OPERATOR’S MANUAL

AutoDriveLawn Tractor

Model 604

Model U604H Shown

IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY

Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forestcovered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required by law (Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 368022 Cleveland, Ohio 44136-9722.

MTD PRODUCTS INC. P.O. BOX 368022 CLEVELAND, OHIO 44136-9722

PRINTED IN U.S.A.

FORM NO. 770-10235A



(9/99)

SECTION 1: TABLE OF CONTENTS

PAGE FINDING YOUR MODEL NUMBER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 CALLING CUSTOMER SUPPORT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 IMPORTANT SAFE OPERATION PRACTICES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 SAFETY LABLES FOUND ON YOUR UNIT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 SLOPE GAUGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 ATTACHMENTS & ACCESSORIES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 TRACTOR SET-UP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 LUBRICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 TROUBLESHOOTING GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 WARRANY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

SECTION 2: FINDING YOUR MODEL NUMBER

This Operator’s Manual is an important part of your new rider. It will help you assemble, prepare and maintain your rider. Please read and understand what it says.

Before you start to prepare your tractor for its first use, please locate the model plate and copy the information from it in this Operator’s Manual. The information on the model plate is very important if you need help from your dealer or the MTD customer support department.

Every tractor has a model plate. You can locate it by lifting the seat and looking at the seat bracket.

An example of what the model plate will look like is shown below.

This is where your model number will be.

XXX-X-XXX-X-XXX XXXXXXXXXXX

This is where your serial number will be.

Copy the model number here:

MTD PRODUCTS INC

Copy the serial number here:

P.O. BOX 368022

CLEVELAND, OHIO 44136



SECTION 3: CALLING CUSTOMER SUPPORT

LOCATE YOUR MODEL NUMBER AND SERIAL NUMBER — Record this information in the space provided. To find your unit’s specific model number and serial number, see SECTION 2: FINDING YOUR MODEL NUMBER.

If you are having difficulty assembling this product or if you have any questions regarding the controls, operation or maintenance of this unit, please call the Customer Support Department.

Customer Support can be reached by dialing: 1- (330) 220-4MTD

(4683)

or

1- (800)-800-7310

Please have your model number and serial number ready when you call.

Although both numbers are important, you will be asked to enter only your serial number before your call can be processed.

2

SECTION 4: IMPORTANT SAFE OPERATION PRACTICES

WARNING: THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH, IF NOT FOLLOWED, COULD ENDANGER THE PERSONAL SAFETY AND/OR PROPERTY OF YOURSELF AND OTHERS. READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE YOUR LAWN MOWER. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. WHEN YOU SEE THIS SYMBOL, HEED ITS WARNING.

WARNING: The Engine Exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.

DANGER: Your lawn mower was built to be operated according to the rules for safe operation in this manual. As with any type of power equipment, carelessness or error on the part of the operator can result in serious injury. This lawn mower is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death.

1.GENERAL OPERATION

Read, understand, and follow all instructions in the operator’s manual and on the machine before starting. Keep this manual in a safe place for future and regular reference and for ordering replacement parts.

Only allow responsible individuals familiar with the instructions to operate the machine. Know controls and how to stop the machine quickly.

Do not put hands or feet under cutting deck or near rotating parts.

Clear the area of objects such as rocks, toys, wire, etc., which could be picked up and thrown by the blade. A small object may have been overlooked and could be accidentally thrown by the mower in any direction and cause injury to you or a bystander. To help avoid a thrown objects injury, keep children, bystanders and helpers at least 75 feet from the mower while it is in operation. Always wear safety glasses or safety goggles during operation or while performing an adjustment or repair, to protect eyes from foreign objects. Stop the blade(s) when crossing gravel drives, walks or roads.

Be sure the area is clear of other people before mowing. Stop machine if anyone enters the area.

Never carry passengers.

Disengage blade(s) before shifting into reverse and backing up. Always look down and behind before and while backing.

Be aware of the mower and attachment discharge direction and do not point it at anyone. Do not operate the mower without either the entire grass catcher or the chute guard in place.

Slow down before turning. Operate the machine smoothly. Avoid erratic operation and excessive speed.

Never leave a running machine unattended. Always turn off blade(s), place transmission in neutral, set park brake, stop engine and remove key before dismounting.

Turn off blade(s) when not mowing.

