Xerox DocuPrint 92C IPS
System Overview Guide
Version 7.1
August 2000
721P89130
Xerox Corporation
Printing Systems Documentation and Education
701 South Aviation Boulevard, ESM1-058
El Segundo, CA 90245
©1997, 1998, 1999, 2000 by Xerox Corporation. All rights reserved.
Copyright protection claimed includes all forms and matters of
copyrightable material and information now allowed by statutory or
judicial law or hereinafter granted, including without limitation,
material generated from the software programs which are displayed
on the screen, such as icons, screen displays, looks, etc.
Printed in the United States of America.
Publication number: 721P89130
Xerox® and all Xerox products mentioned in this publication are
trademarks of Xerox Corporation. Products and trademarks of other
companies are also acknowledged.
Changes are periodically made to this document. Changes, technical
inaccuracies, and typographic errors will be corrected in subsequent
editions.
Laser safety
Warning: Adjustments, use of controls, or performance of
!
procedures other than those specified herein may result in
hazardous light exposure.
The Xerox DocuPrint printers are certified to comply with the
performance standards of the U.S. Department of Health, Education,
and Welfare for Class 1 laser products. Class 1 laser products do not
emit hazardous radiation. The DocuPrint printers do not emit
hazardous radiation because the laser beam is completely enclosed
during all modes of customer operation.
The laser danger labels on the system are for Xerox service
representatives and are on or near panels or shields that must be
removed with a tool. DO NOT REMOVE LABELED PANELS OR
PANELS NEAR LABELS. ONLY XEROX SERVICE
REPRESENTATIVES HAVE ACCESS TO THESE PANELS.
Ozone information
This product produces ozone during normal operation. The amount
of ozone produced depends on copy volume. Ozone is heavier than
air. The environmental parameters specified in the Xerox installation
instructions ensure that concentration levels are within safe limits. If
you need additional information concerning ozone, call 1-800-8286571 to request the Xerox publication 600P83222, OZONE.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE iii
Operation safety
Your Xerox equipment and supplies have been designed and tested
to meet strict safety requirements. They have been approved by
safety agencies, and they comply with environmental standards.
Please observe the following precautions to ensure your continued
safety.
• Always connect equipment to a properly grounded electrical
outlet. If in doubt, have the outlet checked by a qualified
electrician.
Warning: Improper connection of the equipment grounding
!
conductor may result in risk of electrical shock.
• Never use a ground adapter plug to connect equipment to an
electrical outlet that lacks a ground connection terminal.
• Always place equipment on a solid support surface with
adequate strength for its weight.
• Always use materials and supplies specifically designed for
your Xerox equipment. Use of unsuitable materials may result in
poor performance and may create a hazardous situation.
• Never move either the printer or the Printer Controller without
first contacting Xerox for approval.
• Never attempt any maintenance that is not specifically
described in this documentation.
• Never remove any covers or guards that are fastened with
screws. There are no operator-serviceable areas within these
covers.
• Never override electrical or mechanical interlocks.
• Never use supplies or cleaning materials for other than their
intended purposes. Keep all materials out of the reach of
children.
• Never operate the equipment if you notice unusual noises or
odors. Disconnect the power cord from the electrical outlet and
call service to correct the problem.
If you need any additional safety information concerning the
equipment or materials Xerox supplies, call Xerox Product Safety at
the following toll-free number in the United States:
1-800-828-6571
For customers outside the United States contact your local Xerox
representative or operating company.
iv XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Table of contents
Laser safety iii
Ozone information iii
Operation safety iv
Introduction ix
About this guide ix
Contents x
Conventions xi
Related publications xii
1. System overview 1-1
Functional overview of the DocuPrint IPS 1-1
Major system components 1-2
Throughput speed 1-2
Host connectivity options 1-3
IPDS data stream 1-4
Dual Mode 1-4
DocuPrint 92C IPS hardware features 1-5
Highlight color 1-5
Multiple input trays 1-5
Advanced paper handling 1-5
600 dpi resolution 1-6
Multiple output trays/bins 1-6
User interface 1-7
Software features 1-8
Mixed paper sizes within a job 1-8
Tray selection capabilities 1-8
IOCA Replicate and Trim 1-9
Mixed plex 1-9
Enhanced N-Up 1-10
Trace facility 1-10
Overstrike, underscore, subscript, and superscript 1-10
Document Feeding and Finishing Architecture (DFA) 1-10
Page origin rotation for continuous form jobs 1-11
Double-byte fonts 1-11
Outline font support 1-11
Printer resident font support 1-12
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE v
TABLE OF CONTENTS
Processing options 1-12
Message translation 1-12
Configuration file processing 1-12
PCI Bus support 1-12
Access control by privilege mode 1-13
Color image support 1-13
Background color for OCA colors 1-13
Bi-level IOCA colors 1-13
Highlight color samples 1-14
Software license 1-14
Remote service (Sixth Sense Technology) 1-15
2. Printer Controller 2-1
Components of the Printer Controller 2-1
Processor 2-3
Hard disk 2-3
Diskette drive 2-4
CD-ROM drive 2-4
Cartridge tape drive 2-4
Monitor 2-4
Keyboard 2-4
Mouse 2-4
Host Channel Unit (HCU) — channel-attached systems only 2-5
Placement of the processor 2-5
3. User interface 3-1
Graphical user interface screen 3-2
IPS main window 3-4
4. Printers 4-1
Printer components 4-2
Components overview 4-2
Printer control console 4-3
Sample tray 4-5
Dual stacker trays 1 and 2 4-5
Feeder trays 4-5
Printer configurations 4-6
High-capacity feeder 4-6
Printer stackers 4-7
Dual stacker 4-7
Stitcher/stacker 4-8
Additional IPS printer features 4-9
vi XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
TABLE OF CONTENTS
Printer paper paths 4-11
5. Bypass transport 5-1
Overview 5-1
Software, firmware, hardware, and paper requirements 5-2
Personality profiles for third-party finishing devices 5-3
Operator tasks 5-4
Mechanical interface 5-5
Electrical connection 5-6
6. Highlight color 6-1
How highlight color is created 6-1
How highlight color is specified 6-2
Extraction color 6-2
Guidelines for selecting the extraction color 6-5
A. Paper and other supplies A-1
Paper and other throughput stocks A-1
Selecting paper A-1
Paper care A-3
Other supplies A-6
Dry ink A-6
Fuser lubricant A-6
Developer A-6
Stitcher wire A-7
Diskettes A-7
Tapes A-7
Fonts A-7
Consumable supplies tables A-9
Paper and special stocks tables A-9
Complete supplies list—Model 92C printer A-12
Ordering supplies A-14
B. Extraction color samples B-1
Index INDEX-1
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE vii
TABLE OF CONTENTS
viii XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
About this guide
Introduction
This Xerox DocuPrint 92C IPS System Overview Guide provides an
overview of the individual components of the DocuPrint IPDS Printer
System (IPS) and how they work together. This reference is
designed to provide you with background information that can be
used to make informed decisions regarding printer use and
performance.
The Xerox DocuPrint 92C IPS System Overview Guide provides
information to help you quickly determine hardware, software, and
connectivity requirements for printing from various clients to
DocuPrint IPS.
This reference is useful for workstation users, printer operators, and
system administrators who want to understand the overall DocuPrint
IPS. Managers can use the reference information to assist them in
making planning decisions.
Before using this guide, become familiar with its contents and
conventions.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE ix
INTRODUCTION
Contents
This section lists the contents of this guide:
• Chapter 1, “System overview,” identifies and describes the
function of the major components of the DocuPrint 92C IPS.
• Chapter 2, “Printer Controller,” provides the information on the
Printer Controller components, software, and fonts.
• Chapter 3, “User interface,” describes the features of the IPS
graphical user interface.
• Chapter 4, “Printer,” details the base printer components and
optional printer components.
• Chapter 5, “Bypass transport,” describes the bypass transport
and the requirements for attaching third-party finishing devices.
• Chapter 6, “Highlight color,” provides information about
highlight color, and discusses how the DocuPrint 92C IPS uses
an extraction color to determine how job-specified colors
appear in print.
• Appendix A, “Paper and other supplies,” provides information
and specifications on paper and other media used with the IPS,
as well as instructions for ordering supplies.
• Appendix B, “Extraction color samples,” shows approximately
how solid, shaded, and tinted areas in your jobs will print in
each Xerox colored ink, for each possible extraction color
selection.
An index is provided at the back of the guide.
x XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Conventions
INTRODUCTION
This guide uses the following conventions:
• All caps and angle brackets — Within procedures, the names of
keys are shown in all caps within angle brackets (for example,
press <RETURN>).
• Italics — Document and library names are shown in italics (for
example, the Xerox DocuPrint 92C IPS System Overview
Guide).
• Capitalization of graphical user interface (GUI) window titles
matches the titles as they appear on the screen. In cases where
a window does not have a title, it is referenced using all lower
case. For example:
— At the graphical user interface, use the Output
Configuration window to group the trays.
— The main window displays the current system status.
Note: Notes are hints that help you perform a task or understand
the text.
Caution: Cautions alert you to an action that could damage
hardware or software.
Warning: Warnings alert you to conditions that could affect the
!
safety of people.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE xi
INTRODUCTION
Related publications
Xerox documents Following is a list of all Xerox DocuPrint IPS documents. For a
This document is part of the Xerox DocuPrint IPS publication set.
complete list and description of available Xerox documentation, refer
to the Xerox Customer Documentation Catalog (publication number
610P17517), or call your service representative.
Application Programmer/System Administrator Quick Reference
Card
Customer Information Quick Reference Card
Generic MICR Fundamentals Guide
Glossary
Guide to Configuring and Managing the System
Guide to Performing Routine Maintenance
Helpful Facts About Paper
Installation Planning Guide
Master Index
Messages Guide
Solutions Guide
System Overview Guide
Troubleshooting Guide
Xerox Standard Font Library Font User Guide
The documentation set also includes an electronic version, the
DocuPrint IPS Interactive Customer Documentation CD.
IBM documents Following are related IBM documents. Contact your local IBM
representative for ordering instructions for IBM AFP/PSF manuals
that might be useful for your specific installation.
IBM 3825 Page Printer Product Description
IBM Intelligent Printer Data Stream Reference
IBM Advanced Function Presentation Printer Summary
IBM ITSC Distributing AFP Printing from a Host System
IBM Advanced Function Printing Data Stream Reference
IBM Data Stream and Object Architectures: Mixed Object Document
Content Architecture Reference
Guide to Advanced Function Presentation
xii XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
1. 1System overview
This chapter introduces the DocuPrint 92C IPS printing system. It
describes the system’s hardware and software components,
features, functions, and modes of operation.
Functional overview of the DocuPrint IPS
The DocuPrint 92C IPS prints high quality documents in simplex or
duplex mode in monochrome or in black plus one highlight color.
DocuPrint IPS printers support:
• Duplex printing
• Media of multiple weights, sizes, and types
• Optional modules for enhanced finishing and output to third-
party finishing devices
• Optional high-capacity feeder for additional feeder trays.
• Printing in various shades and tints of a highlight color plus
black.
