internal Memory............................................ 156

Enterprise Folder .................................................................................................. 156

Managing Apps ........................................................................................................... 156

App Details ........................................................................................................... 157

Managing Downloads.................................................................................................. 157

Maintenance and Troubleshooting ............................................................................................... 158

Introduction ................................................................................................................. 158

Maintaining the Device................................................................................................ 158

Battery Safety Guidelines............................................................................................ 158

Cleaning Instructions................................................................................................... 159

Approved Cleanser Active Ingredients ................................................................. 159

Harmful Ingredients .............................................................................................. 160

Device Cleaning Instructions ................................................................................ 160

Special Cleaning Notes ........................................................................................ 160

Cleaning Materials Required ................................................................................ 160

Cleaning Frequency ............................................................................................. 160

Cleaning Battery Connectors................................................................................ 161

Troubleshooting .......................................................................................................... 162

Resetting the Device ............................................................................................ 162

Performing a Soft Reset................................................................................. 162

Performing a Hard Reset ............................................................................... 162

Charge Only Cradle.............................................................................................. 163

Communication and Charging Cradles................................................................. 163

Expansion Backs .................................................................................................. 164

4-Slot Charge Only Cradle ................................................................................... 165

Charging Adapter ................................................................................................. 165

4-Slot Battery Charger.......................................................................................... 166

Specifications ................................................................................................................................. 167

Technical Specifications.............................................................................................. 167

SE4750 Expansion Back Decode Range.................................................................... 167

Integrated Scanner Decode Zones ............................................................................. 168

Accessory Specifications ............................................................................................ 168

Charge Only Cradle.............................................................................................. 168

Communication and Charging Cradle .................................................................. 169

Rugged Communication and Charging Cradle..................................................... 169

Expansion Backs .................................................................................................. 170

About This Guide

This guide provides information about setting up and using the ET51 and ET56 tables with the Android ™ 10 operating system. Some screens shown in this guide may differ from the actual screens shown on the device.

Configurations

This guide covers the following configurations:

Table 1 Configurations

Configuration

ET51CE Android 10 WLAN:

ET51CE with Integrated Scanner

ET51CT Android 10 WLAN:

Operating

System

802.11a/b/g/n/ac/d/h/i/k/r

WPAN: Bluetooth

Android 10 WLAN:

802.11a/b/g/n/ac/d/h/i/k/r

WPAN: Bluetooth

802.11a/b/g/n/ac/d/h/i/k/r

WPAN: Bluetooth

Radios Display Memory Data Capture

8.4 in. color

10.1” color

4 GB RAM/ 32 GB Flash

Camera, SE4750 Expansion Back, Ring Scanners. Bluetooth Scanners, and USB Scanners.

Camera, integrated scanner, Ring Scanners. Bluetooth Scanners, and USB Scanners.

Camera, SE4750 Expansion Back, Ring Scanners. Bluetooth Scanners, and USB Scanners.

Table 1 Configurations (Continued)

Configuration

ET56DE Android 10 WLAN:

ET56DT Android 10 WLAN:

ET56ET Android 10 WLAN:

Operating

System

Radios Display Memory Data Capture

802.11a/b/g/n/ac/d/h/i/k/r

WPAN: Bluetooth

WWAN: LTE

802.11a/b/g/n/ac/d/h/i/k/r

WPAN: Bluetooth

WWAN: LTE

802.11a/b/g/n/ac/d/h/i/k/r

WPAN: Bluetooth

WWAN: LTE

Notational Conventions

Notational conventions are used to highlight important information.

• Bold text is used to highlight the following:

• Dialog box, window and screen names

• Drop-down list and list box names

• Check box and radio button names

• Icons on a screen

• Key names on a keypad

• Button names on a screen

• Bullets (•) indicate:

• Action items

• Lists of alternatives

• Lists of required steps that are not necessarily sequential.

• Sequential lists (for example, those that describe step-by-step procedures) appear as numbered lists.

Icon Conventions

The following icons are used throughout the document. The icons and their associated meanings are described below.

NOTE: The text here indicates information that is supplemental for the user to know and that is not required to complete a task.

IMPORTANT: The text here indicates information that is important for the user to know.

CAUTION: If the precaution is not heeded, the user could receive minor or moderate injury.

WARNING: If danger is not avoided, the user CAN be seriously injured or killed.

DANGER: If danger is not avoided, the user WILL be seriously injured or killed.

Service Information

If you have a problem with your equipment, contact Customer Support for your region. Contact information is available at: zebra.com/support

When contacting support, please have the following information available:

• Serial number of the unit (found on manufacturing label)

• Model number or product name (found on manufacturing label)

• Software type and version number

• IMEI number

Customer Support responds to calls by email or telephone within the time limits set forth in support agreements.

If the problem cannot be solved by Customer Support, the user may need to return the equipment for servicing and will be given specific directions. We are not responsible for any damages incurred during shipment if the approved shipping container is not used. Shipping the units improperly can possibly void the warranty. If applicable, remove the SIM card and/or microSD card from the device before shipping for service.

If the device was purchased from a business partner, contact that business partner for support.

Determining Software Versions

Before contacting Customer Support, determine the current software version on your device.

1. Swipe down from the Status bar with two fingers to open the Quick Access panel, and then touch .

2. Touch About phone.

3. Scroll to view the following information:

• Battery information

• Emergency information

• SW components

• Legal information

• Model & hardware

• Android version

• Android security patch level

• Android security patch version

• Baseband version

• Kernel version

• Build number

To determine the device IMEI information (WWAN only), touch About phone > IMEI.

• IMEI - Displays the IMEI number for the device.

• IMEI SV - Displays the IMEI SV number for the device.

Determining the Serial Number

Before contacting Customer Support, determine the serial number of your device.

1. Swipe down from the Status bar with two fingers to open the Quick Access panel, and then touch .

2. Touch About phone > Model & hardware > Serial number.

Getting Started

Introduction

This chapter explains how to set the device up for the first time.

Unpacking

Carefully remove all protective material from around the tablet and save the shipping container for later storage and shipping.

Verify that you received all equipment listed below:

• Tablet with lithium-ion battery

• Quick Reference Guide

• Additional hand strap screws (ET51 Enterprise Tablet with integrated Scanner only).

• Cradle caps (ET51 Enterprise Tablet with integrated Scanner only).

Inspect the equipment for damage. If you are missing any equipment or if you find any damaged equipment, contact the Zebra Support Center immediately. See Service Information on page 13 for contact information.

ET51/56 Features

Figure 1 ET51/ET56 Front View

Getting Started

8.4 in. version

Table 2 ET51/ET56 Front View

Item Description

1 Ambient Light Sensor - Recognizes the ambient light and adjusts the display brightness

(if enabled).

2 Dual Front-Facing Microphones - Use for voice communications for audio recordings.

3 Front Facing Camera - Use for video conferencing or capturing images and video.

4 Notification LED - Lights blue when an application sends a notification.

5 Charging Indicator LED - Indicates charging status.

• Off - device is not connected to charger.

• Blinking Amber - device is charging.

• Green - device is connected and fully charged.

• Red - charge error.

10.1 in. version

Figure 2 ET51/ET56 Back View

Getting Started

Table 3 ET51/ET56 Back View

Item Description

6 Rear Camera - Auto-focus camera for capturing high resolution images and video.

7 Camera LED Flash - Provides illumination for the camera.

8 Power Button - Push once to start the device; push it again to enable sleep mode. Push and

hold it to shut down the tablet.

9 Volume Key - Push the left side to reduce the volume. Press the right side to increase the

volume.

10 USB-C / Display - Provides communications with a host computer using a USB-C cable or a

video monitor using a third-party adapter.

11 Battery Cover - Covers the replaceable battery.

Getting Started

Figure 3 ET51/ET56 Bottom View

8.4 in. Version

Table 4 Bottom View

Item Description

12 NFC Antenna Position - Use to read NFC cards.

13 Stereo Speakers - Provides audio playback.

14 Alignment Holes - Use to align tablet with cradle

15 Latching Slots - Insertion point for Communication and Charging cradle locks.

16 Charging Pins - Contact point for cradle charging.

17 Docking Connector - Interfaces with the cradle.

10.1 in. Version

ET51 with Integrated Scanner Features

Figure 4 ET51 with Integrated Scanner Front View

Getting Started

Table 5 ET51 with Integrated Scanner Front View

Item Description

1 Adjustable Hand Strap - Use to securely hold the device in your hand.

2 Exit Window - Provides data capture using the imager.

3 Ambient Light Sensor - Recognizes the ambient light and adjusts the display brightness

(if enabled).

4 Dual Front-Facing Microphones - Use for voice communications for audio recordings.

5 Front Facing Camera - Use for video conferencing or capturing images and video.

6 Power Button - Push once to start the device; push it again to enable sleep mode. Push

and hold it to shut down the device.

7 Volume Key - Press the left side to reduce the volume. Press the right side to increase

the volume.

8 USB-C Port - Use to charge the device using a USB-C cable and power supply.

9 Charging Indicator LED - Indicates charging status.

• Off - device is not connected to charger.

• Blinking Amber - device is charging.

• Green - device is connected and fully charged.

• Red - charge error.

10 Notification LED - Lights blue when an application sends a notification.

Figure 5 ET51 with Integrated Scanner Back View

Table 6 ET51 with Integrator Scanner Back View

Item Description

11 Back Cover - Covers the replaceable battery.

12 NFC Antenna Position - Use to read NFC cards.

13 Scan Button - Initiates barcode data capture when a scan-enabled application is active.

14 Rear Camera - Use for high resolution images and video.

15 Camera LED Flash - Provides illumination for the camera.

16 Stereo Speakers - Provides audio playback.

17 Docking Connector - Interfaces with the cradle.

Getting Started

In order to start using the device for the first time:

• Install microSD card

• Install nano SIM Card (ET56 only)

Getting Started

• Charge the device

• Perform basic configuration.

Installing a microSD Card

To install a microSD card:

1. Press and hold the Power button until the menu appears.

2. Touch Power off.

3. Lift the notched corner of the battery cover and carefully lift the battery cover off the device.

4. On the 8.4 in. version, push the two locking tabs up, then pull up on the tab to remove battery.

On the 10.1 in. version, push the two locking tabs up (1), then lift the battery up (2).

Getting Started

Figure 6 Removing the Battery - 8.4 in.

1 Locking tabs

2 Pull tabs

Figure 7 Removing the Battery - 10.1 in.

Install the microSD Card

1. Insert the microSD card with contacts facing down; 8.4 in. version shown here.

Figure 8 Inserting microSD Card

Getting Started

8.4 in. Version

2. Push the micro SD card in and ensure that it locks into place.

Install the nano SIM Card

NOTE: ET56 only.

To install the nano SIM card:

1. Insert the nano SIM card with contacts facing down.

Figure 9 Inserting the nano SIM Card - 8.4 in.

10.1 in. Version

NANO

Getting Started

NANO

Figure 10 Inserting the nano SIM Card - 10.1 in.

2. Push the SIM card in and ensure that it locks into place.

3. Replace the battery.

4. Press the battery down to ensure the two battery latches engage.

CAUTION: Be aware of the orientation of the battery cover. Failure to replace the battery cover properly

may damage the battery cover.

5. Align the tabs on the underside of the cover with the slot around the battery well. Make sure that the

notch on the battery cover is at the bottom left cover of the device.

Getting Started

Carefully press down around the edge of the cover. Make sure that the cover is seated properly.

7. Press Power button to turn on the device.

Charging the Battery

Use one of the cradles to charge the main battery installed in the device. See the Accessories for charging accessories.

The 8.4 in. tablet main battery charges from fully depleted to 90% in approximately 2.5 hours and from fully depleted to 100% in approximately 3.5 hours.

The 10.1 in. tablet main battery charges from fully depleted to 90% in approximately three hours and from fully depleted to 100% in approximately four hours.

NOTE: The Charging indicator only illuminates when the tablet is connected to AC power.

Google Account Setup

NOTE: The device has to be connected to the internet in order to set up a Google ™ account.

A Google account is only required on devices with GMS software.

The first time the device starts, the Setup Wizard displays. Follow the on-screen instructions to set up a Google account, configure Google Pay personal information, and enable backup/restore features.

Getting Started

™ for purchasing items from the Google Play ™ store, to enter your

Turning Off the Tablet

NOTE: After the device is powered off and external power is applied to the device, the device will

automatically power on. This includes powered cradles, Expansion Back with Power Pack, Rugged Charge Connector, and power supply/USB-C cable.

To turn off the device:

1. Press and hold the power button until the menu appears.

2. Touch Power off.

Replacing the SIM Card

NOTE: ET56 only.

CAUTION: To avoid damage to the SIM slot, do not pull the SIM card out of the SIM slot. Push the SIM

card in to eject it.

To replace the SIM card:

1. Press and hold the Power button until the menu appears.

2. Touch Power off.

3. Lift the notched corner of the battery cover and carefully lift the battery cover off the device.

4. On the 8.4 in. version, push the two locking tabs up, then pull up on the tab to remove battery.

On the 10.1 in. version, push the two locking tabs up, then lift the battery up.

5. Push in the SIM card and release. The card eject slightly.

6. Remove the SIM card from the card slot. The card should easily slide out. If not, the SIM card was not

ejected correctly. Repeat step 5.

Replace the battery.

8. Press the battery down to ensure the two battery latches engage.

9. Replace the battery cover.

Replacing the microSD Card

CAUTION: To avoid damage to the microSD card slot, do not pull the microSD card out of the microSD

Card slot. Push the microSD card in to eject it.

