EDITION 66 CATALOG

SPECIALIZED AND GENERAL USE GAUGES

MACHINES

RECOVERY

99 Washington Street Melrose, MA 02176

Phone 781-665-1400 Toll Free 1-800-517-8431

Visit us at www.TestEquipmentDepot.com

VACUUM PUMP

SYSTEMS

CHARGING HOSES

VACUUM AND

VALVES AND PARTS

HOSE ADAPTERS,

CHARGING

SYSTEMS

WIRELESS AND

INSTRUMENTS

ELECTRONIC

INSTRUMENTS

HEATING

AND DETECTORS

LEAK MONITORS

SYSTEM TOOLSGAUGES

Page 2

RECOVERY

MACHINES

SYSTEMS

VACUUM PUMP

VACUUM AND

CHARGING HOSES

HOSE ADAPTERS,

VALVES AND PARTS

YELLOW JACKET HVAC&R

SYSTEMS

CHARGING

GAUGES

ELECTRONIC

INSTRUMENTS

WIRELESS AND

HEATING

INSTRUMENTS

YELLOW JACKET

3-1/8" Dry Manifold Gauges

Class 1 (1% accuracy) calibration with high visibility colored temperature scales

LEAK MONITORS

AND DETECTORS

SYSTEM TOOLS

Page 3

EDITION 66 CATALOG

3-1/8" (80 mm) DRY MANIFOLD GAUGES (°F and °C) RED, BLUE AND BLACK With 1% accuracy (Class 1) calibration

Large 3-1/8" gauges are housed in a red or blue steel case with front recalibrator screw. High visibility colored temperature scales are easy to read through the full view polycarbonate crystal.

™

• Flutterless needle pulsation

• Brass gauge movement

• Copper alloy Bourdon tube

• 1/8" NPT Male connection

• Calibrated to 1% accuracy

• Color-coded red for pressure and blue for compound

• Color-coded refrigerant types

When a gauge has a RETARD zone, full scale is considered to be the last marked reading prior to entering the RETARD zone. For example, this gauge has a full scale reading of 120 psi. Gauge accuracy is not speciﬁ ed in the RETARD zone.

ºF - Fahrenheit Gauges

UPC# Description Pressure scale Refrigerants

49103 3-1/8" Red pressure 0 - 500 psi 49104 3-1/8" Blue compound 30"-0-120** psi 49105 3-1/8" Red pressure 0 - 500 psi 49106 3-1/8" Blue compound 30"-0-120** psi 49111 3-1/8" Red pressure 0 - 500 psi 49112 3-1/8" Blue compound 30"-0-120** psi 49133 49134 49137 3-1/8" Red pressure 0 - 800 psi 49138 3-1/8" Blue compound 30"-0-350*** psi 49141* 49142* 49151 3-1/8" Red pressure 0 - 500 psi 49152 3-1/8" Blue compound 30"-0-120** psi 49157 3-1/8" Red pressure 49158 3-1/8" Blue compound

Universal Gauges

UPC# Description Pressure scale Refrigerants

49149 3-1/8" Red pressure bar, KPa, psi 49150 3-1/8" Blue compound bar, KPa, psi 49155 3-1/8" Red pressure 49156 3-1/8" Blue compound

Certiﬁ ed Gauges

49203 3-1/8" Red pressure 0 - 500 psi 49204 3-1/8" Blue compound 30"-0-120** psi 49205 3-1/8" Red pressure 0 - 500 psi 49206 3-1/8" Blue compound 30"-0-120** psi

* These gauges have °C and °F on dial. ** Features retard protection to 350 psi.

49237 3-1/8" Red pressure 0 - 800 psi

*** Features retard protection to 500 psi.

49238 3-1/8" Blue compound 30"-0-350*** psi 49251 3-1/8" Red pressure 0 - 500 psi 49252 3-1/8" Blue compound 30"-0-120** psi 49100 Replacement crystal

