Yamaha PSR-1100, PSR-2100 User's Manual

Data List

Daten-Liste

Liste des données

Lista de datos

Voice List Voice-Liste Liste des voix

Lista de voces ......................................................2

Drum/key Assignment List Liste der Tastenzuordnungen der Schlaginstrumente Liste d'assignation instrument de batterie/touche du clavier

Lista de asignación de teclas/batería .........................10

Style List Liste der Styles Liste des styles

Lista de estilos ....................................................12

Multi Pad Bank List Multi-Pad-Bank-Liste Liste des banques multi-pads

Lista de bancos de Multi Pad ...................................13

Effect Type List Liste der Effekttypen Liste des types d'effet

Lista de tipos de efecto ..........................................14

Effect Parameter List Liste der Effektparameter Liste des paramètres d'effets

Lista de parámetros de efectos ................................17

Effect Data Assign Table Effektdaten-Zuordnungstabelle Tableau d'assignation des données d'effets

Tabla de asignación de datos para efectos ..................23

Harmony/Echo Type List Liste der Harmony/Echo-Effekttypen Liste des types d'harmonie/d’écho

Lista de tipos de ecos/armonías............................... 24

Vocal Harmony Type List Liste der Vocal-Harmony-Effekttypen Liste des types d'harmonie vocale

Lista de tipos de armonía ...................................... 24

Parameter Chart Parametertabelle Tableau des paramètres

Gráfico de parámetros........................................... 25

MIDI Data Format MIDI-Datenformat Format des données MIDI

Formato de datos MIDI ..........................................31

Song System Exclusive Message List Liste der System-Exclusive-Meldungen der Songs Liste des messages exclusifs au système de morceaux Lista de mensajes exclusivos del sistema de canciones...46

Song Meta Event List Liste der Meta-Events der Songs Liste des méta-événements des morceaux

Lista de meta-eventos de canciones ......................... 46

MIDI Implementation Chart MIDI-Implementierungstabelle Tableau d'implémentation MIDI

Gráfico de implementacíon MIDI ............................. 47

Voice List / Voice-Liste / Liste des voix / Lista de voces

PSR-2100

Category

Piano & Harpsi GrandPiano Live! 0 113 0

E.Piano GalaxyEP Regular 0 114 4

Organ & Accordion Elec.Organ Cool! 0 118 18

Percussion Vibraphone Regular 0 112 11

Voice Name

BrightPiano Regular 0 112 1 Harpsichord Live! 0 122 6 GrandHarpsi Live! 0 123 6 HonkyTonk Regular 0 112 3 RockPiano Regular 0 114 2 MidiGrand Regular 0 112 2 CP80 Regular 0 113 2 Oct.Piano1 Regular 0 113 3 Oct.Piano2 Regular 0 114 3 GrandPiano Regular 0 112 0 Harpsichord Regular 0 112 6 GrandHarpsi Regular 0 113 6

StageEP Regular 0 117 4 PolarisEP Regular 0 115 4 JazzChorus Regular 0 118 5 HyperTines Regular 0 113 5 E.Piano Cool! 0 119 4 PhaseEP Regular 0 120 4 NewTines Regular 0 116 5 FunkEP Regular 0 112 4 DX Modern Regular 0 112 5 VintageEP Regular 0 116 4 ModernEP Regular 0 115 5 TremoloEP Regular 0 113 4 SuperDX Regular 0 117 5 Clavi Regular 0 112 7 SuitcaseEP Regular 0 118 4 VenusEP Regular 0 114 5 WahClavi Regular 0 113 7

JazzOrgan Cool! 0 117 16 RotorOrgan Regular 0 117 18 RockOrgan1 Regular 0 112 18 DanceOrgan Regular 0 113 17 GospelOrg Regular 0 119 16 PurpleOrg Regular 0 114 18 JazzOrgan1 Regular 0 112 16 RockOrgan2 Regular 0 113 18 RotaryDrive Regular 0 116 18 FullRocker Regular 0 115 18 Elec.Organ Regular 0 118 17 DrawbarOrg Regular 0 115 16 ClickOrgan Regular 0 112 17 StadiumOrg Regular 0 118 16 MellowDraw Regular 0 115 17 JazzOrgan2 Regular 0 113 16 BrightDraw Regular 0 116 16 60'sOrgan Regular 0 116 17 JazzOrgan3 Regular 0 120 16 TheatreOrg1 Regular 0 114 16 TheatreOrg2 Regular 0 114 17 Musette Regular 0 112 21 TuttiAccrd Regular 0 113 21 SmallAccrd Regular 0 115 21 Accordion Regular 0 116 21 Steirisch Regular 0 117 21 TangoAccrd Regular 0 112 23 Bandoneon Regular 0 113 23 SoftAccrd Regular 0 114 21 Harmonica Sweet! 0 122 22 ModernHarp Regular 0 113 22 BluesHarp Regular 0 114 22 Harmonica Regular 0 112 22 PipeOrgan Regular 0 112 19 ChapelOrgn1 Regular 0 113 19 ChapelOrgn2 Regular 0 114 19 ChapelOrgn3 Regular 0 115 19 ReedOrgan Regular 0 112 20

JazzVibes Regular 0 113 11 Marimba Regular 0 112 12 Xylophone Regular 0 112 13 SteelDrums Regular 0 112 114 Celesta Regular 0 112 8 Glocken Regular 0 112 9 MusicBox Regular 0 112 10 TubularBell Regular 0 112 14 Kalimba Regular 0 112 108 Dulcimer Regular 0 112 15

Voice Type Bank Select MIDI

MSB LSB

Program

Number

Category

Percussion Timpani Regular 0 112 47

Guitar Nylon Guitar Live! 0 116 24

Bass FingerBass Regular 0 112 33

Voice Name

StandardKit1 Drums 127 0 0 StandardKit2 Drums 127 0 1 HitKit Drums 127 0 4 RoomKit Drums 127 0 8 RockKit Drums 127 0 16 ElectroKit Drums 127 0 24 AnalogKit Drums 127 0 25 DanceKit Drums 127 0 27 JazzKit Drums 127 0 32 BrushKit Drums 127 0 40 SymphonyKit Drums 127 0 48 ArabicKit SFX Kit 126 0 35 SFXKit1 SFX Kit 126 0 0 SFXKit2 SFX Kit 126 0 1 StyStd.Kit Drums 127 0 80 StyBrushKit Drums 127 0 82

Jazz Guitar Cool! 0 115 26 Elec.Gtr Cool! 0 114 28 12StrGuitar Regular 0 113 25 Smooth Lead Regular 0 119 26 Mandolin Sweet! 0 124 25 FunkGuitar Regular 0 113 28 VintageAmp Regular 0 115 29 CrunchGtr Regular 0 113 30 AlohaGtr Regular 0 118 26 ClassicGtr Live! 0 115 24 Jazz SolGt Cool! 0 116 26 FolkGuitar Regular 0 112 25 SolidChord Regular 0 121 27 ChorusGtr Regular 0 124 27 VintageMute Regular 0 115 28 VintageOpen Regular 0 123 27 LeadGuitar Regular 0 114 29 SolidGuitar Regular 0 118 27 PedalSteel Regular 0 115 27 SpanishGtr Regular 0 113 24 OctaveGtr Regular 0 113 26 DeepChorus Regular 0 114 27 CampfireGtr Regular 0 115 25 SmoothNylon Regular 0 114 24 TremoloGtr Regular 0 113 27 HawaiianGtr Regular 0 114 26 HeavyStack Regular 0 114 30 60'sClean Regular 0 117 27 WahGuitar Regular 0 122 27 ClassicGtr Regular 0 112 24 Elec.12Str Regular 0 119 27 FeedbackGtr Regular 0 113 29 BrightClean Regular 0 116 27 Distortion Regular 0 112 30 SlideGuitar Regular 0 125 27 VintageTrem Regular 0 120 27 Mandolin Regular 0 114 25 CleanGuitar Regular 0 112 27 MutedGuitar Regular 0 112 28 JazzGuitar Regular 0 112 26 Overdrive Regular 0 112 29 FolkGw_pick1 Regular 0 116 25 FolkGw_pick2 Regular 0 117 25 FolkGw_pick3 Regular 0 118 25

UprightBass Regular 0 113 32 PickBass Regular 0 112 34 SuperFretles Regular 0 113 35 SlapBass Regular 0 112 36 AnalogBass Regular 0 112 39 DrySynBass Regular 0 116 39 TouchBass Regular 0 115 39 HiQBass Regular 0 113 38 FunkBass Regular 0 112 37 Aco.Bass Regular 0 112 32 Fretless Regular 0 112 35 Bass&Cymbal Regular 0 114 32 FusionBass Regular 0 113 36 RaveBass Regular 0 114 38 DanceBass Regular 0 113 39 SynthBass Regular 0 112 38 SnapBass Regular 0 114 39 ClickBass Regular 0 115 38

Voice Type Bank Select MIDI

MSB LSB

Program

Number

2

Category

Brass Trumpet Sweet! 0 115 56

W.Wind TenorSax Sweet! 0 117 66

Voice Name

Trombone Sweet! 0 117 57 MutedTrump Sweet! 0 114 59 FlugelHorn Sweet! 0 118 56 JazzTrumpet Regular 0 116 56 HyperBrass Live! 0 118 62 PopBrass Live! 0 117 62 OctaveBrass Live! 0 116 62 BrassCombo Regular 0 115 66 BrassSection Regular 0 112 61 SoloTrumpet Regular 0 112 56 SoloTromb Regular 0 112 57 MutedTrump Regular 0 112 59 FrenchHorn Regular 0 112 60 AirTrumpet Regular 0 117 56 Sforzando Regular 0 125 61 BrightBrass Regular 0 120 61 SoftBrass Regular 0 123 61 FullHorns Regular 0 114 61 HighBrass Regular 0 115 61 TrumpetEns Regular 0 122 61 Trombone Regular 0 116 57 SoftTromb Regular 0 115 57 MellowTromb Regular 0 114 57 SmoothTromb Regular 0 118 57 MellowHorns Regular 0 119 61 BallroomBrs Regular 0 113 59 Trb.Section Regular 0 113 57 SmallBrass Regular 0 117 61 BrassHit Regular 0 126 61 SoftTrumpet Regular 0 114 56 FlugelHorn Regular 0 113 56 MellowBrass Regular 0 116 61 BigBrass Regular 0 121 61 PopBrass Regular 0 118 61 BigBandBrs Regular 0 113 61 StepBrass Regular 0 124 61 OberBrass Regular 0 113 63 AnalogBrs Regular 0 112 63 SoftAnalog Regular 0 114 63 FunkyAnalog Regular 0 115 62 TechnoBrass Regular 0 114 62 SynthBrass Regular 0 112 62 80'sBrass Regular 0 113 62 BaritonHorn Regular 0 113 58 BaritonHit Regular 0 114 58 AlpBass Regular 0 113 33 Tuba Regular 0 112 58

AltoSax Sweet! 0 114 65 SopranoSax Sweet! 0 113 64 Clarinet Sweet! 0 114 71 GrowlSax Regular 0 118 66 Flute Sweet! 0 114 73 PanFlute Sweet! 0 113 75 Oboe Sweet! 0 122 68 SaxSection Regular 0 116 66 BaritoneSax Regular 0 112 67 BreathTenor Regular 0 114 66 BreathyAlto Regular 0 113 65 SopranoSax Regular 0 112 64 Clarinet Regular 0 112 71 WoodwindEns Regular 0 113 66 Class.Flute Regular 0 115 73 PanFlute Regular 0 113 73 Piccolo Regular 0 112 72 EthnicFlute Regular 0 112 75 RockBari Regular 0 113 67 TenorSax Regular 0 112 66 AltoSax Regular 0 112 65 MelClarinet Regular 0 113 71 Oboe Regular 0 112 68 EnglishHorn Regular 0 112 69 Bassoon Regular 0 112 70 Flute Regular 0 112 73 Shakuhachi Regular 0 112 77 Whistle Regular 0 112 78 Recorder Regular 0 112 74 Ocarina Regular 0 112 79 Bagpipe Regular 0 112 109

Voice Type Bank Select MIDI

MSB LSB

Program

Number

Category

Strings Strings Live! 0 117 49

Choir & Pad Gospel Live! 0 116 52

Synthesizer Oxygen Regular 0 122 81

Voice Name

Allegro Live! 0 122 49 Orchestra Live! 0 116 49 Symphon.Str Regular 0 114 48 Violin Sweet! 0 122 40 OrchStrings Regular 0 113 48 Orch.Brass Regular 0 118 49 Orch.Flute Regular 0 119 49 Orch.Fl.Br Regular 0 120 49 Orch.Oboe Regular 0 121 49 Strings Regular 0 112 48 SoloViolin Regular 0 112 40 SoftViolin Regular 0 113 40 Fiddle Regular 0 112 110 Viola Regular 0 112 41 Cello Regular 0 112 42 Contrabass Regular 0 112 43 ChamberStrs Regular 0 112 49 Str.Quartet Regular 0 114 49 ConcertoStr Regular 0 115 48 BowStrings Regular 0 116 48 MarcatoStrs Regular 0 115 49 SlowStrings Regular 0 113 49 TremoloStrs Regular 0 112 44 PizzStrings Regular 0 112 45 AnalogStrs Regular 0 112 51 SynStrings Regular 0 112 50 TechStrings Regular 0 113 50 Harp Regular 0 112 46 Hackbrett Regular 0 113 46 Banjo Regular 0 112 105 Sitar Regular 0 112 104 Koto Regular 0 112 107 Shamisen Regular 0 112 106 Orch.Hit Regular 0 112 55

HahChoir Regular 0 114 52 GothicVox Regular 0 113 53 VocalEnsbl Regular 0 113 52 VoxHumana Regular 0 112 53 Choir Regular 0 112 52 AirChoir Regular 0 112 54 SweetHeaven Regular 0 118 88 DreamHeaven Regular 0 121 88 CyberPad Regular 0 113 99 Fantasia Regular 0 112 88 Voices Regular 0 113 54 Insomnia Regular 0 113 94 Wave2001 Regular 0 112 95 NeoWarmPad Regular 0 115 89 Atmosphere Regular 0 112 99 XenonPad Regular 0 112 91 Skydiver Regular 0 112 101 FarEast Regular 0 112 97 Template Regular 0 114 95 Equinox Regular 0 112 94 GlassPad Regular 0 114 93 DX Pad Regular 0 112 92 Symbiont Regular 0 113 88 Stargate Regular 0 114 88 Area51 Regular 0 112 89 DarkMoon Regular 0 113 89 Ionosphere Regular 0 115 94 GoldenAge Regular 0 115 88 Solaris Regular 0 114 94 TimeTravel Regular 0 116 88 Millennium Regular 0 117 88 Transform Regular 0 113 95 Dunes Regular 0 114 89

Matrix Regular 0 123 81 WireLead Regular 0 120 81 HipLead Regular 0 113 80 HopLead Regular 0 117 80 SquareLead Regular 0 112 80 Saw.Lead Regular 0 112 81 FireWire Regular 0 116 81 Analogon Regular 0 115 81 FunkyLead Regular 0 121 81 Paraglide Regular 0 114 84

Voice Type Bank Select MIDI

MSB LSB

Program

Number

3

Category

Synthesizer Robolead Regular 0 124 81

Organ Flutes JazzDraw! Organ Flutes 0 126 16

Voice Name

Fargo Regular 0 119 81 Portatone Regular 0 112 84 Blaster Regular 0 114 81 BigLead Regular 0 113 81 Warp Regular 0 117 81 Adrenaline Regular 0 113 84 Synchronize Regular 0 112 96 TinyLead Regular 0 118 80 Stardust Regular 0 112 98 AeroLead Regular 0 112 83 MiniLead Regular 0 114 80 SynthFlute Regular 0 119 80 SubAqua Regular 0 118 81 Impact Regular 0 113 87 SunBell Regular 0 113 98 UnderHeim Regular 0 112 87 Rhythmatic Regular 0 113 96 HiBias Regular 0 116 80 Vinylead Regular 0 115 80 Skyline Regular 0 115 84 Clockwork Regular 0 114 96

BluesOrgan! Organ Flutes 0 126 16 SixteenOne! Organ Flutes 0 126 16 EvenBars! Organ Flutes 0 126 16 PopOrgan! Organ Flutes 0 126 16 RockingOrg! Organ Flutes 0 126 16 Percussive! Organ Flutes 0 126 16 GospelOrg! Organ Flutes 0 126 16 PadOrgan! Organ Flutes 0 126 16 FullRanks! Organ Flutes 0 126 16

Voice Type Bank Select MIDI

MSB LSB

Program

Number

4

PSR-1100

Category Voice Name Voice Type Bank Select MIDI

Piano & Harpsi GrandPiano Regular 0 112 0

E.Piano GalaxyEP Regular 0 114 4

Organ & Accordion RotorOrgan Regular 0 117 18

Percussion Vibraphone Regular 0 112 11

BrightPiano Regular 0 112 1 Harpsichord Regular 0 112 6 GrandHarpsi Regular 0 113 6 HonkyTonk Regular 0 112 3 RockPiano Regular 0 114 2 MidiGrand Regular 0 112 2 CP80 Regular 0 113 2 Oct.Piano1 Regular 0 113 3 Oct.Piano2 Regular 0 114 3

StageEP Regular 0 117 4 PolarisEP Regular 0 115 4 JazzChorus Regular 0 118 5 HyperTines Regular 0 113 5 E.Piano Cool! 0 119 4 PhaseEP Regular 0 120 4 NewTines Regular 0 116 5 FunkEP Regular 0 112 4 DX Modern Regular 0 112 5 VintageEP Regular 0 116 4 ModernEP Regular 0 115 5 TremoloEP Regular 0 113 4 SuperDX Regular 0 117 5 Clavi Regular 0 112 7 SuitcaseEP Regular 0 118 4 VenusEP Regular 0 114 5 WahClavi Regular 0 113 7

RockOrgan1 Regular 0 112 18 DanceOrgan Regular 0 113 17 GospelOrg Regular 0 119 16 PurpleOrg Regular 0 114 18 RotaryDrive Regular 0 116 18 JazzOrgan1 Regular 0 112 16 RockOrgan2 Regular 0 113 18 FullRocker Regular 0 115 18 Elec.Organ Regular 0 118 17 DrawbarOrg Regular 0 115 16 ClickOrgan Regular 0 112 17 MellowDraw Regular 0 115 17 JazzOrgan2 Regular 0 113 16 BrightDraw Regular 0 116 16 60'sOrgan Regular 0 116 17 JazzOrgan3 Regular 0 120 16 16+1Organ Regular 0 121 16 16+2Organ Regular 0 122 16 16+4Organ Regular 0 123 16 BluesOrgan Regular 0 117 17 Musette Regular 0 112 21 TuttiAccrd Regular 0 113 21 SmallAccrd Regular 0 115 21 Accordion Regular 0 116 21 TangoAccrd Regular 0 112 23 Bandoneon Regular 0 113 23 SoftAccrd Regular 0 114 21 ModernHarp Regular 0 113 22 BluesHarp Regular 0 114 22 Harmonica Regular 0 112 22 TheatreOrg1 Regular 0 114 16 TheatreOrg2 Regular 0 114 17 PipeOrgan Regular 0 112 19 ChapelOrgn1 Regular 0 113 19 ChapelOrgn2 Regular 0 114 19 ChapelOrgn3 Regular 0 115 19 ReedOrgan Regular 0 112 20

JazzVibes Regular 0 113 11 Marimba Regular 0 112 12 Xylophone Regular 0 112 13 SteelDrums Regular 0 112 114 Celesta Regular 0 112 8 Glocken Regular 0 112 9 MusicBox Regular 0 112 10 TubularBell Regular 0 112 14 Kalimba Regular 0 112 108 Dulcimer Regular 0 112 15 Timpani Regular 0 112 47 StandardKit1 Drums 127 0 0 StandardKit2 Drums 127 0 1 RoomKit Drums 127 0 8

MSB LSB

Program

Number

Category Voice Name Voice Type Bank Select MIDI

Percussion RockKit Drums 127 0 16

Guitar NylonGuitar Regular 0 115 24

Bass FingerBass Regular 0 112 33

Brass Trumpet Sweet! 0 115 56

ElectroKit Drums 127 0 24 AnalogKit Drums 127 0 25 DanceKit Drums 127 0 27 JazzKit Drums 127 0 32 BrushKit Drums 127 0 40 SymphonyKit Drums 127 0 48 StyStd.Kit Drums 127 0 80 StyBrushKit Drums 127 0 82 ArabicKit SFX Kit 126 0 35 SFXKit1 SFX Kit 126 0 0 SFXKit2 SFX Kit 126 0 1 HitKit Drums 127 0 4

E.Guitar Cool! 0 114 28 12StrGuitar Regular 0 113 25 SolidGuitar Regular 0 118 27 VintageAmp Regular 0 115 29 PedalSteel Regular 0 125 27 CrunchGtr Regular 0 113 30 FunkGuitar Regular 0 113 28 60'sClean Regular 0 117 27 VintageOpen Regular 0 123 27 FolkGuitar Regular 0 112 25 SolidChord Regular 0 121 27 VintageMute Regular 0 115 28 LeadGuitar Regular 0 114 29 ChorusGtr Regular 0 124 27 VintageTrem Regular 0 120 27 SpanishGtr Regular 0 113 24 OctaveGtr Regular 0 113 26 DeepChorus Regular 0 114 27 CampfireGtr Regular 0 115 25 SmoothNylon Regular 0 114 24 TremoloGtr Regular 0 113 27 HawaiianGtr Regular 0 114 26 HeavyStack Regular 0 114 30 BrightClean Regular 0 116 27 WahGuitar Regular 0 122 27 ClassicGtr Regular 0 112 24 Distortion Regular 0 112 30 Elec.12Str Regular 0 119 27 Mandolin Regular 0 114 25 CleanGuitar Regular 0 112 27 FeedbackGtr Regular 0 113 29 MutedGuitar Regular 0 112 28 JazzGuitar Regular 0 112 26 Overdrive Regular 0 112 29 FolkGw_pick1 Regular 0 116 25 FolkGw_pick2 Regular 0 117 25 FolkGw_pick3 Regular 0 118 25

UprightBass Regular 0 113 32 PickBass Regular 0 112 34 SuperFretles Regular 0 113 35 SlapBass Regular 0 112 36 AnalogBass Regular 0 112 39 DrySynBass Regular 0 116 39 TouchBass Regular 0 115 39 HiQBass Regular 0 113 38 FunkBass Regular 0 112 37 Aco.Bass Regular 0 112 32 Fretless Regular 0 112 35 Bass&Cymbal Regular 0 114 32 FusionBass Regular 0 113 36 RaveBass Regular 0 114 38 DanceBass Regular 0 113 39 SynthBass Regular 0 112 38 SnapBass Regular 0 114 39 ClickBass Regular 0 115 38

Trombone Sweet! 0 117 57 MutedTrump Regular 0 112 59 FlugelHorn Regular 0 113 56 SoftTrumpet Regular 0 114 56 BrassSection Regular 0 112 61 MellowBrass Regular 0 116 61 BigBandBrs Regular 0 113 61 PopBrass Regular 0 118 61 BrassCombo Regular 0 115 66 SoloTrumpet Regular 0 112 56

MSB LSB

Program

Number

5

Category Voice Name Voice Type Bank Select MIDI

Brass SoloTromb Regular 0 112 57

W.Wind TenorSax Sweet! 0 117 66

Strings Orchestra Live! 0 116 49

JazzTrumpet Regular 0 116 56 FrenchHorn Regular 0 112 60 AirTrumpet Regular 0 117 56 BrightBrass Regular 0 120 61 SoftBrass Regular 0 123 61 FullHorns Regular 0 114 61 HighBrass Regular 0 115 61 TrumpetEns Regular 0 122 61 Trombone Regular 0 116 57 SoftTromb Regular 0 115 57 MellowTromb Regular 0 114 57 SmoothTromb Regular 0 118 57 MellowHorns Regular 0 119 61 BallroomBrs Regular 0 113 59 Trb.Section Regular 0 113 57 SmallBrass Regular 0 117 61 BrassHit Regular 0 126 61 StepBrass Regular 0 124 61 OberBrass Regular 0 113 63 AnalogBrs Regular 0 112 63 SoftAnalog Regular 0 114 63 FunkyAnalog Regular 0 115 62 TechnoBrass Regular 0 114 62 SynthBrass Regular 0 112 62 80'sBrass Regular 0 113 62 Tuba Regular 0 112 58

AltoSax Sweet! 0 114 65 SopranoSax Sweet! 0 113 64 Clarinet Sweet! 0 114 71 GrowlSax Regular 0 118 66 Flute Sweet! 0 114 73 PanFlute Sweet! 0 113 75 WoodwindEns Regular 0 113 66 SaxSection Regular 0 116 66 BaritoneSax Regular 0 112 67 BreathTenor Regular 0 114 66 BreathyAlto Regular 0 113 65 SopranoSax Regular 0 112 64 Clarinet Regular 0 112 71 Oboe Regular 0 112 68 EnglishHorn Regular 0 112 69 Bassoon Regular 0 112 70 Class.Flute Regular 0 115 73 Piccolo Regular 0 112 72 PanFlute Regular 0 113 73 EthnicFlute Regular 0 112 75 RockBari Regular 0 113 67 TenorSax Regular 0 112 66 AltoSax Regular 0 112 65 MelClarinet Regular 0 113 71 Flute Regular 0 112 73 Shakuhachi Regular 0 112 77 Whistle Regular 0 112 78 Recorder Regular 0 112 74 Ocarina Regular 0 112 79 Bagpipe Regular 0 112 109

Strings Regular 0 112 48 OrchStrings Regular 0 113 48 Symphon.Str Regular 0 114 48 SlowStrings Regular 0 113 49 SoloViolin Regular 0 112 40 AnalogStrs Regular 0 112 51 Orch.Brass Regular 0 118 49 Orch.Flute Regular 0 119 49 Orch.Oboe Regular 0 121 49 SoftViolin Regular 0 113 40 Fiddle Regular 0 112 110 Viola Regular 0 112 41 Cello Regular 0 112 42 Contrabass Regular 0 112 43 ChamberStrs Regular 0 112 49 Str.Quartet Regular 0 114 49 ConcertoStr Regular 0 115 48 BowStrings Regular 0 116 48 MarcatoStrs Regular 0 115 49 TremoloStrs Regular 0 112 44 PizzStrings Regular 0 112 45 SynStrings Regular 0 112 50

MSB LSB

Program

Number

Category Voice Name Voice Type Bank Select MIDI

Strings TechStrings Regular 0 113 50

Choir & Pad HahChoir Regular 0 114 52

Synth Oxygen Regular 0 122 81

Harp Regular 0 112 46 Hackbrett Regular 0 113 46 Banjo Regular 0 112 105 Sitar Regular 0 112 104 Koto Regular 0 112 107 Shamisen Regular 0 112 106 Orch.Hit Regular 0 112 55

GothicVox Regular 0 113 53 VocalEnsbl Regular 0 113 52 VoxHumana Regular 0 112 53 Choir Regular 0 112 52 AirChoir Regular 0 112 54 SweetHeaven Regular 0 118 88 CyberPad Regular 0 113 99 Fantasia Regular 0 112 88 Insomnia Regular 0 113 94 Wave2001 Regular 0 112 95 Atmosphere Regular 0 112 99 NeoWarmPad Regular 0 115 89 XenonPad Regular 0 112 91 Equinox Regular 0 112 94 DX Pad Regular 0 112 92 Symbiont Regular 0 113 88 Stargate Regular 0 114 88 Area51 Regular 0 112 89 DarkMoon Regular 0 113 89 Ionosphere Regular 0 115 94 GoldenAge Regular 0 115 88 Solaris Regular 0 114 94 Millennium Regular 0 117 88 Transform Regular 0 113 95 Dunes Regular 0 114 89

Matrix Regular 0 123 81 WireLead Regular 0 120 81 HipLead Regular 0 113 80 SquareLead Regular 0 112 80 Saw.Lead Regular 0 112 81 FireWire Regular 0 116 81 Analogon Regular 0 115 81 FunkyLead Regular 0 121 81 Fargo Regular 0 119 81 Portatone Regular 0 112 84 Blaster Regular 0 114 81 BigLead Regular 0 113 81 Warp Regular 0 117 81 Adrenaline Regular 0 113 84 TinyLead Regular 0 118 80 Stardust Regular 0 112 98 AeroLead Regular 0 112 83 MiniLead Regular 0 114 80 SynthFlute Regular 0 119 80 SubAqua Regular 0 118 81 SunBell Regular 0 113 98 UnderHeim Regular 0 112 87 HiBias Regular 0 116 80 Vinylead Regular 0 115 80 Skyline Regular 0 115 84

MSB LSB

Program

Number

6

XG

Category Voice Name Voice Type Bank Select MIDI

PIANO GrandPiano Regular 0 0 0

CHROMATIC PERC. Celesta Regular 0 0 8

ORGAN DrawbarOrgan Regular 0 0 16

GrndPianoKSP Regular 0 1 0 MellowGrPno Regular 0 18 0 PianoStrings Regular 0 40 0 Dream Regular 0 41 0 BrightPiano Regular 0 0 1 BritePnoKSP Regular 0 1 1 ElecGrandPno Regular 0 0 2 ElecGrPnoKSP Regular 0 1 2 DetunedCP80 Regular 0 32 2 LayeredCP1 Regular 0 40 2 LayeredCP2 Regular 0 41 2 Honkytonk Regular 0 0 3 HonkytonkKSP Regular 0 1 3 El.Piano1 Regular 0 0 4 El.Piano1KSP Regular 0 1 4 MellowEP1 Regular 0 18 4 ChorusEP1 Regular 0 32 4 HardEl.Piano Regular 0 40 4 VXfadeEl.P1 Regular 0 45 4 60sEl.Piano1 Regular 0 64 4 El.Piano2 Regular 0 0 5 El.Piano2KSP Regular 0 1 5 ChorusEP2 Regular 0 32 5 DXEPHard Regular 0 33 5 DXLegend Regular 0 34 5 DXPhaseEP Regular 0 40 5 DX+AnalogEP Regular 0 41 5 DXKotoEP Regular 0 42 5 VXfadeEl.P2 Regular 0 45 5 Harpsichord Regular 0 0 6 Harpsi.KSP Regular 0 1 6 Harpsichord2 Regular 0 25 6 Harpsichord3 Regular 0 35 6 Clavi. Regular 0 0 7 Clavi.KSP Regular 0 1 7 Clavi.Wah Regular 0 27 7 PulseClavi. Regular 0 64 7 PierceClavi. Regular 0 65 7

Glockenspiel Regular 0 0 9 MusicBox Regular 0 0 10 Orgel Regular 0 64 10 Vibraphone Regular 0 0 11 VibesKSP Regular 0 1 11 HardVibes Regular 0 45 11 Marimba Regular 0 0 12 MarimbaKSP Regular 0 1 12 SineMarimba Regular 0 64 12 Balimba Regular 0 97 12 LogDrums Regular 0 98 12 Xylophone Regular 0 0 13 TubularBells Regular 0 0 14 ChurchBells Regular 0 96 14 Carillon Regular 0 97 14 Dulcimer Regular 0 0 15 Dulcimer2 Regular 0 35 15 Cimbalom Regular 0 96 15 Santur Regular 0 97 15

