Yamaha CVP-103, CVP-103M User Manual
Owner’s Manual
IMPORTANT
Check Your Power Supply
Make sure that your local AC mains voltage matches
the voltage specified on the name plate on the bottom
panel. In some areas a voltage selector may be
provided on the bottom panel of the main keyboard
unit near the power cord. Make sure that the voltage
selector is set for the voltage in your area. The voltage
selector is set at 240V when the unit is initially shipped.
To change the setting use a “minus” screwdriver to
rotate the selector dial so that the correct voltage
appears next to the pointer on the panel.
SPECIAL MESSAGE SECTION
PRODUCT SAFETY MARKINGS: Yamaha electronic
products may have either labels similar to the graphics
shown below or molded/stamped facsimiles of these
graphics on the enclosure. The explanation of these graphics appears on this page. Please observe all cautions indicated on this page and those indicated in the safety instruction section.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
See bottom of Keyboard enclosure for graphic symbol markings.
The exclamation point within the equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.
ENVIRONMENTAL ISSUES: Yamaha strives to produce products that are both user safe and environmentally
friendly. We sincerely believe that our products and the
production methods used to produce them, meet these
goals. In keeping with both the letter and the spirit of the
law, we want you to be aware of the following:
Battery Notice: This product MAY contain a small nonrechargable battery which (if applicable) is soldered in
place. The average life span of this type of battery is approximately five years. When replacement becomes necessary, contact a qualified service representative to perform the replacement.
Warning: Do not attempt to recharge, disassemble, or
incinerate this type of battery. Keep all batteries away
from children. Dispose of used batteries promptly and as
regulated by applicable laws. Note: In some areas, the
servicer is required by law to return the defective parts.
However, you do have the option of having the servicer
dispose of these parts for you.
Disposal Notice: Should this product become damaged
beyond repair, or for some reason its useful life is considered to be at an end, please observe all local, state, and
federal regulations that relate to the disposal of products
that contain lead, batteries, plastics, etc.
The lightning flash with arrowhead
symbol, within the equilateral triangle,
is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute a risk of electrical shock.
IMPORTANT NOTICE: All Yamaha electronic products are tested and approved by an independent safety
testing laboratory in order that you may be sure that when
it is properly installed and used in its normal and customary manner, all foreseeable risks have been eliminated.
DO NOT modify this unit or commission others to do so
unless specifically authorized by Yamaha. Product performance and/or safety standards may be diminished.
Claims filed under the expressed warranty may be denied
if the unit is/has been modified. Implied warranties may
also be affected.
SPECIFICATIONS SUBJECT TO CHANGE: The
information contained in this manual is believed to be
correct at the time of printing. However, Yamaha reserves
the right to change or modify any of the specifications
without notice or obligation to update existing units.
NOTICE: Service charges incurred due to lack of knowledge relating to how a function or effect works (when the
unit is operating as designed) are not covered by the
manufacturer’s warranty, and are therefore the owners
responsibility. Please study this manual carefully and consult your dealer before requesting service.
NAME PLATE LOCATION: The graphic below indicates the location of the name plate. The model number,
serial number, power requirements, etc., are located on
this plate. You should record the model number, serial
number, and the date of purchase in the spaces provided
below and retain this manual as a permanent record of
your purchase.
92-469- ➀ (bottom)
Model _____________________________________
Serial No. __________________________________
Purchase Date ______________________________
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
* Please keep these precautions in a safe place for future reference.
WARNING
Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical shock,
short-circuiting, damages, fire or other hazards. These precautions include, but are not limited to, the following:
• Do not open the instrument or attempt to disassemble the internal parts or
modify them in any way. The instrument contains no user-serviceable parts.
If it should appear to be malfunctioning, discontinue use immediately and
have it inspected by qualified Yamaha service personnel.
• Do not expose the instrument to rain, use it near water or in damp or wet
conditions, or place containers on it containing liquids which might spill
into any openings.
• If the power cord or plug becomes frayed or damaged, or if there is a sudden
loss of sound during use of the instrument, or if any unusual smells or
CAUTION
Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage to the
instrument or other property. These precautions include, but are not limited to, the following:
smoke should appear to be caused by it, immediately turn off the power
switch, disconnect the electric plug from the outlet, and have the instrument
inspected by qualified Yamaha service personnel.
• Only use the voltage specified as correct for the instrument. The required
voltage is printed on the name plate of the instrument.
• Before cleaning the instrument, always remove the electric plug from the
outlet. Never insert or remove an electric plug with wet hands.
• Check the electric plug periodically and remove any dirt or dust which may
have accumulated on it.
• Do not place the power cord near heat sources such as heaters or radiators,
and do not excessively bend or otherwise damage the cord, place heavy
objects on it, or place it in a position where anyone could walk on, trip over,
or roll anything over it.
• When removing the electric plug from the instrument or an outlet, always
hold the plug itself and not the cord. Pulling by the cord can damage it.
• Do not connect the instrument to an electrical outlet using a multiple-connector. Doing so can result in lower sound quality, or possibly cause overheating in the outlet.
• Remove the electric plug from the outlet when the instrument is not to be
used for extended periods of time, or during electrical storms.
• Before connecting the instrument to other electronic components, turn off
the power for all components. Before turning the power on or off for all
components, set all volume levels to minimum. Also, be sure to set the
volumes of all components at their minimum levels and gradually raise the
volume controls while playing the instrument to set the desired listening
level.
• Do not expose the instrument to excessive dust or vibrations, or extreme
cold or heat (such as in direct sunlight, near a heater, or in a car during the
day) to prevent the possibility of panel disfiguration or damage to the internal components.
• Do not use the instrument near other electrical products such as televisions,
radios, or speakers, since this might cause interference which can affect
proper operation of the other products.
• Do not place the instrument in an unstable position where it might accidentally fall over.
• Before moving the instrument, remove all connected cables.
• When cleaning the instrument, use a soft, dry cloth. Do not use paint thinners,
solvents, cleaning fluids, or chemical-impregnated wiping cloths. Also, do
not place vinyl, plastic or rubber objects on the instrument, since this might
discolor the panel or keyboard.
• Do not rest your weight on, or place heavy objects on the instrument, and do
not use excessive force on the buttons, switches or connectors.
• If the instrument has a key cover, take care that the key cover does not pinch
your fingers, and do not insert a finger or hand in the key cover gap.
• If the instrument has a key cover, never insert or drop paper or metallic or
other objects between the slits of the key cover and the keyboard. If this
happens, immediately turn off the power and remove the electric plug from
the outlet and have the instrument inspected by qualified Yamaha service
personnel.
• Do not place the instrument against a wall (allow at least 3 cm/one-inch
from the wall), since this can cause inadequate air circulation, and possibly
result in the instrument overheating.
• Read carefully the attached documentation explaining the assembly process. Failure to assemble the instrument in the proper sequence might result in damage to the instrument or even injury.
• Do not operate the instrument for a long period of time at a high or uncomfortable volume level, since this can cause permanent hearing loss. If you
experience any hearing loss or ringing in the ears, consult a physician.
■USING THE BENCH (if included)
• Do not play carelessly with or stand on the bench. Using it as a tool or stepladder or for any other purpose might result in accident or injury.
• Only one person should sit on the bench at a time, in order to prevent the
possibility of accident or injury.
• If the bench screws become loose due to extensive long-term use, tighten
them periodically using the included tool.
■SAVING USER DATA
• Always save data to a floppy disk frequently, in order to help prevent the loss
of important data due to a malfunction or user operating error.
Yamaha cannot be held responsible for damage caused by improper use or
modifications to the instrument, or data that is lost or destroyed.
Always turn the power off when the instrument is not in use.
(1)B_EL/CL-4vari.
1
CVP-103
3
Thank you for purchasing the Yamaha Clavinova! We recommend that you read this man ual carefully so that you can fully take advantage of the advanced and convenient functions of the Clavinova.
We also recommend that you keep this manual in a safe and handy place for future reference.
Accessories
● Music Software Collection Disk (and Music Book)
This disk features sample songs that you can play back on your Clavinova, as well as MIDI
driver software for computers.
● Floppy Disk
Use this blank disk to record your performances.
● Owner’s Manual
This manual contains complete instructions for operating your Clavinova.
