VTech LS6245 User Manual

User’s manual

w w w.v t e c h p h o n e s . c o m

Model: LS6245

Congratulations

on purchasing your new VTech product. Before using this telephone, please read the Important safety instructions on page 90 of this manual.

This manual has all the feature operations and troubleshooting necessary to install and operate your new VTech telephone. Please review this manual thoroughly to ensure proper installation and operation of this innovative and feature rich VTech product. For support, shopping, and everything new at VTech, visit our website at www.vtechphones.com.

The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR® label indicating it

meets the latest energy efciency guidelines.

The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by VTech Holdings Limited is under license. VTech Holdings Limited is a member of Bluetooth SIG, Inc. Other trademarks and trade names are those of their respective owners.

Table of contents

Getting started .........................1

Parts checklist ............................1

Important notes ..........................2

Installation ..................................2

Cleaning tips for your touch

screen telephone ....................2

Telephone base installation .......3

Battery installation .....................4

Battery charging .........................5

Handset layout ...........................6

Telephone base layout ...............7

Handset main menu ...................9

Telephone base main menu .......10

BLUETOOTH® ...........................11

Introducing Bluetooth .................11

Glossary of terms ......................12

Bluetooth at a glance .................13

Bluetooth setup ..........................14

Setup cell ....................................14

Setup headset ............................15

Paired devices ............................16

Rename a paired device ............16

Remove a paired device ............17

View information of a

paired device...........................17

Active devices ............................18

Review the active devices list ....18

Connect/disconnect an

active device ...........................18

Replace an active device ...........19

Add an active device ..................19

Remove an active device ...........20

View information of an

active device ...........................20

Change PIN ................................20

Handset settings ......................21

Settings ......................................21

LCD language ............................21

Clear voicemail ...........................22

Auto keylock ...............................23

Key tone .....................................23

Set date/time ..............................24

Home area code .........................25

Ringers .......................................26

Ringer volume ............................26

Ringer tone .................................27

Telephone base settings .........28

Settings ......................................28

Set date/time ..............................28

Key tone .....................................28

LCD language ............................29

Clear voicemail ...........................30

Home area code .........................31

Ringers .......................................32

Ringer volume ............................32

Ringer tone .................................33

Answering system settings ....34

Answering system setup ............34

Answer ON/OFF .........................34

Call screening ............................35

Announcement ...........................36

Play your announcement ...........36

Record your

own announcement ...............37

Delete your announcement ........38

Number of rings ..........................39

Remote access code .................40

Message alert tone.....................41

Telephone operation ................42

Make, answer or end a

home call ................................42

Call waiting on the home line .....43

Make, answer or end a

cell call ...................................44

Call waiting on the cell line .........45

Answer a cell call while on a

home call .................................45

Answer a home call while on a

cell call ....................................46

Conference home and

cell calls ..................................46

Handset speakerphone ..............47

Table of contents

Volume control ...........................47

Silence the ringer .......................47

Mute ...........................................47

Infrared sensor ...........................48

Hold ............................................48

Handset locator ..........................48

Chain dialing...............................49

Redial list ....................................50

Review the redial list ..................50

Dial a redial entry .......................50

Save a redial entry to

the directory ............................50

Delete a redial entry ...................51

Intercom .....................................52

Answer an incoming call

during an intercom call ............53

Share an outside call ..................54

Transfer a call .............................54

Directory .....................................55

Create a new directory entry ......55

Character chart ..........................57

Review the directory...................58

Alphabetical search ....................58

Dial a directory entry ..................59

Edit a directory entry ..................59

Delete a directory entry ..............60

About caller ID ............................61

Caller ID history ..........................62

Missed calls indicator ................62

Memory match ..........................63

Review the call log ....................63

Make a call log entry ready

to dial ......................................64

Dial a call log entry ....................64

Save a call log entry to

the directory ............................65

Delete from the call log ..............66

Call log display

screen messages ....................66

Message capacity ......................67

New message indication ............67

Call intercept ..............................67

Message playback .....................68

Delete all old messages .............69

Record and play memos ............70

Remote access ..........................71

Appendix ...................................72

Screen display messages ..........72

Handset and telephone

base indicators ........................74

Battery ........................................77

Expand your telephone system ..78

Add and register a handset ........78

Replace a handset .....................79

Troubleshooting ..........................80

Important safety instructions ......90

Operating range .........................91

Maintenance ...............................91

About cordless telephones.........92

The RBRC® seal .........................92

Warranty .....................................93

FCC, ACTA and IC regulations ..95

Technical specications .............97

Index ..........................................98

Answering system operation ..67

Answering system

and voicemail ..........................67

Getting started

Parts checklist

Your telephone contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.

Tele phone line cord

Batte ry Quick star t guide

Tele phone base power adapter

HandsetTele phone base

User’s manu al

Clean ing cloth

Batte ry compartme nt cover

To purchase a replacement battery or power adapter, visit our website at www.vtechphones.com or call 1 (800) 595-9511.

Getting started

Important notes

Auto keylock: To prevent accidental key presses, the

handset keys automatically lock after 10 seconds without presses. Press the UNLOCK softkey to unlock the keypad (see page 23).

Dialing 911: You must unlock the keypad before you can dial 911 or any other number on the handset.

When the handset is idle, the backlight is off. You must rst touch the touch

panel in order to take the handset or telephone base out of idle mode before using it with the exception of the UNLOCK softkey. This rst touch is not an operational keystroke.

Installation

Install the telephone base close to a telephone jack and a power outlet not connected to a wall switch. For optimum range and better reception, place the telephone base in a central and open location.

This product may be shipped with a protective sticker covering the handset and/or telephone base display. Remove it before use.

Avoid placing the telephone base too close to:

Communication devices such as: personal computers, computer routers,

• television sets, VCRs, wireless routers (wireless broadband, Wi-Fi, or

802.11) or other cordless telephones. Excessive heat sources.

•

Noise sources such as a window with trafc outside, motors, microwave

•

ovens, refrigerators, or uorescent lighting.

Excessive dust sources such as a workshop or garage.

• Excessive moisture.

• Extremely low temperature.

• Mechanical vibration or shock such as on top of a washing machine or

• work bench.

HANDSET X

On

Press U NLOCK

to use keys

UNLOCK

Cleaning tips for your touch screen telephone

Use the cleaning cloth provided to clean your telephone. Clean your telephone only with a dry non-abrasive cloth. Using a dampened cloth or cleaning solvents of any kind may activate the keys on the telephone.

If you unplug the telephone before cleaning, remember to reset the clock when done.

Getting started

Telephone base installation

Install the telephone base as shown below. The telephone base is designed for tabletop use only.

Make sure that the electrical outlet is not controlled by a wall switch. If you subscribe to digital subscriber line (DSL) high-speed Internet service

through your telephone line, you must install a DSL lter between the

telephone line cord and the telephone wall jack. The lter prevents noise and

caller ID problems caused by DSL interference. Contact your DSL service

provider for more information about DSL lters.

Elect ri cal outlet not controlled by a wall switch

Tele phone base power adapter

Tele phone base

Use only the power adapter supplied with this product. To order a

• replacement, visit our website at www.vtechphones.com or call 1 (800) 595-9511.

The power adapter is intended to be correctly oriented in a vertical or

•

oor mount position. The prongs are not designed to hold the plug in place if

it is plugged into a ceiling, under-the-table or cabinet outlet.

Tele phone wa ll jack

DSL filt er (not include d) is required if you have DSL high speed Interne t service

Tele phone line cord

Getting started

Battery installation

Install the battery as shown below.

If the battery compartment cover is on the handset, press on the triangle

1. and slide the cover to remove.

Plug the battery connector securely into the socket inside the handset

2. battery compartment, matching the color-coded label.

Place the battery with the label THIS SIDE UP facing up and the wires

3. inside the battery compartment.

Align the cover at against the battery compartment, then slide it towards

4. the center of the handset until it clicks into place.

Charge the handset by placing it in the telephone base. The CHARGE

5. light is on when the handset charges.

If the handset will not be used for a long time, disconnect and remove the

• battery to prevent possible leakage.

To purchase a replacement battery, visit our website at

• www.vtechphones.com or call 1 (800) 595-9511.

CHARGE light

Getting started

Battery charging

Once you have installed the battery, the screen indicates the battery status (see the table below). If necessary, place the handset in the telephone base to charge the battery. For best performance, keep the handset in the telephone base when not in use. The battery is fully charged after 16 hours of continuous charging. See the table on page 77 for battery operating times.

If the screen is blank, you need to charge the handset without interruption for at least 10 minutes to give the handset enough charge to use the telephone for a short time. The handset beeps and shows Low battery. If you are on a call in low battery mode, the handset beeps every minute.

The following table summarizes the battery charge indicators and actions to take.

Battery indicators Battery status Action

The screen is blank. Battery has no charge

The screen shows Place in charger and

ashes.

The screen shows Low battery,

ashes, and the

handset beeps.

The screen shows HANDSET X.

and the handset cannot be used.

Battery has very little charge and the handset cannot be used.

Battery has enough charge to be used for a short time.

Battery is charged. To keep the battery charged,

Charge without interruption until the screen shows HANDSET X (at least 10 minutes).

Charge without interruption until the screen shows HANDSET X (at least four minutes).

Charge without interruption until the screen shows HANDSET X (at least 30 minutes).

place it in the telephone base when not in use.

Getting started

Handset layout

Softkeys (2)

Pre ss to se lect a menu i tem displayed above the key.

/VOL+/

While in a menu, pr ess to scroll up.

Durin g a call , p ress to increase t he listening volume (page 47).

When the hand set i s n ot in use, pre ss to enter the direc tory (p age 58).

/H OM E/FLASH

Pre ss to ma ke or answer a home call (pa ge 42).

Flash es quickly when ther e is an in coming hom e cal l.

Flash es sl owly when a home call is on hold.

Durin g a home call, p ress to receive an in co ming call when you re ce ive a call waiting alert (pag e 43).

While reviewi ng a cal l log entry, pres s rep eatedly to add or remove 1 i n front of the teleph one number before d ialin g or saving it in the direct or y (page 64).

Pre ss then the LOC K softkey to activate the keypad lock manua lly (page 23).

Pre ss to ma ke or answer a home call (pa ge 42).

Durin g a call , p ress to switc h between sp eaker phone and handset (page 47).

HOLD

Pre ss to pu t a call on hold (page 48).

Infrared senso r

When the infr ared sensor i s covered durin g a call , a ll key s on the d ial pad are disa bled (page 48).

CI D/ VO L- /

When the hand set i s n ot in use, press to revie w t he ca ll log (pag e 63).

Durin g a call , p ress to decreas e t he li stening volume ( page 47).

While in a menu, pr ess to scroll dow n.

OFF/CLEAR

Durin g a call , p ress to hang up (page 42).

While the han dset is ringing , press to silence t he ringer tempo rarily (page 47).

Pre ss an d hol d w hile the telep hone is not in use to erase the mis sed c alls indicator (page 62).

While in a menu, pr ess to exi t wit hout makin g changes, o r p ress and hold to return to i dle m ode.

While enterin g or edi ting a d irector y entry, pres s t o erase a digit or char acter.

Pre ss re peatedly to show other di aling opti ons w hen reviewing a call log entry (page 64).

/CELL

Pre ss to ma ke or answer a cell call (page 44).

Flash es quickly when ther e is an in coming cell cal l.

Flash es sl owly when a cell

CHARGE light On when the handset i s cha rging

in the teleph one base.

call is on hold.

Getting started

Telephone base layout

While reviewi ng a cal l log entry, pres s rep eatedly to add or remove 1 i n front of the tele phone number be fore diali ng or saving it in the direc tory (p age 6 4).

/H OM E

Pre ss to ma ke or answer a h ome c all (pag e 42).

Flash es quickly when there is an incomi ng home call.

Flash es sl owly when a home call is on hold.

HOLD

Pre ss to pu t a call on hold (page 4 8).

Pre ss re peatedly to show other diali ng options when reviewing a call log entr y (page 64).

/CELL

Pre ss to ma ke or answer a ce ll call (page 44).

Flash es quickly when ther e i s an incomin g c ell c all.

Flash es sl owly when a cell call is on hold.

Getting started

Telephone base layout

Telephone base layout (continued)

/VOL

While in a menu, pr ess to s croll up. Durin g a call , p ress to increase t he

listening vol ume (pag e 47).

Softkeys (2)

Pre ss to se lect a menu i tem displayed above the key.

FL ASH/ X

Durin g a home call, press to rece ive an incomin g c all w hen you receive a ca ll waiting alert (pag e 43).

Pre ss to de lete the message cu rrent ly playing (page 68).

CANCEL /

While the tel ephone is ringi ng, press to sil ence the ringer te mporarily (page 47).

Pre ss an d hol d w hile the tele phone is not in use to erase the mis sed c alls indicator (page 62).

While in a menu, pr ess to exit with out making cha nges or press and hold to return to idle mode.

Pre ss to re peat a messag e or press tw ic e t o play the pr eviou s mes sage (page 68).

VOL-/

While in a menu, pr ess to scroll dow n.

Durin g a call , p ress to decreas e t he li stening volume ( page 47).

Pre ss to pl ay messages (page 68).

Pre ss to stop message playback (pag e 68).

Pre ss to sk ip to th e next m essage (page 68).

Getting started

BACK SELECT

ANS. SYSTEM

BACK SELECT

Directory

Call log

SELECT

Page all HS - pa ge the system handset(s).

Directory Call log

Page all HS

SELECT

Bluetoo th - set up and man age your Bluetooth dev ic es.

Page all HS Intercom

Bluet ooth

SELECT

Sett ings - c hange your telepho ne base set ti ngs.

Intercom Bluet ooth

Ringers

SELECT

Bluet ooth Ringers

Settings

SELECT

Bluetooth

Introducing Bluetooth

Your new LS6245 telephone system with Bluetooth wireless technology has the following features:

Pair up to four Bluetooth enabled cell phones with the telephone base.

• Connect a maximum of two cell phones to make and receive cell calls.

• Only one cell phone can be active on a call at a time.

Connect a Bluetooth enabled headset for making and receiving home calls.

• Conference cell and home calls.

• Make and receive calls using your cell phone plan while utilizing the ease

• and comfort of your home telephone system.

IMPORTANT INFORMATION

After plugging in the telephone base, wait at least 20 seconds before

• connecting a Bluetooth device. The screen shows Bluetooth system busy if you try to connect too soon.

Refer to the user's manual of your cell phone or headset for more

• information about its Bluetooth function.

Bluetooth wireless technology operates within a short range (about

• 30 feet). When using a cell phone with the LS6245, it is best to place

your cell phone between one and fteen feet from the telephone base.

When using a Bluetooth headset with the LS6245, you are limited to the range of your headset (see the user’s manual of your headset for more information).

Make sure that your cell phone has sufcient signal strength. You may

• need to move the cell phone and telephone base to a location where the cell phone signal strength is stronger.

Charge your Bluetooth cell phone while it is connected to the telephone

• base. Your cell phone's battery discharges faster while it is connected to the telephone base via Bluetooth wireless technology.

Monitor your cell phone's usage because airtime is deducted from your

• cellular plan for the duration of all cell calls.

