Zebra EM220II Reference Guide

EM220II
Mobile Printer SDK API Reference Guide
P1007752-033 Rev. 1.00
EM220II
- 2 -
Mobile Printer SDK API Reference Guide
Table of Contents
1. Manual Information ........................................................................................................ 6
1-1 Supporting O/S & Platform.......................................................................................... 6
1-2 Supporting Devices ..................................................................................................... 6
2. Properties ....................................................................................................................... 7
2-1 CharacterSet (LONG R/W) ......................................................................................... 7
2-2 International CharacterSet (LONG R/W) .................................................................... 8
2-3 State (LONG R) .......................................................................................................... 8
2-4 PowerValue (LONG R) ............................................................................................... 9
2-5 MsrMsgMode (BOOL W) ............................................................................................ 9
3. Methods ........................................................................................................................ 10
3-1 PrinterOpen .............................................................................................................. 10
3-2 PrinterClose .............................................................................................................. 11
3-3 LineFeed ................................................................................................................... 11
3-4 PrintBarcode ............................................................................................................. 12
3-5 PrintText .................................................................................................................... 14
3-6 PrintBitmap ............................................................................................................... 16
3-7 CheckPrinter ............................................................................................................. 17
3-8 MsrReadReady ......................................................................................................... 17
3-9 MsrReadCancel ........................................................................................................ 18
3-10 MsrReadTrack ........................................................................................................ 18
3-11 DirectIO ................................................................................................................... 19
3-12 NextPrintPos ........................................................................................................... 20
3-13 GetTrack1 ............................................................................................................... 20
3-14 GetTrack2 ............................................................................................................... 20
3-15 GetTrack3 ............................................................................................................... 21
3-16 MsrReadFullTrack................................................................................................... 21
3-17 MsrRead1Track ...................................................................................................... 22
3-18 MsrRead2Track ...................................................................................................... 22
3-19 MsrRead3Track ...................................................................................................... 23
4. Message ........................................................................................................................ 24
4-1 BXL_LPARAM _MSR ............................................................................................... 24
Rev. 1.00
EM220II
- 3 -
Mobile Printer SDK API Reference Guide
Proprietary Statements
This manual contains proprietary information of Zebra Technologies Corporation. It is intended solely for the information and use of parties operating and maintaining the equip­ment described herein. Such proprietary information may not be used, reproduced, or dis­closed to any other parties for any other purpose without the expressed written permission of Zebra Technologies Corporation.
Product Improvements Since continuous product improvement is a policy of Zebra Technologies Corporation, all specifications and signs are subject to change without notice.
FCC Compliance Statement NOTE: This equipment has been tested and found to comply with the limits or a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equip­ment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet or circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Exposure to Radio Frequency radiation. To conform to FCC RF exposure re­quirements this device shall be used in accordance with the operating conditions and in­structions listed in this manual. NOTE: This unit was tested with shielded cables on the peripheral devices. Shielded cables must be used with the unit to insure compliance. Changes or modifications to this unit not expressly approved by Zebra Technologies Cor­poration could void the user’s authority to operate this equipment.
Rev. 1.00
EM220II
- 4 -
Mobile Printer SDK API Reference Guide
Canadian Compliance Statement
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada. “IC:” before the equipment certification number signifies that the Industry Canada technical specifications were met. It does not guarantee that the certified product will operate to the user’s satisfaction.
Liability Disclaimer Inasmuch as every effort has been made to supply accurate information in this manual, Zebra Technologies Corporation is not liable for any erroneous information or omissions. Zebra Technologies Corporation reserves the right to correct any such errors and disclaims liability resulting therefrom.
No Liability for Consequential Damage In no event shall Zebra Technologies Corporation or anyone else involved in the creation, production, or delivery of the accompanying product (including hardware and software) be liable for any damages whatsoever (including, without limitation, damages for loss of business profits, business interruption, loss of business information, or other pecuniary loss) arising out of the use of or the results of use of or inability to use such product, even if Zebra Technologies Corporation has been advised of the possibility of such damages. Because some states do not allow the exclusion of liability for consequential or incidental damages, the above limitation may not apply to you.
