1. Notice

This Control Commands Manual contains information on the protocol and functions of all control commands that can be used with this printer (EM220II).

2. Control Commands List

Rev. 1.00

EM220II

- 7 -

Mobile Printer Command Manual

No

Command

Name

31

ESC t

Select character code table

32

ESC {

Turn upside-down print mode on/off

33

FS &

Select Kanji character mode

34

FS .

Cancel Kanji character mode

35

GS !

Select character size

36

GS $

Set absolute vertical print position in page mode

37

GS ( A

Execute test print

38

GS ( F

Set black mark control functions

39

GS ( k

Specify and print the symbol

40

GS ( E

Set NV user memory area

41

GS ( L

GS 8 L

Select graphics data

42

GS :

Start/end macro definition

43

GS B

Turn white/black reverse print mode on/off

44

GS H

Select print position of HRI characters

45

GS I

Transmit printer ID

46

GS I b

Transmit battery status

47

GS L

Set left margin

48

GS W

Set print area width

49

GS \

Set relative vertical print position in page mode

50

GS ^

Execute macro

51

GS a

Enable/disable Automatic Status Back (ASB)

52

GS f

Select font for HRI characters

53

GS h

Set bar code height

54

GS k

Print bar code

55

GS r

Transmit status

56

GS v 0

Print raster bit image

57

GS w

Set bar code width

58

BS L A

Execute automatic calibration in label mode

59

BS L L

Select label mode

60

BS L R

Select receipt mode

61

BS M

Select device font type

62

BS M S

Sentinel character set up commands

Rev. 1.00

- 8 -

Mobile Printer Command Manual

3-1 Command Notation

[Name] [Format]

[Range]

[Description]

The name of the command. The code sequence: ASCII indicates the ASCII character equivalents.

Hex indicates the hexadecimal equivalents. Decimal indicates the decimal equivalents.

[ ] k indicates that the content of the [ ] should be repeated k times. Provides the allowable ranges for the arguments.

Describes the function of the command.

3-2 Explanation of Terms

LSB

Least Significant Bit

3. Control Commands Details

EM220II

Rev. 1.00

- 9 -

Mobile Printer Command Manual

3-3 Control Commands Details

EOT n

[Name] [Format]

[Range] [Description]

Transmit status

ASCII

EOT n

Hex

04 n

Decimal

4 n

1 ≤ n ≤ 4 ▪ Transmits the status specified by n as follows:

n

Function

1

Transmit printer status

2

Transmit off-line status

3

Transmit error status

4

Transmit paper roll sensor status

▪ This printer transmits the following status.

n=1: Printer status

Bit

Off/On

Hex

Decimal

Function

0

Off

00

0

Fixed

1

On

02

2

Fixed

2

Off

00

0

Fixed

3

Off

00

0

On-Line

On

08

8

Off-Line

4

On

10

16

Fixed

5

Off

00

0

Fixed

6

Off

00

0

Fixed

7

Off

00

0

Fixed

n=2: Off-line status

Bit

Off/On

Hex

Decimal

Function

0

Off

00

0

Fixed

1

On

02

2

Fixed

2

Off

00

0

Cover is closed

On

04

4

Cover is open

3

Off

00

0

Paper is not being fed by using the paper FEED

button

On

08 8 Paper is being fed by the paper FEED button

4

On

10

16

Fixed

5

Off

00

0

No paper-end stop

On

20

32

Printing is being stopped

6

Off

00

0

Fixed

7

Off

00

0

Fixed

EM220II

Rev. 1.00

EM220II

- 10 -

Mobile Printer Command Manual

n=3: Error status

Bit

Off/On

Hex

Decimal

Function

0

Off

00

0

Fixed

1

On

02

2

Fixed

2

Off

00

0

Fixed

3

Off

00

0

Fixed

4

On

10

16

Fixed

5

Off

00

0

Fixed

6

Off

00

0

Fixed

7

Off

00

0

Fixed

n=4: Continuous paper sensor status

Bit

Off/On

Hex

Decimal

Function

0

Off

00

0

Fixed

1

On

02

2

Fixed

2

Off

00

0

Fixed

3

Off

00

0

Fixed

4

On

10

16

Fixed

5

Off

00

0

Paper end sensor; paper present

On

20

32

Paper end sensor; paper not present

6

Off

00

0

Paper end sensor; paper present

On

40

64

Paper end sensor; paper not present

7

Off

00

0

Fixed

[Notes]

This is a status request command to determine if the printer is off-line or if an error condition has occurred. Take the following into consideration:

• If this command interrupts the code string of another command, this command is processed as a parameter of the other command; therefore, the print result will not be correct.

• If a command such as graphics data or defined data has a code string

that is the same as a code string in a parameter, the printer processes and then continues with the bit-image or other command.

• This command following DLE can be executed in real-time command

mode.

This command is ignored when transmitting block data (Header ~ NUL).

Rev. 1.00

EM220II

- 11 -

Mobile Printer Command Manual

HT

[Name] [Format]

[Description]

Horizontal tab.

ASCII

HT

Hex

09

Decimal

9

▪ Moves the print position to the next horizontal tab position.

LF

[Name] [Format]

[Description]

Print and line feed.

ASCII

LF

Hex

0A

Decimal

10

▪ In standard mode, prints the data in the print buffer and feeds one line

based on the current line spacing.

▪ In page mode, only the print position moves, and the printer does not

perform actual printing

FF

[Name]

[Format]

[Description]

If in page mode, after printing, the printer is returned to standard mode. If the label function is set, the paper is fed to the next printing position.

ASCII

FF

Hex

0C

Decimal

12

▪ All data collected to the current point is printed, and then the printer is

converted from page mode to standard mode.

▪ After printing, the printer does not clear the buffer data of page mode. ▪ If the label function is set, the paper is fed to the next printing position.

CR

[Name] [Format]

[Description]

Print and carriage return.

ASCII

CR

Hex

0D

Decimal

13

▪ This command is ignored CR.

Rev. 1.00

EM220II

- 12 -

Mobile Printer Command Manual

DLE

[Name] [Format]

[Description]

Set real-time command mode.

ASCII

DLE

Hex

10

Decimal

16

▪ Set real-time command mode. ▪ A single command following this command is regarded as a real time

command that the printer executes upon receiving it.

▪ The real time command mode using DLE is activated for following

commands.

Command

Function

EOT

Transmit printer status

GS r

Transmit status

GS I

Transmit printer ID

CAN

[Name] [Format]

[Description]

Cancel print data in page mode.

ASCII

CAN

Hex

18

Decimal

24

▪ In page mode, deletes all the print data in the current print area.

ESC FF

[Name] [Format]

[Description]

Print data in page mode.

ASCII

ESC

FF

Hex

1B

0C

Deciml

27

12

▪ In page mode, prints all buffered data in the print area. ▪ After printing, the printer does not clear the buffer data. ▪ This command is used when the page mode data is printed repeatedly.

Rev. 1.00

EM220II

- 13 -

Mobile Printer Command Manual

ESC SP

[Name] [Format]

[Range] [Default] [Description]

Set right-side character spacing.

ASCII

ESC

SP n

Hex

1B

20 n

Decimal

27

32 n

0 ≤ n ≤ 255 n=0 ▪ Sets the character spacing for the right side of the character to

[n ×horizontal or vertical motion units].

▪ The maximum right-side character spacing is:

- 31.875mm.

ESC !

[Name] [Format]

[Range] [Default] [Description]

Select print mode(s).

ASCII

ESC ! n

Hex

1B

21 n

Decimal

27

33 n

0 ≤ n ≤ 255 n=0 ▪ Selects print mode(s) using n as follows:

Bit

Off/On

Hex

Decial

Function

0

Off

00

0

Character font A (12 × 24) selected.

On

01

1

Character font B (9 x 24) selected.

1,2

Off

00

0

Reserved.

3

Off

00

0

Emphasized mode not selected.

On

08

8

Emphasized mode selected.

4

Off

00

0

Double-height mode not selected.

On

10

16

Double-height mode selected.

5

Off

00

0

Double-width mode not selected.

On

20

32

Double-width mode selected.

6

Off

00

0

Reserved.

7

Off

00

0

Underline mode not selected.

On

80

128

Underline mode selected.

Rev. 1.00

EM220II

- 14 -

Mobile Printer Command Manual

ESC $

[Name] [Format]

[Range] [Description]

Set absolute print position.

ASCII

ESC

$

nL

nH

Hex

1B

24

nL

nH

Decimal

27

36

nL

nH

0 ≤ (nL + nH x 256) ≤ 65535 (0 ≤ nH ≤ 255, 0 ≤ nL ≤ 255) ▪ Sets the next print starting position, and the absolute print position, in

reference to the left margin. The distance from the beginning of the line to the left margin is [(nL + nH x 256) x (vertical or horizontal motion units)].

ESC *

[Name] [Format]

[Range]

[Description]

Select bit image mode.

ASCII

ESC

* m nL

nH

d1...dk

Hex

1B

2A m nL

nH

d1...dk

Decimal

27

42 m nL

nH

d1...dk

m=0, 1, 32, 33

1 ≤ (nL + nH x 256) ≤ 1023 (0 ≤ nL ≤ 255, 0 ≤ nH ≤ 3) 0 ≤ d ≤ 255

▪ Specifies the bit image in m mode for the number of dots specified by nL

and nH.

* dpi : dots per 25.4mm {1”}

m

Mode

Number of dots in

vertical direction

Vertical dot

density

Horizontal

dot density

Number of bytes (k)

0

8-dot

single-density

8

203/3 dpi

203/2 dpi

nL + nH x 256

1

8-dot

double-density

8

203/3 dpi

203 dpi

nL + nH x 256

32

24-dot

single-density

24

203 dpi

203/2 dpi

(nL + nH x 256) x 3

33

24-dot

double-density

24

203 dpi

(nL + nH x 256) x 3

Rev. 1.00

EM220II

- 15 -

Mobile Printer Command Manual

ESC –

[Name] [Format]

[Range] [Default] [Description]

Turn underline mode on/off.

ASCII

ESC - n

Hex

1B

2D n

Decimal

27

45 n

0 ≤ n ≤ 2, 48 ≤ n ≤ 50 n=0 ▪ Turn underline mode on or off, based on the following values of n:

n

Function

0,48

Turns off underline mode.

1,49

Turns on underline mode, set at 1-dot width.

2,50

Turns on underline mode, set at 2-dot width.

ESC 2

[Name] [Format]

[Description]

Select default line spacing.

ASCII

ESC 2

Hex

1B

32

Decimal

27

50

▪ The default line spacing is approximately 3.75 mm, which is equivalent to

30 dots.

ESC 3

[Name] [Format]

[Range] [Default] [Description]

Set line spacing

ASCII

ESC 3 n

Hex

1B

33 n

Decimal

27

51 n

0 ≤ n ≤ 255 n = 30 ▪ The vertical or horizontal motion unit is approximately 0.125 mm {1/203

inches}. This value equals one dot pitch.

▪ Sets the current line spacing to [n x vertical motion units] inches. ▪ The maximum settable line spacing is 31.875mm.

Rev. 1.00

EM220II

- 16 -

Mobile Printer Command Manual

ESC =

[Name] [Format]

[Range] [Default] [Description]

Select peripheral device

ASCII

ESC = n

Hex

1B

3D n

Decimal

27

61 n

1 ≤ n ≤ 3 n = 1 ▪ The selection of peripherals according to the n value is as follows.

n

Function

1,3

Printer Activation

2

Printer Deactivation

ESC @

[Name] [Format]

[Range] [Description]

Initialize printer.

ASCII

ESC @

Hex

1B

40

Decimal

27

64

32 ≤ n ≤ 126 ▪ Clears the data in the print buffer and resets the printer mode to the mode

that was in effect when the power was turned on.

ESC D

[Name] [Format]

[Range] [Default]

[Description]

Set horizontal tab positions.

ASCII

ESC

D

n1...nk

NUL

Hx

1B

44

n1...nk

00

Decimal

27

68

n1...nk

0

1 ≤ n ≤ 255 , 0 ≤ k ≤ 32

n=8, 16, 24, 32, 40,....., 232, 240, 248

(for font A in a standard character size width) ▪ Sets horizontal tab positions.

- n specifies the number of digits from the setting position to the left

margin or the beginning of the line.

- k specifies the number of bytes set for the horizontal tab position.

▪ The horizontal tab position is stored as a value of [character width x n]

measured form the beginning of the line.

Rev. 1.00

EM220II

- 17 -

Mobile Printer Command Manual

ESC E

[Name] [Format]

[Range] [Default] [Description]

Turn emphasized mode on / off.

ASCII

ESC E n

Hex

1B

45 n

Decimal

27

69 n

0 ≤ n ≤ 255 n=0 ▪ Turns emphasized mode on or off.

- When the LSB of n is 0, emphasized mode is turned off.

- When the LSB of n is 1, emphasized mode is turned on.

ESC G

[Name] [Format]

[Range] [Default] [Description]

Turn double-strike mode on/off.

ASCII

ESC G n

Hex

1B

47 n

Decimal

27

71 n

0 ≤ n ≤ 255 n=0 ▪ Turns double-strike mode on or off.

- When the LSB of n is 0, double-strike mode is turned off.

- When the LSB of n is 1, double-strike mode is turned on.

ESC J

[Name] [Format]

[Range] [Description]

Print and feed paper.

ASCII

ESC J n

Hex

1B

4A n

Decimal

27

74 n

0 ≤ n ≤ 255 ▪ Prints the data in the print buffer and feeds the paper [n X vertical motion unit].

ESC L

[Name] [Format]

[Description]

Select page mode.

ASCII

ESC L

Hex

1B

4C

Decimal

27

76

▪ Switches from standard mode to page mode.

Rev. 1.00

EM220II

- 18 -

Mobile Printer Command Manual

ESC M

[Name] [Format]

[Range] [Default] [Description]

Select character font/ MSR card read

ASCII

ESC M n

Hex

1B

4D n

Decimal

27

77 n

n = 0, 1, 48, 49 , 67, 68, 69, 70, 71, 72, 73 n=0

▪ Selects only-byte character fonts ▪ Selects Card reader mode

n

Function

0, 48

Character font A (12 × 24) selected

1, 49

Character font B (9 × 17) selected

2, 50

Character font C (9 × 24) selected

70

Set 1 track card reader mode

71

Set 2 track card reader mode

72

Set 1,2 track card reader mode

73

Transmits the MSR setting value(s)

67

Set 2 track card reader mode

68

Set 3 track card reader mode

69

Set 2,3 track card reader mode

66

Set 1,2,3 track card reader mode

99

Cancel MSR reader mode

02H 41H 31H 31H 1CH

Max DATA 76 characters (1Track data)

03H 0DH 0AH

02H 41H 31H 31H 1CH

(Header)

25H

(STX)

Max DATA 76 characters

(1Track data)

3FH

(ETX)

03H 0DH 0AH

(End)

START characters

(Max 10 byte)

Max DATA 76 characters (1Track data)

END characters

(Max 10 byte)

0DH 0AH

Magnetic card read out put format

Refer to function 3 memory switch #8 (8 - 6 & 7 setting) of BS ^ E command and function 1 of BS M S command.

