Xerox® VersaLink® B400
Black and White Printer
User Guide
© 2017 Xerox Corporation. All rights reserved. Unpublished rights reserved under the copyright laws of the United States. Contents of this publication may not be reproduced in any form without permission of Xerox Corporation.
Copyright protection claimed includes all forms of matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as styles, templates, icons, screen displays, looks, and so on.
Xerox® and Xerox and Design®, Phaser®, PhaserSMART®, PhaserMatch®, PhaserCal®, PhaserMeter™, CentreWare®, PagePack®, eClick®, PrintingScout®, Walk-Up®, WorkCentre®, FreeFlow®, SMARTsend®, Scan to PC Desktop®, MeterAssistant®, SuppliesAssistant®, Xerox Secure Access Unified ID System®, Xerox Extensible Interface Platform®, ColorQube®, ConnectKey®, Global Print Driver®, VersaLink®, AltaLink®, and Mobile Express Driver® are trademarks of Xerox Corporation in the United States and/or other countries.
Adobe® Reader®, Adobe® Type Manager®, ATM™, Flash®, Macromedia®, Photoshop®, and PostScript® are trademarks of Adobe Systems Incorporated in the United States and/or other countries.
Apple®, Bonjour®, EtherTalk™, TrueType®, iPad®, iPhone®, iPod®, iPod touch®, Mac® and Mac OS® are trademarks of Apple Inc., registered in the U.S. and other countries. AirPrint® and the AirPrint Logo® are trademarks of Apple Inc.
Google Cloud Print™ web printing service, Gmail™ webmail service, and Android™ mobile technology platform are trademarks of Google, Inc.
HP-GL®, HP-UX®, and PCL® are trademarks of Hewlett-Packard Corporation in the United States and/or other countries. IBM® and AIX® are trademarks of International Business Machines Corporation in the United States and/or other countries.
Microsoft®, Windows Vista®, Windows®, and Windows Server® are trademarks of Microsoft Corporation in the United States and other countries.
McAfee®, ePolicy Orchestrator®, and McAfee ePO™ are trademarks or registered trademarks of McAfee, Inc. in the United States and other countries.
Novell®, NetWare®, NDPS®, NDS®, IPX™, and Novell Distributed Print Services™ are trademarks of Novell, Inc. in the United States and other countries.
PANTONE® and other Pantone, Inc. trademarks are the property of Pantone, Inc.
SGI® and IRIX® are trademarks of Silicon Graphics International Corp. or its subsidiaries in the United States and/or other countries.
Sun, Sun Microsystems, and Solaris are trademarks or registered trademarks of Oracle and/or its affiliates in the United States and other countries.
UNIX® is a trademark in the United States and other countries, licensed exclusively through X/ Open Company Limited. Wi-Fi CERTIFIED Wi-Fi Direct® is a trademark of the Wi-Fi Alliance.
Document version 1.0: February 2017
Contents |
|
|
1 |
Safety |
9 |
|
Notices and Safety....................................................................................................................................................... |
10 |
|
Electrical Safety............................................................................................................................................................. |
11 |
|
General Guidelines................................................................................................................................................ |
11 |
|
Power Cord .............................................................................................................................................................. |
12 |
|
Emergency Turn Off............................................................................................................................................. |
12 |
|
Operational Safety....................................................................................................................................................... |
13 |
|
Operational Guidelines ....................................................................................................................................... |
13 |
|
Ozone Release........................................................................................................................................................ |
13 |
|
Printer Location ..................................................................................................................................................... |
13 |
|
Printer Supplies ...................................................................................................................................................... |
14 |
|
Maintenance Safety .................................................................................................................................................... |
15 |
|
Printer Symbols.............................................................................................................................................................. |
16 |
|
Environmental, Health, and Safety Contact Information............................................................................. |
18 |
2 |
Getting Started |
19 |
|
Parts of the Printer ....................................................................................................................................................... |
20 |
|
Front View................................................................................................................................................................ |
20 |
|
Control Panel .......................................................................................................................................................... |
21 |
|
Internal Parts.......................................................................................................................................................... |
23 |
|
Rear View ................................................................................................................................................................. |
23 |
|
Power Options................................................................................................................................................................ |
24 |
|
Powering On the Printer ..................................................................................................................................... |
24 |
|
Exiting Low-Power Mode or Sleep Mode...................................................................................................... |
25 |
|
Restarting, Entering Sleep Mode or Low-Power Mode............................................................................ |
25 |
|
Accessing the Printer ................................................................................................................................................... |
26 |
|
Logging In................................................................................................................................................................ |
26 |
|
Introduction to Apps ................................................................................................................................................... |
27 |
|
Information Pages ....................................................................................................................................................... |
28 |
|
Printing Information Pages............................................................................................................................... |
28 |
|
Configuration Report........................................................................................................................................... |
29 |
|
The Embedded Web Server....................................................................................................................................... |
30 |
|
Accessing the Embedded Web Server........................................................................................................... |
30 |
|
Finding the IP Address of Your Printer.......................................................................................................... |
30 |
|
Installation and Setup ................................................................................................................................................ |
31 |
|
Installation and Setup Overview..................................................................................................................... |
31 |
|
Selecting a Location for the Printer ............................................................................................................... |
31 |
|
Connecting the Printer........................................................................................................................................ |
32 |
|
More Information......................................................................................................................................................... |
45 |
|
Xerox® VersaLink® B400 Printer |
3 |
|
User Guide |
|
Contents |
|
|
3 |
Customize and Personalize |
47 |
|
Customize and Personalize Overview.................................................................................................................... |
48 |
|
Customizing or Personalizing the Home Screen................................................................................................ |
49 |
|
Customizing or Personalizing the Apps ................................................................................................................ |
50 |
|
Customizing or Personalizing the Feature List........................................................................................... |
50 |
|
Saving Presets ........................................................................................................................................................ |
50 |
|
Removing App Customization.......................................................................................................................... |