● Reference Booklet
This manual contains lists of voices, styles, and parameters, etc., as well as specifications
and assembly instructions for your Clavinova.
● Bench
A bench may be included or optional, depending on your locale.
• The CVP-103M will be referred to as the CVP-103 in this Owner’s Manual.
• The illustrations and LCD screens as shown in this owner’s
manual are for instructional purposes only, and may appear
somewhat different from those on your instrument.
• Unauthorized copying of copyrighted software for purposes other
than the purchaser’s personal use is prohibited.
● Trademarks:
• Apple and Macintosh are trademarks of Apple Computer, Inc.
• IBM-PC/AT is a trademark of International Business
Machines Corporation.
• Windows is the registered trademark of Microsoft®
Corporation.
• All other trademarks are the property of their respective holders.
The Panel Logos
The logos printed on the Clavinova panel indicate standards/formats it supports and special features it includes.
GM System Level 1
“GM System Level 1” is an addition to the MIDI standard which
guarantees that any data conforming to the standard will play
accurately on any GM-compatible tone generator or synthesizer
from any manufacturer.
XG Format
XG is a new Yamaha MIDI specification which significantly expands and improves on the “GM System Level 1” standard with
greater voice handling capacity, expressive control, and effect
capability while retaining full compatibility with GM. By using the
Clavinova’s XG voices, it is possible to record XG-compatible
song files.
The DOC voice allocation format provides data playback compatibility with a wide range of Yamaha instruments and MIDI
devices.
The Style File Format (SFF) is Yamaha’s original style file
format, which uses a unique conversion system to provide highquality automatic accompaniment based on a wide range of
chord types. The Clavinova uses the SFF internally, reads
optional SFF style disks, and creates SFF styles using the
Custom Style feature.
Disk Orchestra Collection
Style File Format
XF Format
The Yamaha XF format enhances the SMF (Standard MIDI File)
standard with greater functionality and open-ended expandability
for the future. The Clavinova is capable of displaying lyrics when
an XF file containing lyric data is played. (SMF is the most common format used for MIDI sequence files. The Clavinova is compatible with SMF Formats 0 and 1, and records “song” data using
SMF Format 0.)
4
CVP-103
2
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Features of the Clavinova
● Easy-to-use LCD Display
The LCD (together with the various panel buttons) provides comprehensive and easy-to-understand
control of the Clavinova’s operations (page 16).
● Wealth of Rich, Realistic Voices
The CVP-103 has a wide variety of authentic and dynamic voices, including 195 original voices,
480 XG voices, and 12 drum/SFX kits. These include exceptionally natural-sounding piano, strings
and brass voices, and the particularly expressive “SweetTrumpet” voice. Moreover, you can play realistic drum and percussion sounds directly from the keyboard (page 31).
● Playback of Song Disks
The Clavinova can play back various commercially available song disks. With the appropriate disk
software, you can play the piano part of the song yourself along with a full orchestra or backing band
(page 93). If the software contains lyrics, you can display them on the Clavinova’s LCD.
● Special Guide Functions for Easy Learning
With the appropriate disk software, the LCD display and guide lamps help you learn songs by
showing you when and where to play the proper notes. The three-step system helps you to master each
song quickly and easily (page 105).
● Fun, Dynamic Automatic Accompaniment
The Auto Accompaniment of the Clavinova gives you full, exciting instrumental backing in your
favorite music styles, according to the chords you play (page 57). There’s even a wide selection of
“Pianist” styles that allow you to enjoy solo piano accompaniment (page 58). Choose from 160 accompaniment styles, or create your own custom styles (page 73).
● Easy Access to a Variety of Musical Enjoyment
The Clavinova off ers several ways to change panel settings without a lot of fuss. You can use the
One Touch Setting feature to select from four sets of voice, effect, and other settings appropriate to
each accompaniment style (page 72). Or access the Music Database to choose from 463 sets of style
and voice settings, selectable by title or style (page 67). You can even save your current setup for instant recall later using the handy Registration function (page 89).
● Easy-to-use Recording Features
You can record songs using a variety of methods, depending on your keyboard expertise and preference. Choose from the Quick Recording, Track Recording, and Chord Sequence Recording functions
(page 110).
● Convenient TO HOST Terminals for Direct Connection to Computers
The Clavinova can be used as a high-quality sound source to play back music software for computers. It can also be used as a master keyboard, to enter performance data and create music with a computer (page 160).
3
CVP-103
5
Table of Contents
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
CHAPTER 1:
Getting Ready
About This Manual 8
Handling the Floppy Disk Drive (FDD) and Floppy Disks 9
Setting Up the Clavinova 10
Music Stand .....................................................................................10
Key Cover (Where Present)............................................................. 10
Turning the Power On and Off ......................................................... 11
Headphones..................................................................................... 11
Other Connections ........................................................................... 11
Panel Controls and Terminals 12
Playing the Demo Songs 14
CHAPTER 2:
Basic Operation
Using the LCD Display Controls 16
Selecting a Function ........................................................................ 16
Changing a Setting .......................................................................... 17
Changing a Setting in a Menu Display ............................................. 18
Displaying a Different Page ............................................................. 19
Resetting a Function’s Value ........................................................... 19
Using Functions in Non-rounded Rectangles .................................. 20
Exiting to the Main Display............................................................... 21
Using the Direct Access Function .................................................... 21
Adjusting the Volume 23
Adjusting the Overall Volume........................................................... 23
Adjusting the Accompaniment or Song Volume...............................23
Setting the Keyboard Volume .......................................................... 23
Adjusting Accompaniment or Song Part Levels............................... 24
Using the Metronome 25
Using the Metronome.......................................................................25
Changing the Metronome Settings .................................................. 26
Using the Help Mode 27
CHAPTER 3:
Voices
Selecting Voices 29
Selecting a Voice from the VOICE SELECT Display ....................... 29
Selecting Voices from the Main Display........................................... 30
Keyboard Percussion ....................................................................... 31
Changing the Keyboard Settings for the Main Voice ....................... 31
Playing Two Voices Simultaneously — Dual Mode 33
Selecting the Second Voice ............................................................. 33
Changing the Main Voice in Dual Mode........................................... 33
Changing the Keyboard Settings for the Second Voice................... 34
Exiting the Dual Mode...................................................................... 35
Playing Two Voices on Different Sides of the Keyboard
— Split Mode 36
Selecting the Left Voice ................................................................... 36
Changing the Main Voice in Split Mode ........................................... 36
Changing the Keyboard Settings for the Left Voice ......................... 37
Using the Dual and Split Functions Simultaneously ........................ 39
Exiting the Split Mode ...................................................................... 39
Using the Pedals 40
Damper Pedal (Right) ...................................................................... 40
Sostenuto Pedal (Center) ................................................................ 40
Soft Pedal (Left) ............................................................................... 40
CHAPTER 4:
Reverb and Other Effects
Reverb 41
Turning the Reverb On or Off .......................................................... 41
Changing the Reverb Settings ......................................................... 41
Chorus 44
Changing the Chorus Settings ......................................................... 44
Voice Effects 46
Turning the Effects On ..................................................................... 46
Changing the Effect Settings ........................................................... 46
CHAPTER 5:
Accompaniment Styles
(Rhythm and Auto Accompaniment)
Selecting Accompaniment Styles 49
Selecting a Style .............................................................................. 49
Playing the Accompaniment Styles 51
Varying the Style .............................................................................. 51
Starting the Accompaniment Style ................................................... 52
Stopping the Accompaniment Style ................................................. 55
Playing with the Auto Accompaniment 57
Using the Auto Accompaniment....................................................... 57
Starting the Auto Accompaniment ................................................... 58
Stopping the Auto Accompaniment.................................................. 58
Changing the Auto Accompaniment Settings .................................. 59
Adjusting Individual Part Levels ....................................................... 65
Other Auto Accompaniment Functions 67
Music Database ............................................................................... 67
Harmony .......................................................................................... 69
One Touch Setting ........................................................................... 72
Creating Your Own Styles 73
Recording a Custom Style ............................................................... 73
Other Custom Style Functions ......................................................... 80
Playing Back Your Custom Styles ................................................... 84
Messages in Custom Style Mode .................................................... 84
Using Style Files 86
About the Yamaha Style File Format ............................................... 86
Loading Styles from a Disk .............................................................. 86
Playing Loaded Style Files............................................................... 88
6
CVP-103
4
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
CHAPTER 6:
Registrations
Using Registrations(Registering and Recalling Panel Setups) 89
Storing a Panel Setup ...................................................................... 89
Recalling the Registered Panel Settings.......................................... 90
Protecting Panel Settings................................................................. 91
CHAPTER 7:
Song Control
Song Playback 93
Song Playback ................................................................................. 93
Part Cancel ...................................................................................... 97
Assignment of Tracks to 1/RIGHT and 2/LEFT, and Voice Assignment......
