Page 1
Save these instructions for future use!
FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS
CAREFULLY BEFORE INSTALLING OR OPERATING THIS
CONTROL COULD CAUSE PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
APPLICATIONS
THERMOSTAT APPLICATION GUIDE
Description
Gas or Oil Heat Yes
Electric Furnace Yes
Heat Pump (No Aux. or Emergency Heat) Yes
Heat Pump (with Aux. or Emergency Heat) No
Systems with up to 3 Stages Heat, 2 Stages Cool No
Heat Only Systems Yes
Millivolt Heat Only Systems – Floor or Wall Furnaces Yes
Cool Only Systems Yes
Hydronic (Hot Water) Zone Heat – 2 Wires Yes
Hydronic (Hot Water) Zone Heat – 3 Wires Yes
80 Series Thermostat with80 Series Thermostat with
80 Series Thermostat with
80 Series Thermostat with80 Series Thermostat with
Automatic Heat/Cool Changeover OptionAutomatic Heat/Cool Changeover Option
Automatic Heat/Cool Changeover Option
Automatic Heat/Cool Changeover OptionAutomatic Heat/Cool Changeover Option
Single Stage or Heat Pump
Installation and Operating Instructions for Model:
Model Programming Choices
1F80-0471
1F86-0471 Non-Programmable
5/2 Day 5/1/1 Day Non-Prog rammable
1F86-0471 Thermostat
SPECIFICATIONS
Electrical Rating:
Battery Power . . . . . . . . . . . . . . . . . . . . . . . . . mV to 30 VAC, NEC Class II, 50/60 Hz or DC
Input-Hardwire . . . . . . . . . . . . . . . . . . . . . . . . 20 to 30 VAC
Terminal Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0 A per terminal, 1.5A maximum all terminals combined
Setpoint Range . . . . . . . . . . . . . . . . . . . . . . . . . . . 45° to 90°F (7° to 32°C)
Differential (Single Stage) . . . . . . . . . . . . . . . . . . . Heat 0.6°F; Cool 1.2°F (adjustable)
Differential (Heat Pump) . . . . . . . . . . . . . . . . . . . . Heat 1.2°F; Cool 1.2°F (adjustable)
Operating Ambient . . . . . . . . . . . . . . . . . . . . . . . . . 32° to +105°F (0° to +41°C)
Operating Humidity . . . . . . . . . . . . . . . . . . . . . . . . 90% non-condensing max.
Shipping Temperature Range . . . . . . . . . . . . . . . . -4° to +150°F (-20° to +65°C)
Dimensions Thermostat . . . . . . . . . . . . . . . . . . . . . 3.4"H x 4.4"W x 1.3"D
CAUTION
!
To prevent electrical shock and/or equipment damage, disconnect electric power to system at main fuse
or circuit breaker box until installation is complete.
Index Page
Installation 2
Wiring Connections 2
Thermostat Quick Reference 3
Installer Configuration Menu 4
Operating Your Thermostat 6
Programming 6
Troubleshooting 8
ATTENTION: MERCURY NOTICE
This product does not contain mercury. However, this
product may replace a product that contains mercury.
Mercury and products containing mercury must not be
discarded in household trash. Do not touch any spilled
mercury. Wearing non-absorbent gloves, clean up any
spilled mercury and place in a sealed container. For proper
disposal of a product containing mercury or a sealed
container of spilled mercury, place it in a suitable shipping
container and send it to:
White-Rodgers
2895 Harrison Street
Batesville, AR 72501
www.white-rodgers.com
PART NO. 37-6749A
0604
Page 2
INSTALLATION
WARNING
!
Thermostat installation and all components of the
control system shall conform to Class II circuits per
the NEC code.
Once fully down, snap the door back into position. To
replace the batteries, set system to OFF, following the
instructions above.
Figure 1 – Battery door shown open
Remove Old Thermostat
A standard heat/cool thermostat consists of three basic parts:
1.The cover, which may be either a snap-on or hinge type.
