Yamaha RX-A1030BL User Manual

AV Receiver

Owner’s Manual

English

Read the supplied booklet “Safety Brochure” before using the unit.

CONTENTS

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

FEATURES 6

What you can do with the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Part names and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Front display (indicators) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

PREPARATIONS 14

General setup procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

1 Connecting speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Basic speaker configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Advanced speaker configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Input/output jacks and cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

2 Connecting a TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3 Connecting playback devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Connecting video devices (such as BD/DVD players) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Connecting audio devices (such as CD players) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Connecting to the jacks on the front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

4 Connecting the FM/AM antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

5 Connecting to a network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

6 Connecting other devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Connecting recording devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Connecting a device with analog multi-channel output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Connecting a device compatible with the trigger function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

7 Connecting the power cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

8 Selecting an on-screen menu language . . . . . . . . . . . . . . . . . . . . . . . . . 40

9 Optimizing the speaker settings automatically (YPAO) . . . . . . . . . . 41

Measuring at one listening position (single measure) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Measuring at multiple listening positions (multi measure) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Checking the measurement results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Reloading the previous YPAO adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

PLAYBACK 49

Basic playback procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Selecting an HDMI output jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Selecting the input source and favorite settings with one touch

(SCENE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Configuring scene assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Selecting setting items to be included as scene assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Selecting the sound mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Enjoying stereoscopic sound fields (CINEMA DSP 3D) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Enjoying surround sound with headphones (SILENT CINEMA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Enjoying unprocessed playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Enjoying pure high fidelity sound (Pure Direct) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Enjoying compressed music with enhanced sound (Compressed Music Enhancer) . . . . . . . . . . . . . . . . . . .57

Listening to FM/AM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Setting the frequency steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Selecting a frequency for reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Registering favorite radio stations (presets) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

HD Radio™ tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

Radio Data System tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62

Operating the radio on the TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

En 2

Playing back iPod music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Connecting an iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Playback of iPod content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Playing back music stored on a USB storage device . . . . . . . . . . . . . . . 69

Connecting a USB storage device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Playback of USB storage device contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Playing back music stored on media servers (PCs/NAS) . . . . . . . . . . . . 72

Media sharing setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Playback of PC music contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Listening to Internet radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Playing back iTunes/iPod music via a network (AirPlay) . . . . . . . . . . . 77

Playback of iTunes/iPod music contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Playing back music in multiple rooms (multi-zone) . . . . . . . . . . . . . . . . 79

Multi-zone configuration examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Preparing Zone2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Controlling Zone2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Viewing the current status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Switching information on the front display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Viewing the status information on the TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Configuring playback settings for different playback sources

(Option menu) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Option menu items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

CONFIGURATIONS 92

Configuring input sources (Input menu) . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Input menu items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Configuring the SCENE function (Scene menu) . . . . . . . . . . . . . . . . . . . . 94

Scene menu items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Configuring sound programs/surround decoders

(Sound Program menu) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Sound Program menu items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Configuring various functions (Setup menu) . . . . . . . . . . . . . . . . . . . . . 100

Setup menu items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101

Speaker (Manual Setup) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103

Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108

HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109

Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110

Multi Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112

Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114

ECO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116

Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117

Viewing information about the unit (Information menu) . . . . . . . . . 117

Types of information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118

Configuring the system settings (ADVANCED SETUP menu) . . . . . . 119

ADVANCED SETUP menu items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119

Changing the speaker impedance setting (SPEAKER IMP.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119

Turning on/off the remote control sensor (REMOTE SENSOR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120

Selecting the remote control ID (REMOTE CON AMP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120

Changing the FM/AM tuning frequency setting (TUNER FRQ STEP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120

Switching the video signal type (TV FORMAT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120

Removing the limitation on HDMI video output (MONITOR CHECK) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121

Backing up/recovering the settings (RECOV./BACKUP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121

Restoring the default settings (INITIALIZE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121

Updating the firmware (FIRM UPDATE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122

Checking the firmware version (VERSION) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122

Controlling external devices with the remote control . . . . . . . . . . . . 123

Registering the remote control code for a TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123

Registering the remote control codes for playback devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124

Programming from other remote controls (learning) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125

Clearing functions learned from other remote controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126

Resetting remote control codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127

Updating the unit’s firmware via the network . . . . . . . . . . . . . . . . . . . 128

En 3

APPENDIX 129

Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .129

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Power, system and remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

FM/AM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134

USB and network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135

Error indications on the front display . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Audio information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

HDMI and video information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Yamaha technologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139

Video signal flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .140

Multi-zone output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Information on HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

HDMI Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141

HDMI signal compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .143

Reference diagram (rear panel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .144

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .145

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

En 4

Accessories

Insert the batteries the right way round.

30° 30°

Within 6 m (20 ft)

Check that the following accessories are supplied with the product.

 Remote control  Batteries (AAA, R03, UM-4) (x2)

 AM antenna  FM antenna

*One of the above is supplied depending on the region

of purchase.

 YPAO microphone  Power cable

Operating range of the remote control

• Point the remote control at the remote control sensor on the unit and remain within the operating range shown below.

 CD-ROM

(Owner’s Manual)

*The supplied power cable varies depending on the region

of purchase.

 Easy Setup Guide  Safety Brochure

• The illustrations of the main unit used in this manual are of the U.S.A. model, unless otherwise specified.

• Some features are not available in certain regions.

• Due to product improvements, specifications and appearance are subject to change without notice.

• This manual explains operations using the supplied remote control.

• This manual describes all the “iPod”, “iPhone” and “iPad” as the “iPod”. “iPod” refers to “iPod”, “iPhone” and “iPad”, unless otherwise specified.

• indicates precautions for use of the unit and its feature limitations.

• indicates supplementary explanations for better use.

Accessories En 5

FEATURES

Speakers

BD/DVD player

HDMI Control

Audio/Video

TV remote control

Audio

HDMI Control

Audio

Audio/Video

Sequential operation of a TV, AV receiver, and BD/DVD player (HDMI Control)

. p.141

Supports 2- to 7-channel (plus front presence) speaker system and up to 2 subwoofer connections. Allows you to enjoy favorite acoustic spaces in various styles.

• Automatically optimizing the speaker settings to suit your room (YPAO)

. p.41

• Reproducing stereo or multichannel sounds with the sound fields like actual movie theaters and concert halls (CINEMA DSP)

. p.53

• Enjoying compressed music with enhanced sound (Compressed Music Enhancer)

. p.57

• Bi-amp connections, channel expansion (with external power-amp) and multi-zone configurations to enhance your system

. p.20

iPod/iPhone/iPad

USB device

Audio

Network contents

Wide variety of supported content

• iPod/iPhone/iPad

. p.65

•USB

. p.69

• Media server (PC/NAS)

. p.72

• Internet radio

. p.75

•AirPlay

. p.77

3D and 4K signals supported

AV receiver (the unit)

Change the input source and favorite settings with one touch (SCENE)

. p.50

Control

Audio/Video (via HDMI/MHL)

Smartphone/Tablet

Control

What you can do with the unit

FEATURES ➤ What you can do with the unit En 6

Full of useful functions!