Refer to the Bluetooth setup section (page 14) to learn how to set up and manage your Bluetooth device(s). Refer to the Telephone operation section (page 42) on how to operate your Bluetooth devices with your new

LS6245 telephone system with Bluetooth wireless technology. Refer to the Troubleshooting section (page 80) if you experience difculty using the

telephone system.

Bluetooth

Glossary of terms

Below are some terms used in this user’s manual to help you become familiar with using your Bluetooth devices and your new LS6245 telephone system.

Active devices - A maximum of two paired devices (two cell phones, or one cell phone and one headset) on the active devices list can be connected to the telephone base, but only one cell phone or headset can be on a call at a time.

Bluetooth cell phone - Refers to a Bluetooth enabled cell telephone.

Cell line - The communication service provided through your Bluetooth

enabled cell telephone.

Connected - A Bluetooth device (cell phone or headset) can only be used when it is connected to the telephone base. When a Bluetooth device is connected to the telephone base and active on the active devices list, it is ready for use.

Disconnected - A diagonal line appears across devices 1 and/or 2 when the corresponding Bluetooth device is disconnected from the telephone base.

Discoverable mode - Before a Bluetooth device can be paired, it must be set in this mode. When pairing your cell phone, the telephone base is set in this mode. When pairing a headset, the headset must be set in this mode. Depending on the manufacturer, this mode is sometimes referred to as

Find Me or Visibility.

Home line - Your conventional telephone land line.

Paired devices - Once Bluetooth devices have been paired with the

telephone base, they appear on the paired devices list. A maximum of four devices can be paired with the telephone base, but only two can be on the active devices list.

Pairing - This refers to the process of Bluetooth devices registering device information with each other. The telephone base must be paired with a Bluetooth enabled cell phone or headset before the Bluetooth device can be used. Depending on the manufacturer, this is also referred to as Bonding.

PIN - By default, the PIN is 0000 for the telephone base and for most Bluetooth devices. PIN information must be exchanged between Bluetooth devices before they can be used. This is also known as a Passkey or Passcode.

Bluetooth

Bluetooth at a glance

The telephone base allows you to pair up to four Bluetooth devices. You can have a maximum of two paired devices connected at any time (two cell phones, or one cell phone and one headset), but only one cell phone or headset can be on a call at a time.

Once you have paired a device with the telephone base, the pairing information is stored on the paired devices list (page 16). To use a paired device, it must be connected and on the active devices list (page 18).

IMPORTANT INFORMATION

Once you have paired a device with the telephone base, you do not have

• to repeat the pairing procedure again, unless you delete the device from the paired devices list (page 16).

When adding, removing, or replacing a Bluetooth device on the active

• devices list, all connected devices are temporarily disconnected until the procedure is complete. It may take up to two minutes to reconnect.

Bluetooth

Bluetooth setup

To use a Bluetooth enabled cell phone or headset with your LS6245, you

must rst pair and connect your Bluetooth device(s) with the telephone base.

Setup cell

Before you begin, make sure that your Bluetooth enabled cell phone is not connected to any other Bluetooth device. Refer to your cell phone user's manual to learn how to search for or add new Bluetooth devices.

To pair and connect a cell phone:

Press the MENU softkey on the telephone base

1. when it is not in use.

Press /VOL+ or VOL-/ to highlight Bluetooth, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Setup cell, then

3. press the SELECT softkey.

If a device is already connected to the telephone

• base, Connected devs will be temp. disconnected displays. Press the OK softkey to temporarily disconnect the device and continue the pairing process.

Press the NEXT softkey to set the telephone base to

4. discoverable mode.

Turn on the Bluetooth feature of your cell phone and

5. search for or add new devices.

Once your cell phone nds VTech LS6245, select it.

6. Enter the PIN of the telephone base (the default

7. PIN is 0000) into your cell phone to continue the pairing process.

When a device is successfully connected,

8. Device connected to base, and 1 and/or 2 displays.

When you already have two devices on the

• active devices list, press the YES softkey to connect to your paired cell phone. You are prompted to replace an existing device on the active devices list (page 18).

The pairing process may take up to one minute. If the pairing process fails, try again.

Page all HS Intercom

Bluet ooth

SELECT

Setup c ell

Setup h eadset Active d evices

SELECT

Pls set your cell to search for devices

LS6245

discoverable

PIN:0000

Pairing

complete

Device

connected

to base

Bluetooth

Setup headset

Before you begin, make sure that your Bluetooth enabled headset is not connected to any other Bluetooth device. Refer to your headset user's manual to learn how to search for or add new Bluetooth devices.

To pair and connect a headset:

Press the MENU softkey on the telephone base when

1. it is not in use.

Press /VOL+ or VOL-/ to highlight Bluetooth, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Setup headset,

3. then press the SELECT softkey.

If a device is already connected to the telephone

• base, Connected devs will be temp. disconnected displays. Press the OK softkey to temporarily disconnect the device and continue the pairing process.

Set your headset to discoverable mode.

4. Press the NEXT softkey on the telephone base to

5. search for your headset.

Once the telephone base nds your headset, press

6. the SELECT softkey.

Enter the PIN of your headset (the PIN for most

7. Bluetooth devices is 0000), then press the NEXT softkey. The screen displays Headset setup complete and then Connect headset to base?

Press the YES softkey. When a device is successfully

8. connected, Device connected to base, and 1 and/or 2 displays.

When you already have two devices on the

• active devices list, press the YES softkey to connect to your paired headset. You are prompted to replace an existing device on the active devices list (page 18).

The pairing process may take up to one minute. If the pairing process fails, try again.

Page all HS Intercom

Bluet ooth

SELECT

Setup c ell

Setup h eadset

Active d evices

Pls set headset to discoverable mode

SELECT HEADSET

Mary’s Headset

----

Heads et setup

Connect headset to base?

YES

SELECT

Searc hing

for headset

SELECT

ENTER PIN

complete

Device

connected

to base

Bluetooth

Paired devices

All paired devices are stored on the paired devices list. Up to four devices (one headset only) can be paired with the telephone base.

To use a paired device, it must be connected and on the active devices list (page 18).

Only the rst 15 characters of the device name are shown on the paired devices list.

Rename a paired device

You can change the name of a paired device on the paired devices list.

Press the MENU softkey on the telephone base

1. when it is not in use.

Press /VOL+ or VOL-/ to highlight Bluetooth, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Paired devices,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight a selected item,

4. then press the OPTION softkey.

Press /VOL+ or VOL-/ to highlight Rename, then

5. press the SELECT softkey. The screen displays ENTER NEW NAME.

Use the dialing keys to edit the name (see step 6 of

6. Edit a directory entry on page 60).

Press the SAVE softkey to conrm.

7. Press and hold CANCEL/ to return to the

8. idle display.

Page all HS Intercom

Bluet ooth

SELECT

Setup h eadset Active d evices

Paired devices

SELECT

PAIRED DEVICES Mary’s Cell

John’s Headset

INFO

Disconnect

Renam e

Remove paired

OPTION

SELECT

ENTER N EW NAME Elizabeth

SAVE

Bluetooth

Remove a paired device

If you already have the maximum of four paired devices on the paired devices

list and you want to add another device, you must rst delete a paired device

from the paired devices list.

Press the MENU softkey on the telephone base

1. when it is not in use.

Press /VOL+ or VOL-/ to highlight Bluetooth, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Paired devices,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight a selected item,

4. then press the OPTION softkey.

Press /VOL+ or VOL-/ to highlight Remove paired,

5. then press the SELECT softkey.

The screen displays Remove device from paired

6. list? Press the YES softkey to conrm or the NO softkey to exit.

View information of a paired device

Press the MENU softkey on the telephone base

1. when it is not in use.

Press /VOL+ or VOL-/ to highlight Bluetooth, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Paired devices,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight a selected item,

4. then press the INFO softkey to view the information.

Press the OK softkey to return to the

5. Paired devices list.

Page all HS Intercom

Bluet ooth

SELECT

Setup h eadset Active d evices

Paired devices

SELECT

PAIRED DEVICES Mary’s Cell

John’s Headset

INFO

Disconnect Renam e

Remove paired

Remove device

paired list?

YES

OPTION

SELECT

from

Bluetooth

Active devices

Only devices on the active devices list can establish a Bluetooth connection with the telephone base. Although two paired devices can be connected to the telephone base, only one Bluetooth cell phone or a headset can be on a call at a time.

Review the active devices list

Press the MENU softkey on the telephone base

1. when it is not in use.

Press /VOL+ or VOL-/ to highlight Bluetooth, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Active devices,

3. then press the SELECT softkey.

Connect/disconnect an active device

While in the active devices menu, you can connect or disconnect your active device.

Press the MENU softkey on the telephone base

1. when it is not in use.

Press /VOL+ or VOL-/ to highlight Bluetooth, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Active devices,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight a selected item.

4. Press the OPTION softkey, then highlight

5. Connect/Disconnect.

Press the SELECT softkey to conrm.

Page all HS Intercom

Bluet ooth

SELECT

Setup c ell Setup H eadset

Active d evices

SELECT

ACTIVE DEVICES Mary’s Cell

John’s Headset

INFO

Disconnect

Remove active

OPTION

SELECT

When your active device is connected, you are prompted to select Disconnect. When your active device is disconnected, you are prompted to select Connect.

Bluetooth

Replace an active device

When you already have two devices on the active devices list, you can replace an active device with a device on the paired devices list.

To replace an active device:

Press the MENU softkey on the telephone base

1. when it is not in use.

Press /VOL+ or VOL-/ to highlight Bluetooth, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Paired devices,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight a selected

4. device, then press the OPTION softkey.

When Replace active is highlighted, press the

5. SELECT softkey.

Press /VOL+ or VOL-/ to select the device to be

6. replaced, then press the SELECT softkey.

When Device added to active list Connect now?

7. appears, press the YES softkey to conrm or the NO softkey to exit.

Page all HS Intercom

Bluet ooth

Setup h eadset Active d evices

Paired devices

PAIRED DEVICES Mary’s Cell

John’s Headset

INFO

SELECT

OPTION

Add an active device

You can have a maximum of two devices on the active devices list.

To add an active device:

Press the MENU softkey on the telephone base

1. when it is not in use.

Press /VOL+ or VOL-/ to highlight Bluetooth, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Active devices,

3. then press the SELECT softkey.

Select an empty position and then press the ADD

4. softkey. You are prompted to select a device from the paired devices list.

Press /VOL+ or VOL-/ to select one paired device,

5. then press the ADD softkey.

When Device added to active list Connect now?

6. appears, press the YES softkey to conrm or the NO softkey to exit.

Replac e active

Renam e Remove paired

SELECT

Setup c ell Setup h eadset

Active d evices

SELECT

ACTIVE DEVICES 1 Mary’s Cell 2 2

2 Empty

ADD

PAIRED DEVICES Mary’s Cell

John’s Headset

INFO

ADD

Bluetooth

Remove an active device

You can remove an active device from the active devices list.

To remove an active device:

Press the MENU softkey on the telephone base

1. when it is not in use.

Press /VOL+ or VOL-/ to highlight Bluetooth, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Active devices,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight a selected

4. device, then press the OPTION softkey.

Press /VOL+ or VOL-/ to highlight Remove active,

5. then press the SELECT softkey. The telephone base displays Device removed from active device list.

View information of an active device

To view the information of an active device:

Press the MENU softkey on the telephone base when

1. it is not in use.

Press /VOL+ or VOL-/ to highlight Bluetooth, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Active devices, then press the

3. SELECT softkey.

Press /VOL+ or VOL-/ to highlight a selected device, then press the

4. INFO softkey to view the information.

Press the OK softkey to return to the Active devices list.

Page all HS Intercom

Bluet ooth

Setup c ell Setup h eadset

Active d evices

ACTIVE DEVICES 1 Mary’s Cell

2 Elizabeth Jones

INFO

Connect

Remove active

SELECT

OPTION

SELECT

Change PIN

You are required to enter a PIN when establishing a Bluetooth connection. The default PIN of your telephone base is 0000.

To change the PIN:

Press the MENU softkey on the telephone base when

1. it is not in use.

Press /VOL+ or VOL-/ to highlight Bluetooth, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Change PIN,

3. then press the SELECT softkey. The screen displays ENTER NEW PIN.

Use the dialing keys to enter a new four-digit code.

4. Press the SAVE softkey to conrm.

Active d evices Paired devices

Chang e PIN

ENTER N EW PIN

----

SELECT

SAVE

Handset settings

Settings

In the settings menu, you can change and edit the handset settings for language, voicemail indicator, keylock, key tone, date and time and home area code.

LCD language

You can select English, Français or Español to be used in all screen displays.

To select a language:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight SETTINGS,

2. then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

3. LCD language, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to choose from

4. English, Français or Español, then press the SET softkey to save or press the BACK softkey to exit to the previous menu.

SETTINGS

LCD language

Clr voicemail Auto keylock Key tone

BACK

LCD LANGUAGE

English

Francais Espanol

BACK

SELECT

SET

Handset settings

Clear voicemail

If you subscribe to voicemail service offered by your telephone service provider, New voicemail and appear on the handset and telephone base when you have new voicemail messages. Contact your telephone service provider for more information and assistance about using your voicemail service.

After you have listened to all new voicemail messages, the indicators on the handset and telephone base turn off automatically.

Use the clear voicemail feature when the telephone indicates that there is new voicemail but there is none (for example, when you have accessed your voicemail while away from home). The clear voicemail feature only turns off the indicators; it does not delete your voicemail messages. As long as you have new voicemail messages, your telephone service provider continues to send the signal that turns on the indicators.

To manually turn off these indicators:

Press the MENU softkey when the handset is not in use.

Press /VOL+/ or CID/VOL-/ to highlight SETTINGS, then press the

SELECT softkey. Press /VOL+/ or CID/VOL-/ to highlight Clr voicemail, then press the

SELECT softkey. The screen displays Turn off indicator? Press the YES softkey to conrm or press the NO softkey to exit to the

4. previous menu.

Your telephone service provider may alert you to new messages with a

• stutter (broken) dial tone. Contact your service provider for details.

Voicemail is different from answering system messages recorded in your

• answering system. For more information about the difference, see page 67.

SETTINGS LCD language

Clr voicemail

Auto keylock Key tone

BACK

Turn off

indicator?

YES

SELECT

Handset settings

Auto keylock

The auto lock feature is on by default to prevent accidental presses of the handset keys. If no key has been pressed for 10 seconds, the keys will lock.

To change the setting:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight SETTINGS,

2. then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

3. Auto keylock, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to choose from On or

Off, then press the SET softkey to save or press the BACK softkey to exit to the previous menu.

You can turn on or off the keylock manually:

Press the ashing UNLOCK softkey when you want to unlock the keypad.

•

Press and then the ashing LOCK softkey to lock the keypad.

•

When the keypad is locked, you have to unlock it before making calls to

• emergency numbers 911 and 411.

When you are using the speakerphone and no keys are pressed within ve

• seconds, the keys are automatically locked.

Key tone

You can turn the key tone feature on or off.

To change the setting:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight SETTINGS,

2. then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

3. Key tone, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to choose from On or

Off, then press the SET softkey to save or press the BACK softkey to exit to the previous menu.