Stop engine and wait until blade(s) comes to a complete stop before (a) removing grass catcher or unclogging chute, or (b) making any repairs, adjusting or removing any grass or debris.

Mow only in daylight or good artificial light.

Do not operate the machine while under the influence of alcohol or drugs.

Watch for traffic when operating near or crossing roadways.

Use extra care when loading or unloading the machine into a trailer or truck. This unit should not be driven up or down a ramp onto a trailer or truck under power, because the unit could tip over, causing serious personal injury. The unit must be pushed manually on a ramp to load or unload properly.

Never make a cutting height adjustment while engine is running if operator must dismount to do so.

Wear sturdy, rough-soled work shoes and closefitting slacks and shirts. Do not wear loose fitting clothes or jewelry. They can be caught in moving parts. Never operate a unit in bare feet, sandals, or sneakers.

Check overhead clearance carefully before driving under power lines, wires, bridges or low hanging tree branches, before entering or leaving buildings, or in any other situation where the operator may be struck or pulled from the unit, which could result in serious injury.

3

Disengage all attachment clutches, thoroughly depress the brake pedal, and shift into neutral before attempting to start engine.

Your mower is designed to cut normal residential grass of a height no more than 10". Do not attempt to mow through unusually tall, dry grass (e.g., pasture) or piles of dry leaves. Debris may build up on the mower deck or contact the engine exhaust presenting a potential fire hazard.

2.SLOPE OPERATION

Slopes are a major factor related to loss of control and tipover accidents which can result in severe injury or death. All slopes require extra caution. If you cannot back up the slope or if you feel uneasy on it, do not mow it.

For your safety, use the slope gauge included as part of this manual to measure slopes before operating this unit on a sloped or hilly area. If the slope is greater than 15° as shown on the slope gauge, do not operate this unit on that area or serious injury could result.

DO:

Mow up and down slopes, not across.

Remove obstacles such as rocks, limbs, etc.

Watch for holes, ruts or bumps. Uneven terrain could overturn the machine. Tall grass can hide obstacles.

Use slow speed. Always keep machine in gear when going down slopes to take advantage of engine braking action.

Follow the manufacturer’s recommendations for wheel weights or counterweights to improve stability.

Use extra care with grass catchers or other attachments. These can change the stability of the machine.

Keep all movement on the slopes slow and gradual. Do not make sudden changes in speed or direction. Rapid engagement or braking could cause the front of the machine to lift and rapidly flip over backwards which could cause serious injury.

Avoid starting or stopping on a slope. If tires lose traction, disengage the blade(s) and proceed slowly straight down the slope.

DO NOT:

Do not turn on slopes unless necessary; then, turn slowly and gradually downhill, if possible.

Do not mow near drop-offs, ditches or embankments. The mower could suddenly turn over if a wheel is over the edge of a cliff or ditch, or if an edge caves in.

Do not mow on wet grass. Reduced traction could cause sliding.

Do not try to stabilize the machine by putting your foot on the ground.

Do not use grass catcher on steep slopes.

3. CHILDREN

Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the machine and the mowing activity. Never assume that children will remain where you last saw them.

Keep children out of the mowing area and in watchful care of an adult other than the operator.

Be alert and turn machine off if children enter the area.

Before and when backing, look behind and down for small children.

Never carry children, even with the blades off. They may fall off and be seriously injured or interfere with the safe machine operation.

Never allow children under 14 years old to operate the machine. Children 14 years and over should only operate machine under close parental supervision and proper instruction.

Remove key when machine is unattended to prevent unauthorized operation.

Use extra care when approaching blind corners, shrubs, trees or other objects that may obscure your vision of a child or other hazard.

4.SERVICE

Use extreme care in handling gasoline and other fuels. They are extremely flammable and the vapors are explosive.

Use only an approved container.

Never remove fuel cap or add fuel with the engine running. Allow engine to cool at least two minutes before refueling.

Replace fuel cap securely and wipe off any spilled fuel before starting the engine as it may cause a fire or explosion.

Extinguish all cigarettes, cigars, pipes and other sources of ignition.

Never refuel the machine indoors because fuel vapors will accumulate in the area.

Never store the fuel container or machine inside where there is an open flame or spark, such as a gas hot water heater, space heater or furnace.

Never run a machine inside a closed area.

To reduce fire hazard, keep the machine free of grass, leaves or other debris build-up. Clean up oil or fuel spillage. Allow machine to cool at least 5 minutes before storing.