BD/DVD

player

Game

console

Camcorder

Set-top box

HDMI Control

TV audio

Video from

external device

Useful tips

❑ Connecting various devices (p.31)

A number of HDMI jacks and various input/output jacks on the unit allow you to connect video devices (such as BD/DVD players), audio devices (such as CD players), game consoles, camcorders, and other devices.

❑ Playing back TV audio in surround sound

with a single HDMI cable connection (Audio Return Channel: ARC) (p.26)

When using an ARC-compatible TV, you only need one HDMI cable to enable video output to the TV, audio input from the TV, and the transmission of HDMI Control signals.

❑ Easy operation and wireless music

playback from iPhone or Android device

By using the application for smartphone/tablet “AV CONTROLLER”, you can control the unit from an iPhone, iPad, iPod touch or Android devices. Visit the Yamaha website for details.

❑ Creating 3-dimensional sound fields (p.53)

Connecting front presence speakers allows you to create a natural 3-dimensional sound field in your own room (CINEMA DSP 3D). Even when no front presence speakers are connected, the Virtual Presence Speaker (VPS) function produces 3D surround sound.

❑ Listening to FM/AM radio (p.58)

The unit is equipped with a built-in FM/AM tuner. You can register up to 40 favorite radio stations as presets.

❑ Enjoying pure high fidelity sound (p.57)

When the Pure Direct mode is enabled, the unit plays back the selected source with the least circuitry, which lets you to enjoy Hi-Fi sound quality.

❑ Easy operation with a TV screen

You can navigate through different types of content (such as iPod, USB, and network), view information, or easily configure the settings using the on-screen menu.

❑ Low power consumption

The ECO mode (power saving function) reduces the unit’s power consumption (p.117).

I want to connect a playback device using HDMI for video and non-HDMI for audio...

Use “Audio Select” in the “Option” menu to specify the type of an audio input jack to be used for the corresponding input source (p.90).

Video and audio are not synchronized...

Use “Lipsync” in the “Setup” menu to adjust the delay between video and audio output (p.106).

I want to hear audio from the TV speakers...

Use “Audio Output” in the “Setup” menu to select the output destination of signals input into the unit (p.109). Your TV speakers may be selected as an output destination.

I want to use the supplied remote control to operate external devices…

I want to change the on-screen menu language...

Use “Language” in the “Setup” menu to select a language from English, Japanese, French, German, Spanish, Russian, Italian and Chinese (p.40).

I want to update the firmware...

Use “FIRM UPDATE” in the “ADVANCED SETUP” menu to update the unit’s firmware (p.122). If the unit is connected to the Internet, a message will be displayed on the TV when a firmware update is available (p.128).

Many other settings are available that let you to customize the unit. For details, see the following pages.

• Input settings (p.92)

• SCENE settings (p.95)

• Sound program and surround decoder settings (p.98)

• Various function settings (p.101)

• Information view (such as audio signal and video signal) (p.118)

• System settings (p.119)

FEATURES ➤ What you can do with the unit En 7

Part names and functions

INPUT

MAIN ZONE

VOLUME

PURE DIRECT

52 3 41

Front panel

1 MAIN ZONE z key

Turns on/off (standby) the unit.

2 Standby indicator

Lights up when the unit is in standby mode under any of the following conditions.

• HDMI Control is enabled (p.109)

• Standby Through is enabled (p.110)

• Network Standby is enabled (p.111)

• An iPod is being charged (p.65)

3 Front display

Displays information (p.10).

4 Remote control sensor

Receives remote control signals (p.5).

5 PURE DIRECT key

Enables/disables Pure Direct (p.57).

6 INPUT knob

Selects an input source.

7 Front panel door

For protecting controls and jacks (p.9).

8 VOLUME knob

Adjusts the volume.

Opening the front panel door

• To use controls or jacks behind the front panel door, gently

press the bottom of the door to open it. Keep the door closed when not using controls or jacks behind the front panel door. (Be careful not to trap your fingers.)

FEATURES ➤ Part names and functions En 8

■ Inside of the front panel door

9 A C D H I KE J LB0

M N O

ON SCREEN

9 ON SCREEN key

Displays the on-screen menu on the TV.

0 Menu operations keys

Cursor keys Select a menu or a parameter. ENTER Confirms a selected item. RETURN Returns to the previous screen.

A OPTION key

Displays the option menu (p.87).

B DISPLAY key

Displays status information on the TV (p.86).

C TONE/BALANCE key

Adjusts the high-frequency range and low-frequency range of output sounds (p.88).

Adjusts the right/left channel volume balance for Zone2 (p.85).

D STRAIGHT key

Enables/disables the straight decode mode (p.56).

OPTION

TONE/BALANCE

YPAO MIC

PROGRAM

PHONES

ENTER

DISPLAYRETURN

5V 2.1A

E PROGRAM keys

Select a sound program or a surround decoder (p.52).

F SCENE keys

Select the registered input source, sound program, and various settings with one touch. Also, turns on the unit when it is in standby mode (p.50).

G MULTI ZONE keys

ZONE 2 Enables/disables the audio output to

ZONE CONTROL Changes the zone (main zone or Zone2)

H INFO key

Selects the information displayed on the front display (p.86).

I MEMORY key

Registers FM/AM radio stations as preset stations (p.59).

STRAIGHT

SILENT CINEMA

SCENE

1234

MULTI ZONE

ZONE 2

VIDEO

LAUDIO

VIDEO AUX

INFO

FM AM

ZONE CONTROL

OPTICAL

Zone2 (p.84).

that is controlled by the keys and knobs on the front panel (p.84).

MEMORY

HDMI/

MHL

PRESET

TUNING

5V 1A

J FM and AM keys

Switch between FM and AM (p.58).

K PRESET keys

Select a preset FM/AM radio station (p.59).

L TUNING keys

Select the radio frequency (p.58).

M USB jack

For connecting a USB storage device (p.69) or an iPod (p.65).

N YPAO MIC jack

For connecting the supplied YPAO microphone (p.41).

O PHONES jack

For connecting headphones.

P VIDEO AUX jacks

For connecting a device, such as a camcorder and a game console (p.34, 35) or a smartphone (p.35).

FEATURES ➤ Part names and functions En 9

Front display (indicators)

OUT 1INOUT 2

VOLUME

MUTE

DRCADAPTIVE

ZONE

SBL SBRSB

CL R

STEREO

ENHANCER

SLEEP

TUNED PARTY

0 BCB

4 53

1 HDMI

Lights up when HDMI signals are being input or output.

Lights up when HDMI signals are being input.

OUT1/OUT2

Indicates the HDMI OUT jacks currently outputting an HDMI signal.

2 STEREO

Lights up when the unit is receiving a stereo FM radio signal.

TUNED

Lights up when the unit is receiving an FM/AM radio station signal.

(U.S.A. model only) Lights up when the unit is receiving an HD Radio station

signal.

3 ZONE2

Lights up when Zone2 is enabled (p.84).

4 SLEEP

Lights up when the sleep timer is on.