2.The base, which is removed by loosening all captive screws.
3.The switching subbase, which is removed by unscrewing
the mounting screws that hold it on the wall or adapter
plate. Before removing wires from old thermostat,
label each wire with the terminal designation from
which it was attached. Disconnect the wires from the old
thermostat one at a time. Do not let wires fall back into
the wall.
Installing New Thermostat
1. Pull the ther mostat body off the thermosta t base. Forcing
or prying on the ther mosta t will cause damage to the unit.
2. Place base over hole in wall and mark mounting hole
locations on wall using base as a template.
3. Move base out of the way. Drill mounting holes. If you
are using existing mounting holes and the holes drilled
are too large and do not allow you to tighten base snugly, use plastic screw anc hors to secure the base.
4. Fasten base snugly to wall using mounting holes shown
in Figure 2 and two mounting screws. Leveling is for
appearance only and will not affect thermostat operation.
5. Connect wires to ter minal bloc k on base.
6. Push excess wire into wall and plug hole with a fire re-
sistant material (such as fiberglass insulation) to prevent
drafts from affecting thermostat operation.
7. Carefully line the ther mostat up with the base and sna p
into place.
SS/HP Switch
(Conventional or Heat Pump Selection)
The SS/HP switch is factory set to the SS position. In this
position, thermostat is configured as conventional single
stage. If you have a single stage heat pump system, switch
SS/HP to HP position (see figure 2).
Electric/Gas Switch (Fan Option)
The ELEC/GAS switch is factory set to the GAS position. In
this position, the thermostat will not power the circulator fan
on a call for heat, but will power the circulator on a call for
cool.
“AA” Alkaline Batteries
Thermostat can be powered by system AC power or Battery.
If is displayed the thermostat is battery powered. If
is not displayed, thermostat is system powered with
optional battery bac k-up. When battery power remaining is
approximately half the will be displayed. If the home is
going to be unoccupied for an extended period (over 3
months ) and is displayed, the batteries should be
replaced before leaving. When Change is displayed,
install fresh “AA” alkaline batteries immedia tely. The setpoint
temperature will offset by 10 degrees (10 degrees cooler in
heat mode / 10 degrees warmer in Cool mode) when less
than two months of battery life remain. (If of fset occur s the
normal setpoint can be manually reset with
or , if
batteries are not replaced another offset will occur within two
days).
Figure 2 – Thermostat base and rear view of thermostat
Mounting
Hole
Place Level
across
Mounting Tabs
(for appearance only)
(for appearance only)
GAS
SS
ELEC
HP
Mounting
Hole
Place Level
across
Mounting Tabs
If your system requires that the thermostat power the
circulator fan on a call for heat, this switch should be set to
the ELEC position. Typically, gas and oil heating systems do
not require the thermostat to power the circulator fan during
a call for heat. If your heat is gas or oil, the switch should be
set to the GAS position.
When the thermostat is configured for Heat Pump, the
thermostat will always power the circulator fan on a call for
heat in the HEAT mode.
Batteries
2 "AA" alkaline batteries are included in the thermosta t. To
install the batteries, pull the battery door as shown by the
arrow and lift open. Using the polarity indicated inside the
battery door, insert the batteries. To close the battery door,
swing the door down while pulling in the direction of arrow.
2
2
WIRING CONNECTIONS
Refer to equipment manufacturers' instructions for specific
system wiring information. After wiring, see CONFIGURATION section for proper thermostat configuration.
TERMINAL DESIGNATION DESCRIPTIONS
Terminal
Designation Description
O/B . . . . .Changeover valve for heat pump
Y . . . . . . Compressor Relay
W . . . . . . Heat Relay
G . . . . . .Fan Relay
RH . . . . .Power for Heating
RC . . . . .Power for Cooling
C . . . . . . Common wire from secondary side of cooling
system transformer or heat only system transformer
Page 3
THERMOSTAT QUICK REFERENCE
Home Screen Description
Displays the power level of the
2 "AA" batteries:
indicates good power level.
indicates batteries at about
half power. “Change ” indicates
batteries are low and should be
replaced with 2 new “AA” Alkaline
batteries.