Overall Song Playback Volume Control ........................................... 99
Adjustment of Track Settings ......................................................... 100
Changing Settings in the MIXER Display....................................... 100
Repeat Functions ........................................................................... 101
Other Playback Controls ................................................................ 103
Playing Other Types of Music Data ............................................... 104
Guide Control 105
Guide Methods and Piano Roll ...................................................... 105
Using the Guide Function .............................................................. 106
Other Guide-related Functions....................................................... 108
Song Recording 110
Recording Setup: Disk Format ....................................................... 111
Quick Recording ............................................................................ 112
Track Recording (Multi-track Recording) ....................................... 115
Adding New Tracks ........................................................................ 118
Punch-in/out Recording ................................................................. 118
98
Disk 139
FUNCTION [DISK 1] Display — page 4......................................... 139
FUNCTION [DISK 2] Display — page 5......................................... 142
FUNCTION [DISK 3] Display — page 6......................................... 144
FUNCTION [DISK 4] Display — page 7......................................... 145
FUNCTION [DISK 5] Display — page 8......................................... 146
MIDI 147
FUNCTION [MIDI 1] Display — page 9 ......................................... 147
FUNCTION [MIDI 2] Display — page 10 ....................................... 148
FUNCTION [MIDI 3] Display — page 11 ....................................... 149
FUNCTION [MIDI 4] Display — page 12 ....................................... 150
Backup 152
FUNCTION [BACKUP 1] Display — page 13 ................................ 152
FUNCTION [BACKUP 2] Display — page 14 ................................ 153
Utility 154
FUNCTION [MICRO TUNING] Display — page 15 ....................... 154
FUNCTION [SCALE TUNING] Display — page 16 ....................... 155
CHAPTER 9:
Connections
Audio Connections 158
Headphones................................................................................... 158
Audio Input and Output .................................................................. 158
Data Connections 160
Connecting MIDI Equipment .......................................................... 160
Connecting to a Host Computer..................................................... 160
APPENDICES
Chord Sequence 121
Other Chord Sequence Functions ................................................. 124
Other Record Edit Functions 126
Setup Memory................................................................................ 126
Song Name .................................................................................... 127
Track Edit ....................................................................................... 128
Initial Edit (Changing the Initial Data)............................................. 130
Making Settings in the INITIAL EDIT Display ................................ 131
Recording Without a Disk 133
About the CVP MEMORY Song..................................................... 133
CHAPTER 8:
The Utility Functions
Keyboard 136
FUNCTION [KEYBOARD 1] Display — page 1 ............................. 136
FUNCTION [KEYBOARD 2] Display — page 2 ............................. 137
Pedal 138
FUNCTION [PEDAL] Display — page 3 ........................................ 138
Effect Type Lists 162
Messages 165
Troubleshooting 170
MIDI and Data Compatibility 172
Index 173
5
CVP-103
7
CHAPTER 1: Getting Ready
About This Manual
This section explains the notation conventions that are used
throughout this manual.
○○○○○○○○○○○○○○○○○○○○○○○○○
■ Square brackets [ ] ............................................................................................
Square brackets enclose the names of panel buttons,
sliders, and connectors as they appear on your
Clavinova. For example, the DEMO button is expressed
as [DEMO] in this manual.
DEMO
HELP
■ Bold characters....................................................................................................
Bold type represents items shown in the LCD display, as well as the corresponding LCD buttons (i.e., the buttons directly belo w, or to the left or
right of, these items). For example, the phrase “Select RIGHT1 VOICE”
means that you should press the button directly below the “RIGHT1
VOICE” label at the bottom of the display .
■ Arrows in Operation Explanations..................................................
Different types of arrows are used to distinguish the steps of an operation
from its results.
Operation steps
♥ ➾ ♣ …indicates that you should do ♥, then do ♣.
Operation results
♥ ➔ ♠ …indicates that doing ♥ results in ♠.
8
CVP-103
6
Handling the Floppy Disk Drive (FDD) and Floppy Disks
● Precautions
Be sure to handle floppy disks and treat the disk drive with
care. Follow the important precautions below.
● Compatible Disk Type
3.5" 2DD and 2HD type floppy disks can be used.
■ Inserting/Ejecting Floppy Disks .............
To insert a floppy disk into the disk drive:
Hold the disk so that the label of the disk is facing
upward and the sliding shutter is facing forward, towards
the disk slot. Carefully insert the disk into the slot, slowly
pushing it all the way in until it clicks into place and the
eject button pops out.
D
IS
K
IN
U
S
E
To eject a floppy disk:
Before ejecting the disk, be sure to confirm that the
FDD is stopped (check if the [DISK IN USE] lamp is off).
Press the eject button slowly as far as it will go; the disk
will automatically pop out. When the disk is fully ejected,
carefully remove it by hand.
DISK IN USE lamp
D
IS
K
IN
U
S
E
Never attempt to remove the disk or turn the power off
during recording, reading and playing back. Doing so can
damage the disk and possibly the disk drive.
If the eject button is pressed too quickly, or if it is not
pressed in as far as it will go, the disk may not eject properly. The eject button may become stuck in a half-pressed
position with the disk extending from the drive slot by only
a few millimeters. If this happens, do not attempt to pull
out the partially ejected disk, since using force in this
situation can damage the disk drive mechanism or the
floppy disk. To remove a partially ejected disk, try pressing the eject button once again, or push the disk back into
the slot and then repeat the eject procedure.
Be sure to remove the floppy disk from the disk drive
before turning off the power. A floppy disk left in the drive
for extended periods can easily pick up dust and dirt that
can cause data read and write errors.
○○○○○○○○○○○
■ Cleaning the Disk Drive Read/Write
Head......................................................................................
● Clean the read/write head regularly. This instrument
employs a precision magnetic read/write head which,
after an extended period of use, will pick up a layer of
magnetic particles from the disks used that will eventually cause read and write errors.
● To maintain the disk drive in optimum working order
Yamaha recommends that you use a commerciallyavailable dry-type head cleaning disk to clean the
head about once a month. Ask your Yamaha dealer
about the availability of proper head-cleaning disks.
● Never open or close the key cover while a disk is
extending from the drive (i.e. in the ejected position).
The key cover may contact the disk,– possibily damaging the disk or even the disk drive.
● Never insert anything but floppy disks into the disk
drive. Other objects may cause damage to the disk
drive or floppy disks.
■ About the Floppy Disks ...................................
To handle floppy disks with care:
● Do not place heavy objects on a disk or bend or
apply pressure to the disk in any way. Always keep
floppy disks in their protective cases when they are
not in use.
● Do not expose the disk to direct sunlight, extremely
high or low temperatures, or excessive humidity, dust
or liquids.
● Do not open the sliding shutter and touch the exposed surface of the floppy disk inside.
● Do not expose the disk to magnetic fields, such as
those produced by televisions, speakers, motors,
etc., since magnetic fields can partially or completely
erase data on the disk, rendering it unreadable.
● Never use a floppy disk with a deformed shutter or
housing.
● Do not attach anything other than the provided labels
to a floppy disk. Also make sure that labels are attached in the proper location.
To protect your data (Write-protect Tab):
To prevent accidental erasure of important data, slide the
disk’s write-protect tab to the “protect” position (tab open).
Data backup
For maximum data security Yamaha
recommends that you keep two copies of
important data on separate floppy disks.
This gives you a backup if one disk is lost
or damaged. To make a backup disk use
the Disk Copy function on page 142.
7
CVP-103
9
Setting Up the Clavinova
Music Stand
○○○○○○○○○○○○○○○○○
■ To raise the music stand:..........................................................................