Rev. 1.00
EM220II
- 5 -
Mobile Printer SDK API Reference Guide
Copyrights
The copyrights in this manual and the label print engine described therein are owned by Zebra Technologies Corporation. Unauthorized reproduction of this manual or the software in the label print engine may result in imprisonment of up to one year and fines of up to $10,000 (17 U.S.C.506). Copyright violators may be subject to civil liability. This product may contain ZPL® , ZPL II® , and ZebraLinktm programs; Element Energy Equalizer® Circuit; E3® ; and AGFA fonts. Software © ZIH Corp. All rights reserved worldwide. ZebraLink and all product names and numbers are trademarks, and Zebra, the Zebra logo, ZPL, ZPL II, Element Energy Equalizer Circuit, and E3 Circuit are registered trademarks of ZIH Corp. All rights reserved worldwide. Monotype® , Intellifont® and UFST® are trademarks of Monotype Imaging, Inc. registered in the United States Patent and Trademark Office and may be registered in certain jurisdic­tions. AndyTM , CG PalacioTM, CG Century SchoolbookTM, CG TriumvirateTM, CG TimesTM, Monotype KaiTM, Monotype MinchoTM and Monotype SungTM are trademarks of Monotype Imaging, Inc. and may be registered in some jurisdictions. HY Gothic HangulTM is a trademark of Hanyang Systems, Inc. AngsanaTM is a trademark of Unity Progress Company (UPC) Limited. Andale® , Arial® , Book Antiqua® , Corsiva® , Gill Sans® , Sorts® and Times New Roman® are trademarks of The Monotype Corporation registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions.
Century Gothic™, Bookman Old StyleTM and Century SchoolbookTM are trademarks of
The Monotype Corporation and may be registered in certain jurisdictions. HGPGothicB is a trademark of the Ricoh company, Ltd. and may be registered in some ju­risdictions. UniversTM is a trademark of Heidelberger Druckmaschinen AG, which may be registered in certain jurisdictions, exclusively licensed through Linotype Library GmbH, a wholly owned subsidiary of Heidelberger Druckmaschinen AG. Futura® is a trademark of Bauer Types SA registered in the United States Patent and Trademark Office and may be registered in some jurisdictions. TrueType® is a trademark of Apple Computer, Inc. registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions. All other product names are the property of their respective owners. All other brand names, product names, or trademarks belong to their respective holders. © 2006 ZIH Corp.
Rev. 1.00
EM220II
- 6 -
Mobile Printer SDK API Reference Guide
1. Manual Information
This SDK Manual provides information on the dll files required for Windows application program development.
1-1 Supporting O/S & Platform
- O/S
Microsoft Windows CE 5.x
Microsoft Windows CE 6.x
Microsoft Windows XP
Microsoft Windows Vista
Microsoft Windows 7
Microsoft Windows 8
- Platform
Pocket PC 2002
Pocket PC 2003
Pocket PC 2003 second edition
Windows Mobile 5
Windows Mobile 6
Custom Platform for Armv4i CPU * supported .Net Framework
1-2 Supporting Devices
This is a list of verified devices. If your PDA cpu type is Armv4 or Armv4i, it is compatible with our module driver.
- Bluebird BIP6000
- ATID AT570
- Widefly WF35
Rev. 1.00
EM220II
- 7 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_CS_PC437 0 Code page PC437
BXL_CS_Katakana 1 Katakana
BXL_CS_PC850 2 Code page PC850
BXL_CS_PC860 3 Code page PC860
BXL_CS_PC863 4 Code page PC863
BXL_CS_PC865 5 Code page PC865
BXL_CS_WPC1252
16
Code page WPC1252
BXL_CS_PC866
17
Code page PC866
BXL_CS_PC852
18
Code page PC852
BXL_CS_PC858
19
Code page PC858
BXL_CS_PC864
22
Code page PC864
BXL_CS_THAI42
23
Code page THAI42
BXL_CS_WPC1253
24
Code page WPC1253
BXL_CS_WPC1254
25
Code page WPC1254
BXL_CS_WPC1257
26
Code page WPC1257
BXL_CS_FARSI
27
Code page Farsi
BXL_CS_WPC1251
28
Code page WPC1251
BXL_CS_PC737
29
Code page PC737
BXL_CS_PC775
30
Code page PC775
BXL_CS_THAI14
31
Code page THAI14
BXL_CS_PC862
33
Code page PC862
BXL_CS_PC855
36
Code page PC855
BXL_CS_PC857
37
Code page PC857
BXL_CS_PC928
38
Code page PC928
BXL_CS_THAI16
39
Code page THAI16
BXL_CS_WPC1256
40
Code page PC1256
BXL_CS_USER
255
User set page
2. Properties
The constant values used in the dll files provided are declared in the BxlConst.h file. The development environment was based on C++.