To replace the microSD card:

1. Press and hold the Power button until the menu appears.

2. Touch Power off.

3. Lift the notched corner of the battery cover and carefully lift the battery cover off the device.

4. On the 8.4 in. version, push the two locking tabs up, then pull up on the tab to remove battery.

On the 10.1 in. version, push the two locking tabs up, then lift the battery up.

5. Push in the SIM card and release. The card eject slightly.

Getting Started

6. Remove the microSD card from the card slot. The card should easily slide out. If not, the microSD card

was not ejected correctly. Repeat step 5.

7. Insert the replacement microSD card with contacts facing down.

8. Push the microSD card in and ensure that it locks into place.

9. Replace the battery.

10. Press the battery down to ensure the two battery latches engage.

11. Replace the battery cover.

Interactive Sensor Technology

The device contains sensors that monitor movement, orientation and ambient light:

• Gyroscope - Measures angular rotational velocity to detect rotation of the device.

• Accelerometer - Measures the linear acceleration of movement to detect the orientation of the device.

• Digital Compass - The digital compass or magnetometer provides simple orientation in relation to the

Earth's magnetic field. As a result, the device always knows which way is North so it can auto rotate digital maps depending on the physical orientation of the device.

• Light Sensor - Detects ambient light and adjusts the screen brightness.

In order to take advantage of these sensors, applications use API commands. Refer to the Zebra Android EMDK for more information.

Turning Off the Display

To turn off the display press and release the power button.

Using the Device

Home Screen

Turn on the device to display the Home screen. Depending on how your system administrator configured your device, your Home screen may appear differently than the graphics in this section.

After a suspend or screen time-out, the Home screen displays with the lock slider. Touch the screen and slide up to unlock.

The Home screen provides four additional screens to place widgets and shortcuts. Swipe the screen left or right to view the additional screens.

NOTE: By default, AOSP devices do not have the same icons on the Home screen as GMS devices. Icons are shown below for example only.

Home screen icons can be configured by the user and may look different than shown.

Figure 11 Home Screen (ET56 Shown)

1 Status Bar Displays the time, status icons (right side), and notification icons (left side).

For more information see Notification Icons on page 29 and Managing

Notifications on page 31.

2 Widgets Launches stand-alone apps that run on the Home screen.

3 Shortcut Icons Opens apps installed on the device.

4 Folder Contains apps.

5 Back Displays the previous screen.

6 Home Displays the Home screen.

7 Recent Displays recently used applications.

Setting Home Screen Rotation

By default, the Home screen rotation is disabled.

1. Touch and hold anywhere on the Home screen until the options appear.

2. Touch Home settings.

3. Touch the Allow Home screen rotation switch.

Using the Device

4. Touch the Home button.

5. Rotate the device.

Status Bar

The Status bar displays the time, notification icons (left side), and status icons (right side).

If there are more notifications than can fit in the Status bar, a dot displays indicating that more notifications exist. Swipe down from the Status bar to open the Notification panel and view all notifications and status.

Figure 12 Notification and Status Icons

1 Notification Icons. See Notification Icons on page 29.

2 Status Icons. See Status Icons on page 30.

Notification Icons

Notification icons indicate app events and messages.

Table 7 Notification Icons

Icon Description

Main battery is low.

More notifications are available for viewing.

Data is syncing.

Indicates an upcoming event. AOSP devices only.

Indicates an upcoming event. GMS devices only.

Open Wi-Fi network is available.

Audio is playing.

Using the Device

Problem with sign-in or sync has occurred.

Device is uploading data.

Animated: the device is downloading data. Static: the download is complete.

Device is connected to or disconnected from a virtual private network (VPN).

Preparing internal storage by checking it for errors.

USB debugging is enabled on the device.

Wired headset with a boom module is connected to the device.

Wired headset without a boom module is connected to the device.

PTT Express Voice client status. See the PTT Express PTT Notification Icons for a complete list.

Indicates the RxLogger app is running.

Indicates the Bluetooth scanner is connected to the device.

Indicates the ring scanner is connected to the device in HID mode.

Status Icons

Status icons display system information for the device.

Table 8 Status Icons

Icon Description

Using the Device

Alarm is active.

Main battery is fully charged.

Main battery is partially drained.

Main battery charge is low.

Main battery charge is very low.

Main battery is charging.

All sounds, except media and alarms, are muted. Vibrate mode is active.

Do Not Disturb mode active.

Airplane Mode is active. All radios are turned off.

Bluetooth is on.

The device is connected to a Bluetooth device.

Connected to a Wi-Fi network. Indicates the Wi-Fi version number.

Not connected to a Wi-Fi network or no Wi-Fi signal.

Connected to an Ethernet network.

Speakerphone enabled.

Portable Wi-Fi hotspot is active (WWAN only).

Connected to a 4G LTE/LTE-CA network (WWAN only)

Connected to a DC-HSPA, HSDPA, HSPA+, HSUPA, LTE/LTE-CA or WCMDMA

network (WWAN only)

Connected to a WCDMA network (WWAN only)

Connected to a DC - HSPA, HSDPA, HSPA+ or HSUPA network (WWAN only)1.

Connected to an EDGE network (WWAN only)

Cellular network icon that appears is dependent upon the carrier/network.

Table 8 Status Icons (Continued)

Icon Description

Connected to a GPRS network (WWAN only)

Roaming from a network (WWAN only).

No SIM card installed (WWAN only).

Cellular network icon that appears is dependent upon the carrier/network.

Managing Notifications

Notification icons report the arrival of new messages, calendar events, alarms, and ongoing events. When a notification occurs, an icon appears in the Status bar with a brief description. See Notification Icons on

page 29 for a list of possible notification icons and their description.

• To view a list of all notifications, open the Notification panel by dragging the Status bar down from the

top of the screen.

Figure 13 Notification Panel

Using the Device

Quick Settings Bar

• To respond to a notification, open the Notification panel and then touch a notification. The Notification

panel closes and the corresponding app opens.

• To manage recent or frequently used notifications, open the Notification panel and then touch Manage

notifications. Touch the toggle switch next to an app to turn off all notifications, or touch an app for

more notification options.

• To clear all notifications, open the Notification panel and then touch CLEAR ALL. All event-based

notifications are removed. Ongoing notifications remain in the list.

• To close the Notification panel, swipe the Notification panel up.

Using the Device

Opening the Quick Access Panel

Use the Quick Access panel to access frequently used settings (for example, Airplane mode). To get to the Quick Access Panel:

• If the device is locked, swipe down once.

• If the device is unlocked, swipe down once with two fingers, or twice with one finger.

• If the Notification panel is open, swipe down from the Quick Settings bar.

Figure 14 Quick Access Panel

NOTE: Not all icons are pictured. Icons may vary.

Quick Access Panel Icons

• Display brightness - Use the slider to decrease or increase the brightness of the screen.

• Wi-Fi network - Turn Wi-Fi on or off. To open Wi-Fi settings, touch the Wi-Fi network name.

• Bluetooth settings - Turn Bluetooth on or off. To open Bluetooth settings, touch Bluetooth.

• Battery saver - Turn Battery saver mode on or off. When Battery saver mode is on the performance of

the device is reduced to preserve battery power.

• Invert colors - Invert the display colors.

• Do not disturb - Control how and when to receive notifications.

• Mobile data - Turns cellular radio on or off. To open Mobile data settings, touch and hold (WWAN only).

• Airplane mode - Turn Airplane mode on or off. When Airplane mode is on the device does not connect

to Wi-Fi or Bluetooth.

• Auto-rotate - Lock the device’s orientation in portrait or landscape mode or set to automatically rotate.

• Flashlight - Turn flashlight on or off. Turn camera flash on or off.

Using the Device

• Location - Enable or disable locationing feature.

• Hotspot - Turn on to share the device’s mobile data connection with other devices.

• Data Saver - Turn on to prevent some apps from sending or receiving data in the background.

• Night Light - Tint the screen amber to make it easier to look at the screen in dim light. Set Night Light to

turn on automatically from sunset to sunrise, or at other times.

• Screen Cast - Share phone content on Chromecast or a television with Google Cast built-in. Touch cast

screen to display a list of devices, then touch a device to begin casting.

• Dark Theme - Toggles dark theme on and off. Dark themes reduce the luminance emitted by the

screen, while meeting minimum color contrast ratios. It helps improve visual ergonomics by reducing eye strain, adjusting brightness to current lighting conditions, and facilitating screen use in dark environments, while conserving battery power.

• Focus mode - Turn on to pause distracting apps. To open Focus mode settings, touch and hold.

• Bedtime mode - Turn grayscale on and off. Grayscale turns the screen black and white, reducing phone

distractions and improving battery life.

• Nearby Share - Helps find and interact with services and devices close to the device.

Editing Icons on the Quick Settings Bar

The first several setting tiles from the Quick Access panel become the Quick Settings bar.

Open the Quick Access panel and touch to edit, add, or remove settings tiles.

Battery Management

Observe the recommended battery optimization tips for your device.

• Set the screen to turn off after a short period of non-use.

• Reduce screen brightness.

• Turn off all wireless radios when not in use.

• Turn off automatic syncing for Email, Calendar, Contacts, and other apps.

• Minimize use of apps that keep the device from suspending, for example, music and video apps.

NOTE: Before checking the battery charge level, remove the device from any AC power source (cradle or

cable).

Checking Battery Status

• Open Settings and touch About phone > Battery Information.

Or, swipe up from the bottom of the screen and touch to open the Battery Manager app. See

Battery Manager on page 49.

• Battery present status indicates if the battery is present.

• Battery level lists the battery charge (as a percentage of fully charged).

• Swipe down with two fingers from the status bar to open the quick access panel.

• Battery percentage is displayed next to the battery icon.

Monitoring Battery Usage

The Battery screen provides battery charge details and power management options to extend battery life.

1. Go to Settings.

2. Touch Battery.

Display battery information and power management options for a specific app.

1. Go to Settings.

2. Touch Apps & notifications.

3. Touch an app.

4. Touch Advanced > Battery.

Different apps display different information. Some apps include buttons that open screens with settings to adjust power use. Use the DISABLE or FORCE STOP buttons to turn off apps that consume too much power.

Low Battery Notification

When the battery charge level drops below 18%, the device displays a notice to connect the device to power. The user should charge the battery using one of the charging accessories.

Using the Device

When the battery charge drops below 10%, the device displays a notice to connect the device to power. The user must charge the battery using one of the charging accessories.

When the battery charge drops below 4%, the device turns off. The user must charge the battery using one of the charging accessories.

Interactive Sensor Technology

The device contains sensors that monitor movement, orientation and ambient light.

• Gyroscope - Measures angular rotational velocity to detect rotation of the device.

• Accelerometer - Measures the linear acceleration of movement to detect the orientation of the device.

• Digital Compass - The digital compass or magnetometer provides simple orientation in relation to the

Earth's magnetic field. As a result, the device always knows which way is North so it can auto rotate digital maps depending on the physical orientation of the device.

• Light Sensor - Detects ambient light and adjusts the screen brightness.

In order to take advantage of these sensors, applications use API commands. Refer to the Google Android Sensor APIs for more information. For information on the Zebra Android EMDK, go to:

techdocs.zebra.com

Waking the Device

The device goes into Suspend mode when you press the Power button or after a period of inactivity (set in the Display settings window).

1. To wake the device from Suspend mode, press the Power button.

The Lock screen displays.

2. Swipe the screen up to unlock.

• If the Pattern screen unlock feature is enabled, the Pattern screen appears instead of the Lock screen.

• If the PIN or Password screen unlock feature is enabled, enter the PIN or password after unlocking the screen.

NOTE: If you enter the PIN, password, or pattern incorrectly five times, you must wait 30 seconds before trying again.

If you forget the PIN, password, or pattern contact your system administrator.

USB Communication

Connect the device to a host computer to transfer files between the device and the host computer.

When connecting the device to a host computer, follow the host computer’s instructions for connecting and disconnecting USB devices, to avoid damaging or corrupting files. For information on USB communication accessories available for this device, see Accessories.

Transferring Files

Using the Device

Use Transfer files to copy files between the device and the host computer.

1. Connect the device to a host computer using a USB accessory.

2. On the device, pull down the Notification panel and touch Charging this device via USB.

By default, No data transfer is selected.

3. Touch File Transfer.

4. On the host computer, open a file explorer application.

5. Locate the device as a portable device.

6. Open the Internal storage folder.

7. Copy files to and from the device or delete files as required.

Transferring Photos

Use PTP to copy photos from the device to the host computer.

1. Connect the device to a host computer using a USB accessory.

2. On the device, pull down the Notification panel and touch Charging this device via USB.

3. Touch PTP.

4. On the host computer, open a file explorer application.

5. Open the Internal storage folder.

6. Copy or delete photos as required.

Using the Device

Disconnect from the Host Computer

Carefully follow the host computer’s instructions to disconnect USB devices correctly to avoid losing information.

To disconnect the device from the host computer:

1. On the host computer, unmount the device.

2. Remove the device from the USB accessory.

Settings

Accessing Settings

There are multiple ways to access settings on a device.

• Swipe down with two fingers from the top of the Home screen to open the Quick Access panel and touch .

• Double-swipe down from the top of the Home screen to open the Quick Access panel and touch .

• Swipe up from the bottom of the Home screen to open APPS and touch Settings.

Display Settings

Use Display settings to change the screen brightness, enable night light, change the background image, enable screen rotation, set sleep time, and change font size.

Setting the Screen Brightness Manually

Manually set the screen brightness using the touchscreen.