- When set to Track 1 Read mode None sentinel character mode

Static sentinel character mode

Dynamic sentinel character mode

Rev. 1.00

- 19 -

Mobile Printer Command Manual

02H 42H 31H 31H 1CH

Max DATA 37 characters (2Track data)

03H 0DH 0AH

02H 42H 31H 31H 1CH

(Header)

3BH

(STX)

Max DATA 37 characters

(2Track data)

3FH

(ETX)

03H 0DH 0AH

(End)

START characters

(Max 10 byte)

Max DATA 37 characters

(2Track data)

END characters (Max 10 byte)

0DH 0AH

02H 44H 31H 31H 1CH

Max DATA104 characters (3Track data)

03H 0DH 0AH

02H 44H 31H 31H 1CH

(Header)

3BH

(STX)

Max DATA 104 characters

(3Track data)

3FH

(ETX)

03H 0DH 0AH

(End)

START characters

(Max 10 byte)

Max DATA 104 characters (3Track data)

END characters

(Max 10 byte)

0DH 0AH

02H 43H 31H 31H 1CH 1CH

Max DATA 76 characters

(1Track data)

1CH

Max DATA 37 Characters

(2Track data)

03H 0DH 0AH

02H 43H 31H

31H 1CH

1CH

(Header)

3BH

(STX)

Max DATA76

characters

(1Track data)

3FH

(ETX)

1CH

(Separator)

3BH

(STX)

Max DATA37

Characters

(2Track data)

3FH

(ETX)

03H 0DH 0AH

(End)

START characters

(Max 10 byte)

Max DATA 76 characters

(1Track data)

END characters

(Max 10 byte)

0DH 0AH

START characters

(Max 10 byte)

Max DATA 37 characters

(2Track data)

END characters

(Max 10 byte)

0DH 0AH

02H 45H 31H 31H 1CH 1CH

Max DATA 37 characters

(2Track data)

1CH

Max DATA104

Characters

(3Track data)

03H 0DH 0AH

02H 45H 31H

31H 1CH

1CH

(Header)

3BH

(STX)

Max DATA37

characters

(2Track data)

3FH

(ETX)

1CH

(Separator)

3BH

(STX)

Max DATA104

Characters

(3Track data)

3FH

(ETX)

03H

0DH

0AH

(End)

- When set to Track 2 Read mode None sentinel character mode

Static sentinel character mode

Dynamic sentinel character mode

- When set to Track 3 Read mode None sentinel character mode

Static sentinel character mode

EM220II

Dynamic sentinel character mode

- When set to Track 1/2 Read mode None sentinel character mode

Static sentinel character mode

Dynamic sentinel character mode

- When set to Track 2/3 Read mode None sentinel character mode

Static sentinel character mode

Rev. 1.00

- 20 -

Mobile Printer Command Manual

START characters

(Max 10 byte)

Max DATA 37 characters

(2Track data)

END characters

(Max 10 byte)

0DH 0AH

START characters

(Max 10 byte)

Max DATA 104 characters

(3Track data)

END characters (Max

10 byte)

0DH 0AH

02H 46H 31H 31H 1CH 1CH

Max DATA76

characters

(1Track data)

1CH

Max

DATA37

Characters

(2Track

data)

1CH

Max

DATA104

Characters

(3Track data)

03H 0DH 0AH

02H 46H 31H

31H 1CH

1CH

(Header)

25H

(STX)

Max DATA76

characters

(1Track data)

3FH

(ETX)

1CH

(Separator)

3BH

(STX)

Max DATA37

Characters

(2Track data)

3FH

(ETX)

1CH

(Separator)

3BH

(STX)

Max

DATA104

Characters

(3Track data)

3FH

(ETX)

03H

0DH

0AH

(End)

START characters

(Max 10 byte)

Max DATA 76 characters

(1Track data)

END characters

(Max 10 byte)

0DH 0AH

START characters

(Max 10 byte)

Max DATA 37 characters

(2Track data)

END characters

(Max 10 byte)

0DH 0AH

START characters

(Max 10 byte)

Max DATA 104 characters

(3Track data)

END characters

(Max 10 byte)

0DH 0AH

Hexadecimal

Decimal

Amount of Data

Header

37H

55

1 byte

Flag

80H

128

1 byte

Data

41H ~ 48H

65 ~ 72

1 bytes

NUL

00H

0

1 byte

Hex.

Function

41

Track 1/2/3 read mode command (3 Track case)

42

Track 1 read mode AUTO trigger (3 Track case)

43

Track 2 read mode AUTO trigger (3 Track case)

44

Track 3 read mode AUTO trigger (3 Track case)

45

Track 1/2 read mode AUTO trigger (3 Track case)

46

Track 2/3 read mode AUTO trigger (3 Track case)

47

Track 1/2/3 read mode AUTO trigger (3 Track case)

48

MSR not used

Dynamic sentinel character mode

EM220II

- When set to Track 1/2/3 Read mode None sentinel character mode

Static sentinel character mode

Dynamic sentinel character mode

Transmits the setting value format

MSR Setting value

Rev. 1.00

EM220II

- 21 -

Mobile Printer Command Manual

ESC R

[Name] [Format]

[Range] [Default] [Description]

Select an international character set.

ASCII

ESC R n

Hex

1B

52 n

Decimal

27

82 n

0 ≤ n ≤ 13 n=0 ▪ Selects international character set in from the following table:

n

Character set

n

Character set

0

U.S.A

7

Spain I

1

France

9

Norway

2

Germany

10

Denmark II

3

U.K

11

Spain II

4

Denmark I

12

Latin America

5

Sweden

13

Korea

6

Italy

ESC S

[Name] [Format]

[Description]

Select standard mode.

ASCII

ESC S

Hex

1B

53

Decimal

27

83

▪ Switches from page mode to standard mode. ESC T

[Name] [Format]

[Range] [Default] [Description]

Select print direction in page mode.

ASCII

ESC T n

Hex

1B

54 n

Decimal

27

84 n

0 ≤ n ≤ 3, 48 ≤ n ≤ 51 n=o ▪ Selects the print direction and starting position in page mode.

n

Print Direction

Starting Position

0,48

Left right

Upper left

1,49

Bottom to top

Lower left

2,50

Right left

Lower right

3,51

Top bottom

Upper right

Rev. 1.00

EM220II

- 22 -

Mobile Printer Command Manual

ESC W

[Name] [Format]

[Range]

[Default]

[Description]

Set print area in page mode.

ASCII

ESC

W

xL

xH

yL

yH

dxL

dxH

dyL

dyH

Hex

1B

57

xL

xH

yL

yH

dxL

dxH

dyL

dyH

Decimal

27

87

xL

xH

yL

yH

dxL

dxH

dyL

dyH

0 ≤ (xL + xH x 256) ≤ 65535 (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 255) 0 ≤ (yL + yH x 256) ≤ 65535 (0 ≤ yL ≤ 255, 0 ≤ yH ≤ 255) 1 ≤ (dxL + dxH x 256) ≤ 65535 (0 ≤ dxL ≤ 255, 0 ≤ dxH ≤ 255) 1 ≤ (dyL + dyH x 256) ≤ 65535 (0 ≤ dyL ≤ 255, 0 ≤ dyH ≤ 255)

Horizontal logical origin and vertical logical origin = 0

xL=0, xH =0, yL=0, yH=0 dxL = 128, dxH = 1, dyL = 72, dyH = 3

▪ When paper width of 58mm is selected: (xL + xH x 256) = 0 (xL=0, xH=0) (dyL + dyH x 256) = 840 (dyL=72, dyH=3) ▪ Set the position and the size of the printing area.

- Horizontal starting position = [(xL + xH x 256) x (horizontal motion units)].

- Vertical starting position = [(yL + yH x 256) x (vertical motion units)].

- Horizontal printing area width = [(dxL + dxH x 256) x (horizontal motion units)].

- Vertical printing area width = [(dyL + dyH x 256) x (vertical motion units)]. ▪ The printer ignores any setting that exceeds the print area. ESC ＼

[Name] [Format]

[Range] [Description]

Set relative print position.

ASCII

ESC

＼

n

nH

Hex

1B

5C

nL

nH

Decimal

27

92

nL

nH

0 ≤ (nL + nH x 256) ≤ 65535 (0 ≤ nL 255, 0 ≤ nH ≤ 255) ▪ Set the print starting position based on the current position to [(nL + nH ×

256) × horizontal or vertical motion unit]

- When (nL + nH × 256 is a positive number, the print starting position is

specified to the right based on the current position.

- When (nL + nH × 256) is a negative number, the print starting position

is specified to the left based on the current position.

▪ The printer ignores any setting that exceeds the print area.

Rev. 1.00

EM220II

- 23 -

Mobile Printer Command Manual

ESC a

[Name] [Format]

[Range] [Default] [Description]

Select justification.

ASCI

ESC a n

Hex

1B

61 n

Decimal

27

97 n

0 ≤ n ≤2, 48 ≤ n ≤50 n=0 ▪ In standard mode, aligns all the data in one line to the position specified

by n as follows:

n

Justification

0, 48

Left justification

1, 49

Centering

2, 50

Right justification

ESC d

[Name] [Format]

[Range] [Description]

Print and feed n lines.

ASCII

ESC d n

Hex

1B

64 n

Decimal

27

10 n

0 ≤ n ≤ 255 ▪ Prints the data in the print buffer and feeds n lines.

ESC t

[Name] [Format]

[Range] [Default]

Select character code table.

ASCII

ESC t n

Hex

1B

74 n

Decimal

27

116 n

0 ≤ n ≤ 5, 16 ≤ n ≤ 19, 21 ≤ n ≤ 31, 33 ≤ n ≤ 41, n=255 For model not supporting Thai character: n=0

For model supporting Thai character support : n = 20

Rev. 1.00

- 24 -

Mobile Printer Command Manual

[Description]

▪ This command specifies code page according to the value of n as follows:

n

Code page

0

Page 0 37 (USA, Standard Europe)

1

Page 1 Katakana

2

Page 2 850 (Multilingual)

3

Page 3 860 (Portuguese)

4

Page 4 863 (Canaian-French)

5

Page 5 865 (Nordic)

16

Page 16 1252 (Latin I)

17

Page 17 866 (Cyrillic #2)

18

Page 18 852 (Latin 2)

19

Page 19 858 (Euro)

21

Page 21 862 (Hebrew DOS code)

22

Page 22 864 (Arabic)

23

Page 23 Thai42

24

Page 24 1253 (Greek)

25

Page 25 1254 (Turkish)

26

Page 26 1257 (Baltic)

27

Page 27 Farsi

28

Page 28 1251 (Cyrillic)

29

Page 29 737 (Greek)

30

Page 30 775 (Baltic)

31

Page 31 Thai14

33

Page 33 1255 (Hebrew New code)

34

Page 34 Thai 11

35

Page 35 Thai 18

36

Page 36 855 (Cyrillic)

37

Page 37 857 (Turkish)

38

Page 38 928 (Greek)

39

Page 39 Thai 16

40

Page 40 1256 (Arabic)

41

Page 41 1258 (Vietnam)

42

Page 42 KHMER(Cambodia)

47

Page 47 1250 (Czech)

255

User Code Page (Space)

EM220II

Rev. 1.00

EM220II

- 25 -

Mobile Printer Command Manual

ESC {

[Name] [Format]

[Range] [Default] [Description]

Turns upside-down printing mode on/off.

ASCII

ESC { n

Hex

1B

7B n

Decimal

27

123 n

0 ≤ n ≤ 255 n=0 ▪ Turns upside-down printing mode on or off.

- When the LSB of n is 0, upside-down printing mode is turned off.

- When the LSB of n is 1, upside-down printing mode is turned on. ▪ The upside-down print mode has no effect in page mode. If this command

is processed in page mode, upside-down printing mode is enabled when the printer returns to standard mode.

▪ When upside-down print mode is turned on, the printer prints 180°

rotated characters from right to left.

FS &

[Name] [Format]

[Description]

Select Kanji character mode

ASCII

FS &

Hex

1C

26

Decimal

28

38

▪ This command sets Kanji character mode. FS .

[Name] [Format]

[Description]

Cancel Kanji character mode

ASCII

FS .

Hex

1C

2E

Decima

28

46

▪ This command cancels Kanji character mode.

Rev. 1.00

- 26 -

Mobile Printer Command Manual

GS !

[Name] [Format]

[Range]

[Default] [Description]

Select character size.

ASCII

GS ! n

Hex

1D

21 n

Decimal

29

33 n

0 ≤ n ≤ 255 (where 1 ≤ Enlargement in vertical direction ≤ 8, 1 ≤ Enlargement in horizontal direction ≤ 8)

n=0 ▪ Selects character size (enlargement in vertical and horizontal directions).

Bit

Function

Setting

0

Specifies the number of times enlarged in the vertical direction

Refer to Table 2 [Enlarged in vertical dirction]

1

2 3 4

Specifies the number of times enlarged in the horizontal direction

Refer to Table 1 [Enlarged in horizontal direction]

5

6

7

- Table 1 [Enlarged in horizontal direction]

Hex

Decimal

Enlargement

00

0

1 time (standard)

10

16

2 times

20

32

3 times

30

48

4 times

40

64

5 times

50

80

6 times

60

96

7 times

70

112

8 times

- Table 2 [Enlarged in vertical direction]

Hex

Decimal

Enlargement

00

0

1 time (standard)

01

1

2 times

02

2

3 times

03

3

4 times

04

4

5 times

05

5

6 times

06

6

7 times

07

7

8 times

EM220II

Rev. 1.00

- 27 -

Mobile Printer Command Manual

GS $

[Name] [Format]

[Range] [Description]

Set absolute vertical print position in page mode.

