It is most important that this instruction book should be
retained with the appliance for future reference. Should
the appliance be sold or transferred to another owner, or
should you move house and leave the appliance, always
ensure that the book is left with the appliance in order that
the new owner can get to know the functioning of the
appliance and the relevant safety information.
This information has been provided in the interest of your
safety. You MUST read it carefully before installing or
using the appliance.
Installation
● Check your dishwasher for any transport damage. Never
connect a damaged machine. If your dishwasher is
damaged, you should contact your supplier.
● For safety reasons it is dangerous to alter the specifications
or attempt to modify this product in any way.
● Any electrical and plumbing work required to install this
appliance should be carried out by a qualified and
competent person.
● Care must be taken to ensure that the appliance does not
stand on the electrical supply cable.
● The sides of the dishwasher must never be drilled to
prevent damage to hydraulic components.
Child safety
● This appliance is designed to be operated by adults.
● Children should not be allowed to tamper with the controls
or play with the product.
● Packaging parts may be dangerous for children, who could
even be suffocated! You should therefore keep all
packaging well away from children.
● The water in your dishwasher is not for drinking. Detergent
residues may still be present in your machine. Keep
children well away from your dishwasher when the door is
open.
● Keep all detergents in a safe place out of children's reach.
Your dishwasher in day-to-day use
● Items that are contaminated by petrol, paint, steel or iron
debris, corrosive, acidic or alkaline chemicals must not be
washed in this dishwasher.
● Under no circumstances should you open the door whilst
the appliance is in operation, especially during the washing
phase, hot water may escape. However, if the door is
opened, a safety device ensures that the machine stops.
● Only use products (detergent, salt and rinse aid) specifically
designed for use in dishwashers.
● Long bladed knives stored in an upright position are a
potential hazard.
● Long and/or sharp items of cutlery such as carving knives
must be positioned horizontally in the upper basket.
● When finishing loading or unloading close the door, as an
open door can be a hazard.
● Do not sit or stand on the open door.
● Isolate the appliance from the power supply and turn off the
water supply after use.
● This product should be serviced by an authorised service
engineer, and only genuine spare parts should be used.
● Under no circumstances should you attempt to repair the
machine yourself. Repairs carried out by inexperienced
persons may cause injury or serious malfunctioning.
Contact your local consumer services department. Always
insist on genuine spare parts.
Safety instructions
33
Safety instructions 33
Disposal 34
Economical and ecological dishwashing 34
Prior to using for the first time 34
The water softener 34
Setting the water softener 34
Filling with salt 34
Rinse aid 35
Use of detergent 37
Maintenance and cleaning 38
Cleaning the filters 38
Prolonged periods of non-operation 38
Frost precautions 38
Moving the machine 38
What to do, when... 39
Service and spare parts 40
Installation instructions 40
Water supply connections 40
Water outlet hose connection 40
Electrical connection 41
Contents
34
Disposal
Dispose of the dishwasher packaging material correctly.
All packaging materials can be recycled.
Plastic parts are marked with standard international
abbreviations:
>PE< for polyethylene, e.g. sheet wrapping material.
>PS< for polystyrene, e.g. padding material (always CFC-
free).
>POM< for polyoxymethylene, e.g. plastic clips.
Cardboard packaging is manufactured from recycled paper
and should be deposited in the waste paper collection for
recycling.
As and when you cease to use your dishwasher and withdraw
it from service, your should render it unserviceable before
having it disposed of.
Warning! Children at play could lock themselves in your
dishwasher or otherwise endanger their lives. Therefore cut off
the power supply cable and make the door closing device
unusable to prevent children from being trapped inside.
For the disposing of the appliance please take it to a recycling
centre or to your dealer who will, for a small contribution to the
costs, dispose it for you.
Economical and
ecological dishwashing
● Ensure that the water softener is correctly adjusted.
● Do not pre-wash under running water.
● Select the wash programme to suit the nature and degree of
the soiling on the dishes.
● Do not use more detergent, special salt and rinse aid than is
recommended in these operating instructions and by the
manufacturer of the respective product.
Prior to using for the first time
Before using your dishwasher for the first time:
1. Ensure that the electrical and water connections comply
with the installation instructions
2. Remove all packaging from inside the appliance
3. Set the water softener
4. Pour 1 litre of water inside the salt container and then fill
with salt
5. Fill the rinse aid dispenser
6. Run a "Rinse and Hold" programme (not all models of
dishwashers are foreseen with this programme)
The water softener
The dishwasher is equipped with a water softener designed to
remove minerals and salts from the water supply, which would
have a detrimental or adverse effect on the operation of the
appliance.