Before cleaning, repairing or inspecting, make certain the blade and all moving parts have stopped. Disconnect the spark plug wire, and keep the wire away from the spark plug to prevent accidental starting.

Check the blade and engine mounting bolts at frequent intervals for proper tightness. Also, visually inspect blade for damage (e.g., excessive wear, bent, cracked). Replace with blade which meets original equipment specifications.

4

Keep all nuts, bolts and screws tight to be sure the equipment is in safe working condition.

Never tamper with safety devices. Check their proper operation regularly. Use all guards as instructed in this manual.

After striking a foreign object, stop the engine, remove the wire from the spark plug and thoroughly inspect the mower for any damage. Repair the damage before restarting and operating the mower.

Grass catcher components are subject to wear, damage and deterioration, which could expose moving parts or allow objects to be thrown. For your safety protection, frequently check components and replace with manufacturer’s recommended parts when necessary.

Mower blades are sharp and can cut. Wrap the blade(s) or wear gloves and use extra caution when servicing blade(s).

Check brake operation frequently. Adjust and service as required.

Muffler, engine and belt guards become hot during operation and can cause a burn. Allow to cool down before touching.

Do not change the engine governor settings or overspeed the engine. Excessive engine speeds are dangerous.

Observe proper disposal laws and regulations. Improper disposal of fluids and materials can harm the environment and the ecology.

Prior to disposal, determine the proper method to dispose of waste from your local Environmental Protection Agency. Recycling centers are established to properly dispose of materials in an environmentally safe fashion.

Use proper containers when draining fluids. Do not use food or beverage containers that may mislead someone into drinking from them. Properly dispose of the containers immediately following the draining of fluids.

DO NOT pour oil or other fluids into the ground, down a drain or into a stream, pond, lake or other body of water. Observe Environmental Protection Agency regulations when disposing of oil, fuel, coolant, brake fluid, filters, batteries, tires and other harmful waste.

WARNING - YOUR RESPONSIBILITY: Restrict the use of this power machine to persons who read, understand and follow the warnings and instructions in this manual and on the machine.

WARNING

TO AVOID SERIOUS INJURY OR DEATH

• GO UP AND DOWN SLOPES, NOT ACROSS. AVOID SUDDEN TURNS.

• DO NOT OPERATE THE UNIT WHERE IT COULD SLIP OR TIP.

• IF MACHINE STOPS GOING UPHILL, STOP BLADE(S) AND BACK DOWNHILL SLOWLY.

• DO NOT MOW WHEN CHILDREN OR OTHERS ARE AROUND.

• NEVER CARRY CHILDREN.

• LOOK DOWN & BEHIND BEFORE AND WHILE BACKING.

• KEEP SAFETY DEVICES (GUARDS, SHIELDS, AND SWITCHES, ETC.) IN PLACE AND WORKING.

• REMOVE OBJECTS THAT COULD BE THROWN BY THE BLADE(S).

• KNOW LOCATION AND FUNCTION OF ALL CONTROLS.

• BE SURE BLADE(S) AND ENGINE ARE STOPPED BEFORE PLACING HANDS OR FEET NEAR BLADE(S).

• BEFORE LEAVING OPERATOR'S POSITION, DISENGAGE BLADE(S), PLACE THE SHIFT LEVER IN NEUTRAL, ENGAGE PARKING BRAKE, SHUT OFF AND REMOVE KEY.

READ OPERATOR'S MANUAL

Figure 1 Safety Labels found on your unit

5

.slopesof face the across never slopes, down and up mowers RIDING Operate

.injury serious in resulting slip, could you and footing your

maintaintodifficultextremelyisitslope,asuchonmowerbehind-walk a operating If .injury serious cause and overturn could

mowerridingA.feet)10everyfeet1/2-2approximatelyof rise (a degrees 15 of excess in slope a with inclines on mow not Do





Slope Gauge





TREEVERTICALAWITHLEVELTHISHOLDANDSIGHT

.SAFELYOPERATENOTMAYYOUWHERESLOPES DETERMINE TO GUIDE A AS PAGE THIS USE

WARNING

15°

POSTFENCEAOR

BUILDINGAOFCORNERA

POLEPOWERA













F





















O





















L





















D





















O





















N





















D





















O





















T





















T





















E





















D





















L





















I





















N





















E





















,





















R





















E





















P





















R





















E





















S





















E





















N





















T





















I





















N





















G





















A





















1





















5





















°





















S





















L





















O





















P





















E









6

SECTION 5: ATTACHMENTS & ACCESSORIES

MODEL NUMBER

DESCRIPTION

OEM-190-601

FastAttachTwin Bagger Grass Collector (For 42-inch Decks Only)