5 PA RT Y

Lights up when the unit is in the party mode. (p.85)

6 Information display

Displays the current status (such as input name and sound mode name). You can switch the information by pressing INFO (p.86).

7 MUTE

Blinks when audio is muted.

8 Volume indicator

Indicates the current volume.

9 ADAPTIVE DRC

Lights up when Adaptive DRC (p.88) is working.

0 ENHANCER

Lights up when Compressed Music Enhancer (p.57) is working.

A CINEMA DSP

Lights up when CINEMA DSP (p.53) is working. “CINEMA DSP n” lights up when CINEMA DSP 3D (p.53) is activated.

B Cursor indicators

Indicate the remote control cursor keys currently operational.

C Speaker indicators

Indicate speaker terminals from which signals are output.

A Front speaker (L) S Front speaker (R) D Center speaker F Surround speaker (L) G Surround speaker (R) H Surround back speaker (L) J Surround back speaker (R) K Surround back speaker Z Front presence speaker (L) X Front presence speaker (R) L Subwoofer

FEATURES ➤ Part names and functions En 10

Rear panel

NETWORKDC OUT

0.5A

( 3

NET

)

MONITOR OUT/ ZONE OUT

HDMI OUT

ARC

(ZONE OUT)

HDMI

(1 BD/DVD)

AV 1 AV 2 AV 3 AV 4 AV 5 AV 6 AV 7

TRIGGER

OUT

RS-232C

YPB PR

MONITOR OUT/ZONE OUT

IN OUT

AV 1

AV 3

REMOTE

COMPONENT VIDEO

AV 2

AV 4

AV OUT

AV 3 AV 4AV 2AV 1

(1 BD/DVD)

OPTICAL

COAXIAL

PHONO

GND

AC IN

75Ω

ANTENNA

HD Radio

OPTICAL

AUDIO 4

MULTI CH INPUT

ZONE OUT

AUDIO 3AUDIO 2AUDIO 1

(2 TV)

CENTER

SUBWOOFER

ZONE 2FRONT

SURROUND SUR. BACK

SPEAKERS

CENTER FRONTSURROUND BACKSURROUND

BI–AMP

ZONE 2/F.PRESENCE/

COAXIAL

L R R RL L L

SINGLE

(4 RADIO)

PRE OUT

SUBWOOFER

CENTER

FRONT

SURROUND SUR. BACK

(SINGLE)

EXTRA SP

12V 0.1A

21 3 7 8 D5 6 CA B9:4

* The area around the video/audio output jacks is

marked in white on the actual product to prevent improper connections.

(U.S.A. model)

1 PHONO jacks

For connecting to a turntable (p.33).

2 DC OUT jack

For connecting to an optional accessory.

3 NETWORK jack

For connecting to a network (p.37).

4 AV 1–4 jacks

For connecting to video/audio playback devices and inputting video/audio signals (p.31).

5 AV OUT jacks

For outputting video/audio to a recording device (such as a VCR) (p.37).

6 MONITOR OUT/ZONE OUT

(composite video/S-video) jacks

For connecting to a TV that supports composite video or S-video and outputting video signals (p.30) or for connecting to a Zone2 video monitor (p.81).

7 HDMI OUT 1 jack

8 HDMI OUT 2 (ZONE OUT) jack

9 COMPONENT VIDEO (AV 1–4) jacks

0 HDMI (AV 1–7) jacks

A MONITOR OUT/ZONE OUT

For connecting to an HDMI-compatible TV and outputting video/audio signals (p.26). When using ARC, TV audio signal can also be input through the HDMI OUT 1 jack.

For connecting to an HDMI-compatible TV and outputting video/audio signals (p.31), or for connecting to an HDMI-compatible device used in Zone2 (p.82).

For connecting to video playback devices that support component video and inputting video signals (p.32).

For connecting to HDMI-compatible playback devices and inputting video/audio signals (p.31).

(component video) jacks

For connecting to a TV that supports component video and outputting video signals (p.30) or for connecting to a Zone2 video monitor (p.81).

B REMOTE IN/OUT jacks

For connecting to an infrared signal receiver/emitter that allows you to operate the unit and other devices from another room (p.83).

C TRIGGER OUT 1–2 jacks

For connecting to devices that support the trigger function (p.38).

D RS-232C terminal

This is a control expansion terminal for custom installation. Consult your dealer for details.

E VOLTAGE SELECTOR

(General model only) Selects the switch position according to your local voltage (p.39).

FEATURES ➤ Part names and functions En 11

PHONO

* The area around the video/audio output jacks is

marked in white on the actual product to prevent improper connections.

(U.S.A. model)

NETWORKDC OUT

( 3

)

0.5A

(1 BD/DVD)

GND

COAXIAL

NET

AV 3 AV 4AV 2AV 1

AV OUT

OPTICAL

COAXIAL

ANTENNA

(4 RADIO)

HD Radio

75Ω

HDMI OUT

ARC

(ZONE OUT)

(2 TV)

OPTICAL

MONITOR OUT/ ZONE OUT

YPB PR

AV 1

AV 2

AUDIO 4

AUDIO 3AUDIO 2AUDIO 1

COAXIAL

AV 1 AV 2 AV 3 AV 4 AV 5 AV 6 AV 7

(1 BD/DVD)

COMPONENT VIDEO

YPB PR

MULTI CH INPUT

SURROUND SUR. BACK

HDMI

AV 3

MONITOR OUT/ZONE OUT

YPB PR

AV 4

CENTER

ZONE OUT

SUBWOOFER

ZONE 2FRONT

SPEAKERS

L R R RL L L

FRONT

PRE OUT

SURROUND SUR. BACK

SINGLE

REMOTE

IN OUT

(SINGLE)

SUBWOOFER

CENTER

CENTER FRONTSURROUND BACKSURROUND

TRIGGER

OUT

12V 0.1A

RS-232C

ZONE 2/F.PRESENCE/ BI–AMP

EXTRA SP

AC IN

H K LGF I J

F ANTENNA jacks

For connecting to FM and AM antennas (p.36).

G AUDIO 1–4 jacks

For connecting to audio playback devices and inputting audio signals (p.33).

H MULTI CH INPUT jacks

For connecting to a device that supports multi-channel output and inputting audio signals (p.38).

I ZONE OUT jacks

For connecting to the external amplifier used in Zone2 and for outputting audio (p.81).

J PRE OUT jacks

For connecting to a subwoofer with built-in amplifier (p.18) or to an external power amplifier (p.24).

K SPEAKERS terminals

For connecting to speakers (p.15).

L AC IN jack

For connecting the supplied power cable (p.39).

FEATURES ➤ Part names and functions En 12

Remote control

A B

RECEIVER

SOURCE

1234

5 6 7

AUDIO

1234

PHONO MULTI

TUNER

MAIN

PROGRAM

SCREEN

ZONE 2

TOP MENU

SCENE

TVBD/DVD

MUTE

USB NET

PARTY HDMI OUT

NET

VOLUME

POP-UP/MENU

ENTER

MODE

TUNING PRESET

MOVIE

INPUT

MUTE

SUR. DECODE

MUSIC

ENHANCER

INFO SLEEP

1234

687

MEMORY

TV VOL TV CH

V-AUX

4321

RADIO

OPTION

DISPLAYRETURN

BAND

STRAIGHT

PURE DIRECT

ENT

CODE SET

1 Remote control signal transmitter

Transmits infrared signals.