1. Swipe down with two fingers from the Status bar to open the Quick Access panel.

2. Slide the icon to adjust the screen brightness level.

Setting the Screen Brightness Automatically

Automatically adjust the screen brightness using the built-in light sensor.

1. Go to Settings.

2. Touch Display.

3. If disabled, touch Adaptive brightness to automatically adjust the brightness.

By default, Adaptive brightness is enabled. Toggle the switch to disable.

4. Touch the Home button.

Setting Night Light

The Night Light setting tints the screen amber, making the screen easier to look at in low light.

1. Go to Settings.

2. Touch Display.

Touch Night Light.

4. Touch Schedule.

5. Select one of the schedule values:

• None (default)

• Turns on at custom time

• Turns on from sunset to sunrise.

6. By default, Night Light is disabled. Touch TURN ON NOW to enable.

7. Adjust the tint using the Intensity slider.

8. Touch the Home button.

Setting Screen Rotation

By default, screen rotation is enabled.

1. Go to Settings.

2. Touch Display > Advanced.

Settings

3. Touch Auto-rotate screen.

NOTE: To change the Home screen rotation, see Setting Home Screen Rotation on page 28.

4. Touch the Home button.

Setting Screen Timeout

Set the screen sleep time.

1. Go to Settings.

2. Touch Display > Advanced > Screen timeout.

3. Select one of the sleep values.

• 15 seconds

• 30 seconds

• 1 minute (default)

• 2 minutes

• 5 minutes

• 10 minutes

• 30 minutes

4. Touch the Home button.

Lock Screen Display

The lock screen display setting wakes the screen when notifications are received.

1. Go to Settings.

2. Touch Display > Advanced.

Touch Lock screen display.

4. In the When to show section, enable or disable an option using the switch.

5. Touch the Home button.

Setting Font Size

Set the size of the font in system apps.

1. Go to Settings.

2. Touch Display > Advanced.

3. Touch Font size.

4. Select one of the font size values.

• Small

• Default

• Large

• Largest.

Settings

5. Touch the Home button.

Touch Panel Mode

The device display is able to detect touches using a finger, a conductive-tip stylus, or gloved finger.

NOTE: A glove can be made of medical latex, leather, cotton, or wool. For optimal performance use a Zebra certified stylus.

1. Go to Settings.

2. Touch Display > Advanced.

3. Touch Touch panel mode.

4. Select:

• Finger Only Mode - Moisture optimized - Rain Mode to use a finger on the screen and when the

device may have water on the screen.

• Stylus and Finger to use a finger or a stylus on the screen.

• Finger and Stylus to use a finger or a stylus on the screen.

• Finger and Glove to use a finger or a gloved finger on the screen.

• Glove and Finger to use a finger or a gloved finger on the screen.

5. Touch the Home button.

Setting the Date and Time

The date and time is automatically synchronized using an NITZ server when the device is connected to a wireless network. You are only required to set the time zone or set the date and time if the wireless LAN does not support Network Time Protocol (NTP) or when not connected to a wireless network.

1. Go to Settings.

2. Touch System > Date & time.

Settings

Touch Use network-provided time to disable automatic date and time synchronization.

4. Touch Use network-provided time zone to disable automatic time zone synchronization.

5. Touch Update Interval.

6. Select the interval time to synchronize your device time from the network.

7. Touch Date.

8. In the calendar, set today’s date.

9. Touch OK.

10. Touch Time.

11. Touch the green circle, drag to the current hour and then release.

12. Touch the green circle, drag to the current minute and then release.

13. Touch AM or PM.

14. Touch OK.

15. Touch Time zone.

16. Select the current time zone from the list.

17. Touch Use 24-hour format.

18. Touch the Home button.

General Sound Setting

Use the Sound settings to configure media and alarm volumes.

1. Go to Settings.

2. Touch Sound.

3. Touch an option to set sounds.

Sound Options

• Zebra volume controls

• Ring volume - Controls the ringtone volume.

• Media volume - Controls the music, games, and media volume.

• Alarm volume - Controls the alarm clock volume.

• Notifications volume - Controls the notification volume.

• In call volume - Controls the volume during a call.

• Scanner volume - Controls the scanner volume.

• Volume presets

• - Mutes the ring, notifications, and scanner so that the device does not make sounds or vibrate.

• - All sounds except media and alarms are silenced and vibrate mode is active.

• - Enables all sounds at the user defined levels.

• Do Not Disturb - Mutes some or all sounds and vibrations.

• Shortcut to prevent ringing - Select how the shortcut method prevents ringing.

• Default notification sound - Select a sound to play for all system notifications.

• Default alarm sound - Select a sound to play for alarms.

• Other sounds and vibrations

• Screen locking sounds - Play a sound when locking and unlocking the screen (default – enabled).

• Charging sounds and vibration - Plays a sound and vibrates when power is applied to the device

(default - enabled).

• Touch sounds - Play a sound when making screen selections (default – enabled).

• Touch vibration - Vibrate the device when making screen selections (default – disabled).

• Wireless Emergency alerts - Touch to configure emergency broadcast settings and notifications.

Remapping a Button

Buttons on the device can be programmed to perform different functions or as shortcuts to installed apps. For a list of key names and descriptions, refer to: techdocs.zebra.com

1. Go to Settings.

2. Touch Key Programmer. A list of programmable buttons displays.

Settings

3. Select the button to remap.

4. Touch the BUTTON REMAPPING tab or the SHORTCUT tab that lists the available functions and

applications.

5. Touch a function or application shortcut to map to the button.

NOTE: If you select an application shortcut, the application icon appears next to the button on the Key

Programmer screen.

6. Touch the Home button.

Remappable Keys

Figure 15 Key Positions

VOLUME_DOWN

VOLUME_UP

• VOLUME_DOWN - Volume down button.

• VOLUME_UP - Volume up button.

Keyboards

The device provides multiple keyboard options.

• Enterprise Keyboard

NOTE: By default the Enterprise and Virtual Keyboards are disabled.

Keyboard Configuration

Enabling Keyboards

1. Go to Settings.

2. Touch System > Languages & input > Virtual keyboard > Manage keyboards.

3. Touch a keyboard to enable.

Switching Between Keyboards

• To switch between keyboards, touch in a text box to display the current keyboard.

• On the Gboard keyboard, touch and hold (GMS devices only).

• On the Android keyboard, touch and hold (AOSP devices only).

• On the Enterprise keyboard, touch . Only available with Mobility DNA Enterprise License.Not

pre-installed on the device. Contact Zebra Support for more information.

Settings

Using the Android and Gboard Keyboards

Use the Android or Gboard keyboards to enter text in a text field.

To configure the keyboard settings, touch and hold

Edit Text

Edit entered text and use menu commands to cut, copy, and paste text within or across apps. Some apps do not support editing some or all of the text they display; others may offer their own way to select text.

Entering Numbers, Symbols, and Special Characters

1. Enter numbers and symbols.

• Touch and hold one of the top-row keys until a menu appears then select a number or special character.

• Touch the Shift key once for a single capital letter. Touch the Shift key twice to lock in uppercase. Touch

the Shift key a third time to unlock Capslock.

• Touch

• Touch the

2. Enter special characters.

• Touch and hold a number or symbol key to open a menu of additional symbols. A larger version of the

key displays briefly over the keyboard.

?123 to switch to the numbers and symbols keyboard.

=\< key on the numbers and symbols keyboard to view additional symbols.

, (comma) and then select Android keyboard settings.

Using the Enterprise Keyboard

The Enterprise Keyboard contains multiple keyboard types.

• Numeric

• Alpha

Settings

• Special characters

• Data capture.

Numeric Tab

The numeric keyboard is labeled 123. The keys displayed vary on the app being used. For example, an arrow displays in Contacts, however Done displays in Email account setup.

Alpha Tab

The alpha keyboard is labeled using the language code. For English, the alpha keyboard is labeled EN.

Additional Character Tab

The additional characters keyboard is labeled #*/.

Touch to enter emoji icons in a text message.

Touch ABC to return to the Symbols keyboard.

Scan Tab

The Scan tab provides an easy data capture feature for scanning barcodes.

Language Usage

Use the Language & input settings to change the device’s language, including words added to the dictionary.

Changing the Language Setting

1. Go to Settings.

2. Touch System > Languages & input.

3. Touch Languages. A list of available languages displays.

4. If the desired language is not listed, touch Add a language and select a language from the list.

5. Touch and hold to the right of the desired language, then drag it to the top of the list.

6. The operating system text changes to the selected language.

Adding Words to the Dictionary

1. Go to Settings.

2. Touch System > Languages & input > Advanced > Personal dictionary.

3. If prompted, select the language where this word or phase is stored.

4. Touch + to add a new word or phrase to the dictionary.

5. Enter the word or phrase.

6. In the Shortcut text box, enter a shortcut for the word or phrase.

7. Touch the Home button.

Notifications

Setting App Notifications

To set notification settings for a specific app:

1. Go to Settings.

2. Touch Apps & notifications > SEE ALL XX APPS. The App info screen displays.

3. Select an app.

4. Touch Notifications.

Options vary depending on the app selected.

5. Select an available option:

Show notifications - Select to turn all notifications from this app on (default) or off.

Touch a notification category to display additional options.

• Alerting - Allow notifications from this app to make sound or vibrate the device.

• Pop on screen - Allow notifications from this app to pop notifications on the screen.

Settings

• Silent - Do not allow notifications from this app to make sound or vibrate.

• Minimize - In the Notification panel, collapse notifications to one line.

• Advanced - Touch for additional options.

• Sound - Select a sound to play for notifications from this app.

• Vibrate - Allow notifications from this app to vibrate the device.

• Blink light - Allow notifications from this app the light the Notification LED blue.

• Show notification dot - Allow notifications from this app to add a notification dot to the app icon.

• Override Do Not Disturb - Allow these notifications to interrupt when Do Not Disturb is enabled.

Advanced

• Allow notification dot - Do not allow this app to add a notification dot to the app icon.

• Additional settings in the app - Open the app settings.

Viewing Notification Settings for All Apps

To view the notification settings for all apps:

1. Go to Settings.

2. Touch Apps & Notifications.

3. Scroll down to Notifications to view how many apps have notifications turned off.

4. To set or view notifications settings for a specific app, see Setting App Notifications on page 44.

Controlling Lock Screen Notifications

To control whether notifications can be seen when the device is locked:

1. Go to Settings.

2. Touch Apps & notifications > Notifications.

Settings

Touch Notifications on lockscreen and select one of the following:

• Show alerting and silent notifications (default)

• Show alerting notifications only

• Don’t show notifications.

Blink Light

The Notification LED lights blue when an app, such as email and VoIP, generates a programmable notification or to indicate when the device is connected to a Bluetooth device. By default, LED notifications are enabled.

To change the notification setting:

1. Go to Settings.

2. Touch Apps & notifications > Notifications > Advanced.

3. Touch Blink light to toggle the notification on or off.

Applications

The APPS screen displays icons for all installed apps. See Application Deployment for information on installing and uninstalling apps. For information on standard Android apps, go to the Google Play Apps

store.

The following table describes the apps installed on the device.

Table 1 Apps

Icon Description

Battery Manager - Displays battery information, including charge level, status, health and

wear level.

Bluetooth Pairing Utility – Use to pair a Zebra Bluetooth scanner with the device by scanning a barcode.

Calculator - Provides the basic and scientific arithmetic functions.

Calendar - Use to manage events and appointments. GMS/GMS-Restricted only.

Calendar - Use to manage events and appointments. AOSP only.

Camera - Take photos or record videos. For more information, see Camera on page 52.

Chrome - Use to access the Internet or intranet. GMS/GMS-Restricted only.

Chromium - Use to access the Internet or intranet. AOSP only.

Clock - Use to schedule alarms for appointments or as a wake-up.

Applications

Table 1 Apps (Continued)

Icon Description

Contacts - Use to manage contact information.

DataWedge - Enables data capture using the imager. For more information, see DataWedge

Demonstration on page 57.

DisplayLink Presenter - Use to present the device screen onto a connected monitor.

Drive - Upload photos, videos, documents, and other files to personal storage site.

GMS/GMS-Restricted only.

Duo - A one-to-one video calling app. GMS/GMS-Restricted only.

DWDemo - Provides a way to demonstrate the data capture features using the imager. For

more information, see DataWedge Demonstration on page 57.

Email - Use to send and receive email. AOSP only.

Files - Organize and manage files on the device.

Gallery - Use to view photos stored on the microSD card. AOSP only.

Gmail - Use to send and receive email using a Google email account. GMS/GMS-Restricted

only.

Google - Launches Google ™ search app. GMS/GMS-Restricted only.

Keep Notes - Use to create, edit, and share notes. GMS/GMS-Restricted only.

License Manager - Use to manage software licenses on the device.

Maps - Use to see your location on a map (with public transit, traffic, or satellite overlays).

Search for any business or place of interest. Provides turn-by-turn navigation with voice guidance, traffic-avoidance, and alternate routes, for drivers, cyclists, walkers, and users of public transportation. GMS/GMS-Restricted only.

Applications

Table 1 Apps (Continued)

Icon Description

MSRN - Use to verify authenticity of the paired Snap-on MSR and to provision the Snap-on

MSR.

Music - Play music stored on the microSD card or internal storage. AOSP only.

Phone - Use to dial a phone number when used with some Voice over IP (VoIP) clients

(VoIP telephony ready only).

Photos - Use to sync photos with Google account. GMS/GMS-Restricted only.

Play Movies & TV - View movies and video on your device. GMS/GMS-Restricted only.

