1. Manual Information

This SDK Manual provides information on the dll files required for Windows application
program development.

1-1 Supporting O/S & Platform

- O/S

• Microsoft Windows CE 3.x / 4.x / 5.x / 6.x

- Platform

• Pocket PC 2002

• Pocket PC 2003

• Pocket PC 2003 second edition

• Windows Mobile 5

• Windows Mobile 6

• Custom Platform for Armv4i CPU
* supported .Net Framework

1-2 Supporting Devices

This is a list of verified devices. If your PDA cpu type is Armv4 or Armv4i, it is compatible
with our module driver.

- Symbol MC3000 / MC7090 / MC9000

- Innoteletek MC3000 /

- Intermec CN2

- CASIO DT-X10M10E

- ATID AT570

- HP iPaq Series

Rev. 1.00

- 6 -

Mobile Printer
SDK API Reference Guide

EM 220

2. Properties

The constant values used in the dll files provided are declared in the BxlConst.h file.
The development environment was based on C++.

2-1 CharacterSet (LONG R/W)

As the attribute that defines the Code Page of the printer, the default setting is
BXL_CS_437. Use the SetCharacterSet(), GetCharacterSet() functions to set values or
recall previously set values.

The Code Pages that can be used are as follows:

Code Value Description
BXL_CS_PC437 0 Code page PC437
BXL_CS_PC850 2 Code page PC850
BXL_CS_PC860 3 Code page PC860
BXL_CS_PC863 4 Code page PC863
BXL_CS_PC865 5 Code page PC865
BXL_CS_WPC1252 16 Code page WPC1252
BXL_CS_PC866 17 Code page PC866
BXL_CS_PC852 18 Code page PC852
BXL_CS_PC858 19 Code page PC858
BXL_CS_PC864 22 Code page PC864
BXL_CS_PC874 23 Code page PC874
BXL_CS_WPC1253 24 Code page WPC1253
BXL_CS_WPC1251 28 Code page WPC1251
BXL_CS_PC737 29 Code page PC737
BXL_CS_THAI16 31 Code page THAI16
BXL_CS_PC862 33 Code page PC862
BXL_CS_PC855 36 Code page PC855
BXL_CS_PC857 37 Code page PC857
BXL_CS_USER 255 User set page

Rev. 1.00

- 7 -

Mobile Printer
SDK API Reference Guide

EM 220

2-2 International CharacterSet (LONG R/W)

As the attribute that defines the International Character Set of the printer, the default
setting is BXL_ICS_USA. Use the SetInterChrSet(), GetInterChrSet()functions to set
values or recall previously set values.

The International Character Sets that can be used are as follows:

Code Value Description
BXL_ICS_USA 0 USA code setting
BXL_ICS_FRANCE 1 FRANCE code setting
BXL_ICS_GERMANY 2 GERMANY code setting
BXL_ICS_UK 3 UK code setting
BXL_ICS_DENMARK1 4 DENMARK1 code setting
BXL_ICS_SWEDEN 5 SWEDEN code setting
BXL_ICS_ITALY 6 ITALY code setting
BXL_ICS_SPAIN 7 SPAIN code setting
BXL_ICS_NORWAY 9 NORWAY code setting
BXL_ICS_DENMARK2 10 DENMARK 2 code setting

2-3 State (LONG R)

This attribute sets the printer State. It can only be read, and is automatically set when
examining the printer State by using the CheckPrinter function. As State values can be
set in duplication, each value can be confirmed via bit calculation. The values of this
attribute can be recalled by using the GetState function.

Printer State values are as follows:

Code Value Description
BXL_STS_NORMAL 0 Printer status is normal
BXL_STS_PAPEREMPTY 1 No paper in printer
BXL_STS_COVEROPEN 2 The printer paper cover is open
BXL_STS_POWEROVER 4 The printer battery capacity is insufficient
BXL_STS_MSR_READY 8 Currently in MSR read mode, printing not possible
BXL_STS_PRINTING 16 Currently printing or transmitting data
BXL_STS_ERROR 32 An error has occurred
BXL_STS_NOT_OPEN 64 The printer is not open
BXL_STS_ERROR_OCCUR 128 An error has occurred

Rev. 1.00

- 8 -

Mobile Printer
SDK API Reference Guide

EM 220

2-4 PowerValue (LONG R)

This attribute sets the battery capacity value of the printer. It can only be read, and is set
every time the status of the printer battery changes. The values of this attribute can be
recalled by using the GetPowerValue function.