Z Pull the stand up and toward yourself as far as it will go.
X Flip down the two metal supports at the left and the right on the rear
of the music stand.
C Lower the music stand so that it rests on the metal supports.
As the illustration shows, the angle of the music stand can be set in
one of three positions, according to the position of the metal supports.
Set the left and right metal supports to the same position.
■ To lower the music stand: ........................................................................
Z Pull the music stand toward yourself as far as it will go.
X Raise the two metal supports until they are flat against the rear sur-
face of the stand.
C Gently lower the music stand backward until it is all the way down.
CAUTION
• Do not try to use the music stand in a half-raised position. Also, when lowering the
stand, let the stand all the way down before releasing it.
Key Cover (Where Present)
■ To open the key cover:.................................................................................
Z Lift the cover slightly (not too much).
X Slide the cover open.
Be careful to avoid catching your
fingers when opening or closing
the cover.
■ To close the key cover:................................................................................
Z Slide the cover toward you.
10
X Gently lower the cover over the keys.
CAUTION
• Hold the cover with both hands when moving it, and do not release it until it is fully
opened or closed. Be careful to avoid catching fingers (yours or others) between the
cover and main unit.
• Do not place objects on top of the key cover. Small objects placed on the key cover
may fall inside the instrument when the cover is opened, and may be impossible to
remove. This could cause electric shock, short circuit, fire or other serious damage to
the instrument.
8
CVP-103
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Turning the Power On and Off
Z Connect the power cord.
Insert the plugs at the ends of the cord, one into the AC INLET on the
bottom panel of the Clavinova, and the other into a standard AC outlet.
In some areas, a plug adapter may be provided to match the pin configuration of the AC wall outlets in your area.
Setting Up the Clavinova
POWER
CONTRAST
VOLUME
MASTER
VOLUME
MAX
MIN
Headphones
Standard stereo phone jacks
ACMP/SONG
VOLUME
MAX
MIN
PHONES
X Press the [POWER] switch.
The main display appears in the LCD display. (Initially, the voice
Grand Piano and the accompaniment style 8 Beat 1 are selected.)
The power lamp below the lower left end of the keyboard also lights.
C Adjust the LCD.
If the LCD is difficult to read, adjust the contrast with the [CONTRAST] knob at the left of the LCD.
V Adjust the volume.
Use the [MASTER VOLUME] slider to adjust the volume to an ap-
propriate level.
● When you’re ready to turn off the power, press the [POWER] switch
again. Both the LCD display and the power lamp below the left end
of the keyboard will turn off.
Connect a set of stereo headphones (optional) to the [PHONES] jack.
When headphones are connected, the internal speaker system is automatically shut off. Since the Clavinova has two PHONES jacks, two sets
of headphones can be used simultaneously, allowing two people to enjoy
listening to the performance.
Other Connections
Your Clavinova is equipped with a variety of jacks and terminals that
let you connect it to other audio and MIDI equipment. These connectors
are located at the left end of the unit on the rear panel.
MIDI
IN
OUT
AUX INRRAUX OUT
9
+
L/L+RL/L
R
THRU
HOST SELECT
TO HOSTPEDAL
PC-1
PC-2
MIDI
Mac
You can connect other instruments that you want to play through the
Clavinova’s speakers to the AUX IN jacks, or output the Clavinova’s
sound to external speakers using the AUX OUT jacks. Use the MIDI
terminals if you want the Clavinova to control — or be controlled by —
another MIDI instrument. There’s even a TO HOST terminal that lets
you connect the Clavinova directly to a personal computer.
Be sure to turn the power off when connecting or disconnecting other
equipment. See the instructions in Chapter 9 of this manual for details.
CVP-103
11
Panel Controls and Terminals
MIDI
OUT
AUX IN
AUX OUT
RR
L/L+RL/L
J K
IN
+
L
R
THRU
HOST SELECT
PC-2
MIDI
: z
x
TO HOSTPEDAL
PC-1
Mac
○○○○○○○○○○○
21
CVP-103
H
PHONES
MASTER
VOLUME
VOLUME
MAX
MIN
ACMP/SONG
VOLUME
3
DEMO
MAX
HELP
4
ACMP ON
MIN
9
ANCEL
C1 D1 E1 F1 G1 A1 B1 C2 D2 E2 F2 G2 A2 B2 C3 D3 E3
B0A0G0F0E0D0C0B-1A-1
Volume Section
1 [MASTER VOLUME] ....................................page 23
2 [ACMP/SONG VOLUME ] ............................page 23
Special Mode Control Section
3 [DEMO] .........................................................page 14
4 [HELP] ..........................................................page 27
Accompaniment Style Section
5 STYLE buttons .............................................page 49
6 [DISK/CUSTOM]...........................................page 73
7 [MUSIC DATABASE] .................................... page 67
8 [HARMONY] .................................................page 69
Auto Accompaniment Section
9 [ACMP ON] ...................................................page 57
0 [INTRO].........................................................page 54
! [MAIN A] .......................................................page 51
@ [ M AI N B ] .......................................................page 51
# [ M AI N C ] .......................................................page 51
$ [ M AI N D ] .......................................................page 51
% [ENDING]......................................................page 55
^ [ FADE IN/OU T] .....................................pages 55, 56
Metronome Section
& [METRONOME]............................................page 25
8BEAT
16BEAT DANCE
SWING/
LATIN
JAZZ
INTRO
MAIN A
5
STYLE
BALLAD
BALL-
COUNTRY
ROOM
AUTO ACCOMPANIMENT
AUTO FILL
MAIN B
MAIN C
ROCK/
TRAD/
WALZ
MAIN D
R&B
PIANIST
CUSTOM
ENDING
6
7
MUSIC
DATABASE
HARMONYDISK
FADE
IN
/
OUT
&
METRONOME RESET
8
TAP SYNCHRO START/STOP
START/STOP
*
TEMPO
0 ! @ # $ % ^ ( ) q
w
CONTRAST
BEAT
e
MIXER
FUNCTION
r t
DIRECT ACCESS
PAGE
u o
i
* TEMPO [–], [+] .............................................page 25
Start/Stop Section
( [TAP] .............................................................page 53
) [SYNCHRO]..................................................page 53
q [START/STOP]......................................pages 52, 55
Display Control Section
w [CONTRAST] ................................................page 11
e [ BEAT] lamps................................................page 52
r [FUNCTION] ...............................................page 136
t[MIXER] .........................................................page 24
y LCD display ..................................................page 16
u PAG E [<], [>] ..............................................page 19
i [DIRECT ACCESS] ......................................page 21
o LCD buttons..................................................page 18
p [EXIT] ............................................................page 21
Q Data dial .......................................................page 17
W [–], [+]............................................................page 17
Song Control Section
E [SONG] .........................................................page 94
R [PLAY/STOP]................................................page 95
T [REC] .......................................................... page 113
Y [PAUSE]......................................................page 103
U [REW] .........................................................page 103
I [FF] .............................................................page 103
y
12
10
CVP-103
Q
EXIT
p W
c
v
b
SONG
E
PAUSE REW FF
Y
EASY PLAY
SONG CONTROL
PLAY/
STOP
R
U
GUIDE CONTROL
NEXT NOTE
SOUND
REPEAT
REC
PIANO E. PIANO GUITAR
T
BRASS
I
1
/
SAX
FLUTE
234
VOICE
s
SYNTHE-
ORGAN
SIZER
PER-
BASS
REGISTRATION/ONE TOUCH SETTING
CUSSION
ENSEMBLE
BANK
O P a j k l ;
STRINGS/
CHOIR
BANK
XG
S
d
DUAL
REVERB
SPLIT
EFFECT
f h
REGISTRATION
A
DISK IN USE
ONE TOUCH
SETTING
g
Panel Controls and Terminals
D
G
F
POWER
F3 G3 A3 B3 C4 D4 E4 F4 G4 A4 B4 C5 D5 E5 F5 G5 A5 B5 C6
Guide Control Section
O [ E A S Y PLAY] ..............................................page 105
P [NEXT NOTE] .............................................page 105
a [SOUND REPEAT] .....................................page 106
Voice Section
s VOICE buttons .............................................page 29
d [DUAL] ..........................................................page 33
f [SPLIT]..........................................................page 36
L [PEDAL] .............. page 42 in the Reference Booklet
: MIDI [IN], [OUT], [THRU] ...........................page 160
z [HOST SELECT] ........................................page 160
x [ TO HOS T ] ..................................................page 160
Pedals
c Soft pedal .....................................................page 40
v Sostenuto pedal ...........................................page 40
b Damper pedal ...............................................page 40
g [REVERB] .....................................................page 41
h [EFFECT]......................................................page 46
Registration/One Touch Setting Section
j [1] through [4] .......................................pages 72, 90
k [ B A N K – ] .......................................................page 89
l [ B AN K + ] .......................................................page 89
; [REGISTRATION] .........................................page 90
A [ONE TOUCH SETTING] .............................page 72
S [DISK IN USE] lamp .......................................page 9
D Floppy disk drive (3.5”) ..................................page 9
F [POWER] ...................................................... page 11
G Keyboard guide lamps ...............................page 109
Connectors
H [PHONES]...................................................page 158
J AUX IN [L/L+R], [R] ....................................page 158
K AUX OUT [L/L+R], [R] ................................page 159
D6 E6 F6 G6 A6 B6 C7
11
CVP-103
13
Playing the Demo Songs
The Clavinova features a total of 50 demo songs: 4 feature songs,
24 special pieces showcasing the voices, and 22 pieces showcasing
the styles. Listen to them all and hear what the Clavinova can do.