Play Store - Download music, movies, books, and Android apps and games from the

Google Play Store. GMS/GMS-Restricted only.

PTT Express - Use to launch PTT Express client for VoIP communication.

RxLogger - Use to diagnose device and app issues. For more information, see RxLogger on

page 59.

Search - Use to search the Web. Requires an Internet connection. AOSP only.

Settings - Use to configure the device.

Sound Recorder - Use to record audio. For more information, see Sound Recorder on

page 60.

StageNow - Allows the device to stage a device for initial use by initiating the deployment of settings, firmware, and software.

VC Settings - Use to control settings for the device. See VC Settings on page 62.

Videos - Use to view videos on the device. AOSP only.

Applications

Table 1 Apps (Continued)

Icon Description

Worry Free Wifi Analyzer - A diagnostic intelligent app. Use to diagnose surrounding area

and display network stats, such as coverage hole detection, or AP in vicinity. Refer to the Worry Free Wi-Fi Analyzer Administrator Guide for Android.

Accessing Apps

All apps installed on the device are accessed using the APPS window.

1. On the Home screen, swipe up from the bottom of the screen.

2. Slide the APPS window up or down to view more app icons.

3. Touch an icon to open the app.

YouTube - Use to view videos on the YouTube

YT Music - Use to listen to music. GMS/GMS-Restricted only.

Zebra Bluetooth Settings - Use to configure Bluetooth logging.

Zebra Data Services - Use to enable or disable Zebra Data Services. Some options are set

by the system administrator.

™ web site. GMS/GMS-Restricted only.

Switching Between Recent Apps

Use the Recent button to switch between recently used apps.

1. Touch Recent button.

A window appears on the screen with icons of recently used apps.

2. Slide the apps displayed up and down to view all recently used apps.

3. Swipe left or right to remove app from the list and force close the app.

4. Touch an icon to open an app or touch Back button to return to the current screen.

Battery Manager

The Battery Manager provides detailed information about the battery and battery swap procedures on supported devices.

Opening Battery Manager

To open the Battery Manager app, swipe up from the bottom of the Home screen, and then touch .

Battery Manager Information Tab

The Battery Manager displays detailed information about battery charging, health, and status.

Table 2 Battery Icon Description

Battery Icon Description

Battery charge level is between 85% and 100%.

Battery charge level is between 19% and 84%.

Battery charge level is between 0% and 18%.

• Level - The current battery charge level as a percentage. Displays -% when level is unknown.

• Wear - The health of the battery in graphical form. When the wear level exceeds 80%, the bar color

changes to red.

Applications

• Health - The health of the battery. If a critical error occurs, appears. Touch to view the error description.

• Decommission - The battery is past its useful life and should be replaced. See system

administrator.

• Good - The battery is good.

• Charge error - An error occurred while charging. See system administrator.

• Over Current - An over-current condition occurred. See system administrator.

• Dead - The battery has no charge. Replace the battery.

• Over Voltage - An over-voltage condition occurred. See system administrator.

• Below Temperature - The battery temperature is below the operating temperature. See system

administrator.

• Failure Detected - A failure has been detected in the battery. See system administrator.

• Unknown - See system administrator.

• Charge Status

• Not charging - The device is not connected to AC power.

• Charging-AC - The device is connected to AC power and charging.

• Charging-USB - The device is connected to a host computer with a USB cable and charging.

• Discharging - The battery is discharging.

• Full - That the battery is fully charged.

• Unknown - The battery status is unknown.

• Time until Full - The amount of time until the battery is fully charged.

• Time since charging - The amount of time since the device began charging.

Applications

• Time until empty - The amount of time until the battery is empty.

• Advanced info - Touch to view additional battery information.

• Battery present status - Indicates that the battery is present.

• Battery level - The battery charge level as a percentage of scale.

• Battery scale - The battery scale level used to determine battery level (100).

• Battery voltage - The current battery voltage in millivolts.

• Battery temperature - The current battery temperature in degrees Centigrade.

• Battery technology - The type of battery.

• Battery current - The average current into or out of the battery over the last second in mAh.

• Battery manufacture date - The date of manufacture.

• Battery serial number - The battery serial number. The number matches the serial number printed

on the battery label.

• Battery part number - The battery part number.

• Battery decommission status - Indicates if the battery is past its life span.

• Battery Good - The battery is in good health.

• Decommissioned Battery - The battery is past its useful life and should be replaced.

• Base cumulative charge - Cumulative charge using Zebra charging equipment only.

• Battery present capacity - Maximum amount of charge that could be pulled from the battery under

the present discharge conditions if the battery were fully charged.

• Battery health percentage - With a range from 0 to 100, this is the ratio of “present_capacity” to

“design_capacity” at a discharge rate of “design_capacity”.

• % decommission threshold - The default % decommission threshold for a gifted battery as 80%.

• Battery present charge - Amount of usable charge remaining in the battery at present under the

current discharge conditions.

• Battery total cumulative charge - The total accumulated charge in all chargers.

• Battery time since first use - The time passed since the battery was placed in a Zebra terminal for

the first time.

• Battery error status - The error status of the battery.

• App version - The application version number.

Camera

Taking Photos

Applications

NOTE: The device saves photos and videos on the microSD card, if installed and the storage path is changed manually. By default, or if a microSD card is not installed, the device saves photos and videos on the internal storage.

This section provides information for taking photos and recording videos using the integrated digital cameras.

NOTE: See Photo Settings on page 54 for camera setting descriptions.

1. Swipe up from the bottom of the Home screen and touch Camera.

2. If necessary, touch the Camera Mode icon and touch .

3. Frame the subject on the screen.

4. To zoom in or out, press two fingers on the display and pinch or expand fingers. The zoom controls

appear on the screen.

5. Touch an area on the screen to focus. The focus circle appears. The two bars turn green when in focus.

6. Touch .

The camera takes a photo and a shutter sound plays.

The photo momentarily displays as a thumbnail in the lower left corner.

Taking a Panoramic Photo

Panorama mode creates a single wide image by panning slowly across a scene.

1. Swipe up from the bottom of the Home screen and touch Camera.

Applications

2. Touch the Camera Mode icon and touch .

3. Frame one side of the scene to capture.

4. Touch and slowly pan across the area to capture. A small white square appears inside the button

indicating the capture is in progress.

If you are panning too quickly, the message Too fast appears.

5. Touch to end the shot. The panorama appears immediately and a progress indicator displays while

it saves the image.

Recording Videos

1. Swipe up from the bottom of the Home screen and touch Camera.

2. Touch the camera mode menu and touch .

Applications

Settings

Audio

Camera

Flip

Color Effect

Camera Mode

Shutter Button

Thumbnail

Point the camera and frame the scene.

4. To zoom in or out, press two fingers on the display and pinch or expand fingers. The zoom controls

appear on the screen.

5. Touch to start recording.

The video time remaining appears in the top left of the screen.

6. Touch to end the recording.

The video momentarily displays as a thumbnail in the lower left corner.

Photo Settings

In Photo mode, photo settings appear on screen. Touch to display the photo settings options.

Rear Camera Photo Settings

• Flash - Select whether the camera relies on its light meter to decide whether a flash is necessary, or to

turn it on or off for all shots.

• Off - Disable flash.

• Auto - Adjust flash automatically depending upon light meter (default).

• On - Enable flash upon taking a photo.

• GPS location - Add GPS location information to the photo meta-data. Turn On or Off (default). (ET56

only).

• Picture size - The size (in pixels) of the photo to: 13M pixels (default), 8M pixels, 5M pixels, 3M pixels, HD 1080, 2M pixels, HD720, 1M pixels, WVGA, VGA, or QVGA.

• Picture quality - Set the picture quality setting to: Low, Standard or High (default).

• Countdown timer - Select Off (default), 2 seconds, 5 seconds or 10 seconds.

Applications

• Storage – Set the location to store the photo to: Phone or SD Card.

• Continuous Shot - Select to take a series of photos quickly while holding the capture button. Off (default) or On.

• Face Detection - Set the camera to automatically adjust the focus for faces.

• ISO - Set camera sensitivity to light to: Auto (default), ISO Auto (HJR), ISO100, ISO200, ISO400, ISO800 or ISO1600.

• Exposure - Set the exposure settings to: +2, +1, 0(default), -1 or -2.

• White balance - Select how the camera adjusts colors in different kinds of light, to achieve the most

natural-looking colors:

• Incandescent - Adjust the white balance for incandescent lighting.

• Fluorescent - Adjust the white balance for florescent lighting.

• Auto - Adjust the white balance automatically (default).

• Daylight - Adjust the white balance for daylight.

• Cloudy - Adjust the white balance for a cloudy environment.

• Redeye reduction - Helps eliminate redeye effect. Options: Disabled (default), or Enable.

• ZSL - Set the camera to immediately take a picture when the button is pressed (default – enabled).

• Shutter Sound - Select to play a shutter sound when taking a photo. Options: Disable (default) or Enable.

• Anti Banding - Allows the camera to avoid problems caused by artificial light sources that are not

constant. These sources cycle (flicker) fast enough to go unnoticed to the human eye, appearing continuous. The camera’s eye (its sensor) can still see this flicker. Options: Auto (default), 60 Hz, 50

Hz, or Off.

Front Camera Photo Settings

• Selfie Flash - Turns screen white to help produce a little extra light in dimmer settings. Options: Off (default), or On.

• GPS location - Add GPS location information to the photo meta-data. Options: On or Off (default). (ET56 only).

• Picture size - Set the size (in pixels) of the photo to: 5M pixels (default), 3M pixels, HD1080, 2M pixels, HD720, 1M pixels, WVGA, VGA, or QVGA.

• Picture quality - Set the picture quality setting to: Low, Standard or High (default).

• Countdown timer - Set to: Off (default), 2 seconds, 5 seconds or 10 seconds.

• Storage – Set location to store the photo to: Phone or SD Card.

• Continuous Shot - Select to take a series of photos quickly while holding the capture button. Off (default) or On.

• Face Detection - Select to turn face detection Off (default) or On.

• ISO - Set how sensitive the camera is to light. Options: Auto (default), ISO Auto (HJR), ISO100, ISO200, ISO400, ISO800 or ISO1600.

• Exposure - Touch to adjust the exposure settings. Options: +2, +1, 0 (default), -1 or -2.

Applications

• White balance - Select how the camera adjusts colors in different kinds of light, to achieve the most natural-looking colors:

• Incandescent - Adjust the white balance for incandescent lighting.

• Fluorescent - Adjust the white balance for florescent lighting.

• Auto - Adjust the white balance automatically (default).

• Daylight - Adjust the white balance for daylight.

• Cloudy - Adjust the white balance for a cloudy environment.

• Redeye reduction - Helps eliminate redeye effect. Options: Disabled (default), or Enable.

• ZSL - Set the camera to immediately take a picture when the button is pressed (default – enabled)

• Selfie Mirror - Select to save a mirror image of the photo. Options: Disable (default), or Enable.

• Shutter Sound - Select to play a shutter sound when taking a photo. Options: Disable (default) or Enable.

• Anti Banding - Allows the camera to avoid problems caused by artificial light sources that are not

Hz, or Off.

Video Settings

In Video mode, video settings appear on screen. Touch to display the video settings options.

Rear Camera Video Settings

• Flash - Select whether Rear-facing Camera relies on its light meter to decide whether a flash is

necessary, or to turn it on or off for all shots.

• Off - Disable flash (default).

• On - Enable flash.

• Video quality - Set video quality to: 4k DCI, 4k UHD, HD 1080p (default), HD 720p, SD 480p, VGA, CIF, or QVGA.

• Video duration - Set to: 30 seconds (MMS), 10 minutes, 30 minutes (default), or no limit.

• GPS location - Add GPS location information to the photo meta-data. Turn On or Off (default). (ET56 only).

• Storage – Set the location to store the photo to: Phone (default) or SD Card.

• White balance - Select how the camera adjusts colors in different kinds of light, to achieve the most

natural-looking colors.

• Incandescent - Adjust the white balance for incandescent lighting.

• Fluorescent - Adjust the white balance for florescent lighting.

• Auto - Adjust the white balance automatically (default).

• Daylight - Adjust the white balance for daylight.

• Cloudy - Adjust the white balance for a cloudy environment.

• Image Stabilization - Set to reduce blurry videos due to device movement. Options: On or Off

(default).

Front Camera Video Settings

• Video quality - Set video quality to: HD1080p (default), HD 720p, SD 480p, VGA, CIF, or QVGA.

• Video duration - Set to: 30 seconds (MMS), 10 minutes, 30 minutes (default), or no limit.

• GPS location - Add GPS location information to the photo meta-data. Turn On or Off (default). (ET56 only).

• Storage – Set the location to store the photo to: Phone (default) or SD Card.

• White balance - Select how the camera adjusts colors in different kinds of light, to achieve the most

natural-looking colors.

• Incandescent - Adjust the white balance for incandescent lighting.

• Fluorescent - Adjust the white balance for florescent lighting.

• Auto - Adjust the white balance automatically (default).

Applications

• Daylight - Adjust the white balance for daylight.

• Cloudy - Adjust the white balance for a cloudy environment.

• Image Stabilization - Set to reduce blurry videos due to device movement. Options: On or Off

(default).

DataWedge Demonstration

Use DataWedge Demonstration to demonstrate data capture functionality. To configure DataWedge, refer to techdocs.zebra.com/datawedge/

NOTE: DataWedge is enabled on the Home screen. To disable this feature, go to the DataWedge settings and disable the Launcher profile.

Table 3 DataWedge Demonstration Icons

Icon Description

Illumination Imager illumination is on. Touch to turn illumination off.