DetDrawOrgan Regular 0 32 16 60sDrawOrg1 Regular 0 33 16 60sDrawOrg2 Regular 0 34 16 70sDrawOrg1 Regular 0 35 16 DrawbarOrg2 Regular 0 36 16 60sDrawOrg3 Regular 0 37 16 EvenBarOrg Regular 0 38 16 16+2'2_3Org Regular 0 40 16 OrganBass Regular 0 64 16 70sDrawOrg2 Regular 0 65 16 CheezyOrgan Regular 0 66 16 DrawbarOrg3 Regular 0 67 16 Perc.Organ Regular 0 0 17 70sPercOrg1 Regular 0 24 17 DetPercOrgan Regular 0 32 17 LightOrgan Regular 0 33 17 Perc.Organ2 Regular 0 37 17 RockOrgan Regular 0 0 18 RotaryOrgan Regular 0 64 18 SlowRotary Regular 0 65 18

MSB LSB

Program

Number

Category Voice Name Voice Type Bank Select MIDI

ORGAN FastRotary Regular 0 66 18

GUITAR NylonGuitar Regular 0 0 24

BASS AcousticBass Regular 0 0 32

ChurchOrgan Regular 0 0 19 ChurchOrgan3 Regular 0 32 19 ChurchOrgan2 Regular 0 35 19 NotreDame Regular 0 40 19 OrganFlute Regular 0 64 19 Trem.OrganFl Regular 0 65 19 ReedOrgan Regular 0 0 20 PuffOrgan Regular 0 40 20 Accordion Regular 0 0 21 AccordIt Regular 0 32 21 Harmonica Regular 0 0 22 Harmonica2 Regular 0 32 22 TangoAccord Regular 0 0 23 TangoAccord2 Regular 0 64 23

NylonGuitar2 Regular 0 16 24 NylonGuitar3 Regular 0 25 24 VelGtrHarmo Regular 0 43 24 Ukulele Regular 0 96 24 SteelGuitar Regular 0 0 25 SteelGuitar2 Regular 0 16 25 12StrGuitar Regular 0 35 25 Nylon&Steel Regular 0 40 25 Steel&Body Regular 0 41 25 Mandolin Regular 0 96 25 JazzGuitar Regular 0 0 26 MellowGuitar Regular 0 18 26 JazzAmp Regular 0 32 26 CleanGuitar Regular 0 0 27 ChorusGuitar Regular 0 32 27 MutedGuitar Regular 0 0 28 FunkGuitar1 Regular 0 40 28 MuteSteelGtr Regular 0 41 28 FunkGuitar2 Regular 0 43 28 JazzMan Regular 0 45 28 Overdriven Regular 0 0 29 GuitarPinch Regular 0 43 29 Distortion Regular 0 0 30 FeedbackGtr Regular 0 40 30 FeedbackGtr2 Regular 0 41 30 GtrHarmonics Regular 0 0 31 GtrFeedback Regular 0 65 31 GtrHarmonic2 Regular 0 66 31

JazzRhythm Regular 0 40 32 VXUprghtBass Regular 0 45 32 FingerBass Regular 0 0 33 FingerDark Regular 0 18 33 FlangeBass Regular 0 27 33 Bass&DistEG Regular 0 40 33 FingerSlap Regular 0 43 33 FingerBass2 Regular 0 45 33 Mod.Bass Regular 0 65 33 PickBass Regular 0 0 34 MutePickBass Regular 0 28 34 FretlessBass Regular 0 0 35 Fretless2 Regular 0 32 35 Fretless3 Regular 0 33 35 Fretless4 Regular 0 34 35 Syn.Fretless Regular 0 96 35 SmthFretless Regular 0 97 35 SlapBass1 Regular 0 0 36 ResonantSlap Regular 0 27 36 PunchThumb Regular 0 32 36 SlapBass2 Regular 0 0 37 Velo.Sw.Slap Regular 0 43 37 SynthBass1 Regular 0 0 38 SynBass1Dark Regular 0 18 38 FastResoBass Regular 0 20 38 AcidBass Regular 0 24 38 ClaviBass Regular 0 35 38 TechnoBass Regular 0 40 38 Orbiter Regular 0 64 38 SquareBass Regular 0 65 38 RubberBass Regular 0 66 38 Hammer Regular 0 96 38 SynthBass2 Regular 0 0 39 MellowSyBass Regular 0 6 39 SequenceBass Regular 0 12 39

MSB LSB

Program

Number

7

Category Voice Name Voice Type Bank Select MIDI

BASS ClickSynBass Regular 0 18 39

STRINGS Violin Regular 0 0 40

ENSEMBLE Strings1 Regular 0 0 48

BRASS Trumpet Regular 0 0 56

SynBass2Dark Regular 0 19 39 SmoothSyBass Regular 0 32 39 ModulrSyBass Regular 0 40 39 DXBass Regular 0 41 39 XWireBass Regular 0 64 39

SlwAtkViolin Regular 0 8 40 Viola Regular 0 0 41 Cello Regular 0 0 42 Contrabass Regular 0 0 43 Trem.Strings Regular 0 0 44 SlwAtTremStr Regular 0 8 44 SuspenseStr Regular 0 40 44 PizzicatoStr Regular 0 0 45 Orch.Harp Regular 0 0 46 YangChin Regular 0 40 46 Timpani Regular 0 0 47

StereoStrngs Regular 0 3 48 SlwAtkStrngs Regular 0 8 48 ArcoStrings Regular 0 24 48 60'sStrings Regular 0 35 48 Orchestra Regular 0 40 48 Orchestra2 Regular 0 41 48 TremOrchstra Regular 0 42 48 Velo.Strings Regular 0 45 48 Strings2 Regular 0 0 49 S.SlowStrngs Regular 0 3 49 LegatoStrngs Regular 0 8 49 WarmStrings Regular 0 40 49 Kingdom Regular 0 41 49 70'sStrings Regular 0 64 49 Strings3 Regular 0 65 49 SynStrings1 Regular 0 0 50 ResoStrings Regular 0 27 50 SynStrings4 Regular 0 64 50 SynStrings5 Regular 0 65 50 SynStrings2 Regular 0 0 51 ChoirAahs Regular 0 0 52 StereoChoir Regular 0 3 52 ChoirAahs2 Regular 0 16 52 MellowChoir Regular 0 32 52 ChoirStrings Regular 0 40 52 VoiceOohs Regular 0 0 53 SynthVoice Regular 0 0 54 SynthVoice2 Regular 0 40 54 Choral Regular 0 41 54 AnalogVoice Regular 0 64 54 OrchestraHit Regular 0 0 55 OrchestrHit2 Regular 0 35 55 Impact Regular 0 64 55

Trumpet2 Regular 0 16 56 BriteTrumpet Regular 0 17 56 WarmTrumpet Regular 0 32 56 Trombone Regular 0 0 57 Trombone2 Regular 0 18 57 Tuba Regular 0 0 58 Tuba2 Regular 0 16 58 MutedTrumpet Regular 0 0 59 FrenchHorn Regular 0 0 60 Fr.HornSolo Regular 0 6 60 FrenchHorn2 Regular 0 32 60 HornOrchestr Regular 0 37 60 BrassSection Regular 0 0 61 Tp&TbSection Regular 0 35 61 BrassSect2 Regular 0 40 61 HighBrass Regular 0 41 61 MellowBrass Regular 0 42 61 SynthBrass1 Regular 0 0 62 QuackBrass Regular 0 12 62 ResoSynBrass Regular 0 20 62 PolyBrass Regular 0 24 62 SynthBrass3 Regular 0 27 62 JumpBrass Regular 0 32 62 AnaVelBrass1 Regular 0 45 62 AnalogBrass1 Regular 0 64 62 SynthBrass2 Regular 0 0 63 SoftBrass Regular 0 18 63

MSB LSB

Program

Number

Category Voice Name Voice Type Bank Select MIDI

BRASS SynthBrass4 Regular 0 40 63

REED SopranoSax Regular 0 0 64

PIPE Piccolo Regular 0 0 72

SYNTH LEAD SquareLead Regular 0 0 80

SYNTH PAD NewAgePad Regular 0 0 88

ChoirBrass Regular 0 41 63 AnaVelBrass2 Regular 0 45 63 AnalogBrass2 Regular 0 64 63

AltoSax Regular 0 0 65 SaxSection Regular 0 40 65 HyperAltoSax Regular 0 43 65 TenorSax Regular 0 0 66 BreathyTenor Regular 0 40 66 SoftTenorSax Regular 0 41 66 TenorSax2 Regular 0 64 66 BaritoneSax Regular 0 0 67 Oboe Regular 0 0 68 EnglishHorn Regular 0 0 69 Bassoon Regular 0 0 70 Clarinet Regular 0 0 71

Flute Regular 0 0 73 Recorder Regular 0 0 74 PanFlute Regular 0 0 75 BlownBottle Regular 0 0 76 Shakuhachi Regular 0 0 77 Whistle Regular 0 0 78 Ocarina Regular 0 0 79

SquareLead2 Regular 0 6 80 LMSquare Regular 0 8 80 Hollow Regular 0 18 80 Shroud Regular 0 19 80 Mellow Regular 0 64 80 SoloSine Regular 0 65 80 SineLead Regular 0 66 80 SawtoothLead Regular 0 0 81 SawtoothLd2 Regular 0 6 81 ThickSaw Regular 0 8 81 DynamicSaw Regular 0 18 81 DigitalSaw Regular 0 19 81 BigLead Regular 0 20 81 HeavySynth Regular 0 24 81 WaspySynth Regular 0 25 81 PulseSaw Regular 0 40 81 Dr.Lead Regular 0 41 81 VelocityLead Regular 0 45 81 Seq.Analog Regular 0 96 81 CalliopeLead Regular 0 0 82 PurePad Regular 0 65 82 ChiffLead Regular 0 0 83 Rubby Regular 0 64 83 CharangLead Regular 0 0 84 DistortedLd Regular 0 64 84 WireLead Regular 0 65 84 VoiceLead Regular 0 0 85 SynthAahs Regular 0 24 85 VoxLead Regular 0 64 85 FifthsLead Regular 0 0 86 BigFive Regular 0 35 86 Bass&Lead Regular 0 0 87 Big&Low Regular 0 16 87 Fat&Perky Regular 0 64 87 SoftWhirl Regular 0 65 87

Fantasy Regular 0 64 88 WarmPad Regular 0 0 89 ThickPad Regular 0 16 89 SoftPad Regular 0 17 89 SinePad Regular 0 18 89 HornPad Regular 0 64 89 RotaryStrngs Regular 0 65 89 PolySynthPad Regular 0 0 90 PolyPad80 Regular 0 64 90 ClickPad Regular 0 65 90 AnalogPad Regular 0 66 90 SquarePad Regular 0 67 90 ChoirPad Regular 0 0 91 Heaven Regular 0 64 91 Itopia Regular 0 66 91 CCPad Regular 0 67 91 BowedPad Regular 0 0 92 Glacier Regular 0 64 92

MSB LSB

Program

Number

8

Category Voice Name Voice Type Bank Select MIDI

SYNTH PAD GlassPad Regular 0 65 92

SYNTH EFFECTS Rain Regular 0 0 96

ETHNIC Sitar Regular 0 0 104

MetallicPad Regular 0 0 93 TinePad Regular 0 64 93 PanPad Regular 0 65 93 HaloPad Regular 0 0 94 SweepPad Regular 0 0 95 Shwimmer Regular 0 20 95 Converge Regular 0 27 95 PolarPad Regular 0 64 95 Celestial Regular 0 66 95

ClaviPad Regular 0 45 96 HarmoRain Regular 0 64 96 AfricanWind Regular 0 65 96 Carib Regular 0 66 96 SoundTrack Regular 0 0 97 Prologue Regular 0 27 97 Ancestral Regular 0 64 97 Crystal Regular 0 0 98 SynthDr.Comp Regular 0 12 98 Popcorn Regular 0 14 98 TinyBells Regular 0 18 98 RoundGlocken Regular 0 35 98 GlockenChime Regular 0 40 98 ClearBells Regular 0 41 98 ChorusBells Regular 0 42 98 SynthMallet Regular 0 64 98 SoftCrystal Regular 0 65 98 LoudGlocken Regular 0 66 98 ChristmasBel Regular 0 67 98 VibeBells Regular 0 68 98 DigitalBells Regular 0 69 98 AirBells Regular 0 70 98 BellHarp Regular 0 71 98 Gamelimba Regular 0 72 98 Atmosphere Regular 0 0 99 WarmAtmos. Regular 0 18 99 HollwRelease Regular 0 19 99 NylonElPiano Regular 0 40 99 NylonHarp Regular 0 64 99 HarpVox Regular 0 65 99 Atmos.Pad Regular 0 66 99 Planet Regular 0 67 99 Brightness Regular 0 0 100 FantasyBells Regular 0 64 100 Smokey Regular 0 96 100 Goblins Regular 0 0 101 GoblinsSynth Regular 0 64 101 Creeper Regular 0 65 101 RingPad Regular 0 66 101 Ritual Regular 0 67 101 ToHeaven Regular 0 68 101 Night Regular 0 70 101 Glisten Regular 0 71 101 BellChoir Regular 0 96 101 Echoes Regular 0 0 102 Echoes2 Regular 0 8 102 EchoPan Regular 0 14 102 EchoBells Regular 0 64 102 BigPan Regular 0 65 102 SynthPiano Regular 0 66 102 Creation Regular 0 67 102 StarDust Regular 0 68 102 Reso&Panning Regular 0 69 102 Sci-Fi Regular 0 0 103 Starz Regular 0 64 103

DetunedSitar Regular 0 32 104 Sitar2 Regular 0 35 104 Tambra Regular 0 96 104 Tamboura Regular 0 97 104 Banjo Regular 0 0 105 MutedBanjo Regular 0 28 105 Rabab Regular 0 96 105 Gopichant Regular 0 97 105 Oud Regular 0 98 105 Shamisen Regular 0 0 106 Koto Regular 0 0 107 Taisho-kin Regular 0 96 107 Kanoon Regular 0 97 107

MSB LSB

Program

Number

Category Voice Name Voice Type Bank Select MIDI

ETHNIC Kalimba Regular 0 0 108

PERCUSSIVE TinkleBell Regular 0 0 112

SOUND EFFECTS GtrFretNoise Regular 0 0 120

SFX CuttingNoise Regular 64 0 0

Bagpipe Regular 0 0 109 Fiddle Regular 0 0 110 Shanai Regular 0 0 111 Shanai2 Regular 0 64 111 Pungi Regular 0 96 111 Hichiriki Regular 0 97 111

Bonang Regular 0 96 112 Altair Regular 0 97 112 GamelanGongs Regular 0 98 112 StereoGamlan Regular 0 99 112 RamaCymbal Regular 0 100 112 AsianBells Regular 0 101 112 Agogo Regular 0 0 113 SteelDrums Regular 0 0 114 GlassPerc. Regular 0 97 114 ThaiBells Regular 0 98 114 Woodblock Regular 0 0 115 Castanets Regular 0 96 115 TaikoDrum Regular 0 0 116 GranCassa Regular 0 96 116 MelodicTom Regular 0 0 117 MelodicTom2 Regular 0 64 117 RealTom Regular 0 65 117 RockTom Regular 0 66 117 SynthDrum Regular 0 0 118 AnalogTom Regular 0 64 118 ElectroPerc. Regular 0 65 118 Rev.Cymbal Regular 0 0 119

BreathNoise Regular 0 0 121 Seashore Regular 0 0 122 BirdTweet Regular 0 0 123 TelephonRing Regular 0 0 124 Helicopter Regular 0 0 125 Applause Regular 0 0 126 Gunshot Regular 0 0 127

CuttingNoiz2 Regular 64 0 1 StringSlap Regular 64 0 3 Fl.KeyClick Regular 64 0 16 Shower Regular 64 0 32 Thunder Regular 64 0 33 Wind Regular 64 0 34 Stream Regular 64 0 35 Bubble Regular 64 0 36 Feed Regular 64 0 37 Dog Regular 64 0 48 Horse Regular 64 0 49 BirdTweet2 Regular 64 0 50 Ghost Regular 64 0 54 Maou Regular 64 0 55 PhoneCall Regular 64 0 64 DoorSqueak Regular 64 0 65 DoorSlam Regular 64 0 66 ScratchCut Regular 64 0 67 ScratchSplit Regular 64 0 68 WindChime Regular 64 0 69 TelphonRing2 Regular 64 0 70 CarEngineIgn Regular 64 0 80 CarTiresSqel Regular 64 0 81 CarPassing Regular 64 0 82 CarCrash Regular 64 0 83 Siren Regular 64 0 84 Train Regular 64 0 85 JetPlane Regular 64 0 86 Starship Regular 64 0 87 Burst Regular 64 0 88 RollrCoaster Regular 64 0 89 Submarine Regular 64 0 90 Laugh Regular 64 0 96 Scream Regular 64 0 97 Punch Regular 64 0 98 Heartbeat Regular 64 0 99 FootSteps Regular 64 0 100 MachineGun Regular 64 0 112 LaserGun Regular 64 0 113 Explosion Regular 64 0 114 Firework Regular 64 0 115

MSB LSB

Program

Number

9

Drum/key Assignment List Liste der Tastenzuordnungen der Schlaginstrumente Liste d’assignation instrument de batterie/touche du clavier Lista de asignación de teclas/batería

Bank Select MSB (0-127) 127 127 127 127 127 127 127 127

Bank Select LSB (0-127) 0 0 0 0 0 0 0 0

Program Change (0-127) 0 1 4 8 16 24 25 27

MIDI

Keyboard

Key

Alternate

Note

Note# Note



13 C 14 D-1 (D0) 3 Surdo Open



15 D 16 E-1 (E0) Whip Slap 17 F-1 (F0) 4 Scratch H



18 F 19 G-1 (G0) Finger Snap



20 G 21 A-1 (A0) Metronome Click



22 A 23 B-1 (B0) Seq Click L 24 C0 C1 Seq Click H 25 C 26 D0 D1 OBrush Swirl 27 D 28 E0 E1 OBrush Tap Swirl Reverse Cymbal Reverse Cymbal Reverse Cymbal 29 F0 F1 O Snare Roll



30 F 31 G0 G1 Snare Soft Snare Soft 2 Snare Electro Snare Noisy Snare Snappy Electro Snare Noisy 4 Snare Techno 32 G 33 A0 A1 Kick Soft Kick Tight L Kick 3 Kick 3 Kick Techno Q 34 A 35 B0 B1 Kick Tight Kick Wet Kick 2 Kick Gate Kick Analog Short Kick Techno L 36 C1 C2 Kick Kick Short Kick Tight H Kick Gate Kick Gate Heavy Kick Analog Kick Techno 37 C 38 D1 D2 Snare Snare Short Snare Ambient Snare Snappy Snare Rock Snare Noisy 2 Snare Analog Snare Clap 39 D 40 E1 E2 Snare Tight Snare Tight H Snare Tight 2 Snare Tight Snappy Snare Rock Tight Snare Noisy 3 Snare Analog 2 Snare Dry 41 F1 F2 Floor Tom L Hybrid Tom 1 Tom Room 1 Tom Rock 1 Tom Electro 1 Tom Analog 1 Tom Analog 1



42 F 43 G1 G2 Floor Tom H Hybrid Tom 2 Tom Room 2 Tom Rock 2 Tom Electro 2 Tom Analog 2 Tom Analog 2 44 G 45 A1 A2 Low Tom Hybrid Tom 3 Tom Room 3 Tom Rock 3 Tom Electro 3 Tom Analog 3 Tom Analog 3 46 A 47 B1 B2 Mid Tom L Hybrid Tom 4 Tom Room 4 Tom Rock 4 Tom Electro 4 Tom Analog 4 Tom Analog 4 48 C2 C3 Mid Tom H Hybrid Tom 5 Tom Room 5 Tom Rock 5 Tom Electro 5 Tom Analog 5 Tom Analog 5 49 C 50 D2 D3 High Tom Hybrid Tom 6 Tom Room 6 Tom Rock 6 Tom Electro 6 Tom Analog 6 Tom Analog 6 51 D 52 E2 E3 Chinese Cymbal 53 F2 F3 Ride Cymbal Cup



54 F 55 G2 G3 Splash Cymbal 56 G 57 A2 A3 Crash Cymbal 2 58 A 59 B2 B3 Ride Cymbal 2 60 C3 C4 Bongo H 61 C 62 D3 D4 Conga H Mute Conga Analog H Conga Analog H 63 D 64 E3 E4 Conga L 65 F3 F4 Timbale H



66 F 67 G3 G4 Agogo H 68 G 69 A3 A4 Cabasa 70 A 71 B3 B4 O Samba Whistle H 72 C4 C5 O Samba Whistle L 73 C 74 D4 D5 O Guiro Long 75 D 76 E4 E5 Wood Block H 77 F4 F5 Wood Block L



78 F 79 G4 G5 Cuica Open Scratch L 2 Scratch L 2 Scratch L 2 80 G 81 A4 A5 2Triangle Open 82 A 83 B4 B5 Jingle Bells 84 C5 C6 Bell Tree 85 C 86 D5 (D6) 87 D 88 E5 (E6) 89 F5 (F6)



90 F 91 G5 (G6)

• Key Off: Keys marked “O” stop sounding the instant they are released.

• Alternate Group: Playing any instrument within a numbered group will immediately stop the sound of any other instrument in the same group of the same number

Off



-1 (C

0) 3 Surdo Mute



-1 (D

0) Hi Q



-1 (F

0) 4 Scratch L



-1 (G

0) Click Noise



-1 (A

0) Metronome Bell



0C

1Brush Tap



0D

1Brush Slap



0F

1 Castanet Hi Q 2 Hi Q 2 Hi Q 2



0G

1Sticks



0A

1 Open Rim Shot Open Rim Shot H Short Snare Pitched Rim Gate



1C

2Side Stick Side Stick Light Stick Ambient Side Stick Analog Side Stick Analog



1D

2 Hand Clap



1F

21Hi-Hat Closed Hi-Hat Closed 2 Hi-Hat Closed Analog Hi-Hat Closed 3



1G

21Hi-Hat Pedal Hi-Hat Pedal 2 Hi-Hat Closed Analog 2 Hi-Hat Closed Analog 3



1A

21Hi-Hat Open Hi-Hat Open 2 Hi-Hat Open Analog Hi-Hat Open 3



2C

3Crash Cymbal 1 Crash Analog Crash Analog



2D

3Ride Cymbal 1



2F

3 Tambourine Tambourine Light



2G

3 Cowbell Cowbell Analog Cowbell Analog



2A

3Vibraslap



3C

4 Bongo L



3D

4 Conga H Open Conga Analog M Conga Analog M



3F

4Timbale L



3G

4 Agogo L



3A

4 Maracas



4C

5 Guiro Short



4D

5Claves Claves 2 Claves 2



4F

5 Cuica Mute Scratch H 2 Scratch H 2 Scratch H 2



4G

52Triangle Mute



4A

5 Shaker



5 (C

6)



5 (D

6)



5 (F

6)

Same as Standard Kit 1

No Sound

Standard Kit1 Standard Kit2 Hit Kit

Group

(PSR-2100)

Room Kit Rock Kit Electro Kit Analog Kit Dance Kit

Conga Analog L Conga Analog L

Maracas 2 Maracas 2

10

Bank Select MSB (0-127) 127 127 127 127 127 126 126 126

Bank Select LSB (0-127) 0 0 0 0 0 0 0 0

Program Change (0-127) 32 40 48 80 82 35 0 1

MIDI

Keyboard

Key

Alternate

Note

Off

Note# Note



13 C

-1 (C

14 D-1 (D0) 3



15 D

-1 (D 16 E-1 (E0) 17 F-1 (F0) 4



18 F

-1 (F 19 G-1 (G0)



20 G

-1 (G 21 A-1 (A0)



22 A

-1 (A 23 B-1 (B0) 24 C0 C1 Nakarazan Dom



25 C

0C

26 D0 D1 O Brush Swirl Style Std Brush Swirl StyleBrush Nakarazan Edge



27 D

0D 28 E0 E1 O BrushTapSwirlStyleStd BrushTapSwirlStyleBrsh Hager Edge 29 F0 F1 O Bongo H



30 F

0F 31 G0 G1 Snare Jazz H Brush Slap 2 Snare Soft Style Std Snare Soft Style Brush Conga H Mute



32 G

0G 33 A0 A1 Kick Soft 2 Kick Soft Style Std Kick Soft Style Brush Conga L



34 A

0A 35 B0 B1 Gran Cassa Kick Tight Style Std Kick Tight Style Brush Zagrouda L 36 C1 C2 Kick Jazz Kick Jazz Gran Cassa Mute Kick Style Std Kick Style Brush Kick Soft Cutting Noise Phone Call



37 C

1C 38 D1 D2 Snare Jazz L Brush Slap 3 Band Snare Snare Style Std Snare Style Brush Snare Soft Door Slam



39 D

1D 40 E1 E2 Snare Jazz M Brush Tap 2 Band Snare 2 Snare Tight Style Std Snare Tight StyleBrush Snare Scratch H 3 41 F1 F2 Tom Brush 1 Floor Tom L Style Std Floor Tom L StyleBrush Floor Tom L Wind Chime



42 F

1F 43 G1 G2 Tom Brush 2 Floor Tom H Style Std Floor Tom H StyleBrush Floor Tom H



44 G

1G 45 A1 A2 Tom Brush 3 Low Tom Style Std Low Tom Style Brush Low Tom



46 A

1A 47 B1 B2 Tom Brush 4 Mid Tom L Style Std Mid Tom L Style Brush Mid Tom L 48 C2 C3 Tom Brush 5 Mid Tom H Style Std Mid Tom H Style Brush Mid Tom H



49 C

2C 50 D2 D3 Tom Brush 6 High Tom Style Std High Tom Style Brush High Tom



51 D

2D 52 E2 E3 53 F2 F3



54 F

2F 55 G2 G3 Splash Cymbal StyleStd



56 G

2G 57 A2 A3 Hand Cymbal 2



58 A

2A 59 B2 B3 60 C3 C4 Katem Dom Burst



61 C

3C 62 D3 D4 Katem Sak Submarine



63 D

3D 64 E3 E4 Doff Tak 65 F3 F4 Tabla Dom



66 F

3F 67 G3 G4 Tabla Tik



68 G

3G 69 A3 A4 Tabla Sak Thunder Scream



70 A

3A 71 B3 B4 O 72 C4 C5 O Sagat 1 Bubble Foot Steps



73 C

4C 74 D4 D5 O Sagat 3



75 D

4D 76 E4 E5 Sagat 2 77 F4 F5 Rik Dom



78 F

4F 79 G4 G5 Rik Finger 1



80 G

4G 81 A4 A5 2 Rik Finger 2



82 A

4A 83 B4 B5 Rik Sak 84 C5 C6 Rik Tik Dog Machine Gun



85 C

5 (C 86 D5 (D6) Bird Tweet 2 Explosion



87 D

5 (D 88 E5 (E6) 89 F5 (F6)



90 F

5 (F 91 G5 (G6) Maou

Group



0) 3



0)



0) 4



0)



0)



1 Brush Tap Style Std Brush Tap Style Brush Cabasa



1 Brush Slap Style Std Brush Slap Style Brush Hager Dom



1 Bongo L



1 Conga H Open



1



2Side Stick Light Side Stick Light Side Stick Style Std Side Stick Style Brush Side Stick Cutting Noise 2 Door Squeak



2 Arabic Hand Clap String Slap Scratch Cut



21 Hi-Hat Closed StyleStd Hi-HatClosedStyleBrush Hi-Hat Closed Telephone Ring 2



21 Hi-Hat Pedal Style Std Hi-HatPedal StyleBrush Hi-Hat Pedal



21 Hi-Hat Open Style Std Hi-HatOpen StyleBrush Hi-Hat Open



3 Hand Cymbal



3 Hand Cymbal Short Ride Cymbal 1 StyleStd RideCymbal1 StyleBrush Ride Cymbal 1



3 Tambourine Car Passing



3 Cowbell Siren



3 Claves Jet Plane



4 Katem Tak Roller Coaster



4 Katem Tak



4 Tabla Tak1



4 Tabla Tak2 Shower Laugh



4



5 Tabel Dom Feed



5 Tabel Tak



5 Rik Tak 2



52 Rik Tak 1



5 Rik Brass Tremolo



6) Horse Laser Gun



6) Firework



6) Ghost

Jazz Kit Brush Kit Symphony Kit Sty Std.Kit Sty BrushKit Arabic Kit SFX Kit1 SFX Kit2

Open Rim Shot Light Open Rim Shot Style Std OpenRimShot StyleBrush

CrashCymbal 1 StyleStd CrashCymbal1StyleBrush

ChineseCymbal StyleStd ChineseCymbalStyleBrsh RideCymbalCup StyleStd RideCymbalCupStyleBrsh

SplashCymbalStyleBrush

CrashCymbal 2 StyleStd CrashCymbal2StyleBrush

Hand Cymbal 2 Short

Ride Cymbal 2 StyleStd

RideCymbal2 StyleBrush

Zagrouda H

Crash Cymbal 1

Crash Cymbal 2 Flute Key Click Duhulla Dom Car Tires Squeal

Duhulla Tak Car Crash

Duhulla Sak Train

Doff Dom Starship

Tabla Roll of Edge Wind Punch Tabla Flam Stream Heart Beat

Car Engine Ignition

11

Style List Liste der Styles Liste des styles Lista de estilos

●

Category Style Name PSR-2100 PSR-1100

Pop&Rock HeartBeat

Ballad 8BeatModern

Swing&Jazz BigBandFast1 ●●

60'sGtrPop 60's8Beat 8Beat1 8Beat2 BubblegumPop OffBeat 60'sRock1 60'sRock2 BritPop HardRock Rock+HalfTime RockShuffle RootRock 8BeatRock PopShuffle1 PopShuffle2 GuitarPop 16BtUptempo KoolShuffle FunkyFusion JazzPop JazzRock Soul DetroitPop1 Twist 60'sRock&Roll GospelBrothers 6-8Soul CrocoTwist Rock&Roll SoulBeat DetroitPop2 SoulShuffle BoogieWoogie 6-8Blues AmazingGospel Country8Beat1 CountryPop1 CountryRock CountrySwing Country2-4 CowboyBoogie Country8Beat2 CountryPop2 CntryBrothers CountryShuffle Hoedown FingerPickin SingrSngWriter

OrganBallad 8BeatAdria 6-8SlowRock1 6-8SlowRock2 ClassicPianoBld PianoBallad AcousticBallad 6-8ModernEP 6-8Orchestral RockBallad LoveSong 16Beat PopBallad 16BeatBallad1 16BeatBallad2 Slow&Easy ●● AnalogBallad ●● R&B ●● R&B Ballad ●● ModCntryPop ●● CountryBallad ●● Unplugged ●● SecretService ●●

BigBandMid1 ●● BigBandFast2 ●● BigBandMid2 ●● DixieJazz ●● BigBandBallad ●● MoonlightBallad ●●

●●

-

Category Style Name PSR-2100 PSR-1100

Swing&Jazz BigBandShfl1 ●●

Dance Ibiza2003 ● -

Ballroom VienneseWaltz1 ●●

Latin BrazilianSamba ●●

BigBandShfl2 ●● MediumJazz ●● JazzClub ●● Swing1 ●● Swing2 ●● TapDanceSwing ●● JazzBallad ●● GypsySwing ●● CatGroove ●● Dixieland ●● Ragtime ●● Bebop ●● Charleston ●●