SETTINGS LCD language Clr voicemail

Auto keylock

Key tone

BACK

AUTO KEYLOCK

On

Off

BACK

SETTINGS LCD language Clr voicemail Auto keylock

Key tone

BACK

KEY TONEs

On

Off

SELECT

SET

SELECT

BACK

SET

Handset settings

Set date/time

The answering system announces the day and time of each message prior to playing it. Before using the answering system, set the date and time as follows. If you subscribe to caller ID service, the day, month and time are set automatically with each incoming call. However, the year must be correct so that the day of the week can be calculated from the caller ID information.

To change the setting:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight SETTINGS,

2. then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

3. Set date/time, then press the SELECT softkey.

Use the dialing keys (0-9) to enter a two-digit number or

4. press /VOL+/ or CID/VOL-/ until the screen displays the desired number. Press the SET softkey to advance.

Repeat step 4 until the date and time are set.

If the date and time are not set, the system announces, “Time and day not set,” before each message plays.

SETTINGS Clr voicemail Auto keylock Key tone

Set date/time

BACK

SELECT

SET DATEs

--/--/--

MM/DD /YY

BACK

SET TIME

BACK

SET

--:- - --

SET

Handset settings

Home area code

If you dial your local calls using only seven digits (area code not required), you can program your home area code so that when you receive a call within your local area, the telephone number is automatically stored without the area code in the call log.

To change the setting:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight SETTINGS,

2. then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Home area

3. code, then press the SELECT softkey. The stored

home area code appears with the last digit ashing.

Use the dialing keys to enter the desired home

4. area code.

Press the BACK softkey or OFF/CLEAR

•

to backspace and erase a digit.

Press the SET softkey to save.

If, in the future, your telephone service provider requires you to dial the area code when making a local call, delete the home area code you have already programmed. After you have deleted the programmed home area code, ___ appears.

SETTINGS Auto keylock Key tone Set date/time

Home area code

BACK

HOME AR EA CODE

800

BACK

SELECT

SET

Handset settings

Ringers

In the ringers menu, you can select the ringer tones and adjust the ringer volume for incoming calls to the home and cell lines.

Ringer volume

To adjust the handset ringer volume:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight RINGERS,

2. then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

3. Ringer volume, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Home,

Cellular 1, Cellular 2 or All home & cell. Press the SELECT softkey to conrm.

Press /VOL+/ or CID/VOL-/ to adjust the ringer

5. volume. A sample of each ringer volume plays as you scroll through the choices.

Press the SET softkey to conrm your setting.

When the ringer volume for all are set to off or the lowest level, a ringer off

• icon appears. When only one or two of the ringer volume is off or set to the lowest level, a ringer off icon ashes.

See page 32 to set the telephone base ringer.

•

RINGERS

Ringer volu me

Ringer tone

BACK

SELECT

RINGER VOLUME

Home

Cellular 1 Cellular 2 All h ome & cell

BACK

SELECT

RINGER VOLUME

OFF

SET

Handset settings

Ringer tone

To select a ringer tone:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight RINGERS,

2. then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

3. Ringer tone, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Home,

Cellular 1, Cellular 2 or All home & cell. Press the SELECT softkey to conrm.

Press /VO L+/ or CID/VOL-/ to select a ringer tone.

5. A sample of each ringer tone plays as you scroll through the choices.

Press the SET softkey to conrm your setting or press

6. the BACK softkey to exit to the previous menu.

When you turn off the ringer volume, you do not hear ringer tone samples

RINGERS Ringer volu me

Ringer tone

BACK

SELECT

RINGER TONE

Home

Cellular 1 Cellular 2 All h ome & cell

BACK

SELECT

RINGER TONES

Melod y 3

Melod y 4 Melod y 5 Melod y 6

BACK

SET

Telephone base settings

Settings

In the settings menu, you can change and edit the telephone base settings of date and time, key tone, language, voicemail indicator and home area code.

Set date/time

To change the setting:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Settings, then

2. press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

3. Set date/time, then press the SELECT softkey.

Use the dialing keys (0-9) to enter a two-digit

4. number or press /VOL+ or VOL-/ until the screen displays the desired number. Press the SET softkey to advance.

Repeat step 4 until the date and time are set.

If the date and time are not set, the system announces, “Time and day not set,” before each message plays.

Bluet ooth Ringers

Settings

SELECT

Set date/time

Key tone LCD language

SELECT

SET DATE

--/--/--

MM/DD /YY

SET

Key tone

You can turn the key tone feature on or off.

To change the setting:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL

press the SELECT softkey. Press /VOL+ or VOL-/ to highlight Key tone, then

3. press the SELECT softkey.

Press /VOL+ or VOL-/ to choose from On or Off,

4. then press the SET softkey to save.

or VOL

/ to highlight Settings, then

Bluet ooth Ringers

Settings

SELECT

Set date/time

Key tone

LCD language

SELECT

KEY TONE

On

Off

SET

Telephone base settings

LCD language

You can select English, Français or Español to be used in all screen displays.

To select a language:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL

press the SELECT softkey. Press /VOL+ or VOL-/ to highlight LCD language,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight English,

4. Français or Español, then press the SET softkey to save.

or VOL

/ to highlight Settings, then

Bluet ooth Ringers

Settings

SELECT

Set date/time Key tone

LCD language

SELECT

LCD LANGUAGE

English

Francais

SET

Telephone base settings

Clear voicemail

After you have listened to all new voicemail messages, the indicators on the handset and telephone base turn off automatically.

To manually turn off these indicators:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Settings, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Clr voicemail,

3. then press the SELECT softkey. The screen displays

Turn off indicator?

Press the YES softkey to conrm or press the NO

4. softkey to exit to the previous menu.

Bluet ooth Ringers

Settings

SELECT

Key tone LCD language

Clr voicemail

SELECT

Turn off

indicator?

YES

Your telephone service provider may alert you to new messages with a

• stutter (broken) dial tone. Contact your service provider for details.

Voicemail is different from answering system messages recorded in your

• answering system. For more information about the difference, see page 67.

Telephone base settings

Home area code

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL

press the SELECT softkey. Press /VOL+ or VOL-/ to highlight Home area

3. code, then press the SELECT softkey. The stored

home area code appears with the last digit ashing.

Use the dialing keys to enter the desired home

4. area code.

Press CANCEL / to backspace and erase a digit.

• Press the SET softkey to save.

or VOL

/ to highlight Settings, then

Bluet ooth Ringers

Settings

SELECT

LCD language Clr voicemail

Home area code

SELECT

HOME AR EA CODE 800

SET

Telephone base settings

Ringers

In the ringers menu, you can select the ringer tones and adjust the ringer volume for incoming calls to the home and cell lines.

Ringer volume

To adjust the handset ringer volume:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Ringers, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Ringer volume,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Home,

Cellular 1, Cellular 2 or All home & cell. Press the SELECT softkey to conrm.

Press /VOL+ or VOL-/ to adjust the ringer volume.

5. A sample of each ringer volume plays as you scroll through the choices.

Press the SET softkey to conrm your setting.

-OR- Press the OFF softkey and then the SET softkey to turn off the ringer volume.

When the ringer volume for all are set to off or the lowest level, a ringer off

• icon appears. When only one or two of the ringer volume is off or set to the lowest level, a ringer off icon ashes.

See page 26 to set the handset ringer volume.

•

Intercom Bluet ooth

Ringers

Ringer volu me

Ringer tone

Home

Cellular 1 Cellular 2

RINGER VOLUME

OFF

SELECT

SET

Telephone base settings

Ringer tone

To select a ringer tone:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Ringers, then

2. press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Ringer tone,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Home,

Cellular 1, Cellular 2 or All home & cell. Press the SELECT softkey to conrm.

Press /VOL+ or VOL-/ to select a ringer tone.

5. A sample of each ringer tone plays as you scroll through the choices.

Press the SET softkey to conrm your setting.

Intercom Bluet ooth

Ringers

SELECT

Ringer volu me

Ringer tone

SELECT

Home

Cellular 1 Cellular 2

SELECT

Tone 1

Tone 2 Tone 3

SET

Answering system settings

Answering system setup

You can change the settings of the answering system in the Ans sys setup menu with either your handset or telephone base.

Answer ON/OFF

If you turn the answering system on, it answers calls and records messages only on the home line.

When the answering system is turned on, ANS ON displays on the handset and telephone base.

To turn the answering system on or off: Using the telephone base:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Ans. system,

2. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Ans sys setup,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight

4. Answer ON/OFF, then press the SELECT softkey.

Press /VOL+ or VOL-/ to choose On or Off, then

5. press the SET softkey to conrm your setting.

Using the handset:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight

2. ANS. SYSTEM, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

3. Ans sys setup, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

4. Answer ON/OFF, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to choose On or Off, then press the SET

5. softkey to conrm your setting; or press the BACK softkey to exit to the previous menu without making any changes.

Ans. system

Directory Call log

SELECT

Del all old Record memo

Ans sys s etup

SELECT

Answer ON/OFF

Anno unceme nt Call screening

SELECT

Answer ON/OFF

On

Off

SET

Answering system settings

Call screening

The call screening feature lets you listen to a caller leaving a message at the telephone base. You can turn this feature on or off with either your handset or telephone base.

To change the setting: Using the telephone base:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Ans. system,

2. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Ans sys setup,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Call screening,

4. then press the SELECT softkey.

Press /VOL+ or VOL-/ to choose On or Off, then

5. press the SET softkey to conrm your setting.

Using a handset:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight

2. ANS. SYSTEM, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

3. Ans sys setup, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

4. Call screening, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to choose On or Off, then press the SET

5. softkey to conrm your setting; or press the BACK softkey to exit to the previous menu without making any changes.

Ans. system

Directory Call log

SELECT

Del all old Record memo

Ans sys s etup

SELECT

Answer ON/OFF Anno unceme nt

Call screening

SELECT

CALL SC REENING

On

Off

SET

Answering system settings

Announcement

The telephone is preset with a greeting that answers calls with

leave a message after the tone.”

replace it with your own.

Play your announcement

Using the telephone base:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Ans. system,

2. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Ans sys setup,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Announcement,

4. then press the SELECT softkey.

The telephone base announces,

record, press 7.”

Using the handset:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight

2. ANS. SYSTEM, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

3. Ans sys setup, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

4. Announcement, then press the SELECT softkey.

The handset announces,

record, press 7.”

softkey to exit to the previous menu.

Press 2 to play.

Press 2 to play; or press the BACK

You can use this preset announcement, or

Ans. system

Directory Call log

Del all old Record memo

Ans sys s etup

“To play, press 2. To

Answer ON/OFF

Anno unceme nt

Call screening

2-Play 3- Delete

“To play, press 2. To

“Hello, please

SELECT

Anno unceme nt

7-Record

Answering system settings

Record your own announcement

Using the telephone base:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Ans. system,

2. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Ans sys setup,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Announcement,

4. then press the SELECT softkey.

The telephone base announces,

record, press 7.”

The telephone base announces,

Press 7 to record.

tone. Press 5 when you are done.”

“To play, press 2. To

“Record after the

After the tone,

speak towards the microphone of the telephone base. Press 5 or the STOP softkey when nished.

7. The answering system automatically plays back the

8. newly recorded announcement. Press 5 to stop the playback at any time; press 2 to replay the recorded announcement; or press 7 to record again if desired.

Using the handset:

Press the MENU softkey when the handset is not in use.

1. Press /VOL+/ or CID/VOL-/ to highlight ANS. SYSTEM, then press the

2. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Ans sys setup, then press the

3. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Announcement, then press

4. the SELECT softkey.

The handset announces,

“To play, press 2. To record, press 7.”

to record. The handset announces,

done.”

After the tone, speak towards the microphone of the handset.

Press 5 or the STOP softkey when nished.

7. The answering system automatically plays back the newly recorded

“Record after the tone. Press 5 when you are

announcement. Press 5 to stop the playback at any time or press the BACK softkey to exit to the previous menu; press 2 to replay the recorded

announcement; or press 7 to record again if desired.

Your announcement can be up to 90 seconds in length.

• Announcements shorter than two seconds are not recorded.

•

Ans. system

Directory Call log

Del all old Record memo

Ans sys s etup

Answer ON/OFF

Anno unceme nt

Call screening

Anno unceme nt

2-Play 3- Delete

7-Record

Press 7

SELECT

Answering system settings

Delete your announcement

Using the telephone base:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Ans. system,

2. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Ans sys setup,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Announcement,

4. then press the SELECT softkey.

The telephone base announces,

2. To record, press 7.”

Press 3 to delete your own

recorded announcement.

Using the handset:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight

2. ANS. SYSTEM, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

3. Ans sys setup, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight

4. Announcement, then press the SELECT softkey.

The handset announces,

record, press 7.”

Press 3 to delete your own

“To play, press 2. To

recorded announcement.

When your announcement is deleted, calls are answered with the preset announcement.

“To play, press

Ans. system

Directory Call log

SELECT

Del all old Record memo

Ans sys s etup

SELECT

Answer ON/OFF

Anno unceme nt

Call screening

SELECT

Anno unceme nt

2-Play 3- Delete

7-Record

Answering system settings

Number of rings

When the answering system is turned on, it answers all incoming home calls after the number of rings set. You can choose from two, four, or six rings; or toll saver. With toll saver selected, the answering system answers after two rings when you have new messages, and after four rings when you have no new messages. This enables you to check for new messages and avoid paying unnecessary long distance charges if you are calling from out of your local area.

To change the setting: Using the telephone base:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Ans. system,

2. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Ans sys setup,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight # of rings, then

4. press the SELECT softkey.

Press /VOL+ or VOL-/ to choose from 2, 4, 6 or

5. Toll saver, then press the SET softkey to conrm your setting.

Using the handset:

Press the MENU softkey when the handset is not in use.

1. Press /VOL+/ or CID/VOL-/ to highlight ANS. SYSTEM, then press the

2. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Ans sys setup, then press the

3. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight # of rings, then press the

4. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to choose from 2, 4, 6 or Toll saver, then

5. press the SET softkey to conrm your setting; or press the BACK softkey to exit to the previous menu without making any changes.

Ans. system

Directory Call log

Del all old Record memo

Ans sys s etup

Anno unceme nt Call screening

# of rings

# OF RINGS

2

SELECT

SET

Answering system settings

Remote access code

A two-digit security code is required to access the answering system remotely from any touch tone telephone. The preset code is 19. You can change the code to any number from 10 to 99.

To change the setting: Using the telephone base:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Ans. system,

2. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Ans sys setup,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Remote code,

4. then press the SELECT softkey.

Use the dialing keys (0-9) to enter a two-digit number

5. from 10-99, then press the SET softkey to conrm your setting.

Using the handset:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight ANS. SYSTEM, then press the

2. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Ans sys setup, then press the

3. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Remote code, then press the

4. SELECT softkey.

Use the dialing keys (0-9) to enter a two-digit number from 10-99, then

5. press the SET softkey to conrm your setting; or press the BACK softkey to exit to the previous menu without making any changes.

Ans. system

Directory Call log

Del all old Record memo

Ans sys s etup

Call screening # of rings

Remote c ode

REMOTE CODE

SELECT

SET

Answering system settings

Message alert tone

When the answering system is turned on, the telephone beeps every 10 seconds to alert you of new messages. The tone stops when all new messages have been reviewed.

To change the setting: Using the telephone base:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Ans. system,

2. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Ans sys setup,

3. then press the SELECT softkey.

Press /VOL+ or VOL-/ to highlight Msg alert tone,

4. then press the SELECT softkey.