2-1 CharacterSet (LONG R/W)
As the attribute that defines the Code Page of the printer, the default setting is BXL_CS_437. Use the SetCharacterSet(), GetCharacterSet() functions to set values or recall previously set values.
The Code Pages that can be used are as follows:
Rev. 1.00
EM220II
- 8 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_ICS_USA 0 USA code setting
BXL_ICS_FRANCE
1
FRANCE code setting
BXL_ICS_GERMANY
2
GERMANY code setting
BXL_ICS_UK
3
UK code setting
BXL_ICS_DENMARK1
4
DENMARK1 code setting
BXL_ICS_SWEDEN
5
SWEDEN code setting
BXL_ICS_ITALY 6 ITALY code setting
BXL_ICS_SPAIN 7 SPAIN code setting
BXL_ICS_NORWAY
9
NORWAY code setting
BXL_ICS_DENMARK2
10
DENMARK 2 code setting
Code
Value
Description
BXL_STS_NORMAL
0
Printer status is normal
BXL_STS_PAPEREMPTY
1
No paper in printer
BXL_STS_COVEROPEN
2
The printer paper cover is open
BXL_STS_POWEROVER
4
The printer battery capacity is insufficient
BXL_STS_MSR_READY
8
Currently in MSR read mode, printing not possible
BXL_STS_PRINTING
16
Currently printing or transmitting data
BXL_STS_ERROR
32
An error has occurred
BXL_STS_NOT_OPEN
64
The printer is not open
BXL_STS_ERROR_OCCUR
128
An error has occurred
2-2 International CharacterSet (LONG R/W)
As the attribute that defines the International Character Set of the printer, the default setting is BXL_ICS_USA. Use the SetInterChrSet(), GetInterChrSet()functions to set values or recall previously set values.
The International Character Sets that can be used are as follows:
2-3 State (LONG R)
This attribute sets the printer State. It can only be read, and is automatically set when examining the printer State by using the CheckPrinter function. As State values can be set in duplication, each value can be confirmed via bit calculation. The values of this attribute can be recalled by using the GetState function.
Printer State values are as follows:
Rev. 1.00
EM220II
- 9 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_PWR_HIGH
0
Battery charge status: 95%
BXL_PWR_MIDDLE
1
Battery charge status: 85% or higher
BXL_PWR_LOW
2
Battery charge status: 50% or higher
BXL_PWR_SMALL
3
Battery charge status: 25% or higher
BXL_PWR_NOT
4
Battery charge status: 25% or lower
Code
Value
Description
TRUE 0 Disable MSR Message functions
FALSE 1 Enable MSR Message functions
2-4 PowerValue (LONG R)
This attribute sets the battery capacity value of the printer. It can only be read, and is set every time the status of the printer battery changes. The values of this attribute can be recalled by using the GetPowerValue function.
Battery Capacity values are as follows:
2-5 MsrMsgMode (BOOL W)
This function sets MSR Message capacity value of the printer. The default setting is FALSE. Use the SetMsrMsgMode() functions to set values. Defaut value is false.
Battery Capacity values are as follows:
Rev. 1.00
EM220II
- 10 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_CREATE_ERROR
102
Failure to create communication target
BXL_NOT_OPENED
101
Unable to open communication port
BXL_STATUS_ERROR
103
Error occurred during status check
BXL_BAD_ARGUMENT
108
Incorrect argument specified
BXL_WRITE_ERROR
300
Failure to transmit data
BXL_READ_ERROR
301
Error in received value or reception failure
3. Methods
The functions disclosed in the provided module are declared in the ExportFunc.h file. The development environment was based on C++.
3-1 PrinterOpen
In order to use the module, this function is enabled. For PDA types with different In/Out ports, port settings for each are required. In general, two-way communication is possible with just the strOutPortName setting.
long PrinterOpen( LPCTSTR strOutPortName,
Long lTimeout
);
[Parameters]
* strOutPortName
[in] Unicode Data ending with null. The virtual Serial Port number and Baudrate of the currently connected device is conveyed for printing. If strOutPortName is NULL, strOutPortName sets to In/Out data processing.(ex: COM4:19200)
* lTimeout
[in] Specifies the timeout, in milliseconds, used to calculate the total timeout period for open operations.
