Volvo Xc90 2016 Owner's Manual
WEB EDITION
OWNER'S MANUAL
VÄLKOMMEN!
We trust that you will enjoy many years of safe driving in your Volvo, an
automobile designed with your safety and comfort in mind. We encourage you to familiarize yourself with the equipment descriptions and operating instructions in this manual.
We also urge you and your passengers to wear seat belts at all times in
this (or any other) vehicle. And, of course, please do not operate a vehi-
cle if you may be affected by alcohol, medication or any impairment that
could hinder your ability to drive.
Your Volvo is designed to meet all applicable federal safety and emission standards. If you have any questions regarding your vehicle, please
contact your Volvo retailer or see the article "Contacting Volvo" for information on getting in touch with Volvo in the United States and Canada.
2
CONTENTS
INTRODUCTION
Contacting Volvo
12
Volvo On Call Roadside Assistance
12
Additional information about your vehicle
12
General information about the XC90
T8 Twin Engine Plug-in Hybrid
14
Volvo and the environment
18
Owner's manual and the environment
19
IntelliSafe—driver support
19
Sensus
20
Owner's manual in mobile devices
23
Options, accessories and the Onboard Diagnostic (OBDII) socket
24
Owner's information
25
Driver distraction
26
Volvo Structural Parts Statement
27
Crash event data
28
Volvo ID
29
Center display overview
30
Changing center display settings
32
Using the center display keyboard
33
Function view buttons
38
Navigating in the center display's views
40
Symbols in the center display status bar
45
Changing settings in different types
of apps
46
Using the center display
47
Using the owner's manual
51
On-board digital owner's manual
53
Navigating in the digital owner's manual
54
Glass
55
Technician certification
55
SAFETY
General safety information
58
Occupant safety
58
Reporting safety defects
59
Recall information
60
Safety during pregnancy
60
Whiplash protection system
61
Seat belts
62
Seat belt pretensioners
63
Buckling and unbuckling seat belts
63
Door and seat belt reminders
65
Child safety
66
Child restraints
68
Infant seats
70
Convertible seats
72
Booster cushions
75
ISOFIX/LATCH lower anchors
76
Lower child seat attachment points
77
Top tether anchors
78
Integrated booster cushion*
79
Raising the integrated booster cushion*
80
Stowing the integrated booster cushion*
81
Occupant weight sensor
82
Safety mode
85
3
Starting or moving a vehicle in safety
mode
86
Airbag system
87
Driver/passenger side airbags
87
Inflatable curtains
90
Side impact airbags
91
INSTRUMENTS AND CONTROLS
Trip computer
94
Displaying trip computer information
95
Displaying trip statistics
96
HomeLink® Wireless Control System*
97
Programming the HomeLink® Wireless Control System*
98
Instruments and controls
100
Adjusting the power door mirrors
102
Laminated panoramic roof*
103
Operating the laminated panoramic roof*
104
Power windows
106
Operating the power windows
106
Rearview mirror
107
Using sun shades
108
Settings view
108
Categories in Settings view
109
Changing system settings in Settings view
111
Changing settings in apps
112
Resetting the settings view
112
Resetting user data when the vehicle
changes owners
113
Ambient temperature sensor
113
Clock
114
Head-up display (HUD)*
114
Voice control
117
Using voice commands
118
Voice control for cell phones
118
Voice control for radio and media
119
Climate system voice commands
119
Navigation system voice commands
121
Voice control settings
122
Indicator symbols in the instrument panel
123
Instrument panel
125
Instrument panel App menu
126
Hybrid-related information in the
instrument panel
127
Instrument panel licenses
129
Warning symbols in the instrument panel
134
Compass
136
Calibrating the compass
136
Lighting panel and controls
137
Low beam headlights
139
Daytime Running Lights (DRL)
139
High and low beam headlights
140
Active Bending Lights*
142
Brake lights
143
Rear fog lights
143
Hazard warning flashers
144
Parking lights
144
4
Approach lighting
145
Home safe lighting
145
Passenger compartment lighting
145
Using turn signals
148
Messages in the instrument panel
and center display
148
Handling messages in the instrument panel and center display
150
Handling messages stored from the
instrument panel and center display
151
Using the instrument panel App menu
153
Using the windshield wipers
153
Activating/deactivating the rain sensor
154
Windshield and headlight washers
155
Tailgate window wiper and washer
156
Steering wheel
157
Adjusting the steering wheel
158
Seats
158
Manually operated front seats
159
Power front seats*
160
Adjusting power front seats*
160
Adjusting the passenger's seat from
the driver's seat*
161
Using the power seat memory function*
161
Multifunctional front seats*
162
Operating multifunctional front seats*
163
Adjusting function settings in the
multifunctional front seats*