Press /VOL+ or VOL-/ to select On or Off, then

5. press the SET softkey to conrm your setting.

Using the handset:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight

2. ANS. SYSTEM, then press the SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Ans sys setup, then press the

3. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Msg alert tone, then press the

4. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to select On or Off, then press the SET

5. softkey to conrm your setting; or press the BACK softkey to exit to the previous menu without making any changes.

The answering system must be turned on for the message alert tone to function.

Ans. system

Directory Call log

Del all old Record memo

Ans sys s etup

# of rings Remote c ode

Msg ale rt tone

MSG ALE RT TONE

On

Off

SELECT

SET

Telephone operation

Make, answer or end a home call

You can make home calls using a handset or the telephone base.

Using a handset: To make a home call:

Press /HOME/FLASH or , then enter the

• telephone number.

To predial a home call:

Enter the telephone number, then press /HOME/FLASH

• or .

To answer a home call:

Press /HOME/FLASH or .

•

The screen shows the elapsed time as you talk (in

• hours, minutes and seconds).

When predialing (preview numbers before dialing), press OFF/CLEAR to

• backspace and delete; press the PAUSE softkey to insert a dialing pause (a p appears).

To end a home call:

Press OFF/CLEAR or put the handset in the telephone base.

•

Using the telephone base: To make a home call:

Press /HOME, then enter the telephone number.

•

To predial a home call:

Enter the telephone number, then press /HOME.

•

To answer a home call:

Press /HOME.

•

To end a home call:

Press /HOME.

•

Telephone operation

Make, answer or end a home call (continued)

Using a Bluetooth headset:

You can use a Bluetooth headset on home calls. However, you will need to stay within 30 feet from the telephone base to maintain the Bluetooth signal. If you move too far from the telephone base and the signal is lost, the call will end.

To make a home call:

Press /HOME on the telephone base, then enter

1. the telephone number.

Press the call button on your headset.

-ORPress the OPTION softkey. Press /VOL+ or VOL-/ to highlight

Use headset, and then press the SELECT softkey.

To predial a home call:

Enter the telephone number, then press /HOME on the telephone base.

1. Press the call button on your headset.

-ORPress the OPTION softkey. Press /VOL+ or VOL-/ to highlight

Use headset, and then press the SELECT softkey.

To switch between the headset and base speakerphone while on a call:

Press the OPTION softkey.

1. Press /VOL+ or VOL-/ to highlight Use speaker or Use headset.

2. Press the SELECT softkey.

To answer a home call:

Press the call button on your headset.

•

To end a home call:

Press /HOME or press the call button on your headset.

•

Use headset

Directory Call log

SELECT

Call waiting on the home line

If you subscribe to call waiting service with your telephone service provider, you hear a beep if someone calls while you are already on a call.

Press /HOME/FLASH on the handset or FLASH/X on the telephone

• base to put your current call on hold and take the new call.

Press /HOME/FLASH on the handset or FLASH/X on the telephone

• base at any time to switch back and forth between calls.

Telephone operation

Make, answer or end a cell call

You can make cell calls using a handset or the telephone base. You can connect a maximum of two Bluetooth enabled cell phones to the

telephone base, but only one cell phone can be used on a cell call at a time. If you only have one cell phone connected to the telephone base, it is

automatically selected to make or answer cell calls. If you have two cell phones connected to the telephone base and on the active device list, the telephone base prompts you to select a cell phone before you make a cell call.

Using a handset: To make a cell call:

Press /CELL, then enter the telephone number.

1. Press the DIAL softkey.

To predial a cell call:

Enter the telephone number, then press /CELL.

•

To answer a cell call:

Press /CELL.

•

If you do not want to answer the call, press the REJECT softkey.

To end a cell call:

Press OFF/CLEAR or put the handset in the telephone base.

•

Using the telephone base: To make a cell call:

Press /CELL, then enter the telephone number.

1. Press the DIAL softkey.

To predial a cell call:

Enter the telephone number, then press /CELL.

•

To answer a cell call:

Press /CELL.

•

If you do not want to answer the call, press the REJECT softkey.

To end a cell call:

Press /CELL.

•

Telephone operation

Call waiting on the cell line

If you subscribe to call waiting service with your cell phone service provider, you hear a beep if someone calls while you are already on a call.

Press the SWAP softkey on the handset or telephone base.

• Press the OPTION softkey and then the SWAP softkey to switch back

• and forth between calls.

Answer a cell call while on a home call

While you are on a home call and there is an incoming cell call, 1 or 2 displays on the handset and telephone base and the telephone rings.

To answer the incoming cell call:

Press /CELL on the handset or telephone base. The home call is

• automatically placed on hold and Home call on hold appears on the handset and telephone base.

To end the cell call:

Press OFF/CLEAR on the handset or /CELL on the telephone base. The

• home line is still on hold.

To resume the home call on hold:

Press /HOME/FL ASH on the handset or /HOME on the telephone

• base.

If you have voicemail service active on your cell phone, and you do not answer the incoming cell call, the call is answered by your cell phone’s voicemail. Contact your cell phone service provider for more information about voicemail service.

Telephone operation

Answer a home call while on a cell call

While you are on a cell call and there is an incoming home call, appears on the handset and telephone base and the telephone rings.

To answer the incoming home call:

Press

• base. The cell call is automatically placed on hold and Cell call on hold appears on the handset and telephone base.

To end the home call:

Press OFF/CLEAR on the handset or /HOME on the telephone base.

• The cell line is still on hold.

To resume the cell call on hold:

Press /CELL on the handset or telephone base.

•

Conference home and cell calls

When you have calls established on the home and cell lines, you can create a 3-way conference using the handset or telephone base.

To conference both home and cell calls:

Press the OPTION softkey on the handset or telephone base.

1. Press

2. Press the SELECT softkey.

To select an option while on a conference call:

Press

1. Press

•

Press the SELECT softkey.

To end a conference call:

Press OFF/CLEAR on the handset or put the handset back in the

• telephone base.

Press /HOME or /CELL on the telephone base.

•

/HOME/FLASH

If you have turned on your answering system and you do not answer the incoming home call, the call is answered by your answering system.

/VOL+ or VOL-/ to highlight Conf. with home/Conf. with cell.

the OPTION softkey on the handset or telephone base.

/VOL+ or VOL-/ to select one of the following options: End home call End cell call

on the handset or /HOME on the telephone

Telephone operation

Handset speakerphone

During a call, press to switch between speakerphone and normal handset use.

When in speakerphone mode, if no keys are pressed within ve seconds, the

keypad is locked automatically. Press the UNLOCK softkey to use the keypad.

Volume control

During a call, you can adjust the listening volume on the handset or telephone base.

To adjust the listening volume of the handset:

Press /VOL+/ or CID/VOL-/ on the handset while on a call.

•

To adjust the listening volume of the telephone base:

Press /VOL+ or VOL-/ on the telephone base while on a call.

•

Silence the ringer

When the home or cell line is ringing, you can temporarily silence the ringer of the handset without disconnecting the call. The next call rings normally at the preset volume.

To silence the ringer of the handset when there is an incoming call:

Press the SILENCE softkey or OFF/CLEAR on the handset and

•

Ringer mute appears.

To silence the ringer of the telephone base when there is an incoming call:

Press the SILENCE softkey or CANCEL/ on the telephone base.

•

Ringer mute appears.

Mute

The mute function turns off the microphone. You can hear the caller, but the caller cannot hear you.

To mute a call on a handset or the telephone base:

Press the MUTE softkey to turn off the microphone. The screen shows

•

Muted for a few seconds and MUTE appears until the mute function is turned off.

To un-mute a call on a handset or the telephone base:

Press the UNMUTE softkey to resume the conversation. The screen

•

temporarily shows Microphone ON.

Telephone operation

Infrared sensor

This feature prevents you from pressing the keys accidentally while you are using the handset during a call.

When you put the earpiece of the handset next to your ear or the infrared sensor is covered during a call, all keys on the dial pad are disabled.

Hold

You can place a home or cell call on hold. You will hear an alert tone if you have not taken the call off of hold after 14 minutes. You will hear another alert tone 30 seconds later. At 15 minutes on hold, the call on hold automatically disconnects.

To place a home call on hold:

Press HOLD on the handset or telephone base. Home call on hold

• appears,

base ash.

To resume a home call on hold:

Press

•

To place a cell call on hold:

Press HOLD on the handset or telephone base. Cell call on hold

• appears, /CELL on the handset and telephone base ash.

To resume a cell call on hold:

Press /CELL on the handset or telephone base.

•

/HOME/FLASH

on the handset and /HOME on the telephone

on the handset or /HOME on the telephone base.

Earpi ec e

Infrared sensor

Handset locator

This feature helps you nd a misplaced handset.

To start paging:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Page all HS,

2. then press the SELECT softkey on the telephone base. The telephone base shows Paging all

handsets and the handset shows ** Paging **.

To end paging:

Press the STOP softkey or CANCEL/ on the

• telephone base.

- OR -

•

Press

/HOME/FLASH, or any dialing keys (0-9, #, ) on the handset.

Directory Call log

Page all HS

SELECT

Paging

all h andsets

STOP

Telephone operation

Chain dialing

Use this feature to initiate a dialing sequence from numbers stored in the directory, call log or redial while you are on a home call. This feature is available only for home calls.

Chain dialing can be useful if you wish to access other numbers (such as bank account numbers or access codes) from the directory, call log or redial list.

To access a number in the directory while on a home call:

Press the OPTION softkey.

1. Press /VOL+ or VOL-/ to highlight Directory and

2. then press the SELECT softkey.

Press /VOL+ or VOL-/ to scroll to the desired entry.

3. Press the DIAL softkey to dial the displayed number.

To access a number in the call log while on a home call:

Press the OPTION softkey.

1. Press /VOL+ or VOL-/ to highlight Call log and

2. then press the SELECT softkey.

Press /VOL+ or VOL-/ to scroll to the desired entry.

3. Press the DIAL softkey to dial the displayed number.

To access the last number redial while on a home call:

Press the OPTION softkey.

1. Press /VOL+ or VOL-/ to highlight Redial last # and then press the

2. SELECT softkey.

Press the DIAL softkey to dial the displayed number.

Intercom

Directory Call log

SELECT

VTech

800-595 -9511

DIAL

You cannot edit a directory entry while on a call. For more details about the

• director y, see page 55.

You cannot copy a call log entry into the directory while on a call. For more

• details about call log, see page 62.

You can only view the last number redial while on a call and cannot erase

• the entry. For more details about the redial memory, see page 50.

Press the BACK softkey on the handset or CANCEL / on the telephone

• base to exit redial, directory or call log while on a call.

Telephone operation

Redial list

The redial list stores up to 20 entries on the handset and telephone base. When there are already 20 entries, the oldest entry is deleted to make room

for the new entry. Entries are shown in reverse chronological order.

Review the redial list

Press the REDIAL softkey when the handset or

1. telephone base is not in use.

Press /VOL+ or VOL-/ to browse.

Dial a redial entry

Press the REDIAL softkey when the handset or

1. telephone base is not in use.

Press /VOL+ or VOL-/ to browse to the

2. desired entry.

Press

/HOME/FLASH

on the handset or /HOME

on the telephone base using the home line.

- OR -

Press /CELL on the handset or telephone base using the cell line.

Save a redial entry to the directory

Press the REDIAL softkey when the handset or telephone base is not

1. in use.

Press /VOL+ or VOL-/ to browse to the desired entry.

2. Press the OPTION softkey.

Press the SELECT softkey to select Save.

4. The screen displays ENTER NUMBER. Use the dialing keys to edit the

5. number, if necessary.

Press the NEXT softkey to move to the name.

6. The screen displays ENTER NAME. Use the dialing keys to enter a name

7. (see step 6 of Create a new directory entry on page 55).

Press the SAVE softkey and Saved displays.

HANDSET

11:00am 12/25

REDIAL

11:00am 12/25

REDIAL

BASE

Telephone operation

Delete a redial entry

Press the REDIAL softkey when the handset or telephone base is not

1. in use.

Press /VOL+ or VOL-/ to browse to the desired entry.

2. Press the OPTION softkey.

Press /VOL+ or VOL-/ to highlight Delete and then press the

4. SELECT softkey.

Telephone operation

BACK SELECT

INTERCOM

Intercom

Use the intercom feature for conversations between two system handsets. You can buy additional expansion handsets (LS6204) for this telephone

system. You can register up to 12 handsets to the telephone base.

To initiate an intercom call from the telephone base:

Press the MENU softkey when the telephone base is

1. not in use.

Press /VOL+ or VOL-/ to highlight Intercom, then

2. press the SELECT softkey.

When the telephone base shows INTERCOM TO:,

3. press /VOL+ or VOL-/ to select a destination handset and then press the SELECT softkey. The telephone base shows Calling handset X. The destination handset rings and its screen shows

Base is calling.

To initiate an intercom call with a handset:

Press the MENU softkey when the handset is not

1. in use.

Press /VOL+/ or CID/VOL-/ to highlight INTERCOM,

2. then press the SELECT softkey.

When the handset shows INTERCOM TO:, press

/VOL+/ or CID/VOL-/ to select a destination and

then press the SELECT softkey.

If you are calling the telephone base, your handset

•

shows Calling base and the telephone base rings and shows Handset X is calling.

If you are calling another handset, your handset

• shows Calling handset X and the destination handset rings and shows Handset X is calling.

To answer an intercom call at the telephone base:

Press /HOME. Both screens show Intercom.

•

To answer an intercom at a handset:

•

Press

/HOME/FLASH or . Both screens show Intercom.

Call log Page all HS

Intercom

INTERCOM TO:

Handset 1

Handset 2

INTERCOM TO:

BASE

Handset 2

BACK

SELECT

Telephone operation

Intercom (continued)

To silence an intercom call:

Press the SILENCE softkey on the telephone base or handset.

•

- OR -

Press OFF/CLEAR on the handset or CANCEL/ on the telephone base.

•

To end an intercom call:

Press the END softkey, or press OFF/CLEAR on the handset or

•

CANCEL/ on the telephone base. Both screens show Intercom ended.

You can cancel the intercom call before it is answered by pressing

•

OFF/CLE AR on your originating handset; or CANCEL/ on the telephone base.

If the other handset or the telephone base does not answer the intercom

• call within 100 seconds, is in the director y or call log, or is out of range, your originating handset or telephone base shows Unable to call try again and returns to idle mode.

You can use a maximum of four handsets, or three handsets and the

• telephone base, at a time. When two handsets are used on an intercom call, use two other system handsets for an outside call.

Answer an incoming call during an intercom call

When you receive an incoming home call during an intercom call, there is an alert tone and Incoming call appears on screens.

Press /HOME/FLASH on the handset or /HOME on the telephone

• base to answer the home call and the intercom call ends automatically.

- OR -

Press the BACK softkey to continue the intercom call.

•

When you receive an incoming cell call during an intercom call, there is an alert tone and Incoming call appears on screens.

Press /CELL on the handset or telephone base to answer the cell call

• and the intercom call ends automatically.

- OR -

Press the BACK softkey to continue the intercom call.

•

OR -

Press the REJECT softkey if you do not want to answer the call. The

• intercom call continues.

Telephone operation

Share an outside call

You can let another handset or the telephone base join you on an outside call. That call continues until all people hang up.

Press /HOME/FLASH on the handset or /HOME on the telephone

• base to join the call.

