Operator's Manual

Automatic

Models

Lawn Tractor

6O4 & 6O5

IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY

Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered,

brush-covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting applicable local or

state laws (if any), If a spark arrester is used, it should be maintained in effective working order by the operator, In the State of California the above is required by law (Section 4442 of the California Public Resources Code), Other states may have similar laws, Federal laws apply on federal lands, A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the

service department, P,O, Box 361131 Cleveland, Ohio 44136-0019,

MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019

PRINTED IN U.S.A.

FORM NO. 770-10448E

(1/3/2005)

TABLEOFCONTENTS

Content CustomerSupport

ImportantSafeOperationPractices SlopeGauge TractorSet-Up

KnowYourLawnTractor OperatingYourLawnTractor

MakingAdjustments

Page Content Page

2 Maintaining Your Lawn Tractor 22

3 Service 23 7 Off Season Storage 27

8 Attachments & Accessories 27

11 Troubleshooting 28 15 Parts List 29

19 Warranty 48

FINDINGMODELNUMBER

This Operator's Manual is an important part of your new lawn tractor. Itwill help you assemble, prepare and maintain the unit for best performance. Please read and understand what it says.

Before you start assembling your new equipment, please locate the model plate under the seat of the tractor and copy the information in the space provided below. A sample model plate is also given below. This information will be necessary to use the manufacturer's web site and/or help from the Customer Support Department or an authorized service dealer.

Copy the model number here:

Copy the serial number here:

YaRD-MaN)/(MToL-c

www.yardman.com 330-220-4683

P. O. BOX 361131

CLEVELAND,OH 44136

800-800-7310

CUSTOMERSUPPORT

Please doNOTretumtheunitto the retailerfromwhereit waspurchased,withoutfirstcontactingCustomerSupport.

If you have difficulty assembling this product or have any questions regarding the controls, operation or maintenance of this unit, you can seek help from the experts. Choose from the options below:

Visit yardman.corn for many useful suggestions. Click on Customer Support button and you will get the four options reproduced here. Click on the appropriate button and help is immediately available.

_;_nsweY you _:_y_}

a mouse crick aw_y!

To reach the Customer Support Line, please call 1-800-800-7310.

[eg_a_/"o d_e_:k the slat_ls e_ y<_l_r q_÷s_ o_s

Hee:l h)cal ass sl _ce_' Click here t_>fh_l

_Manusb O#_i#e

/ook]ngroycou/dbejust

a mouse crickaw_y!

The engine manufacturer is responsible for all engine-related issues with regards to performance, power-rating, specifications, warranty and service. Please refer to the engine

manufacturer's Owner's/Operator's Manual, at the end of this manual, for more information.

SECTION1: IMPORTANTSAFEOPERATIONPRACTICES

WARNING: This symbol points out important safety instructions which, if not followed, could endanger

the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury. When you see this symbol--heed its warning.

DANGER: This machine was built to be operated according to the rules for safe operation in this man-

ual. As with any type of power equipment, carelessness or error on the part of the operator can result in serious injury. This machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death.

California Proposition 65 Warning:

,_ WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain

GENERAL OPERATION

1. Read, understand, and follow all instructions on the

2. Be familiar with all controls and their proper

3. Never allow children under 14 years old to operate

4. Never allow adults to operate this machine without

5. To help avoid blade contact or a thrown object

6. Thoroughly inspect the area where the equipment

7. Plan your mowing pattern to avoid discharge of

8. Always wear safety glasses or safety goggles

9. Wear sturdy, rough-soled work shoes and close-

or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

10. Be aware of the mower and attachment discharge direction and do not point it at anyone. Do not

machine and in the manual(s) before attempting to assemble and operate. Keep this manual in a safe place for future and regular reference and for ordering replacement parts.

operation. Know how to stop the machine and disengage them quickly.

this machine. Children 14 years old and over

should read and understand the operation instructions and safety rules in this manual and should be trained and supervised by a parent.

proper instruction.

injury, keep bystanders, helpers, children and pets at least 75 feet from the machine while it is in

operation. Stop machine if anyone enters the area.

is to be used. Remove all stones, sticks, wire, bones, toys, and other foreign objects which could

be picked up and thrown by the blade(s). Thrown objects can cause serious personal injury.

material toward roads, sidewalks, bystanders and

the like. Also, avoid discharging material against a

wall or obstruction which may cause discharged material to ricochet back toward the operator.

during operation and while performing an adjustment or repair to protect your eyes. Thrown objects which ricochet can cause serious injury to

the eyes.

fitting slacks and shirts. Loose fitting clothes and jewelry can be caught in movable parts. Never

operate this machine in bare feet or sandals.

operate the mower without the discharge cover or entire grass catcher in its proper place.

11. Do not put hands or feet near rotating parts or under the cutting deck. Contact with the blade(s)

can amputate hands and feet.

12. A missing or damaged discharge cover can cause blade contact or thrown object injuries.

13. Stop the blade(s) when crossing gravel drives,

walks, or roads and while not cutting grass.

14. Watch for traffic when operating near or crossing roadways. This machine is not intended for use on

any public roadway.

15. Do not operate the machine while under the influence of alcohol or drugs.

16. Mow only in daylight or good artificial light.

17. Never carry passengers.

18. Disengage blade(s) before shifting into reverse. Back up slowly. Always look down and behind before and while backing to avoid a back-over

accident.

19. Slow down before turning. Operate the machine smoothly. Avoid erratic operation and excessive speed.

20. Disengage blade(s), set parking brake, stop engine and wait until the blade(s) come to a complete stop

before removing grass catcher, emptying grass, unclogging chute, removing any grass or debris, or making any adjustments.

21. Never leave a running machine unattended. Always turn off blade(s), place transmission in neutral, set

parking brake, stop engine and remove key before

dismounting.

22. Use extra care when loading or unloading the

machine into a trailer or truck. This unit should not be driven up or down ramp(s), because the unit

could tip over, causing serious personal injury. The

unit must be pushed manually on ramp(s) to load or unload properly.

23.Mufflerandenginebecomehotandcancausea burn.Donottouch.

24.Checkoverheadclearancescarefullybeforedriving underlowhangingtreebranches,wires,door openingsetc.,wheretheoperatormaybestruckor pulledfromtheunit,whichcouldresultinserious injury.

25.Disengageallattachmentclutches,depressthe brakepedalcompletelyandshiftintoneutralbefore attemptingtostartengine.

26.Yourmachineisdesignedtocutnormalresidential grassofaheightnomorethan10".Donotattempt

tomowthroughunusuallytall,drygrass(e.g.,

pasture)orpilesofdryleaves.Drygrassorleaves maycontacttheengineexhaustand/orbuildupon

themowerdeckpresentingapotentialfirehazard.

27.Useonlyaccessoriesandattachmentsapproved

forthismachinebythemachinemanufacturer.

Read,understandandfollowallinstructions providedwiththeapprovedaccessoryor

attachment.

28.Dataindicatesthatoperators,age60yearsand above,areinvolvedinalargepercentageofriding mower-relatedinjuries.Theseoperatorsshould evaluatetheirabilitytooperatetheridingmower safelyenoughtoprotectthemselvesandothers

fromseriousinjury.

29.Ifsituationsoccurwhicharenotcoveredinthis manual,usecareandgoodjudgment.Contactan

authorizedMTDServiceDealerforassistance.

SLOPE OPERATION

Slopes are a major factor related to loss of control and tip-over accidents which can result in severe injury or death. All slopes require extra caution. If you cannot back up the slope or ifyou feel uneasy on it,do not mow

it. For your safety, use the slope gauge included as part of

this manual to measure slopes before operating this unit on a sloped or hilly area. If the slope is greater than 15 degrees as shown on the slope gauge, do not operate this unit on that area or serious injury could

result.

DO:

1. Mow up and down slopes, not across. Exercise extreme caution when changing direction on slopes.

2. Watch for holes, ruts, bumps, rocks, or other hidden objects. Uneven terrain could overturn the machine. Tall grass can hide obstacles.

3. Use slow speed. Choose a low enough speed setting so that you will not have to stop or shift while on the slope. Tires may lose traction on slopes even though the brakes are functioning properly. Always keep machine in gear when going down slopes to take advantage of engine braking action.

4. Follow the manufacturer's recommendations for wheel weights or counterweights to improve

stability.

5. Use extra care with grass catchers or other attachments. These can change the stability of the

machine.

6. Keep all movement on the slopes slow and gradual.

Do not make sudden changes inspeed or direction.

Rapid engagement or braking could cause the front of the machine to lift and rapidly flip over backwards which could cause serious injury.

7. Avoid starting or stopping on a slope. If tires lose traction, disengage the blade(s) and proceed slowly straight down the slope.

DO NOT:

1. Do not turn on slopes unless necessary; then, turn slowly and gradually downhill, if possible.

2. Do not mow near drop-offs, ditches or embankments. The mower could suddenly turn over if a wheel is over the edge of a cliff, ditch, or if an edge caves in.

3. Do not try to stabilize the machine by putting your foot on the ground.

4. Do not use a grass catcher on steep slopes.

5. Do not mow on wet grass. Reduced traction could cause sliding.

6. Do not shift to neutral and coast downhill. Over- speeding may cause the operator to lose control of

the machine resulting in serious injury or death.

7. Do not tow heavy pull behind attachments (e.g. loaded dump cart, lawn roller, etc.) on slopes

greater than 5 degrees. When going down hill, the extra weight tends to push the tractor and may cause you to loose control. (e.g. tractor may speed

up, braking and steering ability are reduced,

attachment may jack-knife and cause tractor to overturn).

CHILDREN

Tragic accidents can occur ifthe operator is not alert to the presence of children. Children are often attracted to the machine and the mowing activity. They do not understand the dangers. Never assume that children will remain where you last

saw them.

a. Keep children out of the mowing area and in

watchful care of a responsible adult other than the operator.

b. Be alert and turn machine off if a child enters

the area.

c. Before and while backing, look behind and

down for small children.

d. Never carry children, even with the blade(s)

shut off. They may fall off and be seriously injured or interfere with safe machine operation.

e. Useextremecarewhenapproachingblind

corners,doorways,shrubs,treesorother objectsthatmayblockyourvisionofachild whomayrunintothemachine.

f. Toavoidback-overaccidents,always

disengagethecuttingblade(s)before shiftingintoreverse.The"Reverse

CautionMode" should not be used when

children or others are around.

g. Keep children away from hot or running

engines. They can suffer burns from a hot

muffler.

h. Remove key when machine is unattended to

prevent unauthorized operation.

Never allow children under 14 years old to operate

the machine. Children 14 years old and over should

read and understand the operation instructions and safety rules in this manual and should be trained and supervised by a parent.

TOWING

1. Tow only with a machine that has a hitch designed for towing. Do not attach towed equipment except

at the hitch point.

2. Follow the manufacturers recommendation for

weight limits for towed equipment and towing on slopes.

3. Never allow children or others in or on towed

equipment.

4. On slopes, the weight of the towed equipment may

cause loss of traction and loss of control.

5. Travel slowly and allow extra distance to stop.

6. Do not shift to neutral and coast downhill.

SERVICE

SAFE HANDLING OF GASOLINE:

To avoid personal injury or property damage use extreme care in handling gasoline. Gasoline is extremely flammable and the vapors are explosive. Serious personal injury can occur when gasoline is spilled on yourself or your clothes which can ignite. Wash your skin and change clothes immediately.

a. Use only an approved gasoline container.

b. Never fill containers inside a vehicle or on a

truck or trailer bed with a plastic liner. Always place containers on the ground away from your vehicle before filling.

c. When practical, remove gas-powered

equipment from the truck or trailer and refuel

it on the ground. If this is not possible, then

refuel such equipment on a trailer with a portable container, rather than from a gasoline dispenser nozzle.

d. Keep the nozzle in contact with the rim of the

fuel tank or container opening at all times

until fueling is complete. Do not use a nozzle

lock-open device.

e. Extinguish all cigarettes, cigars, pipes and

other sources of ignition.

f. Neverfuel machine indoors. g. Never remove gas cap or add fuel while the

engine is hot or running. Allow engine to cool at least two minutes before refueling.

h. Never over fill fuel tank. Fill tankto no more

than _/2inch below bottom of filler neck to

allow space for fuel expansion. i. Replace gasoline cap and tighten securely. j. If gasoline is spilled, wipe it off the engine

and equipment. Move unit to another area.

Wait 5 minutes before starting the engine. k. To reduce fire hazards, keep machine free of

grass, leaves, or other debris build-up. Clean

up oil or fuel spillage and remove any fuel

soaked debris. I. Never store the machine or fuel container

inside where there is an open flame, spark or

pilot light as on a water heater, space heater,

furnace, clothes dryer or other gas

appliances. m. Allow a machine to cool at least 5 minutes

before storing.