Figure 4 – Home Screen Display
FAN
Button
Room
Temperature
MENU/SCHEDULE/RUN
Button
SYSTEM
Indicator
SYSTEM
Button
Time
Day of Week
FAN
Indicator
Figure 5 – Programming & Configuration Items
2
1
Setting
Temperature
Temperature Up/Down
HOLD Button
8
3
9
5
Programming and Configuration Items
Flame icon ( ) is displayed when the system is in
1
HEAT mode. Snowflake icon (
system is in COOL mode.
The word HOLD is displayed when the thermostat is
2
in the HOLD mode. Temp HOLD is displayed when
the thermostat is in a Temporary HOLD mode.
Displays Change Filter when the system has run for
3
the programmed filter time period as a reminder to
change or clean your filter.
Displays "Set" for setpoint when in Run Program mode.
4
Displays System Mode (Heat, Cool, Auto, Off) or
5
Time in menu mode.
) is displayed when the
4
10
7
6
Displays Fan Mode (On, Auto) or "Run" in Menu
6
mode or "Saving" in Cool Savings
Displays "Run Schedule", "Schedule", or "Menu".
7
Displays "Save" when Cool SavingsTM is working.
8
Displays "Heat Pump" when system is configured
9
as Heat Pump thermostat.
Displays "Hold" in programmable mode when in "Hold"
10
mode. Displays Light Bulb in non-programmable
mode.
TM
Mode.
3
Page 4
INSTALLER/CONFIGURATION MENU
Press the Menu button for at least 5 seconds. The display will show item #1 in the table below. Press Menu to advance to the
next menu item. Press or to change a menu item.
INSTALLER/CONFIGURATION MENU
MENU PRESS DISPLAYED Press or to
REF. HP SS BUTTON (FACTORY DEFAULT) select from listed options COMMENTS
1 1 MENU On (Cool O) Heat b On Reversing Valve Output (Heat Pump switch S8
must be in the Heat Pump HP position)
2 2 1 MENU P (2) P 3, P 0 Selectable Programs Per Week
(For programmable thermostat only)
3 3 2 MENU Cool Saving CS (OFF) Cool Saving CS On Select Cool Savings on or off
CS (3) 6, 5, 4, 2, 1 Selects Cool Savings value 1 (low) to 6 (high)
4 4 3 MENU E (On) E OFF Selects Energy Management Recovery (EMR)
on or off
5 4 MENU CR Heat FA, SL Adjustable Anticipation (Heat) (only when
(ME) heat pump switch is at the SS position)
6 5 MENU CR Cool SL Adjustable Anticipation (Cool) (only when
(FA) heat pump switch is at the SS position)
7 5 MENU CR Heat Pump SL Adjustable Anticipation (Heat Pump) (only
(FA) when heat pump switch is at the HP position)
8 6 6 MENU CL (OFF) CL On Compressor Lockout Time
9 7 7 MENU Auto Heat Heat Cool Off, System Mode Configuration
Cool Off Heat Off with Fan icon, with Automatic Changeover
Heat Off without Fan
icon, Cool Off,
Auto Off
Cool Off Heat Heat Off with Fan icon, System Mode Configuration
Heat Off without without Automatic Changeover
Fan icon, Cool Off
10 8 8 MENU L (On) L OFF Selects Display Light on or off
11 9 9 MENU 0 HI 1 HI, 2 HI, 3HI, 4 HI, Adjustable Ambient Temperature Display
1 LO, 2 LO, 3 LO, 4 LO
12 10 10 MENU F C Selects Fahrenheit/Celcius Temperature Display
13 11 11 MENU Change Filter (OFF) Change Filter On Selects Filter Change-out Indicator
Change Filter 200 h 25 h to 1975 h in When on, selects time in 25 hour increments
25-hour increment
14 12 12 RUN Returns to Normal Operation
1) Select Reversing Valve Output (Heat Pump switch S8
must be set at HP) – The O/B option is factory set at
"O" position. This will accommodate the majority of heat
pump applications, which require the changeover relay to
be energized in COOL. If the thermostat you are replacing or the heat pump being installed with this thermostat
requires a "B" terminal, to energize the changeover relay
in HEAT, the O/B option should be set at "B" position.