Transfer a call

You can use intercom to transfer an outside call to another system handset or the telephone base.

When on an outside call, press the OPTION softkey.

1. Press /VOL+ or VOL-/ to highlight Intercom, then press the SELECT

2. softkey. The outside is put on hold.

When the handset shows INTERCOM TO:, press /VOL+/ or CID/VOL-/

3. to select a destination.

Press the SELECT softkey.

If you are calling the telephone base, your handset shows Calling

•

base and the telephone base rings and shows Handset X is calling.

If you are calling another handset, your handset shows

• Calling handset X and the destination handset rings and shows Handset X is calling.

When the destination handset answers the intercom call, both screens

5. show Intercom.

Press OFF/CLEAR or the END softkey on the originating handset. Both

6. screens show Intercom ended.

The destination handset screen shows Home call on hold or

7. Cell call on hold. Press /HOME/FLASH to answer a home call or /CELL to answer a cell call on the handset.

-OR-

Press /HOME to answer a home call or /CELL to answer a cell call on the telephone base.

Telephone operation

Directory

The directory stores up to 100 entries with up to 30 digits for each phone number and 15 characters for each name.

Directory entries are stored at the telephone base and shared by all

• system handsets. Any changes made on one handset or the telephone base apply to all.

Only one handset or the telephone base can review the directory at a

• time. If another handset or the telephone base tries to enter the directory, its screen shows Not available at this time.

When there are no records in the directory, the screen shows

• Directory empty.

When the directory is full and you try to save an entry, the screen shows

• Directory is full.

When you try to save a number already stored in the directory, the screen

• shows Already saved.

Create a new directory entry

Using a handset:

Press the MENU softkey when the handset is not in use.

1. Press /VOL+/ or CID/VOL-/ to highlight DIRECTORY, then press the

2. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Store, then press the SELECT

3. softkey. The screen shows ENTER NUMBER.

Use the dialing keys to enter a telephone number.

Press OFF/CLEAR to backspace and erase a digit.

•

Press the PAUSE softkey to insert a dialing pause (a p appears).

•

Press /VOL+/ to move the cursor to the right or CID/VOL-/ to

• the left.

Press and hold OFF/CLEAR to exit and return to idle mode.

• Press the NEXT softkey to move to the name. The screen shows

5. ENTER NAME.

Use the dialing keys (see page 57) to enter the name.

Press OFF/CLEAR to backspace and erase a character.

•

Press /VOL+/ to move the cursor to the right or CID/VOL-/ to

• the left.

Press and hold OFF/CLEAR to exit and return to idle mode.

• Press the SAVE softkey, then the screen shows the saved directory.

Telephone operation

Create a new directory entry (continued)

Using the telephone base:

Press the MENU softkey when the telephone base is not in use.

1. Press /VOL+ or VOL-/ to highlight Directory, then press the

2. SELECT softkey.

Press /VOL+ or VOL-/ to highlight Store, then press the SELECT

3. softkey. The screen shows ENTER NUMBER.

Use the dialing keys to enter a telephone number.

Press CANCEL / to backspace and erase a digit.

•

Press the PAUSE softkey to insert a dialing pause (a p appears).

•

Press /VOL+ to move the cursor to the right or VOL-/ to the left.

•

Press and hold CANCEL/ to exit and return to idle mode.

• Press the NEXT softkey to move to the name. The screen shows

5. ENTER NAME.

Use the dialing keys (see page 57) to enter the name.

Press CANCEL / to backspace and erase a character.

•

Press /VOL+ to move the cursor to the right or VOL-/ to the left.

•

Press and hold CANCEL/ to exit and return to idle mode.

• Press the SAVE softkey, then the screen shows the saved directory.

Telephone operation

Character chart

Use the dialing keys and the chart below to enter a name (up to 15 characters). Each press of a particular key causes the characters to be displayed in the following order:

Number

key

1 1 #

2 A B C 2 a b c

3 D E F 3 d e f

4 G H I 4 g h i

5 J K L 5 j k l

6 M N O 6 m n o

7 P Q R S 7 p q r s

8 T U V 8 t u v

9 W X Y Z 9 w x y z

0 0

# space

1 2 3 4 5 6 7 8 9

Characters by num be r o f key pr es ses

, - . &

? ! / ( ) @

When entering a name in the directory, the rst letter of each word is

automatically capitalized.

Telephone operation

Review the directory

Entries are sorted alphabetically.

To review the directory: Using a handset:

Press /VOL+/ when the handset is not in use.

1. Press /VOL+/ or CID/VOL-/ to browse the entries.

- OR -

Press the MENU softkey when the handset is not in use.

1. Press /VOL+/ or CID/VOL-/ to highlight DIRECTORY, then press the

2. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Review, then press the

3. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to browse the entries.

Using the telephone base:

Press the MENU softkey when the telephone base is not in use.

1. Press /VOL+ or VOL-/ to highlight Directory, then press the

2. SELECT softkey.

Press /VOL+ or VOL-/ to highlight Review, then press the

3. SELECT softkey.

Press /VOL+ or VOL-/ to browse the entries.

Alphabetical search

To start an alphabetical search:

Follow the steps in Review the directory above to enter the directory.

1. Use the dialing keys to enter the letters associated with the name. For

2. example, if you have name entries Jenny, Jessie, Kristen and Laura in your directory, press 5 (JKL) once to see Jenny, twice to see Jessie, three times to see Kristen, or four times to see Laura. If there is no name

matching the rst letter entered, the next closest match in alphabetical

order appears. If necessary, use /VOL+/ or CID/VOL-/ to browse.

Telephone operation

Dial a directory entry

You can dial a directory entry on either a home or cell line.

To dial a directory entry: Using a handset:

Search for the desired entry in the directory (see Review the directory or

1. Alphabetical search on page 58).

Press /HOME/FLASH or , or /CELL.

Using the telephone base:

Search for the desired entry in the directory (see Review the directory or

1. Alphabetical search on page 58).

Press /HOME or /CELL.

Edit a directory entry

Using a handset:

Search for the desired entry in the directory (see Review the directory or

1. Alphabetical search on page 58).

When the desired entry appears, press the EDIT softkey. The screen

2. shows EDIT NUMBER.

Use the dialing keys to edit the number.

Press OFF/CLEAR to backspace and erase a digit.

•

Press the PAUSE softkey to insert a dialing pause (a p appears).

•

Press /VOL+/ to move the cursor to the right or CID/VOL-/ to

• the left.

Press and hold OFF/CLEAR to exit and return to idle mode.

• Press the NEXT softkey to move to the name. The screen shows

4. EDIT NAME.

Use the dialing keys (see page 57) to edit the name.

Press OFF/CLEAR to backspace and erase a character.

•

Press /VOL+/ to move the cursor to the right or CID/VOL-/ to

• the left.

Press and hold OFF/CLEAR to exit and return to idle mode.

• Press the SAVE softkey, then the screen shows the saved directory.

Telephone operation

Edit a directory entry (continued)

Using the telephone base:

Search for the desired entry in the directory (see Review the directory or

1. Alphabetical search on page 58).

When the desired entry appears, press the EDIT softkey. The screen

2. shows EDIT NUMBER.

Use the dialing keys to enter a telephone number.

Press CANCEL / to backspace and erase a digit.

•

Press the PAUSE softkey to insert a dialing pause (a p appears).

•

Press /VOL+ to move the cursor to the right or VOL-/ to the left.

•

Press and hold CANCEL/ to exit and return to idle mode.

• Press the NEXT softkey to move to the name. The screen shows

4. EDIT NAME.

Use the dialing keys (see page 57) to enter the name.

Press CANCEL / to backspace and erase a character.

•

Press /VOL+ to move the cursor to the right or VOL-/ to the left.

•

Press and hold CANCEL/ to exit and return to idle mode.

• Press the SAVE softkey, then the screen shows the saved directory.

Delete a directory entry

You can delete a directory entry using a handset or the telephone base. Once a directory entry is deleted, it cannot be retrieved.

To delete an entry:

Search for the desired entry in the directory (see Review the directory or

1. Alphabetical search on page 58).

When the desired entry appears, press the DELETE softkey. The screen

2. then shows the next alphabetical entry in the directory.

Telephone operation

About caller ID

This product supports caller ID services provided by most telephone service providers. Depending on your service subscription, you may see the caller’s number, or the caller’s name and number from the telephone service provider

after the rst or second ring. Caller ID from the home line allows you to see

the name, number, date and time of the incoming calls. However, caller ID from the cell line only shows the number of the incoming caller and the name of the paired Bluetooth cell phone; date and time of the call is not shown.

Information about caller ID with call waiting

Caller ID with call waiting lets you see the name and telephone number of the caller before answering the telephone, even while on another call.

It may be necessary to change your telephone service to use this feature. Contact your telephone service provider and cell phone service provider if:

You have both caller ID and call waiting, but as separate services (you

• may need to combine these services).

You have only caller ID service, or only call waiting service.

• You do not subscribe to any caller ID or call waiting services.

•

There are fees for caller ID services. In addition, services may not be available in all areas.

Caller ID information is available only if both you and the caller are in areas offering caller ID service, and if both telephone service providers use compatible equipment.

Caller ID information may not be available for every incoming call. Callers may intentionally block their names and/or telephone numbers. To view call log entries with numbers between 16 and 24 digits, you must save the entry to the directory (see page 65).

You can use this product with regular caller ID service, or you can use this product’s other features without subscribing to caller ID or combined caller ID with call waiting service.

Telephone operation

Caller ID history

If you subscribe to caller ID service provided by your telephone service provider and/or cell phone service provider, information about each caller

appears after the rst or second ring. If you answer a call before the caller

information appears on the screen, it is not saved in the call log.

The call log stores up to 100 entries. Each entry has up to 24 digits for the

• phone number and 15 characters for the name. If the name has more than 15 characters, only the rst 15 characters are shown and saved in the call log.

You can review, redial, and copy an entry into the directory.

• Entries are in reverse chronological order.

• When the call log is full, the oldest entry is deleted to make room for new

• incoming call information.

XX New call(s) shows when there are new call log entries (including

•

missed and unreviewed calls).

Call log empty shows when there are no records in the call log.

•

Only one handset or the telephone base can review the call log at a

• time. If a handset tries to enter the call log while another handset or the telephone base is already in it, Not available at this time appears.

If the phone number has more than 24 digits, it is not saved or shown in the call log.

Missed calls indicator

When there are unreviewed calls in the call log, the handset and the telephone base show XX New call(s).

Each time you review a call log entry marked NEW, the number of missed calls decreases by one.

When you have reviewed all the missed calls, the missed calls indicator no longer shows.

If you do not want to review the missed calls one by one, press and hold OFF/CLEAR on the handset or CANCEL/ on the telephone base to erase the missed calls indicator. All the entries are then considered old and kept in the call log.

HANDSET X

XX New calls

3:45am 12/25

REDIAL

NEW

800-595 -9511

3:45am 12/25

VTech

DELETE

SAVE

Telephone operation

Memory match

When the incoming telephone number exactly matches a telephone number in your directory, the name on the screen matches the corresponding name in your directory.

For example, when Linda Jones calls, her name appears as Linda if this is how you entered it into your directory.

The number shown in the call log is in the format sent by the telephone service provider. The telephone service provider usually delivers ten-digit phone numbers (area code plus phone number). If the telephone number of the caller does not exactly match a number in your directory, the name appears as it is delivered by the telephone ser vice provider. For example, if the telephone service provider includes the area code but your directory number does not, the name appears as delivered by the telephone company.

Review the call log

Using a handset:

Press CID/VOL-/ when the handset is not in use.

1. Press /VOL+/ or CID/VOL-/ to browse the entries.

-OR-

Press the MENU softkey when the handset is not in use.

1. Press /VOL+/ or CID/VOL-/ to highlight CALL LOG, then press the

2. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Review, then press the

3. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to browse the entries.

Using the telephone base:

Press the MENU softkey when the handset is not in use.

1. Press /VOL+ or VOL-/ to highlight Call log, then press the

2. SELECT softkey.

Press /VOL+ or VOL-/ to highlight Review, then press the

3. SELECT softkey.

Press /VOL+ or VOL-/ to browse the entries.

The name (if available), telephone number, date and time of all incoming

• calls are shown on the screen.

You hear a double beep when you reach the beginning or end of the

• call log.

Telephone operation

Make a call log entry ready to dial

Although the call log entries received have 10 digits (the area code plus the seven-digit number), in some areas, you may need to dial only the seven digits, or 1 plus the seven digits, or 1 plus the area code plus the seven digits. You can change the number of digits that you dial from the call log or store to the directory.

While reviewing the call log, press # repeatedly to show different dialing options for local and long distance numbers before dialing or saving the telephone number in the directory.

Press 1 repeatedly if you need to add or remove 1 in front of the telephone number before dialing or saving it in the directory.

Dial a call log entry

Using a handset:

Search for the desired entry in the call log (see Review the call log on

1. page 63).

When the desired entry appears and is in the correct format for dialing,

2. press /HOME/FLASH or using the home line, or /CELL using the cell line.

Using the telephone base:

Search for the desired entry in the call log (see Review the call log on

1. page 63).

When the desired entry appears and is in the correct format for dialing,

2. press /HOME using the home line, or /CELL using the cell line.

800-595-9511

1-800-595-9511

595-9511

1-595-9511

595-9511

1-595-9511

800-595-9511

1-800-595-9511

Telephone operation

Save a call log entry to the directory

Using a handset:

Select a desired entry in the call log (see Review the call log on

1. page 63).

When the desired entry appears, press the SAVE softkey. The screen

2. shows EDIT NUMBER.

Use the dialing keys to edit the number.

Press OFF/CLEAR to backspace and erase a digit.

•

Press the PAUSE softkey to insert a dialing pause (a p appears).

•

Press /VOL+/ to move the cursor to the right or CID/VOL-/ to

• the left.

Press and hold OFF/CLEAR to exit and return to idle mode.

• Press the NEXT softkey to move to the name. The screen shows

4. EDIT NAME.

Use the dialing keys (see page 57) to edit the name.

Press OFF/CLEAR to backspace and erase a character.

•

Press /VOL+/ to move the cursor to the right or CID/VOL-/ to

• the left.

Press and hold OFF/CLEAR to exit and return to idle mode.

• Press the SAVE softkey, then the screen shows the saved directory.

Using the telephone base:

Select a desired entry in the call log (see Review the call log on

1. page 63).

When the desired entry appears, press the SAVE softkey. The screen

2. shows EDIT NUMBER.

Use the dialing keys to edit a telephone number.

Press CANCEL / to backspace and erase a digit.

•

Press the PAUSE softkey to insert a dialing pause (a p appears).

•

Press /VOL+ to move the cursor to the right or VOL-/ to the left.

•

Press and hold CANCEL/ to exit and return to idle mode.

• Press the NEXT softkey to move to the name. The screen shows

4. EDIT NAME.

Use the dialing keys (see page 57) to edit the name.

Press CANCEL / to backspace and erase a character.

•

Press /VOL+ to move the cursor to the right or VOL-/ to the left.

•

Press and hold CANCEL/ to exit and return to idle mode.

• Press the SAVE softkey, then the screen shows the saved directory.

Telephone operation

Delete from the call log

You can use a handset or the telephone base to delete from the call log.