OEM-190-602

FastAttachTwin Bagger Grass Collector (For 46-inch Decks Only)

OEM-190-112

Mulch Kit (For 42-inch Decks Only)

OEM-190-118

Mulch Kit (For 46-inch Decks Only)

OEM-190-603

FastAttachGrille Guard (mounts on front of tractor)

OEM-190-604

TracPacStorage Container (mounts on rear of tractor)

OEM-190-822

FastAttach46-inch Front Dozer Blade

OEM-190-823

42-inch Two-stage Snow Thrower

SECTION 6: TRACTOR SET-UP

ATTACHING THE BATTERY CABLES

NOTE: The positive battery terminal is marked Pos. (+). The negative battery terminal is marked Neg. (–).

The positive cable (heavy red wire) is secured to the positive battery terminal (+) with a hex bolt and hex nut at the factory. Make certain that the rubber boot covers the terminal to help protect it from corrosion.

Remove the hex bolt and wing nut from the negative cable. Attach the negative cable (heavy black wire) to the negative battery terminal (–) with the bolt and wing nut.

Place the hold-down strap in position over the battery to secure it in place. See Figure 2.

Positive

Rubber

Boot

Terminal





Battery

Wing



Nut

Tray

Negative





Hold-down Strap





Terminal

Bolt

Figure 2

NOTE: If battery is put into service after date shown on top of battery, charge for minimum of one hour at 6-10 amps. Refer to the MAINTENANCE section of this manual for more detailed instructions regarding proper battery charging procedure.

GAS AND OIL FILL-UP

Service the engine with gasoline and oil as instructed in the separate engine manual packed with your tractor. Read instructions carefully.

IMPORTANT: Your tractor is shipped with oil; however, you MUST check the oil level before operating. Be careful not to overfill. Overfilling with oil may cause the engine to smoke. This will result in poor engine performance and could cause permanent engine damage.

The gasoline tank is located under the hood and has a capacity of approximately two gallons. Do not overfill.

WARNING: Gasoline produces noxious fumes. Never fill fuel tank indoors. Always fill the fuel tank in a well ventilated area to avoid inhalation of gasoline fumes.

WARNING: Never smoke while fueling your tractor or fill the fuel tank while engine is running or while engine is hot.

WARNING: Do not fill closer than 1/2 inch from the top of the fuel tank to prevent spills and to allow for fuel expansion. If gasoline is accidently spilled, move tractor away from area of spill. Avoid creating any source of ignition until gasoline vapors have disappeared.

INSTALLING THE MULCH KIT

On units equipped with a 42-inch deck, the mulch kit is installed at the factory. To remove it, unfasten the wing knob found on the top of the cutting deck and carefully pull the mulch plug out from the discharge area of the deck.

On units equipped with a 46-inch deck, the mulch kit is packaged separately within the crate.

7

Yard-Man 604 User Manual

SECTION 7: CONTROLS

B

D

I

N*

M

F*

A

+

1/10

P

P

C

J

L

Figure 3

H

G

E

K

NOTE: Steering Wheel not shown for clarity.

A

Ignition Switch

H

Brake Pedal

B

Throttle Control Lever

I

Parking Brake Button

C

Choke Control (if so equipped)

J

Shift Lever

D

Indicator Monitor/Hour Meter

K

Seat Adjustment Lever

E

Lift Lever

L

Cup Holder

F

PTO (Power Take-Off) Lever*

M

Cruise Control Button

G

AutoDrivePedal

N

PTO (Power Take-Off) Knob*

*Tractors vary by model and are equipped with either a PTO lever or a PTO knob, NEVER both.

NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.

8

IGNITION SWITCH

To start the engine, insert key into the ignition switch and turn clockwise to the START position. Release key to the ON position once engine has fired. See Figure 4. Refer to STARTING THE ENGINE in the OPERATION section of this manual for detailed starting instructions. The ignition switch is also used to operate the headlights. Refer to OPERATING THE HEADLIGHTS in the OPERATION section of this manual for detailed instructions

WARNING: Remove the key from the tractor when the tractor is not in use to prevent accidental starting.