ASCII

GS $ nL

nH

Hex

1D

24

nL

nH

Decimal

29

36

nL

nH

0 ≤ (nL + nH x 256) ≤ 65535 (0 ≤ nL ≤ 255, 0 ≤ nH ≤ 255) ▪ Sets the absolute vertical print starting position to [(nL + nH × 256) ×

(vertical or horizontal motion units)].

GS ( A

[Name] [Format]

[Range]

[Description]

[Notes]

Execute test print.

ASCII

GS ( A

pL

pH n m

He

1D

28

41

pL

pH n m

Decimal

29

40

65

pL

pH n m

(pL + pH x 256) = 2 (pL=2, pH=0)

0 ≤ n ≤ 2, 48 ≤ n ≤ 50 1 ≤ m ≤ 3, 49 ≤ m ≤ 51

▪ Executes a test print with a specified test pattern on a specified paper

type (roll paper).

- n specifies the paper type as listed below to be tested:

m

Paper type

0, 48 1, 49 2, 50

Paper roll

- m specifies a test pattern as listed below:

m

Test pattern

1, 49

Hexadecimal dump

2, 50

Self Test Printing

3, 51

Self Test rolling pattern

▪ If this command is processed while a macro is being defined, the printer

cancels macro definition and starts processing this command. At that time, the macro becomes undefined.

▪ After processing this command, the printer performs a software reset.

EM220II

Rev. 1.00

EM220II

- 28 -

Mobile Printer Command Manual

GS ( F

[Name] [Description]

[Notes]

Set black mark control functions. ▪ This command performs various functions to control the black mark(BM)

paper as follows:

m

Format

Function

2

GS ( F pL pH m a

nL nH

Sets the paper feed amount to adjust the

paper cutting position after sensing BM.

112

GS ( F pL pH m aL

aH bL bH

Specifies the black mark paper format.

▪ This command is effective only when the BM(black mark) sensor is

enabled.

▪ This command is stored in the receive buffer and processed in FIFO so

that the delay in execution of this command might be occurred.

<Function 2> GS ( F pL pH m a nL nH (m=2)

[Format]

[Range]

[Default] [Description]

[Notes]

ASCII

GS ( F

pL

pH m a

nL

nH

Hex

1D

28

46

04

00

02 a nL

nH

Decimal

29

40

70 4 0 0 a

nL

nH

(pL + pH × 256) = 4 (pL = 4, pH = 0) m = 2 a = 0, 48

0 ≤ (nL + nH × 256) ≤ 65535 (0 ≤ nL ≤ 255, 0 ≤ nH ≤ 255) nL=0, nH=0 ▪ This command sets the value for the adjustment of paper cutting position

after sensing BM.

- pL, pH specifies (pL + pH × 256) as the number of bytes after pH (m, a,

nL, and nH)

- nL, nH specifies [(nL + nH × 256) × vertical motion units] as the

adjustment value.

▪ This command affects to the cutting operations as follows:

- Paper cut by GS V m n.

- Paper cut after paper feeding triggered by the paper FEED button.

- Paper cut after initializing the BM.(optional)

- Paper cut after paper feeding with the cover closed.(optional)

▪ This command is only effective for the forward paper feeding. ▪ The maximum adjustable length is 400 mm. If the adjustment value to be

specified exceeds the maximum value, the adjustment value is automatically set to the maximum value.

Rev. 1.00

EM220II

- 29 -

Mobile Printer Command Manual

<Function 112> GS ( F pL pH m aL aH bL bH (m=112)

[Format]

[Range]

[Default]

[Description]

[Notes]

ASCII

GS ( F

pL

pH m aL

aH

bL

bH

Hex

1D

28

46

05

00

70

aL

aH

bL

bH

Decimal

29

40

70 5 0

223

aL

aH

bL

bH

(pL + pH × 256) = 5 (pL = 5, pH = 0) m = 112

0 ≤ (aL + aH × 256) ≤ 65535 (0 ≤ aL ≤ 255, 0 ≤ aH ≤ 255) 0 ≤ (bL + bH × 256) ≤ 65535 (0 ≤ bL ≤ 255, 0 ≤ bH ≤ 255)

aL = 141, aH = 0 (BM height(top of a BM ~ bottom of BM): 20 mm) bL = 20, bH = 11 (BM interval(top of a BM ~ top of next BM): 400 mm)

▪ This command sets the black mark paper format.

- pL, pH specifies (pL + pH × 256) as the number of bytes after pH (m, aL, aH,bL, bH).

- aL, aH specifies [(aL + aH × 256) × vertical motion units] as the BM height.

- bL, bH specifies as [(bL + bH × 256) × vertical motion units] as the BM interval.

▪ The available BM height ranges from 4 to 20 mm. ▪ If the BM height specified is out of range, this command is ignored. ▪ The BM interval ranges from 40 to 400 mm. ▪ If the BM interval specified is out of range, this command is ignored.

Rev. 1.00

- 30 -

Mobile Printer Command Manual

GS ( k pL pH cn fn [parameter]

[Name] [Description]

Specify and print the symbol. ▪ Processes the data concerning two-dimensional code.

- Symbol type is specified by cn.

- Function is specified by fn.

cn

Type of Symbol

48

PDF417 (2-dimensional code)

49

QR CODE (2-dimensional code)

50

MAXI CODE(2-dimensional code)

51

DATAMATRIX(2-dimensional code)

cn

fn

Function

48

65

Function 065

PDF417 : Specify the number of columns

66

Function 066

PDF417 : Specify the number of rows

67

Function 067

PDF417 : Specify the width of module

68

Function 068

PDF417 : Specify the module height

69

Function 069

PDF417 : Specify the error correction level

70

Function 070

PDF417 : Specify the option

80

Function 080

PDF417 : Store the received data in the symbol

save area

81

Function 081

PDF417 : Print the symbol data in the symbol

save area

82

Function 082

PDF417 : Send the size information of the

symbol data in the symbol save area

49

65

Function 165

QR CODE: module selection

67

Function 167

QR CODE: module size selection

69

Function 169

QR CODE: error level setting

80

Function 180

QR CODE: saving of symbol data in storage

area

81

Function 181

QR CODE: printing of symbol data saved in

storage area

82

Function 182

QR CODE: transmission of size information of

symbol data saved in storage area

50

65

Function 265

MAXI CODE: mode selection

80

Function 280

MAXI CODE: saving of symbol data in storage

area

81

Function 281

MAXI CODE: printing of symbol data saved in

storage area

51

67

Function 367

DATAMATRIX: module size selection

80

Function 380

DATAMATRIX: saving of symbol data in

storage area

81

Function 381

DATAMATRIX: printing of symbol data saved in

storage area

EM220II

Rev. 1.00

- 31 -

Mobile Printer Command Manual

[Notes]

For PDF417 symbol data (when cn=48) ▪ The symbol data specified by Function 080 d1...dk is stored in the printer

and is printed by the specification of Function 081. The symbol data in the save area is reserved until the following processing is performed:

- Function 080 is executed

- ESC @ is executed

- The printer is reset or the power is turned off ▪ When processing Function 081 or 082, the setting values of Functions

065 to 070 are used. If the printable area is not large enough, the symbol may not be printed.

▪ Executing Function 081 after executing Function 080 repeatedly prints the

same symbol data.

▪ By using Functions 065 to 070 combined with Function 081, the same

symbol data d1...dk is printed differently.

▪ By using Function 082, the symbol size printed by Function 081 is available.

QRCODE Symbol Data (cn = 49) ▪ Symbol data is saved according to <Function 180> and printed according

to <Function 181>. The symbol data in the storage area is saved until the following actions:

- Execution of Function 180

- Execution of ESC @

- Turn off printer power ▪ When either Function 181 or Function 182 is executed, the setting values

of Functions 165~169 are used. If the printable area is insufficient in size, the symbol data is not printed.

▪ According to the settings of <Function 165> to <Function 169>, <Function

181> has and prints the same data d1….dk.

▪ <Function 182> uses the size printed by <Function 181>.

Rev. 1.00

EM220II

- 32 -

Mobile Printer Command Manual

MAXI CODE Symbol Data (cn = 50) ▪ Symbol data is saved according to <Function 280> and printed according

to <Function 281>. The symbol data in the storage area is saved until the following actions:

- Execution of Function 280

- Execution of ESC @

- Turn off printer power ▪ When either <Function 281> or <Function 282> is executed, the setting

value of <Function 265> is used.

DATAMATRIX Symbol Data (cn=51) ▪ Symbol data is saved according to <Function 380> and printed according

to <Function 381>. The symbol data in the storage area is saved until the following actions:

- Execution of Function 380

- Execution of ESC @

- Turn off printer power ▪ When <Function 381> is executed, the setting value of <Function 367> is

used.

Rev. 1.00

EM220II

- 33 -

Mobile Printer Command Manual

<Function 065> GS ( k pL pH cn fn n (fn=65)

[Format]

[Range]

[Default] [Description]

[Notes]

ASCII

GS ( k

pL

pH

cn

fn

n

Hex

1D

28

6B

03

00

30

41

n

Decimal

29

40

107 3 0

48

65

n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=48, fn=65 0 ≤ n ≤ 30

n=0 Specifies the number of columns of the data area of PDF417.

- n=0 specifies auto processing

- When n is not 0, specifies the number of columns of the data area as

n code word.

▪ Settings of this function affect the processing of Functions 081 and 082. ▪ When auto processing (n=0) is specified, the maximum number of

columns in the data area is 30 columns.

▪ The following data is not included in the number of columns :

- Start pattern and stop pattern

- Indicator code word of left and right ▪ When auto processing (n=0) is specified, the number of columns is

calculated by the printing area when processing Functions 081, 082, module width (Function 067), and option setting (Function 070).

▪ This function is effective until ESC @ is executed, the printer is reset, or

the power is turned off.

<Function 066> GS ( k pL pH cn fn n (fn=66)

[Format]

[Range]

[Default] [Description]

[Notes]

ASCII

GS ( k

pL

pH

cn

fn

n

Hex

1D

28

6B

03

00

30

42

n

Decimal

29

40

107 3 0

48

66

n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=48, fn=66 n=0, 3 ≤ n ≤ 90

n=0 Specifies the number of rows of data area of PDF417.

- n=0 specifies auto processing

- When n is not 0, specifies the number of rows of the symbol as n rows.

▪ Settings of this function effect the processing of Functions 081 and 082. ▪

When auto processing (n=0) is specified, the maximum number of rows is 90.

▪ When auto processing (n=0) is specified, the number of rows is calculated

by the printing area when processing Functions 081, 082, module height

(Function 068). ▪ This function is effective until ESC @ is executed, the printer is reset, or the power is turned off.

Rev. 1.00

EM220II

- 34 -

Mobile Printer Command Manual

<Function 067> GS ( k pL pH cn fn n (fn=67)

[Format]

[Range]

[Default] [Description] [Notes]

ASCII

GS ( k

pL

pH

cn

fn

n

Hex

1D

28

6B

03

00

30

43

n

Decimal

29

40

107 3 0

48

67

n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=48 fn=67 2 ≤ n ≤ 3

n=3 Specifies the width of a module of PDF417 symbol.

▪ Settings of this function affect the processing of Functions 081 and 082. ▪ The setting unit differs, depending on the printer models. ▪ This function is effective until ESC @ is executed, the printer is reset, or

the power is turned off.

<Function 068> GS ( k pL pH cn fn n (fn=68)

[Format]

[Range]

[Default] [Description]

[Notes]

ASCII

GS ( k

pL

pH

cn

fn

n

Hex

1D

28

6B

03

00

30

44

n

Decimal

29

40

107 3 0

48

68

n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=48 fn=68 2 ≤ n ≤ 4

n=3 Specifies the module height of PDF417 symbol.

- Specify the height to [a module width x n].

▪ Settings of this function affect the processing of Functions 081 and 082. ▪ This function is effective until ESC @ is executed, the printer is reset, or

the power is turned off.

Rev. 1.00

EM220II

- 35 -

Mobile Printer Command Manual

<Function 069> GS ( k pL pH cn fn m n (fn=69)

[Format]

[Range]

[Default] [Description]

[Notes]

ASCII

GS ( k

pL

pH

cn

fn m n

Hex

1D

28

6B

04

00

30

45 m n

Decimal

29

40

107 4 0

48

69 m n

(pL + pH x 256) = 4 (pL=4, pH=0) cn=48 fn=69 m=48 48 ≤ n ≤ 8 [m=48] n=1 Specifies the error correction level of PDF417.

m

Function

48

The error correction level is specified by “level”

▪ Settings of this function affect the processing of Functions 081 and 082. ▪ Error correction level is specified by “level”. ▪ Error correction level specified by “level” (m=48) is as follows:

The number of the error correction code word is fixed regardless of the

number of code words in the data area.

m

Function

Number of error correction code word

48

Error correction level 0

2

49

Error correction level 1

4

50

Error correction level 2

8

51

Error correction level 3

16

52

Error correction level 4

32

53

Error correction level 5

64

54

Error correction level 6

128

55

Error correction level 7

256

56

Error correction level 8

512

<Function 070> GS ( k pL pH cn fn m (fn=70)

[Format]

[Range]

[Default] [Description]

[Notes]

ASCII

GS ( k

pL

pH

cn

fn

m

Hex

1D

28

6B

03

00

30

46

m

Decimal

29

40

107 3 0

48

70

m

(pL + pH x 256) = 3 (pL=3, pH=0) cn=48 fn=70 m=0,1 m=0 Set or cancels the option of PDF417.

m

Function

0

Cancels the processing of simplified PDF417 symbol.

1

Sets the processing of simplified PDF417 symbol.

- m=0 cancels the processing of simplified PDF417 symbol.

- m=1 sets the processing of simplified PDF417 symbol.

▪ Settings of this function affect the processing of Functions 081 and 082. ▪ When simplified PDF417 symbol is canceled, standard PDF417 symbol is

automatically selected. ▪ This function is effective until ESC @ is executed, the printer is reset, or

the power is turned off.

Rev. 1.00

EM220II

- 36 -

Mobile Printer Command Manual

<Function 080> GS ( k pL pH cn fn m d1...dk (fn=80)

[Format]

[Range]

[Description] [Notes]

ASCII

GS ( k

pL

pH

cn

fn m d1...dk

Hex

1D

28

6B

pL

pH

30

50

30

d1...dk

Decimal

29

40

107

pL

pH

48

80

48

d1...dk

4 ≤ (pL + pH x 256) ≤ 65535 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 255) cn=48 fn=80 m=48 0 ≤ d ≤ 255 k = (pL + pH x 256) - 3 Stores the PDF417 symbol data (d1...dk) in the symbol save area. ▪ Data stored in the symbol save area by this function are processed by

Function 081 and 082. The data in the symbol save area are reserved

after processing Function 081 or 082.