164
Rear seats
166
Easy access to and from the driver seat
166
Adjusting the second row head restraints
167
Adjusting the second row backrest tilt
168
Folding the second row backrests
169
Moving the second row seats forward/rearward
171
Getting into and out of the third row
of seats
171
Folding the third row backrests
172
CLIMATE
Climate control system
174
Perceived temperature
174
Climate system sensors
175
Parking climate (preconditioning)
175
Activating/deactivating the parking
climate timer
177
Activating/deactivating the climate
comfort retaining function*
177
Preconditioning timer
178
Setting the parking climate (preconditioning) timer
178
Starting and stopping preconditioning
180
Preconditioning symbols and messages
181
Air quality
182
Clean Zone Interior Package (CZIP)*
182
Interior Air Quality System (IAQS)*
182
Passenger compartment air filter
183
Automatic climate control
183
Climate system controls
184
Climate system controls in the center
display
185
Rear climate system controls on the
tunnel console
186
Setting the blower speed
187
Setting the temperature
188
Turning recirculation on and off
190
5
Defrosting windows and mirrors
191
Turning steering wheel heating* on
and off
193
Air conditioning
194
Turning seat heating* on and off
195
Turning front seat ventilation* on and off
196
Air distribution
197
Opening/closing/directing air vents
198
Adjusting air distribution
198
Air distribution table
200
LOADING AND STORAGE
Cargo space
204
Passenger compartment storage spaces
204
Using the glove compartment
205
Tunnel console
206
Sun visors
207
Electrical sockets
208
Loading
211
Grocery bag holder
213
Cargo net
213
Steel cargo grid*
215
Load anchoring eyelets
216
Cargo compartment cover*
217
LOCKS AND ALARM
Locks and remote keys
220
Alarm
220
Automatically arming/disarming the
alarm
222
Deactivating the alarm without a
functioning remote key
222
Child safety locks
222
Antenna locations for the start and
lock system
224
Start and lock system type designations
224
Immobilizer
225
Changing the remote key's battery
226
Remote key's range
229
Remote key
229
Restricted key*
231
Detachable key blade
232
Foot movement tailgate operation*
233
Locking and unlocking confirmation
234
Locking/unlocking from inside the
vehicle
236
Locking/unlocking from outside the
vehicle
237
Locking/unlocking the tailgate
238
Power tailgate*
240
Locking/unlocking with the detachable key blade
242
6
DRIVER SUPPORT
Driver support systems
246
Driver support system camera
246
Camera limitations
247
Driver support system radar unit
250
Radar sensor limitations
251
Cruise Control (CC)
254
Starting and activating Cruise Control
254
Changing Cruise Control speed
255
Deactivating/resuming Cruise
Control (CC)
256
Turning Cruise Control off
257
Adaptive Cruise Control (ACC)*
258
Starting and activating Adaptive
Cruise Control (ACC)
260
Deactivating/resuming Adaptive
Cruise Control (ACC)
261
Changing Adaptive Cruise Control
(ACC) speed
263
Setting an Adaptive Cruise Control
time interval
264
Pilot Assist*
265
Starting and activating Pilot Assist
268
Deactivating/resuming Pilot Assist
269
Setting a Pilot Assist time interval
271
Pilot Assist auto-hold brake function
272
Pilot Assist limitations
272
Other Adaptive Cruise Control (ACC)
functions
274
Radar sensor
275
Radar sensor - type approval
276
Adaptive cruise control passing
assistance
276
Adaptive Cruise Control (ACC) - fault
tracing
277
Adaptive Cruise Control (ACC) symbols and messages
278
City Safety™
279
City Safety warning level settings
281
Detecting cyclists and pedestrians
with City Safety
282
City Safety in crossing traffic
283
Rear Collision Warning (RCW)
284
City Safety limitations
285
City Safety™ troubleshooting
287
City Safety symbols and messages
289
Speed limiter (SL)*
290
Starting and activating the Speed
Limiter (SL)*
291
Changing a Speed Limiter (SL)*
maximum speed
291
Automatic Speed Limiter (ASL)*
292
Activating/deactivating the
Automatic Speed Limiter (ASL)*
293
Changing tolerance for the
Automatic Speed Limiter
294
Deactivating/reactivating the Speed
Limiter*
295
Turning the Speed Limiter* off
296
Road Sign Information (RSI)*
297
Road Sign Assistance (RSI)* operation
298
Road Sign Assistance (RSI)* limitations
299
Park Assist*
299
Activating/deactivating Park Assist
301
Park Assist limitations
301
Park assist symbols and messages
303
Park Assist Camera (PAC)*
304
Park Assist Camera (PAC)* trajectory
lines and fields
306
Starting the Park Assist Camera (PAC)*
308
Park Assist Camera (PAC)* limitations
308
Park Assist Pilot (PAP)*
309
Using Park Assist Pilot (PAP)*
310
Park Assist Pilot (PAP)* limitations
313
Park Assist Pilot (PAP)* symbols and
messages
315
Adjustable steering force*
316
Electronic Stability Control (ESC)
316
Electronic Stability Control (ESC)
sport mode
317
7
Electronic Stability Control (ESC)
symbols and messages