technology with brass surge protector to minimize

R-12/22/134a

R-22/134a/404A

R-417A/422A/422D

3-1/8" Heat pump red dial 3-1/8" Heat pump blue dial

0 - 800 psi

0 - 800 psi 0 - 800 psi

R-22/407C/410A

R-22/404A/410A

R-410A

R-134a/404A/407C

R-600

R-32

R-12/22/134a

R-22/134a/404A

R-22/404A/410A

R-134a/404A/407C

ºC - Celsius Gauges

UPC# Description Pressure scale Refrigerants

49107 3-1/8" Red pressure kPa and psi 49108 3-1/8" Blue compound kPa and psi 49169 3-1/8" Red pressure bar and psi 49170 3-1/8" Blue compound bar and psi 49109* 3-1/8" Red pressure kPa and psi 49110* 3-1/8" Blue compound kPa and psi 49153 3-1/8" Red pressure bar and MPa 49154 3-1/8" Blue compound bar and MPa 49131 3-1/8" Red pressure bar and psi 49132 3-1/8" Blue compound bar and psi 49139 3-1/8" Red pressure psi 49140 3-1/8" Blue compound psi 49141*

3-1/8" Heat pump red dial

49142*

3-1/8" Heat pump blue dial 49145 3-1/8" Red pressure bar and psi 49146 3-1/8" Blue compound bar and psi 49147 3-1/8" Red pressure MPa 49148 3-1/8" Blue compound MPa 49159* 3-1/8" Red pressure bar and psi 49160* 3-1/8" Blue compound bar and psi 49163 3-1/8" Red pressure bar and MPa 49164 3-1/8" Blue compound bar and MPa 49165 3-1/8" Red pressure bar and psi 49166 3-1/8" Blue compound bar and psi 49181 3-1/8" Red pressure bar and psi 49182 3-1/8" Blue compound bar and psi

Certiﬁ ed Gauges

49231 3-1/8" Red pressure bar and psi 49232 3-1/8" Blue compound bar and psi 49245 3-1/8" Red pressure bar and psi 49246 3-1/8" Blue compound bar and psi 49259 3-1/8" Red pressure bar and psi 49260 3-1/8" Blue compound bar and psi 49263 3-1/8" Red pressure bar and MPa 49264 3-1/8" Blue compound bar and MPa 49265 3-1/8" Red pressure bar and psi 49266 3-1/8" Blue compound bar and psi 49269 3-1/8" Red pressure bar and psi 49270 3-1/8" Blue compound bar and psi 49100 Replacement crystal

* These gauges have °C and °F on dial.

0 - 800 psi 0 - 800 psi

R-22/134a/404A

R-32/410A

R-410A

R-134a/404A/407C

R-22/404A/410A

R-410A

R-12/22/502

R-32/410A

R-134a/404A/407C

R-12/134a/413A

R-134a/404A/407F

R-134a/404A/407C

R-12/22/502

R-32/410A

R-134a/404A/407C

R-12/134a/413A

R-22/134a/404A

MACHINES

RECOVERY

VACUUM PUMP

SYSTEMS

CHARGING HOSES

VACUUM AND

VALVES AND PARTS

HOSE ADAPTERS,

CHARGING

SYSTEMS

GAUGES

WIRELESS AND

INSTRUMENTS

ELECTRONIC

INSTRUMENTS

HEATING

AND DETECTORS

LEAK MONITORS

SYSTEM TOOLSGAUGES

Page 4

RECOVERY

MACHINES

3-1/2" (90 mm) LIQUID-FILLED

With 1% accuracy (Class 1) calibration

SYSTEMS

VACUUM PUMP

VACUUM AND

CHARGING HOSES

HOSE ADAPTERS,

VALVES AND PARTS

Gauges are completely ﬁ lled with glycerin for maximum protection from pulsation. Large 3-1/2" (90 mm) diameter gauge with refrigerants color-coded on the dials in bold numbers. Offset stem ﬁ ts all major manifold brands.

• Now with zero adjustment

SYSTEMS

CHARGING

• 1/8" NPT Male connection

• Temperature rating of 0° to 122°F (-18° to 50°C)

• Calibrated to 1% accuracy (Class 1)

GAUGES

ELECTRONIC

WIRELESS AND

HEATING

INSTRUMENTS

LEAK MONITORS

AND DETECTORS

ºF - Fahrenheit and ºC - Celsius Gauges

UPC# Description Pressure scale Refrigerants

49511 3-1/2" Red pressure 0-500 psi (0 to 34 bar) 49512 3-1/2" Blue compound 30"-0-120 psi (-1 to 8 bar) 49519 3-1/2" Red pressure 0-800 psi (0 to 55 bar) 49520 3-1/2" Blue compound 30"-0-300* psi (-1 to 21 bar)

