User’s Manual

IM CA71-E

Model CA51, CA71 HANDY CAL (Calibrator)

5 Commonwealth Ave Woburn, MA 01801 Phone 781-665-1400

Free 1-800-517-8431

Toll

Visit us at www.TestEquipmentDepot.com

Store this manual in an easily accessible place for quick reference.

10th Edition: Nov. 2018 (YMI)

IM CA71-E

Introduction

Thank you for purchasing the CA51/CA71 HANDY CAL Calibrator. This User’s Manual explains the functions of the CA51 and CA71, as well as the operating methods and handling precautions. Before using this product, thoroughly read this manual to understand how to use it properly.

■ List of Manuals

The following manuals, including this one, are provided as manuals for the CA51 and CA71. Please read all manuals.

Manual No. Description

IM CA71-E User's Manual (this manual) IM CA71-93Z2 Document for Korea

Contact information of Yokogawa ofces worldwide is provided on

the following sheet.

Document No. Description

PIM 113-01Z2 Inquiries List of worldwide contacts

10th Edition: November 2018 (YMI) All Rights Reserved. Copyright © 2002, Yokogawa M&C Corporation, 2014, Yokogawa Meters & Instruments Corporation, 2017, Yokogawa Test & Measurement Corporation Printed in Japan

IM CA71-E

Introduction

■ Notes

● This manual exclusively describes the CA71, which is more

multifunctional than the CA51. The CA51 has no temperature measurement and communication functions.

● The contents of this manual are subject to change without prior

notice for reasons of improvements in performance and/or functionality.

● Every effort has been made to ensure the accuracy of this manual.

If you notice any errors or have any questions, however, please contact the vender from which you purchased the instrument.

● The content of this manual may not be transcribed or reproduced,

in part or in whole, without prior permission.

■ Trademark Acknowledgments

● All other company and product names appearing in this document

are trademarks or registered trademarks of their respective holders.

■ Revision Information

February 2002: First Edition December 2006: 2nd Edition November 2007: 3rd Edition January 2012: 4th Edition July 2014: 5th Edition April 2015: 6th Edition April 2016: 7th Edition August 2017: 8th Edition October 2017: 9th Edition November 2018: 10th Edition

IM CA71-E

Checking Items in the Package

After opening the package, check the product as follows before use. If the delivered product is the wrong model, any item is missing, or there are visible defects, contact the vendor from which you purchased the product.

Main Unit

Check the model (specications) codes in the MODEL and SUFFIX elds of the nameplate at the back of the instrument to ensure that the instrument is exactly as specied in your purchase order.

• Model Codes

Model Specication

CA51 Basic model CA71 Provided with temperature measurement and

communication functions

• NO. (Serial Number) Refer to this serial number on the nameplate when contacting the vendor about the instrument.

IM CA71-E

iii

Checking Items in the Package

Lead cables

Lead cables for

Carrying case

Terminal adapter

Standard Accessories

Make sure that the package contains all the accessories listed below and that they are all free from any damage. Standard accessories are not covered by warranty of this instrument.

for source

(98020)

(99021)

measurement

(RD031)

AA-size (LR6)

alkaline batteries

(four units)

(93016)

User’s manual

(IM CA71-E)

Optional Accessories

The products listed below are available as optional accessories. If you purchased some of the optional accessories, make sure the delivered package is complete with the ordered items and they are free from any damage. For technical and ordering inquiries concerning the accessories, contact the vendor from which you purchased the instrument.

IM CA71-E

Accessories case

RJ sensor Communication cable

Checking Items in the Package

Product Part Number Remarks

AC adapter 94012 For 100 VAC AC adapter 94013 For 120 VAC AC adapter 94016 For 220 to 240 VAC RJ sensor B9108WA For reference junction compensation Accessories case B9108XA Communication cable (RS232)

91017 (For CA71 only)

Power cord of AC adapter: 94016-F (VDE standard), 94016-S (BS stanndard)

Make sure that the attached power cord meets the designated standards of the country and area that you are using it in.