Data Capture Indicates a USB scanner is connected to the device.

Imager illumination is off. Touch to turn illumination on.

Indicates a USB scanner is not connected to the device.

Table 3 DataWedge Demonstration Icons (Continued)

Scan Mode Imager is in picklist mode. Touch to change to normal scan mode.

Menu Opens a menu to view the application information or to set the

Scanner Selection

Applications

Icon Description

A Bluetooth scanner is connected.

A Bluetooth scanner is not connected.

The data capture function is through the rear camera.

Imager is in normal scan mode. Touch to change to picklist mode.

application DataWedge profile.

To select a scanner, touch > Settings > Scanner selection.

See the Data Capture section for more information.

Press the scanner trigger button or touch the on-screen yellow scan button to capture data. The data appears in the text field below the yellow button.

RxLogger

RxLogger is a comprehensive diagnostic tool that provides application and system metrics, and diagnoses device and application issues. RxLogger logs the following information: CPU load, memory load, memory snapshots, battery consumption, power states, wireless logging, cellular logging, TCP dumps, Bluetooth logging, GPS logging, logcat, FTP push/pull, ANR dumps, etc. All generated logs and files are saved onto flash storage on the device (internal or external).

RxLogger Configuration

RxLogger is built with an extensible plug-in architecture and comes packaged with a number of plug-ins already built-in. For information on configuring RxLogger, refer to techdocs.zebra.com/rxlogger/

To open the configuration screen, from the RxLogger home screen touch Settings.

Configuration File

RxLogger configuration can be set using an XML file. The config.xml configuration file is located in the

RxLogger\config folder. Copy the file from the device to a host computer using a USB connection. Edit the

configuration file and then replace the XML file on the device. There is no need to stop and restart the RxLogger service since the file change is automatically detected.

Applications

Enabling Logging

To enable logging:

1. Swipe the screen up and select .

2. Touch Start.

3. Touch the Home button.

Disabling Logging

To disable logging:

1. Swipe the screen up and select .

2. Touch Stop.

3. Touch the Home button.

Extracting Log Files

1. Connect the device to a host computer using an USB connection.

2. Using a file explorer, navigate to the RxLogger folder.

3. Copy the file from the device to the host computer.

4. Disconnect the device from the host computer.

Backing Up

RxLogger Utility allows the user to make a zip file of the RxLogger folder in the device, which by default contains all the RxLogger logs stored in the device.

To save the backup data, touch > BackupNow.

RxLogger Utility

RxLogger Utility is a data monitoring application for viewing logs in the device while RxLogger is running. Logs and RxLogger Utility features are accessed using Main Chat Head.

Initiating the Main Chat Head

To initiate the Main Chat Head:

1. Open RxLogger.

2. Touch > Toggle Chat Head. The Main Chat Head icon appears on the screen.

3. Touch and drag the Main Chat head icon to move it around the screen.

Removing the Main Chat Head

To remove the Main Chat Head icon:

1. Touch and drag the icon. A circle with an X appears.

Applications

2. Move the icon over the circle and then release.

Viewing Logs

To view logs:

1. Touch the Main Chat Head icon. The RxLogger Utility screen appears.

2. Touch a log to open it. The user can open many logs with each displaying a new sub Chat Head.

3. If necessary, scroll left or right to view additional Sub Chat Head icons.

4. Touch a Sub Chat Head to display the log contents.

Removing a Sub Chat Head Icon

To remove a sub chat Head icon, press and hold the icon until it disappears.

Backing Up In Overlay View

RxLogger Utility allows the user to make a zip file of the RxLogger folder in the device, which by default contains all the RxLogger logs stored in the device.

The Backup icon is always available in Overlay View.

1. Touch . The Backup dialog box appears.

2. Touch Yes to create the back up.

Sound Recorder

Use Sound Recorder to record audio messages.

Recordings are saved on the microSD card (if installed) or the internal storage, and are available in the Music application (AOSP devices) or the Play Music application (GMS devices).

Touch to open options menu.

Applications

• File type - Select the file type for the recording file.

• AMR

• 3GPP

• AAC

• WAV

• AMR-WB

• AMR-WB-3GPP.

• Storage location - Select the location for the recording file.

• Phone storage

• SD card

VC Settings

Use the VC Settings app with a third-party vehicle cradle.

Display

Enable/disable Stay awake to keep the device awake when the external power source is connected.

Screen Blanking

The optional Screen Blanking setting turns the screen off when the vehicle is moving and back on when the vehicle stops.

To use Screen Blanking, first connect a serial ports on the vehicle cradle to a user-supplied switch or relay.

• Screen Blanking - Enable/disable screen blanking feature.

• Input signal - Select the port that the screen blank cable is connected to. Options: Input 1 or Input 2.

• Source polarity - Select blank screen option. De-select to disconnect the blank screen option.

Applications

• Blank screen delay - Set the amount of time after the device receives the signal to blank the screen. Options 1 to 30 seconds (default - 1).

Data Capture

The device supports data capture using:

• integrated camera

• integrated scanner (ET51 with Integrated Scanner only)

• SE4750 Expansion Back

• Ring scanners:

• RS507 and RS507X Hands-free Imager

• RS5100 Ring Scanner

• RS6000 Ring Scanner

• Bluetooth scanners:

• DS2278, and DS3678 scanners

• USB scanners:

• LI3608, and DS3608.

Imaging

The imager uses imaging technology to take a picture of a bar code, stores the resulting image in its memory, and executes state-of-the-art software decoding algorithms to extract the bar code data from the image.

The device with a 2D imager has the following features:

• Omnidirectional reading of a variety of bar code symbologies, including the most popular linear, postal, PDF417, and 2D matrix code types.

• Advanced intuitive laser aiming cross-hair and dot aiming for easy point-and-shoot operation.

Scanning Considerations

Typically, scanning is a simple matter of aim, scan, and decode, with a few quick trial efforts to master it. However, consider the following to optimize scanning performance:

• Range: Scanners decode best over a particular working range — minimum and maximum distances from the barcode. This range varies according to barcode density and scanning device optics. Scan within range for quick and constant decodes; scanning too close or too far away prevents decodes. Move the scanner closer and further away to find the right working range for the barcodes being scanned.

• Angle: Scanning angle is important for quick decodes. When the illumination/flash reflects directly back into the imager, the specular reflection can blind/saturate the imager. To avoid this, scan the barcode so that the beam does not bounce directly back. Do not scan at too sharp an angle; the scanner needs to collect scattered reflections from the scan to make a successful decode. Practice quickly shows what tolerances to work within.

• Hold the device farther away for larger symbols.

• Move the device closer for symbols with bars that are close together.

NOTE: Scanning procedures depend on the app and device configuration. An app may use different scanning procedures from the one listed above.

Expansion Back

The Expansion Back is a bar code scanning solutions for both 1D and 2D bar code symbologies that attach to the tablet. Expansion Back is available for the 8.4" and 10.1” tablet.

Install the Expansion Back prior to use. Refer to the ET51/56 Integration Guide for installation instructions.

Integrated Scanner

The ET51 Enterprise Tablet with Integrated Scanner contains a built-in 2D scan engine for both 1D and 2D bar code symbologies.

RS507/RS507X Hands-Free Imager

The RS507/RS507X Hands-free Imager is a wearable barcode scan solution for both 1D and 2D barcode symbologies.

Figure 1 RS507/RS507X Hands-Free Imager

Refer to the RS507/RS507X Hands-free Imager Product Reference Guide for more information.

RS5100 Ring Scanner

The RS5100 Ring Scanner is a wearable barcode scan solution for both 1D and 2D bar code symbologies.

Figure 2 RS5100 Ring Scanner

Refer to the RS5100 Ring Scanner Product Reference Guide for more information.

RS6000 Bluetooth Ring Scanner

The RS6000 Bluetooth Ring Scanner is a wearable barcode scan solution for both 1D and 2D barcode symbologies.

Figure 3 RS6000 Bluetooth Ring Scanner

Refer to the RS6000 Bluetooth Ring Scanner Product Reference Guide for more information.

DS36X8 Digital Scanner

The corded DS3608 and the cordless DS3678 combines superior 1D and 2D omnidirectional barcode scanning performance and advanced ergonomics in a lightweight design. See the DS36X8 Product Reference Guide for more information.

Figure 4 DS36X8 Digital Scanner

DS2278 Digital Scanner

The DS2278 digital imager scanner scans both 1D and 2D bar codes and does not compromise performance or features.

Figure 5 DS2278 Digital Scanner

Refer to the DS22788 Digital Scanner Product Reference Guide for more information.

DS8178 Scanner

The DS8178 digital imager scanner scans both 1D and 2D bar codes and does not compromise performance or features.

Figure 6 DS8178 Digital Scanner

Refer to the DS8178 Digital Scanner Product Reference Guide for more information.

Scanning with SE4750 Expansion Back

To read a barcode, a scan-enabled app is required. The device contains the DataWedge app that allows the user to enable the scanner to decode barcode data and display the barcode content.

To scan with the SE4750 Expansion Back:

1. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

2. Point the Expansion Back exit window at a bar code.

Figure 7 Bar Code Scanning with Expansion Back with SE4750

3. Press and hold the Scan button.

The red laser aiming pattern turns on to assist in aiming. Ensure the bar code is within the area formed by the cross-hairs in the aiming pattern. The aiming dot is used for increased visibility in bright lighting conditions.

The Expansion Back beeps to indicate the bar code was decoded successfully.

Figure 8 SE4750 Expansion Back Aiming Pattern

Release the Scan button. The bar code data displays on the screen.

Scanning with the Integrated Scanner

To read a barcode, a scan-enabled app is required. Devices that contain the Zebra DataWedge app allows you to enable the scanner to decode barcode data and display the barcode content.

To scan with the integrated scanner:

1. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

2. Point the device at a barcode.

3. Press and hold one of the triggers.

4. Ensure the barcode is within the area formed by the aiming pattern. The aiming dot increases visibility

in bright lighting conditions.

A beep sounds to indicate the barcode was decoded successfully. When the Integrated Scanner is in Pick List mode, the device does not decode the barcode until the aiming dot touches the barcode.

Figure 9 Integrated Scanner Aiming Pattern

Figure 10 Integrated Scanner Pick List Mode with Multiple Barcodes in Aiming Pattern

5. The captured data appears in the text field.

Scanning with RS507/RS507X Hands-Free Imager

To read a barcode, a scan-enabled app is required. The device contains the DataWedge app that allows you to enable the scanner to decode barcode data and display the barcode content.

To scan with the RS507/RS507X:

1. Pair the RS507/RS507X with the device. Pairing a Bluetooth Scanner on page 77 for more information.

2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

3. Point the RS507/RS507X at a barcode.

Press and hold the trigger.

The red laser aiming pattern turns on to assist in aiming. Ensure the barcode is within the area formed by the cross-hairs in the aiming pattern. The aiming dot increases visibility in bright lighting conditions.

The RS507/RS507X LEDs light green and a beep sounds to indicate the barcode was decoded successfully. When the RS507/RS507X is in Pick List mode, the RS507/RS507X does not decode the barcode until the center of the crosshair touches the barcode.

Figure 11 RS507/RS507X Aiming Pattern

Figure 12 RS507/RS507X Pick List Mode with Multiple Barcodes in Aiming Pattern

5. The captured data appears in the text field.

Scanning with RS5100 Ring Scanner

To read a barcode, a scan-enabled app is required. The device contains the DataWedge app that allows you to enable the scanner to decode barcode data and display the barcode content.

To scan with the RS5100:

1. Pair the RS5100 with the device. See Pairing a Bluetooth Scanner on page 77

2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

for more information.

3. Point the RS5100 at a barcode.

4. Press and hold the trigger.

The RS5100 LEDs light green and a beep sounds to indicate the barcode was decoded successfully. When the RS5100 is in Pick List mode, the RS5100 does not decode the barcode until the center of the crosshair touches the barcode.

Figure 13 RS5100 Aiming Pattern

Figure 14 RS5100 Pick List Mode with Multiple Barcodes in Aiming Pattern

5. The captured data appears in the text field.

Scanning with RS6000 Bluetooth Ring Scanner

To read a barcode, a scan-enabled app is required. Devices that contain the Zebra DataWedge app allows you to enable the scanner to decode barcode data and display the barcode content.

To scan with the RS6000:

1. Pair the RS6000 with the device. See Pairing a Bluetooth Scanner on page 77 for more information.

2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

3. Point the RS6000 at a barcode.

Figure 15 Barcode Scanning with RS6000

4. Press and hold the trigger.

The RS6000 LEDs light green and a beep sounds to indicate the barcode was decoded successfully. When the RS6000 is in Pick List mode, the RS6000 does not decode the barcode until the center of the crosshair touches the barcode.

Figure 16 RS6000 Aiming Pattern

Figure 17 RS6000 Pick List Mode with Multiple Barcodes in Aiming Pattern

5. The captured data appears in the text field.

Scanning with the DS36X8 Scanner

To scan:

1. Connect the USB scanner to the device or pair the Bluetooth scanner with the device. For more

information, see Connecting a USB Scanner Using HID on page 78 for the USB scanners or Pairing a

Bluetooth Scanner on page 77 for Bluetooth scanners.

2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

3. Point the scanner at a barcode.

Figure 18 Barcode Scanning (DS3678 shown)

4. Press and hold the trigger.

Ensure the barcode is within the area formed by the aiming pattern. The aiming dot increases visibility in bright lighting conditions.