51 |
4 |
Xerox® Apps |
53 |
|
Xerox® App Gallery....................................................................................................................................................... |
54 |
|
Xerox® Apps Gallery Overview ......................................................................................................................... |
54 |
|
Creating a Xerox® App Gallery Account....................................................................................................... |
54 |
|
Logging in to your Xerox® App Gallery Account ....................................................................................... |
55 |
|
Installing or Updating an App from the Xerox® App Gallery............................................................... |
56 |
|
Device................................................................................................................................................................................ |
57 |
|
Device Overview .................................................................................................................................................... |
57 |
|
About......................................................................................................................................................................... |
59 |
|
Supply Status.......................................................................................................................................................... |
60 |
|
Billing and Usage Counters............................................................................................................................... |
61 |
|
Reset to Factory Defaults .................................................................................................................................. |
61 |
|
Remote Services .................................................................................................................................................... |
61 |
|
Jobs .................................................................................................................................................................................... |
62 |
|
Jobs Overview......................................................................................................................................................... |
62 |
|
Managing Jobs....................................................................................................................................................... |
62 |
|
Managing Special Job Types............................................................................................................................ |
63 |
|
Managing Jobs using the Embedded Web Server.................................................................................... |
67 |
|
Print From USB............................................................................................................................................................... |
68 |
|
Print From USB Overview ................................................................................................................................... |
68 |
|
Printing From a USB Flash Drive ..................................................................................................................... |
68 |
5 |
Printing |
71 |
|
Printing Overview.......................................................................................................................................................... |
72 |
|
Selecting Printing Options......................................................................................................................................... |
73 |
|
Print Driver Help .................................................................................................................................................... |
73 |
|
Windows Printing Options ................................................................................................................................. |
74 |
|
Macintosh Printing Options .............................................................................................................................. |
76 |
|
UNIX and Linux Printing..................................................................................................................................... |
77 |
|
Mobile Printing Options...................................................................................................................................... |
79 |
|
Printing From a USB Flash Drive ............................................................................................................................. |
80 |
|
Printing Features........................................................................................................................................................... |
81 |
|
Managing Jobs....................................................................................................................................................... |
81 |
|
Printing Special Job Types................................................................................................................................. |
82 |
|
Selecting Paper Options for Printing.............................................................................................................. |
86 |
|
Scaling....................................................................................................................................................................... |
86 |
|
Printing on Both Sides of the Paper............................................................................................................... |
86 |
4Xerox® VersaLink® B400 Printer User Guide
|
Contents |
|
|
Printing Mirror Images........................................................................................................................................ |
87 |
|
Printing Multiple Pages to a Single Sheet.................................................................................................... |
87 |
|
Print Quality ............................................................................................................................................................ |
88 |
|
Image Options ....................................................................................................................................................... |
88 |
|
Contrast.................................................................................................................................................................... |
88 |
|
Lightness .................................................................................................................................................................. |
88 |
|
Image Shift ............................................................................................................................................................. |
88 |
|
Printing Booklets ................................................................................................................................................... |
88 |
|
Using Special Pages ............................................................................................................................................. |
89 |
|
Printing Watermarks for Windows ................................................................................................................. |
91 |
|
Orientation .............................................................................................................................................................. |
92 |
|
Printing Banner Pages......................................................................................................................................... |
92 |
|
Selecting Job Completion Notification for Windows .............................................................................. |
92 |
|
Using Custom Paper Sizes ......................................................................................................................................... |
93 |
|
Printing on Custom Paper Sizes....................................................................................................................... |
93 |
|
Defining Custom Paper Sizes............................................................................................................................ |
94 |
6 |
Paper and Media |
95 |
|
Supported Paper............................................................................................................................................................ |
96 |
|
Ordering Paper....................................................................................................................................................... |
96 |
|
General Paper Loading Guidelines ................................................................................................................. |
96 |
|
Paper That Can Damage Your Printer........................................................................................................... |
97 |
|
Paper Storage Guidelines................................................................................................................................... |
97 |
|
Supported Standard Paper Sizes..................................................................................................................... |
98 |
|
Supported Paper Types and Weights............................................................................................................ |
98 |
|
Supported Standard Paper Sizes for Automatic 2-Sided Printing ...................................................... |
98 |
|
Supported Paper Types and Weights for Automatic 2-Sided Printing ............................................. |
99 |
|