Battery Capacity values are as follows:

Code Value Description
BXL_PWR_HIGH 0 Battery charge status: 95%
BXL_PWR_MIDDLE 1 Battery charge status: 85% or higher
BXL_PWR_LOW 2 Battery charge status: 50% or higher
BXL_PWR_SMALL 3 Battery charge status: 25% or higher
BXL_PWR_NOT 4 Battery charge status: 25% or lower

Rev. 1.00

- 9 -

Mobile Printer
SDK API Reference Guide

EM 220

3. Methods

The functions disclosed in the provided module are declared in the ExportFunc.h file.
The development environment was based on C++.

3-1 PrinterOpen

In order to use the module, this function is enabled. For PDA types with different In/Out
ports, port settings for each are required. In general, two-way communication is possible
with just the strOutPortName setting.

long PrinterOpen(
LPCTSTR strOutPortName,

Long lTimeout

);

Inju

[Parameters]

* strOutPortName

Unicode Data ending with [in] null. The virtual Serial Port number and Baud rate of the
currently connected device is conveyed for printing. If strInPortName is NULL,
strOutPortName sets to In/Out data processing.(ex: COM4:19200)

* lTimeout

Specifies the timeout, in milliseconds, used to calculate the total timeout period for open
operations.

[Return Values]

Code Value Description
BXL_SUCCESS 0 Returns after function success
BXL_CREATE_ERROR 102 Failure to create communication target
BXL_NOT_OPENED 101 Unable to open communication port
BXL_STATUS_ERROR 103 Error occurred during status check
BXL_WRITE_ERROR 300 Failure to transmit data
BXL_READ_ERROR 301(0) Error in received value or reception failure

Rev. 1.00

- 10 -

Mobile Printer
SDK API Reference Guide

EM 220

3-2 PrinterClose

This function disables the SDK module. Functions related to printing and MSR are no
longer available for use.

long PrinterClose();

[Parameters]

None

[Return Values]

Code Value Description
BXL_SUCCESS 0 Returns after function success

3-3 LineFeed

This function dictates line feeding to the integer value conveyed for printing.

long LineFeed (
int nFeed,
);

[Parameters]

* nFeed

The [in] integer value conveys the number of lines for line feeding in the form of printing
value.

[Return Values]

Code Value Description
BXL_SUCCESS 0 Returns after function success
BXL_NOT_OPENED 101 Unable to open communication port
BXL_STATUS_ERROR 103 Error occurred during status check
BXL_WRITE_ERROR 300 Failure to transmit data

Rev. 1.00

- 11 -

Mobile Printer
SDK API Reference Guide

EM 220

3-4 PrintBarcode

This function supports the 1-dimension and 2-dimension barcode printing function.

long PrintBarcode(

PCHAR Data,
long symbology,
long Height,
long Width,
long Alignment,
long TextPosition

);

[Parameters]

* Data

ANSI Code Data ending with [in] null. Barcode data to be printed are conveyed.

* symbology

Defines the [in] barcode type. The barcode type is defined in Bxldll.h.

Code Value Data Number Limit Data Value Range
BXL_BCS_UPCA 101
BXL_BCS_UPCE 102

BXL_BCS_EAN13
BXL_BCS_JAN13

BXL_BCS_EAN8
BXL_BCS_JAN8

103
104
105
106

BXL_BCS_Code39 107

BXL_BCS_ITF 108

BXL_BCS_Codabar 109

BXL_BCS_Code93 110
BXL_BCS_Code128 111
BXL_BCS_PDF417 200
BXL_BCS_MAXICODE 201
BXL_BCS_QRCODE 202

* Height

This value sets the [in] barcode height in Dot units. The value range is 1~255. Two
dimensional barcodes are not affected.

* Width

This value sets the [in] barcode width according to a value range of 2~7. If the print
area of the barcode exceeds the printing paper, barcode printing may not be possible.
Two dimensional barcodes are not affected by this value.