2 SOURCE z key

Turns on/off an external device.

SOURCE key

Sets the remote control to operate external devices (p.124). This key lights up in green after pressed.

RECEIVER key

Sets the remote control to operate the unit (p.124). This key lights up in orange after pressed.

RECEIVER z key

Turns on/off (standby) the unit.

3 Input selection keys

Select an input source for playback.

AV 1 – 7 AV 1–7 jacks V-A UX VIDEO AUX jacks (on the front panel) AUDIO 1–4 AUDIO 1–4 jacks PHONO PHONO jacks MULTI MULTI CH INPUT jacks USB USB jack (on the front panel) NET NETWORK jack (press repeatedly to select a

desired network source)

TUNER FM/AM radio

4 MAIN/ZONE2 switch

Changes the zone (main zone or Zone2) that is controlled by the remote control (p.84).

5 SCENE keys

Select the registered input source, sound program, and various settings with one touch. Also, turns on the unit when it is in standby mode (p.50).

6 PROGRAM keys

Select a sound program (p.52).

7 External device operation keys

Select menus for external devices (p.124).

8 ON SCREEN key

Displays the on-screen menu on the TV.

9 Menu operation keys

Cursor keys Select a menu or a parameter. ENTER Confirms a selected item. RETURN Returns to the previous screen.

0 MODE key

Switches the iPod operation modes (p.67). (U.S.A. model only) Selects an HD Radio audio program

(p.60).

A Radio keys

Operate the FM/AM radio when “TUNER” is selected as the input source (p.58).

BAND Switches between FM and AM radio. PRESET Select a preset station. TUNING Select the radio frequency.

External device operation keys

Let you play back and perform other operations for external devices when an input source other than “TUNER” is selected (p.124).

B Sound mode keys

Select a sound mode (p.52).

C INFO key

Selects the information displayed on the front display (p.86).

D SLEEP key

Switches the unit to standby mode automatically after a specified period of time has elapsed (sleep timer). Press repeatedly to set the time (120 min, 90 min, 60 min, 30 min, off).

E Numeric keys

Let you enter numerical values, such as radio frequencies.

MEMORY key

Registers FM/AM radio stations as presets (p.59).

F TV operation keys

Let you select TV input and volume, and perform other TV operations (p.123).

G HDMI OUT key

Selects HDMI OUT jacks to be used for video/audio output (p.49).

H PA RTY k e y

Turns on/off the party mode (p.85).

I VOLUME keys

Adjust the volume.

J MUTE key

Mutes the audio output.

K OPTION key

Displays the option menu (p.87).

L DISPLAY key

Displays status information on the TV (p.86).

M CODE SET key

Registers remote control codes of external devices on the remote control (p.123).

• To operate external devices with the remote control, register a remote control code for each device before using (p.123).

FEATURES ➤ Part names and functions En 13

PREPARATIONS

General setup procedure

1 Connecting speakers (p.15)

2 Connecting a TV (p.26)

3 Connecting playback devices (p.31)

4 Connecting the FM/AM antennas (p.36)

5 Connecting to a network (p.37)

6 Connecting other devices (p.37)

7 Connecting the power cable (p.39)

Selecting an on-screen menu language

(p.40)

Optimizing the speaker settings

automatically (YPAO) (p.41)

Basic speaker configuration (p.16)

Select the speaker layout and connect the speakers to the unit.

Advanced speaker configuration (p.20)

Apply bi-amp connections, channel expansion (using an external power amplifier) or multi-zone configurations to enhance the system.

Connect a TV to the unit.

Connect video devices (such as BD/DVD players) and audio devices (such as CD players) to the unit.

Connect the supplied FM/AM antennas to the unit.

Connect the unit to a network.

Connect external devices such as recording devices.

After all the connections are complete, plug in the power cable.

Select the desired on-screen menu language (default: English).

Optimize the speaker settings, such as volume balance and acoustic parameters, to suit your room (YPAO).

This completes all the preparations. Enjoy playing movies, music, radio and other content with the unit!

PREPARATIONS ➤ General setup procedure En 14

0.3 m (1 ft) or more

1.8 m

(5.9 ft)

0.5 to 1 m

(1.6 to 3.3 ft)

1.8 m (5.9 ft)

0.5 to 1 m

(1.6 to 3.3 ft)

10°~30°10°~30°

Speaker connections

2 3 4 5 6 7 8 9

1 Connecting speakers

The unit has 7 built-in amplifiers. You can connect 2 to 9 speakers and up to 2 subwoofers to create the favorite acoustic space in your room.

You can also apply bi-amp connections, channel expansion (using an external power amplifier) or multi-zone configurations to enhance your system (p.20).

Caution

• Under its default settings, the unit is configured for 8-ohm speakers. When connecting 6-ohm speakers, set the unit’s speaker impedance to “6  MIN”. In this case, you can also use 4-ohm speakers as the front speakers. For details, see “Setting the speaker impedance” (p.18).

Functions of each speaker

Speaker type Abbr. Function

Front (L) 1

Front (R) 2

Center 3 Produces center channel sounds (such as movie dialogues and vocals).

Surround (L) 4 Produce surround right/left channel sounds. Surround speakers also

Surround (R) 5

Surround back (L)

Surround back (R)

Front presence (L)

Front presence (R)

Subwoofer 9

• We recommend using front presence speakers to have a full effect of the 3-dimensional sound fields. However, the unit creates Virtual Presence Speaker (VPS) using the front, center and surround speakers to produce 3-dimensional sound fields even when no front presence speakers are connected (p.53).

• Use “Ideal speaker layout” (diagram on the right) as reference. You do not need to exactly adjust the speaker layout to this diagram since the YPAO function of the unit will automatically optimize the speaker settings (such as distances) to suit the speaker layout.

• When using only one surround back speaker, place it straight behind the listening position (middle of “SBL” and “SBR” in the diagram).

Produce front right/left channel sounds (stereo sounds).

produce surround back channel sounds when no surround back speakers are connected.

Produce surround back right/left channel sounds.

Produce CINEMA DSP effect sounds. In combination with CINEMA DSP 3D (p.53), the front presence speakers create a natural 3-dimensional sound field in your room.

Produces LFE (low-frequency effect) channel sounds and reinforces bass parts of other channels.

This channel is counted as “0.1”. You can connect 2 subwoofers to the unit and place them on the right/left (or front/rear) sides of the room.

Ideal speaker layout

PREPARATIONS ➤ Connecting speakers En 15

Speaker connections

2 3 4 5 6 7 8 9

Basic speaker configuration

■ Placing speakers in your room

Depending on the number of speakers, place the speakers and subwoofer in your room. This section describes the representative speaker layout examples.

❑ 7.1+2-channel system

(using both surround back and front presence speakers)

This speaker system brings out the full performance of the unit and allows you to enjoy a highly-natural 3-dimensional sound field with any contents.