Off

On/Lights

On

Start

Figure 4

THROTTLE CONTROL LEVER

The throttle lever is located on the right side of the tractor’s dash panel. This lever controls the speed of the engine, and on some units the choke control also. When set in a given position, the throttle will maintain a uniform engine speed. See Figure 5.

Throttle



Throttle



Symbol









Symbol







Choke



Fast





















Position







Position

















Fast













Position





































































































































































































Slow



Slow

Position



Position



Figure 5

IMPORTANT: When using PTO operated equipment such as the cutting deck or other attachments, always operate the tractor with the throttle lever in the FAST (rabbit) position.

CHOKE CONTROL

On some units, moving the throttle lever all the way forward activates the engine’s choke control. On all other units, the choke control can be found on the left side of the dash panel and is activated by

pulling the knob outward. Activating the choke control closes the choke plate on the carburetor and aids in starting the engine. Refer to STARTING THE ENGINE in the OPERATION section of this manual for detailed starting instructions.

INDICATOR MONITOR / HOUR METER

Your tractor is equipped with four indicator lights and an hour meter located on the left side of the dash panel. See Figure 6.

Battery













Oil

+

Hour

Meter

1/10

P

PTO

Brake

Figure 6

If a light illuminates when attempting to start the unit, proceed as follows:

BRAKE — Depress the brake pedal.

PTO — Move PTO lever, or PTO knob into the disengaged (OFF) position.

OIL— Check the crankcase oil level, and add oil as required.

The BATTERY indicator light will illuminate any time the ignition key is the On position and the engine is not running. If it illuminate’s while the engine is running, it indicates that the battery is in need of a charge. Refer to the MAINTENANCE section of this manual for the proper battery charging procedure.

The hour meter operates whenever the ignition key is in the On or On/Lights position and records the actual hours of tractor operation.

9

ELECTRIC PTO

(POWER TAKE-OFF) KNOB

To engage the power to the cutting deck or other attachments, pull outward on the PTO knob. Push the PTO knob inward to disengage the power to the attachments.

NOTE: The PTO knob must be in the disengaged (OFF) position when starting the engine, when shifting into reverse and if the operator leaves the seat.

PTO (POWER TAKE-OFF) LEVER

The PTO lever is located on the left side of the dashboard next to the steering wheel. Move the PTO lever forward to engage the power to the cutting deck or other attachments; move the PTO lever backward (toward the rear of the tractor) to disengage the power to the attachments.

NOTE: The PTO lever must be in the disengaged (OFF) position when starting the engine, when shifting into reverse and if the operator leaves the seat.

AUTODRIVEPEDAL

The AutoDrivepedal is located below the brake pedal on the right front side of the tractor along the running board. Depress the AutoDrivepedal with your right foot when the tractor shift lever is in either forward or reverse to cause the tractor to move. Ground speed is also controlled with the AutoDrivepedal. The further down the pedal is depressed, the faster the tractor will travel. The pedal will return to its original position when it’s not depressed.

IMPORTANT: Always set the parking brake when leaving the tractor unattended.

BRAKE PEDAL

BRAKE

The brake pedal is located on the right front side of the tractor above the AutoDrivepedal along the running board. The brake pedal can be used for sudden stops or setting the parking brake.

NOTE: The brake pedal must be fully depressed to activate the safety interlock switch when starting the tractor.

LIFT LEVER

The lift lever is used to change the operating position (height) of the cutting deck. To operate, move the lever to the left, then place in the notch best suited for your application.

PARKING BRAKE BUTTON

To set the parking brake, fully depress

P

the brake pedal and push the parking

brake button in. Hold the button in



while taking your foot off the brake



pedal. Both the parking button and



the brake pedal will then stay



depressed. To release the parking



brake, depress the brake pedal



slightly. The parking brake button will



then return to its original position.



NOTE: The parking brake must be set if the operator leaves the seat with the engine running or the engine will automatically shut off.

IMPORTANT: Always set the parking brake when leaving the tractor unattended.

10

SHIFT LEVER



F

The shift lever is located

on the left side of the



fender

and

has

three



positions,

FORWARD,



NEUTRAL and REVERSE.