318
Roll stability control (RSC)
320
Driver Alert Control (DAC)
320
Driver Alert Control limitations
321
Using Driver Alert Control (DAC)
321
Distance Alert*
322
Using Distance Alert*
323
Distance Alert* limitations
323
Blind Spot Information (BLIS)*
324
Blind Spot Information (BLIS)* On/Off
325
Blind Spot Information (BLIS)* limitations
326
Cross Traffic Alert (CTA)*
326
Activating/deactivating Cross Traffic
Alert (CTA)*
327
Cross Traffic Alert (CTA)* limitations
328
Blind Spot Information (BLIS)* with
Cross Traffic Alert (CTA)* symbols
and messages
330
Driving lane assistance
331
Activating/deactivating Lane
Departure Warning (LDW)
333
Activating/deactivating Lane
Keeping Aid (LKA)*
333
Driving lane assistance symbols and
messages
335
STARTING AND DRIVING
Starting and driving
338
Brakes
338
Brake functions
340
Auto-hold brake function
341
Brake assist system
341
Braking effect after a collision
342
Emergency brake lights
342
Hill Descent Control (HDC)
342
Hill Start Assist
343
Parking brake
344
Using the parking brake
344
Parking brake malfunctions
346
Before a long distance trip
347
Driving economically
347
Driving through standing water
349
Overheating the engine and transmission
349
Winter driving
350
Towing eyelet
351
Towing recommendations
352
Fuel
353
Octane rating
354
Opening/closing the fuel filler door
355
Emission controls
356
Jump starting
357
Driving with a trailer
359
Detachable trailer hitch
360
Trailer Stability Assist (TSA)
361
Ignition modes
362
Battery drain
364
Starting the engine
364
Turning the engine off
366
Driving systems
366
Hybrid battery charging cable
367
Hybrid charging cable circuit breaker
369
Hybrid-related symbols and messages
370
Preparations for charging the hybrid
battery
372
Stopping hybrid battery charging
373
Initiating hybrid battery charging
374
Charging the hybrid battery
375
Hybrid battery charge status
377
Charger status indicators
379
Hybrid battery charging current
379
Long-term storage of a vehicle with
a hybrid battery
380
Using the electric motor in city driving
381
Drive modes
382
ECO drive mode
386
Automatic transmission
387
8
Gear selector positions
387
Shiftlock
389
Gear shift indicator
390
Steering wheel paddles*
390
Low Speed Control (LSC)
391
All Wheel Drive (AWD)
392
Suspension and leveling control*
392
INFOTAINMENT
The infotainment system
396
Sound settings
396
Radio
397
Radio settings
397
RBDS radio
398
Changing and searching for radio
stations
398
HD Radio™reception
399
Switching HD Radio on and off
401
HD Radio sub-channels
401
HD Radio limitations
402
SiriusXM® Satellite radio*
403
Using SiriusXM® Satellite radio radio*
404
SiriusXM® Satellite radio* settings
405
Phone
406
Pairing a cell phone
407
Connecting/disconnecting a cell phone
408
Handling phone calls
409
Handling text messages
410
Phone settings
411
Text message settings
412
Connecting a Bluetooth® device
412
Connecting a device via the
AUX/USB socket
412
Media player
413
CD (media) player*
414
Playing media
414
Media searches
416
Playing media through the
AUX/USB sockets
417
Streaming media through a Bluetooth connection
417
Media sound settings
417
Gracenote
418
Video
419
Media player technical data
419
Internet connected vehicle
420
Connecting to the Internet
421
Apps (applications)
422
Bluetooth settings
423
Downloading, updating and uninstalling apps
424
Internet connection troubleshooting
425
Tethering (Wi-Fi sharing)
425
Deleting Wi-Fi networks
426
Wi-Fi technology and security
426
Vehicle modem settings
426
Infotainment system license information
427
Terms, conditions and confidentiality
431
9
WHEELS AND TIRES
Tires
434
Tire sidewall designations
435
Wheel (rim) designations
437
Tire terminology
437
Tire direction of rotation
438
Tread wear indicator
439
Loading specifications
439
Uniform Tire Quality Grading
440
Snow tires and chains
441
Checking tire inflation pressure
441
Changing tires
443
Tools in the cargo compartment
443
Jack
443
Wheel bolts
444
Removing a wheel
444
Installing a wheel
446
Tire Pressure Monitoring System (TPMS)
447
Checking inflation pressure
448
Reinflating tires equipped with the
Tire Pressure Monitoring System (TPMS)
449
Calibrating the Tire Pressure
Monitoring System (TPMS)
450
Tire Pressure Monitoring System
type approval
451
Tire sealing system
451
Using the tire sealing system
453
Inflating a tire with the tire sealing
system compressor
457
Refilling coolant
458
MAINTENANCE AND SERVICING
Volvo's service program
462
System updates
464
Remote updates
465
Vehicle status
465
Booking service and repairs
465
Wi-Fi connection to a workshop
468
Climate system service
469
Start battery
469
Hybrid battery
471
Battery symbols
472
Fuses
473
Replacing fuses
473
Fuses in the engine compartment
474
Fuses in the passenger compartment
478
Fuses in the cargo compartment
481
Replacing bulbs
483
Removing the rectangular headlight