RetroPop ●● DreamDance ● - EuroTrance ●● Ibiza 2000 ●● HouseMusik ●● SwingHouse ●● TechnoPolis ●● Clubdance ●● ClubLatin ●● Garage1 ●● Garage2 ●● TechnoParty ●● UKPop ●● HipHopGroove ●● HipHopLight ●● ModernR&B ● - HipShuffle ●● HipHopPop ●● 70'sDisco1 ●● 70'sDisco2 ●● 70'sDisco3 ●● LatinDisco ●● DiscoPhilly ●● SaturdayNight ●● DiscoChocolate ●● DiscoHands ●● DiscoFunk ●● DiscoSamba ●● DiscoParty ●● DiscoFox ●● FunkyDisco ●●

VienneseWaltz2 ● - EnglishWaltz ●● Slowfox ●● Foxtrot ●● Quickstep ●● OrgQuickstep ●● Tango1 ●● Tango2 ●● Swingfox ●● Pasodoble ●● Samba ●● ChaChaCha ●● Rumba ●● Jive ●● SchlagerBeat ●● SchlagerPop ●● SchlagerRock ● - SchlagerAlp ●● SchlagerRumba ●●

PopSamba ●● BossaNova ●● PopBossa ●● BigBandMambo ●● BigBandSalsa ●● SlowBossa ●● Tijuana ●● DiscoLatin ●● Cumbia ●● RockChaCha ●● FastBossa ●● Mambo ●● Salsa ●● Beguine ●●

12

Category Style Name PSR-2100 PSR-1100 Bank Name

Latin GypsyRumba ●●

March&Waltz USMarch ●●

RmbFlamenca ●● RumbaIsland ●● Espagnole ● - Caribbean ●● HappyReggae ●● JumboReggae ●● Bolero ● -

6-8March ●● GermanMarch1 ●● GermanMarch2 ● - BandMarch ● - OrchMarch ●● OrchPolka ●● PolkaPop ●● OberPolka ●● MariachiWaltz ●● Tarantella ●● GuitarSerenade ●● SwingWaltz ●● PopWaltz ● - JazzWaltz ●● BandWaltz ● - CountryWaltz ●● TraditionalWaltz ● - OberWalzer ●● Musette ●● Bluegrass1 ●● Bluegrass2 ● - Showtune ●● PubPiano ●● ChildrensMarch ●● Santa'sSwing ●● ChristmasSwing ●● ChristmasWaltz ●● ScottishReel ●● Jig ● - Hawaiian ●● LimboRock ●● HullyGully ●●

Multi Pad Bank List Multi-Pad-Bank-Liste Liste des banques multi-pads Lista de bancos de Multi Pad

Tom Flam Crash Kit Drum Kit 1 Drum Kit 2 Drum Kit 3 ArabicPerc 1 ArabicPerc 2 Latin Perc 1 Latin Perc 2 Dance Kit Attention 1 Attention 2 Fanfare 1 Fanfare 2 Swingy Brassy 1 Brassy 2 SynBrass Mallet Fills Piano Man Heaven Arp Piano Arp Harpeggio 1 Harpeggio 2 Arpeggio Crystal Arp Twinkle Arp Piano Gliss Xmas 1 Xmas 2 Guitar Cut 1 Guitar Cut 2 GuitarRiff 1 GuitarRiff 2 Guitar Strum DrumFill Limbo Dancer DJ Set 1 DJ Set 2 OrchestraHit Water SE Horror SE Night SE Day SE Car SE Big Bells Whistle MagicBell SE Classical Flamenco Gtr Salsa Piano Samba Show1 Samba Show2 TimbalesRoll

13

Effect Type List / Liste der Effekttypen / Liste des types d’effet / Lista de tipos de efecto

■ XG Effect Type

❍ Reverb Type

HALL1 1 0 HALL2 1 16 HALL3 1 17 HALL4 1 18 HALL5 1 1 HALL M 1 6 ● HALL L 1 7 ● ROOM1 2 16 ROOM2 2 17 ROOM3 2 18 ROOM4 2 19 ROOM5 2 0 ROOM6 2 1 ROOM7 2 2 ROOM S 2 5 ● ROOM M 2 6 ● ROOM L 2 7 ● STAGE1 3 16 STAGE2 3 17 STAGE3 3 0 STAGE4 3 1 PLATE1 4 16 PLATE2 4 17 PLATE3 4 0 GM PLATE 4 7 ● WHITE ROOM 16 0 TUNNEL 17 0 CANYON 18 0 BASEMENT 19 0 NO EFFECT 0 0

❍ Chorus Type

CHORUS1 66 17 CHORUS2 66 8 CHORUS3 66 16 CHORUS4 66 1 CHORUS5 65 2 CHORUS6 65 0 CHORUS7 65 1 CHORUS8 65 8 GM CHORUS1 65 3 ● GM CHORUS2 65 4 ● GM CHORUS3 65 5 ● GM CHORUS4 65 6 ● FB CHORUS 65 7 ● CELESTE1 66 0 CELESTE2 66 2 FLANGER1 67 8 FLANGER2 67 16 FLANGER3 67 17 FLANGER4 67 1 FLANGER5 67 0 GM FLANGER 67 7 ● SYMPHONIC1 68 16 ● SYMPHONIC2 68 0 ● PHASER1 72 0 ● ENS DETUNE (ENSEMBLE DETUNE) 87 0 ● NO EFFECT 0 0

●: PSR-2100 only

Effect Name Type MSB Type LSB

❍ DSP Type

DSP Block

Variation DSP 1 DSP Insertion 1 DSP 2 Insertion 2 DSP 3 Insertion 3 DSP 4

PSR-2100 PSR-1100

PSR-2100 Variation

HALL1 1 0 HALL2 1 16 HALL3 1 17 HALL4 1 18 HALL5 1 1 HALL M 1 6 HALL L 1 7 ROOM1 2 16 ROOM2 2 17 ROOM3 2 18 ROOM4 2 19 ROOM5 2 0 ROOM6 2 1 ROOM7 2 2 ROOM S 2 5 ROOM M 2 6 ROOM L 2 7 STAGE1 3 16 STAGE2 3 17 STAGE3 3 0 STAGE4 3 1 PLATE1 4 16 PLATE2 4 17 PLATE3 4 0 GM PLATE 4 7 WHITE ROOM 16 0 TUNNEL 17 0 CANYON 18 0 BASEMENT 19 0 CHORUS1 66 17 CHORUS2 66 8 CHORUS3 66 16 CHORUS4 66 1 CHORUS5 65 2 CHORUS6 65 0 CHORUS7 65 1 CHORUS8 65 8 GM CHORUS1 65 3 GM CHORUS2 65 4 GM CHORUS3 65 5 GM CHORUS4 65 6 FB CHORUS 65 7 CELESTE1 66 0 CELESTE2 66 2 SYMPHONIC1 68 16 SYMPHONIC2 68 0 ENS DETUNE (ENSEMBLE DETUNE) 87 0 KARAOKE1 20 0 KARAOKE2 20 1 KARAOKE3 20 2 ER1 9 0 ER2 9 1 GATE REVERB 10 0 REVERS GATE 11 0 EQ DISCO 76 16 EQ TEL 76 17 2BAND EQ 77 0 3BAND EQ 76 0 HM ENHANCE1 (HARMONIC ENHANCER 1) 81 16 HM ENHANCE2 (HARMONIC ENHANCER 2) 81 0 FLANGER1 67 8 FLANGER2 67 16 FLANGER3 67 17 FLANGER4 67 1 FLANGER5 67 0 GM FLANGER 67 7 DELAY LCR1 5 16 DELAY LCR2 5 0 DELAY LR 6 0 ECHO 7 0 CROSS DELAY 8 0 TEMPO DELAY 21 0 TEMPO ECHO 21 8 TEMPO CROSS 22 0 DIST HEAVY 73 0 ST DIST (STEREO DISTORTION) 73 8 COMP+DIST1 (COMPRESSOR+DISTORTION 1) 73 16 COMP+DIST2 (COMPRESSOR+DISTORTION 2) 73 1 OVERDRIVE 74 0 ST OD (STEREO OVER DRIVE) 74 8 DIST HARD (DISTORTION HARD) 75 16 DIST SOFT (DISTORTION SOFT) 75 17 ST DIST HARD (STEREO DISTORTION HARD) 75 18 ST DIST SOFT (STEREO DISTORTION SOFT) 75 19 V_DIST HARD (V DISTORTION HARD) 98 0 V_DIST SOFT (V DISTORTION SOFT) 98 2 AMP SIM (AMP SIMULATOR) 75 0 ST AMP1 (STEREO AMP SIMIULATOR 1) 75 20

Effect Name Type MSB Type LSB

14

ST AMP2 (STEREO AMP SIMIULATOR 2) 75 21 ST AMP3 (STEREO AMP SIMIULATOR 3) 75 8 DST+DELAY1 (DISTORTION+DELAY 1) 95 16 DST+DELAY2 (DISTORTION+DELAY 2) 95 0 OD+DELAY1 (OVERDRIVE+DELAY 1) 95 17 OD+DELAY2 (OVERDRIVE+DELAY 2) 95 1 CMP+DST+DLY1 (COMPRESSOR+DISTORTION+DELAY 1) 96 16 CMP+DST+DLY2 (COMPRESSOR+DISTORTION+DELAY 2) 96 0 CMP+OD+DLY1 (COMPRESSOR+OVERDRIVE+DELAY 1) 96 17 CMP+OD+DLY2 (COMPRESSOR+OVERDRIVE+DELAY 2) 96 1 V_DST H+DLY (V DISTORTION HARD+DELAY) 98 1 V_DST S+DLY (V DISTORTION SOFT+DELAY) 98 3 DST+TDLY (DISTORTION+TEMPO DELAY) 100 0 OD+TDLY (OVERDRIVE+TEMPO DELAY) 100 1 CMP+DST+TDL (COMPRESSOR+DISTORTION+TEMPO DELAY) 101 0 CMP+OD+TDLY (COMPRESSOR+OVERDRIVE+TEMPO DELAY) 101 1 V_DST H+TDLY (V DISTORTION HARD+TEMPO DELAY) 103 0 V_DST S+TDLY (V DISTORTION SOFT+TEMPO DELAY) 103 1 COMPRESSOR 83 0 NOISE GATE 84 0 VCE CANCEL 85 0 AMBIENCE 88 0 TALKING MOD 93 0 LO-FI 94 0 PHASER1 72 0 PHASER2 72 8 EP PHASER1 72 17 EP PHASER2 72 18 EP PHASER3 72 16 PITCH CHG1 (PITCH CHANGE 1) 80 16 PITCH CHG2 (PITCH CHANGE 2) 80 0 PITCH CHG3 (PITCH CHANGE 3) 80 1 ROTARY SP1 69 16 ROTARY SP2 71 17 ROTARY SP3 71 18 ROTARY SP4 70 17 ROTARY SP5 66 18 ROTARY SP6 69 0 2WAY ROT SP (2WAY ROTARY SP) 86 0 DST+ROT SP (DISTORTION+ROTARY SP) 69 1 DST+2ROT SP (DISTORTION+2WAY ROTARY SP) 86 1 OD+ROT SP (OVERDRIVE+ROTARY SP) 69 2 OD+2ROT SP (OVERDRIVE+2WAY ROTARY SP) 86 2 AMP+ROT SP (AMP SIMULATOR+ROTARY SP) 69 3 AMP+2ROT SP (AMP SIMULATOR+2WAY ROTARY SP) 86 3 DUAL ROT SP1 (DUAL ROTOR SPEAKER 1) 99 0 DUAL ROT SP2 (DUAL ROTOR SPEAKER 2) 99 1 AUTO PAN1 71 16 AUTO PAN2 71 0 EP AUTOPAN 71 21 TREMOLO1 70 16 TREMOLO2 71 19 TREMOLO3 70 0 EP TREMOLO 70 18 GT TREMOLO1 71 20 GT TREMOLO2 70 19 AUTO WAH1 78 16 AUTO WAH2 78 0 AT WAH+DST1 (AUTO WAH+DISTORTION 1) 78 17 AT WAH+DST2 (AUTO WAH+DISTORTION 2) 78 1 AT WAH+OD1 (AUTO WAH+OVERDRIVE 1) 78 18 AT WAH+OD2 (AUTO WAH+OVERDRIVE 2) 78 2 TOUCH WAH1 82 0 TOUCH WAH2 82 8 TC WAH+DST1 (TOUCH WAH+DISTORTION 1) 82 16 TC WAH+DST2 (TOUCH WAH+DISTORTION 2) 82 1 TC WAH+OD1 (TOUCH WAH+OVERDRIVE 1) 82 17 TC WAH+OD2 (TOUCH WAH+OVERDRIVE 2) 82 2 CLAVI TC WAH (CLAVI TOUCH WAH) 82 18 EP TC WAH (EP TOUCH WAH) 82 19 WH+DST+DLY1 (WAH+DISTORTION+DELAY 1) 97 16 WH+DST+DLY2 (WAH+DISTORTION+DELAY 2) 97 0 WH+DST+TDLY (WAH+DISTORTION+TEMPO DELAY) 102 0 WH+OD+DLY1 (WAH+OVERDRIVE+DELAY 1) 97 17 WH+OD+DLY2 (WAH+OVERDRIVE+DELAY 2) 97 1 WH+OD+TDLY (WAH+OVERDRIVE+TEMPO DELAY) 102 1 THRU 64 0 NO EFFECT 0 0

Effect Name Type MSB Type LSB

PSR-2100 Insertion1 – 3

HALL1 1 0 HALL2 1 16 HALL3 1 17 HALL4 1 18 HALL5 1 1 ROOM1 2 16 ROOM2 2 17 ROOM3 2 18 ROOM4 2 19 ROOM5 2 0 ROOM6 2 1 ROOM7 2 2 STAGE1 3 16 STAGE2 3 17 STAGE3 3 0 STAGE4 3 1 PLATE1 4 16 PLATE2 4 17 PLATE3 4 0 CHORUS1 66 17 CHORUS2 66 8 CHORUS3 66 16 CHORUS4 66 1 CHORUS5 65 2 CHORUS6 65 0 CHORUS7 65 1 CHORUS8 65 8 CELESTE1 66 0 CELESTE2 66 2 SYMPHONIC1 68 16 SYMPHONIC2 68 0 ENS DETUNE (ENSEMBLE DETUNE) 87 0 KARAOKE1 20 0 KARAOKE2 20 1 KARAOKE3 20 2 EQ DISCO 76 16 EQ TEL 76 17 2BAND EQ 77 0 3BAND EQ 76 0 HM ENHANCE1 (HARMONIC ENHANCER 1) 81 16 HM ENHANCE2 (HARMONIC ENHANCER 2) 81 0 FLANGER1 67 8 FLANGER2 67 16 FLANGER3 67 17 FLANGER4 67 1 FLANGER5 67 0 DELAY LCR1 5 16 DELAY LCR2 5 0 DELAY LR 6 0 ECHO 7 0 CROSS DELAY 8 0 TEMPO DELAY 21 0 TEMPO ECHO 21 8 TEMPO CROSS 22 0 DIST HEAVY 73 0 OVERDRIVE 74 0 DIST HARD (DISTORTION HARD) 75 16 DIST HARD2 75 22 DIST SOFT (DISTORTION SOFT) 75 17 DIST SOFT2 75 23 AMP SIM (AMP SIMULATOR) 75 0 ST AMP2 75 21 COMPRESSOR 83 0 NOISE GATE 84 0 PHASER1 72 0 EP PHASER1 72 17 EP PHASER2 72 18 EP PHASER3 72 16 ROTARY SP1 69 16 ROTARY SP2 71 17 ROTARY SP3 71 18 ROTARY SP4 70 17 ROTARY SP5 66 18 ROTARY SP6 69 0 ROTARY SP7 71 22 AUTO PAN1 71 16 AUTO PAN2 71 0 EP AUTOPAN 71 21 TREMOLO1 70 16 TREMOLO2 71 19 TREMOLO3 70 0 EP TREMOLO 70 18 GT TREMOLO1 71 20 GT TREMOLO2 70 19 AUTO WAH1 78 16 AUTO WAH2 78 0 TOUCH WAH1 82 0 TOUCH WAH2 82 8 THRU 64 0

Effect Name Type MSB Type LSB

15

PSR-1100 Variation

HALL1 1 0 HALL2 1 16 HALL3 1 17 HALL4 1 18 HALL5 1 1 ROOM1 2 16 ROOM2 2 17 ROOM3 2 18 ROOM4 2 19 ROOM5 2 0 ROOM6 2 1 ROOM7 2 2 STAGE1 3 16 STAGE2 3 17 STAGE3 3 0 STAGE4 3 1 PLATE1 4 16 PLATE2 4 17 PLATE3 4 0 CHORUS1 66 17 CHORUS2 66 8 CHORUS3 66 16 CHORUS4 66 1 CHORUS5 65 2 CHORUS6 65 0 CHORUS7 65 1 CHORUS8 65 8 CELESTE1 66 0 CELESTE2 66 2 SYMPHONIC1 68 16 SYMPHONIC2 68 0 KARAOKE1 20 0 KARAOKE2 20 1 KARAOKE3 20 2 ER1 9 0 ER2 9 1 GATE REVERB 10 0 REVERS GATE 11 0 EQ DISCO 76 16 EQ TEL 76 17 2BAND EQ 77 0 3BAND EQ 76 0 FLANGER1 67 8 FLANGER2 67 16 FLANGER3 67 17 FLANGER4 67 1 FLANGER5 67 0 DELAY LCR1 5 16 DELAY LCR2 5 0 DELAY LR 6 0 ECHO 7 0 CROSS DELAY 8 0 DIST HEAVY 73 0 OVERDRIVE 74 0 DIST HARD (DISTORTION HARD) 75 16 DIST HARD2 75 22 DIST HARD3 75 25 DIST SOFT (DISTORTION SOFT) 75 17 DIST SOFT2 75 23 AMP SIM (AMP SIMULATOR) 75 0 ST AMP2 75 21 ST AMP3 75 24 PHASER1 72 0 PHASER2 72 8 EP PHASER1 72 17 EP PHASER2 72 16 ROTARY SP1 69 16 ROTARY SP2 71 17 ROTARY SP3 71 18 ROTARY SP4 70 17 ROTARY SP5 66 18 ROTARY SP6 69 0 ROTARY SP7 71 22 ROTARY SP8 69 17 ROTARY SP9 66 19 ROTARY SP10 71 25 AUTO PAN1 71 16 AUTO PAN2 71 0 AUTO PAN3 71 23 EP AUTOPAN 71 21 EP AUTOPAN2 71 24 TREMOLO1 70 16 TREMOLO2 71 19 TREMOLO3 70 0 TREMOLO4 70 20 EP TREMOLO 70 18 EP TREMOLO2 70 21 GT TREMOLO1 71 20 AUTO WAH1 78 16 AUTO WAH2 78 0 AUTO WAH3 78 19 AUTO WAH4 78 20 THRU 64 0

Effect Name Type MSB Type LSB

16

Effect Parameter List / Liste der Effektparameter / Liste des paramètres d’effets / Lista de parámetros de efectos

If a table has no LSB number specified, the table applies for any LSB numbers. Parameters marked with a ● in the Control column can be controlled from an AC1 (assignable controller 1) etc. However, this is valid only for a Variation effect (when selected for Insertion).

MSB = 1 MSB = 2 MSB = 3 MSB = 4

No. Parameter Display Value See Table Control

1 Reverb Time 0.3 – 30.0s 0 – 69 table#4 2Diffusion 0 – 10 0 – 10 3Initial Delay 0.1mS – 99.3mS 0 – 63 table#5 4 HPF Cutoff Thru – 8.0kHz 0 – 52 table#3 5 LPF Cutoff 1.0k – Thru 34 – 60 table#3 6 7 8 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 Rev Delay 0.1mS – 99.3mS 0 – 63 table#5 12 Density 0 – 4 (rev, var) 0 – 4

13 Er/Rev Balance E63>R – E=R – E<R63 1 – 127 14 High Damp (*1) 0.1 – 1.0 1 – 10 15 Feedback Level -63 – +63 1 – 127 16

0 – 2 (ins1-3) (*1) 0 – 2

MSB = 5

No. Parameter Display Value See Table Control

1 Lch Delay 0.1 – 1486.0ms (*2) 1 – 14860

2 Rch Delay 0.1 – 1486.0ms (*2) 1 – 14860

3 Cch Delay 0.1 – 1486.0ms (*2) 1 – 14860

4 Feedback Delay 0.1 – 1486.0ms (*2) 1 – 14860

5 Feedback Level -63 – +63 1 – 127 6 Cch Level 0 – 127 0 – 127 7High Damp 0.1 – 1.0 1 – 10 8 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 12 13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 14 EQ Low Gain -12 – +12dB 52 – 76 15 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 16 EQ High Gain -12 – +12dB 52 – 76

0.1 – 715.0ms (*3) 1 – 7150

MSB = 6

No. Parameter Display Value See Table Control

1 Lch Delay 0.1 – 1486.0ms (*2) 1 – 14860

2 Rch Delay 0.1 – 1486.0ms (*2) 1 – 14860

3 Feedback Delay 1 0.1 – 1486.0ms (*2) 1 – 14860

4 Feedback Delay 2 0.1 – 1486.0ms (*2) 1 – 14860

5 Feedback Level -63 – +63 1 – 127 6High Damp 0.1 – 1.0 1 – 10 7 8 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 12 13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 14 EQ Low Gain -12 – +12dB 52 – 76 15 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 16 EQ High Gain -12 – +12dB 52 – 76

0.1 – 715.0ms (*3) 1 – 7150

MSB = 7

No. Parameter Display Value See Table Control

1 Lch Delay1 0.1 – 743.0ms (*2) 1 – 7430

2 Lch Feedback Level -63 – +63 1 – 127 3 Rch Delay1 0.1 – 743.0ms (*2) 1 – 7430

4 Rch Feedback Level -63 – +63 1 – 127 5High Damp 0.1 – 1.0 1 – 10 6 Lch Delay2 0.1 – 743.0ms (*2) 1 – 7430

7 Rch Delay2 0.1 – 743.0ms (*2) 1 – 7430

8 Delay2 Level 0 – 127 0 – 127 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 12 13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 14 EQ Low Gain -12 – +12dB 52 – 76 15 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 16 EQ High Gain -12 – +12dB 52 – 76

0.1 – 355.0ms (*3) 1 – 3550

MSB = 8

No. Parameter Display Value See Table Control

→R Delay 0.1 – 743.0ms (*2) 1 – 7430

1L

2R

→L Delay 0.1 – 743.0ms (*2) 1 – 7430

3 Feedback Level -63 – +63 1 – 127 4Input Select L, R, L&R 0 – 2 5High Damp 0.1 – 1.0 1 – 10 6 7 8 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 12 13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 14 EQ Low Gain -12 – +12dB 52 – 76 15 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 16 EQ High Gain -12 – +12dB 52 – 76

0.1 – 355.0ms (*3) 1 – 3550

MSB = 9

No. Parameter Display Value See Table Control

1 Type S-H, L-H, Rdm, Rvs, Plt, Spr 0 – 5 2 Room Size 0.1 – 7.0 0 – 44 table#6 3Diffusion 0 – 10 0 – 10 4Initial Delay 0.1mS – 200.0mS 0 – 127 table#5 5 Feedback Level -63 – +63 1 – 127 6 HPF Cutoff Thru – 8.0kHz 0 – 52 table#3 7 LPF Cutoff 1.0k – Thru 34 – 60 table#3 8 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 Liveness 0 – 10 0 – 10 12 Density 0 – 3 0 – 3 13 High Damp 0.1 – 1.0 1 – 10 14 15 16

MSB = 10 MSB = 11

No. Parameter Display Value See Table Control

1 Type TypeA,TypeB 0 – 1 2 Room Size 0.1 – 7.0 0 – 44 table#6 3Diffusion 0 – 10 0 – 10 4Initial Delay 0.1mS – 200.0mS 0 – 127 table#5 5 Feedback Level -63 – +63 1 – 127 6 HPF Cutoff Thru – 8.0kHz 0 – 52 table#3 7 LPF Cutoff 1.0k – Thru 34 – 60 table#3 8 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 Liveness 0 – 10 0 – 10 12 Density 0 – 3 0 – 3 13 High Damp 0.1 – 1.0 1 – 10 14 15 16

MSB = 16 MSB = 17 MSB = 18 MSB = 19

No. Parameter Display Value See Table Control

1 Reverb Time 0.3 – 30.0s 0 – 69 table#4 2Diffusion 0 – 10 0 – 10 3Initial Delay 0.1mS – 99.3mS 0 – 63 table#5 4 HPF Cutoff Thru – 8.0kHz 0 – 52 table#3 5 LPF Cutoff 1.0k – Thru 34 – 60 table#3 6Width 0.5 – 10.2m 0 – 37 table#11 7 Heigt 0.5 – 20.2m 0 – 73 table#11 8 Depth 0.5 – 30.2m 0 – 104 table#11 9Wall Vary 0 – 30 0 – 30

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 Rev Delay 0.1mS – 99.3mS 0 – 63 table#5 12 Density (*1) 0 – 4 0 – 4 13 Er/Rev Balance (*1) E63>R – E=R – E<R63 1 – 127 14 High Damp (*1) 0.1 – 1.0 1 – 10 15 Feedback Level (*1) -63 – +63 1 – 127 16

17

MSB = 20

No. Parameter Display Value See Table Control

1 Delay Time 0.1mS – 400.0mS 0 – 127 table#7 2 Feedback Level -63 – +63 1 – 127 3 HPF Cutoff Thru – 8.0kHz 0 – 52 table#3 4 LPF Cutoff 1.0k – Thru 34 – 60 table#3 5 6 7 8 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 12 13 14 15 16

MSB = 68

No. Parameter Display Value See Table Control

1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 2 LFO Depth 0 – 127 0 – 127 3 Delay Offset 0.0mS – 50mS 0 – 127 table#2 4 5 6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 9 EQ High Gain -12 – +12dB 52 – 76

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3 12 EQ Mid Gain (*4) -12 – +12dB 52 – 76 13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120 14 15 16

MSB = 21

No. Parameter Display Value See Table Control

1 Delay Time 64th/3 – 4thx6 0 – 19 table#14 2 Feedback Level -63 – +63 1 – 127 3 Feedback High Dump 0 – 1.0 0 – 10 4L/R Diffusion 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127 5 Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127 6 7 8 9

10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127 ●

11 12 13 EQ Low Frequency 32 – 2.0kH 4 – 40 14 EQ Low Gain -12 – +12dB 52 – 76 15 EQ High Frequency 500 – 16.0kHz 28 – 58 16 EQ High Gain -12 – +12dB 52 – 76

MSB = 22

No. Parameter Display Value See Table Control

1 Delay Time L>R 64th/3 – 4thx6 0 – 19 table#14 2 Delay Time R>L 64th/3 – 4thx6 0 – 19 table#14 3 Feedback Level -63 – +63 1 – 127 4Input Select L, R, L&R 0 – 2 5 Feedback High Dump 0 – 1.0 0 – 10 6 Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127 7 8 9

10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127 ●

11 12 13 EQ Low Frequency 32 – 2.0kH 4 – 40 14 EQ Low Gain -12 – +12dB 52 – 76 15 EQ High Frequency 500 – 16.0kHz 28 – 58 16 EQ High Gain -12 – +12dB 52 – 76

MSB = 65 MSB = 66

No. Parameter Display Value See Table Control

1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 2 LFO Depth 0 – 127 0 – 127 3 Feedback Level -63 – +63 1 – 127 4 Delay Offset 0.0mS – 50mS 0 – 127 table#2 5 6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 9 EQ High Gain -12 – +12dB 52 – 76

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3 12 EQ Mid Gain (*4) -12 – +12dB 52 – 76 13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120 14 15 Input Mode mono/stereo 0 – 1 16

MSB = 69, LSB = 0, 16, 17

No. Parameter Display Value See Table Control

1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 ● 2 LFO Depth 0 – 127 0 – 127 3 4 5 6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 9 EQ High Gain -12 – +12dB 52 – 76

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127

11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3 12 EQ Mid Gain (*4) -12 – +12dB 52 – 76 13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120 14 15 16

MSB = 69, LSB = 1 MSB = 69, LSB = 2

No. Parameter Display Value See Table Control

1 LFO Frequenct 0.0 – 39.7Hz 0 – 127 ● 2 LFO Depth 0 – 127 0 – 127 3 4 5 6 EQ Low Frequency 32 – 2.0kHz 4 – 40 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500 – 16.0kHz 28 – 58 9 EQ High Gain -12 – +12dB 52 – 76

10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127

11 12 13 14 Drive 0 – 127 0 – 127 15 LPF Cuttoff 1kHz – Thru 34 – 60 16 Output Level 0 – 127 0 – 127

MSB = 69, LSB = 3

No. Parameter Display Value See Table Control

1 LFO Frequenct 0.0 – 39.7Hz 0 – 127 ● 2 LFO Depth 0 – 127 0 – 127 3 AMP Type Off, Stack, Combo, Tube 0 – 3 4 5 6 EQ Low Frequency 32 – 2.0kHz 4 – 40 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500 – 16.0kHz 28 – 58 9 EQ High Gain -12 – +12dB 52 – 76

10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127

11 12 13 14 Drive 0 – 127 0 – 127 15 LPF Cuttoff 1kHz – Thru 34 – 60 16 Output Level 0 – 127 0 – 127

MSB = 67

No. Parameter Display Value See Table Control

1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 2 LFO Depth 0 – 127 0 – 127 3 Feedback Level -63 – +63 1 – 127 4 Delay Offset 0.0mS – 50mS 0 – 127 table#2 5 6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 9 EQ High Gain -12 – +12dB 52 – 76

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3 12 EQ Mid Gain (*4) -12 – +12dB 52 – 76 13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120 14 LFO Phase Difference -180 – +180deg (resolution=3deg.) 4 – 124 15 16

MSB = 70

No. Parameter Display Value See Table Control

1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 ● 2 AM Depth 0 – 127 0 – 127 3 PM Depth 0 – 127 0 – 127 4 5 6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 9 EQ High Gain -12 – +12dB 52 – 76

10

11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3 12 EQ Mid Gain (*4) -12 – +12dB 52 – 76 13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120 14 LFO Phase Difference -180 – +180deg (resolution=3deg.) 4 – 124 15 Input Mode mono/stereo 0 – 1 16

18

MSB = 71

No. Parameter Display Value See Table Control

1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 ● 2L/R Depth 0 – 127 0 – 127 3F/R Depth 0 – 127 0 – 127 4 PAN Direction L 5 6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 9 EQ High Gain -12 – +12dB 52 – 76

10

11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3 12 EQ Mid Gain (*4) -12 – +12dB 52 – 76 13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120 14 15 16

↔R, L→R, L←R, Lturn, Rturn, L/R 0 – 5

MSB = 72, LSB = 0, 16, 17, 18

No. Parameter Display Value See Table Control

1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 2 LFO Depth 0 – 127 0 – 127 3 Phase Shift Offset 0 – 127 0 – 127 4 Feedback Level -63 – +63 1 – 127 5 6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 9 EQ High Gain -12 – +12dB 52 – 76

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 Stage 4, 5, 6 (*5) 4 – 6

12 Diffusion (*1) mono/stereo 0 – 1 13 14 15 16

4 – 12 (*4) 4 – 12 6, 7, 8, 9, 10 (*6) 6 – 10

MSB = 72, LSB = 8

No. Parameter Display Value See Table Control

1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 2 LFO Depth 0 – 127 0 – 127 3 Phase Shift Offset 0 – 127 0 – 127 4 Feedback Level -63 – +63 1 – 127 5 6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 9 EQ High Gain -12 – +12dB 52 – 76

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 Stage 3, 4, 5, 6 (*1) 3 – 6