The brake pedal must be



depressed and the tractor

N

must not be in motion

when

the

moving

shift



lever.









IMPORTANT: Never

Shift

force the shift lever. Doing

Knob

so may result in serious

R

damage to

the tractor’s

transmission.







CRUISE CONTROL BUTTON

The cruise control button is located on

the tractor dash panel to the left of the ignition switch. Push the cruise control

button while traveling forward at a desired speed. While holding the

button in, release pressure from the AutoDrivepedal. This will engage the

cruise control and allow the tractor to remain at that speed without applying

pressure to the AutoDrivepedal. Depress the brake pedal or the AutoDrivepedal to deactivate cruise

control. Refer to the OPERATION section of this manual for detailed instructions regarding the cruise control feature.

SECTION 8: OPERATION

SAFETY INTERLOCK SWITCHES

This tractor is equipped with a safety interlock system for the protection of the operator. If the interlock system should ever malfunction, do not operate the tractor. Contact an authorized MTD Service Dealer in your area. The safety interlock system prevents the engine from cranking or starting unless the brake pedal is fully depressed, and the PTO lever, or PTO knob is in the disengaged (OFF) position.

The safety interlock system will automatically shut off the engine if the operator leaves the seat before engaging the brake lock.

The safety interlock system will automatically shut off the engine if the operator leaves the seat with the PTO PTO lever, or PTO knob in the engaged (ON) position, regardless of whether the brake lock is engaged. The PTO lever, or PTO knob must be in the disengaged (OFF) position to restart the engine.

On units equipped with an electric PTO, the safety interlock system will automatically shut off the PTO if the PTO knob is moved into the engaged (ON) position with the shift lever in the REVERSE position.

On units equipped with a manual PTO, the safety interlock system will automatically shut off the tractor’s engine if the PTO lever is moved into the engaged (ON) position with the shift lever in the REVERSE position.

WARNING: Do NOT attempt to bypass or disconnect the tractor’s safety interlock. Doing so could result in serious personal injury or death.

IMPORTANT: Tampering with or attempting to bypass the tractors Safety Interlock Switches in any way WILL void your warranty.

WARNING

AVOID SERIOUS INJURY OR DEATH

GO UP AND DOWN SLOPES, NOT ACROSS.

AVOID SUDDEN TURNS.

DO NOT OPERATE THE UNIT WHERE IT COULD SLIP OR TIP.

IF MACHINE STOPS GOING UPHILL, STOP BLADE(S) AND BACK DOWNHILL SLOWLY.

DO NOT MOW WHEN CHILDREN OR OTHERS ARE AROUND.

NEVER CARRY CHILDREN.

LOOK DOWN AND BEHIND BEFORE AND WHILE BACKING.

KEEP SAFETY DEVICES (GUARDS, SHIELDS, AND SWITCHES) IN PLACE AND WORKING.

REMOVE OBJECTS THAT COULD BE THROWN BY THE BLADE(S).

KNOW LOCATION AND FUNCTION OF ALL CONTROLS.

BE SURE BLADE(S) AND ENGINE ARE STOPPED BEFORE PLACING HANDS OR FEET NEAR BLADE(S).

BEFORE LEAVING OPERATOR’S POSITION, DISENGAGE BLADE(S), PLACE THE SHIFT LEVER IN NEUTRAL, ENGAGE

BRAKE LOCK, SHUT ENGINE OFF AND REMOVE KEY. READ OPERATOR’S MANUAL

11

SETTING THE CUTTING HEIGHT

Select the height position of the cutting deck by placing the deck lift lever in any of the six different cutting height notches on the right side of the fender. Then adjust the deck wheels so that they are at least 1/4 inch to 1/2 inch above the ground when the tractor is on a smooth, flat surface such as a driveway.

WARNING: Keep hands and feet away from the discharge chute opening of the cutting deck.

NOTE: The deck wheels are an anti-scalp feature of the deck and are not designed to support the weight of the cutting deck.

Refer to the ADJUSTMENTS section of this manual for more detailed instructions regarding various deck adjustments.

STARTING THE ENGINE

NOTE: Refer to the TRACTOR SET-UP section of this manual for Gasoline and Oil fill-up instructions.

Insert the tractor key into the ignition switch.

Place the PTO lever, or PTO knob in the disengaged (OFF) position.

Depress the brake pedal and set the parking brake.