[Return Values]
Rev. 1.00
EM220II
- 11 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_STATUS_ERROR
103
Error occurred during status check
BXL_WRITE_ERROR
300
Failure to transmit data
3-2 PrinterClose
This function disables the SDK module. Functions related to printing and MSR are no longer available for use.
long PrinterClose();
[Parameters]
None
[Return Values]
3-3 LineFeed
This function dictates line feeding to the integer value conveyed for printing.
long LineFeed ( int nFeed, );
[Parameters]
* nFeed
[in] The integer value conveys the number of lines for line feeding in the form of printing value.
[Return Values]
Rev. 1.00
- 12 -
Mobile Printer SDK API Reference Guide
3-4 PrintBarcode
Code
Value
Data Number Limit
Data Value Range
BXL_BCS_UPCA
101
11 ≤ n ≤ 12
48 ≤ data ≤ 57
BXL_BCS_UPCE
102
11 ≤ n ≤ 12
48 ≤ data ≤ 57
BXL_BCS_EAN13 BXL_BCS_JAN13
103 104
12 ≤ n ≤ 13
48 ≤ data ≤ 57
BXL_BCS_EAN8 BXL_BCS_JAN8
105 106
7 ≤ n ≤ 8
48 ≤ data ≤ 57
BXL_BCS_Code39
107
1 ≤ n ≤ 255
48 ≤ data ≤ 57, 65 ≤ data ≤ 90,
data =32,36,37,43,45,46,47
BXL_BCS_ITF
108
1 ≤ n ≤ 255
(even number)
48 ≤ data ≤ 57
BXL_BCS_Codabar
109
1 ≤ n ≤ 255
48 ≤ data ≤ 57, 65 ≤ data ≤ 68,
data =36,43,45,46,47,58
BXL_BCS_Code93
110
1 ≤ n ≤ 255
0 ≤ data ≤ 127
BXL_BCS_Code128
111
2 ≤ n ≤ 255
0 ≤ data ≤ 127
BXL_BCS_PDF417
200
2 ≤ n ≤ 928
0 ≤ data ≤ 255
BXL_BCS_QRCODE
202~3
2 ≤ n ≤ 928
0 ≤ data ≤ 255
BXL_BCS_DATAMATRIX
204
2 ≤ n ≤ 928
0 ≤ data ≤ 255
BXL_BCS_MAXICODE
205~6
2 ≤ n ≤ 928
0 ≤ data ≤ 255
This function supports the 1-dimension and 2-dimension barcode printing function.
long PrintBarcode(
PCHAR Data, long symbology, long Height, long Width, long Alignment, long TextPosition
);
[Parameters]
* Data
[in] ANSI Code Data ending with null. Barcode data to be printed are conveyed.
* symbology
[in] Defines the barcode type. The barcode type is defined in BxlConst.h.
EM220II
* Height
[in] This value sets the barcode height in Dot units. The value range is 1~255. Two dimensional barcodes are not affected.
* Width
[in] This value sets the barcode width according to a value range of 2~7. If the print area of the barcode exceeds the printing paper, barcode printing may not be possible. Two dimensional barcodes are not affected by this value.
Rev. 1.00
EM220II
- 13 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_ALIGNMENT_LEFT
0
Left-aligned
BXL_ALIGNMENT_CENTER
1
Centered
BXL_ALIGNMENT_RIGHT
2
Right-aligned
Code
Value
Description
BXL_BC_TEXT_NONE
0
Barcode data not printed
BXL_BC_TEXT_ABOVE
1
Barcode data printed above barcode
BXL_BC_TEXT_BELOW
2
Barcode data printed below barcode
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_STATUS_ERROR
103
Error occurred during status check
BXL_WRITE_ERROR
300
Failure to transmit data
BXL_BC_DATA_ERROR
500
Error in barcode data
BXL_BC_NOT_SUPPORT
501
Barcode type not supported
* Alignment
[in] This value sets the barcode alignment.