12 13 LFO Phase Difference -180deg – +180deg (resolution=3deg.) 4 – 124 14 15 16

MSB = 73, LSB = 0 MSB = 74

No. Parameter Display Value See Table Control

1 Drive 0 – 127 0 – 127 ● 2 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 3 EQ Low Gain -12 – +12dB 52 – 76 4 LPF Cutoff 1.0k – Thru 34 – 60 table#3 5 Output Level 0 – 127 0 – 127 6 7 EQ Mid Frequency 100Hz – 10.0kHz 14 – 54 table#3 8 EQ Mid Gain -12 – +12dB 52 – 76 9 EQ Mid Width 1.0 – 12.0 10 – 120

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127

11 Edge (Clip Curve) 0 (mild) – 127 (sharp) 0 – 127 12 13 14 15 16

3, 4, 5 (*6) 3 – 5

MSB = 73, LSB = 1, 16

No. Parameter Display Value See Table Control

1 Drive 0 – 127 0 – 127 ● 2 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 3 EQ Low Gain -12 – +12dB 52 – 76 4 LPF Cutoff 1.0k – Thru 34 – 60 table#3 5 Output Level 0 – 127 0 – 127 6 7 EQ Mid Frequency 100Hz – 10.0kHz 14 – 54 table#3 8 EQ Mid Gain -12 – +12dB 52 – 76 9 EQ Mid Width 1.0 – 12.0 10 – 120

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127

11 Edge (Clip Curve) 0 (mild) – 127 (sharp) 0 – 127 12 Attack 1ms – 40ms 0 – 19 table#8 13 Release 10ms – 680ms 0 – 15 table#9 14 Threshold -48dB – -6dB 79 – 121 15 Ratio 1.0 – 20.0 0 – 7 table#10 16

MSB = 73, LSB = 8 MSB = 74, LSB = 8

No. Parameter Display Value See Table Control

1 Drive 0 – 127 0 – 127 ● 2 EQ Low Frequency 32 – 2.0kHz 4 – 40 table#3 3 EQ Low Gain -12 – +12dB 52 – 76 4 LPF Cuttoff 1kHz – Thru 34 – 60 5 Output Level 0 – 127 6 7 EQ Mid Frequency 100 – 10.0kHz 14 – 54 table#3 8 EQ Mid Gain -12 – +12dB 52 – 76 9 EQ Mid Width 1 – 12 10 – 120

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127

11 Edge (Clip Curve) 0 – 127 0 – 127 12 13 14 15 16

MSB = 75

No. Parameter Display Value See Table Control

1 Drive 0 – 127 0 – 127 ● 2 AMP Type Off, Stack, Combo, Tube 0 – 3 3 LPF Cutoff 1.0k – Thru 34 – 60 table#3 4 Output Level 0 – 127 0 – 127 5 6 7 8 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127

11 Edge (Clip Curve) 0 (mild) – 127 (sharp) 0 – 127 12 13 14 15 16

MSB = 76

No. Parameter Display Value See Table Control

1 EQ Low Gain -12 – +12dB 52 – 76 2 EQ Mid Frequency 100Hz – 10.0kHz 14 – 54 table#3 3 EQ Mid Gain -12 – +12dB 52 – 76 4 EQ Mid Width 1.0 – 12.0 10 – 120 5 EQ High Gain -12 – +12dB 52 – 76 6 EQ Low Frequency 50Hz – 2.0kHz 8 – 40 table#3 7 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 8 9

10

11 12 13 14 15 Input Mode mono/stereo 0 – 1 16

MSB = 77

No. Parameter Display Value See Table Control

1 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 2 EQ Low Gain -12 – +12dB 52 – 76 3 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 4 EQ High Gain -12 – +12dB 52 – 76 5 6 7 8 9

10

11 12 13 14 15 16

MSB = 78, LSB = 0, 16, 19, 20

No. Parameter Display Value See Table Control

1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 2 LFO Depth 0 – 127 0 – 127 3 Cutoff Frequency Offset 0 – 127 0 – 127 ● 4 Resonance 1.0 – 12.0 10 – 120 5 6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 9 EQ High Gain -12 – +12dB 52 – 76

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127

11 Drive (*4) 0 – 127 0 – 127 12 13 14 15 16

19

MSB = 78, LSB = 1, 17 MSB = 78, LSB = 2, 18

No. Parameter Display Value See Table Control

1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 2 LFO Depth 0 – 127 0 – 127 3 Cutoff Frequency Offset 0 – 127 0 – 127 ● 4 Resonance 1.0 – 12.0 10 – 120 5 6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 9 EQ High Gain -12 – +12dB 52 – 76

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127

11 Drive 0 – 127 0 – 127 12 EQ Low Gain (distortion) -12 – +12dB 52 – 76 13 EQ Mid Gain (distortion) -12 – +12dB 52 – 76 14 LPF Cutoff 1.0kHz – thru 34 – 60 table#3 15 Output Level 0 – 127 0 – 127 16

MSB = 82, LSB = 8 MSB = 82, LSB = 2, 17, 18, 19

No. Parameter Display Value See Table Control

1 Sensitive 0 – 127 0 – 127 2 Cutoff Frequency Offset 0 – 127 0 – 127 ● 3 Resonance 1.0 – 12.0 10 – 120 4 5 6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 9 EQ High Gain -12 – +12dB 52 – 76

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127

11 Drive 0 – 127 (*4) 0 – 127 12 EQ Low Gain(distortion) -12 – +12dB (*4) 52 – 76 13 EQ Mid Gain(distortion) -12 – +12dB (*4) 52 – 76 14 LPF Cutoff 1.0kHz – thru (*4) 34 – 60 table#3 15 Output Level 0 – 127 (*4) 0 – 127 16 Release 10 – 680mS (*4) 52 – 67 table#12

MSB = 80, LSB = 0, 16

No. Parameter Display Value See Table Control

1Pitch -24 – +24 40 – 88 2Initial Delay 0.1mS – 400.0mS 0 – 127 table#7 3Fine 1 -50 – +50 14 – 114 4Fine 2 -50 – +50 14 – 114 5 Feedback Level -63 – +63 1 – 127 6 7 8 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 Pan 1 L63 – R63 1 – 127 12 Output Level 1 0 – 127 0 – 127 13 Pan 2 L63 – R63 1 – 127 14 Output Level 2 0 – 127 0 – 127 15 16

MSB = 80, LSB = 1

No. Parameter Display Value See Table Control

1Pitch -24 – +24 40 – 88 2Initial Delay 0.1mS – 400.0mS 0 – 127 table#7 3Fine 1 -50 – +50cent 14 – 114 4Fine 2 -50 – +50cent 14 – 114 5 Feedback Level -63 – +63 1 – 127 6 7 8 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 Pan 1 L63 – R63 1 – 127 12 Output Level 1 0 – 127 0 – 127 13 Pan 2 L63 – R63 1 – 127 14 Output Level 2 0 – 127 0 – 127 15 16

MSB = 81

No. Parameter Display Value See Table Control

1 HPF Cutoff 500Hz – 16.0kHz 28 – 58 2 Drive 0 – 127 0 – 127 3Mix Level 0 – 127 0 – 127 4 5 6 7 8

9 10 11 12 13 14 15 16

MSB = 82, LSB = 0 MSB = 82, LSB = 1, 16

No. Parameter Display Value See Table Control

1 Sensitive 0 – 127 0 – 127

2 Cutoff Frequency Offset 0 – 127 0 – 127 ●

3 Resonance 1.0 – 12.0 10 – 120

4

5

6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3

7 EQ Low Gain -12 – +12dB 52 – 76

8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3

9 EQ High Gain -12 – +12dB 52 – 76 10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127

11 Drive 0 – 127 (var/ins1-4 block) 0 – 127 12 13 14 15 16

MSB = 83

No. Parameter Display Value See Table Control

1Attack 1 – 40ms 0 – 19 table#8 2 Release 10 – 680ms 0 – 15 table#9 3 Threshold -48 – -6dB 79 – 121 4 Ratio 1.0 – 20.0 0 – 7 table#10 5 Output Level 0 – 127 0 – 127 6 7 8 9

10

11 12 13 14 15 16

MSB = 84

No. Parameter Display Value See Table Control

1Attack 1 – 40ms 0 – 19 table#8 2 Release 10 – 680ms 0 – 15 table#9 3 Threshold -72 – -30dB 55 – 97 4 Output Level 0 – 127 0 – 127 5 6 7 8 9

10

11 12 13 14 15 16

MSB = 85

No. Parameter Display Value See Table Control

1 2 3 4 5 6 7 8 9

10

11 Low Adjust 0 – 26 0 – 26 12 High Adjust 0 – 26 0 – 26 13 14 15 16

MSB = 86, LSB = 0

No. Parameter Display Value See Table Control

1 Rotor Speed 0.0Hz – 39.7Hz 0 – 127 table#1 ● 2 Drive Low 0 – 127 0 – 127 3 Drive High 0 – 127 0 – 127 4 Low/High L63>H – L=H – L<H63 1 – 127 5 6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3 7 EQ Low Gain -12 – +12dB 52 – 76 8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3 9 EQ High Gain -12 – +12dB 52 – 76

10

11 Crossover Frequency 100Hz – 10.0kHz 14 – 54 table#3 12 Mic L-R Angle 0deg – 180deg (resolution=3deg.) 0 – 60 13 14 15 16

20

MSB = 86, LSB = 1 MSB = 86, LSB = 2

No. Parameter Display Value See Table Control

1 Rotor Speed 0.0 – 39.7Hz 0 – 127 ●

2 Drive Low 0 – 127 0 – 127

3 Drive High 0 – 127 0 – 127

4 Low/High Balance L63>H – L=H – L<H=63 1 – 127

5

6 EQ Low Frequency 32 – 2.0kHz 4 – 40

7 EQ Low Gain -12 – +12dB 52 – 76

8 EQ High Frequency 500 – 16.0kHz 28 – 58

9 EQ High Gain -12 – +12dB 52 – 76 10

11 Crossover Frequency 100 – 10.0kHz 14 – 54 12 Mic L-R Angle 0 – 180deg 0 – 60 13 14 Drive 0 – 127 15 LPF Cuttoff 1kHz – Thru 34 – 60 16 Output Level 0 – 127

MSB = 86, LSB = 3

No. Parameter Display Value See Table Control

1 Rotor Speed 0.0 – 39.7Hz 0 – 127 ●

2 Drive Low 0 – 127 0 – 127

3 Drive High 0 – 127 0 – 127

4 Low/High Balance L63>H – L=H – L<H=63 1 – 127

5

6 EQ Low Frequency 32 – 2.0kHz 4 – 40

7 EQ Low Gain -12 – +12dB 52 – 76

8 EQ High Frequency 500 – 16.0kHz 28 – 58

9 EQ High Gain -12 – +12dB 52 – 76 10

11 Crossover Frequency 100 – 10.0kHz 14 – 54 12 Mic L-R Angle 0 – 180deg 0 – 60 13 AMP Type 14 Drive 0 – 127 15 LPF Cuttoff 1kHz – Thru 34 – 60 16 Output Level 0 – 127

Off, Stack, Combo, Tube (AMPSIM only)

0 – 3

MSB = 87

No. Parameter Display Value See Table Control

1 Detune -50 – +50cent 14 – 114

2 Lch Init Delay 0.0mS – 50mS 0 – 127 table#2

3 Rch Init Delay 0.0mS – 50mS 0 – 127 table#2

4

5

6

7

8

9 10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 EQ Low Frequency 32Hz – 2.0kHz (variation, insertion block) 4 – 40 table#3 12 EQ Low Gain -12 – +12dB (variation, insertion block) 52 – 76 13 EQ High Frequency 500Hz – 16.0kHz (variation, insertion

14 EQ High Gain -12 – +12dB (variation, insertion block) 52 – 76 15 16

block)

28 – 58 table#3

MSB = 88

No. Parameter Display Value See Table Control

1 Delay Time 0.0mS – 50mS 0 – 127 table#2

2 Output Phase normal/invers 0 – 1

3

4

5

6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3

7 EQ Low Gain -12 – +12dB 52 – 76

8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3

9 EQ High Gain -12 – +12dB 52 – 76 10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 12 13 14 15 16

MSB = 93

No. Parameter Display Value See Table Control

1 Vowel a, i, u, e, o 0 – 4 ●

2 Move speed 1 – 62 1 – 62

3 Drive 0 – 127 0 – 127

4 Output Level 0 – 127 0 – 127

5

6

7

8

9 10

11 12 13 14 15 16

MSB = 94

No. Parameter Display Value See Table Control

1 Sampling Freq Control 44.1kHz – 345Hz 0 – 127 table#13 2Word Length 1 – 127 1 – 127 3 Output Gain -6 – +12dB 0 – 18 4 LPF Cutoff 63Hz – Thru 10 – 60 table#3 5Filter Type Thru, PowerBass, Radio, Tel, Clean, Low 0 – 5 6 LPF Resonance 1.0 – 12.0 10 – 120 7Bit Assign 0 – 6 0 – 6 8 Emphasis Off/On 0 – 1 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 12 13 14 15 Input Mode mono/stereo 16

MSB = 95

No. Parameter Display Value See Table Control

1 Lch Delay Time 0.1 – 1486.0ms 1 – 14860 2 Rch Delay Time 0.1 – 1486.0ms 1 – 14860 3 Delay Feedback Time 0.1 – 1486.0ms 1 – 14860 4 Delay Feedback Level -63 – +63 1 – 127 5 Delay Mix 0 – 127 0 – 127 6Dist Drive 0 – 127 0 – 127 7Dist Output Level 0 – 127 0 – 127 8Dist EQ Low Gain -12 – +12dB 52 – 76 9Dist EQ Mid Gain -12 – +12dB 52 – 76

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 12 13 14 15 16

MSB = 96

No. Parameter Display Value See Table Control

1 Delay Time 0.1 – 1486.0ms 1 – 14860 2 Delay Feedback Level -63 – +63 1 – 127 3 Delay Mix 0 – 127 0 – 127 4Dist Drive 0 – 127 0 – 127 5Dist Output Level 0 – 127 0 – 127 6Dist EQ Low Gain -12 – +12dB 52 – 76 7Dist EQ Mid Gain -12 – +12dB 52 – 76 8 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 Comp. Attack 1ms – 40ms 0 – 19 table#8 12 Comp. Release 10ms – 680ms 0 – 15 table#9 13 Comp. Threshold -48dB – -6dB 79 – 121 14 Comp. Ratio 1.0 – 20.0 0 – 7 table#10 15 16

MSB = 97

No. Parameter Display Value See Table Control

1 Delay Time 0.1 – 1486.0ms 1 – 14860 2 Delay Feedback Level -63 – +63 1 – 127 3 Delay Mix 0 – 127 0 – 127 4Dist Drive 0 – 127 0 – 127 5Dist Output Level 0 – 127 0 – 127 6Dist EQ Low Gain -12 – +12dB 52 – 76 7Dist EQ Mid Gain -12 – +12dB 52 – 76 8 9

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 Wah Sensitive 0 – 127 0 – 127 12 Wah Cutoff Freq Offset 0 – 127 0 – 127 13 Wah Resonance 1.0 – 12.0 10 – 120 14 Wah Release 10 – 680ms 52 – 67 table#12 15 16

MSB = 98, LSB = 0 MSB = 98, LSB = 2

No. Parameter Display Value See Table Control

1 Overdrive 0 – 100% 0 – 100 2 Device Transister/Vintage Tube/ 0 – 4

3 Speaker Flat/Stack/Combo/Twin/ 0 – 5

4 Presence 0 – 20 0 – 20 5 Output Level 0 – 100% 0 – 100 6 7 8 9

10 Dry/Wet Balance Balance D63>W – D=W – D<W63 1 – 127 ●

11 12 13 14 15 16

Dist1/Dist2/Fuzz

Radio/Megaphone

21

MSB = 98, LSB = 1 MSB = 98, LSB = 3

No. Parameter Display Value See Table Control

1 Overdrive 0 – 100% 0 – 100

2 Device Transister/Vintage Tube/ 0 – 4

3 Speaker Flat/Stack/Combo/Twin/ 0 – 5

4 Presence 0 – 20 0 – 20

5 Output Level 0 – 100% 0 – 100

6 Delay Time L 0.1ms – 1486.0ms 1 – 14860

7 Delay Time R 0.1ms – 1486.0ms 1 – 14860

8 Delay Feedback Time 0.1ms – 1486.0ms 1 – 14860

9 Delay Feedback Level -63 – +63 1 – 127 10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 Delay Mix 0 – 127 0 – 127 12 13 14 15 16

Dist1/Dist2/Fuzz

Radio/Megaphone

MSB = 99

No. Parameter Display Value See Table Control

1 Rotor Speed Slow 0.0 – 2.65Hz 0 – 63 table#1

2 Horn Speed Slow 0.0 – 2.65Hz 0 – 63 table#1

3 Rotor Speed Fast 2.69 – 39.7Hz 64 – 127 table#1

4 Horn Speed Fast 2.69 – 39.7Hz 64 – 127 table#1

5Slow-Fast Time of R 0 – 127 0 – 127

6Slow-Fast Time of H 0 – 127 0 – 127

7 Drive Low 0 – 127 0 – 127

8 Drive High 0 – 127 0 – 127

9 Low/High Balance L63>H – L=H – L<H=63 1 – 127 10

11 EQ Low Frequency 32 – 2.0kH 4 – 40 table#3 12 EQ Low Gain -12 – +12dB 52 – 76 13 EQ High Frequency 500 – 16.0kHz 28 – 58 table#3 14 EQ High Gain -12 – +12dB 52 – 76 15 Mic L-R Angle 0 – 180deg 0 – 60 16 Speed Control Slow/Fast 0/1 ●

MSB = 100

No. Parameter Display Value See Table Control

1 Delay Time 64th/3 – 4thx6 0 – 19 table#14

2 Delay Feedback Level -63 – +63 1 – 127

3 Delay Mix 0 – 127 0 – 127

4Dist Drive 0 – 127 0 – 127

5Dist Output Level 0 – 127 0 – 127

6Dist EQ Low Gain -12 – +12dB 52 – 76

7Dist EQ High Gain -12 – +12dB 52 – 76

8L/R Diffusion 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127

9 Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127 10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127 ●

11 12 13 14 15 16

MSB = 101

No. Parameter Display Value See Table Control

1 Delay Time 64th/3 – 4thx6 0 – 19 table#14

2 Delay Feedback Level -63 – +63 1 – 127

3 Delay Mix 0 – 127 0 – 127

4Dist Drive 0 – 127 0 – 127

5Dist Output Level 0 – 127 0 – 127

6Dist EQ Low Gain -12 – +12dB 52 – 76

7Dist EQ High Gain -12 – +12dB 52 – 76

8L/R Diffusion 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127

9 Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127 10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127 ●

11 Comp. Attack 1ms – 40ms 0 – 19 12 Comp. Release 10ms – 680ms 0 – 15 13 Comp. Threshold -48dB – -6dB 79 – 121 14 Comp. Ratio 1.0 – 20.0 0 – 7 15 16

MSB = 103

No. Parameter Display Value See Table Control

1 Overdrive 0 – 100% 0 – 100 2 Device Transister/Vintage Tube/ 0 – 4

3 Speaker Flat/Stack/Combo/Twin/ 0 – 5

4 Presence 0 – 20 0 – 20 5 Output Level 0 – 100% 0 – 100 6 Delay Time 64th/3 – 4thx6 0 – 19 table#14 7 Delay Feedback Level -63 – +63 1 – 127 8L/R Diffusion 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127 9 Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127

10 Dry/Wet Balance D63>W – D=W – D<W63 1 – 127 ●

11 Delay Mix 0 – 127 0 – 127 12 13 14 15 16

Dist1/Dist2/Fuzz

Radio/Megaphone

MSB = 0

No. Parameter Display Value See Table Control

1 2 3 4 5 6 7 8 9

10

11 12 13 14 15 16

MSB = 64

No. Parameter Display Value See Table Control

1 2 3 4 5 6 7 8 9

10

11 12 13 14 15 16

Parameter 10 Dry/Wet Balance only affects insertion type effects. *1

PSR-2100 only *2

PSR-2100: Variation *3

PSR-2100: Insertion 1 – 3 PSR-1100: Variation

*4 PSR-2100 Variation only

*5 PSR-2100 Chorus, Insertion only

*6 PSR-1100 only

MSB = 102

No. Parameter Display Value See Table Control

1 Delay Time 64th/3 – 4thx6 0 – 19 table#14

2 Delay Feedback Level -63 – +63 1 – 127

3 Delay Mix 0 – 127 0 – 127

4Dist Drive 0 – 127 0 – 127

5Dist Output Level 0 – 127 0 – 127

6Dist EQ Low Gain -12 – +12dB 52 – 76

7Dist EQ High Gain -12 – +12dB 52 – 76

8L/R Diffusion 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127

9 Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127 10 Dry/Wet Balance D63>W – D=W – D<W=63 1 – 127 ●

11 Wah Sensitive 0 – 127 0 – 127 12 Wah Cutoff Freq Offset 0 – 127 0 – 127 13 Wah Resonance 1.0 – 12.0 10 – 120 14 Wah Release 10 – 680mS 52 – 67 15 16

22

Effect Data Assign Table / Effektdaten-Zuordnungstabelle / Tableau d’assignation des données d’effets / Tabla de asignación de datos para efectos

Table#1 LFO Frequency

Data Value Data Value Data Value Data Value

00.00 321.35 642.69968.41

10.04 331.39 652.78978.75

20.08 341.43 662.86989.08

30.13 351.47 672.94999.42

40.17 361.51 683.03100 9.76

50.21 371.56 693.11101 10.1

60.25 381.60 703.20102 10.8

70.29 391.64 713.28103 11.4

80.34 401.68 723.37104 12.1

90.38 411.72 733.45105 12.8 10 0.42 42 1.77 74 3.53 106 13.5 11 0.46 43 1.81 75 3.62 107 14.1 12 0.51 44 1.85 76 3.70 108 14.8 13 0.55 45 1.89 77 3.87 109 15.5 14 0.59 46 1.94 78 4.04 110 16.2 15 0.63 47 1.98 79 4.21 111 16.8 16 0.67 48 2.02 80 4.37 112 17.5 17 0.72 49 2.06 81 4.54 113 18.2 18 0.76 50 2.10 82 4.71 114 19.5 19 0.80 51 2.15 83 4.88 115 20.9 20 0.84 52 2.19 84 5.05 116 22.2 21 0.88 53 2.23 85 5.22 117 23.6 22 0.93 54 2.27 86 5.38 118 24.9 23 0.97 55 2.31 87 5.55 119 26.2 24 1.01 56 2.36 88 5.72 120 27.6 25 1.05 57 2.40 89 6.06 121 28.9 26 1.09 58 2.44 90 6.39 122 30.3 27 1.14 59 2.48 91 6.73 123 31.6 28 1.18 60 2.52 92 7.07 124 33.0 29 1.22 61 2.57 93 7.40 125 34.3 30 1.26 62 2.61 94 7.74 126 37.0 31 1.30 63 2.65 95 8.08 127 39.7

Table#4 Reverb Time

Data Value Data Value Data Value

00.3323.5 64 17.0

10.4333.6 65 18.0

20.5343.7 66 19.0

30.6353.8 67 20.0

40.7363.9 68 25.0

50.8374.0 69 30.0

60.9384.1

71.0394.2

81.1404.3

91.2414.4 10 1.3 42 4.5 11 1.4 43 4.6 12 1.5 44 4.7 13 1.6 45 4.8 14 1.7 46 4.9 15 1.8 47 5.0 16 1.9 48 5.5 17 2.0 49 6.0 18 2.1 50 6.5 19 2.2 51 7.0 20 2.3 52 7.5 21 2.4 53 8.0 22 2.5 54 8.5 23 2.6 55 9.0 24 2.7 56 9.5 25 2.8 57 10.0 26 2.9 58 11.0 27 3.0 59 12.0 28 3.1 60 13.0 29 3.2 61 14.0 30 3.3 62 15.0 31 3.4 63 16.0

Table#7 Delay Time (400.0ms)

Data Value Data Value Data Value Data Value

00.1 32 100.9 64 201.6 96 302.4

13.2 33 104.0 65 204.8 97 305.5

26.4 34 107.2 66 207.9 98 308.7

39.5 35 110.3 67 211.1 99 311.8 4 12.7 36 113.5 68 214.2 100 315.0 5 15.8 37 116.6 69 217.4 101 318.1 6 19.0 38 119.8 70 220.5 102 321.3 7 22.1 39 122.9 71 223.7 103 324.4 8 25.3 40 126.1 72 226.8 104 327.6

9 28.4 41 129.2 73 230.0 105 330.7 10 31.6 42 132.4 74 233.1 106 333.9 11 34.7 43 135.5 75 236.3 107 337.0 12 37.9 44 138.6 76 239.4 108 340.2 13 41.0 45 141.8 77 242.6 109 343.3 14 44.2 46 144.9 78 245.7 110 346.5 15 47.3 47 148.1 79 248.9 111 349.6 16 50.5 48 151.2 80 252.0 112 352.8 17 53.6 49 154.4 81 255.2 113 355.9 18 56.8 50 157.5 82 258.3 114 359.1 19 59.9 51 160.7 83 261.5 115 362.2 20 63.1 52 163.8 84 264.6 116 365.4 21 66.2 53 167.0 85 267.7 117 368.5 22 69.4 54 170.1 86 270.9 118 371.7 23 72.5 55 173.3 87 274.0 119 374.8 24 75.7 56 176.4 88 277.2 120 378.0 25 78.8 57 179.6 89 280.3 121 381.1 26 82.0 58 182.7 90 283.5 122 384.3 27 85.1 59 185.9 91 286.6 123 387.4 28 88.3 60 189.0 92 289.8 124 390.6 29 91.4 61 192.2 93 292.9 125 393.7 30 94.6 62 195.3 94 296.1 126 396.9 31 97.7 63 198.5 95 299.2 127 400.0

Table#12 Wah Release Time

Data Value

52 10.0 53 15.0 54 25.0 55 35.0 56 45.0 57 55.0 58 65.0 59 75.0 60 85.0 61 100.0 62 115.0 63 140.0 64 170.0 65 230.0 66 340.0 67 680.0

Table#2 Modulation Delay Offset

Data Value Data Value Data Value Data Value

00.0323.2 64 6.4 96 9.6

10.1333.3 65 6.5 97 9.7

20.2343.4 66 6.6 98 9.8

30.3353.5 67 6.7 99 9.9

40.4363.6 68 6.8 100 10.0

50.5373.7 69 6.9 101 11.1

60.6383.8 70 7.0 102 12.2

70.7393.9 71 7.1 103 13.3

80.8404.0 72 7.2 104 14.4

90.9414.1 73 7.3 105 15.5 10 1.0 42 4.2 74 7.4 106 17.1 11 1.1 43 4.3 75 7.5 107 18.6 12 1.2 44 4.4 76 7.6 108 20.2 13 1.3 45 4.5 77 7.7 109 21.8 14 1.4 46 4.6 78 7.8 110 23.3 15 1.5 47 4.7 79 7.9 111 24.9 16 1.6 48 4.8 80 8.0 112 26.5 17 1.7 49 4.9 81 8.1 113 28.0 18 1.8 50 5.0 82 8.2 114 29.6 19 1.9 51 5.1 83 8.3 115 31.2 20 2.0 52 5.2 84 8.4 116 32.8 21 2.1 53 5.3 85 8.5 117 34.3 22 2.2 54 5.4 86 8.6 118 35.9 23 2.3 55 5.5 87 8.7 119 37.5 24 2.4 56 5.6 88 8.8 120 39.0 25 2.5 57 5.7 89 8.9 121 40.6 26 2.6 58 5.8 90 9.0 122 42.2 27 2.7 59 5.9 91 9.1 123 43.7 28 2.8 60 6.0 92 9.2 124 45.3 29 2.9 61 6.1 93 9.3 125 46.9 30 3.0 62 6.2 94 9.4 126 48.4 31 3.1 63 6.3 95 9.5 127 50.0

Table#3 EQ Frequency

Data Value Data Value

0 THRU(0) 32 800 12233900

225341.0k

328351.1k

432361.2k

536371.4k

640381.6k

745391.8k

850402.0k

956412.2k 10 63 42 2.5k 11 70 43 2.8k 12 80 44 3.2k 13 90 45 3.6k 14 100 46 4.0k 15 110 47 4.5k 16 125 48 5.0k 17 140 49 5.6k 18 160 50 6.3k 19 180 51 7.0k 20 200 52 8.0k 21 225 53 9.0k 22 250 54 10.0k 23 280 55 11.0k 24 315 56 12.0k 25 355 57 14.0k 26 400 58 16.0k 27 450 59 18.0k 28 500 60 29 560 30 630 31 700

THRU(20.0k)

#8-10, 12-14: PSR-2100

Table#5 Delay Time (200.0ms)

Data Value Data Value Data Value Data Value

00.1 32 50.5 64 100.8 96 151.2

11.7 33 52.0 65 102.4 97 152.8

23.2 34 53.6 66 104.0 98 154.4

34.8 35 55.2 67 105.6 99 155.9

46.4 36 56.8 68 107.1 100 157.5

58.0 37 58.3 69 108.7 101 159.1

69.5 38 59.9 70 110.3 102 160.6 7 11.1 39 61.5 71 111.9 103 162.2 8 12.7 40 63.1 72 113.4 104 163.8

9 14.3 41 64.6 73 115.0 105 165.4 10 15.8 42 66.2 74 116.6 106 166.9 11 17.4 43 67.8 75 118.2 107 168.5 12 19.0 44 69.4 76 119.7 108 170.1 13 20.6 45 70.9 77 121.3 109 171.7 14 22.1 46 72.5 78 122.9 110 173.2 15 23.7 47 74.1 79 124.4 111 174.8 16 25.3 48 75.7 80 126.0 112 176.4 17 26.9 49 77.2 81 127.6 113 178.0 18 28.4 50 78.8 82 129.2 114 179.5 19 30.0 51 80.4 83 130.7 115 181.1 20 31.6 52 81.9 84 132.3 116 182.7 21 33.2 53 83.5 85 133.9 117 184.3 22 34.7 54 85.1 86 135.5 118 185.8 23 36.3 55 86.7 87 137.0 119 187.4 24 37.9 56 88.2 88 138.6 120 189.0 25 39.5 57 89.8 89 140.2 121 190.6 26 41.0 58 91.4 90 141.8 122 192.1 27 42.6 59 93.0 91 143.3 123 193.7 28 44.2 60 94.5 92 144.9 124 195.3 29 45.7 61 96.1 93 146.5 125 196.9 30 47.3 62 97.7 94 148.1 126 198.4 31 48.9 63 99.3 95 149.6 127 200.0