Place the shift lever in the NEUTRAL position.

Move the throttle control lever into the FAST (or CHOKE, if so equipped) position.

Pull out the choke control knob, if so equipped (a warm engine may not require choking).

Turn the ignition key clockwise to the START position. After the engine starts, release the key. It will return to the ON position.

IMPORTANT: Do NOT hold the key in the START position for longer than ten seconds at a time. Doing so may cause damage to your engine’s starter.

NOTE: If starting problems are encountered, refer to the TROUBLESHOOTING section of this manual.

After the engine starts, slowly release the brake pedal. As the engine warms up, gradually push the choke control knob inward (or move the throttle control lever out of the CHOKE position into the FAST position) to open up the choke plate on the engine’s carburetor.

NOTE: Do NOT leave the choke control out while operating the tractor. Doing so will result in a "rich" fuel mixture and cause the engine to run poorly.

STOPPING THE ENGINE

Place the PTO lever, or PTO knob in the disengaged (OFF) position

Move the throttle control into the SLOW (turtle) position and allow the engine to "idle down" for ten seconds. Failure to do so may result in an engine afterfire.

Turn the ignition key counterclockwise to the OFF position.

Remove the key from the ignition switch to prevent accidental starting.

IMPORTANT: If you think you’ve struck a foreign object, stop the engine immediately. Remove the wire(s) from the spark plug(s), thoroughly inspect the unit for any damage, and repair the damage before restarting and operating the tractor.

DRIVING THE TRACTOR

WARNING: Avoid sudden starts, excessive speed and sudden stops.

WARNING: Do not leave the seat of the tractor without first placing the PTO lever, or PTO knob in the disengaged (OFF) position, depressing the brake pedal and engaging the parking brake. If leaving the tractor unattended, also turn the ignition key off and remove the key.

Depress the brake pedal to release the parking brake and let the pedal up. Move the throttle lever into the FAST (rabbit) position.

IMPORTANT: Do NOT use the shift lever to change the direction of travel when the tractor is in motion. Always use the brake pedal to bring the tractor to a complete stop before shifting.

To move forward, place the shift lever in the FORWARD position, then slowly depress the AutoDrivepedal until the desired speed is achieved.

To move in reverse, place the shift lever in the REVERSE position, check that the area behind is clear then slowly depress the AutoDrivepedal.

SETTING THE CRUISE CONTROL

NOTE: The cruise control feature should only be utilized in the forward direction.

Place the shift lever in the FORWARD position, then slowly depress the AutoDrivepedal until the desired speed is achieved.

Lightly depress the cruise control button.

12

While continuing to hold the cruise button in, lift your foot from the AutoDrivepedal (you should feel the cruise latch engage).

If properly engaged, the cruise control button and the AutoDrivepedal should lock in the down position, and the tractor will maintain the same forward speed.

Disengage the cruise control using one of the following methods:

Depress the brake pedal to disengage the cruise control and stop the tractor.

Lightly depress the AutoDrivepedal.

To change to the reverse direction when operating with cruise control, depress the brake pedal to disengage the cruise control and bring the tractor to a complete stop. Then place the shift lever in the REVERSE position and depress the AutoDrivepedal.

DRIVING ON SLOPES

Refer to the SLOPE GAUGE on page 6 to help determine slopes where you may not operate safely.

WARNING: Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet). The tractor could overturn and cause

serious injury.

Operate the tractor up and down slopes, never across slopes. Do not drive so that the tractor may tip over sideways.

Before operating the tractor on any slope, walk the slope to look for possible hazards such as rocks. mounds, ruts, stumps or other surface irregularities which could cause the tractor to be upset.

Avoid turns when driving on a slope. If a turn must be made, turn down the slope. Turning up a slope greatly increases the chance of a roll over.

Avoid stopping when driving up a slope. If it is necessary to stop while driving up a slope, start up smoothly and carefully to reduce the possibility of flipping the tractor over backward.

OPERATING THE HEADLIGHTS

To turn the tractor’s headlights on:

Start the engine following the instructions earlier in this section.

Turn the key one notch counterclockwise into the On/Lights position of the ignition switch. Refer to Figure 4.

To turn the tractor’s headlights off:

Turn the key either into the On position (to leave the engine running) or the Off position (to shut the engine off). Refer to Figure 4.

IMPORTANT: Never move the key into the Start position while the engine is running. Doing so may cause damage to your engine’s starter.