The IPS emulates an IBM AFP Group 3 page printer with the
Advanced Function Image and Graphics (AFIG) option. The IPS can
print in all the following PSF environments:
• MVS
• VM (channel-attached only)
• VSE (channel-attached only)
• OS/2
• OS/400 (with TCP/IP only)
• AIX
Note: Although PSF/VSE does not support TCP/IP directly, a
printing system with PSF/2, PSF/6000, or IBM InfoPrint Manager can
attach to a PSF/VSE system and the PSF/2, PSF/6000, or IBM
InfoPrint Manager can furnish the TCP/IP support for the IPS printer.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 1-1
SYSTEM OVERVIEW
Major system components
Printer Controller The Printer Controller accepts IPDS data from the host, processes
Graphical user interface The full-color graphical user interface (GUI) provides an easy-to-use,
The IPS has the following main components, each of which is
described in greater detail in later chapters of this guide:
the data, and sends it to the printer using the IPS operating system
for IPDS or the NPS operating system for PostScript or PCL.
The Printer Controller provides the printer with print data and
commands and receives status information from the printer.
Host Channel Unit: On channel-attached systems, the Printer
Controller has an additional component called the Host Channel Unit,
or HCU. The HCU contains the channel communications board, and
handles communication between PSF and the controller when data
is received over a bus and tag connection.
mouse-driven interface to the IPS. Using the windows on the GUI
screen, you can configure your system; perform diagnostic and
administrative tasks; and set up, change, and implement system
options, and run print jobs.
Throughput speed
The IPS main window displays the current system status, as well as
the current printer settings, including the current input and output tray
configurations. From the IPS main window you access the various
menus and windows you use to configure and operate the system.
Refer to the chapter “User interface” in this guide, for more detailed
information on the IPS graphical user interface components.
Printer The printer accepts data from the Printer Controller and prints the
document according to the print options specified by the user. The
printer also provides paper stacking, collating, and optional finishing.
The DocuPrint 92C IPS can print up to 92 impressions per minute,
using stocks 8.5 by 11 inches / 216 by 279 mm to 8.5 by 14 inches /
216 by 356 mm.
1-2 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Host connectivity options
1
Channel-attached configuration Figure 1-1 illustrates the components of a channel-attached IPS.
SYSTEM OVERVIEW
The IPS can be set up to receive data from a host in one of two ways:
• Over a channel with bus and tag cable connection, via the Host
Channel Unit (HCU)
• Through a Token Ring or Ethernet interface, using TCP/IP
protocol (not available in a VM or VSE host environment)
Note: A transmission rate of at least 16 megabits per second
should be used with a Token Ring interface on the IPS. (Overall
performance depends on network traffic and job density.)
This configuration requires a Host Channel Unit (HCU) to interface
between the host channel and the IPS controller.
Figure 1-1. DocuPrint 92C IPS: channel-attached configuration
IBM
Host
7
4
6
5
3
2
1 Host system (PC or mainframe)
2 DocuPrint 92C IPS printer
3 Printer interface cable
4 Printer Controller
5 SCSI interface
6 Host Channel Unit (HCU)
7 Bus and tag cables
TCP/IP configuration If you are using Token Ring or Ethernet with TCP/IP, as shown in
figure 1-2, the bus and tag cables and the HCU are not required.
Figure 1-2. 92C IPS: TCP/IP configuration
1 Host system (PC or mainframe)
2 Token Ring or Ethernet network connection
3 Printer Controller
4 Printer interface cable
5 92C IPS printer
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 1-3
SYSTEM OVERVIEW
IPDS data stream
All IPDS resources (print data sets, page definitions, form definitions,
page segments, fonts, and overlays) supported by the IBM 3825 and
3827 printers are supported by the Xerox IPS software. Additionally,
there are several data towers supported within the AFP environment
which are fully supported by the IPS software, to a level supported by
the IBM 3825 and IBM 3827 printer capabilities:
• IM Image IMD1
• FOCA: Font Object Content Architecture
• MO:DCA-P: Mixed Object Document Content Architecture for
Presentation
• PTOCA PT1, PT2, and PT3: Presentation Text Object Content
Architecture
• IOCA: Image Object Content Architecture
• GOCA: Graphics Object Content Architecture
• BCOCA: Bar code Object Content Architecture
• OL1: Overlay One
• PS1: Page Segment One
Dual Mode
• Line mode data streams
Each of the data objects follow the same object rule of containing
delimiting fields with structured fields describing each object.
Xerox DocuPrint Dual Mode option enables both DocuPrint NPS and
IPS systems to coexist on the same Printer Controller (Sun
workstation). This allows the DocuPrint system to receive data
streams supported by NPS and IPS, including IPDS, PostScript
Levels 1 and 2, HP PCL5c, HP PCL5e, and ASCII.
Either of the following types of configurations may be used:
• The same Token Ring or Ethernet connection can be used for
both IPDS (IPS) and Postscript/PCL (NPS).
• Both a Token Ring card and an Ethernet card can reside in the
Sun workstation controller, with one being used for IPDS and
the other for PostScript/PCL.
• Bus and tag attachment through the HCU can be used for
IPDS, and Token Ring or Ethernet connection for the NPS.
When the DocuPrint system is in IPS mode, it can accept PostScript
and PCL data streams in the background; however, it can print these
jobs only after it is switched to NPS mode. However, when the
system is in NPS mode, it cannot accept IPDS data streams in the
background.
1-4 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
DocuPrint 92C IPS hardware features
The 92C IPS provides numerous features that can be enabled or
configured using the graphical user interface on the printer controller.
Highlight color
The DocuPrint 92C IPS can print in one highlight color plus black.
These inks are available for adding color to documents: red, green,
blue, cyan, magenta, brown, cardinal, royal, ruby, and violet.
When a colored ink is installed in the IPS, you can combine black and
the additional color under software control to:
• Create darker shades by mixing black and a color
• Create lighter tints by letting the white of the paper show
through between the black or colored dots.
Multiple input trays
SYSTEM OVERVIEW
Advanced paper handling
Two addressable input trays are standard with the printing system.
Two additional feeder trays are available as options. These trays can
be used to configure print jobs in the most effective manner. For
example, the trays can be used to provide nonstop printing of a
complex job that requires multiple paper stocks, or only a few paper
stocks, but using the continuous loading capability of the input trays.
A different tray can also be selected for each copy of a specific page
in a print job; for example, to provide different paper colors for specific
pages.
Feeder tray capacities, based on 20-pound or 80 gsm (grams per
square meter) bond, are:
• Tray 1: 1000 sheets
• Tray 2: 500 sheets
• High-capacity feeder trays (3 and 4): 1000 sheets each.
The DocuPrint 92C IPS can handle paper stocks ranging in size from
8 by 10 inches / 203 by 254 mm to 8.5 by 14 inches / 216 by 356 mm,
including A4, and in weight from 20-pound or 80 gsm bond to 110pound / 200 gsm index. Jobs can also be printed on special stocks
such as labels and transparencies.
The printer engine monitors the print job so that, should a paper jam
occur, the job resumes on the correct page, providing complete
document integrity.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 1-5
SYSTEM OVERVIEW
600 dpi resolution
Multiple output trays/bins
The DocuPrint 92C IPS provides high print quality at 600 dpi
resolution. It can receive data at 240, 300, or 600 dpi; The controller
coverts 240 and 300 data to 600.
Caution: The DocuPrint 92C IPS must be configured to the same
font resolution as the host input data stream (refer to your Xerox
DocuPrint 92C IPS Guide to Configuring and Managing the System
for instructions on configuring for the correct input resolution).
Conflicts between the input font resolution and the IPS configuration
could result in inability to print the job, or in missing variable data in
the output.
Better print quality is usually achieved if you convert all 240 dpi and
300 dpi fonts and other resources to 300 dpi or 600 dpi before
printing, rather than leaving the conversion for the controller to do.
However, you should always run test prints to validate your particular
application.
Your DocuPrint 92C IPS is available with one of two stacker types: a
dual stacker, with two output trays, or a stitcher/stacker, which can
place a wire stitch in sets of up to 50 sheets.
Output tray capacities, based on 20-pound or 80 gsm bond, are:
• Dual stacker trays 1 and 2: 750 sheets each
• Stitcher/stacker: 2000 sheets.
1-6 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
User interface
SYSTEM OVERVIEW
The IPS full-color graphical user interface provides an easy-to-use,
mouse-driven interface to the IPS. Using the graphical screens, you
can configure your system; perform diagnostic and administrative
tasks; and set up, change, and implement system options.
The IPS main window displays the current system status, as well as
the current printer settings, including the current input and output tray
configurations. From the IPS main window you access the various
menus and windows you use to change the system settings and
perform diagnostic and administrative tasks. Refer the “User
interface” chapter in this guide for further information on the IPS
graphical user interface.
Figure 1-3. DocuPrint 92C IPS main window
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 1-7
SYSTEM OVERVIEW
Software features
Mixed paper sizes within a job
The following special IPS software features increase system
flexibility.
The IPS can print jobs that call for a mix of paper sizes, without
needing to interrupt or slow down printing.
An example of such an application would be a multi-page billing
statement consisting of:
• One or more 8 1/2 by 11-inch sheets itemizing charges, and
• A final 8 1/2 by 14-inch page containing the rest of the billing
items, the total amount due, and a tear-off section to mail back
with payment.
Note: When a print job calls for paper sizes that span over different
pitch modes, the software will either cycle down or run at a lower
pitch mode, based on the different pitch modes required, the paper
sizes called for, the speed of the printer, and the time it takes to shut
down the printer.
Tray selection capabilities
Note: Paper size and printer trays cannot be changed while the job
is running.
Note: Mixed paper sizes are not supported for stitching. If your
system has a stitcher/stacker, the printer cycles down if it detects any
specification for stitching different sized papers.
You can select a different input tray or output bin for each job. You
can also select a different input tray for each page of a job.
Input tray With the input tray selection capability at the Copy Subgroup level,
you can select a different input tray for each copy of a page of a job.
You can use this capability to print each page of a multiple-part form
on a different color paper stock, or to print the cover of a job on a card
stock and to print specific pages within the job on a different color
stock.
To specify a different input tray for each job, use the BIN command
in the SUBGROUP level of the COPYGROUP in the FORMDEF.
1-8 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
IOCA Replicate and Trim
SYSTEM OVERVIEW
Output tray With the output bin selection capability you can select a different
output bin group for each print job. This selection requires two steps:
1. At the host, set the JCL keyword OUTBIN in the OUTPUT
statement to specify a bin number from 1 to 65535, or use the
OUTBIN command in the FORMDEF to specify a bin number
from 1 to 255.
2. At the graphical user interface, use the Output Configuration
window to group the trays. You must also select Allow Host
Control from the Bin Selection Mode pull-down menu.
The IPS also supports Replicate and Trim, which improves the
processing of IM and IO images that contain large areas of shaded
graphics. (IM images are resolution-dependent images that cannot
be compressed or scaled; IO images are resolution-independent.)
The IOCA Replicate and Trim capability allows for faster
transmission to the printer of AFP applications with IM images that
have large or widespread shaded areas. It also reduces the storage
area required on the host and on the printer.
Mixed plex
The IPS allows switching between plex modes (simplex to duplex
and vice versa) within and between jobs without shutting down the
printer.
Switching of plex modes occurs as follows:
• From simplex to duplex: The switch is done without a printer
shutdown or dead cycles.
• From duplex to simplex: The switch is done without a printer
shutdown. However, the printer may, if necessary, dead cycle to
clear the paper path of all duplex sheets before feeding the first
simplex sheet.