GENERAL SERVICE:

1. Never run an engine indoors or in a poorly ventilated area. Engine exhaust contains carbon

monoxide, an odorless, and deadly gas.

2. Before cleaning, repairing, or inspecting, make certain the blade(s) and all moving parts have stopped. Disconnect the spark plug wire and ground against the engine to prevent unintended starting.

3. Periodically check to make sure the blades come to complete stop within approximately (5) five seconds after operating the blade disengagement control. If the blades do not stop within the this time frame, your unit should be serviced professionally by an authorized MTD Service Dealer.

4. Check brake operation frequently as it is subjected to wear during normal operation. Adjust and service as required.

5. Check the blade(s) and engine mounting bolts at frequent intervals for proper tightness. Also, visually inspect blade(s) for damage (e.g., excessive wear, bent, cracked).

Replace the blade(s) with the original equipment manufacturer's (O.E.M.) blade(s) only, listed in this manual. "Use of parts which do not meet the

original equipment specifications may lead to

improper performance and compromise safety!"

6. Mower blades are sharp. Wrap the blade or wear gloves, and use extra caution when servicing them.

7. Keep all nuts, bolts, and screws tight to be sure the equipment is in safe working condition.

8. Nevertamperwiththesafetyinterlocksystemor othersafetydevices.Checktheirproperoperation regularly.

9. Afterstrikingaforeignobject,stoptheengine, disconnectthesparkplugwire(s)andground againsttheengine.Thoroughlyinspectthe machineforanydamage.Repairthedamage beforestartingandoperating.

10.Neverattempttomakeadjustmentsorrepairsto

themachinewhiletheengineisrunning.

11.Grasscatchercomponentsandthedischarge coveraresubjecttowearanddamagewhichcould exposemovingpartsorallowobjectstobethrown.

Forsafetyprotection,frequentlycheckcomponents

andreplaceimmediatelywithoriginalequipment

manufacturer's(O.E.M.)partsonly,listedinthis manual."Useofpartswhichdonotmeetthe

originalequipmentspecificationsmayleadto

improperperformanceandcompromisesafety!"

12.

Donotchangetheenginegovernorsettingsor

over-speedtheengine.Thegovernorcontrolsthe

maximumsafeoperatingspeedoftheengine.

13.

Maintainorreplacesafetyandinstructionlabels,as necessary.

14.

Observeproperdisposallawsandregulationsfor gas,oil,etc.toprotecttheenvironment.

_, ARNING: YOURRESPONSIBILITYRestricttheuseofthispowermachinetopersonswhoread,

understandandfollowthewarningsandinstructionsinthismanualandonthemachine.

ROTATING BLADES CAUSE

SERIOUS iNJURY OR DEATH

• DOHOTMOWWHENCHILBREHOROTHERSARE

AROUHD

• HEVERCAP_YCH&DREHEVEHWITHBLADE(S)OFF.

• LOOKDOWNAHDBEHINDBEFOREANDWHILE

BACKING.

o MOWINGiNREVERSEJSHOTRECOMMEHDED.

O >,

Q,.

£)_ o

t- >,

£)_

Sight andh01dthis levelwith averticaltree,,,

_ or acornerof a building,,,

,,_ _ _ a_ or afencepost

! o

15°

&J .I_

t- O

.co r--

WARNING

Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet). A riding mower

could overturn and cause serious injury. If operating a walk-behind mower on such a slope, it is extremely difficult to maintain your footing and you could slip, resulting in serious injury. Operate RIDING mowers up and down slopes, never across the face of slopes.

SECTION3: TRACTORSET-UP

AttachingtheBatteryCables

NOTE: The positive battery terminal is marked Pos.

(+). The negative battery terminal is marked Neg. (-).

• The positive cable (heavy red wire) is secured to

the positive battery terminal (+) with a hex bolt and

hex nut at the factory. Make certain that the rubber boot covers the terminal to help protect itfrom

corrosion.

• Remove the hex bolt and wing nut from the negative cable.

• Remove the black plastic cover, if present, from the negative battery terminal and attach the negative cable (heavy black wire) to the negative battery

terminal (-) with the bolt and wing nut.

• Make certain the hold-down strap is in position over

the battery, securing it in place. See Figure 1.

Rubber Boot

Service the engine with gasoline and oil as instructed in

the separate Briggs & Stratton Operator/Owner Manual

packed with your tractor. Read instructions carefully. IMPORTANT:Your tractor is shipped with motor oil in the

engine. However, you MUST check the oil level before

operating. Be careful not to overfill.

ShippingBraceRemoval

engine is off, remove the ignition key, and set

WARNING: Make sure the riding mower's the parking brake before removing the

shipping brace.

Locate the shipping brace, if present, and accompanying warning tag found on the right side of the mower, between the discharge chute and the cutting deck. See Figure 2.

WingNut

HexBolt

Figure 1

NOTE: If the battery is put into service after the date

shown on top of battery, charge the battery as instructed on page 23 of this manual prior to operating

the tractor.

GasandOilFill-up

The gasoline tank is located under the hood and has a capacity of either two or three gallons. Do not overfill.

WARNING: Use extreme care when

handling gasoline. Gasoline is extremely flammable and the vapors are explosive.

Never fuel machine indoors or while the engine is hot or running. Extinguish

cigarettes, cigars, pipes, and other sources of ignition.

WarningTag

Figure 2

While holding the discharge chute with your left

hand, remove the shipping brace with your right

hand by grasping it between your thumb and index finger and rotating it clockwise.

WARNING: The shipping brace, used for

packaging purposes only, must be removed

and discarded before operating your riding

mower.

WARNING: The mowing deck is capable of

throwing objects. Failure to operate the riding

mower without the discharge cover in the proper operating position could result in serious personal injury and/or property

damage.

AttachingTheSeat

Seat styles vary by tractor model and there are three different styles available:

• Standard Adjustment

• Quick Adjustment &

• Knob Adjustment If the seat for your tractor did not come attached, refer

to Figure 3, Figure 4, and Figure 5 to identify your tractor's seat style and follow the applicable instructions

below to attach it.

NOTE: For shipping reasons, seats are either

fastened to the tractor seat's pivot bracket with a plastic tie, or mounted backward to the pivot bracket. In either case, free the seat form its shipping position and remove the two hex screws (or knobs, on models so equipped) from the bottom of seat before proceeding

with applicable instructions below.

Standard AdjustmentSeat

1. Position the shoulder screws (found on the base of the seat) inside the slot openings in the seat pivot

bracket. Figure 3.

2. Slide the seat slightly rearward in the seat pivot

bracket, lining up the rear slots in the pivot bracket with the remaining two holes in the seat's base.

3. Select desired position for the seat, and secure with the two hex screws removed earlier. See Figure 3.

QuickAdjustmentSeat

Standard Adjustment

Hex Screws

Shoulder

Screws

Opening

in Slot

Pivot Bracket

Figure 3

QuickAdjustment

Seat Stop

NOTE: If your seat was shipped mounted backwards on the seat pivot bracket, pull out the tab found on the

seat stop and hold # open while sliding the seat off the seat pivot bracket. See Figure 4.

1. Line up the plastic seat spacers with the slots in

seat pivot bracket.

2. Slide seat in until front seat spacer engages the

seat stop. See Figure 4.

WARNING: Before operating this machine, make sure the seat is engaged in the seat stop, stand behind the machine and pull back on seat until fully engaged into stop.

KnobAdjustmentSeat

1. Position the shoulder screws (found on the base of the seat) inside the slot openings in the seat pivot

bracket. Figure 5.

2. Slide the seat slightly rearward in the seat pivot

bracket, lining up the rear slots in the pivot bracket with the remaining two holes in the seat's base.

3. Select desired position for the seat, and secure with the two knobs removed earlier. See Figure 5.

Pivot Bracket

Figure 4

KnobAdjustment

Knobs

Shoulder

Screws

Opening

in Slot

Figure 5

AttachingTheSteeringWheel

• If the steering wheel for your tractor did not come

attached, the hardware for attaching it has been packed within the steering wheel, beneath the steering wheel cap. Carefully pry off the steering wheel cap and remove the hardware.

NOTE: There are two different styles of steering

wheel cap. See Figure 6. Styles vary by model.

• With the wheels of the tractor pointing straight

forward, place the steering wheel over the steering shaft.

• Place the washer (with the cupped side down) over the steering shaft and secure with the hex bolt. See

Figure 6.

• Place the steering wheel cap over the center of the

steering wheel and push downward until it "clicks" into place.

Steering

Wheel Cap I

IdentifyingtheMulchPlug(ifsoequipped)

On tractor models so equipped, a mulch plug can either be found within the cutting deck's discharge opening or packed separately with your unit.

NOTE: Refer to Mulchingon page 18 for more detailed

information.

If you'd prefer to operate the cutting deck without mulching, simply remove the mulch plug by

unthreading the plastic wing nut which fastens itto the cutting deck. This will allow the clippings to discharge out of the discharge opening during operation. See

Figure 7.

Steering

Shaft

Figure 6

Plastic Wing Nut

Mulch Plug

Figure 7

SECTION4: KNOWYOURLAWNTRACTOR

- NOTE: Steering Wheel notshown for clarity, t Ifso equipped

Figure 8

A Systems Indicator Monitor H Cruise Control Button B PTO (Blade Engage) Lever I Ignition Switch Module

C Choke Knob J Brake Pedal D Parking Brake Button K Drive Pedal

E Shift Lever L Deck Lift Lever F Cup Holder M Seat Adjustment Levert

G Throttle Lever

NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator's position.

ThrottleControlLever

The throttle control lever is located on the right side of the tractor's dash panel. This lever controls the speed of the engine and, on some models, when pushed all the way forward, the choke control also. When set in a given position, the throttle will maintain a uniform engine speed. See Figure 9.

Choke

Position

Fast

Position

Slow

Position

Figure 9

IMPORTANT:When operating the tractor with the cutting

deck engaged, be certain that the throttle lever is always in the FAST (rabbit) position.

Fast

Position

Slow

Position

IgnitionSwitchModule

WARNING: Never leave a running machine

unattended. Always disengage PTO, move shift lever into neutral position, set parking brake, stop engine and remove key to prevent unintended starting.

To start the engine, insert the key into the ignition

switch and turn clockwise to the START position. Release the key into the NORMAL MOWING MODE position once the engine has fired.

To stop the engine, turn the ignition key counterclockwise to the OFF position. See Figure 10.

NO CI-{ILOREN AROUND

BUTTON

REVERSE PUSH

Stop

Position

Normal

MowingMode

Start

Position

ChokeControl

On some models, moving the throttle lever all the way forward activates the engine's choke control. On all other models, the

choke control can be found on the left side of the dash panel and

is activated by pulling the knob outward. Activating the choke control closes the choke plate on the carburetor and aids in starting the engine. Refer to StartingTheEngineon page 16 of this manual for detailed starting instructions.

BrakePedal

The brake pedal is located on the right front side of the tractor above the drive pedal along the running board. The brake pedal can be used for sudden stops or setting the parking brake.

NOTE: The brake pedal must

be fully depressed to activate the safety interlock switch when

starting the tractor.

(o)

Figure 10

IMPORTANT:Prior to operating the tractor, refer to both SafetyInterleckSwitcheson page 15 and StartingTheEngine on page 16 of this manual for detailed instructions

regarding the Ignition Switch Module and operating the tractor in REVERSE CAUTION MODE.

DrivePedal

The drive pedal is located below the brake pedal on the right front

side of the tractor along the

running board. Depress the drive

pedal with your right foot when the tractor shift lever is in either (_)

FORWARD or REVERSE to cause the tractor to move.

Ground speed is also controlled with the drive pedal. The further down the pedal is depressed, the faster the tractor will travel. The pedal will return to its original position when

it's not depressed.

IMPORTANT:Always set the parking brake when

leaving the tractor unattended.

SystemsIndicatorMonitor

Your tractor is equipped with a ammeter as part of its systems indicator monitor. Locate the monitor on the left side of your dash panel and compare itto Figure 11.

PTO(BladeEngage)Lever

PTO

DP SV

Oil

Brake

Ammeter-

PTO

Figure 11

If the Brake light or PTO light illuminates when attempting to start the unit, proceed as follows:

BRAKE -- Depress the brake pedal. PTO -- Move PTO (Blade Engage) lever into the

disengaged (OFF) position.

NOTE: It is normal for the Oil light and the Battery light

to ifluminate while the engine is cranking, but if either illuminate's while the engine is running, proceed as

follows:

OIL-- Stop the tractor immediately and check

the crankcase oil level as instructed in the Briggs & Stratton Operator/Owner

Manual included with your tractor.

BATTERY-- The battery is in need of a charge, or the

engine's charging system is not generating sufficient amperage. Refer to

the MAINTENANCEsection of this manual for the proper battery charging procedure

or have the charging system checked by a Briggs & Stratton engine's dealer.