Table#6 Room Size

Data Value Data Value Data Value Data Value

00.1325.1 64 10.1 96 15.1

10.3335.3 65 10.3 97 15.3

20.4345.4 66 10.4 98 15.5

30.6355.6 67 10.6 99 15.6

40.7365.7 68 10.8 100 15.8

50.9375.9 69 10.9 101 15.9

61.0386.1 70 11.1 102 16.1

71.2396.2 71 11.2 103 16.2

81.4406.4 72 11.4 104 16.4

91.5416.5 73 11.5 105 16.6 10 1.7 42 6.7 74 11.7 106 16.7 11 1.8 43 6.8 75 11.9 107 16.9 12 2.0 44 7.0 76 12.0 108 17.0 13 2.1 45 7.2 77 12.2 109 17.2 14 2.3 46 7.3 78 12.3 110 17.3 15 2.5 47 7.5 79 12.5 111 17.5 16 2.6 48 7.6 80 12.6 112 17.6 17 2.8 49 7.8 81 12.8 113 17.8 18 2.9 50 7.9 82 12.9 114 18.0 19 3.1 51 8.1 83 13.1 115 18.1 20 3.2 52 8.2 84 13.3 116 18.3 21 3.4 53 8.4 85 13.4 117 18.4 22 3.5 54 8.6 86 13.6 118 18.6 23 3.7 55 8.7 87 13.7 119 18.7 24 3.9 56 8.9 88 13.9 120 18.9 25 4.0 57 9.0 89 14.0 121 19.1 26 4.2 58 9.2 90 14.2 122 19.2 27 4.3 59 9.3 91 14.4 123 19.4 28 4.5 60 9.5 92 14.5 124 19.5 29 4.6 61 9.7 93 14.7 125 19.7 30 4.8 62 9.8 94 14.8 126 19.8 31 5.0 63 10.0 95 15.0 127 20.0

Table#8 Compressor Attack Time

Data Value

01 12 23 34 45 56 67 78 89

910 10 12 11 14 12 16 13 18 14 20 15 23 16 26 17 30 18 35 19 40

Table#11 Reverb Width; Depth; Height

Data Value Data Value Data Value Data Value

00.5328.8 64 17.6 96 27.5

10.8339.1 65 17.9 97 27.8

21.0349.4 66 18.2 98 28.1

31.3359.6 67 18.5 99 28.5

41.5369.9 68 18.8 100 28.8

51.83710.2 69 19.1 101 29.2

62.03810.4 70 19.4 102 29.5

72.33910.7 71 19.7 103 29.9

82.64011.0 72 20.0 104 30.2

92.84111.2 73 20.2 10 3.1 42 11.5 74 20.5 11 3.3 43 11.8 75 20.8 12 3.6 44 12.1 76 21.1 13 3.9 45 12.3 77 21.4 14 4.1 46 12.6 78 21.7 15 4.4 47 12.9 79 22.0 16 4.6 48 13.1 80 22.4 17 4.9 49 13.4 81 22.7 18 5.2 50 13.7 82 23.0 19 5.4 51 14.0 83 23.3 20 5.7 52 14.2 84 23.6 21 5.9 53 14.5 85 23.9 22 6.2 54 14.8 86 24.2 23 6.5 55 15.1 87 24.5 24 6.7 56 15.4 88 24.9 25 7.0 57 15.6 89 25.2 26 7.2 58 15.9 90 25.5 27 7.5 59 16.2 91 25.8 28 7.8 60 16.5 92 26.1 29 8.0 61 16.8 93 26.5 30 8.3 62 17.1 94 26.8 31 8.6 63 17.3 95 27.1

Table#9 Compressor Release Time

Data Value

010 115 225 335 445 555 665 775 885

9 100 10 115 11 140 12 170 13 230 14 340 15 680

Table#10 Compressor Ratio

Data Value

01.0

11.5

22.0

33.0

45.0

57.0

6 10.0

7 20.0

Table#13 Sampling Freq Control

Data Value Data Value Data Value Data Value

0 44.1K 32 1.34K 64 678.0 96 455.0 1 22.1K 33 1.30K 65 668.0 97 450.0 2 14.7K 34 1.26K 66 658.0 98 445.0 3 11.0K 35 1.23K 67 649.0 99 441.0

48.8K 36 1.19K 68 639.0 100 437.0

57.4K 37 1.16K 69 630.0 101 432.0

66.3K 38 1.13K 70 621.0 102 428.0

75.5K 39 1.10K 71 613.0 103 424.0

84.9K 40 1.08K 72 604.0 104 420.0

94.5K 41 1.05K 73 596.0 105 416.0 10 4.0K 42 1.03K 74 588.0 106 412.0 11 3.7K 43 1.00K 75 580.0 107 408.0 12 3.4K 44 980.0 76 573.0 108 405.0 13 3.2K 45 959.0 77 565.0 109 401.0 14 2.9K 46 938.0 78 558.0 110 397.0 15 2.8K 47 919.0 79 551.0 111 394.0 16 2.6K 48 900.0 80 544.0 112 390.0 17 2.5K 49 882.0 81 538.0 113 387.0 18 2.3K 50 865.0 82 531.0 114 383.0 19 2.2K 51 848.0 83 525.0 115 380.0 20 2.1K 52 832.0 84 519.0 116 377.0 21 2.0K 53 817.0 85 513.0 117 374.0 22 1.92K 54 802.0 86 507.0 118 371.0 23 1.84K 55 788.0 87 501.0 119 368.0 24 1.76K 56 774.0 88 496.0 120 364.0 25 1.70K 57 760.0 89 490.0 121 361.0 26 1.63K 58 747.0 90 485.0 122 359.0 27 1.58K 59 735.0 91 479.0 123 356.0 28 1.52K 60 723.0 92 474.0 124 353.0 29 1.47K 61 711.0 93 469.0 125 350.0 30 1.42K 62 700.0 94 464.0 126 347.0 31 1.38K 63 689.0 95 459.0 127 345.0

Table#14 Tempo Delay

Data Value Data Value Data Value

0 64th/3 32 4thX19 64 4thX51 1 64th. 33 4thX20 65 4thX52 2 32th 34 4thX21 66 4thX53 3 32th/3 35 4thX22 67 4thX54 4 32th. 36 4thX23 68 4thX55 5 16th 37 4thX24 69 4thX56 6 16th/3 38 4thX25 70 4thX57 7 16th. 39 4thX26 71 4thX58 88th 40 4thX27 72 4thX59

98th/3 41 4thX28 73 4thX60 10 8th. 42 4thX29 74 4thX61 11 4th 43 4thX30 75 4thX62 12 4th/3 44 4thX31 76 4thX63 13 4th. 45 4thX32 77 4thX64 14 2nd 46 4thX33 15 2nd/3 47 4thX34 16 2nd. 48 4thX35 17 4thX4 49 4thX36 18 4thX5 50 4thX37 19 4thX6 51 4thX38 20 4thX7 52 4thX39 21 4thX8 53 4thX40 22 4thX9 54 4thX41 23 4thX10 55 4thX42 24 4thX11 56 4thX43 25 4thX12 57 4thX44 26 4thX13 58 4thX45 27 4thX14 59 4thX46 28 4thX15 60 4thX47 29 4thX16 61 4thX48 30 4thX17 62 4thX49 31 4thX18 63 4thX50

23

Harmony/Echo Type List Liste der Harmony/Echo-Effekttypen Liste des types d’harmonie/d’écho Lista de tipos de ecos/armonías

STANDARD DUET STANDARD TRIO FULL CHORD ROCK DUET COUNTRY DUET COUNTRY TRIO BLOCK 4-WAY CLOSE 1 4-WAY CLOSE 2 4-WAY OPEN 1+5 OCTAVE STRUM MULTI ASSIGN ECHO TREMOLO TRILL

Vocal Harmony Type List

Liste der Vocal-Harmony-Effekttypen

Liste des types d’harmonie vocale

Lista de tipos de armonía

(PSR-2100 only)

Display Name Harmony Type Mode

Std Duet Standard Duet Chordal/Vocoder Girl Duet Girl in Duet Chordal/Vocoder Lisa&Tina Lisa and Tina Chordal/Vocoder Sing B+G Sing B+G Chordal/Vocoder Dream Girls Dream Girls Chordal/Vocoder MenChoir Men Choir Chordal/Vocoder WomenChoir Women Choir Chordal/Vocoder ClosedChoir Closed Choir Chordal/Vocoder MixedChoir Mixed Choir Chordal/Vocoder CountryMen Country Men Chordal/Vocoder CntryGirls Country Girls Chordal/Vocoder Barbershop Barbershop Chordal/Vocoder JazzMenCho JazzMenChoir Chordal/Vocoder J_WomenCho JazzWomenCho Chordal/Vocoder J_CloseCho JazzClosedCho Chordal/Vocoder J_MixedCho JazzMixedCho Chordal/Vocoder DiatncJazz Diatonic Jazz Chordal/Vocoder DiatncGirl Diatonic Girl Chordal/Vocoder ACapellBoy A Capella Boy Chordal/Vocoder ACapellaMix A Capella Mix Chordal/Vocoder ACapellaDia A Capella Dia Chordal/Vocoder FalsetDuet Falsetto Duet Chordal/Vocoder FalsettTrio Falsetto Trio Chordal/Vocoder FalsettoDia Falsetto Dia Chordal/Vocoder FalsetJazz Falsetto Jazz Chordal/Vocoder FalACapella Fal A Capella Chordal/Vocoder 2UnisonLow 2 Unison Low Chordal/Vocoder 2UnisonHigh 2 Unison High Chordal/Vocoder 3UnisonLow 3 Unison Low Chordal/Vocoder 3UnisonHigh 3 Unison High Chordal/Vocoder Voice&Inst Voice & Inst Chordal/Vocoder ChordalXG ChordalXG Chordal/Vocoder VocodAutoU Vocoder Auto Upper Chordal/Vocoder VocodAutoL Vocoder Auto Lower Chordal/Vocoder VocodModeU Vocoder Mode Upper Chordal/Vocoder VocodModeL Vocoder Mode Lower Chordal/Vocoder VocodGirlU Vocoder Girl Upper Chordal/Vocoder VocodGirlL Vocoder Girl Lower Chordal/Vocoder VocodPichU Vocoder Pitch Upper Chordal/Vocoder VocodPichL Vocoder Pitch Lower Chordal/Vocoder KaraokAuto Karaoke Auto Chordal/Vocoder KaraokMode Karaoke Mode Chordal/Vocoder KaraokGirl Karaoke Girl Chordal/Vocoder KaraokPich Karaoke Pitch Chordal/Vocoder VocoderXG VocoderXG Chordal/Vocoder SingBass Sing the Bass Chromatic SpdyMouse Speedy Mouse Chromatic ChromatXG ChromaticXG Chromatic DetuneXG DetuneXG Detune Thru Thru -

Vocal harmony types that have "Chordal/Vocoder" in the Mode column can be used in either Chordal or Vocoder Mode.

24

Parameter Chart / Parametertabelle / Tableau des paramètres / Gráfico de parámetros

Settings are saved/called up for each type.

Data Type The data is saved... The data is called up... Saved Location

Setup When you change settings in a display page and then exit from

Voice When you change settings in the Voice Set display and then

Song When you save the recorded or edited (current) song as a Song

Style When you save the recorded or edited data as a Style file. When you call up a style. Style File OTS When you memorize settings with the REGISTARATION

Regist. When you memorize settings with the REGISTARATION

If parameters belonging to more than one type are set, the new settings take priority over the old.

Parameter System

MainWindow

Transpose X X - X - X X O Tune/Trans UpperOctave X X - X - X X O Voice -

SplitPoint (Accomp) O X - O Guide Setting X X O Style Split SplitPoint (Left) O X - X - X X O Style Split SongFile X X - X - X X O Song StyleFile X X - O - X X O Style IntroEndingSection X X - X - O X X - VoiceFile (Main, Layer, Left) X X - X - X X X - -

MultiPadFile X X - O Keyboard Voice X O O MultiPad RegistrationBankFile X X - X - X X X - -

PartSelect X X - X - X X X - PartOnOff (Main, Layer) X X - O Keyboard Voice X O O Voice -

PartOnOff (Left) XX-OKeyboard Voice X O O Style BalancePopup

SongVolume X X - X - X X O Song StyleVolume X X - O - X X O Style M.PadVolume X X - O Keyboard Voice X O O MultiPad -

MicVolume X X - O Mic. Setting X X O Mic MainVolume X X - O Keyboard Voice X O O Voice -

LeftVolume XX-OKeyboard Voice X O O Style LayerVolume X X - O Keyboard Voice X O O Voice -

Channel OnOffPopup

ChannelOnOff (Song) X X - X - X X X - -

ChannelOnOff (Style) X X - O - O X O Style -

VoiceEffect

Touch X X - X - X X O Voice Sustain X X - X - X X O Voice LeftHoldXX-OKeyboard Voice X O O Style -

Dsp (Main, Layer) X O Effect O Keyboard Voice X O O Voice Dsp (Left) X O Effect O Keyboard Voice X O O Style Variation (Main, Layer) X O Effect O Keyboard Voice X O O Voice Variation (Left) XOEffect O Keyboard Voice X O O Style Harmony/Echo X X - O Keyboard Voice X O O Harmony Poly/Mono (Main, Layer) X O Voice O Keyboard Voice X O O Voice Poly/Mono (Left) X O Voice O Keyboard Voice X O O Style -

Registration

FreezeOnOff X X - X - X X X - RegistMemoryPopupSetting O X - X - X X X - -

RegistNumber X X - X - X X X - RegistContentsName X X - X - X X O - -

Menu>Function

MasterTune/ScaleTune MasterTune

MasterTune O X - X - X X X - ScaleTune

Scale X X - X - X X O Scale -

Tune X X - X - X X O Scale -

BaseNote X X - X - X X O Scale -

Scale Part X X - X - X X O Scale SongSetting QuickStart O X - X - X X X - SongChainPlay O X - X - X X X - Channel Setting

Track1 Channel O X - O - X X X - -

Track2 Channel O X - O - X X X - -

Vocal Harmony Channel ➞ Mic>MicSetup>VH Song Track

Auto Ch Set O X - X - X X X - -

Phrase Mark X X - X - X X X - -

Lyrics Language O X - O Lyrics Language X X X - StyleSetting/SplitPoint/ChordFingering StyleSetting/SplitPoint

StopAcmp O X - X - X X X - -

OTSLinkTiming O X - X - X X X - -

SynchroStopWindow O X - X - X X X - -

AccompTouch O X - X - X X X - -

SectionSet O X - X - X X X - -

SplitPoint(Accomp) ➞ MainWindow

SplitPoint(Left) ➞ MainWindow ChordFingering

FingeringType O X - X - X X O Style -

TutorRoot X X - X - X X X - -

TutorType X X - X - X X X - -

the page.

save the data as Voice file.

file.

buttons and then save the current style as a Style file.

buttons and then save the data as a Registaration Bank File.

Voice Voice Set

SetUp

When you turn off the power and then turn on the power.

When you call up a voice. Voice File

When you call up a song, play a song or move the song position.

When you call up an OTS by pressing one of OTS buttons.

When you call up an Regist. by pressing one of REGISTRATION MEMORY buttons.

Song Song Setup Group Style OTS Registration Param Lock

Group

System area of the internal memory (Flash Memory)

Song File

Registration Bank File

Regist Freeze/Memory

Group

The data that is saved to Regist./OTS is not actual Voice, but Program Change.

PSR-2100 only

For songs that have no channel on/off message, all are set to on.

Filter settings when registering Registration.

Notes

O: Memorized X: Not Memorized

25

Parameter System

Controller Pedal

PedalType X O (Left o nly) LPDL O

PedalSettings X O (Left on l y) LPDL O

PedalTypeDefaultSetting X X X X - X X X X -

PedalPolarity O X - X - X X X - Keyboard/Panel

TouchSense O X - X - X X X - -

TouchOffLevel X X - X - X X O Voice -

TouchOnOff X X - X - X X O Voice -

ModulationWheel X X - X - X X O Voice -

TransposeAssign O X - X - X X X - Regist.Sequence/Freeze/VoiceSet RegistrationSequence

RegistSequenceData X X - X - X X O - -

RegistSequenceEnable O X - X - X X X - -

Regist(+)Pedal O X - X - X X X - -

Regist(-)Pedal O X - X - X X X - -

SequenceEnd X X - X - X X O - Freeze

FreezeGroupSetting O X - X - X X X - VoiceSet

VoiceSetEnable Main O X - X - X X X - -

VoiceSetEnable Layer O X - X - X X X - -

VoiceSetEnable Left O X - X - X X X - Harmony/Echo Type X O Harm O Keyboard Voice X O O Harm Volume XOHarm O Keyboard Voice X O O Harm Speed X O Harm O Keyboard Voice

Assign X O Harm O Keyboard Voice X O O Harm ChordNoteOnly X O Harm O Keyboard Voice X O O Harm TouchLimit X O Harm O Keyboard Voice X O O Harm Utility Configuration

Speaker O X - X - X X X - -

DisplayVoiceNumber O X - X - X X X - -

MetronomeVolume O X - X - X X X - -

MetronomeSound O X - X - X X X - -

TimeSignature X X - O - O X X - -

ParameterLock O X - X - X X X - -

TapCountPercussion X X - O Keyboard Voice X O O Style -

TapCountVelocity X X - O Keyboard Voice X O O Style -

LCDBrightness O X - X - X X X - -

FadeInTime O X - X - X X X - -

FadeOutTIme O X - X - X X X - -

FadeOutHoldTime O X - X - X X X - Disk

FloppyDiskSongAutoOpen O X - X - X X X - Owner

OwnerName O X - X - X X X - -

Language O X - X - X X X - -

MainPicture O X - X - X X X - SystemReset

FactoryResetSetting X X - X - X X X - MIDI

System

Local Control X X - X - X X X - -

Clock X X - X - X X X - -

Transmit Clock X X - X - X X X - -

Receive Transpose X X - X - X X X - -

Receive Start/Stop X X - X - X X X - -

SysEx Transmit X X - X - X X X - -

SysEx Receive X X - X - X X X - -

Chord SysEx Transmit X X - X - X X X - Chord SysEx Receive X X - X - X X X - Transmit

Part (Ch1 – 16) X X - X - X X X - -

Filter (Ch1 – 16) X X - X - X X X - Receive

Mode (Ch1 – 32) X X - X - X X X - -

Filter (Ch1 – 32) X X - X - X X X - Root X X - X - X X X - Chord Detect X X - X - X X X - MIDI Template

Template No. O X - X - X X X - -

Template Name X X - X - X X X - -

Lyrics

BackGround (Panel Setting) O X - X Lyrics Language X X X - BackGround (Song Setting) X X - O Lyrics Language X X X - -

MusicScore

Left on/offOX-OScore Setting X X X - Right on/offOX-OScore Setting X X X - Lyric on/offOX-OScore Setting X X X - Chord on/off O X - O Score Setting X X X - NoteName on/off O X - O Score Setting X X X - Size OX -OScore Setting X X X - Left ch. XX-OScore Setting X X X - Right ch. XX -OScore Setting X X X - KeySignature X X - O Score Setting X X X - Quantize O X - O Score Setting X X X - NoteName O X - O Score Setting X X X - ColorNoteOX-OScore Setting X X X - -

Song

Track1, 2 On/Off X X - O Guide Setting X X X - ExtraTracks On/Off X X - X - X X X - Synchro Start X X - X - X X X - -

StartStop X X - X - X X X - A-B Repeat X X - X - X X X - -

SetUp

Voice Voice Set

Group

Song Song Setup Group Style OTS Registration Param Lock

Keyboard Voice X O (Left only) O Pedal -

(Left only)

Keyboard Voice X O (Left only) O Pedal -

(Left only)

(Included in Type)

XOOHarm -

Regist Freeze/Memory

Group

Memorized as a single Registration Bank file.

Cannot be reset with Factory Reset.

Cannot be reset with Factory Reset. Cannot be reset with Factory Reset. Cannot be reset with Factory Reset.

Cannot be reset with Factory Reset.

Cannot be reset with Factory Reset. Reset to default background with Factory Reset.

Setting is linked to Channel on/off. Setting is linked to Channel on/off.

Notes

26

Parameter System

DigitalStudio>DigitalRecording>Song Creator Rec Mode

Rec Start X X - X - X X X - -

PunchInAt X X - X - X X X - -

Rec Stop X X - X - X X X - -

PunchOutAt X X - X - X X X - -

Pedal Punch In/Out X X - X - X X X - Quantize

Track X X - X - X X X - -

Size X X - X - XXX - -

Strength X X - X - X X X - Delete X X - X - X X X - Mix

Source1 X X - X - X X X - -

Source2 X X - X - X X X - -

Destination X X - X - X X X - Channel Transpose X X - X - X X X - SetUp O X - X - X X X - Filter

Main Filter O X - X - X X X - -

Control Change Filter O X - X - X X X - -

Accompaniment Filter O X - X - X X X - -

Tempo

Tempo X X - O - O X O Tempo -

Transpose ➞ MainWindow

UpperOctave ➞ MainWindow

MultiPad

Multi Pad ContentsName X X - X - X X X - DigitalStudio>DigitalRecording>Multi Pad Creator Repeat X X - X - X X X - Chord Match X X - X - X X X - Filter

Main Filter O X - X - X X X - -

Control Change Filter O X - X - X X X - -

DigitalStudio>DigitalRecording>Style Creator

Basic

Section X X - X - X X X - -

Pattern Length X X - X - O X X - -

Tempo X X - X - O X X - -

Beat X X - X - O X X - Assembly

Source Pattern X X - X - X X X - -

Section X X - X - X X X - -

Part X X - X - X X X - -

Play Type X X - X - X X X - Groove

Original Beat X X - X - X X X - -

Beat Converter X X - X - X X X - -

Swing X X - X - X X X - -

Fine X X - X - XXX - Dynamics

Part X X - X - X X X - -

Accent Type X X - X - X X X - -

Strength X X - X - X X X - -

Expand/Comp. X X - X - X X X - -

Boost/Cut X X - X - X X X - Quantize

Part X X - X - X X X - -

Size X X - X - XXX - -

Strength X X - X - X X X - Velocity Change

Part X X - X - X X X - -

Boost/Cut X X - X - X X X - Measure Copy

Part X X - X - X X X - -

Measure Top X X - X - X X X - -

Measure Last X X - X - X X X - -

Destination X X - X - X X X - Measure Clear

Part X X - X - X X X - -

Measure Top X X - X - X X X - -

Measure Last X X - X - X X X - Remove Event

Part X X - X - X X X - -

Event X X - X - X X X - Parameter

Part X X - X - X X X - -

Source Root X X - X - O X X - -

Source Chord X X - X - O X X - -

NTR X X - X -OXX- -

NTT X X - X -OXX- -

High Key X X - X - O X X - -

Note Limit X X - X - O X X - -

RTR X X - X -OXX- Filter

Main Filter O X - X - X X X - -

Control Change Filter O X - X - X X X - -

Style

AccompanimentOnOff X X - X - X O (On) O Style AutoFillOnOff O X - X - X X X - OTSLink O X - X - X X X - Section X X - O - XXOStyle SynchroStart X X - X - X O (On) X - SynchroStop X X - X - X X X - StartStop X X - O - X X X - -

SetUp

Voice Voice Set

Group

Song Song Setup Group Style OTS Registration Param Lock

Regist Freeze/Memory

Group

Notes

27

Parameter System

MusicFinder

SortKind O X - X - X X X - SortOrder O X - X - X X X - TempoLock O X - X - X X X - Search1/2

Music O X - X - X X X - -

Keyword O X - X - X X X - -

FileNumber O X - X - X X X - -

Beat O X - X - X X X - -

SearchArea O X - X - X X X - -

Tempo O X - X - X X X - -

Genre O X - X - X X X - -

Search results X X - X - X X X - Record (=Property settings) X X - X - X X X - -

Mic (PSR-2100 only)

VocalHarmonyOnOff X X - O Mic. Setting X X O Mic Mic TalkOnOff X X - X - X X X - EffectOnOff X X - O Mic. Setting X X O Mic Mic VHType X X - O Mic. Setting X X O Mic Mic VHParameters X X - O Mic. Setting X X X - Mic

MicSetting (PSR-2100 only) OverallSetting

EQ Low Freq. O X - X - X X X - -

EQ Low Gain O X - X - X X X - -

EQ Mid Freq. O X - X - X X X - -

EQ Mid Gain O X - X - X X X - -

EQ High Freq. O X - X - X X X - -

EQ High Gain O X - X - X X X - -

Noise Gate SW O X - X - X X X - -

Noise Gate TH O X - X - X X X - -

Compressow SW O X - X - X X X - -

Compressor TH O X - X - X X X - -

Compressor RAT O X - X - X X X - -

Compressor OUT O X - X - X X X - -

VH Song Track Mute X X - X - X X O Mic Mic

VH Song Track X X - X - X X O Mic Mic

VH Keyboard X X - O Mic. Setting X X O Mic Mic

VH Balance X X - X - X X O Mic Mic

VH Mode X X - X - X X O Mic Mic

VH Chord Detect X X - X - X X O Mic Mic

Mute X X - X - X X X - -

MicVol ➞ BalancePoup>MicVolume TalkSetting

Volume O X - X - X X X - -

Pan O X - X - X X X - -

ReverbDepth O X - X - X X X - -

ChorusDepth O X - X - X X X - -

TotalVolumeAttenuator O X - X - X X X - -

DSPOnOff O X - X - X X X - -

DSPDepth O X - X - X X X - -

DSPType O X - X - X X X - -

DigitalStudio>SoundCreator

Voice (Main, Layer) X O Voice O Keyboard Voice X O O Voice Voice (Left) XOVoice O Keyboard Voice X O O Style Volume for Balance (Main, Layer) X O Voice O Keyboard Voice X O O Voice Volume for Balance (Left) X O Voice O Keyboard Voice X O O Style Touch Sens (Main, Layer) X O Voice X Keyboard Voice X O O Voice Touch Sens (Left) X O Voice X Keyboard Voice X O O Style Octave for Left X O Voice X - X X X - Octave for Main/Layer X O Voice X - X X X - Mono/Poly ➞ Voice Effect Portament Time ➞ DigitalStudio>Mixing Console Filter Brightness ➞ DigitalStudio>Mixing Console Filter Resonance ➞ DigitalStudio>Mixing Console EG Attack (Main, Layer) X O Voice O Keyboard Voice X O O Voice EG Attack (Left) X O Voice O Keyboard Voice X O O Style EG Decay (Main, Layer) X O Voice O Keyboard Voice X O O Voice EG Decay (Left) X O Voice O Keyboard Voice X O O Style EG Release (Main, Layer) X O Voice O Keyboard Voice X O O Voice EG Release (Left) X O Voice O Keyboard Voice X O O Style Vibrato Depth (Main, Layer) X O Voice O Keyboard Voice X O O Voice Vibrato Depth (Left) X O Voice O Keyboard Voice X O O Style Vibrato Speed (Main, Layer) X O Voice O Keyboard Voice X O O Voice Vibrato Speed (Left) X O Voice O Keyboard Voice X O O Style Vibrato Delay (Main, Layer) X O Voice O Keyboard Voice X O O Voice Vibrato Delay (Left) XOVoice O Keyboard Voice X O O Style Reverb Depth ➞ DigitalStudio>Mixing Console Chorus Depth ➞ DigitalStudio>Mixing Console DSP On/Off ➞ Voice Effect DSP Depth ➞ DigitalStudio>Mixing Console Panel Sustain (Main, Layer) X O Voice O Keyboard Voice X O O Voice -

Panel Sustain (Left) X O Voice O Keyboard Voice X O O Style DSP Type (Main, Layer) X O Effect O Keyboard Voice X O O Voice -

DSP Type (Left) X O Effect O Keyboard Voice X O O Style LastSelectedDSP X X - X - X X X - -

DSP Variation ➞ Voice Effect DSP Fast Value (Main, Layer) X O Effect O Keyboard Voice X O O Voice DSP Fast Value (Left) X O Effect O Keyboard Voice X O O Style EQ Low Freq (Main, Layer) X O EQ O Keyboard Voice X O O Voice -

EQ Low Freq (Left) X O EQ O Keyboard Voice X O O Style EQ Low Gain ➞ DigitalStudio>Mixing Console EQ High Freq (Main, Layer) X O EQ O Keyboard Voice X O O Voice EQ High Freq (Left) XOEQ O Keyboard Voice X O O Style EQ High Gain ➞ DigitalStudio>Mixing Console Harmony/Echo

Type ➞ Harmony/Echoe

Volume

Speed ➞ Harmony/Echoe

Assign ➞ Harmony/Echoe

ChordNoteOnly ➞ Harmony/Echoe

TouchLimit ➞ Harmony/Echoe

SetUp

Voice Voice Set

Group

Song Song Setup Group Style OTS Registration Param Lock

Regist Freeze/Memory

Group

Notes

Current VH Type settings and Type name

Memorized only when Sound Creator opened

PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only

28

Parameter System

Organ Flutes Footage (Main, Layer) X O Voice O Keyboard Voice X O O Voice Organ Flutes Footage (Left) X O Voice O Keyboard Voice X O O Style Organ Flutes Type (Main, Layer) X O Voice O Keyboard Voice X O O Voice Organ Flutes Type (Left) X O Voice O Keyboard Voice X O O Style Organ Vib On/Off (Main, Layer) X O Voice O Keyboard Voice X O O Voice Organ Vib On/Off (Left) X O Voice O Keyboard Voice X O O Style Organ Flutes Attack Footage (Main, Layer) X O Voice O Keyboard Voice X O O Voice Organ Flutes Attack Footage (Left) X O Voice O Keyboard Voice X O O Style Organ Flutes Attack Mode (Main, Layer) X O Voice O Keyboard Voice X O O Voice Organ Flutes Attack Mode (Left) X O Voice O Keyboard Voice X O O Style Organ Flutes Attack length (Main, Layer) X O Voice O Keyboard Voice X O O Voice Organ Flutes Attack length (Left) X O Voice O Keyboard Voice X O O Style Organ Flutes Response (Main, Layer) X O Voice O Keyboard Voice X O O Voice Organ Flutes Response (Left) X O Voice O Keyboard Voice X O O Style Organ Flutes Volume (Main, Layer) X O Voice O Keyboard Voice X O O Voice Organ Flutes Volume (Left) X O Voice O Keyboard Voice X O O Style -

DigitalStudio>Mixing Console

Auto Revoice

On/Off O X - X - X X X - -

Setup O X - X - X X X - Volume

Style Part X X - O - O X O Style -

Song Part X X - O Volume X X X - Main, Layer ➞ MainWindow>BalancePopup>MainVolume/LayerVolume Left ➞ MainWindow>BalancePopup>LeftVolume Acmp (Offset) ➞ MainWindow>BalancePopup>StyleVolume Song (Offset) ➞ MainWindow>BalancePopup>SongVolume Multi Pad ➞ MainWindow>BalancePopup>M.PadVolume Mic ➞ MainWindow>BalancePopup>MicVolume Voice

Acmp Part X X - X - O X O Style -

Song Part X X - O Voice X X X - PanPot

Acmp Part X X - O - O X O Style -

Song Part X X - O Pan X X X - -

Main, Layer X X - O Keyboard Voice X O O Voice -

LeftXX-OKeyboard Voice X O O Style -

Acmp (Offset) X X - X - X X O Style -

Song (Offset) X X - X - X X X - -

Multi Pad X X - X - X X O Multi Pad -

MicXX-OMic. Setting X X O Mic Brightness

Acmp Part X X - X - O X O Style -

Song Part X X - O Filter X X X - -

Main, Layer X O Voice O Keyboard Voice X O O Voice -

LeftXOVoice O Keyboard Voice X O O Style Harmonic Contents

Acmp Part X X - X - O X O Style -

Song Part X X - O Filter X X X - -

Main, Layer X O Voice O Keyboard Voice X O O Voice -

LeftXOVoice O Keyboard Voice X O O Style Octave

Main, Layer X O Voice O Keyboard Voice X O O Voice -

LeftXOVoice O Keyboard Voice X O O Style Tune

Main, Layer X X - O Keyboard Voice X O O Voice -

LeftXX-OKeyboard Voice X O O Style Portamento Time

Main, Layer X O Voice O Keyboard Voice X O O Voice -

LeftXOVoice O Keyboard Voice X O O Style Pitch Bend Range

Main, Layer X X Voice X - X X O Voice -

Left X X Voice X - X X O Style Transpose

Master X X - X - X X O Tune Trans -

Song X X - X - X X O Tune Trans -

Keyboard X X - X - X X O Tune Trans Reverb Type X X - X - O X O Style/Song Reverb Type Reverb Return Level X X - X - X X O Style/Song Reverb Return

Natural Voice Reverb Type X O Effect X - O X O Voice/Style/

Reverb Depth

Acmp Part X X - X - O X O Style -

Song Part X X - O Effect X X X - -

Main, Layer X O Effect O Keyboard Voice X O O Voice -

LeftXOEffect O Keyboard Voice X O O Style -

Acmp (Offset) X X - X - X X O Style -

Song (Offset) X X - X - X X X - -

Multi Pad X X - X - X X O Multi Pad -

MicXX-OMic. Setting X X O Mic - PSR-2100 only Chorus Type X X - X - O X O Style/Song Chorus Return Level X X - X - X X O Style/Song Chorus Return

Natural Voice Chorus Type X O Effect X - O X O Voice/Style/

Chorus Depth

Acmp Part X X - X - O X O Style -

Song Part X X - O Effect X X X - -

Main, Layer X O Effect O Keyboard Voice X O O Voice -

LeftXOEffect O Keyboard Voice X O O Style -

Acmp (Offset) X X - X - X X O Style -

Song (Offset) X X - X - X X X - -

Multi Pad X X - X - X X O Multi Pad -

MicXX-OMic. Setting X X O Mic -

SetUp

Voice Voice Set

Group

Song Song Setup Group Style OTS Registration Param Lock

Regist Freeze/Memory

Group

Song

Group

Level

PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only

PSR-2100 only

Notes

29

Parameter System

DSP1 Type X O Effect O Keyboard Voice X O O Voice/Song - PSR-1100 only DSP1 Type X X - X - O X O Style/Song - PSR-2100 only DSP1 Return Level X X - X - X X O Voice/Song DSP1 Return

DSP1 Return Level X X - X - X X O Style/Song DSP1 Return

Natural Voice DSP Type X O Effect X - O X O Voice/Style/

DSP Depth

Style Part X X - X - O X O Style -

Song Part X X - O Effect X X X - -

Main, Layer X O Effect O Keyboard Voice X O O Voice -

LeftXOEffect O Keyboard Voice X O O Style -

MicXX-OMic. Setting X X O Mic - PSR-2100 only DSP Type

Main, Layer X O Effect O Keyboard Voice X O O Voice -

LeftXOEffect O Keyboard Voice X O O Style -

Song X X - O - X X O Song Effect Parameter X X - X - X X X - -

MasterEQ Type O X - X - X X X - Master EQ MasterEQ Parameter X X - X - X X X - Master EQ EQ Low Gain

Acmp Part X X - X - O X O Style -

Song Part X X - O Filter X X X - -

Main, Layer X O EQ O Keyboard Voice X O O Voice -

LeftXOEQOKeyboard Voice X O O Style -

Acmp (Offset) X X - X - X X O Style -

Song (Offset) X X - X - X X X - -

Multi Pad X X - X - X X O Multi Pad EQ High Gain

Acmp Part X X - X - O X O Style -

Song Part X X - O Filter X X X - -

Main, Layer X O EQ O Keyboard Voice X O O Voice -

LeftXOEQOKeyboard Voice X O O Style -

Acmp (Offset) X X - X - X X O Style -

Song (Offset) X X - X - X X X - -

Multi Pad X X - X - X X O Multi Pad -

SetUp

Voice Voice Set

Group

Song Song Setup Group Style OTS Registration Param Lock

Regist Freeze/Memory

Group

Song

Group

Level (on PSR-

1100: DSP

Return Level)

Level

-

PSR-1100 only

PSR-2100 only

PSR-2100 only PSR-2100 only PSR-2100 only

PSR-2100 only PSR-2100 only

PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only PSR-2100 only

Notes

30

MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI

Many MIDI messages listed in the MIDI Data Format are expressed in decimal numbers, binary numbers and hexadecimal numbers. Hexadecimal numbers may include the letter “H” as a suffix. Also, “n” can freely be defined as any whole number. To enter data/values, refer to the table below.