• The surround back speakers and front presence speakers do not produce sounds simultaneously. The unit automatically changes the speakers to be used, depending on the selected CINEMA DSP (p.53).

❑ 7.1-channel system

(using front presence speakers)

This speaker system uses the front presence speakers to produce a highly-natural 3-dimensional sound field, and is suited for enjoying 5.1-channel contents.

❑ 7.1-channel system (using surround back speakers)

This speaker system creates Virtual Presence Speaker (VPS) using the front, center and surround speakers to produce a 3-dimensional sound field, and also allows you to enjoy extended surround sounds using the surround back speakers.

PREPARATIONS ➤ Connecting speakers En 16

Speaker connections

2 3 4 5 6 7 8 9

❑ 5.1-channel system

This speaker system creates Virtual Presence Speaker (VPS) using the front, center and surround speakers to produce a 3-dimensional sound field, and is suited for enjoying

5.1-channel contents.

❑ Front 5.1-channel system

❑ 2.1-channel system

Even when no surround speakers are connected, the unit creates the virtual surround speakers using the front speakers to allow you to enjoy multi-channel surround sound (Virtual CINEMA DSP).

• Add the center speaker to configure a 3.1-channel system.

This speaker system uses the front presence speakers to produce a natural 3-dimensional sound field, and creates the virtual surround speakers using the front speakers to allow you to enjoy multi-channel surround sound (Virtual CINEMA DSP).

PREPARATIONS ➤ Connecting speakers En 17

MAIN ZONE z STRAIGHT

Speaker connections

2 3 4 5 6 7 8 9

■ Setting the speaker impedance

Under its default settings, the unit is configured for 8-ohm speakers. When connecting 6-ohm speakers, set the speaker impedance to “6  MIN”. In this case, you can also use 4-ohm speakers as the front speakers.

Before connecting speakers, connect the power cable to an AC wall

outlet.

While holding down STRAIGHT on the front panel, press

MAIN ZONE z.

Check that “SPEAKER IMP.” is displayed on the front display.

DOCK TAG

SPIMP.-

STEREO

OUT 1INOUT 2

ENHANCER

Press STRAIGHT to select “6  MIN”.

Press MAIN ZONE z to set the unit to standby mode and remove the

power cable from the AC wall outlet.

You are now ready to connect the speakers.

SPEAKERIMP.

TUNED

PRE

AMP

PARTY

ZONE

ZONE3ZONE

SLEEP

8MIN

MUTE

SW1SLSW2SW SBLPL SBRSB PR

VOLUME

CL R

DRCADAPTIVE

PR SR

■ Connecting speakers

Connect the speakers placed in your room to the unit.

Caution

• Remove the unit’s power cable from an AC wall outlet and turn off the subwoofer before connecting the speakers.

• Ensure that the core wires of the speaker cable do not touch one another or come into contact with the unit’s metal parts. Doing so may damage the unit or the speakers. If the speaker cables short circuit, “Check SP Wires” will appear on the front display when the unit is turned on.

Speakers to be connected

Speaker system

Room Speaker type Abbr.

(the number of channels)

7+2 7 5 2

Front (L) 1 ●●●●

Front (R) 2 ●●●●

Center 3 ●●●

Surround (L) 4 ●●*3

Surround (R) 5 ●●*3

Main zone

Surround back (L)

Surround back (R)

Front presence (L)

Front presence (R)

6 ● *1

7 ● *1

E ● *2 *4

R ● *2 *4

If you have seven speakers, use two of them as surround back speakers (*1) or front presence speakers (*2).

If you have five speakers, use two of them as surround speakers (*3) or front presence speakers (*4).

Power Am p

Assign (p.103)

Basic (default)

• You can also connect up to 2 subwoofers (with built-in amplifier) to the unit.

• To use an external power amplifier (Hi-Fi amplifier, etc.) to enhance speaker output, see “Connecting an external power amplifier” (p.24).

PREPARATIONS ➤ Connecting speakers En 18

–

ZONE OUT

CENTER

SUBWOOFER

ZONE 2

SPEAKERS

CENTER FRONTSURROUND BACKSURROUND

BI–AMP

ZONE 2/F.PRESENCE/

R L R R RL L L

SINGLE

PRE OUT

SUBWOOFER

CENTER

FRONT

SURROUND SUR. BACK

(SINGLE)

EXTRA SP

The unit (rear)

FRONT

+ (red)

– (black)

FRONT

Banana plug

(

SINGLE

)

SUBWOOFER

CENTER

SUR. BACKSURRUND

FRONT

Audio pin cable

Speaker connections

2 3 4 5 6 7 8 9

Cables necessary for connection (commercially available)

Speaker cables (x the number of speakers)

Audio pin cable (two for connecting two subwoofers)

Connection diagram

Refer to the following diagram and connect the speakers to the unit.

❑ Connecting speaker cables

Speaker cables have two wires. One is for connecting the negative (-) terminal of the unit and the speaker, and the other is for the positive (+) terminal. If the wires are colored to prevent confusion, connect the black wire to the negative and the other wire to the positive terminal.

a Remove approximately 10 mm (3/8”) of insulation from the ends of the speaker cable, and

twist the bare wires of the cable firmly together.

b Loosen the speaker terminal.

c Insert the bare wires of the cable into the gap on the side (upper right or bottom left) of the

terminal.

d Tighten the terminal.

Using a banana plug

(U.S.A., Canada, China, Australia and General models only)

a Tighten the speaker terminal.

b Insert a banana plug into the end of the terminal.

• When using only one surround back speaker, connect it to the SINGLE jack (L side).

❑ Connecting the subwoofer (with built-in amplifier)

Use an audio pin cable to connect the subwoofer.

PREPARATIONS ➤ Connecting speakers En 19

Using the four internal amplifiers for front speakers to have more high-quality sounds

(Example) (Example) (Example)

Bi-amp connection

Combining with an external

power amplifier (Hi-Fi

amplifier, etc.) to build an

extended system

Using the excess internal

amplifiers for stereo speakers

in another room

External power amplifier

Main zone

Zone2

Bi-amp connection Power-amp channel expansion Multi-zone configuration

Speaker connections

2 3 4 5 6 7 8 9

Advanced speaker configuration

In addition to the basic speaker configuration (p.16), the unit also allows you to apply the following speaker configurations to enhance your system.

PREPARATIONS ➤ Connecting speakers En 20

Bi-amp

Speaker Connect to

12 FRONT and EXTRA SP (bi-amp connection)

3 CENTER

45 SURROUND

67 (not used)

ER (not used)

9 SUBWOOFER 1–2

Speaker connections

2 3 4 5 6 7 8 9

■ Available speaker configurations

Main zone

Output

channel

(max)

5  5ch BI-AMP 21

7 

7 +1 (Zone2) 7ch +1ZONE 22

• When applying one of these configurations, you need to configure the “Power Amp Assign” setting (p.103) in the “Setup” menu.