11 ≤ n ≤ 12 48 ≤ data ≤ 57
11 ≤ n ≤ 12 48 ≤ data ≤ 57

12 ≤ n ≤ 13 48 ≤ data ≤ 57

7 ≤ n ≤ 8 48 ≤ data ≤ 57

1 ≤ n ≤ 255

1 ≤ n ≤ 255

(even number)

1 ≤ n ≤ 255

1 ≤ n ≤ 255 0 ≤ data ≤ 127
2 ≤ n ≤ 255 0 ≤ data ≤ 127

2 ≤ n ≤ 928 0 ≤ data ≤ 255
Not supported Not supported
Not supported Not supported

48 ≤ data ≤ 57, 65 ≤ data ≤ 90,

data =32,36,37,43,45,46,47

48 ≤ data ≤ 57

48 ≤ data ≤ 57, 65 ≤ data ≤ 68,

data =36,43,45,46,47,58

Rev. 1.00

- 12 -

Mobile Printer
SDK API Reference Guide

EM 220

* Alignment

This value sets the [in] barcode alignment.

Code Value Description
BXL_ALIGNMENT_LEFT 0 Left-aligned
BXL_ALIGNMENT_CENTER 1 Centered
BXL_ALIGNMENT_RIGHT 2 Right-aligned

* TextPosition

This value sets the print position of the [in] barcode data. Two dimensional barcodes
have only the BXL_BC_TEXT_NONE value.

Code Value Description
BXL_BC_TEXT_NONE 0 Barcode data not printed
BXL_BC_TEXT_ABOVE 1 Barcode data printed above barcode
BXL_BC_TEXT_BELOW 2 Barcode data printed below barcode

[Return Values]

Code Value Description
BXL_SUCCESS 0 Returns after function success
BXL_NOT_OPENED 101 Unable to open communication port
BXL_STATUS_ERROR 103 Error occurred during status check
BXL_WRITE_ERROR 300 Failure to transmit data
BXL_BC_DATA_ERROR 500 Error in barcode data
BXL_BC_NOT_SUPPORT 501 Barcode type not supported

Rev. 1.00

- 13 -

Mobile Printer
SDK API Reference Guide

EM 220

3-5 PrintText

This function supports the text printing function.

long PrintText(
LPCTSTR Data,
long Alignment,
long Attribute,
long TextSize
);

[Parameters]

* Data

Unicode Data ending with [in] null. Conveys the barcode data to be printed.

* Alignment

This value sets the [in] barcode alignment.

Code Value Description
BXL_ALIGNMENT_LEFT 0 Left-aligned
BXL_ALIGNMENT_CENTER 1 Centered
BXL_ALIGNMENT_RIGHT 2 Right-aligned

* Attribute

This value sets the [in] text properties. The following values can be duplicated.

Code Value Description

BXL_FT_DEFAULT 0

BXL_FT_FONTB 1 Set to Font B
BXL_FT_BOLD 2 Adds Bold lettering attribute
BXL_FT_UNDERLINE 4 Adds Underlining attribute
BXL_FT_REVERSE 8 Adds Reverse lettering attribute

Font A, print using the basic device font

Basic setting value

Rev. 1.00

- 14 -

Mobile Printer
SDK API Reference Guide

EM 220

* TextSize

This value sets the [in] text size properties. The width and height values can be
duplicated.

Code Va lue Description
BXL_TS_0WIDTH 0 Width magnification set to x1
BXL_TS_1WIDTH 16 Width magnification set to x2
BXL_TS_2WIDTH 32 Width magnification set to x3
BXL_TS_3WIDTH 48 Width magnification set to x4
BXL_TS_4WIDTH 64 Width magnification set to x5
BXL_TS_5WIDTH 80 Width magnification set to x6
BXL_TS_6WIDTH 96 Width magnification set to x7
BXL_TS_7WIDTH 112 Width magnification set to x8