The ammeter measures the electrical output of the engine's charging system. Under normal operating conditions, with the engine at full throttle, the ammeter's needle should measure a positive charge.

PTO / BLADE

The PTO (Blade Engage) lever is located on the left

side of the dashboard next to the steering wheel. Move the PTO (Blade Engage) lever forward to engage the

power to the cutting deck or other (separately available) attachments; move the PTO (Blade Engage) lever

rearward to disengage the power to the attachments.

ENGAGE

NOTE: The PTO (Blade Engage) lever must be in the

disengaged (OFF) position when starting the engine,

when traveling in reverse and if the operator leaves the

seat.

SeatAdjustmentLever

To adjust the seat forward or backward on units

equipped with a quick-adjust seat, slide the seat adjustment lever to the left and reposition the seat to the desired position. Once a comfortable position is found, release the seat adjustment lever to lock the

seat in place. Refer to SeatAdjustmenton page 20 of this

manual for more detailed instructions.

DeckLift Lever

Found on your tractor's right fender, the deck lift lever is

used to change the height of the cutting deck. To use,

move the lever to the left, then place in the notch best

suited for your application.

ParkingBrakeButton

To set the parking brake, fully depress the brake pedal and

push the parking brake button in.

Hold the button in while taking your foot off the brake pedal.

Both the parking button and the

brake pedal will then stay depressed. To release the

parking brake, depress the brake

pedal slightly. The parking brake

button will then return to its original position.

NOTE: The parking brake must be set if the operator

leaves the seat with the engine running or the engine

will automatically shut off.

IMPORTANT:Always set the parking brake when

leaving the tractor unattended.

WARNING

AVOIDSERIOUSINJURYORDEATH

NOTE: Cruise control can NOT be engaged at the

tractor's fastest ground speed. If the operator should

attempt to do so, the tractor will automatically

decelerate to the fastest optimal mowing ground speed.

• GO UP AND DOWN SLOPES, NOT ACROSS.

• AVOID SUDDEN TURNS.

• DO NOT OPERATE THE UNIT WHERE IT COULD SLIP OR TIR

• IF MACHINE STOPS GOING UPHILL, STOP BLADE(S) AND BACK DOWNHILL SLOWLY.

• DO NOT MOW WHEN CHILDREN OR OTHERS ARE AROUND.

• NEVER CARRY CHILDREN, EVEN WITH BLADES OFR

• LOOK DOWN AND BEHIND BEFORE AND WHILE BACKING.

• KEEP SAFETY DEVICES (GUARDS, SHIELDS, AND SWITCHES) IN PLACE AND WORKING.

• REMOVE OBJECTS THAT COULD BE THROWN BY THE BLADE(S).

• KNOW LOCATION AND FUNCTION OF ALL CONTROLS.

• BE SURE BLADE(S) AND ENGINE ARE STOPPED BEFORE PLAC- ING HANDS OR FEET NEAR BLADE(S).

• BEFORE LEAVING OPERATOR'S POSITION, DISENGAGE BLADE(S), PLACE THE SHIFT LEVER IN NEUTRAL, ENGAGE BRAKE LOCK, SHUT ENGINE OFF AND REMOVE KEY.

READOPERATOR'SMANUAL

CruiseControlButton

The cruise control button is

to the left of the ignition switch.

located on the tractor dash panel ;I_

Push the cruise control button while traveling forward at a

desired speed. While holding the II_l button in, release pressure from

the drive pedal. This will engage the cruise control and allow the

tractor to remain at that speed without applying pressure to the drive pedal. Depress the brake pedal or the drive pedal to deactivate cruise control. Refer to SettingtheCruiseControlon page 17 this manual for detailed instructions regarding the cruise

control feature.

Shift Lever

The shift lever is located on the leftside of the fender and has three positions, FORWARD, NEUTRAL and

REVERSE. The brake pedal must be depressed and

the tractor must not be in motion when the moving shift

lever. See Figure 12.

;r,

ShiftKnob

Figure 12

IMPORTANT:Never force the shift lever. Doing so may result in serious damage to the tractor's transmission.

SECTION5: OPERATINGYOURLAWNTRACTOR

SafetyInterlockSwitches

This tractor is equipped with a safety interlock system for the protection of the operator. If the interlock system should ever malfunction, do not operate the tractor.

Contact an authorized MTD service dealer.

• The safety interlock system prevents the engine from cranking or starting unless the parking brake is

engaged, and the PTO (Blade Engage) lever is in

the disengaged (OFF) position.

• The engine will automatically shut off if the operator

leaves the seat before engaging the parking brake.

• The engine will automatically shut off if the operator

leaves the tractor's seat with the PTO (Blade Engage) lever in the engaged (ON) position, regardless of whether the parking brake is engaged.

• The engine will automatically shut off if the operator

engages the PTO with the parking brake ON.

• With the ignition key in the NORMAL MOWING

position, the engine will automatically shut off ifthe PTO (Blade Engage) lever is moved into the engaged (ON) position with the shift lever in

Reverse.

interlock system is malfunctioning. This

WARNING: Do not operate the tractor ifthe system was designed for your safety and

protection.

ReverseCautionMode

3. Depress the REVERSE PUSH BUTTON (Orange, Triangular Button) at the top, right corner of the key switch module. The red indicator light at the top, left corner of the key switch module will be ON while activated. See Figure 13.

4. Once activated (indicator light ON), the tractor can be driven in reverse with the cutting blades (PTO) engaged.

5. Always look down and behind before and while backing to make sure no children are around.

6. After resuming forward motion, return the key to the

NORMAL MOWING position.

IMPORTANT:The REVERSE CAUTION MODE will remain activated until:

a. The key is placed in either the NORMAL

MOWING position or STOP position.

b. The operator engages the parking brake by

fully depressing the brake pedal and holding it down while gently pushing the parking

brake button inward.

-_ Reverse

Indicator PushButton

Light Reverse

Stop Position

Position

BUTTON ===_

REVERSE PUSH

- CautionMode

Start

Position

WARNING: Use extreme caution while operating the tractor in the REVERSE

CAUTION MODE. Always look down and behind before and while backing. Do not operate the tractor when children or others are around. Stop the tractor immediately if

someone enters the area.

The REVERSE CAUTION MODE position of the key switch module allows the tractor to be operated in reverse with the blades (PTO) engaged.

IMPORTANT: Mowing in reverse is not recommended. To use the REVERSE CAUTION MODE:

IMPORTANT:The operator MUST be seated in the tractor seat.

Start the engine as previously instructed in this Operator's Manual.

Turn the key from the NORMAL MOWING (Green) position to the REVERSE CAUTION MODE (Yellow) position of the key switch module. See Figure 13.

Figure 13

EngagingtheParkingBrake

To engage the parking brake:

• Fully depress the brake pedal and hold it down with your foot while gently pushing the parking brake

button inward.

• Hold the parking brake button in while removing your foot from the brake pedal.

• Once engaged, the parking brake button and the brake pedal will lock inthe "down" position.

To disengage the parking brake:

• Slightly depress the brake pedal.

NOTE: The parking brake must be engaged ff the

operator leaves the seat with the engine running or the engine will automatically shut off.

SettingtheCuttingHeight

Select the height position of the cutting deck by placing the deck lift lever in any of the six different cutting height notches on the right side of the fender. Then adjust the deck wheels so that they are between 1A-inchand _/2- inch above the ground when the tractor ison a smooth, flat surface such as a driveway.

from the discharge opening of the cutting

WARNING: Keep hands and feet away deck.

NOTE: The deck wheels are an anti-scalp feature of

the deck and are not designed to support the weight of the cutting deck.

Refer to LevelingtheBeckon page 19 of this manual for more detailed instructions regarding various deck adjustments.

Startingthe Engine

damage. Repair the damage before restarting and operating

• If the blades are engaged, place the PTO (Blade

Engage) lever in the disengaged (OFF) position.

• Turn the ignition key counterclockwise to the STOP position.

• Remove the key from the ignition switch to prevent unintended starting.

DrivingTheTractor

WARNING: Avoid sudden starts, ex- cessive speed and sudden stops.

WARNING: Do not leave the seat of the tractor without first placing the PTO (Blade

Engage) lever in the disengaged (OFF) position, depressing the brake pedal and

engaging the parking brake. If leaving the tractor unattended, also turn the ignition key off and remove the key.

interlock system is malfunctioning. This

WARNING: Do not operate the tractor ifthe system was designed for your safety and

protection.

NOTE:

manual for Gasoline and Oil fill-up instructions.

• Insert the tractor key into the ignition switch.

• Place the PTO (Blade Engage) lever inthe

• Engage the tractor's parking brake.

• Activate the choke control.

• Turn the ignition key clockwise to the START

IMPORTANT: Do NOT hold the key in the START position for longer than ten seconds at a time. Doing so may cause damage to your engine's electric starter.

• After the engine starts, deactivate the choke control

Refer to the TRACTORSET-UPon page 8 of this

disengaged (OFF) position.

position. After the engine starts, release the key. It will return to the ON position.

and place the throttle control in the FAST position.

NOTE: Do NOT leave the choke control on while

operating the tractor. Doing so will result in a "rich" fuel mixture and cause the engine to run poorly.

StoppingtheEngine

_, WARNING: If you strike a foreign object,

stop the engine, disconnect the spark plug wire(s) and ground against the engine. Thoroughly inspect the machine for any

• Depress the brake pedal to release the parking brake and let the pedal up.

• Move the throttle lever into the FAST (rabbit) position.

IMPORTANT:Do NOT use the shift lever to change the

direction of travel when the tractor is in motion. Always

use the brake pedal to bring the tractor to a complete stop before shifting.

• To move forward, place the shift lever in the

FORWARD position, then slowly depress the drive

pedal until the desired speed is achieved.

• To move in reverse, place the shift lever in the

REVERSE position, check that the area behind is

clear then slowly depress the drive pedal.

DrivingOnSlopes

Refer to the SLOPEGAUGEon page 7 to help determine

slopes where you may operate the tractor safely.

_, ARNING: Do not mow on inclines with a

• Mow up and down slopes, NEVER across.

• Exercise extreme caution when changing direction

• Watch for holes, ruts, bumps, rocks, or other

slope in excess of 15 degrees (a rise of

approximately 2-1/2 feet every 10 feet). The tractor could overturn and cause serious

injury.

on slopes.

hidden objects. Uneven terrain could overturn the machine. Tall grass can hide obstacles.

Avoid turns when driving on a slope. Ifa turn must be made, turn down the slope. Turning up a slope greatly increases the chance of a roll over. Avoid stopping when driving up a slope. If it is necessary to stop while driving up a slope, start up smoothly and carefully to reduce the possibility of

flipping the tractor over backward.

SettingTheCruiseControl

• Place the shift lever in the FORWARD position, then slowly depress the drive pedal until the desired

speed is achieved.

• Lightly depress the cruise control button.

• While continuing to hold the cruise button in, lift your foot from the drive pedal (you should feel the cruise latch engage).

• Once engaged, the cruise control button and the drive pedal will lock inthe "down" position, and the tractor will maintain the same forward speed.

IMPORTANT:The engine will automatically shut off if the PTO is engaged with the shift lever in position for reverse travel with the ignition key in the NORMAL MOWING position. Refer to SafetyInterlockSwitcheson page 15.

Usingthe DeckLift Lever

To raise the cutting deck, move the deck lift lever to the

left, then place it inthe notch best suited for your

application. Refer to SettingTheCuttingHeightearlier in

this section.

Mowing

WARNING: To help avoid blade contact or

a thrown object injury, keep bystanders,

helpers, children and pets at least 75 feet

from the machine while it is in operation. Stop

machine if anyone enters the area.

NOTE: Cruise control can not be engaged at the

tractor's fastest ground speed. If the operator should attempt to do so, the tractor will automatically decelerate to the fastest optimal mowing ground speed.

Disengage the cruise control using one of the following methods:

• Depress the brake pedal to disengage the cruise

control and stop the tractor.

• Lightly depress the drive pedal.

To change to the reverse direction when operating with cruise control, depress the brake pedal to disengage the cruise control and bring the tractor to a complete stop. Then place the shift lever in the REVERSE position and depress the drive pedal.

EngagingtheBlades

Engaging the PTO (Blade Engage) transfers power to the cutting deck or other (separately available) attachments. To engage the blades, proceed as

follows:

• Move the throttle control lever to the FAST (rabbit)

position.

• Grasp the PTO (Blade Engage) lever and pivot it all the way forward into the engaged (ON) position.

• Keep the throttle lever in the FAST (rabbit) position for the most efficient use of the cutting deck or other

(separately available) attachments.

The following information will be helpful when using the cutting deck with your tractor.

WARNING: Plan your mowing pattern to

avoid discharge of materials toward roads,

sidewalks, bystanders and the like. Also, avoid discharging material against a wall or obstruction which may cause discharged

material to ricochet back toward the operator.