Bi-amp

External

power

amplifier

(required)

Surround

back

Multi-zone

Power Amp Assign

(p.103)

5ch BI-AMP +SB 22

❑ 5ch BI-AMP

Page

PREPARATIONS ➤ Connecting speakers En 21

Bi-amp

via external amp

Speaker Connect to

12 FRONT and EXTRA SP (bi-amp connection)

3 CENTER

45 SURROUND

67 SUR.BACK (PRE OUT) via external power amplifier

ER (not used)

9 SUBWOOFER 1–2

Main zone

Zone2

• When Zone2 output is enabled (p.84), the surround back speakers in the main zone do not output sound.

Speaker Connect to

12 FRONT

3 CENTER

45 SURROUND

67 SURROUND BACK

ER (not used)

9 SUBWOOFER 1–2

Zone2 speakers EXTRA SP

Speaker connections

2 3 4 5 6 7 8 9

❑ 5ch BI-AMP +SB ❑ 7ch +1ZONE

PREPARATIONS ➤ Connecting speakers En 22

The unit (rear)

FL FR

The unit (rear)

Main zone

Zone2

Speaker connections

■

Connecting front speakers that support bi-amp connections

2 3 4 5 6 7 8 9

When using front speakers that support bi-amp connections, connect them to the FRONT terminals and EXTRA SP terminals.

To enable the bi-amp function, configure the “Power Amp Assign” setting (p.103) in the “Setup” menu after connecting the power cable to an AC wall outlet.

■ Connecting Zone2 speakers

When using Zone2 speakers, connect them to the EXTRA SP terminals.

To utilize the EXTRA SP terminals for Zone2 speakers, configure the “Power Amp Assign” setting (p.103) in the “Setup” menu after connecting the power cable to an AC wall outlet.

SPEAKERS

R L R R RL L L

CENTER FRONTSURROUND BACKSURROUND

SINGLE

• The FRONT terminals and EXTRA SP terminals output the same signals.

ZONE 2/F.PRESENCE/ BI–AMP

EXTRA SP

SPEAKERS

R L R R RL L L

CENTER FRONTSURROUND BACKSURROUND

SINGLE

• You can also connect Zone2 speakers using an external amplifier (p.81).

ZONE 2/F.PRESENCE/ BI–AMP

EXTRA SP

Caution

• Before making bi-amp connections, remove any brackets or cables that connect a woofer with a tweeter. Refer to the instruction manual of the speakers for details. If you are not making bi-amp connections, make sure that the brackets or cables are connected before connecting the speaker cables.

PREPARATIONS ➤ Connecting speakers En 23

HDMI

3 AV 4 AV 5 AV 6 AV 7

TRIGGER

OUT

RS-232C

YPB PR

MONITOR OUT/ZONE OUT

IN OUT

REMOTE

AC IN

ZONE OUT

ZONE 2

SPEAKERS

CENTER FRONTSURROUND BACK

BI–AMP

ZONE 2/F.PRESENCE/

SINGLE

PRE OUT

SUBWOOFER

CENTER

FRONT

SURROUND SUR. BACK

(SINGLE)

EXTRA SP

12V 0.1A

1 234

The unit (rear)

MAIN IN

The unit (rear)

PRE OUT (FRONT) jacks

Main input jack

Amplifier with volume control bypass (such as A-S2000)

Speaker connections

2 3 4 5 6 7 8 9

■ Connecting an external power amplifier

When connecting an external power amplifier (pre-main amplifier) to enhance speaker output, connect the input jacks of the power amplifier to the PRE OUT jacks of the unit. The same channel signals are output from the PRE OUT jacks as from their corresponding SPEAKERS terminals.

Caution

• To prevent the generation of loud noises or abnormal sounds, make sure the followings before making connections.

– Remove the power cable of the unit and turn off the external power amplifier before connecting them.

– When using the PRE OUT jacks, do not connect speakers to the corresponding SPEAKERS

– When using a pre-main amplifier that does not have the volume control bypass, turn up the volume of

1 FRONT jacks

Output front channel sounds.

2 SURROUND jacks

Output surround channel sounds.

3 SUR. BACK jacks

Output surround back channel sounds. When using only one surround back speaker, connect the external amplifier to the SINGLE jack (L side).

4 CENTER jack

Outputs center channel sounds.

terminals.

the pre-main amplifier enough and fix it. In this case, do not connect other devices (except the unit) to the pre-main amplifier.

(Example)

Connecting front speakers via an external power amplifier

TRIGGER

12V 0.1A

OUT

FRONT

RS-232C

ZONE 2/F.PRESENCE/ BI–AMP

EXTRA SP

AC IN

4 AV 5 AV 6 AV 7

REMOTE

ONITOR OUT/ZONE OUT

PB PR

IN OUT

(SINGLE)

PRE OUT

SUBWOOFER

FRONT

SURROUND SUR. BACK

SPEAKERS

CENTER FRONTSURROUND BACK

SINGLE

CENTER

R RL L L

About external power amplifiers

We recommend using power amplifiers that meet the following conditions.

• With unbalanced inputs

• With volume control bypass (or without volume control circuit)

• Output power: about 100 W (6 to 8 )

PREPARATIONS ➤ Connecting speakers En 24

Input/output jacks and cables

AV 1

HDMI cable

MHL cable

COMPONEN

AV 1

Component video cable

S-video cable

Video pin cable

Digital optical cable

Digital coaxial cable

Stereo pin cable

■ Video/audio jacks

❑ HDMI jacks

Transmit digital video and digital sound through a single jack. Use an HDMI cable.

• Use a 19-pin HDMI cable with the HDMI logo. We recommend using a cable less than 5.0 m (16.4 ft) long to prevent signal quality degradation.

• The unit’s HDMI jacks support the HDMI Control, Audio Return Channel (ARC), and 3D and 4K video transmission features.

• Use high speed HDMI cables to enjoy 3D or 4K videos.

❑ HDMI/MHL jack

Transmits digital video and digital sound. Use an MHL cable.

■ Video jacks

❑ COMPONENT VIDEO jacks

Transmit video signals separated into three components: luminance (Y), chrominance blue (P and chrominance red (P

R). Use a component video

cable with three plugs.

❑ S VIDEO jack

Transmits S-video signals that include luminance (Y) and chrominance (C) components. Use an S-video cable.

❑ VIDEO jacks

Transmit analog video signals. Use a video pin cable.

B),

■ Audio jacks

❑ OPTICAL jacks

Transmit digital audio signals. Use a digital optical cable. Remove the tip protector (if available) before using the cable.

❑ COAXIAL jacks

Transmit digital audio signals. Use a digital coaxial cable.

❑ AUDIO jacks

Transmit analog stereo audio signals. Use a stereo pin cable (RCA cable).

• The VIDEO AUX jack on the front panel of the unit supports both HDMI and MHL connections. Use a cable that matches the jack on your MHL-compatible mobile device. When connecting an HDMI-compatible playback device to the VIDEO AUX jack, use an HDMI cable. For details on an MHL connection, see “MHL connection” (p.35).

AV 1

PREPARATIONS ➤ Input/output jacks and cables En 25

Does your TV support

Audio Return Channel (ARC)?