To delete a single entry:

Select a desired entry in the call log (see Review the call log on

1. page 63).

When the desired entry appears, press the DELETE softkey. The screen

2. shows the previous call log entry.

To delete all entries: Using a handset:

Press the MENU softkey when the handset is not in use.

1. Press /VOL+/ or CID/VOL-/ to highlight CALL LOG, then press the

2. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Del all calls, then press the

3. SELECT softkey. The screen displays Delete all calls?

Press the YES softkey to conrm or the NO softkey to exit.

Using the telephone base:

Press the MENU softkey when the telephone base is not in use.

1. Press /VOL+ or VOL-/ to highlight Call log, then press the

2. SELECT softkey.

Press /VOL+ or VOL-/ to highlight Del all calls, then press the

3. SELECT softkey. The screen displays Delete all calls?

Press the YES softkey to conrm or the NO softkey to exit.

Call log display screen messages

Displays When

Private name

Private number

Private caller

Unknown name

Unknown number

Unknown caller

Long distance OR L (before the caller’s number)

The caller is blocking the name.

The caller is blocking the telephone number.

The caller is blocking the name and number.

This caller’s name is unavailable.

This caller’s number is unavailable.

No information is available about this caller.

It is a long distance call.

Answering system operation

Answering system and voicemail

Your telephone has separate indicators for two different types of voice messages: those left on its built-in answering system and those left at your service provider’s voicemail (fees may apply). Your telephone’s built-in answering system messages and voicemail messages are separate. Each alerts you to new messages differently. If and New voicemail display on the telephone base and handset, your telephone service provider is indicating that it has new voicemail for you. To listen to your voicemail, you typically dial an access number provided by your telephone service provider, followed by a security code or PIN. To listen to messages recorded on your digital answering system, press /PLAY/STOP on the telephone base (page 68).

Some service providers bundle or combine multiple services like voicemail and call waiting, so you may not be aware that you have voicemail. To check what services you have and how to access them, contact your telephone service provider.

You can use your telephone answering system and voicemail together by setting your built-in answering system to answer before voicemail answers. To learn how to program your voicemail settings, contact your telephone service provider. Set your answering system to answer calls at least two rings earlier than your voicemail is set to answer. For example, if your voicemail answers after six rings, set your answering system to answer after four rings. Some voicemail providers may program the delay before answering calls in seconds instead of rings. In this case, allow six seconds per ring when determining the appropriate setting. By doing this, if you are on a call, or if the answering system is busy recording a message and you receive another call, the second caller can leave a voicemail message.

Message capacity

The answering system can record and store up to 99 messages. Each message can be up to four minutes in length. The total storage capacity for the announcement, messages and memos is approximately 14 minutes. The actual recording time depends on individual message characteristics. Messages remain available for replay until you delete them.

New message indication

When there are new answering system messages, shows on the handset and the telephone base.

When the new message alert tone is turned on, the telephone base beeps every 10 seconds when there are unreviewed messages.

Call intercept

When a caller is leaving a message on your answering system, you can stop recording and talk to the caller by pressing /HOME/FL ASH or on the handset or /HOME on the telephone base.

Answering system operation

Message playback

If you have new messages, the handset displays New messages. The telephone base screen backlight turns on and XX New messages ashes. The backlight will turn off after you listen to the new messages. You can press the OFF softkey to turn the backlight off without listening to the messages.

When playback begins, the screen displays PLAYING MESSAGE and you hear the total number of messages followed by the day and time of the

message. The telephone plays only the new messages (oldest rst). If there are no new messages, the telephone plays back all messages (oldest rst).

After the last message, the telephone announces, the screen displays End of messages.

To play messages with the telephone base:

Press to listen to messages.

Options during playback:

Press /VOL+ or VOL-/ to adjust the speaker volume.

•

Press to skip to the next message.

•

Press CANCEL/ to repeat the message currently playing. Press

• CANCEL/ twice to listen to the previous message.

Press FLASH/X to delete the current message. The system advances to

• the next message.

Press to stop.

•

To play messages with a handset:

Press the MENU softkey when the handset is not in use.

1. Press /VOL+/ or CID/VOL-/ to highlight ANS. SYSTEM, then press the

2. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Play msgs, then press the

3. SELECT softkey.

Options during playback:

Press /VOL+/ or CID/VOL-/ to adjust the speaker volume.

•

Press 6 to skip to the next message.

•

Press 4 to repeat the message currently playing. Press 4 twice to listen

• to the previous message.

Press 3 to delete the current message. The system advances to the

• next message.

Press 5 to stop.

•

Press the BACK softkey to exit and return to the previous menu.

•

When the answering system has less than ve minutes of recording time

left, the remaining time is announced. When the answering system has no recording time left, it announces “Memory is full,” and Rec time full displays.

“End of messages,”

and

Answering system operation

Delete all old messages

Using the telephone base:

Press the MENU softkey when the telephone base is not in use.

1. Press /VOL+ or VOL-/ to highlight Ans. system, then press the

2. SELECT softkey.

When Del all old displays, press the SELECT softkey. The telephone

3. base displays Delete all old messages?

Press the YES softkey to conrm or the NO softkey to exit.

Using a handset:

Press the MENU softkey when the handset is not in use.

1. Press /VOL+/ or CID/VOL-/ to highlight ANS. SYSTEM, then press the

2. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Del all old, then press the

3. SELECT softkey. The handset displays Delete all old messages?

Press the YES softkey to conrm or the NO softkey to exit.

You can only delete old messages, which are messages you have played.

Answering system operation

Record and play memos

Memos are your own recorded messages used as reminders for yourself or others using the same answering system. You can record your own memos using a system handset or the telephone base. Playback and delete them the same way as incoming messages.

To record a memo Using the telephone base:

Press the MENU softkey when the telephone base is not in use.

1. Press /VOL+ or VOL-/ to highlight Ans. system, then press the

2. SELECT softkey.

Press /VOL+ or VOL-/ to highlight Record memo, then press the

3. SELECT softkey.

The system announces, “

done

.” After the tone, speak towards the microphone.

Press 5 or the STOP softkey when nished recording. The handset

5. announces, “

Recorded

Using a handset:

Press the MENU softkey when the handset is not in use.

1. Press /VOL+/ or CID/VOL-/ to highlight ANS. SYSTEM, then press the

2. SELECT softkey.

Press /VOL+/ or CID/VOL-/ to highlight Record memo, then press the

3. SELECT softkey.

The system announces, “

done

.” After the tone, speak towards the microphone.

Press 5 or the STOP softkey when nished recording. The handset

5. announces, “

• memory is full.

•

Recorded

The system announces “Memory is full,” if you record a memo when the

Each memo can be up to four minutes in length. Memos shorter than one second are not recorded.

Recorded after the tone. Press 5 when you are

” and then returns to the previous menu.

Recorded after the tone. Press 5 when you are

” and then returns to the previous menu.

Answering system operation

Remote access

A two-digit security code is required to access the answering system remotely from any touch tone telephone. The preset code is 19. See Remote access code on page 40 to change it.

Dial your telephone number from any touch tone telephone.

1. When the system plays your announcement, enter the two-digit

2. security code.

You can also enter one of the following remote commands.

Command Function

1 Play all messages.

2 Play only new messages.

3 Delete the current message (during playback).

33 Delete all old messages.

4 Repeat the current message (during playback).

5 Stop.

*5 Hear a list of remote commands.

6 Skip to the next message (during playback).

*7 Record a new announcement.

8 End the call.

0 Turn the answering system on or off.

Hang up or press 8 to end the call.

If you do not press any keys after you enter the remote access code, all new

• messages play. If there are no new messages, all old messages play.

Once the new messages have played, the telephone announces the help

• menu options. If you do not press any key within 20 seconds, the remote access call automatically disconnects.

When the answering system is turned off, the telephone answers after 10

• rings, and announces,

When the memory is full, the answering system answers incoming calls

• after 10 rings and announces,

“Please enter your remote access code.”

“Memor y is full. Enter the remote access code.”

Appendix

Screen display messages

Already saved

Base is calling

Bluetooth system busy

Call log empty

Calling base

Calling handset X

(for models with two or more handsets)

Cell

Cell call on hold

Cell line in use

Charging

Directory empty

Directory is full

Ended

Handset X is calling

(for models with two or more handsets)

Home

Home call answered

Home call on hold

Home & cell calls on hold

Home line in use

Incoming call

Intercom

Intercom ended

The telephone number entered is already stored in the directory.

The telephone base is calling another handset.

You are trying to use a handset to make a cell call while another handset is already in cell call predial mode.

There are no call log entries.

A system handset is calling the telephone base.

The telephone base or the handset is calling another handset.

The cell line is in use.

A call on the cell line has been put on hold.

A system handset or the telephone base on the cell line is in use.

The handset with low battery is recharging.

There are no directory entries.

The directory is full.

You have just ended a call.

Another system handset is calling.

The home line is in use.

The answering system has answered the incoming home call.

A call on the home line has been put on hold

Calls on the home and cell lines have been put on hold.

A system handset, the telephone base or another telephone on the same home line is in use.

There is an incoming call.

The handset or the telephone base is on an intercom call.

You have just ended an intercom call.

Appendix

Screen display messages (continued)

KEYPAD LOCKED

Low battery

Microphone ON

Muted

New voicemail

No connected cellular phones

No home line

No signal, call ended

Not available at this time

Paging all handsets

** Paging **

Place in charger

Rec time full

Ringer mute

Saved

Searching for BASE

Unable to call try again

Unable to save

XX New calls

XX New messages

The keypad is locked.

The battery needs to be recharged.

Mute is turned off and the person on the other end can hear you.

You have turned off the handset microphone. The other party cannot hear you but you can hear the other party.

There are new voicemail message(s) from your telephone service provider.

There is no cell phone connected when you tries to make a call on the cell line.

There is no telephone line connected.

Communication between handset and telephone base is lost during a call.

One handset or the telephone base is already viewing the call log or directory and another handset/telephone base attempts to review it.

The telephone base is paging handset(s).

The system handset is paged.

The battery is very low. Place the handset in the telephone base for recharging.

The answering system has no recording time left.

The ringer is muted temporarily during an incoming call.

Your selection has been saved.

The cordless handset is searching for the telephone base.

You try to make an intercom call, but the handset you are calling is in the directory, in the call log, out of range or on an outside call, or the telephone base is in the directory or call log or on an outside call.

You try to save a caller ID entry with no name or number.

There are unreviewed calls in your call log.

You have new messages in the answering system.

Appendix

Handset and telephone base indicators

Handset lights

On when the handset speakerphone is in use.

/CELL

/HOME/FLASH

CHARGE On when the handset is charging in the telephone base.

Flashes quickly when there is an incoming cell call.

Flashes slowly when the cell line is on hold.

Flashes quickly when there is an incoming home call.

Flashes slowly when the home line is on hold.

Telephone base lights

/CELL

/HOME

On when the cell line is in use.

Flashes quickly when there is an incoming cell call.

Flashes slowly when the cell line is on hold.

On when the home line is in use.

Flashes quickly when there is an incoming home call.

Flashes slowly when the home line is on hold.

Appendix

Handset icons

1 2

HOME line - on steadily when the home line is in use or there is an incoming home call.

CELL line - on steadily when the cell line is in use or there is an incoming cell call.

Bluetooth connected device(s) - indicates that there are Bluetooth connected devices on the active devices list.

Bluetooth disconnected device(s) - indicates that there are Bluetooth disconnected devices on the active devices list.

Speakerphone - the speakerphone is in use.

Ringer off - on steadily when all the ringers of Home, Cellular 1 and Cellular 2 are turned off. Flashes when only

one or two of the ringers are turned off.

New voicemail - indicates you have new voicemail message(s) from the telephone service provider.

New answering system message - indicates you have a new answering system message(s).

Battery status - animates when the battery is charging. Becomes solid when the battery is fully charged.

ANS O N

NEW

MUTE

Battery status - ashes when the battery is low and needs

charging.

Answering system on - indicates that the answering system is turned on to answer incoming home calls.

New call log - indicates that the missed call is new.

Mute - the microphone is muted.

Appendix

Telephone base icons

HOME line - on steadily when the home line is in use or

there is an incoming home call.

1 2

1 or 2

ANS O N

NEW

CELL line - on steadily when the cell line is in use or there is an incoming cell call.

Bluetooth connected device(s) - indicates that there are Bluetooth connected devices on the active devices list.

Bluetooth disconnected device(s) - indicates that there are Bluetooth disconnected devices on the active devices list.

Bluetooth wireless headset - on steadily when a Bluetooth wireless headset is in use on the home line.

Ringer off - on steadily when all the ringers of Home, Cellular 1 and Cellular 2 are turned off. Flashes when only

one or two of the ringers are turned off.

New voicemail - indicates you have new voicemail message(s) from the telephone service provider.

New answering system message - indicates you have a new answering system message(s).

Answering system on - indicates that the answering system is turned on to answer incoming home calls.

New call log - indicates that the missed call is new.

MUTE

Mute - the microphone is muted.

Appendix

Battery

It takes up to 16 hours for the battery to be fully charged. When it is fully charged, you can expect the following performance:

Operation Operating time

While in handset use (talking*) Up to 11 hours

While in speakerphone mode (talking*) Up to six hours

While not in use (standby**) Up to ve days

*Operating times vary depending on your actual use and the age of the battery.

**Handset is not charging or in use.

The battery needs charging when:

A new battery is installed in the handset.

• The handset beeps every minute while on a call.

• The handset beeps and Low battery displays on the handset.

•

Place in charger displays on the handset.

•

A battery is properly installed but the screen is blank.

•

CAUTION:

To reduce the risk of re or injury, read and follow these instructions:

Use only the battery(ies) provided or equivalent. To order a replacement, visit our

• website at ww w.vtechphones.com or call 1 (800) 595-9511.

Do not dispose of the battery(ies) in a re. Check with local waste management

• codes for special disposal instructions.

Do not open or mutilate the battery(ies). Released electrolyte is corrosive and

• might cause burns or injury to the eyes or skin. The electrolyte might be toxic if swallowed.

Exercise care in handling batteries in order not to create a short circuit with

• conductive materials.

Charge the battery(ies) provided with or identied for use with this product only in

•

accordance with the instructions and limitations specied in this manual.

Observe proper polarity orientation between the battery and metallic contacts.

• To prevent re or shock hazard, do not expose this product to water or any type

• of moisture.

Appendix

Expand your telephone system

The handset provided with your telephone system is pre-registered as HANDSET. Additional handsets registered to the telephone system are assigned in sequential order. If you register another new handset to your telephone system, the new registered handset is assigned HANDSET 2. This telephone system accommodates up to 12 handsets.

Add and register a handset (optional)

You can add new handsets (LS6204, purchased separately) to your telephone system, but each handset must be registered with the telephone base before use. When rst purchased, each expansion handset shows NOT REGISTERED. You may need to charge the handset before registering to the telephone base. For more details on battery charging, see the table on page 5.

To register a handset:

Place the unregistered handset in the telephone base. If To register,

1. press HOLD on BASE for 4 sec does not appear on the handset screen after a few seconds, remove the handset and place it in the telephone base again.

On the telephone base, press and hold HOLD for about four seconds until

2. the telephone base displays Registering handset. The handset shows Please wait... and it takes up to 60 seconds to complete the registration. The handset shows HANDSET X Registered (X represents the handset number assigned) and you hear a beep when the registration completes.