* TextPosition
[in] This value sets the print position of the barcode data. Two dimensional barcodes have only the BXL_BC_TEXT_NONE value.
[Return Values]
Rev. 1.00
- 14 -
Mobile Printer SDK API Reference Guide
3-5 PrintText
Code
Value
Description
BXL_ALIGNMENT_LEFT
0
Left-aligned
BXL_ALIGNMENT_CENTER
1
Centered
BXL_ALIGNMENT_RIGHT
2
Right-aligned
Code
Value
Description
BXL_FT_DEFAULT
0
Font A, print using the basic device font
Basic setting value
BXL_FT_FONTB 1 Set to Font B
BXL_FT_BOLD
2
Adds Bold lettering attribute
BXL_FT_UNDERLINE
4
Adds Underlining attribute
BXL_FT_REVERSE
8
Adds Reverse lettering attribute
This function supports the text printing function.
long PrintText( LPCTSTR Data, long Alignment, long Attribute, long TextSize );
[Parameters]
* Data
[in] Unicode Data ending with null. Conveys the barcode data to be printed.
* Alignment
[in] This value sets the barcode alignment.
EM220II
* Attribute
[in] This value sets the text properties. The following values can be duplicated.
Rev. 1.00
EM220II
- 15 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_TS_0WIDTH
0
Width magnification set to x1
BXL_TS_1WIDTH
16
Width magnification set to x2
BXL_TS_2WIDTH
32
Width magnification set to x3
BXL_TS_3WIDTH
48
Width magnification set to x4
BXL_TS_4WIDTH
64
Width magnification set to x5
BXL_TS_5WIDTH
80
Width magnification set to x6
BXL_TS_6WIDTH
96
Width magnification set to x7
BXL_TS_7WIDTH
112
Width magnification set to x8
Code
Value
Description
BXL_TS_0HEIGHT
0
Height magnification set to x1
BXL_TS_1HEIGHT
1
Height magnification set to x2
BXL_TS_2HEIGHT
2
Height magnification set to x3
BXL_TS_3HEIGHT
3
Height magnification set to x4
BXL_TS_4HEIGHT
4
Height magnification set to x5
BXL_TS_5HEIGHT
5
Height magnification set to x6
BXL_TS_6HEIGHT
6
Height magnification set to x7
BXL_TS_7HEIGHT
7
Height magnification set to x8
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_STATUS_ERROR
103
Error occurred during status check
BXL_WRITE_ERROR
300
Failure to transmit data
* TextSize
[in] This value sets the text size properties. The width and height values can be uplicated.
[Return Values]
Rev. 1.00
EM220II
- 16 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_WIDTH_FULL
-1
Set to a value of 384, image is fit to full size of paper
BXL_WIDTH_NONE
-2
No variation given to image size
Code
Value
Description
BXL_ALIGNMENT_LEFT
0
Left-aligned
BXL_ALIGNMENT_CENTER
1
Centered
BXL_ALIGNMENT_RIGHT
2
Right-aligned
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_STATUS_ERROR
103
Error occurred during status check
BXL_WRITE_ERROR
300
Failure to transmit data
BXL_BITMAPLOAD_ERROR
400
Failure to read image file
3-6 PrintBitmap
This function prints image files. Only Bmp files are supported.
long PrintBitmap ( LPCTSTR FileName, long Width, long Alignment, long Level );
[Parameters]
* FileName
[in] Expressed as a row of Unicode characters, the full path of the image file is set.
* Width
[in] This value is the width of the image file to be converted. The value range is 0~384. When setting the value as below, the image size is modified to fit conditions.
* Alignment
[in] This value sets the barcode alignment.
* Level
[in] This value sets the color level of the image. The value range is 0~100.
[Return Values]
Rev. 1.00
EM220II
- 17 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_READ_ERROR
301
Failure to receive data
BXL_WRITE_ERROR
300
Failure to transmit data
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_WRITE_ERROR
300
Failure to transmit data
3-7 CheckPrinter
This function checks printer status and sets the printer status properties.
long CheckPrinter ();
[Parameters]
None
[Return Values]
3-8 MsrReadReady
This function switches the printer to MSR Ready status. Printing is not possible when in eady status. After returning via BXL_SUCCESS and if the State property is BXL_STS_MSR_READY, the standby status is deemed normal.