Decimal Hexadecimal Binary

0000000 0000 1010000 0001 2020000 0010 3030000 0011 4040000 0100 5050000 0101 6060000 0110 7070000 0111 8080000 1000

9090000 1001 10 0A 0000 1010 11 0B 0000 1011 12 0C 0000 1100 13 0D 0000 1101 14 0E 0000 1110 15 0F 0000 1111 16 10 0001 0000 17 11 0001 0001 18 12 0001 0010 19 13 0001 0011 20 14 0001 0100 21 15 0001 0101 22 16 0001 0110 23 17 0001 0111 24 18 0001 1000 25 19 0001 1001 26 1A 0001 1010 27 1B 0001 1011 28 1C 0001 1100 29 1D 0001 1101 30 1E 0001 1110 31 1F 0001 1111

Decimal Hexadecimal Binary

32 20 0010 0000 33 21 0010 0001 34 22 0010 0010 35 23 0010 0011 36 24 0010 0100 37 25 0010 0101 38 26 0010 0110 39 27 0010 0111 40 28 0010 1000 41 29 0010 1001 42 2A 0010 1010 43 2B 0010 1011 44 2C 0010 1100 45 2D 0010 1101 46 2E 0010 1110 47 2F 0010 1111 48 30 0011 0000 49 31 0011 0001 50 32 0011 0010 51 33 0011 0011 52 34 0011 0100 53 35 0011 0101 54 36 0011 0110 55 37 0011 0111 56 38 0011 1000 57 39 0011 1001 58 3A 0011 1010 59 3B 0011 1011 60 3C 0011 1100 61 3D 0011 1101 62 3E 0011 1110 63 3F 0011 1111

Decimal Hexadecimal Binary

64 40 0100 0000 65 41 0100 0001 66 42 0100 0010 67 43 0100 0011 68 44 0100 0100 69 45 0100 0101 70 46 0100 0110 71 47 0100 0111 72 48 0100 1000 73 49 0100 1001 74 4A 0100 1010 75 4B 0100 1011 76 4C 0100 1100 77 4D 0100 1101 78 4E 0100 1110 79 4F 0100 1111 80 50 0101 0000 81 51 0101 0001 82 52 0101 0010 83 53 0101 0011 84 54 0101 0100 85 55 0101 0101 86 56 0101 0110 87 57 0101 0111 88 58 0101 1000 89 59 0101 1001 90 5A 0101 1010 91 5B 0101 1011 92 5C 0101 1100 93 5D 0101 1101 94 5E 0101 1110 95 5F 0101 1111

Decimal Hexadecimal Binary

96 60 0110 0000 97 61 0110 0001 98 62 0110 0010

99 63 0110 0011 100 64 0110 0100 101 65 0110 0101 102 66 0110 0110 103 67 0110 0111 104 68 0110 1000 105 69 0110 1001 106 6A 0110 1010 107 6B 0110 1011 108 6C 0110 1100 109 6D 0110 1101 110 6E 0110 1110 111 6F 0110 1111 112 70 0111 0000 113 71 0111 0001 114 72 0111 0010 115 73 0111 0011 116 74 0111 0100 117 75 0111 0101 118 76 0111 0110 119 77 0111 0111 120 78 0111 1000 121 79 0111 1001 122 7A 0111 1010 123 7B 0111 1011 124 7C 0111 1100 125 7D 0111 1101 126 7E 0111 1110 127 7F 0111 1111

• Except the table above, for example 144-159(decimal)/9nH/1001 0000-1001 1111(binary) denotes the Note On Message for each channel (1-16). 176-191/BnH/ 1011 0000-1011 1111 denotes the Control Change Message for each channel (1-16). 192-207/CnH/1100 0000-1100 1111 denotes the Program Change Message for each channel (1-16). 240/FOH/1111 0000 denotes the start of a System Exclusive Message. 247/F7H/1111 0111 denotes the end of a System Exclusive Message.

• aaH (hexidecimal)/0aaaaaaa (binary) denotes the data address. The address contains High, Mid, and Low.

• bbH/0bbbbbbb denotes the byte count.

• ccH/0ccccccc denotes the check sum.

• ddH/0ddddddd denotes the data/value.

O: available

PSR-2100 PSR-1100 Regular Voice O O Organ (Organ Flutes) Voice O Mic O Vocal Harmony O M. Pad (Multi Pad) O O

31

MIDI CHANNEL MESSAGE (1)

MIDI Events Status byte 1st Data byte 2nd Data byte

Key Off 8nH (n: Channel

Key On 9nH (n: Channel

Control Change

Mode Message

Status Data (HEX) Parameter Data (HEX) Parameter Regular/

Number)

BnH (n: Channel

Number)

BnH (n: Channel

Number)

kk Key no.

0(00H) Bank Select

1(01H) Modulation 0 – 127 (00H – 7FH) Data O X X O O O

5(05H) Portamento

6(06H) Data Entry

7(07H) Main Volume 0 – 127 (00H – 7FH) Data O O

10 (0AH) Panpot 0 – 127 (00H – 7FH) L64 – C – R63 O O

11 (0BH) Expression 0 – 127 (00H – 7FH) Data O X O O O O

32 (20H) Bank Select

38 (26H) Data Entry

64 (40H) Sustain

65 (41H) Portamento 0 – 127 (00H – 7FH) 0 – 63,

66 (42H) Sostenuto 0 – 127 (00H – 7FH) 0 – 63,

67 (43H) Soft Pedal 0 – 127 (00H – 7FH) 0 – 63,

71 (47H) Harmonic

72 (48H) Release

73 (49H) Attack Time 0 – 127 (00H – 7FH) -64 – 0 – +63 O X X O O O

74 (4AH) Brightness 0 – 127 (00H – 7FH) -64 – 0 – +63 O X X O O O

84 (54H) Portamento

91 (5BH) Effect1

93 (5DH) Effect3

94 (5EH) Effect4

96 (60H) RPN

97 (61H) RPN

98 (62H) NRPN LSB 0 – 127 (00H – 7FH) Data O O

99 (63H) NRPN MSB 0 – 127 (00H – 7FH) Data O O

100 (64H) RPN LSB 0 – 127 (00H – 7FH) Data O O

101 (65H) RPN MSB 0 – 127 (00H – 7FH) Data O O

120 (78H) All Sound Off 0 (00H) Data O X O O O O

121 (79H) Reset All

122 (7AH) Local Control 0

123 (7BH) All Note Off 0 (00H) Data O O

124 (7CH) Omni Off 0 (00H) Data O X X O X X X X X X O X O X 125 (7DH) Omni On 0 (00H) Data O X X O X X X X X X O X O X 126 (7EH) Mono 0 – 16 (00H – 10H) Data O X X O X X X X X X O X O X 127 (7FH) Poly 0 (00H) Data O X X O X X X X X X O X O X

(0 – 127)

MSB

Time

MSB

LSB

(Damper)

Content

Time

Control

Depth (Reverb Send Level)

Depth (Chorus Send Level)

Depth (Variation Send Level)

Increment

Decrement

Controllers

vv Velocity

vv Key On:

0(00H) Normal O X O O O O

64 (40H) SFX voice 126 (7EH) SFX kit 127 (7FH) Drum kit

0 – 127 (00H – 7FH) Data O X X O O O

0 – 127 (00H – 7FH) Data O O

0 – 127 (00H – 7FH) Data O X O O O O

0 – 127 (00H – 7FH) Data O O

0 – 127 (00H – 7FH) -64 – 0 – +63 O X X O O O

0 – 127 (00H – 7FH) Key no.

0 – 127 (00H – 7FH) Data O O

--*1 OO

0(00H) Data O X O O X X X X X X O X O X

(00H)

127

(7FH)

(0 – 127)

vv=1 – 127 Key Off: vv=0

64 – 127 (OFF, ON)

(0 – 127)

OFF ON

Corresponding Voice/Part

Mic/Vocal Harmony Natural

Organ

Voice

OO

(Harmony Channel/

Melody Channel)

OO

(Harmony Channel/

Melody Channel)

(Harmony Channel/

Melody Channel)

(Mic)

(Harmony Channel/

Melody Channel)

(Harmony Channel/

Melody Channel)

OXXOOO

OXOOO O

OXXOOXOOO

(Mic)

(Harmony Channel/

Melody Channel)

(Harmony Channel/

Melody Channel)

(Harmony Channel/

Melody Channel)

(Harmony Channel/

Melody Channel)

(Harmony Channel/

Melody Channel)

(Harmony Channel/

Melody Channel)

---OOOOOXXXXXX

(Harmony Channel/

Melody Channel)

MIDI Reception (respond/ignore) MIDI Transmission (generated data)

Song Main

Voice

OOO O OO X XXXOX

OOO O OO O

OOO O

XOOO (Main/

OOO X OO X XOXOX

XOO X OO O

OOO O

OOOO (Main/

Keyboard Style Extra Panel

Layer

Left

OO O

(Main)

(Main/Layer/

Layer/Left)

(Main/Layer/

Layer/Left)

OO O

Left)

XO O

Left)

OO O

Left)

OO O

Left)

OO O

Left)

OO O

Left)

OO O

(Main)

XO O

Left)

XO O

Left)

XO O

Left)

XO O

Left)

XO O

Left)

OO O

Left)

OO O

Left)

OO O

Left)

XO O

Left)

OO O

Left)

OO O

Left)

OO O

Left)

OO O

Left)

OO X X O XOX

Left)

OO X X O XOX

(main generation

method

)

(Keyboard)

(Voice)

(Wheel *5,

Pedal)

(Mixing

Console)

(Mixing

Console)

(Mixing

Console)

(Mixing

Console)

(Pedal)

(Voice)

(Mixing

Console)

(Pedal)

(Poly/Mono Sw)

(Pedal)

(Mixing

Console)

(Sound

Creator)

(Sound

Creator)

(Sound

Creator)

(Auto Accom-

paniment)

(Mixing

Console)

(Mixing

Console)

(Mixing

Console)

(Sound

Creator)

(Sound

Creator)

(Mixing

Console)

(Mixing

Console)

Upper Lower

OOOOX

XOOOX

OOOOX

XOXOX

XOOOX

OOOOX

XOOOX

XOXOX

OOXOX

XOOOX

XOXOX

XOOOX

O: available

M.Pad Style Song MIDI

32

MIDI Events Status byte 1st Data byte 2nd Data byte

Program Change

Channel After Touch

Polyphonic After Touch

Pitch Bend Change

Realtime Message

*1 The data byte is ignored. *2 Received when the Clock is set to External. *3 Transmitted when the Clock is set to Internal and Transmit Clock is set to on. *4 Transmitted when the Transmit Clock is set to on. *5 PSR-2100 only.

About Mic/Vocal Harmony column: The relevant parameters are received by the song part designated by the Effect's Harmony Channel Parameter or Melody Parameter.

Status Data (HEX) Parameter Data (HEX) Parameter Regular/

CnH (n: Channel

Number)

DnH (n: Channel

Number)

AnH (n: Channel

Number)

EnH (n: Channel

Number)

F8H MIDI Clock - - - ----O (*2) O (*3) FAH Start - - - ----O (*2) O (*4) FBH Continue - - - ----X X FCH Stop - - - ----O (*2) O (*4) FEH Active Sens - - - ----O O FFH System

Reset

pp (00H – 7FH) Voice

vv (00H – 7FH) Data - - -OXXOOO

kk (00H – 7FH) Key no.

cc (00H – 7FH) LSB dd (00H – 7FH) MSB O O

- - - ----X X

Number (0 – 127)

(0 – 127)

- - -OXOOO O

vv (00H – 7FH) Data X X X X X X X X X X X X O X

Corresponding Voice/Part

Mic/Vocal Harmony Natural

Organ

Voice

(Harmony Channel/

Melody Channel)

MIDI Reception (respond/ignore) MIDI Transmission (generated data)

Song Main

Voice

OOO O

Keyboard Style Extra Panel

Layer

Left

(Main/Layer/

OO O

(Main)

XO X X OXOX

Left)

OO O

Left)

(main generation

method

)

(Voice)

(Wheel, Pedal)

Upper

M.Pad Style Song MIDI

Lower

XOOOX

OOOOX

MIDI CHANNEL MESSAGE (2)

NRPN

NRPN Data Entry Parameter Data Range Corresponding Voice/Part MIDI Reception (respond/ignore) MIDI Transmission (generated data)

MSB LSB MSB LSB Regular/

01H 08H mmH -- Vibrato Rate mm: 00H – 40H – 7FH

01H 09H mmH -- Vibrato Depth mm: 00H – 40H – 7FH

01H 0AH mmH -- Vibrato Delay mm: 00H – 40H – 7FH

01H 20H mmH -- Low Pass Filter Cutoff

01H 21H mmH -- Low Pass Filter Resonance mm: 00H – 40H – 7FH

01H 30H mmH -- EQ BASS (*1) mm: 00H – 40H – 7FH

01H 31H mmH -- EQ TREBLE (*1) mm: 00H – 40H – 7FH

01H 34H mmH -- EQ BASS Frequency (*1) mm: 04H – 28H (32 – 2.0k[Hz]) O X X O X X X X X X X X O X 01H 35H mmH -- EQ TREBLE Frequency (*1) mm: 1CH – 3AH (500 – 16.0k[Hz]) O X X O X X X X X X X X O X 01H 63H mmH -- EG Attack Time mm: 00H – 40H – 7FH

01H 64H mmH -- EG Decay Time mm: 00H – 40H – 7FH

01H 66H mmH -- EG Release mm: 00H – 40H – 7FH

14H rrH mmH -- Drum Low Pass Filter Cutoff

15H rrH mmH -- Drum Low Pass Filter

16H rrH mmH -- Drum EG Attack Rate rr: drum instrument note number

17H rrH mmH -- Drum EG Decay Rate rr: drum instrument note number

18H rrH mmH -- Drum Pitch Coarse rr: drum instrument note number

19H rrH mmH -- Drum Pitch Fine rr: drum instrument note number

1AH rrH mmH -- Drum Level rr: drum instrument note number

1CH rrH mmH -- Drum Pan rr: drum instrument note number

1DH rrH mmH -- Drum Reverb Send Level rr: drum instrument note number

1EH rrH mmH -- Drum Chorus Send Level rr: drum instrument note number

1FH rrH mmH -- Drum Variation Send Level rr: drum instrument note number

NRPN MSB: 14H-1FH (for drums) message is accepted as long as the channel is set with a drum voice. Data Entry LSB: Ignored.

Frequency

Resonance

(-64 – 0 – +63)

mm: 00H – 40H – 7FH (-64 – 0 – +63)

(-64 – 0 – +63)

(-64 – 0 – +63) rr: drum instrument note number

mm: 00H – 40H – 7FH (-64 – 0 – +63)

rr: drum instrument note number mm: 00H – 40H – 7FH (-64 – 0 – +63)

mm: 00H – 40H – 7FH (-64 – 0 – +63)

mm: 00H – 7FH (0 – 127)

mm: 00H, 01H – 40H – 7FH (RND, L63 – C – R63)

mm: 00H – 7FH (0 – 127)

mm: 00H – 7FH (0 – 127) (Variation Connection= SYSTEM) mm: 00H, 01H – 7FH (OFF, ON) (Variation Connection= INSERTION)

Organ Voice

(Drum Only)

Mic/Vocal

OO

(Harmony

Channel)

OO

(Harmony

Channel)

OO

(Harmony

Channel)

OXXOXXOX X XOXOX

OXXOXXOXXXXXOX

OXXOXXOX X XOXOX

OXXOOXOO O

OXXOXXOX X XOXOX

O

Natural

Harmony

Channel/

Melody

Channel/

Melody

Channel/

Melody

XXOXXXXXXXOOX

Song Main

Voice

XOOXOO O

Keyboard Style Extra Panel

Layer

Left

(main generation

method)

(Sound Creator)

Upper

M.Pad Style Song MIDI

Lower

X OOOX

33

NRPN (Vocal Harmony)

NRPN Data Entry Parameter Data Range Corresponding Voice/Part MIDI Reception (respond/ignore) MIDI Transmission (generated data)

MSB LSB MSB LSB Regular/

00H 00H mmH -- Harmony Mute (*1) 0 – 63, 64 – 127 (Off, On) X O

01H 1AH mmH -- Detune Modulation (*1) mm: 00H – 7FH (0 – 127) X O

02H 10H mmH -- Harmony1 Volume (*1) mm: 00H – 7FH (0 – 127) X O

02H 11H mmH -- Harmony2 Volume (*1) mm: 00H – 7FH (0 – 127) X O

02H 12H mmH -- Harmony3 Volume (*1) mm: 00H – 7FH (0 – 127) X O

02H 20H mmH -- Harmony1 Pan (*1) mm: 00H, 01H – 40H – 7FH

02H 21H mmH -- Harmony2 Pan (*1) mm: 00H, 01H – 40H – 7FH

02H 30H mmH -- Harmony1 Detune (*1) mm: 00H – 40H – 7FH

02H 31H mmH -- Harmony2 Detune (*1) mm: 00H – 40H – 7FH

Data Entry LSB: Ignored.

(RND, L63 – C – R63)

(-64 – 0 – +63)

Organ Voice

Mic/Vocal

(Harmony Channel)

XO

(Harmony Channel)

XO

(Harmony Channel)

XO

(Harmony Channel)

XO

(Harmony Channel)

Harmony

Natural

Song Main

Voice

XXXXXX X XXXOX

XXXXXX O

Keyboard Style Extra Panel

Layer

Left

(main generation

method)

(Vocal Harmony

Type Edit)

(Vocal Harmony

Type Edit)

(Vocal Harmony

Type Edit)

(Vocal Harmony

Type Edit)

(Vocal Harmony

Type Edit)

(Vocal Harmony

Type Edit)

(Vocal Harmony

Type Edit)

Upper

M.Pad Style Song MIDI

Lower

XXXOX

RPN

NRPN Data Entry Parameter Data Range Corresponding Voice/Part MIDI Reception (respond/ignore) MIDI Transmission (generated data)

MSB LSB MSB LSB Regular/

00H 00H mmH -- Pitch Bend Sensitivity mm: 00H – 18H

00H 01H mmH llH Fine Tune mm ll : 00H 00H -100[cent]

00H 02H mmH -- Coarse Tune mm: 28H – 40H – 58H

7FH 7FH -- -- Null - O O O O O O

(0 – +24[semitones])

... mm ll : 40H 00H 0[cent] ... mm ll : 7FH 7FH 100[cent]

(-24 – 0 – +24[semitones])

Organ Voice

Mic/Vocal

OO

(Harmony

Channel)

OXOOOO

Harmony

Channel/

Melody

Natural

Song Main

Voice

OOOO

Keyboard Style Extra Panel

Layer

Left

(Main/ Layer/

Left)

(Main/ Layer/

Left)

(Main/ Layer/

Left)

(Main/ Layer/

Left)

Upper

(main generation

OO O

OO X XOOOX

method)

(Mixing Console)

M.Pad Style Song MIDI

Lower

X OOOX

*1 PSR-2100 only About Mic/Vocal Harmony column:

The relevant parameters are received by the song part designated by the Effect's Harmony Channel Parameter or Melody Parameter.

34

MIDI PARAMETER CHANGE TABLE

* Not Received when Receive System Exclusive Message Parameters is set to off. * Not transmitted when Transmit System Exclusive Message Parmeters is set to off.

MIDI Parameter Change table (XG SYSTEM)

Address Size Data Parameter Description XG Default Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)

(H) (H) (H) (H) Regular/

00 00 00 4 00 – 0F MASTER TUNE -102.4 – 0 – +102.3[cent] *Panel setting

01 00 – 0F 1st bit 3 – 0→bit 15 – 12 02 00 – 0F 2nd bit 3 – 0→bit 11 – 8 03 00 – 0F 3rd bit 3 – 0→bit 7 – 4

04 1 00 – 7F MASTER VOLUME 0 – 127 7F O X O O X X X X X X X O X 05 1 00 – 7F MASTER ATTENUATOR 0 – 127 00 X X X X X X X X X XXXX 06 1 28 – 58 TRANSPOSE -24 – 0 – +24[semitones] 40 O X O O X X X X X X X O X

7D 1NDRUM SETUP RESET N: Drum setup number - O

7E 100XG SYSTEM ON 00=XG system ON - O X O O X X X O X X X O X 7F 100ALL PARAMETER RESET 00=ON - O X O O X X X O X X X O X

TOTAL SIZE 07

4th bit 3 – 0→bit 3 – 0

value

Mic/Vocal

Natural

Organ Voice

Harmony

OXOO O (Function) X X O X

(Drum only)

X XOX XXX X XXOX

Voice

Song Main

Keyboard Style Extra Panel

Layer Left

(main

generation method)

M.Pad Style Song MIDI

MIDI Parameter Change table (SYSTEM INFORMATION)

Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)

(H) (H) (H) Regular/

01 00 00 E 20 – 7F Model Name 1 32 – 127(ASCII CHARACTER) - - - - - - - - X X X X O

... ... ... ...

0D 20 – 7F Model Name 14 32 – 127(ASCII CHARACTER) 0E 1 NOT USED 0F 1 NOT USED

TOTAL SIZE 10 Transmitted in response to Dump Request. Not received.

Organ Voice

Mic/Vocal

Harmony

Natural

Voice

Song Main

Layer Left

Keyboard Style Extra Panel (main

generation method)

M.Pad Style Song MIDI

O: available

MIDI Parameter Change table (EFFECT1)

Address Size Data Parameter Description XG Default Corresponding Voice/Part

(H) (H) (H) (H) Regular/

02 01 00 2 00 – 7F REVERB TYPE MSB Refer to Effect Parameter

00 – 7F REVERB TYPE LSB ˝ 00

02 1 00 – 7F REVERB PARAMETER 1 ˝ 03 1 00 – 7F REVERB PARAMETER 2 ˝ Depends on

04 1 00 – 7F REVERB PARAMETER 3 ˝ Depends on

05 1 00 – 7F REVERB PARAMETER 4 ˝ Depends on

06 1 00 – 7F REVERB PARAMETER 5 ˝ Depends on

07 1 00 – 7F REVERB PARAMETER 6 ˝ Depends on

08 1 00 – 7F REVERB PARAMETER 7 ˝ Depends on

09 1 00 – 7F REVERB PARAMETER 8 ˝ Depends on

0A 1 00 – 7F REVERB PARAMETER 9 ˝ Depends on

0B 1 00 – 7F REVERB PARAMETER 10 ˝ Depends on

0C 1 00 – 7F REVERB RETURN -∞dB – 0dB – +6dB

0D 1 01 – 7F REVERB PAN L63 – C – R63 40 O O X O X X O O X

TOTAL SIZE 0E

02 01 10 1 00 – 7F REVERB PARAMETER 11 Refer to Effect Parameter

11 1 00 – 7F REVERB PARAMETER 12 ˝ Depends on

12 1 00 – 7F REVERB PARAMETER 13 ˝ Depends on

13 1 00 – 7F REVERB PARAMETER 14 ˝ Depends on

14 1 00 – 7F REVERB PARAMETER 15 ˝ Depends on

15 1 00 – 7F REVERB PARAMETER 16 ˝ Depends on

TOTAL SIZE 06

List

(0 – 96 – 127)

List

01 (=HALL1) O O X O O (Mixing Console) X O O X

Depends on Reverb Type

Reverb Type

40 OOXOO (Mixing Console) X O O X

Depends on Reverb Type

Reverb Type

Mic/Vocal

Organ Voice

Harmony

OOXO (*Depends on Reverb Type) O (Mixing Console X O O X OOXO (*Depends on Reverb Type) O (Mixing Console

OOXO (*Depends on Reverb Type) O (Mixing Console

MIDI Reception (effective or not for each part)

Natural

Voice

Song Main

Keyboard Style Extra Panel (main

Layer Left

MIDI Transmission (generated data)

generation method)

*Depends on Reverb

Type)

*Depends on Reverb

Type)

*Depends on Reverb

Type )

*Depends on Reverb

Type)

*Depends on Reverb

Type)

*Depends on Reverb

Type)

*Depends on Reverb

Type)

*Depends on Reverb

Type)

*Depends on Reverb

Type)

*Depends on Reverb

Type)

*Depends on Reverb

Type)

*Depends on Reverb

Type)

*Depends on Reverb

Type)

*Depends on Reverb

Type)

*Depends on Reverb

Type)

M.Pad Style Song MIDI

XOOX

35

Address Size Data Parameter Description XG Default Corresponding Voice/Part

(H) (H) (H) (H) Regular/

02 01 20 2 00 – 7F CHORUS TYPE MSB Refer to Effect Parameter

00 – 7F CHORUS TYPE LSB ˝ 00

22 1 00 – 7F CHORUS PARAMETER 1 ˝ Depends on

23 1 00 – 7F CHORUS PARAMETER 2 ˝ Depends on

24 1 00 – 7F CHORUS PARAMETER 3 ˝ Depends on

25 1 00 – 7F CHORUS PARAMETER 4 ˝ Depends on

26 1 00 – 7F CHORUS PARAMETER 5 ˝ Depends on

27 1 00 – 7F CHORUS PARAMETER 6 ˝ Depends on

28 1 00 – 7F CHORUS PARAMETER 7 ˝ Depends on

29 1 00 – 7F CHORUS PARAMETER 8 ˝ Depends on

2A 1 00 – 7F CHORUS PARAMETER 9 ˝ Depends on

2B 1 00 – 7F CHORUS PARAMETER 10 ˝ Depends on

2C 1 00 – 7F CHORUS RETURN -∞dB – 0dB – +6dB

2D 1 01 – 7F CHORUS PAN L63 – C – R63 40 O O X O X X X O X 2E 1 00 – 7F SEND CHORUS TO

TOTAL SIZE 0F

REVERB

List

(0 – 96 – 127)

-∞dB – 0dB – +6dB (0 – 96 – 127)

41 (=CHORUS1)

Chorus Type

40 OOXOO (Mixing Console) X O O X

00 O O X O XXXOX

Mic/Vocal

Organ Voice

Harmony

OOXOO (Mixing Console) X O O X

OOXO (*Depends on Chorus Type) O (Mixing Console

MIDI Reception (effective or not for each part)

Natural

Voice

Song Main

Keyboard Style Extra Panel (main

Layer Left

MIDI Transmission (generated data)

generation method)

*Depends on Chorus

Type)

*Depends on Chorus

Type)

*Depends on Chorus

Type)

*Depends on Chorus

Type)

*Depends on Chorus

Type)

*Depends on Chorus

Type)

*Depends on Chorus

Type)

*Depends on Chorus

Type)

*Depends on Chorus

Type)

*Depends on Chorus

Type)