Users can avoid switching from duplex to simplex mode (and thus,
avoid the dead cycles) by using the Maximum Simplex GUI panel to
perform simulated simplex. For more details, refer to the “Setting the
system configuration” chapter in the Xerox DocuPrint 92C IPS Guide
to Configuring and Managing the System.
Note: When you print simplex pages in duplex mode, the
throughput speed is halved. The blank back pages of the simulated
simplex sheets are counted as billable pages by the system’s
meter.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 1-9
SYSTEM OVERVIEW
Enhanced N-Up
Enhanced N-Up provides the following capabilities:
Sheets On a given sheet, users can place individual pages:
• At any position on either side of the sheet
• In any orientation
• In any size that fits on the sheet
Each side of the sheet of paper can have up to four pages.
Overlays Users can place overlays relative to any partition origin, with or
without variable page data from the application program.
Users can specify different overlays for each page.
Offsets Users can specify different offsets for each page.
Rotations Users can specify different rotations for each page.
Form ejection Users can specify form ejection to a new partition or a new sheet.
Trace facility
To help diagnose problems, the system provides a trace mechanism.
Trace files store system configuration information, maintain TCP/IP
protocol headers, and time-stamp all records.
For detailed information on this feature, refer to the “Setting the
system configuration” chapter in the Xerox DocuPrint 92C IPS Guide
to Configuring and Managing the System.
Overstrike, underscore, subscript, and superscript
Support for the PT2 Subset of PTOCA enables the IPS to print
overstrikes, underscores, subscripts, and superscripts where
specified in jobs.
Document Feeding and Finishing Architecture (DFA)
The Document Feeding and Finishing Architecture (DFA) on the
DocuPrint 92C IPS supports all third-party finishing devices currently
validated for the LCDS (J11) printers (third-party feeding devices are
not supported on the DocuPrint 92C IPS). The bypass transport
option is required for in-line finishing devices and support of
ENDOFSET and ENDOFJOB (using the PSF MARKFORM or
FORMDEF JOG command). DFA also supports personality profiles,
which identify the unique characteristics of the attached finishing
devices (for example, the sheet timing and the status feedback
profiles).
1-10 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Page origin rotation for continuous form jobs
The 90-degree page origin rotation feature enables the IPS to print
jobs designed for continuous form printing, without the need to
rework an existing application. At the user interface, you can set a
job’s page origin to be rotated 90
continuous form jobs on cut-sheet paper.
Double-byte fonts
Double-byte fonts consist of characters that are larger and more
complex than the single-byte characters making up the Roman
alphabet. Therefore, each character of a double-byte font requires
two bytes to represent it. Some languages requiring double-byte
fonts include Chinese, Korean, and Japanese.
The IPS supports printing with certain double-byte fonts, which can
be used in combination with single-byte fonts.
The following double-byte character sets are supported:
• Simplified Chinese
• Traditional Chinese
• Japanese
• Korean
• Thai.
SYSTEM OVERVIEW
o
to accommodate printing
Outline font support
Note: When using double-byte fonts, the font loading time will
increase if a font change occurs between reports.
The IPS supports the use of IBM outline fonts for both single-byte and
double-byte applications. These fonts may be downloaded during the
jobs or may be loaded into the system and made resident through the
use of a user interface option on the Configuration menu.
These outline fonts allow users to specify a single font that can be
rasterized in a variety of point sizes by the IPS. The IBM outline fonts
are based on Adobe type 1 and type 0 fonts that are in PostScript
format.
Note: The IPS supports printer resident outline fonts. It does not
support printer resident raster fonts.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 1-11
SYSTEM OVERVIEW
Printer resident font support
Processing options
The IPS stores both single-byte and double-byte fonts locally on the
Printer Controller and does not require you to download the fonts
from the host. This can lead to significant performance gains,
especially when the printer is attached remotely.
Users can also set the default font for text or barcode Human
Readable Interpretation (HRI) to one of the installed fonts to replace
a font that is distributed with the system.
Fonts can be installed from an IBM supplied font CD or via FTP to the
Controller workstation.
Note: The IPS supports printer resident outline fonts. It does not
support printer resident raster fonts.
The IPS allows users to specify processing options using the GUI.
For example, changing the model number reported to the host. Refer
to the Xerox DocuPrint 92C IPS Guide to Configuring and Managing
the System for details on these options.
Message translation
Configuration file processing
PCI Bus support
The IPS provides some message translatability for the GUI and
printer monitor. Users can select the language of their choice from a
GUI menu option.
The IPS adds a version identifier to the configuration files. The
identifier allows for migration of configuration data from one release
to a subsequent release at upgrade time. The IPS allows users to
save, upgrade, and restore configuration data such as input and
output tray mappings and DFA configurations.
The IPS supports the SUN Peripheral Component Interconnect (PCI)
Bus architecture, in addition to the S-Bus platform. PCI support
provides the following advantages:
• Migration of Printer Controller components to newer technology
• Higher performance on the Printer Controller
• Wider selection of system peripherals
• Adherence to industry standards.
1-12 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Access control by privilege mode
Color image support
SYSTEM OVERVIEW
The IPS controls access to various functions based on four privilege
modes:
1. User
2. Operator
3. Administrator
4. Service.
Depending on the privilege mode set by the Customer Service
Engineer, users will have access to certain graphical user interface
(GUI) functions, while other functions will be grayed out. Refer to the
Xerox DocuPrint 92C IPS Guide to Configuring and Managing the
System for details on this functionality.
Some IM1 images (for example, logos) can be converted to IOCA for
resolution correction. The bi-level IOCA feature enables such IM1
images to be printed in color on the DocuPrint 92C IPS. PSF does
not strip the color information from the print job.
Background color for OCA colors
Bi-level IOCA colors
Users can specify COLOR on DRAWBOX (i.e., background color) as
long as the color is restricted to colors defined with the OCA model.
The IPS accepts the new IOCA color spaces in the extended controls
(referred to as the “4E” color triplets). These include the Highlight
Color and Standard OCA Color.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 1-13
SYSTEM OVERVIEW
Highlight color samples
Color samples for each available highlight color are stored on the
Printer Controller in the /var/db directory. You can print out these
samples using the “Executing trace files” procedure described in your
Xerox DocuPrint 92C IPS Guide to Configuring and Managing the
System. The following color samples are provided:
• Blue
• Brown
• Cardinal
• Cyan
• Green
• Magenta
• Red
• Royal (dark blue)
• Ruby
• Violet.
In addition, a set of printed color samples is provided (in a different
form) in appendix A of the Xerox DocuPrint 92C IPS System
Overview Guide.
Software license
Note: The printed colors in these samples may differ slightly from
the actual color your IPS prints.
When an IPS is purchased, the owner needs a license to use the
operating system software. After a user calls in with a host ID (Sun
SPARC/Ultra host ID), the user will receive a license string.
The user license is enabled by entering the 20-character
authorization text string at the Printer Controller keyboard. Your
Xerox service representative can obtain the license text string for you
and enter it when your IPS is installed, or when you receive your IPS
software upgrade. For details on how to obtain the license string from
Xerox, refer to the Xerox DocuPrint 92C IPS Guide to Configuring
and Managing the System, in the chapter “Setting up the printer
controller.”
Until the license string is entered, your IPS cannot receive data from
the host to print. You can power on and boot the system, and perform
all offline tasks such as setting up input and output configurations,
but the IPS remains in Disabled mode and cannot print.
Although your service representative usually does this for you, you
are able to enter your license string yourself from the IPS main
window. The procedures are outlined in the chapter “Setting up the
printer controller” in your Xerox DocuPrint 92C IPS Guide to
Configuring and Managing the System.
Note: If your system will be operating in Dual Mode, it requires two
license strings: one for IPS and one for NPS.
1-14 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Remote service (Sixth Sense Technology)
Sixth Sense Technology is a user-friendly suite of tools that allow
service personnel to connect with a customer system and evaluate
its performance while the system is being used. The Customer
Service Engineer (CSE) can troubleshoot problems remotely,
transfer, apply, and remove patches remotely, and, if an on-site call
is required, arrive with the solution to fix the problem.
Customer benefits of using this technology include:
• Diagnostic help and identification of required parts before the
service visit
• Planned visits based on known problems and/or replacement of
wear-out items
• Customer self-maintenance to provide faxed replacement
change reminder to trained operators.
Using the Sixth Sense Technology, CSEs can access your system’s
diagnostic data remotely using a regular telephone line almost as if
they were at the Printer Controller (SPARCstation).
For security reasons, the customer maintains control of the modem
connection, and may leave the modem disconnected. Also, the
customer provides a password for access to the Sixth Sense
Technology via the modem.
SYSTEM OVERVIEW
For information on enabling and disabling of the Sixth Sense
Technology, refer to the chapter “Calling for Service” in your Xerox
DocuPrint 92C IPS Troubleshooting Guide.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 1-15
SYSTEM OVERVIEW
1-16 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
2. 2Printer Controller
This chapter describes the DocuPrint IPS Printer Controller (also
called the system controller). It includes a list of component
hardware, software, and fonts, and discusses the key elements of
software operation.
Components of the Printer Controller
The Printer Controller enables you to use proprietary Xerox IPS
hardware, firmware, and software to control the printer. It has the
following major hardware components:
• Sun UltraSPARC workstation. The Sun workstation has a
high-performance RISC processor chipset, based on the
industry-standard Scalable Processor Architecture (SPARC)
and a high-capacity hard disk drive. It contains the following
components:
— Processor
– Hard disk
– Diskette drive
– CD-ROM drive
– Connectivity boards for Ethernet and, optionally, Token
Ring
— Monitor
— Keyboard
— Mouse
• Host Channel Unit (HCU) (Channel-attached systems only).
The HCU contains the channel communications board. This is
used only when printing data received over a channel via a bus
and tag connection.
Note: Some elements and components of the Printer Controller are
accessible only by a service representative; for example, the
diagnostics for the Sun workstation processor.
Note: Printer controller hardware configurations are subject to
upgrade.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 2-1
PRINTER CONTROLLER
The Sun Ultra workstation consists of the processor, monitor,
keyboard and mouse. Both Sun Ultra 2 and Sun Ultra 60
workstations are available.
Figure 2-1. Components of the Sun Ultra 2
1 Processor
2 Monitor
3 Mouse and mouse pad
4 Keyboard
5 Diskette drive
6 CD-ROM drive
2-2 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Figure 2-2. Components of the Sun Ultra 60
1 Monitor
2 Keyboard
3 Mouse
4 Processor
5 Diskette drive
6 CD-ROM drive
7 Cartridge tape drive
PRINTER CONTROLLER
Processor
The processor is the central processing unit (CPU) of the Sun
workstation. It contains a power switch, a hard drive, a diskette drive,
a CD-ROM drive, a power receptacle and outlet, connectors, and
ports.
A Data Control Interface Module (DCIM2) card for the Sun Ultra 2, or
a PCIM2 card for the Sun Ultra 60 is installed in the processor, to
which the printer cable is connected. In addition, the processor
contains the connectivity boards for Ethernet and, optionally, Token
Ring.
Hard disk
One addressable, high-speed, high-capacity hard disk is provided.