▪ k bytes of d1...dk are processed as symbol data. ▪ Specify only the data code word of the symbol with this function. Do not

include the following data in the data d1..dk as this information is

automatically added by the printer:

- Start pattern and stop pattern.

- Indicator code word of left and right.

- The descriptor of symbol length. (the first code word in the data area)

- The error correction code word calculated by modulus 929. ▪ This function is effective until the following processing is performed:

- Function 080 or 180 is executed.

- ESC @ is executed.

- The printer is reset or the power is turned off.

<Function 081> GS ( k pL pH cn fn m (fn=81)

[Format]

[Range]

[Description] [Notes]

ASCII

GS ( k

pL

pH

cn

fn

m

Hex

1D

28

6B

03

00

30

51

m

Decimal

29

40

107 3 0

48

81

m

(pL + pH x 256) = 3 (pL=3, pH=0) cn=48 fn=81 m=48 Encodes and prints the PDF417 symbol data in the symbol save area.

▪ In standard mode, use this function when printer is “at the beginning of a

line,” or “there is no data in the printer buffer.” ▪ A symbol with a size that exceeds the printing area can not be printed. ▪ If there is any error described below in the data of the symbol save area, it

cannot be printed.

- There is no data (Function 080 is not processed).

- If [(number of columns x number of rows) < number of code word] when

auto processing is specified for number of columns and number of rows.

- Number of code word exceeds 928 in the data area.

Rev. 1.00

EM220II

- 37 -

Mobile Printer Command Manual

▪ The following data is added automatically by the encode processing:

- Start pattern and stop pattern.

- Indicator code word of left and right.

- The descriptor of symbol length. (the first code word in the data area)

- The error correction code word calculated by modulus 929.

- Pad codeword. ▪ The data area includes the following code words:

- Data specified by Function 080.

- The descriptor of symbol length. (the first code word in the data area)

- The error correction code word calculated by modulus 929.

- Pad codeword. ▪ When auto processing (Function 065) is specified, the number of

columns is calculated by the current printing area, module width (Function

067), option setting (Function 070), and the code word in the data area.

The maximum number of columns is 30. ▪ When auto processing (Function 066) is specified in page mode, the

number of rows is calculated by the current printing area, module height

(Function 068), and the code word in the data area. The maximum number

of rows is 90.

▪ Printing of symbol is not affected by print mode (emphasized, double-

strike, underline, white/black reverse printing, or 90˚ clockwise-rotated),

except for character size and upside-down printing mode. ▪ In standard mode, this command executes paper feeding for the amount

needed for printing the symbol, regardless of the paper feed amount set by

the paper feed setting command. The printing position returns to the left

side of the printable area after printing the symbol, and printer is in the

status “beginning of the line,” or “ there is no data in the print buffer.” ▪ In page mode, the printer stores the symbol data in the print buffer without

executing actual printing. The printer moves printing position to the next

dot of the last data of the symbol. ▪ The quiet zone is not included in the printing data. Be sure to include the

quiet zone when using this function.

Rev. 1.00

- 38 -

Mobile Printer Command Manual

<Function 082> GS ( k pL pH cn fn m (fn=82)

[Format]

[Range]

[Description]

[Notes]

ASCII

GS ( k

pL

pH

cn

fn

m

Hex

1D

28

6B

03

00

30

52

m

Decimal

29

40

107 3 0

48

82

m

(pL + pH x 256) = 3 (pL=3, pH=0) cn=48 fn=82 m=48

Encodes and sends size information of the PDF417 symbol data in the symbol save area.

▪ In standard mode, use this function when the printer is “at the beginning of

a line,” or “there is no data in the printer buffer.” ▪ The size information for each data is as follows:

Send data

Hex

Decimal

Data

Header

37H

55

1 byte

Flag

2FH

47

1 byte

Width

30H – 39H

48 – 57

1 – 5 byte

Separator

1FH

31

1 byte

Height

30H – 39H

48 – 57

1 – 5 byte

Separator

1FH

31

1 byte

Fixed value

31H

49

1 byte

Separator

1FH

31

1 byte

Other information

30H or 31H

48 or 49

1 byte

NUL

00H

0

1 byte

▪ Description of the width and height of the data sent:

- The height and width values of the symbol data are in dot units.

▪ Description of the other information data sent:

Hex

Decimal

Condition

30H

48

Printing is possible

31H

49

Printing is impossible

▪ This command does not print the PDF417 symbols. ▪ Users must consider the quiet zone for the PDF417 symbols (upward and

downward spaces and left and right spaces for the PDF417 symbols specified in the specifications for the PDF417 symbols.)

EM220II

Rev. 1.00

EM220II

- 39 -

Mobile Printer Command Manual

<Function 165> GS ( k pL pH cn fn n1 n2 (fn=65)

[Format]

[Range]

[Defaults]

[Description]

[Notes]

ASCII

GS ( k

pL

pH

cn

fn

n1

n2

Hex

1D

28

6B

04

00

31

41

n1 0 Decimal

29

40

107 3 0

49

65

n1

0

(pL + pH x 256) = 4 (pL=4, pH=0) cn=49 fn=65 n1 = 49 n2 =0

Sets the QR code model

n1

Function

49

Model 1

▪ The setting of this function impacts <Function 181> and <Function 182>. ▪ This function is effective until ESC @ is executed or the printer power is

turned off.

<Function 167> GS ( k pL pH cn n (fn=67)

[Format]

[Range]

[Default] [Description]

ASCII

GS ( k

pL

pH

cn

fn

n

Hex

1D

28

6B

03

00

31

43

n

Decimal

29

40

107 3 0

49

67

n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=49 fn=67 0<n<9

n=3 Sets the size of the QR code module

▪ It impacts the execution of <Function 181> and <Function 182>. ▪ This function is effective until ESC @ is executed or the printer power is

turned off. ▪ n becomes the value for the module width and height. (The QR CODE module is square-shaped.)

Rev. 1.00

EM220II

- 40 -

Mobile Printer Command Manual

<Function 169> GS ( k pL pH cn n (fn=69)

[Format]

[Range]

[Default] [Description]

ASCII

GS ( k

pL

pH

cn

fn

n

Hex

1D

28

6B

03

00

31

45

n

Decimal

29

40

107 3 0

49

69

n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=49 fn=69 48≤n≤51

n=48 Sets the error correction level of the QR code

n

Function

Recovery Amount (%)

48

Error Correction Level L

7

49

Error Correction Level M

15

50

Error Correction Level Q

25

51

Error Correction Level H

30

▪ The setting of this function impacts the execution of <Function 181> and

<Function 182>.

▪ This function is effective until ESC @ is executed or the printer power is

turned off.

▪ For correction with regard to the continuous error correction of the QR

code, the Reed-Solomon correction method is used.

Rev. 1.00

EM220II

- 41 -

Mobile Printer Command Manual

<Function 180> GS ( k pL pH cn fn m d1...dk (fn=80)

[Format]

[Range]

[Description] [Notes]

ASCII

GS ( k

pL

pH

cn

fn m d1...dk

Hex

1D

28

6B

pL

pH

31

50

30

d1...dk

Decimal

29

40

107

pL

pH

49

80

48

d1...dk

4 ≤ (pL + pH x 256) ≤7092 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 27) cn=49 fn=80 m=48 0 ≤ d ≤ 255 k = (pL + pH x 256) - 3 Saves symbol data of the QR CODE to the symbol storage area ▪ Execution of this command saves data to the data storage area and

executes Functions 181 and 182. Following execution of Functions 181

and 182, the data remains saved in the symbol storage area. ▪ k byte represents the symbol data of d1...dk.

Character Type

Usable Characters

Numeric Data

“0” ~ “9”

Alphanumeric Data

“0” ~ “9”, “A” ~ “Z”, SP, $, %, *, +, -, ., /, :

Kanji Data

Shift JIS value

8bit Byte Data

00H ~ FFH

▪ The setting impacts the function until the following actions are carried out:

- Execution of Function 180

- Execution of ESC @

- Turning off of printer power

Rev. 1.00

- 42 -

Mobile Printer Command Manual

<Function 181> GS ( k pL pH cn fn m (fn=81)

[Format]

[Range]

[Description] [Notes]

ASCII

GS ( k

pL

pH

cn

fn

m

Hex

1D

28

6B

03

00

31

51

m

Decimal

29

40

107 3 0

49

81

m

(pL + pH x 256) = 3 (pL=3, pH=0) cn=49 fn=81 m=48

Encodes and prints QR CODE symbol data saved in the storage area ▪ This function is used in regular mode when the printer is at the first line or

no data is present in the printer buffer.

▪ If the size of any one symbol is larger than the print area, printing cannot

be done:

▪ If any of the following errors is present in the symbol storage area, printing

cannot be done.

- There is no data. (Function 180 cannot be executed)

- If [(number of columns x number of rows) < number of code words], the

numbers of columns and rows are automatically processed.

- The four types of data compression mode are as follows: *Numeric Data Code *Alphanumeric Data mode *Kanji Data mode

*8 bit Data mode Note: According to the symbol data in the data storage area, automatic

conversion to optimal compression is done.

▪ The following data is automatically added during encoding:

- Position sensor pattern

- Segregator for the position sensor pattern

- Timing pattern

- Format information

- Version information

- Error correction code text

- Pad code text

- Indicator for counting bits of bytes

- Mode indicator

- Concluder

- Queue pattern (when model 2 is selected)

- Expansion pattern (when model 1 is selected) ▪ During symbol printing, the printer mode has no effect (bold, underline, reverse direction, contrast). ▪ In regular mode, this command supplies enough paper required for

symbol printing. If the paper supply is not sufficient, the paper supply command is executed. When printing, the printing position is to the left of the print area. After symbol printing, the printer returns to the start position of the line, and the buffer is emptied.

Rev. 1.00

EM220II

- 43 -

Mobile Printer Command Manual

<Function 182> GS ( k pL pH cn fn m (fn=82)

[Format]

[Range]

[Description]

ASCII

GS ( k

pL

pH

cn

fn

m

Hex

1D

28

6B

03

00

31

52

m

Decimal

29

40

107 3 0

49

82

m

(pL + pH x 256) = 3 (pL=3, pH=0) cn=49 fn=82 m=48

▪ Transmits size information of the QR CODE symbols encoded via

Function 180 to the host

▪ In regular mode, this function is executed when the printer is on standby

or the buffer is empty.

▪ The information size of each data item is as follows:

Transmission Data

Hex

Decimal

Data

Header

37H

55

1 byte

Flag

36H

54

1 byte

Width

30H – 39H

48 – 57

1 – 5 byte

Separator

1FH

31

1 byte

Height

30H – 39H

48 – 57

1 – 5 byte

Separator

1FH

31

1 byte

Fixed Value

31H

49

1 byte

Separator

1FH

31

1 byte

Other Information

30H or 31H

48 or 49

1 byte

NUL

00H

0

1 byte

▪ Description of Width & Height Transmission Data

- Height and width are dot unit values for symbol data.

▪ Description of Other Information

Hex

Decimal

Condition

30H

48

Can be printed

31H

49

Cannot be printed

▪ The user quiet zone is not included in size information.

Rev. 1.00

EM220II

- 44 -

Mobile Printer Command Manual

<Function 265> GS ( k pL pH cn fn n1 n2 (fn=65)

[Format]

[Range]

[Default] [Description]

[Notes]

ASCII

GS ( k

pL

pH

cn

fn

n

Hex

1D

28

6B

03

00

32

41

n

Decimal

29

40

107 3 0

50

65

n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=50 fn=65 50 ≤ n ≤ 52

n = 50 Maxi Code Mode Settings

n

Function

50

Mode 2 Setting

51

Mode 3 Setting

52

Mode 4 Setting

▪ The setting of this function impacts <Function 281> and <Function 282>. ▪ This function is effective until ESC @ is executed or the printer power is

turned off.

<Function 280> GS ( k pL pH cn fn m d1...dk (fn=80)

[Format]

[Range]

[Description] [Notes]

ASCII

GS ( k

pL

pH

cn

fn m d1...dk

Hex

1D

28

6B

pL

pH

32

50

30

d1...dk

Decimal

29

40

107

pL

pH

50

80

48

d1...dk

4 ≤ (pL + pH x 256) ≤ 141 (4 ≤ pL ≤141, 0 ≤ pH ≤0) cn=50 fn=80 m=48 0 ≤ d ≤ 255 k = (pL + pH x 256) – 3

Saves MAXI CODE symbol data in the symbol storage area ▪ Execution of this command saves data to the data storage area and

executes Functions 281 and 282. Following execution of Functions 281

and 282, the data remains saved in the symbol storage area.

▪ k byte represents the symbol data of d1...dk. ▪ The setting impacts the function until the following actions are carried out:

- Execution of Function 280

- Execution of ESC @

- Turning off of printer power

Rev. 1.00

- 45 -

Mobile Printer Command Manual

<Function 281> GS ( k pL pH cn fn m (fn=81)

[Format]

[Range]

[Description] [Notes]

ASCII

GS ( k

pL

pH

cn

fn

m

Hex

1D

28

6B

03

00

32

51

m

Decimal

29

40

107 3 0

50

81

m

(pL + pH x 256) = 3 (pL=3, pH=0) cn=50 fn=81 m=48

Encodes and prints MAXI CODE symbol data saved in the storage area ▪ This function is used in regular mode when the printer is at the first line or

no data is present in the printer buffer.

▪ If the size of any one symbol is larger than the print area, printing cannot

be done.

▪ If any of the following errors is present in the symbol storage area, printing

cannot be done.

- There is no data. (Function 280 cannot be executed)

- The number of numeric characters exceeds 138.

- The number of alphanumeric characters exceeds 93.

- When mode 2 is selected, the primary message does not include all of the following:

Primary Message

Data Number

Character

Postal Code

1~9

Numeric

ISO Country Code

1~3

Numeric

Service Type Code

1~3

Numeric

- When mode 3 is selected, the primary message does not include all of the following:

Primary Message

Data Number

Character

Postal Code

1~6

Setting Code A

ISO Country Code

1~3

Numeric

Service Type Code

1~3

Numeric

▪ Modes 2 and 3 are executed according to the following procedures: (RS, GS indicate the control code of MAXI CODE. y indicates the 2byte

numeric data.)

a) 9 byte data including ”[)>”,”RS”,”01”,”GS”,”yy” are regarded as the

Header.