2) Program Options: This control can be configured for 5/2
day or 5/1/1 day programming or non-programming mode.
The default setting is P2, indicating 5/2 day programming.
The programs per week can be toggled to P3 or P0 by
pressing the
non-programmable will eliminate the need for EMR, and
that step in the menu will be skipped.
3) Select Cool Savings™: With Cool Savings™ enabled,
the thermostat will make small adjustments to the setpoint
temperature during periods of high demand to reduce AC
or keys. A selection of 0 Days for
4
system running time and save energy. When the cooling
system has been running for more than 20 minutes,
humidity in the home will be lower and a higher setpoint
temperature will feel comfortable. After 20 minutes of run
time, the thermostat will star t increasing the setpoint
temperature in steps of less than one degree as the
system continues to run. These adjustments will eventually cause the system to satisfy the thermostat to turn the
system off and reduce the energy consumption. When
the Cool Savings™ feature is active and making adjustments, the display will show “Save” next to the setpoint
temperature. The amount of the adjustments to the
setpoint temperature is dependent on the Cool Savings™
value that is set, 1 being the least adjustment and 6 being
the most adjustment. With this feature set to OFF, no
change will occur when the AC system is continuously
running during the periods of high demand. Periods of
high demand will normally occur during the late after noon
and early evening on the hottest days of the summer.
Page 5
INSTALLER/CONFIGURATION MENU
4) Energy Management Recovery: (this step is skipped if
configured to be non-programmable).
Energy Management Recovery (E) On enables the
thermostat to start heating or cooling early to make the
building temperature reach the program setpoint at the
time you specify. Heating will start 5 minutes early for
every 1° of temperatur e required to reach setpoint.
Example: If E On is selected and have your heating programmed to 65° at night and 70° at 7 AM. If the building
temperature is 65°, the difference between 65° and 70° is
5°. Allowing 5 minutes per degree, the thermostat setpoint will change to 70° at 6:35 AM. Cooling allows more
time per degree, because it takes longer to reach set
temperature.
5, 6 & 7) Cycle Rate Selection – The factory default setting
for Heat is medium cycle (ME), which cycles heat at
approximately 0.6°F. If you prefer fast or slow cycle,
press the
will cycle at approximately 0.4 or 1.2°F. For Heat Pump
and Cool, the default setting is fast (FA CR), which cycles
heat and cool at 1.2°F. If you prefer slow cycle, press
or to change to SL. Cool or heat will cycle at
1.7°F. For Cool the default setting is fast cycle (FA CR),
which cycles cool at approximately 1.2°F.
If you prefer slow cycle, press the
change to SL, cool will cycle at approximately 1.7°F.
8) Select Compressor Lockout CL OFF or ON – Selecting
CL ON will cause the thermostat to wait 5 minutes between cooling cycles. This is intended to help protect the
compressor from short cycling. Some newer compressors already have a time delay built in and do not require
this feature. Your compr essor manufacturer can tell you if
the lockout feature is already present in their system.
When the thermostat compressor time delay occurs, it
will flash the setpoint for up to five minutes.
or key to change to FA or SL. Heat
or key to
9) System Mode Configuration – This thermostat is
configured for Heat and Cool with Auto changeover
(SYSTEM switch with Cool Off Heat Auto) default. It can
also be configured for Heat and Cool (Cool Off Heat),
Heat only with fan (Off Heat), Heat only without fan,
Auto only (Auto Off), and Cool only (Cool Off).