• Do not mow at high ground speed, especially if a mulch kit or grass collector is installed.

• For best results it is recommended that the first two laps be cut with the discharge thrown towards the

center. After the first two laps, reverse the direction to throw the discharge to the outside for the balance of cutting. This will give a better appearance to the lawn.

• Do not cut the grass too short. Short grass invites

weed growth and yellows quickly in dry weather.

• Mowing should always be done with the engine at

full throttle.

• Under heavier conditions it may be necessary to go

back over the cut area a second time to get a clean cut.

• Do NOT attempt to mow heavy brush and weeds

and extremely tall grass. Your tractor is designed to

mow lawns, NOT clear brush.

• Keep the blades sharp and replace the blades

when worn. Refer to CuttingBladeson page 24 of this

manual for proper blade sharpening instructions.

Mulching(If Equipped)

Select models come equipped with a mulch kit which

incorporates special blades, already standard on the tractor, ina process of recirculating grass clippings

repeatedly beneath the cutting deck. The ultra-fine clippings are then forced back intothe lawn where they act as a natural fertilizer. Observe the following points for the best results when mulching.

• Never attempt to mulch if the lawn isdamp. Wet grass tends to stick to the underside of the cutting deck preventing proper mulching of the clippings.

• Do NOT attempt to mulch more than 1/3 the total height of the grass or approximately 1-1/2 inches. Doing so will cause the clippings to clump up beneath the deck and not be mulched effectively.

• Maintain a slow ground speed to allow the grass clippings more time to effectively be mulched.

• Always position the throttle control lever in the FAST (rabbit) position and allow itto remain there while mowing. Failing to keep the engine at full

throttle places strain on the tractor's engine and

does not allow the blades to properly mulch grass.

NOTE: It is not necessary to remove the discharge

chute to operate the mower with the mulch kit installed.

• To operate the cutting deck without mulching, simply remove the mulch plug by unthreading the plastic wing nut which fastens it to the cutting deck.

This will allow the clippings to discharge out the side. See Figure 14.

CarriageScrew

PlasticWingNut MulchPlug

Figure 14

Headlights

On some models, the lamps are ON whenever the tractor's engine is running. On other models, the lamps are ON whenever the ignition key is moved out of the

STOP position.

On all models, the lamps turn OFF when the ignition

key is moved to the STOP position.

SECTION6: MAKINGADJUSTMENTS

_, WARNING: Never attempt to make any

LevelingtheDeck

NOTE: Check the tractor's tire pressure before

performing any deck leveling adjustments. Refer to Tires on page 23 for information regarding tire pressure.

FrontTo Rear

The front of the cutting deck is supported by a stabilizer bar that can adjusted to level the deck from front to rear.

The front of the deck should be between 1/4-inch and 3/8-inch lower than the rear of the deck. Adjust if

necessary as follows:

• With the tractor parked on a firm, level surface,

• Measure the distance from the front of the blade tip

• The first measurement taken should be between

• Loosen the two jam nuts, if present, on the rear side

• Locate the two lock nuts on the front side of the

adjustments while the engine is running, except where specified in the operator's

manual.

place the deck lift lever in the top notch (highest position) and rotate the blade nearest the discharge chute so that it is parallel with the tractor.

to the ground and the rear of the blade tip to the

ground. 1/4" and 3/8" less than the second measurement.

Determine the approximate distance necessary for proper adjustment and proceed, if necessary, to the next step.

of the deck stabilizer bracket.

stabilizer bracket. See Figure 16. Tighten the lock nuts to raise the front of the deck; loosen the lock

nuts to lower the front of the deck.

• Retighten the two jam nuts loosened earlier when

proper adjustment is achieved.

Sideto Side

If the cutting deck appears to be mowing unevenly, a

side to side adjustment can be performed. Adjust if

necessary as follows:

• With the tractor parked on a firm, level surface,

place the deck lift lever in the top notch (highest position) and rotate both blades so that they are perpendicular with the tractor.

• Measure the distance from the outside of the left

blade tip to the ground and the distance from the outside of the right blade tip to the ground. Both

measurements taken should be equal. If they're not, proceed to the next step.

• Loosen, but do NOT remove, the hex cap screw on

the left deck hanger bracket. See Figure 16.

Adjustment Gear

Hex Bolt

Figure 16

• Balance the deck by using a wrench to turn the

adjustment gear (found immediately behind the hex cap screw just loosened) clockwise/up or

counterclockwise/down.

• The deck is properly balanced when both blade tip

measurements taken earlier are equal.

• Retighten the hex cap screw on the left deck

hanger bracket when proper adjustment is

achieved.

Loosen Tighten -_

, to 10werdeck to raise deck J

Figure 15

ParkingBrakeAdjustment

WARNING: Never attempt to adjust the

brakes while the engine is running. Always disengage PTO, move shift lever into neutral position, stop engine and remove key to prevent unintended starting.

If the tractor does not come to a complete stop when the brake pedal is completely depressed, or if the tractor's rear wheels can roll with the parking brake applied, the brake is in need of adjustment. The brake disc can be found on the right side of the transmission in the rear of the tractor. Adjust if necessary as follows:

• Looking at the transmission from the right side of the tractor, locate the compression spring and

brake disc. See Figure 17.

HexNut -__-_____

To adjust the position of the seat on models equipped with a seat adjustment lever, move the lever to the left

and slide the seat forward or rearward. Make sure seat

is locked into position before operating the tractor.

KnobAdjustmentSeat(if soequipped)

To adjust the position of the seat on models so

equipped, loosen the two knobs on the bottom of the seat. See Figure 18. Slide the seat forward or backward

as desired. Retighten the two knobs.

Knobs

SetGap

at.011"

Compression

Spring

Transmission

NOTE: View shown from beneath tractor,

Figure 17

• Loosen, but do NOT remove, the hex nut found on the right side of the brake assembly. See Figure 17.

• Using a feeler gauge, set the gap between the

brake disc and the brake puck at.011 ".

• Re-tighten the hex nut loosened earlier.

SeatAdjustment

Quick-adjustSeat(if soequipped)

WARNING: Before operating this machine, make sure the seat is engaged in the seat

stop, stand behind the machine and pull back on seat until fully engaged into stop.

Figure 18

StandardSeat

To adjust the position of the seat, loosen the two hex

screws on the bottom of the seat. Slide the seat forward

or backward as desired. Retighten the two screws. See

Figure 19.

Hex Screws

Figure 19

SteeringAdjustment

If the tractor turns tighter inone direction than the other, or ifthe ball joints are being replaced due to damage or wear, the steering drag links may need to be adjusted.

Adjust the drag links so that equal lengths are threaded into the ball joint on the left side and the ball joint on the right side:

• Loosen the jam nut found on the drag link at the

rear of the ball joint. See Figure 20.

Hex Nut

Jam Nut

BallJoint

PivotBar

Dra_jLink

• Remove the hex nut on the top of ball joint. See Figure 20.

• Thread the ball joint toward the jam nut to shorten

the drag link. Thread the ball joint away from the jam nut to lengthen the drag link.

• Replace hex nut and retighten the jam nut after

proper adjustment is achieved.

NOTE: Threading the ball joints too far onto the drag

links will cause the front tires to "toe-in" too far. Proper toe-in is between 1/16" and 5/16".

Front tire toe-in can be measured as follows:

• Place the steering wheel in position for straight

ahead travel.

• In front of the axle, measure the distance horizontally from the inside of the left rim to the

inside of the right rim. Note the distance.

• Behind the axle, measure the distance horizontally

from the inside of the left rim to the inside of the

right rim. Note the distance.

• The measurement taken in front of the axle should

be between 1/16" and 5/16" less than the

measurement taken behind the axle. Adjust if necessary.

Figure 20

SECTION7: MAINTAININGYOURLAWNTRACTOR

• Refill the engine with new motor oil.

_, WARNING: Before performing any

Engine

Refer to the Briggs & Stratton Operator/Owner Manual for engine maintenance instructions.

Check engine oil level before each use as instructed in the Briggs & Stratton Operator/Owner Manual packed with your unit. Follow the instructions carefully.

ChangingEngineOil NOTE: Depending on the engine model found on your

tractor, # may be necessary to remove the tractor's side

panel in order to replace the oil filter (if so equipped).

maintenance or repairs, disengage PTO, move shift lever into neutral position, set parking brake, stop engine and remove key to prevent unintended starting.

IMPORTANT:Refer to the Briggs & Stratton Operator/ Owner Manual packed with your unit for information regarding the quantity and proper weight of motor oil.

AirCleaner

Service the pre-cleaner, if so equipped, and cartridge/ air cleaner element as instructed in the Briggs & Stratton Operator/Owner Manual packed with your unit.

SparkPlug(s)

The spark plug(s) should be cleaned and the gap reset once a season. Spark plug replacement is recommended at the start of each mowing season. Refer to the Briggs & Stratton Operator/Owner Manual

for correct plug type and gap specifications.

Lubrication

• Unscrew oil fill cap and remove dipstick from the oil fill tube. See Figure 21.

Oil Fill Cap

Oil Drain Hose

OilFillTube

Figure 21

• Pop open the protective cap on the end of the oil drain valve to expose the drain port. See Figure 21.

• Push the oil drain hose (packed with this manual) onto the oil drain port. Route the opposite end of the hose into an appropriate oil collection container with a capacity of no less than 64 oz.

• Push the oil drain valve in slightly, then rotate counterclockwise and pull outward to begin draining oil. See Figure 21.

• Service the oil filter (if so equipped) as instructed

in the separate Briggs & Stratton Operator/Owner

Manual packed with your unit. Perform the above steps in the opposite order after oil has finished draining.

ProtectiveCap

OilDrainValve

DrainPort

WARNING: Before lubricating, repairing, or inspecting, always disengage PTO, move

shift lever into neutral position, set parking brake, stop engine and remove key to prevent unintended starting.

Engine

Lubricate the engine with motor oil as instructed in the Briggs & Stratton Owner Manual packed with your unit.

Pivot Points& Linkage Lubricate all the pivot points on the drive system,

parking brake and lift linkage at least once a season with light oil.

RearWheels

The rear wheels should be removed from the axles once a season. Lubricate the axles and the rims well

with an all-purpose grease before re-installing them.

FrontAxles

Each end of the tractor's front pivot bar may be equipped with a grease fitting. Lubricate with a grease gun after every 25 hours of tractor operation.

CleaningtheEngineAndDeck

Any fuel or oil spilled on the machine should be wiped off promptly. Do NOT allow debris to accumulate around the cooling fins of the engine or on any other part of the machine.

IMPORTANT:The use of a pressure washer to clean your tractor is NOT recommended. It may cause damage to electrical components, spindles, pulleys, bearings or the engine.

SECTION8: SERVICE

CuttingDeckRemoval

To remove the cutting deck, proceed as follows:

• Place the PTO (Blade Engage) lever inthe disengaged (OFF) position and engage the parking

brake.

• Lower the deck by moving the deck lift lever into the bottom notch on the right fender.

• Remove the PTO belt (46" Deck)/deck belt (42" Deck) from around the tractor's engine pulley and idler pulley(s). Refer to Changing The Deck Belt & PTO Belt and Figure 26 and Figure 27.

NOTE: On models with a 46-inch deck, it may be

necessary to remove the belt keepers from around the engine pulley, in order to removes the PTO belt.

• Looking at the cutting deck from the left side of the

tractor, locate the deck support pin on the rear left

side of the deck. See Figure 22.

Figure 22

• Pull the deck support pin outward to release the deck from the deck lift arm.

• Rotate the pin slightly toward the rear of the tractor and release the pin into the hole provided.

• Repeat the above steps on the tractor's right side.

• Move the deck lift lever into the top notch on the right fender to raise the deck lift arms up and out of

the way.

NOTE: Models with a 46-inch deck are equipped with

a short cable which controls the deck spindle brake. It is necessary to unhook this cable in order to fully remove the cutting deck from the tractor. Be certain to reattach the cable when re-mounting the cutting deck.

• Gently slide the cutting deck toward the front of the tractor allowing the hooks on the deck to release

themselves from the deck stabilizer rod.

• Gently slide the cutting deck (from the right side) out from underneath the tractor.

Tires

_, WARNING: Never exceed the maximum

The recommended operating tire pressure is:

• Approximately 10 psi for the rear tires

• Approximately 14 psi for the front tires

IMPORTANT:Refer to the tire sidewall for exact tire

manufacturer's recommended or maximum psi. Do not overinflate. Uneven tire pressure could cause the cutting deck to mow unevenly.

inflation pressure shown on the sidewall of the

tire.

Battery

The battery is sealed and is maintenance-free. Acid

levels cannot be checked.

• Always keep the battery cables and terminals clean

and free of corrosive build-up.

• After cleaning the battery and terminals, apply a

light coat of petroleum jelly or grease to both

terminals.

• Always keep the rubber boot positioned over the

positive terminal to prevent shorting.