Does your TV support

HDMI Control?

Does your TV have an

HDMI input jack?

■ Connection Method 3 (p.29)

■ Connection Method 2 (p.28)

■ Connection Method 1 (p.26)

■ Connection Method 4 (p.30)

Yes

HDMI OUT 1 jack

HDMI input

(ARC-compatible)

The unit (rear)

TV connection

1 2

3 4 5 6 7 8 9

2 Connecting a TV

Connect a TV to the unit so that video input to the unit can be output to the TV.

You can also enjoy playback of TV audio on the unit.

The connection method varies depending on the functions and video input jacks available on your TV.

Refer to the instruction manual of the TV and choose a connection method.

About HDMI Control

HDMI Control allows you to operate external devices via HDMI. If you connect a TV that supports HDMI Control to the unit with an HDMI cable, you can control the unit’s power and volume with the TV’s remote control. You can also control playback devices (such as an HDMI Control-compatible BD/DVD player) connected to the unit with an HDMI cable. For details, see “HDMI Control” (p.141).

About Audio Return Channel (ARC)

ARC allows audio signals to travel both ways under HDMI Control. If you connect a TV that supports HDMI Control and ARC to the unit with a single HDMI cable, you can output video/audio to the TV or input TV audio to the unit.

■

Connection Method 1 (HDMI Control/ARC-compatible TV)

Connect the TV to the unit with an HDMI cable.

• The following explanation is based on the assumption that you have not changed the “HDMI” parameters (p.109) in the “Setup” menu.

• HDMI Control is available only on the HDMI OUT 1 jack.

• Use an HDMI cable that supports ARC.

HDMI OUT

ARC

(ZONE OUT)

HDMI

NETWORKDC OUT

( 3

)

NET

0.5A

AV 3 AV 4AV 2AV 1

(1 BD/DVD)

OPTICAL4OPTICAL3COAXIAL2COAXIAL

ANTENNA

(4 RADIO)

HD Radio

75Ω

PHONO

GND

• By connecting a TV to the unit with an HDMI cable, any video input to the unit can be output to the TV, regardless of the method used to connect the video device to the unit. For details, see “Video signal flow” (p.140).

• By connecting a TV to the unit with an HDMI cable, you can navigate the iPod, USB storage device and network sources, or configure the settings of the unit with the menu displayed on the TV.

• You can connect another TV or a projector by using the HDMI OUT 2 jack (p.31).

HDMI OUT

ARC

MONITOR OUT/

AV OUT

ZONE OUT

(2 TV)

OPTICAL

COAXIAL

AV 1

AV 2

(ZONE OUT)

AUDIO 4AU DIO 3AUDIO 2AUDIO 1

YPB

AV 1

(1 BD/

HDMI

ARC

HDMI

FRONT

PREPARATIONS ➤ Connecting a TV En 26

DISPLAYRETURN

ENTER

SCREEN

OPTION

ON SCREEN Cursor keys ENTER

1 2

TV connection

3 4 5 6 7 8 9

❑ Necessary settings

To use HDMI Control and ARC, you need to configure the following settings.

For details on settings and operating your TV, refer to the instruction manual for the TV.

After connecting external devices (such as a TV and playback devices)

and the power cable to the unit, turn on the unit, TV, and playback devices.

Configure the settings of the unit.

a Check that ARC is enabled on the TV. b Switch the TV input to display video from the unit. c Press ON SCREEN.

PTI

DISPLA

d Use the cursor keys to select “Setup” and press ENTER.

Configure the settings for HDMI Control.

a Enable HDMI Control on the TV and playback devices (such as HDMI

Control-compatible BD/DVD player).

b Turn off the TV’s main power and then turn off the unit and playback devices.

c Turn on the unit and playback devices and then turn on the TV’s main power.

d Switch the TV input to display video from the unit.

e Check the following.

On the unit: The input to which the playback device is connected is selected. If not, select the input source manually.

On the TV: The video from the playback device is displayed.

f Check that the unit is properly synchronized with the TV by turning off the TV or

adjusting the TV volume with the TV remote control.

This completes the necessary settings.

If you select a TV program with the TV remote control, the input source of the unit will be automatically switched to “AUDIO 1” and the TV audio will be played back on the unit.

If you cannot hear the TV’s audio, check that “ARC” (p.109) in the “Setup” menu is set to “On”.

• If HDMI Control does not work properly, try turning off and on (or unplugging and then plugging in again) the devices. It may solve the problem.

• If the unit is not synchronized to the TV’s power operations, check the priority of the audio output setting on the TV.

• If the audio is interrupted while using ARC, set “ARC” (p.109) in the “Setup” menu to “Off” and use an audio cable (digital optical or stereo pin cable) to input TV audio to the unit (p.28).

e Use the cursor keys (e/r) to select “HDMI”.

• “AUDIO 1” is set as TV audio input at the factory. If you have connected any external device to the AUDIO 1 jacks, use “TV Audio Input” (p.109) in the “Setup” menu to change the TV audio input assignment. To use the SCENE function (p.50), you also need to change the input assignment for SCENE(TV).

f Use the cursor keys (q/w) to select “HDMI Control” and press ENTER. g Use the cursor keys to select “On”. h Press ON SCREEN.

PREPARATIONS ➤ Connecting a TV En 27

The unit (rear)

HDMI OUT 1 jack

AUDIO 1

(OPTICAL or AUDIO)

jacks

Audio output

(digital optical or analog stereo)

HDMI input

ON SCREEN Cursor keys ENTER

1 2

TV connection

3 4 5 6 7 8 9

■ Connection Method 2 (HDMI Control-compatible TV)

Connect the TV to the unit with an HDMI cable and an audio cable (digital optical or stereo pin cable).

• The following explanation is based on the assumption that you have not changed the “HDMI” parameters (p.109) in the “Setup” menu.

• HDMI Control is available only on the HDMI OUT 1 jack.

HDMI OUT

ARC

(ZONE OUT)

HDMI

NETWORKDC OUT

( 3

)

PHONO

GND

NET

0.5A

AV 3 AV 4AV 2AV 1

(1 BD/DVD)

OPTICAL4OPTICAL3COAXIAL2COAXIAL

ANTENNA

(4 RADIO)

HD Radio

75Ω

• By connecting a TV to the unit with an HDMI cable, you can navigate the iPod, USB storage device and network sources, or configure the settings of the unit with the menu displayed on the TV.

• You can connect another TV or a projector by using the HDMI OUT 2 jack (p.31).

ARC

MONITOR OUT/

AV OUT

ZONE OUT

(2 TV)

OPTICAL

COAXIAL

HDMI OUT

(ZONE OUT)

AV 1

AV 2

AUDIO 1

(2 TV)

OPTICAL

AV 1

(1 BD/

YPB

AUDIO 4AU DIO 3AUDIO 2AUDIO 1

FRONT

AUDIO

OPTICAL

HDMI

❑ Necessary settings

To use HDMI Control, you need to configure the following settings.

For details on settings and operating your TV, refer to the instruction manual for the TV.

After connecting external devices (such as a TV and playback

devices) and power cable of the unit, turn on the unit, TV, and playback devices.

