Welch Allyn Connex and Acuity Network Installation Best Practices Installation Guide

Welch Allyn Acuity
Network installation

Best practices

ii Welch Allyn Network installation

© 2014 Welch Allyn. All rights are reserved. To support the intended use of the product described in this publication, the purchaser of
the product is permitted to copy this publication, for internal distribution only, from the media provided by Welch Allyn. No other use,
reproduction, or distribution of this publication, or any part of it, is permitted without written permission from Welch Allyn

Welch Allyn assumes no responsibility for any injury to anyone, or for any illegal or improper use of the product, that may result from
failure to use this product in accordance with the instructions, cautions, warnings, or statement of intended use published in this
manual.

For patent information, please visit www.welchallyn.com/patents.

For information about any Welch Allyn product, or to contact your nearest Welch Allyn representative, go to

http://www.welchallyn.com/en/about-us/locations.html.

Manual DIR 80017361 Ver J

Welch Allyn, Inc.
4341 State Street Road
Skaneateles Falls, NY 13153 USA

www.welchallyn.com

Contents

1 - Introduction .............................................1

2 - Acuity ..................................................3

iii

Welch Allyn Acuity overview ........................................1

Implementation...................................................3

Best practices ....................................................3

LAN/WLAN requirements .......................................4

Aruba LAN/WLAN requirements ..................................5

Cisco LAN/WLAN requirements ..................................7

WLAN Controller requirements ...................................9

Aruba controller requirements ...................................10

Cisco controller requirements ...................................12

Validation ......................................................14

iv Contents Welch Allyn Network installation

1

Introduction

Welch Allyn Acuity overview

Welch Allyn connected workstations, servers and patient monitors utilize standards based
communications protocols including, but not limited to, 802.3 for wired Ethernet and

802.11a/b/g for wireless. This guide specifies the requirements and recommendations
needed to successfully complete and maintain a Welch Allyn patient monitoring system in
your wireless or wired network.

Implementation and maintenance of a stable and usable integrated network is the sole
responsibility of the customer.

Although ultimately your responsibility, Welch Allyn recommends that you conduct a
hazards analysis per IEC 80001 to determine if any issues exist that should be mitigated
to ensure your patients safety.

2 Introduction Welch Allyn Network installation
