EM 220

Mobile Printer Command Manual

P1007752-015 Rev. 1.00

EM 220

Table of Contents

1. Notice............................................................................................................................. 6

2. Control Commands List ............................................................................................... 6

3. Control Commands Details.......................................................................................... 8

3-1 Command Notation.................................................................................................... 8

3-2 Explanation of Terms................................................................................................. 8

3-3 Control Commands Details........................................................................................ 9

Rev. 1.00

- 2 -

Mobile Printer Command Manual

EM 220

■ Proprietary Statements

This manual contains proprietary information of Zebra Technologies Corporation. It is intended solely for the information and use of parties operating and maintaining the equipment described herein. Such proprietary information may not be used, reproduced, or disclosed to any other parties for any other purpose without the expressed written permission of Zebra Technologies Corporation.

Product Improvements Since continuous product improvement is a policy of Zebra Technologies Corporation, all specifications and signs are subject to change without notice.

FCC Compliance Statement NOTE: This equipment has been tested and found to comply with the limits or a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet or circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help. WARNING: Exposure to Radio Frequency radiation. To conform to FCC RF exposure requirements this device shall be used in accordance with the operating conditions and instructions listed in this manual. NOTE: This unit was tested with shielded cables on the peripheral devices. Shielded cables must be used with the unit to insure compliance. Changes or modifications to this unit not expressly approved by Zebra Technologies Corporation could void the user’s authority to operate this equipment.

Rev. 1.00

- 3 -

Mobile Printer Command Manual

EM 220

Canadian Compliance Statement

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada. “IC:” before the equipment certification number signifies that the Industry Canada technical specifications were met. It does not guarantee that the certified product will operate to the user’s satisfaction.

Liability Disclaimer Inasmuch as every effort has been made to supply accurate information in this manual, Zebra Technologies Corporation is not liable for any erroneous information or omissions. Zebra Technologies Corporation reserves the right to correct any such errors and disclaims liability resulting therefrom.

No Liability for Consequential Damage In no event shall Zebra Technologies Corporation or anyone else involved in the creation, production, or delivery of the accompanying product (including hardware and software) be liable for any damages whatsoever (including, without limitation, damages for loss of business profits, business interruption, loss of business information, or other pecuniary loss) arising out of the use of or the results of use of or inability to use such product, even if Zebra Technologies Corporation has been advised of the possibility of such damages. Because some states do not allow the exclusion of liability for consequential or incidental damages, the above limitation may not apply to you.

Rev. 1.00

- 4 -

Mobile Printer Command Manual

EM 220

Copyrights

The copyrights in this manual and the label print engine described therein are owned by Zebra Technologies Corporation. Unauthorized reproduction of this manual or the software in the label print engine may result in imprisonment of up to one year and fines of up to $10,000 (17 U.S.C.506). Copyright violators may be subject to civil liability. This product may contain ZPL®, ZPL II®, and ZebraLinktm programs; Element Energy Equalizer® Circuit; E3®; and AGFA fonts. Software © ZIH Corp. All rights reserved worldwide. ZebraLink and all product names and numbers are trademarks, and Zebra, the Zebra logo, ZPL, ZPL II, Element Energy Equalizer Circuit, and E3 Circuit are registered trademarks of ZIH Corp. All rights reserved worldwide. Monotype®, Intellifont® and UFST® are trademarks of Monotype Imaging, Inc. registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions. AndyTM , CG PalacioTM, CG Century SchoolbookTM, CG TriumvirateTM, CG TimesTM, Monotype KaiTM, Monotype MinchoTM and Monotype SungTM are trademarks of Monotype Imaging, Inc. and may be registered in some jurisdictions. HY Gothic HangulTM is a trademark of Hanyang Systems, Inc. AngsanaTM is a trademark of Unity Progress Company (UPC) Limited. Andale®, Arial®, Book Antiqua®, Corsiva®, Gill Sans®, Sorts® and Times New Roman® are trademarks of The Monotype Corporation registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions. Century Gothic™, Bookman Old StyleTM and Century SchoolbookTM are trademarks of The Monotype Corporation and may be registered in certain jurisdictions. HGPGothicB is a trademark of the Ricoh company, Ltd. and may be registered in some jurisdictions. UniversTM is a trademark of Heidelberger Druckmaschinen AG, which may be registered in certain jurisdictions, exclusively licensed through Linotype Library GmbH, a wholly owned subsidiary of Heidelberger Druckmaschinen AG. Futura® is a trademark of Bauer Types SA registered in the United States Patent and Trademark Office and may be registered in some jurisdictions. TrueType® is a trademark of Apple Computer, Inc. registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions. All other product names are the property of their respective owners. All other brand names, product names, or trademarks belong to their respective holders. ©2006 ZIH Corp.

Rev. 1.00

- 5 -

Mobile Printer Command Manual

EM 220

1. Notice

This Control Commands Manual contains information on the protocol and functions of all control commands that can be used with this printer (EM 220).

2. Control Commands List

No Command Name Function Type

1 HT Horizontal tab 2 LF Print and line feed

3 FF

4 CR Print and carriage return 5 CAN Cancel print data in page mode 6 DLE Set real-time command mode 7 EOT n Transmit status 8 ESC FF Print data in page mode

9 ESC SP n Set right-side character spacing 10 ESC ! n Select print mode(s) 11 ESC $ Set absolute print position 12 ESC * Select bit-image mode 13 ESC - n Turn underline mode on/off 14 ESC 2 Select default line spacing 15 ESC 3 n Set line spacing 16 ESC @ Initialize printer 17 ESC D n Set horizontal tab positions 18 ESC E n Turn emphasized mode on/off 19 ESC G n Turn double-strike mode on/off 20 ESC J n Print and feed paper 21 ESC L Select page mode 22 ESC M n Select character font or Set card reader mode 23 ESC R n Select an international character set 24 ESC S Select standard mode 25 ESC T n Select print direction in page mode 26 ESC W n Set print area in page mode 27 ESC \ Set relative print position 28 ESC a n Select justification 29 ESC d n Print and feed n lines 30 ESC t n Select character code table

Print and return to standard mode

(in page mode)

Print Position

Character

Status Status

Print Character Character

Print Position

Bit-image

Character

Line Spacing Line Spacing

Misc.

Print Position

Character Character

Misc.

Character/MSR

Character

Misc. Print Position Print Position Print Position Print Position

Character

Rev. 1.00

- 6 -

Mobile Printer Command Manual

EM 220

No Command Name Function Type

31 ESC { Turn upside-down print mode on/off 32 GS ! n Select character size 33 GS $ n Set absolute vertical print position in page mode 34 GS ( A Execute test print 35 BS ^ E Set user setup commands 36 BS ^ L or BS ^ 7 Set graphics data 37 GS ( k Select print control method(s) 38 GS : Start/end macro definition 39 GS B n Turn white/black reverse print mode on/off 40 GS H n Select print position of HRI characters 41 GS I b Transmit battery power 42 GS I n Transmit printer ID 43 GS L Set left margin 44 GS W Set print area width 45 GS \ Set relative vertical print position in page mode 46 GS ^ Execute macro 47 GS f n Select font for HRI characters 48 GS h n Set bar code height 49 GS k Print bar code 50 GS r n Transmit status 51 GS v 0 Print raster bit image 52 GS w n Set bar code width 53 FS . Cancel Kanji character mode 54 FS & Select Kanji character mode 55 US L R Change Receipt mode 56 US L L Change Label mode 57 US L A Execute auto calibration in label mode

Character Character

Print Position

Misc.

Customize

Bit-image

Two dimension

Macro

Character

Bar code

Misc.

Misc. Print Position Print Position Print Position

Macro Bar code Bar code Bar code

Status

Bit-image

Bar code

2bytes code 2bytes code

Misc. Misc. Misc.

Rev. 1.00

- 7 -

Mobile Printer Command Manual

3. Control Commands Details

3-1 Command Notation

[Name]

[Format]

[Range]

[Description]

3-2 Explanation of Terms

LSB Least Significant Bit

The name of the command.

The code sequence: ASCII indicates the ASCII character equivalents. Hex indicates the hexadecimal equivalents. Decimal indicates the decimal equivalents.

[ ] k indicates that the content of the [ ] should be repeated k times. Provides the allowable ranges for the arguments.

Describes the function of the command.

EM 220

Rev. 1.00

- 8 -

Mobile Printer Command Manual

3-3 Control Commands Details

HT [Name]

[Format]

[Description]

LF [Name]

[Format]

[Description]

Horizontal tab.

ASCII HT Hex 09 Decimal 9

▪ Moves the print position to the next horizontal tab position.

Print and line feed.

ASCII LF Hex 0A Decimal 10

▪ In standard mode, prints the data in the print buffer and feeds one line

based on the current line spacing.

▪ In page mode, only the print position moves, and the printer does not

EM 220

FF [Name]

[Format]

[Description]

perform actual printing

If in page mode, after printing, the printer is returned to standard mode. If the label function is set, the paper is fed to the next printing position.

ASCII FF Hex 0C Decimal 12

▪ All data collected to the current point is printed, and then the printer is

converted from page mode to standard mode.

▪ After printing, the printer does not clear the buffer data of page mode. ▪ If the label function is set, the paper is fed to the next printing position.

Rev. 1.00

- 9 -

Mobile Printer Command Manual

CR [Name]

[Format]

[Description]

CAN [Name]

[Format]

[Description]

DLE [Name]

[Format]

[Description]

Command Function

EOT Transmit printer status GS r

Print and carriage return.

ASCII CR Hex 0D Decimal 13

▪ This command is ignored CR.

Cancel print data in page mode.

ASCII CAN Hex 18 Decimal 24

▪ In page mode, deletes all the print data in the current print area.

Set real-time command mode.

ASCII DLE Hex 10 Decimal 16

▪ Set real-time command mode. ▪ A single command following this command is regarded as a real time

command that the printer executes upon receiving it.

▪ The real time command mode using DLE is activated for following

commands.

Transmit status

EM 220

GS I

Rev. 1.00

Transmit printer ID

- 10 -

Mobile Printer Command Manual

EOT n [Name]

[Format]

[Range]

[Description]

n Function 1 Transmit printer status 2 Transmit off-line status 3 Transmit error status 4 Transmit paper roll sensor status

▪ This printer transmits the following status.

Transmit status

ASCII EOT N Hex 04 n Decimal 4 n

1 ≤ n ≤ 4

▪ Transmits the status specified by n as follows:

EM 220

n=1: Printer status

Bit Off/On Hex Decimal Function

0 Off 00 0 Fixed 1 On 02 2 Fixed 2 Off 00 0 Fixed

4 On 10 16 Fixed

7 Off 00 0 Fixed

Off 00 0 On-Line On 08 8 Off-Line

Off 00 0 Off line waiting status On 20 32 On line waiting status Off 00 0 Paper FEED button is turned Off On 40 64 Paper FEED button is turned On

Rev. 1.00

- 11 -

Mobile Printer Command Manual

Bit Off/On Hex Decimal Function

0 Off 00 0 Fixed 1 On 02 2 Fixed

4 On 10 16 Fixed

7 Off 00 0 Fixed

Bit Off/On Hex Decimal Function

0 Off 00 0 Fixed 1 On 02 2 Fixed 2 Off 00 0 Fixed 3 Off 00 0 Fixed 4 On 10 16 Fixed 5 Off 00 0 Fixed 6 Off 00 0 Fixed 7 Off 00 0 Fixed

Off 00 0 Cover is closed On 04 4 Cover is open Off 00 0 Paper is not being fed by using the paper FEED button On 08 8 Paper is being fed by the paper FEED button

Off 00 0 No paper-end stop On 20 32 Printing is being stopped Off 00 0 No error On 40 64 Error has occurred

EM 220

n=2: Off-line status

n=3: Error status

n=4: Continuous paper sensor status

Bit Off/On Hex Decimal Function

0 Off 00 0 Fixed 1 On 02 2 Fixed 2 Off 00 0 Fixed 3 Off 00 0 Fixed 4 On 10 16 Fixed

7 Off 00 0 Fixed

Off 00 0 Paper end sensor; paper present On 20 32 Paper end sensor; paper not present Off 00 0 Paper end sensor; paper present On 40 64 Paper end sensor; paper not present

Rev. 1.00

- 12 -

Mobile Printer Command Manual

[Notes]

ESC FF [Name]

[Format]

[Description]

ESC SP n [Name]

[Format]

[Range]

[Default]

[Description]

EM 220

This is a status request command to determine if the printer is off-line or if an error condition has occurred. Take the following into consideration:

• If this command interrupts the code string of another command, this command is processed as a parameter of the other command; therefore, the print result will not be correct.