Configure the settings of the unit.

a Switch the TV input to display video from the unit.

b Press ON SCREEN.

SCREEN

c Use the cursor keys to select “Setup” and press ENTER.

d Use the cursor keys (e/r) to select “HDMI”.

ENTER

OPTION

DISPLAYRETURN

DISPLA

PTI

e Use the cursor keys (q/w) to select “HDMI Control” and press ENTER.

f Use the cursor keys to select “On”.

g Press ON SCREEN.

PREPARATIONS ➤ Connecting a TV En 28

HDMI OUT

ARC

(ZONE OUT)

HDMI

OPTICAL

AUDIO 1

(2 TV)

AUDIO

OPTICAL

HDMI

The unit (rear)

HDMI OUT 1 jack

AUDIO 1

(OPTICAL or AUDIO)

jacks

Audio output

(digital optical or analog stereo)

HDMI input

1 2

TV connection

3 4 5 6 7 8 9

Configure the settings for HDMI Control.

a Enable HDMI Control on the TV and playback devices (such as a HDMI

Control-compatible BD/DVD player).

b Turn off the TV’s main power and then turn off the unit and playback devices.

c Turn on the unit and playback devices and then turn on the TV.

d Switch the TV input to display video from the unit.

e Check the following.

On the unit: The input to which the playback device is connected is selected. If not, select the input source manually.

On the TV: The video from the playback device is displayed.

f Check that the unit is properly synchronized with the TV by turning off the TV or

adjusting the TV volume with the TV remote control.

This completes the necessary settings.

If you select a TV program with the TV remote control, the input source of the unit will be automatically switched to “AUDIO 1” and the TV audio will be played back on the unit.

• If HDMI Control does not work properly, try turning off and on (or unplugging and then plugging in again) the devices. It may solve the problem.

• If the unit is not synchronized to the TV’s power operations, check the priority of the audio output setting on the TV.

■ Connection Method 3 (TV with HDMI input jacks)

Connect the TV to the unit with an HDMI cable and an audio cable (digital optical or stereo pin cable).

NETWORKDC OUT

( 3

)

PHONO

GND

NET

0.5A

AV 3 AV 4AV 2AV 1

(1 BD/DVD)

OPTICAL4OPTICAL3COAXIAL2COAXIAL

ANTENNA

(4 RADIO)

HD Radio

75Ω

If you select “AUDIO 1” as the input source by pressing AUDIO 1 or SCENE(TV) on the remote control, the TV audio will be played back on the unit.

• By connecting a TV to the unit with an HDMI cable, you can navigate the iPod, USB storage device and network sources, or configure the settings of the unit with the menu displayed on the TV.

• If you have connected any external device to the AUDIO 1 jacks, connect the TV to one of the AUDIO 2–4 jacks. To use the SCENE function (p.50), you also need to change the input assignment for SCENE(TV).

• You can connect another TV or a projector by using the HDMI OUT 2 jack (p.31).

HDMI OUT

ARC

MONITOR OUT/

AV OUT

ZONE OUT

(2 TV)

OPTICAL

COAXIAL

AV 1

AV 2

(ZONE OUT)

AUDIO 4AU DIO 3AUDIO 2AU DIO 1

YPB

AV 1

(1 BD/

FRONT

PREPARATIONS ➤ Connecting a TV En 29

The unit (rear)

MONITOR OUT

(COMPONENT VIDEO) jacks

Video input

(component video)

AUDIO 1 (OPTICAL or AUDIO) jacks

Audio output

(digital optical or analog stereo)

OPTICAL

AUDIO 1

(2 TV)

AUDIO

OPTICAL

MONITOR OUT/

ZONE OUT

S VIDEO

The unit (rear)

MONITOR OUT (S VIDEO) jack

Video input (S-video)

AUDIO 1

(OPTICAL or AUDIO)

jacks

Audio output

(digital optical or analog stereo)

OPTICAL

AUDIO 1

(2 TV)

AUDIO

OPTICAL

VIDEO

MONITOR OUT/

ZONE OUT

The unit (rear)

MONITOR OUT (VIDEO) jack

Video input (S-video)

AUDIO 1

(OPTICAL or AUDIO)

jacks

Audio output

(digital optical or analog stereo)

1 2

TV connection

3 4 5 6 7 8 9

■ Connection Method 4 (TV without HDMI input jacks)

Depending on the video input jacks available on your TV, choose one of the following connections.

If you select “AUDIO 1” as the input source by pressing AUDIO 1 or SCENE(TV) on the remote control, the TV audio will be played back on the unit.

• If you connect your TV to the unit with a cable other than HDMI, video input to the unit via HDMI cannot be output to the TV.

• Operations with TV screen are available only when your TV is connected to the unit via HDMI.

❑ COMPONENT VIDEO connection (with a component video cable)

HDMI OUT

ARC

(ZONE OUT)

MONITOR OUT/

V OUT

ZONE OUT

AV 1

AV 2

AUDIO 3AU DIO 2AUDIO 1

(2 TV)

OPTICAL

COAXIAL

AUDIO 1

(2 TV)

OPTICAL

MONITOR OUT/ZONE OUT

YPB PR

AV 1 AV 2 AV 3 AV 4 AV 5

(1 BD/DVD)

COMPONENT VIDEO

YPB PR

AV 3

MULTI CH INPUT

SURROUND SUR. BACK

AV 4

CENTER

SUBWOOFER

ZONE OUT

ZONE 2FRONT

L R L

AUDIO 4

HDMI

MONITOR OUT/ZONE OUT

YPB PR

SPEAKERS

SURROUND BACKSURROUND

FRONT

PRE OUT

SURROUND SUR. BACK

(SINGLE)

COMPONENT VIDEO

YPB PR

AUDIO

SINGLE

OPTICAL

❑ S VIDEO connection (with an S-video cable)

NETWORKDC OUT

( 3

)

PHONO

GND

NET

0.5A

AV 3 AV 4AV 2AV 1

(1 BD/DVD)

OPTICAL4OPTICAL3COAXIAL2COAXIAL

ANTENNA

(4 RADIO)

HD Radio

75Ω

HDMI OUT

ARC

MONITOR OUT/

AV OUT

ZONE OUT

(2 TV)

OPTICAL

COAXIAL

AV 1

AV 2

(ZONE OUT)

AUDIO 4AU DIO 3AUDIO 2AU DIO 1

❑ VIDEO (composite video) connection (with a video pin cable)

NETWORKDC OUT

( 3

)

PHONO

GND

NET

0.5A

AV 3 AV 4AV 2AV 1

(1 BD/DVD)

OPTICAL4OPTICAL3COAXIAL2COAXIAL

ANTENNA

(4 RADIO)

HD Radio

75Ω

HDMI OUT

ARC

MONITOR OUT/

AV OUT

ZONE OUT

(2 TV)

OPTICAL

COAXIAL

AV 1

AV 2

(ZONE OUT)

AUDIO 4AU DIO 3AUDIO 2AU DIO 1

PREPARATIONS ➤ Connecting a TV En 30

+ 124 hidden pages