Supported Custom Paper Sizes........................................................................................................................ |
99 |
|
Cardstock.................................................................................................................................................................. |
99 |
|
Loading Paper .............................................................................................................................................................. |
100 |
|
Changing Paper Settings.................................................................................................................................. |
100 |
|
Loading Paper in Trays 1–4............................................................................................................................. |
101 |
|
Loading Paper in the Bypass Tray ................................................................................................................ |
104 |
|
Loading Small Paper Sizes in the Bypass Tray......................................................................................... |
107 |
|
Configuring Trays 1–4 for the Paper Length............................................................................................ |
110 |
|
Printing on Special Paper......................................................................................................................................... |
112 |
|
Envelopes ............................................................................................................................................................... |
112 |
|
Labels....................................................................................................................................................................... |
118 |
7 |
Maintenance |
123 |
|
General Precautions................................................................................................................................................... |
124 |
|
Cleaning the Printer ................................................................................................................................................... |
125 |
|
Cleaning the Exterior of the Printer ............................................................................................................. |
125 |
|
Cleaning the Interior ......................................................................................................................................... |
125 |
|
Adjustments and Maintenance Procedures...................................................................................................... |
126 |
|
Adjusting Paper Registration.......................................................................................................................... |
126 |
|
Xerox® VersaLink® B400 Printer |
5 |
|
User Guide |
|
Contents |
|
|
|
Supplies........................................................................................................................................................................... |
129 |
|
Consumables ........................................................................................................................................................ |
129 |
|
Routine Maintenance Items........................................................................................................................... |
129 |
|
Ordering Supplies................................................................................................................................................ |
130 |
|
Toner Cartridges.................................................................................................................................................. |
132 |
|
Recycling Supplies............................................................................................................................................... |
133 |
|
Managing the Printer ................................................................................................................................................ |
134 |
|
Viewing the Meter Reading ............................................................................................................................ |
134 |
|
Printing the Billing Summary Report ........................................................................................................... |
134 |
|
Moving the Printer...................................................................................................................................................... |
135 |
8 |
Troubleshooting |
137 |
|
General Troubleshooting ......................................................................................................................................... |
138 |
|
Printer Does Not Power On.............................................................................................................................. |
138 |
|
Printer Resets or Powers Off Frequently..................................................................................................... |
139 |
|
Printer Does Not Print........................................................................................................................................ |
139 |
|
Printing Takes Too Long................................................................................................................................... |
140 |
|
Document Prints From Wrong Tray ............................................................................................................. |
141 |
|
Automatic 2-Sided Printing Problems ......................................................................................................... |
141 |
|
Printer is Making Unusual Noises.................................................................................................................. |
141 |
|
Paper Tray Will Not Close ................................................................................................................................ |
141 |
|
Condensation has Formed Inside the Printer........................................................................................... |
142 |
|
Paper Jams .................................................................................................................................................................... |
143 |
|
Locating Paper Jams.......................................................................................................................................... |
143 |
|
Minimizing Paper Jams..................................................................................................................................... |
144 |
|
Clearing Paper Jams .......................................................................................................................................... |
145 |
|
Troubleshooting Paper Jams .......................................................................................................................... |
156 |
|
Print-Quality Problems .............................................................................................................................................. |
158 |
|
Controlling Print-Quality................................................................................................................................... |
158 |
|
Paper and Media................................................................................................................................................. |
158 |
|
Solving Print-Quality Problems....................................................................................................................... |
159 |
|
Getting Help.................................................................................................................................................................. |
163 |
|
Viewing Warning Messages on the Control Panel.................................................................................. |
163 |
|
Viewing Current Errors on the Control Panel............................................................................................ |
163 |
|
Using the Integrated Troubleshooting Tools........................................................................................... |
163 |
|
Online Support Assistant.................................................................................................................................. |
164 |
|
Information Pages.............................................................................................................................................. |
164 |
|
More Information............................................................................................................................................... |
164 |
A |
Specifications |
165 |
|
Printer Configurations and Options..................................................................................................................... |
166 |
|
Available Configurations.................................................................................................................................. |
166 |
|
Standard Features .............................................................................................................................................. |
166 |
|
Options and Upgrades...................................................................................................................................... |
167 |
|
Physical Specifications.............................................................................................................................................. |
168 |
|
Weights and Dimensions ................................................................................................................................. |
168 |
6Xerox® VersaLink® B400 Printer User Guide
|
Contents |
|
|