10)Select Backlight Display – The display backlight
improves display contrast in low lighting conditions. When
the "C" terminal is powered, selecting backlight CdL ON
will keep the light on continuously. Select backlight OFF
will keep the light on momentarily after any key is
pressed. When the "C" terminal is not powered, the light
will be on momentarily after any key is pressed no matter
whether the backlight is selected ON or OFF.
11)Select Temperature Display Adjustment 4 LO to 4 HI
Allows you to adjust the room temperature display up to
4° higher or lower. Your thermostat was accurately calibrated at the factory, but you have the option to change
the display temperature to match your previous thermostat. The current or adjusted room temperature will be
displayed on the left side of the display.
12)Select F° or C° Readout – Changes the display readout
to Centigrade or Fahrenheit as required.
13)Select Filter Replacement Run Time – The thermosta t
will display "Change Filter" after a set time of blower
operation. This is a reminder to change or clean your air
filter. This time can be set from 25 to 1975 hours in 25
hour increments. A selection of OFF will cancel this
feature. When "Change Filter" is displayed, you can
clear it by pressing Menu button. In a typical application,
200 hours of run time is a pproximately 30 days.
5
Page 6
OPERATING YOUR THERMOSTAT
Choose the Fan Setting (Auto or On)
Set the FAN Switch to Auto or On.
Fan Auto is the most commonly selected setting and runs
the fan only when the heating or cooling system is on.
Fan On runs the fan continuously for increased air circulation
or to allow additional air cleaning.
Choose the System Setting
(Heat, Off, Cool, Auto)
Press the SYSTEM button to select:
Heat: Thermostat controls only the hea ting system.
Off: Heating and Cooling systems are off.
Cool: Thermostat controls only the cooling system.
Auto: Auto Changeover is used in areas where both heating
and cooling may be required on the same day. AUTO allows
the thermostat to automa tically select heating or cooling
depending on the indoor temperature and the selected heat
and cool temperatures. When using AUTO, be sure to set the
Cooling temperatures more than 1° Fahrenheit higher than
the heating temperature.
Manual Operation for Non-Programmable
Thermostats (1F86 or 1F80)
Press the SYSTEM button to select Heat or Cool and use
the
desired setting. After selecting your desired settings you can
also press the SYSTEM button to select AUTO to allow
the thermostat to automatically change between Heat and
Cool.
or buttons to adjust the temperature to your
IMPORTANT!
Manual Operation (Bypassing the Program)
Programmable Thermostats
Press or and the HOLD button and adjust the
temperature wherever you like. This will override the program. The HOLD feature bypasses the program and allows
you to adjust the temperature manually, as needed. Whatever temperature you set in HOLD will be maintained 24
hours a day, until you manually change the temperature or
press Run Schedule to cancel HOLD and resume the
programmed schedule.
Program Override (Temporary Override)
Press or buttons to adjust the temperature. This will
override the temperature setting until the next programmed
time. To cancel the temporary setting a t any time and return
to the program, press Run Schedule. If the SYSTEM button
is pressed to select AUTO the thermostat will change to Heat
or Cool, whichever ran last. If it switches to heat but you want
cool, or it changes to cool but you want heat, press both
and buttons simultaneously to change to the other
mode.
PROGRAMMING (For Programmable Model Only)
Set Current Time and Day
1) Press Menu and then Time button once. The display
will show the hour only.
2) Press and hold either the
the correct hour and AM/PM designation (AM begins a t
midnight, PM begins at noon).
3) Press Time once again. The display window will show
the minutes only.
4) Press and hold either the
the correct minutes.
5) Press Time once again. The display will show the day
of the week.
6) Press the
of the week.