Z Call up the Demo Play mode. ..............................................................
Press [DEMO]. The lamps of the STYLE button and VOICE button
flash continuously, and the DEMO display appears.
DEMO
HELP
X Select the desired play mode. ............................................................
○○○○○○○○○○○○○○○○○
Select the desired play mode by pressing the rightmost LCD button. The
following three modes are available:
ALL All the songs play back continuously in order, starting from the
selected song. Playback continues repeatedly until stopped.
RANDOM All the songs play back randomly, starting from the selected
song. Playback continues repeatedly until stopped.
SINGLE Only the selected song plays back. When the song is finished,
playback stops automatically.
C Select the song and start playback..............................................
When you select a song, the demo automatically starts playing in the
selected play mode. There are three ways to select a demo song, as described below:
(A) To listen to one of the featured demo songs, press one of
the buttons under the numbers 1 through 4 in the display.
➔ The current song number is highlighted during playback.
• You can also start the demo playback,
beginning with the first feature song, by
pressing [START/STOP] or [PLAY/
STOP].
• For a complete list of the Clavinova’s
demo songs, refer to page 9 of the
Reference Booklet.
14
12
CVP-103
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
(B) To listen to a voice demo, press the VOICE button corre-
sponding to the desired voice category.
➔ Playback starts from the first demo song for the selected category.
The lamp of the corresponding VOICE button flashes.
VOICE
PIANO E. PIANO GU ITAR
SYNTHE-
SIZER
ORGAN
STRINGS/
CHOIR
DUAL
REVERB
Playing the Demo Songs
There are two demo songs for each voice
category. To skip to the second song,
press the flashing button a second time.
BRASS
SAX
FLUTE
/
BASS
PER-
CUSSION
ENSEMBLE
SPLI T
XG
EFFECT
(C) To listen to a style demo, press the STYLE button corre-
sponding to the desired style category.
➔ Playback starts from the first demo song for the selected category.
The lamp of the corresponding STYLE button flashes.
8BEAT
SWING/
JAZZ
STYLE
16BEAT DANCE
LATIN
BALLAD
COUNTRY
BALLROOM
ROCK/
R&B
TRAD/
WALZ
PIANIST
CUSTOM
MUSIC
DATABASE
HARMONYDISK
V Adjust the volume. ..........................................................................................
Use the [MASTER VOLUME] slider to adjust the volume.
There are two demo songs for each style
category. To skip to the second song,
press the flashing button a second time.
The [ACMP/SONG VOLUME] control
cannot be used.
B Stop the demo playback. .........................................................................
To stop playback, press either [START/STOP] or [PLAY/STOP], or
the LCD button corresponding to the song that’s currently playing.
N Exit the Demo mode......................................................................................
To exit the Demo mode, press [DEMO] again (or press [EXIT]).
● Playing Along with the Demo Songs
You can play the keyboard while a demo song is playing back. You
can also change the tempo (page 25) and use the [REW], [FF] and
[PAUSE] buttons. When you play 3. Lyric Demo, the Clavinova will
display the lyrics so you can sing (as well as play) along. Also, you can
use the Guide function (page 105) while the Clavinova is playing 4.
GUIDE Demo. You cannot change the voice selection while the demo
is playing, however.
To change songs during playback:
Press the LCD button, VOICE button, or
STYLE button of another song; the song
then changes. When ALL or RANDOM is
selected as the play mode, the Clavinova
will play other songs when the selected
song is finished.
Demo song data is not output through
the [MIDI OUT] terminal; however, your
keyboard performance data is output.
13
CVP-103
15
CHAPTER 2: Basic Operation
Using the LCD Display Controls
You will refer to the LCD displa y frequently as you operate your
Clavinova. This section consists of a short tutorial that will help
you learn how to read the LCD display and use the related
controls.
Selecting a Function
Many of the Clavinova’s functions are displayed at the bottom of the
LCD. The main display shown below contains two functions: KBD VOL
and RIGHT1 VOICE. These items are displayed in rounded rectangles,
which means they represent settings that can be changed.
○○○○○○○○○
Main display
Remember, the
play that appears first when you turn the
power on.
main display
is the dis-
Before you can change a function’ s setting, however, you have to select it
first. In the main display, the RIGHT1 VOICE function is highlighted, indi-
cating that this function is currently selected.
To select a function, press and quickly release the LCD button directly
below that function. For example, you can select KBD VOL by pressing the
leftmost LCD button.
Press to select.
Highlighted items
Selected items are
letters on a dark background).
LCD buttons
The five LCD buttons under the LCD
display represent different functions,
depending on the contents of the display.
highlighted
(i.e., white
16
14
CVP-103
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Changing a Setting
There are several ways to change a function’s value. Here are two of the
main ways:
■ Using the data dial or [–] and [+] buttons.................................
Once you have selected a function, you can change its setting with the
data dial or the [–] and [+] buttons. Since you have just selected KBD
VOL, try turning the dial or pressing the [–] button until it reads 0.
The KBD VOL function sets the keyboard volume. When you set it to
0, you will find that the keyboard won’t pr oduce any sound, no matter
how high you set the [MASTER V OLUME] slider!
Using the LCD Display Controls
You can press the [–] and [+] buttons
repeatedly to change the value a little, or
hold them down to change it quickly.
Refer to page 23 for details on the KBD
VOL function.
■ Using the LCD buttons..................................................................................
You can also increase a setting by simply pressing and holding the
corresponding LCD button. For now, since you’ll want to hear your keyboard later on, press and hold the leftmost LCD button until the value for
KBD VOL is back up to 127.
Hold down to increase.
Once you’ve got the keyboard volume back where it belongs, you can
learn about a couple of other ways to change settings.
This is why you should release the LCD
button quickly when you select a function: you could end up raising its value
when you want to lower it!
15
CVP-103
17
Using the LCD Display Controls
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Changing a Setting in a Menu Display
You can use either of the methods described previously to change the current voice
selection. Just press RIGHT1 VOICE and hold the button down, or use the data dial or
the [+] button to scan through the options. Try listening to a few of the voices while
you’re at it…
The problem with this method is that it can be hard to find the voice you’re looking
for — after all, the Clavinova has more than 600 voices! So you’ll probably want to use
a menu display to see what your choices are. Try pressing the [PIANO] button now.
Voice
A voice is one of the sounds
the Clavinova uses to make
music.
PIANO E. PIANO GUITAR
SYNTHE-
SIZER
When you press one of the VOICE buttons, the LCD displays a new set of
functions listing the voices of that type. You should now be looking at a menu of
piano voices.
■ Using the LCD buttons.................................................................................................
Each piano voice in this display is listed as a separate function in a rounded rectangle. This means that you can use the LCD buttons to select voices, just like you did to
select the KBD VOL and RIGHT1 VOICE functions at the beginning of this tutorial.