cover
485
Replacing low beam headlight bulbs
485
Replacing High Beam headlight bulbs
486
Replacing parking light bulbs
487
Replacing front turn signal bulbs
487
Bulb specifications
488
Hoisting the vehicle
489
Opening and closing the hood
491
10
Engine compartment overview
492
Engine oil
493
Checking and refilling engine oil
494
Windshield wipers in the service position
495
Replacing wiper blades
496
Refilling the windshield washer fluid
reservoir
498
Cleaning the exterior
498
Cleaning the interior
500
Cleaning the center display
502
Corrosion protection
503
Paint damage
503
Touching up paint damage
504
Polishing and waxing
505
SPECIFICATIONS
Label information
508
Dimensions
511
Weights
513
Air conditioning refrigerant
515
Hybrid battery specifications
515
Brake fluid specification and volume
516
Coolant specifications and volumes
516
Engine specifications
517
Engine oil specifications and volume
518
Fuel tank volume
518
Tire inflation pressure table
519
Transmission fluid specification and
volume
520
INDEX
Index 521
INTRODUCTION
INTRODUCTION
12
Contacting Volvo
Use the following contact information if you
would like to get in touch with Volvo in the United States or Canada.
In the USA:
Volvo Cars of North America, LLC
Customer Care Center
1 Volvo Drive,
P.O. Box 914
Rockleigh, New Jersey 07647
1-800-458-1552
www.volvocars.com/us
In Canada:
Volvo Cars of Canada
National Customer Service
9130 Leslie Street, Suite 101
Richmond Hill, Ontario L4B 0B9
1-800-663-8255
www.volvocars.com/ca
Volvo On Call Roadside Assistance
Your new Volvo comes with a four year ON
CALL roadside assistance.
Additional information, features, and benefits of
this program are described in a separate information package in your glove compartment.
If you require assistance, dial:
In the U.S. 1-800-638-6586 (1-800-63-
VOLVO)
In Canada 1-800-263-0475
NOTE
Some vehicles may be equipped with
Volvo On Call with Sensus Connect, which
will allow access to the call center and additional features directly from the vehicle. This
is in addition to the Volvo On Call Roadside
Assistance program mentioned above.
Volvo On Call with Sensus Connect will be
a customer pay subscription offer after an initial complimentary trial period.
Additional information about your vehicle
Volvo Cars' website and support site provide
additional information about your vehicle.
Support on the Internet
Go to support.volvocars.com or use the QR code
below to visit the site, which is available in most
markets.
QR code to the support site
The information on the support site is searchable
and is grouped into different categories. It
includes support for e.g., Internet-based services
and functions, Volvo On Call (VOC), the navigation system and apps. Video and step-by-step
instructions explain various procedures such as
how to connect the vehicle to the Internet via a
cell phone.
Downloadable information
Maps
Sensus Navigation system maps can be downloaded from the support site.
INTRODUCTION
13
Mobile apps
For certain model year 2014 and 2015 Volvos,
the owner's manual is available in the form of an
app. The VOC app can also be found here.
Owner's manuals for earlier model Volvos
Owner's manuals for earlier model Volvos are
available in PDF format. Quick Guides and supplements can also be found on the support site.
Select a model and a model year and download
the desired information.
Contact
Contact information for customer support and the
nearest Volvo retailer are available on the site.
Related information
•
Using the owner's manual (p. 51)
•
On-board digital owner's manual (p. 53)
•
Volvo ID (p. 29)
INTRODUCTION
14
General information about the XC90 T8 Twin Engine Plug-in Hybrid
The XC90 T8 Twin Engine Plug-in Hybrid is
driven like any other vehicle but it has certain
functionality that differs from a vehicle powered
exclusively by a gasoline engine. The electric
motor powers the vehicle primarily at low
speeds; the gasoline engine is used at higher
speeds or during more active driving.
INTRODUCTION
}}
15
Overview
||
INTRODUCTION
16
Electrical current for charging the hybrid battery
Electric motor for powering the rear wheels
Hybrid battery
Drive modes (change in the center display or
by using the drive mode control in the tunnel
console)
Instrument panel showing unique hybrid-related information
WARNING
Please be aware that there is no sound from
the engine when the vehicle is being powered
by the electric motor and it may be difficult to
detect by children, pedestrians, cyclists and
animals. This is especially true at low speeds.
High-voltage electrical current
WARNING
A number of electrical components in the
XC90 T8 Twin Engine Plug-in Hybrid use
high-voltage current and can be extremely
dangerous if handled incorrectly. These components and any orange wiring in the vehicle
may only be handled by trained and qualified
Volvo service technicians.