• If a command such as graphics data or defined data has a code string that is the same as a code string in a parameter, the printer processes and then continues with the bit-image or other command.

• This command following DLE can be executed in real-time command mode.

This command is ignored when transmitting block data (Header ~ NUL).

Print data in page mode.

ASCII ESC FF Hex 1B 0C Decimal 27 12

▪ In page mode, prints all buffered data in the print area. ▪ After printing, the printer does not clear the buffer data. ▪ This command is used when the page mode data is printed repeatedly.

Set right-side character spacing.

ASCII ESC SP n Hex 1B 20 n Decimal 27 32 n

0 ≤ n ≤ 255

n=0

▪ Sets the character spacing for the right side of the character to

[n ×horizontal or vertical motion units].

▪ The maximum right-side character spacing is:

- 31.875mm.

Rev. 1.00

- 13 -

Mobile Printer Command Manual

ESC ! n [Name]

[Format]

[Range]

[Default]

[Description]

ESC $ nL nH [Name]

[Format]

[Range]

[Description]

EM 220

Select print mode(s).

ASCII ESC ! n Hex 1B 21 n Decimal 27 33 n

0 ≤ n ≤ 255

n=0

▪ Selects print mode(s) using n as follows:

Bit Off/On Hex Decimal Function

1,2 Off 00 0 Reserved.

6 Off 00 0 Reserved.

Set absolute print position.

ASCII ESC $ nL nH Hex 1B 24 nL nH Decimal 27 36 nL nH

0 ≤ (nL + nH x 256) ≤ 65535 (0 ≤ nH ≤ 255, 0 ≤ nL ≤ 255)

▪ Sets the next print starting position, and the absolute print position, in

reference to the left margin. The distance from the beginning of the line to the left margin is [(nL + nH x 256) x (vertical or horizontal motion units)].

Off 00 0 Character font A (12 × 24) selected. On 01 1 Character font B (9 x 24) selected.

Off 00 0 Emphasized mode not selected. On 08 8 Emphasized mode selected. Off 00 0 Double-height mode not selected. On 10 16 Double-height mode selected. Off 00 0 Double-width mode not selected. On 20 32 Double-width mode selected.

Off 00 0 Underline mode not selected. On 80 128 Underline mode selected.

Rev. 1.00

- 14 -

Mobile Printer Command Manual

ESC * m nL nH d1...dk [Name]

[Format]

[Range]

[Description]

Select bit image mode.

ASCII ESC * m nL nH d1...dk Hex 1B 2A m nL nH d1...dk Decimal 27 42 m nL nH d1...dk

m=0, 1, 32, 33 1 ≤ (nL + nH x 256) ≤ 1023 (0 ≤ nL ≤ 255, 0 ≤ nH ≤ 3) 0 ≤ d ≤ 255

▪ Specifies the bit image in m mode for the number of dots specified by nL

and nH.

EM 220

* dpi : dots per 25.4mm {1”}

m Mode

ESC – n [Name]

[Format]

[Range]

[Default]

[Description]

n Function 0,48 Turns off underline mode. 1,49 Turns on underline mode, set at 1-dot width. 2,50 Turns on underline mode, set at 2-dot width.

8-dot

single-density

8-dot

double-density

24-dot

single-density

24-dot

double-density

Turn underline mode on/off.

ASCII ESC - n Hex 1B 2D n Decimal 27 45 n

0 ≤ n ≤ 2, 48 ≤ n ≤ 50

n=0

▪ Turn underline mode on or off, based on the following values of n:

Number of dots in

vertical direction

8 203/3 dpi 203/2 dpi nL + nH x 256

8 203/3 dpi 203 dpi nL + nH x 256

24 203 dpi 203/2 dpi (nL + nH x 256) x 3

24 203 dpi 203 dpi (nL + nH x 256) x 3

Vertical dot

density

Horizontal

dot density

Number of bytes (k)

Rev. 1.00

- 15 -

Mobile Printer Command Manual

ESC 2 [Name]

[Format]

[Description]

ESC 3 n [Name]

[Format]

[Range]

[Default]

[Description]

ESC @ [Name]

[Format]

[Range]

[Description]

EM 220

Select default line spacing.

ASCII ESC 2 Hex 1B 32 Decimal 27 50

▪ The default line spacing is approximately 3.75 mm, which is equivalent to

30 dots.

Set line spacing

ASCII ESC 3 n Hex 1B 33 n Decimal 27 51 n

0 ≤ n ≤ 255

n = 30

▪ The vertical or horizontal motion unit is approximately 0.125 mm {1/203

inches}. This value equals one dot pitch.

▪ Sets the current line spacing to [n x vertical motion units] inches. ▪ The maximum settable line spacing is 31.875mm.

Initialize printer.

ASCII ESC @ Hex 1B 40 Decimal 27 64

32 ≤ n ≤ 126

▪ Clears the data in the print buffer and resets the printer mode to the mode

that was in effect when the power was turned on.

Rev. 1.00

- 16 -

Mobile Printer Command Manual

ESC D n1… nk NUL [Name]

[Format]

[Range]

[Default]

[Description]

ESC E n [Name]

[Format]

[Range]

[Default]

[Description]

Set horizontal tab positions.

ASCII ESC D n1...nk NUL Hex 1B 44 n1...nk 00 Decimal 27 68 n1...nk 0

1 ≤ n ≤ 255 , 0 ≤ k ≤ 32

n=8, 16, 24, 32, 40,....., 232, 240, 248

(for font A in a standard character size width)

▪ Sets horizontal tab positions.

- n specifies the number of digits from the setting position to the left margin or the beginning of the line.

- k specifies the number of bytes set for the horizontal tab position.

▪ The horizontal tab position is stored as a value of [character width x n]

measured form the beginning of the line.

Turn emphasized mode on / off.

ASCII ESC E n Hex 1B 45 n Decimal 27 69 n

0 ≤ n ≤ 255

n=0

▪ Turns emphasized mode on or off.

- When the LSB of n is 0, emphasized mode is turned off.

- When the LSB of n is 1, emphasized mode is turned on.

EM 220

Rev. 1.00

- 17 -

Mobile Printer Command Manual

ESC G n [Name]

[Format]

[Range]

[Default]

[Description]

ESC J n [Name]

[Format]

[Range]

[Description]

ESC L [Name]

[Format]

[Description]

EM 220

Turn double-strike mode on/off.

ASCII ESC G n Hex 1B 47 n Decimal 27 71 n

0 ≤ n ≤ 255

n=0

▪ Turns double-strike mode on or off.

- When the LSB of n is 0, double-strike mode is turned off.

- When the LSB of n is 1, double-strike mode is turned on.

Print and feed paper.

ASCII ESC J n Hex 1B 4A n Decimal 27 74 n

0 ≤ n ≤ 255

▪

Prints the data in the print buffer and feeds the paper [n X vertical motion unit].

Select page mode.

ASCII ESC L Hex 1B 4C Decimal 27 76

▪ Switches from standard mode to page mode.

Rev. 1.00

- 18 -

Mobile Printer Command Manual

ESC M n [Name]

[Format]

[Range]

[Default]

[Description]

Select character font./ MSR card read

ASCII ESC M n Hex 1B 4D n Decimal 27 77 n

n = 0, 1, 48, 49 , 67, 68, 69, 70, 71, 72, 73

n=0

▪ Selects only-byte character fonts ▪ Selects Card reader mode

n Function 0, 48 Character font A (12 × 24) selected 1, 49 Character font B (9 × 24) selected

70 Set 1 track card reader mode 71 Set 2 track card reader mode 72 Set 1,2 track card reader mode 73 Transmits the MSR setting value(s) 67 Set 2 track card reader mode 68 Set 3 track card reader mode 69 Set 2,3 track card reader mode 66 Set 1,2,3 track card reader mode 99 Cancel MSR reader mode

Magnetic card read out put format

EM 220

Track 1

02H 41H 31H 31H 1CH DATA 76 characters 03H 0DH 0AH

Track 2

02H 42H 31H 31H 1CH DATA 37 characters 03H 0DH 0AH

Track 1,2

02H 43H 31H 31H 1CH 1CH DATA 76 characters 1CH DATA 37 Characters 03H 0DH 0AH

Track 3

02H 44H 31H 31H 1CH DATA104characters 03H 0DH 0AH

Track 2,3

02H 45H 31H 31H 1CH 1CH DATA 37 characters 1CH DATA104Characters 03H 0DH 0AH

Track 1,2,3

02H 46H 31H 31H 1CH 1CH DATA76

characters

1CH DATA37

characters

1CH DATA104

characters

03H 0DH 0AH

Rev. 1.00

- 19 -

Mobile Printer Command Manual

Transmits the setting value format

Hexadecimal Decimal Amount of Data

Header 37H 55 1 byte

Flag 80H 128 1 byte Data 41H ~ 48H 65 ~ 72 1 bytes NUL 00H 0 1 byte

MSR Setting value

Hex. Function

41 Track 1/2/3 read mode command (3 Track case) 42 Track 1 read mode AUTO trigger (3 Track case) 43 Track 2 read mode AUTO trigger (3 Track case) 44 Track 3 read mode AUTO trigger (3 Track case) 45 Track 1/2 read mode AUTO trigger (3 Track case) 46 Track 2/3 read mode AUTO trigger (3 Track case) 47 Track 1/2/3 read mode AUTO trigger (3 Track case) 48 MSR not used

ESC R n [Name]

[Format]

[Range]

[Default]

[Description]

ESC S [Name]

[Format]

[Description]

Select an international character set.

ASCII ESC R n Hex 1B 52 n Decimal 27 82 n

0 ≤ n ≤ 13

n=0

▪ Selects international character set in from the following table:

n Character set n Character set 0 U.S.A 7 Spain I 1 France 9 Norway 2 Germany 10 Denmark II 3 U.K 4 Denmark I 5 Sweden 6 Italy

Select standard mode.

ASCII ESC S Hex 1B 53 Decimal 27 83

▪ Switches from page mode to standard mode.

EM 220

Rev. 1.00

- 20 -

Mobile Printer Command Manual

ESC T n [Name]

[Format]

[Range]

[Default]

[Description]

Select print direction in page mode.

ASCII ESC T n Hex 1B 54 n Decimal 27 84 n

0 ≤ n ≤ 3, 48 ≤ n ≤ 51

n=o

▪ Selects the print direction and starting position in page mode.

n Print Direction Starting Position 0,48 Left right Upper left 1,49 Bottom to top Lower left 2,50 Right left Lower right 3,51 Top bottom Upper right

EM 220

ESC W xL xH yL yH dxL dxH dyL dyH [Name]

[Format]

[Range]

[Default]

[Description]

Set relative print position.