Refer to page 29 for more
details about selecting voices.
18
Press an LCD button to select the corresponding voice.
■ Using the data dial or [–] and [+] buttons................................................
There is another way to select voices in this display. You can use the data dial
or the [–] and [+] buttons to change the selection. Press [–] or turn the data dial
counterclockwise to select a voice to the left; press [+] or turn the dial clockwise
to select a voice to the right.
Keep in mind that you can use the data dial or [–] and [+] buttons to select
functions only when viewing a menu display. In other displays, these controls
will change the value of the currently selected function instead.
Try selecting different piano voices in this display before you move on to the
next step.
CVP-103
Menu displays
You will use menu displays for
only two purposes: to select a
voice, as shown here, or to
select an accompaniment style
(page 49).
Use the data dial or
[–] and [+] buttons to
select a voice.
16
○ ○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Displaying a Different Page
As you were trying out the piano voices in the preceding step, you
may have been surprised to see all the voice names suddenly replaced by
an entirely different set of voices. Specifically, this occurs when you
select the rightmost voice in the display (Midi Grand), then turn the
data dial clockwise or press the [+] button.
This happens because the CVP-103 has more piano voices than it can
fit in the display. When one of the Clavinova’s features includes more
functions than will fit in the display, the functions are divided among two
or more display pages. The VOICE SELECT Piano display consists of
two display pages, as shown below:
Using the LCD Display Controls
Display pages
Some displays are divided into two or
more pages, indicated by a series of
overlapping boxes in the upper right
corner of the display. The number in the
topmost box is the number of the current
display page.
PAG E
Use the PAGE buttons to switch between pages.
When a display is divided into pages, you can use PAGE buttons to
change pages. Try it: press the [<] button to see page 1, or the [>] button to see page 2. Once you have displayed the desired page, you can use
the LCD buttons select a voice in that page as described in the preceding
step.
Resetting a Function’s Value
After you have changed a function’s value, you may find you want to
restore its basic setting. To demonstrate this, we’ll have to look at another of
the Clavinova’s displays. Press the [FUNCTION] button.
FUNCTION
This button calls up one of the Clavinova’s FUNCTION displays. You
can use this display to tune and transpose the keyboard.
The TUNE function in this display corresponds to two LCD buttons
labeled ▼ and ▲. You can use these buttons to tune the keyboard up or
down. Press and hold the ▼ button (or use the data dial or the [–] button)
to tune the keyboard down as far as it will go.
MIXER
Refer to page 138 for details about the
functions on the FUNCTION [PEDAL]
display page.
Basic settings
• The functions of the Clavinova are set
to certain standard values or standard
conditions when the instrument is
shipped. These settings and conditions
are called the basic settings.
• A function’s basic settings are generally noted in the sidebar together with
the possible settings for that function.
• You can also use the Recall function
(page 153) to restore basic settings at
any time.
Refer to page 136 for details on the
TUNE and TRANSPOSE functions.
17
CVP-103
19
Using the LCD Display Controls
If you play a few notes, you’ll notice that your Clavinova is flat by quite
a bit. Now, let’s assume that you want to reset the k eyboard to the standard
440.0 Hz. You could use the ▲ button (or the data dial, or the [
return the value to its basic setting — but there’s an easier way:
When a function has a basic setting, you can reset it to that value by
pressing both the ▲ and ▼ buttons (or both the [–] and [+] buttons) simultaneously. Try doing this now.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
There are some functions whose settings
+
] button) to
cannot be returned to the basic value by
pressing the ▲ and ▼ buttons (or [–] and
[+] buttons) simultaneously.
When you’ve got the keyboard back in tune, you’re ready to go on to the
next operation.
Using Functions in Non-rounded Rectangles
If you look at the upper right corner of the LCD, you’ll notice that the
FUNCTION display consists of several display pages. Press the PAGE [>]
key once to open the next page, which is titled FUNCTION [KEYBOARD
2]. We’ll use the functions on this page to discuss the next operation.
In addition to the FIXED VELOCITY function, which is selected in this
display, the FUNCTION [KEYBOARD 2] page has two functions in normal
rectangles: KEY TOUCH and VOICE SETTING. Such functions cannot be
selected; instead, pressing the corresponding LCD button changes the setting
directly without selecting the function.
The FIXED VELOCITY function is described on page 137.
20
18
CVP-103
○ ○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
By pressing the LCD button under KEY TOUCH, for example, you can
set the Clavinova’s response to how hard you play. The value displayed in
the rectangle switches from NORMAL to SOFT, then FIXED, then HARD
— but the FIXED VELOCITY function remains selected.
The VOICE SETTING function determines whether reverb, chorus,
effect, and other settings are automatically selected when a voice is selected. It works a little differently: when you press the LCD button, the
highlighted setting switches between AUTO and MANUAL. Still,
FIXED VELOCITY remains selected.
Using the LCD Display Controls
For more details on the KEY TOUCH
function, refer to page 137.
For more details on the VOICE SETTING
function, refer to page 137.
There are other sorts of functions that are displayed in non-rounded
rectangles, like the ones you used to select a demo song in Demo mode
(see page 14). The important thing to remember about these functions is
that you don’t select them, you execute them.
Now we’re ready to return to the main display. First, however, set the
KEY TOUCH and VOICE SETTING functions back to NORMAL and
AUTO, respectively.
Exiting to the Main Display
To exit the current display, press the [EXIT] button.
EXIT
The main display should show the name of the last piano voice that you
selected in the VOICE SELECT Piano display.
Using the Direct Access Function
You can usually use [EXIT] to get back to
the main display. In some cases, however, this button will return you to a previous setting display instead. When this
happens, pressing [EXIT] again will get
you back to the main display.
The last function we need to discuss is Direct Access. The [DIRECT ACCESS] button lets you jump directly to pages with particularly useful settings.
When you press [DIRECT ACCESS] , the “Press a button to display
corresponding settings” message will appear in the LCD display.
DIRECT ACCESS
19
CVP-103
21
Using the LCD Display Controls
This message will remain onscreen for about three seconds. Press the
button corresponding to the settings you want to display before the message disappears.
Here is a list of pages you can access with Direct Access:
[DIRECT ACCESS] plus: Displays: See page:
[HARMONY] HARMONY 69
[ACMP ON]
[METRONOME] METRONOME 26
Any VOICE button KEYBOARD [RIGHT2]
[DUAL] KEYBOARD [RIGHT2] 34
[SPLIT] KEYBOARD [LEFT] 37
[REVERB]
[EFFECT]
[REGISTRATION]
(4)
(4)
ACCOMPANIMENT MODE
KEYBOARD [RIGHT1]
KEYBOARD [LEFT]
REVERB 41
REVERB DEPTH 43
EFFECT 46
EFFECT DEPTH 48
REGISTRATION [FREEZE]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
You can also press an appropriate button
while holding down the [DIRECT ACCESS] button.
59
(1)
(2)
(3)
31
31
31
91
(1)
When RIGHT1 VOICE is selected in
the main display.
(2)
When RIGHT2 VOICE is selected in
the main display.
(3)
When LEFT VOICE is selected in the
main display.
(4)
Selects whichever page was most
recently displayed.
● A Word about Messages
For ease of operation, the Clavinova displays various messages (like the message displayed by the Direct
Access function as described above) that either prompt you to the next operation, ask for confirmation, or inform you that the last operation is not effective, valid, or appropriate. When such messages appear, follow the
instructions as shown. For details about each message, please refer to the “Messages” section on page 165.
● Saving Your Changes
Now that you’ve started learning how to change the Clavinova’s settings, you may be wondering whether it
will remember the changes you’ve made even after you’ve turned the power off. The answer is yes — but you
need to tell it which settings you want it to remember .
By default, the Clavinov a will not remember most of your setting changes. You have two ways to tell it which
settings you want to remember:
• You can register your settings with the Registration function (page 89). Once you have registered your
settings, you can restore them at any time by pressing a couple of buttons.
• You can instruct the Clavinova to remember certain settings when the power is off, and recall these settings when you turn the power back on. To do this, you need to change the settings of the Backup function
(page 152).
22
20
CVP-103
Adjusting the Volume
The Clavinova has two sliders that let you adjust the overall volume
and the accompaniment or song playback volume. There are also
settings that you can use to adjust the keyboard volume and the
volume of each part of the automatic accompaniment or song.