Hybrid-unique functions
Drive modes
Different drive modes can be selected while driving, e.g., electric power only or a combination of
electric and gasoline power. The vehicle calculates the optimal combination of drivability, driving
experience, environmental impact and fuel economy for the selected drive mode. See also the
article "Drive modes" for additional information.
Instrument panel
In certain driving situations, hybrid-unique information may be displayed in the instrument panel,
such as: a hybrid battery gauge (current charge
level), the current drive mode, a symbol that illuminates when the gasoline engine is being used,
a Hybrid Guide and the level of energy regeneration.
Preconditioning
In order to function optimally, the hybrid battery
(and its related electrical systems) and the gasoline engine (and its drive systems) should be at
the correct operating temperature. The hybrid
battery's capacity is reduced considerably if it is
too cold or hot. Preconditioning prepares the
vehicle's drive systems and passenger compartment before the vehicle is driven to help reduce
wear and energy consumption.
Charging the hybrid battery
CAUTION
Never connect the charging cable if there is a
risk of thunderstorms/lightning.
The XC90 T8 Twin Engine Plug-in Hybrid uses a
lithium-ion battery that can be charged in several
ways:
•
A charging cable can be connected from the
vehicle to a 110-volt AC socket. Charging
time depends on the strength of the current.
•
When the brakes are applied lightly, the electric motor is used for engine braking, during
which the vehicle's kinetic energy is converted into electric current that is used to help
recharge the hybrid battery.
•
The hybrid battery is also recharged to a certain extent when the gasoline engine is in
operation.
Related information
•
Drive modes (p. 382)
•
Hybrid-related information in the instrument
panel (p. 127)
•
Charging the hybrid battery (p. 375)
INTRODUCTION
17
•
Preparations for charging the hybrid battery
(p. 372)
•
Starting the engine (p. 364)
INTRODUCTION
18
Volvo and the environment
Volvo is committed to the well-being of its customers. As a natural part of this commitment, we
care about the environment in which we all live.
Concern for the environment means an everyday
involvement in reducing our environmental
impact.
Volvo's environmental activities are based on a
holistic view, which means we consider the overall environmental impact of a product throughout
its complete life cycle. In this context, design, production, product use, and recycling are all important considerations. In production, Volvo has
partly or completely phased out several chemicals
including CFCs, lead chromates, asbestos, and
cadmium; and reduced the number of chemicals
used in our plants 50% since 1991.
Volvo was the first in the world to introduce into
production a three-way catalytic converter with a
Lambda sond, now called the heated oxygen sensor, in 1976. The current version of this highly
efficient system reduces emissions of harmful
substances (CO, HC, NOx) from the exhaust pipe
by approximately 95 – 99% and the search to
eliminate the remaining emissions continues.
Volvo is the only automobile manufacturer to
offer CFC-free retrofit kits for the air conditioning
system of all models as far back as the 1975
model 240. Advanced electronic engine controls
and cleaner fuels are bringing us closer to our
goal. In addition to continuous environmental
refinement of conventional gasoline-powered
internal combustion engines, Volvo is actively
looking at advanced technology alternative-fuel
vehicles.
When you drive a Volvo, you become our partner
in the work to lessen the car's impact on the
environment. To reduce your vehicle's environmental impact, you can:
•
Maintain proper air pressure in your tires.
Tests have shown decreased fuel economy
with improperly inflated tires.
•
Follow the recommended maintenance
schedule in your Warranty and Service
Records Information booklet.
•
Drive at a constant speed whenever possible.
•
See a trained and qualified Volvo service
technician as soon as possible for inspection
if the check engine (malfunction indicator)
light illuminates, or stays on after the vehicle
has started.
•
Properly dispose of any vehicle-related waste
such as used motor oil, used batteries, brake
pads, etc.
•
When cleaning your vehicle, please use genuine Volvo car care products. All Volvo car
care products are formulated to be environmentally friendly.
Volvo XC90 T8 Twin Engine Plug-in Hybrid
•
If possible, precondition the vehicle with the
charging cable before driving.
•
If preconditioning is not possible in cold
weather, use the seat and steering wheel
heating primarily. Avoid heating the entire
passenger compartment, which reduces the
hybrid battery's charge level.
•
Choose the
Pure drive mode to help mini-
mize electric power consumption.
•
In hilly terrain, put the gear selector in mode
B to utilize the electric motor's braking function when the accelerator pedal is released.
This helps charge the hybrid battery.
•
Select the
Save drive mode for higher
speeds when driving farther than is possible
using the electric motor only.
Related information
•
Driving economically (p. 347)
INTRODUCTION
* Option/accessory, for more information, see Introduction.
19
Owner's manual and the environment
The wood pulp in Volvo's printed owner's information comes from FSC® (Forest Stewardship
Council®) certified forests and other responsible
sources.
FSC
®
The symbol above indicates that the wood pulp is
FSC® certified.