Standard Configuration.................................................................................................................................... |
168 |
|
Configuration with Three Optional 550-Sheet Feeders ....................................................................... |
168 |
|
Total Space Requirements............................................................................................................................... |
169 |
|
Clearance Requirements .................................................................................................................................. |
169 |
|
Clearance Requirements with Three Optional 550-Sheet Feeders .................................................. |
169 |
|
Environmental Specifications................................................................................................................................. |
170 |
|
Temperature......................................................................................................................................................... |
170 |
|
Relative Humidity ............................................................................................................................................... |
170 |
|
Elevation................................................................................................................................................................. |
170 |
|
Electrical Specifications............................................................................................................................................ |
171 |
|
Power Supply Voltage and Frequency ........................................................................................................ |
171 |
|
Power Consumption........................................................................................................................................... |
171 |
|
ENERGY STAR Qualified Product................................................................................................................... |
171 |
|
Germany - Blue Angel........................................................................................................................................ |
171 |
|
Recycling Supplies............................................................................................................................................... |
171 |
|
Performance Specifications .................................................................................................................................... |
172 |
|
Print Speed ............................................................................................................................................................ |
172 |
B |
Regulatory Information |
173 |
|
Basic Regulations........................................................................................................................................................ |
174 |
|
United States FCC Regulations...................................................................................................................... |
174 |
|
Canada.................................................................................................................................................................... |
174 |
|
Certifications in Europe .................................................................................................................................... |
175 |
|
European Union Lot 4 Imaging Equipment Agreement Environmental Information.............. |
175 |
|
Germany................................................................................................................................................................. |
178 |
|
Turkey RoHS Regulation................................................................................................................................... |
179 |
|
Eurasian Economic Community Certification .......................................................................................... |
179 |
|
Regulatory Information for 2.4-GHz and 5-GHz Wireless Network Adapter................................ |
179 |
|
Ozone Release...................................................................................................................................................... |
179 |
|
Copy Regulations........................................................................................................................................................ |
180 |
|
United States........................................................................................................................................................ |
180 |
|
Canada.................................................................................................................................................................... |
181 |
|
Other Countries.................................................................................................................................................... |
182 |
|
Safety Certification.................................................................................................................................................... |
183 |
|
Material Safety Data Sheets .................................................................................................................................. |
184 |
C |
Recycling and Disposal |
185 |
|
All Countries.................................................................................................................................................................. |
186 |
|
North America.............................................................................................................................................................. |
187 |
|
European Union........................................................................................................................................................... |
188 |
|
Domestic/Household Environment .............................................................................................................. |
188 |
|
Professional/Business Environment ............................................................................................................. |
188 |
|
Collection and Disposal of Equipment and Batteries............................................................................ |
189 |
|
Battery Symbol Note ......................................................................................................................................... |
189 |
|
Battery Removal.................................................................................................................................................. |
189 |
|
Other Countries............................................................................................................................................................ |
190 |
|
Xerox® VersaLink® B400 Printer |
7 |
|
User Guide |
|
Safety |
1 |
This chapter includes: |
|
|
• |
Notices and Safety .......................................................................................................................................................... |
10 |
• |
Electrical Safety ................................................................................................................................................................ |
11 |
• |
Operational Safety .......................................................................................................................................................... |
13 |
• |
Maintenance Safety ....................................................................................................................................................... |
15 |
• |
Printer Symbols................................................................................................................................................................. |
16 |
• Environmental, Health, and Safety Contact Information ................................................................................ |
18 |
|
Your printer and the recommended supplies have been designed and tested to meet strict safety |
|
|
requirements. Attention to the following information ensures the continued safe operation of your |
|
|
Xerox printer. |
|
Xerox® VersaLink® B400 Printer |
9 |
User Guide |
|
Safety
Read the following instructions carefully before operating your printer. Refer to these instructions to ensure the continued safe operation of your printer.
Your Xerox® printer and supplies are designed and tested to meet strict safety requirements. These include safety agency evaluation and certification, and compliance with electromagnetic regulations and established environmental standards.
The safety and environment testing and performance of this product have been verified using Xerox® materials only.
Note: Unauthorized alterations, which can include the addition of new functions or connection of external devices, can affect the product certification. For more information, contact your Xerox representative.
10Xerox® VersaLink® B400 Printer User Guide
|
|
Safety |
Electrical Safety |
|
|
This section includes: |
|
|
• |
General Guidelines........................................................................................................................................................... |
11 |
• |
Power Cord ......................................................................................................................................................................... |
12 |
• |
Emergency Turn Off........................................................................................................................................................ |
12 |
WARNINGS:
•Do not push objects into slots or openings on the printer. Touching a voltage point or shorting out a part could result in fire or electric shock.