The hard disk stores the operating system, the IPS application, and
any buffered pages. Do not use the hard disk to store other
applications or data except as directed by your service
representative.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 2-3
PRINTER CONTROLLER
Diskette drive
The floppy disk drive is located in the processor, on the front section
of the UltraSPARC. It uses industry standard 3.5 inch, 1.44-MB,
double-sided, high-density floppy disks. This disk drive is not an input
source for print jobs or for any other data or application. It is reserved
exclusively for use by a service representative to update software
and to store files.
CD-ROM drive
The CD-ROM drive, located in the processor above the diskette
drive, is a high-density, read-only, optical laser storage device used
for loading the IPS operating system, online documentation, and
other files.
Cartridge tape drive
An optional 8 GB, 4 mm external SCSI cartridge tape drive also is
available for the IPS. Like the diskette and CD drives, this tape drive
is not an input source for print jobs or for any other data or
application. It provides the service representative with another
means of loading system maintenance files or saving diagnostic
information.
Monitor
Keyboard
Mouse
The monitor has a high-resolution color screen, which displays the
IPS graphical user interface screen.
The type 4 or 5 keyboard has 107 alphanumeric keys, symbol and
special character keys, an extended character set, and function keys.
The mouse has three buttons. The left and right buttons are used to
select IPS functions. The center button provides additional functions
that you will not be required to use.
If your workstation has an optical mouse, it must remain on its
designated metallic pad to be active. If the mouse has a roller ball
instead of an optical sensor underneath, it requires a non-metallic
pad.
2-4 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Host Channel Unit (HCU) — channel-attached systems only
The HCU handles all of the IPDS communications and handshaking
with PSF on the host when receiving data over a channel. (It is not
used when the IPS is printing data using TCP/IP.)
• The front panel of the HCU has a single-digit LED display,
which enables you to monitor power-up and offline status, and
alerts you to error conditions. (Refer to your IPS Messages
Guide for an explanation of the HCU codes displayed here.)
• The back panel of the HCU has a power switch and outlet, bus
and tag cable input and bypass connectors, and a dual serial
port. The standard switching power supply is capable of 10 amp
on the 5-volt output.
Note: You are responsible for obtaining, stringing, and maintaining
fully-populated bus and tag cables.
Figure 2-3. Host channel unit (HCU)
PRINTER CONTROLLER
Placement of the processor
When you place your Printer Controller processor on a desktop,
make sure to allow at least 6 inches / 152 mm of unobstructed space
at the rear and both sides of the processor. Do not allow any piece of
equipment to blow warm air into the air-intake vents of the processor.
Caution: Do not place a monitor with a base larger than the
processor on top of the unit. Do not block any fan or vents on the
sides or rear of the processor.
Caution: If you plan to move the Printer Controller, make sure to
consult with your service representative.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 2-5
PRINTER CONTROLLER
2-6 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
3. 3User interface
The IPS graphical user interface on the Printer Controller enables
you to interact with the IPS. It contains windows and pull-down
menus through which you can perform operator and system
administrator tasks.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 3-1
USER INTERFACE
Graphical user interface screen
After you power on the HCU (if appropriate) and the Sun workstation,
the Printer Controller monitor displays three windows:
• IPS main window
• IPS Console window
• IPS Print Engine Monitor window.
The IPS main window is the largest window on the screen. The main
window displays the current system setup, the current system status,
and any jobs that are running. This window also provides access to
menus and subwindows from which you can configure and operate
your system.
The IPS Console window displays messages that warn you of
Printer Controller problems. (This window initially displays below the
IPS main window on the left, but it can be moved where desired.)
Note: High frequency service indicator (HFSI) messages may
appear occasionally in this window. These messages do not indicate
any problem, merely that you should advise your service
representative to check the indicated areas during the next service
call.
The IPS Print Engine Monitor window shows printer error
messages, indicates the printer status and displays printer and DFA
messages. (This window initially displays below the IPS main window
on the right, but it can be moved where desired.)
The following figure shows these windows on the screen of the
Printer Controller monitor.
3-2 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
USER INTERFACE
Figure 3-1. Printer Controller monitor with IPS main window,
IPS Console window, and IPS Print Engine Monitor
window
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 3-3
USER INTERFACE
IPS main window
Use the IPS main window to access other windows for configuring,
setting up, and operating the system, for monitoring the current setup
and status of the system, for performing various administration tasks,
and for interrupting and resuming printing.
Figure 3-2. IPS main window
The IPS main window consists of the following:
• Menus:
— Configuration
— Diagnostics
— Administration
— System Options
• Input Configuration section, which provides access to the
windows that enable you to configure input trays to feed
required paper stocks, and to set up margin values. It also
displays the current configuration of the feeder trays.
3-4 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
USER INTERFACE
• Output Configuration section, which provides access to the
direct windows that enable you to direct printed output to the
desired output tray or bin. It also displays the current
configuration of the stacker trays.
• Setup and status information, which consists of the following
sections:
— Control Unit Configuration section, which displays the
current configuration of the system
— Status section, which indicates what the printer is doing
— Host Job Control section, which allows you to stop or
continue job processing.
For detailed information on the main window and its various
functions, refer to the chapter “Introduction to the graphical user
interface” in the Xerox DocuPrint 92C IPS Guide to Configuring and
Managing the System.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 3-5
USER INTERFACE
3-6 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
4. 4Printers
The printer (sometimes referred to as the image output terminal or
IOT) is where the actual printing takes place. This chapter discusses
the components of the DocuPrint 92C IPS printer.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 4-1
PRINTERS
1
Printer components
Components overview
The DocuPrint IPS printers contain a xerographic engine, two
standard feeder trays, a sample tray, the printer control console, and
one of two output tray configurations: the dual stacker or the stitcher/
stacker.
The components of the base printer for the 92C IPS are shown in
figure 4-1
Figure 4-1. DocuPrint 92C IPS printer (shown with dual
stacker)
2
3
4
6
5
1 Printer control console
2 Sample tray
3 Stacker tray 1
4 Stacker tray 2
5 Feeder tray 1
6 Feeder tray 2
These components are described in more detail in the following
sections.
4-2 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Printer control console
1
PRINTERS
The printer control console contains message and graphic displays,
an Information button, Stop and Continue buttons, and a power
switch (for the printer only). Indicator lights show which feeder tray is
active and the paper size in use.
Note: The IPS does not provide sample prints while a job is
running; therefore, the Sample Print button has no effect on
operation.
Figure 4-2. DocuPrint 92C printer control console
11
10
9
8
1 Attention light
2 Message display
3 Graphic display
4 Wire percentage indicator
5 Feeder tray indicators
6 Power on/off switch
7 Sample button (disabled)
8 Continue button
9 Stop button
10 Fault code display
11 Information button
2
3
4
5
6
7
Attention light The yellow attention light glows whenever the system detects an
actual or potential problem.
• When the light is flashing, you should act immediately to
remedy situations that have caused the printer to stop. The
flashing light can also indicate system problems. (Typical
problems are a paper jam or a full waste container.)
• When the light glows steadily, act soon to avoid a cycle-down. A
steady glow typically indicates that the paper or dry ink is low.
Note: When the attention light starts flashing, an explanatory
message appears on the printer console display. A similar error or
warning message appears on the Printer Controller screen in the
Print Engine Monitor window.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 4-3
PRINTERS
Message display Printer status and simple operating and maintenance instructions are
shown in a two-line message.
Graphic display The graphic display shows a specific area of the printer requiring
attention. The graphics help you locate the problem.
Icon display The icon displ.ay is located in a rectangle below the graphic display.
The printer mode is indicated by the words that are lighted—Black or
Highlight (color). The IPS indicates the color ink loaded in the printer
by lighting one of the icons on the right (red, blue, green, or “other”).
Black
Printer Mode
Highlight
Wire percentage indicator If your printer has the stitcher/stacker, this indicator displays the
percentage of stitcher wire remaining on the spool.
Feeder tray indicators These lights indicate the selected feeder tray or trays and the size of
paper loaded in each tray.
Power on/off switch This switch controls power to the printer and is used primarily by
service representatives.
Sample button (disabled) The IPS does not support printing sample pages while a job is
running. Therefore, pressing the Sample button has no effect on
system operation.
Continue button The Continue button resumes printing when it is pressed.
While it is formatting a complex page, the Printer Controller may
cycle down the printer if the page image is not available within a
certain time frame. If this occurs, the following message appears:
Press <CONTINUE> to resume printing
You can ignore this message. As soon as the page image is
available, the Printer Controller cycles up the printer and printing
automatically resumes.
Stop button Pressing the Stop button halts printing without interrupting input
processing.
Fault code display Shows the number of completed prints and printer fault codes. When
a fault code displays here, the corresponding message appears in
the message display.
Information button When “i” appears on the message display, you can press this button
for additional information on printer operation. You can press the
button repeatedly for more information as long as “i” appears.
4-4 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Sample tray
Dual stacker trays 1 and 2
Feeder trays
PRINTERS
This output tray receives sample prints of system files, rejected
prints, and transparencies. The capacity of the sample tray is 100
sheets of 20-pound or 80 gsm (grams per square meter) bond.
Each output stacker tray has a capacity of 750 sheets of 20-pound or
80 gsm bond (1500 sheets total capacity). An alternative to the dual
stacker configuration is the stitcher/stacker.
The standard configuration contains two feeder trays with the
following capacities (based on 20-pound or 80 gsm bond):
• Tray 1: 1000 sheets
• Tray 2: 500 sheets. (Except for capacity, this tray is identical to
tray 1.)
High-capacity feeder: An additional feeder module containing two
trays (trays 3 and 4) is available as an option. Each high-capacity
feeder tray holds 1000 sheets of 20-pound or 80 gsm bond, for a total
of 2000 additional sheets.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 4-5
PRINTERS
Printer configurations
High-capacity feeder
The DocuPrint 92C IPS is available in several configurations of dual
stacker, stitcher stacker, and high-capacity feeder.
In addition, the DocuPrint 92C IPS is available with the bypass
transport option. For more information, refer to the “Bypass transport”
chapter.
The high-capacity feeder (HCF) provides two additional feeder trays.
The extra trays work interchangeably with feeder trays 1 and 2 to
allow automatic tray switching and uninterrupted printing time.
Figure 4-3. DocuPrint 92C IPS printer with high-capacity
feeder
3
2
1 High-capacity feeder module
2 Feeder tray 3
3 Feeder tray 4
1
Tray capacities Each high-capacity feeder tray holds 1000 sheets of 20-pound or 80
gsm bond.
Paper sizes Both high-capacity feeder trays handle paper sizes from 8 by 10
inches / 203 by 254 mm to 8.5 by 14 inches / 216 by 352 mm. This
range includes international paper size A4 (8.27 by 11.16 inches /
210 by 297 mm).
4-6 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Printer stackers
1
PRINTERS
The stacker, or output section, provides the capacity for stacking,
offsetting, report collating, print sampling, or stitching. Your IPS has
either a dual stacker or a stitcher/stacker.
Dual stacker
The dual stacker contains two identical output trays. Using the
Output Configuration windows on the graphical user interface, you
can send output to either or both of these trays in the desired order.
Figure 4-4. DocuPrint 92C IPS printer with dual stacker
2
3
Sample tray Used for sample prints, rejected prints, and transparencies. Holds up
Stacker tray 1 Holds up to 750 sheets of 20-pound or 80 gsm bond.
Stacker tray 2 Holds up to 750 sheets of 20-pound or 80 gsm bond.