IMPORTANT:If removing the battery for any reason, disconnect the NEGATIVE (Black) wire from it's terminal first, followed by the POSITIVE (Red) wire. When re-installing the battery, always connect the

POSITIVE (Red) wire its terminal first, followed by the

NEGATIVE (Black) wire. Be certain that the wires are connected to the correct terminals; reversing them could change the polarity and result in damage to your

engine's alternating system.

Charging

If the tractor has not been put into use for an extended

period of time, charge the battery with an automotive- type 12-volt charger for a minimum of one hour at six

amps.

WARNING: Batteries give off an explosive

gas while charging. Charge battery in a well ventilated area and keep away from an open flame or pilot light as on a water heater, space

heater, furnace, clothes dryer or other gas appliances.

JumpStarting

,_ WARNING: When removing or installing

IMPORTANT: Never jump your tractor's dead battery with the battery of a running vehicle.

• Connect end of one jumper cable to the positive

• Connect the other jumper cable to the negative

the battery, follow these instructions to prevent the screwdriver from shorting against

the frame.

terminal of the good battery, then the other end to the positive terminal of the dead battery.

terminal of the good battery, then to the frame of the unit with the dead battery.

WARNING: Failure to use this procedure

could cause sparking, and the gas in either battery could explode.

Cleaning Clean the battery by removing it from the tractor and

washing with a baking soda and water solution. If necessary, scrape the battery terminals with a wire brush to remove deposits. Coat terminals and exposed wiring with grease or petroleum jelly to prevent

corrosion.

BatteryFailures

Some common causes for battery failure are:

• incorrect initial activation • undercharging

• overcharging • corroded connections

• freezing These failures are NOT covered by your tractor's

warranty.

CuttingBlades

Use a 15/16" wrench to remove the hex flange nut

that secures the blade to the spindle assembly. See

Figure 23.

Hex Flange Nut Block

Spindle

Figure 23

To properly sharpen the cutting blades, remove equal amounts of metal from both ends of the blades along the cutting edges, parallel to the trailing edge, at a 25° to 30° angle. See Figure 24.

IMPORTANT:If the cutting edge of the blade has already

been sharpened to within 5/8" of the wind wing radius, or if any metal separation is present, replace the blades with new ones. See Figure 24.

Blade Separation

Worn Blade Edge

Wind Wing

WARNING: Be sure to shut the engine off, remove ignition key, disconnect the spark plug wire(s) and ground against the engine to prevent unintended starting before removing the cutting blade(s) for sharpening or replacement. Protect your hands by using heavy gloves or a rag to grasp the cutting

blade.

_, ARNING: Periodically inspect the bladespindles for cracks or damage, especially if

you strike a foreign object. Replace immediately if damaged.

The blades may be removed as follows.

• Remove the deck from beneath the tractor, (refer to CuttingDeckRemovalon page 23) then gently flip the deck over to expose its underside.

• Place a block of wood between the center deck housing baffle and the cutting blade to act as a

stabilizer. See Figure 23.

Sharpen Edge Evenly

Figure 24

It is important that each cutting blade edge be ground equally to maintain proper blade balance.

A poorly balanced blade will cause excessive vibration and may cause damage to the tractor and result in

personal injury. The blade can be tested by balancing it

on a round shaft screwdriver. Grind metal from the

heavy side until it balances evenly.

When replacing the blade, be sure to install the blade with the side of the blade marked "Bottom" (or with a

part number stamped in it) facing the ground when the mower is in the operating position.

IMPORTANT: Use a torque wrench to tighten the blade spindle hex flange nut to between 70 foot-pounds and 90 foot-po unds.

Fuses

Two fuses are installed in your tractor's wiring harness to protect the tractor's electrical system from damage caused by excessive amperage.

If the electrical system does not function, or your tractor's engine will not crank, first check to be certain

that the fuse has not blown. One can be found under the hood mounted behind the

top of the dash panel on the support bar. The other can be found under the seat mounted to the inside of the

tractor frame next to the battery tray.

42" Beck

• Remove the belt keeper rod from around the engine pulley.

• Insert a 3/8"-drive ratchet wrench (set to loosen)

into the square hole found inthe idler bracket on

the left side of the deck's surface. See Figure 25.

idler Bracket Belt Guard

Square

_, ARNING: Always use a fuse with the

same amperage capacity for replacement.

Changingthe DeckBelt

WARNING: Be sure to shut the engine off, remove ignition key, disconnect the spark

plug wire(s) and ground against the engine to prevent unintended starting before removing the belt(s).

WARNING: Avoid the possibility of a

pinching injury. Do not place your fingers on the idler spring or between the belt and a pulley while removing the belt.

All belts on your tractor are subject to wear and should be replaced if any signs of wear are present.

IMPORTANT:The V-belts found on your tractor are specially designed to engage and disengage safely. A substitute (non-OEM) V-belt can be dangerous by not disengaging completely. For a proper working machine, use factory approved belts.

To change or replace the deck belt on your tractor, proceed as follows:

• Lower the deck by moving the deck lift lever into the bottom notch on the right fender.

• Remove the belt guards by removing the self-

tapping screws that fasten them to the deck.

Figure 25

• Grasp the ratchet's handle and pivot it toward the front of the tractor to relieve tension on the belt.

• With belt tension relieved, carefully remove the belt from around the left-hand spindle pulley.

IMPORTANT:Carefully allow the ratchet to pivot rearward before removing it from the square hole.

46" Beck

• Grasp the rearmost portion of the PTO idler bracket and pivot it toward the discharge chute to relieve

tension on the PTO belt.

• Remove the PTO belt from around the engine pulley and the PTO idler pulley(s).

• Grasp the deck idler pulley and pivot it toward the left side of the deck to relieve tension on the deck

belt.

All Models

• Remove the deck belt from around all pulleys,

including the deck idler pulley(s).

• Route the new belt(s) (deck belt first - 46" deck) as shown in Figure 26 and Figure 27.

• Remount the belt guards removed earlier.

Left Hand Spindle Pulley

42-inchDecks

Figure 26

Engine Pulley

)eck Idler

Left Hand _

Double Pulley

Center Pulley

]OTE: FrontDeck wheels are NOT standard equipment,

Figure 27

PTO Idler Bracket

(mounted on tractor)

46-inchDecks

Deckbelt (Bottom)

[] PTO belt(Top)

Right Hand Pulley

belt guard)

ChangingtheTransmissionDriveBelts

NOTE: Several components must be removed and special tools (i.e. air/impact wrench) in order to change the

tractor's drive belts. See an authorized MTD Service Dealer to have your drive belts replaced or phone Customer Support as instructed on page 2 for information on ordering an MTD Service Manual.

SECTION9: OFF-SEASONSTORAGE

Clean and lubricate the tractor as instructed in Section7: MAINTAININGYOURLAWNTRACTORon page 22 of this

manual before storing for an extended period.

WARNING: Drain fuel only into an approved container outdoors, away from an

open flame. Allow engine to cool. Extinguish cigarettes, cigars, pipes, and other sources of ignition prior to draining fuel.

Follow the instructions in the Service, Storage & Specifications section of the Briggs & Stratton Operator/Owner Manual for proper engine care prior to storing your tractor.

WARNING: Never store the machine or fuel container indoors where there is an open

flame, spark or pilot light such as on water

heater, furnace, clothes dryer or other gas

appliance.

SECTION10: ATTACHMENTS& ACCESSORIES

The following attachments and accessories are compatible for Model 604 and 605 Lawn Tractors. See the retailer from which you purchased your tractor, an authorized MTD Service Dealer or phone (800) 800-7310 for information regarding price and availability.

NOTE: Model 604 and 605 Lawn Tractors are NOT designed for use with any type of ground-engaging

attachments (e.g. tiller or plow). Use of this type of equipment WILL void the tractor's warranty.

MODEL

0EM-190-116 0EM-190-118 0EM-190-180 0EM-190-182 0EM-190-604 0EM-190-607 0EM-190-672 0EM-190-823 0EM-190-833

42-inch Deck Mulch Kit 46-inch Deck Mulch Kit

FastAttach TM Twin Bagger Grass Collector (for 42-inch Decks)

FastAttach TM FastAttach TM FastAttach TM FastAttach TM FastAttach TM FastAttach TM

Twin Bagger Grass Collector (for 46-inch Decks) Yard-Mate TM Storage Container/Toolbox (mounts on rear of tractor)*

Deluxe Tractor Sunshade* Grille Guard Bumper Kit (mounts on front of tractor)

42-inch Two-stage Snow Thrower

46-inch Front Dozer Blade

DESCRIPTION

* Not compatible with tractors equipped with a Grass Collector

SECTION11:TROUBLESHOOTING

Trouble Possible Cause(s)

Engine fails to start PTO engaged.

Parking brake not engaged.

Spark plug wire(s) disconnected. Throttle control lever not in correct

starting position. Choke not activated

Fuel tank empty, or stale fuel. Blocked fuel line.

Faulty spark plug. Engine flooded.

Engine runs erratic

Engine overheats Engine oil level low.

Engine hesitates at high RPM Spark plug(s) gap too close. Idles poorly Spark plug(s) fouled, faulty or gap too

Excessive vibration

Mower will not mulch grass

Uneven cut Deck not balanced properly.

Unit running with CHOKE applied.

Spark plug wire(s) loose.

Blocked fuel line or stale fuel.

Vent in gas cap plugged. Water or dirt in fuel system.

Dirty air cleaner.

Air flow restricted.

wide.

Dirty air cleaner.

Cutting blade loose or unbalanced. Damaged or bent cutting blade. Engine speed too low.

Wet grass.

Excessively high grass.

Dull blade.

Dull blade. Uneven tire pressure.

Corrective Action Place PTO lever in disengaged (OFF)

position. Engage parking brake. Connect wire(s) to spark plug(s). Place throttle lever to FAST position.

Pull out the CHOKE control (if so equipped) or place the

throttle control in CHOKE position.

Fill tank with clean, fresh (less than 30 days old) gas. Clean fuel line or replace fuel filter, if so equipped. Clean, adjust gap or replace plug. Crank engine with throttle in FAST position. Push CHOKE control (if so equipped) in, or move the

throttle control out of the CHOKE position.

Connect and tighten spark plug wire(s). Clean fuel line; fill tank with clean, fresh (less than 30 days old) gasoline. Replace fuel filter, if so equipped. Clear vent or replace cap if damaged. Drain fuel tank. Refill with clean, fresh (less than 30 days old) gasoline. Replace air cleaner cartridge/element or clean pre-

cleaner, if so equipped.

Fill crankcase with proper capacity and weight of oil. Clean grass clippings and debris from around the engine's cooling fins and blower housing. Remove spark plug(s) and reset the gap. Replace spark plug(s). Set plug(s) gap.

Replace air cleaner cartridge/element or clean pre- cleaner, if so equipped. Tighten blade and spindle. Balance blade.

Replace blade.

Place throttle control in FAST (rabbit) position.

Do not mow when grass is wet; wait until later to cut.

Mow once at a high cutting height, then mow again at

desired height or make a narrower cutting swath.

Sharpen or replace blade.

Perform side-to-side deck adjustment.

Sharpen or replace blade.

Check tire pressure in all four tires.

SECTION12: ILLUSTRATEDPARTSLIST

(for choke)(_ @

(forthrottle)

REF.

NO.

1 2 3 4 5 6 7 8 9

10 11 12

NOTE:

PART

NO. 710-0227 710-0599 710-0726 710-1237 710-1314A 710-1315 712-3005 721-0460 726-0205 725-0157 736-0300 751 B221535

Tractor features vary by model. NOT all parts fisted and pictured above are standard equipment.

Screw, #8-18 x.50 13 Screw, 1/4-20 x.50 14

Screw, 5/16-18 x.750 15 Screw, #10-32 x.625 16 Socket Cap Screw, 5/16-18 x.625 17 Self-tapping Screw, 3/8-16 x 1.25 18 Flange Lock Nut, 3/8-16 19

Exhaust Gasket 20 Hose Clamp 21

Cable Tie 22 Lock Washer,.406 x.875 x.059 23

Casing Clamp

DESCRIPTION NO.

REF.

PART

NO. 751-0535 751-0564A 751-0616A 751-0650B 751-0651B 751-3140 751-3141 751-3142 783-0615D 712-0271 783-0625C

Fuel Line Hose Muffler Deflector

Muffler, Twin Inlet RH Exhaust Pipe LH Exhaust Pipe

Oil Drain Valve Oil Drain Hose

Oil Drain Cap

Muffler Bracket Sems Nut, 1/4-20

Heat Shield

DESCRIPTION

Models604 & 605

Models604&605

REF.

NO.