•Do not remove the covers or guards that are fastened with screws unless you are installing optional equipment and are instructed to do so. Power off the printer when performing these installations. Disconnect the power cord when removing covers and guards for installing optional equipment. Except for user-installable options, there are no parts that you can maintain or service behind these covers.
The following are hazards to your safety:
•The power cord is damaged or frayed.
•Liquid is spilled into the printer.
•The printer is exposed to water.
•The printer emits smoke, or the surface is unusually hot.
•The printer emits unusual noise or odors.
•The printer causes a circuit breaker, fuse, or other safety device to activate.
If any of these conditions occur, do the following:
1.Power off the printer immediately.
2.Disconnect the power cord from the electrical outlet.
3.Call an authorized service representative.
Xerox® VersaLink® B400 Printer |
11 |
User Guide |
|
Safety
Use the power cord supplied with your printer.
•Plug the power cord directly into a properly grounded electrical outlet. Ensure that each end of the cord is connected securely. If you do not know if an outlet is grounded, ask an electrician to check the outlet.
WARNING: To avoid risk of fire or electrical shock, do not use extension cords, power strips, or power plugs for more than 90 days. When a permanent outlet receptacle cannot be installed, use only one factory-assembled extension cord of the appropriate gauge for each printer or multifunction printer. Always adhere to national and local building, fire, and electrical codes regarding length of cord, conductor size, grounding, and protection.
•Do not use a ground adapter plug to connect the printer to an electrical outlet that does not have a ground connection terminal.
•Verify that the printer is plugged into an outlet that is providing the correct voltage and power. Review the electrical specification of the printer with an electrician if necessary.
•Do not place the printer in an area where people can step on the power cord.
•Do not place objects on the power cord.
•If the power cord becomes frayed or worn, replace it.
•To avoid electrical shock and damage to the cord, grasp the plug when unplugging the power cord.
The power cord is attached to the printer as a plug-in device on the back of the printer. If it is necessary to disconnect all electrical power from the printer, disconnect the power cord from the electrical outlet.
If any of the following conditions occur, power off the printer immediately and disconnect the power cord from the electrical outlet. Contact an authorized Xerox service representative to correct the problem if:
•The equipment emits unusual odors or makes unusual noises.
•The power cable is damaged or frayed.
•A wall panel circuit breaker, fuse, or other safety device has been tripped.
•Liquid is spilled into the printer.
•The printer is exposed to water.
•Any part of the printer is damaged.
12Xerox® VersaLink® B400 Printer User Guide
Safety
Your printer and supplies were designed and tested to meet strict safety requirements. These include safety agency examination, approval, and compliance with established environmental standards.
Your attention to the following safety guidelines helps to ensure the continued, safe operation of your printer.
•Do not remove any trays while the printer is printing.
•Do not open the doors when the printer is printing.
•Do not move the printer while is printing.
•Keep hands, hair, neckties, and so on away from the exit and feed rollers.
•Covers, which require tools for removal, protect the hazard areas within the printer. Do not remove the protective covers.
•Do not override any electrical or mechanical interlock devices.
•Do not attempt to remove paper that is jammed deeply inside the product. Switch off the product promptly and contact your local Xerox representative.
WARNING: The metallic surfaces in the fuser area are hot. Always use caution when removing paper jams from this area and avoid touching any metallic surfaces.
This printer produces ozone during normal operation. The amount of ozone produced is dependent on copy volume. Ozone is heavier than air and is not produced in amounts large enough to harm anyone. Install the printer in a well-ventilated room.
For more information in the United States and Canada, go to www.xerox.com/environment. In other markets, please contact your local Xerox representative or go to www.xerox.com/environment_europe.
•Place the printer on a level, solid, non-vibrating surface with adequate strength to hold its weight. To find the weight for your printer configuration, refer to Physical Specifications on page 168.
•Do not block or cover the slots or openings on the printer. These openings are provided for ventilation and to prevent overheating of the printer.
•Place the printer in an area where there is adequate space for operation and servicing.
•Place the printer in a dust-free area.
•Do not store or operate the printer in an extremely hot, cold, or humid environment.
•Do not place the printer near a heat source.
Xerox® VersaLink® B400 Printer |
13 |
User Guide |
|
Safety
•Do not place the printer in direct sunlight to avoid exposure to light-sensitive components.
•Do not place the printer where it is directly exposed to the cold air flow from an air conditioning system.
•Do not place the printer in locations susceptible to vibrations.
•For optimum performance, use the printer at the elevations specified in Elevation on page 170.
•Use the supplies designed for your printer. The use of unsuitable materials can cause poor performance and a possible safety hazard.