The higher the content of these salts, the harder your water is.
Water hardness is measured in equivalent scales, German
degrees, French degrees and PPM (parts per Million).
The softener should be adjusted according to the hardness of
the water in your area. Your local Water Authority can advise
you on the hardness of the water in your area.
The dishwasher is factory set at position 2.
If your water is below level 1 it is already soft and therefore
there is no need to use salt. In this case adjust the water
softener on level 1 without using salt.
Only for dishwasher models with salt refilling
indicator light:
If the water softener has been adjusted on level 1 and no salt
is being used, the salt refilling indicator light on the control
panel, will always remain illuminated when the machine is
switched on and the door closed.
Setting the water softener
1. Open the dishwasher door.
2. Remove the lower basket from the dishwasher.
3. Turn the water hardness switch until the required level (see
table) corresponds with the marker .
4. Replace the lower basket.
Filling with salt
Special salt can be added in one of two ways:
● If you are using dishwasher detergent that already contains
salt, the detergent including the salt is placed in the
detergent compartment.
- In this case the water softener must be set to level 1 to
ensure that the special salt is taken from the detergent
container only.
● If you are using dishwasher detergent and salt separately,
the special salt is to be put into the salt container.
- In this case the water softener must be set to between
level 1 and 5 (depending on the water hardness in your
area) to ensure that the special salt is taken from the salt
container only.
PPM
parts per million
°TH
french degrees
°dH
german degrees
41 - 50
30 - 40
19 - 29
4 - 18
< 4
71 - 90
51 - 70
31 - 50
8 - 30
< 8
701 - 900
501 - 700
301 - 500
80 - 300
< 80
level 5
level 4
level 3
level 2
level 1
yes
yes
yes
yes
no
Water hardness
Water
hardness
setting
Use of
salt
AA08
35
Only use salt specifically designed for use in
dishwashers.
All other types of salt not specifically designed for use in
a dishwasher, especially table salt, will damage the water
softener.
Only fill with salt just before starting one of the washing
programmes (except the Rinse and Hold programme).
This will prevent any grains of salt or salty water, which
may have been spilt, remaining on the bottom of the
machine for any period of time, which may cause
corrosion.
To fill:
1. Open the door, remove the lower basket and unscrew the
cap of the salt container by turning it anticlockwise.
2. Pour 1 litre of water inside the container (this is necessary
only before filling with salt for the first time).
3. Using the funnel provided,
pour in the salt until the
container is full.
4. Replace the cap making
sure that there is no trace
of salt on the screw
thread or on the gasket.
5. Screw on the cap tightly
turning it clockwise until it
stops with a click.
The salt container will require topping up periodically.
According to the model of dishwasher, you are reminded
of this by:
A) The salt cap has a refill indicator window in the centre.
A green float is clearly visible when there is salt inside the
container and almost disappears when the salt has finished
reminding you to add salt.
B) Asalt indicator light on
the control panel will come on when the salt has finished.
The salt indicator light on the control panel can remain
illuminated for 2-6 hours after the salt has been replenished,
assuming the dishwasher remains switched on. If you are
using salts that take longer to dissolve then this can take
longer. The function of the machine is not affected.
Do not worry if water over flows from the unit when filling with
salt, this is quite normal.
Rinse aid
Rinse aid is automatically added during the last rinse, ensuring
thorough rinsing, and spot and streak free drying. The
dispenser, which is positioned inside the door, holds about
110 ml of rinse aid, which is sufficient for 16 - 40 dishwashing
programmes, depending upon the dosage setting.
Rinse aid can be added in one of two ways:
● If you are using dishwasher detergent that already contains
rinse aid, the detergent including the rinse aid is placed in
the detergent compartment.
- In this case the rinse aid compartment must be empty.
If in the rinse aid dispenser there is still rinse aid you
must wait until it has finished before using detergent that
contains rinse aid.
● If you are using dishwasher detergent and rinse aid
separately, the rinse aid is to be put into the rinse aid
dispenser.
- In this case the rinse aid dosage must be set in position
from 1 to 6 (see "Adjusting the dose") and the rinse aid
indicator light activated.
Filling with rinse aid
(Rinse aid dispenser type A)
1. Open the container by pressing the release button (A).
2. Fill with rinse aid exactly up to the level indicator marked
"max".
Ensure that the lid is closed after every refill.
Adjusting the dose
According to the finish and drying results obtained, adjust the
dose of rinse aid by means of the 6 position selector (position
1 minimum dosage, position 6 maximum dosage).
Increase the dose if there are drops of water or lime spots on
the dishes after washing.
The dose is factory set in
position 4.