long CheckPrinter ();
[Parameters]
None
[Return Values]
Rev. 1.00
- 18 -
Mobile Printer SDK API Reference Guide
3-9 MsrReadCancel
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_WRITE_ERROR
300
Failure to transmit data
BXLMSR_NOTREADY
602
Not in READY status
BXLMSR_FAILEDMODE
601
In automatic read mode
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_WRITE_ERROR
300
Failure to transmit data
BXLMSR_DATAEMPTY
603
Not in READY status
This function deactivates the MSR Ready status of the printer. Long MsrReadCancel();
[Parameters]
None
[Return Values]
EM220II
3-10 MsrReadTrack
This function recalls MSR data. If the MSR is in read mode and BXLMSR_DATAEMPTY is returned, the card has not yet been read in the MSR. Scanning the card in the MSR again can be tried, or the MSRReadCancel function can be used to cancel read mode.
Long MsrReadTrack (
PCHAR Data1, PCHAR Data2, PCHAR Data3
);
[Parameters]
* PCHAR Data1
[in, out] MSR Data Track 1 read from the buffer defined by the caller.
* PCHAR Data2
[in, out] MSR Data Track 2 read from the buffer defined by the caller.
* PCHAR Data3
[in, out] MSR Data Track 3 read from the buffer defined by the caller.
[Return Values]
Rev. 1.00
EM220II
- 19 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_STATUS_ERROR
103
Error occurred during status check
BXL_WRITE_ERROR
300
Failure to transmit data
BXL_READ_ERROR
301
Error in received value or reception failure
3-11 DirectIO
This function can send and read data defined by the user.
Long DirectIO (
PCHAR Data, UINT uiWrite, PCHAR pRequet, UINT uiRead
);
[Parameters]
* PCHAR Data,
[in] Data to be sent to the printer, data is ANSI code
* UINT uiWrite
[in] Size of data to be sent to the printer
* PCHAR pRequet
[in, out] Sets the values read from the buffered defined by the caller
* UINT uiRead
[in, out] Converts the size of date to be read by the caller to the actual size of read data
[Return Values]
Rev. 1.00
EM220II
- 20 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_STATUS_ERROR
103
Error occurred during status check
BXL_WRITE_ERROR
300
Failure to transmit data
3-12 NextPrintPos
If the label function is set, the paper is fed up to the next printing position.
Long NextPrintPos ();
[Parameters]
* None
[Return Values]
3-13 GetTrack1
This function returns MSR Track1 data. If the MSR is in read mode and NULL is returned, the card has not yet been read by the MSR. Strip the card with the MSR again. MSRReadCancel function can be used to cancel read mode.
TCHAR * GetTrack1 ();
[Parameters]
* None
[Return Values]
If the function is successful, MSR Track1 data will be returned. If it has failed, the function will return NULL pointer.
3-14 GetTrack2
This function returns MSR Track2 data. If the MSR is in read mode and NULL is returned, the card has not yet been read by the MSR. Strip the card with the MSR again. MSRReadCancel function can be used to cancel read mode.
TCHAR * GetTrack2 ();
Rev. 1.00
EM220II
- 21 -
Mobile Printer SDK API Reference Guide
[Parameters]
* None
[Return Values]
If the function is successful, MSR Track2 data will be returned. If it has failed, the function will return NULL pointer.
3-15 GetTrack3
This function returns MSR Track3 data. If the MSR is in read mode and NULL is returned, the card has not yet been read by the MSR. Strip the card with the MSR again. MSRReadCancel function can be used to cancel read mode.
TCHAR * GetTrack3 ();
[Parameters]
* None
[Return Values]
If the function is successful, MSR Track2 data will be returned. If it has failed, the function will return NULL pointer.
3-16 MsrReadFullTrack
This function returns MSR Full Track data. If the MSR is in read mode and ERROR Code is returned, the card has not yet been read by the MSR. Strip the card with the MSR again. MSRReadCancel function can be used to cancel read mode.
long MsrReadFullTrack (PCHAR Track, UINT uiLength);
[Parameters]
* PCHAR Track
[in, out] MSR Track data read from the buffer defined by the caller.
If Printer sentinel mode is 0 or 1(None, Static), each Track, Track Data format set as below.