•Follow all warnings and instructions marked on, or supplied with, the product, options, and supplies.
•Store all consumables in accordance with the instructions given on the package or container.
•Keep all consumables away from the reach of children.
•Never throw toner, toner cartridges, drum cartridges, or waste cartridges into an open flame.
•When handling cartridges, for example toner and such, avoid skin or eye contact. Eye contact can cause irritation and inflammation. Do not attempt to disassemble the cartridge, which can increase the risk of skin or eye contact.
CAUTION: Use of non-Xerox supplies is not recommended. The Xerox Warranty, Service Agreement, and Total Satisfaction Guarantee do not cover damage, malfunction, or degradation of performance caused by use of non-Xerox supplies, or the use of Xerox supplies not specified for this printer. The Total Satisfaction Guarantee is available in the United States and Canada. Coverage could vary outside these areas. Please contact your Xerox representative for details.
14Xerox® VersaLink® B400 Printer User Guide
Safety
Do not attempt any maintenance procedure that is not specifically described in the documentation supplied with your printer.
•Clean the device with a dry lint-free cloth only.
•Do not burn any consumables or routine maintenance items. For information on Xerox® supplies recycling programs, go to www.xerox.com/gwa.
WARNING: Do not use aerosol cleaners. Aerosol cleaners can be explosive or flammable when used on electromechanical equipment.
When installing the device in a hallway or similar restricted area, additional space requirements can apply. Ensure that you comply with all workspace safety regulations, building codes, and fire codes for your area.
Xerox® VersaLink® B400 Printer |
15 |
User Guide |
|
Safety
Symbol |
Description |
|
Warning: |
|
Indicates a serious hazard that can result in death or serious injury if not avoided. |
|
Hot Warning: |
|
Hot surface on or in the printer. Use caution to avoid personal injury. |
|
Warning: Moving parts. To avoid personal injury, use caution. |
|
Caution: |
|
Indicates a mandatory action to take in order to avoid damage to the property. |
|
Caution: |
|
To avoid damage to the property, be careful not to spill toner when handling the |
|
waste cartridge. |
|
Do not touch the part or area of the printer. |
|
Do not expose the drum cartridges to direct sunlight. |
|
Do not burn the toner cartridges. |
|
Do not burn the waste cartridge. |
|
Do not burn the drum cartridges. |
16Xerox® VersaLink® B400 Printer User Guide
Safety
Symbol |
Description |
|
Do not use paper attached with staples or any form of binding clip. |
|
Do not use folded, creased, curled, or wrinkled paper. |
|
Do not use inkjet paper. |
|
Do not use transparencies or overhead projector sheets. |
|
Do not reload paper previously printed on or used. |
|
Do not copy money, revenue stamps, or postage stamps. |
For details about all the printer symbols that appear on your printer, refer to the Printer Symbols guide at www.xerox.com/office/VLB400docs.
Xerox® VersaLink® B400 Printer |
17 |
User Guide |
|
Safety
Environmental, Health, and Safety Contact
Information
For more information on Environment, Health, and Safety in relation to this Xerox product and supplies, contact the following customer help lines:
United States and Canada: |
1-800-ASK-XEROX (1-800-275-9376) |
Europe: |
+44 1707 353 434 |
For product safety information in the United States and Canada, go to www.xerox.com/environment.
For product safety information in Europe, go to www.xerox.com/environment_europe.
18Xerox® VersaLink® B400 Printer User Guide
Getting Started |
2 |
This chapter includes: |
|
|
• Parts of the Printer........................................................................................................................................................... |
20 |
|
• |
Power Options ................................................................................................................................................................... |
24 |
• |
Accessing the Printer....................................................................................................................................................... |
26 |
• |
Introduction to Apps....................................................................................................................................................... |
27 |
• |
Information Pages........................................................................................................................................................... |
28 |
• The Embedded Web Server.......................................................................................................................................... |
30 |
|
• |
Installation and Setup ................................................................................................................................................... |
31 |
• |
More Information............................................................................................................................................................ |
45 |
Xerox® VersaLink® B400 Printer |
19 |
User Guide |
|
Getting Started |
|
|
Parts of the Printer |
|
|
This section includes: |
|
|
• |
Front View........................................................................................................................................................................... |
20 |
• |
Control Panel ..................................................................................................................................................................... |
21 |
• |
Internal Parts..................................................................................................................................................................... |
23 |
• |
Rear View ............................................................................................................................................................................ |
23 |
5
4
3 |
2 |
1 |
1.Tray 1
2.Bypass Tray
3.Front Door
4.USB Memory Port
6 |
7 |
8
5.Control Panel
6.Output Tray
7.Output Tray Paper Stop
8.Optional 550-Sheet Feeder, maximum of 3 (Trays 2–4)
20Xerox® VersaLink® B400 Printer User Guide
Getting Started
The control panel consists of a touch screen and buttons you press to control the functions available on the printer. The control panel:
•Displays the current operating status of the printer.