7) Press Run to exit the Time mode.
or key until you reach the current day
or key until you reach
or key until you reach
Enter the Heating Program
1) Press SYSTEM button to select "Heat" in the system
switch area indicating the active mode being programmed.
2) Press the Menu button for at least 5 seconds and then
press Schedule.
3) The top of the display will show the day(s) being programmed. The time and temperature (flashing) are also
displayed. "1" will also be displayed to indicate
the period.
4) Press
selected temperature for the 1st heating period.
5) Press Time button, time will flash.
6) Press
1st period.
7) The time will change in 15 minute increments.
8) After you have set the time and the temperature for
the period to begin, press Schedule to advance to the
next program period.
9) Repeat steps 2 through 8 until all of the pro g ram times
and temperatures are set for all program periods on
that day.
10)Press Schedule to the next day and repeat steps 2
through 9.
11)When prog ramming is complete and all of the times and
temperatures match your desired heating schedule, press
Run Schedule. The thermostat will now run your program.
or key to change the temperature to your
or key to adjust the start time for the
Enter the Cooling Program
1) Press SYSTEM button to select "Cool" in the system
switch area indicating the active mode being programmed.
2) Follow Enter Heating Program instructions for entering
cooling times and temperatures.
Page 7
PROGRAMMING (For Programmable Model Only)
Energy Saving Factory Pre-Program
The 1F80-0471 thermostats are prog rammed with the energy saving settings shown in the table below for all days of the
week. If this pro g ram suits your needs, simply set the thermostat c lock and press the RUN button.
The table below shows the factory set heating and cooling sc hedule for all days of the week.
Wake Up Leave For Work Return Home Go To Bed
(Period 1) (Period 2) (Period 3) (Period 4)
Heating
Program
Cooling
Program
Planning Your Program – Important
The Heating and Cooling Program schedules below allow you to pencil in your own program times and temperatures.
The 1F80-0471 comes configured for 5/2 day programming and can also be configured for 5+1+1 programming (see configuration section).
Factory settings are listed on Monday through Friday, Saturday and Sunday. If you are re-programming a 5/2 day schedule,
pencil in your own times and temperatures directly below the factory times and temperatures.
If you are re-programming a 5+1+1 fill in all lines with the times and temperatures you want.
Keep the following guidelines in mind when planning your program.
• In Heating, lower temperatures will save energy.
• In Cooling, higher temperatures will save energy.
• If you plan on using Auto Changeover, do not program the heating higher than the cooling.
6:00 AM 70°F 8:00 AM 62°F 5:00 PM 70°F 10:00 PM 62°F
6:00 AM 75°F 8:00 AM 83°F 5:00 PM 75°F 10:00 PM 78°F
Worksheet for Re-Programming 5/2 Day and 5+1+1 Day Program
Heating
Program
Mo-Fr
Sat-Sun
or Sat
Sun
5+1+1
Cooling
Program
Mo-Fr
Sat-Sun
or Sat
Sun
5+1+1
only
only
Wake Up Leave For Work Return Home Go To Bed
(Period 1) (Period 2) (Period 3) (Period 4)
6:00 AM 70°F 8:00 AM 62°F 5:00 PM 70°F 10:00 PM 62°F
6:00 AM 70°F 8:00 AM 62°F 5:00 PM 70°F 10:00 PM 62°F
6:00 AM 70°F 8:00 AM 62°F 5:00 PM 70°F 10:00 PM 62°F
Wake Up Leave For Work Return Home Go To Bed
(Period 1) (Period 2) (Period 3) (Period 4)
6:00 AM 75°F 8:00 AM 83°F 5:00 PM 75°F 10:00 PM 83°F
6:00 AM 75°F 8:00 AM 83°F 5:00 PM 75°F 10:00 PM 83°F
6:00 AM 75°F 8:00 AM 83°F 5:00 PM 75°F 10:00 PM 83°F
Page 8
TROUBLESHOOTING
Reset Operation
Note: When thermostat is reset, installer configuration menu settings and programming will reset to factory settings.