1 Sample tray
2 Stacker tray 1
3 Stacker tray 2
to 100 sheets of 20-pound or 80 gsm bond.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 4-7
PRINTERS
1
Stitcher/stacker
The optional stitcher/stacker places a wire stitch in stacks of up to 50
sheets. It can also offset jobs and reports.
Figure 4-5. DocuPrint 92C IPS printer with stitcher/stacker
2
1 Sample tray
2 Stitcher/stacker tray
Sample tray Used for sample prints, rejected prints, and transparencies. Holds up
to 100 sheets of 20-pound or 80 gsm bond.
Stitcher/stacker tray A single tray for output that is stitched (stapled) and/or offset. The
tray holds up to 2000 sheets of unstitched 20-pound or 80 gsm bond,
or an equally high stack of stitched sets (200 two-sheet sets). A
stitched set consists of up to 50 sheets of 20-pound or 80 gsm bond.
The wire supply provides up to 32000 staples.
4-8 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Additional IPS printer features
Instruction labels Located throughout the printer to assist you with jam clearance and
Audible tones Alert you to certain printer error conditions. Volume may be adjusted
Power savers To conserve energy, the printer has two power savers: one for the
PRINTERS
Additional features of the DocuPrint 92C IPS printer include:
other tasks.
by a service representative.
raster output scanner (ROS) and one for the fuser.
After a predetermined period, each of these parts times itself out and
shuts down. The time-out period can be adjusted by a service
representative to meet your needs. The Printer Controller
automatically disables power saver mode when a document must be
printed.
• The ROS power saver times itself out after about an hour of
inactivity and requires about 30 seconds to warm back up.
• The fuser power saver times itself out after about four hours and
requires four to seven minutes to warm up.
Language button Systems with the dual language option have this button to select a
different language, such as French instead of English, for the
message display.
Figure 4-6. Language button on the printer control console
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 4-9
PRINTERS
CCU changeout cart The cart is used to remove and install the customer changeable unit
(CCU). The CCU consists of the color developer housing and the dry
ink bottle. Because the CCU is heavy, you will need the cart to make
the changeout.
The carts also serve as storage devices for the CCUs that are not
currently in use. For example, if you use both the red and blue dry
inks in your operation, one CCU is always out of the machine in
storage on the cart while the other CCU is installed.
Figure 4-7. Customer changeable unit (CCU) on cart
Note: You should have a cart for each CCU, so that one cart is
always empty and available to remove the CCU that is installed in the
system. However, if your printer will only be used to print one color
(that is, the CCU will never be removed), or if there is more than one
DocuPrint 92C IPS in operation at your site, it may not be necessary
to have one cart per CCU. Consult your site representative for more
details.
4-10 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Printer paper paths
Simplex paper path The following figure illustrates the simplex (one-sided output) paper
PRINTERS
The paper path is the route that materials (paper, transparencies,
labels, and so on) follow through the printer from the feeder trays to
the output bins or finisher receptacle.
path of a printer with a dual stacker tray and a standard feeder tray.
The materials move from either feeder tray 1 or feeder tray 2 and are
stacked in either stacker tray 1, stacker tray 2, or the sample tray,
depending on your selection at the beginning of the job.
Figure 4-8. Simplex paper path (dual stacker configuration)
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 4-11
PRINTERS
Duplex paper path The following figure illustrates the duplex (two-sided output) paper
path of a printer with a dual stacker and a standard feeder.
Materials may originate in either feeder tray 1 or feeder tray 2. The
duplex paper tray receives the materials before they go through a
second time to receive the second image. As the pages move
through for the second image, they follow the simplex path. The
pages are then stacked in either stacker tray 1 or stacker tray 2,
depending on your selection at the beginning of the job.
Figure 4-9. Duplex paper path (dual stacker configuration)
4-12 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
PRINTERS
High-capacity feeder paper path When you add a high-capacity feeder to your system, only the
beginning of the paper path changes, which is the source of paper
supply. (This is the same for both simplex and duplex paper paths.)
The following figure illustrates the simplex paper path of a printer with
the high-capacity feeder.
Figure 4-10. Simplex paper path on printer with high-capacity
feeder
Stitcher/stacker paper path If you have the stitcher/stacker option, the paper path is the same,
except there is only one tray for the output (other than the sample
tray).
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 4-13
PRINTERS
4-14 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Overview
5. 5Bypass transport
The optional bypass transport enables individual printed sheets of
paper to pass through the DocuPrint 92C IPS output tray to thirdparty finishing devices. These devices perform a variety of finishing
tasks, such as saddle-stitching, binding, folding, stapling, trimming,
and stacking.
The bypass transport fits into tray 1 of the DocuPrint 92C IPS dual
stacker. Printed pages flow from left to right (when viewed from the
front of the printer). The printed pages travel through the IPS output
module and bypass transport, out of the paper exit slot, and into the
finishing device. For paper up to 14 inches long, the maximum
delivery rate is 92 sheets per minute.
Figure 5-1. Bypass transport
1 Bypass transport
2 Bypass transport support
1
2
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 5-1
BYPASS TRANSPORT
Software, firmware, hardware, and paper requirements
The optional bypass transport requires the following:
• Document Feeding and Finishing Architecture (DFA) software
loaded on the IPS, provided by Xerox or the local operating
company. (Note that DFA runs on IPS software version 4.5 and
higher.)
• Dual stacker output module
• Standard white, colored, predrilled, or preprinted paper.
To minimize paper jams and misfeeds, use 20 pound or 80 gsm
(grams per square meter) bond xerographic grade. Xerox 4024
Dual Purpose Paper and Xerox 10 Series Dual Purpose paper
are optimal. Use paper with less than 6% moisture content so
that the paper will not curl and jam.
Note: The time between sheets exiting the bypass transport for 8.5
by 11-inch / 216 by 279 mm paper, A4 paper, and 8.5 by 14-inch /
216 by 352 mm paper is 492 milliseconds in simplex mode and 1052
milliseconds in duplex mode. All times are measured between the
trail edge of the exiting sheet and the lead edge of the next entering
sheet.
5-2 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Personality profiles for third-party finishing devices
2
1
Once a bypass transport is connected to the IPS, you can add any
number of third-party finishing devices.
Figure 5-2. Third-party finishing device configuration
1 Paper path
2 Bypass transport
3 Third-party finishing devices
BYPASS TRANSPORT
3
Each third-party device is identified by a specific personality profile.
The personality profile contains information about the options
available with the finishing device (for example, a booklet-making
device that can produce both side-stitched and saddle-stitched
booklets). It also specifies timing requirements, constraints, flags,
and other parameters.
With your IPS finishing enhancements, you can make any necessary
hardware modifications to the third-party finishing device.
You can create several personality profiles that correspond to
different configurations of the finishing device. Refer to your Xerox
DocuPrint 92C IPS Guide to Configuring and Managing the System
for information on creating personality profiles at the IPS graphical
user interface.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 5-3
BYPASS TRANSPORT
Operator tasks
To use the bypass transport and third-party finishing device, you
must perform several tasks:
• Install and remove the bypass transport
• Set up DFA personality profiles to provide the IPS with
information about the finishing device
• Prepare the finishing device hardware necessary to finish the
printed output and inform the IPS of device names and
parameters
• Enter appropriate commands at the Printer Controller to initiate
finisher jobs
• Clear paper jams.
You learn how to install and remove the bypass transport and clear
jams in the Xerox-provided operator training that follows installation
of the bypass transport. In addition, you must know how to prepare
the third-party finishing device to process printed output.
5-4 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Mechanical interface
BYPASS TRANSPORT
To connect a third-party finishing device to the IPS bypass transport,
you align the finishing device with the paper exit slot of the bypass
transport, dock the finishing device, and establish an electrical
interface between the two.
The mechanical interface of the bypass transport with third-party
finishing devices involves the following:
• Alignment — You must consider the feature locations and the
vertical alignment. Your finishing device must be capable of
aligning at the correct height without interference from
protruding features.
• Paper exit — Printed sheets travel through the IPS output
module and bypass transport, out of the paper exit, and into the
finishing device. The paper exit slot is 16.75 inches (425.45
mm) wide. The finishing device must align with this exit slot.
• Module mobility — Your finishing device must be easy to move
so that you can align it precisely.
The following figure illustrates the alignment and docking locations
for the bypass transport on the printer (the bypass transport support
is not shown).
Figure 5-3. Alignment and docking locations (in millimeters)
1 Sheet registration edge
2 Sheet edge
3 Vertical slot to accept 13 mm
4 Floor
5 22 mm diameter docking zone
6 Center line of docking features
7 Sheet path
8 Finishing device left edge
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 5-5
BYPASS TRANSPORT
Electrical connection
Command signals The IPS can send three command signals to third-party finishing
The printer automatically detects the presence of the bypass
transport and third-party finishing devices when it is powered up. The
system also begins monitoring the interlocks (physical links) between
the bypass transport and the finishing device and starts finishing
device interface communications.
After a sheet of paper passes through the bypass transport to the
external finishing device, the printer loses all record of it.
Communications between the IPS with bypass transport and the
finishing device consist of command and status signals.
devices:
• Cycle up — The printer is powered up and signals the finishing
device to power up
• Sheet exit — A sheet of paper has entered the finishing device
• End of set — The last sheet of a print job set has been sent
Status signals The third-party finishing device can send five status signals to the
IPS:
• Sheet delivered — A sheet of paper has been successfully
delivered to the finishing device
• Set delivered — A print job set has been successfully delivered
to the finishing device
• Offline — The finishing device has no power or is not
connected to the IPS
• Full — The finishing device is full and cannot accept more
sheets
• Faulted — The finishing device is jammed or faulted and is not
ready to accept sheets of paper
5-6 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
How highlight color is created
6. 6Highlight color
This chapter explains the concept of highlight color and discusses
the process by which the IPS uses extraction color to add the desired
colors to a document.
A document with highlight color contains one color plus black. The
color may be printed either as a solid color or combined with black.
To create tints and shades, the DocuPrint 92C prints dots of black
and dots of color very close together. Our eyes mix the dots visually
to produce a wide range of color. DocuPrint prints the black and color
dots in a single pass, ensuring near-perfect registration.
• Tints of black or the highlight color are created by printing dots
of black or color with white space between them, producing a
percentage value of the color, for example, gray or pink.
• Shades are created by printing black dots next to dots of the
highlight color, producing, for example, a dark red.
• Tones are created by printing a combination of black dots, color
dots, and blank space. The result is a percentage value of black
and the highlight color such as a dark red made by mixing dots
of red and black, or a gray-pink made by mixing dots of red and
black dots with some blank space as well.
These patterns of dots are known as screens. Screens are defined in
the Printer Controller software as a matrix of bits, which correspond
to printed dots. The screen defines which dots in the matrix are black,
which are highlight color, and which are not printed.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 6-1
HIGHLIGHT COLOR
How highlight color is specified
Extraction color
You specify color in application software. The DocuPrint provides a
selection of ten colors and black.
If you specify a color in your document that DocuPrint cannot print, it
is printed either as a shade of gray or as an equivalent tone of the
highlight color installed in the printer at the time.
The “extraction color” is the color you select from the Extraction
Color window on the IPS user interface. This selection determines
how the solid-color, shaded, and tinted areas specified in the job sent
from the host will actually appear when printed by the IPS.