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19

20 21 22 23 24 25

27 28 29 30 31 32

34 35 36 37 38 39

PART

NO. 710-04095 710-0514 710-0643 711-1408 711-1409A 712-0214 712-04065 712-0459 712-3004A 712-0240 717-1550E 717-1554 723-0448A 736-3004 736-3084 710-0726 738-04154 738-1001A 741-0475 738-0143 783-0726D 783-0727C 783-0728 631-04008 731-04065 731-04040 738-04128 738-1011A 734-2290A 736-0316 714-04039 719-04105 726-0341 638-04006 638-04003 638-04005 638-04004 711-0332 714-04023 783-0720A 783-04568 741-0656A 634-04086 634-04087 734-1731 734-04040 634-04081

DESCRIPTION

Hex Screw, 3/8-16, 1.00, Gr5 Hex Screw, 3/8-16, 1.00, Gr5 Hex Screw, 5/16-18, 1.00, Gr5 Link, Drag, RH Link, Drag, LH Nut, Hex Lock, 3/8-24 Nut, Flange Lock, 3/8-16, Grf, Nylon Nut, Flange Lock, 7/16-20 Nut, Flange Lock, 5/16-18, Gr5 Nut, Jam, 7/16-20, Gr2 Gear, Steering, 11/90 Ratio Gear, Pinion, Steering Ball Joint, 7/16-20, Lock Washer, Flat,.406 x.875 x.105 Washer, Flat,.51 x 1.12x.06 Screw, 5/16-12, 0.750 Spacer, Shoulder,.38 x 1.00 x.31 Shaft, Steering,.625 OD x 24.25 Lg Plastic Bushing.380 ID Screw, Shoulder,.498 x.340, 3/8-16 Pivot Bracket, Support RH Pivot Bracket, Support LH

Pivot Bracket, Bar Steering Wheel, 3 Spoke, Soft Grip Steering Wheel Cover (Model 604) Steering Wheel Cap (Model 605) Shlder Screw,.5 x 2.380, 3/8-16 (42" Deck) Shlder Screw,.5 x 2.2, 3/8-16 (46" Deck) Deluxe Hub Cap Flat Washer,.78 x 1.589 x.06 Cotter Pin, 5/32 x 1.25

Cast Iron Pivot Bar Push Cap

LH Axle Assembly,.750 (42" Deck) LH Axle Assembly,.750 (46" Deck) RH Axle Assembly,.750 (42" Deck) RH Axle Assembly,.750 (46" Deck) Pin, Clevis,.50 x.78 (46" Deck) Cotter Pin, Inter,.080 x 1.5625 (46" Deck) Front Adjustment Bracket (46" Deck) Deck Hanger Bracket, Front (42" Deck) Hex Flange Bearing Wheel Ass'y Complete, 15 x 6 (42" Deck) Wheel Ass'y Complete, 15 x 6 (46" Deck) Tire Only 15 x 6 x 6 (42" Deck) Tire Only 15 x 6 x 6 (46" Deck) Rim Only w/Valve Stem (All Models)

NOTE: Tractor features vary by model. NOT all parts listed above and pictured on theprevious page are standard equipment.

Model604

\\\

X i

Model604

REE PART

NO. NO.

1 710-3015 2 710-0599 3 712-04064 4 710-0895 5 710-0924 6 710-0376 7 712-0292 8 712-04063 9 726-0201

10 783-0808A 11 731-1978

731-1979 12 747-1132A 13 731-1980B 14 731-1981C 15 731-1982C 16 736-0173 17 736-0342 18 783-04323B 19 736-3078

20 710-0642 21 710-1611B 22 710-1652 23 710-1017 24 710-3217

DESCRIPTION

Hex Cap Screw, 1/4-20 x.75 Self-tapping Screw, 1/4-20 x.5 Flange Lock Nut, 1/4-20 Self-tapping Screw, 1/4-15 x.75 Pan Phillips Screw, 1/4-20 x.75 Hex Cap Screw, 5/16-18 x 1.0 U-type Speed Nut, 1/4-20 Flange Lock Nut, 5/16-18 Speed Nut

Hood Heat Shield RH Headlight Lens

LH Headlight Lens Hood Support Rod

Hood LH Side Panel RH Side Panel

Flat Washer,.28 x.74 x.063 Flat Washer,.283 x.75 x.030 Dash Support Plate LH Flat Washer,.349 x 1.0 x.063 Self-tapping Screw, 1/4-20 x.75 Self-tapping Screw, 5/16-18 x.75 Self-tapping Screw, 1/4-20 x.625 Self-tapping Screw, 1/4-14 x.625 Screw, #8-32 x.375

REF.

NO.

25 26 27 28 29 30 31 32 33 34 35

36 37 38 39 40 41 42 43 44

t Not

PART

NO. 712-0142 731-05002 731-04213 731-1857 731-04214 747-1155 783-04285B 731-2234A 751-0658E 751-0603 725-1745 725-1744 710-0726 747-04301 725-04156 725-04227 725-1649 725-0963 736-0142 746-1086 746-1085A

629-04083t 629-04103t 629-04144t

Shown

DESCRIPTION

Hex Nut, 8-32 Dash Panel

Parking Brake Lever Throttle Control Knob

Cruise Control Lever Brake/Cruise Pivot Rod

Dash Support Plate RH Intake Bellow (Not Shown) Fuel Tank, 3-gallon Fuel Cap Ignition Key w/plastic cover Ignition Key w/o plastic cover Self-tapping Screw, 5/16-18 x.75 Side Panel Support Systems Indicator Monitor, Ammeter Ignition Switch Lamp Socket Lamp, 12V Flat Washer,.281 x.50 x.063

Throttle Control/Cable Choke Knob/Cable

Headlight Wire Harness Tractor Wire Harness

Jumper Harness Assembly

Model605

\\\\\\\\\\\\\\\\

.I j-_

_, j.-J

\ ....

.J'J

Model605

Ref.

No.

10.

11.

12.

13.

14.

15.

16.

17.

18.

19.

20.

Part

No.

710-0726 710-0599 710-0751

746-1086 746-1085A 731-04949 738-04091 783-04551 783-04552 783-04578 783-04577

783-04621 712-04064 751-0658E 751-0603 710-1017 710-0895 710-3217 712-0142 731-1857 731-05001

Description

Screw, 5/16-12 x.750 Self-tapping Screw, 1/4-20 x.5

Hex Cap Screw, 1/4-20 x.62

Throttle Control/Cable

Choke Knob/Cable Headlight Lens

Shoulder Screw,.43 x.29 Hood, 1 Style

Grill, 1 Style Pivot Bracket - RH

Pivot Bracket - LH Grill Pivot Bracket

Flange Lock Nut, 1/4-20 Fuel Tank, Three Gallon Fuel Cap Screw, 1/4-14 x.625 Self-tapping Screw, 1/4-15 x.75

Truss Phillips Screw, #8-32 x.375

Hex Nut, #8-32

Throttle Control Knob

Dash Panel

Ref. Part

No. No.

21. 731-04215

22. 731-04217

23. 736-0142

24. 747-1196

25. 629-04083t

26. 731-05165

27. 783-04285B

28. 710-0642

29. 783-04323B

30. 725-0963

31. 736-0270

32. 710-1611B

33. 725-1649

34. 710-1652

35. 731-05173

36. 725-1745 725-1744

37. 725-04227

38. 725-04156

-- 629-04103t

-- 629-04144t

t Not Shown

Description

Cruise Control Button Parking Brake Button

Flat Washer, 9/32 x 1/2 x 1/16 Brake/Cruise Pivot Rod

Headlight Wire Harness Hood Plenum

RH Dash Support Plate Self-tapping Screw, 1/4-20 x.75 LH Dash Support Plate Lamp

Bell Washer,.265 x.75 x.062 Screw, 5/16-18 x.75

Headlight Socket Hex Index Screw, 1/4-20 x.625

Hood Cover, 5 Style Ignition Key w/plastic cover Ignition Key w/o plastic cover

Ignition Switch Systems Ind. Monitor w/Ammeter

Wire Harness Jumper Harness Assembly

Models604 & 605

i!i!i_

Left Hand Transmission

Bolt Mounting

Models604&605

REE PART

NO. NO.

1 17840 2 725-04039 3 17962 4 647-04020 5 710-0607 6 710-0726 7 710-0809 8 710-1007 9 710-1266

10 710-3144 11 711-0736 12 712-0241 13 712-04063 14 712-0431 15 712-0700 16 714-0104 17 714-0111 18 714-0209

19 714-0470 20 718-0758A 21 720-04028 22 723-3018

23 731-04602

24 731-04604 25 732-0384 26 732-0525 27 732-0716 28 732-0963 29 736-0169 30 710-0224 31 738-0372B 32 747-04146 33 747-04164 34 747-1127 35 748-0334 36 750-0566A 37 754-0467 38 754-0468 39 756-04002 40 756-0981B 41 783-04283 42 783-04360 43 783-04442

44 647-0031B 45 647-0032A 46 683-0266 47 710-0650 48 710-1260A 49 710-1611B

50 711-04159B 51 712-3004A

DESCRIPTION

Mounting Bracket, Transaxle Switch, Interlock Plate, Switch Lever Assembly, Shift Screw, 5/16-18, 0.500 Screw, 5/16-12, 0.750 Screw, 1/4-20, 1.250 Screw, Sems, 3/8-16, 1.500 Screw, 5/16-18, 3.50, Gr5 Screw, 3/8-16, 2.00, Gr5

Adjustment Ferrule 1/4-20 x 1.

Nut, Hex, 3/8-24, Gr5 Nut, Flange Lock, 5/16-18, GrF, Nylon Nut, Flange Lock, 3/8-16, GrF, Nylon Nut, Flange, 9/16-18, Gr2 Pin, Cotter,.072 Dia. x 1.13 Pin, Cotter, 3/32, 1.0 Cotter Pin, Internal,.125 Dia. Pin, Cotter, 1/8 x 1.25 Pulley Hub, 5/8 Spline Knob, Shift

Ball Joint Sleeve,.758 x.821 x 3.3125

Sleeve,.758 x.821 x 2.4375 Spring, Extension,.62 Dia x 6.12 Spring Clip, Shifter Spring, Extension,.59 OD x 4.00 Spring, Extension,.50 Dia x 6.37

Washer, Lock, 3/8

Screw, #10-16,.50 Spacer, Shoulder, 1.00 x.38 x.38 Rod, Shift Rod, Brake Idler Rod, Adjustable, 3/8 Spacer, .68 Spacer,.260 x.372 x 1.030 Belt, V-Type Belt, V-Type Pulley, V-Type, 7.25 Dia. Idler Pulley, Flat 2.75 OD Bracket, Shift Bracket, Shift, F-N-R Idler Bracket, Center Double Control Assembly, Brake Control Assembly, Speed Pedal Assembly Screw, 5/16-18, 0.875 Screw,5/16-18, 0.750 Screw, 5/16-18, 0.750 Pin, 3/8-16 x 2.68 Nut, Flange Lock, 5/16-18, Gr5

REF.

NO.

52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97

PART

NO. 732-0335 732-0955 732-0963 735-0662 735-3049 736-0187 736-0262 736-0300 736-3008 738-0155 738-0380 741-0225 741-3065B 747-04093 747-04096 748-04039B 683-04186 783-0773A 783-04612 618-04034 683-04055A 683-04130 710-0227 710-0514 710-0604A 710-1315 712-0130 725-1644 726-0320 750-04294 756-0116A 656-04015 683-04129 710-0627 710-0642 718-04012 736-0362 741-0600 783-04707 736-0242 712-04065 710-0599 736-0430 731-2290A 736-0119 634-0177 634-0104 734-1873 734-1730 634-0070 734-0603A

DESCRIPTION

Spring, Compression,.405 x 1.17

Spring, Extension,.50 OD x 1.41 Spring, Extension,.50 OD x 6.37

Pad

Pad, Brake Washer, Flat,.64 x 1.24 x.06, Ht Washer, Flat,.385 x.870 x.092 Washer, Flat,.406 x.875 x.059 Washer, Flat,.344 x.750 x. 120

Screw, Shoulder.437 Dia x.162 Screw, Shoulder,.50 x.27 Lg, 3/8-16

Bearing, Hex Flange

Split Bearing, Hex Flange

Rod, Brake Lock

Rod, Cruise Control

Latch, Cruise Control

Bracket, Lockout

Ped, Brake

Bracket, Steering Support Transmission, Single Speed

Bracket Assembly, Torque

Bracket, Idler Screw, #8-18 x.50 Screw, 3/8-16, 1.00

Screw, 5/16-18,.625 Screw, 3/8-16, 1.250

Nut, Lock, 3/8-16, Nylon

Switch Spring, Short

Plate, Insulator

Spacer, Shoulder

Pulley, V-Type, 3.06

Pulley Assembly, Variable Speed

Bracket, Pulley

Screw, 5/16-24, .750

Screw, 1/4-20,.750 Cup, Bearing Washer, Flat

Ball Bearing

Switch Bracket, Parking Brake Washer, Bell,.340 x.872 x.060

Nut, Flange Lock, 3/8-16, GrF, Nylon

Screw, 1/4-20 x.500

Flat Washer,.350 x 1.59 x.062

Hub Cap

Lock Washer, 5/16 Whl Ass'y Comp., 20 x 10 x 8 (Model 604) Whl Ass'y Comp., 20 x 8 x 8 (Model 605) Tire Only 20 x 10 x 8 (Model 604) Tire Only 20 x 8 x 8 (Model 605)

Rim Only w/Valve Stem (Model 604)

Rim Only w/Valve Stem (Model 605)

NOTE: Tractor features vary by model NOT all parts listed above and pictured on theprevious page are standard equipment.