ASCII ESC W xL xH yL yH dxL dxH dyL dyH Hex 1B 57 xL xH yL yH dxL dxH dyL dyH Decimal 27 87 xL xH yL yH dxL dxH dyL dyH

0 ≤ (xL + xH x 256) ≤ 65535 (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 255) 0 ≤ (yL + yH x 256) ≤ 65535 (0 ≤ yL ≤ 255, 0 ≤ yH ≤ 255) 1 ≤ (dxL + dxH x 256) ≤ 65535 (0 ≤ dxL ≤ 255, 0 ≤ dxH ≤ 255) 1 ≤ (dyL + dyH x 256) ≤ 65535 (0 ≤ dyL ≤ 255, 0 ≤ dyH ≤ 255)

Horizontal logical origin and vertical logical origin = 0

xL=0, xH =0, yL=0, yH=0 dxL = 128, dxH = 1, dyL = 72, dyH = 3

▪ When paper width of 58mm is selected: (xL + xH x 256) = 0 (xL=0, xH=0) (dyL + dyH x 256) = 840 (dyL=72, dyH=3) ▪ Set the position and the size of the printing area.

Horizontal starting position = [(xL + xH x 256) x (horizontal motion units)].

- Vertical starting position = [(yL + yH x 256) x (vertical motion units)].

Horizontal printing area width = [(dxL + dxH x 256) x (horizontal motion units)].

Vertical printing area width = [(dyL + dyH x 256) x (vertical motion units)].

▪ The printer ignores any setting that exceeds the print area.

Rev. 1.00

- 21 -

Mobile Printer Command Manual

ESC ＼ nL nH [Name]

[Format]

[Range]

[Description]

ESC a n [Name]

[Format]

[Range]

[Default]

[Description]

ESC d n [Name]

[Format]

[Range]

[Description]

EM 220

Set relative print position.

ASCII ESC Hex 1B 5C nL nH

Decimal 27 92 nL nH

0 ≤ (nL + nH x 256) ≤ 65535 (0 ≤ nL 255, 0 ≤ nH ≤ 255)

▪ Set the print starting position based on the current position to [(nL + nH ×

256) × horizontal or vertical motion unit]

- When (nL + nH × 256 is a positive number, the print starting position is specified to the right based on the current position.

- When (nL + nH × 256) is a negative number, the print starting position is specified to the left based on the current position.

▪ The printer ignores any setting that exceeds the print area.

Select justification.

ASCII ESC a n Hex 1B 61 n Decimal 27 97 n

0 ≤ n ≤2, 48 ≤ n ≤50

n=0

▪ In standard mode, aligns all the data in one line to the position specified

by n as follows:

n Justification 0, 48 Left justification 1, 49 Centering 2, 50 Right justification

Print and feed n lines.

ASCII ESC d n Hex 1B 64 n Decimal 27 100 n

0 ≤ n ≤ 255

▪ Prints the data in the print buffer and feeds n lines.

＼

nL nH

Rev. 1.00

- 22 -

Mobile Printer Command Manual

)

ESC t n [Name]

[Format]

[Range]

[Default]

[Description]

EM 220

Select character code table.

ASCII ESC t n Hex 1B 74 n Decimal 27 116 n

0 ≤ n ≤ 5, 16 ≤ n ≤ 19, 21 ≤ n ≤ 24, 27 ≤ n ≤ 29, n=21, n=33, 36 ≤ n ≤37 n=255

n=0

For model without Thai character support: n=0 ▪ Selects a page n from the character code table.

n Page STD Other 0 Page 0 437 (USA, Standard Europe 1 Page 1 Katakana ○ ○ 2 Page 2 850 (Multilingual 3 Page 3 860 (Portuguese 4 Page 4 863 (Canadian-French

5 Page 5 865 (Nordic 16 Page 16 1252 (Latin I 17 Page 17 866 (Cyrillic #2 18 Page 18 852 (Latin 2 19 Page 19 858 (Euro 21 Page 21 862 (Hebrew DOS code 22 Page 22 864 (Arabic 23 Page 23 Thai42 ○ ○ 24 Page 24 1253 (Greek 25 Page 25 1254 (Turkish 26 Page 26 1257 (Baltic 27 Page 27 Farsi ○ ○ 28 Page 28 1251 (Cyrillic 29 Page 29 737 (Greek 30 Page 30 775 (Baltic 31 Page 31 Thai14 ○ ○ 33 Page 33 1255 (Hebrew New code 34 Page 34 Thai 11 ○ 35 Page 35 Thai 18 ○ 36 Page 36 855 (Cyrillic 37 Page 37 857 (Turkish 38 Page 38 928 (Greek 39 Page 39 Thai 16 ○ 40 Page 40 1256 (Arabic

- Character codes support all the above listed code pages in the STD version,

and in all remaining versions, only the character codes displayed in Other are supported.

○ ○

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

○ ○ ○

○ ○

○

○ ○ ○ ○

○

○ ○

○ ○ ○ ○

○

Ｘ

ＸＸ

Ｘ

ＸＸ

ＸＸＸ

Rev. 1.00

- 23 -

Mobile Printer Command Manual

ESC { n [Name]

[Format]

[Range]

[Default]

[Description]

EM 220

Turns upside-down printing mode on/off.

ASCII ESC { n Hex 1B 7B n Decimal 27 123 n

0 ≤ n ≤ 255

n=0

▪ Turns upside-down printing mode on or off.

- When the LSB of n is 0, upside-down printing mode is turned off.

- When the LSB of n is 1, upside-down printing mode is turned on.

▪ The upside-down print mode has no effect in page mode. If this command

is processed in page mode, upside-down printing mode is enabled when the printer returns to standard mode.

▪ When upside-down print mode is turned on, the printer prints 180°

rotated characters from right to left.

Rev. 1.00

- 24 -

Mobile Printer Command Manual

GS ! n [Name]

[Format]

[Range]

[Default]

[Description]

EM 220

Select character size.

ASCII GS ! n Hex 1D 21 n Decimal 29 33 n

0 ≤ n ≤ 255 (where 1 ≤ Enlargement in vertical direction ≤ 8, 1 ≤ Enlargement in horizontal direction ≤ 8)

n=0

▪ Selects character size (enlargement in vertical and horizontal directions).

Bit Function Setting

0 1 2 3 4 5 6 7

- Table 1 [Enlarged in horizontal direction] Hex Decimal Enlargement

00 0 1 time (standard) 10 16 2 times 20 32 3 times 30 48 4 times 40 64 5 times 50 80 6 times 60 96 7 times 70 112 8 times

- Table 2 [Enlarged in vertical direction] Hex Decimal Enlargement

00 0 1 time (standard) 01 1 2 times 02 2 3 times 03 3 4 times 04 4 5 times 05 5 6 times 06 6 7 times 07 7 8 times

Specifies the number of times enlarged in the vertical direction

Specifies the number of times enlarged in the horizontal direction

Refer to Table 2 [Enlarged in vertical direction]

Refer to Table 1 [Enlarged in horizontal direction]

Rev. 1.00

- 25 -

Mobile Printer Command Manual

GS $ nL nH [Name]

[Format]

[Range]

[Description]

GS ( A pL pH n m [Name]

[Format]

[Range]

[Description]

[Notes]

Set absolute vertical print position in page mode.

ASCII GS $ nL nH Hex 1D 24 nL nH Decimal 29 36 nL nH

0 ≤ (nL + nH x 256) ≤ 65535 (0 ≤ nL ≤ 255, 0 ≤ nH ≤ 255)

▪ Sets the absolute vertical print starting position to [(nL + nH × 256) ×

(vertical or horizontal motion units)].

Execute test print.

ASCII GS ( A pL pH n m Hex 1D 28 41 pL pH n m Decimal 29 40 65 pL pH n m

(pL + pH x 256) = 2 (pL=2, pH=0) 0 ≤ n ≤ 2, 48 ≤ n ≤ 50 1 ≤ m ≤ 3, 49 ≤ m ≤ 51

▪ Executes a test print with a specified test pattern on a specified paper

type (roll paper).

- n specifies the paper type as listed below to be tested:

0, 48 1, 49 2, 50

- m specifies a test pattern as listed below:

1, 49 Hexadecimal dump 2, 50 Self Test Printing 3, 51 Self Test rolling pattern

▪ If this command is processed while a macro is being defined, the printer

cancels macro definition and starts processing this command. At that time, the macro becomes undefined.

▪ After processing this command, the printer performs a software reset.

EM 220

m Paper type

Paper roll

m Test pattern

Rev. 1.00

- 26 -

Mobile Printer Command Manual

EM 220

BS ^ E pL pH fn [parameter] [Name]

[Description]

fn Format No. Function

1 BS ^ E pL pH fn 1 Changes into the user setting mode.

2 BS ^ E pL pH fn 2

4 BS ^ E pL pH fn a 4

11 BS ^ E pL pH fn d1...dk 11

12 BS ^ E pL pH fn a 12

[Notes] ▪ pL, pH specifies (pL + pH x 256) the number of bytes after pH (fn and

BS ^ E pL pH fn [b18...b11]...

Customize NV memory area.

▪ Customize the NV user memory area. The table below explains the

functions available in this command. Executes commands related to the user setting mode by specifying the function code fn.

Ends the user setting mode session.

(Performs a soft reset.)

[bk8...bk1]

[parameter]).

▪ The user setting mode is a special mode to change the values in the NV

user memory with this command.

▪ In Function 2, the printer performs software reset. Therefore, the printer

clears the receive and print buffers, and resets all settings (user-defined characters, macros, and the character style) to the mode in effect at power on.

▪ Frequent write commands by this command, may damage the NV memory.

Therefore, it is recommended to write to NV memory no more than 10 times a day.

▪ While processing this command, the printer is BUSY when writing data to

the user NV memory and stops receiving data. Therefore, it is prohibited to transmit data including real-time commands during the execution of this command.

3 Sets value(s) for the memory switch.

Transmits the settings of the memory

switch to the host.

Sets the communication conditions for the

serial interface.

Transmits the communication conditions for

the serial interface.

Rev. 1.00

- 27 -

Mobile Printer Command Manual

<Function 1> BS ^ E pL pH fn (fn=1) [Format]

[Range]

[Description]

<Function 2> BS ^ E pL pH fn d1 d2 d3 (fn=2) [Format]

[Range]

[Description]

ASCII BS ^ E pL pH fn Hex 08 5E 45 pL pH fn Decimal 08 94 69 pL pH fn

(pL + pH x 256) = 1 (pL=1, pH=0) fn=1

▪ Enter the user setting mode and notifies that the mode has changed.

Hexadecimal Decimal Number of Data

Header 37H 55 1 byte

Flag 20H 32 1 byte

NUL 00H 0 1 byte ▪ The following commands are enabled in the user setting mode. <Function 2> through

ASCII GS ( E pL pH fn Hex 1D 28 45 pL pH fn Decimal 29 40 69 pL pH fn

(pL + pH x 256) = 1 (pL=1, pH=0) fn=2

▪ Ends the user setting mode and performs a software reset. Therefore, the

printer clears the receive and print buffers, and resets all (downloaded bit images, macros, and the print mode) to the mode that was in effect at power on.

▪ This function code (fn=2) is enabled only in the user setting mode.

EM 220

Rev. 1.00

- 28 -

Mobile Printer Command Manual

<Function 3> BS ^ E pL pH fn [b18...b11]...[ bk8...bk1] (fn=3) [Format]

[Range]

[Default]

[Description]

▪ b1 value is set the memory switch 1 as follows:

ASCII BS ^ E pL pH fn Hex 08 5E 45 pL pH fn Decimal 08 94 69 pL pH fn

9≤ (pL + pH x 256) ≤ 65535 fn=3 b=48, 49, 50

▪ All switches are set to Off (b=48). ▪Changes all the Memory Switch 1~8 to the value specified by b at a time.

- When b=48, the applicable bit is turned to Off.

- When b=49, the applicable bit is turned to On.

- When b=50, the applicable bit is not changed.