M.Pad Style Song MIDI

XOOX

02 01 30 1 00 – 7F CHORUS PARAMETER 11 Refer to Effect Parameter

31 1 00 – 7F CHORUS PARAMETER 12 ˝ Depends on

32 1 00 – 7F CHORUS PARAMETER 13 ˝ Depends on

33 1 00 – 7F CHORUS PARAMETER 14 ˝ Depends on

34 1 00 – 7F CHORUS PARAMETER 15 ˝ Depends on

35 1 00 – 7F CHORUS PARAMETER 16 ˝ Depends on

TOTAL SIZE 06

02 01 40 2 00 – 7F VARIATION TYPE MSB Refer to Effect Parameter

00 – 7F VARIATION TYPE LSB ˝ 00

42 2 00 – 7F VARIATION PARAMETER

44 2 00 – 7F VARIATION PARAMETER

46 2 00 – 7F VARIATION PARAMETER

48 2 00 – 7F VARIATION PARAMETER

4A 2 00 – 7F VARIATION PARAMETER

4C 2 00 – 7F VARIATION PARAMETER

4E 2 00 – 7F VARIATION PARAMETER

50 2 00 – 7F VARIATION PARAMETER

52 2 00 – 7F VARIATION PARAMETER

54 2 00 – 7F VARIATION PARAMETER

56 1 00 – 7F VARIATION RETURN -∞dB – 0dB – +6dB

57 1 01 – 7F VARIATION PAN L63 – C – R63 40 O O X O X X O O X 58 1 00 – 7F SEND VARIATION TO

59 1 00 – 7F SEND VARIATION TO

1 MSB

00 – 7F VARIATION PARAMETER

1 LSB

2 MSB

00 – 7F VARIATION PARAMETER

2 LSB

3 MSB

00 – 7F VARIATION PARAMETER

3 LSB

4 MSB

00 – 7F VARIATION PARAMETER

4 LSB

5 MSB

00 – 7F VARIATION PARAMETER

5 LSB

6 MSB

00 – 7F VARIATION PARAMETER

6 LSB

7 MSB

00 – 7F VARIATION PARAMETER

7 LSB

8 MSB

00 – 7F VARIATION PARAMETER

8 LSB

9 MSB

00 – 7F VARIATION PARAMETER

9 LSB

10 MSB

00 – 7F VARIATION PARAMETER

10 LSB

REVERB

CHORUS

List

˝ Depends on

˝

˝ Depends on

˝

˝ Depends on

˝

˝ Depends on

˝

˝ Depends on

˝

˝ Depends on

˝

˝ Depends on

˝

˝ Depends on

˝

˝ Depends on

˝

˝ Depends on

˝

(0 – 96 – 127)

-∞dB – 0dB – +6dB (0 – 96 – 127)

Depends on Chorus Type

Chorus Type

05 (=DELAY L, C, R)

Variation Type

40 OOXOO (Mixing Console) X O O X

00 O O X O X X O O X

OOXO (*Depends on Chorus Type) O (Mixing Console

OOXOO (Mixing Console) X O O X

OOXO (*Depends on Variation Type) O (Mixing Console

*Depends on Chorus

Type)

*Depends on Chorus

Type)

*Depends on Chorus

Type )

*Depends on Chorus

Type)

*Depends on Chorus

Type)

*Depends on Chorus

Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

XOOX

36

Address Size Data Parameter Description XG Default Corresponding Voice/Part

(H) (H) (H) (H) Regular/

5A 1 00 – 01 VARIATION CONNECTION INSERTION, SYSTEM 00 O O X O X X O O X 5B 1 00 – 7F VARIATION PART

5C 1 00 – 7F MW VARIATION

5D 1 00 – 7F BEND VARIATION

5E 1 00 – 7F CAT VARIATION

5F 1 00 – 7F AC1 VARIATION

60 1 00 – 7F AC2 VARIATION

TOTAL SIZE 21

NUMBER

CONTROL DEPTH

Reception: Part1 – 16 (0 – 15) Transmission: Part1 – 16 (0 – 15) AD (64) OFF (127)

-64 – 0 – +63 40 O O X O X X O O X

-64 – 0 – +63 40 XXXX XXXXX

7F OOXOO (Mixing Console) X O O X

Organ Voice

Mic/Vocal

Harmony

MIDI Reception (effective or not for each part)

Natural

Voice

Song Main

Keyboard Style Extra Panel (main

Layer Left

MIDI Transmission (generated data)

generation method)

M.Pad Style Song MIDI

02 01 70 1 00 – 7F VARIATION PARAMETER 11Refer to Effect Parameter

71 1 00 – 7F VARIATION PARAMETER

72 1 00 – 7F VARIATION PARAMETER

73 1 00 – 7F VARIATION PARAMETER

74 1 00 – 7F VARIATION PARAMETER

75 1 00 – 7F VARIATION PARAMETER

TOTAL SIZE 06

12

13

14

15

16

List

˝ Depends on

Depends on Variation Type

Variation Type

OOXO (*Depends on Variation Type) O (Mixing Console

*Depends on

Variation Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

*Depends on

Variation Type)

XOOX

MIDI Parameter Change table (MULTI EQ) (PSR-2100 only)

Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)

(H) (H) (H) Regular/

02 40 00 1 00 – 04 EQ TYPE flat, jazz, pops, rock, classic O O X O X X X O X

01 1 34 – 4C EQ GAIN1 -12 – 0 – +12[dB] O O X O O (Mixing Console) X X O X 02 1 04 – 28 EQ FREQUENCY1 32 – 2.0k[Hz] O O X O O (Mixing Console) X X O X 03 1 01 – 78 EQ Q1 0.1 – 12.0 O O X O O (Mixing Console) X X O X 04 1 00 – 01 EQ SHAPE1 shelving, peaking O O X O X X X O X 05 1 34 – 4C EQ GAIN2 -12 – 0 – +12[dB] O O X O O (Mixing Console) X X O X 06 1 0E – 36 EQ FREQUENCY2 100 – 10.0k[Hz] O O X O O (Mixing Console) X X O X 07 1 01 – 78 EQ Q2 0.1 – 12.0 O O X O O (Mixing Console) X X O X 08 1 NOT USED - - - - - ---09 1 34 – 4C EQ GAIN3 -12 – 0 – +12[dB] O O X O O (Mixing Console) X X O X 0A 1 0E – 36 EQ FREQUENCY3 100 – 10.0k[Hz] O O X O O (Mixing Console) X X O X 0B 1 01 – 78 EQ Q3 0.1 – 12.0 O O X O O (Mixing Console) X X O X 0C 1 NOT USED - - - - - ---0D 1 34 – 4C EQ GAIN4 -12 – 0 – +12[dB] O O X O O (Mixing Console) X X O X 0E 1 0E – 36 EQ FREQUENCY4 100 – 10.0k[Hz] O O X O O (Mixing Console) X X O X 0F 1 01 – 78 EQ Q4 0.1 – 12.0 O O X O O (Mixing Console) X X O X 10 1 NOT USED - - - - - ---11 1 34 – 4C EQ GAIN5 -12 – 0 – +12[dB] O O X O O (Mixing Console) X X O X 12 1 1C – 3A EQ FREQUENCY5 0.5k – 16.0k[Hz] O O X O O (Mixing Console) X X O X 13 1 01 – 78 EQ Q5 0.1 – 12.0 O O X O O (Mixing Console) X X O X 14 1 00 – 01 EQ SHAPE5 shelving, peaking O O X O X X X O X

TOTAL SIZE 5 The MULTI EQ Parameter cannot be reset to its factory setting with XG SYSTEM ON.

Organ Voice

Mic/Vocal Harmony

Natural

Voice

Song Main

Layer Left

Keyboard Style Extra Panel (main

generation method)

M.Pad Style Song MIDI

MIDI Parameter Change table (EFFECT2) (PSR-2100 only)

Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)

(H) (H) (H) Regular/

03n00200 – 7F INSERTION EFFECT TYPE

02 1 00 – 7F INSERTION EFFECT

03 1 00 – 7F INSERTION EFFECT

04 1 00 – 7F INSERTION EFFECT

05 1 00 – 7F INSERTION EFFECT

06 1 00 – 7F INSERTION EFFECT

07 1 00 – 7F INSERTION EFFECT

08 1 00 – 7F INSERTION EFFECT

09 1 00 – 7F INSERTION EFFECT

0A 1 00 – 7F INSERTION EFFECT

MSB

00 – 7F INSERTION EFFECT TYPE

LSB

PARAMETER 1

PARAMETER 2

PARAMETER 3

PARAMETER 4

PARAMETER 5

PARAMETER 6

PARAMETER 7

PARAMETER 8

PARAMETER 9

Refer to Effect Parameter List

˝

˝OOX O (*Depends on Insertion Type ) O (Mixing Console

Mic/Vocal

Natural

Organ Voice

Harmony

OOXOO (Mixing Console) X X O X

Voice

Song Main

Keyboard Style Extra Panel (main

Layer Left

generation method)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

M.Pad Style Song MIDI

X XOX

37

Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)

(H) (H) (H) Regular/

0B 1 00 – 7F INSERTION EFFECT

0C 1 00 – 7F INSERTION EFFECT PART

0D 1 00 – 7F MW INSERTION CONTROL

0E 1 00 – 7F BEND INSERTION

0F 1 00 – 7F CAT INSERTION CONTROL

10 1 00 – 7F AC1 INSERTION CONTROL

11 1 00 – 7F AC2 INSERTION CONTROL

TOTAL SIZE 12

PARAMETER 10

NUMBER

DEPTH

CONTROL DEPTH

DEPTH

Reception: Part1 – 16 (0 – 15) Transmission: Part1 – 16 (0 – 15) AD (64) OFF (127)

-64 – 0 – +63 O O X O X X X O X

-64 – 0 – +63 XXXX XXXXX

˝OOX O (*Depends on Insertion Type ) O (Mixing Console

Mic/Vocal

Natural

Organ Voice

Harmony

OOXOO (Mixing Console) X X O X

Voice

Song Main

Keyboard Style Extra Panel (main

Layer Left

generation method)

*Depends on Insertion

Type)

M.Pad Style Song MIDI

X XOX

03n20100 – 7F INSERTION EFFECT

21 1 00 – 7F INSERTION EFFECT

22 1 00 – 7F INSERTION EFFECT

23 1 00 – 7F INSERTION EFFECT

24 1 00 – 7F INSERTION EFFECT

25 1 00 – 7F INSERTION EFFECT

TOTAL SIZE 6

03n30200 – 7F INSERTION EFFECT

32 2 00 – 7F INSERTION EFFECT

34 2 00 – 7F INSERTION EFFECT

36 2 00 – 7F INSERTION EFFECT

38 2 00 – 7F INSERTION EFFECT

3A 2 00 – 7F INSERTION EFFECT

3C 2 00 – 7F INSERTION EFFECT

3E 2 00 – 7F INSERTION EFFECT

40 2 00 – 7F INSERTION EFFECT

42 2 00 – 7F INSERTION EFFECT

TOTAL SIZE 14 The EFFECT 2 Parameter cannot be reset to its factory setting with XG SYSTEM ON.

The second byte of the address is considered as an Insertion effect number. n : insertion effect number

For effect types that do not require MSB, the Parameters for Address 02-0B will be received and the Parameters for Address 30-42 will not be received. For effect types that require MSB, the Parameters for Address 30-42 will be received and the Parameters for Address 02-0B will not be received. When Bulk Dumps that include Effect Type data are transmitted, the Parameters for Address 02-0B will always be transmitted. But, effects that require MSB, when the bulk dump is received the Parameters for Address 02-0B will not be received.

*1 PSR-2100: n=0 – 2

PARAMETER 11

PARAMETER 12

PARAMETER 13

PARAMETER 14

PARAMETER 15

PARAMETER 16

PARAMETER 1 MSB

00 – 7F INSERTION EFFECT

PARAMETER 1 LSB

PARAMETER 2 MSB

00 – 7F INSERTION EFFECT

PARAMETER 2 LSB

PARAMETER 3 MSB

00 – 7F INSERTION EFFECT

PARAMETER 3 LSB

PARAMETER 4 MSB

00 – 7F INSERTION EFFECT

PARAMETER 4 LSB

PARAMETER 5 MSB

00 – 7F INSERTION EFFECT

PARAMETER 5 LSB

PARAMETER 6 MSB

00 – 7F INSERTION EFFECT

PARAMETER 6 LSB

PARAMETER 7 MSB

00 – 7F INSERTION EFFECT

PARAMETER 7 LSB

PARAMETER 8 MSB

00 – 7F INSERTION EFFECT

PARAMETER 8 LSB

PARAMETER 9 MSB

00 – 7F INSERTION EFFECT

PARAMETER 9 LSB

PARAMETER 10 MSB

00 – 7F INSERTION EFFECT

PARAMETER 10 LSB

Refer to Effect Parameter List

˝OOX O (*Depends on Insertion Type ) O (Mixing Console

Refer to Effect Parameter List

˝

˝OOX O (*Depends on Insertion Type ) O (Mixing Console

˝

˝OOX O (*Depends on Insertion Type ) O (Mixing Console

˝

˝OOX O (*Depends on Insertion Type ) O (Mixing Console

˝

˝OOX O (*Depends on Insertion Type ) O (Mixing Console

˝

˝OOX O (*Depends on Insertion Type ) O (Mixing Console

˝

˝OOX O (*Depends on Insertion Type ) O (Mixing Console

˝

˝OOX O (*Depends on Insertion Type ) O (Mixing Console

˝

˝OOX O (*Depends on Insertion Type ) O (Mixing Console

˝

˝OOX O (*Depends on Insertion Type ) O (Mixing Console

˝

OOXO (*Depends on Insertion Type ) O (Mixing Console

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

*Depends on Insertion

Type)

X XOX

38

MIDI Parameter Change table (SPECIAL EFFECT) (PSR-2100 only)

Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)

(H) (H) (H) Regular/

04 00 00 2 00 – 7F INSERTION EFFECT TYPE

02 1 00 – 7F INSERTION EFFECT

03 1 00 – 7F INSERTION EFFECT

04 1 00 – 7F INSERTION EFFECT

05 1 00 – 7F INSERTION EFFECT

06 1 00 – 7F INSERTION EFFECT

07 1 00 – 7F INSERTION EFFECT

08 1 00 – 7F INSERTION EFFECT

09 1 00 – 7F INSERTION EFFECT

0A 1 00 – 7F INSERTION EFFECT

0B 1 00 – 7F INSERTION EFFECT

0C 1 00 – 7F INSERTION EFFECT PART

0D 1 00 – 7F MW INSERTION CONTROL

0E 1 00 – 7F BEND INSERTION

0F 1 00 – 7F CAT INSERTION CONTROL

10 1 00 – 7F AC1 INSERTION CONTROL

11 1 00 – 7F AC2 INSERTION CONTROL

TOTAL SIZE 12

MSB

00 – 7F INSERTION EFFECT TYPE

LSB

PARAMETER 1 Harmony Mode

PARAMETER 2 Harmony Gender Type

PARAMETER 3 Lead Gender Type

PARAMETER 4 Lead Gender Depth

PARAMETER 5 Lead Pitch Correction

PARAMETER 6 Auto Upper Gender Threshold

PARAMETER 7 Auto Lower Gender Threshold

PARAMETER 8 Upper Gender Depth

PARAMETER 9 Lower Gender Depth

PARAMETER 10

NUMBER

DEPTH

CONTROL DEPTH

DEPTH

Vocoder (89), Chordal (90), Detune (91), Chromatic (92), Thru (0 – 88, 93 – 127)

Off (0), Auto (1)XOXXX XXXO (VH Type Select) X X O X

Off (0), Unison (1), Male (2), Female (3)

-64 – 0 – +63 (0 – 127) X O X X X X X X O (VH Type Select) X X O X

Free (0), Correct (1)XOXXX XXXO (VH Type Select) X X O X

0 – 12 (0 – 12) XOXXX XXXO (VH Type Select) X X O X

-64 – 0 – +63 (0 – 127) X O X X X X X X O (VH Type Select) X X O X

L63>H – L=H – L<H63 (1 – 64 – 127)

AD (64), OFF (0 – 63, 65 – 127)

-64 – 0 – +63 XXXXX XXXXXXXX

Mic/Vocal

Natural

Organ Voice

Harmony

XOXXX XXXO (VH Type Select) X X O X

XOXXX XXXO (MicSetting) X X O X

XOXXX XXXO (Vocal Harmony

Voice

Song Main

Keyboard Style Extra Panel (main generation

Layer Left

method)

Sw)

M.Pad Style Song MIDI

X XOX

14 1 00 – 7F UNIQUE INSERTION

15 1 00 – 7F UNIQUE INSERTION

TOTAL SIZE 2

20 1 00 – 7F INSERTION EFFECT

21 1 00 – 7F INSERTION EFFECT

22 1 00 – 7F INSERTION EFFECT

23 1 00 – 7F INSERTION EFFECT

24 1 00 – 7F INSERTION EFFECT

25 1 00 – 7F INSERTION EFFECT

TOTAL SIZE 6 The SPECIAL EFFECT Parameter cannot be reset to its factory setting with XG SYSTEM ON.

EFFECT EXTERNAL CONTROL CH1 (HARMONY CHANNEL)

EFFECT EXTERNAL CONTROL CH1 (MELODY CHANNEL)

PARAMETER 11 Vibrate Depth

PARAMETER 12 Vibrate Rate

PARAMETER 13 Vibrate Delay

PARAMETER 14

PARAMETER 15

PARAMETER 16

1 – 16 (0 – 15), OFF (127) X O X X X X X X O (MicSetting) X X O X

1 – 16 (0 – 15), OFF (127) X O X X X X X X X X X O X

0 – 100cent (0 – 127) X O X X X X X X O (VH Type Select) X X O X

0Hz (0),

0.1 – 12.7Hz (1 – 127)

0 – 2.54sec (0 – 127) X O X X X X X X O (VH Type Select) X X O X

XOXXX XXXO (VH Type Select) X X O X

XXXXX XXXXXXXX

MIDI Parameter Change table (MULTI PART)

Address Size Data Parameter Description XG Default Corresponding Voice/Part

(H) (H) (H) (H) Regular/

08 nn 00 1 00 – 20 ELEMENT RESERVE 0 – 32 part10=00,

01 1 00 – 7F BANK SELECT MSB 0 – 127 part10=7F,

02 1 00 – 7F BANK SELECT LSB 0 – 127 00 O X O O O X O O X X X O X 03 1 00 – 7F PROGRAM NUMBER 0 – 127 00 O X O O O X O O X X X O X 04 1 00 – 0F, 7FRcv CHANNEL 1 – 16, OFF Part No. O X X O X X X X X X X O X

05 1 00 – 01 MONO/POLY MODE MONO, POLY 01 O X X O X X X X X X X O X 06 1 00 – 02 SAME NOTE NUMBER

07 1 00 – 03 PART MODE NORMAL, DRUM,

08 1 00 – 7F CHANNEL TRANSPOSE -24 – 0 – +24[semitones] 40 O X O O O X O O X X X O X 090A2 00 – 0F

0B 1 00 – 7F VOLUME 0 – 127 64 O X O O O X O O X X X O X 0C 1 00 – 7F VELOCITY SENSE DEPTH 0 – 127 40 O X O O O X X O O (Sound Creator) OXOX 0D 1 00 – 7F VELOCITY SENSE

0E 1 00 – 7F PAN RND, L63 – C – R63 40 O X O O O X O O X X X O X 0F 1 00 – 7F NOTE LIMIT LOW C-2 – G8 00 O X X O X X X X X X X O X 10 1 00 – 7F NOTE LIMIT HIGH C-2 – G8 7F O X X O X X X X X X X O X

KEY ON ASSIGN

DETUNE -12.8 – 0 – +12.7[Hz]

00 – 0F

OFFSET

SINGLE, MULTI, INST (for Drum)

DRUMS1 – 2

1st bit3 – 0→bit7 – 4 2nd bit3 – 0→bit3 – 0

0 – 127 40 OXOOO XXOO (Sound Creator) OXOX

other parts=02

other parts =00

01 O X XOX XOX X XXOX

part10=02, other parts=00

08 00 O X O O O X O O X X X O X

Mic/Vocal

Organ Voice

Harmony

OXXOX XXX X XXOX

OXOOO XOO X XXOX

OXOOXXXXO (Drum Voice) X X O X

MIDI Reception (effective or not for each part)

Natural

Voice

Song Main

Keyboard Style Extra Panel (main generation

Layer Left

MIDI Transmission (generated data)

method)

M.Pad Style Song MIDI

39

Address Size Data Parameter Description XG Default Corresponding Voice/Part

(H) (H) (H) (H) Regular/

11 1 00 – 7F DRY LEVEL 0 – 127 7F O X X O O X O O O (Sound Creator) OXOX 12 1 00 – 7F CHORUS SEND 0 – 127 00 O X O O O X O O X X X O X 13 1 00 – 7F REVERB SEND 0 – 127 28 O X O O O X O O X X X O X 14 1 00 – 7F VARIATION SEND 0 – 127 00 O X X O O X O O X X X O X 15 1 00 – 7F VIBRATO RATE -64 – 0 – +63 40 O X X O O X O O X X X O X 16 1 00 – 7F VIBRATO DEPTH -64 – 0 – +63 40 O X X O O X O O X X X O X 17 1 00 – 7F VIBRATO DELAY -64 – 0 – +63 40 O X X O O X O O X X X O X 18 1 00 – 7F FILTER CUTOFF

19 1 00 – 7F FILTER RESONANCE -64 – 0 – +63 40 O X X O O X O O X X X O X 1A 1 00 – 7F EG ATTACK TIME -64 – 0 – +63 40 O X X O O X O O X X X O X 1B 1 00 – 7F EG DECAY TIME -64 – 0 – +63 40 O X X O O X O O X X X O X 1C 1 00 – 7F EG RELEASE TIME -64 – 0 – +63 40 O X X O O X O O X X X O X 1D 1 28 – 58 MW PITCH CONTROL -24 – 0 – +24[semitones] 40 O X X O O X O O X X X O X 1E 1 00 – 7F MW LOW PASS FILTER

1F 1 00 – 7F MW AMPLITUDE

20 1 00 – 7F MW LFO PMOD DEPTH 0 – 127 0A O X X O O X O O X X X O X 21 1 00 – 7F MW LFO FMOD DEPTH 0 – 127 00 O X X O O X O O X X X O X 22 1 00 – 7F MW LFO AMOD DEPTH 0 – 127 00 O X X O O X O O X X X O X 23 1 28 – 58 BEND PITCH CONTROL -24 – 0 – +24[semitones] 42 O X O O O X O O X X X O X 24 1 00 – 7F BEND LOW PASS FILTER

25 1 00 – 7F BEND AMPLITUDE

26 1 00 – 7F BEND LFO PMOD DEPTH 0 – 127 00 O X X O O X O O X X X O X 27 1 00 – 7F BEND LFO FMOD DEPTH 0 – 127 00 O X X O O X O O X X X O X 28 1 00 – 7F BEND LFO AMOD DEPTH 0 – 127 00 O X X O O X O O X X X O X

TOTAL SIZE 29

30 1 00 – 01 Rcv PITCH BEND OFF, ON 01 X X X X X X X X X XXXX 31 1 00 – 01 Rcv CH AFTER TOUCH

32 1 00 – 01 Rcv PROGRAM CHANGE OFF, ON 01 X X X X X X X X X XXXX 33 1 00 – 01 Rcv CONTROL CHANGE OFF, ON 01 X X X X X X X X X XXXX 34 1 00 – 01 Rcv POLY AFTER TOUCH

35 1 00 – 01 Rcv NOTE MESSAGE OFF, ON 01 O X O O X X X X X X X O X 36 1 00 – 01 Rcv RPN OFF, ON 01 X X X X X X X X X XXXX 37 1 00 – 01 Rcv NRPN OFF, ON XG mode=01,

38 1 00 – 01 Rcv MODULATION OFF, ON 01 X X X X X X X X X XXXX 39 1 00 – 01 Rcv VOLUME OFF, ON 01 X X X X X X X X X XXXX 3A 1 00 – 01 Rcv PAN OFF, ON 01 X X X X X X X X X XXXX 3B 1 00 – 01 Rcv EXPRESSION OFF, ON 01 X X X X X X X X X XXXX 3C 1 00 – 01 Rcv HOLD1 OFF, ON 01 X X X X X X X X X XXXX 3D 1 00 – 01 Rcv PORTAMENTO OFF, ON 01 X X X X X X X X X XXXX 3E 1 00 – 01 Rcv SOSTENUTO OFF, ON 01 X X X X X X X X X XXXX 3F 1 00 – 01 Rcv SOFT PEDAL OFF, ON 01 X X X X X X X X X XXXX 40 1 00 – 01 Rcv BANK SELECT OFF, ON 01 X X X X X X X X X XXXX 41 1 00 – 7F SCALE TUNING C -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X X O X 42 1 00 – 7F SCALE TUNING C -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X X O X 43 1 00 – 7F SCALE TUNING D -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X X O X 44 1 00 – 7F SCALE TUNING D -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X X O X 45 1 00 – 7F SCALE TUNING E -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X X O X 46 1 00 – 7F SCALE TUNING F -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X X O X 47 1 00 – 7F SCALE TUNING F -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X X O X 48 1 00 – 7F SCALE TUNING G -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X X O X 49 1 00 – 7F SCALE TUNING G -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X X O X 4A 1 00 – 7F SCALE TUNING A -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X X O X 4B 1 00 – 7F SCALE TUNING A -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X X O X 4C 1 00 – 7F SCALE TUNING B -63 – 0 – +63[cent] 40 O X O O O X O O O (Function) X X O X 4D 1 28 – 58 CAT PITCH CONTROL -24 – 0 – +24[semitones] 40 O X X O O X X O X X X O X 4E 1 00 – 7F CAT LOW PASS FILTER

4F 1 00 – 7F CAT AMPLITUDE

50 1 00 – 7F CAT LFO PMOD DEPTH 0 – 127 00 O X X O O X X O X OXOX 51 1 00 – 7F CAT LFO FMOD DEPTH 0 – 127 00 O X X O O X X O X X X O X 52 1 00 – 7F CAT LFO AMOD DEPTH 0 – 127 00 O X X O O X X O X X X O X 53 1 28 – 58 PAT PITCH CONTROL -24 – 0 – +24[semitones] 40 X X X X X X X X X XXXX 54 1 00 – 7F PAT LOW PASS FILTER

55 1 00 – 7F PAT AMPLITUDE

56 1 00 – 7F PAT LFO PMOD DEPTH 0 – 127 00 X X X X X X X X X XXXX 57 1 00 – 7F PAT LFO FMOD DEPTH 0 – 127 00 X X X X X X X X X XXXX 58 1 00 – 7F PAT LFO AMOD DEPTH 0 – 127 00 X X X X X X X X X XXXX 59 1 00 – 5F AC1 CONTROLLER

5A 1 28 – 58 AC1 PITCH CONTROL -24 – 0 – +24[semitones] 40 X X X X X X X X X XXXX 5B 1 00 – 7F AC1 LOW PASS FILTER

5C 1 00 – 7F AC1 AMPLITUDE

5D 1 00 – 7F AC1 LFO PMOD DEPTH 0 – 127 00 X X X X X X X X X XXXX 5E 1 00 – 7F AC1 LFO FMOD DEPTH 0 – 127 00 X X X X X X X X X XXXX 5F 1 00 – 7F AC1 LFO AMOD DEPTH 0 – 127 00 X X X X X X X X X XXXX 60 1 00 – 5F AC2 CONTROLLER

61 1 28 – 58 AC2 PITCH CONTROL -24 – 0 – +24[semitones] 40 X X X X X X X X X XXXX 62 1 00 – 7F AC2 LOW PASS FILTER

63 1 00 – 7F AC2 AMPLITUDE

64 1 00 – 7F AC2 LFO PMOD DEPTH 0 – 127 00 X X X X X X X X X XXXX 65 1 00 – 7F AC2 LFO FMOD DEPTH 0 – 127 00 X X X X X X X X X XXXX 66 1 00 – 7F AC2 LFO AMOD DEPTH 0 – 127 00 X X X X X X X X X XXXX 67 1 00 – 01 PORTAMENTO SWITCH OFF, ON 00 O X X O O X X O X X X O X 68 1 00 – 7F PORTAMENTO TIME 0 – 127 00 O X X O O X X O X X X O X 69 1 00 – 7F PITCH EG INITIAL LEVEL -64 – 0 – +63 40 X X X X X X X X X XXXX

FREQUENCY

CONTROL

(CAT)

(PAT)

CONTROL

NUMBER

CONTROL

NUMBER

CONTROL

-64 – 0 – +63 40 O X X O O X O O X X X O X

-9600 – 0 – +9450[cent] 40 O X X O O X O O X X X O X

-100 – 0 – +100[%] 40 O X X O O X O O X X X O X

-9600 – 0 – +9450[cent] 40 O X X O O X O O X X X O X

-100 – 0 – +100[%] 40 O X X O O X O O X X X O X

OFF, ON 01 X X X X X X X X X XXXX

GM mode=00

-9600 – 0 – +9450[cent] 40 O X X O O X X O X X X O X

-100 – 0 – +100[%] 40 O X X O O X X O X OXOX

-9600 – 0 – +9450[cent] 40 X X X X X X X X X XXXX

-100 – 0 – +100[%] 40 X X X X X X X X X XXXX

0 – 95 10 XXXXX XXXXXXXX

-9600 – 0 – +9450[cent] 40 X X X X X X X X X XXXX

-100 – 0 – +100[%] 40 X X X X X X X X X XXXX

0 – 95 11 XXXXX XXXXXXXX

-9600 – 0 – +9450[cent] 40 X X X X X X X X X XXXX

-100 – 0 – +100[%] 40 X X X X X X X X X XXXX

Mic/Vocal

Organ Voice

Harmony

XXXXX XXXXXXXX

MIDI Reception (effective or not for each part)

Natural

Voice

Song Main

Keyboard Style Extra Panel (main generation

Layer Left

MIDI Transmission (generated data)

method)

M.Pad Style Song MIDI

40

Address Size Data Parameter Description XG Default Corresponding Voice/Part

(H) (H) (H) (H) Regular/

6A 1 00 – 7F PITCH EG ATTACK TIME -64 – 0 – +63 40 X X X X X X X X X XXXX 6B 1 00 – 7F 6C 1 00 – 7F PITCH EG RELEASE TIME -64 – 0 – +63 40 X X X X X X X X X XXXX 6D 1 01 – 7F VELOCITY LIMIT LOW 1 – 127 01 X X X X X X X X X XXXX 6E 1 01 – 7F VELOCITY LIMIT HIGH 1 – 127 7F X X X X X X X X X XXXX

TOTAL SIZE 3F

70 1 NOT USED - - - - - - - - - - ---71 1 NOT USED - - - - - - - - - - ---72 1 00 – 7F EQ BASS GAIN -12dB – +12dB 40 O (*2) X X O *2) O (*2) X O (*2) O (*2) O (Mixing Console)

73 1 00 – 7F EQ TREBLE GAIN -12dB – +12dB 40 O (*2) X X O (*2) O (*2) X O (*2) O (*2) O (Mixing Console)

TOTAL SIZE 04

74 1 NOT USED - - - - - - - - - - ---75 1 NOT USED - - - - - - - - - - ---76 1 04 – 28 EQ BASS FREQUENCY 32 – 2.0k[Hz] 0C O (*2) X X O (*2) O (*2) X X O (*2) O (Sound Creator) (*2) OXOX 77 1 1C – 3A EQ TREBLE FREQUENCY 500 – 16.0k[Hz] 36 O (*2) X X O (*2) O (*2) X X O (*2) O (Sound Creator) (*2) OXOX 78 1 NOT USED - - - - - - - - - - ---79 1 NOT USED - - - - - - - - - - ---7A 1 NOT USED - - - - - - - - - - ---7B 1 NOT USED - - - - - - - - - - ---7C 1 NOT USED - - - - - - - - - - ---7D 1 NOT USED - - - - - - - - - - ---7E 1 NOT USED - - - - - - - - - - ---7F 1 NOT USED - - - - - - - - - - ----

TOTAL SIZE 0C

nn = PART NUMBER If there is a Drum Voice assigned to the part, the following parameters are ineffective.

• BANK SELECT LSB

• MONO/POLY MODE

• SCALE TUNING

• PORTAMENTO

• PITCH EG

• FILTER MODULATION DEPTH (FMOD DEPTH)

• AMPLITUDE MODULATION DEPTH (AMOD DEPTH) *2 On PSR-2100, the following parameters are not accepted, or are not transmitted by the Panel operations.