•Provides access to printing features.
•Provides access to reference materials.
•Provides access to Tools and Setup menus.
•Prompts you to load paper, replace supplies, and clear jams.
•Displays errors and warnings.
•Provides the Power/Wake button used for powering on or off the printer. This button also supports the power-saver modes, and blinks to indicate the power status of the printer.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Xerox® VersaLink® B400 Printer |
21 |
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
User Guide |
|
Getting Started
Item |
Name |
Description |
|
|
|
|
|
|
NFC Area |
Near Field Communication (NFC), is a technology that enables devices to |
|
1 |
|
communicate when they are within 10 cm (4 in.) of each other. Use the NFC |
|
|
area to obtain a network interface or to establish a TCP/IP connection |
||
|
|
||
|
|
between your device and the printer. |
|
|
|
|
|
2 |
Touch Screen Display |
The screen displays information and provides access to printer functions. |
|
|
|
|
|
3 |
Home Button |
This button provides access to the Home menu for access to printer features. |
|
|
|
|
|
|
Power/Wake |
This button serves several power-related functions. |
|
|
|
• When the printer is powered off, this button powers on on the printer. |
|
|
|
• When the printer is powered on, pressing this button displays a menu on |
|
|
|
the control panel. From this menu, you can choose to enter Sleep mode, |
|
|
|
restart, or power off the printer. |
|
|
|
• When the printer is powered on, but in a low-power mode or Sleep mode, |
|
4 |
|
pressing this button wakes the printer. |
|
|
• When the printer is powered on, holding this button for 10-seconds turns |
||
|
|
||
|
|
off the printer. |
|
|
|
This button also blinks to indicate the power status of the printer. |
|
|
|
• When the light blinks slowly, the printer is in low-power mode or |
|
|
|
Sleep mode. |
|
|
|
• When the light blinks rapidly, the printer is powering down, or exiting a |
|
|
|
low-power mode. |
|
|
|
|
|
|
Status LED |
This light blinks blue or amber to indicate printer status. |
|
|
|
Blue |
|
|
|
• Blinks blue once to acknowledge a successful Authentication request. |
|
|
|
• Blinks blue once slowly for a print job initiated at the control panel. |
|
|
|
• Blinks blue twice slowly for a print job received from the network. |
|
5 |
|
• Blinks blue rapidly while the printer is powering up, or to signal detection of |
|
|
a Wi-Fi Direct connection request. |
||
|
|
||
|
|
Amber |
|
|
|
• Blinks amber to indicate an error condition or warning that requires your |
|
|
|
attention. For example, an out-of-toner condition, a paper jam, or out of |
|
|
|
paper for the current job. |
|
|
|
• It also blinks amber to indicate a system error, which typically is associated |
|
|
|
with an error code. |
|
|
|
|
|
|
Notification Banner |
Notifications and messages are displayed in a pop-up banner below the apps |
|
6 |
|
area. To view the full notification, touch the down arrow. Once you have |
|
|
|
reviewed the information, touch X to close. |
|
7 |
Pause Button |
When a job is being processed, a Pause icon appears in the notification banner |
|
|
area. To pause the current job, touch the Pause icon. The job pauses with the |
||
|
|
option to resume or delete the job. |
|
|
|
|
22Xerox® VersaLink® B400 Printer User Guide
Getting Started
1. |
Front Cover |
4. |
Drum Cartridge |
2. |
Output Tray Paper Stop |
5. |
Toner Cartridge |
3. |
Cover Release |
|
|
5
3 |
4 |
|
|
2 |
|
1 |
|
6 |
7 |
8 |
9
10
11
12
13
1. |
Duplex Unit |
8. |
Power Switch |
2. |
Transfer Roll |
9. |
Foreign Device Interface Connector |
3. |
Fuser |
10. USB 2.0 Port |
|
4. |
Power Connector |
11. USB 3.0 Port |
|
5. |
Back Cover |
12. Wireless Network Adapter Port Cover |
|
6. |
Control Board |
13. Ethernet Port |
|
7. |
Left-Side Cover |
|
|
Xerox® VersaLink® B400 Printer |
23 |
User Guide |
|
Getting Started
The Power/Wake button is a single multifunction button on the control panel.
•When used in conjunction with the power switch, the Power/Wake button powers on the printer.
•If the printer is already powered on, the Power/Wake button can be used to:
−restart the printer
−enter or exit sleep mode
−enter or exit low-power mode
•The Power/Wake button also flashes when the printer is in low-power mode.
To power on the printer when it is off, press the power switch and then press the Power/Wake button.
2 |
1 |
CAUTION: Do not unplug the power cord while the printer powers on.