EM 220

[b18...b11]... [bk8...bk1] [b18...b11]... [bk8...bk1] [b18...b11]... [bk8...bk1]

Msw

1-1~3

1-4

1-5

1-6 48 not used

Set Value

Function

3 2 1

48 48 48 print density 130% 48 48 49 print density 120%

48 49 48 print density 110% 48 49 49 print density 150%

49 48 48 print density 100% 49 48 49 print density 140%

49 49 48 print density 90% 49 49 49 print density 80%

48 2 byte character mode not selected 49 2 byte character mode selected

48 print speed 80mm/s 49 print speed 50mm/s

Rev. 1.00

▪ b2 value is set the memory switch 2 as follows:

Msw

2-1 48 not used

2-2 48 not used

2-3 48 not used

Set Value Function

- 29 -

Mobile Printer Command Manual

EM 220

▪ Code Page Settings

Msw2-8 Msw2-7 Msw2-6 Msw2-5 Msw2-4

48 48 48 48 48 PC437 ○ ○ 48 48 48 48 49 Katakana ○ ○ 48 48 48 49 48 PC850 ○ ○ 48 48 48 49 49 PC860 ○ ○ 48 48 49 48 48 PC863 ○ ○ 48 48 49 48 49 PC865 ○ ○ 48 48 49 49 48 WPC1252 ○ ○ 48 48 49 49 49 PC866 ○ ○ 48 49 48 48 48 PC852 ○ ○ 48 49 48 48 49 PC858 ○ ○ 48 49 48 49 48 PC862 ○ × 48 49 48 49 49 PC864 ○ ○ 48 49 49 48 48 Thai42 ○ ○ 48 49 49 48 49 WPC1253 ○ ○ 48 49 49 49 48 WPC1254 ○ × 48 49 49 49 49 WPC1257 ○ × 49 48 48 48 48 Farsi ○ ○ 49 48 48 48 49 WPC1251 ○ ○ 49 48 48 49 48 PC737 ○ ○ 49 48 48 49 49 PC775 ○ × 49 48 49 48 48 Thai 14 ○ ○ 49 48 49 48 49 not used ○ ○ 49 48 49 49 48 WPC1255 ○ ○ 49 48 49 49 49 Thai 11 ○ × 49 49 48 48 48 Thai 18 ○ × 49 49 48 48 49 PC855 ○ ○ 49 49 48 49 48 PC857 ○ ○ 49 49 48 49 49 PC928 ○ × 49 49 49 48 48 Thai 16 ○ × 49 49 49 48 49 WPC1256 ○ × 49 49 49 49 48 not used 49 49 49 49 49 not used

For versions other than the STD version, only code pages displayed in

Character

Table

STD Other

Rev. 1.00

Other can be selected.

- 30 -

Mobile Printer Command Manual

EM 220

▪ b3 value is set the memory switch 3 as follows:

Msw Set Value Function

3-1

3-2

3-3

3-4

48 PDF417 not selected

49 PDF417 selected

48 DATAMATRIX not selected

49 DATAMATRIX selected

48 MAXI CODE not selected

49 MAXI CODE selected

48 QR CODE not selected

49 QR CODE selected

▪ b4 value is set the memory switch 5 as follows:

Specify the length of idle time before the printer enters the power-down mode.

When memory switch value is 0, the power-down mode is not active.

MSW5-8 MSW5-7 MSW5-6 MSW5-5 MSW5-4 MSW5-3 MSW5-2 MSW5-1 Value

48 48 48 48 48 48 48 48 0

48 48 48 48 48 48 48 49 1

48 48 48 48 48 48 49 48 2

48 48 48 48 48 48 49 49 3

48 48 48 48 48 49 48 48 4

. . . . . . . .

48 49 48 49 49 48 49 48 90

▪ b5 value is set the memory switch 6 as follows

Minimum = 10 seconds Maximum = 255 seconds

Set the standby time before the printer enters the power saving mode. When memory switch value is 0, the power saving mode does not work.

MSW6-8 MSW6-7 MSW6-6 MSW6-5 MSW6-4 MSW6-3 MSW6-2 MSW6-1 Value

48 48 48 48 49 48 49 48 10

48 48 48 48 49 48 49 49 11

48 48 48 48 49 49 48 48 12

48 48 48 48 49 49 48 49 13

Rev. 1.00

48 48 48 48 49 49 49 48 14

. . . . . . . .

49 49 49 49 49 49 49 49 255

- 31 -

Mobile Printer Command Manual

▪ b6 value is set the memory switch 7 as follows:

MSW 8 7 6 5 Function

48 48 48 49 Track 1/2/3 read mode command

48 48 49 48 Track 1 read mode AUTO trigger

48 48 49 49 Track 2 read mode AUTO trigger

EM 220

7-5~8

48 49 48 48 Track 3 read mode AUTO trigger

48 49 48 49 Track 1/2 read mode AUTO trigger

48 49 49 48 Track 2/3 read mode AUTO trigger

48 49 49 49 Track 1/2/3 read mode AUTO trigger

49 48 48 48 MSR not used

▪ b7 value is set the memory switch 8 as follows:

Msw Setting Value Function

8-1 48 Reserved

8-2

8-3

8-4

8-5

48 12X24 font

49 9X24 font

48 No beeps for roll paper end

49 Beeps for roll paper end

48 Beeps for low battery status

49 No beeps low battery status

48 Label function deactivated

49 Label function activated

8-6 48 Reserved

8-7 48 Reserved

8-8 48 Reserved

Rev. 1.00

- 32 -

Mobile Printer Command Manual

<Function 4> BS ^ E pL pH fn a (fn=4) [Format]

[Range]

[Description]

ASCII BS ( E pL pH fn a Hex 08 5E 45 pL pH fn a Decimal 08 94 69 pL pH fn a

(pL + pH x 256) = 2 (pL=2, pH=0) fn=4 a=1, 2, 3, 5, 6, 7, 8

▪ Transmits the setting value(s) of the memory switch specified by a.

Hexadecimal Decimal Amount of Data

Header 37H 55 1 byte

Flag 21H 33 1 byte Data 30H or 31H 48 or 49 8 bytes NUL 00H 0 1 byte

▪ Data for the setting is transmitted as 8 bytes or a data string in the order

from bit 8 to bit 1, as follows:

- Off : Hexadecimal = 30H / Decimal = 48

- On : Hexadecimal = 31H / Decimal = 49

<Function 11>BS ^ E pL pH fn a d1….dk (fn=11) [Format]

[Range]

[Default]

[Description]

ASCII BS ^ E pL pH fn d1 dk Hex 08 5E 45 pL pH 0B d1 dk Decimal 08 94 69 pL pH 11 d1 dk

8<=(pL + pH x 256) <=10 (8<=pL<=10,0<= pH<=255) fn=11, 48<=d<=57 7<=k<=9

Baud rate: 115200, Parity: 48, Flow control: 48, Data length: 56

When (pL+pH x256) =10 d1~d6 is Baud rate value d7 is parity setting value d8 is Flow control setting value d9 is Data length setting value

When (pL+pH x256) =9 d1~d5 is Baud rate value d6 is parity setting value d7 is Flow control setting value d8 is Data length setting value

When (pL+pH x256) =8 d1~d4 is Baud rate value d5 is parity setting value d6 is Flow control setting value d7 is Data length setting value

EM 220

Rev. 1.00

- 33 -

Mobile Printer Command Manual

EM 220

Sets the configuration item for the serial interface specified by d1..dk

Setting Oder Configuration item

1 Transmission speed 2 Parity 3 Flow control 4 Data length

Example : When defining 19200 bps and Noparity, DTR/DSR, 8bit Data length : d1~dk(Hexadecimal = 32H,30H,30H,30H,30H,38H /Decimal= 49,57,50,48,48,48,48,56) Baud rate is specified by d1~dk-3 as follows:

d1~dk-3 Function

“115200” Baud rate 115200

“57600” Baud rate 57600 “38400” Baud rate 38400 “19200” Baud rate 19200

“9600” Baud rate 9600 “4800” Baud rate 4800 “2400” Baud rate 2400

Parity is specified by dk-2 as follows:

dk-2 Function

48 Select no parity 49 Select odd parity 50 Select even parity

Flow control is specified by dk-1 as follows:

dk-1 Function

48 Select Flow control DTR/DSR 49 Select Flow control XON/XOFF

Data Length(a=4) is specified by dk as follows:

dk Function 55 Select 7bit length 56 Select 8bit length

Rev. 1.00

- 34 -

Mobile Printer Command Manual

<Function 12> BS ^ E pL pH fn a (fn=12) [Format]

[Range]

[Description]

ASCII BS ^ E pL pH fn a Hex 08 5E 45 pL pH fn a Decimal 08 94 69 pL pH fn a

(pL + pH x 256) = 2 (pL=2, pH=0) fn=12, 1 ≤ a ≤ 4

▪

Transmits the communication conditions of the serial interface specified by a.

a Communication Condition 1 Baud rate 2 Parity 3 Flow control 4 Data length

Hexadecimal Decimal Amount of Data

Header 37H 55 1 byte

Flag 33H 39 1 byte

Type of communication

condition

Separator 1FH 31 1 byte

Setting value 30H - 39H 48 - 57 1 - 6 bytes

NUL 00H 0 1 byte

▪ Configuration of the setting value

- When the baud rate (a=1) is specified: Baud rate (bps) d1 d2 d3 d4 d5 d6

2400 50 52 48 48 -- -4800 52 56 48 48 -- --

9600 57 54 48 48 -- -19200 49 57 50 48 48 -38400 51 56 52 48 48 -57600 53 55 54 48 48 --

115200 49 49 53 50 48 48

▪ When the parity setting (a=2) is specified:

d1 Parity 48 No parity 49 Odd parity 50 Even parity

- When the flow control setting (a=3) is specified: d1 Flow control 48 DTR / DSR (Fixed) 49 XON / XOFF

- When the data length setting (a=4) is specified: d1 Data length 55 7 bits 56 8 bits

▪

If a is out of range, this command ignores the value which is specified with a.

EM 220

31H - 34H 49 - 52 1 byte

Rev. 1.00

- 35 -

Mobile Printer Command Manual

EM 220

BS ^ L pL pH fn [parameter], BS ^ 7 p1 p2 p3 p4 fn [parameter] [Name]

[Format]

[Description]

fn Format Function No. Function

2, 50 BS ^ L pL pH fn Function 50

65 BS ^ L pL pH fn Function 65

66 BS ^ L pL pH fn c Function 66

BS ^ 7 p1 p2 p3 p4 fn N {b

d1...dk]1}...{ b xL xH yL yH

69 BS ^ L pL pH fn c x y Function 69

112

BS ^ L pL pH fn a bx by c

▪ pL, pH specifies (pL + pH x 256) the number of bytes after pH(m, fn, and

<Function 50> BS ^ L pL pH fn (fn=2, 50) [Format]

[Range]

[Description]

Select graphics data.

ASCII BS ^ L pL pH fn [parameter] Hex 08 5E 4C pL pH fn [parameter] Decimal 08 94 76 pL pH fn [parameter]

ASCII BS ^ 7 p1 p2 p3 p4 fn [parameter] Hex 08 5E 37 p1 p2 p3 p4 fn [parameter] Decimal 08 94 55 p1 p2 p3 p4 fn [parameter]

▪ In the description below, BS ^ L is used for the explanation. ▪ Processes graphics data according to the function code fn.

Prints the graphics data in the print

buffer.

Deletes all NV graphics data.

Deletes the specified NV graphics

data.

xL xH yL yH [c

Function 67

Defines the graphics data in the non-

volatile memory.

[c d1 dk]N}

Prints the specified NV graphics data.

Stores the graphics data in the print

buffer memory.

xL xH yL yH d1...dk

Function 112

[parameter]).

▪ Frequent write command executions may damage the NV memory.

Therefore, it is recommended to write to the NV memory no more than 10 times a day.

▪ While processing this command, the printer is BUSY writing data to the

NV graphics memory and stops receiving data. Therefore, it is prohibited to transmit data including the real-time commands during the execution of this command.