VOLUME
MASTER
ACMP/SONG
VOLUME
VOLUME
MAX
MAX
MIN
MIN
VOLUME
MASTER
ACMP/SONG
VOLUME
VOLUME
MAX
MIN
Adjusting the Overall Volume
STYLE
ROCK/
R&B
DEMO
8BEAT
16BEAT DANCE
PIANIST
BALLAD
MAX
SWING/
BALL-
TRAD/
LATIN
COUNTRY
JAZZ
ROOM
WALZ
HELP
ACMP ON
MIN
ANCEL
CUSTOM
AUTO ACCOMPANIMENT
AUTO FILL
INTRO
ENDING
MAIN B
MAIN D
MAIN A
MAIN C
CONTRAST
MUSIC
TEMPO
DATABASE
BEAT
METRONOME RESET
FUNCTION
HARMONYDISK
START/STOP
FADE
/
OUT
IN
TAP SYNCHRO START/STOP
○○○○○○○○○○○○○○○○○○○○○
SONG CONTROL
PLAY/
STOP
MIXER
DIRECT ACCESS
PAGE
SONG
PAUSE REW FF
GUIDE CONTROL
EXIT
EASY PLAY
NEXT NOTE
VOICE
SYNTHE-
STRINGS/
DUAL
ORGAN
REC
PIANO E. PIANO GUITAR
SAX
BRASS
FLUTE
SOUND
REPEAT
234
1
/
BASS
REGISTRATION/ONE TOUCH SETTING
REVERB
SIZER
CHOIR
PER-
XG
ENSEMBLE
SPLIT
EFFECT
CUSSION
ONE TOUCH
REGIST-
SETTING
RATION
BANK
BANK
Use the [MASTER VOLUME]
slider to set the overall volume of
the Clavinova.
MASTER
VOLUME
VOLUME
ACMP/SONG
MAX
MIN
VOLUME
MAX
MIN
Adjusting the Accompaniment or Song Volume
MASTER
VOLUME
VOLUME
ACMP/SONG
MAX
MIN
VOLUME
MAX
MIN
Use the [ACMP/SONG VOL-
UME] slider to set the playback
volume of the automatic accompaniment and songs.
Setting the Keyboard Volume
• The [MASTER VOLUME] slider also
determines the output level of the
signal at the [PHONES] jack.
• Signals input to the AUX IN jacks are
also affected by the [MASTER VOLUME] setting; however, signals output
via the AUX OUT jacks are not.
This control has no effect on the volume
of your keyboard performance.
Select KBD VOL in the main
display, then use the data dial or
the [–] and [+] buttons to change
the keyboard volume.
21
CVP-103
23
Adjusting the Volume
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Adjusting Accompaniment or Song Part Levels
Call up the MIXER display by pressing [MIXER]. In the Mixer display,
the volume of Automatic Accompaniment and indi vidual parts of a song can
be adjusted. Press [MIXER] again (or [EXIT]) to return to the previous
display .
There are two types of mixer display, as shown below.
● Automatic Accompaniment Mixer
This MIXER display appears when you’re not using the Song mode.
See “Adjusting Individual Part Levels” (page 65) for details.
● Song Mixer
This MIXER display appears in the Song mode. See “Adjusting Indi-
vidual Track Levels” (page 100) for details.
24
22
CVP-103
Using the Metronome
○○○○○○○○○○○○○○○○○○○○
The Clavinova features a convenient metronome that is ideal for practicing. The
procedure for setting the metronome tempo can also be used to set the playback
tempo for the Auto Accompaniment (page 49) and Song (page 93) modes.
CONTRAST
MUSIC
TEMPO
DATABASE
BEAT
METRONOME RESET
MIXER
FUNCTION
HARMONYDISK
START/STOP
FADE
IN
/
OUT
TAP SYNCHRO START/STOP
DIRECT ACCESS
PAGE
METRON OME
VOLUME
MASTER
ACMP/SONG
VOLUME
VOLUME
MAX
MAX
MIN
MIN
STYLE
ROCK/
R&B
16BEAT DANCE
DEMO
HELP
ACMP ON
ANCEL
PIANIST
8BEAT
BALLAD
SWING/
BALL-
TRAD/
LATIN
COUNTRY
JAZZ
ROOM
WALZ
CUSTOM
AUTO ACCOMPANIMENT
AUTO FILL
ENDING
INTRO
MAIN B
MAIN D
MAIN A
MAIN C
Using the Metronome
You can start the metronome and set the tempo from any display, including
the main display.
■ Starting and Stopping the Metronome .......................................
To start the metronome, simply press the [METRONOME] button.
TEMPO
METRONOME RESET
➔ The [METRONOME] lamp lights, and the metronome starts keeping
time (indicated by the flashing of the BEAT lamps).
SONG CONTROL
PLAY/
STOP
SONG
PAUSE RE W FF
GUIDE CONTROL
EXIT
EASY PLAY
NEXT NOTE
VOICE
SYNTHE-
STRINGS/
DUAL
ORGAN
/
BASS
REGISTRATION/ONE TOUCH SETTING
REVERB
SIZER
CHOIR
PER-
XG
ENSEMBLE
SPLIT
EFFECT
CUSSION
ONE TOUCH
REGIST-
SETTING
RATION
BANK
BANK
REC
PIANO E. PIANO GUITAR
SAX
BRASS
FLUTE
SOUND
REPEAT
234
1
• The metronome can also be used
during playback in Auto Accompaniment (page 49) or Song mode
(page 93).
• The metronome cannot be used
when playing disk software that
was recorded in free-tempo (see
page 96).
CONTRAST
BEAT
Press the [METRONOME] button again to stop the metronome.
■ Adjusting the Tempo......................................................................................
The current tempo, indicated at the left edge of the display, depends on
the selected style (see page 49). To change the tempo, press the TEMPO [–]
and [+] buttons.
TEMPO
METRONOME RESET
Slower Faster
➔ The tempo indication in the main display is highlighted, and the
tempo changes.
You can either press TEMPO [–] or [+] buttons briefly to change the
tempo value by one, or hold down the button to change it continuously.
When the tempo is highlighted in the display, you can also use the data
dial or [–] and [+] buttons to set the tempo.
Tempo
• Range: 32 — 280
• Basic setting: Depends on style.
Restoring the Basic Tempo
You can restore the preset tempo for
the currently selected style by simultaneously pressing both TEMPO [–]
and [+] buttons.
During Style or Song Playback…
• If a style or song is started while the
metronome is playing, the metronome will continue to sound along
with the style or song.
• The metronome uses the time signa-
ture of the style or song instead of
the BEAT setting during style or
song playback.
• The metronome stops when the
style or song stops.
23
CVP-103
25
Using the Metronome
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Changing the Metronome Settings
You can change the metronome’s time signature and volume using the
settings in the METRONOME page.
■ Displaying the Metronome Settings..............................................
To display the METRONOME page, press [DIRECT ACCESS], then
[METRONOME].
DIRECT ACCESS
➾
➔ The METRONOME display appears.
METRONOME RESET
TEMPO
■ Setting the Beat (Time Signature)....................................................
Use the BEAT ▼ and ▲ buttons to change the time signature. (If the BEAT
function is highlighted, you can also change its settings with the data dial or the
[–] and [+] buttons.)
When NORMAL is selected, the metronome ticks steadily at the current
tempo with no accented beats.
When BEAT is set to 2, 3, 4, or 5, the metronome ticks of f measures with the
selected number of beats, playing a bell sound on the first beat of each measure.
■ Setting the Metronome Volume ..........................................................
Use the VOLUME ▼ and ▲ buttons to change the metronome volume.
(If the VOLUME function is highlighted, you can also change its settings
with the data dial or the [–] and [+] buttons.)
BEAT
• Settings: NORMAL, 2 — 5
• Basic setting: NORMAL
VOLUME
• Range: 0 — 127
• Basic setting: 64
26
The volume of the metronome is determined by both the VOLUME func-
tion and the [ACMP/SONG V OLUME] slider (exce pt in Song mode, in
which case the volume of the metronome is not affected by the slider). If you
use the slider, the playback v olume for the Automatic Accompaniment (page
50) will also be affected.