Related information
•
Volvo and the environment (p. 18)
IntelliSafe—driver support
IntelliSafe is Volvo's philosophy regarding vehicle safety. It encompasses a number of systems,
both standard and optional, that are designed to
help make driving and traveling in a Volvo safer.
Support
Systems that help make driving safer are an integral part of IntelliSafe. These include optional
features such as Adaptive Cruise Control* that
helps maintain a set distance to a vehicle ahead,
Park Assist Pilot*, which assists in parking the
vehicle, Cross Traffic Alert*, Blind Spot
Information*, etc.
Accident prevention
Systems such as City Safety are designed to
automatically apply the brakes in situations in
which the driver does not have time to react.
Lane Keeping Aid* alerts the drive if the vehicle
inadvertently crosses a lane's/road's side marker
line.
Protection
The vehicle is equipped with e.g., seat belt pretensioners that pull the seat belts taut in critical
situations when there is a collision risk and
numerous airbags designed to help provide cushioning if certain types of collisions should occur.
Related information
•
Adaptive Cruise Control (ACC)* (p. 258)
•
Park Assist Pilot (PAP)* (p. 309)
•
High and low beam headlights (p. 140)
•
Cross Traffic Alert (CTA)* (p. 326)
•
Blind Spot Information (BLIS)* (p. 324)
•
City Safety™ (p. 279)
•
Driving lane assistance (p. 331)
•
Airbag system (p. 87)
•
Roll stability control (RSC) (p. 320)
•
Seat belts (p. 62)
•
General safety information (p. 58)
INTRODUCTION
20
Sensus
Sensus is the core of your personal Volvo experience and provides information, entertainment
and features that make owning your vehicle easier.
This is Sensus
Sensus provides an intelligent interface and
Internet-connected service with an intuitive navigation structure that offers access to relevant
information when it is needed, with minimal distractions.
Sensus also includes all of your vehicle's solutions relating to entertainment, connecting to the
Internet, navigation and the user interface
between the driver and the vehicle. Sensus
makes communication between you, the vehicle
and the digital world around you possible.
INTRODUCTION
}}
* Option/accessory, for more information, see Introduction.
21
Information when it's needed, where it's needed
Information is presented in different displays depending on how it should be prioritized (generic illustration)
Head-up-display*
The head up-display presents types of information that the driver should be aware of immedi-
ately, such as traffic warnings, speed information
and navigation. Road sign information and incoming phone calls are also displayed here. The
head-up display is controlled from the right-side
steering wheel keypad and the center display.
Instrument panel
The instrument panel displays information such
as speed, an incoming phone call or the track
||
INTRODUCTION
* Option/accessory, for more information, see Introduction.
22
that is currently playing. It is controlled using both
steering wheel keypads.
Center display
Many of the vehicle's main functions are controlled from the center display, a touchscreen that
reacts to taps or other gestures. The number of
physical buttons is thereby minimized. The screen
can be operated with or without gloves.
The center display is used to control e.g., the climate and infotainment systems and to adjust the
power seats*. The information shown here can be
dealt with by the driver or the front seat passenger.
Voice control system
The voice control system enables the driver to operate certain vehicle functions without
removing his/her hands from
the steering wheel and it
understands natural speech.
Use voice commands to e.g.,
play a track on the infotainment system, make a
phone call, raise the passenger compartment
temperature or to read a text message.
For additional information about all of the functions/system, see the respective articles in the
on-board owner's manual or the printed supplement.
Related information
•
Using the center display (p. 47)
•
Center display overview (p. 30)
•
Navigating in the center display's views
(p. 40)
•
Head-up display (HUD)* (p. 114)
•
Instrument panel (p. 125)
•
Voice control (p. 117)
INTRODUCTION
23
Owner's manual in mobile devices
Owner's information mobile app1 can be downloaded from the App Store and Google Play and
is adapted for both cell phones and tablets.
These apps also contain videos and interior/
exterior hotspot views of the vehicle that you can
click on for additional information.
This QR code will take you
directly to the app or you can
search for "Volvo manual" in
the App Store or Google Play.
The app contains videos and exterior/interior
views of the vehicle with certain components/
functions highlighted in hotspots, which lead
directly to related information. It is easy to navigate between the various categories and articles
and the contents are searchable.
The mobile app is available at the App Store and Google
Play
Related information
•
Using the owner's manual (p. 51)
•
Additional information about your vehicle
(p. 12)
1
Certain models and mobile devices
INTRODUCTION
24
Options, accessories and the Onboard Diagnostic (OBDII) socket
We strongly recommend that Volvo owners
install only genuine, Volvo-approved accessories, and that accessory installations be performed only by a trained and qualified Volvo
service technician.
Optional or accessory equipment described in
this manual is indicated by an asterisk.
Optional or accessory equipment may not be
available in all countries or markets. Please note
that some vehicles may be equipped differently,
depending on special legal requirements.
Contact your Volvo retailer for additional information.