Models604 & 605 (42" Deck)

IMPORTANT:For a proper working machine, use

Factory Approved Parts. V-belts are designed to engage and disengage safely. A substitute (non OEM) V-belt can be dangerous by not disengaging completely.

_2_

'\ y

(4_.............

(

Models604&605(42" Deck)

REE PART

NO. NO.

1 17962 2 647-04036 3 710-0809 4 710-0859 5 710-0276 6 710-1260A 7 710-3157A 8 710-0726 9 714-0145

10 732-04248 11 736-0171 12 746-04092 13 712-04065 14 750-0566A 15 714-0470 16 726-0201 17 731-2111A 18 783-04590

19 736-0322 20 741-0708 21 747-04307 22 747-1112D 23 748-0415B 24 750-0956 25 756-04064A

DESCRIPTION

Plate, Switch Lever Assembly, Engagement Screw, 1/4-20 x 1.250 Screw, 3/8-16, 2.50 Screw, Carriage, 5/16-18, 1.00 Screw, 5/16-18 x.750 Screw, 7/16-20, 3.25, Gr5 Screw, 5/16-12, 0.750

Click Pin Extension Spring,.38OD x 3.9LG

Lock Washer, 7/16 Deck Engagement Cable Nut, Flange Lock, 3/8-16, GrF, Nylon Spacer,.260 x.372 x 1.030LG Pin, Cotter, 1/8 x 1.25 Nut, Speed,.3125 ID Knob, PTO

Cable Bracket

Washer, Flat,.450 x1.250 x.164

Bearing, Flange, Hex Split.500 ID Keeper Rod, Belt Engagement Handle, Deck Spacer,.385 ID x.635 OD x 1.54 Spacer, 1.010 x 1.400 x.825 Pulley, Engine, 3.39 x 6.12 Diameter

REF. PART

NO. NO.

26 783-0744A 27 683-04173 28 710-0607 29 710-0642 30 710-3005 31 712-04064 32 712-3006 33 732-04035 34 736-0222 35 736-0329 36 738-04058 37 747-04121A 38 783-0349 39 783-04329A 40 783-04375A 41 710-0599 42 725-1426 43 725-04039 44 710-0224 45 712-04063 46 712-0271 47 725-1737A 48 738-1132 49 710-0703 50 712-3087

DESCRIPTION Stop Bracket, Engagement Frame Assembly, Lower

Screw, 5/16-18, 0.500

Screw, 1/4-20, 0.750 Screw, 3/8-16, 1.25, Gr5

Nut, Flange Lock, 1/4-20, GrF, Nylon Nut, Hex, 1/4-20, Gr5

Spring, Compression, 1.28 OD x 3.125

Washer, Lock, 1/4, External Washer, Lock, 1/4

Spacer, Shoulder,.38 x 1.0 x.70 Hold Rod, Battery Battery Tray Seat Bracket, Frame

Frame, Upper

Screw, 1/4-20, 0.50

Solenoid, 12V, 100 Amp Switch, Interlock Screw, #10-16, .50

Nut, Flange, Lock Nut, 5/16-18 Nut, Sems, 1/4-20

Battery, 190 CCA

Screw, Shoulder,.250 x.15, 1/4-20

Screw, Carriage, 1/4-20,.75 Nut, Wing, 1/4-20

NOTE: Tractor features vary by model. NOT all parts listed above and pictured on theprevious page are standard equipment.

_25_

IMPORTANT:For a proper working machine, use Factory Approved Parts. V-belts are designed to engage and disengage safely. A substitute (non OEM) V-belt can be dangerous by not disengaging completely.

d_ ...................

Models604&605(46" Deck)

REE PART

NO. NO.

1 17962 2 647-0064 3 683-0302 4 710-0224 5 710-0276 6 710-0347 7 710-04377 8 710-0726 9 710-0831

10 711-1044 11 712-0229 12 712-04063 13 712-04065 14 712-3004A 15 714-0470 16 726-0201 17 731-2111A 18 732-04245A

19 732-0944 20 732-1013 21 736-0108 22 736-0119 23 736-0140 24 736-0227 25 736-0242 26 736-0275 27 736-0300 28 736-0322 29 736-3010 30 738-0372B 31 741-0708 32 747-04355

DESCRIPTION

Plate, Switch Lever Assembly, Engagement Plate Assembly, Engagement Screw, #10-16, 0.500 Screw, Carriage, 5/16-18, 1.00 Screw, 3/8-16, 1.75, Gr5 Screw, 7/16-20, 2.75, Gr5 Screw, 5/16-12, 0.750 Screw, 3/8-16, 5.50, Gr5 Pin, Belt Guard, 5/16 x 4.75 Nut, Push, 3/8 Nut, Flange Lock, 5/16-18, GrF, Nylon Nut, Flange Lock, 3/8-16, GrF, Nylon Nut, Flange Lock, 5/16-18, Gr5 Pin, Cotter, 1/8 x 1.25 Nut, Speed,.3125 ID Knob, PTO

Belt Guard Spring, Extension,.75 OD x 6.75

Belt Guard

Washer, Flat,.510 x.750 x.033 Washer, Lock, 5/16 Washer, Flat,.385 x.62 x.063 Washer, Flat,.390 x 1.500 x.134 Washer, Bell,.340 x.872 x.060 Washer, Flat,.344 x.688 x.065 Washer, Flat,.406 x.875 x.059 Washer, Flat,.450 x1.250 x.164 Washer, Flat,.407 x.812 x.135

Spacer, Shldr, 1.00 x.38 x.38 Bearing, Flange, Hex Split.500 ID Keeper Rod, Belt

REF.

NO.

33 34 35 36 37 38 39 4O 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63

PART

NO. 747-1112D 748-0415B 750-0956 756-04142 756-0487 756-0627D 783-04467 783-0744A 683-04173 710-0607 710-0642 710-3005 712-04064 712-3006 732-04035 736-0222 736-0329 738-04058 747-04121A 783-0349 783-04329A 783-04375A 710-0599 725-1426A 725-04039 710-0703 712-0271 712-3087 725-1750A 738-1132 754-04064

DESCRIPTION Engagement Handle, Deck Spacer,.385 ID x.635 OD x 1.54

Spacer, 1.010 x 1.400 x.825 Pulley, Engine, 3.39 x 6.12 Diameter

Pulley, Idler, V-type 5/8 x 4.0 Diameter Pulley, Idler, 3.50 Diameter Stop Bracket, Deck-Up

Stop Bracket, Engagement Frame Assembly, Lower

Screw, 5/16-18, 0.500

Screw, 1/4-20, 0.750 Screw, 3/8-16, 1.25, Gr5

Nut, Flange Lock, 1/4-20, GrF, Nylon Nut, Hex, 1/4-20, Gr5

Spring, Compression, 1.28 OD x 3.125

Washer, Lock, 1/4, External Washer, Lock, 1/4

Spacer, Shoulder,.38 x 1.0 x.70 Hold Rod, Battery

Battery Tray Seat Bracket, Frame

Frame, Upper

Screw, 1/4-20, 0.50

Solenoid, 12V, 100 Amp Switch, Interlock

Screw, Carriage, 1/4-20,.75, Gr5 Nut, Sems, 1/4-20

Nut, Wing, 1/4-20 Battery, 235 CCA

Screw, Shoulder,.250 x.150, 1/4-20 V-Belt, PTO

Models604 &605

Modelsw/Manually

AdjustingSeat

Modelsw/Quick

Adjust Seat

(1;

\\\

Models604 & 605

REE PART

NO. NO.

1 710-1268 2 712-04063 3 712-3027 4 720-0309A 5 726-0201 6 731-04074 7 732-0499 8 732-1184 9 736-0275

10 736-3019 11 738-0137A 12 738-0296 13 738-0966 14 783-0209C

683-04193 15 783-0611 16 783-0738B 17 783-0739A 18 783-0753 19 757-04011C 20 726-3046 21 735-0656

735-0672 22 735-0657

735-0673 23 710-0451 24 710-0599 25 710-0726 26 710-0895 27 731-1990 28 731-2104C

731-04591A 29 736-3078 30 783-04333A

REF.

DESCRIPTION

Screw, #10-16 x.375 Nut, Flange Lock, 5/16-18, GrF, Nylon 31 Nut, Flange Lock, 1/4-20 Seat Adjuster Grip 32 Nut, Speed,.3125 ID 33 Spacer 34 Compression Spring,.41 x 1.5 35 Spring, Extension,.84 Dia. x 4.6 36 Wash, Flat,.344 x.688 x.065 37 Wash, Flat,.53 lx 1.062 x. 134 38 Screw, Shoulder,.340 x.285,1/4-20 39 Screw, Shoulder,.437 x.268, 5/16-18 40 Screw, Shoulder,.50 x.925, 3/8-16 41 Seat Bracket, Lift (Model 604H/605H) 42 Seat Bracket, Lift (Model 605G) 43 Seat Stop 44

Seat Pivot Bracket 45 Seat Adjustment Lever

Seat Adjustment Selector Medium Back Seat, Yellow Ratchet Clip RH Foot Pad, Rubber (Model 604H/605H) RH Foot Pad, Rubber (Model 605G) LH Foot Pad, Rubber (Model 604H/605H) LH Foot Pad, Rubber (Model 605G) Bolt, Carriage, 5/16-18,.75, Grl Screw, 1/4-20, 0.500 52 Screw, 5/16-12, 0.750 53 Screw, 1/4-15, 0.750 (Model 604H/605H) Cover, Lift Lever (Model 604H/605H) 54 Cover, w/Cup Holder (Model 604H/605H) 55 Cup Holder (Model 605G) 56 Washer, Flat,.344 x 1.0 x.063 57 Fender (Model 604H/605H) 58

NO.

47 48 49 5O 51

PART

NO. 783-04314A 783-0677 783-1010A 783-1489A 710-0227 726-0279 725-1303 725-1439 726-0278

683-04079 712-04065 714-0104 714-0111 716-0106A 720-0311 732-0874 738-0138A 738-04130 738-0380 741-0225 746-0968 747-04155 756-1154 783-04711 783-04494 783-0678A 736-0607 710-0726 710-1611B 738-04012 720-04009 736-0101 783-04081A 710-0870

DESCRIPTION

Fender (Model 605G) Adjustment Brkt, Lift (Model 604H/605H) Adjustment Brkt, Lift (Model 605G) Mounting Bracket, Seat Screw, #8-18 x.50 Plate, Insulator Spring Switch, Outer Spring Switch, Inner Plate, Insulator Boss Shaft Assembly, Lift Nut, Flange Lock, 3/8-16, GrF, Nylon Pin, Cotter,.072 Dia. x 1.13 Pin, Cotter, 3/32, 1.0 Ring, E Type,.625 Dia. Grip, Handle, 1/2 Spring, Torsion Screw, 5/16-18 x.620 Gr2 Screw, Shldr,.625 x.165, 3/8-16 (42" Deck) Screw, Shld,.50 x.27, 3/8-16 (46" Deck) Bearing, Hex Flange Cable, Lift, 16.16 Handle, Lift Pulley, Roller Arm, Lift - LH (42" Deck)

Arm, Lift - RH (42" Deck)

Arm, Lift- LH & RH (46" Deck) Lock Washer, 5/16 Screw, 5/16-12, 0.750 (Model 604H/605H) Screw, 5/16-18 x.750 (Model 605G)

Shoulder Screw Knob, 3/8-16

Flat Washer,.406 x 1.00 x.030 Seat Pivot Bracket, Manually Adjusted Hex Head Washer Screw, 3/8-16 x.625

NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.

Models604 & 605

3 8

22 23

Models604&605

REF.

NO.