- The next data item after the Header is the Primary Message.

- When printing, the Header is inserted at the beginning of the

Secondary Message.

b) When Header data is absent, the Primary Message is regarded as

the first data item.

EM220II

Rev. 1.00

EM220II

- 46 -

Mobile Printer Command Manual

c) In the Primary Message, GS is regarded as the separator that divides

the postal code, ISO country code, and service type code. The GS text is ignored.

d) All data of the Secondary Message is regarded as symbol data. ▪ Mode 4 does not distinguish between the Primary Message and the

Secondary Message.

▪ In the detection and correction of errors, MAXI CODE uses the Reed-

Solomon algorithm.

▪ The following data is automatically added during the encoding process:

- Position sensor pattern

- Position pattern

- Error correction code text

- Mode separator

- Pad code text

▪ During symbol printing, the printer mode has no effect (bold, underline, reverse direction, contrast).

▪ In regular mode, this command supplies enough paper required for

symbol printing. If the paper supply is not sufficient, the paper supply command is executed. When printing, the printing position is to the left of the print area. After symbol printing, the printer returns to the start position of the line, and the buffer is emptied.

<Function 367> GS ( k pL pH cn n (fn=67)

[Format]

[Range]

[Default] [Description]

ASCII

GS ( k

pL

pH

cn

fn

n

Hex

1D

28

6B

03

00

33

43

n

Decimal

29

40

107 3 0

51

67

n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=51 fn=67 2<=n<7

n=3 Sets the DATAMATRIX code size

▪ It impacts the execution of <Function 381>. ▪ This function is effective until ESC @ is executed or the printer power is

turned off.

▪ n becomes the value for the module width and height.

(The DATAMATRIX module is square-shaped.)

Rev. 1.00

EM220II

- 47 -

Mobile Printer Command Manual

<Function 380> GS ( k pL pH cn fn m d1...dk (fn=80)

[Format]

[Range]

[Description] [Notes]

ASCII

GS ( k

pL

pH

cn

fn m d1...dk

Hex

1D

28

6B

pL

pH

33

50

30

d1...dk

Decimal

29

40

107

pL

pH

51

80

48

d1...dk

0 ≤ (pL + pH x 256) ≤ 3116 (0≤ pL ≤255, 0 ≤ pH ≤13) cn=51 fn=80 m=48 0 ≤ d ≤ 255 k = (pL + pH x 256) – 3

Saves DATAMATRIX symbol data to the symbol storage area ▪ Execution of this command saves data to the data storage area and

executes Function 281. Following execution of Function 281, the data remains saved in the symbol storage area.

▪ k byte represents the symbol data of d1...dk. ▪ The setting impacts the function until the following actions are carried out:

- Execution of Function 380

- Execution of ESC @

- Turning off of printer power

Rev. 1.00

- 48 -

Mobile Printer Command Manual

<Function 381> GS ( k pL pH cn fn m (fn=81)

[Format]

[Range]

[Description]

[Notes]

ASCII

GS ( k

pL

pH

cn

fn

m

Hex

1D

28

6B

03

00

33

51

m

Decimal

29

40

107 3 0

51

81

m

(pL + pH x 256) = 3 (pL=3, pH=0) cn=51 fn=81 m=48

Encodes and prints DATAMATRIX symbol data saved in the storage area ▪ This function is used in regular mode when the printer is at the first line or

no data is present in the printer buffer.

▪ If the size of any one symbol is larger than the print area, printing cannot

be done.

▪ If any of the following errors is present in the symbol storage area, printing

cannot be done:

- There is no data. (Function 380 cannot be executed)

- The number of alphanumeric characters exceeds 2334.

- The number of 8bit byte characters exceeds 1558.

- The number of numeric characters exceeds 3116.

▪ DATAMATRIX uses ECC 200 symbols. ▪ In the detection and correction of errors, DATAMATRIX uses the Reed-

Solomon algorithm.

▪ The following data is automatically added during the encoding process:

- Position pattern

- Error correction code text

- Mode separator

- Pad code text

▪ During symbol printing, the printer mode has no effect (bold, underline, reverse direction, contrast).

▪ In regular mode, this command supplies enough paper required for

symbol printing. If the paper supply is not sufficient, the paper supply command is executed. When printing, the printing position is to the left of the print area. After symbol printing, the printer returns to the start position of the line, and the buffer is emptied.

Rev. 1.00

EM220II

- 49 -

Mobile Printer Command Manual

GS ( E

[Name] [Description]

[Notes]

Set NV user memory area ▪ This command stores the customized values to the NV user memory area

and uses them for the printer operation. The table below explains the functions available in this command. Executes commands related to the user setting mode by specifying the function code fn.

fn

Format

No.

Function

1

GS ( E pL pH fn d1 d2

1

Start the user setting mode

2

GS ( E pL pH fn d1 d2 d3

2

End the user setting mode (Performs a soft reset)

3

GS ( E pL pH fn [a1 b18...b11]... [ak bk8...bk1]

3

Set value(s) for the memory switch

4

GS ( E pL pH fn a

4

Transmit the settings of the memory switch to the host

5

GS ( E pL pH fn a

5

Specify the paper width

6

GS ( E pL pH fn a

6

Transmit the paper width

11

GS ( E pL pH fn a d1...dk

11

Set the communication conditions for the serial interface

12

GS ( E pL pH fn a

12

Transmit the communication conditions for the serial interface

▪ pL, pH is used to set the number of bytes following pH to (pL + pH x 256). ▪ The change in the items of the NV user memory is available only after

entering the user setting mode.

▪ After completing the user setting mode (Function 2), the printer performs

software reset to restore the initial settings in effect at power on. Receive and print buffers are cleared as well.

▪ Since frequent write operation by this command may deteriorate the

performance of the NV memory, it is recommended to write to NV memory when the significant change in the setting is required.

▪ While processing this command, the printer remains busy. Therefore the

data transmission by the host is not available. The real time commands and ASB operations are not processed.

<Function 1> GS ( E pL pH fn d1 d2 (fn=1)

[Format]

[Range]

ASCII

GS ( E

pL

pH

fn

d1

d2

Hex

1D

28

45

pL

pH

fn

d1

d2

Decimal

29

40

69

pL

pH

fn

d1

d2

(pL + pH x 256) = 3 (pL=3, pH=0) fn=1 d1=73, d2=78

EM220II

Rev. 1.00

EM220II

- 50 -

Mobile Printer Command Manual

[Description]

[Notes]

▪ This command starts the user setting mode, enabling the printer to notify

that the mode has changed as follows:

[Mode change feedback]

Hexadecimal

Decimal

Number of Data

Header

37H

55

1 byte

Flag

20H

32

1 byte

NUL

00H

0

1 byte

▪ This command is effective only in standard mode, not in page mode. ▪ Upon entering the user mode setting mode by this command, the printer

transmits “mode change feedback” to the host.

▪ The user setting mode should be enabled prior to processing <Function

2> through 12. Otherwise, those functions are ignored.

▪ After confirming “mode change feedback”, it is recommended to send the

command to reconfigure the NV user memory.

<Function 2> GS ( E pL pH fn d1 d2 d3 (fn=2)

[Format]

[Range]

[Description]

[Notes]

ASCII

GS ( E

pL

pH

fn

d1

d2

d3

Hex

1D

28

45

pL

pH

fn

d1

d2

d3

Decimal

29

40

69

pL

pH

fn

d1

d2

d3

(pL + pH x 256) = 4 (pL=4, pH=0) fn=2 d1=79, d2=85, d3=84

▪ This command terminates the user setting mode and performs a software

reset.

▪ This command activates setting items set in the user setting mode. ▪ All the setting items will be effective only after performing this command. ▪ After executing a software reset, the printer resumes the setting in effect

at power on.

<Function 3> GS ( E pL pH fn [a1 b18...b11]...[ak bk8...bk1] (fn=3)

[Format]

[Range]

[Default]

ASCII

GS ( E

pL

pH

fn

[b18...b11]... [bk8...bk1]

Hex

1D

28

45

pL

pH

fn

[b18...b11]... [bk8...bk1]

Decimal

29

40

69

pL

pH

fn

[b18...b11]... [bk8...bk1]

10 ≤ (pL + pH x 256) ≤ 65535 fn=3 a= 1, 2, 5, 6, 7, 8 b=48, 49, 50 1 ≤ k ≤ 10

It varies depending on the printer model ▪ This command terminates the user setting mode and performs a software

reset.

Rev. 1.00

- 51 -

Mobile Printer Command Manual

[Description]

▪ This command changes all the Memory Switch(Msw) 1 through 8 to the

value specified by b simultaneously as follows:

- When b=48, 49, the corresponding bit is set to Off and On respectively.

- When b=50, there is no change in the memory switch.

▪ The setting items of the memory switch 1 are as follows:

Msw

Value

Function

3 2 1

1-1~3

48

Print density 130%

48

49

Print density 120%

48

49

48

Print density 110%

48

49

Print density 150%

49

48

Print density 100%

49

48

49

Print density 140%

49

48

Print density 90%

49

Print density 80%

Msw

Value

Function

1-4

48

2 byte character mode not selected

49

2 byte character mode selected

1-5

48

Print speed 90mm/s

49

Print speed 50mm/s

1-6

48

Reserved

- The print density adjusts the darkness of characters to be printed.

- 2-byte character mode is selected to support for Chinese, Japanese, and Korean model.

- The printer supports 2 different printing speeds, 80 and 50mm/sec. Please be sure that the printing quality at higher speed may be worse than at the lower.

▪ The setting items of the memory switch 2 are as follows:

Msw

Value

Function

2-1

48

Reserved

2-2

48

Reserved

EM220II

Rev. 1.00

- 52 -

Mobile Printer Command Manual

▪ Code page selection using the memory switch 2-3 through 2-8.

Msw2-8

Msw2-7

Msw2-6

Msw2-5

Msw2-4

Msw2-3

Character

Table

48

PC437

48

49

48

Katakana

48

49

48

PC850

48

49

48

PC860

48

49

48

PC863

48

49

48

49

48

PC865

48

49

48

WPC1252

48

PC437

48

49

48

PC866

48

49

48

PC852

48

49

48

49

48

PC858

48

49

48

49

48

PC862

48

49

48

49

48

PC864

48

49

48

Thai42

48

49

48

49

48

WPC1253

48

49

48

WPC1254

48

49

48

WPC1257

49

48

Farsi

49

48

49

48

WPC1251

49

48

49

48

PC737

49

48

49

48

PC775

49

48

49

48

Thai 14

49

48

49

48

49

48

Hebrew old code

49

48

49

48

WPC1255

49

48

49

48

Thai 11

49

48

Thai 18

49

48

49

48

PC855

49

48

49

48

PC857

49

48

49

48

PC928

49

48

Thai 16

49

48

49

48

WPC1256

49

48

WPC1258

49

48

KHMER

48

49

48

49

WPC1250

EM220II

Rev. 1.00

- 53 -

Mobile Printer Command Manual

▪ The setting items of the memory switch 5 are as follows:

Specify the length of idle time before the printer enters the power-down mode.

- Range of idle time: 0 min ≤ idle time ≤ 90 min

When memory switch value is 0, the power-down mode is not active

MSW5-

8

MSW5-

7

MSW5-

6

MSW5-

5

MSW5-

4

MSW5-

3

MSW5-

2

MSW5-

1

Value

(Min)

48

48 0 48

48

49 1 48

48

49

48 2 48

48

49

49 3 48

48

49

48

48 4 . . . . . . . . . . . . . . . . . . . . . . . .

48

49

48

49

48

49

48

90

▪ The setting items of the memory switch 6 are as follows:

Set the standby time before the printer enters the power saving mode.

- Range of standby time: 10 sec ≤ standby time ≤ 255 sec

When memory switch value is 0, the power saving mode does not work.

MSW6-

8

MSW6-

7

MSW6-

6

MSW6-

5

MSW6-

4

MSW6-

3

MSW6-

2

MSW6-

1

Value

48

49

48

49

48

10

48

49

48

49

11

48

49

48

12

48

49

48

49

13

48

49

48

14 . . . . . . . . . . . . . . . . . . . . . . . . 49

49

255

▪ The setting items of the memory switch 7 are as follows:

Specify the magnetic card read mode using the memory switch 7-5 through 7-8.

MSW

8 7 6

5

Function

7-5~8

48

49

Track 1/2/3 read mode command

48

49

48

Track 1 read mode AUTO trigger

48

49

Track 2 read mode AUTO trigger

48

49

48

Track 3 read mode AUTO trigger

48

49

48

49

Track 1/2 read mode AUTO trigger

48

49

48

Track 2/3 read mode AUTO trigger

48

49

Track 1/2/3 read mode AUTO trigger

49

48

MSR not used

EM220II

Rev. 1.00

- 54 -

Mobile Printer Command Manual

▪ The setting items of the memory switch 8 are as follows:

- Either the character font A or B or C is selected.

- The beep is activated for the audible paper empty warning signal.

- The beep is activated for the audible low battery warning signal.

- The label printing is available by the setting.

Msw

Setting Value

Function

8-1

Refer to the following Table 1

8-2

8-3

48

No beeps for roll paper end

49

Beeps for roll paper end

8-4

48

Beeps for low battery status

49

No beeps low battery status

8-5

49

Reserved

8-6

Refer to the following Table2

8-7

8-8

48

Reserved

Table 1

Function

MSW 8-2

MSW 8-1

Select font 12x24

48

Select font 9x17

48

49

Select font 9x24

49

48

Table 2

Function

MSW 8-7

MSW 8-6

Select Normal MSR data mode

48

Select 1byte sentinel character mode

48

49

Select Multi byte sentinel characters mode

49

48

- When set to 1-byte sentinel character mode, 1-byte sentinel characters are added to the beginning parts and the end parts of each track data.

- 1Track sentinel characters: STX (%), EXT (?)

- 2Track sentinel characters: STX (;), EXT (?)

- 3Track sentinel characters: STX (;), EXT (?)

- When set to Multi-byte sentinel characters mode, the header and the footer, which have been used in normal mode, are not used any more and the specified Start characters and End characters are added to the beginning parts and the end parts of each track data to be transmitted.

- When set to Multi-byte sentinel characters mode but Start characters and End characters are not set by fn2 and fn3 of BS M S command respectively, the default Start and End characters are applied to MSR data to be transmitted to host.