ºF - Fahrenheit Gauges

UPC# Description Pressure scale Refrigerants

INSTRUMENTS

49513 3-1/2" Red pressure 0-500 psi 49514 3-1/2" Blue compound 30"-0-120 psi 49515 3-1/2" Red pressure 0-800 psi 49516 3-1/2" Blue compound 30"-0-300* psi 49517 3-1/2" Red pressure 0-500 psi 49518 3-1/2" Blue compound 30"-0-120 psi

ºC - Celsius Gauges

UPC# Description Pressure scale Refrigerants

49521 3-1/2" Red pressure 0-500 psi (0 to 35 bar) 49522 3-1/2" Blue compound 30"-0-116 psi (-1 to 8 bar)

*Features retard protection to 500 psi.

MANIFOLD GAUGES (°F and °C) RED AND BLUE

R-22

R-410A

R-22/134a/404A

R-22/410A

R-134a/404A/407C

R-134a/ 404A/407C

YELLOW JACKET HVAC&R

2-1/2" (68 mm) MANIFOLD GAUGES (°F and °C) RED AND BLUE Class B

• Steel case with 3-2-3% accuracy

• High-visibility dials - colored temperature scales for easy reading;

™

• Flutterless pulsation for improved accuracy

• 1/8" NPT Male connection; calibration traceable to NIST standards

ºF - Fahrenheit Gauges

UPC# Description Pressure scale Refrigerants

49001 2-1/2" Red pressure 0 - 500 psi 49002 2-1/2" Blue compound 30"-0-120** psi R-12/22/502 49013* 2-1/2" Red pressure 0 - 500 psi 49014* 2-1/2" Blue compound 30"-0-120** psi 49015 2-1/2" Red pressure 0 - 500 psi 49016 2-1/2" Blue compound 30"-0-120** psi 49035* 2-1/2" Red pressure 0 - 800 psi/kg/cm 49036* 2-1/2" Blue compound 49051 2-1/2" Red pressure 0 - 500 psi 49052 2-1/2" Blue compound 30"-0-120** psi 49053* 2-1/2" Red pressure 0 - 55 bar (0-5.5 MPa) 49054* 2-1/2" Blue compound -1 - 21 bar (-0.1 - 2.1 MPa) 49010 Replacement crystal

* These gauges have ºC and ºF on dial. ** Features retard protection to 350 psi. *** Features retard protection to 500 psi. Note: Small screw in back is 6/32" x 5/32" Phillips pan head screw. Note: Gauges not meant to be used with nitrogen.

ºC - Celsius Gauges

UPC# Description

49005 2-1/2" Red pressure bar and psi 49006 2-1/2" Blue compound bar and psi 49027 2-1/2" Red pressure kg/cm 49028 2-1/2" Blue compound kg/cm 49031 2-1/2" Red pressure bar and psi 49032 2-1/2" Blue compound bar and psi 49033 2-1/2" Red pressure bar and psi 49034 2-1/2" Blue compound bar and psi 49055 2-1/2" Red pressure bar and psi 49056 2-1/2" Blue compound bar and psi 49057 2-1/2" Red pressure kg/cm 49058 2-1/2" Blue compound kg/cm

* These gauges have ºC and ºF on dial.

49063 2-1/2" Red pressure bar and psi 49064 2-1/2" Blue compound bar and psi 49010 Replacement crystal

technology surge protector minimizes the needle

R-134a

R-22/134a/404A

30"-0-300*** psi/kg/cm2

Pressure scale

and psi

R-410A

R-134a/404A/507

R-410A

Refrigerants

R-12/22/502

R-22/134a/407C

R-22/134a/404A

R-134a/404A/507

R-134a/404A/407C

SYSTEM TOOLS

Page 5

EDITION 66 CATALOG

HEAVY DUTY 2-1/2" BRASS MANIFOLD GAUGES (°F and °C)

With 1% accuracy (Class 1) calibration

• 1/8" NPT Male connection

• Calibrated to 1% accuracy

• Full view glass crystal

UPC# Description Pressure scale Refrigerants

49067 °F Brass pressure 0 - 500 psi 49068 °F Brass compound 30"-0-120* psi 49073 °C Brass pressure 0 - 500 psi 49074 °C Brass compound 30"-0-120* psi

Certiﬁ ed Gauges

49199 2-1/2" Brass pressure 0 - 500 psi 49200 2-1/2" Brass compound 30"-0-120* psi

Solid brass case and premium movements. Heavy duty phosphor bronze and stainless steel internal components for longer service life under severe use.