1 2 3

4 5 6 7 8

9 10 11 12 13 14 15 17 19

21 22 23 24 25 26 27 28 29

PART

NO. 732-0614 716-0231 736-0336* 736-0337* 736-0349* 736-0335 710-1325 719-04017 711-1109 741-0335 717-1464 716-0108 741-0340 721-0338 618-04041 741-0336 717-04056 718-04045 711-04134 736-0495* 736-0494* 741-0337 611-0011 741-0862 732-0863 719-04018 717-0678 761-0202 710-1206 661-0001 737-0148

DESCRIPTION

Ring, Wire Ring, E Type,.750 Flat Washer, 5/8 x 1.0 x.030 Flat Washer, 5/8 x 1.0 x.040

Flat Washer, 5/8 x 1.0 x.020 Washer, Thrust.635 x 1.26 x.06 Self-tapping Screw, 1/4-20 x 1.625

Upper Housing

Input Shaft

Needle Bearing,.625 x.813 x.495

14-tooth Bevel Pinion

Retaining Ring,.437 Sleeve Bearing,.75 x.1.0 x 1.0 Seal,.75 x 1.0 x.125

Differential Assembly

Flange Bearing, 5/8 x 3/4 x 3/4 42-tooth Bevel Gear

Clutch Collar

Drive Shaft Thrust Washer, 1.0 x.632 x.0

Flat Washer,.632 x 1.00 x.035

Flange Bearing, 5/8 x 3/4 x 15/16

Detent Shaft Assembly

Detent Ball Compression Spring

Lower Housing

Brake Puck

Brake Disc Self-tapping Screw, 1/4-20 x 2.375

Brake Assembly Grease (19 oz.)

*Use applicable washers (ref. no.'s 3 or 20) in this application allowing.0150/.O020 in. end-play.

NOTE: If rebuilding the upper housing, include two ounces (2 oz.) of Unirex ® N3 grease (Part No. 737-0289) in the input shaft cavity.

Models604 & 605 (42" Deck)

\\\\\\\

\\\\\

Models604&605(42" Deck)

REF.

NO.

1 2 3 4 5 6 7 8 9

10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29

PART

NO. 618-0624 683-04138 683-04162 683-04167 683-0254B 710-0751 710-0650 710-0528 710-0726 710-1260A 710-0778 710-3085 711-04069 712-3006 712-0417A 712-04064 712-04063 712-04065 712-0641 712-3083 712-0206 714-0470 714-0104 717-04074 726-0233 732-0306A 732-0308A 734-0973 736-0119

DESCRIPTION

Pulley/Spindle Assembly Deck Brake Assembly 42" Deck Assembly Deck Brake Assembly Deck Hanger Bracket Assembly Screw, 1/4-20 x.620 Screw, 5/16-18 x.875 Screw, 5/16-18 x 1.25 Screw, 5/16-12 x.750 Screw, 5/16-18 x.750 Screw, 1/4-20 x 1.500 Screw, 3/8-16 x 3.50

Grass catcher Pin Hex Nut, 1/4-20

Flange Nut, 5/8-18 Flange Lock Nut, 1/4-20 Flange Lock Nut, 5/16-18 Flange Lock Nut, 3/8-16 Hex Nut, M16-1.5 Hex Lock Nut, 1/2-13 Hex Nut, 1/2-13 Cotter Pin, 1/8 x 1.25 Cotter Pin,.072 Dia. x 1.13 Lg. Deck Adjustment Gear Push Nut,.25 ID x.50 OD Compression Spring,.531 OD x 1.75 Lg. Extension Spring,.50 Dia. x 6.37 Lg.

Deck Wheel Lock Washer, 5/16

REE PART

NO. NO.

30 736-0270 31 736-0289 32 736-0267 33 736-0225 34 736-0187 35 738-0373 36 738-04162 37 738-04146 38 742-0616A 39 747-1116 40 747-04269A 41 747-04379 42 748-04069 43 750-0566A 44 754-04060B 45 756-04129 46 783-04327 47 783-1025 48 710-3144 49 712-0431 50 712-0229 51 732-04287 52 750-04446 53 731-1032B

54 710-0134t 55 710-0599t 56 712-3087t 57 731-2363t 58 783-1146At

tlfEquipped

DESCRIPTION

Bell Washer,.265 x.75 x.062 Shoulder Bushing,.320 ID x.135 Lg. Flat Washer,.385 x.87 x.06 Lock Washer, 5/8 Flat Washer,.64 x 1.24 x.06 Shoulder Screw,.498 x 1.53 x 3/8-16 Shoulder Spacer,.8540 x.200 Plug Blade, 21.23", Star 3-in-One

Deck Release Handle Rod Front Deck Adjustment Rod

Brake Control Rod Deck Lift Pivot Cup

Spacer,.260 x.372 x 1.030 Lg.

V-Belt, 96.3 Lg.

Idler Pulley, 4.25" Dia. Belt Cover

Chute Stop Screw, 3/8-16 x 2.00 Flange Lock Nut, 3/8-16 Push Nut, 3/8 Extension Spring,.500 Dia. x 6.375 Lg Spacer, 3/8 ID x.68 OD x 1.46 Lg Discharge Chute Carriage Screw, 1/4-20 x.62 Screw, 1/4-20 x.500

Wing Nut, 1/4-20

Mulch Plug Deck Skirt

IMPORTANT:For a proper working machine, use

Factory Approved Parts. V-belts are designed to engage and disengage safely. A substitute (non OEM) V-belt can be dangerous by not disengaging completely.

NOTE: Tractor features vary by model NOT all parts listed above and pictured on the previous page are standard equipment.

Models604 &605 (46" Deck)

\\ -3

/ i

128)

Models604&605(46" Deck)

REE PART

NO. NO.

1 17116 2 17258D 3 618-0240A 4 618-04134B 5 683-0254B 6 683-04104A 7 710-0344 8 710-0514 9 710-0528

10 710-0599 11 710-3015 12 710-0778 13 710-0805 14 710-1260A 15 710-3180 16 711-04069 17 711-0993 18 711-1554 19 712-0206 20 712-04063 21 712-04064 22 712-04065 23 712-0417A 24 712-0431 25 712-0641 26 712-3006 27 712-3010 28 712-3083 29 714-0470 30 717-04074 31 726-0233 32 732-0306A 33 732-0429A

DESCRIPTION

Brake Assembly, Deck RH Belt Cover, Deck 46" Spindle Assembly, 5.00 Dia. Spindle Ass'y, Double Pulley Hanger Bracket Assembly

Deck Weldment Screw, 3/8-16, 1.50, Gr5

Screw, 3/8-16, 1.00, Gr5 Screw, 5/16-18, 1.25, Gr5 Screw, 1/4-20, 0.500 Screw, 1/4-20 x.75, Gr5 Screw, 1/4-20, 1.500 Screw, 5/16-18, 1.50, Gr5 Screw, Ld, 5/16-18, 0.750 Screw, 5/16-18, 1.75, Gr5 Pin, Grass catcher, 1/4-20

Belt Guard Pin 1/4 Dia x 1.43 Pin, 1/4-20, 3/8 x 2.0

Nut, Hex, 1/2-13, Gr5 Nut, Flange Lock, 5/16-18, GrF, Nylon Nut, Flange Lock, 1/4-20, GrF, Nylon Nut, Flange Lock, 3/8-16, GrF, Nylon Nut, Flange, 5/8-18 Nut, Flange Lock, 3/8-16, GrF Nut, Hex, M16-1.5 Nut, Hex, 1/4-20, Gr5 Nut, Hex, 5/16-18, Gr5 Nut, Hex Lock, 1/2-13, Gr8, Nylon Pin, Cot, 1/8x 1.25 Adjustment Gear, Deck Nut, Push,.25 ID x.50 OD Spring, Compression,.531 OD x 1.75 Spring, Extension,.50 Dia x 3.97

REF. PART

NO. NO.

34 732-0594A 35 732-04197 36 734-0973 37 736-0119 38 736-0225 39 736-0270 40 736-0418A 41 736-3084 42 731-1032B 43 738-0347 44 738-0373 45 738-04146 46 742-0611A 47 742-0612A 48 746-1107 49 747-1116 50 747-1130B 51 748-0234 52 750-0566A 53 750-1320 54 754-0349

55 731-1636t 56 756-04129

57 783-1348B 58 783-0141 59 783-0142 60 783-04641 61 783-1025

62 710-0578t 63 712-3006t 64 712-3087t 65 736-01731-

t If Equipped

DESCRIPTION

Spring, Extension,.91 Dia x 7.33 Spring, Extension,.68 OD x 5.00 Lg Wheel, Deck 5.0 x 1.38 Washer, Lock, 5/16 Washer, Lock, 5/8 Washer, Bell,.265 x.75 x.062 Washer, Flat,.34 x 2.25 x. 10 Washer, Flat,.51 x 1.12 x.06 Chute Assembly Spacer, Shoulder,.625 ID x. 169 Spacer, Shoulder,.498 x 1.53, 3/8-16 Plug, Screw, M16 x 1.5 Blade, 16.28", Star 3-in-One Blade, 14.88", Star 3-in-One Cable, 12.00" Rod, Deck Release Rod, Deck Shoulder Spacer Spacer,.260 x.372 x 1.030 Spacer,.375 x.63 x.595 Belt, V-Type, Poly Mulch Plug Pulley, Idler, 4.25" Dia. Belt Cover, LH Deck Skirt, Center Deck Skirt, RH Bracket, Idler Stop, Chute Screw, 1/4-20 x 1.500 Hex Nut, 1/4-20

Wing Nut, 1/4-20

Flat Washer,.28 x.74 x.063

IMPORTANT:For a proper working machine, use

Factory Approved Parts. V-belts are designed to engage and disengage safely. A substitute (non OEM) V-belt can be dangerous by not disengaging completely.

NOTE: Tractor features vary by model NOT all parts listed above and pictured on the previous page are standard equipment.

NOTES

MANUFACTURER'S LIMITED WARRANTY FOR:

YaRD.MaNTM

The limited warranty set forth below is given by MTD LLC with respect to new merchandise purchased and used in the United States, its possessions and territories.

"MTD" warrants this product against defects in material and workmanship for a period of two (2) years commencing on the date of original purchase and will, at its option, repair or replace, free of charge, any part found to be defective in materials or workmanship. This limited warranty shall only apply if this product has been operated and maintained in accordance with the Operator's Manual furnished with the product, and has not been subject to misuse, abuse, commercial use, neglect, accident, improper maintenance, alteration, vandalism, theft, fire, water, or damage because of other peril or natural disaster. Damage resulting from the installation or use of any part, accessory or attachment not approved by MTD for use with the product(s) covered by this manual will void your warranty as to any resulting damage.

Normal wear parts are warranted to be free from defects in material and workmanship for a period of thirty (30) days from the date of purchase. Normal wear parts include, but are not limited to items such as: batteries, belts, blades, blade adapters, grass bags, rider deck wheels, seats, snow thrower skid shoes, shave plates, auger spiral rubber and tires.

HOW TO OBTAIN SERVICE: Warranty service is available, WITH PROOF OF PURCHASE, through your local authorized service dealer. To locate the dealer in your area, check your Yellow Pages, or contact MTD LLC at P.O. Box 361131, Cleveland, Ohio 44136-0019, or call 1-800-800-7310 or log on to our Web site at www.mtdproducts.com.

This limited warranty does not provide coverage in the following cases:

The engine or component parts thereof. These items

may carry a separate manufacturer's warranty. Refer to applicable manufacturer's warranty for terms and

conditions.

Log splitter pumps, valves, and cylinders have a

separate one year warranty.

Routine maintenance items such as lubricants, filters,

blade sharpening, tune-ups, brake adjustments, clutch adjustments, deck adjustments, and normal

deterioration of the exterior finish due to use or exposure.

Service completed by someone other than an

authorized service dealer.

MTD does not extend any warranty for products sold or

exported outside of the United States, its possessions and territories, except those sold through MTD's authorized channels of export distribution.

Replacement parts that are not genuine MTD parts. Transportation charges and service calls.

No implied warranty, including any implied warranty of merchantability of fitness for a particular purpose, applies after the applicable period of express written warranty above as to the parts as identified. No other express warranty, whether written or oral, except as mentioned above, given by any person or entity, including a dealer or retailer, with respect to any product, shall bind MTD. During the period of the warranty, the exclusive remedy is repair or replacement of the product

as set forth above. The provisions as set forth in this warranty provide the

sole and exclusive remedy arising from the sale. MTD shall not be liable for incidental or consequential loss or damage including, without limitation, expenses incurred

for substitute or replacement lawn care services or for

rental expenses to temporarily replace a warranted product.

Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how

long an implied warranty lasts, so the above exclusions or limitations may not apply to you.

In no event shall recovery of any kind be greater than the amount of the purchase price of the product sold. Alteration of safety features of the product shall void this warranty. You assume the risk and liability for loss, damage, or injury to you and your property and/or to others and their property arising out of the misuse or inability to use the product.

This limited warranty shall not extend to anyone other than the original purchaser orto the person for whom it was purchased as a gift.

HOW STATE LAW RELATES TO THIS WARRANTY: This limited warranty gives you specific legal rights, and you may

also have other rights which vary from state to state.

IMPORTANT:Owner must present Original Proof of

Purchase to obtain warranty coverage.

MTD LLC, P.O.BOX361131CLEVELAND,OHIO44136-0019; Phone:1-800-800-7310

Yard-man 605 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