Reduce it if there are sticky
whitish streaks on the dishes.
SR14
SALE
ZOUT
SALT
SALZ
SEL
SR22
BR07
BR14
BR09
36
Filling with rinse aid
(Rinse aid dispenser type B)
1. Open the container by turning the lid (A) anticlockwise.
2. Fill with rinse aid exactly up to the level indicator marked
"max".
Ensure the lid is closed after every refill.
Adjusting the dose
According to the finish and drying results obtained, adjust the
dose of rinse aid by means of the 6 position selector (C)
(position 1 minimum dosage, position 6 maximum dosage).
Increase the dose if there are drops of water or lime spots on
the dishes after washing.
The dose is factory set in position 5.
Reduce it if there are sticky
whitish streaks on the
dishes.
Top up with rinse aid when:
1. The indicator (B) becomes clear,
2. Only for dishwasher models with rinse aid indicator
light:
When the rinse aid indicator light on the control panel
illuminates (when the machine is switched on and the door
closed).
Clean up any rinse aid spilt during filling with an absorbent
cloth to avoid excess foaming during the next wash.
Only use branded rinse aid for dishwashers. Never fill the rinse
aid dispenser with any other substances (e.g. dishwasher
cleaning agent, liquid detergent). This would damage the
appliance.
BR01
BR13
BR11
BR03
BR02
37
Use of detergent
Only use detergents specifically designed for use in
dishwashers.
Using no more then the correct amount of detergent
contributes to reducing pollution.
Prior to the start of a wash programme (not for the "Rinse and
Hold" programme). The detergent is released during the
washing phase.
Please observe the manufacturer’s dosing and storage
recommendations as stated on the detergent packaging.
Fill with detergent
(Detergent dispenser type A)
1. If the lid is closed: press release button (1).
The lid springs open.
2. Fill the detergent dispenser (2) with detergent.
The marking indicates the dosing levels:
20 = approximately 20 ml of detergent
30 = approximately 30 ml of detergent
3. All programmes with prewash need an additional detergent
dose (5 g) that must be placed in the prewash detergent
chamber (3). This detergent will take effect during the
prewash phase.
4. Close the lid and press until it locks in place.
Fill with detergent
(Detergent dispenser type B)
1. Open the dispenser by pulling the catch (A).
The lid springs open.
2. Fill the detergent dispenser with detergent.
The marking indicates the dosing levels:
Min = approximately 15 g of detergent
Max = approximately 30 g of detergent
3. Close the lid and press until it locks in place.
4. All programmes with prewash need an additional detergent
dose (5 g) that must be placed over the lid of the dispenser.
This detergent will take effect during the prewash phase.
Use of "3 in 1" combi detergent tablets
General advice
These products are tablets with combined detergent/rinse-aid
and salt functions.
1. Before using these products you should first check that the
water hardness in your supply is compatible with the use of
these products as per the detergent manufacturers (on the
product packaging).
2. These products should be strictly used according to the
detergent manufacturers instructions.
Do not place the tablets in the tub or in the cutlery
basket as this will result in poorer wash results. The
tablets should be placed in the detergent dispenser.
3. If you encounter problems when using 3 in 1 products for
the first time then please contact the detergent
manufacturers care line (the telephone number is given on
the product packaging).
Special advice
When using combination products, the rinse-aid and salt
indicators are no longer useful (please note that only some
dishwashers have these options). Select the lowest possible
setting for water hardness.
For more information please refer to the instruction manual.
If you decide to turn back to the use of the standard detergent
system we advise that you:
● Refill both the salt container and rinse aid dispenser.
● Switch the water hardness setting to the highest possible
position and run a normal washing programme without a
load.
● Readjust the water hardness setting again according to the
hardness of the water in your area.
Concentrated detergent
Based on their chemical composition, dishwasher detergents
can be split into two basic types:
- conventional, alkaline detergents with caustic components.
- low alkaline concentrated detergents with natural enzymes.
The use of 50°C washing programmes in conjunction with
concentrated detergents reduces pollution and is good for your
dishes; these wash programmes are specially matched to the
dirt-dissolving properties of the enzymes in the concentrated
detergent. For this reason 50°C wash programmes in which
concentrated detergents are used can achieve the same
results that can otherwise only be achieved using 65°C
programmes.
Detergent tablets
Detergent tablets of different brands dissolve at different
speeds. For this reason some detergent tablets cannot
develop their full cleaning power during short programmes.
Therefore please use normal programmes with prewash when
using detergent tablets.
DE19
DE22
DE17
DE02
38
Clean the external surfaces of the machine and control panel
with a damp soft cloth. If necessary use only neutral
detergents. Never use abrasive products, scouring pads or
solvent (acetone, trichloroethylene etc....).