™

• Flutterless needle pulsation

technology with brass surge protector to minimize

49010 Replacement crystal (polycarbonate) for old 49011, 49012 49039 Glass crystal for brass gauge 49040 Brass gauge ring

*Features retard protection to 350 psi.

Note: Gauges are not meant to be used with nitrogen.

R-22/134a/404A

R-134a/404A/407C

R-22/134a/404A

MACHINES

RECOVERY

VACUUM PUMP

SYSTEMS

CHARGING HOSES

VACUUM AND

VALVES AND PARTS

HOSE ADAPTERS,

CHARGING

SYSTEMS

PROTECTIVE GAUGE BOOTS

For 2-1/2" and 3-1/8" gauges

• Rubber boots slip easily around gauges to cushion and protect them from impact

• Fit 2-1/2" or 3-1/8" gauges without covering easy access

recalibration screw

• Color-coded red or blue to match gauge

UPC# Description

49090 2-1/2" Set of gauge boots 49091 2-1/2" Red protective gauge boot 49092 2-1/2" Blue protective gauge boot 49190 3-1/8" Set of gauge boots 49191 3-1/8" Red protective gauge boot 49192 3-1/8" Blue protective gauge boot 49087 Red solar gauge boot 49088 Blue solar gauge boot 49089 Set red and blue solar gauge boots

GAUGES

WIRELESS AND

INSTRUMENTS

ELECTRONIC

INSTRUMENTS

HEATING

AND DETECTORS

LEAK MONITORS

SYSTEM TOOLSGAUGES

Page 6

RECOVERY

MACHINES

SYSTEMS

VACUUM PUMP

VACUUM AND

CHARGING HOSES

HOSE ADAPTERS,

VALVES AND PARTS

SYSTEMS

CHARGING

YELLOW JACKET HVAC&R

3-1/8" MECHANICAL VACUUM GAUGES

Full range mechanical Bourdon tube steel gauges for determining system vacuum is more accurate than a compound gauge. All gauges are 1/8" NPT Male bottom connection.

• Larger to show vacuum more accurately in inches of mercury and Torr (or millibar)

CAUTION: Vacuum gauges must be handled carefully. Dropping, pressurizing and rough handling reduce their life.

GAUGES

LOW PRESSURE DIAPHRAGM

2-1/2" GAUGES

ELECTRONIC

INSTRUMENTS

WIRELESS AND

HEATING

INSTRUMENTS

• The bronze diaphragm is designed for better protection on incidental overpressure

• Intended for low pressure applications only

LEAK MONITORS

AND DETECTORS

• Black steel case

• Cannot be recalibrated

UPC# Description Range

78056 2-1/2" Barb type connection 0-10" W.C. 78061 2-1/2" Barb type connection 0-35" W.C.

SYSTEM TOOLS

78057 2-1/2" 1/4" NPT Male connection 0-10" W.C. 78066 2-1/2" 1/4" NPT Male connection 0-35" W.C.

UPC# Size Scale Connection Case

69044 3-1/8" 0-30" Hg & 760-0 Torr 1/8" NPT Male lower Green 69045 3-1/8" 1000-0 millibar & 30-0" (Euro) 1/8" NPT Male lower Green

2-1/2" AMMONIA GAUGES

With dual scale

Ammonia gauges are designed for use on manifolds and as permanent gauges on any system or equipment charged with ammonia. The Bourdon tube is made of 316 stainless. The dials show dual temperature and pressure scales. All gauges are equipped with restrictors to protect the gauges against pulsating pressure.

• 1/4" NPT Male connection

• Steel sockets

UPC # Description Range

40201 2-1/2" Gauge with twist 30" - 0 - 400 psi °F

on polycarbonate crystal and -0.1-0-28 bar °C

40202 2-1/2" Gauge with twist 30" - 0 - 150 psi °F

on polycarbonate crystal and -0.1-0-10 bar °C

49010 2-1/2" Replacement crystal

• Black steel gauges

• Calibrated to 3-2-3% accuracy