24Xerox® VersaLink® B400 Printer User Guide
Getting Started
Once the printer is powered on:
•The printer exits Low-Power mode or Sleep mode automatically when it receives data from a connected device.
•The touch screen may appear blank and unresponsive when the printer is in Low-Power mode or Sleep mode. To wake the printer manually, press the Power/Wake button.
CAUTION: Do not plug or unplug the power cord while the printer is powered on.
To restart, enter sleep mode, or enter low-power mode:
1.At the printer control panel, press the Power/Wake button.
2.Select an option:
−To restart the printer, touch Restart.
−To place the printer in Sleep Mode, touch Sleep.
In Sleep Mode, the touch screen goes dark and the Power/Wake button flashes.
Xerox® VersaLink® B400 Printer |
25 |
User Guide |
|
Getting Started
Logging in is the process by which you identify yourself to the printer for authentication. If authentication is set, to access printer features, you log in with your user credentials.
1.At the printer control panel, press the Home button.
2.Touch Log In.
3.Type the User Name using the keypad, then touch Enter.
4.If prompted, enter the password, then press Enter.
5.Touch OK.
Note: To access each service that is password-protected, repeat steps 3 and 4.
26Xerox® VersaLink® B400 Printer User Guide
Getting Started
Xerox Apps are a gateway to the features and functions of your device. There are standard Apps that are already installed on the device and that appear on the Home screen. There are also Apps that are installed as standard but are hidden when your device is used for the first time.
When you log in, the apps that are configured for your personal account appear on the control panel.
You can download more Apps for your device from the Xerox® App Gallery. For details, refer to Xerox Apps Gallery Overview on page 54.
Xerox® VersaLink® B400 Printer |
27 |
User Guide |
|
Getting Started
Your printer has a set of information pages that you can print. These pages include configuration and font information, demonstration pages, and more.
The following Information Pages are available:
Name |
Description |
Configuration Report |
The Configuration Report provides printer information including |
|
installed options, network settings, port setup, tray information, and |
|
more. |
Billing Summary Report |
The Billing Summary Report provides information about the device |
|
and a detailed listing of the billing meters and sheet counts. |
Supplies Usage Report |
The Supplies Usage Report provides coverage information and part |
|
numbers for reordering supplies. |
PostScript Font List |
The PostScript Font List provides a printout of all PostScript fonts |
|
that are available on the printer. |
PCL Font List |
The PCL Font List provides a printout of all PCL fonts that are |
|
available on the printer. |
Demonstration Print |
Demonstration Print provides a demonstration of the current print |
|
quality. |
Startup Page |
The Startup Page provides basic printer configuration and network |
|
information. |
Job History Report |
The printer retains information on previous print jobs, including the |
|
date, time, job type, document name, output color, paper size, |
|
number of pages, and results. The status of a maximum of 20 jobs |
|
prints on the Job History Report. |
1.At the printer control panel, press the Home button.
2.Touch Device > About > Information Pages.
3.To print an information page, touch the desired page.
4.To return to the Home screen, press the Home button.
28Xerox® VersaLink® B400 Printer User Guide
Getting Started
The Configuration Report provides product information including, installed options, network settings, port setup, tray information, and more.
1.At the printer control panel, press the Home button.
2.Touch Device > About > Information Pages.
3.Touch Configuration Report.
4.To return to the Home screen, press the Home button.
Xerox® VersaLink® B400 Printer |
29 |
User Guide |
|
Getting Started
The Embedded Web Server is the administration and configuration software that is installed in the printer. It allows you to configure and administer the printer from a Web browser.
The Embedded Web Server requires:
•A TCP/IP connection between the printer and the network in Windows, Macintosh, UNIX, or Linux environments.
•TCP/IP and HTTP enabled in the printer.
•A network-connected computer with a Web browser that supports JavaScript.
At your computer, open a Web browser. In the address field, type the IP address of the printer, then press Enter or Return.
To install the print driver for a network-connected printer, you need the IP address of your printer. You also need the IP address to access the settings of your printer through the Embedded Web Server. You can view the IP address of your printer on the control panel or on the Configuration Report.
Note: Wait until the printer has been on for 2 minutes to view the TCP/IP address. If the TCP/IP address is 0.0.0.0, or begins with 169, it indicates a network connectivity issue.
To view the IP address of the printer on the control panel:
1.At the printer control panel, press the Home button.
2.Touch Device > About.
3.Record the IP address from the display.
4.To return to the Home screen, press the Home button.
To obtain the printer IP address from the Configuration Report:
1.At the printer control panel, press the Home button.
2.Touch Device > About > Information Pages.
3.Touch Configuration Report. The IP address appears in the Connectivity section of the Configuration Report for IPv4 or IPv6.
To return to the Home screen, press the Home button.
30Xerox® VersaLink® B400 Printer User Guide