NOTE
•
Do not export your Volvo to another
country before investigating that country's applicable safety and exhaust emission requirements. In some cases it may
be difficult or impossible to comply with
these requirements. Modifications to the
emission control system(s) may render
your Volvo not certifiable for legal operation in the U.S., Canada and other countries.
•
All information, illustrations and specifications contained in this manual are based
on the latest product information available at the time of publication. Please note
that some vehicles may be equipped differently, depending on special legal
requirements. Optional equipment described in this manual may not be available in
all markets.
•
Some of the illustrations shown are
generic and may not depict the exact
model for which this manual is intended.
•
Volvo reserves the right to make model
changes at any time, or to change specifications or design without notice and
without incurring obligation.
WARNING
If your vehicle is involved in an accident,
unseen damage may affect its drivability and
safety.
WARNING
CALIFORNIA proposition 65
Engine exhaust, some of its constituents, and
certain vehicle components contain or emit
chemicals known to the state of California to
cause cancer, and birth defects or other
reproductive harm. In addition, certain fluids
contained in vehicles and certain products of
component wear contain or emit chemicals
known to the State of California to cause cancer, and birth defects or other reproductive
harm.
WARNING
Certain components of this vehicle such as air
bag modules, seat belt pretensioners, adaptive steering columns, and button cell batteries may contain Perchlorate material. Special
handling may apply for service or vehicle end
of life disposal.
See www.dtsc.ca.gov/hazardouswaste/
perchlorate.
•
Genuine Volvo accessories are tested to
ensure compatibility with the performance,
safety, and emission systems in your vehicle.
Additionally, a trained and qualified Volvo
INTRODUCTION
}}
25
service technician knows where accessories
may and may not be safely installed in your
Volvo. In all cases, please consult a trained
and qualified Volvo service technician before
installing any accessory in or on your vehicle.
•
Accessories that have not been approved by
Volvo may or may not be specifically tested
for compatibility with your vehicle. Additionally, an inexperienced installer may not be
familiar with some of your car's systems.
•
Any of your car's performance and safety
systems could be adversely affected if you
install accessories that Volvo has not tested,
or if you allow accessories to be installed by
someone unfamiliar with your vehicle.
•
Damage caused by unapproved or improperly
installed accessories may not be covered by
your new vehicle warranty. See your Warranty
and Service Records Information booklet for
more warranty information. Volvo assumes no
responsibility for death, injury, or expenses
that may result from the installation of nongenuine accessories.
Connecting equipment to the On-board Diagnostic (OBDII) socket
WARNING
Volvo Cars takes no responsibility for the consequences of connecting non-authorized
equipment to the On-board Diagnostic
(OBDII) socket. This socket should only be
used by a trained and qualified Volvo service
technician.
The diagnostic socket OBDII under the dashboard on
the driver's side
Owner's information
Complete on-board digital owner's information is
available on the center display, as a mobile app
and on Volvo's support website.
The printed owner's manual in the glove compartment is an excerpt from the digital information
and contains important texts, the latest updates
and instructions that can be useful in situations
where it is not practical to read the information
on the screen.
Changing the language used for the on-board
information could mean that some of the information displayed may not comply with national or
local statutes and regulations.
If the content of the on-board digital information and the printed manual differ, the printed
information always has precedence.
WARNING
The driver is always responsible for operating
the vehicle in a safe manner and adhering to
current laws and traffic regulations.
It is also important that the vehicle be operated, maintained and serviced according to
Volvo's recommendations/instructions in the
owner's manual.
||
INTRODUCTION
26
Related information
•
Owner's manual in mobile devices (p. 23)
•
Navigating in the digital owner's manual
(p. 54)
•
On-board digital owner's manual (p. 53)
Driver distraction
Please keep the following warnings in mind
when operating/servicing your vehicle.
A driver has a responsibility to do everything possible to ensure his or her own safety and the
safety of passengers in the vehicle and others
sharing the roadway. Avoiding distractions is part
of that responsibility.
Driver distraction results from driver activities that
are not directly related to controlling the vehicle
in the driving environment. Your new Volvo is, or
can be, equipped with many feature-rich entertainment and communication systems. These
include hands-free cellular telephones, navigation
systems, and multipurpose audio systems. You
may also own other portable electronic devices
for your own convenience. When used properly
and safely, they enrich the driving experience.
Improperly used, any of these could cause a distraction.
For all of these systems, we want to provide the
following warning that reflects the strong Volvo
concern for your safety. Never use these devices
or any feature of your vehicle in a way that distracts you from the task of driving safely. Distraction can lead to a serious accident. In addition to
this general warning, we offer the following guidance regarding specific newer features that may
be found in your vehicle:
WARNING
•
Never use a hand-held cellular telephone
while driving. Some jurisdictions prohibit
cellular telephone use by a driver while
the vehicle is moving.
•
If your vehicle is equipped with a navigation system, set and make changes to
your travel itinerary only with the vehicle
parked.
•
Never program your audio system while
the vehicle is moving. Program radio presets with the vehicle parked, and use your
programmed presets to make radio use
quicker and simpler.