- When set to Multi-byte sentinel characters mode, <CR/LF> characters after End characters of each track data are automatically applied to the card data to be transmitted to host.

EM220II

Rev. 1.00

EM220II

- 55 -

Mobile Printer Command Manual

<Function 4> GS ( E pL pH fn a (fn=4)

[Format]

[Range]

[Description]

ASCII

GS ( E

pL

pH

fn

a

Hex

1D

28

45

pL

pH

fn

a

Decimal

29

40

69

pL

pH

fn

a

(pL + pH x 256) = 2 (pL=2, pH=0) fn=4 a=1, 2, 5, 6, 7, 8

▪ This command transmits the setting value of the memory switch

corresponding to a.

Hexadecimal

Decimal

Amount of Data

Header

37H

55

1 byte

Identifier

21H

33

1 byte

Setting value

30H or 31H

48 or 49

8 bytes

NUL

00H

0

1 byte

▪ The setting value is sent from bit 8 to bit 1, consisting of 8 bytes in total.

- Off: Hexadecimal = 30H / Decimal = 48

- On: Hexadecimal = 31H / Decimal = 49

<Function 11> GS ( E pL pH fn a d1….dk (fn=11)

[Format]

[Range]

[Default]

[Description]

ASCII

GS ( E

pL

pH

fn a d1

Hex

1D

28

45

pL

pH

0B a d1

Decimal

29

40

69

pL

pH

11 a d1

3 ≤ (pL + pH x 256) ≤ 8 (3 ≤ pL ≤ 8,0 pH=0) fn=11, 1 ≤ a ≤ 4 48 ≤ d ≤ 57 [a=1] 48 ≤ d ≤ 50 [a=2]

d=48,49 [a=3] d=55,56 [a=4]

1 ≤ k ≤ 6 d1..dk=”115200” [a=1]

d=48[a=2] d=48[a=3] d=56[a=4]

▪ Sets the configuration item for the serial interface specified by a to the

values specified by d1..dk

a

Configuration item

1

Transmission speed

2

Parity

3

Flow control

4

Data length

▪ Transmission speed (a=1) is specified by number.

Example : When defining 19200 bps : 5bytes d1…dk “19200”(Hexadecimal

= 31H,39H,32H,30H,30H/Decimal= 49,57,50,48,48)

Rev. 1.00

EM220II

- 56 -

Mobile Printer Command Manual

[Notes]

▪ Baud rate is specified as follows: (1 ≤ k ≤ 6)

d11~dk1

Function

“115200”

Baud rate 115200

“57600”

Baud rate 57600

“38400”

Baud rate 38400

“19200”

Baud rate 19200

“9600”

Baud rate 9600

“4800”

Baud rate 4800

“2400”

Baud rate 2400

▪ Parity (a=2) is specified by d as follows:

d

Function

48

Select no parity

49

Select odd parity

50

Select even parity

▪ Flow control(a=3) is specified by d as follows:

d

Function

48

Select flow control DTR/DSR

49

Select flow control XON/XOFF

▪ Data Length(a=4) is specified by d14 as follows:

d

Function

55

Select 7bits length

56

Select 8bits length

▪ The change of settings of serial interface is available by adjusting the

corresponding DIP switch that is recommended for setting of serial interface.

▪ To enable the settings by this command, it is first required to adjust the

DIP switch that activates the serial interface configuration set by the memory switch.

<Function 12> GS ( E pL pH fn a (fn=12)

[Format]

[Range]

ASCII

GS ( E

pL

pH

fn

a

Hex

1D

28

45

pL

pH

fn

a

Decimal

29

40

69

pL

pH

fn

a

(pL + pH x 256) = 2 (pL=2, pH=0) fn=12, 1 ≤ a ≤ 4

Rev. 1.00

- 57 -

Mobile Printer Command Manual

[Description]

▪ This command transmits the communication conditions of the serial

interface according to a as follows:

a

Communication Condition

1

Baud rate

2

Parity

3

Flow control

4

Data length

▪ The data format to be transmitted is as follows:

Hexadecimal

Decimal

Amount of Data

Header

37H

55

1 byte

Identifier

33H

39

1 byte

Communication

condition(a)

31H - 34H

49 - 52

1 byte

Separator

1FH

31

1 byte

Setting value

30H - 39H

48 - 57

1 - 6 bytes

NUL

00H

0

1 byte

Communication condition is define by “a” and setting value defined as

shown in the following. ▪ Configuration of the setting value

- When the baud rate (a=1) is specified:

Baud rate (bps)

d1

d2

d3

d4

d5

d6

2400

50

52

48

--

4800

52

56

48

--

9600

57

54

48

--

19200

49

57

50

48

--

38400

51

56

52

48

--

57600

53

55

54

48

--

115200

49

53

50

48

- When the parity setting (a=2) is specified:

d1

Parity

48

No parity

49

Odd parity

50

Even parity

- When the flow control setting (a=3) is specified:

d1

Flow control

48

DTR / DSR (Fixed)

49

XON / XOFF

- When the data length setting (a=4) is specified:

d1

Data length

55

7 bits

56

8 bits

EM220II

Rev. 1.00

- 58 -

Mobile Printer Command Manual

GS ( L, GS 8 L

[Name] [Format]

[Description]

[Notes]

Select graphics data

ASCII

GS ( L

pL

pH m fn

[parameter]

Hex

1D

28

4C

pL

pH m fn

[parameter]

Decimal

29

40

76

pL

pH m fn

[parameter]

ASCII

GS 8 L

p1

p2

p3

p4 m fn

[parameter]

Hex

1D

38

4C

p1

p2

p3

p4 m fn

[parameter]

Decimal

29

56

76

p1

p2

p3

p4 m fn

[parameter]

▪ This command processes graphics data according to the function

code (fn).

fn

Format

Function No.

Function

0, 48

GS ( L pL pH m fn

Function 48

Transmits the NV graphics

memory capacity.

2, 50

GS ( L pL pH m fn

Function 50

Prints the graphics data in

the print buffer.

3, 51

GS ( L pL pH m fn

Function 51

Transmits the remaining

capacity of the NV graphics

memory.

64

GS ( L pL pH m fn d1 d2

Function 64

Transmits the defined NV

graphics key code list.

65

GS ( L pL pH m fn d1 d2 d3

Function 65

Deletes all NV graphics data.

66

GS ( L pL pH m fn kc1 kc2

Function 66

Deletes the specified NV

graphics data.

67

GS ( L pL pH m fn a kc1 kc2 b

xL xH yL yH [c d1...dk]1...[c d1

dk]b

Function 67

Defines the raster graphics

data in the non-volatile

memory.

69

GS ( L pL pH m fn kc1 kc2 x y

Function 69

Prints the specified NV

graphics data.

112

GS ( L pL pH m fn a bx by c xL

xH yL yH d1...dk

Function 112

Stores the raster graphics

data in the print buffer

memory.

▪ This command is adapted to print image data. ▪ pL, pH specifies the number of bytes following pH using (pL + pH x 256). ▪ Since frequent writing operation could cause the damage to the NV

memory, it is recommended to write only when being required.

▪ While storing data by this command, the printer is in BUSY state where

receiving of data is not available. Therefore, it is not recommended to send data during this process.

▪ The real time commands and ASB operations are not allowed during NV

memory operation process.

Rev. 1.00

EM220II

- 59 -

Mobile Printer Command Manual

<Function 48> GS ( L pL pH m fn (fn=0, 48)

[Format]

[Range]

[Description]

ASCII

GS ( L

pL

pH m fn

Hex

1D

28

4C

pL

pH m fn

Decimal

29

40

76

pL

pH m fn

(pL + pH x 256) = 2 (pL=2, pH=0) m=48, fn=0, 48

▪ Transmits the total capacity of the NV bit-image memory (number of bytes

in the memory area).

Hexadecimal

Decimal

Amount of Data

Header

37H

55

1 byte

Flag

30H

48

1 byte

Data

30H - 39H

48 - 57

1 - 8 bytes

NUL

00H

0

1 byte

▪ The total capacity data is converted to character codes corresponding to

decimal data, then transmitted from the MSB.

<Function 50> GS ( L pL pH fn (fn=2, 50)

[Format]

[Range]

[Description]

[Notes]

ASCII

GS ( L

pL

pH m fn

Hex

1D

28

4C

pL

pH m fn

Decimal

29

40

76

pL

pH m fn

(pL + pH x 256) = 2 (pL=2, pH=0) m=48, fn=2, 50

▪ This command prints the graphics data defined by the process of

Function 112.

▪ The graphics data stored in the printer buffer is printed. ▪ This command is available in standard mode, not in page mode. ▪ The graphics data is defined by Function 112. ▪ The required amount of line feed pitch is used for printing graphics data,

regardless of the existing setting value of the pitch.

Rev. 1.00

EM220II

- 60 -

Mobile Printer Command Manual

<Function 51> GS ( L pL pH m fn (fn=3, 51)

[Format]

[Range]

[Description]

ASCII

GS ( L

pL

pH m fn

Hex

1D

28

4C

pL

pH m fn

Decimal

29

40

76

pL

pH m fn

(pL + pH x 256) = 2 (pL=2, pH=0) m=48, fn=3, 51

▪ Transmits the number of bytes of remaining memory (unused area) in the

NV user memory.

Hexadecimal

Decimal

Amount of Data

Header

37H

55

1 byte

Flag

31H

49

1 byte

Data

30H – 39H

48 - 57

1 - 8 bytes

NUL

00H

0

1 byte

▪ The number of bytes of remaining memory is converted to character

codes corresponding to decimal data, then transmitted from the MSB.

▪ The data length is variable

<Function 64> GS ( L pL pH m fn d1 d2 (fn=64)

[Format]

[Range]

[Description]

ASCII

GS ( L

pL

pH m fn

d1

d2

Hex

1D

28

4C

pL

pH m fn

d1

d2

Decimal

29

40

76

pL

pH m fn

d1

d2

(pL + pH x 256) = 4 (pL=4, pH=0) m=48 fn=64 d1=75, d2=67

▪ Transmits the defined NV graphics key code list.

- When the key code is present:

Hexadecimal

Decimal

Amount of Data

Header

37H

55

1 byte

Flag

72H

114

1 byte

Status

40H or 41H

64 or 65

1 byte

Data

30H - 39H

48 - 57

2 - 80 bytes

NUL

00H

0

1 byte

- When the key code is not present :

Hexadecimal

Decimal

Amount of Data

Header

37H

55

1 byte

Flag

72H

114

1 byte

Status

40H

64

1 byte

NUL

00H

0

1 byte

▪ If the number of the key code exceeds 40, the key code is transmitted

dividing up to 40.

- The status if the continuous transmission data block is present is 41H.

- The status if the continuous transmission data block is not present is 40H.

Rev. 1.00

EM220II

- 61 -

Mobile Printer Command Manual

▪ After the [Header-NULL] is transmitted, the printer receives a response

from the host; then it performs the process defined by the response. (See the tables below.)

- When the status (existence of the next data block) is Hexadecimal = 41H / Decimal = 65

Response

Process performed

ASCII

Decimal

ACK 6 Transmits the next data

NAK

21

Transmits the previous data again

CAN

24

Ends the process

- When the status (for the last data block) is Hexadecimal = 40H / 40H/Decimal = 64

Response

Process performed

ASCII

Decimal

ACK

6

Ends the process

NAK

21

Transmits the previous data again

CAN

24

Cancels the process

<Function 65> GS ( L pL pH m fn d1 d2 d3 (fn=65)

[Format]

[Range]

[Description]

ASCII

GS ( L

pL

pH m fn

d1

d2

d3

Hex

1D

28

4C

pL

pH m fn

d1

d2

d3

Decimal

29

40

76

pL

pH m fn

d1

d2

d3

(pL + pH x 256) = 5 (pL=5, pH=0) m=48 fn=65 d1=67, d2=76, d3=82

▪ The graphics data is define by Function 67 into the NV graphics memory

with the sector dedicated for storing NV graphics data.

<Function 66> GS ( L pL pH m fn kc1 kc2 (fn=66)

[Format]

[Range]

[Description]

[Notes]

ASCII

GS ( L

pL

pH m fn

kc1

kc2

Hex

1D

28

4C

pL

pH m fn

kc1

kc2

Decimal

29

40

76

pL

pH m fn

kc1

kc2

(pL + pH x 256) = 4 (pL=4, pH=0) m=48 fn=66

32 ≤ kc1 ≤ 126 32 ≤ kc2 ≤ 126

▪ This command deletes the NV graphics data corresponding to kc1 and

kc2.

▪ The graphics data is define by Function 67. ▪ kc1 and kc2 is given to each of the graphics data groups to be stored into

the NV graphics memory in the order of download.

Rev. 1.00

EM220II

- 62 -

Mobile Printer Command Manual

<Function 67> GS ( L pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1...dk]b (fn=67)

[Format]

[Range]

[Description]

[Notes]

ASCII

GS ( L

pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1...dk]b

Hex

1D

28

4C

pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1...dk]b

Decimal

29

40

76

pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1...dk]b

GS ( L parameter3 ≤ (pL + pH x 256) ≤ 65535 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 255) [When using GS 8 L: 12 ≤ (p1 + ≤256 + p3 ≤65536 + p4 ≤16777216)

≤253119] m=48, fn=67, a=48, 32 ≤ kc1 ≤ 126, 32 ≤ kc2 ≤ 126, b=1, 2, 1 ≤ (xL + xH x

256) ≤ 384, 1 ≤ (yL + yH x 256) ≤ 1662c=49, 0 ≤ d ≤ 255, k = ( int ( ( xL + xH x 256 ) + 7 ) / 8 ) x ( yL + yH x 256 )

▪ The total capacity of the NV graphic memory is only 256K bytes ▪ Defines the raster graphics data in the NV graphics area.

- b specifies the number of the color of the defined data.

- xL, xH specifies the defined data in the horizontal direction to (xL + xH x

256) dots.

- xL, xH specifies the defined data in the vertical direction to (yL + yH x

256) dots.

- c specifies the color of the defined data.

C

Defined data color

49

Color 1

- Color 1 means black

<Function 69> GS ( L pL pH m fn kc1 kc2 b x y (fn=69)

[Format]

[Range]

[Description]

[Notes]

ASCII

GS ( L

pL

pH m fn

kc1

kc2 x y

Hex

1D

28

4C

pL

pH m fn

kc1

kc2 x y

Decimal

29

40

76

pL

pH m fn

kc1

kc2 x y

(pL + pH x 256) = 6 (pL=6, pH=0) m=48, fn=69

32 ≤ kc1 ≤ 126 32 ≤ kc2 ≤ 126

x=1, 2 y=1, 2

▪ Prints the NV graphics data defined by the key codes kc1 and kc2. The

graphics data is enlarged by x and y in the horizontal and vertical directions.

