Whirlpool AWF 505/IG (EE) INSTRUCTION FOR USE

AWF 505

GB PRIOR TO THE FIRST USE OF THE WASHING MACHINE

1. Removal of the transport bracket

The washing unit is firmly connected with the cabinet during the transport. Prior to switching the washing

machine on, it is necessary to remove the packaging and all polystyrene plinths as well as the transport bracket

from the back of the washing machine (see the chapter How to remove the transport bracket).

There is a danger of serious damages to the washing machine if is used without removing the transport

bracket.

2. First washing cycle

Before washing clothes for the first time, it is recommended to run one cycle without laundry to clean the inside

of the drum from dust and dirt.

1. Select a 60°C colour programme

2. Fill the detergent dispenser II with a small amount of detergent.

3. Start the washing machine by switching the ON / OFF button.

Before connecting the washing machine read this manual carefully

2

TABLE OF CONTENTS

THE WASHING MACHINE PAGE 4

CONTROL PANEL PAGE 4

BEFORE USING THE WASHING MACHINE PAGE 5

ADVICE AND PRECAUTIONS PAGE 6

LOADING THE LAUNDRY PAGE 6

FILLING DETERGENT AND ADDITIVES IN THE DISPENSER PAGE 7

OPERATING THE WASHING MACHINE PAGE 8

INFORMATION ABOUT THE WASHING MACHINE FUNCTIONS PAGE 9

INTERRUPTING THE PROGRAMME PAGE 9

SELECTING THE WASHING PROGRAMMES PAGE 10

MAINTENANCE THE WASHING MACHINE PAGE 11/12

TROUBLE - SHOOTING GUIDE PAGE 13

AFTER-SALES SERVICE PAGE 13

HOW TO REMOVE THE TRANSPORT BRACKET PAGE 14

INSTALLATION PAGE 14

WATER CONNECTION PAGE 14

WATER DRAIN PAGE 15

ELECTRICAL CONNECTION PAGE 15

3

THE WASHING MACHINE

1

1. Lid

2. Inner door

3. Detergent dispenser

4. Drum flaps

5. Drain pump

6. Plinth

3

4

5

6

THE CONTROL PANEL

2

12 3

1. Programme selector knob

Turn this knob clockwise to select the wash pro-

grammes (turning it anti-clockwise can cause timer

damage).

2. Half load button

By pressing this button the amount of water entering

the washing machine is decreased. As a result the

consumption of water , electricity and detergents is

4

also decreased. It is used for washing small

amounts of laundry - about half of the normally

recommended load.

Note: When using the half load option, you must

decrease the amount of detergent.

3. ON/OFF button

Press this button to start the programme. To stop

the machine press it again.

BEFORE USING THE WASHING MACHINE

1. Unpack the washing machine according to the

drawing on the top package. When taking out

polystyrene plinth from under the appliance, be

sure to also remove the black plastic cone that

fixes the washing machine.

Packaging (plastic bags, polystyrene parts, etc.:)

must be stored out of the reach of children as it is

potentially hazardous.

2. The package is recyclable and is marked with the

recycling symbol .

3. The appliance is built with re-usable material.

When scrapping, follow the local environmental-

protection regulations. To render the washing

machine inoperative, cut the power cable off and

offer the washing machine to scrap.

4. After unwrapping check that the washing machine

is not damaged and that the lid and the door close

perfectly.

5. Only use the washing machine for washing

laundry. If you use it for other purposes, the

warranty conditions stated in guaranty booklet are

void.

6. The installation of washing machine must be carry

out according to this manual.

Electrical safety of washing machine is guaranteed

only if it is connected correctly with earth , in

compliance with state safety regulations.

In case of doubt have the electrical installation

checked or carried out by a qualified technician.

Transportation

1. Close the water tap and disconnect the inlet hose.

2. Disconnect the electrical plug.

3. Drain away any residual water by opening the

pump filter.

4. Transport the washing machine upright.

5