ASCII BS ^ L pL pH fn Hex 08 5E 4C pL pH fn Decimal 08 94 76 pL pH fn

(pL + pH x 256) = 1 (pL=2, pH=0) m=48, fn=2, 50

▪

Prints the buffer graphics that are stored by the process of Function 112.

▪ Feeds paper by the amount corresponding to the number of dots in the y

direction of the buffered graphics.

Rev. 1.00

- 36 -

Mobile Printer Command Manual

<Function 65> BS ^ L pL pH fn (fn=65) [Format]

[Range]

[Description]

<Function 66> BS ^ L pL pH fn c (fn=66) [Format]

[Range]

[Description]

ASCII BS ^ L pL pH fn Hex 08 5E 4C pL pH fn Decimal 08 94 76 pL pH fn

(pL + pH x 256) = 1 (pL=1, pH=0) fn=65

▪ Deletes all defined NV graphics data.

ASCII BS ^ L pL pH fn c Hex 08 5E 4C pL pH fn c Decimal 08 94 76 pL pH fn c

(pL + pH x 256) = 2 (pL=2, pH=0)

fn=66

0 ≤ c ≤ 77

▪ Deletes the NV graphics data defined by the key codes c

EM 220

<Function 67> [Format]

[Range]

[Description]

BS ^ 7 p1 p2 p3 p4 fn N {b xL xH yL yH [c d1...dk]1}...{b xL xH yL yH [c d1...dk]N}(fn=67)

ASCII BS ^ 7

Hex 08 5E 37

Decimal 08 94 55

▪ BS ^ 7 parameter 3 ≤ (p1 + p2 x 256+p3 x 65536 + p4 x 16777216) ≤ 262144 (0 ≤ p1 ≤ 255, 0 ≤ p2 ≤ 255, 0 ≤ p3 ≤ 255, 0 ≤ p4 ≤ 255)

fn=67 1 ≤ c ≤ 255 b=1 1 ≤ (xL + xH x 256) ≤ 1024 1 ≤ (yL + yH x 256) ≤ 1200 c=49

0 ≤ d ≤ 255 k = ( int ( ( xL + xH x 256 ) + 7 ) / 8 ) x ( yL + yH x 256 ) 0 ≤ N ≤ 77

▪ The total capacity of the NV graphic memory is only 256K bytes ▪ Defines the raster graphics data in the NV graphics area.

- b specifies the number of the color of the defined data.

- N specifies the number of the NV graphics data.

- xL, xH specifies the defined data in the horizontal direction to (xL + xH x

256) dots.

P1 p2 p3 p4 fn N {b xL xH yL yH [c d1...dk]1} ...{b xL xH yL yH [c d1...dk]N} P1 p2 p3 p4 fn N {b xL xH yL yH [c d1...dk]1}

...{b xL xH yL yH [c d1...dk]N}

P1 p2 p3 p4 fn N {b xL xH yL yH [c d1...dk]1}

...{b xL xH yL yH [c d1...dk]N}

Rev. 1.00

- 37 -

Mobile Printer Command Manual

[Notes]

<Function 69> BS ^ L pL pH fn c x y (fn=69) [Format]

[Range]

[Description]

<Function 112> BS ^ L pL pH fn a bx by c xL xH yL yH d1...dk (fn=112) [Format]

[Range]

[Description]

[Notes]

- yL, yH specifies the defined data in the vertical direction to (yL + yH x

256) dots.

- c specifies the color of the defined data.

C Defined data color

49 Color 1

- Color 1 means black

- When NV graphics data is saved, existing data in NV memory is

removed and updated with new one.

- When NV graphics data are saved, Key codes are given automatically.

ASCII BS ^ L pL pH fn c x y Hex 08 5E 4C pL pH fn c x y Decimal 08 94 76 pL pH fn c x y

(pL + pH x 256) = 3 (pL=3, pH=0) fn=69 0 ≤ c ≤ 77 x=1, 2 y=1, 2

▪ Prints the NV graphics data defined by the key codes c. The graphics

data is enlarged by x and y in the horizontal and vertical directions.

ASCII BS ^ L pL pH fn a bx by c xL xH yL yH d1...dk Hex 08 5E 4C pL pH fn a bx by c xL xH yL yH d1...dk

Decimal 08 94 76 pL pH fn a bx by c xL xH yL yH d1...dk ▪ BS ^ L parameter 11 ≤ (pL + pH x 256) ≤ 65535 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 255) fn=112, a=48 bx=1, 2 by=1, 2 c=49 1 ≤ (xL + xH x 256) ≤ 1024

1 ≤ (yL + yH x 256) ≤ 1200 (when by = 1)

k = ( int ( ( xL + xH x 256 ) + 7 ) / 8 ) x ( yL + yH x 256 ) ▪ Stores the raster graphics data, enlarged by bx and by in the horizontal

and vertical directions to the print buffer.

- xL, xH specifies the raster graphics data in the horizontal direction

as (xL + xH x 256) dots.

- yL, yH specifies the raster graphics data in the vertical direction to

(yL + yH x 256) dots.

- c specifies the color of the defined data.

c Printing color

49 Color 1

- Color 1 means black

▪ In standard mode, each color can be defined only once.

EM 220

Rev. 1.00

- 38 -

Mobile Printer Command Manual

GS ( k pL pH cn fn [parameter] [Name]

[Description]

Specify and print the symbol.

▪ Processes the data concerning two-dimensional code.

- Symbol type is specified by cn.

- Function is specified by fn. cn Type of Symbol 48 PDF417 (2-dimensional code) 49 QR CODE (2-dimensional code) 50 MAXI CODE(2-dimensional code) 51 DATAMATRIX(2-dimensional code)

cn fn Function

65 Function 065 PDF417 : Specify the number of columns 66 Function 066 PDF417 : Specify the number of rows 67 Function 067 PDF417 : Specify the width of module 68 Function 068 PDF417 : Specify the module height 69 Function 069 PDF417 : Specify the error correction level 70 Function 070 PDF417 : Specify the option

80 Function 080

81 Function 081

EM 220

PDF417 : Store the received data in the symbol

save area

PDF417 : Print the symbol data in the symbol

save area

82 Function 082

65 Function 165 QR CODE: module selection 67 Function 167 QR CODE: module size selection 69 Function 169 QR CODE: error level setting

80 Function 180

81 Function 181

82 Function 182

65 Function 265 MAXI CODE: mode selection

80 Function 280

81 Function 281

67 Function 367 DATAMATRIX: module size selection

80 Function 380

81 Function 381

PDF417 : Send the size information of the

symbol data in the symbol save area

QR CODE: saving of symbol data in storage

area

QR CODE: printing of symbol data saved in

storage area

QR CODE: transmission of size information of

symbol data saved in storage area

MAXI CODE: saving of symbol data in storage

area

MAXI CODE: printing of symbol data saved in

storage area

DATAMATRIX: saving of symbol data in

storage area

DATAMATRIX: printing of symbol data saved in

storage area

Rev. 1.00

- 39 -

Mobile Printer Command Manual

[Notes] For PDF417 symbol data (when cn=48)

▪ The symbol data specified by Function 080 d1...dk is stored in the printer

and is printed by the specification of Function 081. The symbol data in the save area is reserved until the following processing is performed:

- Function 080 is executed

- ESC @ is executed

- The printer is reset or the power is turned off

▪ When processing Function 081 or 082, the setting values of Functions

065 to 070 are used. If the printable area is not large enough, the symbol may not be printed.

▪ Executing Function 081 after executing Function 080 repeatedly prints the

same symbol data.

▪ By using Functions 065 to 070 combined with Function 081, the same

symbol data d1...dk is printed differently.

▪ By using Function 082, the symbol size printed by Function 081 is available.

QRCODE Symbol Data (cn = 49)

▪ Symbol data is saved according to <Function 180> and printed according

to <Function 181>. The symbol data in the storage area is saved until the following actions:

- Execution of Function 180

- Execution of ESC @

- Turn off printer power

▪ When either Function 181 or Function 182 is executed, the setting values

of Functions 165~169 are used. If the printable area is insufficient in size, the symbol data is not printed.

▪ According to the settings of <Function 165> to <Function 169>, <Function

181> has and prints the same data d1….dk.

▪ <Function 182> uses the size printed by <Function 181>.

EM 220

Rev. 1.00

- 40 -

Mobile Printer Command Manual

MAXI CODE Symbol Data (cn = 50)

▪ Symbol data is saved according to <Function 280> and printed according

to <Function 281>. The symbol data in the storage area is saved until the following actions:

- Execution of Function 280

- Execution of ESC @

- Turn off printer power

▪ When either <Function 281> or <Function 282> is executed, the setting

value of <Function 265> is used.

DATAMATRIX Symbol Data (cn=51)

▪ Symbol data is saved according to <Function 380> and printed according

to <Function 381>. The symbol data in the storage area is saved until the following actions:

- Execution of Function 380

- Execution of ESC @

- Turn off printer power

▪ When <Function 381> is executed, the setting value of <Function 367> is

used.

EM 220

Rev. 1.00

- 41 -

Mobile Printer Command Manual

<Function 065> GS ( k pL pH cn fn n (fn=65) [Format]

[Range]

[Default]

[Description]

[Notes]

<Function 066> GS ( k pL pH cn fn n (fn=66) [Format]

[Range]

[Default]

[Description]

[Notes]

ASCII GS ( k pL pH cn fn n Hex 1D 28 6B 03 00 30 41 n Decimal 29 40 107 3 0 48 65 n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=48, fn=65 0 ≤ n ≤ 30

n=0

Specifies the number of columns of the data area of PDF417.

- n=0 specifies auto processing

- When n is not 0, specifies the number of columns of the data area as n code word.

▪ Settings of this function affect the processing of Functions 081 and 082. ▪ When auto processing (n=0) is specified, the maximum number of

columns in the data area is 30 columns.

▪ The following data is not included in the number of columns :

- Start pattern and stop pattern

- Indicator code word of left and right ▪ When auto processing (n=0) is specified, the number of columns is

calculated by the printing area when processing Functions 081, 082, module width (Function 067), and option setting (Function 070).

▪ This function is effective until ESC @ is executed, the printer is reset, or

the power is turned off.

ASCII GS ( k pL pH cn fn n Hex 1D 28 6B 03 00 30 42 n Decimal 29 40 107 3 0 48 66 n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=48, fn=66 n=0, 3 ≤ n ≤ 90

n=0

Specifies the number of rows of data area of PDF417.

- n=0 specifies auto processing

- When n is not 0, specifies the number of rows of the symbol as n rows. ▪ Settings of this function effect the processing of Functions 081 and 082.

When auto processing (n=0) is specified, the maximum number of rows is 90.

▪ ▪ When auto processing (n=0) is specified, the number of rows is calculated

by the printing area when processing Functions 081, 082, module height

(Function 068). ▪ This function is effective until ESC @ is executed, the printer is reset, or the power is turned off.

EM 220

Rev. 1.00

- 42 -

Mobile Printer Command Manual

<Function 067> GS ( k pL pH cn fn n (fn=67) [Format]

[Range]

[Default]

[Description]

[Notes]

<Function 068> GS ( k pL pH cn fn n (fn=68) [Format]

[Range]

[Default]

[Description]

[Notes]

ASCII GS ( k pL pH cn fn n

Hex 1D 28 6B 03 00 30 43 n

Decimal 29 40 107 3 0 48 67 n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=48 fn=67 2 ≤ n ≤ 3

n=3

Specifies the width of a module of PDF417 symbol.

▪ Settings of this function affect the processing of Functions 081 and 082. ▪ The setting unit differs, depending on the printer models. ▪ This function is effective until ESC @ is executed, the printer is reset, or

the power is turned off.