▪ This command prints the NV graphics data defined by Function 67. ▪ In page mode, this command is not effective. ▪ NV graphics data beyond the print area for one line is not printed.

Rev. 1.00

EM220II

- 63 -

Mobile Printer Command Manual

<Function 112> GS ( L pL pH m fn a bx by c xL xH yL yH d1...dk (fn=112)

[Format]

[Range]

[Description]

[Notes]

ASCII

GS ( L

pL pH m fn a bx by c xL xH yL yH d1...dk

Hex

1D

28

4C

pL pH m fn a bx by c xL xH yL yH d1...dk

Decimal

29

40

76

pL pH m fn a bx by c xL xH yL yH d1...dk

▪ GS ( L parameter 11 ≤ (pL + pH x 256) ≤ 65535 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 255) ▪ Common parameter for GS ( L m=48, fn=112, a=48 bx=1, 2 by=1, 2 c=49 1 ≤ (xL+xHx256) ≤ 384 1 ≤ (yL + yH x 256) ≤ 1662 (when by = 1) k = ( int ( ( xL + xH x 256 ) + 7 ) / 8 ) x ( yL + yH x 256 )

▪ This command stores the raster graphics data in the print buffer, enlarged

by bx and by in the horizontal and vertical directions.

- xL, xH specifies the raster graphics data in the horizontal direction as (xL + xH x 256) dots.

- yL, yH specifies the raster graphics data in the vertical direction to (yL + yH x 256) dots.

- d denotes the stored data(raster format).

- k denotes the number of the graphics data.

- c specifies the color of the defined data.

C

Defined data color

49

Color 1

50

Color 2

- Color 1 means black, and Color 2 red or blue that is available for 2color paper.

▪ The graphics data is stored in the printer buffer directly. ▪ Real time command is not effective during processing of this command.

GS :

[Name] [Format]

[Description]

Start/end macro definition.

ASCII

GS

: Hex

1D

3A

Decimal

29

58

▪ Starts or ends macro definition.

- The contents of the macro can be defined up to 2048 bytes.

Rev. 1.00

EM220II

- 64 -

Mobile Printer Command Manual

GS B

[Name] [Format]

[Range] [Default] [Description]

Turns white/black reverse printing mode on / off.

ASCII

GS

B

n

Hex

1D

42

n

Decimal

29

66

n

0 ≤ n ≤ 255 n=0 ▪ Turns white/black reverse printing mode on or off.

- When the LSB of n is 0, white/black reverse mode is turned off.

- When the LSB of n is 1, white/black reverse mode is turned on.

GS H

[Name] [Format]

[Range] [Default]

[Description]

Selects the printing position of HRI characters.

ASCII

GS H n

Hex

1D

48 n

Decimal

29

72 n

0 ≤ n ≤ 3, 48 ≤ n ≤ 51 n=0 ▪ Selects the printing position of HRI characters when printing a bar code.

- n selects the execution of printing and the printing position as follows:

n

Printing position

0, 48

Not printed.

1, 49

Above the bar code.

2, 50

Below the bar code.

3, 51

Both above and below the bar code.

Rev. 1.00

- 65 -

Mobile Printer Command Manual

GS I

[Name] [Format]

[Range] [Description]

Transmits printer ID.

ASCII

GS I n

Hex

1D

49 n

Decimal

29

73 n

1 ≤ n ≤ 69, ▪ Transmits the printer ID specified.

- Transmits 1 byte of printer ID, using n as follows:

n

Printer ID

ID

1,49

Printer model ID

65

2,50

Type ID

0(2byte character is not supported) or 1(2byte character is supported)

3, 51

Version ID

111

- Transmits specified printer information, using n as follows:

n

Printer ID type

ID

65

Firmware version

Depends on firmware version

66

Manufacturer

Zebra

67

Printer name

EM220II

69

Font of Language for

each country

Chinese : GB2312 or BIG5 Korean : KS-5601 Japanese : SHIFT-JIS Each default code page

-Printer information (When n = 65, 66, 67, 69) consist of[Header ~ NULL] as Shown in the following table:

Transmitted data

Hex

Decimal

Amount of data

Header

5FH

95

1byte

Printer information

Depends on the

model

Depends on the

model

1byte

NUL

00H

0

1byte

• This command following DLE can be executed in real-time command mode.

EM220II

Rev. 1.00

- 66 -

Mobile Printer Command Manual

GS I b

[Name] [Format]

[Description] [Notes]

Transmits battery status.

ASCII

GS I b

Hex

1D

49

62

Decimal

29

73

98

Transmits the battery power status of the printer The transmitted battery status from this printer is constructed by [Header ~

NUL] as shown in the table below.

Transmitted data

Hex

Decimal

Amount of data

Header

37H

55

1byte

Identifier

45H

69

1byte

Battery remaining

30h-34H

48-52

1byte

NUL

00H

0

1byte

“Battery remaining amount“ is as indicated in the following table:

Battery remaining amount

Information

Hex

Decimal

30H

48

Battery remaining amount : H level

31H

49

Battery remaining amount : M level

32H

50

Battery remaining amount : L level

33H

51

Battery remaining amount : S level

▪ You can confirm the battery remaining amount by looking at the battery

LED.

▪ When battery remaining amount is S level, the red LED of battery LED is

blinking.

• This command following DLE can be executed in real-time command

mode.

EM220II

Rev. 1.00

EM220II

- 67 -

Mobile Printer Command Manual

GS L

[Name] [Format]

[Range] [Default] [Description]

Set left margin.

ASCII

GS L nL

nH

Hex

1D

4C

nL

nH

Decimal

29

76

nL

nH

0 ≤ nL ≤ 255, 0 ≤ nH ≤ 255 (nL + nH x 256)=0 (nL=0, nH=0) ▪ Sets the left margin specified by nL and nH.

- The left margin is [(nL + nH x 256) x (horizontal motion units)].

Printable area

Left margin

Printing area width

GS W

[Name] [Format]

[Range] [Default] [Description]

Set printing area width.

ASCII

GS W nL nH

Hex

1D

57

nL

nH

Decimal

29

87

nL

nH

0 ≤ nL ≤ 255, 0 ≤ nH ≤ 255 (nL + nH x 256)=384 (nL=128, nH=1) (for 58mm of the paper width) ▪ Sets the printing area width specified with nL and nH.

- The printing area width is [(nL + nH x 256) x (horizontal motion units)].

Printable area

Left margin

Printing area width

Rev. 1.00

EM220II

- 68 -

Mobile Printer Command Manual

GS ＼

[Name] [Format]

[Range] [Description]

Set relative vertical print position in page mode.

ASCII

GS ＼ nL

nH

Hex

1D

5C

nL

nH

Decimal

29

92

nL

nH

0 ≤ nL ≤ 255, 0 ≤ nH ≤ 255 ▪ Sets the relative vertical print starting position from the current position in

page mode. The distance from the current position to the starting position is [(nL + nH x 256) x (vertical or horizontal motion units)].

GS ^

[Name] [Format]

[Range]

[Description]

Execute macro.

ASCII

GS ^ r t m

Hex

1D

5E r t

m

Decimal

29

94 r t

m

0 ≤ r ≤ 255 0 ≤ t ≤ 255

m=0, 1 ▪ Executes a macro.

- r specifies the number of times to execute the macro.

- t specifies the waiting time for executing the macro.

- m specifies macro executing mode from the table below.

m

Function

0

Executes the macro r times at the interval specified by t.

1

After waiting for the time specified by t, the FEED button must be pressed. After the button is pressed, the macro is executed once. This operation is then repeated r times.

Rev. 1.00

- 69 -

Mobile Printer Command Manual

GS a

[Function] [Code]

[Range] [Default] [Description]

[Remarks]

Enable/Disable Automatic Status Back. (ASB)

ASCII

GS a n

Hex

1D

61 n

Decimal

29

97 n

0 ≤ n ≤ 255 n=0 This enables or disables ASB (Automatic Status Back) according to n.

- ASB is enabled when n > 0.

The check time interval of ASB can be set by BS ^ T command. ▪ ASB is the function that transmit the printer status such as cover open/close

and Online/Offline if ASB is enabled. Using this ASB function, the host can check to see if the printer is running properly.

▪ Once ASB has been enabled, the printer transmit the current printer status

When its status is changed, until ASB is disabled.

▪ When n = 0, ASB is disabled. The printer stops transmitting the status. ▪ The setting of this command remains effective until ESC @, printer reset or

power cycling is executed.

▪ The printer information transmitted is comprised of 4 bytes as follows:

- First byte(printer information)

Bit

Off/On

Hex

Decimal

Function

0

Off

00

0

Not used. Fixed to Off

1

Off

00

0

Not used. Fixed to Off

2

Off

00

0

Not used. Fixed to Off

3

Off

00

0

On-line

On

08

8

Off-line

4

On

10

16

Not used. Fixed to On

5

Off

00

0

Cover is close

On

20

32

Cover is open

6

Off

00

0

Paper is not being fed by

the paper feed button

On

40

64

Paper is being fed by the paper feed button

7

Off

00

0

Not used. Fixed to Off

- Second byte(printer information)

Bit

Off/On

Hex

Decimal

Function

0

Off

00

0

Not used. Fixed to Off

1

Off

00

0

Not used. Fixed to Off

2

Off

00

0

Not used. Fixed to Off

3

Off

00

0

Not used. Fixed to Off

4

Off

00

0

Not used. Fixed to Off

5

Off

00

0

Not used. Fixed to Off

6

Off

00

0

Not used. Fixed to Off

7

Off

00

0

Not used. Fixed to Off

EM220II

Rev. 1.00

EM220II

- 70 -

Mobile Printer Command Manual

- Third byte (paper sensor information)

Bit

Off/On

Hex

Decimal

Function

0,1

Off

00

0

Not used. Fixed to Off

2,3

Off

00 0 Paper sensor: paper present

On

0C

12

Paper sensor: no paper present

4

Off

00

0

Not used. Fixed to Off

5

Off

00

0

Not used. Fixed to Off

6

Off

00

0

Not used. Fixed to Off

7

Off

00

0

Not used. Fixed to Off

- Fourth byte (paper sensor information)

Bit

Off/On

Hex

Decimal

Function

0

On

01

1

Not used. Fixed to On

1

On

02

2

Not used. Fixed to On

2

On

04

4

Not used. Fixed to On

3

On

08

8

Not used. Fixed to On

4

Off

00

0

Not used. Fixed to Off

5

Off

00

0

Not used. Fixed to Off

6

Off

00

0

Not used. Fixed to Off

7

Off

00

0

Not used. Fixed to Off

GS f

[Name] [Format]

[Range] [Default] [Description]

Select font for HRI characters.

ASCII

GS

f

n

Hex

1D

66

n

Decimal

29

102

n

n=0, 1, 48, 49 n=0 ▪ Selects a font for the HRI characters used when printing a bar code.

- n specifies the font of the HRI characters as follows:

n

Font

0, 48

Font A (12 x 24)

1, 49

Font B (9 x 17)

Rev. 1.00

EM220II

- 71 -

Mobile Printer Command Manual

GS h

[Name] [Format]

[Range] [Default] [Description]

Selects bar code height.

ASCII

GS h n

Hex

1D

68 n

Decimal

29

104 n

1 ≤ nL ≤ 255 n=162 ▪ Selects the height of the bar code as n dots. GS k

[Name] [Format]

[Range]

[Description]

Print bar code.

①

ASCII

GS k m

d1...dk

NUL

Hex

1D

6B

m

d1...dk

NUL

Decimal

29

107

m

d1...dk

NUL

②

ASCII

GS k m

n

d1...dn

Hex

1D

6B m n

d1...dn

Decimal

29

107 m n

d1...dn

① 0 ≤ m ≤ 6 (k and d depend on the bar code system used) ② 65 ≤ m ≤ 73 (n and d depend on the bar code system used)

▪ Selects a bar code system and prints the bar code.

For ①

m

Bar Code System

Range of k

Range of d

0

UPC-A

11 ≤ k ≤ 12

48 ≤ d ≤ 57

1

UPC-E

11 ≤ k ≤ 12

48 ≤ d ≤ 57

2

JAN13(EAN)

12 ≤ k ≤ 13

48 ≤ d ≤ 57

m

Bar Code System

Range of k

Range of d

3

JAN8(EAN)

7 ≤ k ≤ 8

48 ≤ d ≤ 57

4

CODE39

1 ≤ k

48 ≤ d ≤ 57, 65 ≤ d ≤ 90,

d=32,36,37,43,45,46,47

5

ITF

1 ≤ k

(even number)

48 ≤ d ≤ 57

6

CODABAR

1 ≤ k

48 ≤ d ≤ 57, 65 ≤ d ≤ 68,

d=36,43,45,46,47,58

Rev. 1.00

- 72 -

Mobile Printer Command Manual

[Notes]

For ②

m

Bar Code System

Range of n

Range of d

65

UPC-A

11 ≤ n ≤ 12

48 ≤ d ≤ 57

66

UPC-E

11 ≤ n ≤ 12

48 ≤ d ≤ 57

67

JAN13(EAN)

12 ≤ n ≤ 13

48 ≤ d ≤ 57

68

JAN8(EAN)

7 ≤ n ≤ 8

48 ≤ d ≤ 57

69

CODE39

1 ≤ n ≤ 255

48 ≤ d ≤ 57, 65 ≤ d ≤ 90,

d=32,36,37,43,45,46,47

70

ITF

1 ≤ n ≤ 255

(even number)

48 ≤ d ≤ 57

71

CODABAR

1 ≤ n ≤ 255

48 ≤ d ≤ 57, 65 ≤ d ≤ 68,

d=36,43,45,46,47,58

72

CODE93

1 ≤ n ≤ 255

48 ≤ d ≤ 57, 65 ≤ d ≤ 90,

d=32,36,37,43,45,46,47

73

CODE128

2 ≤ n ≤ 255

0 ≤ d ≤ 127

▪ The user must consider the quiet zone of the bar code (left and right

spaces of the bar code)

GS r

[Name] [Format]

[Range] [Description]

Transmit status.