•
Never use portable computers or personal digital assistants while the vehicle
is moving.
Accessory installation
•
We strongly recommend that Volvo owners
install only genuine, Volvo-approved accessories, and that accessory installations be
performed only by a trained and qualified
Volvo service technician.
•
Genuine Volvo accessories are tested to
ensure compatibility with the performance,
safety, and emission systems in your vehicle.
Additionally, a trained and qualified Volvo
service technician knows where accessories
may and may not be safely installed in your
Volvo. In all cases, please consult a trained
INTRODUCTION
}}
27
and qualified Volvo service technician before
installing any accessory in or on your vehicle.
•
Accessories that have not been approved by
Volvo may or may not be specifically tested
for compatibility with your vehicle. Additionally, an inexperienced installer may not be
familiar with some of your car's systems.
•
Any of your car's performance and safety
systems could be adversely affected if you
install accessories that Volvo has not tested,
or if you allow accessories to be installed by
someone unfamiliar with your vehicle.
•
Damage caused by unapproved or improperly
installed accessories may not be covered by
your new vehicle warranty. See your Warranty
and Service Records Information booklet for
more warranty information. Volvo assumes no
responsibility for death, injury, or expenses
that may result from the installation of nongenuine accessories.
WARNING
The driver is always responsible for operating
the vehicle in a safe manner and for complying with current statutes and regulations.
It is also essential to maintain and service the
vehicle according to Volvo's recommendations
as stated in the owner's information and the
service and warranty booklet.
If the on-board information differs from the
printed owner's manual, the printed information always takes precedence.
Related information
•
Volvo Structural Parts Statement (p. 27)
Volvo Structural Parts Statement
Volvo has always been and continues to be a
leader in automotive safety.
Volvo engineers and manufactures vehicles
designed to help protect vehicle occupants in the
event of a collision.
Volvos are designed to absorb the impact of a
collision. This energy absorption system including,
but not limited to, structural components such as
bumper reinforcement bars, bumper energy
absorbers, frames, rails, fender aprons, A-pillars,
B-pillars and body panels must work together to
maintain cabin integrity and protect the vehicle
occupants.
The supplemental restraint system including but
not limited to air bags, side curtain air bags, and
deployment sensors work together with the
above components to provide proper timing for
air bag deployment.
Due to the above, Volvo Cars of North America
does not support the use of aftermarket, alternative or anything other than original Volvo parts for
collision repair.
In addition Volvo does not support the use or reuse of structural components from an existing
vehicle that has been previously damaged.
Although these parts may appear equivalent, it is
difficult to tell if the parts have been previously
replaced with non-OE parts or if the part has
been damaged as a result of a prior collision. The
||
INTRODUCTION
28
quality of these used parts may also have been
affected due to environmental exposure.
Related information
•
Crash event data (p. 28)
•
Contacting Volvo (p. 12)
Crash event data
This vehicle is equipped with an event data
recorder (EDR). The main purpose of an EDR is
to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting
a road obstacle, data that will assist in understanding how a vehicle's systems performed.
The EDR is designed to record data related to
vehicle dynamics and safety systems for a short
period of time, typically 30 seconds or less. The
EDR in this vehicle is designed to record such
data as:
How various systems in your vehicle were operating; • Whether or not the driver and passenger
safety belts were buckled/fastened; • How far (if
at all) the driver was depressing the accelerator
and/or brake pedal; and, • How fast the vehicle
was traveling.
•
How various systems in your vehicle were
operating;
•
Whether or not the driver and passenger
safety belts were buckled/fastened;
•
How far (if at all) the driver was depressing
the accelerator and/or brake pedal; and,
•
How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances in which crashes and
injuries occur.
EDR data are recorded by your vehicle only if a
non-trivial crash situation occurs; no data are
recorded by the EDR under normal driving conditions and the EDR never registers who is driving
the vehicle or the location of a crash or a near
crash-like situation. However, other parties, such
as law enforcement, could combine the EDR data
with the type of personally identifying data routinely acquired during a crash investigation. To
read data recorded by an EDR, special equipment
is required, and access to the vehicle or the EDR
is needed.
Furthermore, your vehicle is equipped with a
number of computers whose task is to continuously control and monitor the vehicle’s operation.
They can also register some of this information
during normal driving conditions, most importantly
if they detect a fault relating to the vehicle’s operation and functionality or upon activation of the
vehicle’s active safety systems (e.g. City Safety
and the auto-brake function). Some of the registered information is required by technicians when
carrying out service and maintenance to enable
them to diagnose and rectify any faults that have
occurred in the vehicle and to enable Volvo to fulfill legal and other regulatory requirements. Information thus registered in the vehicle is registered
in the vehicle’s computers until the vehicle is
serviced or repaired. In addition to the above, the
registered information may – on an aggregated
basis – be used for research and product development purposes in order to continuously
improve the safety and quality of Volvo vehicles.
For additional information, contact:
Loading...