ASCII GS ( k pL pH cn fn n

Hex 1D 28 6B 03 00 30 44 n

Decimal 29 40 107 3 0 48 68 n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=48 fn=68 2 ≤ n ≤ 8

n=3

Specifies the module height of PDF417 symbol.

- Specify the height to [a module width x n].

▪ Settings of this function affect the processing of Functions 081 and 082. ▪ This function is effective until ESC @ is executed, the printer is reset, or

the power is turned off.

EM 220

Rev. 1.00

- 43 -

Mobile Printer Command Manual

<Function 069> GS ( k pL pH cn fn m n (fn=69) [Format]

[Range]

[Default] [Description]

[Notes]

<Function 070> GS ( k pL pH cn fn m (fn=70) [Format]

[Range]

[Default] [Description]

[Notes]

ASCII GS ( k pL pH Cn fn m n

Hex 1D 28 6B 04 00 30 45 m n

Decimal 29 40 107 4 0 48 69 m n (pL + pH x 256) = 4 (pL=4, pH=0) cn=48 fn=69 m=48 48 ≤ n ≤ 8 [m=48] n=1 Specifies the error correction level of PDF417.

M Function

48 The error correction level is specified by “level”

▪ Settings of this function affect the processing of Functions 081 and 082. ▪ Error correction level is specified by “level”. ▪ Error correction level specified by “level” (m=48) is as follows:

The number of the error correction code word is fixed regardless of the

number of code words in the data area.

M Function Number of error correction code word 48 Error correction level 0 2 49 Error correction level 1 4 50 Error correction level 2 8 51 Error correction level 3 16 52 Error correction level 4 32 53 Error correction level 5 64 54 Error correction level 6 128 55 Error correction level 7 256 56 Error correction level 8 512

ASCII GS ( k pL pH cn fn m Hex 1D 28 6B 03 00 30 46 m

Decimal 29 40 107 3 0 48 70 m (pL + pH x 256) = 3 (pL=3, pH=0) cn=48 fn=70 m=0,1 m=0 Set or cancels the option of PDF417.

M Function

0 Cancels the processing of simplified PDF417 symbol. 1 Sets the processing of simplified PDF417 symbol.

- m=0 cancels the processing of simplified PDF417 symbol.

- m=1 sets the processing of simplified PDF417 symbol.

▪ Settings of this function affect the processing of Functions 081 and 082. ▪ When simplified PDF417 symbol is canceled, standard PDF417 symbol is

automatically selected. ▪ This function is effective until ESC @ is executed, the printer is reset, or

the power is turned off.

EM 220

Rev. 1.00

- 44 -

Mobile Printer Command Manual

<Function 080> GS ( k pL pH cn fn m d1...dk (fn=80) [Format]

[Range]

[Description] [Notes]

<Function 081> GS ( k pL pH cn fn m (fn=81) [Format]

[Range]

[Description] [Notes]

ASCII GS ( k pL pH cn fn m d1...dk

Hex 1D 28 6B pL pH 30 50 30 d1...dk

Decimal 29 40 107 pL pH 48 80 48 d1...dk 4 ≤ (pL + pH x 256) ≤ 65535 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 255) cn=48 fn=80 m=48 0 ≤ d ≤ 255 k = (pL + pH x 256) - 3 Stores the PDF417 symbol data (d1...dk) in the symbol save area. ▪ Data stored in the symbol save area by this function are processed by

Function 081 and 082. The data in the symbol save area are reserved

after processing Function 081 or 082.

▪ k bytes of d1...dk are processed as symbol data. ▪ Specify only the data code word of the symbol with this function. Do not

include the following data in the data d1..dk as this information is

automatically added by the printer:

- Start pattern and stop pattern.

- Indicator code word of left and right.

- The descriptor of symbol length. (the first code word in the data area)

- The error correction code word calculated by modulus 929. ▪ This function is effective until the following processing is performed:

- Function 080 or 180 is executed.

- ESC @ is executed.

- The printer is reset or the power is turned off.

ASCII GS ( k pL pH cn fn m

Hex 1D 28 6B 03 00 30 51 m

Decimal 29 40 107 3 0 48 81 m (pL + pH x 256) = 3 (pL=3, pH=0) cn=48 fn=81 m=48 Encodes and prints the PDF417 symbol data in the symbol save area. ▪ In standard mode, use this function when printer is “at the beginning of a

line,” or “there is no data in the printer buffer.”

▪ A symbol with a size that exceeds the printing area can not be printed. ▪ If there is any error described below in the data of the symbol save area, it

cannot be printed.

- There is no data (Function 080 is not processed).

- If [(number of columns x number of rows) < number of code word] when

auto processing is specified for number of columns and number of rows.

- Number of code word exceeds 928 in the data area.

EM 220

Rev. 1.00

- 45 -

Mobile Printer Command Manual

EM 220

▪ The following data is added automatically by the encode processing:

- Start pattern and stop pattern.

- Indicator code word of left and right.

- The descriptor of symbol length. (the first code word in the data area)

- The error correction code word calculated by modulus 929.

- Pad codeword. ▪ The data area includes the following code words:

- Data specified by Function 080.

- The descriptor of symbol length. (the first code word in the data area)

- The error correction code word calculated by modulus 929.

- Pad codeword. ▪ When auto processing (Function 065) is specified, the number of

columns is calculated by the current printing area, module width (Function

067), option setting (Function 070), and the code word in the data area.

The maximum number of columns is 30. ▪ When auto processing (Function 066) is specified in page mode, the

number of rows is calculated by the current printing area, module height

(Function 068), and the code word in the data area. The maximum number

of rows is 90. ▪ Printing of symbol is not affected by print mode (emphasized, double-

strike, underline, white/black reverse printing, or 90˚ clockwise-rotated),

except for character size and upside-down printing mode. ▪ In standard mode, this command executes paper feeding for the amount

needed for printing the symbol, regardless of the paper feed amount set by

the paper feed setting command. The printing position returns to the left

side of the printable area after printing the symbol, and printer is in the

status “beginning of the line,” or “ there is no data in the print buffer.” ▪ In page mode, the printer stores the symbol data in the print buffer without

executing actual printing. The printer moves printing position to the next

dot of the last data of the symbol. ▪ The quiet zone is not included in the printing data. Be sure to include the

quiet zone when using this function.

Rev. 1.00

- 46 -

Mobile Printer Command Manual

<Function 082> GS ( k pL pH cn fn m (fn=82) [Format]

[Range]

[Description]

[Notes]

ASCII GS ( k pL pH cn fn m

Hex 1D 28 6B 03 00 30 52 m

Decimal 29 40 107 3 0 48 82 m

(pL + pH x 256) = 3 (pL=3, pH=0) cn=48 fn=82 m=48

Encodes and sends size information of the PDF417 symbol data in the symbol save area.

▪ In standard mode, use this function when the printer is “at the beginning of

a line,” or “there is no data in the printer buffer.”

▪ The size information for each data is as follows:

Send data Hex Decimal Data

Header 37H 55 1 byte

Flag 2FH 47 1 byte

Width 30H – 39H 48 – 57 1 – 5 byte

Separator 1FH 31 1 byte

Height 30H – 39H 48 – 57 1 – 5 byte

Separator 1FH 31 1 byte

Fixed value 31H 49 1 byte

Separator 1FH 31 1 byte

Other information 30H or 31H 48 or 49 1 byte

NUL 00H 0 1 byte

▪ Description of the width and height of the data sent:

- The height and width values of the symbol data are in dot units.

▪ Description of the other information data sent:

Hex Decimal Condition 30H 48 Printing is possible 31H 49 Printing is impossible

▪ This command does not print the PDF417 symbols.

▪ Users must consider the quiet zone for the PDF417 symbols (upward and

downward spaces and left and right spaces for the PDF417 symbols specified in the specifications for the PDF417 symbols.)

EM 220

Rev. 1.00

- 47 -

Mobile Printer Command Manual

<Function 165> GS ( k pL pH cn fn n1 n2 (fn=65) [Format]

[Range]

[Defaults]

[Description]

[Notes]

<Function 167> GS ( k pL pH cn n (fn=67) [Format]

[Range]

[Default]

[Description]

ASCII GS ( k pL pH cn fn n1 n2 Hex 1D 28 6B 04 00 31 41 n1 0 Decimal 29 40 107 3 0 49 65 n1 0

(pL + pH x 256) = 3 (pL=3, pH=0) cn=49 fn=65 n1 = 49, 50 n2 =0 n1=50, n2 =0

Sets the QR code model

N1 Function

49 Model 1 50 Model 2

▪ The setting of this function impacts <Function 181> and <Function 182>. ▪ This function is effective until ESC @ is executed or the printer power is

turned off.

ASCII GS ( k pL pH cn fn n Hex 1D 28 6B 03 00 31 43 n Decimal 29 40 107 3 0 49 67 n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=49 fn=67 0<=n<9

n=3

Sets the size of the QR code module

▪ It impacts the execution of <Function 181> and <Function 182>. ▪ This function is effective until ESC @ is executed or the printer power is

turned off. ▪ n becomes the value for the module width and height. (The QR CODE module is square-shaped.)

EM 220

Rev. 1.00

- 48 -

Mobile Printer Command Manual

<Function 169> GS ( k pL pH cn n (fn=69) [Format]

[Range]

[Default]

[Description]

ASCII GS ( k pL pH cn fn n Hex 1D 28 6B 03 00 31 45 n Decimal 29 40 107 3 0 49 69 n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=49 fn=69 48≤n≤51

n=48

Sets the error correction level of the QR code

N Function Recovery Amount (%) 48 Error Correction Level L 7 49 Error Correction Level M 15 50 Error Correction Level Q 25 51 Error Correction Level H 30

▪ The setting of this function impacts the execution of <Function 181> and

<Function 182>.

▪ This function is effective until ESC @ is executed or the printer power is

turned off.

▪ For correction with regard to the continuous error correction of the QR

code, the Reed-Solomon correction method is used.

EM 220

Rev. 1.00

- 49 -

Mobile Printer Command Manual

<Function 180> GS ( k pL pH cn fn m d1...dk (fn=80) [Format]

[Range]

[Description] [Notes]

ASCII GS ( k pL pH cn fn m d1...dk Hex 1D 28 6B pL pH 31 50 30 d1...dk

Decimal 29 40 107 pL pH 49 80 48 d1...dk 4 ≤ (pL + pH x 256) ≤7092 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 27) cn=49 fn=80 m=48 0 ≤ d ≤ 255 k = (pL + pH x 256) - 3 Saves symbol data of the QR CODE to the symbol storage area ▪ Execution of this command saves data to the data storage area and

executes Functions 181 and 182. Following execution of Functions 181

and 182, the data remains saved in the symbol storage area. ▪ k byte represents the symbol data of d1...dk.

Character Type Usable Characters

Numeric Data “0” ~ “9”

Alphanumeric Data “0” ~ “9”, “A” ~ “Z”, SP, $, %, *, +, -, ., /, :

Kanji Data Shift JIS value

8bit Byte Data 00H ~ FFH

▪ The setting impacts the function until the following actions are carried out:

- Execution of Function 180

- Execution of ESC @

- Turning off of printer power

EM 220

Rev. 1.00

- 50 -

Mobile Printer Command Manual

<Function 181> GS ( k pL pH cn fn m (fn=81) [Format]

[Range]

[Description] [Notes]

ASCII GS ( k pL pH cn fn M

Hex 1D 28 6B 03 00 31 51 M

Decimal 29 40 107 3 0 49 81 M (pL + pH x 256) = 3 (pL=3, pH=0) cn=49 fn=81 m=48

Encodes and prints QR CODE symbol data saved in the storage area ▪ This function is used in regular mode when the printer is at the first line or

no data is present in the printer buffer.

▪ If the size of any one symbol is larger than the print area, printing cannot

be done:

▪ If any of the following errors is present in the symbol storage area, printing

cannot be done.