Figure 6-1. Extraction Color window
Exact Color Only: If you click this option to enable it, the job is
printed in solid black and one solid highlight color—the extraction
color identified on this screen. No shades or tints are printed. Colors
other than the extraction color are printed in solid black.
The IPDS data stream allows eight colors to be specified in a job:
1. Red
2. Green
3. Blue
4. Cyan
5. Magenta
6. Yellow
7. Brown
8. Black.
6-2 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
HIGHLIGHT COLOR
However, the DocuPrint 92C IPS has available a different set of ten
colored inks that can be selected for loading in the printer, plus black:
1. Red
2. Green
3. Blue
4. Cyan
5. Magenta
6. Cardinal (red)
7. Royal (blue)
8. Ruby
9. Violet
10. Brown.
Therefore, a job may specify a color for which the DocuPrint 92C IPS
does not have corresponding ink; or you may wish to print the job in
an ink different from what is specified.
When the DocuPrint 92C IPS receives a highlight color job, it prints
in whatever color of ink is loaded in the printer, using one solid color
and a variety of shades and tints. The Extraction Color window
enables you to specify how the IPDS color(s) specified in the job will
map to the shades, tints, and solid of the ink in the printer.
Note: Solid black is not affected by the extraction color selection; if
specified in the job, it always prints as solid black.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 6-3
HIGHLIGHT COLOR
Extraction color menu On the Extraction Color window, you can access the color pull-down
menu to select an IPDS color. The selected color represents the
predetermined print job areas that are to be printed in a solid color.
This selected color is the extraction color.
Figure 6-2. Extraction color menu
In addition to the eight IPDS colors, you have the following two
options on this menu:
• Executive Black: The entire job is printed in black, with no
highlight color.
• Printer Color: The color of the ink currently loaded in the
printer will be the extraction color.
If the incoming IPDS data requires other colors in addition to the
chosen extraction highlight color, the DocuPrint 92C IPS translates
these other colors into variations of the installed printer housing
color.
6-4 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Guidelines for selecting the extraction color
Consider the following guidelines for printing highlight color and
selecting an extraction color.
• If multiple colors are specified in the incoming job, you must
decide which of those colors you want to print in the solid color
areas. Select this as the extraction color. The IPS can print only
one solid color; therefore, all saturated areas containing colors
other than the one you picked as your extraction color will print
in shades and tints of the ink in the printer.
Example: Your document contains solid areas of red, green,
and yellow. You have green ink in the printer. You decide you
want all the solid yellow areas in the job to print in solid color.
You must specify yellow on the Extraction Color window. When
the document prints, all yellow areas will appear as solid green.
All other colored areas—red and green—will appear as shades
and tints of green.
• If the job contains only one highlight color and you want to print
the colored areas exactly as the job specifies, make sure the
job color, the Extraction Color window selection, and the ink in
the printer are the same.
Example: Your job specifies certain areas to print in solid blue.
To print those areas in solid blue, you must select blue from the
Extraction Color window, and the ink loaded in the printer must
be blue.
HIGHLIGHT COLOR
• If the job specifies only one highlight color and you want to
ensure that the solid color areas specified in the job remain as
solid color of whatever color ink is loaded in the printer, select
the same extraction color from the Extraction Color window as
is specified in the job.
Example: You have red ink loaded in the printer. The job calls
for green. You must select green from the Extraction Color
menu. When your job prints, all solid-colored areas appear as
solid red (all shaded or tinted areas appear as different shades
or tints of red).
• If your extraction color selection does not match the job-
specified solid color, the areas specified as solid color in the job
print as shades or tints of the ink in the printer. Refer to
appendix A in this guide to see approximately how these
shades and tints will appear in your printed document.
Color samples Appendix A of this guide contains samples (palettes) showing how all
the possible combinations of printer ink, job-specified color, and
selected extraction color will appear when printed in all the inks
available for the DocuPrint 92C IPS.
Caution: The illustrations in appendix A are approximations of how
these colors will print. Printed output can vary in color from printer to
printer, and the colors in your printed documents may appear slightly
different from those shown in this guide. To ensure results that are
satisfactory to you, print some test pages from your job with the
desired extraction color selected.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE 6-5
HIGHLIGHT COLOR
6-6 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
A. APaper and other supplies
This appendix provides information and specifications for the media
you use with your Xerox DocuPrint Model 92C printer. Instructions for
ordering supplies are also provided.
Consumable supplies (those that are depleted during operation of
the system), such as paper, dry ink, developer, fuser agent, etc.,
must be ordered for your printer. It is important that an adequate
supply of these items be on hand for installation, and that your supply
be maintained afterwards.
Paper and other throughput stocks
The success of any print run is greatly dependent on the proper
selection, care, and handling of the stock used.
Selecting paper
You need to select your paper carefully. If you do not use the proper
paper, you increase the probability of paper jams and misfeeds. The
stocks you use must meet the specifications set forth by Xerox for
operability in the printer. For additional information about paper
specifications, refer to Helpful Facts about Paper, delivered with your
printer.
Acceptable paper stocks and sizes Your DocuPrint Model 92C printer accepts the following standard
size cut-sheet papers:
• US Letter: 8.5 by 11 inches / 216 by 279 mm
• US Legal: 8.5 by 14 inches / 216 by 356 mm
• A4: 8.27 by 11.69 inches / 210 by 297 mm
Recommended weight and grade: Use a good quality, xerographic-grade paper. For best results, use
paper that is 20-pound or 80 gsm (grams per square meter) bond,
xerographic grade. Xerox 4024 Dual Purpose Paper provides optimal
performance in the printer. Refer to the consumable supplies table,
later in this appendix.
Use paper within these parameters:
• Lightest: 20-pound or 80 gsm bond
• Heaviest: 110-pound or 200 gsm index.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE A-1
PAPER AND OTHER SUPPLIES
Characteristics The paper stock should have the following characteristics:
• Low moisture content (a paper-to-moisture ratio below 5.7
percent). Paper with higher moisture content may curl and jam.
• Smooth surface
• Moisture-resistant wrapping
• No defects (bent edges, uneven surfaces)
• Grain long (parallel with the long side of paper).
Paper is usually fed into the printer with the long side as the
leading edge. When you purchase paper, buy long-grain paper.
Make sure the grain is parallel with the long side (long-grain) for
the most reliable feeding and stacking.
Special stocks Following are some guidelines for choosing and using special
materials:
• Labels — Must be the type designed for high-speed printers
and must meet the specifications described in the section
above. Loading instructions are printed on all paper trays.
Load labels with the label side up. You can direct them to any
output tray.
• Transparencies — Must be the type designed for high-speed
printers and must meet the specifications described in the
section above. Loading instructions are printed on all paper
trays.
Load transparencies with the opaque strip to the right. All
printed transparencies are delivered to the sample tray.
As long as they meet your printer’s paper specifications, you
can also use:
• Tinted paper — Available in a variety of colors, it has many
uses, including calling attention to certain printed material,
separating special sections, or dividing chapters of a report.
• Preprinted paper — May be letterhead, forms, or logos.
• Predrilled paper — Has a varying number of holes for use in
binders or binder rings. Before loading predrilled paper, fan it to
remove loose plugs that could cause paper jams. Load
predrilled paper in the printer with holes to the right.
• Perforated paper
A-2 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Paper care
PAPER AND OTHER SUPPLIES
Once you have purchased your paper, you must be sure it is stored
and conditioned properly, so that it performs optimally in the printer
with a minimum of jams.
Storing paper Paper has a tendency to curl under the heat that is present inside
xerographic equipment. To minimize the amount of curling, use
paper with low moisture content. Paper with excessive moisture
content has a tendency to jam because of the greater curl. The
maximum recommended moisture content is 5.7 percent.
Keep these points in mind when preparing your paper storage area:
• Store paper in its own wrapper; do not leave it unwrapped or
where it can be damaged by dampness or heat.
• Store paper on a flat surface and not on its side or edge.
• Store reams of paper in a closed cabinet.
• Always store paper in a cool, dry area. Store on pallets or
shelves, not on the floor.
• Plan ahead and keep at least a day’s supply of paper in the
same area as the printer to allow environmental stabilization
prior to printing.
For more detailed information on paper for Xerox printers, refer to
Helpful Facts about Paper, provided with your printer.
Figure A-1. Storing paper correctly
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE A-3
PAPER AND OTHER SUPPLIES
Conditioning paper Because temperature and humidity affect paper performance in the
Figure A-2. Recommended temperature and humidity for paper
storage
printer, you need to condition paper before using it. To do this, store
paper for a specified length of time in the same type of environment
as your printer.
The length of time you should condition your paper depends on the
amount of paper and the difference between the storage and
operating temperatures.
A-4 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
PAPER AND OTHER SUPPLIES
Use the following chart to determine the length of time needed to
condition stacked cartons of paper.
Note: The numbers in the top two rows indicate the temperature
difference between the storage area and the operating environment,
not actual room temperatures.
Table A-1. Paper conditioning: Recommended temperature
differences between storage and operating areas
Temperature differences between storage and
operating areas
Fahrenheit
10
o
15
o
20
o
25
o
30
o
40
o
Centigrade
5.5
o
8.5
o
11
o
13
o
17
o
22
o
Cartons Hours
50
28
o
o
14
55
8 1114172434
9 1215182535
10 8 14 18 22 27 38 51
20 11
40 14
16 23 28 35 48 67
19 26 32 38 54 75
Example: (See the shaded rows in the table above.) If you want to
move ten cartons of paper from a storage area with a temperature of
o
F to an operating area with a temperature of 75 oF (a 15o
90
difference), you should do so at least 14 hours before using the
paper.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE A-5
PAPER AND OTHER SUPPLIES
Other supplies
Dry ink
This section describes the supplies other than paper that are
necessary for installation and afterward. Your sales representative
will help you place your initial supply order.
Dry ink (also called toner) is the powder which forms the image on
the printed page. There are six cartridges of black dry ink or three
cartridges of colored dry ink in each carton. You should keep at least
one extra cartridge on hand at all times. The disposable cartridges
are easily changed with no mess. The consumption rate of Xerox dry
ink is approximately one cartridge per 30,000 pages for black dry ink
and 86,500 pages for colored dry ink. Use only dry ink that is
specified for use in the DocuPrint Model 92C printer, as described in
the consumable supplies table.
Note: Dry ink (toner) yields are based on 5% area coverage for
black dry ink and 1.5% area coverage for colored dry ink. Your yield
may vary, depending on coverage.
Fuser lubricant
Developer
Fuser lubricant is a consumable item required by the printer. You
should keep at least two boxes (each box contains two tubes) on
hand for installation by the service representative. The consumption
rate of Xerox fuser lubricant is approximately one tube per 120,000
pages. For product information, refer to the consumable supplies
table in this appendix.
Developer is not consumed by the printer but does have an effective
life of approximately 300,000 pages per bottle, guaranteed by Xerox.
Developer is a required item and must be kept on hand.
Use only the developer specified for use in your DocuPrint Model
92C printer.
For colored inks, use the color developer specified for each color in
the table below:
Table A-2. Developers for use with colored inks
Ink color Use developer Part number
Black Black 502S63250
Blue Blue 502S63252
Brown Consult your Xerox representative.