ASCII

GS r n

Hex

1D

72 n

Decimal

29

114 n

n=1, 2, 49, 50 ▪ Transmits the normal status specified by n as follows:

n

Function

1, 49

Transmits paper sensor status.

▪ Paper sensor status (n=1, 49) :

Bit

Off/On

Hex

Decimal

Function

0, 1

Off

00

0

Reserved

.

On

03

3

Reserved

.

2, 3

Off

00 0 Paper roll end sensor; paper present.

On

0C

12

Paper roll end sensor; paper not present.

4

Off

00

0

Fixed.

5

Off

00

0

Reserved.

6

Off

00

0

Reserved.

7

Off

00

0

Fixed.

- Bits 2 and 3: This command can not be executed when the printer is

offline due to the lack of paper. Therefore, the status of bit 2 (1) and bit 3 (1) is not transmitted.

• This command following DLE can be executed in real-time command

mode.

EM220II

Rev. 1.00

EM220II

- 73 -

Mobile Printer Command Manual

GS v 0

[Name] [Format]

[Range]

Print raster bit image.

ASCII

GS v 0 M xL xH yL yH d1...dk

Hex

1D

76

30 M xL xH yL yH d1...dk

Decimal

29

118

48 M xL xH yL yH d1...dk

0 ≤ m ≤ 3, 48 ≤ m ≤ 51 1 ≤ (xL + xH x 256) ≤ 128 (0 ≤ xL ≤ 128, xh=0) 1 ≤ (yL + yH x 256) ≤ 4095 (0 ≤ yL ≤ 255, 0 ≤ yH ≤ 15) 0 ≤ d ≤ 255

k = (xL + xH x 256) x (yL + yH x 256)

[Description]

▪ Prints a raster bit image in m mode.

- m specifies the bit image mode.

m

Mode

Vertical dot density

Horizontal dot density

0, 48

Normal

203 dpi

1, 49

Double-width

203 dpi

203/2 dpi

2, 50

Double-height

203/2 dpi

203 dpi

3, 51

Quadruple

203/2 dpi

dpi : dots per 25.4mm {1"}

-

xL, xH specifies (xL + xH x 256) byte(s) in the horizontal direction for the bit image.

-

yL, yH specifies (yL + yH x 256) dot(s) in the vertical direction for the bit image.

- d specifies the definition data of the bit image data.

GS w

[Name] [Format]

[Range] [Description]

[Notes]

Set bar code width.

ASCII

GS w n

Hex

1D

77 n

Decimal

29

119 n

2 ≤ n ≤ 6 , n=3 ▪ Set the horizontal size of the bar code, using n as follows:

n

Multi-level Bar Code

Module Width (mm)

Binary-level Bar Code

Thin element width

(mm)

Thick element width

(mm)

2

0.250

0.625

3

0.375

1.000

4

0.500

1.250

5

0.625

1.625

6

0.750

2.000

▪ Multi-level bar codes are as follows:

- UPC-A, UPC-E, JAN13, HAN8, CODE93, CODE128

▪ Binary-level bar codes are as follows:

- CODE39, ITF, CODABAR

Rev. 1.00

EM220II

- 74 -

Mobile Printer Command Manual

BS L A

[Name] [Format]

[Description] [Notes]

Execute auto calibration in label mode.

ASCII

BS L A

Hex

08

4C

41

Decimal

8

76

65

▪ Execute auto calibration in label mode. ▪ Store the value for the liner into NV memory during three-label feed

process without printing.

▪ The leading edge of the label is positioned at the print line by the use of

the stored value.

BS L L

[Name] [Format]

[Description] [Notes]

Change label mode.

ASCII

BS L L

Hex

08

4C

Decimal

8

76

▪ Change from receipt mode to Label mode. ▪ The memory switch setting is changed.

BS L R

[Name] [Format]

[Description] [Notes]

Change receipt mode.

ASCII

BS L R

Hex

08

4C

52

Decimal

8

76

82

▪ Change from label mode to receipt mode. ▪ The memory switch setting is changed.

Rev. 1.00

EM220II

- 75 -

Mobile Printer Command Manual

BS M

[Name] [Format]

[Range]

[Default] [Description]

[Notes]

Select device font type

ASCII

BS L n m

Hex

08

4D n m

Decimal

8

77 n m

65 ≤ m ≤ 67 ( m = 65,66,67) n = 0

n = 0 ▪ Font type select by m value as follows:

m

Function ( Select font type )

65

Font A (12x24)

66

Font B (9x17)

67

Font C (9x24)

▪ The setting of this command remains effective until ESC !, ESC M ESC

@, printer reset or power cycling is executed.

BS M S

[Name] [Format]

[Range]

[Default] [Description]

Set sentinel character mode

ASCII

BS M S

pL

pH

fn1

n

Hex

1D

42 n 02

00

31

n

Decimal

29

66 n 2 0 49

n

0 ≤ n ≤ 2 (pL+pHx256) = 0

Depends on memory switch 8-6~7 setting value.

▪ Sets sentinel characters by n value as follows:

n

Mode

Description

0, 48

None sentinel character mode

Transmits data as normal data without sentinel characters.

1, 49

Static sentinel character

Adds 1-byte sentinel characters to the beginning and the end of card data and then transmits to host. STX: 1 Track (%), 2, 3 Track (;),ETX: 1, 2, 3 Track (?)

2, 50

Dynamic sentinel characters

Adds Start characters and End characters to the beginning and the end of card data and then transmits to host.

Rev. 1.00

EM220II

- 76 -

Mobile Printer Command Manual

- When set to Static sentinel character mode, 1-byte sentinel characters are

added to the beginning parts and the end parts of each track data.

-1 Track sentinel characters: STX (%),ETX (?)

-2 Track sentinel characters: STX (;),ETX (?)

-3 Track sentinel characters: STX (;),ETX (?)

- When set to Dynamic sentinel characters mode, the header and the footer, which have been used in None sentinel character mode, are not used any more and the specified Start characters and End characters are added to the beginning parts and the end parts of each track data to be transmitted.

- When set to Dynamic sentinel characters mode but Start characters and End characters are not set by fn2 and fn3 of BS M S command respectively, the default Start and End characters are applied to card data to be transmitted to host.

- When set to Dynamic sentinel character mode, <CR/LF> characters after End characters are automatically applied to the card data to be transmitted to host.

02H 41H 31H 31H 1CH

Max DATA 76 characters (1Track data)

03H 0DH 0AH

02H 41H 31H 31H 1CH

(Header)

25H

(STX)

Max DATA 76 characters

(1Track data)

3FH

(ETX)

03H 0DH 0AH

(End)

START characters

(Max 10 byte)

Max DATA 76 characters (1Track data)

END characters

(Max 10 byte)

0DH 0AH

02H 42H 31H 31H 1CH

Max DATA 37 characters (2Track data)

03H 0DH 0AH

02H 42H 31H 31H 1CH

(Header)

3BH

(STX)

Max DATA 37 characters

(2Track data)

3FH

(ETX)

03H 0DH 0AH

(End)

START characters

(Max 10 byte)

Max DATA 37 characters

(2Track data)

END characters (Max 10 byte)

0DH 0AH

MSR Data Transmission Format by Setting Mode

Refer to ESC M command and the function 3 memory switch #8 (8 – 6 & 7 setting) of BS ^ E command.

- When set to Track 1 Read mode None sentinel character mode

Static sentinel character mode

Dynamic sentinel character mode

- When set to Track 2 Read mode None sentinel character mode

Static sentinel character mode

Dynamic sentinel character mode

Rev. 1.00

- 77 -

Mobile Printer Command Manual

02H 44H 31H 31H 1CH

Max DATA104 characters (3Track data)

03H 0DH 0AH

02H 44H 31H 31H 1CH

(Header)

3BH

(STX)

Max DATA 104 characters

(3Track data)

3FH

(ETX)

03H 0DH 0AH

(End)

START characters

(Max 10 byte)

Max DATA 104 characters (3Track data)

END characters

(Max 10 byte)

0DH 0AH

02H 43H 31H 31H 1CH 1CH

Max DATA 76 characters

(1Track data)

1CH

Max DATA 37 Characters

(2Track data)

03H 0DH 0AH

02H 43H 31H

31H 1CH

1CH

(Header)

3BH

(STX)

Max DATA76

characters

(1Track data)

3FH

(ETX)

1CH

(Separator)

3BH

(STX)

Max DATA37

Characters

(2Track data)

3FH

(ETX)

03H 0DH 0AH

(End)

START characters

(Max 10 byte)

Max DATA 76 characters

(1Track data)

END characters

(Max 10 byte)

0DH 0AH

START characters

(Max 10 byte)

Max DATA 37 characters

(2Track data)

END characters

(Max 10 byte)

0DH 0AH

02H 45H 31H 31H 1CH 1CH

Max DATA 37 characters

(2Track data)

1CH

Max DATA104

Characters

(3Track data)

03H 0DH 0AH

02H 45H 31H

31H 1CH

1CH

(Header)

3BH

(STX)

Max DATA37

characters

(2Track data)

3FH

(ETX)

1CH

(Separator)

3BH

(STX)

Max DATA104

Characters

(3Track data)

3FH

(ETX)

03H

0DH

0AH

(End)

START characters

(Max 10 byte)

Max DATA 37 characters

(2Track data)

END characters

(Max 10 byte)

0DH 0AH

START characters

(Max 10 byte)

Max DATA 104 characters

(3Track data)

END characters (Max

10 byte)

0DH 0AH

- When set to Track 3 Read mode None sentinel character mode

Static sentinel character mode

Dynamic sentinel character mode

EM220II

- When set to Track 1/2 Read mode None sentinel character mode

Static sentinel character mode

Dynamic sentinel character mode

- When set to Track 2/3 Read mode None sentinel character mode

Static sentinel character mode

Dynamic sentinel character mode

Rev. 1.00

- 78 -

Mobile Printer Command Manual

02H 46H 31H 31H 1CH 1CH

Max DATA76

characters

(1Track data)

1CH

Max

DATA37

Characters

(2Track

data)

1CH

Max

DATA104

Characters

(3Track data)

03H 0DH 0AH

02H 46H 31H

31H 1CH

1CH

(Header)

25H

(STX)

Max DATA76

characters

(1Track data)

3FH

(ETX)

1CH

(Separator)

3BH

(STX)

Max DATA37

Characters

(2Track data)

3FH

(ETX)

1CH

(Separator)

3BH

(STX)

Max

DATA104

Characters

(3Track data)

3FH

(ETX)

03H

0DH

0AH

(End)

START characters

(Max 10 byte)

Max DATA 76 characters

(1Track data)

END characters

(Max 10 byte)

0DH 0AH

START characters

(Max 10 byte)

Max DATA 37 characters

(2Track data)

END characters

(Max 10 byte)

0DH 0AH

START characters

(Max 10 byte)

Max DATA 104 characters

(3Track data)

END characters

(Max 10 byte)

0DH 0AH

BS M S PL PH fn2 m d1~dk

[Name] [Format]

[Range] [Default]

[Description]

Set Start characters

ASCII

BS M S

pL

pH

fn2

m

d1~dk

Hex

1D

42

53

pL

pH

32 m d1~dk

Decimal

29

66

83

pL

pH

50 m d1~dk

m = 49, 50, 51 32 ≤d ≤127, k ≤ 10 Track 1 : “START1 “

Track 2 : “START2 “ Track 3 : “START3 “

▪ m defines the track to set Start characters. ▪ d indicates the characters to be set as Start characters. ▪ k indicates the number of characters to be used as Start characters. ▪ k is defined as (PL + PH x 256) - 2

▪ If Dynamic sentinel character mode is set by fn1 after setting Start

characters, the Start characters are added to the beginning parts of each

track data after reading card data and then the card data is transmitted.

▪ The specified Start characters are saved to non-volatile memory so the

setting value is not changed even though the printer is reset.

- When set to Track 1/2/3 Read mode None sentinel character mode

Static sentinel character mode

Dynamic sentinel character mode

EM220II

Rev. 1.00

EM220II

- 79 -

Mobile Printer Command Manual

BS M S PL PH fn3 m d1~dk

[Name] [Format]

[Range] [Default]

[Description]

Set End characters

ASCII

BS M S

pL

pH

fn3

m

d1~dk

Hex

1D

42

53

pL

pH

33 m d1~dk

Decimal

29

66

83

pL

pH

51 m d1~dk

m = 49, 50, 51 32 ≤d ≤127, k ≤ 10 Track 1 : “END”

Track 2 : “END” Track 3 : “END”

▪ m defines the track to set an End character. ▪ d indicates the character to be set as an End character. ▪ k indicates the number of characters to be used as End characters. ▪ k is defined as (PL + PH x 256) - 2 ▪ If Dynamic sentinel character mode is set by fn1 after setting End

characters, the End characters are added to the end parts of each track

data after reading card data and then the data is transmitted.

▪ If d is set to Null 1-byte, it allows the setting of no End character. ▪ The specified End characters are saved to non-volatile memory so the

setting value is not changed even though the printer is reset.

BS M S PL PH fn4 m

[Name] [Format]

[Range]

[Description]

Transmit Start and End characters setting information

ASCII

BS M S

pL

pH

fn4

m

Hex

1D

42

53

pL

pH

34

m

Decimal

29

66

83

pL

pH

52

m

m = 49, 50, 51

▪ m defines the track to be transmitted. ▪ The transmission format is as follows:

Hexadecimal

Decimal

Amount of Data

Header

37H

55

1 byte

Flag

81H

129

1 byte

Track

31H~33H

49~51

1byte

Start characters

20H ~ 7FH

32~127

Max 10 bytes

Separate

1F

31

1byte

End characters

20H~7FH

32~127

Max 10 bytes

NUL

00H

0

1 byte

- The track on the above table indicates the track information of transmission data.

- For example, the track value of 31H indicates the information on the Start and End characters of Track 1.

- If d is set to Null 1-byte in fn3, End characters are not transmitted.

Rev. 1.00

www.zebra.com

Zebra Technologies International, LLC Zebra Technologies Europe Limited

333 Corporate Woods Parkway Dukes Meadow

Vernon Hills, Illinois 60061, 3109 USA Millboard Road

Phone: +1.847.634.6700

Toll-Free: +1.800.423.0422

Fax: +1.847.913.8766

Bourne End

Buckinghamshire, SL8 5XF, UK

Phone: +44 (0)1628 556000

Fax: +44 (0)1628 556001

Zebra EM220II EM220II Mobile Printer Command Manual (en)

Specifications and Main Features

Frequently Asked Questions

User Manual