1,2,3 Track Format : [TRACK1 DATA] 0x1C [TRACK2 DATA] 0x1C [TRACK3 DATA] 1,3 Track Format : [TRACK1 DATA] 0x1C 0x1C [TRACK3 DATA] If Printer sentinel mode is 2(Dynamic), Track Data format set as below.
1,2,3 Track Format : [TRACK1 DATA] [TRACK2 DATA] [TRACK3 DATA]
* UINT uiLength
[in] Size of Track buffer to be sent to the printer
Rev. 1.00
EM220II
- 22 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_NOT_SUPPORT
107
If sentinel mode set 2, it isnt support
BXLMSR_DATAEMPTY
603
Not in READY status
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_NOT_SUPPORT
107
If sentinel mode set 2, it isnt support
BXLMSR_DATAEMPTY
603
Not in READY status
[Return Values]
If the function is successful, MSR Full track data will be returned. If it has failed, the function will return error code and NULL pointer.
3-17 MsrRead1Track
This function returns MSR 1 Track data. If the MSR is in read mode and ERROR Code is returned, the card has not yet been read by the MSR. Strip the card with the MSR again. MSRReadCancel function can be used to cancel read mode.
long MsrRead1Track (PCHAR Track, UINT uiLength);
[Parameters]
* PCHAR Track
[in, out] MSR Track data read from the buffer defined by the caller.
* UINT uiLength
[in] Size of Track buffer to be sent to the printer
[Return Values]
If the function is successful, MSR 1 track data will be returned. If it has failed, the function will return error code and NULL pointer.
3-18 MsrRead2Track
This function returns MSR 2 Track data. If the MSR is in read mode and ERROR Code is returned, the card has not yet been read by the MSR. Strip the card with the MSR again. MSRReadCancel function can be used to cancel read mode.
long MsrRead2Track (PCHAR Track, UINT uiLength);
Rev. 1.00
EM220II
- 23 -
Mobile Printer SDK API Reference Guide
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_NOT_SUPPORT
107
If sentinel mode set 2, it isnt support
BXLMSR_DATAEMPTY
603
Not in READY status
Code
Value
Description
BXL_SUCCESS
0
Returns after function success
BXL_NOT_OPENED
101
Unable to open communication port
BXL_NOT_SUPPORT
107
If sentinel mode set 2, it isnt support
BXLMSR_DATAEMPTY
603
Not in READY status
[Parameters]
* PCHAR Track
[in, out] MSR Track data read from the buffer defined by the caller.
* UINT uiLength
[in] Size of Track buffer to be sent to the printer
[Return Values]
If the function is successful, MSR 2 track data will be returned. If it has failed, the function will return error code and NULL pointer.
3-19 MsrRead3Track
This function returns MSR 3 Track data. If the MSR is in read mode and ERROR Code is returned, the card has not yet been read by the MSR. Strip the card with the MSR again. MSRReadCancel function can be used to cancel read mode.
long MsrRead3Track (PCHAR Track, UINT uiLength);
[Parameters]
* PCHAR Track
[in, out] MSR Track data read from the buffer defined by the caller.
* UINT uiLength
[in] Size of Track buffer to be sent to the printer
[Return Values]
If the function is successful, MSR 3 track data will be returned. If it has failed, the function will return error code and NULL pointer.
Rev. 1.00
EM220II
- 24 -
Mobile Printer SDK API Reference Guide
Value
Description
BXL_MSG_TRACK1
0x01
BXL_MSG_TRACK2
0x02
BXL_MSG_TRACK3
0x04
4. Message
If some events have occurred in printer, the SDK will send WM_MSR_ARRIVED (WM_USER+3) message.
4-1 BXL_LPARAM _MSR
This message will be posted when the printer reads MSR Track data from MSR sensor. lParam = 0 wParam
wParam is set by the following data.
Example) BXL_MSG_TRACK1 + BXL_MSG_TRACK2 = 0x03
Rev. 1.00
www.zebra.com
Zebra Technologies International, LLC Zebra Technologies Europe Limited
333 Corporate Woods Parkway Dukes Meadow
Vernon Hills, Illinois 60061, 3109 USA Millboard Road
Phone: +1.847.634.6700
Toll-Free: +1.800.423.0422
Fax: +1.847.913.8766
Bourne End
Buckinghamshire, SL8 5XF, UK
Phone: +44 (0)1628 556000
Fax: +44 (0)1628 556001
Loading...