Cardinal Red 502S63251
Cyan Cyan 502S63992
Green Green 502S63253
A-6 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Stitcher wire
PAPER AND OTHER SUPPLIES
Table A-2. Developers for use with colored inks
Ink color Use developer Part number
Magenta Magenta 502S63993
Red Red 502S6325
Royal Blue 502S63252
Ruby Magenta 502S63993
Violet Magenta 502S63993
The developer is changed by your service representative. For
product information, refer to the consumable supplies table, later in
this appendix.
Stitcher wire is a consumable item for a printer equipped with the
stitcher/stacker option. You need to order stitcher wire reels and
keep them on hand. They are installed by the service representative
or operators who have completed the Advanced Customer Training
(ACT) or eXcellerate courses offered by Xerox.
Diskettes
Tap es
Fonts
Diskettes are optional items that provide loading and backup of fonts,
forms, and user files to and from the printing system. The processor
accepts 3.5-inch, 1.44 MB, double-sided, high density diskettes.
The optional 4 mm cartridge tape drive uses 5 GB or 8 GB tapes.
The 1/4-inch QIC tape drive uses quarter-inch stream cartridge
tapes. The tape data capacity should be 320/525 MB. Tape density
is critical. The QIC drive can read low density tapes, but to write
reliably requires tape with 21,000 Flux Transitions Per Inch (FTPI).
The FTPI figure is usually listed on the cartridge.
Data can be printed on DocuPrint printers in many sizes and type
styles called fonts. A font is a character set which has unique
characteristics, such as type style, size, weight, orientation (portrait,
landscape, inverse portrait, and inverse landscape), character
spacing (fixed and proportional), line spacing, and postures (Roman,
italic, and so forth).
There are three classifications of fonts:
• Standard fonts
• Licensed fonts
• Custom fonts.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE A-7
PAPER AND OTHER SUPPLIES
Standard fonts A library of 51 fonts is provided with your printer’s operating system
software.
Licensed fonts Additional fonts may be ordered from your local Xerox Font Center.
Custom fonts Custom fonts and graphic images such as company logos and
signatures can be digitized by the Xerox Font Center for use on your
printer.
Receiving fonts Fonts are received on a diskette from your local Xerox Font Center.
A-8 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Consumable supplies tables
Paper and special stocks tables
Item Description Part number
PAPER AND OTHER SUPPLIES
A number of supplies are available from Xerox for your DocuPrint
printer. Use the following tables to help determine your supply needs.
Note: Customers in the U. S. may use the part numbers in these
tables to order supplies. Customers outside the U. S. should contact
their local service organization for part numbers.
The following tables list all throughput stocks available for the
DocuPrint Model 92C printer, with size, order number, and a brief
description for each.
Table A-3. Stocks list for DocuPrint Model 92C printer
Paper Xerox paper quantities are 10 reams (5,000 sheets) to a carton
unless otherwise noted below.
8.5 x 11 inch 4024 Dual Purpose Paper 3R721
A4 4024 Dual Purpose Paper 3R2594
8.5 x 14 inch 4024 Dual Purpose Paper 3R727
8.5 x 11 inch 4024 Dual Purpose Paper, 3-hole 3R723
8.5 x 11 inch 4024 Dual Purpose Paper, 3-hole* 3R2193
8.5 x 11 inch 4024 Dual Purpose Paper, 4-hole 3R1983
8.5 x 11 inch 4024 Dual Purpose Paper, 4-hole* 3R3008
8.5 x 11 inch 4024 Dual Purpose Paper, 7-hole 3R1984
8.5 x 11 inch 4024 Dual Purpose Paper, 7-hole* 3R3010
8.5 x 11 inch 4024 Smooth 3R2675
8.5 x 14 inch 4024 Smooth 3R2677
8.5 x 11 inch Dual Purpose Colors—Blue 3R3052
8.5 x 11 inch Dual Purpose Colors—Blue, 3-hole 3R3068
8.5 x 14 inch Dual Purpose Colors—Blue, 3-hole 3R3084
8.5 x 11 inch Dual Purpose Colors—Green 3R3056
8.5 x 11 inch Dual Purpose Colors—Green, 3-hole 3R3072
8.5 x 14 inch Dual Purpose Colors—Green 3R3088
8.5 x 11 inch Dual Purpose Colors—Pink 3R3058
*5/16-inch drilled holes
** Rainbow pack contains 750 sheets each of blue and yellow, 500 sheets each of green
and pink, and 250 sheets each of buff, gray, goldenrod, and ivory.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE A-9
PAPER AND OTHER SUPPLIES
Table A-3. Stocks list for DocuPrint Model 92C printer
(continued)
Item Description Part number
8.5 x 11 inch Dual Purpose Colors—Pink, 3-hole 3R3074
8.5 x 14 inch Dual Purpose Colors—Pink 3R3090
8.5 x 11 inch Dual Purpose Colors—Yellow 3R3054
8.5 x 11 inch Dual Purpose Colors—Yellow, 3-hole 3R3070
8.5 x 14 inch Dual Purpose Colors—Yellow 3R3086
8.5 x 11 inch Dual Purpose Colors—Buff 3R3060
8.5 x 11 inch Dual Purpose Colors—Buff, 3-hole 3R3076
8.5 x 14 inch Dual Purpose Colors—Buff 3R3092
8.5 x 11 inch Dual Purpose Colors—Goldenrod 3R3062
8.5 x 11 inch Dual Purpose Colors—Goldenrod, 3-hole 3R3078
8.5 x 14 inch Dual Purpose Colors—Goldenrod 3R3094
8.5 x 11 inch Dual Purpose Colors—Ivory 3R3064
8.5 x 11 inch Dual Purpose Colors—Ivory, 3-hole 3R3080
8.5 x 14 inch Dual Purpose Colors—Ivory 3R3096
8.5 x 11 inch Dual Purpose Colors—Gray 3R3066
8.5 x 11 inch Dual Purpose Colors—Gray, 3-hole 3R3802
8.5 x 14 inch Dual Purpose Colors—Gray 3R3098
8.5 x 11 inch** Dual Purpose Colors, Rainbow Pack—35,000
3R3107
sheets per carton**
8.5 x 11 inches 4200 Primary Image 3R5802
8.5 x 14 inches 4200 Primary Image 3R5804
8.5 x 11 inches 4200 Primary Image, 3-hole 3R5803
8.5 x 11 inch 10 Series Dual Purpose Paper 3R2950
8.5 x 11 inch 10 Series Dual Purpose Paper, 3-hole 3R2952
8.5 x 11 inch 10 Series Dual Purpose Paper, 3-hole* 3R3016
8.5 x 14 inch 10 Series Dual Purpose Paper 3R2954
8.5 x 11 inch 10 Series Smooth 3R54
8.5 x 14 inch 10 Series Smooth 3R83
8.5 x 11 inch 4024 Dual Purpose, reinforced 3-hole* 3R2057
*5/16-inch drilled holes
** Rainbow pack contains 750 sheets each of blue and yellow, 500 sheets each of green
and pink, and 250 sheets each of buff, gray, goldenrod, and ivory.
A-10 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
PAPER AND OTHER SUPPLIES
Table A-3. Stocks list for DocuPrint Model 92C printer
(continued)
Item Description Part number
Transparencies Xerox transparencies are packaged 100 sheets to a box.
8.5 x 11 inch Clear, with a white strip on the edge 3R2780
8.5 x 11 inch Clear, high speed, with paper backing 3R3028
Labels (Gummed) Xerox labels are packaged 100 sheets to a box.
8.5 x 11 inch 33 labels per sheet 3R3139
8.5 x 11 inch 6 labels per sheet 3R3146
8.5 x 11 inch Custom form (uncut) Contact Xerox
Supplies Order
Service
8.5 x 11 inch 1-up label 3R4476
8.5 x 11 inch 1-up label 3R4475
8.5 x 11 inch 1-up label 3R4474
Cover stock Xerox cover stock is packaged 2,500 sheets per carton.
8.5" x 11" 65-pound, blue 3R3044
8.5" x 11" 65-pound, white 3R3041
*5/16-inch drilled holes
** Rainbow pack contains 750 sheets each of blue and yellow, 500 sheets each of green
and pink, and 250 sheets each of buff, gray, goldenrod, and ivory.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE A-11
PAPER AND OTHER SUPPLIES
Complete supplies list—Model 92C printer
The following table lists the supplies in addition to paper that are
available for your printer. Use this table to help you determine your
supplies needs.
Table A-4. Complete supplies list for DocuPrint Model 92C
Item Description
Developer
material
Packaged one container per carton. (Needs replacement only if current supply becomes
contaminated.)
Black developer
Red developer (also for cardinal ink)
Blue developer (also for royal ink)
Green developer
Cyan developer
Magenta developer (also for ruby and
violet inks)
Part
number
502S63250
502S63251
502S63252
502S63253
502S63992
502S63993
Items/
carton Expected yield
1/carton
1/carton
1/carton
1/carton
1/carton
1/carton
For brown ink, ask your Xerox
representative about the correct
developer to use.
Diskettes 3.5-inch, 1.44 MB, double-sided,
8R7683 10/box
high density diskettes. Packaged 10
diskettes per box.
Dry ink Colored dry ink is packaged three bottles per carton; black, six bottles per carton.
Black dry ink 6R296 6/carton 180,000 prints/carton
Red dry ink 6R297 3/carton 260,000 prints/carton
Blue dry ink 6R754 3/carton 260,000 prints/carton
Green dry ink 6R299 3/carton 260,000 prints/carton
Cyan dry ink 6R755 3/carton 260,000 prints/carton
Magenta dry ink 6R816 3/carton 260,000 prints/carton
Royal blue dry ink 6R826 3/carton 260,000 prints/carton
Cardinal dry ink 6R825 3/carton 260,000 prints/carton
Violet dry ink 6R828 3/carton 260,000 prints/carton
Ruby dry ink 6R827 3/carton 260,000 prints/carton
Brown dry ink 6R842 3/carton 260,000 prints/carton
Fuser lubricant Packaged two tubes per carton. 8R983 2/carton 240,000 prints/carton
Cartridge tapes 4mm blank cartridge tape, 5GB
4mm blank cartridge tape, 8GB
Cartridge tape
supplies
Cleaning
supplies
QIC blank (26-track) cartridge
QIC tape drive head cleaning kit
4mm cartridge tape head cleaning kit
Foam-tipped swabs
Lint-free towels
9R01190
109R00314
9R84168
9R88432
9R01189
99P87256
35P2163
A-12 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
PAPER AND OTHER SUPPLIES
Table A-4. Complete supplies list for DocuPrint Model 92C
Item Description
Waste
containers
Dry ink waste container (Model 92C)
Developer waste container (Model 92C)
Part
number
93K1403
93K850
Items/
carton Expected yield
400,000/carton
100,000/carton
Stitcher wire Packaged one reel per box. 8R1174 One reel 32,000 staples
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE A-13
PAPER AND OTHER SUPPLIES
Ordering supplies
To avoid unnecessary downtime, always have an adequate amount
of the necessary supplies. To do this, you need to establish a
procedure for checking and ordering supplies. A supplies checklist is
provided at the end of this appendix to help you with this task. It lists
the supplies needed for the printer and contains a column for you to
enter the date when you want to place the order and a column to
record the date of the actual order. The consumable supplies table,
above, contains a list of Xerox supplies available for the printer.
It is important that you check your supplies regularly and order before
you run out. Plan on approximately five working days for delivery
after placing the order. You can make arrangements to receive them
sooner in emergency situations.