- There is no data. (Function 180 cannot be executed)

- If [(number of columns x number of rows) < number of code words], the

numbers of columns and rows are automatically processed.

- The four types of data compression mode are as follows: *Numeric Data Code *Alphanumeric Data mode *Kanji Data mode

*8 bit Data mode

Note: According to the symbol data in the data storage area, automatic conversion to optimal compression is done.

▪ The following data is automatically added during encoding:

- Position sensor pattern

- Segregator for the position sensor pattern

- Timing pattern

- Format information

- Version information

- Error correction code text

- Pad code text

- Indicator for counting bits of bytes

- Mode indicator

- Concluder

- Queue pattern (when model 2 is selected)

- Expansion pattern (when model 1 is selected) ▪ During symbol printing, the printer mode has no effect (bold, underline, reverse direction, contrast). ▪ In regular mode, this command supplies enough paper required for

symbol printing. If the paper supply is not sufficient, the paper supply command is executed. When printing, the printing position is to the left of the print area. After symbol printing, the printer returns to the start position of the line, and the buffer is emptied.

EM 220

Rev. 1.00

- 51 -

Mobile Printer Command Manual

<Function 182> GS ( k pL pH cn fn m (fn=82) [Format]

[Range]

[Description]

ASCII GS ( k pL pH cn fn m

Hex 1D 28 6B 03 00 31 52 m

Decimal 29 40 107 3 0 49 82 m

(pL + pH x 256) = 3 (pL=3, pH=0) cn=49 fn=82 m=48

▪ Transmits size information of the QR CODE symbols encoded via

Function 180 to the host

▪ In regular mode, this function is executed when the printer is on standby

or the buffer is empty.

▪ The information size of each data item is as follows:

Transmission Data Hex Decimal Data

Header 37H 55 1 byte

Flag 36H 54 1 byte

Width 30H – 39H 48 – 57 1 – 5 byte

Separator 1FH 31 1 byte

Height 30H – 39H 48 – 57 1 – 5 byte

Separator 1FH 31 1 byte

Fixed Value 31H 49 1 byte

Separator 1FH 31 1 byte

Other Information 30H or 31H 48 or 49 1 byte

NUL 00H 0 1 byte

▪ Description of Width & Height Transmission Data

- Height and width are dot unit values for symbol data.

▪ Description of Other Information

Hex Decimal Condition 30H 48 Can be printed 31H 49 Cannot be printed

▪ The user quiet zone is not included in size information.

EM 220

Rev. 1.00

- 52 -

Mobile Printer Command Manual

<Function 265> GS ( k pL pH cn fn n1 n2 (fn=65) [Format]

[Range]

[Default]

[Description]

[Notes]

ASCII GS ( k pL pH cn fn n1 n2 Hex 1D 28 6B 04 00 32 41 n1 0 Decimal 29 40 107 3 0 50 65 n1 0

(pL + pH x 256) = 3 (pL=3, pH=0) cn=50 fn=65 50 ≤ n ≤ 52

n = 50

Maxi Code Mode Settings

n Function 50 Mode 2 Setting 51 Mode 3 Setting

52 Mode 4 Setting

▪ The setting of this function impacts <Function 281> and <Function 282>. ▪ This function is effective until ESC @ is executed or the printer power is

turned off.

EM 220

<Function 280> GS ( k pL pH cn fn m d1...dk (fn=80) [Format]

[Range]

[Description]

[Notes]

ASCII GS ( k pL pH cn fn m d1...dk Hex 1D 28 6B pL pH 32 50 30 d1...dk Decimal 29 40 107 pL pH 5 50 48 d1...dk

4 ≤ (pL + pH x 256) ≤ 141 (4 ≤ pL ≤141, 0 ≤ pH ≤0) cn=50 fn=80 m=48 0 ≤ d ≤ 255 k = (pL + pH x 256) – 3

Saves MAXI CODE symbol data in the symbol storage area

▪ Execution of this command saves data to the data storage area and

executes Functions 281 and 282. Following execution of Functions 281 and 282, the data remains saved in the symbol storage area.

▪ k byte represents the symbol data of d1...dk. ▪ The setting impacts the function until the following actions are carried out:

- Execution of Function 280

- Execution of ESC @

- Turning off of printer power

Rev. 1.00

- 53 -

Mobile Printer Command Manual

<Function 281> GS ( k pL pH cn fn m (fn=81)

[Format]

[Range]

[Description]

[Notes]

ASCII GS ( k pL pH cn fn m Hex 1D 28 6B 03 00 32 51 m Decimal 29 40 107 3 0 50 81 m

(pL + pH x 256) = 3 (pL=3, pH=0) cn=50 fn=81 m=48

Encodes and prints QR CODE symbol data saved in the storage area

▪ This function is used in regular mode when the printer is at the first line or

no data is present in the printer buffer.

▪ If the size of any one symbol is larger than the print area, printing cannot

be done.

▪ If any of the following errors is present in the symbol storage area, printing

cannot be done.

- There is no data. (Function 280 cannot be executed)

- The number of numeric characters exceeds 138.

- The number of alphanumeric characters exceeds 93.

- When mode 2 is selected, the primary message does not include all of the following:

Primary Message Data Number Character

Postal Code 1~9 Numeric

ISO Country Code 1~3 Numeric

Service Type Code 1~3 Numeric

- When mode 3 is selected, the primary message does not include all of the following:

Primary Message Data Number Character

Postal Code 1~6 Setting Code A

ISO Country Code 1~3 Numeric

Service Type Code 1~3 Numeric

▪ Modes 2 and 3 are executed according to the following procedures: (RS, GS indicate the control code of MAXI CODE. y indicates the 2byte

numeric data.)

a) 9 byte data including ”[]>”,”RS”,”01”,”GS”,”yy” are regarded as the

Header.

- The next data item after the Header is the Primary Message.

- When printing, the Header is inserted at the beginning of the

Secondary Message.

b) When Header data is absent, the Primary Message is regarded as

the first data item.

c) In the Primary Message, GS is regarded as the separator that divides

EM 220

Rev. 1.00

- 54 -

Mobile Printer Command Manual

EM 220

the postal code, ISO country code, and service type code. The GS text is ignored.

d) All data of the Secondary Message is regarded as symbol data.

▪ Mode 4 does not distinguish between the Primary Message and the

Secondary Message.

▪ In the detection and correction of errors, MAXI CODE uses the Reed-

Solomon algorithm.

▪ The following data is automatically added during the encoding process:

- Position sensor pattern

- Position pattern

- Error correction code text

- Mode separator

- Pad code text

▪ During symbol printing, the printer mode has no effect (bold, underline, reverse direction, contrast).

▪ In regular mode, this command supplies enough paper required for

<Function 367> GS ( k pL pH cn n (fn=67) [Format]

[Range]

[Default]

[Description]

ASCII GS ( k pL pH cn fn n Hex 1D 28 6B 03 00 33 43 n Decimal 29 40 107 3 0 51 67 n

(pL + pH x 256) = 3 (pL=3, pH=0) cn=51 fn=67 2<=n<7

n=3

Sets the DATAMATRIX code size

▪ It impacts the execution of <Function 381>. ▪ This function is effective until ESC @ is executed or the printer power is

turned off.

▪ n becomes the value for the module width and height.

(The DATAMATRIX module is square-shaped.)

Rev. 1.00

- 55 -

Mobile Printer Command Manual

<Function 380> GS ( k pL pH cn fn m d1...dk (fn=80) [Format]

[Range]

[Description]

[Notes]

ASCII GS ( k pL pH cn fn m d1...dk Hex 1D 28 6B pL pH 32 50 30 d1...dk Decimal 29 40 107 pL pH 5 50 48 d1...dk

0 ≤ (pL + pH x 256) ≤ 3116 (0≤ pL ≤255, 0 ≤ pH ≤13) cn=51 fn=80 m=48 0 ≤ d ≤ 255 k = (pL + pH x 256) – 3

Saves DATAMATRIX symbol data to the symbol storage area

▪ Execution of this command saves data to the data storage area and executes Function 281. Following execution of Function 281, the data remains saved in the symbol storage area.

▪ k byte represents the symbol data of d1...dk.

▪ The setting impacts the function until the following actions are carried out:

- Execution of Function 380

- Execution of ESC @

- Turning off of printer power

EM 220

Rev. 1.00

- 56 -

Mobile Printer Command Manual

<Function 381> GS ( k pL pH cn fn m (fn=81) [Format]

[Range]

[Description]

[Notes]

ASCII GS ( k pL pH cn fn m Hex 1D 28 6B 03 00 33 51 m Decimal 29 40 107 3 0 51 81 m

(pL + pH x 256) = 3 (pL=3, pH=0) cn=51 fn=81 m=48

Encodes and prints DATAMATRIX symbol data saved in the storage area

▪ This function is used in regular mode when the printer is at the first line or

no data is present in the printer buffer.

▪ If the size of any one symbol is larger than the print area, printing cannot

be done.

▪ If any of the following errors is present in the symbol storage area, printing

cannot be done:

- There is no data. (Function 380 cannot be executed)

- The number of alphanumeric characters exceeds 2334.

- The number of 8bit byte characters exceeds 1558.

- The number of numeric characters exceeds 3116.

▪ DATAMATRIX uses ECC 200 symbols.

▪ In the detection and correction of errors, DATAMATRIX uses the Reed-

Solomon algorithm.

▪ The following data is automatically added during the encoding process:

- Position pattern

- Error correction code text

- Mode separator

- Pad code text

▪ During symbol printing, the printer mode has no effect (bold, underline, reverse direction, contrast).

▪ In regular mode, this command supplies enough paper required for

EM 220

Rev. 1.00

- 57 -

Mobile Printer Command Manual

GS : [Name]

[Format]

[Description]

GS B n [Name]

[Format]

[Range]

[Default]

[Description]

EM 220

Start/end macro definition.

ASCII GS : Hex 1D 3A Decimal 29 58

▪ Starts or ends macro definition.

- The contents of the macro can be defined up to 2048 bytes.

Turns white/black reverse printing mode on / off.

ASCII GS B n Hex 1D 42 n Decimal 29 66 n

0 ≤ n ≤ 255

n=0

▪ Turns white/black reverse printing mode on or off.

- When the LSB of n is 0, white/black reverse mode is turned off.

- When the LSB of n is 1, white/black reverse mode is turned on.

Rev. 1.00

- 58 -

Mobile Printer Command Manual

GS H n [Name]

[Format]

[Range]

[Default]

[Description]

GS I b [Name]

[Format]

[Description]

[Notes]

EM 220

Selects the printing position of HRI characters.

ASCII GS H n Hex 1D 48 n Decimal 29 72 n

0 ≤ n ≤ 3, 48 ≤ n ≤ 51

n=0

▪ Selects the printing position of HRI characters when printing a bar code.

- n selects the execution of printing and the printing position as follows:

n Printing position 0, 48 Not printed. 1, 49 Above the bar code. 2, 50 Below the bar code. 3, 51 Both above and below the bar code.

Transmits battery status.

ASCII GS I b Hex 1D 49 62 Decimal 29 73 98

Transmits the battery power status of the printer

The transmitted battery status from this printer is constructed by [Header ~ NUL] as shown in the table below.

Transmitted data Hex Decimal Amount of data

Header 37H 55 1byte

Identifier 45H 69 1byte

Battery remaining 30h-34H 48-52 1byte

“Battery remaining amount“ is as indicated in the following table:

NUL 00H 0 1byte

Battery remaining amount

Information

Hex Decimal

Rev. 1.00

30H 48 Battery remaining amount : H level

31H 49 Battery remaining amount : M level

32H 50 Battery remaining amount : L level

33H 51 Battery remaining amount : S level

▪ You can confirm the battery remaining amount by looking at the battery

LED.

▪ When battery remaining amount is S level, the red LED of battery LED is

blinking.