If the registration fails, the handset shows NOT REGISTERED. To reset

• the handset, remove the handset from the telephone base and place it back in. Try the registration process again.

You cannot register a handset if any other system handset is in use.

•

Appendix

Replace a handset

If you want to replace a handset or re-assign the designated handset number of a registered handset, you must deregister all the handsets and then individually register each handset.

To make deregistration easier, read all of the instructions on this page before you begin.

To deregister all handsets:

Press and hold HOLD on the telephone base for about 10 seconds until

1. the telephone base displays Deregister all handsets?

Press the YES softkey.

2. All system handsets show Searching for BASE. The deregistration

3. process takes about 10 seconds to complete. All handsets show NOT REGISTERED when the deregistration completes.

If deregistration fails, the handset displays Registration failed and then To register, pick up handset from CHARGER. Pick up the registered handset and try the deregistration process above again.

You cannot deregister a handset if any system handset is in use.

Appendix

Troubleshooting

If you have difculty with your telephone, please try the suggestions below.

For Customer Service, visit our website at www.vtechphones.com or call 1 (800) 595-9511.

I cannot use the keypad.

To prevent accidental presses of keys, the keypad locks after 10 seconds of no

• key presses when you are not on a call (page 23). While you are on a call using

the speakerphone, if no keys are pressed within ve seconds, the keypad locks

automatically. Press the UNLOCK softkey to use the keypad. You must unlock the keypad before dialing 911.

•

I cannot pair my cell phone to the telephone base.

Make sure the Bluetooth function of your cell phone is turned on. See the user’s

• manual of your cell phone for more information.

Remove VTech LS6245 from your cell phone’s handsfree device history list (see

• the user’s manual of your cell phone for more information).

Carefully follow the pairing instructions on page 14 and make sure that your cell

• phone is not connected to any other Bluetooth device.

Turn off your cell phone, then turn it on again.

• Reset the telephone base. Unplug the unit’s electrical power. Wait for

• approximately 15 seconds, then plug it back in. Repeat the above suggestions.

I cannot pair my headset to the telephone base

Make sure that your Bluetooth headset is in discoverable mode when pairing with

• the telephone base. See the user’s manual of your headset for more information on how to set your headset in discoverable mode.

Carefully follow the pairing instructions on page 15 and make sure that your

• headset is not connected to any other Bluetooth device.

Reset the telephone base. Unplug the unit’s electrical power. Wait for

• approximately 15 seconds, then plug it back in. Repeat the above suggestions.

I cannot connect my cell phone with the telephone base.

Make sure that the Bluetooth function of your cell phone is turned on. See the

• user’s manual of your cell phone for more information.

Make sure that your Bluetooth cell phone is not connected to any other Bluetooth

• device.

Turn off your cell phone, then turn it on again.

• Make sure that your cell phone is connected and on the active devices list.

• For some cell phones, you must authorize VTech LS6245 device in your cell

• phone’s Bluetooth feature. See the user’s manual of your cell phone for more information.

Manually connect your cell phone to VTech LS6245. Refer to the user’s manual of

• your cell phone for more information.

Appendix

Troubleshooting

I cannot connect my headset with the telephone base.

Make sure that your Bluetooth headset is not connected to any other

• Bluetooth device.

Make sure that your headset is connected and on the active devices list.

•

I cannot put my headset in discoverable mode.

Refer to the user’s manual of your headset for information on how to set your

• headset in discoverable mode.

Make sure that the headset is not connected to any other Bluetooth device in order

• to successfully pair and connect to the telephone base.

Carefully follow the pairing process on page 15.

• Reset the telephone base. Unplug the unit’s electrical power. Wait for

• approximately 15 seconds, then plug it back in. Repeat the above suggestions.

I cannot nd VTech LS6245 on my cell phone.

Make sure that the telephone base is in discoverable mode. Carefully follow the

• setup instructions on page 14.

Make sure that you manually set your cell phone to search for devices.

• Remove VTech LS6245 from your cell phone’s handsfree device history list (see

• the user’s manual of your cell phone).

Turn off your cell phone, then turn it on again.

• Reset the telephone base. Unplug the unit’s electrical power. Wait for

• approximately 15 seconds, then plug it back in. Repeat the above suggestions.

I don’t know how to search for or add new devices on my cell phone.

Most cell phones have the Bluetooth feature in the connection or setup menus.

• Please refer to the user’s manual of your cell phone.

In general, press the menu key on your cell phone, then look for the Bluetooth

• menu in the settings or connection menu. In the Bluetooth menu, select the option to search for or add new devices.

My cell phone disconnects with the telephone base.

Turn off your cell phone, then turn it on again.

• Make sure that you are not using your cell phone when on a cell call.

•

My cell phone is connected to the telephone base, but I cannot make a cell call.

Make sure that your cell phone is not in use when you are trying to make a

• cell call.

Make sure that your cell phone is compatible.

• For some smartphones, make sure that the cellular function is turned on.

•

Appendix

Troubleshooting

Bluetooth system busy appears on the display.

Make sure that your cell phone is not in use when connected and on the

• active devices list.

Make sure that your cell phone or headset is not connected to any other

• Bluetooth device.

LS6245 can only use one Bluetooth device at a time.

•

Unplug the telephone base power for 15 seconds, then plug it back in.

•

The PIN on the telephone base does not work.

The default PIN is 0000.

• If you have changed the PIN, it appears on the telephone base in the pairing process.

•

I cannot hear any audio on my telephone system when on a cell call.

Reset the telephone base. Unplug the unit’s electrical power. Wait for

• approximately 15 seconds, then plug it back in.

Turn off your cell phone, then turn it on again.

•

My telephone does not work at all.

Make sure the battery is installed and charged correctly (page 4). For optimum

• daily performance, return the handset to the telephone base or charger after use.

Make sure the power adapter is securely plugged into an outlet not controlled by a

• wall switch.

Make sure the telephone line cord is plugged rmly into the telephone base and

• the telephone wall jack.

Unplug the electrical power to the telephone base. Wait for approximately 15

• seconds, then plug it back in. Allow up to one minute for the cordless handset and telephone base to synchronize.

Charge the battery in the handset for up to 16 hours.

• If the batter y is completely depleted, it can take up to 10 minutes to charge the

• handset before HANDSET X appears on the screen (page 5).

Remove and re-insert the battery. If that still does not work, it might be necessary to

• purchase a new battery.

Disconnect the telephone base from the telephone wall jack and plug in a working

• telephone. If the other telephone does not work, the problem is probably in the wiring or the telephone ser vice. Call your telephone service provider.

Low battery shows on screen.

Place the handset in the telephone base for recharging.

• Remove and re-install the battery and use it until fully depleted, then recharge the

• handset in the telephone base for up to 16 hours.

If the above measures do not correct the problem, replace the battery.

•

Appendix

Troubleshooting

The battery does not charge in the handset or the handset battery does not accept charge.

Make sure the handset is placed in the telephone base correctly. The charge light

• on the handset should be on.

Remove and reinstall the battery, then charge for up to 16 hours.

• If the handset is in the telephone base but the charge light on the handset is not

• on, refer to The CHARGE light is off in this section.

If the batter y is completely depleted, it can take up to 10 minutes to charge the

• handset before HANDSET X appears on the screen (page 5).

Purchase a new battery. Refer to the Battery section (page 77).

•

The CHARGE light is off.

Clean the charging contacts on the handset and telephone base each month with

• a pencil eraser or a dry non-abrasive fabric.

Make sure the power adapter and telephone line cord are plugged in correctly

• and securely.

Unplug the power adapter. Wait for 15 seconds before plugging it back in. Allow up

• to one minute for the handset and telephone base to reset.

There is no dial tone.

First, try all the above suggestions.

• Move the handset closer to the telephone base. It may be out of range.

• The telephone line cord might be malfunctioning. Install a new telephone line cord.

• Disconnect the telephone base from the telephone wall jack and connect a

• different telephone. If there is no dial tone on this telephone either, the problem is in your wiring or telephone service. Contact your telephone service provider.

Appendix

Troubleshooting

The telephone does not ring when there is an incoming call.

Make sure the handset ringer volume is not set to off or the lowest level (page 26)

• and the telephone base ringer volume is not set to off or the lowest level (page 32).

Make sure the telephone line cord and power adapter are plugged in properly

• (page 3).

The handset may be too far from the telephone base. Move it closer to the

• telephone base.

There may be too many extension phones on the telephone line to allow all of them

• to ring simultaneously. Unplug some of them.

If the other telephones in your home are having the same problem, the problem

• is in the wiring or telephone service. Contact your telephone service provider (charges may apply).

Other electronic products may cause interference to your cordless telephone.

• Install your telephone as far away as possible from electronic devices such as: wireless routers, radios, cellular telephones, digital telephones, intercoms, room monitors, televisions, VCRs, personal computers, kitchen appliances, and other cordless telephones.

Test a working telephone at the telephone wall jack. If another telephone has the

• same problem, the problem is in the telephone wall jack. Contact your telephone service provider (charges may apply).

The telephone line cord may be malfunctioning. Install a new telephone line cord.

• Re-install the batter y and place the handset in the telephone base.

•

Wait for the handset to synchronize with the telephone base. Allow up to one

• minute for this to take place.

I cannot dial out.

First, try all the above suggestions.

• Make sure there is a dial tone before dialing. It is normal if the handset takes a

• second or two to synchronize with the telephone before producing a dial tone. Wait an extra second before dialing.

If the other telephones in your home are having the same problem, the problem

• is in the wiring or telephone service. Contact your telephone service provider (charges may apply).

Eliminate any background noise. Mute the cordless handset before dialing, or dial

• from another room in your home with less background noise.

Appendix

Troubleshooting

My handset beeps and is not performing normally.

Make sure the power cord is securely plugged into the telephone base. Plug

• the telephone base into a different working electrical outlet not controlled by a wall switch.

Move the handset closer to the telephone base. It may be out of range.

• Reset the telephone base by unplugging the electrical power to the base. Wait

• for 15 seconds and plug it back in again. Allow up to one minute for the cordless handset and the telephone base to synchronize.

Other electronic products may cause interference to your cordless telephone.

• Install your telephone as far away from these electronic devices as possible: wireless routers, radios, radio towers, pager towers, cellular telephones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless telephones.

There is interference during a telephone conversation. My calls fade out when I am using the cordless handset.

The handset may be out of range. Move it closer to the telephone base.

• If you subscribe to high-speed Internet service (digital subscriber line - DSL)

•

through your telephone line, you must install a DSL lter between the telephone base and the telephone wall jack. The lter prevents noise and caller ID problems

caused by DSL interference. Please contact your DSL service provider for more

information about DSL lters.

Appliances or other cordless telephones plugged into the same circuit as the

• telephone base can cause interference. Try moving the appliance or telephone base to another outlet.

Other electronic products may cause interference to your cordless telephone.

• Install your telephone as far away as possible from the following electronic devices: wireless routers, radios, radio towers, pager towers, cellular telephones, digital telephones, intercoms, room monitors, televisions, VCRs, personal computers, kitchen appliances, and other cordless telephones.

If your telephone is plugged in with a modem or a surge protector, plug the

• telephone (or modem/surge protector) into a different location. If this doesn’t solve the problem, re-locate your telephone or modem farther apart from each other, or use a different surge protector.

The location of your telephone base can impact the performance of your cordless

• phone. For better reception, install the telephone base in a centralized location

within your home or ofce, away from walls or other obstructions. In many

environments, elevating the telephone base improves overall performance. Disconnect the telephone base from the telephone wall jack and plug in a corded

• telephone. If calls are still not clear, the problem is probably in the wiring or telephone service. Contact your telephone service provider (charges might apply).

If the other telephones in your home are having the same problem, the problem

• is in the wiring or telephone service. Contact your telephone service provider (charges may apply).

Appendix

Troubleshooting

I hear other calls when using the telephone.

Disconnect the telephone base from the telephone wall jack. Plug in a different

• telephone. If you still hear other calls, the problem is probably in the wiring or telephone service. Call your telephone service provider.

I hear noise on the cordless handset and the keys do not work.

Make sure the telephone line cord is plugged in securely.

•

Registration failed appears on the handset.

Only one handset can be registered at a time. If you have multiple handsets to

• register, please follow the instructions on page 78 for the rst handset. Once a handset has been successfully registered, repeat the steps for each handset that needs to be registered.

Make sure that the telephone base and handset(s) are in idle mode when

• registering a handset.

Follow the steps on page 89 for the common cure for electronic equipment, then

• try again to register a handset.

My caller ID features are not working properly.

Caller ID is a subscription service. You must subscribe to this service from your

• telephone service provider for this feature to work on your telephone.

The caller may not be calling from an area which supports caller ID.

• Both you and the caller’s telephone companies must use equipment compatible

• with the caller ID service.

The caller ID information shows after the rst or second ring.

• If you subscribe to high-speed Internet service (digital subscriber line - DSL)

•

through your telephone line, you must install a DSL lter between the telephone base and the telephone wall jack. The lter prevents noise and caller ID problems

caused by DSL interference. Contact your DSL ser vice provider for more

information about DSL lters.

The telephone does not receive caller ID or the telephone does not show caller ID during call waiting.

Make sure you subscribe to caller ID with call waiting features provided by the

• telephone service provider.

The caller may not be calling from an area which supports caller ID.

• Both you and the caller’s telephone companies must use equipment compatible

• with caller ID service.

If you subscribe to high-speed Internet service (digital subscriber line - DSL)

•

through your telephone line, you must install a DSL lter between the telephone base and the telephone wall jack. The lter prevents noise and caller ID problems

caused by DSL interference. Contact your DSL ser vice provider for more

information about DSL lters.

Appendix

Troubleshooting

Caller ID entries do not match the numbers I need to dial.

Caller ID service delivers 10 digits (the area code plus the seven-digits number).

• If you need to dial something other 10 digits, see page 64 for instructions on changing the number.

If you dial seven digits for local calls, you may want to use the home area code

• feature (page 25 and page 31).

Searching for BASE shows in the handset screen.

The handset may be out of range. Move it closer to the telephone base.

• Make sure the power cord is securely plugged into the telephone base. Use a

• working electrical outlet not controlled by a wall switch.

Reset your telephone by unplugging the power adapter from the telephone base.

• Disconnect the battery from the cordless handset. Wait for 15 seconds, then plug in the power adapter and re-install the battery. Place the handset in the telephone base and allow up to one minute for the handset and telephone base to synchronize.

Other electronic products may prevent your handset and telephone base from

• communicating with each other. Install your telephone base as far away from these electronic devices as possible: wireless routers, radios, cellular telephones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless telephones.

and New voicemail appear on the handset telephone base and I don’t

know why.

Your telephone has voicemail indication that is separate from the built-in

• answering system. If and New voicemail appear on the handset and telephone base, your telephone has received a signal from your telephone ser vice provider that you have a voicemail message waiting for you to retrieve from your telephone service provider. Contact your telephone service provider for more information on how to access your voicemail.

I cannot retrieve my voicemail messages.

Your telephone has both a built-in answering system and voicemail indication.

• They are independent features and each alerts you to new messages differently (page 67). If you subscribe to voicemail service from your telephone service provider (charges may apply), contact your telephone service provider for more information on how to access your voicemail.

Appendix

Troubleshooting

The answering system does not answer after the correct number of rings.