STOPPING THE ENGINE

Place the PTO lever, or PTO knob in the disengaged (OFF) position.

Move the throttle control into the SLOW position and allow the engine to "idle down" for ten seconds, then turn the ignition key counterclockwise to the OFF position.

Remove the key from the ignition switch to prevent accidental starting.

IMPORTANT: If you think you’ve struck a foreign object, stop the engine immediately. Remove the wire(s) from the spark plug(s), thoroughly inspect the unit for any damage, and repair the damage before restarting and operating the mower.

USING THE LIFT LEVER

To raise the cutting deck, move the lift lever to the left, then place it in the notch best suited for your application. Refer to SETTING THE CUTTING HEIGHT earlier in this section.

ENGAGING THE ELECTRIC PTO (POWER TAKE-OFF) KNOB (if so equipped)

Front View

Pull Out

Push In

OFF

ON

Figure 7

Move the throttle control lever to the FAST (rabbit) position.

Pull the PTO knob outward into the engaged (ON) position. See Figure 7.

Keep the throttle lever in the FAST (rabbit) position for the most efficient use of the cutting deck and other attachments.

13

The operator must remain in the tractor seat at all times. If the operator should leave the seat without pushing the PTO knob inward into the disengaged (OFF) position, the tractor’s engine will shut off.

IMPORTANT: The PTO knob cannot be in the engaged (ON) position when the tractor is driving in the reverse direction. The PTO knob must be in the disengaged (OFF) position when the shift lever is in REVERSE or the PTO will automatically shut off. Refer to SAFETY INTERLOCK SWITCHES in this section.

ENGAGING THE PTO

(POWER TAKE-OFF) LEVER (if so equipped)

Move the throttle control lever to the FAST (rabbit) position.

Move the PTO lever forward into the engaged (ON) position.

Keep the throttle lever in the FAST (rabbit) position for the most efficient use of the cutting deck and other attachments.

The operator must remain in the tractor seat at all times. If the operator should leave the seat without moving the PTO lever into the disengaged (OFF) position and setting the parking brake, the engine will shut off.

IMPORTANT: The PTO lever cannot be in the engaged (ON) position when the tractor is driving in the reverse direction. The safety interlock system will automatically shut off the engine if the PTO lever is moved into the engaged (ON) position with the shift lever in the REVERSE position. Refer to SAFETY INTERLOCK SWITCHES earlier in this section.

MOWING

This tractor is equipped with one of MTD’s high quality cutting decks. The following information will be helpful when using the cutting deck with your tractor.

WARNING: To avoid possible injury, do not allow anyone in the area of the tractor while mowing. Even if the area to be mowed has been cleared of foreign objects, small objects may be picked up and discharged by the mower.

WARNING: Never direct the discharge of material toward bystanders or allow anyone near the machine while in operation.

For best results it is recommended that the first two laps be cut with the discharge thrown towards the center. After the first two laps, reverse the direction to throw the discharge to the outside for the balance of cutting. This will give a better appearance to the lawn.

Do not cut the grass too short. Short grass invites weed growth and yellows quickly in dry weather.

Mowing should always be done with the engine at full throttle.

Do not mow at high ground speed, especially if a mulch kit or grass collector is installed.

Under heavier conditions it may be necessary to go back over the cut area a second time to get a clean cut.

Do NOT attempt to mow heavy brush and weeds and extremely tall grass. Your tractor is designed to mow lawns, NOT clear brush.

Keep the blades sharp and replace the blades when worn. Refer to the MAINTENANCE section of this manual for proper blade sharpening instructions.

SECTION 9: ADJUSTMENTS

LEVELING THE DECK

WARNING: Cutting blades are sharp. Always protect hands by wearing heavy leather work gloves to grasp blades.

NOTE: Check the tractor’s tire pressure before performing any deck leveling adjustments. Refer to TIRES in the maintenance section of this manual for further information regarding tire pressure.

Front to Rear

The front of the cutting deck is supported by a stabilizer bar that can adjusted to level the deck from front to rear. The front of the deck should be 1/4" to 3/8" lower than the rear of the deck. Adjust if necessary as follows:

WARNING: Turn the tractor’s engine off, remove the key from the ignition switch and apply the tractor’s parking brake before making any adjustments to the deck.

14

Loading...
+ 30 hidden pages