Figure 19 DS36X8 Aiming Pattern

Figure 20 DS36X8 Pick List Mode with Multiple Barcodes in Aiming Pattern

5. The captured data appears in the text field.

Scanning with DS2278 Digital Scanner

To scan with the DS2278:

1. Pair the DS2278 with the device. See Pairing a Bluetooth Scanner on page 77 for more information.

2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

3. Point the scanner at a barcode.

4. Press and hold the trigger.

5. Ensure the aiming pattern covers the barcode.

Figure 21 DS2278 Aiming Pattern

6. Upon successful decode, the scanner beeps and the LED flashes, and the scan line turns off.

7. The captured data appears in the text field.

Scanning with DS8178 Digital Scanner

To scan with the DS8178:

1. Pair the DS8178 with the device. See Pairing a Bluetooth Scanner on page 77

2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).

3. Point the scanner at a barcode.

Figure 22 Barcode Scanning with DS8178

4. Press and hold the trigger.

5. Ensure the aiming pattern covers the barcode.

for more information.

6. Upon successful decode, the scanner beeps and the LED flashes, and the scan line turns off.

7. The captured data appears in the text field.

Pairing the RS507/RS5100/RS6000 Ring Scanner

To connect the ring scanner to the device, use one of the following methods:

• Simple Serial Interface (SSI)

• Bluetooth Human Interface Device (HID) Mode.

Pairing Using Simple Serial Interface (SSI)

To pair the RS507, RS5100, or RS6000 with the device using SSI.

1. Swipe up from the bottom of the Home screen and touch .

Using the ring scanner, scan the barcode on the screen.

The ring scanner emits a string of high/low/high/low beeps. The Scan LED flashes green indicating that the ring scanner is attempting to establish connection with the device. When connection is established, the Scan LED turns off and the ring scanner emits one string of low/high beeps.

A notification appears on the Notification panel and the icon appears in the Status bar.

Pairing Using Bluetooth Human Interface Device

To pair the ring scanner with the device using Human Interface Device (HID):

1. Ensure that Bluetooth is enabled on both devices.

2. Ensure that the Bluetooth device to discover is in discoverable mode.

3. Ensure that the two devices are within 10 meters (32.8 feet) of one another.

4. Place the ring scanner in HID mode. If the ring scanner is already in HID mode, skip to step 5.

a. Remove the battery from the ring scanner.

b. Press and hold the Restore key.

c. Install the battery onto the ring scanner.

d. Keep holding the Restore key for about five seconds until a chirp is heard and the Scan LEDs flash

green.

e. Scan the barcode below to place the ring scanner in HID mode.

Figure 23 RS507/RS507X Bluetooth HID Barcode

Figure 24 RS5100/RS6000 Bluetooth HID Barcode

5. Remove the battery from the ring scanner.

6. Re-install the battery into the ring scanner.

7. Swipe down from the Status bar to open the Quick Access panel and then touch .

8. Touch Bluetooth.

9. Touch Pair new device. The device begins searching for discoverable Bluetooth devices in the area

and displays them under Available devices.

10. Scroll through the list and select the ring scanner.

The device connects to the ring scanner and Connected appears below the device name. The Bluetooth device is added to the Paired devices list and a trusted (“paired”) connection is established.

A notification appears on Notification panel and the icon appears in the Status bar.

Pairing a Bluetooth Scanner

Connect the scanner to the device using one of the following methods:

• Simple Serial Interface (SSI) mode

• Bluetooth Human Interface Device (HID) mode.

Pairing Using Simple Serial Interface

To pair the Bluetooth scanner with the device using SSI:

1. Ensure that the two devices are within 10 meters (32.8 feet) of one another.

2. Install the battery into the scanner.

3. On the device swipe up from the bottom of the Home screen and touch .

4. Using the scanner, scan the barcode on the screen.

The scanner emits a high/low/high/low beeps. The Scan LED flashes green indicating that the scanner is attempting to establish connection with the device. When connection is established, the Scan LED turns off and the scanner emits one string of low/high beeps.

5. On the device touch Home.

Pairing Using Bluetooth Human Interface Device

To pair the Bluetooth scanner with the device using HID:

1. Remove the battery from the scanner.

2. Replace the battery.

After the scanner reboots, scan the barcode below to place the scanner in HID mode.

4. On the device, swipe down from the Status bar to open the Quick Access panel and then touch .

5. Touch Bluetooth.

6. Touch Pair new device. The device begins searching for discoverable Bluetooth devices in the area

and displays them under Available devices.

7. Scroll through the list and select XXXXX xxxxxx, where XXXXX is the scanner and xxxxxx is the serial

number.

The device connects to the scanner, the scanner beeps once and Connected appears below the device name. The Bluetooth device is added to the Paired devices list and a trusted (“paired”) connection is established.

Connecting a USB Scanner Using HID

NOTE: Refer to the scanner Product Reference Guide for the appropriate USB cable.

To connect a USB scanner using HID mode:

1. Connect the scanner cable USB connector to the USB port of the device (using a third-party USB-A to

USB-C adapter). The scanner beeps.

2. Ensure that the scanner is in HID mode. Refer to the Refer to the DS36X8 Product Reference Guide

and scan the HID Keyboard barcode or perform a factory reset.

DataWedge

DataWedge is a utility that adds advanced barcode scanning capability to any application without writing code. It runs in the background and handles the interface to built-in barcode scanners. The captured barcode data is converted to keystrokes and sent to the target application as if it was typed on the keypad.

DataWedge allows any app on the device to get data from input sources such as a barcode scanner, MSR, RFID, voice, or serial port and manipulate the data based on options or rules.

Configure DataWedge to:

• Provide data capture services from any app.

• Use a particular scanner, reader or other peripheral device.

• Properly format and transmit data to a specific app.

To configure DataWedge refer to techdocs.zebra.com/datawedge/

Enabling DataWedge

1. Swipe up from the bottom of the Home screen and touch .

2. Touch > Settings.

3. Touch the DataWedge enabled checkbox. A blue checkmark appears in the checkbox indicating that

DataWedge is enabled.

Touch the Home button.

Disabling DataWedge

1. Touch .

2. Touch Settings.

3. Touch DataWedge enabled.

The blue check disappears from the checkbox indicating that DataWedge is disabled.

Supported Decoders

NOTE: DataWedge supports the decoders listed below but not all are validated on this device.

Table 4 Supported Decoders

Decoders

Camera

Australian Postal O O O O O O O O O

Aztec X X X X X X X X X

Canadian Postal O O O O O -- -- -- --

Chinese 2 of 5 O O O O O O O O O

Codabar X X X X X X X X X

Code 11 O O O O O O O O O

Code 128 X X X X X X X X X

Code 39 X X X X X X X X X

Code 93 O O O O O O O O O

Composite AB O O O O O O O O O

Composite C O O O O O O O O O

Discrete 2 of 5 O O O O O O O O O

Datamatrix X X X X X X X X X

Dutch Postal O O O O O O O O O

SE4710

Internal Imager

SE4750 Expansion Back

RS5100

RS6000

DS2278

RS507/RS507X

DS3678

DS8178

Table 4 Supported Decoders (Continued)

Decoders

Camera

SE4710

Internal Imager

RS5100

RS6000

DS2278

RS507/RS507X

DS3678

SE4750 Expansion Back

DotCode X O N/A O O O O O O

EAN13 X X X X X X X X X

EAN8 X X X X X X X X X

Grid Matrix O O O O O O O O O

GS1 DataBar X X X X X X X X X

GS1 DataBar

X X X X X X X X X

Expanded

GS1 DataBar Limited O O O O O O O O O

GS1 Datamatrix O O O O O -- O O O

GS1 QRCode O O O O O -- O O O

HAN XIN O -- O O O -- -- O --

Interleaved 2 of 5 O O O O O O O O O

Japanese Postal O O O O O O O O O

Korean 3 of 5 O O O O O O O O O

MAIL MARK X X X X X -- X X X

Matrix 2 of 5 O O O O O O O O O

Maxicode X X X X X X X X X

MicroPDF O O O O O O O O O

MicroQR O O O O O O O O O

MSI O O O O O O O O O

PDF417 X X X X X X X X X

QR Code X X X X X X X X X

Decoder Signature O O O O O O O -- --

TLC 39 O O O O O O O O O

Trioptic 39 O O O O O O O O O

UK Postal O O O O O O O O O

UPCA X X X X X X X X X

UPCE0 X X X X X X X X X

DS8178

Table 4 Supported Decoders (Continued)

Decoders

Camera

SE4710

Internal Imager

RS5100

RS6000

DS2278

RS507/RS507X

DS3678

SE4750 Expansion Back

UPCE1 O O O O O O O O O

US4state O O O O O O O O O

US4state FICS O O O O O O O O O

US Planet O O O O O O O O O

US Postnet O O O O O O O O O

Key

DS8178

X = Enabled O = Disabled

-- = Not Supported

Touch the Back button to return to the previous screen.

Wireless

This section provides information on the following wireless features:

• Wireless Wide Area Network (WWAN)

• Wireless Local Area Network (WLAN)

• Bluetooth

• Near Field Communications (NFC)

Wireless Wide Area Networks

NOTE: ET56 only.

Use Wireless wide area networks (WWANs) to access data over a cellular network. This section provides information on:

• Sharing a data connection

• Monitoring data usage

• Changing Cellular Network settings

Sharing the Mobile Data Connection

The Tethering & Portable Hotspot settings allows sharing the mobile data connection with a single computer via USB tethering or Bluetooth tethering. Share the data connection with up to eight devices at once, by turning it into a portable Wi-Fi hotspot. While the device is sharing its data connection, an icon displays at the top of the screen and a corresponding message appears in the notification list.

Enabling USB Tethering

NOTE: USB tethering is not supported on computers running Mac OS. If the computer is running Windows

or a recent version of Linux (such as Ubuntu), follow these instructions without any special preparation. If running a version of Windows that precedes Windows 7, or some other operating system, you may need to prepare the computer to establish a network connection via USB.

1. Connect the device to a host computer with the USB cable.

2. The notification Charging this device via USB appears in the Notifications panel.

3. Go to Settings.

4. Touch Network & Internet.

Touch Hotspot & tethering.

6. Touch the USB tethering switch to enable.

The host computer is now sharing the device’s data connection.

To stop sharing the data connection, touch the USB tethering switch again or disconnect the USB cable.

Enabling Bluetooth Tethering

Use Bluetooth tethering to share the data connection with a host computer.

Configure the host computer to obtain its network connection using Bluetooth. For more information, see the host computer’s documentation.

1. Pair the device with the host computer.

2. Go to Settings.

3. Touch Networking & Internet.

4. Touch Hotspot & tethering.

5. Touch the Bluetooth tethering switch to enable.

The host computer is now sharing the device’s data connection.

Wireless

To stop sharing the data connection, touch the Bluetooth tethering switch again.

Enabling Wi-Fi Hotspot

To enable the Wi-Fi Hotspot:

1. Go to Settings.

2. Touch Network & Internet.

3. Touch Hotspot & tethering.

4. Touch Wi-Fi hotspot.

5. Toggle the switch to enable.

After a moment, the device starts broadcasting its Wi-Fi network name (SSID). Connect to it with up to eight computers or other devices. The Hotspot icon appears in the Status bar.

To stop sharing the data connection, touch the toggle switch again.

Configuring the Wi-Fi Hotspot

1. Go to Settings.

2. Touch Network & Internet.

3. Touch Hotspot & tethering.

4. Touch Wi-Fi hotspot.

5. In the Hotspot name text field, edit the name for the hotspot.

6. Touch Security and select a security method from the drop-down list.

• WPA2-Personal

a. Touch Hotspot password.

b. Enter a password.

c. Touch OK.

• None - If None is selected in the Security option, a password is not required.

7. Touch Advanced.

8. If desired, touch Turn off hotspot automatically to turn off Wi-Fi Hotspot when no devices are

9. In the AP Band drop-down list, select 2.4 GHz Band or 5.0 GHz Band.

Data Usage

Data usage refers to the amount of data uploaded or downloaded by the device during a given period. Depending on the wireless plan, you may be charged additional fees when your data usage exceeds your plan's limit.

To monitor your data usage:

1. Go to Settings.

2. Touch Network & internet > Mobile network > Data usage.

CAUTION: The usage displayed on the data usage settings screen is measured by your device. Your

carrier's data usage accounting may differ. Usage in excess of your carrier plan's data limits can result in steep overage charges. The feature described here can help you track your usage, but is not guaranteed to prevent additional charges.

Wireless

connected.

Data usage settings allow:

• Enable Data Saver.

• Set the data usage warning level.

• Set a data usage limit.

• View or restrict data usage by app.

• Identify mobile hotspots and restrict background downloads that may result in extra charges.

By default, the data usage settings screen displays the mobile data settings. That is, the data network or networks provided by your carrier.

Setting Data Usage Warning

To set a warning alert when the device has used a certain amount of mobile data:

1. Go to Settings.

2. Touch Network & internet > Mobile network > Data usage > .

3. If necessary, touch Set data warning to enable it.

4. Touch Data warning.

5. Enter a number. To switch between megabytes (MB) and gigabytes (GB), touch the down arrow.

6. Touch SET.

When the usage reaches the set level, a notification appears.

Setting Data Limit

1. Go to Settings.

2. Touch Network & internet > Mobile network > Data usage > .

3. Touch Set data limit.

Touch OK.

5. Touch Data limit.

6. Enter a number. To switch between megabytes (MB) and gigabytes (GB), touch the down arrow.

7. Touch Set.

When the limit is reached, data automatically turns off and a notification appears.