• This command following DLE can be executed in real-time command mode.

- 59 -

Mobile Printer Command Manual

GS I n [Name]

[Format]

[Range]

[Description]

EM 220

Transmits printer ID.

ASCII GS I n Hex 1D 49 n Decimal 29 73 n

1 ≤ n ≤ 69,

▪ Transmits the printer ID specified.

- Transmits 1 byte of printer ID, using n as follows: n Printer ID ID

1,49 Printer model ID 65

2,50 Type ID

3, 51 Version ID 111

- Transmits specified printer information, using n as follows: n Printer ID type ID

65 Firmware version Depends on firmware version 66 Manufacturer Zebra 67 Printer name

Font of Language for

each country

-Printer information (When n = 65, 66, 67, 69) consist of[Header ~ NULL] as Shown in the following table:

Transmitted data Hex Decimal Amount of data

Header 5FH 95 1byte

Printer information

NUL 00H 0 1byte

Depends on the

model

0(2byte character is not supported) or 1(2byte character is supported)

EM 220

Chinese : GB2312 or BIG5 Korea n : KS-5601 Japanese : SHIFT-JIS Each default code page

Depends on the

model

1byte

Rev. 1.00

• This command following DLE can be executed in real-time command mode.

- 60 -

Mobile Printer Command Manual

GS L nL nH [Name]

[Format]

[Range]

[Default]

[Description]

GS W nL nH [Name] [Format]

[Range] [Default]

[Description]

GS ＼ nL nH [Name]

[Format]

[Range]

[Description]

EM 220

Set left margin.

ASCII GS L nL nH Hex 1D 4C nL nH Decimal 29 76 nL nH

0 ≤ nL ≤ 255, 0 ≤ nH ≤ 255

(nL + nH x 256)=0 (nL=0, nH=0)

▪ Sets the left margin specified by nL and nH.

- The left margin is [(nL + nH x 256) x (horizontal motion units)].

Printable area

Left margin Printing area width

Set printing area width.

ASCII GS W nL nH Hex 1D 57 nL nH

Decimal 29 87 nL nH 0 ≤ nL ≤ 255, 0 ≤ nH ≤ 255 (nL + nH x 256)=384 (nL=128, nH=1) (for 58mm of the paper width)

▪ Sets the printing area width specified with nL and nH.

- The printing area width is [(nL + nH x 256) x (horizontal motion units)].

Printable area

Left margin Printing area width

Set relative vertical print position in page mode.

ASCII GS

＼

Hex 1D 5C nL nH

Decimal 29 92 nL nH

0 ≤ nL ≤ 255, 0 ≤ nH ≤ 255

▪ Sets the relative vertical print starting position from the current position in

page mode. The distance from the current position to the starting position is

[(nL + nH x 256) x (vertical or horizontal motion units)].

nL nH

Rev. 1.00

- 61 -

Mobile Printer Command Manual

GS ^ r t m [Name]

[Format]

[Range]

[Description]

m Function

0 Executes the macro r times at the interval specified by t.

GS f n [Name]

[Format]

[Range]

[Default]

[Description]

GS h n [Name]

[Format]

[Range] [Default] [Description]

Execute macro.

ASCII GS ^ r t m

Hex 1D 5E r t m

Decimal 29 94 r t m

0 ≤ r ≤ 255 0 ≤ t ≤ 255 m=0, 1

▪ Executes a macro.

- r specifies the number of times to execute the macro.

- t specifies the waiting time for executing the macro.

- m specifies macro executing mode from the table below.

After waiting for the time specified by t, the FEED button must be pressed. After the button is pressed, the macro is executed once. This operation is then repeated r times.

Select font for HRI characters.

ASCII GS f n

Hex 1D 66 n

Decimal 29 102 n

n=0, 1, 48, 49

n=0

▪ Selects a font for the HRI characters used when printing a bar code.

- n specifies the font of the HRI characters as follows:

n Font 0, 48 Font A (12 x 24) 1, 49 Font B (9 x 17)

Selects bar code height.

ASCII GS h n Hex 1D 68 n Decimal 29 104 n

1 ≤ nL ≤ 255 n=162 ▪ Selects the height of the bar code as n dots.

EM 220

Rev. 1.00

- 62 -

Mobile Printer Command Manual

① GS k m d1...dk NUL ② GS k m n d1...dn

[Name]

[Format]

[Range]

[Description]

Print bar code.

① Hex 1D 6B m d1...dk NUL Decimal 29 107 m d1...dk NUL ② Hex 1D 6B m n d1...dn Decimal 29 107 m n d1...dn

① 0 ≤ m ≤ 6 (k and d depend on the bar code system used) ② 65 ≤ m ≤ 73 (n and d depend on the bar code system used)

▪ Selects a bar code system and prints the bar code.

For ①

Bar Code System

0 UPC-A 11 ≤ k ≤ 12 48 ≤ d ≤ 57 1 UPC-E 11 ≤ k ≤ 12 48 ≤ d ≤ 57 2 JAN13(EAN) 12 ≤ k ≤ 13 48 ≤ d ≤ 57 3 JAN8(EAN) 7 ≤ k ≤ 8 48 ≤ d ≤ 57

4 CODE39 1 ≤ k

5 ITF 1 ≤ k

6 CODABAR 1 ≤ k

For ②

Bar Code System

65 UPC-A 11 ≤ n ≤ 12 48 ≤ d ≤ 57 66 UPC-E 11 ≤ n ≤ 12 48 ≤ d ≤ 57 67 JAN13(EAN) 12 ≤ n ≤ 13 48 ≤ d ≤ 57 68 JAN8(EAN) 7 ≤ n ≤ 8 48 ≤ d ≤ 57

69 CODE39 1 ≤ n ≤ 255

70 ITF 1 ≤ n ≤ 255

[Notes]

71 CODABAR 1 ≤ n ≤ 255

72 CODE93 1 ≤ n ≤ 255 0 ≤ d ≤ 127 73 CODE128 2 ≤ n ≤ 255 0 ≤ d ≤ 127

▪ The user must consider the quiet zone of the bar code (left and right

spaces of the bar code)

EM 220

ASCII GS k m d1...dk NUL

ASCII GS k m n d1...dn

Range of k Range of d

48 ≤ d ≤ 57, 65 ≤ d ≤ 90, d=32,36,37,43,45,46,47

(even number)

Range of k Range of d

(even number)

48 ≤ d ≤ 57

48 ≤ d ≤ 57, 65 ≤ d ≤ 68, d=36,43,45,46,47,58

48 ≤ d ≤ 57, 65 ≤ d ≤ 90, d=32,36,37,43,45,46,47

48 ≤ d ≤ 57

48 ≤ d ≤ 57, 65 ≤ d ≤ 68, d=36,43,45,46,47,58

Rev. 1.00

- 63 -

Mobile Printer Command Manual

GS r n [Name]

[Format]

[Range] [Description]

EM 220

Transmit status.

ASCII GS r n Hex 1D 72 n Decimal 29 114 n

n=1, 2, 49, 50 ▪ Transmits the normal status specified by n as follows:

n Function 1, 49 Transmits paper sensor status.

▪ Paper sensor status (n=1, 49) :

Bit Off/On Hex Decimal Function

0, 1

2, 3

4 Off 00 0 Fixed. 5 Off 00 0 Reserved. 6 Off 00 0 Reserved. 7 Off 00 0 Fixed.

- Bits 2 and 3: This command can not be executed when the printer is

• This command following DLE can be executed in real-time command

Off 00 0 Reserved On 03 3 Reserved Off 00 0 Paper roll end sensor; paper present. On 0C 12

offline due to the lack of paper. Therefore, the status of bit 2 (1) and bit 3 (1) is not transmitted.

Paper roll end sensor; paper not present.

. .

mode.

GS v 0 m xL xH yL yH d1...dk [Name]

[Format]

[Range]

[Description] ▪ Prints a raster bit image in m mode.

Print raster bit image.

ASCII GS v 0 M xL xH yL yH d1...dk Hex 1D 76 30 M xL xH yL yH d1...dk Decimal 29 118 48 M xL xH yL yH d1...dk

0 ≤ m ≤ 3, 48 ≤ m ≤ 51 1 ≤ (xL + xH x 256) ≤ 128 (0 ≤ xL ≤ 128, xh=0) 1 ≤ (yL + yH x 256) ≤ 4095 (0 ≤ yL ≤ 255, 0 ≤ yH ≤ 15) 0 ≤ d ≤ 255 k = (xL + xH x 256) x (yL + yH x 256)

- m specifies the bit image mode. m Mode Vertical dot density Horizontal dot density

0, 48 Normal 203 dpi 203 dpi 1, 49 Double-width 203 dpi 203/2 dpi 2, 50 Double-height 203/2 dpi 203 dpi 3, 51 Quadruple 203/2 dpi 203/2 dpi

xL, xH specifies (xL + xH x 256) byte(s) in the horizontal direction for the bit image.

yL, yH specifies (yL + yH x 256) dot(s) in the vertical direction for the bit image.

- d specifies the definition data of the bit image data.

dpi : dots per 25.4mm {1"}

Rev. 1.00

- 64 -

Mobile Printer Command Manual

GS w n [Name]

[Format]

[Range]

[Description]

[Notes]

FS . [Name]

[Format]

[Range]

[Description]

EM 220

Set bar code width.

ASCII GS w n Hex 1D 77 n Decimal 29 119 n

2 ≤ n ≤ 6 , n=3

▪ Set the horizontal size of the bar code, using n as follows:

Multi-level Bar Code

Module Width (mm)

2 3 4 5 6

0.250 0.250 0.625

0.375 0.375 1.000

0.500 0.500 1.250

0.625 0.625 1.625

0.750 0.750 2.000

Thin element width

▪ Multi-level bar codes are as follows:

- UPC-A, UPC-E, JAN13, HAN8, CODE93, CODE128 ▪ Binary-level bar codes are as follows:

- CODE39, ITF, CODABAR

Cancel Kanji character mode.

ASCII FS . Hex 1C 2E Decimal 28 45

n=0

▪ Cancels Kanji character mode.

Binary-level Bar Code

(mm)

Thick element width

(mm)

FS & [Name]

[Format]

[Description]

Rev. 1.00

Select Kanji character mode.

ASCII FS & Hex 1C 26 Decimal 28 38

▪ Select Kanji character mode.

- 65 -

Mobile Printer Command Manual

US L R [Name]

[Format]

[Description] [Notes]

US L L [Name]

[Format]

[Description] [Notes]

US L A [Name]

[Format]

[Description] [Notes]

EM 220

Change receipt mode.

ASCII US L R Hex 1F 4C 52 Decimal 31 76 82

▪ Change from label mode to receipt mode. ▪ The memory switch setting is changed.

Change label mode.

ASCII US L L Hex 1F 4C 4C Decimal 31 76 76

▪ Change from receipt mode to Label mode. ▪ The memory switch setting is changed.

Execute auto calibration in label mode.

ASCII US L A Hex 1F 4C 41 Decimal 31 76 65

▪ Execute auto calibration in label mode. ▪ Store the value for the liner into NV memory during three-label feed

process without printing.

▪ The leading edge of the label is positioned at the print line by the use of

the stored value.

Rev. 1.00

- 66 -

Mobile Printer Command Manual

www.zebra.com

______________________________________________________________________

Zebra Technologies International, LLC

333 Corporate Woods Parkway

Vernon Hills, Illinois 60061, 3109 USA

Phone: +1.847.634.6700

Toll-Free: +1.800.423.0422

Fax: +1.847.913.8766

Zebra EM220 Microsoft Word - EM 220_Command_Manual_english_Rev_1_00.doc

Specifications and Main Features

Frequently Asked Questions

User Manual

1. Notice

2. Control Commands List

3. Control Commands Details

3-1 Command Notation

3-2 Explanation of Terms

3-3 Control Commands Details