• EQ BASS GAIN

• EQ TREBLE GAIN

• EQ BASS FREQUENCY

• EQ TREBLE FREQUENCY

PITCH EG RELEASE LEVEL

-64 – 0 – +63 40 XXXXX XXXXXXXX

Organ Voice

Mic/Vocal

Harmony

MIDI Reception (effective or not for each part)

Natural

Voice

Song Main

Keyboard Style Extra Panel (main generation

Layer Left

MIDI Transmission (generated data)

method)

(*2)

M.Pad Style Song MIDI

OOOX

MIDI Parameter Change table (A/D PART) (PSR-2100 only)

Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)

(H) (H) (H) Regular/

10 00 00 1 00 – 01 INPUT GAIN MIC, LINE X X X X X X X X X XXXX

01 1 00 – 7F BANK SELECT MSB 0 – 127 X X X X X X X X X XXXX 02 1 00 – 7F BANK SELECT LSB 0 – 127 X X X X X X X X X XXXX 03 1 00 – 7F PROGRAM NUMBER 0 – 127 X X X X X X X X X XXXX 04 1 00 – 1F, 7FRcv CHANNEL 1 – 16, OFF X O X X X X X X X X X O X

05 1 NOT USED - - - - - - - - - ---06 1 NOT USED - - - - - - - - - ---07 1 NOT USED - - - - - - - - - ---08 1 NOT USED - - - - - - - - - ---09 1 NOT USED - - - - - - - - - ---0A 1 NOT USED - - - - - - - - - ---0B 1 00 – 7F VOLUME 0 – 127 X O X X X X X X O (Mixing Console) X X O X 0C 1 NOT USED - - - - - - - - - ---0D 1 NOT USED - - - - - - - - - ---0E 1 01 – 7F PAN L63 – C – R63 X O X X X X X X O (Mixing Console) X X O X 0F 1 NOT USED - - - - - - - - - ---10 1 NOT USED - - - - - - - - - ---11 1 00 – 7F DRY LEVEL X O X X X X X X X X X O X 12 1 00 – 7F CHORUS SEND X O X X X X X X O (Mixing Console) X X O X 13 1 00 – 7F REVERB SEND X O X X X X X X O (Mixing Console) X X O X 14 1 00 – 7F VARIATION SEND X O X X X X X X X X X O X

TOTAL SIZE 15

10 0n 30 1 NOT USED - - - - - - - - - ----

31 1 NOT USED - - - - - - - - - ---32 1 00 – 01 Rcv PROGRAM CHANGE OFF, ON X X X X X X X X X XXXX 33 1 00 – 01 Rcv CONTROL CHANGE OFF, ON X X X X X X X X X XXXX 34 1 NOT USED - - - - - - - - - ---35 1 00 – 01 MUTE ON, OFF X X X X X X X X X XXXX 36 1 NOT USED - - - - - - - - - ---37 1 NOT USED - - - - - - - - - ---38 1 NOT USED - - - - - - - - - ---39 1 00 – 01 Rcv VOLUME OFF, ON X X X X X X X X X XXXX 3A 1 00 – 01 Rcv PAN OFF, ON X X X X X X X X X XXXX 3B 1 00 – 01 Rcv EXPRESSION OFF, ON X X X X X X X X X XXXX 3C 1 NOT USED - - - - - - - - - ---3D 1 NOT USED - - - - - - - - - ---3E 1 NOT USED - - - - - - - - - ---3F 1 NOT USED - - - - - - - - - ---40 1 00 – 01 Rcv BANK SELECT OFF, ON X X X X X X X X X XXXX 41 1 NOT USED - - - - - - - - - ---42 1 NOT USED - - - - - - - - - ---43 1 NOT USED - - - - - - - - - ---44 1 NOT USED - - - - - - - - - ---45 1 NOT USED - - - - - - - - - ---46 1 NOT USED - - - - - - - - - ---47 1 NOT USED - - - - - - - - - ---48 1 NOT USED - - - - - - - - - ----

Organ Voice

Mic/Vocal Harmony

Natural

Voice

Song Main

Layer Left

Keyboard Style Extra Panel (main generation

method)

M.Pad Style Song MIDI

41

Address Size Data Parameter Description Corresponding Voice/Part MIDI Reception (effective or not for each part) MIDI Transmission (generated data)

(H) (H) (H) Regular/

49 1 NOT USED - - - - - - - - - ---4A 1 NOT USED - - - - - - - - - ---4B 1 NOT USED - - - - - - - - - ---4C 1 NOT USED - - - - - - - - - ---4D 1 NOT USED - - - - - - - - - ---4E 1 NOT USED - - - - - - - - - ---4F 1 NOT USED - - - - - - - - - ---50 1 NOT USED - - - - - - - - - ---51 1 NOT USED - - - - - - - - - ---52 1 NOT USED - - - - - - - - - ---53 1 NOT USED - - - - - - - - - ---54 1 NOT USED - - - - - - - - - ---55 1 NOT USED - - - - - - - - - ---56 1 NOT USED - - - - - - - - - ---57 1 NOT USED - - - - - - - - - ---58 1 NOT USED - - - - - - - - - ---59 1 00 – 5F AC1 CONTROLLER

5A 1 NOT USED - - - - - - - - - ---5B 1 NOT USED - - - - - - - - - ---5C 1 NOT USED - - - - - - - - - ---5D 1 NOT USED - - - - - - - - - ---5E 1 NOT USED - - - - - - - - - ---5F 1 NOT USED - - - - - - - - - ---60 1 00 – 5F AC2 CONTROLLER

TOTAL SIZE 31 The A/D PART Parameter cannot be reset to its factory setting with XG SYSTEM ON.

NUMBER

0 – 95 XXXXX XXXXXXXX

Organ Voice

Mic/Vocal Harmony

Natural

Voice

Song Main

Layer Left

Keyboard Style Extra Panel (main generation

method)

M.Pad Style Song MIDI

MIDI Parameter Change table (DRUM SETUP)

Address Size Data Parameter Description XG Default Corresponding Voice/Part

(H) (H) (H) (H) Regular/

3n rr 00 1 00 – 7F PITCH COARSE -64 – 0 – +63 40 O

01 1 00 – 7F PITCH FINE -64 – 0 – +63[cent] 40 O

02 1 00 – 7F LEVEL 0 – 127

03 1 00 – 7F ALTERNATE GROUP OFF, 1 – 127 Depends on

04 1 00 – 7F PAN RND, L63 – C – R63 Depends on

05 1 00 – 7F REVERB SEND 0 – 127 Depends on

06 1 00 – 7F CHORUS SEND 0 – 127 Depends on

07 1 00 – 7F VARIATION SEND 0 – 127 7F O

08 1 00 – 01 KEY ASSIGN SINGLE, MULTI 00 O

09 1 00 – 01 Rcv NOTE OFF OFF, ON Depends on

0A 1 00 – 01 Rcv NOTE ON OFF, ON 01 O

0B 1 00 – 7F LOW PASS FILTER

0C 1 00 – 7F LOW PASS FILTER

0D 1 00 – 7F EG ATTACK RATE -64 – 0 – +63 40 O

0E 1 00 – 7F EG DECAY1 RATE -64 – 0 – +63 40 O

0F 1 00 – 7F EG DECAY2 RATE -64 – 0 – +63 40 O

TOTAL SIZE 10

Address Size Data Parameter Description XG Default Corresponding Voice/Part

(H) (H) (H) (H) Regular/

20 1 00 – 7F EQ BASS GAIN -12 – +12[dB] 40 X X X X X X X X X XXXX 21 1 00 – 7F EQ TREBLE GAIN -12 – +12[dB] 40 X X X X X X X X X XXXX 22 1 NOT USED - - - - - - - - - - ---23 1 NOT USED - - - - - - - - - - ---24 1 04 – 28 EQ BASS FREQUENCY 32 – 2.0k[Hz] 0C X X X X X X X X X XXXX 25 1 1C – 3A EQ TREBLE FREQUENCY 500 – 16.0k[Hz] 36 X X X X X X X X X XXXX 26 1 NOT USED - - - - - - - - - - ---27 1 NOT USED - - - - - - - - - - ---28 1 NOT USED - - - - - - - - - - ---29 1 NOT USED - - - - - - - - - - ---2A 1 NOT USED - - - - - - - - - - ---2B 1 NOT USED - - - - - - - - - - ---2C 1 NOT USED - - - - - - - - - - ---2D 1 NOT USED - - - - - - - - - - ----

TOTAL SIZE 0E

CUTOFF FREQUENCY

RESONANCE

-64 – 0 – +63 40 O

Depends on the note

the noteO (Drum only)

Organ Voice

(Drum only)

O

(Drum only)

Organ Voice

Mic/Vocal

Harmony

X XOX XXX X XOOX

X XOX XXX X XXOX

X XOX XXX X XOOX

X XOX XXX X XXOX

X XOX XXX X XOOX

Mic/Vocal

Harmony

MIDI Reception (effective or not for each part)

Natural

Song Main

Voice

MIDI Reception (effective or not for each part)

Natural

Song Main

Voice

Keyboard Style Extra Panel (main generation

Layer Left

Keyboard Style Extra Panel (main generation

Layer Left

MIDI Transmission (generated data)

method)

MIDI Transmission (generated data)

method)

M.Pad Style Song MIDI

n: Drum Setup Number (0 – 1) rr: note number (0D – 5B)

In the following cases, the PSR-2100/1100 will initialize all Drum Setups.

XG SYSTEM ON received GM SYSTEM ON received DRUM SETUP RESET received (only when in XG mode)

[Note]

When a part to which a Drum Setup is assigned receives a program change, the assigned Drum Setup will be initialized. If the same Drum Setup is assigned to two or more parts, changes in Drum Setup parameters (including program changes) will apply to all parts to which it is assigned.

42

SYSTEM EXCLUSIVE MESSAGES

* Not received when the Receive System Exclusive Message is set to off. * Not transmitted when the Transmit System Exclusive Message is set to on.

System Exclusive Messages

MIDI Event Data Format Corresponding Voice/Part

Section Control

Tempo Control

Chord Control

F0 43 7E 00 ss dd F7 ----- ---O (Section LED) O (Section Sw) X X O X

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 01111110 7E = Style 00000000 00 = 0sssssss ss = Switch No.

0ddddddd dd = Switch On/Off

11110111 F7 = End of Exclusive

F0 43 7E 01 t4 t3 t2 t1 F7 ----- ---O (Tempo

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 01111110 7E = Style 00000001 01 = 0ttttttt t4 = tempo4 0ttttttt t3 = tempo3 0ttttttt t2 = tempo2 0ttttttt t1 = tempo1 11110111 F7 = End of Exclusive

F0 43 7E tt d1 d2 d3 d4 F7 ----- ---O (Chord Type 1 (tt=2)

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 01111110 7E = Style 00000010 02 = type 1 0ddddddd d1 = chord root(cr) 0ddddddd d2 = chord type(ct) 0ddddddd d3 = bass note(bn) 0ddddddd d4 = bass type(bt) 11110111 F7 = End of Exclusive

cr: Chord Root 0fffnnnn

ct: Chord Type 0 – 34,127

bn : On Bass Chord Same as Chord root

bt : Bass Chord Same as Chord type

* Not received when Receive Chord System Exclusive Message is set to

off.

* Not transmitted when Transmit Chord System Exclusive Message is set

to on.

Type2 (tt=3) ----- ---O (Chord

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 01111110 7E = Style 00000011 03 = type 2 0ddddddd dd = note1 0ddddddd dd = note2 0ddddddd dd = note3

: :

0ddddddd dd = ... note10 11110111 F7 = End of Exclusive

00H INTRO A 01H INTRO B 02H INTRO C 03H INTRO D 08H MAIN A 09H MAIN B 0AH MAIN C 0BH MAIN D 10H FILL IN AA 11H FILL IN BB 12H FILL IN CC 13H FILL IN DD 18H BREAK FILL 20H ENDING A 21H ENDING B 22H ENDING C 23H ENDING D

00H (Off) 7HF (On)

fff: b or #, nnnn: note(root)

0000nnnn 0n bbb 0fff0000 x0 reserved 0001nnnn 1n bb 0fff0001 x1 C 0010nnnn 2n b 0fff0010 x2 D 0011nnnn 3n natural 0fff0011 x3 E 0100nnnn 4n # 0fff0100 x4 F 0101nnnn 5n ## 0fff0101 x5 G 0110nnnn 6n ### 0fff0110 x6 A

00000000 00 0 Maj 00010010 12 18 dim7 00000001 01 1 Maj6 00010011 13 19 7th 00000010 02 2 Maj7 00010100 14 20 7sus4 00000011 03 3 Maj7(#11) 00010101 15 21 7b5 00000100 04 4 Maj(9) 00010110 16 22 7(9) 00000101 05 5 Maj7(9) 00010111 17 23 7(#11) 00000110 06 6 Maj6(9) 00011000 18 24 7(13) 00000111 07 7 aug 00011001 19 25 7(b9) 00001000 08 8 min 00011010 1A 26 7(b13) 00001001 09 9 min6 00011011 1B 27 7(#9) 00001010 0A 10 min7 00011100 1C 28 Maj7aug 00001011 0B 11 min7b5 00011101 1D 29 7aug 00001100 0C 12 min(9) 00011110 1E 30 1+8 00001101 0D 13 min7(9) 00011111 1F 31 1+5 00001110 0E 14 min7(11) 00100000 20 32 sus4 00001111 0F 15 minMaj7 00100001 21 33 1+2+5 00010000 10 16 minMaj7(9) 00100010 22 34 cc 00010001 11 17 dim

0fff0111 x7 B

127: No bass chord

Regular/

Organ Voice

Mic/Vocal

Harmony

Natural

Voice

MIDI Reception (effective or not for each part)

Song Main

Keyboard Style Extra Panel

Layer Left

MIDI Reception

(affecting the

panel)

indication)

O: available

MIDI Transmission (generated data)

(main generation

O (Tempo Sw) X X O X

O (Keyboard) X X O X

M.Pad Style Song MIDI

method)

X XXXX

43

System Exclusive Messages (Universal Realtime messages)

MIDI Event Data Format Corresponding Voice/Part

Master Volume

F0 7F 7F 04 01 ll mm F7 O-OOXXXX XXXXXX

11110000 F0 = Exclusive status 01111111 7F = Universal Real Time 01111111 7F = ID of target device 00000100 04 = Sub-ID #1=Device Control Message 00000001 01 = Sub-ID #2=Master Volume 0lllllll ll = Volume LSB 0mmmmmmm mm= Volume MSB 11110111 F7 = End of Exclusive

or

F0 7F XN 04 01 ll mm F7

11110000 F0 = Exclusive status 01111111 7F = Universal Real Time 0xxxnnnn XN = When N is received N=0 – F, whichever is received.

X=ignored

00000100 04 = Sub-ID #1=Device Control Message 00000001 01 = Sub-ID #2=Master Volume 0lllllll ll = Volume LSB 0mmmmmmm mm= Volume MSB 11110111 F7 = End of Exclusive

Regular/

Organ Voice

Mic/Vocal

Harmony

Natural

Voice

System Exclusive Messages (Universal Non Realtime messages)

MIDI Event Data Format Corresponding Voice/Part

General MIDI System On

F0 7E 7F 09 01 F7 O-OOXXXO O

11110000 F0 = Exclusive status 01111110 7E = Universal Non-Real Time 01111111 7F = ID of target device 00001001 09 = Sub-ID #1=General MIDI Message 00000001 01 = Sub-ID #2=General MIDI On 11110111 F7 = End of Exclusive

or

F0 7E XN 09 01 F7

11110000 F0 = Exclusive status 01111110 7E = Universal Non-Real Time 0xxxnnnn XN = When N is received N=0 – F,whichever is received.

00001001 09 = Sub-ID #1=General MIDI Message 00000001 01 = Sub-ID #2=General MIDI On 11110111 F7 = End of Exclusive

X=ignored

Regular/

Organ Voice

Mic/Vocal

Harmony

Natural

Voice

MIDI Reception (effective or not for each part)

Song Main

MIDI Reception (effective or not for each part)

Song Main

Keyboard Style Extra Panel

Layer Left

Keyboard Style Extra Panel

Layer Left

MIDI Reception

(affecting the

panel)

MIDI Reception

(affecting the

panel)

(Mixing Console)

MIDI Transmission (generated data)

(main generation

M.Pad Style Song MIDI

method)

MIDI Transmission (generated data)

(main generation

M.Pad Style Song MIDI

method)

XXXOX

(Output as XG Master

Volume )

System Exclusive Messages (XG)

MIDI Event Data Format Corresponding Voice/Part

XG Parameter Change

XG Bulk Dump

XG Parameter Request

XG Dump Request

F0 43 1n 4C hh mm ll dd ... F7 *Refer to Parameter Change

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 0001nnnn 1n = Device Number n=always 0 (when transmit), n=0 – F

01001100 4C = Model ID

0hhhhhhh hh = Address High

0mmmmmmm mm= Address Mid 0lllllll ll = Address Low 0ddddddd dd = Data

: : 11110111 F7 = End of Exclusive

F0 43 0n 4C aa bb hh mm ll dd ... dd cc F7 *Refer to Parameter Change

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 0000nnnn 0n = Device Number n=always 0 (when transmit), n=0 – F

01001100 4C = Model ID 0aaaaaaa aa = Byte Count MSB 0bbbbbbb bb = Byte Count LSB 0hhhhhhh hh = Address High 0mmmmmmm mm= Address Mid 0lllllll ll = Address Low 0ddddddd dd = Data

: :

0ddddddd dd = Data 0ccccccc cc = Checksum 11110111 F7 = End of Exclusive

F0 43 3n 4C hh ll F7 --------O

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 0011nnnn 3n = Device Number n=always 0 (when transmit), n=0 – F

01001100 4C = Model ID 0hhhhhhh hh = Address High 0mmmmmmm mm= Address Mid 0lllllll ll = Address Low 11110111 F7 = End of Exclusive

F0 43 2n 4C hh mm ll F7 --------O

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 0010nnnn 2n = Device Number n=always 0 (when transmit), n=0 – F

01001100 4C = Model ID 0hhhhhhh hh = Address High 0mmmmmmm mm= Address Mid 0lllllll ll = Address Low 11110111 F7 = End of Exclusive

(when recieve)

Regular/

Organ Voice

Mic/Vocal Harmony

Table

Natural

Voice

MIDI Reception (effective or not for each part)

Song Main

*Refer to Parameter Change Table - *Refer to Parameter Change Table O

*Refer to Parameter Change Table - X X X X

Keyboard Style Extra Panel

Layer Left

MIDI Reception

(affecting the

panel)

(-)

MIDI Transmission (generated data)

(main generation

M.Pad Style Song MIDI

method)

(Output as

Parameter

Change)

XXXX X

(When

receiving

the XG

Parameter

Request)

O

(When

receiving

the XG

Dump

Request)

44

System Exclusive Messages (Clavinova compliance)

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 01110011 73 = Clavinova ID

: : 11110111 F7 = End of Exclusive

MIDI Event Data Format Corresponding Voice/Part

Internal Clock

External Clock

Organ Flutes data Bulk Dump (PSR-2100 only)

F0 43 73 01 02 F7 ---X XXXX O (Function) X XXXX

00000001 01 = Model ID (Clavinova common ID) 00000010 02 = Internal Clock Substatus

F0 43 73 01 03 F7 ---X XXXX O (Function) X XXXX

00000001 01 = Model ID (Clavinova common ID) 00000011 03 = External Clock Substatus

F0 43 73 01 06 0B 00 00 01 06 0n [Bulk Data] sum F7 O (Organ

01H Model ID (Clavinova common ID) 06H Bulk ID 0BH Bulk No. (Organ Flutes data Bulk Dump) 00H, 00H, 01H, 06H Data Length :16bytes

1st Channel No. 0nH 2nd Footage [1'] 00 – mmH mm : maximum 3rd [1 1/3'] 00 – mmH 4th [1 3/5'] 00 – mmH (not used) 5th [2'] 00 – mmH 6th [2 2/3'] 00 – mmH 7th [4'] 00 – mmH 8th [5 1/3'] 00 – mmH 9th [8'] 00 – mmH 10th [16'] 00 – mmH 11th [Attack 2'] 00 – mmH 12th [Attack 2 2/3'] 00 – mmH 13th [Attack 4'] 00 – mmH 14th Settings [Attack Length] 00 – mmH 15th [Response] 00 – mmH 16th [Attack Mode] 00 – 01H 00H: Each, 01H: First 17th [Wave Variation] 00 – 01H 00H: Sine, 01H: Tone Wheel 18th [Volume] 01 – vvH vv: maximum 19th [aux] 00H 20th [aux] 00H 21th [aux] 00H 22th [aux] 00H sum Check Sum = 0-sum (BULK DATA)

Regular/

Organ Voice

Flute)

Mic/Vocal

Harmony

XXOO XXO O

MIDI Reception (effective or not for each part)

Natural

Voice

Song Main

Keyboard Style Extra Panel

Layer Left

System Exclusive Messages Special Operators (Vocal Harmony Additional Parameters)

MIDI Event Data Format Corresponding Voice/Part

Vocal Harmony Pitch to Note ON/OFF (PSR-2100 only)

Vocal Harmony Pitch to Note Part (PSR-2100 only)

Vocal Harmony Vocoder Part (Harmony Part (Panel)) (PSR-2100 only)

F0 43 73 01 11 0n 50 00 ss F7 XOXXX XXX O

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 01110011 73 = Clavinova ID 00000001 01 = Model ID (Clavinova common ID) 00010001 11 = Special Operators 0000nnnn 0n = Channel No. (Always 00) 01010000 50 = Vocal Harmony Additional Parameter Control No. 00000000 00 = Pitch to Note Parameter No. 0ddddddd dd = data (00H : Off, 01H : On) 11110111 F7 = End of Exclusive

F0 43 73 01 11 00 50 01 ss F7 XOXXX XXX O

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 01110011 73 = Clavinova ID 00000001 01 = Model ID (Clavinova common ID) 00010001 11 = Special Operators 0000nnnn 0n = Channel No. (Always 00) 01010000 50 = Vocal Harmony Additional Parameter Control No. 00000001 01 = Pitch to Note Part Parameter No. 0ddddddd dd = data 00H : Main

11110111 F7 = End of Exclusive

F0 43 73 01 11 00 50 10 ss F7 XOXXX XXX O

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 01110011 73 = Clavinova ID 00000001 01 = Model ID (Clavinova common ID) 00010001 11 = Special Operators 0000nnnn 0n = Channel No. (Always 00) 01010000 50 = Vocal Harmony Additional Parameter Control No. 00010000 10 = Vocoder Part Parameter No. 0ddddddd dd = data 00H : Off

11110111 F7 = End of Exclusive

01H : Layer 02H : Left 04H : Upper

01H : Upper 02H : Lower

Regular/

Organ Voice

Mic/Vocal

Harmony

MIDI Reception (effective or not for each part)

Natural

Voice

Song Main

Keyboard Style Extra Panel

Layer Left

MIDI Reception

(affecting the

panel)

(Sound Creator)O (Sound Creator)

MIDI Reception

(affecting the

panel)

(Vocal Harmony

Edit)

(Vocal Harmony

Edit)

(Mic Setting)O(Mic Setting)

MIDI Transmission (generated data)

(main generation

method)

MIDI Transmission (generated data)

(main generation

method)

O

(Vocal Harmony

Edit)

O

(Vocal Harmony

Edit)

M.Pad Style Song MIDI

X XOX

M.Pad Style Song MIDI

X XOX

System Exclusive Messages (Others)

MIDI Event Data Format Corresponding Voice/Part

MIDI Master Tuning

F0 43 1n 27 30 00 00 mm ll cc F7 OXOOO (Function) X XXXX

11110000 F0 = Exclusive status 01000011 43 = YAMAHA ID 0001nnnn 1n n= always 0 (when transmit), n=0 – F (when receive) 00100111 27 = Model ID of TG100 00110000 30 = Address High 00000000 00 = Address Mid 00000000 00 = Address Low 0000mmmm 0m = Master Tune MSB 0000llll 0l = Master Tune LSB 0ccccccc cc = don't care 11110111 F7 = End of Exclusive

Regular/

Organ Voice

Mic/Vocal

Harmony

Natural

Voice

45

MIDI Reception (effective or not for each part)

Song Main

Keyboard Style Extra Panel

Layer Left

MIDI Reception

(affecting the

panel)

MIDI Transmission (generated data)

(main generation

M.Pad Style Song MIDI

method)

Song System Exclusive Message List Liste der System-Exclusive-Meldungen der Songs Liste des messages exclusifs au système de morceaux Lista de mensajes exclusivos del sistema de canciones

Data Format Parameter Description

Panel Setting

F0 43 73 01 22 00 0n mm ll pp F7 Panel Program Change pp=Bank Select MSB, ll=Bank Select LSB,

F0 43 73 01 22 01 0n vv F7 Panel Voice Volume 00H – 07FH, On=Channel F0 43 73 01 22 02 0n vv F7 Panel Voice Reverb Depth 00H – 07FH, On=Channel F0 43 73 01 22 03 0n vv F7 Panel Voice Effect Depth 00H – 07FH, On=Channel

Score

F0 43 73 01 50 12 00 00 dd F7 Left Part indication On/Off 00H: OFF, 7FH: ON F0 43 73 01 50 12 00 01 dd F7 Right Part indication On/Off 00H: OFF, 7FH: ON F0 43 73 01 50 12 00 02 dd F7 Lyrics indication On/Off 00H: OFF, 7FH: ON F0 43 73 01 50 12 00 03 dd F7 Chord indication On/Off 00H: OFF, 7FH: ON F0 43 73 01 50 12 00 04 dd F7 N.Name indication On/Off 00H: OFF, 7FH: ON F0 43 73 01 50 12 00 05 dd F7 Size designation 00H: SMALL, 01H: MIDDLE, 02H: LARGE, 03H: Xlarge F0 43 73 01 50 12 00 06 dd F7 Left Ch 00H – 0FH=CH, 7EH=OFF, 7FH=AUTO F0 43 73 01 50 12 00 07 dd F7 Right Ch 00H – 0FH=CH, 7EH=OFF, 7FH=AUTO F0 43 73 01 50 12 00 08 dd F7 Quantize triplet On/Off 00H: Triplet OFF, 7FH: Triplet ON F0 43 73 01 50 12 00 09 dd F7 Quantize 00H: quarter, 01H: eighth, 02H: sixteenth, 03H: thirty-second F0 43 73 01 50 12 00 0A dd F7 NoteName 00H: ABC, 01H: FixedDo, 02H: MovableDo F0 43 73 01 50 12 00 0B dd F7 Color Note 00H: OFF, 7FH: ON

Style

F0 43 73 dd 11 00 16 dd dd F7 Style No. dd dd=StyleNo.

F0 43 73 01 51 05 00 00 08 Rhy1 Rhy2 Bass Chd1 Chd2 Pad Phr1 Phr2 7F

F0 43 73 01 51 00 00 00 03 10 00 dd F7 ACMP SPLIT POINT 00H – 7FH

Style Part On / Off 00H: OFF, 01H:ON

nn=Program Change, On=Channel

PSR-2100: 7F 3C PSR-1100: 7F 3B

Song Meta Event List Liste der Meta-Events der Songs Liste des méta-événements des morceaux Lista de meta-eventos de canciones

Data Format Parameter Description

SMF META Event

FF 01 len [Data] TEXT len=Data length, [Data]=Text data FF 02 len [Data] Copyright len=Data length, [Data]=Copyright data FF 03 len [Data] Sequence Name len=Data length, [Data]=Sequence Name FF 05 len [Data] Lyrics len=Data length, [Data]=Lyrics data FF 2F 00 End Of Track FF 51 03 t1 t2 t3 Set Tempo t1 t2 t3 = 01D4C0H – B71B00 (5 – 500) FF 58 04 nn dd cc bb Beat (Time signature) nn =Denominator (2n), dd=Numerator,

FF 59 02 sf mi Key Signature sf=-7 – 7 (7 – 7)

YAMAHA META Event

FF 7F 07 43 73 0A 00 07 dd Song Offset Measure -100 – -1, 1 – 100 FF 7F len 43 73 0C 00 [Data] Style Name len=Data length, [Data]=Style Name FF 7F len 43 73 0D 00 [Data] Song OTS len=Data length, [Data]=OTS Data

YAMAHA XF META Event

FF 7F 07 43 7B 01 cr ct bn bt Chord Name

FF 7F 05 43 7B 03 dd 08 Phrase Mark See below FF 7F 04 43 7B 04 dd Max Phrase Number 01H – 7FH FF 7F 05 43 7B 0C rr ll Guide Track Flag rr=Melody Track 1 Ch, ll=Melody Track 2 Ch FF 7F len 43 7B 21 00 pp [Data] Lyrics Bitmap pp=Display type

[Phrase mark]

FF 7F 05 43 7B 03 xx 08 Phrase mark

xx Phrase mark 0hfccccc

bit6(h) 0:Right, 1:Left Right hand/Left hand bit5(f) 0:Channel available, 1:Channel not available Flag for whether channel information (bit 4 - 0) is valid or not Phrases common to all channels assigned to 1 bit4-0(ccccc) CH(0:1ch – 31:32ch) Channel information whose phrase mark is available

CC=MIDI clock per metronome click, dd=Number of thirty-second notes in MIDI quarter note

mi=0:Major key, 1:Minor key

Refer to "Chord Control" in the MIDI Data Format (System Exclusive Messages)

00H: Center 01H: Tile

len=Data length, [Data]=File Path

46

YAMAHA [ Portable Keyboard ] Date : 10,Sep 2002

Model PSR-2100/1100 MIDI Implementation Chart

Version : 1.00

TransmittedFunction... Recognized Remarks

Basic Channel

Mode

Default Changed

Default Messages Altered

Note Number : True voice

Velocity

Note ON Note OFF

After Touch

Key's Ch's

Pitch Bend Control

Change

1,5,7,10,11

0,32 6,38

64,65,66,67

71-74

84

91,93,94

96-97 98-99

100-101

120 121

1 - 16 1 - 16

3

˛

**************

0 - 127 **************

Ø 9nH,v=1-127 ˛ 9nH,v=0

˛ ˛

Ø

Ø Ø Ø Ø Ø Ø Ø ˛ Ø Ø ˛ ˛

1 - 16 1 - 16

3

˛ ˛

0 - 127 0 - 127

Ø 9nH,v=1-127

˛

˛ Ø

Ø

0 - 24 semi

Ø Ø Ø Ø Ø Ø Ø Ø Ø Ø Ø Ø

Bank Select Data Entry Sound Controller

Portament Cntrl Effect Depth RPN Inc,Dec NRPN LSB,MSB RPN LSB,MSB All Sound Off Reset All Cntrls

Prog Change : True #

System Exclusive

Common : Song Pos. : Song Sel. : Tune

System : Clock Real Time : Commands

: All Sound Off Aux :

Reset All Cntrls : Local ON/OFF Mes- : All Notes OFF sages: Active Sense : Reset

Ø

0 - 127

**************

Ø

˛ ˛

˛

Ø

˛ ˛ ˛ ˛ Ø ˛

Ø 0 - 127

Ø

˛ ˛

˛

Ø

Ø Ø (120,126-127)

Ø (121)

Ø

Ø (123-125)

Ø ˛

Notes:

Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO

Ø : Yes ˛ : No

47

WA44120 301MWAP3.3-01A0

Printed in China

Yamaha PSR-1100, PSR-2100 User's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Vocal Harmony Type List