Cellular Network Settings

Cellular network settings applies to WWAN devices only.

Data When Roaming

Roaming is disabled by default to prevent the device from transmitting data over other carriers’ mobile networks when leaving an area that is covered by the carrier’s networks. This is useful for controlling expenses if the service plan does not include data roaming.

Enabling Data on GSM Devices

1. Go to Settings.

Wireless

2. Touch Network & Internet > Mobile network.

3. Touch Roaming.

The switch moves to the on position.

Setting Preferred Network

Change the network operating mode.

1. Go to Settings.

2. Touch Network & Internet > Mobile network > Advanced.

3. Touch Automatically select network.

4. Touch Network.

5. In the Available network list, select a carrier network.

Using Search for MicroCell

A MicroCell acts like a mini cell tower in a building or residence and connects to an existing broadband Internet service. It improves cell signal performance for voice calls, texts, and cellular data applications like picture messaging and Web surfing.

1. Go to Settings.

2. Touch Network & Internet > Mobile network.

3. Touch Search for MicroCell.

Configuring the Access Point Name

NOTE: Many service provider Access Point Name (APN) data are pre-configured in the device. The APN

information for all other service provides must be obtained from the wireless service provider.

To use the data on a network, configure the APN information.

1. Go to Settings.

Touch Network & Internet > Mobile network > Advanced.

3. Touch Access Point Names.

4. Touch an APN name in the list to edit an existing APN or touch to create a new APN.

5. Touch each APN setting and enter the appropriate data obtained from the wireless service provider.

6. When finished, touch > Save.

7. Touch the radio button next to the APN name to start using it.

8. Touch the Home button.

Locking the SIM Card

Locking the SIM card requires the user to enter a PIN every time the device is turned on. If the correct PIN is not entered, only emergency calls can be made.

1. Go to Settings.

2. Touch Security > SIM card lock.

3. Touch Lock SIM card.

4. Enter the PIN associated with the card. Touch OK.

Wireless

5. Reset the device.

Wireless Local Area Networks

Wireless local area networks (WLANs) allow the device to communicate wirelessly inside a building. Before using the device on a WLAN, the facility must be set up with the required hardware to run the WLAN (sometimes known as infrastructure). The infrastructure and the device must both be properly configured to enable this communication.

Refer to the documentation provided with the infrastructure (access points (APs), access ports, switches, Radius servers, etc.) for instructions on how to set up the infrastructure.

Once the infrastructure is set up to enforce the chosen WLAN security scheme, use the Wireless & networks settings configure the device to match the security scheme.

The device supports the following WLAN security options:

• None

• Enhanced Open

• Wireless Equivalent Privacy (WEP)

• Wi-Fi Protected Access (WPA)/WPA2 Personal (PSK)

• WPA3-Personal

• WPA/WPA2/WPA3 Enterprise (EAP)

• Protected Extensible Authentication Protocol (PEAP) - with MSCHAPV2 and GTC authentication.

• Transport Layer Security (TLS)

• Tunneled Transport Layer Security (TTLS) - with Password Authentication Protocol (PAP),

MSCHAP and MSCHAPv2 authentication

• Password (PWD)

• Lightweight Extensible Authentication Protocol (LEAP).

• WPA3-Enterprise 192-bit

The Status bar displays icons that indicate Wi-Fi network availability and Wi-Fi status.

NOTE: To extend the life of the battery, turn off Wi-Fi when not in use.

Connecting to a Wi-Fi Network

To connect to a Wi-Fi network:

1. Go to Settings.

2. Touch Wi-Fi to open the Wi-Fi screen. The device searches for WLANs in the area and lists them.

3. Scroll through the list and select the desired WLAN network.

4. For open networks, touch profile once or press and hold and then select Connect or for secure

networks enter the required password or other credentials then touch Connect. See the system administrator for more information.

The device obtains a network address and other required information from the network using the dynamic host configuration protocol (DHCP) protocol. To configure the device with a fixed internet protocol (IP) address, see Configuring the Device to Use a Static IP Address on page 90.

Wireless

5. In the Wi-Fi setting field, Connected appears indicating that the device is connected to the WLAN.

Removing a Wi-Fi Network

To remove a remembered or connected network:

1. Go to Settings.

2. Touch Network & Internet > W-Fi.

3. Scroll down to the bottom of the list and touch Saved networks.

4. Touch the name of the network.

5. Touch FORGET.

6. Touch the Home button.

WLAN Configuration

This section provides information on configuring Wi-Fi settings.

Configuring a Secure Wi-Fi Network

1. Go to Settings.

2. Touch Network & Internet > Wi-Fi.

3. Slide the switch to the ON position.

4. The device searches for WLANs in the area and lists them on the screen.

5. Scroll through the list and select the desired WLAN network.

6. Touch the desired network. If the network security is Open, the device automatically connects to the

network. For all other network security a dialog box appears.

Wireless

If the network security is WPA/WPA2-Personal, WPA3-Personal, or WEP, enter the required password

and then touch Connect.

8. If the network security is WPA/WPA2/WPA3 Enterprise:

• Touch the EAP method drop-down list and select one of the following:

• PEAP

• TLS

• TTLS

• PWD

• LEAP.

• Touch the Phase 2 authentication drop-down list and select an authentication method.

• If required, touch CA certificate and select a Certification Authority (CA) certificate. Note:

Certificates are installed using the Security settings.

• If required, touch User certificate and select a user certificate. Note: User certificates are installed

using the Security settings.

• If required, in the Identity text box, enter the username credentials.

• If desired, in the Anonymous identity text box, enter an anonymous identity username.

• If required, in the Password text box, enter the password for then given identity.

9. If the network security is WPA3-Enterprise 192-bit:

• Touch CA certificate and select a Certification Authority (CA) certificate. Note: Certificates are

installed using the Security settings.

• Touch User certificate and select a user certificate. Note: User certificates are installed using the

Security settings.

• In the Identity text box, enter the username credentials.

NOTE: By default, the network Proxy is set to None and the IP settings is set to DHCP. See Configuring

for a Proxy Server for setting connection to a proxy server and see Configuring the Device to Use a Static IP Address for setting the device to use a static IP address.

10. Touch Connect.

11. Touch the Home button.

Manually Adding a Wi-Fi Network

Manually add a Wi-Fi network if the network does not broadcast its name (SSID) or to add a Wi-Fi network when out of range.

1. Go to Settings.

2. Touch Network & Internet > Wi-Fi.

3. Slide the Wi-Fi switch to the On position.

4. Scroll to the bottom of the list and select Add network.

5. In the Network name text box, enter the name of the Wi-Fi network.

6. In the Security drop-down list, set the type of security to:

• None

Wireless

• Enhanced Open

• WEP

• WPA/WPA2-Personal

• WPA3-Personal

• WPA/WPA2/WPA3-Enterprise

• WPA3-Enterprise 192-bit

7. If the network security is None or Enhanced Open, touch Save.

8. If the network security is WEP, WPA3-Personal, or WPA/WPA2-Personal, enter the required

password and then touch Save.

9. If the network security is WPA/WPA2/WPA3-Enterprise:

• Touch the EAP method drop-down list and select one of the following:

• PEAP

• TLS

• TTLS

• PWD

• LEAP.

• Touch the Phase 2 authentication drop-down list and select an authentication method.

• If required, touch CA certificate and select a Certification Authority (CA) certificate. Note:

Certificates are installed using the Security settings.

• If required, touch User certificate and select a user certificate. Note: User certificates are installed

using the Security settings.

• If required, in the Identity text box, enter the username credentials.

• If desired, in the Anonymous identity text box, enter an anonymous identity username.

• If required, in the Password text box, enter the password for the given identity.

10. If the network security is WPA3-Enterprise 192-bit:

• Touch CA certificate and select a Certification Authority (CA) certificate. Note: Certificates are

installed using the Security settings.

• Touch User certificate and select a user certificate. Note: User certificates are installed using the

Security settings.

• In the Identity text box, enter the username credentials.

NOTE: By default, the network Proxy is set to None and the IP settings is set to DHCP. See Configuring

for a Proxy Server on page 90 for setting connection to a proxy server and see Configuring the Device to Use a Static IP Address on page 90 for setting the device to use a static IP address.

11. Touch Save. To connect to the saved network, touch and hold on the saved network and select

Connect to network.

12. Touch the Home button.

Configuring for a Proxy Server

A proxy server is a server that acts as an intermediary for requests from clients seeking resources from other servers. A client connects to the proxy server and requests some service, such as a file, connection, web page, or other resource, available from a different server. The proxy server evaluates the request according to its filtering rules. For example, it may filter traffic by IP address or protocol. If the request is validated by the filter, the proxy provides the resource by connecting to the relevant server and requesting the service on behalf of the client.

It is important for enterprise customers to be able to set up secure computing environments within their companies, making proxy configuration essential. Proxy configuration acts as a security barrier ensuring that the proxy server monitors all traffic between the Internet and the intranet. This is normally an integral part of security enforcement in corporate firewalls within intranets.

1. Go to Settings.

2. Touch Network & Internet > Wi-Fi.

3. Slide the Wi-Fi switch to the On position.

4. In the network dialog box, select and touch a network.

5. Touch Advanced options.

6. Touch Proxy and select Manual.

Wireless

7. In the Proxy hostname text box, enter the address of the proxy server.

8. In the Proxy port text box, enter the port number for the proxy server.

9. In the Bypass proxy for text box, enter addresses for web sites that are not required to go through the

proxy server. Use a comma “,” between addresses. Do not use spaces or carriage returns between addresses.

10. Touch Connect.

11. Touch the Home button.

Configuring the Device to Use a Static IP Address

By default, the device is configured to use Dynamic Host Configuration Protocol (DHCP) to assign an Internet protocol (IP) address when connecting to a wireless network.

1. Go to Settings.

2. Touch Network & Internet > Wi-Fi.

3. Slide the Wi-Fi switch to the On position.

4. In the network dialog box, select and touch a network.

5. Touch Advanced options.

6. Touch IP settings and select Static.

7. In the IP address text box, enter an IP address for the device.

8. If required, in the Gateway text box, enter a gateway address for the device.

9. If required, in the Network prefix length text box, enter the prefix length.

10. If required, in the DNS 1 text box, enter a Domain Name System (DNS) address.

11. If required, in the DNS 2 text box, enter a DNS address.

12. Touch Connect.

Touch the Home button.

13.

Wi-Fi Preferences

Use the Wi-Fi preferences to configure advanced Wi-Fi settings. From the Wi-Fi screen scroll down to the bottom of the screen and touch Wi-Fi preferences.

• Turn on Wi-Fi automatically - When enabled, Wi-Fi automatically turns back on when near high quality saved networks.

• Open network notification - When enabled, notifies the user when an open network is available.

• Advanced - Touch to expand options.

• Additional settings - See Additional Settings.

• Install Certificates – Touch to install certificates.

• Network rating provider - Disabled (AOSP devices). To help determine what constitutes a good

Wi-Fi network, Android supports external Network rating providers that provide information about the quality of open Wi-Fi networks. Select one of the providers listed or None. If none are available or selected, the Connect to open networks feature is disabled.

• Wi-Fi Direct - Displays a list of devices available for a direct Wi-Fi connection.

Wireless

• MAC address - Displays the Media Access Control (MAC) address of the device when connecting

to Wi-Fi networks.

• IP address - Displays the IP address of the device when connecting to Wi-Fi networks.

Additional Wi-Fi Settings

NOTE: Additional Wi-Fi settings are for the device, not for a specific wireless network.

Use the Additional Settings to configure additional Wi-Fi settings. To view the additional Wi-Fi settings, scroll to the bottom of the Wi-Fi screen and touch Wi-Fi Preferences > Advanced > Additional settings.

• Regulatory

• Country Selection - Displays the acquired country code if 802.11d is enabled, else it displays the

currently selected country code.

• Region code - Displays the current region code.

• Band and Channel Selection

• Wi-Fi frequency band - Set the frequency band to: Auto (default), 5 GHz only or 2.4 GHz only.

• Available channels (2.4 GHz) - Touch to display the Available channels menu. Select specific

channels and touch OK.

• Available channels (5 GHz) - Touch to display the Available channels menu. Select specific

channels and touch OK.

• Logging

• Advanced Logging – Touch to enable advanced logging or change the log directory.

• Wireless logs - Use to capture Wi-Fi log files.

• Fusion Logger - Touch to open the Fusion Logger application. This application maintains a

history of high level WLAN events which helps to understand the status of connectivity.

• About

• Version - Displays the current Fusion information.

Wi-Fi Direct

Wi-Fi Direct devices can connect to each other without having to go through an access point. Wi-Fi Direct devices establish their own ad-hoc network when required, letting you see which devices are available and choose which one you want to connect to.

1. Go to Settings.

2. Touch Wi-Fi > Wi-Fi preferences > Advanced > Wi-Fi Direct. The device begins searching for

another Wi-Fi Direct device.

3. Under Peer devices, touch the other device name.

4. On the other device, select Accept.

Connected appears on the device. On both devices, in their respective Wi-Fi Direct screens, the other

device name appears in the list.

Wireless

• Fusion Status - Touch to display live status of WLAN state. Also provides information about the device and connected profile.

Bluetooth

Bluetooth devices can communicate without wires, using frequency-hopping spread spectrum (FHSS) radio frequency (RF) to transmit and receive data in the 2.4 GHz Industry Scientific and Medical (ISM) band (802.15.1). Bluetooth wireless technology is specifically designed for short-range (10 m (32.8 ft)) communication and low power consumption.