Code Va lue Description
BXL_TS_0HEIGHT 0 Height magnification set to x1
BXL_TS_1HEIGHT 1 Height magnification set to x2
BXL_TS_2HEIGHT 2 Height magnification set to x3
BXL_TS_3HEIGHT 3 Height magnification set to x4
BXL_TS_4HEIGHT 4 Height magnification set to x5
BXL_TS_5HEIGHT 5 Height magnification set to x6
BXL_TS_6HEIGHT 6 Height magnification set to x7
BXL_TS_7HEIGHT 7 Height magnification set to x8

[Return Values]

Code Value Description
BXL_SUCCESS 0 Returns after function success
BXL_NOT_OPENED 101 Unable to open communication port
BXL_STATUS_ERROR 103 Error occurred during status check
BXL_WRITE_ERROR 300 Failure to transmit data

Rev. 1.00

- 15 -

Mobile Printer
SDK API Reference Guide

EM 220

3-6 PrintBitmap

This function prints image files. Only Bmp files are supported.

long PrintBitmap (
LPCTSTR FileName,
long Width,
long Alignment,
long Level
);

[Parameters]

* FileName

Expressed as a row of Unicode characters, the full path of the [in] image file is set.

* Width

This value is the width of the [in] image file to be converted. The value range is 0~384.
When setting the value as below, the image size is modified to fit conditions.

Code Value Description
BXL_WIDTH_FULL -1 Set to a value of 384, image is fit to full size of paper
BXL_WIDTH_NONE -2 No variation given to image size

* Alignment

This value sets the [in] barcode alignment.

Code Value Description
BXL_ALIGNMENT_LEFT 0 Left-aligned
BXL_ALIGNMENT_CENTER 1 Centered
BXL_ALIGNMENT_RIGHT 2 Right-aligned

* Level

This value sets the color level of the [in] image. The value range is 0~100.

[Return Values]

Code Value Description
BXL_SUCCESS 0 Returns after function success
BXL_NOT_OPENED 101 Unable to open communication port
BXL_STATUS_ERROR 103 Error occurred during status check
BXL_WRITE_ERROR 300 Failure to transmit data
BXL_BITMAPLOAD_ERROR 400 Failure to read image file

Rev. 1.00

- 16 -

Mobile Printer
SDK API Reference Guide

EM 220

3-7 CheckPrinter

This function checks printer status and sets the printer status properties.

long CheckPrinter ();

[Parameters]

None

[Return Values]

Code Value Description
BXL_SUCCESS 0 Returns after function success
BXL_NOT_OPENED 101 Unable to open communication port
BXL_READ_ERROR 301(0) Failure to receive data
BXL_WRITE_ERROR 300 Failure to transmit data

3-8 MsrReadReady

This function switches the printer to MSR Ready status. Printing is not possible when in
Ready status.
After returning via BXL_SUCCESS and if the m_lState is BXL_STS_MSR_READY, the
standby status is deemed normal.

long CheckPrinter ();

[Parameters]

None

[Return Values]

Code Value Description
BXL_SUCCESS 0 Returns after function success
BXL_NOT_OPENED 101 Unable to open communication port
BXL_WRITE_ERROR 300 Failure to transmit data

Rev. 1.00

- 17 -

Mobile Printer
SDK API Reference Guide

EM 220

3-9 MsrReadCancel

This function deactivates the MSR Ready status of the printer.

Long MsrReadCancel();

[Parameters]

None

[Return Values]

Code Value Description
BXL_SUCCESS 0 Returns after function success
BXL_NOT_OPENED 101 Unable to open communication port
BXL_WRITE_ERROR 300 Failure to transmit data
BXLMSR_NOTREADY 602 Not in READY status
BXLMSR_FAILEDMODE 601 In automatic read mode

3-10 MsrReadTrack

This function recalls MSR data. If the MSR is in read mode and BXLMSR_DATAEMPTY
is returned, the card has not yet been read in the MSR. Scanning the card in the MSR
again can be tried, or the MSRReadCancel function can be used to cancel read mode.

Long MsrReadTrack (

PCHAR Data1,
PCHAR Data2,
PCHAR Data3

);

[Parameters]

* PCHAR Data1

[in, out] MSR Data Track 1 read from the buffer defined by the caller.

* PCHAR Data2

[out, out] MSR Data Track 2 read from the buffer defined by the caller.

* PCHAR Data3

[out, out] MSR Data Track 3 read from the buffer defined by the caller.