Ensure that the seals around the door, the detergent and rinse
aid dispensers are cleaned regularly with a damp cloth.
We recommend every 3 months to run a 65°C wash
programme without dishes using detergent.
Cleaning the filters
The filters in the base of the washing compartment are to a
large extent self-cleaning. Nevertheless the filters should be
checked and cleaned from time to time. Dirty filters will
degrade the washing result.
1. Open the door, remove the lower basket.
2. The dishwasher filter system comprises a coarse/fine filter
(A/B), a microfilter (C) and a flat filter (D).
Some dishwasher models filter system comprises only a
coarse filter (A), a microfilter (C) and a flat filter (D).
Unlock the filter system using the handle on the microfilter,
and remove.
3. Turn the handle about
1
/4a turn anticlockwise and remove.
4. Take hold of the coarse/fine filter (A/B) by the handle with
the hole and remove from the microfilter (C).
5. Clean all filters thoroughly under running water.
6. Remove the flat filter (D) from the base of the washing
compartment and clean both faces thoroughly.
7. Put the flat filter back in the base of the washing
compartment.
8. Place the coarse/fine filter in the microfilter and press
together.
9. Put the filter combination in place and lock by turning the
handle clockwise to the stop. During this process ensure
that the flat filter does not protrude above the base of the
washing compartment.
Under no circumstances may the dishwasher be used
without filters.
To ensure a correct
working of the dishwasher,
NEVER try to remove the
upper spray arm.
If residues of soil have
clogged the holes in the
upper spray arm, remove
them with a toothpick.
Prolonged periods of non-operation
If you are not using the machine for any period of time you are
advised to:
1. Unplug the appliance and then turn off the water.
2. Fill the rinse aid dispenser.
3. Leave the door ajar to prevent the formation of any
unpleasant smells.
4. Leave the inside of the machine clean.
Frost precautions
Avoid placing the machine in a location where the temperature
is below 0°C. If this is unavoidable, empty the machine, close
the appliance door, disconnect the water inlet pipe and empty
it.
Moving the machine
If you have to move the machine (moving house etc....):
1. Unplug it.
2. Turn the water tap off.
3. Remove the water inlet and discharge hoses.
4. Pull the machine out together with the hoses.
Avoid over tilting the machine during transportation.
Maintenance and cleaning
MA33
MA32
MA36
MA35
MA31
...the wash results are not satisfactory
The dishes are not clean
● The wrong washing programme has been selected.
● The dishes were arranged in such a way as to stop water reaching all parts of the surface. The baskets must not be overloaded.
● The spray arms do not rotate freely due to wrong arrangement of the load.
● The filters in the base of the washing compartment are dirty or incorrectly positioned.
● Too little or no detergent has been used.
● Where there are limescales deposits on the dishes; the salt container is empty or the wrong level of the water softener has been
selected.
● The drain hose connection is not correct.
● The salt container cap is not properly closed.
The dishes are wet and dull
● Rinse aid was not used.
● The rinse aid dispenser is empty.
There are streaks, milky spots or a bluish coating on glasses and dishes
● Decrease rinse aid dosing.
Water drops have dried onto glasses and dishes
● Increase rinse aid dosing.
● The detergent may be the cause. Contact the detergent manufacturer’s consumer care line.
39
What to do, when...
Certain problems are due to the lack of simple maintenance or oversights, which can be solved with the help of the instructions
given here, without calling out an engineer.
...there are problems when operating the dishwasher
The dishwasher will not start or stops during operation. All push buttons are inoperative except for the On/Off push button. Press the
On/Off push button to switch the dishwasher off and carry out the following suggested corrective actions.
Once the checks have been carried out, press the On/Off push button, the programme will continue from the point in which it was
interrupted. If the malfunction reappears contact the consumer services department.
The machine does not fill with
water.
The dishwasher will not drain.
Malfunction Possible cause Solutions
The water tap is blocked or furred with
limescale.
The water tap is turned off.
The filter (where present) in the threaded hose
fitting at the water inlet valve is blocked.
The water inlet hose has not been correctly laid
or it is bent or squashed.
Clean the water tap.
Turn the water tap on.
Clean the filter in the threaded hose
fitting.
Check the water inlet hose connection.
The siphon is blocked. Clean out the siphon.
The water drain hose has not been correctly laid
or it is bent or squashed.
Check the water drain hose connection.
The programme does not start
There is a whistling noise during
washing
The dishwasher door has not been properly
closed.
The main plug is not plugged in.
The fuse has blown in the household fuse box.