Your Xerox sales representative can help you submit the initial order
of supplies needed for installation. These items include paper, dry
ink, fuser lubricant, and developer.
Once your printer volume is established, planning ahead and buying
Xerox supplies in quantity can save you money. Your Xerox supply
specialists can help you. There are two centers available to assist
you:
• To order Xerox paper, transparencies, labels, dry ink, developer,
fuser lubricant, stitcher wire, cartridge tapes, and diskettes, call
the Xerox Supply Center at 1-800-822-2200, weekdays
between 7:30 a.m. and 6:00 p.m., Pacific time.
If you prefer, you may mail orders to the following address:
Xerox Corporation
P. O. Box 25075
Santa Ana, CA 92799-5075
• To order cleaning supplies, call the Xerox Customer Parts and
Product Support Center at 1-800-828-5881, weekdays between
5:30 a.m. and 5:00 p.m., Pacific time, (U.S. only).
You may also mail cleaning supply orders to the following
address:
Xerox Corporation
Parts Marketing Center
Building 214-07S
P. O. Box 1020
Webster, NY 14580
Please provide the following information when placing orders:
• Your customer number (provided by your Xerox sales
representative)
• Your printer model
• Your supply order, including the following information:
— Item name
— Part number
— Quantity desired
— If your company requires a purchase order for payment of
an invoice, you need to provide the purchase order number
to Xerox at the time you place the order.
A-14 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
PAPER AND OTHER SUPPLIES
The following table is a checklist you can use to keep track of the
supplies you order.
Table A-5. Supplies checklist for DocuPrint Model 92C printer
Supplies checklist
Use this checklist to help record the supplies and accessories you need, the date you plan to place the order,
and the actual date of the order.
Item Description and part number Quantity Date to order Date ordered
Paper
Transparencies, labels,
and special stocks
Dry ink
Fuser lubricant
Diskettes
Stitcher wire
Cartridge tapes
Cleaning supplies
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE A-15
PAPER AND OTHER SUPPLIES
A-16 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
B. BExtraction color samples
This appendix contains sample pages for each of the colored inks
available for printing on your DocuPrint 92C IPS: red, green, blue,
cyan, magenta, brown, cardinal, royal, ruby, and violet.
Each of these pages shows approximately how one of the colored
inks will print with each of the eight IPDS colors:
1. Black
2. Red
3. Green
4. Blue
5. Cyan
6. Magenta
7. Yellow
8. Brown.
Note: The illustrations in appendix A are approximations of how
these colors will print. Printed output can vary in color from printer to
printer, and the colors in your printed documents may appear slightly
different from those shown in this guide. To ensure results that are
satisfactory to you, print some test pages from your job with the
desired extraction color selected.
Additional information For an explanation of highlight color printing on the IPS and the
selection of extraction colors, refer to the “Highlight color” chapter in
this guide, and to “Selecting the extraction color” section in your
Xerox DocuPrint 92C IPS Guide to Configuring and Managing the
System, provided with your IPS.
For guidelines for selecting, adding, and using highlight color in your
applications, refer to Designing for Highlight Color, also provided with
your IPS.
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE B-1
EXTRACTION COLOR SAMPLES
B-2 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
Index
Numerics
240 dpi resolution, 1-6
300 dpi resolution, 1-6
600 dpi resolution, 1-6
A
access control, 1-13
Advanced Function Image and Graphics (AFIG), 1-1
AFP environment, 1-4
alignment, third-party finishing devices, 5-5
Attention light, 4-3
audible tones, 4-9
B
BCOCA (Bar code Object Content Architecture), 1-4
BIN command, 1-8
bus and tag cable input, 2-5
bus and tag cables, 1-3
bypass connectors, 2-5
bypass transport, 1-6, 1-10, 5-1–5-6
C
cartridge tape drive, 2-4
CCU changeout cart, 4-10
CD-ROM drive, 2-4
channel communications board, 2-1
color
extraction samples, B-1
samples, 6-5
command signals, third-party finishing devices, 5-6
components
printer, 4-2–4-10
Printer Controller, 2-1–2-5
conditioning paper, A-4–A-5
configuration files, version identifier, 1-12
connectivity boards, 2-3
consumable supplies tables, A-9–A-13
Continue button, 4-3, 4-4
continuous form jobs, 1-11
Copy Subgroup level, 1-8
customer changeable unit, see CCU
D
danger labels, iii
Data Control Interface Module (DCIM2) card, 2-3
data streams, 1-1, 1-4
developer, A-6
DFA, 1-10
diskettes, A-7
Document Feeding and Finishing Architecture, see
DFA
documentation
other, xii
double-byte fonts, 1-11
drives, cartridge tape, 2-4
dry ink
toner, A-6
Dual Mode, 1-1
dual stacker
description, 4-7
tray capacity, 4-3
duplex
paper path, 4-12
duplex, simplex flexibility, 1-9
E
electrical connection, third-party finishing devices, 5-6
Ethernet, 2-3
extraction color
samples, B-1
selecting, 6-5
Extraction Color menu, 6-4
Extraction Color window, 6-2
F
Fault code display, 4-4
feeder trays, 1-5
capacity, 1-5
indicator lights, 4-4
fonts, resident, 1-12
fuser
agent, A-6
shield, A-6
fuser power saver, 4-9
G
GOCA (Graphics Object Content Architecture), 1-4
graphic display, 4-4
GUI, 3-2–3-3
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE INDEX-1
INDEX
H
hard disk, 2-3
HCF
description, 4-6
tray capacity, 4-5
HCU, 2-1, 2-5
HFSI (high frequency service indicator), 3-2
high-capacity feeder, see HCF
highlight color
available colors, 6-2
creation, 6-1
description, 1-5
extraction color
available colors, 6-3
explained, 6-3
overview, 6-1
screens, 6-1
specification, 6-2
Host Channel Unit, see HCU
hotlines
ozone information, iii
safety, iv
Human Readable Interpretation (HRI), 1-12
I
IBM AFP Group 3 page printer, 1-1
IBM, outline fonts, 1-11
indicator lights, 4-3, 4-4
information button, 4-4
input tray
capabilities, 1-8
input trays, 1-5
instruction labels, 4-9
interface
mechanical, 5-5
IOCA (Image Object Content Architecture), 1-4
IOCA colors, 1-13
IOCA Replicate and Trim, 1-9
IPDS data streams, 1-1, 1-4
IPS Engine Monitor window, 3-2
IPS main window
components, 3-4–3-5
described, 3-2
description, 1-2, 1-7
IPS Print Service Console window, 3-2
L
labels
selecting, A-2
language button, 4-9
language, messages, 1-12
laser safety, iii
license, software, 1-14
M
mechanical interface, 5-5
messages
display, 4-4
HFSI, 3-2
translation, 1-12
warning, 4-3
mixed paper sizes, printing on, 1-8
mixed plex, 1-9
MO:DCA-P (Mixed Object Document Content
Architecture for Presentation, 1-4
modem, enable or disable, 1-15
module mobility, third-party finishing devices, 5-5
monitor, 2-4
mouse, 2-4
N
N-Up, enhanced, 1-10
O
OCA colors, 1-13
operation safety, iv
operator tasks, 5-4
optical mouse, 2-4
ordering supplies, A-14
outline fonts, 1-11
output bins, 1-9
Output Configuration window, 1-9
output trays
capacity, 1-6
sample, 4-3
overstrike support, 1-10
ozone, iii
P
J
jam clearance assistance, 4-9
JCL keyword, 1-9
page rotation, 1-11
paper
characteristics, A-2
conditioning, A-4–A-5
exit, third-party finishing devices, 5-5
K
handling, 1-5
path
keyboard, 2-4
duplex, 4-12
high-capacity feeder, 4-13
INDEX-2 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
INDEX
simplex, 4-11
stitcher/stacker, 4-13
recommended weight, grade, A-1
size, 4-6, A-1–A-2
storing, A-3
PCI Bus support, 1-12
PCIM2 card, 2-3
PCL data streams, 1-1
perforated paper, A-2
personality profiles, 5-3
plex, mixed, 1-9
PostScript data streams, 1-1
power
on/off switch, 4-4
savers, 4-9
supply, 2-5
switch, 4-3
predrilled paper, A-2
preprinted paper, A-2
printer control console, 4-3
Printer Controller
components, 2-1–2-5
HCU, 2-1
Sun UltraSPARC workstation, 2-1
description, 1-2
keyboard, 2-4
monitor, 2-4
mouse, 2-4
processor
CD-ROM drive, 2-4
described, 2-3–2-4
hard disk, 2-3
printers
capabilities, 1-1
components, 4-2–4-10
description, 1-2
privilege modes, 1-13
PSF compatibility, 1-1
PT2 Subset, 1-10
PTOCA (Presentation Text Object Content
Architecture), 1-4, 1-10
publications, related, xii
standards, iii
Sample button, 4-4
sample tray, 4-3
dual stacker, 4-7
stitcher/stacker, 4-8
selecting
labels, A-2
paper, characteristics, A-2
transparencies, A-2
simplex, 4-11
simplex, duplex flexibility, 1-9
Sixth Sense Technology, 1-15
software
features, IPS, 1-8
supported products, 1-4
Software license, 1-14
specification, highlight color, 6-2
stacker
trays, 4-7
types, 1-6
status signals, third-party finishing devices, 5-6
stitcher wire, ordering, A-7
stitcher/stacker, 4-8
Stop button, 4-3, 4-4
subscript support, 1-10
Sun workstation, 2-2
superscript support, 1-10
supplies
checklist, A-15
consumable supplies tables, A-9–A-13
developer, A-6
diskettes, A-7
dry ink
toner, A-6
fuser
agent, A-6
shield, A-6
paper, A-1–A-3
stitcher wire, A-7
tapes, A-7
supplies table, A-9–A-13
support services, A-14
R
raster output scanner (ROS) power saver, 4-9
remote service, 1-15
requirements, bypass transport, 5-2
resident fonts, 1-12
resolution, 1-6
RISC processor chipset, 2-1
T
tape
ordering, A-7
tape drive, 2-4
TCP/IP, 1-3
telephone numbers
Xerox Parts and Product Support Center, A-14
Xerox Supply Center, A-14
S
third-party finishing devices
mechanical interface, 5-5
safety
hotline, iv
precautions, iv
XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE INDEX-3
operator tasks, 5-4
personality profiles, 5-3
throughput speed, 1-2
INDEX
tinted paper, A-2
Token Ring, 2-3
toner, see dry ink
trace facility, 1-10
transparencies, selecting, A-2
trays
capacity
dual stacker, 4-5
feeder, 1-5, 4-5
HCF, 4-5, 4-6
output, 1-6
sample, 4-5
dual stacker, 4-7
input capabilities, 1-8
output bins, 1-9
selecting, 1-8
stitcher/stacker, 4-8
U
UltraSPARC workstation, 2-1
underscore support, 1-10
V
version identifier, configuration files, 1-12
W
windows
IPS Engine Monitor, 3-2
IPS main, 3-4–3-5
IPS main, described, 3-2
IPS Print Service Console, 3-2
wire percentage indicator, 4-4
workstations
processor placement, 2-5
Sun UltraSPARC, 2-1
X
Xerox Customer Parts and Product Support Center,
A-14
Xerox Supply Center, A-14
INDEX-4 XEROX DOCUPRINT 92C IPS SYSTEM OVERVIEW GUIDE