[Return Values]

Code Value Description
BXL_SUCCESS 0 Returns after function success
BXL_NOT_OPENED 101 Unable to open communication port
BXL_WRITE_ERROR 300 Failure to transmit data
BXLMSR_DATAEMPTY 603 Not in READY status

Rev. 1.00

- 18 -

Mobile Printer
SDK API Reference Guide

EM 220

3-11 DirectIO

This function can send and read data defined by the user.

Long DirectIO (

PCHAR Data,
UINT uiWrite,
PCHAR pRequet,
UINT uiRead

);

[Parameters]

* PCHAR Data,

Data to be sent to the [int] printer, data is ANSI code

* UINT uiWrite

Size of data to be sent to the [in] printer

* PCHAR pRequet

Sets the values read from the buffered defined by the [in,out] caller

* UINT uiRead

Converts the size of date to be read by the [in, out] caller to the actual size of read data

[Return Values]

Code Value Description
BXL_SUCCESS 0 Returns after function success
BXL_NOT_OPENED 101 Unable to open communication port
BXL_STATUS_ERROR 103 Error occurred during status check
BXL_WRITE_ERROR 300 Failure to transmit data
BXL_READ_ERROR 300(1) Error in received value or reception failure

Rev. 1.00

- 19 -

Mobile Printer
SDK API Reference Guide

EM 220

3-12 NextPrintPos

If the label function is set, the paper is fed up to the next printing position.

Long NextPrintPos ();

[Parameters]

* None

[Return Values]

Code Value Description
BXL_SUCCESS 0 Returns after function success
BXL_NOT_OPENED 101 Unable to open communication port
BXL_STATUS_ERROR 103 Error occurred during status check
BXL_WRITE_ERROR 300 Failure to transmit data

3-13 GetTrack1

This function returns MSR Track1 data. If the MSR is in read mode and NULL is returned,
the card has not yet been read by the MSR. Strip the card with the MSR again or wait for
WM_MSR_ARRIVED message. MSRReadCancel function can be used to cancel read
mode.

TCHAR * GetTrack1 ();

[Parameters]

* None

[Return Values]

If the function is successful, MSR Track1 data will be returned. If it has failed, the function
will return NULL pointer.

Rev. 1.00

- 20 -

Mobile Printer
SDK API Reference Guide

EM 220

3-14 GetTrack2

This function returns MSR Track2 data. If the MSR is in read mode and NULL is returned,
the card has not yet been read by the MSR. Strip the card with the MSR again or wait for
WM_MSR_ARRIVED message. MSRReadCancel function can be used to cancel read
mode.

TCHAR * GetTrack2 ();

[Parameters]

* None

[Return Values]

If the function is successful, MSR Track2 data will be returned. If it has failed, the function
will return NULL pointer.

3-15 GetTrack3

This function returns MSR Track3 data. If the MSR is in read mode and NULL is returned,
the card has not yet been read by the MSR. Strip the card with the MSR again or wait for
WM_MSR_ARRIVED message. MSRReadCancel function can be used to cancel read
mode.

TCHAR * GetTrack3 ();

[Parameters]

* None

[Return Values]

If the function is successful, MSR Track2 data will be returned. If it has failed, the function
will return NULL pointer.

Rev. 1.00

- 21 -

Mobile Printer
SDK API Reference Guide

EM 220

4. Message

If some events have occurred in printer, the SDK will send WM_BXL_PRINTER_
UPDATED message.

4-1 BXL_LPARAM _MSR

This message will be posted when the printer reads MSR Track data from MSR sensor.

lParam = 0

wParam
wParam is set by the following data.

Value Description
BXL_MSG_TRACK1 0x01
BXL_MSG_TRACK2 0x02
BXL_MSG_TRACK3 0x04

Example) BXL_MSG_TRACK1 + BXL_MSG_TRACK2 = 0x03

Rev. 1.00

- 22 -

Mobile Printer
SDK API Reference Guide

www.zebra.com

______________________________________________________________________

Zebra Technologies International, LLC

333 Corporate Woods Parkway

Vernon Hills, Illinois 60061, 3109 USA

Phone: [phone]

Toll-Free: +1.800.423.0422

Fax: [phone]