If a voltage spike or static discharge blanks out the display or causes erratic thermostat operation, you can reset the thermostat by removing
the wires from terminals R and C (do not short them together) and removing batteries for 2 minutes. After resetting the thermostat, replace
the wires and batteries. If the thermostat has been reset and still does not function correctly contact your heating/cooling service person or
place of purchase.
Note: Be sure to review the installer configuration menu settings.
To reset the programming, clock and configuration settings, press and and the FAN button simultaneously. The thermostat should
go blank and then all segments will be displayed momentarily.
Symptom
No Heat/No Cool/No Fan
(common problems)
Possible Cause
1. Blown fuse or tripped circuit breaker.
2. Furnace power switch to OFF.
3. Furnace blower compartment door or
panel loose or not properly installed.
4. Loose connection to thermostat or system.
Corrective Action
Replace fuse or reset breaker.
Turn switch to ON.
Replace door panel in proper position to engage safety
interlock or door switch.
Tighten connections.
No Heat
No Cool
Heat, Cool or Fan
Runs Constantly
1. Pilot light not lit.
2. Furnace Lock-Out Condition. Heat
may also be intermittent.
3. Heating system requires service or
thermostat requires replacement.
1. Cooling system requires service or
thermostat requires replacement.
1. Possible short in wiring.
2. Possible short in thermostat.
3. Possible short in heat/cool/fan system.
4. FAN Switch set to Fan ON.
Re-light pilot.
Many furnaces have safety devices that shut down when a
lock-out condition occurs. If the heat works intermittently
contact the furnace manufacturer or local HVAC service
person for assistance.
Diagnostic: Set SYSTEM Switch to HEAT and raise the
setpoint above room temperature. Within a few seconds
the thermostat should make a soft click sound. This sound
usually indicates the thermostat is operating properly. If
the thermostat does not click, try the reset operation listed
above. If the thermostat does not click after being reset
contact your heating and cooling service person or place
of purchase for a replacement. If the thermostat clicks,
contact the furnace manufacturer or a HVAC service
person to verify the heating is operating correctly.
Same as diagnostic for No Heat condition except set the
thermostat to COOL and lower the setpoint below the
room temperature. There may be up to a five minute delay
before the thermostat clicks in Cooling.
Check each wire connection to verify they are not shorted
or touching together. No bare wire should stick out from
under terminal block. Try resetting the thermostat as
described above. If the condition persists the manufacturer
of your system or service person can instruct you on how
to test the Heat/Cool system for correct operation. If the
system operates correctly, replace the thermostat.
Thermostat Setting &
Thermostat Thermometer
Disagree
Furnace (Air Conditioner)
Cycles Too Fast or Too Slow
(narrow or wide
temperature swing)
White-Rodgers is a division
of Emerson Electric Co.
The Emerson logo is a
trademark and service mark
of Emerson Electric Co.
1. Thermostat thermometer setting
requires adjustment.
1. The location of the thermostat and/or
the size of the Heating System may
be influencing the cycle rate.
The thermometer can be adjusted +/- 4 degrees. See
Temperature Display Adjustment in the Configuration
Menu section.
Digital thermostats provide precise control and cycle faster
than older mechanical models. The system turns on and
off more frequently but runs for a shorter time so there is
no increase in energy use. If you would like an increased
cycle time, choose SL for slow cycle in the Configuration
menu, step 6 (heat), 7 (cool) or 8 (heat pump). If an
acceptable cycle rate is not achieved, contact a local
HVAC service person for additional suggestions.
HOMEOWNER HELP LINE: 1-800-284-2925
St. Louis, Missouri
www.white-rodgers.comwww.white-rodgers.com
www.white-rodgers.com
www.white-rodgers.comwww.white-rodgers.com
Loading...