Devices with Bluetooth capabilities can exchange information (for example, files, appointments, and tasks) with other Bluetooth enabled devices such as printers, access points, and other mobile devices.

The device supports Bluetooth Low Energy. Bluetooth Low Energy is targeted at applications in the healthcare, fitness, security, and home entertainment industries. It provides reduced power consumption and cost while maintaining standard Bluetooth range.

Adaptive Frequency Hopping

Adaptive Frequency Hopping (AFH) is a method of avoiding fixed frequency interferers, and can be used with Bluetooth voice. All devices in the piconet (Bluetooth network) must be AFH-capable in order for AFH to work. There is no AFH when connecting and discovering devices. Avoid making Bluetooth connections and discoveries during critical 802.11b communications. AFH for Bluetooth consists of four main sections:

• Channel Classification - A method of detecting an interference on a channel-by-channel basis, or pre-defined channel mask.

• Link Management - Coordinates and distributes the AFH information to the rest of the Bluetooth network.

• Hop Sequence Modification - Avoids interference by selectively reducing the number of hopping channels.

• Channel Maintenance - A method for periodically re-evaluating the channels.

When AFH is enabled, the Bluetooth radio “hops around” (instead of through) the 802.11b high-rate channels. AFH coexistence allows enterprise devices to operate in any infrastructure.

Security

Wireless

NOTE: It is not recommended to perform Bluetooth wireless technology inquiry when high rate 802.11b operation is required.

The current Bluetooth specification defines security at the link level. Application-level security is not specified. This allows application developers to define security mechanisms tailored to their specific need. Link-level security occurs between devices, not users, while application-level security can be implemented on a per-user basis. The Bluetooth specification defines security algorithms and procedures required to authenticate devices, and if needed, encrypt the data flowing on the link between the devices. Device authentication is a mandatory feature of Bluetooth while link encryption is optional.

Pairing of Bluetooth devices is accomplished by creating an initialization key used to authenticate the devices and create a link key for them. Entering a common personal identification number (PIN) in the devices being paired generates the initialization key. The PIN is never sent over the air. By default, the Bluetooth stack responds with no key when a key is requested (it is up to user to respond to the key request event). Authentication of Bluetooth devices is based-upon a challenge-response transaction. Bluetooth allows for a PIN or passkey used to create other 128-bit keys used for security and encryption. The encryption key is derived from the link key used to authenticate the pairing devices. Also worthy of note is the limited range and fast frequency hopping of the Bluetooth radios that makes long-distance eavesdropping difficult.

Recommendations are:

• Perform pairing in a secure environment

• Keep PIN codes private and do not store the PIN codes in the device

• Implement application-level security.

Bluetooth Profiles

The device supports the Bluetooth services listed.

Table 5 Bluetooth Profiles

Service Discovery Protocol (SDP)

Serial Port Profile (SPP) Allows use of RFCOMM protocol to emulate serial cable

Object Push Profile (OPP) Allows the device to push and pull objects to and from a push

Advanced Audio Distribution Profile (A2DP)

Audio/Video Remote Control Profile (AVRCP)

Personal Area Network (PAN) Allows the use of Bluetooth Network Encapsulation Protocol to

Human Interface Device Profile (HID)

Profile Description

Handles the search for known and specific services as well as general services.

connection between two Bluetooth peer devices. For example, connecting the device to a printer.

server.

Allows the device to stream stereo-quality audio to a wireless headset or wireless stereo speakers.

Allows the device to control A/V equipment to which a user has access. It may be used in concert with A2DP.

provide L3 networking capabilities over a Bluetooth link. Only PANU role is supported.

Allows Bluetooth keyboards, pointing devices, gaming devices and remote monitoring devices to connect to the device.

Wireless

Table 5 Bluetooth Profiles (Continued)

Profile Description

Headset Profile (HSP) Allows a hands-free device, such as a Bluetooth headset, to place

and receive calls on the device.

Hands-Free Profile (HFP) Allows car hands-free kits to communicate with the device in the

car.

Phone Book Access Profile (PBAP)

Out of Band (OOB) Allows exchange of information used in the pairing process. Pairing

Symbol Serial Interface (SSI) Allows for communication with Bluetooth Imager.

File Transfer Profile (FTP) Provides the capability to browse, manipulate and transfer files in

Generic Attribute Profile (GATT) Provides profile discovery and description services for Bluetooth

HID Over GATT Profile (HOGP) Defines the procedures and features used by Bluetooth low energy

Generic Access Profile (GAP) Use for device discovery and authentication.

OBject EXchange (OBEX) Facilitates the exchange of binary objects between devices.

Allows exchange of Phone Book Objects between a car kit and a mobile device to allow the car kit to display the name of the incoming caller; allow the car kit to download the phone book so you can initiate a call from the car display.

is completed using the Bluetooth radio, but requires information from the OOB mechanism. Using OOB with NFC enables pairing when devices simply get close, rather than requiring a lengthy discovery process.

is initiated by NFC but completed using the Bluetooth radio. Paring requires information from the OOB mechanism. Using OOB with NFC enables pairing when devices simply get close, rather than requiring a lengthy discovery process.

file system of another system. Uses GOEP as a basis.

Low Energy protocol. It defines how attributes are grouped together into sets to form services.

HID Devices using GATT and Bluetooth HID Hosts using GATT.

Bluetooth Power States

The Bluetooth radio is off by default.

• Suspend - When the device goes into suspend mode, the Bluetooth radio stays on.

• Airplane Mode - When the device is placed in Airplane Mode, the Bluetooth radio turns off. When

Airplane mode is disabled, the Bluetooth radio returns to the prior state. When in Airplane Mode, the Bluetooth radio can be turned back on if desired.

Bluetooth Radio Power

Turn off the Bluetooth radio to save power or if entering an area with radio restrictions (for example, an airplane). When the radio is off, other Bluetooth devices cannot see or connect to the device. Turn on the Bluetooth radio to exchange information with other Bluetooth devices (within range). Communicate only with Bluetooth radios in close proximity.

NOTE: To achieve the best battery life, turn off radios when not in use.

Enabling Bluetooth

1. Swipe down from the Status bar to open the Notification panel.

2. Touch to turn Bluetooth on.

3. Touch the Home button.

Disabling Bluetooth

1. Swipe down from the Status bar to open the Notification panel.

2. Touch to turn Bluetooth off.

3. Touch the Home button.

Discovering Bluetooth Device(s)

The device can receive information from discovered devices without pairing. However, once paired, the device and a paired device exchange information automatically when the Bluetooth radio is on.

1. Ensure that Bluetooth is enabled on both devices.

2. Ensure that the Bluetooth device to discover is in discoverable mode.

Wireless

3. Ensure that the two devices are within 10 meters (32.8 feet) of one another.

4. Swipe down from the Status bar to open the Quick Access panel.

5. Touch and hold Bluetooth.

6. Touch Pair new device. The device begins searching for discoverable Bluetooth devices in the area

and displays them under Available devices.

7. Scroll through the list and select a device. The Bluetooth pairing request dialog box appears.

8. Touch Pair on both devices.

9. The Bluetooth device is added to the Paired devices list and a trusted (“paired”) connection is

established.

Changing the Bluetooth Name

By default, the device has a generic Bluetooth name that is visible to other devices when connected.

1. Go to Settings.

2. Touch Connected devices > Connection preferences > Bluetooth.

3. If Bluetooth is not on, move the switch to turn Bluetooth on.

4. Touch Device name.

5. Enter a name and touch RENAME.

6. Touch the Home button.

Connecting to a Bluetooth Device

Once paired, connect to a Bluetooth device.

1. Go to Settings.

2. Touch Connected devices > Connection preferences > Bluetooth.

Wireless

In the list, touch the unconnected Bluetooth device.

When connected, Connected appears below the device name.

Selecting Profiles on the Bluetooth Device

Some Bluetooth devices have multiple profiles.

1. Go to Settings.

2. Touch Connected devices > Connection preferences > Bluetooth.

3. In the Paired Devices list, touch next to the device name.

4. Turn on or off a profile to allow the device to use that profile.

5. Touch the Home button.

Unpairing a Bluetooth Device

Unpairing a Bluetooth device erases all pairing information.

1. Go to Settings.

2. Touch Connected devices > Connection preferences > Bluetooth.

3. In the Paired Devices list, touch next to the device name.

4. Touch FORGET.

5. Touch the Home button.

Cast

Use Cast to mirror the device screen on a Miracast enabled wireless display.

1. Go to Settings.

2. Touch Connected devices > Connection preferences > Cast.

3. Touch > Enable wireless display.

The device searches for nearby Miracast devices and lists them.

4. Touch a device to begin casting.

5. Touch the Home button.

Near Field Communications

NFC/HF RFID is a short-range wireless connectivity technology standard that enables secure transaction between a reader and a contactless smartcard. The technology is based on ISO/IEC 14443 type A and B (proximity), ISO/IEC 15693 (vicinity), and FeliCa standards, using the HF 13.56 MHz unlicensed band.

The device supports the following operating modes:

• Reader mode

• Peer-to-Peer communication

• Card Emulation mode.

Using NFC, the device can:

• Read contactless cards such as contactless tickets, ID cards and ePassport.

• Read and write information to contactless cards such as SmartPosters and tickets, as well as devices

with NFC interface such as vending machines.

• Read information from supported medical sensors.

• Pair with supported Bluetooth devices such as printers , ring scanners (ex. RS6000), and headsets (ex.

HS3100).

• Exchange data with another NFC device.

• Emulate contactless card such as payment, or ticket.

The device NFC antenna is positioned to read NFC cards from the top of the device while the device is being held.

Reading NFC Cards

Read contactless cards using NFC.

Figure 25 Reading Cards

Wireless

1. Launch an NFC enabled application.

2. Hold device as shown.

3. Move the device close to the NFC card until it detects the card.

4. Hold the card steadily until the transaction is complete (usually indicated by the application).

Enterprise NFC Settings

Improve NFC performance or increase battery life by selecting which NFC features to use on the device.

• Card Detection Mode - Select a card detection mode.

• Low - Increases battery life by lowering the NFC detection speed.

• Hybrid - Provides a balance between NFC detection speed and battery life (default).

• Standard - Provides the best NFC detection speed, but reduces battery life.

• Supported Card Technology - Select an option to detect only one NFC tag type, increasing battery

life, but reducing detection speed.

• All (Default) - Detects all NFC tag types.

Wireless

• ISO 14443 Type A/B

• FeliCa

• ISO15693

• Other NFC settings available with Zebra administrator tools (CSP) - Allows configuration of

additional Enterprise NFC Settings through staging tools and Mobile Device Management (MDM) solutions with an MX version that supports the Enterprise NFC Settings Configuration Service Provider (CSP). For more information on using the Enterprise NFC Settings CSP, refer to: techdocs.zebra.com

Accessories

Introduction

The device accessories provide a variety of product support capabilities.

Table 6 Device Accessories

Accessory Part Number Description

Cradles

Charge Only Cradle CRD-ET5X-1SCG2 Charges the main battery and optional

Communication and Charging Cradle

Rugged Communication and Charging Cradle

4-Slot Charge Only Cradle CRD-ET5X-SE4CO2-01 Charges up to four main batteries and

CRD-ET5X-1SCOM1 Charges the main battery and optional

CRD-ET5X-1SCOM2R Charges the main battery and optional

Power Pack installed in the Expansion Back. Requires power supply

PWR-BGA12V50W0WW, DC line cord

CBL-DC-388A1-01 and country-specific AC line cord.

Power Pack installed in the Expansion Back. Requires power supply

PWR-BGA12V50W0WW, DC line cord

CBL-DC-388A1-01, and country-specific AC line cord.

Power Pack installed in the Expansion Back. Supports rugged frame and rugged IO Adapter. Requires power supply

PWR-BGA12V50W0WW, DC line cord

CBL-DC-388A1-01, and country-specific AC line cord.

optional Power Pack installed in the Expansion Back and up to four Power Packs in the optional 4-Slot Battery Charger. Requires power supply

PWR-BGA12V108W0WW, DC line cord

CBL-DC-388A1-01, and country-specific AC line cord.

Accessories

Table 6 Device Accessories (Continued)

Accessory Part Number Description

Chargers

Power Supply PWR-BGA12V108W0WW Provides power to the 4-Slot Charge Only

Cradle.

Power Supply PWR-BGA12V50W0WW Provides power to the Charge Only

Cradle, Communication and Charging Cradle, Rugged Communication and Charging Cradle, and 4-Slot Battery Charger for Optional Battery Power Pack.

Power Supply PWR-WUA5V12W0xx

Where xx:

AR = Argentina

AU = Australia

BR = Brazil

CN = China

EU = European Union Countries

GB = Great Britain

IN = India

KR = Korea

US = United States

4-Slot Battery Charger SAC-ET5X-4PPK1-01 Chargers up to four Power Packs.

Rugged Charge Connector CHG-ET5X-CBL2-01 Charges the main battery and optional

Miscellaneous

Replacement 8.4 in. Internal Battery

Replacement 10.1 in. Internal Battery

Replacement 8.4 in. Battery Cover

Replacement 10.1 in. Battery Cover

8.4 in. Rugged Frame with IO Adapter

BTRY-ET5X-8IN5-01 Replacement battery for 8.4 in. tablet.

BTRY-ET5X-10IN5-01 Replacement battery for 10.1 in. tablet.

KT-ET5X-8BTDR2-01 Replacement battery cover for 8.4 in.

KT-ET5X-10BTDR2-01 Replacement battery cover for 10.1 in.

SG-ET5X-8RCSE2-02 Add extra protection for the 8.4 in. tablet