Optional Spare Parts

Product Part Number Remarks

Lead cable for source 98020 Lead cable for measurement Carrying case 93016 Terminal adapter 99021 Used for temperature measurement Fuse --- A1635EF (1 piece)

RD031

IM CA71-E

AC adapter

Precautions for Safe Use of the Instrument

This product is designed to be used by a person with specialized knowledge.When operating the instrument, be sure to observe the cautionary notes given below to ensure correct and safe use of the instrument. If you use the instrument in any way other than as instructed in this manual, the instrument’s protective measures may be impaired. This manual is an essential part of the product; keep it a safe place for future reference. YOKOGAWA is by no means liable for any damage resulting from use of the instrument in contradiction to these cautionary notes.

The following symbols are used on the instrument and in the User’s Manual to ensure safe use.

Danger! Handle with Care. This symbol indicates that the operator must refer to an explanation in the User’s Manual in order to avoid

the risk of injury or loss of life of personnel or damage to

the instrument. This symbol indicates DC voltage/current. This symbol indicates AC voltage/current. This symbol indicates AC or DC voltage/current.

WARNING

Indicates that there is a possibility of serious personal injury or loss of life if the operating procedure is not followed correctly and describes

the precautions for avoiding such injury or loss of life.

CAUTION

Indicates that there is a possibility of serious personal injury or damage to the instrument if the operating procedure is not followed correctly and

describes the precautions for avoiding such injury or damage.

IM CA71-E

Precautions for Safe Use of the Instrument

NOTE

Draws attention to information essential for understanding the operation and features.

TIP

Provides additional information to complement the present topic.

Damage to the instrument or personal injury or even loss of life may result from electrical shock or other factors. To avoid this, follow the precautions below.

WARNING

• Use the instrument Only for Its Intended Purpose

This instrument is for generating (sourcing)/measuring voltage or current. (This instrument is for generating and measuring resistance and generating and measuring temperature using resistance or thermocouples.) Do not use this instrument for other purpose.

• Check the Physical Appearance

Do not use the instrument if there is a problem with its physical appearance.

• Use in gases

Do not operate this instrument in areas where inammable or explosive gases or vapor exists. It is extremely hazardous to use the instrument under such environments.

• Defects in protective features

Do not operate this instrument if any defect seems to exist in such protective features as fuses. Before operating the instrument, make sure the protective features are free from any defect.

• External connection

When connecting the instrument to the object under test or an external control circuit, or if you need to touch any external circuit, cut off the power to the circuit and make sure no voltage is being supplied.

• Fuses

In order to prevent a possible re, use a fuse with ratings (current, voltage, and type) specied for the instrument. Do not short-circuit the fuse holder.

IM CA71-E

vii

Precautions for Safe Use of the Instrument

WARNING

• Correct Use of Lead Cables

Use the lead cables supplied by YOKOGAWA with this instrument. Do not use lead cables that have deteriorated or are defective. Check lead cables continuity. Correctly use the lead cables for measurement (P/N: RD031) and source (P/N: 98020) without mistaking one for the other. For high-voltage measurement, always use the lead cable for measurement.

• Damaged Signal Cable

If the signal cable (lead cables) is torn and the inner metal is exposed or if a color different from the outer sheath appears, stop using the cable immediately.

• Do Not Remove the Casing or Disassemble

Only Yokogawa service personnel are authorized to remove the casing or disassemble or modify the instrument. Do not attempt to repair the instrument yourself, as doing so is extremely dangerous. Some parts inside the instrument are extremely dangerous because they use a high voltage. When the instrument needs an internal inspection or calibration, contact YOKOGAWA or the dealer from whom you purchased the instrument.

CAUTION

This product is for domestic use (Class B) and meets the electromagnetic compatiblity requirements.

viii

IM CA71-E

Precautions for Safe Use of the Instrument

For the safe use of the optional AC adapter, follow the precautions given below.

WARNING

• Make sure that the rated power supply voltage of the instrument matches the voltage of the power supply before turning on the power.

• To prevent the possibility electrical shock or re, be sure to use the AC adapter and the power cord supplied by YOKOGAWA.

Additionally, do not use the AC adapter and the power cord supplied with

this instrument with another instrument.

• Do not place anything on the AC adapter or power cord, and prevent heat sources from coming into contact with them.

• When unplugging the power cord from the outlet, be sure to hold the plug and never pull the actual cord.

• Do not throw (dispose of ) the AC adapter in re or apply heat to it.

• Do not use it, where the cord is bundled (bent).

• If the power cord is damaged, contact your dealer.

IM CA71-E