24
CVP-103
Using the Help Mode
The Help mode provides convenient explanations of the main
functions of the Clavinov a. You can select help topics from a menu
displayed on the LCD, or press a button on the panel to get help
information related to that control.
○○○○○○○○○○○○○○○○○○○○○○
HELP
VOLUME
MASTER
ACMP/SONG
VOLUME
VOLUME
MAX
MAX
MIN
MIN
STYLE
ROCK/
DEMO
ACMP ON
R&B
8BEAT
16BEAT DANCE
PIANIST
BALLAD
SWING/
BALL-
TRAD/
LATIN
COUNTRY
JAZZ
ROOM
WALZ
HELP
ANCEL
CUSTOM
AUTO ACCOMPANIMENT
AUTO FILL
INTRO
ENDING
MAIN B
MAIN D
MAIN A
MAIN C
CONTRAST
MUSIC
TEMPO
DATABASE
BEAT
METRONOME RESET
MIXER
FUNCTION
HARMONYDISK
START/STOP
FADE
/
OUT
IN
TAP SYNCHRO START/STOP
DIRECT ACCESS
PAGE
EXIT
Z Call up the Help mode. ...............................................................................
Press the [HELP] button.
DEMO
HELP
➔ The Help menu display appears.
SONG CONTROL
SONG
PAUSE RE W FF
GUIDE CONTROL
EASY PLAY
PLAY/
STOP
NEXT NOTE
VOICE
SYNTHE-
STRINGS/
DUAL
ORGAN
REC
PIANO E. PIANO GUITAR
SAX
BRASS
FLUTE
SOUND
REPEAT
234
1
/
BASS
REGISTRATION/ONE TOUCH SETTING
REVERB
SIZER
CHOIR
PER-
XG
ENSEMBLE
SPLIT
EFFECT
CUSSION
ONE TOUCH
REGIST-
SETTING
RATION
BANK
BANK
While the Help mode is active, no other
operations can be performed.
X Select the language if necessary....................................................
Select the desired language for help (ENGLISH, JAPANESE, GER-
MAN, FRENCH, or SPANISH) by pressing the fourth LCD button.
C Select a help topic. .........................................................................................
Use the SELECT ▲ and ▼ LCD buttons to select one of the follow-
ing eight menu items.
Help Topics
• Basic Operations • Accompaniment
• Demo Songs • Song Playback
• Voices • Song Recording
• Styles • Functions
➔ The selected menu is highlighted.
➾ Press the LCD button under ENTER to enter your selection.
➔ The first page of the selected help information is displayed.
The selected language is always backed
up even after the power is turned off.
25
CVP-103
27
Using the Help Mode
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
V Turn the pages and read the help information. ................
Use the fourth LCD button to advance the page. You can also press
the third LCD button if you want to go back and read the previous page.
B Exit the Help topic...........................................................................................
Press the LCD button under EXIT to return to the Help menu. You
can select another menu item or panel button and read through other help
topics.
N Exit the Help mode. ........................................................................................
To exit the Help mode and to go back to the main display at any time,
simply press [HELP].
DEMO
HELP
28
26
CVP-103
CHAPTER 3: Voices
Selecting Voices
○○○○○○○○○○○○○○○○○○○○○○○○○○
The Clavinov a features a wealth of rich, authentic voices, including
piano, strings and brass instruments. It also features a Keyboard
Percussion function that lets you play the realistic drum and
percussion sounds directly from the keyboard.
VOLUME
MASTER
ACMP/SONG
VOLUME
VOLUME
MAX
MAX
MIN
MIN
STYLE
ROCK/
MUSIC
R&B
DEMO
8BEAT
16BEAT DANCE
PIANIST
BALLAD
SWING/
BALL-
LATIN
COUNTRY
JAZZ
ROOM
HELP
AUTO ACCOMPANIMENT
AUTO FILL
ACMP ON
INTRO
MAIN B
MAIN A
MAIN C
ANCEL
TEMPO
DATABASE
METRONOME RESET
TRAD/
WALZ
HARMONYDISK
CUSTOM
START/STOP
FADE
IN
/
OUT
ENDING
TAP SYNCHRO START/STOP
MAIN D
● Voice Types
• Clavinova Voices :195
• XG Voices : 480
CONTRAST
BEAT
MIXER
FUNCTION
DIRECT ACCESS
PAGE
SONG CONTROL
PLAY/
STOP
SONG
PAUSE RE W FF
GUIDE CONTROL
EXIT
EASY PLAY
NEXT NOTE
VOICE
SYNTHE-
STRINGS/
DUAL
REVERB
ORGAN
REC
PIANO E. PIANO GUITAR
SIZER
CHOIR
PER-
SAX
/
BASS
XG
ENSEMBLE
SPLIT
CUSSION
REGISTRATION/ONE TOUCH SETTING
EFFECT
ONE TOUCH
REGIST-
SETTING
RATION
BANK
BANK
BRASS
FLUTE
SOUND
REPEAT
234
1
* For a list of the voices, see page 5 in the Reference Booklet.
* The Clavinova’s voices are divided into twelve groups, corre-
sponding to the twelve VOICE buttons on the panel.
PIANO E. PIANO GUITAR
SAX
BRASS
FLUTE
• Drum/SFX Kits : 12
VOICE
SYNTHE-
SIZER
BASS
PER-
CUSSION
/
ORGAN
ENSEMBLE
STRINGS/
CHOIR
XG
DUAL
SPLIT
REVERB
EFFECT
Selecting a Voice from the VOICE SELECT Display
ZSelect the voice group.............................................................................
Select the desired voice group by pressing the appropriate VOICE
button.
➔ The VOICE SELECT display appears.
VOICE
PIANO E. PIANO GU ITAR
SAX
/
BRASS
FLUTE
BASS
SYNTHE-
SIZER
PER-
CUSSION
ORGAN
ENSEMBLE
STRINGS/
CHOIR
XG
DUAL
SPLI T
REVERB
EFFECT
Exiting the Display
To return to the main display, press [EXIT].
Backing Up the Selected Voice
• When the power is turned ON, the Grand
Piano voice is selected automatically.
However, if the Backup function (page
152) is set to ON, the last selected voice
will automatically be selected.
• The last selected voice in each group can
be retained in memory, even after turning
off the power, when the Backup function
(page 152) is set to ON.
27
CVP-103
29
Selecting Voices
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
XSelect the voice..................................................................................................
Select the desired voice by pressing the appropriate LCD button. The
data dial and [–] and [+] buttons can be also used.
Each VOICE SELECT display consists of two or more pages. Use the
PAGE [<] and [>] buttons to call up the various pages.
CPlay the selected voice..............................................................................
Adjust the volume by using the [MASTER V OLUME] slider.
Selecting Voices from the Main Display
You can also select a voice using the RIGHT1 VOICE function in the
main display.
Automatic Voice-related Settings
Selecting a voice automatically selects
the best-suited reverb, chorus, effect,
and other settings for that particular
voice. You can disable this so that settings are not automatically selected by
using the VOICE SETTING function
(page 137).
ZSelect the RIGHT1 VOICE function. ..............................................
If the RIGHT1 VOICE function is not already highlighted, press the
fourth LCD button to highlight it.
XSelect the voice...................................................................................................
Select the voice using the data dial or [–] and [+] buttons. You can
also hold down RIGHT1 VOICE to advance the voice selection continuously. (When selecting a voice in this way, the voice can be selected not
only from a certain voice group but from all voices.)
CPlay the voice........................................................................................................
Adjust the volume by using the [MASTER V OLUME] slider.
About Ensemble Voices
The Clavinova’s ensemble voices are
rich, dual-like voices that you can play
without entering the Dual mode (page
33.) Press the [Ensemble] button to
display a menu of ensemble voices.
About XG Voices
Yamaha’s XG format is a major new
enhancement to the GM (General MIDI)
System Level 1 format. It provides for
more instrument sounds and variations,
as well as greater expressive control over
voices and effects. XG also ensures
compatibility with future instruments and
software.
• Press the [XG] button to display a
menu of XG voices.
• Press another VOICE button while
holding down the [XG] button to display a list of XG voices in the corresponding category.
30
28
CVP-103
Loading...