Make sure the answering system is on. When the answering system is on,

• ANS ON should show on the handset and telephone base.

If toll saver is selected, the number of rings changes to two when there are new

• messages waiting (page 39).

If the memor y is full or if the answering system is off, the answering system

• answers after 10 rings.

In some cases, the answering system is affected by the ringing system used by the

• telephone service provider.

If you subscribe to voicemail service, change the number of rings so that your

• answering system answers before your voicemail answers (page 39). To determine how many rings will activate your voicemail, please contact your local telephone service provider.

If there is a fax machine connected to the same telephone line, try disconnecting

• the fax machine. It that solves the problem, consult your fax machine documentation for information on compatibility with answering systems.

The outgoing announcement is not clear.

When recording the announcement, make sure you speak in a normal tone of

• voice towards the microphone of the handset.

Make sure there is no background noise when recording.

•

The messages on the answering system are very difcult to hear.

Press /VOL+ on the telephone base or handset to increase the speaker

• volume.

The answering system does not record messages.

Make sure the answering system is on.

• When the answering machine memory is full, it does not record new messages

• until some old messages are deleted.

If you subscribe to voicemail service, change the number of rings so that your

• answering system answers before your voicemail answers (page 39). To determine how many rings will activate your voicemail, please contact your local telephone service provider.

If there is a fax machine connected to the same telephone line, try disconnecting

• the fax machine. It that solves the problem, consult your fax machine documentation for information on compatibility with answering systems.

Appendix

Troubleshooting

The messages on the answering system are incomplete.

If a caller leaves a very long message, part of it may be lost when the answering

• system disconnects the call after four minutes.

If the memor y on the answering system becomes full during a message, the

• answering system stops recording and disconnects the call.

If the caller’s voice is very soft, the answering system may stop recording and

• disconnect the call.

The answering system does not respond to remote commands.

Make sure your remote access code is correct (page 40).

• Make sure you are calling from a touch-tone telephone. When dialing a number,

• there should be tones. If there are clicks, then it is not a touch-tone telephone and cannot activate the answering system.

The answering system may not detect the remote access code when your

• announcement is playing. Wait until the announcement is over before entering the code.

There may be inter ference on the telephone line you are using. Press the dial pad

•

keys rmly when dialing.

Common cure for electronic equipment.

If the telephone is not responding normally, put the cordless handset in the

• telephone base. If it does not respond, try the following (in the order listed):

Disconnect the power to the telephone base.

• Disconnect the battery on the cordless handset.

• Wait a few minutes before connecting power to the telephone base.

• Re-install the batter y and place the cordless handset in the telephone base.

• Wait for the cordless handset to synchronize with the telephone base. Allow up to

• one minute for this to take place.

Appendix

Important safety instructions

When using your telephone equipment, basic safety precautions should always be followed to

reduce the risk of re, electric shock and injury, including the following:

Read and understand all instructions.

1. Follow all warnings and instructions marked on the product.

2. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners.

3. Use a dry non-abrasive cloth for cleaning.

Do not use this product near water.

4. Do not place this product on an unstable table, shelf, stand or other unstable surfaces.

5. Slots and openings in the back or bottom of the telephone base and handset are provided for

6. ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. This product should not be placed in any area where proper ventilation is not provided.

This product should be operated only from the type of power source indicated on the marking

7. label. If you are not sure of the type of power supply in your home, consult your dealer or local power company.

Do not allow anything to rest on the power cord. Do not install this product where the cord

8. may be walked on.

Never push objects of any kind into this product through the slots in the telephone base or

9. handset because they may touch dangerous voltage points or create a short circuit. Never spill liquid of any kind on the product.

To reduce the risk of electric shock, do not disassemble this product, but take it to an

10. authorized service facility. Opening or removing parts of the telephone base or handset other

than specied access doors may expose you to dangerous voltages or other risks. Incorrect

reassembling can cause electric shock when the product is subsequently used. Do not overload wall outlets and extension cords.

11. Unplug this product from the wall outlet and refer servicing to an authorized service facility

12. under the following conditions:

When the power supply cord or plug is damaged or frayed.

If liquid has been spilled onto the product.

If the product has been exposed to rain or water.

If the product does not operate normally by following the operating instructions. Adjust only

those controls that are covered by the operation instructions. Improper adjustment of other controls may result in damage and often requires extensive work by an authorized technician to restore the product to normal operation.

If the product has been dropped and the telephone base and/or handset has been damaged.

If the product exhibits a distinct change in performance.

Avoid using a telephone (other than cordless) during an electrical storm. There is a remote

13. risk of electric shock from lightning.

Do not use the telephone to report a gas leak in the vicinity of the leak.

14. Only put the handset of your telephone next to your ear when it is in normal talk mode.

15.

The power adapter is intended to be correctly oriented in a vertical or oor mount position.

16. The prongs are not designed to hold the plug in place if it is plugged into a ceiling or an underthe-table/cabinet outlet.

SAVE THESE INSTRUCTIONS

Appendix

Operating range

This cordless telephone operates with the ma ximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and telephone base can communicate over only a certain distance - which can vary with the locations of the telephone base and

handset, the weather, and the layout of your home or ofce.

When the handset is out of range, the handset displays Searching for base.

If there is a call while the handset is out of range, it might not ring, or if it does ring, the call might not connect well when you press /HOME/FLASH. Move closer to the telephone base, then press /HOME/FLASH to answer the call.

If the handset moves out of range during a telephone conversation, there might be interference.

To improve reception, move closer to the telephone base.

Maintenance

Taking care of your telephone

Your cordless telephone contains sophisticated electronic parts, so it must be treated with care.

Avoid rough treatment

Place the handset down gently. Save the original packing materials to protect your telephone if you ever need to ship it.

Avoid water

Your telephone can be damaged if it gets wet. Do not use the handset outdoors in the rain, or handle it with wet hands. Do not install the telephone base near a sink, bathtub or shower.

Electrical storms

Electrical storms can sometimes cause power surges harmful to electronic equipment. For your own safety, take caution when using electrical appliances during storms.

Cleaning your telephone

Your telephone has a durable plastic casing that should retain its luster for many years. Clean it only with a dry non-abrasive cloth. Do not use dampened cloth or cleaning solvents of any kind.

Remember that electrical appliances can cause serious injury if used when you are wet or standing in the water. If the telephone base should fall into the water, DO NOT RETRIEVE IT UNTIL YOU UNPLUG THE POWER CORD AND TELEPHONE LINE CORD FROM THE WALL. Then remove the telephone by the unplugged cords.

Appendix

About cordless telephones

Privacy: The same features that make a cordless telephone convenient create some

• limitations. Telephone calls are transmitted between the telephone base and the cordless handset by radio waves, so there is a possibility that the cordless telephone conversations could be intercepted by radio receiving equipment within range of the cordless handset. For this reason, you should not think of cordless telephone conversations as being as private as those on corded telephones.

Electrical power: The telephone base of this cordless telephone must be connected to a

• working electrical outlet. The electrical outlet should not be controlled by a wall switch. Calls cannot be made from the cordless handset if the telephone base is unplugged, switched off, or if the electrical power is interrupted.

Potential T V interference: Some cordless telephones operate at frequencies that may cause

• interference to televisions and VCRs. To minimize or prevent such interference, do not place the telephone base of the cordless telephone near or on top of a TV or VCR. If interference is experienced, moving the cordless telephone farther away from the TV or VCR often reduces or eliminates the interference.

Rechargeable batteries: Exercise care in handling batteries in order not to create a short

• circuit with conducting material such as rings, bracelets, and keys. The battery or conductor may overheat and cause harm. Observe proper polarity between the batter y and the bat tery charger.

Nickel- metal hydride rechargeable batteries: Dispose of these bat teries in a safe manner. Do

• not burn or puncture the battery. Like other batteries of this type, if burned or punctured, they could release caustic material which could cause injury.

The RBRC® seal

The RBRC® seal on the nickel-metal hydride battery indicates that V Tech Communications, Inc. is voluntarily participating in an industry program to collect and recycle these batteries at the end of their useful lives, when taken out of ser vice within the United States and Canada.

The RBRC® program provides a convenient alternative to placing used nickel-metal hydride batteries into the trash or municipal waste, which may be illegal in your area.

VTech’s participation in RBRC participating in the RBRC® program or at authorized V Tech product service centers. Please call

1-80 0- 8-BATTERYTM for information on Ni-MH batter y recycling and disposal bans/restrictions

in your area. VTech’s involvement in this program is part of its commitment to protecting our environment and conserving natural resources.

RBRC® is a registered trademark of Rechargeable Battery Recycling Corporation.

makes it easy for you to drop off the spent bat tery at local retailers

Appendix

Warranty

What does this limited warranty cover?

The manufacturer of this VTech Product warrants to the holder of a valid proof of purchase (“Consumer” or “you”) that the Product and all accessories provided in the sales package (“Product”) are free from defects in material and workmanship, pursuant to the following terms and conditions, when installed and used normally and in accordance with the Product operating instructions. This limited warranty extends only to the Consumer for Products purchased and used in the United States of America and Canada.

What will VTech do if the Product is not free from d efects in materials and workmanship during the limited warranty period (“Materially Defective Product”)?

During the limited warranty period, VTech’s authorized service representative will repair or replace at VTech’s option, without charge, a Materially Defective Product. If we repair the Product, we may use new or refurbished replacement parts. If we choose to replace the Product, we may replace it with a new or refurbished Product of the same or similar design. We will retain defective parts, modules, or equipment. Repair or replacement of the Product, at VTech’s option, is your exclusive remedy. VTech will return the repaired or replacement Products to you in working condition. You should expect the repair or replacement to take approximately 30 days.

How long is the limited warranty period?

The limited warranty period for the Product extends for ONE (1) YEAR from the date of purchase. If VTech repairs or replaces a Materially Defective Product under the terms of this limited warranty, this limited warranty also applies to repaired or replacement Product for a period of either (a) 90 days from the date the repaired or replacement Product is shipped to you or (b) the time remaining on the original one-year warranty; whichever is longer.

What is not covered by this limited warranty?

This limited warranty does not cover:

Product that has been subjected to misuse, accident, shipping or other physical damage,

improper installation, abnormal operation or handling, neglect, inundation, re, water or other

liquid intrusion; or

Product that has been damaged due to repair, alteration or modication by anyone other than

2. an authorized service representative of VTech; or

Product to the extent that the problem experienced is caused by signal conditions, network

3. reliability, or cable or antenna systems; or

Product to the extent that the problem is caused by use with non-VTech accessories; or

Product whose warranty/quality stickers, product serial number plates or electronic serial

5. numbers have been removed, altered or rendered illegible; or

Product purchased, used, serviced, or shipped for repair from outside the United States of

6. America or Canada, or used for commercial or institutional purposes (including but not limited to Products used for rental purposes); or

Product returned without a valid proof of purchase (see item 2 below); or

Charges for installation or set up, adjustment of customer controls, and installation or repair of

8. systems outside the unit.

Appendix

Warranty

How do you get warranty service?

To obtain warrant y service in the United States of America, visit www.vtechphones.com or call 1 (800) 595-9511. NOTE: Before calling for service, please review the user’s manual - a check of the Product’s controls and features may save you a service call.

Except as provided by applicable law, you assume the risk of loss or damage during transit and transportation and are responsible for delivery or handling charges incurred in the transport of the Product(s) to the service location. VTech will return repaired or replaced Product under this limited warranty. Transportation, delivery or handling charges are prepaid. VTech assumes no risk for damage or loss of the Product in transit. If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will request that you authorize the cost of repair prior to any fur ther repair activity. You must pay for the cost of repair and return shipping costs for the repair of Products that are not covered by this limited warranty.

What must you return with the Product to get warranty service?

Return the entire original package and contents including the Product to the VTech service

location along with a description of the malfunction or difculty; and

Include a “valid proof of purchase” (sales receipt) identif ying the Product purchased (Product

2. model) and the date of purchase or receipt; and

Provide your name, complete and correct mailing address, and telephone number.

Other limitations

This warranty is the complete and exclusive agreement between you and VTech. It supersedes all other written or oral communications related to this Product. VTech provides no other warranties for this Product. The warranty exclusively describes all of VTech’s responsibilities regarding the

Product. There are no other express warranties. No one is authorized to make modications to this limited warranty and you should not rely on any such modication.

State/Provincial Law Rights: This warranty gives you specic legal rights, and you may also have

other rights, which vary from state to state or province to province.

Limitations: Implied warranties, including those of tness for a particular purpose and merchantability (an unwritten warranty that the Product is t for ordinary use) are limited to one

year from the date of purchase. Some states/provinces do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. In no event shall V Tech be liable for any indirect, special, incidental, consequential, or similar damages (including, but not

limited to lost prots or revenue, inability to use the Product or other associated equipment, the

cost of substitute equipment, and claims by third parties) resulting from the use of this Product. Some states/provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

Please retain your original sales receipt as proof of purchase.

Appendix

FCC, ACTA and IC regulations

FCC Part 15

This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

• connec ted.

Consult the dealer or an experienced radio/TV technician for help.

•

Changes or modications to this equipment not expressly approved by the par ty responsible for

compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including inter ference that may cause undesired operation. Privacy of communications may not be ensured when using this telephone.

To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset may be safely held against the ear of the user. The telephone base shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 20 cm (8 inches) or more.

This Class B digital apparatus complies with Canadian ICES-003.

FCC Part 68 and ACTA

This equipment complies with Par t 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal At tachments (ACTA). The label on the back or

bottom of this equipment contains, among other things, a product identier in the format US: AAAEQ##TXXXX. This identier must be provided to your local telephone company upon request.

The plug and jack used to connect this equipment to premises wiring and the telephone network must comply with applicable Par t 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connec ted to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See Installation Instructions in the user’s manual.

The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to your telephone line and still have them ring when you are called. The REN for this product is

encoded as the 6th and 7th characters following the US: in the product identier (e.g., if ## is 03, the REN is 0.3). In most, but not all areas, the sum of all RENs should be ve (5.0) or less. For

more information, please contact your local telephone company.

This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment,

consult your telephone company or a qualied installer.

Appendix

FCC, ACTA and IC regulations

If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents. For repair procedures, follow the instructions outlined under the Limited Warranty.

If this equipment is causing harm to the telephone network, the telephone company may temporarily discontinue your telephone ser vice. The telephone company is required to notif y

you before interrupting service. If advance notice is not practical, you will be notied as soon as

possible. You will be given the opportunity to correct the problem and the telephone company is

required to inform you of your right to le a complaint with the FCC. Your telephone company may

make changes in its facilities, equipment, operation, or procedures that could affect the proper functioning of this product. The telephone company is required to notify you if such changes are planned.

If this product is equipped with a corded or cordless handset, it is hearing aid compatible.

If this product has memory dialing locations, you may choose to store emergency telephone

numbers (e.g., police, re, medical) in these locations. If you do store or test emergency numbers,

please:

Remain on the line and briey explain the reason for the call before hanging up.

Perform such activities in off-peak hours, such as early morning or late evening.

Industry Canada

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation.

The term ‘’IC:‘’ before the certication/registration number only signies that the Industry Canada technical specications were met.

The Ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the

requirement that the sum of the RENs of all the devices does not exceed ve.

This product meets the applicable Industry Canada technical specications.

VTech LS6245 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