For dishwasher models with delay start
option:
Delay start has been selected.
Close the door.
Insert the mains plug.
Replace the fuse.
If dishes are to be washed immediately,
cancel the delay start.
Use a different brand of detergent.The whistling is not a cause for concern.
40
If after all these checks, the problem persists, contact your
local consumer services department, quoting the model
(Mod.), product number (PNC) and serial number (S.N.).
This information can be found on the rating plate located on
the right hand side of the dishwasher door (see picture).
So that you always have these numbers at hand, we
recommend you to make a note of them here:
Mod. : . . . . . . . . . . . . . . . . . .
PNC : . . . . . . . . . . . . . . . . . .
S.N. :. . . . . . . . . . . . . . . . . . .
Service and spare parts
This product should be serviced by an authorised service
engineer, and only genuine spare parts should be used.
Under no circumstances should you attempt to repair the
machine yourself.
Repairs carried out by inexperienced persons may cause injury
or serious malfunctioning. Contact your local consumer
services department.
Always insist on genuine spare parts.
Installation instructions
Any electrical and/or plumbing work required to install
this appliance should be carried out by a qualified
electrician and/or plumber or competent person.
Remove all packaging before positioning the machine.
If possible, position the machine next to a water tap and a
drain.
Water supply connections
This dishwasher may be fed with either hot (max. 60°) or cold
water (See "Technical specifications" - Instruction book part 2).
Nevertheless we advise you a cold water supply.
A hot water supply is not always efficient with very soiled
crockery as it shortens the washing programmes a lot.
The dishwasher must not be connected to open hot water
appliances or instantaneous water heaters.
The water pressure must be within the limits given in the
technical specifications. Your local Water Authority will advise
you on the average mains pressure in your area.
The water inlet hose must not be kinked, crushed, or entangled
when it is being connected up.
The dishwasher features fill and drain hoses which can be
turned either to the left or the right to suit the installation.
The dishwasher is fitted with safety devices that prevent the
wash water returning into the drinking water system and
comply with the applicable plumbing regulations.
Do not use, for connection, old hoses which have been
used in another appliance.
If the machine is connected to new pipes or pipes which have
not been used for a long time, you should run the water for a
few minutes before connecting the inlet hose.
Water outlet hose connection
The end of the drain hose can be connected in the following
ways:
1. To the sink outlet spigot, securing it to the underside of the
work surface. This will prevent waste water from the sink
running into the machine.
2. Hooked over the edge of the sink using the special curved
plastic guide provided (if provided with the machine).
3. To a stand pipe provided with vent-hole, minimum internal
diameter 4 cm.
The waste connection must be at a height of between 30 cm
(minimum) and 100 cm (maximum) from the bottom of the
dishwasher.
The drain hose can face either to the right or left of the
dishwasher
Ensure the hose is not bent or squashed as this could prevent
or slow down the discharge of water.
The sink plug must not be in place when the machine is
draining as this could cause the water to siphon back into the
machine.
If you use a drain hose extension it must be no longer than 2
metres and its internal diameter must be no smaller than the
diameter of the hose provided.
Likewise the internal diameter of the couplings used for
connections to the waste outlet must be no smaller than the
diameter of the hose provided.
Attention!
Our appliances are supplied with a security device to protect
against the return of dirty water back into the machine.
If the spigot of your sink has a "no return valve" incorporated
this can prevent the correct draining of your dishwasher.
We advise you therefore to remove it.
RA08
CS18
41
Electrical connection
Information concerning the electrical connection is given on the
rating plate on the edge of the dishwasher’s door on the right.
Before plugging the appliance into the wall socket, make sure
that:
1. The mains voltage and current rating at the site of
installation match the nominal voltage and current rating
given on the rating plate.
2. The meter, fuses, mains power supply and wall socket can
all take the maximum load required. Make sure that the
socket and plug are compatible without having to use any
type of adaptor. If necessary, have the domestic wiring
system socket replaced.
To isolate the dishwasher from mains, remove the mains plug.
Important!
The plug must still be accessible after the appliance
has been installed.
In case that the electrical cable has to be replaced,
please contact your local consumer services
department.
Safety standards require the appliance to be
earthed.
The manufacture accepts no liability for failure to
observe the above safety precautions.
This appliance complies with the following E.E.C. Directives:
- 73/23 or 19.2.73 (Low Voltage Directive) and subsequent modifications;
- 89/336 or 3.5.89 (Electromagnetic Compatibility Directive) and subsequent modifications.
Wijzigingen voorbehouden - sous réserve de modifications
Änderungen vorbehalten - subject to change with notice
152971 02/1
1 01/03
Loading...
